Gasboy Fleet PLUS User Manual

Download
PT-1963C
l
IIlllluussttrraatteedd SSppaarree PPaarrttss MMaannuuaal
Illustrate d Spare Parts Manual Page 1 of 45
Table of Content
1. Spare Parts Table ................................................................................................. 3
2. Islander PLUS / ICR PLUS ................................................................................. 6
3. ICR PLUS for electronic dispenser ..................................................................... 9
4. CFN PLUS & Extension box ............................................................................ 12
5. Fuel tank controller ........................................................................................... 14
6. Pump interface ................................................................................................... 16
7. Outdoor wireless gateway terminal - PA04000001 .......................................... 17
8. Nozzles Readers Reference Table & Spare Parts .............................................. 18
9. General Spare Parts Units .................................................................................. 19
10. Reference manuals ............................................................................................ 45
Illustrated Spare Parts Manual Page 2 of 45
Record of Modifications
Date Version Modified By Modifications
03-02-2010 A Idan Sinay First Release 25-02-2010 A Idan Sinay GVR new part numbers 01-03-2010 A Idan Sinay Pump interfaces changes 06-09-2010 A Idan Sinay Update GVR new part numbers 09-10-2010 A Idan Sinay Update GVR new part numbers 11-01-2011 A Idan Sinay Orpak new part numbers 23-02-2011 A Tamar Raz Orpak new part numbers and updated
existing.
1. Spare Parts Table
Gasboy Part number Vs Orpak Part Number
Part Description GVR Part
Number
Payment Panel includes Card Swiper and MiFare Reader 8 Port CommVerter M09680B021 8P COMMVERTER+STRT.LAN, TESTED 819523469
Controller M09680B004 ORCU-N (METAL)-TESTED 811035510 Transformer - 24V M09680B022 TRANSF.24V 3.33A,CL2-80-24 811338000 Line Filter M09680B008 LINE FILTER,5500.2042,SCHURTER 811400200 Lock M09680B018 LOCK 813100800 Solid State Relay - 12VDC, 12A M09680B011 RELAY,SSR,12VDC,12A-W6212DDX-1 813105900 Card Swiper M09680B013 SWIPE READ.COATED TRACK1 and 2,
Head of Printer PLUS Harness M09680B023 PRIN.HIGH SPEED +HARNESS,24V 813107480 HID Installation Kit M09680B040 Hid PLUS Kit-set ORIC/OrIT 819218000 Terminal Block INT. MODULE M09680B025 T.B.INT.MODULE,100-240V UL CSA 813317800 Keyboard Label M09680B026 LABEL KBD.ORPT PANEL 817322505 Fleet Key Socket and Harness M09680B027 HARNESS,DATA KEY SOCKET/ORPT 819138050 Graphic Display M09680B015 DISPLAY ASSY.GRA-ORPT,EXTEND.T 819222553 Tokheim Pump Interface Card M09680B028 TOKH.INT.P.B.(8P), TESTED 819223420 Current Loop Pump Interface Card M09680B029 GILBARCO PUMP (PB-8P)-TEST 819223431 RS-232 VR/Pump Interface Card M09680B016 RS232 INT. (PB-8P)-TEST 819223451 RS-485 Pump Interface Card M09680B017 RS485 P.B. 8P-TEST 819223460 RS-422 Pump Interface Card M09680B030 RS422 819223471 Nuovo Pignone Pump Interface Card M09680B031 Nuovo Pignone 819223485 Mechanical Pump Interface Card M09680B019 ASSY,MPI+SUB P.B.