Site Controller II
CPU/Memory Board/Program
Upgrade Instructions
MDE-4504
(formerly C35837)
Computer Programs and Documentation
Federal Communications Commission (FCC) Warning
All Gasboy computer programs (including software on diskettes and within memory chips) and documentation are copyrighted by, and shall remain the property of, Gasboy. Such
computer programs and documents may also contain trade secret information. The duplication, disclosure, modification, or unauthorized use of computer programs or
documentation is strictly prohibited, unless otherwise licensed by Gasboy.
This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Changes or modifications not expressly
approved by the manufacturer could void the user’s authority to operate this equipment.
Approvals
Gasboy, Greensboro, is an ISO 9001:2000 registered facility.
Underwriters Laboratories (UL):
UL File# Products listed with UL
MH4314
MH6418
MH7404
MH10581 Key control unit, Model GKE-B Series
All dispensers and self-contained pumping
units
Power operated Transfer Pump Models 25,
25C, 26, 27, 28, 72, 72S, 72SP, 72X, 73 and
1820
Hand operated Transfer Pump Models 1230
Series, 1243 Series, 1520 and 1720 Series
Card reader terminals, Models 1000, 1000P
Site controller, Model 2000S CFN Series
Data entry terminals, Model TPK-900 Series
Fuel Point Reader System
New York City Fire Department (NYFD):
NYFD C of A # Product
4823 9100A, 9140A, 9152A, 9153A,
4997 9822A, 9823A
5046 9100Q, 9140Q, 9152Q, 9153Q,
9800A, 9840A, 9850A, 9852A,
9853A, 9140
9800Q, 9840Q, 9852Q, 9853Q
National Conference of Weights and Measures (NCWM) - Certificate of Compliance (CoC):
Gasboy pumps and dispensers are evaluated by NCWM under the National Type Evaluation Program (NTEP). NCWM has issued the following CoC:
CoC# Product Model # CoC# Product Model # CoC# Product Model #
95-179A2 Dispenser
95-136A5 Dispenser 9800 Series 91-057A3 Controller
9100 Retail Series, 8700
Series, 9700 Series
91-019A2 Dispenser
9100 Commercial
Series
1000 Series FMS,
2000S-CFN Series
California Air Resources Board (CARB):
Executive Order # Product
G-70-52-AM Balance Vapor Recovery
G-70-150-AE VaporVac
Patents
Gasboy products are manufactured or sold under one or more of the following US patents:
Dispensers
5,257,720
Point of Sale/Back Office Equipment
D335,673
Trademarks
Non-registered trademarks
Atlas™
Consola™
Infinity™
Registered trademarks
ASTRA
Fuel Point
Gasboy
Keytrol
Slimline
Additional US and foreign patents pending.
®
®
®
®
®
Additional US and foreign trademarks pending.
Other brand or product names shown may be
trademarks or registered trademarks of their
respective holders.
This document is subject to change without notice. · For information regarding Gasboy Literature, call (336) 547-5661
E-mail: literature@gasboy.com · Internet: http://www.gasboy.com
© 2005 GASBOY · All Rights Reserved
Table of Contents
Table of Contents
1 – Introduction 1-1
Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Intended Users. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Related Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Abbreviations and Acronyms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
2 – Preparing to Upgrade 2-3
Cleaning Disk Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Taking Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Systems with Dual Floppy Disk Drives. . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
Systems with a Hard Drive and a Floppy Drive . . . . . . . . . . . . . . . . . . . . . .2-4
Updating Framos.Cfg. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
V1.0 to V2.0X or above on an SC II with a Hard Drive . . . . . . . . . . . . . . . .2-4
V1.0 to V2.0X or above on an SC II with Two Floppy Drives . . . . . . . . . . . .2-4
V2.0 to V2.0C or above . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
3 – Upgrading 3-7
Installing a New CPU Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
CPU PCB Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-9
Installing a New Memory Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Installing New Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Procedure A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13
Procedure B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-14
Procedure C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-15
POS Software Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Reports Package Upgrade. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
Index Index-1
MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005 Page i
Table of Contents
This page is intentionally left blank.
Page ii MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005
Purpose Introduction
1 – Introduction
Purpose
This manual provides instructions to upgrade a Site Controller (SC) II site to the latest version
of the Central Processing Unit (CPU) and the Memory Board. It also provides instructions to
update the software to the latest version. While performing these upgrades, the following
restrictions need to be considered:
• This upgrade will not work with sites that have 5-1/4" floppy drives.
