FUNAI V07LCD15 User Manual

15” Digital / Analog

LCD TV

Owner’s Manual

V07LCD15

WATCHING TVINTRODUCTION CONNECTION INITIAL SETTING

OPTIONAL SETTING

TO RECEIVE DIGITAL/ANALOG SIGNAL,

YOU MUST CONNECT ANTENNA.

HIGH-DEFINITION TELEVISION

TROUBLESHOOTING

INFORMATION

NTRODUCTION

I

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

The important note is located on the rear of the cabinet.

Important Safeguards

1. READ INSTRUCTIONS - All the safety and operating instructions

should be read before the appliance is operated.

2. RETAIN INSTRUCTIONS - The safety and operating instructions

should be retained for future reference.

3. HEED WARNINGS - All warnings on the appliance and in the

operating instructions should be adhered to.

4. FOLLOW INSTRUCTIONS - All operating and use instructions

should be followed.

5. CLEANING - Unplug TV from the wall outlet before cleaning. Do

not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.

EXCEPTION: A product that is meant for uninterrupted service and,

that for some speci c reason, such as the possibility of the loss
of an authorization code for a CAT V converter, is not intended to
be unplugged by the user for cleaning or any other purpose, may
exclude the reference to unplugging the appliance in the cleaning
description otherwise required in item 5.

6. ATTACHMENTS - Do not use attachments not recommended by

the TV manufacturer as they may cause hazards.

7. WATER AND MOISTURE - Do not use this TV near water, for

example, near a bath tub, wash bowl, kitchen sink, or laundry tub,
in a wet basement, or near a swimming pool, and the like.

8. ACCESSORIES - Do not place this TV on

an unstable cart, stand, tripod, bracket,
or table. The TV may fall, causing serious
injury to someone, and serious damage to
the appliance. Use only with a cart, stand,
tripod, bracket, or table recommended by the
manufacturer, or sold with the TV.

Any mounting of the appliance should follow

the manufacturer’s instructions and should
use a mounting accessory recommended by the manufacturer.
An appliance and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the
appliance and cart combination to overturn.

AMEUBLES - Cet appareil ne doit être placé

que sur un meuble (avec ou sans roulettes)
recommandé par le fabricant. Si vous l’
installez sur un meuble à roulettes, déplacez
les deux ensembles avec précaution. Un arrêt
brusque, l’utilisation d’une force excessive
et des surfaces irrégulières risquent de
déstabiliser l’ensemble et de le renverser.

9. VENTILATION - Slots and openings in the cabinet and the back

or bottom are provided for ventilation and to ensure reliable
operation of the TV and to protect it from overheating, these
openings must not be blocked or covered. The openings should
never be blocked by placing the TV on a bed, sofa, rug, or other
similar surface. This TV should never be placed near or over a
radiator or heat register. This TV should not be placed in a built-in
installation such as a bookcase or rack unless proper ventilation is
provided or the manufacturer’s instructions have been adhered to.

10. POWER SOURCES - This TV should be operated only from the type

of power source indicated on the marking label. If you are not sure
of the type of power supply to your home, consult your appliance
dealer or local power company. For TVs intended to operate from
battery power, or other sources, refer to the operating instructions.

2

EN

THIS SYMBOL INDICATES THAT DANGEROUS
VOLTAGE CONSTITUTING A RISK OF ELECTRIC
SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE
IMPORTANT OPERATING AND MAINTENANCE
INSTRUCTIONS IN THE LITERATURE
ACCOMPANYING THE APPLIANCE.

11. GROUNDING OR POLARIZATION - This TV is equipped with a

polarized alternating-current line plug (a plug having one blade
wider than the other). This plug will  t into the power outlet only
one way. This is a safety feature. If you are unable to insert the plug
fully into the outlet, try reversing the plug. If the plug should still
fail to  t, contact your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the polarized plug.

