Galaxy Audio AS-900-K1 User manual

Headphone Jack.
Headphone Level Control.

Left turn for output level decrease, right
turn for output level increase.

Left Channel Input Level Meter.

Right Channel Input Level Meter.
On/Off Switch.

Press to switch on, meters will blink
once. Press again to switch off.

1

DC Power Input Jack.

2

Stereo/Mono Switch.
Stereo position preserves Left/Right
signals throughout system. Mono
position mixes Left/Right signals together.

3

Left Channel XLR/1/4" Combo Input Jack.

4

Right Channel XLR/1/4" Combo Input Jack.

5

Left Channel Input Level Control.

6

Right Channel Input Level Control.

7

Antenna Jack. 50 ohms.