(8P),TESTED 819223490 Hub Switch M09680B032 KIT ASSY.-5 PORT SWITCH-TESTED 819225210 PCB Card for Printer M09680B033 PCB ASSY.G2 PRINTER ENG,TESTED 819519910 Printer - Islander and ICR PLUS M09680B034 PRINTER MODULE ASSY KIT, ORIC 819238095 FTC Shock Absorber M09680B035 Shock Observer 814605600 Fuse M09680B036 HARNESS,P.S.FUSE CONN.24V 819138051 Interface Card Extractor M09680B037 Card Extractor (8P COMMVERTER) 814423700 Power Supply: 100 - 240 VAC, 100W M09680B041 P.S 100-240VAC,100W 811300164
M09680B038 ORPT PAN.EXTENDED+SWIP.MIF.GRA 800922576
Orpak Description Orpak Part
Number
813106881
43m
Illustrated Spare Parts Manual Page 3 of 45
Part Description GVR Part
Number
Islander and ICR PLUS Top Cover M0968 0B042 Top Cover GB 819238056 Paper Roll for Receipt Printer M09680B043 Paper Roll-57mm, D-150mm-Therm 816600430 Paper Roll Pivot for Receipt Printer M09680B108 SHAFT,PAPER ROLL-ISCU+AXIOHM 814911100 HS - Tag (One per ring) M09680B020 FuelOpass HS 819205541 Relay Solid State 250V, 25A M09680B044 Relay Solid State 250V, 25A 813105950 Switch M09680B045 Switch 813104530 Power Supply 110-240V/24V DC, 15W M09680B046 Power Supply 110-240V/24V DC, 15W 811309400 WGT-CARDS SET-TESTED M09680B047 WGT-CARDS SET-TESTED 819239310 Circuit Breaker M09680B048 Circuit Breaker 813104450 Harness ANT LOOP-Wireless Programmer M09680B049 Harness ANT LOOP-Wireless Programmer 819120900 Harness ANT LOOP-W. Programmer 110mm M09680B091 Harness ANT -W. Programmer 110 mm 819120915
HARNESS D9P/D9S RS232 W.L.PROG M09680B050 HARNESS D9P/D9S RS232 W.L.PROG 819120935 DataPass Harness M09680B051 DataPass Harness 819107670 PCB Assy P.S -32V DC M09680B052 PCB Assy P.S -32V DC 819538036 PCB Assy P.S -24V DC- 8 Hoses M09680B083 PCB Assy P.S -24V DC 819538035 Heater Set M09680B063 Heater Set 819204152 HID Indala - KIT M09680B058 HID Indala - KIT 819218100 Simulator for MPI-C M09680B059 Simulator for MPI-C 819523691 Extension KIT - 5 Port M09680B060 Extension KIT - 5 Port 819225250 Battery-Wireless Vehicle Programmer M09680B067 Battery-Wireless Vehicle Programmer 812520900 S/P NR, ADAPTORS TYPE-H-T M09680B071 S/P NR,ADAPTORS TYPE-H-T 819039195 S/P NR, TYPE-2 M09680B114 S/P NR, TYPE-2 819039099 S/P NR, TYPE-1 M09680B115 S/P NR, TYPE-1 819039098 NR,Coil- Type 1 M09680B074 NR,Coil- Type 1 819339006 NR,Coil- Type 2/3 M09680B075 NR,Coil- Type 2/3 819339005 NR-H, Coil-70mm M09680B076 NR-H, Coil-70mm 819339110 NR-H/T, Coil-55mm, ZVA 32 M09680B077 NR-H/T, Coil-55mm, ZVA 32 819339120 NR-H/T, Coil-OPW 7H M09680B078 NR-H/T, Coil-OPW 7H 819339122 NR-H ,Coil-Rectangular - OPW 11B M09680B079 NR-H ,Coil -Rectangular - OPW 11B 819339130 NR-H, Coil-WIGGINS M09680B080 NR-H, Coil-WIGGINS 819339143 NR-H, Coil-POSILOCK M09680B081 NR-H, Coil-POSILOCK 819339160 NR-T, Coil-HUSKY 1+8 M09680B082 NR-T, Coil-HUSKY 1+8 819339124 Relay, 30A (8 Hose) M09680B085 Relay,30A (8 Hose) 813111300 PCB ASSY, SSR (8 hose) M09680B084 PCB ASSY , SSR CNTRL(8 hose) 819538040 KIT, COIL HOLDER CLAMP (30pc) M09680B086 CLAMP-COIL HOLDER (30pc) 815806030