12. POWER-CORD PROTECTION - Power-supply cords should be

routed so that they are not likely to be walked on or pinched by
items placed upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point where they
exit from the appliance.

13. OUTDOOR ANTENNA GROUNDING - If an outside antenna or

cable system is connected to the TV, be sure the antenna or cable
system is grounded so as to provide some protection against
voltage surges and built-up static charges. Article 810 of the
National Electrical Code, ANSI/NFPA No. 70, provides information
with respect to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge
unit, size of grounding conductors, location of antenna-discharge
unit, connection to grounding electrodes, and requirements for
the grounding electrode. (Fig. A)

EXAMPLE OF ANTENNA GROUNDING AS PER

S2898A

14. LIGHTNING - For added protection for this TV receiver during a

15. POWER LINES - An outside antenna system should not be located

16. OVERLOADING - Do not overload wall outlets and extension

FIGURE A

NATIONAL ELECTRICAL CODE

GROUND
CLAMP

ELECTRIC
SERVICE
EQUIPMENT

NEC - NATIONAL ELECTRICAL CODE POWER SERVICE GROUNDING

lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage to the TV due
to lightning and power-line surges.

in the vicinity of overhead power lines or other electric light of
power circuits, or where it can fall into such power lines or circuits.
When installing an outside antenna system, extreme care should
be taken to keep from touching such power lines or circuits as
contact with them might be fatal.

cords as this can result in a risk of  re or electric shock.

GROUND CLAMPS

ELECTRODE SYSTEM
(NEC ART 250, PART H)

ANTENNA
LEAD IN WIRE

ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)

GROUNDING CONDUCTORS
(NEC SECTION 810-21)

INTRODUCTION

17. OBJECT AND LIQUID ENTRY - Never push objects of any kind into

this TV through openings as they may touch dangerous voltage
points or short out parts that could result in a  re or electric shock.
Never spill liquid of any kind on the TV.

18. SERVICING - Do not attempt to service this TV yourself as opening

or removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to quali ed service personnel.

19. DAMAGE REQUIRING SERVICE - Unplug this TV from the wall

outlet and refer servicing to quali ed service personnel under the
following conditions:
a. When the power supply cord or plug is damaged or frayed.
b. If liquid has been spilled, or objects have fallen into the TV.
c. If the TV has been exposed to rain or water.
d. If the TV does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the
operating instructions, as improper adjustment of other controls
may result in damage and will often require extensive work by a

quali ed technician to restore the TV to its normal operation.
e. If the TV has been dropped or damaged in any way.
f. When the TV exhibits a distinct change in performance, this

indicates a need for service.

Precautions

5

20. REPLACEMENT PARTS - When replacement parts are required, be

sure the service technician uses replacement parts speci ed by
the manufacturer that have the same characteristics as the original
part. Unauthorized substitutions may result in  re, electric shock,
injury to persons or other hazards.

21. SAFETY CHECK - Upon completion of any service or repairs to this

TV, ask the service technician to perform routine safety checks to
determine that the TV is in proper operating condition.

22. HEAT - This TV product should be situated away from heat sources

such as radiators, heat registers, stoves, or other products (including
ampli ers) that produce heat.

LAMP IN LCD CONTAINS MERCURY, DISPOSE ACCORDING TO LOCAL, STATE OR FEDERAL LAW.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA

BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

FCC WARNING

This equipment may generate or use radio frequency energy. Changes or modifications to this equipment
may cause harmful interference unless the modifications are expressly approved in the manual. The user
could lose the authority to operate this equipment if an unauthorized change or modification is made.

CONNECTION

INITIAL SETTING

WATCHING TV INFORMATION

OPTIONAL SETTING TROUBLESHOOTING

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Note to CATV system installer:

This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides guidelines
for proper grounding and, in particular, specifies that the cable ground should be connected to the grounding system of the
building as close to the point of cable entry as practical.

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D
symbol are trademarks of Dolby Laboratories.

