Gardena 9824 Operators manual

EasyCut Li-18/23
Art. 9824

DE Betriebsanleitung

Accu-Turbotrimmer

EN Operating Instructions

Accu Turbotrimmer

FR Mode d’emploi

Coupe-bordures à batterie

NL Gebruiksaanwijzing

Accu-Turbotrimmer

SV Bruksanvisning

Accu-Turbotrimmer

DA Brugsanvisning

Accu-turbotrimmer

FI Käyttöohje

Accu-turbotrimmeri

NO Bruksanvisning

Batteri-turbotrimmer

IT Istruzioni per l’uso

Turbotrimmer a batteria

ES Instrucciones de empleo

Recortabordes con accu

PT Manual de instruções

Aparador de relva Accu-Turbotrimmer

PL Instrukcja obsługi

Podkaszarka akumulatorowa

HU Használati utasítás

Akkumilátoros damilos

fűszegélynyíró

CS Návod k obsluze

Akumulátorový turbotrimmer

SK Návod na obsluhu

Akumulátorový turbotrimmer

EL Οδηγίες χρήσης

Επαναφορτιζόμενο κουρευτικό

πετονιάς

RU Инструкция по эксплуатации

Аккумуляторный турботриммер

SL Navodilo za uporabo

Akumulatorski turbo obrezovalnik

HR Upute za uporabu

Baterijski turbo trimer za travu

SR / Uputstvo za rad
BS Baterijska turbo trimer-kosilica

UK Інструкція з експлуатації

Акумуляторний турботример

RO Instrucţiuni de utilizare

Turbotrimmer cu baterie

TR Kullanma Kılavuzu

Akülü Turbo Tırpan

BG Инструкция за експлоатация

Акумулаторен Турботример

SQ Manual përdorimi

Kositëse bari turbo me bateri

ET Kasutusjuhend

Akuga turbotrimmer

LT Eksploatavimo instrukcija

Akumuliatorinė turbo žoliapjovė

LV Lietošanas instrukcija

Turbotrimmeris ar akumulatoru

HR SL RU EL SK CS HU PL PT ES IT NO FI DA SV NL FR EN DE

BS

SR /

LV LT ET SQ BG TR RO UK

GARDENA EasyCut Li-18/23

EN

1. Safety Instructions ...................14

2. Assembly ..........................16

3. Initial Operation ......................17

4. Operation ..........................18

5. Storage ............................ 20

6. Maintenance ........................ 20

7. Troubleshooting .....................21

8. Available accessories ................. 23

9. Technical Data ......................23

10. Service / Warranty ...................24

Original instructions.

Never operate the product when you are tired, ill or
under the influence of alcohol, drugs or medicine.

This product may be used
under supervision, or if instruc-

tion regarding the safe use of
the product has been provided and the
resulting dangers have been under­stood, by children aged 8 and above,

1. Safety Instructions

v Please read the notes on safety on the Trimmer.

IMPORTANT!
Read the operator’s manual carefully before
use and keep for future reference.

Symbols on the product:

CAUTION!
v Please read the operating

DANGER!
v Keep your Turbotrimmer

DANGER!

v Keep bystanders away.

Switch off!

v Warning: The cutting line continues to rotate

after the machine has been switched off.

instructions before using
this tool.

away from water and rain!

360°

Risk of injury to other
people!

Remove battery pack before
adjusting or cleaning.

as well as by persons with physical,
sensory or mental disabilities or a lack
of experience and knowledge. Children
must not be allowed to play with the
product. Cleaning and user mainte­nance must not be performed by chil­dren without supervision. The use of
this product by young people under the
age of 16 is not recommended.

Intended use:

The GARDENA Turbotrimmer is designed for
trimming and cutting areas of grass and lawns in
private house and hobby gardens.

The Turbotrimmer must not be used in public
facilities, parks, sports grounds, next to roads or
in agriculture or forestry.

DANGER! For safety reasons, the GARDENA
Turbotrimmer must not be used for hedge
trimming or for shredding for composting.

DANGER! Eye and ear injuries!
v Wear eye and hearing

protection!

Check your Trimmer before each use

v Always visually inspect your Trimmer before

each use.

v Check that the ventilation slots are not

obstructed in any way.

Do not use the trimmer if it is damaged or if its
safety devices (pressure switch, safety cover)
and / or the filament cassette are damaged or
worn.

v Never bypass the safety devices.
v Inspect the area to be cut before you begin

work. Remove any foreign objects and look
out for foreign objects (such as stones,
pieces of wood, strings and wires) while you
are working.

v However, should you encounter an obstacle

during work, take the trimmer out of operation
and remove the battery. Remove the obstacle;
inspect the trimmer for potential damage and
arrange for it to be repaired if necessary.

14

Use / responsibility

DANGER! Tool does not stop

immediately when turned off!

v Keep hands and feet away

from the work area until the
cutting filament is stationary!

The Trimmer can cause serious injuries.
v Use the Trimmer only for the purpose

specified in these operating instructions.

You are responsible for safety in the work area
(2 metre radius).

v Ensure that no other people (especially

children) and animals are in close proximity
to the danger area (15 metre radius).

Familiarise yourself with the surroundings

v Familiarise yourself with the surroundings and

look out for possible dangers which you may
not hear due to machine noise.

v Never use the Trimmer when there is a risk of

thunderstorms, when it is raining or in damp,
wet areas.

v Do not use the trimmer in the immediate

vicinity of or in water (swimming pool, streams
or garden ponds).

Battery safety

v Please observe the safety instructions on the

battery.

EN

Warning! When wearing hearing protec­tion,and due to the noise produced by the
unit, the operator may not notice persons
approaching.

Remove the battery after use and regularly
inspect the trimmer, especially the filament
cassette, for damage and arrange appropriate
repair if necessary.

v Always wear an eye shield or safety goggles!
v Wear sturdy shoes and long trousers to

protect your legs. Keep your fingers and feet
away from the cutting filament – above all
when starting work.

v Always ensure that you have a secure

foothold whilst working and that you keep
your balance at all times.

Take extra care when walking backwards.
You may stumble!

v Only work in the daylight or when visibility

is good.

v Do not overreach. In order to prevent

overtiredness, alternate working positions
and ensure suf ficient breaks are taken.
This enables better control of the power tool
in unexpected situations.

Interrupting work

v Never leave the Trimmer unattended where

you are working.

v When stopping work, remove the battery and

store the trimmer in a safe place.

v If you stop work in order to move to another

work area, the trimmer must be switched
off, wait until the work tool is stationary and
remove the battery. Always carry the trimmer
at the handle.

FIRE RISK! Short-circuit!

v Do not bridge the contacts of the battery

with metal components.

FIRE RISK!

The battery to be charged must be placed
on a non-flammable, heat resistant and non­conductive surface while charging.

Keep corrosive, flammable and easily com­bustible objects clear of the battery charger
and the battery. Do not cover the battery
charger and the battery while charging.

Unplug the battery charger immediately in the
event of smoke formation or fire.

Only use the original GARDENA Battery
Charger for charging. The use of other
battery chargers may damage the batteries
irreparably and even cause a fire.

RISK OF EXPLOSION!

Protect battery from heat and fire.
Do not leave on radiators or expose to
strong sunshine for long periods.

Do not use the battery charger

outdoors.

v Protect the the battery charger from

damp or wet areas.

Only use the battery in ambient temperatures
of between 0 °C and 40 °C.

A non-functioning battery must be disposed
of correctly. It may not be sent via post.
For further details, please contact your local
disposal companies.

15

The battery charger should be checked regularly

EN

for signs of damage or ageing (brittleness) and
may only be used if it is in perfect condition.

The charger unit provided may only be used to
charge the rechargeable batteries supplied with
the Turbotrimmer.

Non-rechargeable batteries must not be charged
with this battery charger (danger of fire).