• Sites with Gasboy Check Point consoles, which use Data Encryption Standard (DES)
encryption or odometer entry through their PIN Pad, have to upgrade their Check Point
firmware to V5.4 or higher (C08721KCON54).
• Upgrading an SC II from a spare parts kit (C04898/C04897) will require new SC II
software (C35570). Contact Gasboy Technical Service at 1-800-444-5529 to place an
order.
Parts List
The kit supplied along with this manual contains the following items:
Part # Qty. Description
C05852 1 SC II CPU board
C07041 1 Memory board
C35570 1 SC II 2.0 and above upgrade diskettes (latest
C08721KS240X 1 D-site chip (latest version)
C08919 1 Profit Point software (latest version)
C09622 1 F/F #8-32 standoff, 11/16" long (nylon)
C04126 1 M/F #8-32 standoff, 1/4" long
C35837 1 Instruction sheet
Intended Users
• Authorized Service Contractors (ASCs)
• Customer Specified Contractors (CSCs)
version)
MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005 Page 1
Introduction Related Reading
Related Reading
The following document contains related information and may be helpful when using this
manual:
Document Number Title GOLD® Library
PT-1941 CFN Series Replacement Parts Manual Gasboy Fuel Management Products
MDE-4356 Profit Point Reference Manual Gasboy Fuel Management Products
MDE-4311 CFN Series Site Controller II Manager’s Manual Gasboy Fuel Management Products
Abbreviations and Acronyms
The following table contains a list of acronyms used in this guide:
Acronym Definition
CARB California Air Resources Board
CoC Certificate of Compliance
CPU Central Processing Unit
DES Data Encryption Standard
FCC Federal Communications Commission
NCWM National Conference of Weights and Measures
NYFD New York City Fire Department
PC Personal Computer
PCB Printed Circuit Board
PIN Personal Identification Number
POS Point of Sale
SC Site Controller
UL Underwriters Laboratories
Page 2 MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005
Cleaning Disk Drives Preparing to Upgrade
2 – Preparing to Upgrade
This section provides information on:
• Cleaning disk drives
• Taking backup
• Updating Framos.cfg
Cleaning Disk Drives
If the Site Controller’s floppy disk drives have not been cleaned in the past one month, clean
the disk drives before upgrading. Refer to Section 21: “How to Clean the Diskette Drive” in
the Site Controller II Manager's Manual (MDE-4311).
Taking Backup
To take backups, proceed as follows:
1 Stop the site.
2 Use the SYSBACK command to back up system data.
3 Use the TRANBACK command to back up transactions.
4 Poll the site.
5 Do a P SIG and note the users and their permission levels.
6 Perform your end of day procedure (s).
7 Type P DA, press ENTER, and note the trans #.
8 If the site interfaces with a bank network, perform a settlement. If the bank router software has
a menu, choose the write to file option.
Systems with Dual Floppy Disk Drives
Make a spare copy of your current Release and Applications disks, then make a spare copy of
the new Release and Applications disks. Refer to Section 1: “Disk Commands”, in the Site
Controller II Manager's Manual (MDE-4311).
MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005 Page 3
Preparing to Upgrade Updating Framos.Cfg
Systems with a Hard Drive and a Floppy Drive
Back up the files on the hard drive by performing a HARDBACK. Refer to Section 13: “How
to Back Up and Restore Hard Disk Files”, in the Site Controller II Manager's Manual (MDE-
4311).
Updating Framos.Cfg
V1.0 to V2.0X or above on an SC II with a Hard Drive
1 Insert the new Release disk in the A: drive, type CP SYSBACK.DTA A: and press ENTER. If
there is not enough disk space remaining on the new Release disk, copy SYSBACK.DTA to
the Applications disk.
2 Insert the new Applications disk in the A: drive, type A:BIN/CONVERT2
C:FRAMOS.CFG A:FRAMOS.CFG, and press ENTER.
3 When prompted, Do you want to save this configuration (Y/N):, insert the new Release disk
in the A: drive, type Y and press ENTER.
V1.0 to V2.0X or above on an SC II with Two Floppy Drives
1 Insert the V1.0 Release disk in the A: drive, and the new Release disk in the B: drive.
2 Type CP SYSBACK.DTA B:, and press ENTER.
3 Insert the new Applications disk in the A: drive, and the V1.0 Release disk in the B: drive.
4 Type A:BIN/CONVERT2 B:FRAMOS.CFG A:FRAMOS.CFG, and press ENTER.
The prompt Insert SCII V1.0 Release disk with current configuration then RETURN:
appears.
