CFN Series

FleetCor Dual Network Special Card Handler

Islander II/CFN II, V2.3J or higher

CFN 3, V3.3J or higher

Version 1.0.1

MDE-4310B

Computer Programs and Documentation

Federal Communications Commission (FCC) Warning

All Gasboy computer programs (including software on diskettes and within memory chips) and documentation are copyrighted by, and shall remain the property of, Gasboy. Such computer programs and documents may also contain trade secret information. The duplication, disclosure, modification, or unauthorized use of computer programs or documentation is strictly prohibited, unless otherwise licensed by Gasboy.

This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate this equipment.

Approvals

Gasboy, Greensboro, is an ISO 9001:2000 registered facility. Underwriters Laboratories (UL):

UL File# Products listed with UL

MH4314

MH6418

MH7404 MH10581 Key con t r o l u n i t , M o d e l G K E - B S e r i e s

All dispensers and self-contained pumping units

Power operated Transfer Pump Models 25, 25C, 26, 27, 28, 72, 72S, 72SP , 72X, 73 and 1820

Hand operated Transfer Pump Models 1230 Series, 1243 Series, 1520 and 1720 Series

Card reader terminals, Models 1000, 1000P Site controller, Model 2000S CFN Series Data entry terminals, Model TPK-900 Series Fuel Point Reader System

New York City Fire Department (NYFD):

NYFD C of A # Product

4823 9100A, 9140A, 9152A, 9153A,

4997 9822A, 9823A 5046 9100Q, 9140Q, 9152Q, 9153Q,

5087 8753K, 8853K, 9153K, 9853K

9800A, 9840A, 9850A, 9852A, 9853A, 9140

9800Q, 9840Q, 9852Q, 9853Q

(restricted to diesel and nonretail gasoline sales)

National Conference of Weights and Measures (NCWM) - Certificate of Compliance (CoC):

Gasboy pumps and dispensers are evaluated by NCWM under the National Type Evaluation Program (NTEP). NCWM has issued the following CoC:

CoC# Product Model # CoC# Product Model #

95-179A2 Dispenser

95-136A5 Dispenser 9800 Series 91-057A3 Controller

9100 Retail Series, 8700 Series, 9700 Series

91-019A2 Dispenser

9100 Commercial Series

1000 Series FMS, 2000S-CFN Series

California Air Resources Board (CARB):

Executive Order # Product

G-70-52-AM Balance Vapor Recovery G-70-150-AE VaporVac

Patents

Gasboy products are manufactured or sold under one or more of the following US patents:

Dispensers

5,257,720

Point of Sale/Back Office Equipment

D335,673

Trademarks

Non-registered trademarks

Atlas™ Consola™ Infinity™

Registered trademarks

ASTRA Fuel Point Gasboy Keytrol Slimline

Additional US and foreign patents pending.

Additional US and foreign trademarks pending.

Other brand or product names shown may be trademarks or registered trademarks of their respective holders.

This document is subject to change without notice. · For information regarding Gasboy Literature, call (336) 547-5661 E-mail: literature@gasboy.com · Internet: http://www.gasboy.com © 2007 GASBOY · All Rights Reserved

Table of Contents

1 – Introduction 1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Host-Site Communication Enhancements . . . . . . . . . . . . . . . . . . . . . . . . .1

Extended Host Transaction Authorization . . . . . . . . . . . . . . . . . . . . . . . . .1

Related Documents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Site Controller - Versions 2.2+, 3.3, and 3.4 and higher . . . . . . . . . . . . . .2

Credit and Debit Card Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Pump Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Remote Communications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Technical Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Card Encoding and Miscellaneous. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2 – T-Chek Cards 5

Prompts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Driver ID or ENTER Prompt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Refer 1=YES 2=NO Prompt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Odometer Prompt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Unit # Prompt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Transaction Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

3 – Gascard/CFN Dual Card 7

Prompts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Odometer Prompt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

PIN Prompt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Transaction Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Receipt Masking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

System Log Card Masking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Using Alter Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

4 – Configuration 9

SYS_PAR Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Working with FleetCor Network Help Desk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Index Index-1

MDE-4310B CFN Series FleetCor Dual Network Special Card Handler V1.0.1 · April 2007 Page i

Table of Contents

This page is intentionally left blank.

