ErgoCut 48-Li Art. 8878

D Betriebsanleitung

Accu-Heckenschere

GB Operating Instructions

Cordless Hedge Trimmer

F Mode d’emploi

Taille-haies sur Accu

NL Instructies voor gebruik

Accu-heggenschaar

S Bruksanvisning

Accu Häcksax

DK Brugsanvisning

Accu hækkeklipper

FIN Käyttöohje

Akkukäyttöinen aitaleikkuri

N Bruksanvisning

Accu Hekksaks

I Istruzioni per l’uso

Tagliasiepi a batteria

E Manual de instrucciones

Recortasetos con Accu

P Instruções de utilização

Corta sebes com acumulador

PL Instrukcja obsługi

Akumulatorowe nożyce do żywopłotów

H Használati utasítás

Akkumulátoros sövénynyíró

CZ Návod k použití

Akumulátorové nůžky na živý plot

SK Návod na použitie

Akumulátorové nožnice na živý plot

GR Οδηγίες χρήσεως

Θανοκοπτικό παταρίας

RUS Инструкция по эксплуатации

Электрические кусторезы

SLO Navodilo za uporabo

Akumulatorske škarje za živo mejo

HR Upute za uporabu

Škare za živicu s akumulatorom

SRB Uputstvo za rad BIH Baterijske makaze za živicu

UA Інструкція з експлуатації

Акумуляторний садовий секатор

RO Instrucţiuni de utilizare

Trimmer de gard viu cu acumulator

TR Kullanım Klavuzu

Akülü Çit Budayıcısı

BG Инструкция за експлоатация

Accu Ножица за жив плет

AL Manual përdorimi

Gërshërë gardhishtesh me akumulator

EST Kasutusjuhend

Akuga hekilõikur

LT Eksploatavimo instrukcija

Akumuliatorinės gyvatvorių žirklės

LV Lietošanas instrukcija

Accu dzīvžoga šķēres

Explanation of Symbols on your product.

WARNING !

Read the user instructions carefully to make sure you understand all the controls and what they do.

Remove Battery before cleaning or maintenance.

Do not expose to rain. Do not leave the product outdoors while it is raining.

The use of eye and hearing protection is recommended.

2. Safety Instructions

If not used properly this product can be dangerous. The warnings and safety instructions must be followed to ensure reasonable safety and efficiency in using this product. The operator is responsible for following the warnings and instructions in this manual and on the product. Never use the product unless the guards provided by the manufacturer are in the correct position.

Correct Use:

Please note

Contents

GARDENA Cordless Hedge Trimmer ErgoCut 48-Li

Translation of the original instructions from German. Please read these operating instructions carefully and observe the notes given. Use these operating instructions to familiarise yourself with the hedge trimmer, its proper use and the notes on safety.

For safety reasons, children under the age of 16 and people not familiar with these operating instructions must not use this hedge trimmer. Persons with reduced physical or mental abilities may use the hedge trimmer only if they are supervised or instructed by a responsible person.

v Please keep these operating instructions in a safe place.

1.Where to Use Your GARDENA Cordless Hedge Trimmer

. . . . 11

2. Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3. Initial Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

5. Storage

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

6. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

7. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

8. Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

9. Technical Data

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

10. Service /Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

1. Where to Use Your GARDENA Cordless Hedge Trimmer

This GARDENA Cordless Hedge Trimmer is intended for the cutting of hedges, shrubs and grass coverings in private domestic gardens and allotments.

Adherence to these operating instructions is a precondition for the correct use of the hedge trimmer.

WARNING ! Risk of injury! The hedge trimmer must not be used for cutting lawns / lawn edges or for chopping up material for composting purposes.

General Power Tool Safety Warnings

WARNING ! Read all safety warnings and all instructions.

Failure to follow the warnings and instructions may result in electric shock, fire and / or serious injury.

Save all warnings and instructions for future reference.

The term “power tool” in the warnings refers to your mains operated (corded) power tool or battery-operated (cordless) power tool.

1) Work area safety a) Keep work area clean and well lit.

Cluttered or dark areas invite accidents.

b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust.

Power tools create sparks

which may ignite the dust or fumes.

c) Keep children and bystanders away while operating a power tool.

Distractions can cause you

to lose control.

2) Electrical safety a) Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any adaptor plugs with earthed (grounded) power tools.

Unmodified plugs and matching outlets will reduce risk of electric shock.

b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electric

shock if your body is earthed or grounded.

c) Do not expose power tools to rain or wet conditions.

Water entering a power tool will increase

the risk electric shock.

d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts.

Damaged or entangled cords increase

the risk of electric shock.

e) When operating a power tool outdoors, use an extension cord suitable for outdoor use.

Use of a cord suitable for outdoor use reduces the risk of electric shock.

f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply.

Use of an RCD reduces the risk

of electric shock.

3) Personal safety a) Stay alert, watch what you are doing and use

common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication.

A moment of inattention while operating

power tools may result in serious personal injury.

b) Use personal protective equipment. Always wear eye protection.

Protective equipment such as dust mask, non-skid safety shoes, hard had, or hearing protection used for appropriate conditions will reduce personal injuries.

c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/ or battery pack, picking up or carrying the tool.

Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.

d) Remove any adjusting key or wrench before turning the power tool on.

A wrench or a key left attached to a rotating part of the power tools may result in personal injury.

e) Do not overreach. Keep proper footing and balance at all times.

This enables better control of

the power tool in unexpected situations.

f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts.

Loose clothes, jewellery or long

hair can be caught in moving parts.

g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.

