PREFACE

For specifications, dimension, and capacities, please refer to the LSB200 spec sheet:

http://www.futek.com/files/pdf/Product%20Drawings/lsb200.pdf

PRECAUTIONS

Remove the shunt before applying any load.

Make sure the cover is not touching the measuring end of the load cell.

Install the LSB200 in a dry, clean environment for optimum performance and to prevent short
circuiting the sensor.

MEASURING END

The top of the sensor is the measuring end.

DISCLAIMER

This documentation was generated and completed to the best ability of

FUTEK’s Engineering Team. The information and recommendations on this

document are presented in good faith and believed to be correct however,

FUTEK Advanced Sensor Technology makes no representations or warranties

as to the completeness or accuracy of the information.

DO NOT USE these products as safety or emergency stop devices, or in

any other application where failure of the product could result in

personal injury. Failure to comply with these instructions could result in

death or serious injury.
