COLOR TV/DVD

WV13D5

(13 inch)

OWNER’S MANUAL

Please read before using this equipment

INSTRUCCIONES EN ESPAÑOL INCLUIDAS

If you need additional operating assistance after reading this owner’s manual or to order replacement accessories, please call

TOLL FREE : 1-800-518-1180. Or visit our WEB SITE at http://www.funai-corp.com

YXY

P O S

R Q

1. Read instructions - All the safety and operating instruc-

tions should be read before the appliance is operated.

2. Retain Instructions - The safety and operating instruc-

tions should be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in

the operating instructions should be adhered to.

4. Follow Instructions - All operating and use instructions

should be followed.

5. Cleaning - Unplug the unit from the wall outlet before

cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6. Attachments - Do not use attachments not recommend-

ed by the unit manufacturer as they may cause hazards.

7. Water and Moisture - Do not use this unit near water-

for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8. Accessories - Do not place this unit on an unstable cart,

stand, tripod, bracket, or table. The unit may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the unit. Any mounting of the appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

AMEUBLES - Cet appareil ne doit être placé que sur un meuble (avec ou sans roulettes) recommandé par le fabricant. Si vous l’installez sur un meuble à roulettes, déplacez les deux ensembles avec précaution. Un arrêt brusque, l’utilisation d’une force excessive et des surfaces irrégulières risquent de déstabiliser l’ensemble et de le renverser.

9. Ventilation - Slots and openings in the cabinet and the

back or bottom are provided for ventilation and to ensure reliable operation of the unit and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat register. This unit should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10. Power Sources - This unit should be operated only from

the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For the units intended to operate from battery power, or other sources, refer to the operating instructions.

11.Grounding or Polarization - This unit is equipped with

a polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12. Power-Cord Protection - Power-supply cords should be

routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

- 2 - EN

IMPORTANT SAFEGUARDS

The caution marking is located on the rear of the cabinet.

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE.

PORTABLE CART WARNING

S3126A

SYMBOLE D'AVERTISSEMENT POUR

LES COMPOSANTES

APPAREIL ET MEUBLE A ROULETTES

S3126A

- 3 - EN

13. Outdoor Antenna grounding - If an outside antenna or

cable system is connected to the unit, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14. Lightning - For added protection for this unit receiver

during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power-line surges.

15. Power Lines - An outside antenna system should not be

located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16. Overloading - Do not overload wall outlets and exten-

sion cords as this can result in a risk of fire or electric shock.

17. Object and Liquid Entry - Never push objects of any

kind into this unit through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the unit.

18. Servicing - Do not attempt to service this unit yourself

as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19. Damage Requiring Service - Unplug this unit from the

wall outlet and refer servicing to qualified service personnel under the following conditions:

a. When the power-supply cord or plug is damaged or

frayed.

b. If liquid has been spilled, or objects have fallen into the

unit. c. If the unit has been exposed to rain or water. d. If the unit does not operate normally by following the

operating instructions. Adjust only those controls that are

covered by the operating instructions, as improper

adjustment of other controls may result in damage and

will often require extensive work by a qualified techni-

cian to restore the unit to its normal operation. e. If the unit has been dropped or damaged in any way.

f. When the unit exhibits a distinct change in performance,

this indicates a need for service.

20. Replacement Parts - When replacement parts are

required, be sure the service technician has used replace-

ment parts specified by the manufacturer that have the

same characteristics as the original part. Unauthorized

substitutions may result in fire, electric shock, injury to

persons or other hazards.

21. Safety Check - Upon completion of any service or

repairs to this unit, ask the service technician to perform

routine safety checks to determine that the unit is in

proper operating condition.

22. Heat - This unit product should be situated away from

heat sources such as radiators, heat registers, stoves, or

other products (including amplifiers) that produce heat.

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

S2898A

FIGURE A

ELECTRIC SERVICE EQUIPMENT

NEC - NATIONAL ELE CTRI CAL CO DE

GROUND

CLAMP

ANTENNA

L EAD IN WIRE

ANTENNA

DISCHARGE UNI T (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDI NG ELECTRODE SYSTEM (NEC ART 250, PART H)

- 4 - EN

The serial number of this product may be found on the back of the unit. No other unit has the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase Dealer Purchase from Dealer Address Dealer Phone No. Model No. Serial No.

A NOTE ABOUT RECYCLING

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

LASER SAFETY

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

CAUTION: TO PREVENT ELECTRIC SHOCK,

MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

PRECAUTIONS

- 5 - EN

AV OID THE HAZARDS OF

ELECTRICAL SHOCK AND FIRE

LOCATION

For safe operation and satisfactory performance of your unit, keep the following in mind when selecting a place for its installation:

•

Shield it from direct sunlight and keep it away from sources of intense heat.

•

Avoid dusty or humid places.

•

Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes at the top or bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

•

Install unit in a horizontal position.

•

Avoid locations subject to strong vibration.

•

Do not place the unit near strong magnetic fields.

•

Avoid moving the unit to locations where temperature differences are extreme.

•

Be sure to remove disc and unplug the AC power cord from the outlet before carrying the unit.

•

Do not handle the power cord with wet hands.

•

Do not pull on the power cord when disconnecting it from an AC wall outlet. Grasp it by the plug.

•

If by accident, water is spilled on your unit, unplug the power cord immediately and take the unit to our Authorized Service Center for servicing.

•

Do not put your fingers or objects into the unit disc loading tray.

•

Do not place anything directly on top of the unit.

WARNING

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place or after heating a cold room or under conditions of high humidity. If a DVD is played in a unit which has moisture, it may damage the DVD and the unit. Therefore when the condensation occurs inside the unit, turn the unit on and allow at least 2 hours for the unit to dry out.

The following symbols below appear in some headings and notes in this manual, with the following meanings.

: Description refers to TV operation (in the TV mode).

: Description refers to playback of DVD video discs

(in the DVD mode).

: Description refers to playback of Audio CDs

(in the DVD mode).

: Description refers to the items to be set by the

QUICK mode (in the DVD mode).

QUICK

DVD-V

SYMBOLS USED IN THIS MANUAL

SUPPLIED ACCESSORIES

•

If you need to replace these accessories, please refer to the PART NO. under the illustrations and call our help line mentioned on the front page.

•

Depending on your antenna system, you may need different types of Combiners (Mixer) or Separators (Splitter). Contact your local electronics store for these items.

BatteriesRemote Control Unit

2 AA Batteries( NE207UD )

Owner’s Manual

( 1EMN20769 )

Owner's Manual

- 6 - EN

TABLE OF CONTENTS

C IMPORTANT SAFEGUARDS . . . . .2

C PRECAUTIONS . . . . . . . . . . . . . . . .4

LOCATION . . . . . . . . . . . . . . . . . . .5

AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE .5

WARNING . . . . . . . . . . . . . . . . . . . .5

SYMBOLS USED IN THIS

MANUAL . . . . . . . . . . . . . . . . . . . . .5

C SUPPLIED ACCESSORIES . . . . . . .5

C TABLE OF CONTENTS . . . . . . . . . .6

C FEATURES . . . . . . . . . . . . . . . . . . . .7

C OPERATING CONTROLS AND

FUNCTIONS . . . . . . . . . . . . . . . . . . .8

C PREPARATION FOR USE . . . . . . .10

ANTENNA/CABLE

CONNECTION . . . . . . . . . . . . . . . .10

CONNECTING TO FRONT A/V

INPUT JACKS . . . . . . . . . . . . . . . .11

CONNECTING TO A STEREO AMPLIFIER EQUIPPED WITH DIGITAL INPUT JACKS (for DVD) .11

CONNECTING TO A DOLBY DIGITAL DECODER (for DVD) . .12

INSTALLING THE BATTERIES . .12

TV SECTION

C TV OPERATION AND SETTINGS .13

WATCHING A TV PROGRAM . . .13

DEGAUSSING . . . . . . . . . . . . . . . .13

PICTURE CONTROL . . . . . . . . . . .13

SLEEP TIMER . . . . . . . . . . . . . . . .14

CLOSED CAPTION SYSTEM . . . .14

CHANNEL SET UP . . . . . . . . . . . .15

V-CHIP SET UP . . . . . . . . . . . . . . .16

TV RATING SET UP . . . . . . . . .16

MPAA RATING SET UP . . . . . .17

CHANGE ACCESS CODE . . . . .17

MENU LANGUAGE . . . . . . . . . . .17

C CABLE CHANNEL

DESIGNATIONS . . . . . . . . . . . . . .18

DVD SECTION

C ABOUT THE DISCS . . . . . . . . . . . .19

PLAYABLE DISCS . . . . . . . . . . . .19

UNPLAYABLE DISCS . . . . . . . . . .19

C PLAYING A DISC . . . . . . . . . . . . . .20

BASIC PLAYBACK . . . . . . . . . . . .20

GENERAL FEATURES . . . . . . . . .20

DISC MENU . . . . . . . . . . . . . . . . .20

TITLE MENU . . . . . . . . . . . . . . . . .20

RESUME . . . . . . . . . . . . . . . . . . . .21

PAUSE . . . . . . . . . . . . . . . . . . . . . .21

STEP BY STEP PLAYBACK . . . . .21

FAST FORWARD /

FAST REVERSE . . . . . . . . . . . . . .21

SLOW FORWARD /

SLOW REVERSE . . . . . . . . . . . . . .21

ZOOM . . . . . . . . . . . . . . . . . . . . . .21

C SEARCH FUNCTION . . . . . . . . . . .22

TRACK SEARCH . . . . . . . . . . . . .22

TITLE / CHAPTER SEARCH . . . .22

TIME SEARCH . . . . . . . . . . . . . . .22

MARKER SETUP SCREEN . . . . . .22

SPECIAL PLAYBACK FUNCTION

. . .23

REPEAT . . . . . . . . . . . . . . . . . . . . .23

PROGRAM . . . . . . . . . . . . . . . . . . .23

RANDOM PLAYBACK . . . . . . . . .23

C CHANGING THE SETTINGS . . . .24

SUBTITLE LANGUAGE . . . . . . . .24

AUDIO LANGUAGE . . . . . . . . . . .24

STEREO SOUND MODE . . . . . . . .24

CAMERA ANGLE . . . . . . . . . . . . .24

BLACK LEVEL SETTING . . . . . . .24

VIRTUAL SURROUND . . . . . . . . .25

THE ON-SCREEN INFORMATION

. .25

C CHANGING THE DVD SET UP

ITEMS . . . . . . . . . . . . . . . . . . . . . . .26

CUSTOM MENU . . . . . . . . . . . . . .26

LANGUAGE SETTING . . . . . . . .26

DISPLAY SETTING . . . . . . . . . .27

AUDIO SETTING . . . . . . . . . . . .27

PARENTAL CONTROL . . . . . . . .28

OTHER SETTINGS . . . . . . . . . . .28

INITIALIZE . . . . . . . . . . . . . . . . . .28

C TROUBLESHOOTING GUIDE . . .29

C MAINTENANCE . . . . . . . . . . . . . . .32

DISC HANDLING . . . . . . . . . . . . .32

C SPECIFICATIONS . . . . . . . . . . . . .33

C ESPAÑOL . . . . . . . . . . . . . . . . . . . .34

C WARRANTY . . . . . . . . . . .Back Cover

- 7 - EN

•

Infrared remote control

•

Trilingual on screen TV setup display selectable in English, Spanish or French

•

181 channel capability PLL frequency synthesizer tuner with direct station call

(A converter may

be necessary to view scrambled cable channels.)

•

Closed Caption Decoder – You may view special-

ly labeled (cc) TV programs, movies, news, etc. with either a dialogue caption or text display added to the program.

•

Auto power off system – If there is no air signal

input from the antenna terminal and no operation for 15 minutes, the unit will turn itself off automatically.

•

Sleep timer – Allows you to have the unit auto-

matically turn off at a desired time.

•

V-CHIP – Enables parents to prevent their children

from watching inappropriate material on TV.

FEATURES

TV Mode

¡Parental lock

You can set the control level to limit playback of discs which may not be suitable for children.

¡Automatic detection of discs

This unit automatically detects if the loaded disc is DVD or Audio CD.