TopKAT PLUS Tag - Orange Tag KIT ORCU ( Dongle + Holder) Journal Printer Nozzle Reader Plastic Cover (OPW 7H) Mobile Printer (12V) for FTC M09680B099 MOBILE PRINTER (12V) FOR ORTC 800921724 Sensor Islander KIT M09680B096 Sensor Oric KIT 819238500 Assembly, Mechanical Printer Box TopKAT M09680B107 Mechanical Assy Printer Box 819020300 Islander Replacement Door With Printer M09680B064 Door Assy - ORIC with Printer 819038090 Assembly, Door-OrIC without Printer M09680B065 Door Assy - ORIC without Printer 819038091 CFN PLUS lock M09680B097 Lock, Rittal Box (OrCU 3000) 813102500 Upgrade Kit OrTC DC/DC Converter M09680B093 Upgrade Kit OrTC DC/DC Converter 819238094 Upgrade Kit FleetKey - OrIC With Printer M09680B094 UPGRADE NEW DATAKEY-ORIC-W/PRN 819038093
M09680B087 M09680B089 M09680B090 M09680B092
Orpak Description Orpak Part
Number
TAG,GILBARCO,ORANGE,INIT KIT ORCU,RS 232 Dongle + Holder 819235520 Journal Printer 800919810 Plastic Cover OPW 7H
819209871
814105200
Illustrated Spare Parts Manual Page 4 of 45
Part Description GVR Part
Number
Upgrade Kit FleetKey – OrIC without Printer M09680B095 UPGRADE NEW DATAKEY-ORIC-W/O-P 819038094 Bracket Metal 7H Round Bobbin M09680B098 Bracket Metal 7H Round Bobbin 819313380 Cold Weather Cable Kit M09680B054 Cold Weather Cable Kit 819138101 Decorative Panel - OrPT M09680B057 Decorative Panel 814942525 Lock Kit M09680B088 Lock Kit 819038200
Orpak Description Orpak Part
Number
Illustrated Spare Parts Manual Page 5 of 45
2. Islander PLUS/ICR PLUS
Islander PLUS/ICR PLUS General View
This general view describes the parts of Islander PLUS pedestal that supports 2/4 mechanical dispensers or electronic dispenses. In ICR PLUS for mechanical dispensers, the only missing part will be the OrCU-N unit (M09680B004), all the rest remain the same. ICR PLUS for electronic dispenser will be described on page # 9
Illustrated Spare Parts Manual Page 6 of 45
Islander PLUS Printer
Illustrated Spare Parts Manual Page 7 of 45
Islander PLUS Lock
Islander PLUS Fuse
Illustrated Spare Parts Manual Page 8 of 45
3. ICR PLUS for Electronic Dispenser
ICR PLUS – Generic View
Illustrated Spare Parts Manual Page 9 of 45
ICR PLUS – Internal View
Illustrated Spare Parts Manual Page 10 of 45
Islander PLUS – 8 Hoses
Illustrated Spare Parts Manual Page 11 of 45
4. CFN PLUS and Extension Box
General View – Door Side
This general view describes the parts of CFN PLUS that supports 2/4 mechanical dispensers or electronic dispenses. In extension box (PA03990000) for mechanical dispensers the only missing part will be the OrCU-N unit (M09680B004), all the rest remain the same.
Illustrated Spare Parts Manual Page 12 of 45
General View – Box Side
Illustrated Spare Parts Manual Page 13 of 45
5. Fuel Truck Controller
FTC General View – Door Side
This general view describes the parts of FTC that supports 2/4 mechanical dispensers.
Illustrated Spare Parts Manual Page 14 of 45
FTC - General View – Box Side
FTC – Installation Kit – MO9680B039
Illustrated Spare Parts Manual Page 15 of 45
6. Pump Interface
8 Port CommVerter and Interface Cards
Note: All Pump interface cards are located on 8 Port CommVerter and it depends on Island installation configuration
Part Description