Page ii MDE-4310B CFN Series FleetCor Dual Network Special Card Handler V1.0.1 · April 2007

Overview Introduction

1 – Introduction

Overview

The FleetCor Dual Network Special Card Handler and some configuration changes allow a CFN II or CFN III to support the features listed below . This special card handler requires CFN II/Islander II or CFN III to operate. Gasboy Island Card Readers (ICRs) require Stargate version 4.2K or higher.

The following are the features of the FleetCor Dual Network Special Card Handler:

• Host-controlled Personal Identification Numbers (PINs)

• Floating PINs (multiple PINs assigned to the same card)

• Host-controlled product authorization

• Host-controlled quantity restrictions

• Host-controlled third party cards (Visa®, Mastercard®, T-Chek, Gascard/CFN dual card)

• Host-controlled messages to user

Note: After installing the software, the participant should contact the FleetCor Network help

desk. The help desk should verify that the site(s) is set up for custom PINs and T-Chek acceptance, the correct site number is used, and the site 99 password is set correctly, if needed. Also, the help desk should verify if the transactions are being processed properly and that product control is working.

When a card is swiped, the special handler identifies the card as a T-Chek or Gascard/CFN dual card that is handled by the host site protocol.

Host-Site Communication Enhancements

• Extended site transaction authorization request response.

• Configuration - New system configuration parameters will be added to enable extended site authorization requests.

• Vehicle field and issuer fields will be appended to the end of the request message if the site is configured to use extended authorization.

Extended Host Transaction Authorization

• Authorization code - An optional 2-digit authorization code field may be included in th e host transaction authorization message.

• If a card contains an authorization code, that code will be checked before the transaction is sent to the host for authorization. The authorization code returned from the host will be checked later, but it must pass the encoded authorization code check first. If the product authorization length is set to 0 in SYS_PAR the product will not be authorized before it is sent to the host.

• Price Level - An optional 2-digit price level field may be included in the host transaction authorization message.

MDE-4310B CFN Series FleetCor Dual Network Special Card Handler V1.0.1 · April 2007 Page 1

Introduction Related Documents

• This field is not implemented at this time and is not necessary for this application. The field must be filled with two non-numeric characters if the new card field is used.

• Product mask - An optional 26 hex character (104 bits) field may be included in the authorization message. The first bit will represent product number 1, the second bit represents product number 2 and so on, through product 99. 0 indicates that the corresponding product is not allowed, and 1 indicates it is allowed. Bits 100-104 are not used at this time.

• Alternate card image - An optional, variable length (0-37 digits) card data field with a ',' termination may be appended to the end of the host transaction authorization message.

• All optional data preceding the optional authorization field must be included.

Warranty

For information on warranty, refer to MDE-4255 Gasboy’s Warranty Policy Statement. If you have any warranty-related questions, contact Gasboy’s Warranty Department at its Greensboro location.

Page 4 MDE-4310B CFN Series FleetCor Dual Network Special Card Handler V1.0.1 · April 2007

Prompts T-Chek Cards

2 – T-Chek Cards

Prompts

Driver ID or ENTER Prompt

• Always prompted for.

• If no driver ID is required, press ENTER to proceed to the next prompt.

Refer 1=YES 2=NO Prompt

• Always prompted for.

• A valid response will be one digit within the 1-2 range.

Odometer Prompt

• Always prompted for.

• Response will be stored in the odometer field.

• A valid response will be eight digits or less.

Unit # Prompt

• Always prompted for.

• Response will be stored in the manual entry (aux.) field.

• This entry will not be printed on receipts.

• A valid response will be eight digits or less.

Transaction Format

• Track II card data occupies the card and account field.

• Unit number occupies the manual entry field.

