Pub. 42003-215A
GAI-TRONICS® CORPORATION
A HUBBELL COMPANY
Red Push Butt on Seali ng Boot Kit
Model 12520-008
Confidentiality Notice
This manua l is provide d sole ly as an operatio nal, installation, and ma inte nance guide and conta ins
sensitive business and t e chnical informatio n tha t is confidentia l and pr opri et ary to GAI- Tronics.
GAI-Tronics retains all intellectual property and other rights in or to the information contained herein,
and such information may only be used in connection with the operation of your GAI-Tronics product or
system. This manu al may not be dis clos e d in any form, in whole or in pa rt, direct ly or i ndir ectly, to a ny
third pa r ty.
General Information
The Model 12520-008 Red Push Button Sealing Boot Kit is intended for use on the Model 290 Series
Emergency Phones to seal the emergency button against moisture.
Installation
1. Open the emergency phone by removing the four tamper-resistant screws in the corners of the front
cover.
2. Loosen the two set screws that hold the red emergency button assembly in place. Unscrew the black
coll ar c ontai ning these sc rews an d pull away t he gra y reta ining rin g ben eath it. The r e d emer gency
button assembly will pull free from the front cover.
3. Holding the emergency button from the back
is no folding of the boot edge. Avoid pressing the button with the palm of your hand to ensure that
the button does not develop a vacuum beneath the sealing boot that could prevent switch activation.
4. Test the button after the sealing boot is in place.
!
Note
activat ing when press e d.
If necessary, allow the vacuum to dissipate by pulling the sealing boot away at the edge, and then
allowing it to regain its shape.
!
Ensure that the button still makes the characteristic clicking sound indicating that it is
, pull the sealing boot over the button making sure there
GAI-Tronics Corporation P.O. Box 1060, Readi ng, PA 19607-1060 USA
610-777-1374 800-492-1212 Fax: 610-796-5954
ISIT WWW.GAI-TRONICS.COM FOR PRODUCT LITERATURE AND MANUALS
V
Pub. 42003-215A
M
ODEL 12520-008 RED PUSH BUTTON SEALING BOOT KIT Page: 2 of 2
5. Aft er the seal ing boot is in pla ce and t he emerge ncy bu tton acti vates ( the clicking soun d wil l be hea rd
when it is pushed), hold the button by the rim and replace the button in the front panel.
6. Replace the gray retaining ring, and then the black collar containing the set screws. Tighten the black
collar and the set screws. Retest the button to ensure a vacuum did not develop upon insertion. If a
vacuum has developed preventing activation, disassemble the button and repeat from step 5.
7. Replace the front panel with the four mounting screws.
\\s_eng\gtc proddoc s \st andard iom s - current release\42003 kit manuals \ 42003-215a.doc
11/06
Warranty
Equipment. GAI-Tronics warrants for a period of one (1) year from the date of shipment, that any
GAI-Tronics equipment supplied hereunder shall be free of defects in material and workmanship, shall
comply with the then-current product specifications and product literature, and if applicable, shall be fit
for the purpose specified in the agreed-upon quotation or proposal document. If (a) Seller’s goods prove
to be defective in workmanship and/or material under normal and proper usage, or unfit for the purpose
specified and agreed upon, and (b) Buyer’s claim is made within the warranty period set forth above,
Buyer may return such goods to GAI-Tronics’ nearest depot repair facility, freight prepaid, at which time
they will be repaired or replaced, at Seller’s option, without charge to Buyer. Repair or replacement shall
be Buyer’s sole and exclusive remedy. The warranty period on any repaired or replacement equipment
shall be the greater of the ninety (90) day repair warranty or one (1) year from the date the original
equipment was shipped. In no event shall GAI-Tronics warranty obligations with respect to equipment
exceed 100% of the total cost of the equipment supplied hereunder. Buyer may also be entitled to the
manufacturer’s warranty on any third-party goods supplied by GAI-Tronics hereunder. The applicability
of any such third-party warranty will be determined by GAI-Tronics.
Services. Any services GAI-Tronics provides hereunder, whether directly or through subcontractors,
shall be performed in accordance with the standard of care with which such services are normally
provided in the industry. If the services fail to meet the applicable industry standard, GAI-Tronics will
re-perform such services at no cost to buyer to correct said deficiency to Company's satisfaction provided
any and all issues are identified prior to the demobilization of the Contractor’s personnel from the work
site. Re-performance of services shall be Buyer’s sole and exclusive remedy, and in no event shall GAITronics warranty obligations with respect to services exceed 100% of the total cost of the services
provided hereunder.
Warranty Periods. Every claim by Buyer alleging a defect in the goods and/or services provided
hereunder shall be deemed waived unless such claim is made in writing within the applicable warranty
periods as set forth above. Provided, however, that if the defect complained of is latent and not
discoverable within the above warranty periods, every claim arising on account of such latent defect shall
be deemed waived unless it is made in writing within a reasonable time after such latent defect is or
should have been discovered by Buyer.
Limitations / Exclusions. The warranties herein shall not apply to, and GAI-Tronics shall not be
responsible for, any damage to the goods or failure of the services supplied hereunder, to the extent
caused by Buyer’s neglect, failure to follow operational and maintenance procedures provided with the
equipment, or the use of technicians not specifically authorized by GAI-Tronics to maintain or service the
equipment. THE WARRANTIES AND REMEDIES CONTAINED HEREIN ARE IN LIEU OF AND
EXCLUDE ALL OTHER WARRANTIES AND REMEDIES, WHETHER EXPRESS OR IMPLIED BY
OPERATION OF LAW OR OTHERWISE, INCLUDING ANY WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
Return Policy
If the equipment requires service, contact your Regional Service Center for a return authorization number
(RA#). Equipment should be shipped prepaid to GAI-Tronics with a return authorization number and a
purchase order number. If the equipment is under warranty, repairs or a replacement will be made in
accordance with the warranty policy set forth above. Please include a written explanation of all defects to
assist our technicians in their troubleshooting efforts.
Call 800-492-1212 (inside the USA) or 610-777-1374 (outside the USA) for help identifying the
Regional Service Center closest to you.
(Rev. 10/06)