Tokheim Pump Interface Card Current Loop Pump Interface Card RS-232 VR/Pump Interface Card RS-485 Pump Interface Card RS-422 Pump Interface Card Nuovo Pignone Pump Interface Card Mechanical Pump Interface Card
GVR Part Number Orpak Description
M09680B028 M09680B029 M09680B016 M09680B017 M09680B030 M09680B031 M09680B019
TOKH.INT.P.B.(8P), TESTED GILBARCO PUMP (PB-8P)-TEST RS232 INT. (PB-8P)-TEST RS485 P.B. 8P-TEST RS422 Nuovo Pignone ASSY,MPI+SUB P.B.(8P),TESTED
Orpak Part
number
819223420 819223431 819223451 819223460 819223471 819223485 819223490
Illustrated Spare Parts Manual Page 16 of 45
7. Outdoor Wireless Gateway Terminal - PA04000001
GVR Part
Part Description
Power Supply 110-240V/24V DC,15W WGT-CARDS SET-TESTED
Number Orpak Description
M09680B046 M09680B047
Power Supply 110-240V/24V DC, 15W WGT-CARDS SET-TESTED
Illustrated Spare Parts Manual Page 17 of 45
Orpak Part
number
811309400 819239310
8. Nozzles Readers Reference Table and Spare Parts
GVR PN Orpak PN Description Type GVR PN
Spare Parts
Coil KIT
Nozzle Type Dimensions
Standard Nozzle Readers
M09677B001 800939007 TYPE #1 1 M09680B074 819339006 OPW7H M09677B002 800939006 TYPE #2 2 M09680B075 819339005 OPW11A
ZVA SL / 25 / OPW -
M09677B003 800939005 TYPE #3 3 M09680B075 819339005
DEF
NR-H Nozzle Readers
Healy,VST
M09677B004 800939110
M09677B005 800939120 M09677B015
800939122
M09677B006 800939130
NOZZ.READER-H WITH VR COIL SET H M09680B076 819339110 NR-H ZVA32 WITH ROUND COIL SET H M09680B077 819339120 ZVA32 55mm NR-H WITH ROUND COIL SET H M09680B078 819339122 OPW 7H 55mm NR-H WITH RECTANGULAR COIL SET H M09680B079 819339130 OPW 11B 30mm
,OPW,EM CO 70mm
NR-T Nozzle Readers
NR-T WITH ROUND
M09677B011 800939123
M09677B012 800939131
M09677B010 800939142
M09677B013 800939161
M09677B014 800939172
COIL SET T M096 80B078 819339122 OPW 7H 55mm NR-T WITH RECTANGULAR COIL SET T M096 80B079 819339130 OPW 11B 30mm NR-T ENGRAVED WIGGINS COIL SET T M09680B080 819339143 WIGGINS 90mm NR-T WITH POSILOCK COIL SET T M09680B081 819339160 NR-T HUSKY 1+8 ORTC T M09680B082 819339124
POSILOC K 90mm HUSKY 1+8 55mm
Nozzle Reader Spare Parts H/W
M09680B115 819039098 S/P NR TYPE-1 1 M09680B114 819039099 S/P NR, TYPE-2 2
Illustrated Spare Parts Manual Page 18 of 45
9. General Spare Parts Units
Gasboy Part Description Orpak Part Description Picture
Mifare Reader
PA04020001
TBD
TBD
TBD
TBD
OrTR (Mifare, Swipe Reader)
P/N: 800910930
ORTR-KB (OR, MF,ENG)
P/N: 800910926
ORTR-KB (OR, MF,SW, ENG)
P/N: 800910927
TBD
TBD
BRACKET, MOUNTING ­FTC REMOTE DISPLAY
M09680B119
ORTR HOLDER KIT (L bracket)
P/N: 819010991
Illustrated Spare Parts Manual Page 19 of 45
TBD
Gasboy Part Description Orpak Part Description Picture
Wireless Gateway for Islander PLUS, ICR PLUS
PA04000000
Wireless Gateway Terminal
P/N: 800939300
Wireless Nozzle Reader
PN: M09677B001
Wireless Nozzle Reader
PN: M09677B002
Wireless Nozzle Reader
PN:M09677B003
Wireless Nozzle Reader Type 1,
P/N: 800939007
Wireless Nozzle Reader Type 2
P/N: 800939006
Wireless Nozzle Reader Type 3
P/N: 800939005
Illustrated Spare Parts Manual Page 20 of 45
Gasboy Part Description Orpak Part Description Picture
NR-H VR, Coil Set­(HEALY,VST,OPW,EMCO)
M09677B004
NR-H Round coil Set­( ZVA 32)
M09677B005
