en-us Use and Care Manual, Installation Instructions
Dryer
WT262700
2
Table of contents
en-us Use and Care Manual, Installation Instructions
Important information 5
Purchase information 5
Customer service 5
Your dryer is intended for 6
Safety Definitions 6
IMPORTANT SAFETY INSTRUCTIONS 6
Introduction to your new dryer 10
Standard features and helpful information 10
Special features 10
Environmentally friendly use of your dryer 11
Dimensions and clearances required 11
Installation for best performance 11
Appliance dimensions 12
Length of power cord and drain hose 12
Minimum clearances 12
INSTALLATION INSTRUCTIONS 14
Introduction 14
Before installing the dryer 15
Waste disposal 15
Parts provided with your dryer 16
Accessories for your appliance 17
Installation - step by step and check list 17
Electrical Connections 19
Leveling the dryer 21
Check heating system 21
Preparing to transport the dryer - step by step 21
Reversing the door - step by step 22
Getting to know your appliance 25
Control panel 25
Display area 26
en-us
OPERATING INSTRUCTIONS 28
Your new dryer 28
Before using the dryer for the first time 29
Temporary disconnection of the dryer 30
Using program selector to choose a drying program 30
Program selection 30
Selecting optional program settings 30
Loading the laundry 31
Starting the program 31
Indicator of program sequence 32
Selecting a different program 32
Cancel program 32
Program end 32
Removing laundry/switching the appliance off 32
Home Connect® 33
Calling up the Home Connect menu 33
Connecting your home network to the
Home Connect app 33
Activating/deactivating Wi-Fi 35
Resetting your network settings 35
Updating the software 35
Information on data protection 36
Declaration of Conformity 36
Wi-Fi® Module FCC/IC Statements 36
Laundry 37
Preparing the laundry 37
Sorting the laundry 37
Drying tips 37
Program selection table 38
Optional program settings 39
U (Low Heat) 39
ü (Time Dry) 39
ý (Remote Start) 39
6 (Finish in) 39
5 (Dryness Level) 39
· (Level Adjust) 39
ò (End Signal) 40
5 (Wrinkle Block™) 40
Appliance settings 40
¯ 3 sec. (Child lock) 40
Activating setting mode 40
Exiting setting mode 41
3
en-us
USER-MAINTENANCE INSTRUCTIONS 41
Cleaning the Dryer's exterior 41
Cleaning the lint filter area 42
Cleaning the lint filter 42
Cleaning the Condenser 43
Cleaning the moisture sensors 44
Maintenance of drain hose 45
Replacing fuses in the Power Adapter - step-by-step 45
Troubleshooting 45
Introduction 45
General Troubleshooting 46
STATEMENT OF LIMITED PRODUCT WARRANTY 50
Gaggenau® Clothes Dryer 50
Additional information on products, accessories,
replacement parts and services can be found at
www.gaggenau.com/us
4XHVWLRQV"
ZZZJDJJHQDXFRPXV
0DLQ6WUHHW6XLWH
,UYLQH&$
:HORRNIRUZDUGWRKHDULQJIURP\RX
4
Important information en-us
Important information
Import ant informati on
Purchase information
Please take a moment to record the following basic
information about the purchase of your new Gaggenau®
dryer.
This information will be helpful in the event you need to
contact Customer Service or would like to order
accessories or replacement parts for your dryer.
(1U
The E-Nr. (model number) and the FD (serial) number can
be found on the rating plate label (shown above) or in the
Home Connect application under Appliance Information.
The model number includes the slash and a two digit
number (eg: "/01"). Please be sure to include the final 2
digit number when filling in your model number. This
helps make sure any parts you may need are correctly
matched to your specific machine.
Date of Purchase:___/___/_____
)'
(1U
)'
Customer service
Your dryer does not require any special care other than
the maintenance and care mentioned in this manual. If
you have a problem with your dryer, please consult the
Troubleshooting section of this manual.
~ Page 45
If problems persist and service is necessary, please
contact our customer service department.
Do not attempt to repair the appliance yourself.