¡On-screen display

Information about the current operation can be displayed on a TV screen, allowing you to confirm the currently active functions (such as program playback), on the TV screen using the remote control.

¡Search

Chapter search / Title search / Track search / Time search

¡Repeat

Chapter / Title / Track / All / A-B

¡Zoom

Magnified screen can be displayed.

¡Marker

The part designated by user can be called back.

¡Resume Play

User can resume to playback from the part at which the play was stopped.

¡Virtual Surround ¡Bit rate indication

¡DRC (Dynamic range control)

You can control the range of sound volume.

¡Dolby Digital sound

This unit can handle Dolby Digital surround sound having 5.1 channels when connected to a Dolby Digital decoder.

¡Still/fast/slow/step playback

Various playback modes are available including still pictures, fast forward/reverse, slow motion and step frames.

¡Random playback for Audio CD

This unit can shuffle the order of tracks to play them in random order.

¡Program playback for Audio CD

You can program the order of tracks to play them in any desired order.

¡DVD menus in a desired language

You can display DVD menus in a desired language, if available on a DVD.

¡Screen saver/Auto power-off functions

The screen saver program starts when there is no input from the unit for 5 minutes in the stop mode. After the screen saver program is activated for 15 minutes, the power automatically turns off.

¡Subtitles in a desired language

You can select a desired language for the display subtitles, if that language is available on a disc.

¡Selecting a camera angle

You can select the desired camera angle, if a disc contains sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound mode, if different languages and modes are available on a disc.

DVD Mode

- 8 - EN

OPERATING CONTROLS AND FUNCTIONS

- REMOTE CONTROL -

[Fig. 2]

- FRONT PANEL - [Fig.1]

HEADPHONE

VIDEO AUDIO

YXY

P O S

R Q

POWER VOLUME CHANNEL SKIP SKIPPLAY PAUSESTOP

OPEN/CLOSE

E –

–

12 4 56 107 9831213119

1.Disc loading tray

2.VIDEO input Jack

Connect to the video output jack of a video camera or VCR.

3.AUDIO L/R input Jacks

Connect to the audio output jacks of a video camera or VCR.

4.POWER Button

[P.13]

Press to turn the power on and off.

5.VOLUME (VOL.) X/

Buttons

[P.13]

Press to control the volume level for the DVD and TV.

6.CHANNEL (CH.) X/

Buttons

[P.13]

Press to select memorized channels.

7.Remote sensor window

8.STOP P Button

[P.20]

Stops operation of the disc.

9.SKIP R / Q Buttons

[P.22]

Press once to skip chapters or tracks to a desired point.

SEARCH E / D Buttons (Front panel) [P.21]

Press and hold to change forward or reverse playback speed.

10. PLAY O Button

[P.20]

Starts playback of the disc.

11. PAUSE

Button

[P.21]

Pauses the current disc operation.

12. OPEN/CLOSE

Button

[P.20]

Press to insert a disc into or remove it from the tray.

13. HEADPHONE Jack

To connect headphone (not supplied) for personal listening.

14. PICTURE Button

[P.13]

Press to adjust the picture.

15. Number Buttons

TV Mode:

[P.13]

Press two digits to directly access the desired channel. Remember to press [0] before a single digit channel.

+100 Button–

Press to select cable channels which are higher than 99.

DVD Mode:

[P.22]

Press to enter the desired number.

+10 Button–

Press to enter the desired numbers which are higher than 9.

16. SLEEP Button

[P.14]

Sets the Sleep Timer.

17. DISPLAY Button

TV Mode:

Displays the current channel number on the TV screen.

DVD Mode:

[P.25]

Displays the current status on the TV screen.

0 +10

STOP

SLOW

SELECT

+100

PLAY

ENTER

REPEATSEARCH MODE

FWD

OPEN/

CH.

VOL.

MUTEZOOM

DISC

RETURNTITLESETUP

ANGLESUBTITLEAUDIO

12 35

34 33

31 30 29

26 25

POWER PICTURE

123

456

789

SLEEP

SKIP

REV

PAUSE

DISPLAY

18 19

CLEAR

MODE

21 22

- 9 - EN

COAXIAL

ANT.

3736

18. SETUP Button

[P.26]

Press to enter or exit the setup menu of TV or DVD.

19. TITLE Button

[P.20]

Displays the title menu.

20. CLEAR Button

[P.22]

Press to clear or cancel a setting currently entered.

21 MODE Button

[P.23. 24, 25]

Press to call up the program screen or the random screen in the stop mode. Press to call up the Black Level Setting screen or the Virtual Surround screen during playback.

22. SEARCH MODE Button

[P.22]

Press to locate a desired point.

23. AUDIO Button

[P.24]

Press to select a desired audio language or sound mode.

24. SUBTITLE Button

[P.24]

Press to select a desired subtitle language.

25. REPEAT Button

[P.23]

Repeats playback of the current disc, title, chapter, or track.

26. ANGLE Button

[P.24]

Press to change the camera angle to see the sequence being played back from a different angle (if available).

27. A-B Button

[P.23]

Repeats playback of a selected section.

28. RETURN Button

[P.22]

Returns to the previous screen in the setup menu.

29.K/L/ { / B Buttons

TV Mode:

[P.13]

Press to select a setting mode from the menu on the TV screen. Press to select or adjust from a particular menu.

DVD Mode:

[P.20]

Press to select a menu item.

30. ENTER Button

[P.15]

Press to accept a setting.

31. DISC MENU Button

[P.20]

Calls up the DVD menu.

32. REV E Button [P.21]

Press to view the DVD picture in fast reverse or slow reverse motion.

FWD D Button [P.21]

Press to view in fast or slow forward motion.

33. ZOOM Button

[P.21]

Enlarges part of a DVD-reproduced image.

34. MUTE Button

[P.13]

Mutes the sound. Press it again to restore sound.

35. SELECT Button

[P.11]

Press to change to TV mode, external input mode or DVD mode.

36. COAXIAL Jack

[P.11]

Connect to the digital input of an external amplifier or decoder (for DVD Audio only).

37. ANT. Jack

[P.10]

Connect to an antenna, cable system or satellite system.

38. Power cord

[P.13]

Connect to a standard AC outlet (120V/60Hz).

NOTE:

•

Remove the power cord from the hook to avoid breaking a wire before you connect to a standard AC outlet.

- REAR PANEL - [Fig.3]

NOTE:

•

We do not recommend the use of universal remote controls. Not all of the functions may be controlled with a universal remote control.

If you decide to use a universal remote control with this unit, please be aware that the code number given may not operate this unit. In this case, please call the manufacturer of the universal remote control.

- 10 - EN

NOTE:

Before plugging the antenna into the ANT. jack of the unit, check that the pin is not bent. If it is bent, straighten the pin as illustrated, then plug the pin into the ANT. jack of the unit.

Bent pin

Cable

Plug

(Needs to be

straightened)

(Straight pin)

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

For your safety and to avoid damages to the unit, unplug the antenna cable from the ANT. jack before moving the unit.

[Fig. 4]

PREPARATION FOR USE

ANTENNA/CABLE CONNECTIONS

Plug the incoming cable into the ANT. jack on the rear of the unit. If your cable service supplies you with a converter box or if you use a satellite system, connect the box with this unit as shown below.

COAXIAL

ANT.

Cable

TV signal

Antenna

OUT

Rear of the unit

*NOTE (DO NOT DISCONNECT FROM BOX) Some cable TV systems use scrambled signals and require a special converter to receive these channels. Consult your local cable company.

Incoming cable from home Antenna / Cable Company (No Cable Box)

Incoming cable from Cable Company or Satellite Antenna

Cable Box or Satellite Box*

- 11 - EN

CONNECTING TO FRONT A/V INPUT JACKS

When you watch a program recorded on another source (VCR or video camera), use the AUDIO/VIDEO input jacks on the front of the unit.

Connect the Audio/Video output jacks of another source to the AUDIO L/R and VIDEO jacks of this unit.

Then press [SELECT] or [CH. KK/LL] until “AUX” appears on the screen.

CONNECTING TO A STEREO AMPLIFIER EQUIPPED WITH

DIGITAL INPUT JACKS (for DVD)

Use an audio coaxial digital cable (commercially available) for the audio connections. Connect to an amplifier equipped with digital input jacks such as MD Deck or DAT Deck.

NOTES:

•

The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital sound by an MD or DAT deck.

•

Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner’s Manuals for the components to be connected to the unit.

•

Set “DOLBY DIGITAL” to “PCM” for audio output in the setup mode. Playing a unit using incorrect settings may generate noise distortion and may also damage the speakers. (Refer to page 27.)

COAXIAL

ANT.

ex. MD deck, DAT deck, etc.

To Coaxial digital Audio input jack

To COAXIAL jack (Only DVD AUDIO OUT)

[Fig. 6]

[Front of the unit]

[Fig. 5]

To the Audio output jacks

To the Video output jack

NOTE:

•

When you connect a monaural VCR (another source) to this unit, connect the Audio output jack of the monaural VCR (another source) to the AUDIO L jack of this unit. The audio will output in both L and R channel equally.

AUX

(OUT)

(IN)

(OUT)

(IN)

(OUT)

(IN)

Audio Cable (commercially available)

Video Cable (commercially available)

VIDEO AUDIO

L R

POWER VOLUME CHANNEL SKIP SKIPPLAY PAUSESTOP

YXY

R Q N

P O S

E –

–

HEADPHONE

OPEN/CLOSE

ex. VCR or video camera

, etc.

VIDEO AUDIOyPOWER

L R

- 12 - EN

COAXIAL

ANT.

Front speaker

(left)

Center

speaker

Front speaker

(right)

Surround

speaker

(left)

Surround

speaker

(right)

Subwoofer

Dolby Digital

decoder

To Coaxial digital Audio input jack

To COAXIAL jack (Only DVD AUDIO OUT)

[Fig. 7]

CONNECTING TO A DOLBY DIGITAL DECODER (for DVD)

If using this unit to play a DVD disc in a 5.1 channel Dolby Digital surround format, the unit outputs a DOLBY DIGITAL Data stream from its COAXIAL jack. By hooking the unit up to a Dolby Digital decoder, you can enjoy a more convincing, realistic ambience with powerful and high-quality surround sound as enjoyed in movie theaters.

Use audio coaxial digital cables (commercially available) for the audio connections.

NOTES:

•

Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner’s Manuals for the components to be connected to the unit.

•

If connected to a Dolby Digital decoder, set “DOLBY DIGITAL” to “BITSTREAM” for audio output in the setup mode. (Refer to page 27.)

•

Unless connected to a Dolby Digital decoder, set “DOLBY DIGITAL” to “PCM” for audio output in the setup mode. Playing a unit using incorrect settings may generate noise distortion and may also damage the speakers. (Refer to page 27.)

Manufactured under license from Dolby Laboratories.“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

(OUT)

(IN)

INSTALLING THE BATTERIES

1)Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.

2)Insert 2 “AA” penlight batteries into the battery compartment in the direction indicated by the polarity (+/-) markings.

3)Replace the cover.

[BATTERY PRECAUTIONS]

•

Be sure to follow the correct polarity as indicated in the battery compartment. Reversed batteries may cause damage to the device.

•

Do not mix different types of batteries together (e.g. Alkaline and Carbon-Zinc) or old batteries with fresh ones.

•

If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from possible battery leakage.

•

Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.

- 13 - EN

TV SECTION

TV OPERATION AND SETTINGS

DEGAUSSING

This television has a degaussing circuit that will clear up color errors on the TV screen that are caused by any excess magnetism which happens to get too close to the TV. This circuit is designed to operate once when the set is first plugged in. If minor color

errors are seen in some locations on the screen, please unplug the TV for approximately 30 minutes. When the TV is plugged back in, the degauss-

ing circuit will operate once to clear them up. Repeat this procedure any time the TV screen is accidentally magnetized or when the TV is moved or relocated.

WATCHING A TV PROGRAM

1 Plug in the unit power cord

Plug the unit power cord into a standard AC outlet.

NOTE:

•

If any digits appear in the corner of the screen, press [POWER] without unplugging the power cord.

