Gasboy CFN Series
SDI/Unitec Interface
Version 1.0
Site Controller III version 3.0 and above
part number: C35924
Gasboy International LLC
Gasboy CFN Series
SDI/Unitec Interface
Version 1.0
for Site Controller III version 3.0 and above
03/07/03
C35924
Gasboy International LLC
Lansdale, Pennsylvania
Gasboy International LLC
P. O. Box 309
Lansdale, PA 19446
Copyright 2003 by Gasboy International LLC
All rights reserved.
Printed in the United States of America.
The information in this document is confidential and proprietary. No furth er disclosure thereof shall be made
without permission from Gasboy International LLC.
Gasboy International LLC believes that the information in this document is accurate and reliable. However,
we assume no responsibility for i ts use, nor for any infringements of patents or other rights of third parties
resulting from its use. We reserve the right to make changes at any time without notice.
REVISION RECORD OF THIS DOCUMENT
Part No. Date Published SC III Release Levels
C35924 April 2, 1998 Version 3.0
C35924 August 5, 1999 Version 3.0
C35924 October 14, 1999 Version 3.0
C35924 March 7, 2003 Version 3.0
i
Site Controller III Related Publications
Site Controller IlI - version 3.0 and above
Part No. Title
C35920 CFN III Manager’s Manual for Windows NT, version 3.0
C09326 CFN III Configuration Manual for Windows NT, version 3.0
C35921 CFN III Pocket Reference
C09204 Check Point Reference Manu al
C35745 Profit Point Clerk’s Manual - Modular series
C35746 Profit Point Reference Manual - Modular series
C35923 Point of Sale and Shift Change, version 003
Credit and Debit Card Networks
C35931 Amoco/DataCard C35909 Generic Dial
C35901 Buypass C35908 PaymenTech (formerly Gensar)
C35902 ADS-CITGO C35910 NaBANCO
C35906 ADS-FINA C35911 NDC
C35919 ADS-ZION C35913 Sinclair
C35904 EDS-CCIS C35914 SPS/Phillips
C35903 Comdata C35915 T-Chek
C35905 FDR C35916 UFDA
C35930 Gasboy Dial C35917 VDOT
C35907 Gascard C35918 VisaNet
Pump Interface
C09146 Pump Interface Manual
C01745 Current Loop Interface Unit Manu al
C35849 SDI/Wayne CAT Interface
C35924 SDI/Unitec Interface
C35933 Insight Interface
Card Encoding and Miscellaneous
C09136 CFN Series Clubcard Format
C01687 CFN Series Card Encoding Manual
Remote Communications
C09141 PC/SiteCo nt r ol User’s Manual
Technical Publications
C01759 CFN Diagnostic Manual
ii
SCIII Unitec Interface iii
001
Table of Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SITE CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Gate configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Gate SubMenus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Unitec Wash Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Unitec Wash Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Unitec Wash Discounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Island Card Reader configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Unitec Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
STARTUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
SDI Box Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Clear memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Terminating the application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Booting an SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Booting SDI from Site III . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Gasboy CFN Series
iv Unitec Interface SCIII
Gasboy CFN Series
SCIII UNITEC Interface 1
001
UNITEC Interface
Overview
The interface from the Gasboy Site Controller III to the Unitec POS4000 Car Wash
Controller uses a device called the Gasboy SDI (Serial Device Interface). This wraps/
unwraps Unitec messages in Gasboy RS-485 loop messages.
The Unitec unit must be equipped with Uni-CAM Mark VII option, version 6.2
hardware (or Unitec specification). Set the Unitec unit for 2400 baud operation on the
serial port. The Unitec car wash protocol we support is called the Uni-CAM protocol.
Please refer to the Unitec documentation for the correct settings.
The SDI uses the SDI Generic Application Program, which allows direct Site
Controller interfaces with serial devices that do not follow the Gasboy RS-485 protocol.
Each kind of device is supported a driver in the Site Controller. The Unitec driver is
supported only with Site Controller III.