NR-H Rectangular Coil Set­(OPW 11B)
M09677B006
NR-H VR, coil SET
P/N: 800939110
NR-H Round coil SET
P/N: 800939120
NR-H Rectangular coil SET
P/N: 800939130
NR-H Round coil SET OPW 7H
M09677B015
NR-H Round coil SET OPW 7H
P/N: 800939122
Illustrated Spare Parts Manual Page 21 of 45
Gasboy Part Description Orpak Part Description Picture
NR-T WIGGINS COIL-SET
M09677B010
NR-T With Round coil ­OPW7H
M09677B011
NR-T Rectangle-OPW 11B
M09677B012
NR-T WIGGINS COIL-SET
P/N: 800939142
NR-T With Round coil ­OPW7H
P/N: 800939123
NR-T Rectangle-OPW 11B
P/N: 800939131
NR-T POSILOCK
M09677B013
HUSKY 1" (i+8)
M09677B014
NR-T POSILOCK
P/N: 800939161
HUSKY 1" (i+8)
P/N: 800939172
Illustrated Spare Parts Manual Page 22 of 45
Gasboy Part Description Orpak Part Description Picture
NR Adaptor OPW 7H Nozzle
M09677B016
Rings
70 mm(2.75")­105 mm(4.13")­120 mm (4.72")­130 mm (5.11")-
M09678B001
M09678B002
M09678B003 M09678B004
Self Install - Installation KIT­Heavy Vehicle (100 units)
M09680B053
NR Adaptor 1" NPT for OPW 7H
P/N: 819739105
FUELOPASS HS SET ASSY (Self install)
P/N: 800905330 P/N: 800905332 P/N: 800905333 P/N: 800905334
Self Install - Installation KIT­Heavy Vehicle (100 units)
P/N: 819005407
FUELOPASS HS SET ASSY
Rings
75 mm (2.95")- M09678B005 85 mm (3.34")- M09678B006 95 mm (3.74")- M09678B007
(Shaped)
P/N: 800905301 P/N: 800905302 P/N: 800905303
Rings
80 mm (3.15")-M09678B010 80 mm (3.15")­90 mm (3.54") 95 mm (3.74")-M09678B013 110 mm (4.33")-M09678B014 120 mm (4.72")-M09678B015 130 mm (5.11")-M09678B016 145 mm (5.71")-M09678B017
M09678B011
-M09678B012
FUELOPASS HS SET ASSY (Molded) P/N: 800905340 P/N: 800905341 P/N: 800905342 P/N: 800905343 P/N: 800905344 P/N: 800905345 P/N: 800905346 P/N: 800905347
Illustrated Spare Parts Manual Page 23 of 45
Gasboy Part Description Orpak Part Description Picture
FuelOpass-HS assembly,
Wiggins 125mm x 183mm
M09678B018
Wiggins 96mm x 154mm
M09678B019
Wiggins,125x183 P/N: 819312640
FuelOpass-HS assembly, Wiggins,96x154 P/N: 819312641
Vehicle Tank Rings Install Kit - 100 rings - Heavy Duty Vehicles
M09678B009
OBD plug unit supporting CAN protocol (Light vehicles )
M09693B002
OBD plug unit supporting K­line protocol (Light vehicles)
M09693B003
Molded Ring - Installation KIT­Heavy Vehicle(100 units)
P/N: 819005401
uDataPass CAN
P/N: 800907400
uDataPass K-line
P/N: 800907405
VEHICLE MODULE OBD CANBUS PLUS
M09693B005
uDataPass CAN (PLUS)
P/N: 800907430
Illustrated Spare Parts Manual Page 24 of 45
Gasboy Part Description Orpak Part Description Picture
VEHICLE MODULE OBD K-LINE PLUS
M09693B006
DataPass (OBD + Pulses) – wired
M09693B004
Heavy vehicles and vehicles without bus that uses pulses (J1708/1587+FMS + Pulses)
M09693B001
uDataPass K-Line (PLUS)
P/N: 800907431
DataPass (OBD+ Pulses)
P/N: 800907300
DataPass (J1708/FMS + Pulses)
P/N: 800907310
Wireless Vehicle Programmer
PA04010000
Mifare Pod connected to FHO to read Tags
PA04020000
Wireless Vehicle Programmer
P/N: 800920910
FHO Mifare POD
P/N: 800910980
Illustrated Spare Parts Manual Page 25 of 45
Gasboy Part Description Orpak Part Description Picture
Mifare Tag Blue
M09679B001
Mifare Tag Red
M09679B002
Mifare Card – White blank
M09679B003
Mifare Tag Blue