Use of

dust collection can reduce dust-related hazards.

4) Power tool use and care a) Do not force the power tool. Use the correct

power tool for your application.

The correct power tool will do the job better and safer at the rate for which it was designed.

b) Do not use the power tool if the switch does not turn it on and off.

Any power tool that cannot be controlled with the switch is dangerous and must be repaired.

c) Disconnect the plug from the power source and / or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools.

Such preventive safety measures reduce the risk of starting the power tool accidentally.

d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.

Power tools are dangerous in the hands

of untrained users.

e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use.

Many accidents are caused by poorly maintained

power tools.

f) Keep cutting tools sharp and clean.

Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed.

Use of the power tool for operations different from those intended could result in a hazardous situation.

5. Battery tool use and care a) Recharge only with the charger specified by the

manufacturer.

A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.

b) Use power tools only with specifically designated battery packs.

Use of any other

battery packs may create a risk of injury and fire.

c) When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another.

Shorting the battery terminals together may

cause burns or a fire.

d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.

Liquid ejected

from the battery may cause irritation or burns.

6. Service Have your power tool serviced by a qualified

repair person using only identical replacement parts.

This will ensure that the safety of the power

tool is maintained.

Hedge trimmer safety warnings:

• Keep all parts of the body away from the cutter blade. Do not remove cut material or hold material to be cut when blades are moving. Make sure the switch is off when clearing jammed material.

A moment of inattention while operating the hedge trimmer may result in serious personal injury.

• Carry the hedge trimmer by the handle with the cutter blade stopped. When transporting or storing the hedge trimmer always fit the cutting device cover.

Proper handling of the hedge trimmer will

reduce possible personal injury from the cutter blades.

• Hold the power tool by insulated gripping surfaces only, because the cutter blade may contact hidden wiring.

Cutter blades contacting a “live” wire may make exposed metal parts of the power tool “live” and could give the operator an electric shock.

Additional Safety Recommendations Work area safety

Only use the product in the manner and for the functions described in these instructions.

The operator or user is responsible for accidents or hazards occurring to other people or their property.

Electrical safety

Use only on AC mains supply voltage shown on the product rating label.

Under no circumstances should an earth be connected to any part of the product.

Personal safety

Always wear suitable clothing, gloves, and stout shoes. Thoroughly inspect the area where the product is to be

used and remove all wires and other foreign objects. Before using the machine and after any impact, check

for signs of wear or damage and repair as necessary. Never attempt to use an incomplete product or one

with an unauthorised modification.

Power tool use and care

Know how to stop the product quickly in an emergency.

Never hold the product by the guard. Do not use the Hedge Trimmer if the protection

equipment (hand protection, 2-hand safety switch, protection cover, quick blade-stop) are damaged.

Do not use ladders whilst operating the product. Remove the battery:

- before leaving the product unattended for any period;

- before clearing a blockage;

- before checking, cleaning or working on the appliance;

- if you hit an object. Do not use your product until you are sure that the entire product is in a safe operating condition;

- if the product starts to vibrate abnormally. Check immediately. Excessive vibration can cause injury.

- before passing to another person.

Maintenance and storage

RISK OF INJURY ! Do not touch blades.

V When work is finished or interrupted, refit the

protective blade cover.

Keep all nuts, bolts and screws secure to be sure the hedge trimmer is in safe working condition.

Battery safety

FIRE RISK !

V Never charge the batteries near acids

or easily inflammable materials.

RISK OF EXPLOSION !

V Protect Cordless Hedge Trimmer from heat and

fire. Do not leave on radiators or expose to strong sunshine for long periods.

Only use your Hedge Trimmer in an ambient temperature between −10 °C and +45 °C.

The charging cable should be checked regularly for signs of damage or ageing (brittleness) and may only be used if it is in perfect condition.

The charger unit provided may only be used to charge the rechargeable batteries supplied with the Hedge Trimmer.

Non-rechargeable batteries must not be charged with this battery charger (danger of fire).

The Hedge Trimmer must not be operated during charging.

Only charge battery between 10 – 45 °C. After heavy duty service allow battery to cool down first.

Storage:

The trimmer must not be stored over 35°C or under direct exposure to sunlight.

Do not store the Hedge Trimmer in places with static electricity.

Charging the battery:

3. Initial Operation

WARNING!

Overvoltage damages batteries and the battery charger.

V Ensure the correct mains voltage.

Before using for the first time, the battery must be fully charged. Charging time (for uncharged battery) see 9. Technical Data.

The lithium-ion battery can be charged in any state of charge, and the charging process can be interrupted at any time without harming the battery (no memory effect).

So that the fully charged battery is not discharged, the battery should be disconnected from the battery charger.

1. Press the locking buttons in

and remove the battery2from

the handle3.

2. Plug the plug of the charger cable

into the battery2.

3. Plug battery charger

into a mains socket.

Charging indicator lamp

lights up red:

The battery is being charged. Charging indicator lamp

lights up green:

The battery is fully charged.

(For charging time, see 9. Technical Data.)

4. First remove the charging cable

from the charging socket

and then unplug the battery charger

from the mains socket.

5. Push the battery

from bottom onto the handle 3.

Avoid exhaustive discharge:

Do not wait until the blade comes to an absolute stop (battery totally discharged) as this shortens the battery life.

v If the output of the hedge trimmer decreases noticeably,

charge the battery.

If the battery has been totally discharged, the LED will flash at the start of charging. If the LED is still flashing after an hour, a fault has occurred (see 7. Troubleshooting).

+ 9 hidden pages
