Garland ECGM-36S Parts List

ELECTRIC CHAIN GRIDDLE

ECGM SERIES

ECGM-24S, ECGM-36S, ECGM-48S, ECGM-60S

Toll Free Phone, (US & Canada): [phone]

Toll Free Fax, (US & Canada): [phone]

http://www.garland-group.com

FORM # Electric Chain Griddle M (Rev. 3)

Page 2 FORM # Electric Chain Griddle M (Rev. 3)

ELECTRIC CHAIN GRIDDLE

ECGM SERIES

ECGM-24S, ECGM-36S, ECGM-48S, ECGM-60S

Contents:

Electric Chain Griddle..............................................................................Page 4

New Swivel Caster Information.....................................................................Page 8

Revision History ...................................................................................Page 9

Page 3FORM # Electric Chain Griddle M (Rev. 3)

ELECTRIC CHAIN GRIDDLE

MODELS: ECGM-24S, -36S, -48S, -60S

SK3892

Page 4 FORM # Electric Chain Griddle M (Rev. 3)

ITEM

PART

NUMBER

GARLAND PARTS IDENTIFICATION

Electric Chain Griddle

Models: ECGM-24S, ECGM-36S, ECGM-48S, ECGM-60S

MODEL DATE

QUANTITY

DESCRIPTION

UP TO FROM

ECGM-24S

ECGM-36S

ECGM-48S

ECGM-60S

4517785 Griddle Assy Reg. 1

1

2

3

4

5 3061800 Element Clamp - Front And Back 4 6 8 10
6 3061900 Element Clamp - Center 2 3 4 5
7 3062000 Element Cover 2 3 4 5
8 3075400 Element Pan Filler 1 1 2 3

9

10 2423600 Bayonet Adapter 2 3 4 5
11 2423501 J Thermocouple 2 3 4 5 C
12 3075800 Conduit Heat Shield 1 1 1 1
13 3075600 Conduit Rear Bracket 1 1 1 1
14 3075900 EMT Connector 1 1/2” 2 2 2 2
15 3075500 Supply Conduit 1 1 1 1

16

17

18 2513898 Side Panel Assy. 2 2 2 2
19 2513798 Body End Assy. - Left 1 1 1 1
20 2513799 Body End Assy. - Right 1 1 1 1

21

22 3076900 Bottom Side Filler 2 2 2 2

23

24

25

* NOT ILLUSTRATED

RECOMMENDED STOCK PARTS

4517786 Griddle Assy Reg. 1
4517787 Griddle Assy Reg. 1
4517788 Griddle Assy Reg. 1
4517834 Main Back 1
3093900 Main Back 1
3093901 Main Back 1
4517835 Main Back 1

3065700 Element - Front And Back 208V 4 6 8 10 C
3065701 Element - Front And Back 240V C

3065600 Element - Center 208V 2 3 4 5
3065601 Element - Center 240V

3062100 Element Pan Side 2 2 2
3062101 Element Pan Side 2

4517836 Lower Back Panel 24” 1
3102801 Lower Back Panel 36” 1
3102800 Lower Back Panel 48” 1
4517837 Lower Back Panel 60” 1
3102900 Wire Mount Bracket 1 1 1
4518125 Wire Mount Bracket 1

3063100 Leg Mount - Stand Model 4 4 4 4
3063101 Leg Mount - Table Model 4 4 4 4

3075398 Bottom Cover Assy. 2
3075397 Bottom Cover Assy. 2
3075396 Bottom Cover Assy. 2
3075399 Bottom Cover Assy 1
3073799 Leg Assy. Right - Casters 2 2 2 2
3073798 Leg Assy. Right - Foot 2 2 2 2
3073899 Leg Assy. Left - Casters 2 2 2 2
3073898 Leg Assy. Left - Foot 2 2 2 2

CRITICAL

Page 5FORM # Electric Chain Griddle M (Rev. 3)

ITEM

PART

NUMBER

GARLAND PARTS IDENTIFICATION

Electric Chain Griddle

Models: ECGM-24S, ECGM-36S, ECGM-48S, ECGM-60S

MODEL DATE

QUANTITY

DESCRIPTION

UP TO FROM

ECGM-24S

ECGM-36S

ECGM-48S

ECGM-60S

3065199 Stand Shelf Assy. 1

26

27

28

29 2468800 Grease Drawer Support - Left 1 1 2 2
30 2468801 Grease Drawer Support - Right 1 1 1 1
31 2468799 Side Grease Drawer 2 2 2 2
32 3074800 Inner Heat Shield - Left 1 1 1 1

33

34

35

36 01499-1 Ground Terminal 1 1

37

38 2585300 Hinge 2 2 2 2

39

40 G01296-3 Pilot Light Green 1 1 1 1 C
41 2667200 Pilot Light Amber 2 3 4 5 C
42 2423301 Main Power Switch 1 1 1 1 C
43 2423300 Switch 2 3 4 5 C
44 2432100 Handle - Knob Guard 4 6 8 10

45

46 2432001 Electronic Thermostat 2 3 4 5 C
47 4515805 Dial Scale Deg 450 (Insert 150 To 450) 2 3 4 5
48 4516733 Dial W/Pointer 1.71 In Dia 2 3 4 5
49 4517828 Handle End 2 2 2 2