Cable Connections
The Gasboy SDI has two RJ handset style connectors on one side to connect to the RS485 loop. On the other side there is a DB25S connector which connects to the DB9P
connector on the Car Wash Controller. The corresponding cable uses a DB25P on one
end, and a DB9S on the other. The cable pinout is:
DB25P DB9S Signal
2 2 TxD
3 3 RxD
7 5 SG
This may be furnished by Gasboy P/N C06010.
The SDI is powered by an external power supply which connects to the SDI box by
way of a circular DIN connector. The power supply plugs into an 110VAC outlet, which
should be on the same phase and referenced to the same ground as the Gasboy Site
Controller.
SITE CONFIGURATION
The Site Controller must contain SDI and Unitec drivers, as shown in the STATUS
command:
Drivers: unitec(000) sdi(001)
The Unitec driver replaces the gate controller driver. TABLE.BIN must have one SDI
entry for each SDI, and in addition, one gate entry.
Gasboy CFN Series
2 UNITEC Interface SCIII
Gate configuration
Use the disk-based configuration program GATE to see the configuration submenus for
the car wash information.
Gate SubMenus
The following is a list of the submenus currently available for the gate and gate
controllers.
1 = Gasboy gates
2 = Gasboy gate controller
3 = Unitec Wash parameter
4 = Unitec Wash types
5 = Unitec Wash discounts
6 = Quit
Unitec Wash Parameters
# Description
1 Reader car wash prompt line 1: what type of wash
2 line 2:
3 line 3:
4 line 4:
5 Car wash price code: 0
6 Days carwash code valid: 0
------------------------------------------------------
Enter number of parameter to modify or q to quit:
The items you can configure in the Unitec wash parameters are:
•
Reader car wash prompt lin e 1 [Wha t typ e of car wash ]:
the display. The default will be displayed between the brackets. Enter additional
information for lines 2-4 if needed. This information will be displayed at the
card reader.
•
Price code for car wash prices [0]:
The car wash driver uses this one price
CODE for all car washes. Each car type uses the price LEVEL corresponding to
its type. For example, car wash type 42 will use price level 42 of the price code
configured here. The price code you assign here must be entered on the site
using the Load Price command.
•
Days car wash code valid [0]:
The Unitec car wash controller does not remove
wash codes from memory automatically. This must be done with a user command at the Unitec console. The number of days listed here is to tell customers
how often you plan to clear the Unitec memory.
To change the
parameters of the
car wash, select
submenu 3, Unitec
Wash Parameters
from the Gate Menu.
Enter the first line of
Unitec Wash Types
To change the types of the car wash, select submenu 4, Unitec Wash Types from the
Gate Menu. If an ICR does not recognize the selection Car Wash, check that you have
entered the car wash types in this screen.
Gasboy CFN Series
SCIII UNITEC Interface 3
# Stock Dept. Disc Name Functions
1
2
3
4
5
.
.
.
13
14
15
16
------------------------------------------Enter a to add, d to delete, m to modify, q to quit, or RETURN for next page
The following can be added or modified:
•
Stock Number (from 100-65530)[0]
: Enter a unique stock number for this
wash type. Required.
•
Associated department [10]:
Enter the department (product code) this wash
will be included in. Required.
•
Discount level [0]
: Discounts are used to allow island reader transactions to
get a reduced price for a wash depending on how much fuel they buy. At the
reader, only wash types of discount level zero may be chosen. When the sale
completes, the type table is scanned for wash types with the same functions
included but a different discount level. If the sale qualifies for the discount and
the price is actually lower, the wash type for the sale will be changed to the discounted one.
For POS transactions, any type of wash can be chosen and it is up to the clerk to
assign the correct wash type to the sale.
•
Name
: Enter the name of the wash type.
•
Enter wash functions
: A car wash consists of from 1 to 12 functions that can
be enabled for a given wash. Consult the way your wash controller is configured
to determine which combinations you desire to sell as different washes.
