FUSION 1100L Instruction Manual
GBC Swingline Fusion
1100L 9" Laminator
- 1703074
Instruction Manual
FUSION™1100L
9" LAMINATOR
start here
démarrez ici
empieza aquí
FUSION™1100L
9" LAMINATOR
GB instruction manual 4
F manuel d’utilisation 10
E manual de instrucciones 12
English
lamination made simple!
Welcome to the Swingline GBC Fusion 1100L laminator
which is simple to use with Swingline GBC lamination.
Perfectly designed for the occasional users, at home or in
the small oce.
For best lamination results and performance, use only
Swingline GBC branded pouches.
Please take a little time to study these instructions to ensure
you get the best results out of your machine.
safety instructions
m
m
Your safety as well as the safety of others is important to ACCO® Brands. In this
instruction manual and on the product are important safety messages. Read these
messages carefully.
The safety alert symbol precedes each safety message in this instruction manual.
This symbol indicates a potential personal safety hazard that could hurt you or others,
as well as cause product damage or property damage.
The following warning is found on the
product in several languages.
c
This safety message means that you
could be seriously hurt or killed if you
open the product and expose yourself
to hazardous voltage.
WARNING
m
Electrical shock hazard.
Do not open. No user
serviceable parts inside.
Refer servicing to qualied
service personnel.
4 register this product online at www.acco.com
points to note
English
m
m
m
m
• Use this unit only for its intended use of laminating documents
• Do not laminate an empty pouch
• The unit must be connected to a supply voltage corresponding to the electrical rating
shown on the unit
• The socket-outlet shall be installed near the equipment and shall be easily accessible
• Do not use a carrier with this machine
• Ensure the machine is clear of pouches prior to starting the next pouch
• Clean the lamination rollers on a regular basis
• Maximum 9” document pouch 9” x 14½” on 9” Swingline GBC Fusion 1100L laminator
• Failure to comply will result in damage and invalidate guarantee
service
Do not attempt to service or repair the pouch laminator yourself. Unplug the unit and contact an
authorised Swingline GBC service representative for any required repairs.
technical specifications
Electrical 120V AC / 60Hz /
2.9A / 350W
Machine Dimensions 14.57x4.23x3.15 inch
(370x107.5x80mm)
Machine Weight 3.0lbs (1.36kg)
Maximum Pouch Width 9.5 inch (241mm)
Maximum Pouch
Thickness
Maximum Thru-put
Thickness
Warm-Up Time Approximately 4 minutes
Speed 13 inches (330mm)
5 mil (125mic)
0.7mm
per minute
FUSION™ 1100L 9" & 12" LAMINATORS 5
English
getting ready to laminate
Easy Set Up
1 Take the electrical plug and place in an appropriate power source, which is near the table you
2 The laminator will respond with a single beep and a sequence of brief ashes across the control
intend to use.
panel.
3 To use the laminator move the slider to the right from the ‘
depending on which pouch selected. Below the slider you will see a white line, this indicates that
you have switched the laminator on.
’ to the 3 mil or 5 mil position
a b
Visual & Audible Ready Alerts
4 The laminator will start to warm up - an orange light will be illuminated to the right of the ‘
When the laminator is ready to use the green light next to the ‘tick ’ is illuminated (b) and a
series of two beeps are heard.
NOTE: Only use 3 mil/5 mil photo pouches
NOTE: Your new laminator may emit a slight
odor during the initial operation. Its is
normal and will diminish after a few
hours of operation.
’ (a).
loading the pouch
1 Take your item to be laminated and place in to the appropriate sized laminating pouch,
ensuring it is rmly located along the sealed edge. This is to help ensure that you get optimal
quality output.
SEALED EDGE
NOTE: Do not cut pouches prior to
lamination.
letter, menu, photo Irregular shaped item
SEALED EDGE
Before laminating important or unique documents, always run a test pouch through
the laminator using a similar type document.
register this product online at www.acco.com
6
laminating
1 On the front of the laminator there are line indicators to help you feed your pouch accurately.
Using the indicators feed the sealed edge of the pouch, into the laminator. The laminator will
grip the pouch and guide it through.
2 Upon exiting remove your laminated item immediately and lay on a at surface to ensure
optimal quality.
English
3 When you are nished laminating push the slider switch back to the ‘
Manual Release
NOTE: If the pouch does not appear at the back of the laminator or you have
mis-fed the pouch - press and hold the release button (indicated with
the
Feed a cleaning card or sheet of paper through the laminator to clean
the rollers before continuing.
Intelligent Power O
NOTE: For added safety and environmental reasons the laminator will automatically stop heating
after 30 minutes of activity. You will see a green and orange light to indicate this state.
Re-set to ‘
) and pull the pouch towards you out of the laminator.
’ before next usage.
’ position and unplug.
cleaning
WARNING: UNPLUG THIS PRODUCT BEFORE CLEANING THE EXTERIOR.
WIPE EXTERIOR ONLY WITH A DAMP CLOTH AND DO NOT USE
m
DETERGENTS OR SOLVENTS.
Regularly feed a cleaning card or sheet of paper through the laminator to clean
the rollers.
FUSION™ 1100L 9" & 12" LAMINATORS 7
