Assembly Instruction
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
www.furinno.com
3.1 Attach L/R Top Panel(A)to Center Top Panel(B)with Hinge(4).
3.2 Install L-Brackets(7)to Center Top Panel(B)and Center Panel(C)using Screw(1).
STEP 3
Recommended Maximum Weight
Furinno Boyate Special Simple
Folding Table
FNAJ1107220140421
MODEL :
FNAJ-11072
35.4”(W) x 28.9”(H) x 23.6”(D)DIMENSION :
50
*Unit in Pound(lbs)
(4)x 4pcs
(7)x 2pcs
C
B
A
A
D
Tool Required
Recomm. 2 Person
Approx. 30 minutes
STEP 2
Attach Center Top Panel(B)to completed unit in Step 1 using Wood Dowel(2)and
Cam-Lock Screw/Nut(3).
STEP 1
1.1 Install Stopper(5)to L/R Panel(D)with Short Screw(6),as shown in Picture(1).
1.2 Attach L/R Panel(D)to opposite side of Center Panel(C)with Screw(1),as shown
in Picture(2).
(2)x 2pcs
(3)x 2pcs
C
B
D
(4)x 4pcs
(1)x 4pcs
(5)x 2pcs
(6)x 4pcs
C
D
D
D
Picture 1 Picture 2
USEFUL HINTS BEFORE YOU START:
1. Read each step carefully before starting.
2. It is important that each step is performed in correct order to avoid difficulties.
3. Identify, sort and count the parts before assembly.
4. Assemble your furniture on packaging cardboard to prevent scratch or damage.
5. Clean the product with mild cleanser using soft damped cloth. Do not use harsh or abrasive cleanser.
6. Using uncompatible hardware might cause damage to product.
1
2
3
36pcs
2pcs
2pcs
A 2pcs
L/R Top Panel
Cam-Lock Screw/Nut
No Hardware List Qty No QtyParts List
Screw
Wood Dowel
4
5
6
8pcs
2pcs
8pcs
Short Screw
7 2pcs
L-Bracket
Hinge
Stopper
B
C
1pcs
1pcs
Center Panel
Center Top Panel
D 2pcs
L/R Bottom Panel
A
A
B
C
D
D