The Trimmer must not be operated during
charging.

Only charge battery between 0 – 45 °C.
After heavy duty service allow battery to cool
down first.

Only the original GARDENA battery may be
used.

2. Assembly

Storage

The trimmer must not be stored over 35 °C or
under direct exposure to sunlight.

Never store the Trimmer with attached battery,
this prevents misuse and accidents.

Do not store the trimmer in places with static
electricity.

Warning! This unit makes an electromagnetic
field while it operates. This field may under some
con ditions interfere with active or passive medi­cal implants. To decrease the risk of conditions
that can possibly injure or kill, we recommend
persons with medical implants to speak with
their physician and the medical implant manu­facturer before operating.

Warning! Keep toddlers away when you assem­ble the unit. Small parts can be easily swal­lowed. There is also a risk that the polybag can
suffocate toddlers.

Assembling the trimmer:

ß

o

R

h

j

g

t

1

2

3

ö

16

0

l

CAUTION!
The handle may only be assembled if the cable

between the handle and the shaft is in a perfect
condition. The handle may not be assembled if
the cable is damaged. Contact GARDENA customer
service in such a case.

CAUTION!

The trimmer may only be operated provided that the

protective cover

1. Carefully remove the handle
the packaging. In doing so, no stress may be exerted upon the
cable.

2. Ensure that the threaded collar
(padlock symbol open).

3. Slide the handle
In doing so, the cable may not become twisted or jammed.

4. By pulling on the handle
to the shaft 2. Once assembled, the handle 1 and shaft 2
cannot be separated.

5. Close the threaded collar

6. Pull the lock
both of the snap-fits g belonging to the additional handle h
and, with the grooves
holder j.

7. From the front, push the plant guard
groove 0 of the trimmer head 3. In doing so, ensure that
the impeller k can rotate freely (i.e. insert the bow with
the kink pointing upwards).

belonging to the additional handle h, push in

o

is assembled.

q

together with the shaft 2 from

1

is in an open position

t

onto the shaft 2 until it audibly engages.

1

, check whether it is firmly fixed

1

(padlock symbol closed).

t

R

pointing forwards, snap them into the

ß

into the upper

ö

A2

654

ß

A1

ß

q

3. Initial Operation

8. Place the protective cover q on top of the trimmer head 3.

9. Turn the protective cover
trimmer head entirely (the two arrows
from each other).

10. Rotate the protective cover
engages.

until it can be pushed over the

q

q

A1

A2

,

are directly across

ß

ß

anti-clockwise until it audibly

EN

Charging the battery:

5

7

WARNING!
Overvoltage damages batteries and the battery

charger.

v Ensure the correct mains voltage.

Before using for the first time, the battery must be fully charged.
Charging time (for uncharged battery) see 9. Technical Data.

The lithium-ion battery can be charged in any state of charge,
and the charging process can be interrupted at any time without
harming the battery (no memory effect).

1. Depress both locking buttons

the battery holder 6 on the handle.

2. Plug the plug of the charger cable

3. Plug battery charger

When the charging control lamp
green the battery is being charged.

When the charging control lamp
green the battery is completely charged

(For charging time, see 9. Technical Data.)

into a mains socket.

8

and remove the battery 5 from

4

into the battery 5.

7

at the charger flashes

9

at the charger illuminates

9

9

8

17

ßBßL1ßL2ßL3ß

EN

2,6Ah

Battery charging status indicator during charging:

100 % charged
66 – 99 % charged
33 – 65 % charged

0 – 32 % charged

Check the charge status regularly while charging.

4. Once completely charged, disconnect the battery

battery charger 8. Disconnect the battery 5 from the battery
charger 8 first, then unplug the battery charger 8.

5. Slide the battery

it audibly engages.

Avoid exhaustive discharge:

If the battery is empty, the full discharge protection automatically
switches off the device to prevent the battery from discharging
fully. To prevent the fully charged battery from self-discharging
via the unplugged charger, it should be disconnected from the

W

charger after charging. If the battery was stored for more than
1 year, it must be fully recharged.
If the battery was fully discharged, the charging indicator lamp
will flash rapidly at the start of charging (twice per second).
If the charging indicator lamp 9 still flashes rapidly after
10 minutes, a fault has occurred (see 7. Troubleshooting).
If the error-LED
(see 7. Troubleshooting). In case of a completely empty battery
it will take approx. 20 minutes until the LEDs on the battery
will indicate charging. But the charging process is indicated by
the flashing LED 9 on the charger.

onto the battery holder 6 on the handle until

5

W

on the battery flashes, a fault has occurred

ß

and € illuminate (for 60 sec.)

«, ∑

and ∑ illuminate, € flashes

«

illuminates, ∑ flashes

«

flashes

«

from the

5

9

Battery charging status indicator during operation:

v Press button
66 – 99 % charged
33 – 65 % charged
10 – 32 % charged
0 – 10 % charged

B

on the battery.

ß

«, ∑

and ∑ illuminate

«

illuminates

«

flashes

«

and € illuminate

4. Operation

DANGER! Risk of injury if the Turbotrimmer does not switch off when

18

you release the start button.
v Never bypass the safety devices or switches (e.g. by tying

the safety lock to the handle).

Risk of injury!
v Remove the battery prior to each adjustment of the

working position, to the shaft length, additional handle
or plant guard!

Setting the working position:

h

z

Working position 1:

Standard trimming

Working position 1:

For standard trimming.

Working position 2:

1. Press the foot pedal

desired working position.

2. Release the foot pedal

CAUTION! Avoid contact between the ground and the trimmer
head in working position 1 + 2.

z

Working position 2:

Trimming beneath obstacles

and lower the shaft downwards into the

and allow the shaft to engage.

z

EN

Setting the trimmer to body
height:

o

Adjusting the plant guard:

t

1

Setting the shaft length:

v Loosen the clamping sleeve

desired shaft length and re-tighten the threaded collar t.

The clamping sleeve
prevent the shaft from being moved.

Setting the additional handle:

v Pull the lock

set the additional handle h to the desired incline and
release the lock o.

If the trimmer is correctly set to the body height, the posture
is upright and the trimmer head in working position 1 is tilted
forwards slightly.

v Hold the trimmer by the handle

such a manner that the trimmer head is tilted forwards slightly.

o

must be fastened firmly enough to

t

belonging to the additional handle h,

, extend the handle 1 to the

t

and additional handle h in

1

ö

ö

Working position Parking position
v Turn plant guard

until it locks into place.

through 90° into the required position

ö

19

Starting the trimmer:

p

EN

a

Switching the trimmer on:

1. Press and hold the safety lock

button a on the handle.

2. Release the safety lock

Switching the trimmer off:

v Release the start button

again.

p

on the handle.

a

and then press the start

p

Lengthening of the filament
(automatic):

A clean cut is achieved only with the maximum filament
length.

The cutting filament U is lengthened automatically when the
filament cassette comes to a standstill after switch off.

V

As the filament can only be lengthened in small increments, it can

U

be necessary in some cases to repeat the switch-off / switch-on
action several times (up to 6 times). Important is that the filament
cassette comes to a complete standstill each time.

The cutting filament has been sufficiently lengthened when,
after switch-on, it audibly strikes the filament limiter

The filament cassette has to be replaced (GARDENA Replacement
Filament Cassette Art. No. 5306) when the cutting filament has
been used up.

5. Storage

To put into storage: The product must be stored away from children.

1. Charge battery.

2. Store your Turbotrimmer in a dry place where it is protected

from frost.

Recommendation:

The trimmer can be suspended by the handle.
The trimmer head is not placed upon any unnecessary
strain if stored in a suspended manner.

Disposal:

(in accordance with
RL2012/19/EC)

Disposal of the
battery:

The product must not be disposed of to normal household waste.
It must be disposed of in line with local environmental regulations.

v Important! Dispose of the product through or via your municipal

recycling collection centre.