P/N: 800909831
Mifare Tag Red
P/N: 800909832
Mifare Card – White blank
P/N: 819209854
Mifare Card – White with Sequential Number
M09679B004
Mifare Card – Green with Sequential Number
M09679B005
Mifare Card White +N
P/N: 819209882
Mifare Card Green +N
P/N: 819209883
Illustrated Spare Parts Manual Page 26 of 45
TBD
TBD
Gasboy Part Description Orpak Part Description Picture
Mifare Card – Yellow with Sequential Number
M09679B006
HID POD connected to FHO to read HID cards
PA04020010
Mifare Card Yellow +N
P/N: 819209884
HID POD
P/N: 800918200
TBD
TBD
HID Indala POD
PA04020020
Payment Panel includes Card Swiper and MiFare Reader
M09680B038
HID Indala POD
P/N: 800918250
ORPT PANL.EXTENDED SWIP MIF.GRA
P/N: 800922576
TBD
8 Port CommVerter
M09680B021
8P commVerter+strt.LAN
P/N: 819523469
Illustrated Spare Parts Manual Page 27 of 45
Gasboy Part Description Orpak Part Description Picture
Controller
M09680B004
Transformer - 24V
M09680B022
Line Filter
M09680B008
OrCU-N (Metal) Tested
P/N: 811035510
TRANSF.24V 3.33A,CL2-80­24
P/N: 811338000
LINE FILTER, 5500. 2042, SCHURTER
P/N: 811400200
Lock
M09680B018
Solid State Relay - 12VDC, 12A
M09680B011
Lock
P/N: 813100800
RELAY,SSR,12VDC,12A­W6212DDX-1
P/N: 813105900
Illustrated Spare Parts Manual Page 28 of 45
Gasboy Part Description Orpak Part Description Picture
Card Swiper
M09680B013
Head of Printer PLUS harness
M09680B023
HID Installation Kit
M09680B040
HID Indala Kit
M09680B058
SWIPE READ.COATED TRACK1 and 2, 43m
P/N: 813106881
PRIN.HIGH SPEED +HARNESS,24V
P/N: 813107480
Hid Kit-set ORIC/OrIT P/N: 819218000
HID Indala Kit P/N: 819218100
T.B Init Module
M09680B025
T.B.INT.MODULE,100-240V UL CSA
P/N: 813317800
Illustrated Spare Parts Manual Page 29 of 45
Gasboy Part Description Orpak Part Description Picture
Keyboard Label
M09680B026
Fleet Key Socket and Harness
M09680B027
Graphic Display
M09680B015
LABEL KBD.ORPT PANEL
P/N: 817322505
HARNESS,DATA KEY SOCKET/ORPT
P/N: 819138050
DISPLAY ASSY.GRA­ORPT,EXTEND.T
P/N: 819222553
Tokheim Pump Interface Card
M09680B028
TOKH.INT.P.B.(8P), TESTED
P/N: 819223420
Illustrated Spare Parts Manual Page 30 of 45
Gasboy Part Description Orpak Part Description Picture
Current Loop Pump Interface Card
M09680B029
RS-232 VR/Pump Interface Card
M09680B016
RS-485 Pump Interface Card
(GASBOY 9800)
M09680B017
GILBARCO PUMP (PB-8P)­TEST
P/N: 819223431
RS232 INT. (PB-8P)-TEST
P/N: 819223451
RS485 P.B. 8P-TEST
P/N: 819223460
RS-422 Pump Interface Card
M09680B030
Nuovo Pignone interface card
M09680B031
RS422 (PB-8P)-TEST
P/N: 819223471
Nuovo Pignone
P/N: 819223485
Illustrated Spare Parts Manual Page 31 of 45
Gasboy Part Description Orpak Part Description Picture
Mechanical Pump Interface Card
M09680B019
Hub Switch
M09680B032
PCB card for Printer
M09680B033
ASSY,MPI+SUB P.B.(8P), TESTED
P/N: 819223490
KIT ASSY. 5 Port switch
P/N: 819225210
PCB ASSY.G2 PRINTER ENG,TESTED
P/N: 819519910
Printer - Islander and ICR PLUS
M09680B034
FTC Shock Absorber
M09680B035
PRINTER MODULE ASSY KIT, ORIC
P/N: 819238095
Shock Observer (for FTC installation KIT)
P/N: 814605600
Illustrated Spare Parts Manual Page 32 of 45
TBD
Gasboy Part Description Orpak Part Description Picture