2 Turn on the unit

Press [POWER] to turn on the unit.

3 Select the channel number

Press [CH.KK/LL] or the Number buttons to select your desired channel number.

Notes for using the Number buttons:

¡You must precede single-digit channel numbers

with a zero (for example: 02, 03, 04 and so on).

¡When selecting cable channels which are higher

than 99, press [+100] first, then press the last two digits. (Example: to select channel 125, first press [+100] then press [2] and [5].)

4 Adjust sound

Press [VOL.X/Y] to adjust the volume.

Press

[MUTE] to instantly mute

the sound. Press it again to restore the previous sound level.

NOTE:

•

If you press [CH.KK/LL] in the DVD mode, you can change the TV channels. Even if you turn off the unit in the DVD mode, when you turn it on again, it will go into the TV mode.

TO WATCH CABLE OR SATELLITE CHANNEL

•

If the unit is connected to a cable box or satellite box, press [CH.KK/LL] to select CH3 or CH4 according to the output channel setting of the device and select desired channel on that device.

TO WATCH EXTERNAL INPUT

•

When an external equipment is connected to the front AUDIO/VIDEO input jacks, press [SELECT] or [CH.KK/LL] repeatedly until “AUX” appears on the screen.

BRIGHT to decrease to increase

brightness brightness

CONTRAST to decrease to increase

contrast contrast

COLOR to pale to brilliant TINT to purple to green

SHARPNESS to soft to clear

PICTURE CONTROL

The unit’s picture controls – BRIGHT, CONTRAST, COLOR, TINT and SHARPNESS – are

preset to factory specifications. Although they are usually the best, you may need to make some further adjustments for a more natural looking image.

Make sure ...

•

The unit must be turned on.

1 Call up the menu

Press [PICTURE].

2 Select item you want to adjust

Press [KK/LL] until desired control is displayed.

BRIGHT CONTRAST COLOR TINT SHARPNESS

3 Adjust the setting

Press [s/ B]to adjust to your desired level within 5 seconds.

•

Even if there is a power failure of any kind, the unit will retain its memory for this feature.

BRIGHT

–

PP PP PP PP PP PP PP CC PP PP PP PP PP PP PP

VOLUME 20

C C C C C C C C C C C C C C C C

- 14 - EN

•

If the unit displays a black box on the TV screen, this means that the unit is set to the TEXT mode. To clear screen, select [CAPTION1], [CAPTION2] or [OFF].

Make sure ...

•

The unit must be turned on.

1 Select “CAPTION”

Press [SETUP]. Press

[KK/LL] to point to “CAP-

TION”.

2 Select your desired caption mode

Press [ENTER] repeatedly until your desired caption menu appears.

([CAPTION1], [CAPTION2], [TEXT1] or [TEXT2])

3 Exit the caption setting mode

Press [SETUP] to exit the menu. NOTE:

•

Even if there is a power failure of any kind, the unit will retain its memory for this feature.

TO CANCEL THE CLOSED CAPTION SYSTEM

Repeat steps 1 to 2 and select [OFF] using [ENTER]. Then press [SETUP] to return to TV mode.

CLOSED CAPTION SYSTEM

You can view specially labeled (cc) TV programs, movies, news and pre-recorded tapes with either a dialogue caption or text display.

CAPTION mode: You can watch dramas, movies and

news while captioning the dialogues and the contents of news.

TEXT mode: You can watch half screen text informa-

tion if you want.

1-2: You may get these captions or text information

by selecting either “1” or “2”. Caption “2” is usually used for a second language if available.

NOTES:

•

Not all programs are broadcast with closed captions. Your unit is designed to provide error free closed captions from high quality antenna, cable and VCR signals. Conversely, poor quality signals are likely to result in caption errors or no captions at all. Common signal conditions which may cause caption errors are listed below:

•

Automobile ignition noise

•

Electric motor brush noise

•

Weak snowy reception on TV screen

•

Multiplex signal reception displaying picture ghosts or airplane flutter

SLEEP TIMER

The Sleep Timer function turns off the unit without using [POWER] after a desired period of time.

1 Call up the Sleep Timer Setting

Press [SLEEP] so that “SLEEP 0 MINUTE” appears.

2 Set sleep time

Press [SLEEP] repeatedly until your desired sleep time appears.

Each additional press will increase the time by 30 minutes up to 120 minutes.

After 5 seconds, the Sleep Timer setting will disappear automatically.

TO CANCEL THE SLEEP TIMER

Press [SLEEP] to call up the Sleep Timer Setting. Press [SLEEP] repeatedly until “SLEEP 0 MINUTE” appears.

SLEEP 120 MINUTE

- TV SETUP -

CHANNEL SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [OFF]

- TV SETUP -

CHANNEL SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [CAPTION1]

- 15 - EN

CHANNEL SET UP

Make sure ...

•

The unit must be turned on.

AUTO CHANNEL PROGRAMMING

As the initial setting, this unit has memorized all channels, including the ones not available in your area. This feature automatically puts only available channels into the memory.

1 Select “CHANNEL SET UP”

Press [SETUP]. Press

[KK/LL]

to point to

“CHANNEL SET UP”, then press [ENTER].

2 Begin channel scanning

Press

[KK/LL]

to point to “AUTO CH

PROGRAMMING”, then press [ENTER].

The tuner scans and memorizes all the active channels in your area.

3 After scanning

The tuner stops on the lowest memorized channel.

NOTES:

•

When “AUTO CH PROGRAMMING” is activated where there is no TV signal input, “NO TV SIGNALS” will appear on the display after the completion of channel scanning.

•

The unit may recognize CATV channels to be TV channels if reception condition is poor. In this case, check the antenna connection and try “AUTO CH PROGRAMMING” again when reception conditions are better.

•

Channel memory programming is NOT necessary when connected to a cable box or satellite box. Just select the channel for cable box or satellite input (ex. CH3) on the unit, then select your desired channel on the cable box or satellite box.

– CHANNEL SET UP –

ADD / DELETE CH (CATV)

B AUTO CH PROGRAMMING

- TV SETUP -

B CHANNEL SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF]

ADDING/DELETING CHANNELS

The channels you no longer receive or seldom watch can be deleted from the memory. (Of course, you can add the deleted channel into the memory again.)

1 Select “CHANNEL SET UP”

Press [SETUP]. Press

[KK/LL]

to point to “CHAN-

NEL SET UP”, then press [ENTER].

2 Select “ADD/DELETE CH”

Press

[KK/LL]

to point to

“ADD/DELETE CH”, then press [ENTER].

3 Enter the desired channel number

Press [CH.KK/LL] or the Number buttons until your desired channel

number appears. (You can also press [KK/LL] to enter it.)

•

You must precede single-digit channel numbers with a zero (Example: 02 ... 09).

•

When selecting cable channels which are higher than 99, press [+100] first, then press the last two digits. (Example: to select channel 125, first press [+100] then press [2] and [5].)

4 Delete (or add) it from (or into) memory

Press [ENTER]. The channel number changes to light red. The channel is deleted from memory.

•

To delete another channel, repeat steps 3 to 4.

•

If you press [ENTER] again, the channel is memorized again.

5 Exit the channel setup mode

Press [SETUP] to exit the menu. NOTE:

•

To confirm that channel(s) has been deleted or added, press [CH.KK/LL].

– CHANNEL SET UP –

B ADD / DELETE CH (CATV)

AUTO CH PROGRAMMING

ADD / DELETE

- TV SETUP -

B CHANNEL SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF]

Added channel : Light blue Deleted channel : Light red

(Example: CH8)

NO TV SIGNALS

- 16 - EN

This feature enables parents to prevent their children from watching inappropriate material on TV. When you try to access a program which is blocked, “PROTECTED PROGRAM by ...” message appears on the TV screen.

V-CHIP SET UP

Make sure ...

•

The unit must be turned on.

1 Select “V-CHIP SET UP”

Press [SETUP]. Press

[KK/LL] to select “V-CHIP SET

UP”, then press [ENTER].

2 Enter Access code

Press the Number buttons to enter the access code.

•

For the first time set-up or in the event the unit has lost power, enter the default code of 0000.

3 Select the desired item

Press [KK/LL] to select “TV RATING”, “MPAA RATING” or “CHANGE CODE”, then press [ENTER].

Refer to the pages below to set up each item.

TV RATING SET UP

Follow steps 1to 3in the “V-CHIP SET UP” section above.

4 Blocking TV programs

Press [KK/LL] to select a rating that you wish to block.

Press

[ENTER] repeatedly to set it

to [BLOCK] or [VIEW].

V-CHIP SET UP

B TV–Y [VIEW]

TV–Y7 ( ) [VIEW] TV–G [VIEW] TV–PG ( ) [VIEW] TV–14 ( ) [VIEW] TV–MA( ) [VIEW]

Selection Rating Category Explanations

TV-Y Appropriate for all children TV-Y7 Appropriate for children seven and older TV-G General Audience TV-PG Parental Guidance suggested TV-14 Unsuitable for children under 14 TV-MA Mature audience only

NOTES:

•

When you select a rating and set it to [BLOCK], the higher ratings will be blocked automatically. The lower ratings will be available for viewing.

•

When you set the lowest rating to [VIEW], all other ratings will automatically be available for viewing.

5 Setting “Sub-Ratings”

When you select the ratings of TVY7, TV-PG, TV-14 or TV-MA you will have the option of setting sub rating categories.

Press

[KK/LL] to select a rating with

sub-ratings you wish to block, then press [ENTER] twice.

Press

[KK/LL] to select a sub-rating,

then press [ENTER] to set it to [BLOCK] or [VIEW].

NOTE:

•

The blocked sub-ratings will appear next to the rating category in the “TV RATING” menu.

6 Exit the V-Chip setting mode

Press [SETUP] to exit the menu. NOTE:

•

To change the rating, the TV must be turned to an unprotected program. If “PROTECTED PROGRAM by ...” appears on the screen, please change the channel to a station that is not protected.

TV–Y [VIEW] TV–Y7 ( ) [VIEW] TV–G [VIEW]

B TV–PG (DLSV ) [BLOCK]

TV–14 (DLSV ) [BLOCK] TV–MA ( LSV) [BLOCK]

TV–Y7 [BLOCK]

B FV [BLOCK]

TV–PG [BLOCK]

B D [BLOCK]

L [BLOCK] S [BLOCK] V [BLOCK]

Selection Rating Category Explanations

TV-Y7

FV Fantasy Violence

TV-PG, TV-14, TV-MA

D Suggestive Dialog

(TV-PG, TV-14 only) L Coarse Language S Sexual Situation VViolence

ACCESS CODE

_ _ _ _

– V-CHIP SET UP –

B TV RATING

MPAA RATING CHANGE CODE

A B C

TV–Y [VIEW]

B TV–Y7 ( ) [VIEW]

TV–G [VIEW] TV–PG ( ) [VIEW] TV–14 ( ) [VIEW] TV–MA( ) [VIEW]

PROTECTED PROGRAM

by TV-Y

TV–Y [VIEW] TV–Y7 ( ) [VIEW]

B TV–G [BLOCK]

TV–PG (DLSV ) [BLOCK] TV–14 (DLSV ) [BLOCK] TV–MA ( LSV) [BLOCK]

P16 Step

P17 Step

- TV SETUP -

CHANNEL SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF]

- 17 - EN

CHANGE ACCESS CODE

Follow steps 1to 3in the “V-CHIP SET UP” section on page 16.

4 Enter New code

Press the Number buttons to enter your desired access code in the “NEW CODE” space, then enter the same code in the “CONFIRM CODE” space. When completed, the menu will return to “V-CHIP SET UP”.

•

Make sure you enter exactly the same new code in the “CONFIRM CODE” space as one in the “NEW CODE” space. If they are different, the “NEW CODE” space is cleared for redoing.

5 Exit the V-Chip setting mode

Press [SETUP] to exit the menu. NOTE:

•

Your personal access code will be erased and will return to the default (0000) when a power failure occurs or when you turn off the power using a wall switch. If you have forgotten the code, unplug the power cord for 10 seconds to restore the access code to 0000.