50

* NOT ILLUSTRATED

RECOMMENDED STOCK PARTS

3065198 Stand Shelf Assy. 1
3065197 Stand Shelf Assy. 1
3065196 Stand Shelf Assy. 1
2442100 Caster - Rear - NLA 2 2 2 2 25-Oct-04
4518093 Swivel Caster - See Page 8 2 2 2 2 25-Oct-04
2442000 Caster - Front _ NLA 2 2 2 2 25-Oct-04

45`8094 Swivel Caster W/Brake - See Page 8 2 2 2 2 25-Oct-04

3076100 Inner Heat Shield - Right 1
3076101 Inner Heat Shield - Right 1
3076102 Inner Heat Shield - Right 1
3076103 Inner Heat Shield - Right 1
3065400 Bottom Mtg. Brkt. 1
3065401 Bottom Mtg. Brkt. 1
3065402 Bottom Mtg. Brkt. 1
3065404 Bottom Mtg. Brkt. 1
3074200 Component Mtg. Brkt. 1
3074300 Component Mtg. Brkt. 1
3074400 Component Mtg. Brkt. 1
3074500 Component Mtg. Brkt. 1

2147300 Terminal Block 1 1
2694801 Terminal Block 1 1

3061100 Front Panel 1
3061200 Front Panel 1
3061300 Front Panel 1
3061400 Front Panel 1

3062500 Circuit Breaker Cover 1 1
3062501 Circuit Breaker Cover 1

4517824 Handle Assembly 1
4517825 Handle Assembly 1
4517826 Handle Assembly 1
4517827 Handle Assembly 1

CRITICAL

Page 6 FORM # Electric Chain Griddle M (Rev. 3)

ITEM

PART

NUMBER

GARLAND PARTS IDENTIFICATION

Electric Chain Griddle

Models: ECGM-24S, ECGM-36S, ECGM-48S, ECGM-60S

MODEL DATE

QUANTITY

DESCRIPTION

UP TO FROM

ECGM-24S

ECGM-36S

ECGM-48S

ECGM-60S

3082399 Cutting Board Tray 1

51

52

53

54

55 1636000 24V Transformer 1 1 1 1 C
56 3062700 Elec. Comp. Mtg. Brkt. 1 1 2 2
57 3077000 Elec Comp. Mtg. Brkt. 1 1
58 3060300 Relay Bracket 2 3 4 5
59 3060200 Relay 4 Pole 2 3 4 5 C

60

61 3060400 Relay 1 Pole 4 6 8 10 C
62 3061600 C.B. Support 2 2 2

63

64

65 3073603 Leg - Table Model 4 4 4 4
66 G02954-1 Bullet Foot Insert - Table Model 4 4 4 4

67

68 3094301 Skirt Side Left 1 1 1 1
69 3094300 Skirt Side Right 1 1 1 1

70 4516847 Dial & Insert Kit - Includes 47 & 48

* NOT ILLUSTRATED

RECOMMENDED STOCK PARTS

3082398 Cutting Board Tray 1
3082397 Cutting Board Tray 1
3082393 Cutting Board Tray 1
4512093 Cutting Board 24” 1 2 1
4517939 Cutting Board 36” 1 1
4515980 Guard Mount Assy 24” 1
4515981 Guard Mount Assy 36” 1
4515982 Guard Mount Assy 48” 1
4515983 Guard Mount Assy 60” 1
4515777 Control Guard 24” 1
4515778 Control Guard 36” 1
4515779 Control Guard 48” 1
4515780 Control Guard 60” 1

3062600 Din Rail 5.5” 1 1 2 2
3062601 Din Rail 3.375” 1 1

3060700 C.B. Box Cover 1 1
3078600 C.B. Box Cover 1

3060100 Circuit Breaker 3 Phase 3 4 5 C
2688801 Circuit Breaker Single Phase 3 4 5 C

4517839 Skirt Front And Rear - Table Model 2
3094100 Skirt Front And Rear - Table Model 2
3094101 Skirt Front And Rear - Table Model 2
4517840 Skirt Front And Rear - Table Model 2

Kit Available

CRITICAL

Page 7FORM # Electric Chain Griddle M (Rev. 3)

Please note that there are dierences between the old and new casters, The new casters are .312"
(5/16) shorter overall so in this case, would not be interchangeable. When replacing the old caster
Garland highly recommends replacing all remaining casters with the new caster. both new and old
casters use (5") diameter wheels.

First unit manufactured with the new casters:
Model: CG-72R-0004
Serial Number: 0410100108836
Implementation Date: October 25/2004

OLD STYLE (NLA)

2442100 Swivel Caster

2442000 Swivel Caster w/Brake

NEW STYLE

4518093 Swivel Caster

4518094 Swivel Caster W/Brake

Swivel Casters.dwg

NEW STYLE SWIVEL CASTER

INFORMATION

Page 8 FORM # Electric Chain Griddle M (Rev. 3)

GARLAND PARTS IDENTIFICATION

Revision History

REV. # PAGE # ITEM # NOTE DATE

Electric Chain Griddle Parts List Released Apr 7/04

1

2

3

6

8 New Swivel Caster Information
6 46 & 47 New Description
7 70 New Part Number
4 Item Number 70 Added

5 ,6, 7 Critical Column Added

27 New Part Number 4518094

Dec 03/0428 New Part Number 4518093

Feb 09/05

Feb 02/09
