Futurecom Systems Group ULC DVEVHF User Manual

MOBEXCOM DVE

Users Manual

8A084X03 Rev. 1.0

1. TABLE OF CONTENTS

Section Page

1. TABLE OF CONTENTS .....................................................................................................2

Notes, Attentions, Important....................................................................................................3

MODES..........................................................................................................................................................7

CONTROL HEAD.........................................................................................................................................7

DVE RADIO UNIT ........................................................................................................................................8

MOBILE RADIO UNIT..................................................................................................................................8

3. OPERATION.........................................................................................................................9

CONTROL HEAD.........................................................................................................................................9

APPENDIX 1................................................................................................................................12

DVE

Futurecom Systems Group Inc. DVE Users Manual 8A084X03_VHF_Rev1_0.DOC Rev. Preliminary Page 2

Notes, Attentions, Important

Throughout this manual, you will see Notes, and Attentions, Important
Their meaning is as follows:

NOTE

A clarifying statement that expands on the text that follows.

IMPORTANT

An important statement that should be considered and / or implemented in order to
achieve adequate equipment operation.

ATTENTION!

An instruction that must be followed in insure compliance with the appropriate
standards or proper equipment operations.

DVE

Futurecom Systems Group Inc. DVE Users Manual 8A084X03_VHF_Rev1_0.DOC Rev. Preliminary Page 3

DVE

NOTE

This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.

ATTENTION!

Changes or modifications not expressly approved by Futurecom Systems Group Inc. could void the
user’s authority to operate the equipment.

IMPORTANT

This manual contains important safety and operating instructions, therefore keep this manual

always on hand!

Prior to using any product, follow all warning, safety and operating instructions written on the product and in

the Users Manual. All instructions should be saved for reference in the future!

RF EXPOSURE

ATTENTION!

To satisfy FCC/IC RF exposure requirements, a separation distance 66cm (26.0”) or more should be
maintained between 0dBd antenna of this device and persons. To ensure compliance, operations at

closer than this distance is not allowed.

RADIO OPERATOR

Futurecom requires the MOBEXCOM DVE operator to ensure FCC Requirements for Radio Frequency

Exposure are met. The DVE output power has to be set such that the maximum Effective Radiated
Power (ERP) does not exceed 3.0W at the antenna. The minimum distance between all possible
personnel and the antenna at 3.0W ERP must be at least 66cm (26.0”).

FAILURE TO OBSERVE THE MPE DISTANCE EXCLUSION AREA AROUND THE ANTENNA MAY
EXPOSE PERSONS WITHIN THIS AREA TO RF ENERGY ABOVE THE FCC EXPOSURE LIMIT FOR
BYSTANDERS (GENERAL POPULATION). IT IS THE RESPONSIBILITY OF THE OPERATOR TO

ENSURE THAT MPE LIMITS ARE OBSERVED AT ALL TIMES DURING TRANSMISSIONS. THE
OPERATOR MUST ENSURE AT ALL TIMES THAT NO PERSON COMES WITHIN MPE DISTANCE FROM
THE ANTENNA.

Futurecom Systems Group Inc. DVE Users Manual 8A084X03_VHF_Rev1_0.DOC Rev. Preliminary Page 4