NEW CODE

X X X X

CONFIRM CODE

_ _ _ _

MPAA RATING SET UP

Follow steps 1to 3in the “V-CHIP SET UP” section on page 16.

4 Select your desired item

Press [KK/LL] to point to your desired item, then press [ENTER] to select [BLOCK] or [VIEW].

•

When you select a rating and set it to [BLOCK], the higher ratings will be blocked automatically. The lower ratings will be available for viewing.

•

When you set the lowest rating to [VIEW], all other ratings will automatically be available for viewing.

5 Exit the V-Chip setting mode

Press [SETUP] to exit the menu.

Selection Rating Category Explanations

G General Audience PG Parental Guidance suggested. PG-13 Unsuitable for children under 13 R Restricted; under 17 requires accompa-

nying parent or adult guardian NC-17 No one under 17 admitted X Mature audience only

G [VIEW] PG [VIEW] PG–13 [VIEW]

B R [BLOCK]

NC–17 [BLOCK] X [BLOCK]

1 Select “LANGUAGE”

Press [SETUP]. Press

[KK/LL] to point to

“LANGUAGE”.

2 Select “ENGLISH”, “ESPAÑOL” or “FRANÇAIS”

Press [ENTER] repeatedly to select “ENGLISH”, “ESPAÑOL”= Spanish or “FRANÇAIS”= French.

3 Exit the Language mode

Press [SETUP] to exit the menu. NOTES:

•

This function effects only the language on the screen menu and not the audio source.

•

If for some reason the menu is in Spanish or French, press [SETUP], press [KK/LL] to point to “IDIOMA [ESPAÑOL]” or “LANGAGE [FRANÇAIS]”, then press [ENTER] repeatedly to select desired language, then press [SETUP].

MENU LANGUAGE

- TV SETUP -

CHANNEL SET UP V-CHIP SET UP

B LANGUAGE [ENGLISH]

CAPTION [OFF]

- 18 - EN

CABLE CHANNEL DESIGNATIONS

If you subscribe to cable TV, the channels are displayed as 1-125. Cable companies often designate channels with letters or letter-number combinations. Please check with your local cable company. The following is a chart of common cable channel designations.

TV Display

CATV channel

TV Display

W+80 W+81 W+82 W+83 W+84

W+65 W+66 W+67 W+68 W+69 W+70 W+71 W+72 W+73 W+74 W+75 W+76 W+77 W+78 W+79

W+55 W+56 W+57 W+58 A-4 A-3 A-2 A-1 W+59 W+60 W+61 W+62 W+63 W+64

W+40 W+41 W+42 W+43 W+44 W+45 W+46 W+47 W+48 W+49 W+50 W+51 W+52 W+53 W+54

W+25 W+26 W+27 W+28 W+29 W+30 W+31 W+32 W+33 W+34 W+35 W+36 W+37 W+38 W+39

W+10 W+11 W+12 W+13 W+14 W+15 W+16 W+17 W+18 W+19 W+20 W+21 W+22 W+23 W+24

A-5

RSTUVWW+1 W+2 W+3 W+4 W+5 W+6 W+7 W+8 W+9

CDEFGH I JK LMNOPQ

5A 2 3 4 5 6 7 8 9 10 11 12 13 A B

123456789101112131415

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

46 47 48 49 50 51 52 53 54 55 56 57 58 59 60

61 62 63 64 65 66 67 68 69 70 71 72 73 74 75

76 77 78 79 80 81 82 83 84 85 86 87 88 89 90

91 92 93 94 95 96 97 98 99 100 101 102 103 104 105

106 107 108 109 110 111 112 113 114 115 116 117 118 119 120

121 122 123 124 125

CATV channel

- 19 - EN

DVD SECTION

ABOUT THE DISCS

If you cannot play back a disc which bears one of the marks above, check the following notes.

*1: This unit conforms to the NTSC color system. Discs recorded in other color systems such as PAL cannot

be played back.

*2: Certain DVD-Video discs do not operate as described in this manual due to the intentions of the disc’s

producers. *3: Discs recorded in the VR (Video Recording) format cannot be played back. *4: Scratched or stained discs may not be played back. *5: Some discs cannot be played back because of incompatible recording conditions, characteristics of the

recorder or special properties of discs. *6: You can play back discs which bear the marks above. If you use nonstandardized discs, this unit may not

play them back. Even if they are played back, the sound or video quality will be compromised. *7: You may play back the unfinalized DVD-R/RW disc recorded in the video format on our brand’s DVD

recorder. However, depending on the recording status of a disc, the disc may not be played back at all or

normally (the picture or sound may not be smooth, etc.). In this case, you need to finalize the disc with

the DVD recorder. Refer to the manual accompanying the DVD recorder. *8: Only the discs recorded in the video format and finalized can be played back.

Unfinalized discs cannot be played back. Depending on the recording status of a disc, the disc may not be

played back at all or normally (the picture or sound may not be smooth, etc.). *9: If there is too much recording space left on a disc (the used portion is less than 55mm across), it may not

play back properly.

*10: Do not glue paper or put stickers on to the disc. These may damage the disc and the unit may not read it

correctly.

*11: The number inside the symbol refers to a region of the world and a disc encoded in a specific region for-

mat can only be played back on unit with the same region code.

DVD-Video

* 1,2,4,6,10,11

* 4,6,10

* 4,5,6,9,10

* 1,3,4,5,6

7,9,10

DVD-RW

DVD-R

* 1,3,4,5,6,8,9,10

DVD+RW

DVD+R

Audio CD

CD-RW

CD-R

Digital video

(MPEG2)

Digital audio

Region code

Mark (logo)

Playable

discs

Recorded

signals

Disc size

Disc types

12 cm

8 cm

12 cm

8 cm

Example

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1

Chapter 2

Chapter 3 Chapter 4

Example

Tra c k 1

Tra c k 2

Tra c k 5

Tra c k 6

Tra c k 3

Tra c k 4

NEVER play back the following discs. Otherwise, malfunction may result!

DVD-RAM / CD-I / Photo CD / Video CD / DVD with region codes other than 1 or ALL / DTS-CD / DVD-ROM for personal computers / CD-ROM for personal computers / MP3

On the following disc, the sound MAY NOT be heard.

Super Audio CD NOTE: Only the sound recorded on the normal CD layer can be delivered.

The sound recorded on the high density Super Audio CD layer cannot be delivered.

Any other discs without compatibility indications

PLAYABLE DISCS

UNPLAYABLE DISCS

is a trademark of DVD Format/Logo Licensing Corporation.

- 20 - EN

PLAYING A DISC

BASIC PLAYBACK

Getting started

¡Turn on the power of amplifier and any other com-

ponents, if necessary.

1 Press [POWER].

¡The power will turn on.

2 Press [OPEN/CLOSE A] to open disc load-

ing tray.

3 Place the chosen disc in the tray, with the

label facing up.

DVD-V

4 Press [PLAY O].

¡The tray will close automatically and playback will

then start from the first chapter or track of the disc.

¡Closing the disc tray manually or by pressing

[OPEN/CLOSE A] also starts playback.

¡If the playback does not start automatically, press

[PLAY O].

¡When you playback a DVD which features a title

menu, it may appear on the screen. In this case, refer to “TITLE MENU” on this page.

5 Press [STOP C] to stop playback.

NOTES:

¡When the DVD mode has been switched to the TV

mode, the DVD mode shuts down first and then the TV picture and sound appears in about 4 seconds. Similarly, when

[POWER] is pressed to turn off in the

DVD mode, this mode shuts down first and then the unit is turned off.

¡A “prohibited icon” may appear at

the top-right on the TV screen during operation, warning that a prohibited operation has been encountered by the DVD or the disc.

¡With DVDs that use titles for playback program sig-

nals, playback may start from the second title or it may skip these titles.

¡During the playback of a two layered disc, pictures

may stop for a moment. This happens when the 1st layer switches to the 2nd layer. This is not a malfunction.

GENERAL FEATURES

VD may contain menus to navigate the disc and

access special features. Press the appropriate Number buttons or [K / L / s / B] to highlight your selection in the DVD main menu and press

[ENTER] to confirm. NOTES:

¡Select DVD mode by pressing [SELECT], then

operate the DVD functions.

¡Unless stated, all operations described are based on

remote control use. Some operations can be carried out using the menu bar on the TV screen.

DVD-V

TITLE MENU

1 Press [TITLE].

¡The title menu will appear. ¡If the feature is not available, symbol may

appear on the TV screen.

2 Press [K / L / s / B] to select an item, and

press [ENTER] to confirm selection.

DVD-V

DISC MENU

1 Press [DISC MENU].

¡The DVD main menu will appear. ¡If the feature is not available, symbol may

appear on the TV screen.

¡If disc menu is available on the disc, audio lan-

guage, subtitle options, chapters for the title and other options will appear for selection.

2 Press [K / L / s / B] to select an item and

press [ENTER] to confirm selection.

DVD-V

CALLING UP A MENU SCREEN

DURING PLAYBACK

¡Press [DISC MENU] to call up the DVD menu. ¡Press [TITLE] to call up the title menu.

NOTE:

¡Contents of menu and corresponding menu opera-

tions may vary between discs. Refer to the manual accompanying the disc for details.

- 21 - EN

STEP BY STEP PLAYBACK

1 During playback, press [PAUSE F].

¡Playback will pause and sound will be muted.

2 The disc goes forward by one frame each

time [PAUSE

F] is pressed.

To exit step by step playback, press [PLAY O].

DVD-V

RESUME

1 During playback, press [STOP C].

¡Resume message will appear on the TV screen.

2 Press [PLAY O], playback will resume from the

point at which playback was stopped.

¡To cancel resume, press [STOP C] twice. ¡The resume information stays on even when the

power is turned off.

DVD-V

1 During playback, press [FWD D] or

[REV

E].

¡“D 1” or “E 1” appears on the screen.

2 To select another speed, repeat step 1 until

your required speed number appears on the screen.

¡For DVDs, fast forward/reverse search speed is dif-

ferent depending on the disc. Approximate speed is 1(×2), 2(×8), 3(×20), 4(×50) and 5(×100).

¡For Audio CDs approximate speed is 1(×2), 2(×8)

and 3(

×30).

When you press buttons on the front panel, press and hold

[SEARCHE/ D] for a few seconds.

To return to normal playback, press [PLAY O]

DVD-V

FAST FORWARD /

FAST REVERSE

PAUSE

1 During playback, press [PAUSE F].

¡Playback will pause and sound will be muted.

2 To continue playback, press [PLAY O].

DVD-V

SLOW FORWARD /

SLOW REVERSE

1 During playback, press [PAUSE F]. 2 Press [FWD D] or [REV E] .

¡“ 1” or “ 1” appears on the screen.

3 To select another speed, repeat step 2 until

your required speed number appears on the screen.

¡Slow forward or reverse speed varies with the disc.

Approximate speed is 1(1/16), 2(1/8) and 3(1/2).

When you press buttons on the front panel, press and hold [SEARCHE/ D] for a few seconds.

To return to normal playback, press [PLAY O].

DVD-V

ZOOM

The Zoom function allows you to enlarge the video image and to pan through the enlarged image.

1 Press [ZOOM] during playback.

¡Playback will continue.

2 Press [ZOOM] repeatedly to select the

required zoom factor: ZOOM1, ZOOM2, ZOOM3 or OFF.

3 Press [K / L / s / B] to move the zoomed

picture across the screen.

4 To exit zoom mode, press [ZOOM] to OFF.

NOTES:

¡Zooming function does not work while disc menu is

shown.

¡Zooming function is not available on some discs. ¡It may take several seconds to slide the zoomed pic-

ture.

¡The picture may be distorted if you operate other

functions repeatedly (ex. [PAUSE FF] or [REV E], etc.) in the zoom mode.

DVD-V

- 22 - EN

SEARCH FUNCTION

TRACK SEARCH

There are three ways to begin playback on an Audio CD at a specific track.

Using the Number buttons

1 Press the Number buttons to enter the

desired track number.

¡Playback will start at the selected track. ¡For single digit tracks (1-9), press a single number

(eg. track 3, press [3]).