5 Press ENTER. The prompt Do you want to save this configuration (Y/N): appears.
6 Insert the new Release disk in the A: drive, remove the disk from the B: drive, type Y, and
press ENTER.
V2.0 to V2.0C or above
Note: If the site has Profit Point(s), before you install the Site Controller upgrade, verify if the
Profit Point version is 2.0 or above. Profit Point versions prior to 2.0 are not supported
in Site Controller versions 2.0C and above. If you need to upgrade the existing Profit
Point(s), see
Page 4 MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005
“POS Software Upgrade” on page 16.
Updating Framos.Cfg Preparing to Upgrade
Note: If you are using the Standard Reports Package and are upgrading to 2.1x or above, you
must be running or upgrading to version 002 or above Standard Reports Package. See
“Reports Package Upgrade” on page 17.
For an SC II with two floppy disk drives
1 Move the old Release disk from the A: drive to the B: drive.
2 Install the new Release disk in the A: drive.
3 Type CP B:FRAMOS.CFG A:FRAMOS.CFG, and press ENTER.
4 Copy any user files from the old disk in the same manner.
5 Remove the old Release disk from the B: drive.
6 Place the new Applications disk in the B: drive.
For an SC II with a hard drive and a floppy disk drive
Note: The information given below is applicable only if you have been using the Reports
Package software.
1 Verify if a HARDBACK has been done as instructed in “Taking Backup” on page 3.
2 Insert the new Applications disk in the A: drive.
3 Type A:BIN/INSTALL, and press ENTER.
4 Type N if prompted to copy SYSBACK.DTA or OFFROAD.DTA.
5 At the prompt: Do you want to install from an additional floppy disk (Y/N):, insert the new
Release disk, type Y, and press ENTER.
6 If prompted, do not copy the new FRAMOS.CFG to the hard drive.
7 Use the CP command to copy user-created files and reports-related files from the C:/
PRESERVE directory to the proper directories on the hard drive and also to the new Release
disk in the A: drive.
8 Remove the disk from the A: drive.
MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005 Page 5
Preparing to Upgrade Updating Framos.Cfg
This page is intentionally left blank
Page 6 MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005
Installing a New CPU Board Upgrading
3 – Upgrading
This section provides information on:
• Installing a new CPU and memory board
• Installing new software
Installing a New CPU Board
To install a new CPU board, proceed as follows:
1 Turn off the power, and unplug the Site Controller.
2 Remove the four Phillips screws from the sides of the Site Controller, and remove the cover.
3 Disconnect all cables going to the CPU board (top board), and make a note of each cable and
its corresponding connector.
4 Remove the Phillips screws that secure the Site Controller CPU board, and carefully remove
the board.
5 Set the jumpers on the new CPU board to match the site's configuration. Refer to Figure 3-1, to
set up the CPU board.
MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005 Page 7
Upgrading Installing a New CPU Board
Figure 3-1 Site Controller II CPU PCB - C05852
K23-K37 CPU Board Jumpers
Page 8 MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005
Installing a New CPU Board Upgrading
Figure 3-2 K1 & K2, Port 1 & Port 3 Configuration Jumpers
CPU PCB Switches
DSW1 - Backup Sign-on, Hard Disk Access, Boot Modes
DSW1-7 & DSW1-8 Mode Set Switches
MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005 Page 9
Upgrading Installing a New Memory Board
DSW2 - Baud Rates
Installing a New Memory Board
To install a new memory board, proceed as follows:
1 From the base of the Site Controller, remove the two Phillips screws securing the old memory
board and remove the board.
2 Remove the standoffs from the old memory board, and install them in the same locations on
the new memory board.
3 Ensure that there are no standoffs in the last two mounting holes, on the back of the memory
board.
4 Install C09622 nylon standoff, and C04126 standoff in the rear left mounting hole. Refer to
Figure
3-3.
Page 10 MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005
Installing a New Memory Board Upgrading
Figure 3-3 Site Controller Memory PCB - C07041
5 Set the switches and jumper settings on the memory board as shown in the following tables
associated with Figure
MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005 Page 11
3-3.