Enter a plus (+) to add or a minus (-) to subtract a function followed by
the function number . You may do more than one. For example: +1+2+3-4-5
will add functions 1, 2, and 3, and subtract 4 and 5.
Note: Multiple Options do not work.
NOTE:
If using a Profit Point, you must have matching Stock and Department numbers
entered. Use the PLU Maintenance program of the Profit Point to enter this information.
Receipts will not print the information unless this is entered.
At the Profit Point menu:
1. Select PLU Maintenance.
2. Select #1, Add an entry.
3. Select #2, Add a stock number.
4. Enter the same stock number that was entered above.
5. Enter the same department number that was entered above.
6. Enter the same retail price that was entered above.
7. Exit the Profit Point menu as directed by the program.
At the Site Controller prompt:
1. Type Load Product;A to load a new product.
2. Enter the Product Code. Assign a code that currently is not in use. 1-10
and 20-29 are set asside for fuel products.
3. Enter the Category number. This would be the merchandise category number if you are assigning the car wash as merchandise.
Gasboy CFN Series
4 UNITEC Interface SCIII
4. Enter the Product Name - Car Wash.
5. Enter the Minimum Price. A minimum price must be entered.
6. Enter the Maximum Price. A maximum price must be entered.
7. Enter the Taxes that are applicable to this site.
8. Exit Load Product.
Load the price code:
1. Type Load Price
2. Enter the Price Code - this must be the same code as entered in the Car
Wash submenu 3.
3. Enter the Price level. Load your price level for Car Wash.
4. Exit Load Price.
Tie it all together:
1. Type the command
POS
to send the information from the site to the Profit
Point.
Unitec Wash Discounts
To change the wash discounts, select submenu 5, Unitec wash discounts from the Gate
Menu. The following information is displayed:
# Description
1 None
2 None
3 None
4 None
5 None
------------------------------------------------------
Enter number of discount to modify or q to quit:
Type of discount [0]:
The currently supported discount types are:
0: discount type disabled
1: Pumping of at least a given amount of fuel.
Island Card Reader configuration
Check the ICR program step 8, Want car wash. This message must appear before the
“Please Wait” step. The default message is Want Car Wash? Change this if necessary.
Please refer to the chapter, Island Card Reader configuration in the SCIII Configuration
Manual.
Troubleshooting
Car Wash Item on receipt shows VOID
No Car Wash Printed on Receipt
Gasboy CFN Series
Make sure the Car Wash Product is loaded and with minimum and maximum
prices.
Make sure Stock numbers are loaded in the GATE, submenu 4.
If Car Wash is not printing at the Profit Point, make sure matching stock numbers are loaded in the PLU Maintenance menu and the POS command was executed at the Site terminal.
SCIII UNITEC Interface 5
INVALID Merchandise error when using a fuel restricted Fleet Card
Currently Fleet Cards with fuel restrictions may cause an Island Car W ash to be
denied.
Unitec Interface
For each Unitec interface you need an application binary and an arguments file. These
are stored in the root directory of the Site Controller. For a SC3 the location would be
C:/SC3/XBIN. The application binary for SDI #1 will have an extension of “B01”, for
SDI interface #2, “B02”. For example, WASH.B01 would be a correct application binary
name for SDI #1. There should only be one file that has the B01 extension in the
C:XBIN directory.
Parameter file extensions begin with ‘A’ instead of ‘B’, so WASH.A01 would be a
valid parameter file name. The site will attempt to keep the SDI loaded with the correct
application and parameters.
The WASH.A01 parameter file for SDI #1 should contain:
ID=Unitec
CHANNEL=RS232
BAUD=2400
PARITY=NONE
CHAR_BITS=8
STOP_BITS=1
FLOW_CONTROL=NONE
RX-TX_DELAY=0
CHAR_DELAY=0
TURN_CHARS=CR EOT
END_CHANNEL
NOTE
: If the site has an Insight or any additional SDIs, each SDI must have unique
.A0# and .B0# files in the XBIN directory. For example, if the site has an Insight.A01 file
then the Unitec parameter file should be named WASH.A02 with a corresponding
WASH.B02 binary file.