¡To play track 26, press [+10], [2], [6].

Using [SEARCH MODE]

1 Press [SEARCH MODE].

¡The track search display appears.

2 Within 30 seconds, select the desired track

number using the Number buttons.

¡For single digits press [0] first, if the total track of

the disc is 10 tracks or more.

¡Playback will start at the selected track.

Using [SKIP

H/ G

]

During playback, press [SKIP G] to move the next track. Press it repeatedly to skip subsequent tracks. Press [SKIP H] to go back to beginning of the current track. Press it repeatedly to go to the previous tracks.

¡If [SKIP H / G ] is pressed while the playback

is paused, the playback will be paused again after skipping to the next track.

NOTE:

¡[SKIP H / G ] are not operative when playback

is stopped.

TITLE / CHAPTER SEARCH

1 Press [SEARCH MODE] once for the

Chapter search, twice for the Title search during playback.

2 Enter the desired chapter/title number using

the Number buttons.

¡Playback will start at the selected chapter or title. ¡Press [CLEAR] to erase the incorrect input. ¡For single digits press [0] first, if the total number of

chapter or title of the disc is 10 or more.

DVD-V

_/2

TIME SEARCH

1 During playback, press [SEARCH MODE]

three times (CD: twice) to display the Time Search on the TV screen.

2 Within 30 seconds, enter a desired disc

time using the Number buttons.

¡Playback will start at the specified time. ¡Press [CLEAR] to erase the incorrect input. ¡When there is no need to enter a number, “0”

appears automatically. For example, “ 0 : 0 - :

- -

” appears in the Time Search display if the total time of the track or title is less than 10 minutes.

DVD-V

MARKER SETUP SCREEN

Use markers to memorize your favorite places on a disc.

1 Press [SEARCH MODE] four times (CD:

three times) during playback.

¡The display screen and Markers will appear on the

TV screen.

2 Press [s / B] to select 1, 2, 3, 4, 5, 6, 7, 8, 9,

or 10 and ensure that “

- - - - :- - :- -

”

appears in the display.

3 When you reach the desired point, press

[ENTER].

¡The Title or Track and elapsed playing time will

appear in the TV screen.

4 To return to the Marker later, press

[SEARCH MODE] four times (CD: three times) during playback and press [

s / B] to choose the desired marker, then press [ENTER].

NOTES:

¡Operations which erase all Markers:

– Opening the disc tray. – Turning off the power. – Pressing [SELECT]. – Selecting “AC” at step

2 and pressing [ENTER].

¡To clear a marker:

– Press [s / B] to select a cursor on to the marker

number and press

[CLEAR].

¡Yo u can mark up to 10 points.

5 Press [SEARCH MODE] or [RETURN] to

exit.

DVD-V

- 23 - EN

SPECIAL PLAYBACK FUNCTION

REPEAT

REPEAT TITLE / CHAPTER

To activate the repeat function, press [REPEAT] during playback.

¡The repeat mode changes as described below every

time you press the button.

DVD-V

REPEAT is available only during playback.

CHAPTER TITLE OFF

(current chapter repeat) (current title repeat)

(repeat

off)

NOTES:

¡Repeat Title/Chapter is not available with some

scenes.

¡The REPEAT setting will be cleared when moving

to other title or chapter.

REPEAT TRACK

To activate the repeat function, press [REPEAT] during playback.

¡The repeat mode changes as described below every

time you press the button.

TRACK ALL OFF

(current track repeat) (entire disc repeat)

(repeat

off)

NOTES:

¡Repeat Track setting will be cleared when moving

to other track.

¡Repeat playback does not function during A-B

repeat playback.

A-B REPEAT

1 Press [A-B] at your chosen starting point.

¡“ A-” appears briefly on the TV screen.

2 Press [A-B] again at your chosen end point.

¡“ A-B” appears briefly on the TV screen, and the

repeat sequence begins.

3 To exit the sequence, press [A-B].

NOTES:

¡The A-B repeat section can only be set within the

current title (for DVDs) or current track (for Audio CDs).

¡A-B repeat is not available with some scenes in

DVD.

¡To cancel the A point which was set, press

[CLEAR].

¡A-B repeat playback does not function during title,

chapter, track or all repeat playback.

DVD-V

PROGRAM

You may determine the order in which tracks will play.

1 In the stop mode, press [MODE].

¡The “PROGRAM” screen will appear.

2 Press [

KK/LL

] to select a track, then press

[ENTER].

¡Press [CLEAR] to erase the

most recently entered track.

¡If the entire Program cannot be

displayed at once on a screen, “G” appears to go to the next page and “H” appears to go back to the previous page.

3 Repeat step 2 until you have selected all the

tracks you want to play in the program.

Press [PLAY O] to play the programmed tracks.

NOTES:

¡While the program is being played back, pressing

[STOP C] works as follows.

¡Press [STOP C] once and then [PLAY O] again,

playback will restart from the point where [STOP C] was pressed. (Program continued)

¡Press [STOP C] twice and then [PLAY O] again,

playback will restart from the track in the usual way. (Program canceled)

¡Up to 99 tracks can be entered. ¡To erase all tracks in the program at once, select

“ALL CLEAR” at the bottom of the list at step 2.

¡If you like to repeat the current track in the program,

press [REPEAT] several times until “ TRACK” appears during playback. If you like to repeat the entire program press [REPEAT] several times until “ ALL” appears during playback.

RANDOM PLAYBACK

This function shuffles the playing order of tracks instead of playback in the sequence.

1 In the stop mode, press [MODE] twice.

¡“RANDOM” screen appears.

2 Press [PLAY O] to start random playback.

NOTE:

¡If you like to repeat the current track in the random

selection, press

[REPEAT] several times until

“ TRACK” appears during playback. If you like

to repeat the entire random selection press [REPEAT] several times until “ ALL” appears during playback.

PROGRAM

ENTER

PLAY

CLEAR

CD-DA

1 3:30 2 4:30 3 5:00 4 3:10 5 5:10 6 1:30 7 2:30

1 3:30

1/4

TOTAL 1:03:30

1 3:30 5 5:10 10 4:20 11 3:00 12 3:20 17 4:10 22 2:50

2/3

RANDOM

CD-DA TOTAL 0:45:55

PLAY

RANDOM PROGRAM

- - no indication - -

- 24 - EN

CHANGING THE SETTINGS

AUDIO LANGUAGE

The unit allows you to select a language during DVD disc (if multi languages are available) playback.

1 Press [AUDIO] during playback.

2 Press [AUDIO] repeatedly to select your

desired language.

NOTE:

¡Pressing [AUDIO] may not work on some DVDs with

multiple audio languages (e.g. DVDs which allow audio language setting on the disc menu).

DVD-V

STEREO SOUND MODE

1 Press [AUDIO] repeatedly during playback to

select between “STEREO”, “L-ch” or “R-ch”.

STEREO - both right and left channels are active (stereo) L-ch - only left channel is active R-ch - only right channel is active

The unit allows you to select a language for subtitles during DVD disc (if available) playback.

1 Press [SUBTITLE] during playback.

¡The subtitle language will

appear on the display bar at the top of the TV screen.

2 Press [SUBTITLE] repeatedly to select your

desired subtitle language.

3 To turn off subtitles, press [SUBTITLE]

repeatedly until “OFF” appears.

NOTES:

¡Pressing [SUBTITLE] may not work on some

DVDs with multiple subtitle languages. In this case, set it on the disc menu. (Operation varies between discs. Refer to the manual of the disc.)

¡If the desired language is not shown after pressing

[SUBTITLE] several times, the disc does not have subtitles in that language.

¡When “NOT AVAILABLE”

appears on the TV screen, it means no subtitle is recorded on the scene.

¡If you choose a language that has a 3 letter language

code, the code will be displayed every time you change the Subtitle language setting. If you choose any other languages, “---” will be displayed instead. (Refer to page 26.)

DVD-V

SUBTITLE LANGUAGE

CAMERA ANGLE

Some DVD discs contain scenes which have been shot simultaneously from various angles. You can change the camera angle when the “ ” icon appears on the screen.

1 Press [ANGLE] during playback.

¡The selected angle will be displayed on the display

bar at the top of the screen.

¡If the “ANGLE ICON” setting is “OFF” in the

“OTHERS” menu, the “ ” icon will not appear. (Refer to page 28.)

2 Press [ANGLE] repeatedly to select your

desired angle.

DVD-V

Adjust the Black Level Settings to make the black parts of the picture brighter.

1 Press [MODE] during playback.

2 Press [ENTER] to switch “ON/OFF”.

ON: Makes the dark parts brighter. OFF: Shows the original picture as recorded.

(Initial setting)

3 Press [MODE] twice or [RETURN] to exit.

NOTE:

¡The setting will be saved even if the unit is turned

off.

DVD-V

BLACK LEVEL SETTING

1.ENG/6

NOT AVAILABLE

STEREO

1 / 8

1.ENG Dolby D 3/2.1ch 48k/ 3

OFF

- 25 - EN

You can enjoy surround-sound effect over two speakers on this unit.

1 Press [MODE] twice (CD: once) during play-

back.

2 Press [ENTER] to set it “1” (Natural effect),

“2” (Emphasized effect) or “OFF”.

3 Press [MODE] to exit.

¡You can also exit the menu by pressing [RETURN].

NOTE: (for CD play only)

¡Virtual Surround will not be effective if the sound

mode is set to something other than STEREO.

DVD-V

VIRTUAL SURROUND

THE ON-SCREEN INFORMATION

For Audio CDs

1 Press [DISPLAY] during playback to show

the current Track.

¡The elapsed and remaining playing time of the cur-

rent track will be displayed.

2 Press [DISPLAY] again to show current Total

Track.

¡The elapsed and remaining playing time of the total

track will be displayed.

3 Press [DISPLAY] again to exit.

NOTE:

¡When you are playing a disc in PROGRAM or

RANDOM mode, “ PROGRAM” (or RANDOM) will be displayed at step 2.

You can check the information about the current disc by pressing [DISPLAY].

DVD-V

For DVD-Vs

1 Press [DISPLAY] during playback to show

current Chapter.

¡The elapsed and remaining

playing time of the current chapter will be displayed.

Press [DISPLAY] again to show current Title.

¡The elapsed and remaining

playing time of the current title will be displayed.

3 Press [DISPLAY] again.

¡The bit rate and the current

repeat setting will be displayed.

¡If you are playing a dual layered disc, the layer num-

ber will also be displayed (L0: Layer 0 is playing. L1: Layer 1 is playing).

4 Press [DISPLAY] again to exit.

OFF

9/49 0:00:00 -0:03:30

4/12 0:03:21 - 0:02:15

4/12 0:13:45 - 0:45:40

1/3 0:00:00 - 1:23:45

TL1

PROGRAM B

- 26 - EN

CHANGING THE DVD SET UP ITEMS

CUSTOM MENU

You can change the DVD player’s settings.

1 Press [SETUP] twice in the stop mode so

that the DVD SETUP menu appears.

Press [L] to select “CUSTOM” then press [ENTER].

NOTE:

If the menu does not appear, press [

PLAY O

] first,

then press

[STOP C]. Make sure the disc is in the stop

mode, then slowly press

[SETUP] twice.

2 Select the desired item.

¡Press [

KK/LL

] to select the desired item then press

[ENTER] to confirm.

Refer to the pages below to set up each item.

LANGUAGE SETTING

Follow steps 1to 2in the “CUSTOM MENU” section above.

3 Press [

KK/LL

] to select the desired item then

press [ENTER].

AUDIO:

Sets the audio language.

SUBTITLE:

Sets the subtitle language.

DISC MENU:

Sets the language for DVD menu.

4 Press [

KK/LL

]to select a setting then press

[ENTER].

¡If “OTHER” is selected on

the “AUDIO”, “SUBTITLE” or “DISC MENU” screen, press four-digit number to enter the code for the desired language. (Refer to the language code list.)

¡Only the languages support-

ed by the disc can be selected.

5 Press [SETUP] to exit the menu.

NOTES:

¡Language Setting for Audio and Subtitle are not

valid for some discs due to default setting of the disc. In this case, set them by pressing

[AUDIO]

and [SUBTITLE]. (Refer to page 24.)

