OWNER’S

MANUAL

COLOR TV/DVD/VCR TRIPLE COMBO

SRCD223B

SRCD227B

(23 inch)

(27 inch)

27” MODEL ILLUSTRATED

This Owner’s Manual is



SUPPLIED ACCESSORIES

made of recycled paper.



ACCESSORIES

PART NO.













Remote Control Unit

NE204UD













Batteries

2 AA Batteries

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.









Owner’s Manual

0EMN02178













As an ENERGYSTAR®

Partner, our company has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. ENERGY STAR® is a U.S. registered mark.

If you need additional operating assistance after reading this owner’s manual, please call

TOLL FREE : 1-800-968-3429.

Please read before using this equipment

PORTABLE CART WARNING
S3126A

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The caution marking is located on the rear of the cabinet.

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

IMPORTANT SAFEGUARDS

1.Read instructions-Allthe safety and operating instructions should be read before the appliance is operated.

2.Retain Instructions-Thesafety and operating instructions should be retained for future reference.

3.Heed Warnings-Allwarnings on the appliance and in the operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions should be followed.

5.Cleaning-UnplugTV/DVD/VCR from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6.Attachments-Donot use attachments not recommended by the TV/DVD/VCR manufacturer as they may cause hazards.

7.Water and Moisture-Donot use this TV/DVD/VCR nearwater-forexample, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8.Accessories-Donot place this TV/DVD/VCR on an unstable cart, stand, tripod, bracket, or table. The TV/DVD/VCR may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the TV/DVD/VCR. Any mounting of

the appliance should follow the manufacturer’s instructions and should use a mounting accessory

recommended by the manufacturer. An appliance and cart combination

should be moved with care.Quick

stops, excessive force, and uneven surfaces may cause the appliance

and cart combination to overturn.

AMEUBLES- Cet appareil ne doit être placé que sur un meuble (avec ou sans roulettes) recommandé par le fabricant. Si vous l’installez sur un meuble à roulettes, déplacez les deux ensembles avec précaution.

Un arrêt brusque, l’utilisation d’une force excessive et des surfaces irrégulières risquent de déstabiliser l’ensemble et de le renverser.

SYMBOLE D'AVERTISSEMENT POUR

LES COMPOSANTES

APPAREIL ET MEUBLE A ROULETTES

S3126A

9.Ventilation-Slotsand openings in the cabinet and the back or bottom are provided for ventilation and to ensure reliable operation of the TV/DVD/VCR and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the TV/DVD/VCR on a bed, sofa, rug, or other similar surface. This TV/DVD/VCR should never be placed near or over a radiator or heat register. This TV/DVD/VCR should not be placed in abuilt-ininstallation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10.Power Sources-ThisTV/DVD/VCR should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For TV/DVD/VCRs intended to operate from battery power, or other sources, refer to the operating instructions.

11.Grounding or Polarization-This TV/DVD/VCR is equipped with a polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12.Power-Cord Protection-Power-supplycords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

- 2 -

EN

1B15

FIGURE A

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECT RICAL CODE













ANTENNA













L EAD I N













W I R E



GROUND



C L A M P













ANTENNA





































DI SCHARG E UN I T













(NEC SECTION 8 10 -20)

EL ECTRI C













SE RV I CE













EQ U I PMEN T

























G RO UNDI NG CO NDUCTORS













(NEC SECTION 8 10 -21)











G RO UND CL AMPS

NEC - NATI O NAL EL ECTRI CAL CO DE





POWER SERVI C E G RO UNDI NG







EL EC TR O DE SYSTEM

S2 8 9 8 A





(NEC ART 2 50 , PART H)

13.Outdoor Antenna grounding-If an outside antenna or cable system is connected to the TV/DVD/VCR, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14.Lightning-Foradded protection for this TV/DVD/VCR receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV/DVD/VCR due to lightning andpower-linesurges.

15.Power Lines-Anoutside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16.Overloading-Donot overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

17.Object and Liquid Entry-Never push objects of any kind into this TV/DVD/VCR through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the TV/DVD/VCR.

18.Servicing-Donot attempt to service this TV/DVD/VCR yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19.Damage Requiring Service-Unplug this TV/DVD/VCR from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a.When the power-supplycord or plug is damaged or frayed.

b.If liquid has been spilled, or objects have fallen into the TV/DVD/VCR.

c.If the TV/DVD/VCR has been exposed to rain or water.

d.If the TV/DVD/VCR does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the TV/DVD/VCR to its normal operation.

e.If the TV/DVD/VCR has been dropped or damaged in any way.

f.When the TV/DVD/VCR exhibits a distinct change in per- formance-thisindicates a need for service.

20.Replacement Parts-Whenreplacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, injury to persons or other hazards.

21.Safety Check-Uponcompletion of any service or repairs to this TV/DVD/VCR, ask the service technician to perform routine safety checks to determine that the TV/DVD/VCR is in proper operating condition.

22.Heat-ThisTV/DVD/VCR product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

- 3 -

EN

1B15

PRECAUTIONS

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.

FCC WARNINGThis equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

RADIO-TVINTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1)Reorient or relocate the receiving antenna.

2)Increase the separation between the equipment and receiver.

3)Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4)Consult the dealer or an experienced radio/TV technician for help.

LASER SAFETY

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003du Canada.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

- 4 -

EN

1B15

LOCATION

WARNING

For safe operation and satisfactory performance of your TV/DVD/VCR, keep the following in mind when selecting a place for its installation:

Shield it from direct sunlight and keep it away from sources of intense heat.

Avoid dusty or humid places.

Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes at the top and bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

Install unit in a horizontal position.

Avoid locations subject to strong vibration.

Do not place the TV/DVD/VCR near strong magnetic fields.

Avoid moving TV/DVD/VCR to locations where temperature differences are extreme.

AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE

Do not handle the power cord with wet hands.

Do not pull on the power cord when disconnecting it from an AC wall outlet. Grasp it by the plug.

If, by accident, water is spilled on your unit, unplug the power cord immediately and take the unit to our Authorized Service Center for servicing.

Do not put your fingers or objects into the TV/DVD/VCR disc loading tray.

Do not place anything directly on top of the unit.

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, or after heating a cold room or under conditions of high humidity. If a DVD is played in a TV/DVD/ VCR which has moisture, it may damage the DVD and TV/DVD/VCR. Therefore when the condensation occurs inside the unit, turn the POWER on and allow at least 2 hours for the unit to dry out.

SYMBOLS USED IN THIS MANUAL

The following symbols below appear in some headings and notes in this manual, with the following meanings

TV/VCR

:Description refers to TV/VCR operation (in the TV/VCR mode).

DVD-V

:Description refers to playback of DVD video discs (in the DVD mode).

CD

:Description refers to playback of audio CDs (in the DVD mode).

MP3

:Description refers to playback of MP3 discs (in the DVD mode).

QUICK

:Description refers to the items to be set by the QUICK mode (in the DVD mode).

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

The serial number of this product may be found on the back of the unit. No other TV/DVD/VCR has the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase

Dealer Purchase from

Dealer Address

Dealer Phone No.

Model No.

Serial No.

- 5 -

EN

1C29

TABLE OF CONTENTS

C IMPORTANT SAFEGUARDS . . .2, 3

C PRECAUTIONS . . . . . . . . . . . . . . . .4

LOCATION . . . . . . . . . . . . . . . . . . .5

AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE .5

WARNING . . . . . . . . . . . . . . . . . . . .5

SYMBOLS USED IN THIS MANUAL . . . . . . . . . . . . . . . . . . . . .5

C TABLE OF CONTENTS . . . . . . . . . .6

C FEATURES . . . . . . . . . . . . . . . . . . . .7

C OPERATING CONTROLS AND

FUNCTIONS . . . . . . . . . . . . . . . .9, 10

C PREPARATION FOR USE . . . . . . .11

ANTENNA/CABLE

CONNECTION . . . . . . . . . . . . . . . .11

CONNECTING TO EXTERNAL INPUT JACKS . . . . . . . . . . . . . . . .12

INSTALLING THE BATTERIES . .12 EXTERNAL INPUT MODE . . . . . .12

CONNECTING TO A STEREO SYSTEM . . . . . . . . . . . . . . . . . . . .13

CONNECTING TO A STEREO AMPLIFIER EQUIPPED WITH DIGITAL INPUT JACKS SUCH AS MD DECK OR DAT DECK . . . . . . . . . .13

CONNECTING TO A RECEIVER WITH DOLBY DIGITAL

DECODER . . . . . . . . . . . . . . . . . . .14

TV/VCR SECTION

C SET UP FOR USE . . . . . . . . . . . . .

15

CHANNEL SET UP

FOR THE FIRST TIME . . . . . . . . .15

DELETING (OR ADDING) CHANNEL . . . . . . . . . . . . . . . . . . .15

CHANNEL SET UP AGAIN . . . . . .16 SELECTING THE LANGUAGE . .16 DAYLIGHT-SAVINGTIME . . . . . .16

CLOCK SET UP

(AUTO / MANUAL) . . . . . . . . .17, 18

C TV OPERATION . . . . . . . . . . . . . . .19

WATCHING A TV PROGRAM . . .19 DEGAUSSING . . . . . . . . . . . . . . . .19 PICTURE CONTROL . . . . . . . . . . .19 CLOSED CAPTION SYSTEM . . . .20 V-CHIPSET UP . . . . . . . . . . . . . . .21

C MTS(Multi-ChannelTelevision

sound)SYSTEM . . . . . . . . . . . . . . . .23

CHECKING THE SELECTED

MTS MODE . . . . . . . . . . . . . . . . . .23

MTS RECORDING/MONITOR MODE . . . . . . . . . . . . . . . . . . . . . .23

SELECTING THE MTS SYSTEM .24

C VIDEO CASSETTE . . . . . . . . . . . . .25

CPLAYBACK . . . . . . . . . . . . . . . . . . .26

NORMAL PLAYBACK . . . . . . . . .26 TRACKING ADJUSTMENT . . . . .26 SLOW MOTION . . . . . . . . . . . . . .26 PICTURE SEARCH . . . . . . . . . . . .26 STILL PICTURE . . . . . . . . . . . . . .26 VERTICAL HOLD CONTROL . . .26

C SPECIAL PLAYBACK . . . . . . . . . .27

RENTAL PLAYBACK . . . . . . . . . .27

AUTO REPEAT PLAYBACK . . . . .27

C SEARCH . . . . . . . . . . . . . . . . . . . . .28

ZERO RETURN . . . . . . . . . . . . . . .28 TIME SEARCH . . . . . . . . . . . . . . .28 INDEX SEARCH . . . . . . . . . . . . . .29

C SPECIAL FEATURES . . . . . . . . . .29

REAL TIME TAPE COUNTER . . .29

AUTO REWIND-EJECT . . . . . . . .29

C RECORDING . . . . . . . . . . . . . . . . .30

NORMAL RECORDING . . . . . . . .30

SKIPPING UNWANTED SCENES DURING RECORDING . . . . . . . . .30

OTR (One Touch Recording) . . . . . .31

COPYING A VIDEO CASSETTE (Requires a VCR or camcorder) . . .31

C TIMER . . . . . . . . . . . . . . . . . . . . . .32

AUTOMATIC

TIMER RECORDING . . . . . . . . . .32 TIMER PROGRAM EXTENSION .33

HINTS FOR AUTOMATIC TIMER RECORDING . . . . . . . . . . . . . . . . .34

AUTO RETURN . . . . . . . . . . . . . . .34 SLEEP TIMER . . . . . . . . . . . . . . . .34

C ON SCREEN DISPLAY . . . . . . . . .35

C CABLE CHANNEL

DESIGNATIONS . . . . . . . . . . . . . .35

DVD SECTION

C ABOUT THE DISCS . . . . . . . . . . . .36

PLAYABLE DISCS . . . . . . . . . . . .36 DISC TYPES . . . . . . . . . . . . . . . . .36

C PLAYING A DISC . . . . . . . . . . . . . .37

BASIC PLAYBACK . . . . . . . . . . . .37 GENERAL FEATURES . . . . . . . . .37 DISC MENU . . . . . . . . . . . . . . . . .37 TITLE MENU . . . . . . . . . . . . . . . . .37 RESUME . . . . . . . . . . . . . . . . . . . .38 PAUSE . . . . . . . . . . . . . . . . . . . . . .38 STEP BY STEP PLAYBACK . . . . .38

FAST FORWARD/REVERSE SEARCH . . . . . . . . . . . . . . . . . . . .38

SLOW FORWARD / SLOW REVERSE . . . . . . . . . . . . . . . . . . . .38

ZOOM . . . . . . . . . . . . . . . . . . . . . .38

C SEARCH FUNCTION . . . . . . . . . . .39

TRACK SEARCH . . . . . . . . . . . . .39 TITLE / CHAPTER SEARCH . . . .39 TIME SEARCH . . . . . . . . . . . . . . .39 MARKER SETUP SCREEN . . . . . .39

C SPECIAL PLAYBACK FUNCTION . . .40

REPEAT . . . . . . . . . . . . . . . . . . . . .40 PROGRAM . . . . . . . . . . . . . . . . . . .40 RANDOM PLAYBACK . . . . . . . . .40

C PLAYING A MP3 DISC . . . . . . . . . .41

MP3 PLAYBACK . . . . . . . . . . . . . .41 TRACK SELECTION . . . . . . . . . . .41 PROGRAM . . . . . . . . . . . . . . . . . . .41 RANDOM PLAYBACK . . . . . . . . .41

C CHANGING THE SETTINGS . . . .42

SUBTITLE LANGUAGE . . . . . . . .42 AUDIO LANGUAGE . . . . . . . . . . .42 STEREO SOUND MODE . . . . . . . .42 CAMERA ANGLE . . . . . . . . . . . . .42 BLACK LEVEL SETTING . . . . . . .42 VIRTUAL SURROUND . . . . . . . . .42

C THEON-SCREENINFORMATION . . .43

C CHANGING THE DVD SETUP

ITEMS . . . . . . . . . . . . . . . . . . . . . . .44

LANGUAGE SETTING . . . . . . . . .44 DISPLAY SETTING . . . . . . . . . . . .45 AUDIO SETTINGS . . . . . . . . . . . .45 PARENTAL CONTROL . . . . . . . . .46

C TROUBLESHOOTING GUIDE . . .47

C MAINTENANCE . . . . . . . . . . . . . . .50

DISC HANDLING . . . . . . . . . . . . .50

C SPECIFICATIONS . . . . . . . . . . . . .51

C WARRANTY . . . . . . . . . . .Back Cover

- 6 -

EN

1C29

FEATURES

TV/VCR Mode

Hi-Fi system–TheHi-Fistereo recording system offers you excellent sound quality with a dynamic range of 80dB, frequency response from 20Hz to 20kHz, and 0.005% wow and flutter.

Rotary 4-headRecord/PlaybackSystem–Four heads ensure excellent picture quality and special effects playback.

Index Search–Fast-forwardsto start of next recording.

Slow Motion–Viewrecorded program at slower than normal speed.

Infrared remote control

Trilingual on screen tv/vcr setup display selectable in English or Spanish or French

Real time counter–Thisshows the elapsed recording or playback time in hours, minutes, and seconds. The“–”indication will appear when the tape is rewound further than the tape counter position “0:00:00”.

181 channel capability PLL frequency synthesizer tuner with direct station call–(A converter may be necessary to view scrambled cable channels.)

Auto Clock Setting–Allowsyou to set the clock function from a PBS broadcast station.

Closed caption system–Youmay view specially labeled (cc) TV programs, movies, news, prerecorded tapes, etc. with either a dialogue caption or text display added to the program.

Auto power on and off system–Automatically turns on the TV/DVD/VCR when you insert the cassette, turns off after auto-rewind, and ejects when the beginning of the tape is reached.

Auto rewind when the end of a tape is reached–This function doesn’t occur when using timer recording.

Smooth mode change–TV/VCR mode, DVD mode automatically changes.

2 Step picture search operation–You can view a video program at a high speed or super high speed in either a forward or reverse direction in LP and SLP mode. For SP mode only high speed.

Three different playback tape speeds : SP/LP/SLP

Two different recording tape speeds : SP/SLP

Auto Head Cleaner–Automaticallycleans video heads as you insert or remove a cassette.

Zero Return–Thetape returns to counter of 0:00:00 by rewinding or fast forwarding.

Still–“Freeze”the picture at any time, for close viewing of a particular scene.

Digital Auto Tracking (DTR)–Automatically adjusts the tracking for each tape you play.

Rental play mode–Improvesplayback picture quality from worn tapes, such as rental tapes.

Auto repeat–Allowsyou to repeat the playing of a tape indefinitely without pressing the PLAY button.