Fuse
M09680B036
Interface Card Extractor ( from 8 Port CommVerter)
M09680B037
Power Supply: 100 - 240 VAC, 100W
M09680B041
HARNESS,P.S.FUSE CONN.24V
P/N: 819138051
Card Extractor (8P COMMVERTER)
P/N: 814423700
P.S 100-240VAC,100W
P/N: 811300164
Islander and ICR PLUS Top Cover
M09680B042
Paper Roll for Receipt Printer
M09680B043
Top Cover GB
P/N: 819238056
Paper Roll-57mm, D-150mm­Therm
P/N: 816600430
Illustrated Spare Parts Manual Page 33 of 45
Gasboy Part Description Orpak Part Description Picture
Paper Roll Pivot for Receipt Printer
M09680B108
FuelOpass HS-Tag
M09680B020
Relay Solid State 250V, 25A
M09680B044
SHAFT,PAPER ROLL­ISCU+AXIOHM
P/N: 814911100
FuelOpass HS
P/N: 819205541
Relay Solid State 250V, 25A
P/N: 813105950
Switch
M09680B045
Power Supply 110-240V/24V DC, 15W (Outdoor WGT)
M09680B046
Switch
P/N: 813104530
Power Supply 110-240V/24V DC, 15W (Outdoor WGT)
P/N: 811309400
Illustrated Spare Parts Manual Page 34 of 45
Gasboy Part Description Orpak Part Description Picture
WGT-CARDS SET­TESTED
M09680B047
Circuit Breaker
M09680B048
WGT-CARDS SET-TESTED
P/N: 819239310
Circuit Breaker
P/N: 813104450
Harness ANT LOOP­Wireless Programmer
M09680B049
Harness ANT LOOP-W. Programmer 110mm
M09680B091
Harness ANT LOOP-Wireless Programmer
P/N: 819120900
Harness ANT -W. Programmer 110 mm
P/N: 819120915
Illustrated Spare Parts Manual Page 35 of 45
Gasboy Part Description Orpak Part Description Picture
HARNESS D9P/D9S RS232 W.L.PROG
M09680B050
DataPass Harness
M09680B051
PCB Assy P.S -32V DC
(CFN PLUS)
M09680B052
HARNESS D9P/D9S RS232 W.L.PROG
P/N: 819120935
DataPass Harness
P/N: 819107670
PCB Assy P.S -32V DC (CFN PLUS)
P/N: 819538036
PCB Assy P.S -24V DC­Islander 8 Hoses
M09680B083
Heater Set
M09680B063
PCB ASSY P.S 24V DC
819538035
Heater Set
P/N: 819204152
Illustrated Spare Parts Manual Page 36 of 45
TBD
Gasboy Part Description Orpak Part Description Picture
Simulator for MPI-C
M09680B059
Extension KIT - 5 Port
M09680B060
Wireless Vehicle Programmer - Battery
M09680B067
Simulator for MPI-C
P/N: 819523691
Extension KIT - 5 Port
P/N: 819225250
Wireless Vehicle Programmer ­Battery P/N: 812520900
S/P NR, TYPE-1-2
M09680B115-M09680B114
S/P NR, Adaptors Type –H-T
M09680B071
S/P NR,TYPE-1-2 P/N: 819039098- 819039099
S/P NR, Adaptors Type –H-T P/N: 819039195
Illustrated Spare Parts Manual Page 37 of 45
TBD
TBD
Gasboy Part Description Orpak Part Description Picture
NR,Coil- Type 1
M09680B074
NR,Coil- Type 2/3
M09680B075
NR-H, Coil-70mm
M09680B076
NR,Coil- Type 1 P/N: 819339006
NR,Coil- Type 2/3
P/N: 819339005
NR-H, Coil-70mm
P/N: 819339110
NR-H/T, Coil-55mm, ZVA 32
M09680B077
NR-H/T, Coil-55mm, ZVA 32
PN: 819339120
Illustrated Spare Parts Manual Page 38 of 45
Gasboy Part Description Orpak Part Description Picture
NR-H/T, Coil-OPW 7H
M09680B078
NR-H ,Coil -Rectangular ­OPW 11B
M09680B079
NR-H/T, Coil-OPW 7H
PN: 819339122
NR-H ,Coil -Rectangular ­OPW 11B
PN: 819339130
NR-H, Coil-WIGGINS
M09680B080
NR-H, Coil-POSILOCK
M09680B081
NR-T, Coil-HUSKY 1+8
M09680B082
NR-H, Coil-WIGGINS
PN: 819339143
NR-H, Coil-POSILOCK
PN: 819339160
NR-T, Coil-HUSKY 1+8
PN: 819339124
Illustrated Spare Parts Manual Page 39 of 45