¡If you select a language that is not supported by the

disc, subtitle will automatically be set OFF and the first item of the audio languages will be automatically set.

DVD-V

If you choose a language that has a 3 letter language code, the code will be displayed every time you change the AUDIO or SUBTITLE language setting above. If you choose any other languages, ‘---’ will be displayed instead. (3 letter language code is written in bracket.)

Language Code

A-B

Abkhazian 4748 Afar 4747 Afrikaans 4752 Albanian 6563 Amharic 4759 Arabic 4764 Armenian 5471 Assamese 4765 Aymara 4771 Azerbaijani 4772 Bashkir 4847 Basque 5167 Bengali;Bangla 4860 Bhutani 5072 Bihari 4854 Bislama 4855 Breton 4864 Bulgarian 4853 Burmese 5971 Byelorussian 4851

C-E

Cambodian 5759 Catalan 4947 Chinese [CHI] 7254 Corsican 4961 Croatian 5464 Czech 4965 Danish [DAN] 5047 Dutch [DUT] 6058 English [ENG] 5160 Esperanto 5161 Estonian 5166

F-H

Faroese 5261 Fiji 5256 Finnish [FIN] 5255 French [FRE] 5264 Frisian 5271 Galician 5358 Georgian 5747 German [GER] 5051 Greek [GRE] 5158 Greenlandic 5758 Guarani 5360 Gujarati 5367 Hausa 5447 Hebrew 5569 Hindi 5455 Hungarian [HUN] 5467

I-K

Icelandic [ICE] 5565 Indonesian 5560 Interlingua 5547 Interlingue 5551 Inupiak 5557 Irish [IRI] 5347 Italian [ITA] 5566 Japanese [JPN] 5647 Javanese 5669 Kannada 5760 Kashmiri 5765 Kazakh 5757 Kinyarwanda 6469 Kirghiz 5771 Kirundi 6460 Korean [KOR] 5761 Kurdish 5767

Language Code

L-N

Laothian 5861 Latin 5847 Latvian;Lettish 5868 Lingala 5860 Lithuanian 5866 Macedonian 5957 Malagasy 5953 Malay 5965 Malayalam 5958 Maltese 5966 Maori 5955 Marathi 5964 Moldavian 5961 Mongolian 5960 Nauru 6047 Nepali 6051 Norwegian [NOR] 6061

O-R

Occitan 6149 Oriya 6164 Oromo(Afan) 6159 Panjabi 6247 Pashto;Pushto 6265 Persian 5247 Polish 6258 Por tuguese [POR] 6266 Quechua 6367 Rhaeto-Romance 6459 Romanian [RUM] 6461 Russian [RUS] 6467

Samoan 6559 Sangho 6553 Sanskrit 6547 Scots Gaelic 5350 Serbian 6564 Serbo-Croatian 6554 Sesotho 6566 Setswana 6660 Shona 6560 Sindhi 6550 Singhalese 6555 Siswat 6565 Slovak 6557 Slovenian 6558 Somali 6561 Spanish [SPA] 5165 Sundanese 6567 Swahili 6569 Swedish [SWE] 6568

Tagalog 6658 Tajik 6653 Tamil 6647 Tatar 6666 Telugu 6651 Thai 6654 Tibetan 4861 Tigrinya 6655 Tonga 6661 Tsonga 6665 Tu rkish [TUR] 6664 Tu rkmen 6657 Tw i 6669

U-Z

Ukrainian 6757 Urdu 6764 Uzbek 6772 Vietnamese 6855 Volapuk 6861 Welsh 4971 Wolof 6961 Xhosa 7054 Yiddish 5655 Yo r uba 7161 Zulu 7267

SUBTITLE

OFF ENGLISH FRENCH

SETUP LANGUAGE

DISC MENU

ENGLISH FRENCH SPANISH

SETUP LANGUAGE

AUDIO

ORIGINAL ENGLISH FRENCH

SETUP LANGUAGE

P26 Step

P27 Step

P28 Step

B C D

SETUP CUSTOM

LANGUAGE DISPLAY AUDIO PARENTAL OTHERS

SETUP

QUICK CUSTOM INITIALIZE

SETUP LANGUAGE

AUDIO SUBTITLE DISC MENU

ORIGINAL OFF ENGLISH

- 27 - EN

AUDIO SETTING

Choose the appropriate Audio settings for your equipment as it only affects during the playback of DVD discs.

Follow steps 1to 2in the “CUSTOM MENU” section

on page 26.

3 Press [

KK/LL

] to select the below items then

press [ENTER].

DRC (Dynamic Range Control):

¡To compress the range of soft

to loud sound.

¡The default setting is “ON”.

DOWN SAMPLING:

¡ON : Output in 48 kHz.

(default)

¡OFF : Output the original

sound.

When playing disc with copyright Protection

¡If you select “OFF”, copyright protection will be

activated and sound will be down sampled at 48kHz.

DOLBY DIGITAL:

Set to “BITSTREAM” when the unit is connected to a Dolby Digital Decoder.

¡BITSTREAM: Output a Dolby Digital signal

(default)

¡PCM: Convert the Dolby Digital to PCM

(2 channel stereo)

4 Press [SETUP] to exit the menu.

QUICK

LANGUAGE SETTING FOR THE ON-SCREEN MENUS

¡You can access the TV SETUP menu by pressing [SETUP] from the DVD mode. Refer to

“MENU LANGUAGE” on page 17 to change the language for the on-screen menus.

DISPLAY SETTING

Follow steps 1to 2in the “CUSTOM MENU” section on page 26.

3 Press [

KK/LL

] to select the below items then

press [ENTER].

TV MODE:

You can change certain aspects of the DVD display screens and on-screen messages on the TV screen.

¡4:3 LETTER BOX (default):

To show black bars on top and bottom of the screen.

¡4:3 PAN & SCAN: To show

a full height picture with both sides trimmed.

STILL MODE

This function allows you to adjust picture resolution and quality in the still mode.

¡AUTO (default):

Automatically select the best resolution setting (FRAME or FIELD) based on the data characteristics of the pictures.

¡FIELD: Select “FIELD” when the pictures are still

unstable even if “AUTO” is selected. FIELD stabilizes the pictures, although the picture quality may become coarse due to the limited amount of data.

¡FRAME: Select “FRAME” to display relatively

motionless pictures in higher resolution. FRAME improves the picture quality, although it may unstabilize the pictures due to simultaneous output of two field data.

4 Press [SETUP] to exit the menu.

QUICK

QUICK MENU

¡You can select the “TV MODE” or “DOLBY DIGITAL” from the QUICK menu quickly. To access the

QUICK menu, select “QUICK” instead of “CUSTOM” at step 1on page 26.

SETUP DISPLAY

TV MODE

AUTO

STILL MODE

4:3 LETTER BOX

SETUP DISPLAY

TV MODE

AUTO

STILL MODE

4:3 LETTER BOX

SETUP AUDIO

DRC ON DOWN SAMPLING DOLBY DIGITAL BITSTREAM

SETUP AUDIO

DRC ON DOWN SAMPLING DOLBY DIGITAL BITSTREAM

SETUP AUDIO

DRC ON DOWN SAMPLING DOLBY DIGITAL BITSTREAM

- 28 - EN

CONTROL LEVELS

ALL

All parental lock is cancelled.

Level 8

DVD software of any grade (adult/general/children) can be played back.

Levels 7 to 2

Only DVD software intended for general use and children can be played back.

Level 1

Only DVD software intended for children can be played back, with those intended for adult and general use prohibited.

PARENTAL CONTROL

Parental Control limits the disc viewing that exceed your setting (with a password or playback will stop). This feature allows you to prevent discs with alternative scenes from being played by your children.

PARENTAL LEVEL

Parental Level allows you to set the rating level of your DVD discs. Playback will stop if the disc’s ratings exceed the level you set.

Follow steps 1 to 2 in the “CUSTOM MENU” section

on page 26.

3 Enter your four-digit password then press

[ENTER].

4 Press [

KK/LL

] to select “PARENTAL LEVEL”

then press [ENTER].

5 Press [

KK/LL

]to select the desired level then

press [ENTER].

6 Press [SETUP] to exit the menu.

NOTES:

When doing this for the first time, enter any 4 digits. (except for 4737) That number will be used as the password. (in the event you forget the password, see below)

¡To change the password, press [

KK/LL

] to select

“PASSWORD CHANGE” at step 4 then press [ENTER]. Enter the four-digit password, then press [ENTER].

¡With some DVDs, it may be difficult to find if they

are compatible with parental lock. Be sure to check if the parental lock function operates in the way that you have set.

¡Record the password in case you forget it.

IF YOU FORGET THE PASSWORD

1 Press the Number buttons [4], [7], [3], [7] at

step 3. Then enter your new password.

¡Password will be cleared and parental level will be

set to “ALL”.

2 Proceed with steps 4 to 6 again.

This allows you to return all selections of SETUP (except for “PARENTAL” and menu language) to their default settings.

1 Press [SETUP] twice in the stop mode so

that the “INITIALIZE” menu appears.

2 Press [

KK/LL

] to select “INITIALIZE” then

press [ENTER].

3 Press [

KK/LL

] to select “YES” then press

[ENTER] twice.

All the settings (except for “PARENTAL” and menu

language

) will be cleared.

¡To cancel the initialization,

select “NO”.

4 Press [SETUP] to exit the menu.

DVD-V

OTHER SETTINGS

Follow steps 1to 2in the “CUSTOM MENU” section on page 26.

3 Press [

KK/LL

] to select the below items, then

press [ENTER].

ANGLE ICON:

¡Press [ENTER] repeatedly to turn Angle icon “ON”

or “OFF”.

¡The default setting is “ON”.

AUTO POWER OFF:

¡Press [ENTER] repeatedly to turn Auto Power off

“ON” or “OFF”.

The default setting is “ON” and the screen saver program starts when there is no input from the unit for 5 minutes in the stop mode. After the screen saver program is activated for 15 minutes, the power is automatically turned off.

4 Press [SETUP] to exit the menu.

INITIALIZE

SETUP PARENTAL

PASSWORD

Enter current password.

SETUP PARENTAL

PARENTAL LEVEL ALL PASSWORD CHANGE

SETUP PARENTAL

PARENTAL LEVEL ALL

8 7 [NC-17] 6 [R]

SETUP OTHERS

ANGLE ICON AUTO POWER OFFONON

SETUP

QUICK CUSTOM INITIALIZE

SETUP INITIALIZE

Initialize? NO YES

- 29 - EN

Sometimes a performance problem can be easily solved by checking seemingly apparent but often overlooked possibilities. Before arranging for service, check these items. It could save your time and money.

TV Mode

TROUBLESHOOTING GUIDE

PROBLEM CORRECTIVE ACTION

No picture or sound

•

Make sure the AC cord is connected to an AC outlet.

•

Check antenna connection.

•

Press [SELECT] to select TV mode. Then try other TV feature.

•

Let the unit program its tuner memory.

No picture or poor picture on the

•

Adjust direction or replace antenna.

unit

•

Adjust picture controls.

•

Check for broken pin of the antenna cable.

No sound or poor sound

•

Adjust volume control on remote control or main unit.

•

Press [MUTE] to restore sound.

Bars On Screen

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

Picture Distorted or Blurred

•

Try a new channel, if OK, then possible station trouble.

•

If outside antenna is being used, check for broken wire.

Picture Rolls Vertically

•

Try a new channel, if OK, then possible station trouble.

Lines or Streaks in Picture

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

No Color

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to jack on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Adjust “COLOR” control.

Poor Reception on Some Channels

•

Try a new channel, if OK, then possible station trouble.

Ghosts in Picture

•

Is antenna connected to jack on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

Weak Picture

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to jack on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Adjust “CONTRAST” & “BRIGHT” control.

Sound OK, Picture Poor

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to jack on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Adjust “CONTRAST” & “BRIGHT” control.

If the unit does not perform properly when operated as instructed in this Owner’s Manual, check the unit, consulting the following checklist.

PROBLEM CORRECTIVE ACTION

No power

•

Make sure the power plug is connected to an AC outlet.