Gaggenau®
BSH Home Appliances Corporation
1901 Main Street, Suite 600
Irvine, CA 92614
or calling us at:
1-877-442-4436
When writing or calling please have the following
information available:
▯ E-Nr. (model number, example: WTG86xxxUC/01)
▯ FD (serial number, example: 9708|90007)
▯ Date of Original Purchase (receipt may be required)
▯ Date Problem Occurred
▯ Explanation of Problem
If writing, please also include a daytime telephone
number and a copy of the sales invoice.
Where Purchased:___________________________
E-Nr. :_______________/____ (ex: WT262700/01)
FD :__________-_________ (ex: 9807|90007, provides
production date)
The manufacturer reserves the right to make changes in
the product or manual without notification.
When calling Customer Service, please be ready to
provide the model number E-Nr. and FD number. This
information will help provide the best support for your
dryer.
Additional information is available at our website:
www.gaggenau.com/us.
5
en-us Your dryer is intended for
Your dryer is intended for
Your dryer is intended for
▯ Only household use and in a non-commercial
environment.
▯ Drying textiles washed in a residential style clothes
washer.
▯ Operating conditions:
Recommended ambient temperatures: 59-86°F / 1530°C.
Min/Max allowable temperatures: 41-95°F / 5-35°C.
Relative humidity: under 95%
▯ Installation by qualified installers.
▯ Installation in accordance with all regulatory
requirements; if in doubt have the appliance installed
by a specialist familiar with these requirements.
Before using the appliance, read the use and installation
instructions and all other information included with the
appliance and act accordingly.
Keep all documents for future use.
Safety Definitions
Safety Definitions
Important safety information is contained in this manual
and on the warning labels located on your dryer.
Standard symbols and headings are used to identify
areas where you should take precautions to avoid injury
or property damage. Please take a moment to become
familiar with each of these symbols and what they mean
before proceeding.
9 WARNING
This indicates that death or serious injuries may
occur as a result of non-observance of this
warning.
9 CAUTION
This indicates that minor or moderate injuries may
occur as a result of non-observance of this
warning.
NOTICE
This indicates that damage to the appliance or property
may occur as a result of non-observance of this warning.
Tip: This symbol is used to draw the user's attention to important matters.
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONSREAD AND SAVE THESE INSTRUCTIONS
9 WARNING
When properly cared for, your new
appliance has been designed to be
safe and reliable. Read all instructions
before using the appliance. These
precautions will reduce the risk of
burns, electric shock, fire, and injury to
persons. When using laundry
appliances, basic safety precautions
must be followed, including those in
the following pages.
6
IMPORTANT SAFETY INSTRUCTIONS en-us
Examine the appliance after unpacking it. In
the event of transport damage, do not plug
it in.
9 WARNING
To reduce the risk of fire, electric shock, serious injury or death when using your dryer, follow basic precautions including the following!
▯ Gaggenau® dryers are provided
with a Use and Care Manual with
Installation Instructions. Read and
understand all instructions before
using the dryer.
▯ Do not dry articles that have been
previously cleaned, washed, soaked,
or spotted with gasoline, dry
cleaning solvents, other flammable
or explosive substances as they give
off vapors that could ignite or
explode.
▯ Before the appliance is removed
from service or discarded, remove
the door (to the drying compartment)
to prevent children from playing or
hiding inside. Also remove the power
cord/plug.
▯ Do not allow anyone to climb, lean or
hang on any part of the dryer
including any protruding
components such as the appliance
door or a pullout shelf.
▯ Do not reach into the appliance if the
drum is moving.
▯ Do not tamper with the controls.
▯ Do not use fabric softeners or
products to eliminate static unless
recommended by the manufacturer
of the fabric softener or product.
▯ Always unplug the dryer from the
power supply before attempting any
service. Disconnect the power cord
by grasping the plug, not the cord.
▯ To reduce the risk of fire, clothes,
cleaning rags, mop heads and the
like which have traces of any
flammable substance, such as
vegetable oil, cooking oil, petroleum
based oils or distillates, waxes, fats,
etc., must not be placed in the dryer.
These items may contain some
flammable substance(s) even after
washing, which may smoke or catch
fire by itself.
▯ Do not place items exposed to
cooking oils in your dryer. Items
contaminated with cooking oils may
contribute to a chemical reaction
that could cause a load to catch fire.