The GARDENA battery contains lithium-ion cells that should not
be disposed of with normal household waste at the end of its life.

U

.

V

6. Maintenance

DANGER!

20

Li-ion

Important!

Dispose of the batteries through or via your municipal recycling
collection centre.

1. Discharge lithium-ion batteries completely.

2. Dispose of lithium-ion batteries properly.

There is a risk of injury from the cutting filament!
v Remove the battery immediately before maintenance!

Risk of injury and risk of damage to property!

e

v Never clean the trimmer with water or with a water jet

(in particular a high-pressure water jet).

EN

Cleaning the
trimmer:

s

Replacing the filament
cassette:

W

Y

The ventilation slots must always be free of dirt.

s

v Clean all moving parts after each use, and especially remove

any grass and dirt from the cover

and ventilation slots s.

q

q

Risk of injury!
v Never use metallic cutting elements or replacement

Only use original GARDENA Filament Cassettes. You can
order Replacement Filament Cassettes from your GARDENA
dealer or directly from the GARDENA Customer Service.

• Filament Cassette for GARDENA Turbotrimmer Art. 5306

1. Remove the battery.

2. Release the cassette cover

W

3. Remove the filament cassette

4. Remove any dirt.

5. Feed the cutting filament

X

6. Insert the filament cassette

7. Fit the cassette cover

U

v If the cassette cover

parts and accessories not provided by GARDENA.

by pressing both locking clips

and remove the cover.

through the hole X and pull out about 10 cm.

Do not trap the cutting filament U when you do this.

click into place.

filament cassette Y to and fro, until the filament cassette Y
is completely in the filament cassette holder.

e

.

Y

of the new filament cassette

U

.

Y

so that you hear both locking clips W

e

cannot be touched down, turn the

e

W

Y

7. Troubleshooting

Risk of injury! Risk of injury from the cutting filament!

Pulling the cutting filament
manually out of the filament
cassette:

37

Uz

v Remove the battery immediately in the event of faults!

A cutting filament that is too short or no longer extends
automatically when the trimmer is turned on can be pulled out
manually.

1. Remove the battery.

2. Hold the automatic slide feed

at the same time pull on the cutting filament U.

37

down with your hand and

ß

21

Releasing a cutting filament

EN

that has gone into the
cassette or which has fused:

Y

37

z

Problem Possible Cause Remedy
The trimmer no longer cuts Filament cassette empty. v Replace the filament cas sette

The filament cannot be
extended

The trimmer does not start Battery is flat. v Charge battery

The filament consumes
quickly

The trimmer stops.
Error-LED

Charging control lamp
the charger does not illuminate

Charging control lamp
the charger flashes red

W

flashes

ß

9

9

on

on

If the cutting filament has disappeared into the filament cassette
or if the automatic filament extension still doesn’t work after
pulling the cutting filament U it may be fused together in the
filament cassette Y.

1. Remove the battery.

2. Remove the filament cassette

6. Maintenance “Replacing the filament cassette”.

3. Unwind the cutting filament

and the cutting filament U and wind the cutting filament U onto

X

the cassette Y once more.

4. Clean the automatic mechanism lever

The automatic lever must move freely.

5. Insert the filament cassette again as described under

6. Maintenance “Replacing the filament cassette”.

as described in

Y

, clean the filament cassette Y

U

37

.

ß

U

(see 6. Maintenance

“Replac ing the filament
cassette” ).

Cutting filament too short
or the automatic filament
extension does not work.

Cutting filament inside the
cassette or fused.

The filament became too dry
and brittle (e. g. over the winter).

Battery not pushed onto the
handle properly.

Motor blockage. v Unblock and restart the device.
Frequent contact between the

filament and hard objects.
Battery overload.

High temperature. The allowed
operation temperature was
exceded.

Battery charger or charging
cable not plugged in properly.

Charging error. v Unplug charger and plug

v Pull the filament out of the

cassette manually.

v Release filament that has

disappeared into the cassette
or fused together.

v Place the filament cassette in

lukewarm water for approx.
10 hours.

(see 3. Initial Operation).

v Push battery onto the handle

and make sure that the locking
buttons snaps in correctly.

v Avoid contact between the

filament and hard objects.

v Wait for 10 sec. Press button

on the battery and restart.

v Leave battery to cool for

approx. 15 min. Press button
on the battery and restart.

v Plug in battery charger and

charging cable properly.

in again.

B

ß

B

ß

22

Problem Possible Cause Remedy
The trimmer stops.

Error-LED

W

flashes

ß

The battery can no longer
be charged

Battery error /
battery defective.

v Press button

battery and restart.

Battery is defective. v Replace the battery

(Art. No. 9839).

Only an original GARDENA BLi-18 Replaceable Battery (Art. No. 9839) may be used.
This can be obtained from your GARDENA dealer or directly from GARDENA Service.

For any other malfunctions please contact the GARDENA service department.
Repairs must only be done by GARDENA service departments or specialist dealers
approved by GARDENA.

8. Available accessories

B

on the

ß

EN

GARDENA
Replacement Battery BLi-18

GARDENA Battery Charger
18 V

Battery for additional duration or
for replacement.

Charger to charge the GARDENA Batteries
BLi-18.

GARDENA Filament Cassette
for Turbotrimmer

9. Technical Data

Turbotrimmer EasyCut Li-18/23

Filament thickness 1.5 mm
Cutting width 230 mm
Filament supply 10 m
Filament feed Fully automatic
Rpm of filament cassette approx. 8500 rpm
Weight including battery approx. 2.8 kg
Workplace-related

emission values L
Uncertainty k

Noise level L

Uncertainty k
Hand / arm vibration a

Uncertainty k

WA

pa

WA

a

1)

pa

2)

1)

vhw

Battery lithium ion (18 V)

Battery capacity 2.6 Ah
Battery charging time approx. 3.5 h 80 % / approx. 5 h 100 %
Idling time *

(Art. No. 9824)

68 dB (A)
3 dB (A)

measured 86 dB (A) /
guaranteed 90 dB (A)

4.3 dB (A)

2

3.5 m/s

1.5 m/s²

approx. 60 min. (with full battery)

Art. No. 9839

Art. No. 8833

Art. No. 5306

23

Battery charger

Mains voltage 230 V / 50 – 60 Hz
Max. output current 600 mA
Output voltage 18 V (DC)

Measuring process complying with 1) IEC 60335-2-91 2) RL 2000/14/EC.

* The actual running time may differ from the stated idle time depending on application, type of cuttings and state of maintenance.

The stated vibration emission value has been measured according to a standardised
test procedure and can be used for comparison of one electric power tool with
another. It can also be used for preliminary evaluation of exposure. The vibration
emission value can vary during actual use of the electric power tool.

10. Service / Warranty

Service:

Please contact the address on the back page.

Warranty:

In the event of a warranty claim, no charge is
levied to you for the services provided.

GARDENA Manufacturing GmbH offers a two­year warranty (effective as of the date of
purchase) for this product. This warranty includes
all significant defects of the product that can be
proved to be material or manufacturing faults.
This warranty is fulfilled by supplying a fully func­tional replacement product or by repairing the
faulty product sent to us free of charge; we reser­ve the right to choose between these options.
This service is subject to the following provisions:

• The product was used for its intended purpose
as per the recommendations in the operating
instructions.

• Neither the purchaser nor a third party has
attempted to repair the product.

This manufacturer’s warranty does not affect
warranty entitlements against the dealer / retailer.

If problems arise with this product, please
contact our Service department or send the
defective product along with a brief description
of the fault to GARDENA Manufacturing GmbH,
making sure to have sufficiently covered any
shipping costs and to have followed the rele­vant postage and packaging guidelines.
A warranty claim must be accompanied by
a copy of the proof of purchase.