Time search–Letyou set the TV/DVD/VCR to advance the tape by entering the desired playback time you want to skip.

OTR (One Touch Recording)–Instant timed recording from 30 to 480 minutes is possible at the push of the REC/OTR button.

1 Year, 8 events (including Daily and Weekly Timer Recording)–The built-in timer allows you to record up to 8 programs at different times on different channels up to 1 year in advance. The Daily timer allows recordings to be made of daily broadcasts, and the Weekly timer allows recording to be made once a week up to the end of the tape.

Auto return–Aftertimer recording is finished, the TV/DVD/VCR can return to the beginning of the recording.

Sleep timer–Allowsyou to have the TV/DVD/VCR automatically turn on or off at a desired time.

Timer Program Extension–Allow you to shift the time schedule for automatic timer recording.

V-CHIP–Enablesparents to prevent their children from watching inappropriate material on TV.

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

- 7 -

EN

1C29

DVD Mode

¡Dolby Digital sound

This player can a Dolby Digital signal having 5.1 channels when connected to a Dolby Digital decoder.

¡Still/fast/slow/step playback

Various playback modes are available including still pictures, fast forward/reverse, slow motion and step frames.

¡Random playback for audio CD and MP3

This player can shuffle the order of tracks to play them in random order.

¡Program playback for audio CD and MP3

You can program the order of tracks to play them in any desired order.

¡DVD menus in a desired language

You can display DVD menus in a desired language, if available on a DVD.

¡Screen saver/Autopower-offfunctions

The screen saver program starts when there is no input from the player for five minutes in the stop mode. When the screen saver program is activated for 15 minutes, the power automatically turns off.

¡Subtitles in a desired language

You can select a desired language for the display subtitles, if that language is available on a disc.

¡Selecting a camera angle

You can select the desired camera angle, if a disc contains sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound mode, if different languages and modes are available on a disc.

¡Parental lock

You can set the control level to limit playback of discs which may not be suitable for children.

¡On-screendisplay

Information about the current operation can be displayed on a TV screen, allowing you to confirm the currently active functions (such as program playback), on the TV screen using the remote control.

¡Search

Chapter search / Title search / Track search / Time search

¡Repeat

Chapter / Title / Track / Group / All / A-B

¡Zoom

Magnified screen can be displayed.

¡Marker

The part designated by user can be called back.

¡Resume Play

User can resume to playback from the part at which

the play was stopped.

¡Virtual Surround

¡Bit rate indication

¡DRC (Dynamic range control)

You can control the range of sound volume.

¡Automatic detection of discs

This player automatically detects if the loaded disc is DVD, audio CD or MP3 on disc.

¡Playback MP3 disc

NOTE:

We do not recommend the use of universal remote controls. Not all of the functions may be controlled with a universal remote control.

If you decide to use a universal remote control with this TV/VCR/DVD, please be aware that the code number given may not operate this TV/VCR/DVD. In this case, please call the manufacturer of the universal remote control.

- 8 -

EN

1C29

OPERATING CONTROLS AND FUNCTIONS

- TV/DVD/VCR FRONT PANEL - [Fig.1]





DVD buttons



TV/VCR buttons





POWER

VOLUME

SKIP PLAY SKIP

STOP OPEN/CLOSE

SELECT

CHANNEL

REC/OTR

REW PLAY F.FWD STOP/EJECT

HEADPHONE VIDEO

AUDIO



L

R























DVD



TV/VCR













SEARCH















1



2

3

4

3

5

6

7 8

9 10 11 12 13 14

4

15 16 17 18 19

20

21

- REMOTE CONTROL -



[Fig. 2]





5.STOP Button [TV/VCR P.26 / DVD P.37]









Stops operation of the disc. (main unit)





















Stops operation of the disc or tape contents.



















(remote control)

























6.OPEN/CLOSE Button[DVD P.37]





1

POWER PICTURE

SLEEP

SELECT



45



Press to open disc tray to insert a disc or to open





























to remove a disc.





22

1

2

3







44















11



7.Disc loading tray















CH.









23























4

5

6











8.DVD Indicator









7

8

9











Lights on during DVD mode.













2



9.SELECT Button







24

PAUSE



+100



VOL.













0

+10











Press to change to TV/VCR mode, external input

25

SPEED

C.RESET

ZOOM



MUTE



43









mode or DVD mode.























26













42



10.TV/VCR Indicator





(DVD) 3



PLAY







3 (DVD)

Lights on during TV/VCR mode.





(TV/VCR) 14



STOP







15 (TV/VCR)

11. CHANNELK/L Buttons





4

RECORD







MENU



5



Press to select memorized channel.













DISC

















13













41



12. Recording Indicator







DISPLAY











40







27













Flashes during recording. Lights up in the Stand-





ENTER









28

SETUP

TITLE





RETURN



39



by mode for Timer Recording.





29

CLEAR

SEARCH MODE REPEAT

A-B



38



13. REC/OTR (RECORD)Button[TV/VCR P.30, 31]



37



30

MODE

AUDIO

SUBTITLE

ANGLE





Press for manual recording. Activates One Touch

31



36



Recording. (OTR is only during TV/VCR mode.)















32













35



14. REW Button (for VCR)[TV/VCR P.26]



33













34



Press to rewind the tape, or to view the picture



















rapidly in reverse during playback mode. (Rewind



















Search)



























15. FWD Button (for VCR)[TV/VCR P.26]





















Press to rapidly advance the tape, or to view the

1.POWER Button [TV/VCR P.15 / DVD P.37]





picture rapidly in forward during playback mode.





(Forward Search)





Press to turn the power on and off.

















16. STOP/EJECT Button (for VCR)[TV/VCR P.28]

2.VOLUMEX/Y Buttons

























Press to stop the tape motion. Press in the Stop

Press to control the volume level for the DVD and TV.

mode to remove tape from the TV/VCR/DVD.

3.SKIP Buttons (for DVD)[P.38]













17. Remote sensor window





Press once to skip chapters or tracks to a desired

18. HEADPHONE Jack





point.





































To connect headphone (not supplied) for personal

Press and hold to change forward or reverse play-

listening.









back speed.









































19. VIDEO input Jack





4.PLAY Button [TV/VCR P.26 / DVD P.37]

















Connect to the video output jack of a video

Starts playback of the disc or tape contents.





camera or VCR, video game.











































- 9 -







EN

1C29

- TV/DVD/VCR REAR PANEL - [Fig.3]

ANT.

1

L









AUDIO OUT





R





COAXIAL

46

47

48 49

20.AUDIO L/R input Jacks

Connect to the audio output jacks of a video camera or VCR, video game.

21.Video Cassette compartment

22.PICTURE Button

Press to adjust the picture.

23.Number Buttons

TV Mode:[P.15]

Press two digits to directly access the desired channel.

Remember to press a "0" before a single digit channel.

+100 Button–

Press to select cable channels which are equal or greater than number 100.

DVD Mode: [P.39]

Press to enter the desired number.

+10 Button–

Press to enter the desired numbers which are equal or greater than number 10.

24.PAUSE Button [TV/VCR P.26 / DVD P.38]

Pauses the current disc or tape operation.

25.SPEED Button [TV/VCR P.30]

Press to choose the desired recording speed: SP/SLP.

26.C.RESET Button [TV/VCR P.28]

Press to reset counter to 0:00:00.

Press to cancel a setting of timer program. (See page 33.)

27.DISPLAY Button TV/VCR Mode: [P.23]

Display the counter or the current channel number and current time on the TV screen.

DVD Mode:[P.43]

Displays the current status on the TV screen for checking purposes.

28.SETUP Button [TV/VCR P.15] [DVDP.44-46]

Press to enter or exit the TV menu or DVD setup mode.

29.TITLE Button [DVD P.37]

Displays the title menu.

30.CLEAR Button [P.39]

Resets a setting.

31.MODE Button [DVD P.41]

Activates program playback or random playback mode.

32.SEARCH MODE Button [DVD P.39]

Press to locate a desired point.

33.AUDIO Button [DVD P.42]

Press to select a desired audio language or sound mode.

34.SUBTITLE Button [DVD P.42]

Press to select a desired subtitle language.

35.REPEAT Button [DVD P.40]

Repeats playback of the current disc, title, chapter or track.

36.ANGLE Button (DVD mode) [DVD P.42]

Press to change the camera angle to see the sequence being played back from a different angle.

37.A-BREPEAT Button[DVD P.40]

Repeats playback of a selected section.

38.RETURN Button [TV/VCR P.15 / DVD P.39]

Returns to the previous operation in the DVD setup mode.

39.ENTER Button [TV/VCR P.15 / DVD P.37]

Press to accept a setting.

40.Arrow Buttons TV/VCR Mode: [P.15]

Press to select a setting mode from the menu on the TV screen.

Press to select or adjust from a particular menu.

DVD Mode: [P.37]

Use when making settings while watching the display on a TV screen.

41.DISC MENU Button [DVD P.37]

Displays the menus in the DVD.

42.ZOOM Button [DVD P.38]

Enlarges part of a DVD-reproducedimage.

43.MUTE Button [P.20]

Mutes the sound. Press it again to resume sound.

44.SLEEP Button [TV/VCR P.34]

Sets the Sleep Timer.

45.SELECT Button [TV/VCR P.26 / DVD P.37]

Press to switch TV/VCR and DVD mode. You can see the mode (TV/VCR or DVD) on the front panel indicator.

- 10 -

EN

1C29

46.ANT. in Jack

Connect to an antenna, cable system, or satellite system.

47.Power cord

Connect to a standard AC outlet (120V/60Hz). NOTE: Remove the power cord from the hook to

avoid breaking a wire before you connect to a standard AC outlet.

48.COAXIAL digital audio out Jack

Connect to the digital input of an external amplifier or decoder for DVD audio only.

49.AUDIO L/R analog output Jack

Connect to the analog audio input of an external amplifier or stereo system.

PREPARATION FOR USE

ANTENNA/CABLE CONNECTION

Satellite Box or

Cable Box (Not supplied)

OUT

IN

VHF/UHF Antenna (Not supplied)

From Cable System or

VHF Antenna (Not supplied)

Satellite Dish





75-ohm





UHF Antenna

From Cable

Coaxial









(Not supplied)

System

Cable













(Not sup-









plied)



or

VHF/UHF





ANT.

1









Combiner









(Not supplied)

75-ohmCoaxial

or

ANT.







Cable (Not



[Fig. 4]





supplied)







or

Flat twin-leadcable







VHF/UHF SEPARATE ANTENNAS

In some areas it will be necessary to use an outdoor antenna.

CABLE WITHOUT CONVERTER/ DESCRAMBLER BOX

Use this connection if your cable system connects directly to your TV/DVD/VCR without a converter box.

By using this connection you can:

1)Use the TV/DVD/VCR remote to select channels.

2)Program one or more unscrambled channels for Automatic Timer Recording.

NOTE: This TV/VCR/DVD willONLY record and view the same channel.

CABLE WITH CONVERTER/ DESCRAMBLER BOX OR SATELLITE BOX

If your cable service supplies you with a converter box or if you use a satellite system, you can use the basic connection shown in the illustration.

By using this connection you can also record scrambled channels. However, channel selection must be made with the converter box or satellite box. This means that channels cannot be changed using the TV/DVD/VCR Remote Control. Unattended timer recording is limited to one channel at a time.

Antenna/Cable Connections

Continued on the Next Page.

- 11 -

EN

1C29

TO RECORD A SCRAMBLED/UNSCRAMBLED CHANNEL

1. Set the TV/DVD/VCR channel selector to the output channel of the Cable Converter Box or Satellite Box. (Ex. CH3)

2.Select the channel to record from your Cable Converter Box or Satellite Box.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

CONNECTING TO EXTERNAL

INPUT JACKS

When you watch a program recorded on an another source (VCR or video camera), use the audio/video input jacks on the front of the TV/DVD/VCR.

Connect the audio/video output jacks of another source to the AUDIO L/R and VIDEO jacks of this TV/DVD/VCR.

Then press the CHANNEL buttons K/L until "AUX" appears on the screen.

NOTE:

When you connect a monaural VCR (another source) to this TV/DVD/VCR, connect the Audio output jack of the monaural VCR (another source) to the AUDIO L jack of this TV/DVD/VCR. The audio will output in both L and R channel equally.



To the audio







output jacks





[Another source]









HEADPHONE

VIDEO

AUDIO



Audio/Video

L

R









coaxial cable







(not supplied)





etc.







To the video

[Front of the

TV/DVD/VCR]

output jack







[Fig. 5]

INSTALLING THE BATTERIES

1)Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.

2)Insert 2 “AA” penlight batteries into the battery compartment in the direction indicated by the polarity (+/-)markings.

3)Replace the cover.

EXTERNAL INPUT MODE

When using an external input signal (another VCR or video camera), connect the player’s audio/video output cables to the AUDIO L/R IN/

VIDEO IN jacks of your AUX TV/DVD/VCR. Then press the

CHANNEL button K orL until “AUX” appears on the screen.

- 12 -

EN

1C29

[Fig. 6]

CONNECTING TO A STEREO SYSTEM

Stereo system

ANT.

1

L

AUDIO OUT

R

COAXIAL

To ANALOG AUDIO INPUT jacks

To Right (red) and Left (white)



AUDIO OUT jacks

NOTES:

Be sure to turn off the power to all components in the system before connecting another component.

Refer to the Owner's Manuals for your stereo system and any other components to be connected to the TV/DVD/VCR.

For analog stereo (2-channel)TV-VCR-DVDsound.

CONNECTING TO A STEREO AMPLIFIER EQUIPPED WITH DIGITAL INPUT JACKS SUCH AS MD DECK OR DAT DECK

Use an audio coaxial digital cable available at retail for the audio connections.

Connecting to an amplifier equipped with digital input jacks such as MD Deck or DAT Deck.

ANT.

1



L



AUDIO OUT



R



COAXIAL

Amplifier equipped with digital

To DIGITAL AUDIO OUT

input jacks, MD deck,

(PCM/BITSTREAM)

DAT deck, etc.

COAXIAL jack

To COAXIAL DIGITAL

AUDIO INPUT jack

(only DVD AUDIO OUT)



[Fig. 7]

NOTES:

The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital sound by an MD or DAT deck.

Be sure to turn off the power to all components in the system before connecting another component.

Refer to the Owner's Manuals for the components to be connected to the TV/DVD/VCR.

Set Dolby Digital to OFF for audio output in the setup mode. Playing a TV/DVD/VCR using incorrect settings may generate noise distortion, and may also damage the speakers.

For digital stereo (2-channel)DVD sound only.

- 13 -

EN

1C29

CONNECTING TO A RECEIVER WITH DOLBY DIGITAL DECODER

If using this TV/DVD/VCR to play a DVD disc, the TV/DVD/VCR outputs DOLBY DIGITAL Data stream from its COAXIAL digital audio out jack. By hooking the player up to a receiver with Dolby Digital decoder, you can enjoy a more convincing, realistic ambience with powerful and high-qualitysurround sound as enjoyed in movie theaters.

Use audio coaxial digital cables available at retail for the audio connections.

Center







speaker

Front speaker





Front speaker

ANT.

L

(left)

(right)

1



AUDIO OUT







R







COAXIAL

Receiver with





To DIGITAL AUDIO OUT

Dolby Digital





To COAXIAL DIGITAL

(PCM/BITSTREAM)

decoder



AUDIO INPUT jack

COAXIAL jack

Surround

Surround

Subwoofer



speaker

speaker





(left)

(right)











[Fig. 8]

NOTES:

Be sure to turn off the power to all components in the system before connecting another component.

Refer to the Owner's Manuals for the components to be connected to the TV/DVD/VCR.

If connected to a receiver with Dolby Digital decoder, set DOLBY DIGITAL to ON for audio output in the setup mode. (See page 45 to set DOLBY DIGITAL to ON.)

Unless connected to a receiver with Dolby Digital decoder, set DOLBY DIGITAL to OFF for audio output in the setup mode. Playing a TV/DVD/VCR using incorrect settings may generate noise distortion, and may also damage the speakers.

Only DVD audio is available using the COAXIAL digital audio out jack.

For TV and VCR audio sound, please refer to “CONNECTING TO A STEREO SYSTEM” section on page 13). You will need to use these connection in addition to the above to enjoy TV and VCR sound through the same receiver.

Manufactured under license from Dolby Laboratories. “Dolby” and the double-Dsymbol are trademarks of Dolby Laboratories.

- 14 -

EN

1C29

TV/VCR SECTION

SET UP FOR USE

You can program the tuner to scan all the channels you receive in your area.

NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just select the TV/DVD/VCR channel selector to the output channel of the cable box or satellite box (Ex CH3). Then select the channel to be viewed on the Cable Box or Satellite Box.

CHANNEL SET UP FOR THE

FIRST TIME

TV/VCR

1 Plug in the TV/DVD/VCR power

cord

Plug the TV/DVD/VCR power cord into a standard AC outlet.

NOTE:

If some digits appear in the corner of

the screen, press the POWER button without unplugging the power cord.

DELETING (OR ADDING)

CHANNEL

TV/VCR

The channels you no longer receive or seldom watch can be deleted from the memory. (Of course, you can add the deleted channel into the memory again.)

1 Select “CHANNEL SET UP”

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK B CHANNEL SET UP

USER’S SET UP

V-CHIPSET UP LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

2 Turn on the TV/DVD/VCR

Press the POWER button to turn on the TV/DVD/VCR.

3 Select “ENGLISH” or “ESPAÑOL” or

“FRANÇAIS”

– SET UP –



Select “ENGLISH” or

B LANGUAGE

[ENGLISH] ESP FRA

“ESPAÑOL”=Spanish or

AUTO PRESET

“FRANÇAIS” =French using the



ENTER button. “[ ]” indicate the



selected language.







4 Begin auto preset

Press the Arrow button K orL to point to “AUTO PRESET”. Then press the ENTER button.

The tuner scans and memorizes all active channels in your area.

NOTES:

– SET UP –

LANGUAGE

[ENGLISH] ESP FRA

B AUTO PRESET

The TV/DVD/VCR distinguishes TV channels and cable channels.

If you want to play or record a video

BEFORE presetting the tuner, you must press the SETUP button on the remote control. To preset the tuner again, see “CHANNEL SET UP AGAIN” on page 16.

The TV/DVD/VCR may memorize TV channels as CATV channels if reception conditions is poor. If this happens, try AUTO MEMO action again when reception conditions are better.

2 Select “ADD/DELETE CH”

– CHANNEL SET UP –



Press the Arrow button K orL to

B ADD / DELETE CH (TV)

AUTO PRESET

point to “ADD/DELETE CH”.



Press the Arrow button K orL until your desired channel number appears.

(You can also use the number buttons

08



or the CHANNEL buttons K/L to

ADD / DELETE

enter it) (Example: CH8)



4 Delete (or add) it from (into) memory

Press the ENTER button. The channel number changes to light red. The channel is deleted from memory.

Added channel: Light blue.

Deleted channel: Light red.

To delete another channel, repeat steps [3] and [4].

If you press the ENTER button again, the channel is memorized again.

Press the RETURN button to return to TV/VCR SETUP MENU.

5 Exit the channel setup mode

5 After scanning



Press the SETUP button on the remote control to



The tuner stops on the lowest memorized channel.



returns to TV mode.





NOTE: To confirm that channel(s) has been deleted

If you want to recall the selected channels, you can





or added, press the CHANNEL button K orL.



select the desired channel directly with the remote con-







trol number buttons or the CHANNEL button K orL.

- 15 -

EN



1C29

CHANNEL SET UP AGAIN

TV/VCR

Make sure ...

Press the POWER button to turn on the TV/DVD/VCR.

1 Select “CHANNEL SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K orL to point to “CHANNEL SET UP”. Then, press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK

BCHANNEL SET UP USER’S SET UP V-CHIPSET UP

LANGUAGE [ENGLISH] CAPTION [OFF]

ZERO RETURN TIME SEARCH INDEX SEARCH

2 Begin auto preset

– CHANNEL SET UP –

Press the Arrow button K orL to

ADD / DELETE CH (TV)

point to “AUTO PRESET”.

B AUTO PRESET

Then, press the ENTER button. The tuner scans and memorizes all the active channels in your area.

3 After scanning

The tuner stops on the lowest

SELECTING THE

Make sure ...

Press the POWER button to turn TV/DVD/VCR.

NOTE: This function effects only the screen menu and not the audio

1 Select “LANGUAGE”

- TV/VCR SETUP -

Press the SETUP button on the

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

remote control.

USER’S SET UP

B LANGUAGE [ENGLISH]



V-CHIPSET UP

Press the Arrow button K orL to

CAPTION [OFF]

TIME SEARCH



ZERO RETURN

point to “LANGUAGE”.

INDEX SEARCH



2 Select “ENGLISH” or “ESPAÑOL” or “FRANÇAIS”

Select “ENGLISH” or “ESPAÑOL”= Spanish or “FRANÇAIS”= French using the ENTER button.

3 Exit the Language mode

Press the SETUP button on the remote control to return to TV mode.

NOTE: If Spanish or French is selected accidentally, 1)Press the SETUP button on the remote control. 2)Press the Arrow buttonK orL to point to “IDIOMA

[ESPAÑOL]” or “LANGAGE” [FRANÇAIS]. 3)Press the ENTER button to select your desired lan-

guage.

4)Press the SETUP button to exit.

DAYLIGHT-SAVINGTIME

When Daylight-SavingTime is ON, the clock will change automatically as follows:

First Sunday of April : At 2 AM the clock immediately changes to 3 AM. Any timer programming you have set to occur between 2 AM and 3 AM will not record.

Last Sunday of October : At 2 AM the clock immediately changes to 1 AM.

Make sure ...

Press the POWER button to turn on the TV/DVD/VCR.

-TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP

USER’S SET UP

V-CHIPSET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

Then, press the ENTER button.

2 Set “D.S.T.”(Daylight-Saving

Time) to [ON]

Press the Arrow button K orL to point to “D.S.T.”

Then, press the ENTER button until [ON] appears.

– SETTING CLOCK –

AUTO CLOCK

[ON]

AUTO CLOCK CH SEARCH

AUTO CLOCK CH

[02]

MANUAL CLOCK SET



B D.S.T.

[ON]

3 Exit theDaylight-SavingTime

Press the SETUP button on the remote control to return to TV mode.

TO CANCEL THE DAYLIGHT-SAVINGTIME

Repeat steps [1] to [2], select [OFF] using the ENTER button.

- 16 -

EN

1C29

CLOCK SET UP (AUTO / MANUAL)

The TV/DVD/VCR clock must be set correctly VCR timer recording is possible. It is suggested clock be set manually when first setting up the

TV/DVD/VCR. Then, setup auto clock correction which will periodically correct the setting if necessary. NOTE: If you cannot receive a station with time signals, auto clock setting cannot be performed. Use manual setting only.

MANUAL CLOCK SETTING

Make sure ...

TV/DVD/VCR power is turned on

In the example below, the clock is to

DATE

May 6th, 2003

SETTING TIME

5:40PM

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control.

Press the Arrow button K orL to point to “SETTING CLOCK”. Then, press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING

BSETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIPSET UP

LANGUAGE [ENGLISH]

CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

2 Select “MANUAL CLOCK



– SETTING CLOCK –

SET”

AUTO CLOCK

[ON]

Press the Arrow button K orL to

AUTO CLOCK CH SEARCH

AUTO CLOCK CH [02]

B MANUAL CLOCK SET

point to “MANUAL CLOCK SET”.

D.S.T.



[OFF]







Then, press the ENTER button.











3 Select the month

– MANUAL CLOCK SET –

Press the Arrow button K orL until

MONTH DAY

YEAR

your desired month appears.

0 5 / – – – – – – – – –

(Example: May 05)

HOUR

MINUTE

Then, press the Arrow button B.

– –

: – –

– –











4 Select the day

– MANUAL CLOCK SET –

Press the Arrow button K orL until

MONTH DAY

YEAR

your desired day appears.

0 5 / 0 6 – – – – – – –

(Example: 6th 06)

HOUR

MINUTE

Then, press the Arrow button B.















5 Select the year







Press the Arrow button K orL until

– MANUAL CLOCK SET –

MONTH DAY

YEAR

your desired year appears.

0 5

/ 0 6

TUE 2 0 0 3

(Example: 2003)

HOUR

MINUTE

Then, press the Arrow button B.

– –

: – –

– –

– MANUAL CLOCK SET –

MONTH

DAY

YEAR

0 5 /

0 6 TUE

2 0 0 3

HOUR

MINUTE



7 Select the minute

– MANUAL CLOCK SET –

Press the Arrow button K orL until

MONTH DAY

YEAR

the desired minute appears.

0 5

/ 0 6 TUE

2 0 0 3







(Example: 40)

HOUR

MINUTE



8 Start the clock

5:40 PM

Press the SETUP button on the remote control.

Although seconds are not displayed, they begin counting from 00 when you press the SETUP button on the remote control. Use this feature to clock with the correct time.

TO CHANGE CLOCK

If you want to change the clock,

4)Press the SETUP button on the start the clock.

PLEASE NOTE:

If there is no local PBS station in your cable system, select “AUTO press the ENTER button to turn Then you can manually adjust the

- 17 -

EN

1C29

AUTOMATIC CLOCK SETTING

Make sure ...

The TV/DVD/VCR is turned on.

Confirm the TV/DVD/VCR is receiving a RF (Radio Frequency) signal from either an cable system connection using the ANT IN the rear of the TV/DVD/VCR.

NOTE:

If a cable converter box is being used, is powered on.

You must use the TV/DVD/VCR perform the clock setting procedure

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control.

Press the Arrow button K orL to select “SETTING CLOCK”. Press the ENTER button to enter “SETTING CLOCK” menu.

- TV/VCR SETUP -

TIMER PROGRAMMING

BSETTING CLOCK CHANNEL SET UP

USER’S SET UP V-CHIPSET UP LANGUAGE [ENGLISH]

CAPTION [OFF] ZERO RETURN

TIME SEARCH INDEX SEARCH

2 Set “AUTO CLOCK” to [ON]

– SETTING CLOCK –

Press the ENTER button until

B AUTO CLOCK

[ON]

AUTO CLOCK [ON] appears.

AUTO CLOCK CH SEARCH

MANUAL CLOCK SET

[02]



AUTO CLOCK CH

3 Begin “AUTO CLOCK CH

Press the Arrow button L to select CH SEARCH”.

Press the ENTER button.

The TV/DVD/VCR is now searching for the station which contain the auto clock set signal. The search for a signal may take up to 20 seconds per channel.

“_ _” appears at the lower left of the screen when the search has ended.

Auto Clock stationwrite down the number(s) that appear on the screen. These are the auto clock station(s) in your area. See item 4 below.

– SETTING CLOCK –

AUTO CLOCK

[ON]

B AUTO CLOCK CH SEARCH

AUTO CLOCK CH

[02]

MANUAL CLOCK SET



D.S.T.

[OFF]

AUTO CLOCK CH SEARCH –

08 10 13

_ _

If no number(s) appear on the TV screen, there are no stations in your area which contain the Auto Clock signal. Auto Clock Setting is not possible. Please use Manual Clock Setting on page 17.

Press the SETUP button to exit the screen. NOTE: During Auto Clock CH Search, the picture may be distorted. This is normal.

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP

USER’S SET UP

V-CHIPSET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

“AUTO CLOCK CH”.

screen.

5 Turn off the TV/DVD/VCR

4Enter the channel number that contains the Automatic Clock Setting Signal

Press the SETUP button on the remote control.

- 18 -

EN

1C29

TV OPERATION

WATCHING A TV PROGRAM

TV/VCR

1 Turn on the TV/DVD/VCR

Press the POWER button to turn on the TV/DVD/VCR.

2 Select the channel number

Press the CHANNEL button K orL to select your desired channel number or press the number on the remote control.

Note for using the Number button on the remote control:

¡When selecting cable channels which are higher than 99, press +100 first, then, press the last two digits. (Example: to select channel 125, first press “+100” then press “2” and “5”).

¡You must precedesingle-digitchannel numbers with a zero (For example: 02, 03, 04 and so on).

Remember: If the TV/DVD/VCR is connected to a cable box or satellite box, the TV/DVD/VCR must be on CH3 or CH4, then the channel to be viewed must be selected on the cable box or satellite box.

3 Adjust sound

Press the VOLUME button X orY to adjust the volume.

VOLUME 20

C C C C C C C C C C C C

NOTES:

If you press the CHANNEL button DVD mode, you can change the TV

Even if you turn off the TV/DVD/VCR DVD mode, when you turn it on

into the TV/VCR mode.

DEGAUSSING

Magnetism from nearby appliances might affect the color of the TV picture

If this happens, move this TV/VCR/DVD the appliance. If the color is still not using the POWER button, then turn it minutes or so later.

PICTURE CONTROL

TV/VCR

The TV/DVD/VCR’s picture controls – BRIGHT, CONTRAST, COLOR, TINT andSHARPNESS – are preset to factory specifications. Although they are usually the best, you may need to make some further adjustments for a natural looking image.

NOTES:

Procedures must be followed within 5 seconds or the Picture Control mode will be cancelled.

When setting the Picture Control, the Game mode will be cancelled.

Make sure ...

TV/DVD/VCR power must be turned on.

1 Select “PICTURE CONTROL”

Press the PICTURE button on the remote control.

2 Select item you want to adjust

Press the Arrow button K orL until desired control is displayed.

BRIGHT

P P P P P P P C P P P P P P P+

3 Adjust the picture control

Press the Arrow button s orB to adjust to your desired level.



Arrow button s

Arrow button B







BRIGHT

to decrease

to increase



brightness

brightness







CONTRAST

to decrease

to increase



contrast

contrast







COLOR

to pale

to brilliant







TINT

to purple

to green







SHARPNESS

to soft

to clear







If there is a power failure of any kind, the TV/VCR/DVD will retain its memory for this feature.

- 19 -

EN

1C29

CLOSED CAPTION SYSTEM

TV/VCR

You can view specially labeled (cc) TV programs, movies, news, pre-recordedtapes with either a dialogue caption or text display.

CAPTION mode: By choosing the caption mode, you can watch dramas, movies and news while captioning the dialogues and the contents of news.

TEXT mode: By choosing the text mode, you can watch half screen text information if you want.1-2: You may get these captions or text information by selecting either “1” or “2”. Caption “2” is used, usually for a second language if available.

NOTE:

Not all programs are broadcast with closed captions. Your television is designed to provide error free closed captions from high quality antenna, cable and VCR signals. Conversely, poor quality signals are likely to result in caption errors or no captions at all. Common signal conditions which may cause captions errors are listed below:

Automobile ignition noise

Electric motor brush noise

Weak snowy reception on TV screen

Multiplex signal reception displaying picture ghosts or airplane flutter.

Playback of poorly recorded or worn VCR tapes.

NOTE:

If the TV/DVD/VCR displays a black box on the TV screen, this means that the TV/DVD/VCR is set to the TEXT mode. To clear screen, select [CAPTION1], [CAPTION2] or [OFF].

Make sure ...

TV/DVD/VCR power must be turned on.

1 Select “CAPTION”

- TV/VCR SETUP -

Press the SETUP button on the

TIMER PROGRAMMING

CHANNEL SET UP



SETTING CLOCK

remote control.

USER’S SET UP

V-CHIPSET UP



LANGUAGE [ENGLISH]

Press the Arrow button K orL to

B CAPTION [OFF]

TIME SEARCH



ZERO RETURN

point to “CAPTION”.







2 Select your desired caption



Press the ENTER button until your

- TV/VCR SETUP -

desired caption menu appears.

TIMER PROGRAMMING

SETTING CLOCK



CHANNEL SET UP

([CAPTION1], [CAPTION2],

USER’S SET UP

LANGUAGE [ENGLISH]



V-CHIPSET UP

[TEXT1] or [TEXT2])

B CAPTION [CAPTION1]

ZERO RETURN



TIME SEARCH



INDEX SEARCH

3 Exit the caption setting mode

Press the SETUP button on the remote control to return to TV mode.

TO CANCEL THE CLOSED CAPTION SYSTEM

Repeat steps [1] and [2], select [OFF] using the ENTER button. Press the SETUP button on the remote control to return to TV mode.

WHEN THE CLOSED CAPTION MODE IS ON

The On-ScreenDisplay will disappear after 5 seconds.

also disappear when the MUTE button is and when the PAUSE button is pressed

recording.

there is a power failure of any kind, the TV/DVD/VCR will retain its memory for this feature.

- 20 -

EN

1C29

V-CHIPSET UP

V-CHIPSET UP

Make sure ...

TV/DVD/VCR is turned on.

1 Select“V-CHIPSET UP”

Press the SETUP button on the remote control.

Press the Arrow button K orL to select“V-CHIPSET UP”.

Then, press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP USER’S SET UP

BV-CHIPSET UP LANGUAGE [ENGLISH]

CAPTION [OFF] ZERO RETURN TIME SEARCH

INDEX SEARCH

2 Enter Access code

Use the number buttons on the remote control to enter the access code.