▯ Do not use heat to dry articles
containing foam rubber (may be
labeled latex foam) or similarly
textured rubber-like materials or
equivalent. Foam rubber materials
can ignite by spontaneous
combustion.
▯ Keep flammable materials and
vapors, such as gasoline, away from
the dryer.
▯ Do not repair or replace any part of
the appliance or attempt any service
unless specifically recommended in
these user maintenance instructions.
▯ Do not use replacement parts that
have not been recommended by the
manufacturer (e.g. parts made by
using a 3D printer).
▯ Clean lint filter before or after each
load.
▯ Do not install or store this appliance
where it will be exposed to the
weather. Hoses and internal parts
may be damaged if exposed to
freezing temperatures.
7
9 IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
▯ Do not use the dryer if it has a
worn power cord or loose plug.
▯ The dryer must only be used for its
intended purpose.
▯ Always follow the fabric care
instructions recommended by the
clothing manufacturer.
▯ Do not operate the dryer if parts
are missing or broken.
▯ Do not sit on top of the dryer.
▯ To reduce the risk of fire or
electrical shock, DO NOT use an
extension cord to connect the
dryer to the electrical power
supply.
▯ Always check pockets and remove
any objects. Cigarette lighters are
particularly hazardous.
▯ Do not operate the dryer if any
guards and/or panels have been
removed.
▯ Do not bypass any safety devices.
▯ Do not operate this dryer until you
are sure that:
▯ To avoid floor damage and mold
growth, do not let spills or
splashout cause standing water
around or under the appliance.
▯ See the Installation Instructions
section in this manual for
grounding requirements.
~ Page 19
▯ The IMPORTANT SAFEGUARDS
and WARNINGS presented in this
manual do not cover all possible
conditions that may occur.
Common sense, caution
and care must be exercised
when installing, maintaining or
operating the dryer.
▯ Always contact your dealer,
distributor, service provider or the
manufacturer about any problems
or conditions that you do not
understand.
▯ Follow the Safety Information in
the INSTALLATION
INSTRUCTIONS and the
OPERATING INSTRUCTIONS.
– All services connected to the dryer
(power, drain, etc.) have been
installed according to the
Installation Instructions.
– Installation and grounding are in
compliance with all local
regulations and/or other applicable
regulations and requirements.
▯ Failure to install, maintain and/or
operate the dryer according to the
manufacturer’s instructions may
result in injury and/or damage.
8
9 IMPORTANT SAFETY INSTRUCTIONS
Y
READ AND SAVE THESE INSTRUCTIONS
9 WARNING
WARNINGS FOR CHILDREN AND PETS!
▯ Do not allow children and pets to
play on or in the appliance. Close
supervision of children is
necessary when the appliance is
used near children.
▯ Make sure to utilize all child lock/
safety features of your appliance,
and be sure to turn the appliance
Off when not in use.
▯ Appliances are not intended for
use by children, however when
children become old enough to
operate the appliance, it is the
responsibility of the parents or
legal guardians to ensure they are
instructed in safe practices by
qualified persons.
▯ Keep all laundry aids (including
detergents, bleach, fabric
softeners, etc.) out of the reach of
children.
9 WARNING
Proposition 65 Warning!
This product may contain a chemical
known to the State of California,
which can cause cancer or
reproductive harm. Therefore, the
packaging of your product may bear
the following label as required by
California:
67$7(2)&$/,)251,$352326,7,21:$51,1*
:$51,1*
&DQFHUDQG5HSURGXFWLYH+DUPZZZ3:DUQLQJVFDJR
SAVE THESE INSTRUCTIONS!
Keep these instructions for future
reference and in case of change of
ownership, manual should be conveyed
with the dryer.
▯ Keep pets away from the
appliance.
9
9 Introduction to your new dryer
READ AND SAVE THESE INSTRUCTIONS
Introduction to your new dryer
Introduction to your new dryer
9 WARNING
Risk of fire, electric shock or injury!
To reduce the risk of fire, electric shock or
injury to persons, read the IMPORTANT
SAFETY INSTRUCTIONS of this manual before
installing or operating this appliance.
~ Page 6
Standard features and helpful information
Thank you for choosing Gaggenau® for your laundry
appliance needs.
