GAI-Tronics 12118-011 User Manual
Pub. 42003-225A
GAI-TRONICS® CORPORATION
A HUBBELL COMPANY
Audio Termination Connection Module Kit
for LE200-RM
Model 12118-011
Confidential ity Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains
sensitive business and technical information that is confidential and proprietary to GAI-Tronics.
GAI-Tronics retains all intellectual property and other rights in or to the information contained herein,
and such information may only be used in connection with the operation of your GAI-Tronics product or
system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any
third party.
General Information
The Model 12118-011 Audio Termination Connection Module Kit provides field wire termination for the
audio lines of the LE200-RM Rack-Mounted Line Extender. This kit includes the following components:
Qty Description
1 Line Extender Audio Termination Connection Module
1 DB25 Cable Assembly, 2.5-foot
Installation
The connection module is DIN rail mountable and is mounted in the cabinet rack where the LE200-RM
Line Extender is installed. The DB25 cable assembly connects J1 of the Connection Module to J4 on the
rear of the LE200-RM. Field audio wiring is then made to the pluggable terminal blocks P5 and P8.
1. Snap the Audio Termination Connection Module to the DIN rail within 2.5 feet of the LE200-RM
Line Extender.
2. Plug one end of the DB25 Cable Assembly into J1 of the Audio Connection Module and secure it by
tightening the DB25 connector jackscrews. See Figure 1.
GAI-Tronics Corporation 400 E. Wyomissing Ave., Mohnton, PA 19540 USA
610-777-1374 800-492-1212 Fax: 610-796-5954
V
ISIT WWW.GAI-TRONICS.COM FOR PRODUCT LITERATURE AND MANUALS
Pub. 42003-225A
ODEL 12118-011 CONNECTION MODULE KIT – AUDIO TERMINATION Page: 2 of 4
M
Figure 1. Line Extender Audio Termination Connection Module
3. Plug the other end of the DB25 cable assembly into J4 (AUDIO) on the rear of the LE200-RM Line
Extender and secure it by tightening the DB25 connector jackscrews. See Figure 2.
Figure 2. LE200-RM Line Extender Rear Panel