For the first time set-upor in the event the TV/DVD/VCR has lost power, enter the default code of the 0000.

3 Select “TV RATING”









V-CHIPSET UP –











Press the Arrow button K orL to

B TV RATING







MPAA RATING





select “TV RATING”.

CHANGE CODE













Then, press the ENTER button.



















4 Blocking TV programs









Press the Arrow button K orL to

B TV–Y



[VIEW]



select “TV rating” that you wish to

TV–Y7(

)

[VIEW]



TV–PG(

)

[VIEW]





TV–G



[VIEW]



block.

TV–14(

)

[VIEW]



TV–MA(

)

[VIEW]



Press the ENTER button to turn it [BLOCK].

When you select the rating category and turn it [BLOCK], the higher rating will turn [BLOCK] automatically. Also, the lower rating will turn [VIEW] automatically.

When you turn “TV-Y”to [VIEW], then all ratings will turn to [VIEW] automatically.

Selection

Rating Category Explanations

TV-Y

Appropriate for all children

TV-Y7

Appropriate for children seven and older

TV-G

General Audience

TV-PG

Parental Guidance suggested.

TV-14

Unsuitable for children under 14





TV-MA

Mature audience only









5 Exit theV-Chipsetting mode

Press the SETUP button on the remote control to exit the screen.

V-CHIPSET UP SUB RATINGS

When you select the ratings of TV-Y7,TV-PG,TV-14orTV-MAyou will have the option of selecting sub rating categories.

1 Select“V-CHIPSET UP”

- TV/VCR SETUP -



Press the SETUP button on the

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

remote control.

USER’S SET UP

LANGUAGE [ENGLISH]



B V-CHIPSET UP

Press the Arrow button K orL to

CAPTION [OFF]

TIME SEARCH



ZERO RETURN

select “V-CHIPSET UP”. Then,

INDEX SEARCH







press the ENTER button.















2 Enter Access code







Use the number buttons on the







remote control to enter the access













code. (Default code is 0000.)















3 Select “TV RATING”







Press the Arrow button K orL to







select “TV RATING”.







Then, press the ENTER button.







4 SelectingSub-Ratings”

Press the Arrow button L to select wish to block. Then, press the ENTER

When you select [TV-Y7]:

Press the Arrow button L orK to select “FV” (Fantasy Violence). Then, press the ENTER button to select [BLOCK] or [VIEW].

When you select [TV-PG],[TV14] or[TV-MA]:

Press the Arrow button L orK to select “D”(Suggestive Dialog), “L”(Coarse Language), “S”(Sexual Situation), or “V”(Violence). Then, press the ENTER button to select [BLOCK]Note: When you select[TV-MA],appear on the TV screen.

The sub-ratingswhich set to [BLOCK] appears next to the rating category in the TV rating menu.

5 Exit theV-Chipsetting mode

Press the SETUP button on the remote enter the setting and exit the screen.

- 21 -

EN

1C29

CHANGING V-CHIPBLOCKED PROGRAMMING

Note: To change the rating, the TV must be turned to a station that is not protected. If the (PROTECTED) appears on the screen, please change the channel to a station that is not protected.

1)Follow steps [1] and [2].

2)Press the Arrow button K orL to select "TV RATING". Then, press the ENTER button. Select a TV rating to be unblocked by pressing the Arrow buttonK orL.

Then press the ENTER button to unblock the rating. 3)Press the SETUP button on the remote control to

exit the screen.

MPAA RATING SET UP

1 Select“V-CHIPSET UP”

- TV/VCR SETUP -

TIMER PROGRAMMING

Press the SETUP button on the

SETTING CLOCK

USER’S SET UP





CHANNEL SET UP

remote control.

B V-CHIPSET UP

LANGUAGE [ENGLISH]





CAPTION [OFF]

Press the Arrow button K orL to

ZERO RETURN

TIME SEARCH

select “V-CHIPSET UP”. Then,

INDEX SEARCH







press the ENTER button.















2 Enter Access code

ACCESS CODE

Use the number buttons on the







remote control to enter the access







_ _ _ _















code.

















3 Select “MPAA RATING”







Press the Arrow button K orL to







point to “MPAA RATING”.







Then, press the ENTER button.















4 Select your desired item







Press the Arrow button K orL to







point to your desired item.







Then, press the ENTER button to







select [BLOCK] or [VIEW].

















Selection

Rating Category







G

General Audience







PG

Parental Guidance







PG-13

Unsuitable for children







RRestricted; under 17 nying parent or adult

NC-17No one under 17

XMature audience only

When you select the rating category and turn it [BLOCK], the higher rating will turn [BLOCK] automatically. Also, the lower rating will turn [VIEW] automatically.

When you turn “G” to [VIEW], then all ratings will turn to [VIEW] automatically.

5 Exit theV-Chipsetting mode

Press the SETUP button on the remote control to exit the screen.

CHANGE ACCESS CODE

To change access code, follow the steps.

1 Select“V-CHIPSET UP”

Press the SETUP button on the remote control. Press the Arrow button K orL to select“V-CHIPSET UP”.

Then, press the ENTER button.

2 Enter Access

ACCESS CODE

UP –

Press the Arrow button K orL to

TV RATING

MPAA RATING

select "CHANGE CODE". Then,

B CHANGE CODE



press the ENTER button.



4 Enter New code

Use the number buttons to enter your desired access code in the NEW CODE space. Then enter the same code in the CONFIRM CODE space. V-CHIPSET UP screen appear on the screen.

If you enter wrong code, repeat sure you enter the same new code confirm code space.

5 Exit theV-Chipsetting mode

Press the SETUP button on the exit the screen.

Note: If you unplug the power code occurs, the changed access code return to default (0000). Change again as necessary.

- 22 -

EN

1C29

MTS(Multi-ChannelTelevision sound)SYSTEM

You can record or listen to a program in MTS stereo.

CHECKING THE SELECTED MTS MODE

When you play a VHS tape, or receive a broadcast on the TV/DVD/VCR tuner channel you are watching, the status shown below will appear when you press the DISPLAY button on the remote control.

4]





PLAY B



12:00AM







HIFI





CH 123

3]







































STEREO/SAP





2]









































1]







SP

COUNT 0:00:00















SAP



Second Audio Program, which means your





program, can also be received in a second





language or sometimes a radio station.







HIFI



High Fidelity records and plays back video-





tape in high quality stereo sound.

























TV/VCR

1] When a program is broadcast in stereo, STEREO appears on the TV screen.

2] When a program is broadcast in second audio, SAP appears on the TV screen.

3] When a program broadcast both in stereo and second audio, STEREO and SAP appear on the TV screen.

NOTE: Although a program may be broadcast in both stereo and second audio, you cannot record in both stereo and second audio at the same time.

4] While the TV/DVD/VCR is set in HIFI stereo mode and playback mode. HIFI appears on the TV screen. While the TV/DVD/VCR is set in monaural(MONO) mode, HIFI disappears from the TV screen.

NOTE: If you playnon-HIFItapes while the TV/DVD/VCR is set in HIFI, HIFI will disappear from the TV screen and the TV/DVD/VCR will play automatically in monaural.

MTS RECORDING/MONITOR MODE















TV/VCR

































Type of broadcast

Display on

STEREO/SAP

Hi-Fiaudiotrack(2-channel)

Normal audio



the TV screen

SELECTION

L-channel

R-channel



track

















Regular

-None-

-Invalid-

Mono

Mono





Mono

(monaural audio)































Stereo broadcast

STEREO

-Invalid-

L

R





L+R

















Bilingual broadcast

SAP

STEREO*

Main audio

Main audio



Main audio







program

program



program





















SAP*

Sub audio

Sub audio



Sub audio







program

program



program

Stereo & Bilingual

STEREO

STEREO*

L

R





L+R

broadcast

SAP

SAP*

sub audio

sub audio



sub audio







program

program



program

















*You must select the recording mode in TV AUDIO [STEREO] or [SAP] when you record a broadcast.

- 23 -

EN

1C29

SELECTING THE MTS SYSTEM

Make sure ...

TV/DVD/VCR power must be turned on.

TO SELECT HIFI MODE

1 Select “USER’S SET UP”

Press the SETUP button on the

- TV/VCR SETUP -

TIMER PROGRAMMING

remote control.

SETTING CLOCK



B USER’S SET UP





CHANNEL SET UP



Press the Arrow button K orL to

V-CHIPSET UP



CAPTION [OFF]





LANGUAGE [ENGLISH]

point to “USER’S SET UP”. Then,

ZERO RETURN



TIME SEARCH



press the ENTER button.

INDEX SEARCH











2 Select“VCR AUDIO”

– USER’S SET UP –

Press the Arrow button K orL to

RENTAL

[OFF]

point to“VCR AUDIO”.

AUTO RETURN

[OFF]



REPEAT PLAY

[OFF]



B VCR AUDIO

[HIFI]



TV AUDIO

[STEREO]





3 Select [HIFI]

– USER’S SET UP –

Press the ENTER button until

RENTAL

[OFF]

[HIFI] appears.

AUTO RETURN

[OFF]



REPEAT PLAY

[OFF]



B VCR AUDIO

[HIFI]



TV AUDIO

[STEREO]

TV/VCR

TO SELECT MONO MODE

You can change the selection to “MONO” if you want to listen to HIFI tapes in normal audio playback.

1)Press the SETUP button on the remote control. Press the Arrow button K orL to point to “USER’S SET UP”.Then, press the ENTER button.

2)Press the Arrow button K orL to point to

“VCR AUDIO”.

3)Press the ENTER button until [MONO] appears.

4)Press the SETUP button on the remote control to return to TV mode.

Select “USER’S SET UP”

– USER’S SET UP –

4 To return to TV mode

Press the SETUP button on the remote return to TV mode.

NOTES:

Normally, “HIFI” should be selected with HIFI sound.

When you play non-HIFItapes, the will play automatically in the

The TV/DVD/VCR records broadcasts in HIFI stereo sound SAP mode recording before you

RENTAL

[OFF]

REPEAT PLAY

[OFF]

AUTO RETURN

[OFF]

VCR AUDIO

[HIFI]

B TV AUDIO

[STEREO]

3 Select [STEREO], [SAP], or [MONO]

Press the ENTER button until [STEREO], [SAP], or [MONO] appears.

4 To return to TV mode

Press the SETUP button on the remote control to return to TV mode.

NOTES:

You must select the recording mode,either TV AUDIO [STEREO] or [SAP] when you record a broadcast.

Refer to “MTS RECORDING/MONITOR MODE”.

If you select second audio when second audio is not

available, the TV/DVD/VCR will record normal audio.

The TV/DVD/VCR records automatically MTS broadcasts in HIFI stereo sound unless you select SAP mode recording before you begin recording.

- 24 -

EN

1C29

VIDEO CASSETTE

This TV/DVD/VCR will operate with any cassette that has the mark. For best results, we recommend the use ofhigh-qualitytapes. Do not use poor quality or damaged tapes.

PRECAUTIONS

Avoid moisture. Moisture condensation may occur on the tape if it is moved from a cold place to a warm place or visa versa. Before using a tape with these conditions, to avoid damage of the tape and your TV/DVD/VCR, wait until the tape has warmed to room temperature and the moisture has evaporated.

Avoid extreme heat, high humidity and magnetic fields.

Do not tamper with the cassette mechanism.

Do not touch the tape with your fingers.

INSERTING A CASSETTE

Insert the cassette in the direction as shown. Push in gently, but continuously, on the center-backof the cassette until it is drawn into the TV/DVD/VCR. The TV/DVD/VCR will automatically turn on.

Window

CORRECT

WRONG

TWO DIFFERENT TAPE SPEEDS

Before recording, select the tape speed from : SP mode (Standard Play) orSLP mode (Super Long Play).

The table below shows the maximum recording/playback time using T60, T120 or T160 tapes in each mode.

Tape Speed

Recording/Playback Time













Type of tape

T60

T120

T160











SP mode

1 hour

2 hours

2-2/3hours











SLP mode

3 hours

6 hours

8 hours











Note: You can play back a tape recorded in LP mode (Long Play).

REMOVING A CASSETTE

1)In the Stop mode, press the EJECT button on the remote control or press the STOP/EJECT button on the TV/DVD/VCR. The cassette will eject.

2)Pull the cassette out of the cassette compartment. 3)Store the cassette in its case as shown.

ERASE PREVENTION

You can prevent accidental erasing of recording by breaking off the tab on the back edge of the cassette.

If you decide to record on the tape again, cover the hole with plastic tape.

NOTE:

Tab

Transparent Tape

In DVD mode, Whether the cassette is with tab or without tab you insert, it doesn’t start playing until you press the PLAY button.

In TV/VCR mode, if th cassette without tab is inserted, playback will automatically start.

- 25 -

EN

1C29

PLAYBACK

NORMAL PLAYBACK



SLOW MOTION

























TV/VCR

TV/VCR

Make sure ...









During pause, press the FWD button to reduce the





TV/DVD/VCR power must be









playback speed. The TV/DVD/VCR mutes the sound









during slow motion. Press the PLAY button to return





















to normal playback.





1 Insert a prerecorded tape



















NOTE: If it is left in the Slow mode for more than

If the erase-protectiontab has been









five minutes, the TV/DVD/VCR will automatically

TV/DVD/VCR will start playback









go into the Stop mode.









































2 To begin playback

B



























Press the PLAY button.





























































will be muted.















1)You may view a video tape at a high speed in





3 To stop playback











STOP



either a forward or reverse direction by pressing

Press the STOP button when play-









the F.FWD or REW button during playback. (in the

back is completed.









SP / LP / SLP modes)















NOTE:





























If you press the F.FWD or REW button on the





NOTES:









front panel in the DVD mode, the VCR forward









or reverse will start. Please press the STOP /





If you press the PLAY button (of the TV/VCR side)









EJECT button once to stop it, twice to eject it.





in the DVD mode, you can start the VCR playback.



2)Press it again and the TV/DVD/VCR will now search

If you press the SELECT button in the VCR play-





in super high speed. (in the LP / SLP modes only)





back, it will stop and the mode will change to the



NOTE:





DVD mode. In addition, the same function oper-



Tapes recorded in the SP or LP mode will dis-

ates with the DVD side PLAY button or the



play a noise bar on the TV screen and the picture

OPEN/CLOSE button.









may revert to Black and White. This is normal.











3)Press the PLAY button to return to normal speed.

TRACKING ADJUSTMENT













STILL PICTURE























TV/VCR





























Tracking adjustment will be set automatically







TV/VCR







You can view a still picture on the TV screen during playback

(Digital Tracking function) when you start play-





(the Still mode). Press the PAUSE button during playback.





back.





















Only tapes recorded in the SLP mode will show the least





However when playingpre-recordedtapes or tapes









amount of lines.Press the PLAY button to return to playback.

recorded on units other than your own, noise lines



NOTES:





(black and white streaks) may appear on the play-









You can advance the picture one frame at a time by

back picture. If this occurs, you can adjust the





pressing the PAUSE button during the Still mode.

tracking control manually by pressing the CHAN-





If it is left in the Pause mode for more than five





NEL button K orL until the streaks disappear. To



minutes, the TV/DVD/VCR will automatically





return to the DTR function, stop the tape once and



switch to the Stop mode.





start playback again.

























VERTICAL HOLD CONTROL

You can reduce the noise lines by pressing the



CHANNEL button K orL in slow mode, too.















TV/VCR



Tracking adjustment in Slow mode will not be set









In the Pause/Still mode only, when the picture begins

automatically.

















to vibrate vertically, stabilize the picture by pressing





















the CHANNEL button K orL.















NOTE:















If there are video noise lines on the screen, see Tracking











Adjustment section.







- 26 -



EN

1C29

SPECIAL PLAYBACK

Make sure ...

TV/DVD/VCR power must be turned

Insert a prerecorded tape.

RENTAL PLAYBACK

This function enables you to improve quality when playing back worn rented tapes.

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K orL to point to “USER’S SET UP”. Then, press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

BUSER’S SET UP

V-CHIPSET UP LANGUAGE [ENGLISH]

CAPTION [OFF] ZERO RETURN TIME SEARCH

INDEX SEARCH

2 Set “RENTAL” to [ON]

– USER’S SET UP –

Press the Arrow button K orL to

B RENTAL

[ON]

point to “RENTAL”.

AUTO RETURN

[OFF]



REPEAT PLAY

[OFF]

Press the ENTER button until [ON]

VCR AUDIO

[HIFI]

TV AUDIO

[STEREO]



appears.

3 Exit the Rental setting

Press the SETUP button on the remote control to return to the TV mode.

4 Start playback

Press the PLAY button to start playback. “RENTAL PLAY B” appears.