Please read and follow the use and care, important
safety instructions and troubleshooting information
contained in this manual. Please retain this manual for
future reference.
~ Page 45
This dryer complies with UL 2158 Electric Clothes
Dryers.
About this manual
These operating and installation instructions apply to
more than one model of dryer. Illustrations used may
show details that differ from your particular model.
Read your user manual. It contains valuable
information about the safety, installation and operation
of your new appliance.
This can save you time, make it easier to correctly
install and use your dryer, and improve your overall
satisfaction with your new appliance.
Special features
▯ A distinctive feature of your dryer is low energy
consumption as it is ENERGY STAR certified.
▯ Gaggenau® dryers feature advanced operation
philosophy, customized drying programs and a
solid touch and feel making them a user-friendly
household assistant.
▯ Gaggenau® load sensing feature controls power
consumption for each cycle based on the amount
and type of laundry. This automatic feature
optimizes energy efficiency.
Standard features
▯ ENERGY STAR® certified to save energy, save
money and protect the climate.
▯ Temperatures inside the drum are lower than
conventional dryers for gentle drying conditions
and fabric care.
▯ Sensor controlled auto cycles.
▯ 17.6 lb (8 kg) large drum capacity (for regular
cotton loads).
▯ Large door opening, 180° opening angle.
Quality tested
Each dryer which leaves our factory has undergone a
thorough performance test and is in full working
condition.
Website
Visit our website at www.gaggenau.com/us for more
information and to view a selection of our products.
10
Dimensions and clearances required en-us
Environmentally friendly use of your dryer
Your new Gaggenau® dryer is designed to use energy in
a highly efficient way to help reduce operating costs,
conserve resources and protect the environment.
To save energy, money and time, Gaggenau®
recommends the following:
▯ Spin the laundry thoroughly
Before drying, spin the laundry thoroughly in the
washing machine. Use the highest possible spin
speed for the type of laundry. Higher spin speeds
reduce the drying time and the energy consumption.
▯ Optimize load and selected drying program
– Use the maximum amount of laundry for the
appropriate drying program.
– Use automatic drying programs for the most
energy efficient use of your dryer. They perform
according to internal moisture and temperature
sensors delivering optimized efficiency and fabric
care.
– Use the Time Dry program for touching up damp
loads or for small loads. This program will use
more energy than the automatic programs.
~ Page 38
Dimensions and clearances required
Dimensions and clearances required
Installation for best performance
9 CAUTION
Do not install the dryer:
▯ outdoors,
▯ in an environment with dripping water,
▯ near flammable materials,
▯ in rooms which are at risk of freezing,
▯ in rooms which may contain gas or other fuels,
▯ on carpets.
Because many variables affect drying time we
recommend allowing as much free air space around your
dryer as possible for the shortest drying cycle time.
NOTICE
If your dryer is located in a closet, leave the closet door
open while the dryer is operating.
Note: The energy rating of this dryer is based on the Cotton program with the Dryness Level set to Dry (all other option settings are off).
▯ Clean filter
Clean the lint filter before or after each drying
process.
▯ Air inlet on the dryer
Do not cover or allow any articles/items to restrict the
air inlet on the front of the dryer.
▯ Energy-saving mode
The display panel lighting goes out after a few minutes
and A (Start/Pause) flashes. To activate the display,
press any button.
Energy-saving mode is not activated if a program is
running.
If Wi-Fi is activated the appliance will not
automatically switch off (automatic switch-off function
is deactivated).
The recommended ambient temperatures (between 5986°F / 15-30°C) are for optimum drying times, outside of
this range drying times may be longer.
The installation surface (floor) must be level and
structurally sound. Using a bubble level and the heightadjustable feet installed on the appliance, level the
appliance side to side and front to back.
11
en-us Dimensions and clearances required
)
Appliance dimensions
E
Label Dimension U.S.
a Width 23.6 60
b Depth (to front of door) 25 63.5
c Height (minimum)
Height (maximum)
d Side clearance
(door open 180°)
e Depth (door open 90°) 42.9 109
D
H
F
G
Metric
Inches
cm
33.23484.3
86.4
16 40.6
Minimum clearances
Closet: Stacked
Only with one of the Bosch required Stacking Kits (sold
separately), can this Bosch Dryer be stacked on top of a
Bosch Washer of the same dimensions to save space.