MDE-4310B CFN Series FleetCor Dual Network Special Card Handler V1.0.1 · April 2007 Page 5

T-Chek Cards Transaction Format

This page is intentionally left blank.

Page 6 MDE-4310B CFN Series FleetCor Dual Network Special Card Handler V1.0.1 · April 2007

Prompts Gascard/CFN Dual Card

3 – Gascard/CFN Dual Card

Prompts

Odometer Prompt

• Always prompted for.

• Response will be stored in the odometer field.

• A valid response will be eight digits or less.

PIN Prompt

• Always prompted for.

• Response will be stored in the PIN field.

• A valid response will be six digits or less.

Transaction Format

• Track II card data occupies the card and account field.

• Odometer occupies the odometer field.

Receipt Masking

All cards handled as a credit tender, including FuelmanSM Plus and Gascard Access, will be masked with only the last four digits appearing on the receipt. With site version V034M and above, the CFN Dual Card receipt masking can be modified to meet the customer requirements better. It is possible to print any four contiguous numbers in the card data by configuring TRFMT and setting a value in sys_par on page 12. Refer to MDE-4316 CFN Series CFN III Configuration Manual for Windows NT masking of CFN Dual Cards and other local cards.

, for more information on specialized

MDE-4310B CFN Series FleetCor Dual Network Special Card Handler V1.0.1 · April 2007 Page 7

Gascard/CFN Dual Card System Log Card Masking

System Log Card Masking

The system log will mask all cards except lo cally authorized Club cards. All cards identified as a credit tender, including Fleet cards, will be fully masked, except for the first two and the last four digits of the account. Remotely authorized Club cards, such as the Dual card, will be masked according to the TRFMT configuration. An exception is for a Dual card that is processed locally for authorization in Fallback mode. A locally authorized Dual card will not be masked on the log.

Note: Account data will not be masked on the logger print-out if a type-29 CARD field is used.

Only type-2 account fields can be masked.

Refer to MDE-4316 CFN Series CFN III Configuration Manual for Windows NT for more information on configuring the transaction format for the system log.

Using Alter Utility

Refer to C35923 Point of Sale and Shift Change for using the Alter Utility to setup Shift and Day Reports.

To use Fuelman Plus and Gascard Access with CFN FleetCor on Shift and Day Reports, accept the payment types "Fuelman FltCor" and "Gascard FltCor". These two cards are set up as a Club tender with the FleetCor host system. Do not accept the card descriptions "Fuelman Plus" and "Gascard Access", as these cards are set up as a Credit tender and are utilized by other host systems.

Page 8 MDE-4310B CFN Series FleetCor Dual Network Special Card Handler V1.0.1 · April 2007

SYS_PAR Configuration Configuration

4 – Configuration

SYS_PAR Configuration

Parameter Name Parameter Value

Page 1: System Parameters

System ID 1220 PIN Key Call Gasboy Lockout Bit mapped, 7 digits, on disk, max card 9999999

Page 2: Club Card Format - Field Widths

Digits in System ID 4 Digits in Account # 19 Digits in Expiration Date 4 Digits in Limitation Code 1 Digits in Authorization Code* 0 Digits in Price Level 1 Digits in Restriction Code 1 Digits Used in PIN Calculation 9

Page 3: Club Card Formats - Offsets

Limitation Code Offset 0 Authorization Code Offset 1 Price Level Offset 3 Restriction Code Offset 4 PIN Calculation Offset 0 Extra Card Digit Offset 5 Club Bit-mapped Account Offset 0

Page 4: Reader Verification and Miscellany

Use remote verification** Club credit*** Check PIN None

Page 5: Console Verification

Use remote verification** Club credit*** Check PIN None

Page 8: Serial Port Configuration

Send Request to host handler Credit

Page 11: Transaction Miscellany

CFN PIN Unencrypted* Yes Send transactions to CFN host* Club

Note: Also specify credit only if a bank network is not being

used and T-Chek or other credit cards are being authorized through FleetCor Network.