Once you select the Rental mode, it stays in effect even after you turn off the TV/DVD/VCR.

TO CANCEL THE RENTAL MODE

Repeat steps [1] and [2], select [OFF] using the ENTER button on the remote control. Press the SETUP button on the remote control to return to TV mode.

If there is a power failure of any kind, the tv/vcr/dvd will retain its memory for this feature.

AUTO REPEAT PLAYBACK

TV/VCR

The TV/DVD/VCR has the auto repeat function that allows you to repeat a tape indefinitely without touching the PLAY button.

ALL REPEAT: Repeat playback from the beginning to the end of the tape.

BLANK REPEAT: Repeat playback from the beginning to a blank part, which is blank for more than 10 seconds.

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

B USER’S SET UP

V-CHIPSET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

Then, press the ENTER button.

2 Select “ALL” or “BLANK”

Press the Arrow button K orL to point to “REPEAT PLAY”.

Press the ENTER button repeatedly until your desired selection [ALL] or [BLANK] appears.

– USER’S SET UP –

RENTAL

[OFF]

B REPEAT PLAY

[ALL]

AUTO RETURN

[OFF]

VCR AUDIO

[HIFI]

TV AUDIO

[STEREO]

3 Exit the Repeat Play setting

Press the SETUP button on the remote control to return to the TV mode.

4 Start playback

Press the PLAY button to start the Repeat Play. “REPEAT PLAY B” appears.

Once you select the Repeat Play mode, it stays in effect even after you turn off the TV/DVD/VCR.

If the Rental mode is set [ON], the “RENTAL PLAY B” display has priority.

TO CANCEL THE REPEAT PLAY MODE

Repeat steps [1] and [2], select [OFF] using the ENTER button on the remote control. Press the SETUP button on the remote control to return to TV mode.

If there is a power failure of any kind, the TV/DVD/VCR will retain its memory for this feature.

- 27 -

EN

1C29

SEARCH

Make sure ...

TV/DVD/VCR power must be turned on.

Insert a tape.

ZERO RETURN

TV/VCR

This function allows you to search easily a beginning point that you want to review by rewinding or fast forwarding.

NOTE:

Zero Return WILL NOT work on a blank tape or a blank portion of a tape.

1 Stop a tape at your desired point

Rewind or fast forward the tape to the beginning point at which you want to review.

2Reset the counter to 0:00:00

Press the C.RESET button repeatedly.

3Begin recording or playback

Press the RECORD or PLAY button.

Press the STOP button when recording or playback is completed.

4To activate “ZERO RETURN” mode

Press the SETUP button on the

- TV/VCR SETUP -

remote control.

TIMER PROGRAMMING

SETTING CLOCK



CHANNEL SET UP

Press the Arrow button K orL to

USER’S SET UP

LANGUAGE [ENGLISH]



V-CHIPSET UP

point to “ZERO RETURN”.

CAPTION [OFF]

B ZERO RETURN



TIME SEARCH

Then, press the ENTER button.

INDEX SEARCH



The counter will appear on the TV



The tape will automatically stop when returns to 0:00:00.

This function will not operate in recording mode.

This function is not operative when a cassette tape is not inserted in the TV/DVD/VCR.

In the example below: To watch a program after 2 hour 50 minutes from the present position, in either direction.

1Insert a tape.

2Select “TIME SEARCH” mode

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

USER’S SET UP

V-CHIPSET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

B TIME SEARCH

INDEX SEARCH

3 Enter your desired time

Press the Arrow button K orL until your desired time appears. (Example: “2:50” stands for 2 hours 50 minutes)

If you wish to cancel the Time Search at this point, press the remote control.

TIME SEARCH

2 : 50

button s or or fast

The time counts down as the searching progresses. When 0:00 is reached, the tape will start playback automatically.

TIME SEARCH

The Time Search function makes it

ly advance the tape to your desired position simply by entering the exact amount of playback time you want to skip.

NOTES:

Time Search can be set up to a maximum of 9 hours 50 minutes (9:50) by 10 minutes at a time.

TO CANCEL THE TIME SEARCH at this point

Press the STOP/EJECT button on the TV/DVD/VCR or the STOP button on the remote control. This will delete the selected time.

- 28 -

EN

1C29

INDEX SEARCH

TV/VCR

This feature provides a method of indexing the starting point so that it can be easily returned to in either fast forward or rewind mode.

The index mark will be made automatically when the REC button is pressed. It will also be marked at the starting point of Timer recording and OTR.

The index mark will not be recorded if the PAUSE button is pressed and released during recording.

The time gap between making the index marks on the tape should be greater than 1 minute for SP recording, 2 minutes for LP recording and 3 minutes for SLP recording.

In some cases, the index mark at the beginning of video tape cannot be detected.

Example: You are watching program number 4 and want to fast forward to program number 7. You must skip three programs.



CURRENT PLAYBACK PROGRAM

Beginning of tape







End of tape



Pro.1

Pro.2

Pro.3

Pro.4

Pro.5

Pro.6 Pro.7

4

3

2

1

1

2

3

INDEX MARK









1 Select “INDEX SEARCH”

Press the SETUP button on the

- TV/VCR SETUP -

SETTING CLOCK



TIMER PROGRAMMING

remote control.

CHANNEL SET UP

USER’S SET UP

Press the Arrow button K orL to

V-CHIPSET UP

CAPTION [OFF]



LANGUAGE [ENGLISH]

point to “INDEX SEARCH”. Then,

ZERO RETURN



press the ENTER button.







2 Enter your desired number



Press the Arrow button K orL until

INDEX SEARCH

the number of programs that you

0 3



want to skip appears.



(Example: “03” for 3 programs)



The Index Search mode will be

canceled if the procedures are not activated in 30 seconds.

3 Begin Index Search

Press the Arrow button s orB. The TV/DVD/VCR begins rewinding or fast forwarding to the beginning of desired program.

NOTE: Every time an index signal is skipped, the number in the program indicator decreases by one.

4 After Index Search

When the preset program is reached, the TV/DVD/VCR will start playback automatically.

A video cassette must be inserted in the TV/DVD/VCR for this function to work.

The number of Index Searches can be set up to 20.

This function will not operate in the recording mode.

When you want to cancel the Index Search while in progress, press the STOP button.

SPECIAL FEATURES

REAL TIME TAPE COUNTER

TV/VCR

This shows the elapsed recording or playback time in hours, minutes, and seconds. (The displayed time will not change on a blank tape or blank portions on the tape.)The “–”indication will appear when the tape has rewound further than “0:00:00” on the tape counter.

AUTO REWIND-EJECT

TV/VCR

When the end of a tape is reached during recording, playback, or fast-forward,the tape will automatically rewind to the beginning. After rewinding finishes, the TV/DVD/VCR will eject the tape and turn itself to off.

This function is operative when Repeat Play is set to the [OFF] position.

The tape will not auto-rewindduring timer recording or One Touch Recording.

- 29 -

EN

1C29

RECORDING

Make sure ...

TV/DVD/VCR power must be turned on.

Insert a cassette tape with its erase prevention tab in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.)

NOTES:

This TV/VCR/DVD will ONLY record and view the same channel.

This TV/VCR/DVD cannot record the contents from the built-inDVD.

NORMAL RECORDING

You can ONLY watch the same TV being recorded.

1 Select the channel to be

recorded

Press the number buttons on the remote control or the CHANNEL button K orL.

Remember: If the TV/DVD/VCR is cable box or satellite box, the

be on CH3 or CH4, then the channel must be selected on the cable box or

2

Select the tape speed



Press the SPEED button to select



the desired tape speed (SP/ SLP).







SP

3

Begin recording

REC

Press the RECORD button.

SP

4 Stop recording

Press the STOP button when recording is completed.

SKIPPING UNWANTED

SCENES DURING RECORDING

TV/VCR

PAUSE

SP

If “CLOSED CAPTION (ON)” is Screen Display will appear for 5 appear.

- 30 -

EN

1C29

OTR(2 : 30)

OTR (One Touch Recording)

TV/VCR

This function enables you to set a recording length simply by pressing the REC/OTR button on the TV/DVD/VCR.

Make sure ...

TV/DVD/VCR power must be turned on.

Insert a cassette tape with its erase prevention tab in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.)

NOTES:

This function CANNOT be done from the remote control.

Recording starts immediately when the REC/OTR button is pressed.

When the REC/OTR button is pressed 18 times, the TV/DVD/VCR returns to the Normal Recording mode.

To stop the OTR operation, press the STOP button on the TV/DVD/VCR or on the remote control.

To show the remaining time, press the DISPLAY button on the remote control so that “OTR” appears on the TV screen. (It will show up momentarily then disappear.)

Recording stops when 0:00 is reached

Please note that in the SLP mode ing time, assuming the tape is started ning, is 8 hours using T-160(or 6

If the tape runs out before the end TV/DVD/VCR will switch to the immediately, ejects the tape and

If you press the POWER button TV/DVD/VCR continues recording ed length is reached.

1 Select the channel to be recorded

Press the number buttons on the remote the CHANNEL button K orL.Remember: If the TV/DVD/VCR is cable box or satellite box, the

be on CH3 or CH4, then the channel is selected on the cable box or satellite

2 Select the tape speed

Press the SPEED button to select the speed (SP/ SLP).

3 Begin OTR

Press the REC/OTR button on the TV/DVD/VCR as many times as needed. The recording length will be determined by the number of times

you press the REC/OTR button. Each SP

additional push will increase the recording time by 30 minutes. It is set up to 8 hours.

Push(es)

Display



Recording length









1 push



(normal recording)









2 pushes

0:30



30 minutes

3 pushes

1:00



60 minutes









17 pushes

8:00



480 minutes









COPYING A VIDEO CASSETTE (Requires a VCR or camcorder)

TV/VCR

You can make copies of video tapes made by friends or relatives for your enjoyment.

You can not copy a DVD to a videotape.

WARNING: Unauthorized recordings of copyrighted video tapes may be an infringement of copyright laws.

Connect your TV/DVD/VCR and a Source (Playing) VCR using the following diagram.



[The TV/DVD/VCR]



[Fig.8]

PLAY

F.FWD STOP/EJECT

HEADPHONE VIDEO

AUDIO











L

R











[Ex: Source (playing)









VCR or camcorder]









AUDIO



Audio/Video





L





OUT

IN



adapter cable





R





VIDEO



(not supplied)



















OUT

IN

1)Insert a pre-recordedvideo cassette into the Source (Playing) VCR or camcorder.

2)Insert a blank video cassette, or one you want to record over, into the TV/DVD/VCR’s cassette compartment.

3)Press the SPEED button on remote control for the TV/DVD/VCR to select the desired recording speed (SP/SLP).

4)Press the CHANNEL button K orL on the TV/DVD/VCR until “AUX” appears on the screen.

button on the TV/DVD/VCR. the tape in the source (Playing)

during copying, use the panel controls whenever pos-

sible. The remote control might affect the source (Playing) VCR’s playback operation.

- 31 -

EN

1C29

- TV/VCR SETUP -
B TIMER PROGRAMMING SETTING CLOCK
CHANNEL SET UP USER’S SET UP V-CHIP SET UP
LANGUAGE [ENGLISH] CAPTION [OFF]
ZERO RETURN
TIME SEARCH
INDEX SEARCH

TIMER

AUTOMATIC TIMER

RECORDING

TV/VCR

You may set the TV/DVD/VCR to start and end a recording while you are away. You can set 8 programs to record on specific days, daily or weekly within a 1 year period.

In the example below, the timer is being set to record:

DATE: July 4th, 2003 SETTING TIME: from 7:30PM to 8:50PM CHANNEL: CH61

TAPE SPEED: SP

Make sure ...

If a cable box or satellite box is connected with the TV/DVD/VCR you will be limited to record only one channel. And the channel selector on the TV/DVD/VCR must be selected to the output channel of the boxes CH 3 or CH 4 and then the actual channel to be recorded must be selected on the boxes.

Clock must be set to the correct time and date before setting the timer.

TV/DVD/VCR power must be turn on to program it.

Insert a cassette tape with its erase prevention tab in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.)

The channel you want to record is properly set in advance. (See page 16.)

Avoid over lap of programs ...

There is a chance that a program will not be recorded. when programs overlap;

The program with an earlier start has priority.

Once the earliest program finishes, the overlapping programs will begin recording in sequence.

The illustration below demonstrates the sequence of recordings.

Program 1 10:00AM - 11:00AM Program 2 9:00AM - 10:00AM Program 3 9:30AM - 12:00PM

Recording Sequence

Program 1 10:00AM-11:00AMProgram 29:00AM-10:00AMProgram 39:30AM-12:00PM

9:00AM

10:00AM

11:00AM

12:00PM

*Recording period is SHADED

1 Select “TIMER PROGRAMMING”

Press the SETUP button on the remote control.

Confirm “TIMER PROGRAMMING” is pointed by pressing the Arrow button K. And press the ENTER button.

If you have not yet set the clock, CLOCK SET” appears. If so, follow [8] on page 17. Then set the timer

2 Select your desired program



– TIMER PROGRAMMING –

position (1~8)

CH DATE

BEGIN END

- -

-/

:

-:

Press the Arrow button K orL to

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

select the desired program position.

B - -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

Then, press the Arrow button B.

- -

-/-- - - -

-:--

-:-- - -









3 Set the channel number

Press the Arrow button K orL until the desired channel number appears. (Example: CH61)

Then, press the Arrow button B. Remember: If the TV/DVD/VCR is connected to a cable box or satellite TV/DVD/VCR must be on CH3 or channel to be recorded is selected satellite box.

– TIMER PROGRAMMING –

CH

DATE

BEGIN

END

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

B 61

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

4 Select once, every day or

For once recording :

Press the Arrow button K (up) until the desired date appears. (Example: “7/04” for July 4th). Then, press the Arrow buttonB.

– TIMER PROGRAMMING –

CH

DATE

BEGIN

END

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

B 61

7/04 FRI

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

For every day recording : To record at the same time on the same channel (Example: Monday through Sunday)

Press the Arrow button L (down) until “EVRY DAY” appears. Then, press the Arrow buttonB.

For weekly recording : To record a the same time on the same channel (Example: every Monday)

Press the Arrow button L (down) until “EVRY” and your desired day of the week appear together. Then, press the Arrow buttonB.

- 32 -

– TIMER PROGRAMMING –

CH

DATE

BEGIN

END

- -

-/--

- - - -:--

-:-- - -

- -

-/--

- - - -:--

-:-- - -

- -

-/--

- - - -:--

-:-- - -

B 61 EVRY MON -:--

-:-- - -

- - -/--

- - - -:--

-:-- - -

- -

-/--

- - - -:--

-:-- - -

- -

-/--

- - - -:--

-:-- - -

- -

-/--

- - - -:--

-:-- - -

EN

1C29

5 Set beginning hour

– TIMER PROGRAMMING –

Press the Arrow button K orL until

CH DATE

BEGIN END

the desired hour appears.

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -



- -

-/-- - - -

-:--

-:-- - -

(Example: “ 7, PM” for 7:30PM)

B 61

7/04 FRI 7:12PM

-:-- - -

- -

-/-- - - -

-:--

-:-- - -



- -

-/-- - - -

-:--

-:-- - -

Then, press the Arrow button B.

- -

-/-- - - -

-:--

-:-- - -



















6 Set beginning minute

– TIMER PROGRAMMING –

Press the Arrow button K orL until

CH DATE

BEGIN END

- -

-/-- - - -

-:--

-:-- - -

the desired minute appears.

- -

-/-- - - -

-:--

-:-- - -

B 61

7/04 FRI 7:30PM

-:-- - -



- -

-/-- - - -

-:--

-:-- - -

(Example: “30” for 7:30PM)

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

Then, press the Arrow button B.

- -

-/-- - - -

-:--

-:-- - -













7 Set end hour

– TIMER PROGRAMMING –

Press the Arrow button K orL until

CH DATE

BEGIN END

the desired hour appears.

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

(Example: “8, PM” for 8:50PM)

B 61

7/04 FRI 7:30PM

8:30PM - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

Then, press the Arrow button B.

- -

-/-- - - -

-:--

-:-- - -













8 Set end minute

– TIMER PROGRAMMING –

CH

DATE

BEGIN END

Press the Arrow button K orL

- -

-/-- - - -

-:--

-:-- - -

until the desired minute appears.

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

B 61

7/04 FRI 7:30PM

8:50PM - -

(Example: “50” for 8:50PM)

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

Then, press the Arrow button B.