STARTUP
Connect the Gasboy RS-485 data loop into one of the phone-type jacks in the SDI box.
SDI status will show up in diagnostics. Additional diagnostics are supported:
NB0 = The number of times SDI program has crashed.
NB1 = The number of times application check failed.
NB2 = The number of times downloads have failed.
NB9 = The number of times downloads have succeeded.
The SDI box has a bank of switches visible through a slot in the side of the box,
next to the LED. Normally the UP position, raised above the switch bank body, is OPEN.
Default settings for these switches are all OPEN.
SDI Box Switches
Switches are numbered 1-8 from left to right. OPEN may be either up or down; check
the label on the switch in your unit. Default switch settings are all OPEN. Switch
assignments are as follows.
123 45 67 8
ADDR ADDR ADDR ADDR ADDR CLR SDI RESET
5 4 3 2 1 MEM LOAD
Gasboy CFN Series
6 UNITEC Interface SCIII
Switch Function
SWA-1 SDI add a4, OPEN = 0
SWA-2 SDI addr a3, OPEN = 0
SWA-3 SDI addr a2, OPEN = 0
SWA-4 SDI addr a1, OPEN = 0
SWA-5 SDI addr a0, OPEN = 0
SWA-6 App b0, OPEN = 0. Suggest: application terminate.
SWA-7 Mode select A + B, Enable SDI programming
SWA-8 Reset
SDI address is switch setting plus 1:
Address SWA-1 SWA-2 SWA-3 SWA-4 SWA-5
1 OPEN OPEN OPEN OPEN OPEN
2 OPEN OPEN OPEN OPEN CLOSE
3 OPEN OPEN OPEN CLOSE OPEN
4 OPEN OPEN OPEN CLOSE CLOSE
5 OPEN OPEN CLOSE OPEN OPEN
6 OPEN OPEN CLOSE OPEN CLOSE
7 OPEN OPEN CLOSE CLOSE OPEN
8 OPEN OPEN CLOSE CLOSE CLOSE
9 OPEN CLOSE OPEN OPEN OPEN
10 OPEN CLOSE OPEN OPEN CLOSE
11 OPEN CLOSE OPEN CLOSE OPEN
12 OPEN CLOSE OPEN CLOSE CLOSE
13 OPEN CLOSE CLOSE OPEN OPEN
14 OPEN CLOSE CLOSE OPEN CLOSE
15 OPEN CLOSE CLOSE CLOSE OPEN
16 OPEN CLOSE CLOSE CLOSE CLOSE
17 CLOSE OPEN OPEN OPEN OPEN
18 CLOSE OPEN OPEN OPEN CLOSE
19 CLOSE OPEN OPEN CLOSE OPEN
20 CLOSE OPEN OPEN CLOSE CLOSE
21 CLOSE OPEN CLOSE OP EN OP EN
22 CLOSE OPEN CLOSE OPEN CLOSE
23 CLOSE OPEN CLOSE CLOSE OPEN
24 CLOSE OPEN CLOSE CLOSE CLOSE
25 CLOSE CLOSE OPEN OPEN OPEN
26 CLOSE CLOSE OPEN OPEN CLOSE
27 CLOSE CLOSE OPEN CLOSE OPEN
28 CLOSE CLOSE OPEN CLOSE CLOSE
29 CLOSE CLOSE CLOSE OPEN OPEN
30 CLOSE CLOSE CLOSE OPEN CLOSE
31 CLOSE CLOSE CLOSE CLOSE OP EN
32 CLOSE CLOSE CLOSE CLOSE CLOSE
Gasboy CFN Series
SCIII UNITEC Interface 7
Reset
To reset the SDI box, momentarily lower (CLOSE) the RESET switch.