Consumables:

The filament cassette and cassette cover are con­sumables and are not covered by the guarantee.

24EN308

DE Produkthaftung

Wir weisen ausdrücklich darauf hin, dass wir in Übereinstimmung mit dem Produkthaftungsgesetz nicht für Schäden
haften, die durch unsere Produkte entstehen, wenn diese unsachgemäß und nicht durch einen von uns autorisierten
Servicepartner repariert wurden oder wenn keine Original GARDENA Teile oder von uns zugelassene Teile verwen­det wurden.

EN Product liability

In accordance with the German Product Liability Act, we hereby expressly declare that we accept no liability for
damage incurred from our products where said products have not been properly repaired by a GARDENA-approved
service partner or where original GARDENA parts or parts authorised by GARDENA were not used.

FR Responsabilité

Conformément à la loi relative à la responsabilité du fait des produits défectueux, nous déclarons expressément
par la présente que nous déclinons toute responsabilité pour les dommages résultant de nos produits, si lesdits
produits n‘ont pas été correctement réparés par un partenaire d‘entretien agréé GARDENA ou si des pièces
d’origine GARDENA ou des pièces agréées GARDENA n‘ont pas été utilisées.

NL Productaansprakelijkheid

Conform de Duitse wet inzake productaansprakelijkheid verklaren wij hierbij uitdrukkelijk dat wij geen aansprakelijk­heid aanvaarden voor schade ontstaan uit onze producten waarbij deze producten niet zijn gerepareerd door
een GARDENA-erkende servicepartner of waarbij geen originele GARDENA-onderdelen of onderdelen die door
GARDENA zijn goedgekeurd zijn gebruikt.

SV Produktansvar

I enlighet med tyska produktansvarslagar förklarar vi härmed uttryckligen att vi inte åtar oss något ansvar för skador
som orsakas av våra produkter där produkterna inte har genomgått korrekt reparation från en GARDENA-godkänd
servicepartner eller där originaldelar från GARDENA eller delar godkända av GARDENA inte använts.

DA Produktansvar

I overensstemmelse med den tyske produktansvarslov erklærer vi hermed udtrykkeligt, at vi ikke påtager os
noget ansvar for skader på vores produkter, hvis de pågældende produkter ikke er blevet repareret korrekt af en
GARDENA-godkendt servicepartner, eller hvor der ikke er brugt originale GARDENA-reservedele eller godkendte
reservedele fra GARDENA.

FI Tuotevastuu

Saksan tuotevastuulain mukaisesti emme ole vastuussa laitteiden vaurioista, jos korjauksia ei ole tehnyt GARDENAn
hyväksymä huoltoliike tai jos niiden syynä on muiden kuin alkuperäisten GARDENA-varaosien tai GARDENAn hyväk­symien varaosien käyttö.

IT Responsabilità del prodotto

In conformità con la Legge tedesca sulla responsabilità del prodotto, con la presente dichiariamo espressamente
che decliniamo qualsiasi responsabilità per danni causati dai nostri prodotti qualora non siano stati correttamente
riparati presso un partner di assistenza approvato GARDENA o laddove non siano stati utilizzati ricambi originali
o autorizzati GARDENA.

ES Responsabilidad sobre el producto

De acuerdo con la Ley de responsabilidad sobre productos alemana, por la presente declaramos expresamente
que no aceptamos ningún tipo de responsabilidad por los daños ocasionados por nuestros productos si dichos
productos no han sido reparados por un socio de mantenimiento aprobado por GARDENA o si no se han utilizado
piezas originales GARDENA o piezas autorizadas por GARDENA.

PT Responsabilidade pelo produto

De acordo com a lei alemã de responsabilidade pelo produto, declaramos que não nos responsabilizamos por
danos causados pelos nossos produtos, caso os tais produtos não tenham sido devidamente reparados por
um parceiro de assistência GARDENA aprovado ou se não tiverem sido utilizadas peças GARDENA originais ou
peças autorizadas pela GARDENA.

PL Odpowiedzialność za produkt

Zgodnie z niemiecką ustawą o odpowiedzialności za produkt, niniejszym wyraźnie oświadczamy, że nie ponosimy
żadnej odpowiedzialności za szkody poniesione na skutek użytkowania naszych produktów, w przypadku gdy
naprawa tych produktów nie była odpowiednio przeprowadzana przez zatwierdzonego przez firmę GARDENA part­nera serwisowego lub nie stosowano oryginalnych części GARDENA albo części autoryzowanych przez tę firmę.

HU Termékszavatosság

A németországi termékszavatossági törvénnyel összhangban ezennel nyomatékosan kijelentjük, hogy nem vállalunk
felelősséget a termékeinkben keletkezett olyan károkért, amelyek valamely GARDENA által jóváhagyott szervizpartner
által nem megfelelően végzett javításból adódtak, vagy amely során nem eredeti GARDENA alkatrészeket vagy
a GARDENA által jóváhagyott alkatrészeket használtak fel.

CS Odpovědnost za výrobek

V souladu s německým zákonem o odpovědnosti za výrobek tímto výslovně prohlašujeme, že nepřijímáme žádnou
odpovědnost za poškození vzniklá na našich výrobcích, kdy zmíněné výrobky nebyly řádně opraveny schváleným
servisním partnerem GARDENA nebo kdy nebyly použity originální náhradní díly GARDENA nebo náhradní díly auto­rizované společností GARDENA.

SK Zodpovednosť za produkt

V súlade s nemeckými právnymi predpismi upravujúcimi zodpovednosť za výrobok týmto výslovne prehlasujeme,
že nenesieme žiadnu zodpovednosť za škody spôsobené našimi výrobkami, v prípade ktorých neboli náležité
opravy vykonané servisným partnerom schváleným spoločnosťou GARDENA alebo neboli použité diely spoločnosti
GARDENA alebo diely schválené spoločnosťou GARDENA.

EL Ευθύνη προϊόντος

Σύμφωνα με τον γερμανικό νόμο περί Ευθύνης για τα Προϊόντα, με το παρόν δηλώνουμε ρητώς ότι δεν
αποδεχόμαστε καμία ευθύνη για τυχόν ζημίες που προκύπτουν από τα προϊόντα μας εάν αυτά δεν έχουν
επισκευαστεί σωστά από κάποιον εγκεκριμένο συνεργάτη επισκευών της GARDENA ή εάν δεν έχουν
χρησιμοποιηθεί αυθεντικά εξαρτήματα GARDENA ή εξαρτήματα εγκεκριμένα από την GARDENA.

SL Odgovornost proizvajalca

V skladu z nemškimi zakoni o odgovornosti za izdelke,izrecno izjavljajo, da ne sprejemamo nobene odgovornosti
za škodo, ki jo povzročijo naši izdelki, če teh niso ustrezno popravili GARDENINI odobreni servisni partnerji ali pri tem
niso bili uporabljeni originalni GARDENINI nadomestni deli ali GARDENINIMI homologiranimi nadomestnimi deli.

HR Pouzdanost proizvoda

Sukladno njemačkom zakonu o pouzdanosti proizvoda, ovime izričito izjavljujemo kako ne prihvaćamo nikakvu
odgovornost za oštećenja na našim proizvodima nastala uslijed neispravnog popravka od strane servisnog partnera
kojeg odobrava GARDENA ili uslijed nekorištenja originalnih GARDENA dijelova ili dijelova koje odobrava GARDENA.

RO Răspunderea pentru produs

În conformitate cu Legea germană privind răspunderea pentru produs, declarăm în mod expres prin prezentul
document că nu acceptăm nicio răspundere pentru defecţiunile suferite de produsele noastre atunci când acestea
nu au fost reparate în mod corect de un atelier de service partener, aprobat de GARDENA, sau când nu au fost
utilizate piese GARDENA originale sau piese autorizate de GARDENA.