EN

3

NTRODUCTION

I

LOCATION

For safe operation and satisfactory performance of the unit, keep the following in mind when selecting a place for its installation:

• Shield it from direct sunlight and keep it away from sources of intense heat.

• Avoid dusty or humid places.

• Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes at the top and bottom of the
unit. Do not place the unit on a carpet because this will block the ventilation holes.

• Install the unit in a horizontal position.

• Avoid locations subject to strong vibration.

• Do not place the unit near strong magnetic fields.

• Avoid moving the unit to locations where temperature differences are extreme.

• Be sure to unplug the AC power cord from the outlet before carrying the unit.

TO AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE

• Do not handle the power cord with wet hands.

• Do not pull on the power cord when disconnecting it from an AC outlet. Grasp it by the plug.

• If, by accident, water is spilled on the unit, unplug the power cord immediately and take the unit to our authorized service center for
servicing.

• Do not place anything directly on top of the unit.

The serial number of this product may be found on the back of the unit. No others have the same serial number as yours. You
should record the number and other vital information here and retain this book as a permanent record of your purchase to aid
identification in case of theft.

date of purchase

dealer purchase from

Note about recycling:

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your
local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning
chemical wastes.

dealer phone No.

model No.

serial No.

dealer address

Supplied Accessories5

owner’s manual
(1EMN22201)

• If you need to replace these accessories, please refer to the part No. with the illustrations and call our toll free
customer support line found on the cover of this manual.

• Depending on your antenna system, you may need different types of combiners (mixers) or separators (splitters).
Contact your local electronics store for these items.

Symbols Used in this Manual

5

The following is the description for the symbols used
in this manual.
Description refers to:

: Digital TV operation

DTV

: Analog TV operation

TV

• If neither symbol appears under the function
heading, operation is applicable to both.

remote control
(NF600UD)

batteries
(AA x 2)

Photo Stand

5

When the unit is unpacked for the first time, pull the
stand to the back of this unit, and place it on a stable
position. Never use the unit with stand closed.

4

EN

INTRODUCTION

CONNECTION

Features5

• DTV/TV/CATV

- You can use your remote control to select channels which
are broadcast in digital format and conventional analog
format. Also, cable subscribers can access their cable TV
channels.

• Program Information Display (DTV only)

- You can display the title, contents and other information
of the current DTV program on the TV screen.

• Auto Channel Scan

- This unit automatically scans and memorizes channels
available in your area, eliminating difficult setup
procedures.

• V-chip

- This feature allows you to block children’s access to
inappropriate programs.

• Closed Caption Decoder

- Built-in closed caption decoder displays text for closed
caption supported programming.

• MTS/SAP Tuner

- Audio can be selected from the remote control.

• Auto Shut Off Function

- If there is no signal input from the antenna terminal and
no operation for 15 minutes, the unit will turn itself off
automatically.

• Sleep Timer

- This feature will automatically turned off the power of the
unit at a specific time.

• Choices for On-screen Language

- Select your on-screen language:
English, Spanish or French.

• Stereo Sound Function

• PLL Frequency Synthesized Tuning

- Provides free and easy channel selection and lets you tune
directly to any channel using the channel number buttons
on the remote control.

• Component Video Input

• S-video Input

• AV Input

• Digital Audio Coaxial Output

Contents5

INTRODUCTION

Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Supplied Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Symbols Used in this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Photo Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Remote Control Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Installing the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

CONNECTION

Basic Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

External Device Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

INITIAL SETTING

Initial Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Auto Channel Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Language Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

WATCHING TV

Channel Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Volume Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Switching Each Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Switching Audio Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Screen Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

TV Screen Display Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Sleep Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

OPTIONAL SETTING

Channel Add/Delete . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Picture Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Closed Caption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

DTV Closed Caption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

DTVCC Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Back Light Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Color Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

V-chip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

TROUBLESHOOTING

Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

CONNECTION

INITIAL SETTING

WATCHING TV INFORMATION

OPTIONAL SETTING TROUBLESHOOTING

INFORMATION

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Cable Channel Designations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

General Speci cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Electrical Speci cation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Other Speci cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back cover

5

EN

NTRODUCTION

I

Remote Control Function5

10

1. POWER button (p11)

Press to turn the unit on and off.