•

Make sure the power is turned on.

No operation by infrared remote

•

Check if the power plug is connected to an AC outlet.

control

•

Check the batteries in the remote control.

•

Aim the remote control directly at the remote sensor. If necessary,

remove all the obstacles between the sensor and the remote control.

•

You have to be within 23 feet of the unit.

•

Check if the correct mode is selected. If not switch the mode by

pressing [SELECT], whichever you need.

- 30 - EN

CLOSED CAPTION PROBLEM POSSIBLE REMEDY

Misspelling in captions

•

Error committed by the closed captioning production company.

•

Possible in a live broadcast. Not in case of a prerecorded program.

Text is not shown in its entirety or

•

A few seconds of delay is common for live broadcast.

a delay occurs from what is being

•

Display capacity may not exceed 220 words per minute. If a dialogue

said

•

exceeds that rate, selective editing is used to insure that the captions

•

remain up-to-date with the current TV screen dialogue.

Captions scrambled with white

•

Caused by interferences of building, power lines, thunderstorms, etc.

boxes No captions in a program which

•

The broadcast may use a time compression process to speed up the

must contain closed caption

•

program. The decoder cannot read the compressed information and

•

captions will be lost.

Black box in the TV screen

•

You are in TEXT mode. Select a CAPTION mode (“C1”, “C2”) or

•

Caption “OFF”.

PROBLEM CORRECTIVE ACTION

Picture OK, Sound Poor

•

Try a new channel, if OK, then possible station trouble.

•

Check for local interference.

No operation by infrared remote

•

Make sure the AC cord is connected to an AC outlet.

control

•

Check batteries in remote control.

Different color marks on screen

•

Magnetism from nearby appliances and geomagnetism might affect the color of the TV picture. Move the unit away from the appliances, the unit can repair itself automatically. If you want to repair immediately,

unplug the power cord, then plug it in again 30 minutes later or

so. This automatically resets the unit.

- 31 - EN

NOTES:

•

Some functions are not available in specific modes, but this is not a malfunction. Read the description in this Owner’s Manual for details on correct operations.

•

Playback from a desired track and random playback are not available during program playback.

PROBLEM CORRECTIVE ACTION

No picture

•

Insert a correct video disc that plays on this unit.

•

Press [SELECT] to select DVD mode, then try other DVD feature.

Disc cannot be played

•

Insert the disc.

•

Clean the disc.

•

Place the disc correctly, with the label side up.

•

Cancel the parental lock or change the control level.

No sound

•

Connect the audio cables firmly.

•

Turn the power of the audio component on.

•

Correct the audio output settings.

•

Correct the input settings on the audio component.

No DTS audio is output

•

This unit does not support DTS audio. This is not a malfunction.

Distorted picture

•

There are some cases where pictures may be slightly distorted,

which are not a sign of a malfunction.

•

Although pictures may stop for a moment, this is not a malfunction.

Audio or subtitle language

•

The selected language is not available for audio or subtitles on the

does not match the set up

•

DVD. (This is not a malfunction.)

The camera angle cannot be changed•The DVD does not contain sequences recorded from different cam-

era angles. (This is not a malfunction.)

Audio or subtitle language cannot be •The DVD does not contain audio source or subtitles in the selected changed

•

language. (This is not a malfunction.)

“Prohibited icon” appears on the

•

That operation is prohibited by the unit or the disc.

screen, prohibiting an operation

•

(This is not a malfunction.)

CD sound dropout

•

Scratched disc. Replace the disc with an unscratched one. No CD reproduction DVD picture dropout DVD picture freeze DVD picture in mosaic No DVD reproduction

DVD Mode

- 32 - EN

CABINET CLEANING

•

Wipe the front panel and other exterior surfaces of the unit with a soft cloth immersed in lukewarm water and wrung dry.

•

Never use a solvent or alcohol. Do not spray insecticide liquid near the unit. Such chemicals may cause damage and discoloration to the exposed surfaces.

SERVICING

•

Should your unit become inoperative, do not try to correct the problem by yourself. There are no userserviceable parts inside. Turn off, unplug the power cord and

please call our help line mentioned on

the front page

, to locate an Authorized Service

Center.

IF THE LASER OPTICAL PICKUP UNIT IS DIRTY

•

If the unit still does not perform properly when it is operated, while referring to the relevant sections and to “TROUBLESHOOTING GUIDE” in this Owner’s Manual, the laser optical pickup unit may be dirty. Consult your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.

•

Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.

•

Always store the disc in its protective case when it is not used.

DISC HANDLING

•

To clean-off, use a soft cloth.

•

Do not use a hard cloth since this will mar the disc.

•

Wipe the disc in a straight line from center to edge.

•

Never wipe with a circular motion.

•

Do not use detergent or abrasive cleaning agents.

MAINTENANCE

- 33 - EN

CRT: 13 inch in-line gun,

90˚ deflection tube Television system: NTSC-M Closed caption system: §15.119/FCC Channel coverage:

VHF: 2 ~ 13 UHF: 14 ~ 69 CATV: 2 ~13, A ~ W,

W+1 ~ W+84,

A-5 ~ A-1, 5A Tuning System: 181 channel

frequency synthesized

tuning system Channel access: Direct access keyboard,

programmable

scan and up/down

Product type: DVD Player Discs: DVD video, Audio CD Output signal format: NTSC color

•

Designs and specifications are subject to change without notice.

•

If there is a discrepancy between languages, the default language will be English.

DVD

GENERAL SPECIFICATIONS ELECTRICAL SPECIFICATIONS

Sound output: 2 speakers, 1W, 8 ohm

OTHER SPECIFICATIONS

Terminals

Antenna input: VHF/UHF/CATV

75 ohm unbalanced (F-type) Video input: RCA connector [ 1 Audio L/R input: RCA connector [ 2 Headphone: 1/8" stereo (3.5 mm) Coaxial digital audio output: One pin jack,

500m Vpp (75 ohm)

Remote control: Digital encoded

infrared light system

Operating temperature: 5°C to 40°C

(41°F~104°F)

Power requirements: AC 120V, 60Hz Power consumption (Maximum): 70W Picture tube: 13" Dimensions: H : 15-13/16" (402mm)

W: 15-3/16" (386mm)

D: 14-13/16" (376mm)

Weight: 21.6 lbs. (9.8kg)

SPECIFICATIONS

- 34 - ES

INDICE

■ INDICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

■ CONTROLES DE OPERACIÓN Y FUNCIONES . . . . . 34

■ PREPARACIÓN PARA LA UTILIZACIÓN . . . . . . . . . . 35

CONEXIONES DE ANTENA/CABLE . . . . . . . . . . . . . . 35

CONEXIÓN A TOMAS DE ENTRADA DELANTERAS 36 CONEXIÓN A UN AMPLIFICADOR ESTÉREO EQUIPADO CON TOMAS DE ENTRADA DIGITAL

(para DVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

CONEXIÓN A UN DECODIFICADOR DOLBY DIGITAL

(para DVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

PARA INSERTAR LAS PILAS . . . . . . . . . . . . . . . . . . . . 36

CONTROLES DE OPERACIÓN Y FUNCIONES

• Consulte la figura 1 de la página 8 para el panel frontal de la unidad

• Consulte la figura 2 de la página 8 para el mando a distancia

• Consulte la figura 3 de la página 9 para la vista posterior

1. Bandeja de carga del disco

2. Toma de entrada VIDEO

Conecte aquí la toma de salida de vídeo de una videocámara o de una videograbadora.

3. Tomas de entrada AUDIO L/R

Conecte aquí las tomas de salida de audio de una videocámara o de una videograbadora.

4. Botón POWER

Presione para encender y apagar la unidad.

5. Botones VOLUME (VOL.) X/

Presione para controlar el nivel de volumen del DVD y el televisor.

6. Botones CHANNEL (CH.) X/

Utilice para seleccionar canales memorizados.

7. Ventanilla del sensor de mando a distancia

8. Botón STOP P

Detiene la operación del disco.

9. Botones SKIP R / Q

Presione una vez para omitir capítulos o pistas y desplazarse a un punto específico.

Botones SEARCH E / D (Panel frontal)

Mantenga el botón presionado para cambiar la velocidad de reproducción en avance o retroceso.

10. Botón PLAY O

Inicia la reproducción del contenido del disco.

11. Botón PAUSE

Hace una pausa en la reproducción del disco.

12. Botón OPEN/CLOSE

Presione para insertar un disco en la bandeja o retirarlo de ella.

13. Toma HEADPHONE

Para conectar auriculares (no incluidos) y escuchar en privado.

14. Botón PICTURE

Presione para ajustar la imagen.

15. Botones Numéricos Modo TV:

Presione dos cifras para acceder directamente al canal deseado. No olvide presionar

[0] antes de elegir un canal de una

sola cifra.

Botón +100

Presione para seleccionar canales de televisión por cable cuyo número sea superior a 99.

Modo DVD:

Presione para introducir el número deseado.

Botón +10

Presione para introducir números superiors a 9.

16. Botón SLEEP

Utilise para ajustar el temporizador de dormir.

17. Botón DISPLAY Modo TV:

Indica el número del canal en la pantalla del televisor.

Modo DVD:

Indica el estado actual en la pantalla del televisor.

18. Botón SETUP

Presione para entrar o salir del menú de configuración de televisor o DVD.

19. Botón TITLE

Para visualizar el menú de títulos.

20 Botón CLEAR

Para cancelar o borrar un ajuste entrado actualmente.

21. Botón MODE

Presione para llamar la pantalla de la reproducción programada o la de reproducción aleatoria en el modo de parada. Presione para llamar la pantalla de ajuste del nivel del negro o la pantalla de sonido ambiental durante la reproducción.

22. Botón SEARCH MODE

Presione para localizar un punto deseado.

23. Botón AUDIO

Presione para seleccionar un modo de sonido o idioma de audio deseado.

24. Botón SUBTITLE

Presione para seleccionar el idioma de subtítulos deseado.

25. Botón REPEAT

Repite la reproducción del disco, título, capítulo o pista actual.

26. Botón ANGLE

Presione para cambiar el ángulo de la cámara y ver la secuencia que se está reproduciendo desde un ángulo diferente (si existe).

SECCIÓN DE TV

PARA MIRAR UN PROGRAMA DE TV . . . . . . . . . . . . 37

IDIOMA DEL MENÚ . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

SECCIÓN DE DVD

REPRODUCCIÓN BÁSICA . . . . . . . . . . . . . . . . . . . . . . 38

MENÚ DE DISCO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

REANUDACIÓN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

- 35 - ES

NOTA:

Antes de enchufar la antena a la toma ANT. de la unidad, compruebe que la clavija no esté doblada. Si esta doblada, póngala derecha como se muestra en la ilustración, y luego conéctela en la toma ANT. de la unidad.

27. Botón A-B

Repite la reproducción de una sección seleccionada.

28. Botón RETURN

Permite volver a la pantalla anterior en el menú de configuración.

29. Botones K / L / { / B Modo TV:

Presione para seleccionar un modo de ajuste en el menú que aparece en la pantalla del televisor. Presiónelos también para seleccionar opciones o establecer ajustes en un menú en particular.

Modo DVD:

Presione para hacer una selección en el menú.

30. Botón ENTER

Presione para establecer un ajuste.

31. Botón DISC MENU

Muestra menú del DVD.

32. Botón REV E

Presione para mover la imagen de DVD en retroceso rápido en o en cámara lenta en retroceso.

Botón FWD D

Presione para mover en avance rápido o en cámara lenta en el disco.

PREPARACIÓN PARA LA UTILIZACIÓN

CONEXIONES DE ANTENA/CABLE

Nota para el instalador de sistemas CATV

Esta nota tiene la finalidad de llamar la atención del instalador de sistemas CATV para que tenga en cuenta el Artículo 820-40 de la NEC, que proporciona recomendaciones para hacer una conexión a tierra apropiada y, en particular, especifica que la tierra del cable debe conectarse al sistema de puesta a tierra del edificio, tan cerca del punto de entrada del cable como sea posible.

