GAI-Tronics 12519-002 User Manual
Pub. 42003-039A
GAI-TRONICS® CORPORATION
A HUBBELL COMPANY
Stationary Cradle Assembly Replacement Kit
Model 12519-002
Confidentiality Notice
This manua l is provide d sole ly as an operatio nal, installation, and ma inte nance guide and conta ins
sensitive business and t e chnic al infor ma tion w hich is conf ident ial and pr op riet ary to GAI-Tro nics.
GAI-Tronics retains all intellectual property and other rights in or to the information contained herein,
and such information may only be used in connection with the operation of your GAI-Tronics product or
system. This manu al may not be dis clos e d in any form, in whole or in pa rt, direct ly or i ndir ectly, to a ny
third pa r ty.
General Information
The Model 12519-002 Stationary Cradle Assembly Replacement Kit is for use on the following
components:
• 519-102 • 601-101 • 601-102 • 701-201
• 701-202 • 701-203 • 701-204 • 701-205
• 711-002 • 711-101 • 7115-002 • 7115-101
• 716-002 • 716-101 • 7165-002 • 7165-101
This kit includes the following components:
Qty Description
1 Cradle Gasket
1 Cradle
2 Screws
2 Plastic Shoulder Washers
Installation
Removal of old cradle assembly
1. Loosen the four screws on the front panel and remove the amplifier from the enclosure.
2. Models 711-002, 711-101, 7115-002, 7115-101, 716-002, 716-101, 7165-002, 7165-101:
Using a small standard screwdriver, remove four screws securing back panel to chassis.
All other mod e ls: Using a hex nut driver, loose n the four screws – two are on the t op surfa c e of the
amplifier and two are on the bottom – holding the front panel to the chassis.
GAI-Tronics Corporation P.O. Box 1060, Readi ng, PA 19607-1060 USA
610-777-1374 800-492-1212 Fax: 610-796-5954
ISIT WWW.GAI-TRONICS.COM FOR PRODUCT LITERATURE AND MANUALS
V
Pub. 42003-039A
M
ODEL 12519-002 STATIONARY CRADLE ASSEMBLY REPLACEMENT KIT Page: 2 of 2
3. Separate the chassis from the front panel.
4. Remove the two screws holding the cradle on the panel. Note the purple wire attached under the
screw head.
5. Remo ve th e c radle, ga sket, a nd shoulder was hers.
Installation of new cradle assembly
1. Insert the new shoulder washers in the panel.
2. Assemble the new cradle and the new gasket to the panel with the new screws. Be sure to reattach the
purple wire under either of the screw heads.
The purple wire should be betw e en s crew and shou l der washer, NOT between th e chassis and
Note:
shoulder washer.
3. Reassemble the front panel to the chassis and tighten the four screws.
4. Place the amplifier in the enclosure.
5. Tighten the four front panel screws t to secure the amplifier.