Upgrading Installing a New Memory Board
Jumpers
Switches
Test Points
6 Install the new memory board into the base of the Site Controller using the Phillips screws
removed from the base.
7 Install the new CPU board in the Site Controller, and secure the board with the Phillips screws
previously removed and reconnect cables.
8 Install the new D-site chip in the U36 socket on the CPU Board. Be careful to place the D-site
chip in the proper position, and do not bend any pins.
Page 12 MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005
Installing New Software Upgrading
Installing New Software
Select the appropriate procedure (from the list below) to install new software:
• If your system has dual floppy drives, and you are upgrading from V1.0x to V2.0x or
Procedure A
above, follow
• If your system has a hard drive and a floppy drive, and you are upgrading from V1.0x to
V2.0x or above, follow
• For all system types, if you are upgrading from a 2.0x version to a higher 2.0x or above,
follow
1 With the new Release disk in the A: drive, hold the CPU reset button for 10 seconds while
powering-up the SC II.
2 Sign on after the files are reconstructed.
“Procedure C” on page 15.
“Procedure A” on page 13.
“Procedure B” on page 14.
3 Insert the new Applications disk in the B: drive.
4 Type FIX TR;I and press ENTER.
5 Type RESTORE EV and press ENTER.
6 Type RESTORE TRANS FR TRANBACK.DTA and press ENTER.
7 Type LO TR xxxx and press ENTER.(xxxx = trans # is noted in step 7 of “Taking Backup”
on page 3.)
8 Type AD SIG and load the users, permission levels, and sign on codes. Refer to step 5 of
“Taking Backup” on page 3.
9 Type RUN;I and press ENTER.
10 Type SYSBACK and press ENTER.
11 Use the CP command to copy any user-created files from the V1.0 Release disk to the new
Release or Applications disk.
12 Once the site is up and running, secure the cover to the Site Controller.
13 Update the spare Release disk made while executing step 5 of “Taking Backup” on page 3, or
use SWAPCOPY+ to copy the entire Release disk again.
MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005 Page 13
Upgrading Installing New Software
Procedure B
1 With the new Release disk still in the A: drive, hold the CPU reset button for 10 seconds while
powering-up the SCII.
2 Sign on after the files are reconstructed.
3 Insert the new Applications disk in the A: drive, type A:BIN/INSTALL, and press ENTER.
4 Answer Y to all the prompts except Install new OFFROAD.DTA file?.
5 When this prompt appears: Do you want to install from another floppy disk at this time (Y/
N):, insert the new Release disk, type Y and press ENTER.
6 Answer Y to all the prompts.
7 When the prompt to install from another disk appears again, type N and press ENTER.
8 Type FIX TR;I and press ENTER.
9 Type RESTORE EV and press ENTER.
10 Type RESTORE TRANS FR TRANBACK.DTA and press ENTER.
11 Type LO TR xxxx and press ENTER.(xxxx = trans # is noted in step 7 of “Taking Backup”
on page 3.)
12 Type AD SIG and load the users, permission levels, and sign on codes. Refer to step 5 of
“Taking Backup” on page 3.
13 Type RUN;I and press ENTER.
14 Type SYSBACK and press ENTER.
15 Use the CP command to copy any user-created files from the PRESERVE directory on the
hard drive to the correct directory on the hard drive and to the new Release disk. (Report files
that need to be edited to work with V2.0x or above.)
16 Type CP C:SYSBACK.DTA A: and press ENTER.
17 Update the spare new Release disk made during step 5 of “Taking Backup” on page 3, or use
DISKCOPY to copy the entire Release disk currently in the A: drive.
18 Once the site is up and running, secure the cover to the Site Controller.
19 Remove the disk from the A: drive. Under normal operation there should be no disk in the A:
drive.
Page 14 MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005
Installing New Software Upgrading
Procedure C
1 Type FIX CONF and press ENTER.
2 Type REBOOT;A and press ENTER.
3 Type RESTORE EV and press ENTER.
4 Type RESTORE TRANS FR TRANBACK.DTA and press ENTER.
5 Type LO TR XXXX where XXXX is the trans # noted in step 7 of “Taking Backup” on
page 3.
6 Type RUN;I and press ENTER.
7 If you have been using the Reports Package software, insert the Reports disk made during
HARDBACK into the A: drive, type A:BIN/HARDLOAD, and press ENTER. Once the
reports package has been restored, remove the disk from the A: drive.
MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005 Page 15
Upgrading POS Software Upgrade
POS Software Upgrade
Note: For more details on this procedure, refer to MDE-4356 - Profit Point Reference
Manual.
1 Before performing an upgrade, back up the data in the POS. You will need 3 formatted
diskettes. If you need to format the diskettes, begin at Step 2. If you already have formatted
diskettes begin at Step 2, but skip Steps 4–8.
2 Press CLEAR MENU and SPECIAL FUNCTION. The Special Function Menu appears.
3 Press 0 Exit to main menu and press ENTER.
4 Press 3 Utility and press ENTER.
5 Press 4 Format a diskette and press ENTER. The Format Diskette Submenu appears.
6 Choose the type of diskette you would like to format. Press 1 for 720K bytes or press 2 for
1.44Mbytes, and press ENTER. The screen prompts you to place the disk in drive A:.
7 After placing the disk in drive A, press ENTER. When the screen prompts you for a volume
label, press ENTER. The display prompts you if you wish to format another diskette.
8 Press Y until all diskettes are formatted, then press N. This returns you to the format diskette
submenu.
9 Press 0 Return to utility menu and press ENTER.
10 Press 0 Return to main menu and press ENTER.
11 Press 6 Backup files to diskette and press ENTER.
12 Press 2 Data and configuration files and press ENTER. The screen prompts you to put a
back-up or blank diskette into drive A: and press any key.
13 Put one of the formatted diskettes in drive A: and press ENTER. The screen prompts you that
this is not a back-up disk and would you like to start a new one?.
14 Press Y. When the back-up process is complete, press any key to return to the Back-up menu.
Ensure that you label the back-up diskettes Data and configuration files with the current date.
15 Press 0 Return to main menu and press ENTER.
16 Press 3 Utility and press ENTER.
17 Press 9 Installation menu and press ENTER. The screen prompts you to place the
Installation disk in drive A:.
18 Place the Installation disk in drive A:, and press ENTER. The screen prompts you to confirm
the date and time.
Page 16 MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005
Reports Package Upgrade Upgrading
19 If the date and time are correct, type Y and proceed to the next step. If the date and time are
incorrect, type N. The program prompts you to enter the correct date.
20 Enter the correct date, and press ENTER. The program prompts you to enter the time.
21 Enter the correct time, and press ENTER. The program re-prompts you to confirm the date
and time.
22 Press CLEAR MENU when prompted. The Profit Point installation menu will appear on the
screen. Press 2 Update all program and menu files from diskette, and press ENTER. When
the installation is complete, press ENTER. You will return to the Profit Point installation
menu.
23 Press 0 Return to Profit Point main menu and press ENTER. Press any key when prompted.
24 Remove the Installation disk from drive A: and store it in a safe place.
25 Reboot the Personal Computer (PC) by switching the power off and on, or by pressing
CTRL+ALT+DEL.
26 The POS terminal initializes and comes up online.
Reports Package Upgrade
To upgrade the Reports Package, proceed as follows:
1 Insert the reports package diskette into drive A:.
2 Sign on to the Site Controller and type INSTALL. The new reports files are transferred to the
hard drive.
3 After all the files are copied, remove the diskette from the drive.
MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005 Page 17
Upgrading Reports Package Upgrade
This page is intentionally left blank
Page 18 MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005
Index
Index
A
Applications disks 3
B
Backup 3
bank router software 3
Baud Rates 10
C
Check Point consoles 1
Check Point firmware 1
Cleaning 3
CP command 5
CPU board 7
D
DES encryption 1
D-site chip 12
F
Framos.Cfg 4
U
U36 socket 12
V
V1.0 to V2.0X 4
V2.0 to V2.0C 4
H
HARDBACK 4
M
Memory Board 10
O
odometer entry 1
P
P DA 3
P SIG 3
Phillips screws 7
PIN Pad 1
S
Site Controller II 1
spare parts kit 1
standoffs 10
SYSBACK 3
T
Technical Service 1
TRANBACK 3
trans # 3
MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005 Page Index-1
Index
This page is intentionally left blank.
Page Index-2 MDE-4504 Site Controller II CPU/Memory Board/Program Upgrade Instructions · August 2005
© 2005 GASBOY
7300 West Friendly Avenue • Post Office Box 22087
Greensboro, North Carolina 27420
Phone 1-800-444-5529 • http://www.gasboy.com • Printed in the U.S.A.
Loading...