Gasboy Part Description Orpak Part Description Picture
Relay, 30A
M09680B085
PCB Assy P.S -24V DC- 8 Hoses
M09680B084
KIT, COIL HOLDER CLAMP (30pc)
M09680B086
Relay 30A (8 Hose)
P/N: 813111300
PCB ASSY , SSR (8 Hose)
P/N: 819538040
CLAMP-COIL HOLDER (30pc)
P/N: 815806030
TopKAT PLUS Tag - Orange Tag
M09680B087
Illustrated Spare Parts Manual Page 40 of 45
TAG,GILBARCO,ORANGE,I NIT
P/N: 819209871
Gasboy Part Description Orpak Part Description Picture
KIT ORCU ( Dongle + Holder)
M09680B089
Journal Printer
M09680B090
Nozzle Reader Plastic Cover (OPW 7H)
KIT ORCU,RS 232 Dongle + Holder
P/N: 819235520
Journal Printer P/N: 800919810
Plastic Cover OPW 7H
P/N: 814105200
PRINTER, MOBILE, FOR FTC 12 V
M09680B099
Illustrated Spare Parts Manual Page 41 of 45
MOBILE PRINTER (12V) For OrTC
P/N: 800921724
Gasboy Part Description Orpak Part Description Picture
Sensor Islander KIT
M09680B096
Assembly, Mechanical Printer Box TopKAT
M09680B107
Sensor Oric KIT
P/N: 819238500
Mechanical Assy Printer Box
P/N: 819020300
TBD
TBD
Islander Replacement Door With Printer
M09680B064
Islander Replacement Door Without Printer
M09680B065
CFN PLUS lock
M09680B097
Door Assy - ORIC with Printer
P/N: 819038090
Door Assy - ORIC without Printer
P/N: 819038091
Lock, Rittal Box (OrCU 3000)
P/N: 813102500
TBD
TBD
Illustrated Spare Parts Manual Page 42 of 45
Gasboy Part Description Orpak Part Description Picture
Upgrade Kit OrTC DC/DC Converter
M09680B093
Upgrade Kit FleetKey - OrIC With Printer
M09680B094
Upgrade Kit FleetKey - OrIC without Printer
M09680B095
Upgrade Kit OrTC DC/DC Converter
P/N: 819238094
UPGRADE NEW DATAKEY­ORIC-W/PRN
P/N: 819038093
UPGRADE NEW DATAKEY­ORIC-W/O-P
P/N: 819038094
Bracket, Metal 7H Round Bobbin
M09680B098
Bracket Metal 7H Round Bobbin
P/N: 819313380
Illustrated Spare Parts Manual Page 43 of 45
Gasboy Part Description Orpak Part Description Picture
Cold Weather Cable Kit
M09680B054
Cold Weather Cable Kit
P/N: 819138101
TBD
Panel, Decorative – OrPT
M09680B057
TBD
TBD
Islander - ICR Lock Kit
M09680B088
Decorative Panel
P/N: 814942525
Hose Clamp
P/N: 815806700
Lock KIT
P/N: 819038200
TBD
Illustrated Spare Parts Manual Page 44 of 45
10. Reference Manuals
For additional and complementary information regarding Gasboy's PLUS solution, refer to the following manuals.
Name GVR P/N Orpak P/N Rev.
Islander PLUS installation Manual Islander PLUS quotation guide CFN PLUS installation Manual Fuel Truck Controller installation Manual OrPT manual for home base 8 port CommVerter FHO & FMS Installation and setup manual
SiteOmat Station Controller Setup and maintenance Manual
SiteOmat Station Controller User’s Manual
MDE-4811 MDE-4812 MDE-4813 MDE-4814 MDE-4819 MDE-4820 MDE-4821
MDE-4817
MDE-4818
817438052 D1 817438053 B 817438033 B 817438029 C1 817422501 A3 817423401 F2 817423707 6.33 – E3
6.4 – F1
817427357 6.33 – F3
6.4 – G1
817423752 6.33 – E1
6.4 – F1
Fuel Point PLUS station Installation and Configuration manual
Fuel Point PLUS Vehicle Installation and Configuration Manual
Illustrated Spare Parts Manual
MDE-4851
MDE-4868
PT-1963
817439321 B
817407301 C2
817438000 A
Illustrated Spare Parts Manual Page 45 of 45
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