Clear memory
To clear application memory (only do this under instruction from qualified support
engineer):
1. CLOSE position 6, enabling memory clear.
2. Wait for the LED to begin flashing in bursts of five short flashes.
3. OPEN position 6. When the Site Controller next talks to the SDI, it will
download a new application program.
Terminating the application
To terminate an application, causing the SDI to request new application download:
1. CLOSE SWA-6.
2. When LED begins flashing groups of five quick flashes, CLOSE SWA-8.
3. OPEN SWA-6.
4. OPEN SWA-8.
5. After the Site Controller says “SDI came up”, the LED will flash somewhat
irregularly as a new application is downloaded.
6. When the application is loaded, it takes over the LED. See the application
documents for LED behavior.
A blank SDI will display no LED flashing at all. While a malfunction may also cause
this, re-loading the SDI is the first thing to try.
Booting an SDI
To boot a blank SDI from DOS PC:
1. Set up a Gasboy RS485 converter box jumpers:
You will need the converter’s power supply plugged in.
2. Connect the serial cable to from PC COMM port 1 or 2 to Gasboy RS485
converter RS232 port, and a RS485 cross cable from the RS485 converter
RS485 port to the SDI RS485 port.
K1
K2
K3
K4
K5
1
2
3
DB25 Connector
1
2
3
1 2
K6
K7
1
2
3
Gasboy CFN Series
8 UNITEC Interface SCIII
The RS485 cross cable is a 1x3, 2x4 cable such as C04500, used for
connecting the Current Loop Interface to the Site Controller. The RS422
cable should be a null modem or printer cable, depending on how your PC
COMM ports are set up.
3. Power up the SDI box.
4. Set SWA-7 DOWN and SWA-8 DOWN. Set all other switches UP.
5. Set SWA-8 UP.
6. Give the command:
BOOTSDI SDI.S19 1
or
BOOTSDI SDI.S19 2
depending on whether the SDI is connected to COM1 or COM2.
7. The SDI LED should blink rapidly and somewhat irregularly, for duration
of the download.
8. BOOTSDI should print a line of dots, and then say:
sdi.s19 successful
Done.
If so, go to step 9.
9. If BOOTSDI, after several seconds, says:
no sync from SDI, enter=retry, q=quit >
You may close SWA-8 again momentarily, then open it, press ENTER, and
return to step 6.
10. When you have received the “Done” message, set SWA-8 CLOSED.
11. Immediately set SWA-7 OPEN.
12. Immediately set SWA-8 OPEN and the SDI will go to run mode. This should
be signaled by regular on-off blink of the LED, a little faster than 30
blinks/minute.
Booting SDI from Site III
You will need the SCIII hardware diagnostics program DIAG.BIN. For this file to operate
properly it must be stored in C:\SC3\DIAG.BIN. You must also have the SDI operating
system must be stored in C:\SC3\XBIN\SDI.HEX.
1. At the console, enter the command: REBOOT;A DIAG to load the hardware
diagnostics.
2. Power up the SDI box.
3. Set SWA-7 DOWN and SWA-8 DOWN. Set all other switches UP.
4. Set SWA-8 UP.
5. After these steps have been completed, give the command ‘L’ which causes
the SDI download. You can have one SCI being downloaded on each loop
for a maximum of three. On the status line for the loop(s) that have a
download proceeding you should see progress of the download indicated.
If a failure is reported, check the cabling, do steps 2-5 again, then type ‘L’
again and proceed.
6. When you receive the “Loaded Successfully” message, set SWA-8 CLOSED.
7. Immediately set SWA-7 OPEN.
8. Next, set SWA-8 OPEN and the SDI will go to run mode. This should be
Gasboy CFN Series
SCIII UNITEC Interface 9
signaled by regular on-off blink of the LED, a little faster than 30 blinks/
minute.
9. Press ‘Q’ to quit and return to the Site OS. FRAMOS.BIN will automatically
load.
Gasboy CFN Series
Loading...