Consulte la figura 4 de la página 10

(Necesita enderezarse)

(Clavija derecha)

Clavija doblada

Cable

Clavija

33. Botón ZOOM

Amplía parte de la imagen reproducida de un DVD.

34. Botón MUTE

Suprime la salida de sonido. Presiónelo de nuevo para restablecer el sonido.

35. Botón SELECT

Presione para cambiar al modo TV, modo de entrada externa o modo de DVD.

36. To ma COAXIAL

Conecte solamente a la entrada digital de un amplificador externo o decodificador (para audio de DVD solamente).

37. Toma ANT.

Conecte a una antena, sistema de televisión por cable o sistema de satélite.

38. Cable eléctrico

Conécte a un toma de CA estándar (120 V/60 Hz).

NOTA:

•

Antes de conectar el cable eléctrico a una toma de CA, retírelo del gancho para evitar dañarlo.

NOTA:

•

Para su seguridad y para evitar que se dañe la unidad, desenchufe el cable de antena de la toma ANT. antes de mover la unidad.

- 36 - ES

CONEXIÓN A UN

DECODIFICADOR DOLBY

DIGITAL (para DVD)

Si utiliza esta unidad para reproducir un disco DVD en un formato de sonido envolvente Dolby Digital de 5,1 canales, la unidad dará salida a un flujo de datos DOLBY DIGITAL desde su toma COAXIAL. Si conecta la unidad a un decodificador Dolby Digital, podrá disfrutar de una tonalidad más convincente y real, con un sonido envolvente potente y de alta calidad similar al de los cines.

Utilice cables digitales coaxiales de audio (disponibles en el comercio) para hacer las conexiones de audio.

NOTAS:

•

Asegúrese de apagar todos los componentes del sistema antes de conectar otro componente.

•

Consulte los manuales de instrucciones de los componentes que va a conectar a la unidad.

•

Si conecta un decodificador Dolby Digital, ajuste la función “DOLBY DIGITAL” a “BITSTREAM” para salida de audio en el modo de configuración.

•

A menos que se haga la conexión a un decodificador Dolby Digital, ajuste la función “DOLBY DIGITAL” a “PCM” para salida de audio en el modo de configuración. La reproducción en una unidad utilizando ajustes incorrectos puede generar ruido y distorsión, y también puede provocar daños a los altavoces.

Fabricado bajo licencia de Dolby Laboratories. “Dolby” y el símbolo de la doble D son marcas comerciales de Dolby Laboratories.

1) Abra la cubierta del compartimiento de las pilas empujando la cubierta del mando a distancia en el sentido de la flecha.

2) Inserte 2 pilas “AA” en el compartimiento de las pilas, en el sentido indicado por las marcas de polaridad (+/-).

3) Vuelva a poner la cubierta.

PARA INSERTAR LAS PILAS

CONEXIÓN A UN AMPLIFICADOR

ESTÉREO EQUIPADO CON TOMAS

DE ENTRADA DIGITAL (para DVD)

Utilice un cable digital coaxial de audio (disponible en el comercio) para hacer las conexiones de audio. Conexión a un amplificador equipado con tomas de entrada digital, platina MD o platina DAT.

NOTAS:

• La fuente de audio de un disco grabado en formato

de sonido envolvente Dolby Digital de 5,1 canales no se puede grabar como sonido digital mediante una platina MD o DAT.

• Asegúrese de apagar todos los componentes del

sistema antes de conectar otro componente.

• Consulte los manuales de instrucciones de los

componentes que va a conectar a la unidad.

• Ajuste la función “DOLBY DIGITAL” a “PCM”

para salida de audio en el modo de configuración. La reproducción en una unidad utilizando ajustes incorrectos puede generar ruido y distorsión, y también puede provocar daños a los altavoces.

Consulte la figura 6 de la página 11

Consulte la figura 7 de la página 12

CONEXIÓN A TOMAS DE

ENTRADA DELANTERAS

Cuando vea un programa grabado en otra fuente (videograbadora o videocámara), utilice las tomas de entrada AUDIO/VIDEO de la parte delantera de la unidad. Conecte las tomas de salida de audio/vídeo de otra fuente a las tomas AUDIO L/R y VIDEO de esta unidad.

Despúes, presione [SELECT] o [CH. KK/LL] hasta que aparezca “AUX” en la pantalla.

Consulte la figura 5 de la página 11

NOTA:

•

Cuando conecte una videograbadora monofónica (otra fuente) a esta unidad, conecte la toma de salida de audio de la videograbadora monofónica (otra fuente) a la toma AUDIO L de esta unidad. El audio saldrá igualmente por los canales izquierdo y derecho.

- 37 - ES

1 Seleccione “LANGUAGE”

Presione [SETUP]. Presione

[KK/LL] para apuntar a “LANGUAGE”.

2 Seleccione “ENGLISH”, “ESPAÑOL” o

“FRANÇAIS”

Presione [ENTER] repetidamente para seleccionar “ENGLISH” = inglés, “ESPAÑOL” o “FRANÇAIS” = francés.

3 Salga del modo de idioma

Presione [SETUP] para salir del menú. NOTAS:

•

Esta función afecta sólo el idioma en el menú de la pantalla y no la fuente de audio.

•

Si por alguna razón, el menú está en francés, presione [SETUP], presione [KK/LL] para apuntar al “LANGAGE [FRANÇAIS]” y presione [ENTER] repetidamente para seleccionar el idioma deseado y presione [SETUP].

IDIOMA DEL MENÚ

1 Enchufe el cable eléctrico

Enchufe el cable eléctrico de la unidad en un tomacorriente de CA del hogar.

NOTA:

•

Si aparecen números en la esquina de la pantalla, presione [POWER] sin desenchufar el cable eléctrico.

2 Encienda la unidad

Presione [POWER] para encender la unidad.

3 Seleccione el número de canal

Presione [CH. KK/LL] o los botones numéricos para seleccionar su número de canal deseado.

Nota para el uso de los botones numéricos:

¡Debe colocar un cero antes de los números de canal

de una sola cifra (por ejemplo: 02, 03, 04, etc.).

Cuando seleccione canales de cable de más de 99, presione primero [+100] y después las dos últimas cifras. (Ejemplo: para seleccionar el canal 125, primero presione [+100] y después presione [2] y [5].)

4 Ajuste el sonido

Presione [VOL. XX/YY] para ajustar el volumen. Presione

[MUTE] para silenciar instantáneamente el

sonido. Presione nuevamente para recuperar el nivel de

sonido anterior.

NOTA:

•

Si presione [CH. KK/LL] en el modo DVD, puede cambiar los canales de TV. Incluso si apaga la unidad en el modo DVD, cuando vuelva a encender, volverá al modo TV.

PARA VER CANALES DE CABLE O SATELITE

•

Si la unidad está conectada a una caja de cable o caja de satélite, presione [CH. KK/LL] para seleccionar CH3 o CH4 de acuerdo con el ajuste de canal de salida del dispositivo y seleccione el canal deseado en el dispositivo.

PARA VER UNA ENTRADA EXTERNA

•

Cuando se conecta un equipo externo en las tomas de entrada AUDIO/VIDEO frontales, presione [SELECT] o [CH. KK/LL] repetidamente hasta que aparezca “AUX” en la pantalla.

SECCIÓN DE TV

PARA MIRAR UN

PROGRAMA DE TV

- 38 - ES

SECCIÓN DE DVD

REPRODUCCIÓN BÁSICA

Para empezar

¡Conecte la alimentación del amplificador y otros

componentes, si es necesario.

1 Presione [POWER].

¡La alimentación se conectará.

2 Presione [OPEN/CLOSE A] para abrir la

bandeja de carga del disco.

3 Ponga el disco deseado en la bandeja, con

la etiqueta hacia arriba.

DVD-V

MENÚ DE DISCO

1 Presione [DISC MENU].

¡Aparecerá el menú principal de DVD. ¡Si no existe la función, puede aparecer el símbolo

en la pantalla de TV.

¡Si el menú de disco existe en el disco, aparecerán el

idioma de audio, opciones de subtítulo, capítulos para el título y otras opciones para su selección.

2 Presione [K / L / s / B] para hacer una

selección y presione [ENTER] para confirmar la selección.

DVD-V

REANUDACIÓN

1 Durante la reproducción, presione

[STOP

C].

¡Aparecerá el mensaje de continuación en la pantalla

de TV.

2 Presione [PLAY O], la reproducción continuará

desde el punto donde se paró la reproducción.

¡Para cancelar la continuación, presione dos veces

[STOP C].

¡La información de continuación permanece activada

incluso cuando apaga el interruptor principal.

DVD-V

4 Presione [PLAY O].

¡La bandeja se cerrará automáticamente y la

reproducción comenzará desde el primer capítulo o pista del disco.

¡La reproducción también empieza cerrando

manualmente la bandeja del disco o presionando [OPEN/CLOSE AA].

¡Si la reproducción no comienza automáticamente,

presione [PLAY O].

¡Cuando reproduzca un DVD que tenga grabado un

menú de títulos, el me

nú podrá aparecer en la pantalla.

Presione [STOP C] para detener la reproducción.

- 39 - ES

MEMO

Printed in Malaysia 1EMN20769

T8109UK

★★★★★

LIMITED WARRANTY

FUNAI CORP. will repair this SV2000 product, free of charge in the USA in the event of defect in materials or workmanship as follows:

DURATION: PARTS:

FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the date of original retail purchase. Two (2) years for Picture Tube. Certain parts are excluded from this warranty.

LABOR: FUNAI CORP. will provide the labor without charge for a period of ninety (90) days from the date

of original retail purchase.

LIMITS AND EXCLUSIONS:

This warranty is extended only to the original retail purchaser. A purchase receipt or other proof of original retail purchase will be required together with the product to obtain service under this warranty.

This warranty shall not be extended to any other person or transferee. This warranty is void and of no effect if any serial numbers on the product are altered, replaced, defaced, missing

or if service was attempted by an unauthorized service center. This SV2000 Limited warranty does not apply to any product not purchased and used in the United States.

This warranty only covers failures due to defects in material or workmanship which occurs during normal use. It does not cover damage which occurs in shipment, or failures which are caused by repairs, alterations or product not supplied by FUNAI CORP. or damage which results from accident, misuse, abuse, mishandling, misapplication, alteration, faulty installation, improper maintenance, commercial use such as hotel, rental or office use of this product or damage which results from fire, flood, lightning or other acts of God.

THIS WARRANTY DOES NOT COVER PACKING MATERIALS, ANY ACCESSORIES (EXCEPT REMOTE CONTROL), ANY COSMETIC PARTS, COMPLETE ASSEMBLY PARTS, DEMO OR FLOOR MODELS.

FUNAI CORP. AND ITS REPRESENTATIVES OR AGENTS SHALL IN NO EVENT BE LIABLE FOR ANY GENERAL, INDIRECT OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR OCCASIONED BY THE USE OF OR THE INABILITY TO USE THIS PRODUCT. THIS WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED AND OF ALL OTHER LIABILITIES ON THE PART OF FUNAI, ALL OTHER WARRANTIES INCLUDING THE WARRANTY OF MERCHANTABILITYAND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED BY FUNAI AND ITS REPRESENTATIVES IN THE UNITED STATES. ALL WARRANTY INSPECTIONS AND REPAIRS MUST BE PERFORMED BY AN AUTHORIZED SERVICE CENTER. THIS WARRANTY IS ONLY VALID WHEN THE UNIT IS CARRIED-IN TO AN AUTHORIZED SERVICE CENTER.

IMPORTANT:

THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE. IF, AT ANY TIME DURING THE WARRANTY PERIOD, YOU ARE UNABLE TO OBTAIN SATISFACTION WITH THE REPAIR OF THIS PRODUCT, PLEASE CONTACT FUNAI CORP.

ATTENTION:

FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY DESIGN OF THIS PRODUCT WITHOUT PRIOR NOTICE.

To locate your nearest AUTHORIZED SERVICE CENTER or for general service inquiries, please contact us at :

FUNAI CORPORATION

Custmer Service

Tel :1-800-518-1180

http://www.funai-corp.com

FUNAI WV13D5 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