9 Set the tape speed

– TIMER PROGRAMMING –

Press the Arrow button K orL

CH

DATE

BEGIN END

until the desired tape speed

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -



- -

-/-- - - -

-:--

-:-- - -

appears. (Example: SP)

B 61

7/04 FRI 7:30PM

8:50PM SP

- -

-/-- - - -

-:--

-:-- - -



- -

-/-- - - -

-:--

-:-- - -



- -

-/-- - - -

-:--

-:-- - -



- -

-/-- - - -

-:--

-:-- - -

10 Finish setting the program

Press the ENTER or RETURN button. The program is now completed.

To set another program, repeat steps [2] to [10].

Press the SETUP button on the remote control to return to original mode.

11 Set the timer

Press the POWER button to set automatic timer recording. The RECORDING indicator lights up.

You must turn off the TV/DVD/VCR to activate automatic timer recording.

If power is not turned off and you continue watching TV, “TIMER REC STANDBY” starts flashing on the TV screen 2 minutes before the programmed start time.

TIMER PROGRAM EXTENSION

1)Press the POWER button. 2)Repeat step [1] on page 32.

3)Press the RECORD button and select the desired program using the Arrow button K orL.

4)Press the RECORD button again.

Each additional push will shift forward the begin/end time for recording by 10 minutes. When the recording is already in progress, each additional push will shift forward the end time only. If you want to cancel while setting, press the PAUSE button on the remote control. The recording time returns to the original time.

NOTE: When you shift forward the time schedule during recording, the recording speed will automatically be set to the SLP mode.

5)Press the ENTER or RETURN button to exit the setting menu. Then press the SETUP button on the remote control to return to original mode.

TO CORRECT A PROGRAM

While setting a program; press the Arrow button s to go back one step and enter the correct numbers using the Arrow button K or L.

After setting a program;

1)Press the POWER button. 2)Repeat steps [1] - [2] on page 32.

3)Press the Arrow button B (or press the Arrow buttons to go back one step) until the part you want to correct begins flashing, then make the changes pressing the Arrow buttonK orL.

4)Press the POWER button to set automatic timer recording.

TO CANCEL AN AUTOMATIC TIMER RECORDING

After setting a program;

1)Press the POWER button.

2)Repeat steps [1] ~ [2] on page 32 and select a program you want to cancel.

3)Press the C.RESET button.

4)Press the SETUP button on the remote control to return to TV mode.

While recording is in progress;

1)Press the POWER button.

2)Press the STOP/EJECT button on the TV/DVD/VCR.

- 33 -

EN

1C29

TO CHECK THE BEGIN/END TIME

1)Press the POWER button so that the indicator goes off.

2)Press the SETUP button on the remote control 3)Confirm “TIMER PROGRAMMING” is 4)Press the ENTER button. The details of

appear on the TV screen.

5)Press the SETUP button on the remote control to return to TV mode.

HINTS FOR AUTOMATIC TIMER RECORDING

TV/VCR

Make sure the channel you want to record is properly set in advance.

It is not necessary to press the RECORD button for timer recording.

Recording begins automatically at the Start time.

You may watch TV or watch a DVD while a timer recording is occurring. To watch the same TV channel that VCR is recording, press the POWER button and then press the SELECT button to select TV. To view a DVD, press the POWER button and then press the SELECT button to select DVD. Press the POWER button to turn the display off and keep the

going.

The erase-preventiontab on the place (or you must put tape over

If the erase-preventiontab is removed, be ejected when the POWER button

If the tape runs out before the end TV/DVD/VCR will switch to the immediately, and the tape will be

AUTO RETURN

With this feature, after timer recording the beginning of the recorded program(s) searched for automatically.

1 Select “USER’S SET UP”

- TV/VCR SETUP -

Press the SETUP button on the

TIMER PROGRAMMING

SETTING CLOCK

remote control.

CHANNEL SET UP

B USER’S SET UP

V-CHIPSET UP

Press the Arrow button K orL to

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

point to “USER’S SET UP”.

TIME SEARCH

INDEX SEARCH

2 Set “AUTO RETURN” to [ON]

– USER’S SET UP –

RENTAL

[OFF]

REPEAT PLAY

[OFF]

B AUTO RETURN

[ON]

VCR AUDIO

[HIFI]

TV AUDIO

[STEREO]

3 Auto Return will begin

When all the timer recordings are TV/DVD/VCR will rewind to the recorded program(s).

NOTE:

If you press the POWER button rewinding, the Auto Return will

4 Watch the recorded program

Press the PLAY button.

TO CANCEL THE AUTO

MODE

Repeat steps [1] and [2], select ENTER button.

If there is a power failure of any TV/VCR/DVD will retain its ture.

SLEEP TIMER

TV/VCR

The Sleep Timer function turns off the TV/DVD/VCR without using the POWER button after a desired period of time.

NOTE:

This function does not operate during Recording mode.

1 Select “SLEEP TIMER”

Press the SLEEP button on the remote control until “SLEEP TIMER” appears.

2 Set sleep time

Press the SLEEP button until your



desired sleep time appears.



Each additional push will increase



the time by 30 minutes up to 120



minutes.

SLEEP 120 MINUTES

After 5 seconds, exit the Sleep Timer



Then, press the ENTER button.

TO CANCEL THE SLEEP





Press the SLEEP button on the remote





“SLEEP TIMER” appears. Press the





until “SLEEP 0 MINUTES” appears





- 34 -

EN

1C29

ON SCREEN DISPLAY

To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows:

When the Closed Caption mode is OFF:

Counter mode: After 5 seconds, only the counter remains. To clear it, press the DISPLAY button.

Clock mode: After 5 seconds, only the clock and the channel number remain. To clear them, press the DISPLAY button.

When the Closed Caption mode is ON:

The On Screen Display disappear after 5 seconds.

This is true even if the MUTE button is pressed, or the PAUSE button is pressed while recording.

OFF mode Counter mode

Clock mode

OFF mode

Clock/Counter mode

STOP

STOP

5:40PM



PM





CH2











SP COUNT 0:12:34

SP







After 5 seconds

After 5 seconds









5:40PM









CH2





COUNT 0:12:34









Counter

Clock & Channel





remains

remains







CABLE CHANNEL DESIGNATIONS

If you subscribe to cable TV, the channels are displayed as 1-125.Cable companies often designate channels with letters orletter-numbercombinations. Please check with your local cable company. The following is a chart of common cable channel designations.

CATV channel

5A

2

3

4

5

6

7

8

9

10

11

12

13

A

B



TV Display

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15





































CATV channel

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q



TV Display

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30





































CATV channel

R

S

T

U

V

W

W+1

W+2

W+3

W+4

W+5

W+6

W+7

W+8

W+9



TV Display

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45





































CATV channel

W+10

W+11

W+12

W+13

W+14

W+15

W+16

W+17

W+18

W+19

W+20

W+21

W+22

W+23

W+24



TV Display

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60





































CATV channel

W+25

W+26

W+27

W+28

W+29

W+30

W+31

W+32

W+33

W+34

W+35

W+36

W+37

W+38

W+39



TV Display

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75



CATV channel

W+40

W+41

W+42

W+43

W+44

W+45

W+46

W+47

W+48

W+49

W+50

W+51

W+52

W+53

W+54



TV Display

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90





































CATV channel

W+55

W+56

W+57

W+58

A-5

A-4

A-3

A-2

A-1

W+59

W+60

W+61

W+62

W+63

W+64



TV Display

91

92

93

94

95

96

97

98

99

100

101

102

103

104

105





































CATV channel

W+65

W+66

W+67

W+68

W+69

W+70

W+71

W+72

W+73

W+74

W+75

W+76

W+77

W+78

W+79



TV Display

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120



CATV channel

W+80

W+81

W+82

W+83

W+84























TV Display

121

122

123

124

125







































































- 35 -















EN

1C29

DVD SECTION

ABOUT THE DISCS

PLAYABLE DISCS

DISC TYPES

The following discs can be played back on this TV/DVD/VCR.

¡DVD video

¡DVD-R/RW*

¡DVD+R/RW*

¡Audio CD

¡CD-R/RW*

¡MP3*

*Depending on the types or the writing method of the medium some discs can not be played.

Some DVD-R/RW,DVD+R/RW, orCD-R/RWdiscs made on personal computers, or on DVD recorders may not be played back properly due to the factors such as scratches, dirt or special properties of the disc.

Discs made on personal computers may not be played back properly due to the different environment or the settings of the application you use. We recommend always to use the standardized, rightly formatted discs.

[DVD]

Data on a DVD is divided into sections called "titles", and then into subsections called "chapters", each of which is given a title or chapter number. Playback conditions are preset on some DVD video discs, and these playback conditions take priority over user operations on this player. If a function you selected does not run as desired, refer to the manual accompanying the disc.

Example

Title 1

Title 2

Chapter 1 Chapter 2 Chapter 3 Chapter 4

Chapter 1 Chapter 2

This player conforms to the NTSC color system. You cannot play discs recorded in other color systems such as PAL or SECAM.

¡Some discs include region codes as shown below.

¡The number inside the symbol refers to a region of the world, and a disc encoded in a specific region format can only be played back on TV/DVD/VCR with the same region code.

The following discs cannot be played back on this TV/DVD/VCR.

¡DVD with region codes other than 1 or ALL.

¡DVD-ROM

¡DVD-RAM(Never play back, otherwise malfunction may result.)

¡CD-ROM

¡VSD

¡CDV (Only plays back the audio part.)

¡CD-G(Only plays back the sound.)

¡CD-I(Never play back, otherwise malfunction may result.)

¡SACD

¡Photo CD (Never play back, otherwise malfunction may result.)

¡Video CD (Never play back, otherwise malfunction may result.)

Any other discs without compatibility indications.

[AUDIO CD]

Data on an audio CD is divided into sections called “tracks”, each of which is given a track number.

Example

Track 1

Track 2

Track 3

Track 4

Track 5

Track 6

[MP3]

Data on an MP3 is divided into sections called "groups", and then into subsections called "tracks", each of which is given a group or track number.

Example

Group 1

Group 2

Track 1 Track 2 Track 3 Track 4

Track 1 Track 2

– 36 –

EN

01A11

PLAYING A DISC

BASIC PLAYBACK

DVD-VCD

Getting started

¡Turn on the power of amplifier and any other components, if necessary.

1Press the POWER button.

¡The power will turn on.

2Press the OPEN/CLOSE button to open disc loading tray.

3Place the chosen disc in the tray, with the label facing up.

GENERAL FEATURES

DVD may contain menus to navigate the disc and access special features. Press the appropriate number buttons or use the Arrow buttons (L/K/s/B) to highlight your selection in the DVD main menu and press the ENTER button to confirm.

NOTES

¡Select DVD mode by pressing the SELECT button on the remote control. Then, operate the DVD functions.

¡Unless stated, all operations described are based on remote control use. Some operations can be carried out using the menu bar on the TV screen.

DISC MENU

DVD-V

1 Press the DISC MENU button.

¡The DVD main menu will appear.

4 Press the PLAY button.

¡The tray will close automatically, and playback will then start from the first chapter or track of the disc. If the playback does not start automatically, press the PLAY button.

¡When you playback the DVD which a title menu is recorded, it may appear on the screen. In this case, refer to “TITLE MENU”.

5 Press the STOP button to stop playback.

NOTES

¡When the DVD mode has been switched to the TV/VCR mode, the DVD mode shuts down first and then TV picture and sound appears in about 4 seconds. Similarly, when the POWER button is pressed to turn off in the DVD mode, this mode shuts down first and then the TV/DVD/VCR’s power is turned off.

¡A “prohibited icon” may appear at thetop-righton the TV screen during operation, warning that a prohibited operation has been encountered by the DVD or the disc.

¡With DVDs that use titles for playback program signals, playback may start from the second title, or it may skip these titles.

¡During the playback of a two layered disc, pictures may stop for a moment. This happens when the 1st layer switches to the 2nd layer. This is not a malfunction.

2If the feature is not available, symbol may appear on the TV screen.

3If disc menu is available on the disc, audio language, subtitle options, chapters for the title and other options will appear for selection.

4Press the Arrow buttons (L/K/s/B) to select an item, and the ENTER button to confirm selection.

TITLE MENU

DVD-V

1Press the TITLE button.

¡The title menu will appear.

2If the feature is not available, symbol may appear on the TV screen.

3Press the Arrow buttons (L/K/s/B) to select an item, and the ENTER button to confirm selection.

CALLING UP A MENU SCREEN DURING PLAYBACK

For DVD-Vs

¡Press the DISC MENU button to call up the DVD menu.¡Press the TITLE button to call up the title menu.

NOTE

¡Contents of menus and corresponding menu operations may vary between discs. Refer to the manual accompanying the disc for details.

– 37 –

EN

01A11

– 38 –

RESUME

DVD-VCD

1During playback, press the STOP button.

¡Resume message will appear on the TV screen.

2Press the PLAY button, playback will resume

from the point at which playback was stopped.

¡To cancel resume, press the STOP button twice.¡If turn off the TV/DVD/VCR, resume function will

be cancelled.

PAUSE

DVD-VCD

1During playback, press the PAUSE button.

¡Playback will pause and sound will be muted.

2To continue playback, press the PLAY button.

STEP BY STEP PLAYBACK

DVD-V

1During playback, press the PAUSE button.

¡Playback will pause and sound will be muted.

2The disc goes forward by one frame each time the PAUSE button is pressed.

3To exit step by step playback, press the PLAY button.

FAST FORWARD/REVERSE

SEARCH

DVD-VCDMP3

1During playback, press and hold down the FWD g or REVh button for a few seconds.

2Each press and hold down the FWD g or REVh button repeatedly to select the

required speed: x2, x8, x50, x100.

¡For audio CDs, the speed is fixed at×16.¡For MP3, the speed is fixed at×8.

3 To return to normal playback, press the PLAY button.

Note for using buttons on the main unit:

During playback, press and hold down the SKIP G/ SEARCHg buttons or the SKIPH/SEARCHh buttons on the TV/DVD/VCR for a few seconds to begin Search in x2 speed. Press and hold down again to change speed to x8. Repeat this procedure to change to x50 and x100.

SLOW FORWARD /

SLOW REVERSE

DVD-V

1During playback, press the PAUSE button.

2Press and hold down the FWD g or REVh button for a few seconds.

3Each press and hold down the FWD g or REVh button repeatedly to select the required speed: 1/16, 1/8, 1/2 of the normal playback.

4To return to normal playback, press the PLAY button.

Note for using buttons on the main unit:

Press the PAUSE button, then, press and hold down the SKIP G/ SEARCHg buttons or the SKIPH /SEARCHh buttons on the TV/DVD/VCR for a few seconds to begin Search in 1/16 speed of the normal playback. Press and hold down again to change speed to 1/8. Repeat this procedure to change to 1/2.

ZOOM

DVD-V

The Zoom function allows you to enlarge the video image and to pan through the enlarged image.

1Press the ZOOM button during playback.

¡Playback will continue.

2Press the ZOOM button repeatedly to select the required zoom factor: ZOOM1, ZOOM2, ZOOM3, or OFF.

3Use the Arrow buttons (K/L/s / B) to move the zoomed picture across the screen.

4To exit zoom mode, press the ZOOM button

to OFF.

NOTES

¡Zooming function does not work while disc menu is shown.

¡Zooming function is not available on some discs.

EN

01A11

SEARCH FUNCTION

TRACK SEARCH

TIME SEARCH

CD

DVD-VCD

There are three ways to begin playback on an Audio CD at a specific Track.

Using the Number buttons on the remote control

1 Press the Number buttons to enter the desired Track number.

¡Playback will start at the selected track.

¡For single digit tracks(1-9),press a single number (eg. track 3, press 3).

¡To play track 26, press +10, 2, 6.

Using the SEARCH MODE button

1Press the SEARCH MODE button.

¡The track search display appears.

2Within 30 seconds, select a desired track number using the Number buttons on the

remote control.

¡For single digits press 0 first.¡Playback will start at the selected track.

Using the SKIP H G buttons

During playback, press the SKIP G button to move the next track. Press it repeatedly to skip subsequent tracks. Press the SKIPH button to go back to beginning of the current track. Press it repeatedly to go to the previous tracks.

¡If the SKIP button is pressed while the playback is paused, the playback will be paused again after skipping to the next track.

NOTE

¡The SKIPH G buttons are not available when playback is stopped.

TITLE / CHAPTER SEARCH

DVD-V

1Press the SEARCH MODE button once for the Chapter search, twice for the Title search during playback.

/2

2 Enter the desired chapter/title number using the Number buttons on the remote control.

¡Playback will start at the selected Chapter or Track.¡Press the CLEAR button to erase the incorrect input.¡For single digits press 0 first.

1During playback, press the SEARCH MODE button three times (CD: twice) to display the Time Search on the TV screen.

2Within 30 seconds, enter a desired disc time using the Number buttons on the

remote control.