BG Отговорност за вреди, причинени от стоки

Съгласно германския Закон за отговорността за вреди, причинени от стоки, с настоящото изрично
декларираме, че не носим отговорност за щети, причинени от нашите продукти, ако те не са били
правилно ремонтирани от одобрен от GARDENA сервиз или ако не са използвани оригинални части
на GARDENA или части, одобрени от GARDENA.

ET Tootevastutus

Vastavalt Saksamaa tootevastutusseadusele deklareerime käesolevaga selgesõnaliselt, et me ei kanna mingisugust
vastutust meie toodetest tingitud kahjude eest, kui need tooted ei ole korrektselt parandatud GARDENA heakskii­detud hoolduspartneri poolt või kui parandamisel ei ole kasutatud GARDENA originaalosi või GARDENA volitatud
osi.

LT Gaminio patikimumas

Mes aiškiai pareiškiame, kad, atsižvelgiant į Vokietijos gaminių patikimumo įstatymą, neprisiimame atsakomybės
dėl bet kokios žalos, patirtos dėl mūsų gaminių, jeigu jie buvo netinkamai taisomi arba jų dalys buvo pakeistos
neoriginaliomis GARDENA dalimis ar nepatvirtintomis dalimis, arba jeigu remonto darbai buvo atliekami ne
GARDENA techninės priežiūros centro specialistų.

LV Atbildība par produkcijas kvalitāti

Saskaņā ar Vācijas likumu par atbildību par produkcijas kvalitāti ar šo mēs paziņojam, ka neuzņemamies atbildību
par bojājumiem, kas radušies, lietojot mūsu izstrādājumus, kuru remontu nav veicis uzņēmuma GARDENA
apstiprināts apkopes partneris vai kuru remontam netika izmantotas oriģinālās GARDENA detaļas vai detaļas,
kuru lietošanu apstiprinājis uzņēmums GARDENA.

309

DE EU-Konformitätserklärung

Der Unterzeichner, Husqvarna AB, 561 82 Huskvarna, Schweden, bescheinigt
hiermit, dass die nachstehend aufgeführten Geräte bei Verlassen des Werks die
harmonisierten EU-Leitlinien, EU-Normen für Sicherheit und besondere Normen
erfüllen. Dieses Zertifikat verliert seine Gültigkeit, wenn die Geräte ohne unsere
Genehmigung verändert werden.

EN EC Declaration of Conformity

The undersigned, Husqvarna AB, 561 82 Huskvarna, Sweden, hereby certifies
that, when leaving our factory, the units indicated below are in accordance with
the harmonised EU guidelines, EU standards of safety and product specific
standards. This certificate becomes void if the units are modified without our
approval.

FR Déclaration de conformité CE

Le constructeur, soussigné : Husqvarna AB, 561 82 Huskvarna, Suède, déclare
qu’à la sortie de ses usines le matériel neuf désigné ci-dessous était conforme
aux prescriptions des directives européennes énoncées ciaprès et conforme
aux règles de sécurité et autres règles qui lui sont applicables dans le cadre de
l’Union européenne. Toute modification apportée à cet appareil sans notre
accord annule la validité de ce certificat.

NL EG-conformiteitsverklaring

De ondergetekende, Husqvarna AB, 561 82 Huskvarna, Zweden, verklaart
hierbij dat de producten die hieronder staan vermeld, wanneer ze onze fabriek
verlaten, in overeenstemming zijn met de geharmoniseerde Europese richtlijnen,
EU-normen voor veiligheid en productspecifieke normen. Dit certificaat vervalt
als de producten worden aangepast zonder onze toestemming.

SV EG-försäkran om överensstämmelse

Undertecknad firma Husqvarna AB, 561 82 Huskvarna, Sverige, intygar härmed
att nedan nämnda produkter, när de lämnar vår fabrik, överensstämmer med
EU:s riktlinjer, EU:s säkerhetsstandarder och produktspecifika standarder.
Detta intyg skall ogiltigförklaras om produkten ändras utan vårt godkännande.

DA EU-overensstemmelseserklæring

Undertegnede, Husqvarna AB, 561 82 Huskvarna, Sverige erklærer hermed, at
nedenfor anførte enheder er i overensstemmelse med de harmoniserede EUret­ningslinjer, EU-standarder for sikkerhed og produktspecifikke standarder, når de
forlader fabrikken. Denne erklæring ugyldiggøres, hvis enhederne ændres uden
vores godkendelse.

FI EY-vaatimustenmukaisuusvakuutus

Husqvarna AB, 561 82 Huskvarna, Ruotsi, vakuuttaa täten, että alla mainitut lait­teet ovat tehtaalta lähtiessään yhdenmukaistettujen EU-säännösten, EU:n turva­standardien ja tuotekohtaisten standardien mukaisia. Tämä vakuutus mitätöityy,
jos laitteita muokataan ilman hyväksyntäämme.

IT Dichiarazione di conformità CE

La sottoscritta Husqvarna AB, 561 82 Huskvarna, Svezia, certifica che il prodotto
qui di seguito indicato, nei modelli da noi commercializzati, è conforme alle
direttive armonizzate UE nonché agli standard di sicurezza UE e agli standard
specifici di prodotto. Qualunque modifica apportata al prodotto senza nostra
specifica autorizzazione invalida la presente dichiarazione.

ES Declaración de conformidad CE

El abajo firmante, Husqvarna AB, 561 82 Huskvarna, Suecia, certifica por la
presente que, cuando salen de la fábrica, las unidades indicadas a continuación
cumplen las normas de armonización de la UE, las normas de la UE sobre
seguridad y las normas específicas del producto. Este certificado quedará sin
efecto si se modifican las unidades sin nuestra autorización.

PT Declaração de conformidade CE

O abaixo-assinado, Husqvarna AB, 561 82 Huskvarna, Suécia, certifica por este
meio que, ao sair da nossa fábrica, as unidades indicadas acima estão em
conformidade com as diretrizes uniformizadas da UE, os padrões de segurança
da UE e os padrões específicos do produto. Este certificado deixa de ser válido
se as unidades forem modificadas sem a nossa aprovação.

PL Deklaracja zgodności WE

Niżej podpisany przedstawiciel firmy Husqvarna AB, 561 82 Huskvarna, Szwecja,
niniejszym oświadcza, że podane poniżej wyroby opuszczające fabrykę są zgodne
ze zharmonizowanymi normami UE oraz z obowiązującymi w UE przepisami
bezpieczeństwa i normami dotyczącymi danego produktu. Modyfikacja wyrobów
bez naszej zgody powoduje unieważnienie niniejszego certyfikatu.

HU EK megfelelőségi nyilatkozat

Alulírott Husqvarna AB, 561 82 Huskvarna, Svédország ezzel tanúsítja, hogy az
alábbiakban leírt egységek a gyár elhagyásakor megfeleltek a harmonizált uniós
előírásoknak és biztonsági és termékspecifikus szabványoknak. Ez a tanúsítvány
érvényét veszti, ha az egységeket jóváhagyásunk nélkül átalakítják.

CS Prohlášení o shodě ES

Níže uvedená společnost Husqvarna AB, 561 82 Huskvarna, Švédsko, tímto
potvrzuje, že při opuštění naší továrny jsou jednotky uvedené níže v souladu
s harmonizovanými pokyny EU, standardy EU ohledně bezpečnosti a specifickými
produktovými standardy. Tento certifikát pozbývá platnosti, pokud dojde k úpravě
jednotek bez našeho schválení.

SK EÚ vyhlásenie o zhode

Dolu podpísaná spoločnosť Husqvarna AB, 561 82 Huskvarna, Švédsko týmto
osvedčuje, že nižšie uvedené jednotky boli v súlade s harmonizovanými usmerne­niami EÚ, normami EÚ v oblasti bezpečnosti a špecifickými normami týkajúcimi
sa produktu v čase opustenia výrobného závodu. Toto osvedčenie stráca platnosť,
ak boli jednotky zmenené bez nášho súhlasu.