MDE-4310B CFN Series FleetCor Dual Network Special Card Handler V1.0.1 · April 2007 Page 9

Configuration Working with FleetCor Network Help Desk

Parameter Name Parameter Value

Use new format for CFN auth host* Yes

Page 13: Miles-per-gallon package

Use aux info field for vehicle number* None

* These changes are required for FleetCor Dual Network features. ** Minimal requirements for FleetCor Dual Network only. Additional card types may be necessary if also

connecting to a bank network. Refer to the network manual.

*** If only the FleetCor handler is being used, this should be Club only.

Working with FleetCor Network Help Desk

After installing the software, the participant should contact the FleetCor Network help desk. The help desk should verify if the site(s) is set up for the following:

• Custom PINs and T-Chek acceptance

• The correct site number is used

• The site 99 password is set correctly (if needed)

Also, the help desk should verify if the transactions are being processed properly and that product control is working.

Page 10 MDE-4310B CFN Series FleetCor Dual Network Special Card Handler V1.0.1 · April 2007

Index

Driver ID 5

Island Card Reader 1

Odometer 7

prompt 5, 7

calculation offset 9 check 9 custom 1, 10 digits used in calculation 9 floating 1 host-controlled 1 key 9 prompt 7 unencrypted 9

Prompts

Driver ID 5 Odometer 5, 7 PIN 7 Refer 5 Unit # 5

Unit # 5 Unit number 5

Refer 5

Stargate 1

Third-party card

Gascard 2 Gascard/CFN dual card 1 Mastercard 1 Sinclair 3 T-Chek 1, 3, 5, 9, 10

Visa 1, 3 Track II card 5, 7 Transaction Format

Odometer 7

Track II card 5, 7

Unit number 5

MDE-4310B CFN Series FleetCor Dual Network Special Card Handler V1.0.1 · April 2007 Index-1

Index

This page is intentionally left blank.

Index-2 MDE-4310B CFN Series FleetCor Dual Network Special Card Handler V1.0.1 · April 2007

Amoco® is a registered trademark of Amoco Oil Company. BuypassSM is a service mark of B uyp ass Inco Corporation. Citgo® is a register ed trademark of Citgo Petroleum Corporation. Comdata

is a registered trademark of FinaMark, Inc. FuelmanSM is a service mark of FleetCor Te chnologies, Inc. Gilbarco® is a registered trademark of

Fina Gilbarco Inc. MasterCard Paymentech, Inc. Sinclair

is a registered trademark of MasterCard International Incorporated. Paymentech® is a registered trademark of

is a register ed trademark of Sinclair Oil Corporation. Unitec® is a register ed trademark of Unitec Inc. VISA® is a registered

trademark of V isa International Service Association. Vi saNet

™

is a trademark of Comdata Network, Inc. Datacard® is a registered trademark of Datacard Corporation.

is a service mark of Visa International Service Association. Wayne® is a registered

trademark of Dresser Industries.

© 2007 GASBOY 7300 West Friendly Avenue · Post Office Box 22087 Greensboro, North Carolina 27420 Phone 1-800-444-5529 · http://www.gasboy.com · Printed in the U.S.A. MDE-4310B CFN Series FleetCor Dual Network Special Card Handler V1.0.1 · April 2007

Gasboy FleetCor Dual Special Card Handler User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

Overview

Host-Site Communication Enhancements

Extended Host Transaction Authorization

Related Documents

Site Controller - Versions 2.2+, 3.3, and 3.4 and higher

Credit and Debit Card Networks

Pump Interface

Remote Communications

Technical Publications

Card Encoding and Miscellaneous

Warranty

Prompts

Driver ID or ENTER Prompt

Refer 1=YES 2=NO Prompt

Odometer Prompt

Unit # Prompt

Transaction Format

Prompts

Odometer Prompt

PIN Prompt

Transaction Format

Receipt Masking

System Log Card Masking

Using Alter Utility

SYS_PAR Configuration

Working with FleetCor Network Help Desk

Index