¡Playback will start at the specified time.

¡Press the CLEAR button to erase the incorrect input.

MARKER SETUP SCREEN

DVD-VCD

Use markers to memorise your favorite places on a disc.

1 Press the SEARCH MODE button four times (CD: three times) during playback.

¡The display screen and Markers will appear on the TV screen.

2Press the Arrow buttons (s /B) to select 1,

2, 3, 4, 5, 6, 7, 8, 9, or 10 and ensure that “- :-- :--”appears in the display.

3When reaches the desired point, press the ENTER button.

¡The Title or Track and elapsed playing time will appear in the TV screen.

4To return to the Marker later, press the SEARCH MODE button four times (CD: three times) during playback and the Arrow buttons (s /B) to choose the desired marker,

then press the ENTER button.

NOTES

¡Opening the disc tray or turning off the power or select AC at step 2 and press the ENTER button will erase all Markers.

¡To clear a marker, using the Arrow buttons (s /B), position the cursor on to the marker number to be cleared and press the CLEAR button.

¡You can mark up to 10 points.

5Press the SEARCH MODE or RETURN button to exit.

– 39 –

EN

01A11

SPECIAL PLAYBACK FUNCTION

REPEAT

PROGRAM

REPEAT is available only during playback.

REPEAT TITLE / CHAPTER

DVD-V

To activate the repeat function, press the REPEAT button during playback.

¡The repeat mode changes as described below every time you press the button.

CHAPTER

TITLE

OFF

(current chapterrepeat)

(current titlerepeat)

(repeat off)

NOTES





¡Repeat Title/Chapter is not available with some scenes.

¡The REPEAT setting will be cleared when moving to other title or chapter.

REPEAT TRACK

CD

To activate the repeat function, press the REPEAT button during playback.

¡The repeat mode changes as described below every time you press the button.

TRACK

ALL

OFF

(current trackrepeat)

(entire discrepeat)

(repeat off)

NOTES





¡Repeat setting will be cleared when moving to other track.

¡Repeat playback does not function during repeatA-Bplayback.

REPEAT A-B

DVD-VCD

1Press the REPEAT A-Bbutton at your chosen starting point.

¡A- appears briefly on the TV screen.

2Press the REPEAT A-Bbutton again at your chosen end point.

¡A-Bappears briefly on the TV screen, and the repeat sequence begins.

3To exit the sequence, press the REPEAT A-

B button.

NOTES

¡The repeatA-Bsection can only be set within the current title (for DVDs), or current track (for audio CDs).

¡RepeatA-Bis not available with some scenes in DVD.¡To cancel the A point which was set, press the

CLEAR button.

¡RepeatA-Bplayback does not function during title, chapter, track or all repeat playback.

CD

You may determine the order in which tracks will play.

1In stop mode, press the MODE button.

¡The PROGRAM screen will appear.

2Press the Arrow button orto select a track, then press the

ENTER button.

TOTAL

¡Press the CLEAR button to



erase the most recently entered



program.



3Repeat step 2 until you have selected all the tracks you want to play in the program.

4Press the PLAY button to play the pro-

grammed tracks.

NOTES

¡While the program is being played back, the STOP works as follows.

¡Press the STOP button once and then the PLAY button again, playback will restart from the point where the STOP button was pressed. (Program continued)

¡Press the STOP button twice and then the PLAY button again, playback will restart from the track in the usual way. (Program cleared)

¡Up to 99 programs can be entered.

¡If you like to repeat the current track in the program, press the REPEAT button repeatedly untilTRACK appears during playback. If you like to repeat the entire program press the REPEAT button repeatedly untilALL appears during playback.

RANDOM PLAYBACK

CD

This shuffles the playing order of tracks instead of playback in the sequence.

1 In stop mode, press the MODE button twice.

¡RANDOM screen appears.

RANDOM

CD [AUDIO]

TOTAL 0:45:55

RANDOM PROGRAM - - no indication - -

PLAY

2 Press the PLAY button to start random playback.

NOTE

¡If you like to repeat the current track in the random selection, press the REPEAT button repeatedly untilTRACK appears during playback. If you like to repeat the entire random selection press the REPEAT button repeatedly untilALL appears

during playback.

– 40 –

EN

01A11

PLAYING A MP3 DISC

MP3 PLAYBACK

TRACK SELECTION

MP3

When a CD with MP3 files is in the TV/DVD/VCR, the MP3 menu will appear on the TV screen in stop mode.

1 In stop mode, press the Arrow buttons (K/L) to select the

desired group track.

¡If a group is selected, press the ArrowB or ENTER but-

ton to go on to the track selection screen. Press the Arrow buttons (K/L) to choose a

track, then press the ENTER button.

¡If a track is selected, press the ENTER button to start playing tracks. Starting from the one you’ve just chosen the subsequent tracks will be played.

¡Choose FIRST PLAY to start playback from the beginning of the listed tracks.

¡Press the TITLE button to return to the first item.

2 Press the STOP button to stop playback.

NOTES

¡Folders are known as Groups; files are known as Tracks.

¡MP3 files are accompanied by3 icon.¡Maximum of 255 folders can be recognized.¡Maximum of 256 files can be recognized.¡Up to 8 hierarchies can be created.

This player recommends the use of files recorded at the below specifications:

¡Sampling frequency: 44.1kHz or 48kHz¡Constant bit rate: 112kbps ~ 320kbps.

MP3

1 Press the SEARCH MODE button during playback.

¡The FILE LIST will appear.

2 Select a desired track using the Arrow buttons (K/L/s/B).

¡Press the Arrow buttonB when you want to go to the next hierarchy.

¡Press the Arrow buttons when you want to go back to the previous hierarchy.

3 Press the PLAY button to start playback.

NOTES

¡Press the SEARCH MODE button to exit.

¡Some selections may take a while to be recognized.

PROGRAM

MP3

This feature allows you to program an MP3 disc to play in a desired sequence.

1In stop mode, press the MODE button.

¡The PROGRAM screen will appear.

2Select a desired track using the Arrow buttons (K/L/s/B). Then, press the ENTER

button.

¡Press the Arrow buttonB when you want to go to the next hierarchy.

¡Press the Arrow buttons when you want to go back to the previous hierarchy.

¡Press the CLEAR button to erase the most recently entered program.

3Repeat step 2 until you have selected all the Tracks you want to play in the program.

4Press the PLAY button to start programmed playback.

RANDOM PLAYBACK

MP3

1In stop mode, press the MODE button twice.

¡RANDOM screen appears.

2Press the PLAY button to start random playback.

– 41 –

EN

01A11

CHANGING THE SETTINGS

SUBTITLE LANGUAGE

CAMERA ANGLE

DVD-V

DVD-V

The DVD allows you to select a language for subtitles during DVD disc (if available) playback.

1Press the SUBTITLE button during playback.

2Press the SUBTITLE button repeatedly to

select your desired subtitle language.

¡The subtitle language will be displayed on the display bar at the top of the screen.

3 To turn off subtitles, press the SUBTITLE button repeatedly until OFF appears.

NOTES

¡Some discs allow audio language setting/subtitle language setting on the disc menu. (Operation varies between discs, so refer to the manual accompanying the disc.)

¡If the desired language is not shown after pressing the SUBTITLE button several times, the disc does not have subtitles in that language.

¡If you choose a Language that has a 3 letter language code, the code will be displayed every time you change the Subtitle language setting. If you choose any other languages,‘---’will be displayed instead. (Refer to page 44.)

AUDIO LANGUAGE

DVD-V

The TV/DVD/VCR allows you to select a language during DVD disc (if multi language available) playback.

1Press the AUDIO button during playback.

2Press the AUDIO button repeatedly to select

your desired language.

NOTE

¡Pressing the AUDIO button may not work on some DVDs with multiple audio languages (e.g. DVDs which allow audio language setting on the disc menu).

STEREO SOUND MODE

CD

Some DVD discs contain scenes which have been shot simultaneously from various angles. You can change the camera angle when the ( ) icon appears on the screen.

1Press the ANGLE button during playback.

¡The selected angle will be displayed on the display bar at the top of the screen.

2Press the ANGLE button repeatedly to select your desired angle.

BLACK LEVEL SETTING

DVD-V

Adjust the Black Level Settings to make the black parts of the picture brighter.

1 Press the MODE button during playback.

ON

2Press the ENTER button to switch OFF.

ON: Makes the dark parts brighter.

OFF: Shows the original picture as recorded.

3Press the MODE button twice or the RETURN button to exit.

VIRTUAL SURROUND

DVD-VCDMP3

You can enjoy stereophonic visual space on your existing stereo system.

¡Make sure you are using the AUDIO L/R analog out jack on the rear panel of the TV/DVD before you use this feature.

1Press the MODE button twice (CD/MP3: once) during playback.

OFF

1Press the AUDIO button repeatedly during playback to select between STEREO, L-CHorR-CH.

¡STEREO - both right and left channels are active (stereo)L-CH- only left channel is active

R-CH- only right channel is active

NOTE

¡If the Virtual Surround setting is ON, the sound mode will be fixed to STEREO, and can not be changed.

2Press the ENTER button to set it 1 (Natural effect) or 2 (Emphasized effect) or OFF.

3Press the MODE or RETURN button to exit.

NOTE (for CD play only)

¡Virtual Surround will not be effective if the sound mode is set to something other than STEREO.

– 42 –

EN

01A11

THE ON-SCREENINFORMATION

DVD-VCDMP3

You can check the information about the current disc by pressing the DISPLAY button on the remote control.

For DVD-Vs

1 Press the DISPLAY button during playback to show current Chapter.

¡The elapsed and remaining



playing time of the current

9/49 0:00:00 -0:00:00

chapter will be displayed.



2 Press the DISPLAY button again to show current Title.

¡The elapsed and remaining playing time of the current title will be displayed.

3 Press the DISPLAY button again.

¡The BIT RATE and the current repeat setting will be displayed.

¡If you are playing a dual layered disc, the layer number will also be displayed (L0: Layer 0 is playing. L1: Layer 1 is playing).

4Press the DISPLAY button again to exit the display.

For audio CDs

1 Press the DISPLAY button during playback to show the current Track.

¡The elapsed and remaining playing time of the current track will be displayed.

2 Press the DISPLAY button again to show current Total Track.

¡The elapsed and remaining playing time of the current total track will be displayed.

3Press the DISPLAY button again to exit the display.

For MP3

1Press the DISPLAY button during playback.

¡The name of the file currently in play will be displayed.

2Press the DISPLAY button repeatedly to show the track number, the repeat status, and the playback status at the top of the screen.

¡will be displayed when repeat play has been selected.

T - indicates Track repeat

G - indicates Group (folder) repeat

A - indicates Disc repeat

3Press the DISPLAY button again to exit the display.

– 43 –

EN

01A11

CHANGING THE DVD SETUP ITEMS

LANGUAGE SETTING

DVD-V

Language options are not available with some discs.

1Press the SETUP button twice in STOP mode so that the DVD SETUP menu appears.

¡If the menu does not appear, press the PLAY button, the STOP button, then the SETUP button twice.

QUICK SETUP



TV MODE

4:3 LETTER BOX

DOLBY DIGITAL

ON

2Press the Arrow button B to select CUS-

TOM, then press the ENTER button.

¡CUSTOM mode will appear.

3Press the Arrow buttons (s /B) to select

LANGUAGE, then press the ENTER button to confirm.

LANGUAGE



AUDIO

ORIGINAL

SUBTITLE

OFF

DISC MENU

ENGLISH

4Press the Arrow buttons (K/L) to select the next items, then press the ENTER button.

AUDIO:

¡Sets the audio language.

SUBTITLE:

¡Sets the subtitle language.

DISC MENU:

¡Sets the language for DVD menu.

5Press the Arrow buttons (K/L) to select a setting, then press the ENTER button.

¡If OTHER is selected on the AUDIO, SUBTITLE or DISC MENU screen, pressfour-digitnumber to enter the code for the desired language. (Refer to the language code list below.)

¡Only the languages supported by the disc can be selected.

6 Press the SETUP button to exit.

NOTE

¡Language Setting for Audio and Subtitle is not available with some discs. Then use the AUDIO and the SUBTITLE buttons. Details are on page 42.

TO CHANGE THE ON-SCREENMENUS

You can access the TV/VCR SETUP menu by pressing the SETUP button from the DVD mode. Refer to “Selecting the Language” on page 16 to changing the on-screenmenus.

¡In case of selecting from the DVD mode, you cannot select “CHANNEL SET UP”,“V-CHIPSET UP”, “CAPTION”, “TIME SEARCH”, or “INDEX SEARCH” menus.

Language

Code

Language

Code

A-B



L-N



Abkhazian

4748

Laothian

5861

Afar

4747

Latin

5847

Afrikaans

4752

Latvian;Lettish

5868

Albanian

6563

Lingala

5860

Amharic

4759

Lithuanian

5866

Arabic

4764

Macedonian

5957

Armenian

5471

Malagasy

5953

Assamese

4765

Malay

5965

Aymara

4771

Malayalam

5958

Azerbaijani

4772

Maltese

5966

Bashkir

4847

Maori

5955

Basque

5167

Marathi

5964

Bengali;Bangla

4860

Moldavian

5961

Bhutani

5072

Mongolian

5960

Bihari

4854

Nauru

6047

Bislama

4855

Nepali

6051

Breton

4864

Norwegian [NOR]

6061

Bulgarian

4853

O-R



Burmese

5971

Occitan

6149

Byelorussian

4851

Oriya

6164

C-E



Oromo(Afan)

6159

Cambodian

5759

Panjabi

6247

Catalan

4947

Pashto;Pushto

6265

Chinese [CHI]

7254

Persian

5247

Corsican

4961

Polish

6258

Croatian

5464

Portuguese [POR]

6266

Czech

4965

Quechua

6367

Danish [DAN]

5047

Rhaeto-Romance

6459

Dutch [DUT]

6058

Romanian [RUM]

6461

English [ENG]

5160

Russian [RUS]

6467

Esperanto

5161

S



Estonian

5166

Samoan

6559

F-H



Sangho

6553

Faroese

5261

Sanskrit

6547

Fiji

5256

Scots Gaelic

5350

Finnish [FIN]

5255

Serbian

6564

French [FRE]

5264

Serbo-Croatian

6554

Frisian

5271

Sesotho

6566

Galician

5358

Setswana

6660

Georgian

5747

Shona

6560

German [GER]

5051

Sindhi

6550

Greek [GRE]

5158

Singhalese

6555

Greenlandic

5758

Siswat

6565

Guarani

5360

Slovak

6557

Gujarati

5367

Slovenian

6558

Hausa

5447

Somali

6561

Hebrew

5569

Spanish [SPA]

5165

Hindi

5455

Sundanese

6567

Hungarian [HUN]

5467

Swahili

6569

I-K



Swedish [SWE]

6568

Icelandic [ICE]

5565

T



Indonesian

5560

Tagalog

6658

Interlingua

5547

Tajik

6653

Interlingue

5551

Tamil

6647

Inupiak

5557

Tatar

6666

Irish [IRI]

5347

Telugu

6651

Italian [ITA]

5566

Thai

6654

Japanese [JPN]

5647

Tibetan

4861

Javanese

5669

Tigrinya

6655

Kannada

5760

Tonga

6661

Kashmiri

5765

Tsonga

6665

Kazakh

5757

Turkish [TUR]

6664

Kinyarwanda

6469

Turkmen

6657

Kirghiz

5771

Twi

6669

Kirundi

6460

U-Z



Korean [KOR]

5761

Ukrainian

6757

Kurdish

5767

Urdu

6764





Uzbek

6772





Vietnamese

6855





Volapuk

6861





Welsh

4971





Wolof

6961





Xhosa

7054





Yiddish

5655





Yoruba

7161





Zulu

7267









If you choose a Language that has a 3 letter language code, the code will be displayed every time you change the Audio or Subtitle language setting on page 42. If you choose any other languages, ‘---’will be displayed instead. (3 letter language code is written in bracket.)

– 44 –

EN

01A11

DISPLAY SETTING

DVD-V

You can change certain aspects of the DVD display screens and on-screenmessages on the TV screen.

1Press the SETUP button twice in STOP mode so that the DVD SETUP menu appears.

¡If the menu does not appear, press the PLAY button, the STOP button, then the SETUP button twice.

QUICK SETUP



TV MODE

4:3 LETTER BOX

DOLBY DIGITAL

ON

2 Press the Arrow buttonB to select CUS-

TOM, then press the ENTER button.

¡CUSTOM mode will appear.

3Press the Arrow button (s/B) to select DIS-

PLAY, then press the ENTER button to confirm.

