AA 490 711
Length 78
3/4
" (2000)
Length 78
3/4
" (2000)
Length 68
7/8
" (1750)
Access to
cable connection
right
dia. 23/8" (dia. 60)
25/16" (59)
33/16" (81)
41/8"
(108)
315/16"
(100)
23/16"
(56)
21/16"
(53)
915/16"
(253)
513/16"
(147)
87/8"
(225)
23/8" (60)
Stainless steel control knob
Vario 400 series control knob for use
with VL 414 downdraft
AA 490
– For operation with 400 series
AR400742 inline, AR401742
remote or AR413722 recirculation
blower
– Solid stainless steel control knob
– Can be perfectly combined with
other Vario 400 series products
Operation
Control knob with illuminated ring and
output marking.
Features
3 electronically controlled power levels
and 1 intensive mode.
Run-on function, 6 min.
Planning notes
For positioning examples of the
knob at any location between Vario
cooktops, see planning notes on
following page.
Note: when using two blowers,
customers can choose to install one or
two control knobs.
The separate electronics box needs to
be installed so that it is accessible.
Possible combinations with the AA 490
control knob:
2x VL 414: 400 series AR400742
inline, AR401742 remote or AR413722
recirculation blower
1x VL 414: all 400 series AR blowers
possible.
One or two blowers can be operated
via one AA 490 control knob at the
same speed level.
Rating
Total rating: 10 W.
Total Amps: 4 A.
120 V / 60 Hz
Connecting cable 69" with plug.
Numbers indicated
inside parenthesis ( ) = mm
www.gaggenau.com