EL Δήλωση Συμμόρφωσης ΕΚ

Η υπογεγραμμένη εταιρεία, Husqvarna AB, 561 82 Huskvarna, Σουηδία, πιστο­ποιεί ότι, κατά την έξοδο από το εργοστάσιο, οι μονάδες που αναφέρονται κατω­τέρω συμμορφώνονται με τις εναρμονισμένες οδηγίες ΕΕ, τα πρότυπα ασφαλείας
της ΕΕ και τα συγκεκριμένα πρότυπα προϊόντος. Αυτό το πιστοποιητικό καθίστα­ταιάκυρο εάν οι μονάδες έχουν τροποποιηθεί χωρίς την έγκρισή μας.

SL Izjava ES o skladnosti

Spodaj podpisana, Husqvarna AB, 561 82 Huskvarna, Švedska, s to izjavo
potrjuje, da je bila spodaj navedena enota ob izhodu iz tovarne skladna z usklaje­nimi smerni cami EU, standardi EU za varnost in standardi, specifičnimi za
izdelek. Izjava postane neveljavna v primeru neodobrene spremembe enote.

HR Izjava o usklađenosti EZ

Niže potpisana Husqvarna AB, 561 82 Huskvarna, Švedska, ovime potvrđuje
kako su u nastavku navedene jedinice prilikom napuštanja tvornice bile u skladu
s usklađenim smjernicama EU, EU sigurnosnim standardima i standardima
specifičnima za proizvod. Ova certifikacija poništava se ako se jedinice izmjenjuju
bez odobrenja.

RO Declaraţie de conformitate CE

Subscrisa, Husqvarna AB, 561 82 Husqvarna, Suedia, certifică prin prezenta că,
la momentul ieşirii din fabrica noastră, unităţile indicate mai jos sunt în conformi­tate cu directivele UE armonizate, cu standardele UE de siguranţă şi cu standar­dele specifice ale produsului. Prezentul certificat devine nul dacă unităţile sunt
modificate fără aprobarea noastră.

BG Декларация за съответствие на ЕО

С настоящото долуподписаната, Husqvarna AB, 561 82 Huskvarna, Швеция,
удостоверява, че при напускане на фабриката модулите, посочени по­долу, са в съответствие с хармонизираните директиви на ЕС, стандартите
на ЕС за безопасност и специфичните за продукта стандарти. Този
сертификат става невалиден, ако модулите са променени без нашето
одобрение.

ET EÜ vastavusdeklaratsioon

Allakirjutanu Husqvarna AB, 561 82 Huskvarna, Rootsi, kinnitab käesolevaga,
et tehasest väljumisel vastavad allpool nimetatud seadmed harmoneeritud EL-i
suunis tele, EL-i ohutusstandarditele ja tootele eriomastele standarditele.
See vastavuskinnitus kaotab kehtivuse, kui seadet muudetakse ilma meie
heakskiiduta.

LT EB atitikties deklaracija

Husqvarna AB, 561 82 Huskvarna, Sweden, garantuoja, kad iš gamyklos
siunčiami toliau nurodyti įrenginiai atitinka suderintus EB reikalavimus,
EB saugos ir konkretaus gaminio standartus. Pakeitus gaminį be mūsų
patvirtinimo, nutraukiamas šio sertifi kato galiojimas.

LV EK atbilstības deklarācija

Uzņēmums Husqvarna AB, 561 82 Huskvarna, Zviedrija, ar parakstu apliecina,
ka tālāk minētās vienības, pametot rūpnīcu, atbilst saskaņotajām ES vadlīnijām,
ES drošības standartiem un izstrādājumam specifiskajiem standartiem.
Šis sertifikāts tiek anulēts, ja šīs vienības tiek modificētas bez mūsu
apstiprinājuma.

310

Produktbezeichnung:
Description of the product:
Désignation de produit:
Productbenaming:
Produktbeteckning:
Produktbetegnelse:
Tuotenimike:
Nome del prodotto:
Designación del producto:
Designação do produto:
Opis produktu:
A termék megnevezése:
Označení produktu:
Označenie výrobku:
Ονομασία προϊόντος:
Ime izdelka:
Naziv proizvoda:
Denumire produs:
Описание на продукта:
Toote nimetus:
Gaminio pavadinimas:
Izstrādājuma nosaukums:

Produkttyp:
Product type:
Type de produit:
Producttype:
Produkttyp:
Produkttype:
Tuotetyyppi:
Tipo di prodotto:
Tipo del producto:
Tipo de produto:
Typ produktu:

Terméktípus:
Typ produktu:
Typ výrobku:
Τύπος προϊόντος:
Tip izdelka:
Tip proizvoda:
Tip produs:
Тип на продукта:
Toote tüüp:
Gaminio tipas:
Izstrādājuma tips:

EasyCut Li-18/23

EU-Richtlinien:
EC-Directives:
Directives UE:
EU-richtlijnen:
EU-riktlinjer:
EU-direktiver:
EU-direktiivit:
Direttive UE:
Directivas de la UE:
Diretivas UE:
Dyrektywy UE:
EU-irányelvek:
Směrnice EU:
Smernice EU:
Οδηγίες ΕΕ:
EU-direktive:
Direktive EU:

Harmonisierte EN-Normen /
Harmonised EN:

EN ISO 12100
EN 60335-1
EN 50636

Hinterlegte Dokumentation:
GARDENA Technische Dokumentation,
M. Kugler 89079 Ulm

Deposited Documentation:
GARDENA Technical Documentation,
M. Kugler 89079 Ulm

Documentation déposée:
Documentation technique GARDENA,
M. Kugler 89079 Ulm

-2-91

Accu-Turbotrimmer
Accu Turbotrimmer
Coupe-bordures à batterie
Accu-Turbotrimmer
Accu-Turbotrimmer
Accu-turbotrimmer
Accu-turbotrimmeri
Turbotrimmer a batteria
Recortabordes con accu
Aparador de relva Accu-Turbotrimmer
Podkaszarka akumulatorowa
Akkumilátoros damilos fűszegélynyíró
Akumulátorový turbotrimmer
Akumulátorový turbotrimmer
Επαναφορτιζόμενο κουρευτικό πετονιάς
Akumulatorski turbo obrezovalnik
Baterijski turbo trimer za travu
Turbotrimmer cu baterie
Акумулаторен Турботример
Akuga turbotrimmer
Akumuliatorinė turbo žoliapjovė
Turbotrimmeris ar akumulatoru

Artikelnummer:
Article number:
Référence :
Artikelnummer:
Artikelnummer:
Artikelnummer:
Artikkelinumero:
Numero articolo:
Número de
artículo:
Número de
referência:

Numer katalogowy:
Cikkszám:
Číslo materiálu:
Číslo výrobku:
Αριθμός προϊόντος:
Številka artikla:
Broj artikla:
Cod articol:
Артикулен номер:
Artikli number:
Gaminio numeris:
Preces numurs:

Art. 9824

Directivele EU:
ЕС-Директиви:
EL-i direktiivid:
ES direktyvos:
ES direktīvas:

2006/42/EG
2011/65/EG
2000/14/EG
2014/30/EG

Ladegerät / Battery charger
Art. 9825-00.630.00

:

2014/35/EG

Batterie / Battery Art. 9839:

EN 62133

Ladegerät /

Battery charger

Art. 9825-00.630.00

:

EN 60335-1
EN 60335-2-29

Konformitätsbewertungs verfahren:
Nach 2000/14/ EG Art. 14
Anhang VI

Conformity Assessment Procedure:
according to 2000/14/EC
Art.14 Annex VI

Procédure d’évaluation
de la conformité :
Selon 2000/14/CE art. 14 Annexe VI

Schall-Leistungspegel: gemessen / garantiert
Noise level: measured / guaranteed
Niveau sonore : mesuré / garanti
Geluidsniveau: gemeten / gegarandeerd
Ljudnivå: uppmätt / garanterad
Støjniveau: målt / garanteret
Äänitaso: mitattu / taattu
Livello acustico: misurato / garantito
Nivel de ruido: medido / garantizado
Nível de ruído: medido / garantido
Poziom hałasu: zmierzony / gwarantowany
Zajszint: mért / garantált
Hladina hluku: naměřená / zaručená
Hladiny hluku: namerané/zaručené
Επίπεδο θορύβου: μετρημένο / εγγυημένο
Raven zvočne moči: izmerjena / zagotovljena
Razina buke: mjerena / zajamčena
Nivel de zgomot: măsurat / garantat
Ниво на шум: измерено / гарантирано
Müratase: mõõdetud / garanteeritud
Triukšmo lygis: išmatuotas / garantuojamas
Trokšņa līmenis : mērītais / garantētais

Art. 9824 86 dB (A) / 90 dB (A)

Anbringungsjahr der
CE-Kennzeichnung:
Year of CE marking:
Année d’apposition du
marquage CE :
Installatiejaar van de CE-aanduiding:
Märkningsår:
CE-Mærkningsår:
CE-merkin kiinnitysvuosi:
Anno di applicazione della
certificazione CE:
Colocación del distintivo CE:
Ano de marcação pela CE:
Rok nadania oznakowania CE:
CE-jelzés elhelyezésének éve:
Rok umístění značky CE:
Rok udelenia značky CE:

Ulm, den 10.01.2018
Ulm, 10.01.2018
Fait à Ulm, le 10.01.2018
Ulm, 10-01-2018
Ulm, 2018.01.10.
Ulm, 10.01.2018
Ulmissa, 10.01.2018
Ulm, 10.01.2018
Ulm, 10.01.2018
Ulm, 10.01.2018
Ulm, dnia 10.01.2018
Ulm, 10.01.2018
Ulm, 10.01.2018
Ulm, dňa 10.01.2018
Ulm, 10.01.2018
Ulm, 10.01.2018
Ulm, dana 10.01.2018
Ulm, 10.01.2018
Улм, 10.01.2018
Ulm, 10.01.2018
Ulm, 10.01.2018
Ulme, 10.01.2018

Έτος σήματος CE:
Leto namestitve CE-oznake:
Godina dobivanja CE oznake:
Anul de marcare CE:
Година на поставяне на
CE-маркировка:
CE-märgistuse paigaldamise aasta:
Metai, kada pažymėta CE-ženklu:
CE-marķējuma uzlikšanas gads:

Der Bevollmächtigte
Authorised representative
Le mandataire
De gevolmachtigde
Auktoriserad representant
Autoriseret repræsentant
Valtuutettu edustaja
Persona delegata
La persona autorizada
O representante
Pełnomocnik
Meghatalmazott
Zplnomocněnec
Splnomocnený
Ο εξουσιοδοτημένος
Pooblaščenec
Ovlaštena osoba
Conducerea tehnică
Упълномощен
Volitatud esindaja
Įgaliotasis atstovas

Pilnvarotā persona

Reinhard Pompe

Vice President

2013

311

Deutschland /Germany

GARDENA
Manufacturing GmbH
Central Service

-

Lorenser-Straße 40

Hans

-

89079 Ulm

D
Produktfragen:
([phone]
Reparaturen:
([phone]
service

Albania

COBALT Sh.p.k.
Rr. Siri Kodra
1000 Tirana

Argentina

Husqvarna Argentina S.A.
Av.del Libertador 5954
Piso 11–Torre B
(C1428ARP) Buenos Aires
Phone: [phone]
info.gardena
ar.husqvarna.com

Armenia

Garden Land Ltd.
61 Tigran Mets
0005 Yerevan

Australia

Husqvarna Australia Pty. Ltd.
Locked Bag 5
Central Coast BC
NSW 2252
Phone: (+61) (0) 2 43527400
customer.service
husqvarna.com.au

Austria /Österreich

Husqvarna Austria GmbH
Industriezeile 36
4010 Linz
Tel.: [phone]
service.gardena
husqvarnagroup.com

Azerbaijan

Firm Progress
a. Aliyev Str. 26A
1052 Baku

Belgium

Husqvarna België nv/ sa
Gardena Division
Rue Egide Van Ophem 111
1180 Uccle /Ukkel
Tel.: [phone]
info

Bosnia / Herzegovina

SILK TRADE d.o.o.
Industrijska zona Bukva bb
74260 Tešanj

Brazil

Husqvarna do Brasil Ltda
Av. Francisco Matarazzo,
1400
São Paulo
CEP: 05001
Tel: 0800
marketing.br.husqvarna
husqvarna.com.br

Bulgaria

AGROLAND България АД
бул. 8 Декември, №13
Офис 5
1700 Студентски град
София
Тел.: (+ 359) 2466 6910
info

Canada /USA

GARDENA Canada Ltd.
100 Summerlea Road
Brampton, Ontario L6T 4X3
Phone: [phone]
info

Chile

Maquinarias Agroforestales
Ltda. (Maga Ltda.)
Santiago, Chile
Avda. Chesterton
# 8355 comuna Las Condes
Phone: [phone]
Dalton
Zipcode: 7560330

-

123

-

290

@

gardena.com

@

@

@

@

gardena.be

–

19º andar

–

SP

-

903

-

112252

@

agroland.eu

@

gardenacanada.com

@

maga.cl

–

-

485

@

312

China

Husqvarna (Shanghai)
Management Co., Ltd.

富世华（上海）管理有限公司

3F, Benq Square B,
No207, Song Hong Rd.,
Chang Ning District,
Shanghai, PRC. 200335

上海市长宁区淞虹路207号明
基广场B座3楼，邮编：200335

Colombia

Husqvarna Colombia S.A.
Calle 18 No. 68 D
Industrial de Montevideo
Bogotá, Cundinamarca
Tel. [phone] ext. 105
jairo.salazar
husqvarna.com.co

Costa Rica

Compania Exim
Euroiberoamericana S.A.
Los Colegios, Moravia,
200 metros al Sur delColegio
Saint Francis
Phone: [phone]
exim_euro

Croatia

Husqvarna Austria GmbH
Industriezeile 36
4010 Linz
Tel.: [phone]
service.gardena
husqvarnagroup.com

Cyprus

Med Marketing
17 Digeni Akrita Ave
P.O. Box 27017
1641 Nicosia

Czech Republic

Husqvarna Česko s.r.o.
Türkova 2319/ 5b
149 00 Praha 4 – Chodov
Bezplatná infolinka:
800 100425

servis

Denmark

GARDENA DANMARK
Lejrvej 19, st.
3500 Værløse
Tlf.: ([phone]
husqvarna
www.gardena.com/ dk

Dominican Republic

BOSQUESA, S.R.L
Carretera Santiago Licey
Km. 5 ½
Esquina Copal II.
Santiago
Dominican Republic
Phone: (+809 ) 736-0333
joserbosquesa

Ecuador

Husqvarna Ecuador S.A.
Arupos E1-181 y 10 de
Agosto
Tel. [phone]
francisco.jacome
husqvarna.com.ec

Estonia

Husqvarna Eesti OÜ
Valdeku 132
EE-11216 Tallinn
info

@

Finland

Oy Husqvarna Ab
Gardena Division
Lautatarhankatu 8 B/ PL 3
00581 HELSINKI
www.gardena.fi

France

Husqvarna France
9/ 11 Allée des pierresmayettes
92635 Gennevilliers Cedex
France
http: //www.gardena.com/ fr
N° AZUR: 0 81000 78 23
(Prix d’un appel local)

-

@

–

San José

@

racsa.co.cr

@

@

cz.husqvarna.com

@

husqvarna.dk

@

claro.net.do

Quito, Pichincha

@

gardena.ee

31, zona

-

485

Georgia

Transporter LLC
8/ 57 Beliashvili street
0159 Tbilisi, Georgia
Phone: [phone]

Great Britain

Husqvarna UK Ltd
Preston Road
Aycliffe Industrial Park
Newton Aycliffe
County Durham
DL5 6UP

@

info.gardena
husqvarna.co.uk

Greece

Π.ΠΑΠΑΔΟΠΟΥΛΟΣ ΑΕΒΕ
Λεωφ. Αθηνών 92
Αθήνα
Τ.Κ.104 42
Ελλάδα
Τηλ. ([phone]

@

papadopoulos.com.gr

info

Hungary

Husqvarna Magyarország Kft.