1
2

3

4

5
6

7

8

9

2. MUTE

11

Press to turn the sound on and off.

3. SLEEP button (p16)

12
13

Press to activate the sleep timer.

4. Number buttons (p13)

14

• Press to select channels.

-/ENT. button

• Press to shift the minor channel

15

from the major channel.

+100 button

• Press to select 100 or higher
channels. (CATV)

• Press to search if there are minor
channels on the currently selected
major channel. (DTV)

5. CH. K/L buttons (p13)

Press to select channels and the

external input mode.

6. VOL. X/Y buttons (p13)

Press to adjust the volume.

7. ENTER button (p11)

Press to confirm your selection.

8. SETUP button (p11)

Press to display the main menu.

9. s / B / K / L buttons (p11)

Press to move left/ right/ up/

down through the items.

button (p13)

10. RETURN

Press to return to previous menu

operation.

11. INPUT button (p14)

• Press to access connected an
external device like a DVD player
or VCR.

• Press to switch between the
digital mode (DTV) and analog
mode.

12. DISPLAY

Digital Mode (DTV)

• Press to display the channel

information, signal type and TV
setting.

Analog Mode (TV)

• Press to display the channel
number, signal type and TV
setting.

External Input Mode

• Press to display the external
input mode, signal type and TV
setting.

13. AUDIO button (p14)

Digital Mode (DTV)

Press to select the audio
language.

Analog Mode (TV)

Press to select the audio mode.

14. SCREEN MODE button (p16)

Press to select aspect ratio

available for the TV screen.

15. CH. RETURN button (p13)

Press to return to previous channel.

button

button (p15)

Installing the Batteries

5

Install the batteries (AA x 2) matching the polarity indicated inside battery compartment of the remote control.

21 3

Battery Precautions:

• Be sure to follow the correct polarity as indicated in the battery compartment. Reversed batteries may cause damage to the device.

• Do not mix different types of batteries together (e.g., Alkaline and Carbon-Zinc) or old batteries with fresh ones.

• If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from possible battery leakage.

• Do not try to recharge batteries; they can overheat and rupture.

6

EN

Control Panel5

SETUP INPUT POWER

top of the unit

VOLUME CHANNEL

1. SETUP button (p11)

1

Press to display the main menu.

2
3

2. VOLUME X / Y buttons (p13)

4

Press to adjust the volume or move right(X)/left(Y)

5

through the main menu items.

3. CHANNEL K / L buttons (p13)
Press to select channels or move up/down through the

main menu items.

4. INPUT button (p14)

• Press to access connected an external device like a
DVD player or VCR.

• Press to switch between the digital mode (DTV) and
analog mode.

5. POWER button (p11)

Press to turn the unit on and off.

6. Infrared Sensor Window

Receives infrared rays transmitted from the remote

control.

INTRODUCTION

CONNECTION

INITIAL SETTING

WATCHING TV INFORMATION

6

OPTIONAL SETTING TROUBLESHOOTING

Rear Panel5

1. ANT jack (p8)

RF coaxial cable connection for your antenna or

cable / satellite box.

2. HEADPHONE jack

Headphone connection for personal listening.

3. COMPONENT and AUDIO input jacks (p9)

Component video cable connection for an external

device.

Use component video and audio output jacks of an

external device.

4. AUDIO input jacks (p9)

RCA audio cable connection for an external device.

5. VIDEO input jack (p10)

RCA video cable connection for an external device.

6. S-VIDEO input jack (p9)

S-video cable connection for an external device.

7. COAXIAL (digital audio) output jack (p10)

Digital audio coaxial cable connection for a decoder or

an audio receiver.