9 CAUTION
▯ Use only the dryer stacking kit noted in this
User Manual's Accessories section.
▯ Do not stack washer on top of dryer.
▯ Do not stack washer on top of another washer.
▯ Ensure washer transportation bolts have been
removed and washer does not vibrate
excessively.
%
(
+
)
Length of power cord and drain hose
To Left* To Right*
U.S.
Inches
Power Cord 40 102 57 145
Drain Hose 19 48 40 102
* Facing the front of the dryer
MetriccmU.S.
Inches
Metric
cm
&
$
*
'
For shortest drying times keep closet door open while
dryer is operating.
NOTICE
When closet doors are closed louvered areas only allow
minimal drying results (expect long drying times).
12
Closet: Stand alone (shown) or Side by Side
Dimensions and clearances required en-us
Under counter (Preferred)
$
(
&
$
.
-
)
Front of the appliance fully open.
No doors or coverings.
'
Minimum opening dimensions
Label Dimension U.S.
Inches
Metric
cm
A 28 in. 71.1 cm
B 23.8 in. 60.5 cm
C 34.5 in. 87.6 cm
A Both Sides 0.6 1.5
B Top 6.3 16
C Rear 2.5 6.2
D Front 2.4 6
E & F are minimum area size!
E Top Vent 63 sq. 404 sq.
F Bottom Vent 63 sq. 404 sq.
Vent spacing is actual (not minimum dimensions)
G3794
H2666
J 3 7.6
K 29 73.6
%
&
13
en-us Installation Instructions
Under counter (Less Desirable)
(
+
)
*
If front of the appliance is covered ventilation openings
must be installed.
E & F are minimum area sizes
E 63 sq.in. 404 sq. cm
F 63 sq.in. 404 sq. cm
G & H
actual spacing dimensions for min. open area sizes
G 3 in. 7.6 cm
H 14 in. 35.6 cm
INSTALLATION INSTRUCTIONS
Installation Instructions
READ AND SAVE THESE INSTRUCTIONS
Introduction
Read these installation instructions completely and
carefully before starting to install your new dryer. The
information contained can save you time and effort and
will help to ensure optimum performance of your new
dryer. Be sure to observe all warnings and cautions.
9 WARNING
Risk of fire, electric shock or injury to persons!
▯ To reduce the risk of fire, electric shock or
injury to persons, read the Important Safety
Instructions at the beginning of this manual
before installing or operating this appliance.
▯ To reduce the risk of severe injury or death,
follow all installation instruction.
▯ Clothes dryer installation must be performed by
a qualified installer, according to these
instructions and according to all local codes.
▯ In addition to the installation and safety
information in this manual, the local water and
electric authorities (services) may have special
requirements that must be followed.
▯ Install the clothes dryer according to these
manufacturer’s instructions and local codes.
▯ Your dryer is supplied with a specific power
adapter that is only to be used with the Bosch
Washers and Dryers having NEMA 6-15P cords.
Any other use of this power adapter is
prohibited. Read and follow the Important
Safety Instructions supplied with the Power
Adapter.
14
Installation Instructions en-us
9 CAUTION
▯ The appliance is heavy. Do not lift it by yourself,
use additional help and care when lifting and
positioning.
▯ If in doubt, have the appliance installed by an
authorized service provider.
▯ Take care to not damage the appliance. Do not
hold on to protruding parts (e.g. door) when
lifting. Do not push against the appliance door
glass due to risk of damage.
▯ Do not install the appliance outdoors or in an
area exposed to freezing conditions.
▯ If freezing conditions exist where appliance is
located all drain water must be removed from
hoses, sumps, pumps, etc.
▯ Hidden surfaces may have sharp edges. During
service wear gloves and use caution when
reaching inside the dryer housing.
These installation instructions are intended for use by
qualified installers. In addition to these instructions, the
installation must comply with:
▯ for the United States - National Electrical Code, ANSI/
NFPA70 - and latest editions of the state and
municipal and/or local regulations.