-

3

Ezred u. 1
1044 Budapest
Telefon: (+36) 1 251
vevoszolgalat.husqvarna
husqvarna.hu

Iceland

Ó. Johnson & Kaaber
Tunguhalsi 1
110 Reykjavik

@

ojk.is

ooj

Ireland

Husqvarna UK Ltd
Preston Road
Aycliffe Industrial Park
Newton Aycliffe
County Durham
DL5 6UP
info.gardena
husqvarna.co.uk

Italy

Husqvarna Italia S.p.A.
Via Santa Vecchia 15
23868 VALMADRERA (LC)
Phone: [phone]
assistenza.italia
it.husqvarna.com

Japan

KAKUICHI Co. Ltd.
Sumitomo Realty &
Development Kojimachi
BLDG., 8F

-

1 Nibanncyo

5
Chiyoda
Tokyo 102
Phone: [phone]
m_ishihara

Kazakhstan

LAMED Ltd.
155/ 1, Tazhibayevoi Str.
050060 Almaty
IP Schmidt
Abayavenue 3B
110 005 Kostanay

Korea

Kyung Jin Trading CO.,LTD.
107-4, SunDuk Bld.,
YangJae-dong,
Seocho-gu,
Seoul, (zipcode: 137-891)
Phone: (+82) (0)2 574-6300

Kyrgyzstan

Alye Maki
av. Moladaya Guardir J 3
720014
Bishkek

Latvia

Husqvarna Latvija SIA
Ulbrokas 19A

LV-1021 Rīga

@

gardena.lv

info

Lithuania

UAB Husqvarna Lietuva
Ateities pl. 77C

-

52104 Kaunas

LT

@

gardena.lt

info

@

-

ku

-

0084

@

kaku-ichi.co.jp

-

4161

@

@

Luxembourg

Magasins Jules Neuberg
39, rue Jacques Stas

-

Luxembourg
Case Postale No. 12
Luxembourg 2010
Phone: [phone]
api

Mexico

AFOSA
Av. Lopez Mateos Sur # 5019
Col. La Calma 45070
Zapopan, Jalisco
Mexico
Phone: [phone]
icornejo

Moldova

Convel S.R.L.
290A Muncesti Str.
2002 Chisinau

Netherlands

Husqvarna Nederland B.V.
GARDENA Division
Postbus 50131
1305 AC ALMERE
Phone: [phone]
info

Neth. Antilles

Jonka Enterprises N.V.
Sta. Rosa Weg 196
P.O. Box 8200
Curaçao
Phone: [phone]
pgm

New Zealand

Husqvarna New Zealand Ltd.
PO Box 76
Manukau City 2241
Phone: (+64) (0) 9 9202410
support.nz

Norway

Husqvarna Norge AS
Gardena Division
Trøskenveien 36
1708 Sarpsborg
info

Peru

Husqvarna Perú S.A.
Jr. Ramón Cárcamo 710
Lima 1
Tel : (+ 51)13 320400 ext.416
juan.remuzgo
husqvarna.com

Poland

Husqvarna
Poland Spółka z o.o.
ul. Wysockiego 15 b
03
Phone: (+ 48) 2233096 00
gardena

Portugal

Husqvarna Portugal, SA
Lagoa
2635
Tel.: [phone]
Fax : [phone]
info

Romania

Madex International Srl
Soseaua Odaii 117
RO 013603 Bucure
Phone: (+ 40) 21 352.76.03

madex

Russia /Россия

ООО „Хускварна“
141400, Московская обл.,
г. Химки,
улица Ленинградская,
владение 39, стр.6
Бизнес Центр
„Химки Бизнес Парк“,
помещение ОВ02_04
http://www.gardena.ru

Serbia

Domel d.o.o.
Autoput za Novi Sad bb

11273 Belgrade
Phone: [phone]
miroslav.jejina

Gasperich 2549

@

neuberg.lu

@

afosa.com.mx

@

gardena.nl

@

jonka.com

-

437

@

husqvarna.co.nz

@

gardena.no

@

-

371 Warszawa

@

husqvarna.com.pl

-

Albarraque

-

595 Rio de Mouro

@

gardena.pt

@

ines.ro

@

domel.rs

-

123,

ş

ti, S1

-

3434

Singapore

Hy-Ray PRIVATE LIMITED
40 Jalan Pemimpin
#02

-

08 Tat Ann Building
Singapore 577185
Phone: [phone]
shiying

@

hyray.com.sg

Slovak Republic

Husqvarna Česko s.r.o.
Türkova 2319/ 5b
149 00 Praha 4 – Chodov
Bezplatná infolinka:
800 154044

servis

@

sk.husqvarna.com

Slovenia

Husqvarna Austria GmbH
Industriezeile 36
4010 Linz
Tel.: [phone]
service.gardena
husqvarnagroup.com

South Africa

Husqvarna
South Africa (Pty) Ltd
Postnet Suite 250
Private Bag X6,
Cascades, 3202
South Africa
Phone: [phone]
info

@

gardena.co.za

Spain

Husqvarna España S.A.
Calle de Rivas nº10
28052 Madrid
Phone: [phone]
atencioncliente

Suriname

Agrofix n.v.
Verlengde Hogestraat #22
Phone: (+ 597) 472426
agrofix

@

sr.net
Pobox : 2006
Paramaribo
Suriname

–

Sweden

Husqvarna AB
Gardena Division
S

-

561 82 Huskvarna

gardenaorder

Switzerland /Schweiz

Husqvarna Schweiz AG
Consumer Products
Industriestrasse 10
5506 Mägenwil
Phone: (+41) (0) 62 88737 90
info

@

gardena.ch

Turkey

Dost Bahçe Dış Ticaret
Mümessillik A.Ş
Yunus Mah. Adil Sok. No:3
Ic Kapi No: 1 Kartal
34873 Istanbul

Phone: [phone]
info

@

dostbahce.com.tr

Ukraine /Україна

ТОВ «Хускварна Україна»
вул. Васильківська, 34,
офіс 204

-

г
03022, м. Київ
Тел. [phone]

info

@

gardena.ua

Uruguay

FELI SA
Entre Ríos 1083 CP 11800
Montevideo
Tel: [phone]
info

@

felisa.com.uy

Venezuela

C

orporación Casa y Jardín C.A.
Av. Caroní, Edif. Trezmen, PB.
Colinas de Bello Monte.
1050 Caracas.
Tlf: (+ 58) 212 992 33 22
info

@

casayjardin.net.ve

0000

-

20.960.08 /0618

9824-20.960.06/0118

GARDENA

©

© GARDENA
Manufacturing GmbH

Manufacturing GmbH

D-89070 Ulm

D- 89070 Ulm

http://www.gardena.com

http: //www.gardena.com

@

@

gardena.es

South America

@

husqvarna.se

–

Uruguay

-

485
