Assembly Instruction
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
Approx. 40 minutes
Recomm. 2 Person
Tools Required
Insert Round Leg(4)to Panel(B)uisng hammer.
STEP 6
Attach Panel(B)to assembled unit with
Screw(1).
STEP 5
Upright the unit.Insert Shelf Support(3)
and place Panel(H)on it.
STEP 7
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
Recommended Maximum Weight
(1)x12pcs
(3)x8pcs
(4)x6pcs
Furinno THE Entertaiment Center
Tube Shelf
1119120140325(2)
MODEL :
11191
43.3”(W) x 13.4”(H) x 13.1”(D)DIMENSION :
its Space. its Budget
www.furinno.com
50
*Unit in Pound(lbs)
15
15
1
2
3
12pcs
12pcs
8pcs
A 1pcs
Top Panel
Shelf Support
No Hardware List Qty No QtyParts List
USEFUL HINTS BEFORE YOU START:
1. Read each step carefully before starting.
2. It is important that each step is performed in correct order to avoid difficulties.
3. Identify, sort and count the parts before assembly.
4. Assemble your furniture on packaging cardboard to prevent scratch or damage.
5. Clean the product with mild cleanser using soft damped cloth. Do not use harsh or abrasive cleanser.
6. Using uncompatible hardware might cause damage to product.
Chipboard Screw
Plastic Dowel
4
5
6
6pcs
8pcs
8pcs
Cam-Lock Nut
PVC Round Leg
Cam-Lock Screw
STEP 2
Insert Cam-Lock Nut(6)into Panel(D)&(E).
**Arrow on Cam-Lock Nut should be pointing toward hole.**
Insert Dowel(2)to Panel(C)(F)(G).
STEP 1
B
C
1pcs
2pcs
Front Panel
Bottom Panel
D
E
F
2pcs
2pcs
1pcs
Center Panel
Side Panel
Back Panel
G
H
1pcs
2pcs
Shelf Panel
Center Back Panel
STEP 3
Screw Cam-Lock Screw(5)into the
pre-drilled holes on Panel(A).
Attach Panel(C)(D)(E)(F)(G)to Panel (A).
Tighten Cam-Lock Nut(6)using phillips
screwdriver.
STEP 4
(6)x2pcs
(5)x8pcs
(A)
unfinished surface
(E)(E)(E)