▯ for Canada - Canadian Electrical Code C22.1 - and
the latest editions of the provincial, municipal and/or
local regulations.
Before installing the dryer
Unpacking the appliance
9 CAUTION
Remove the appliance packaging carefully to
prevent damage to the surfaces.
After removing the packaging, immediately remove
all objects from the drum.
Check the dryer for transportation damage. Do not
connect the utilities (power or drain) to a dryer which is
visibly damaged. If in doubt, contact your dealer.
Waste disposal
Disposal of Packaging Materials
After unpacking your new appliance dispose of the
protective packaging materials in an environmentally
friendly way. Ask your dealer or inquire with your local
authority regarding currently acceptable means of
disposal.
9 WARNING
Warnings for children!
Do not let children play with packaging and
associated parts to avoid risk of choking or
suffocation.
Disposal of Your Old Appliance
Your old appliance can be recycled if it is no longer to be
used. Prior to disposing of your old appliance observe
the following precautions to reduce safety risks.
9 WARNING
To avoid risk of injury or death, do the following!
▯ After unplugging the old appliance, remove the
electric power cord and dispose of properly.
▯ Remove the door or permanently disable the
door lock to prevent children from being locked
inside.
15
en-us Installation Instructions
Parts provided with your dryer
Back side of the dryer
( Power cord with plug
0 Drain hose connected to the dryer
8 Elbow to form the hose to fit the drain
Dryer drum contents
A literature pack is shipped in the dryer drum. Be sure to
remove this item before using the dryer.
@
User Manual and Product Registration
H
Power Adapter:
Supplied Power Adapter
2 spare fuses
Instruction sheet
Drain Set Pack:
P
(2) plastic ties for securing drain hose
Plastic elbow
Plastic connector for alternate drain connections
(see hose installation instructions).
Summary of drain hose installation instructions
NOTICE
If any parts are missing please notify your dealer
immediately.
16
Installation Instructions en-us
9 WARNING
RISK OF FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS!
▯ The supplied Power Adapter is intended to be
used only for powering the Bosch Washers and
Dryers having NEMA 6-15P cords. This Power
Adapter is unique as it allows for both the Dryer
and Washer to plug into the home's existing 4prong dryer receptacle. If the home has an
existing 3-prong dryer receptacle it and its
complete branch circuit must be changed to a 4prong circuit.
▯ Use only Bosch replacement fuses in the Power
Adapter (Customer Service part number
10013781).
▯ If any parts are missing please notify your
dealer immediately.
Tip: For correct adapter installation see ~ Page 19
Accessories for your appliance
Pedestal
The dryer can be mounted on a Bosch pedestal, noted
below, for easier loading and unloading (see washing
machine user manual for unique pedestal model number
for the washer).
Pedestal item number: WMZ20500 or replacement
WTZPW20D
Power Adapter
The Power Adapter is for plugging into home's existing 4prong receptacle and has two power outlets, one each
for your current Bosch Dryer and Washer to plug into.
Power Adapter item number: WTZPA20UC
Tip: Your Bosch dryer comes with the Power Adapter included in the drum. The accessory number is given here only if it is lost or damaged and a replacement is needed.
Accessories can be purchased from Customer Service or
your local dealer.
~ Page 5
Installation - step by step and check list
Review the following list and check off each step as it is
completed during installation, if necessary.
1. Unpack the dryer.
2. Remove all objects from the dryer drum.
3. Check the dryer for visible damage.
4. Position the dryer near the installation location.
5. Disconnect the power cord and drain hose from their
clips on the back of the dryer.
9 CAUTION
Do not disconnect the drain hose from the
sump/pump connection at the bottom of the
dryer.
Stacking kits
The dryer can be stacked on a Gaggenau® washer of the
same dimensions to save space. Only the below Stacking
kits must be used when stacking this dryer on a Bosch
washer.
Stacking kit without a shelf: WTZ20410UC
Stacking kit with a shelf: WTZ11400UC
(QVXUHWKHGUDLQKRVH
UHPDLQVFRQQHFWHG
WRVXPSSXPSRXWOHW
NOTICE
Do not reuse an old or different drain hose. Only use
the drain hose included with the dryer.
17
Loading...