Use digital audio input jack of an external device.

8. AC power cord

Connect to a standard AC outlet to supply power to

this unit.

rear of this unit

COAXIAL

VIDEO 2

PrPbY

VIDEO 1

AUDIOCOMPONENT

LR

AUDIO

LVIDEOS-VIDEO

R

1

2

side of the unit

3

4
5
6
7
8

7

EN

ONNECTION

C

Cables not included.

Please purchase the necessary cables at your local store.

Basic Connection

5

This section describes how to connect the unit to an antenna, cable/satellite box, etc.

Note:

• Be sure your antenna or other device is connected properly before plugging in the power cord.

[Antenna Cable Connection]

When connecting the unit to an antenna or cable TV company (without cable/satellite box)
Connect the RF coaxial cable on your home outlet to the antenna input jack of this unit.

e.g.)

VHF / UHF

antenna

RF coaxial cable

or

cable TV

company

rear of this unit

* Once connections are completed, turn on the unit and begin initial setup.

Channel scanning is necessary for the unit to memorize all available channels in your area.
(Refer to “Initial Setup” on page 11.)

Note:

• For your safety and to avoid damage to device, please unplug the RF coaxial cable from the antenna input jack before moving the unit.

• If you use an antenna to receive analog TV, it should also work for DTV reception. Outdoor or attic antennas will be more effective than set­top versions.

• To easily switch your reception source between antenna and cable, install an antenna selector.

• If you connect to the cable system directly, contact the CATV installer.

[Connection to Cable Box or Satellite Box]

Connect the RF coaxial cable on your home outlet to the input jack of the cable/satellite box.
Use another RF coaxial cable to connect the antenna input jack of the unit to the output jack of the cable/satellite box.

e.g.)

satellite

dish

or

cable TV

company

* Required cables and connecting methods differ depending on the cable/satellite box.

For more information, please contact your cable/satellite provider.

RF coaxial cable RF coaxial cable

cable/satellite box

RF OUTANT. IN

rear of this unit

8

EN

(red)

(blue)

(green)

Cables not included.

Please purchase the necessary cables at your local store.

External Device Connection

5

[Component Video Cable Connection]

Component video connection offers better picture quality for video devices connected to the unit.
Use a component video cable to connect the unit to external video devices equipped with component video output
jacks.
If you connect to the unit’s component video input jack, connect RCA audio cables to the audio L/R jacks of VIDEO2.

component
video cable

rear of this unit

COAXIAL

(green)

(blue)

VIDEO 2

(red)

(red)(blue)(green)

PrPbY

VIDEO 1

AUDIOCOMPONENT

LR

AUDI O

LVIDEOS-VIDEO

R

e.g.)

DVD player with the component
video output jacks

COMPONENT VIDEO OUT

AUDIO OUT

RL

(red)(blue)(green)

PrPbY

CONNECTION

INITIAL SETTING

WATCHING TVINTRODUCTION

RCA audio cable

Note:

• This unit accepts 480i / 480p / simplified 1080i video signals.

• Simplified 1080i video signal differs to the original 1080i video signal because it is displayed after converted into 480p signal.

[S-video Cable Connection]

S-video connection offers good picture quality for video devices connected to the unit.
Use an S-video cable to connect the unit to external video devices equipped with S-video output jack.
If you connect to the unit’s S-video input jack, connect RCA audio cables to the audio L/R jacks of VIDEO1.

e.g.)

DVD player with the S-video
output jack

AUDIO OUT

rear of this unit

S-VIDEO

OUT

RL

COAXIAL

VIDEO 2

PrPbY

VIDEO 1

AUDIOCOMPONENT

LR

AUDI O

LVIDEOS-V I D E O

S-video cable

RCA audio cable

OPTIONAL SETTING

TROUBLESHOOTING

INFORMATION

R

Note:

• If you connect to the S-video jack and the video jack at the same time, the S-video connection will have priority.

9

EN
