Furinno FNBL-22001, FNBL-22003 Assembly Instruction Manual

8kg
MODEL:
Furinno Besi Office Computer Desk
FNBL-22001
STEP 3
Insert Keyboard Panel(E) into the finshed product from Step 2.
STEP 4
Screw in the Adjustable Leg(3) to complete the assembly process. If the floor surface is not even, adjust the legs to fit.
A
A
E
D
D
(3)x 4pcs
20kg
www.furinno.com
Assembly Instruction
Recomm. 1 Person
Approx. 30 minutes
Tools Required
Customer Service
Tel/Fax: 281.500.9372 Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm) Email: support@furinno.com
WARNING:
>This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
Recommended Maximum Weight
1
2
3
4pcs
8pcs
4pcs
A
A
B
B
B
B
B
C
C
C
A
D
D
D
D
E
E
1pcs
2pcs
1pcs
1pcs
1pcs
STEP 1
Attach Back Panel(C), Bottom Panel(D) to L/R-Support Frame(B) with Screw/Dowel Nut(2).
STEP 2
Attach Top Panel(A) to L/R-Support Panel(B) with Screw(1).
Top Panel Screw
Screw/ Dowel Nut
Adjustable Leg
L/R-Support Frame
Back Panel
Bottom Panel
Keyboard Panel
(2)x 8pcs
(1)x 4pcs
No Hardware List Qty No QtyParts List
USEFUL HINTS BEFORE YOU START:
1. Read each step carefully before starting.
2. It is important that each step is performed in correct order to avoid difficulties.
3. Identify, sort and count the parts before assembly.
4. Assemble your furniture on packaging cardboard to prevent scratch or damage.
5. Clean the product with mild cleanser using soft damped cloth. Do not use harsh or abrasive cleanser.
6. Using uncompatible hardware might cause damage to product.
Note: Dowel nuts are inserted from the bottom of the Bottom Panel with the nut hole facing outwards to receive Screw.