DISPLAY



TV MODE

4:3 LETTER BOX

ANGLE ICON

ON

AUTO POWER OFF ON

4 Press the Arrow buttons (K/L) to select the below items, then press the ENTER button.

TV MODE: QUICK

¡Press the Arrow buttons (K/L) for an item selection, then press the ENTER button.

¡Select 4:3 LETTER BOX for a black bars appears on top and bottom of the screen.

¡Select 4:3 PAN & SCAN for a full height picture with both sides trimmed.

¡The default setting is 4:3 LETTER BOX.

ANGLE ICON:

¡Press the ENTER button repeatedly to turn Angle icon ON or OFF.

¡The default setting is ON.

AUTO POWER OFF:

¡Press the ENTER button repeatedly to turn Auto Power off ON or OFF.

¡The default setting is ON and it will turn the TV/DVD/VCR to off automatically after 15 minutes of no use.

5 Press the SETUP button to exit.

AUDIO SETTINGS

Choose the appropriate Audio settings for your equipment as it only affect during the playback of DVD discs.

1Press the SETUP button twice in STOP mode so that the DVD SETUP menu appears.

¡If the menu does not appear, press the PLAY button, the STOP button, then the SETUP button twice.

QUICK SETUP



TV MODE

4:3 LETTER BOX

DOLBY DIGITAL

ON

2 Press the Arrow buttonB to select CUS-

TOM, then press the ENTER button.

¡CUSTOM mode will appear.

3Press the Arrow buttons (s /B) to select

AUDIO, then press the ENTER button to confirm.

AUDIO



DRC

OFF

DOLBY DIGITAL

ON

DOWN SAMPLING

ON

4 Press the Arrow buttons (K/L) to select the below items, then press the ENTER buttons.

DRC (Dynamic Range Control):

¡To compress the range of soft to loud sound.¡The default setting is OFF.

DOLBY DIGITAL: QUICK

Set to On when the unit is connected to a Dolby Digital Decoder.

(ON: Output a Dolby Digital signal)

(OFF: Convert the Dolby Digital to PCM (2 channel stereo))

¡The default setting is ON.

DOWN SAMPLING:

¡Set to ON when outputting in 48 kHz.¡The default setting is ON.

When playing disc with copyright Protection

¡If you select OFF, copyright protection will be activated and sound will be down sampled at 48kHz.

5 Press the SETUP button to exit.

– 45 –

EN

01A11

PARENTAL CONTROL

DVD-V

Parental Control limits the disc viewing that exceed your settings. (with a password or playback will stop.) This feature allows you to prevent discs with alternative scenes from being played by your children.

PARENTAL LEVEL

Parental Level allows you to set the rating level of your DVD discs. Playback will stop if the disc’s ratings exceed the level you set.

1Press the SETUP button twice in STOP mode so that the QUICK SETUP menu appears.

¡If the menu does not appear, press the PLAY button, the STOP button, then the SETUP button twice.

CONTROL LEVELS

¡ALL

All parental lock is cancelled.

¡Level 8

DVD software of any grade (adult/general/children) can be played back.

¡Levels 7 to 2

Only DVD software intended for general use and children can be played back.

¡Level 1

Only DVD software intended for children can be played back, with those intended for adult and general use prohibited.

QUICK SETUP



TV MODE

4:3 LETTER BOX

DOLBY DIGITAL

ON

2Press the Arrow button B to select CUS-

TOM, then press the ENTER button.

3Press the Arrow buttons (s/B) to select

PARENTAL, then press the ENTER button.

PARENTAL

PARENTAL LEVEL ALL

IF YOU FORGET THE PASSWORD

1 Press the number buttons 4, 7, 3, 7 at step 4. Then enter your new password.

¡Password will be cleared and parental level will be set to ALL.

2 Proceed the above Steps5-7again.

4Enter your four-digitpassword then press the ENTER button.

5Press the Arrow buttons (K/L) to select

PARENTAL LEVEL, then press the ENTER button.

6Press the Arrow buttons (K/L) to select the desired level.

7Press the SETUP button to exit

NOTES

¡When doing this for the first time, enter any 4 digits. (except for 4737) That number will be used as the password.(in the event you forget the password, see below)

¡To change the password, press the Arrow buttons (K/L) to select CHANGE at step 5, then press the ENTER button. Enter thefour-digitpass-word,then press the ENTER button.

¡With some DVDs, it may be difficult to find if they are compatible with parental lock. Be sure to check if the parental lock function operates in the way that you have set.

¡Record the password in case you forget it.

– 46 –

EN

01A11

TROUBLESHOOTING GUIDE

If the TV/DVD/VCR does not perform properly when operated as instructed in this Owner’s Manual, check the player, consulting the following checklist.

PROBLEM

CORRECTIVE ACTION

No power.

Make sure the power plug is connected to an AC outlet.



Make sure the power is turned on.

The TV/DVD/VCR does not

Check if the power plug is connected to an AC outlet.

respond to the remote control.

Check the batteries in the remote control.



Aim the remote control directly at the remote sensor. If necessary,



remove all the obstacles between the sensor and the remote.



You have to be within 23 feet of the TV/DVD/VCR.



Check if the correct mode is selected. If not switch the mode by



pressing the SELECT button on the remote control,whichever you need.

TV/VCR Mode

Sometimes a performance problem can be easily solved by checking seemingly apparent but often overlooked possibilities. Before arranging for service, check these items. It could save your time and money.

PROBLEM

CORRECTIVE ACTION



No picture and sound.

Make sure the AC cord is connected to an AC outlet.





Check antenna connection.





Press the SELECT button on the remote control to select TV mode.



Then try other TV feature.





Let the TV/DVD/VCR program its tuner memory.



No picture or poor picture on

Adjust direction or replace antenna.



TV/DVD/VCR.

Adjust picture controls.



No sound or poor sound.

Adjust volume control on remote control or main unit.





Press the MUTE button to restore sound.



Bars On Screen

If outside antenna is being used, check for broken wire.





Check for local interference.



Picture Distorted or Blurred

Try a new channel, if OK, then possible station trouble.





If outside antenna is being used, check for broken wire.



Picture Rolls Vertically

Try a new channel, if OK, then possible station trouble.



Lines or Streaks in Picture

If outside antenna is being used, check for broken wire.





Check for local interference.



No Color

Try a new channel, if OK, then possible station trouble.





Is antenna connected to terminal on the back of the set?





If outside antenna is being used, check for broken wire.





Adjust COLOR control.



Poor Reception on Some Channels

Try a new channel, if OK, then possible station trouble.



Ghosts in Picture

Is antenna connected to terminal on the back of the set?





If outside antenna is being used, check for broken wire.





Check for local interference.



Weak Picture

Try a new channel, if OK, then possible station trouble.





Is antenna connected to terminal on the back of the set?





If outside antenna is being used, check for broken wire.





Adjust CONTRAST & BRIGHT control.



Sound OK, Picture Poor

Try a new channel, if OK, then possible station trouble.





Is antenna connected to terminal on the back of the set?





If outside antenna is being used, check for broken wire.





Check for local interference.





Adjust CONTRAST & BRIGHT control.





– 47 –

EN

01A11

PROBLEM

CORRECTIVE ACTION

Picture OK, Sound Poor

Try a new channel, if OK, then possible station trouble.



Check for local interference.

Timer recording is not possible.

Make sure the timer recording is set correctly.



Make sure the power is off.



Make sure the TV/DVD/VCR clock is set correctly.

Cannot go into Record mode.

Make sure the tape has anerase-preventiontab. If need, cover the



hole with plastic tape.

Playback picture is partially noisy.

Adjust tracking control for a better picture using the CHANNEL



buttonK orL on the TV/DVD/VCR.

No picture but the audio is OK in

Head cleaning may be necessary. Refer to “AUTO HEAD

playback.

CLEANING” on page 50.

No operation by infrared Remote

Make sure the AC cord is connected to an AC outlet.

Control.

Check batteries in remote control.

Video or color fades in and out

You can not copy a copyrighted video tape. You are experiencing

when making a copy of a video tape.

copy guard protection.

Different color marks on screen.

Magnetism from nearby appliances and geomagnetism might affect



the color of the TV picture. Move the TV/DVD/VCR away from the



appliances, the TV/DVD/VCR can repair itself automatically. If you



want to repair immediately, turn off using the POWER button, then



turn it on again 30 minutes or so later.





CLOSED CAPTION PROBLEM

POSSIBLE REMEDY

My TV/DVD/VCR is showing

• You are watching a live broadcast and spelling errors made by the

captions that are misspelled.

closed captioning production company may pass through uncorrected.



A prerecorded program will not show any misspelled words because



of the normal time available for editing the captions.





My TV/DVD/VCR will not show

• Captions that are delayed a few seconds behind the actual

the text dialogue

are common for live broadcast. Most captioning production

in its entirety or there is a delay of

companies can display a dialogue to a maximum of 220 words

what is being said.

per minute. If a dialogue exceeds that rate, selective editing is used



to insure that the captions remainup-to-datewith the current



TV screen dialogue.

My captions are scrambled with

• Interference caused by building, power lines, thunderstorms, etc.

white boxes on the TV screen.

may cause scrambled or incomplete captions to appear.





My program guide listed a TV show

• Broadcasters may at times use a time compression process to speed

as being closed captioned but none

up the actual program so that additional advertising time can be

of the captions were displayed.

given. Since the decoder cannot read the compressed information,



captions will be lost.





My prerecorded video tape does not

• The video tape was either an illegal copy or the tape duplicating

show any captions. The tape box

company accidentally left out the captioning signals during the

mentions it being closed captioned.

copying process.





My TV screen shows a black box

• You are in the TEXT mode. Select CAPTION mode to CAPTION

on certain channels.

[OFF].





– 48 –

EN

01A11

DVD Mode

PROBLEM

CORRECTIVE ACTION

No picture.

• Connect the video cables firmly.



• Insert a correct video disc that plays on this TV/DVD/VCR.



• Press the SELECT button on the remote control to select DVD mode.



Then, try other DVD feature.

Disc cannot be played.

• Insert the disc.



• Clean the disc.



• Place the disc correctly, with the label side up.



• Cancel the parental lock or change the control level.

No sound.

• Connect the audio cables firmly.



• Turn the power of the audio component on.



• Correct the audio output settings.



• Correct the input settings on the audio component.

No DTS audio is output.

• This TV/DVD/VCR does not support DTS audio. This is not a mal-



function.

Distorted picture.

• There are some cases where pictures may be slightly distorted, which



are not a sign of a malfunction.



• Although pictures may stop for a moment, this is not a malfunction.

Audio or subtitle language

• The selected language is not available for audio or subtitles on the DVD.

does not match the set up

This is not a malfunction

The camera angle cannot be changed

• The DVD does not contain sequences recorded from different camera



angles. This is not a malfunction

Audio or subtitle language cannot be

• The DVD does not contain audio source or subtitles in the selected

changed

language. This is not a malfunction.

“Prohibited icon” appears on the

• That operation is prohibited by the player or the disc.

screen, prohibiting an operation

This is not a malfunction.

CD sound dropout

• Scratched disc. Replace the disc with unscratched one.

No CD reproduction



DVD picture dropout



DVD picture freeze



DVD picture in mosaic



No DVD reproduction







NOTES:

Some functions are not available in specific modes, but this is not a malfunction. Read the description in this Owner’s Manual for details on correct operations.

Playback from a desired track and random playback are not available during program playback.

– 49 –

EN

01A11

MAINTENANCE

CABINET CLEANING

Wipe the front panel and other exterior surfaces of the TV/DVD/VCR with a soft cloth immersed in lukewarm water and wrung dry.

Never use a solvent or alcohol. Do not spray insecticide liquid near the TV/DVD/VCR. Such chemicals may cause damage and discoloration to the exposed surfaces.

AUTO HEAD CLEANING

Automatically cleans video heads as you insert or remove a cassette, so you can see a clear picture.

Playback picture may become blurred of interrupted while the TV program reception is clear. Dirt accumulated on the video heads after long periods of use, or the usage of rental or worn tapes can cause this problem.

If a streaky or snowy picture appears during playback, the video heads in your TV/DVD/VCR may need to be cleaned.

1.Please visit your local Audio/Video store and purchase a good quality VHS Video Head Cleaner.

2.If a Video Head Cleaner does not solve the problem, please call our help line at 1-800-488-1222,to locate an Authorized Service Center.

NOTES:

Remember to read the instructions included with the video head cleaner before use.

Clean video heads only when problems occur.

SERVICING

Should your TV/DVD/VCR become inoperative, do not try to correct the problem by yourself. There are no user-serviceableparts inside. Turn off, unplug the power cord, and please call our help line at1-800-488-1222,to locate an Authorized Service Center.

IF THE LASER OPTICAL PICKUP UNIT IS DIRTY

If the player still does not perform properly when it is operated while referring to the relevant sections and to "TROUBLESHOOTING GUIDE" in this Owner's Manual, the laser optical pickup unit may be dirty. Consult your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.

DISC HANDLING

Use discs which have the following logos on them. (Optical audio digital discs.)

RecordableReWritable

Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.

To clean-off,use a soft cloth.

Do not use a hard cloth since this will mar the disc.

Wipe the disc in a straight line from center to edge.

Never wipe with a circular motion.

Do not use detergent or abrasive cleaning agents.

Always store the disc in its protective case when it is not used.

– 50 –

EN

01A11

GENERAL SPECIFICATIONS
TV/VCR

SPECIFICATIONS

CRT



[23 inch model]:

23 inch in-linegun, 90˚

[27 inch model]:

deflection tube

27 inch in-linegun, 110˚



deflection tube

Television system :

NTSC-M

Closed caption system :§15.119/FCC

Video Heads :

Rotary four-head

Tape width :

1/2 inch

Tape speed



SP :

33.40mm/sec.

LP :

16.67mm/sec.

SLP :

11.12mm/sec.

Tuner channel



TV VHF Low :

#2~#6

TV VHF High :

#7~#13

TV UHF :

#14~#69

CATV



VHF :

5A

MID band :

A5~A1, A~I

SUPER band :

J~W

HYPER band :

W+1~W+84

DVD

Product type:

DVD Player

Discs:

DVD video, Audio CD

Output signal format:

NTSC color

Frequency response



(out put jack)



DVD (linear sound):

20 Hz to 22 kHz



(sample rate: 48 kHz)



20 Hz to 44 kHz



(sample rate: 96 kHz)

CD:

20 Hz to 20 kHz

Signal-to-noiseratio



(S/N ratio)(out put jack)

CD:

75 dB (EIAJ)

Dynamic range



(out put jack)



DVD (linear sound):

85 dB

CD:

84 dB (EIAJ)

Total distortion factor



CD:

0.07% (EIAJ)

Wow and flutter:

Below the measurement



limitation (+/-0.001%



W PEAK) (EIAJ)

ELECTRICAL SPECIFICATIONS

Sound output: 2 speakers, 1W, 8 ohm

OTHER SPECIFICATIONS

Terminals



Antenna input:

VHF/UHF/CATV



75 ohm unbalanced (F-type)

Video input:

RCA connector [ 1

Audio L/R input:

RCA connector [ 2

Headphone:

1/8” stereo (3.5 mm)

Coaxial digital



audio output:

One pin jack,



500m Vpp (75 ohm)

Analog audio L/R



output :

RCA connector [ 2

Remote control:

Digital encoded



infrared light system

Operating



temperature:

5ºC to 40ºC



(41ºF~104ºF)

Power requirements:

AC 120V, 60Hz

[23 inch model]



Power consumption



(Maximum):

120W

Picture tube:

23"

Dimensions:

H:23-3/4”(594mm)



W:24-1/2”(612mm)



D:18-15/16”(473mm)

Weight:

61.6 lbs (28.0kg)

[27 inch model]



Power consumption



(Maximum):

125W

Picture tube:

27"

Dimensions:

H:25-1/2”(648mm)



W:26-9/16”(675mm)



D:19-11/16”(500mm)

Weight:

86 lbs (39.0kg)

Designs and specifications are subject to change without notice.

If there is a discrepancy between languages, the default language will be English.

– 51 –

EN

01A11

INDICE

CONTROLES DE OPERACIÓN Y FUNCIONES . . . . . 52

PANEL FRONTAL DEL TELEVISOR/DVD. . . . . . . . . . 52 MANDO A DISTANCIA . . . . . . . . . . . . . . . . . . . . . . . . . 52 VISTA POSTERIOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

PREPARACIÓN PARA LA UTILIZACIÓN . . . . . . . . . . 53

CONEXIONES DE ANTENA/CABLE . . . . . . . . . . . . . . 53 CONEXIÓN A TOMAS DE ENTRADA EXTERNA. . . . 53 PARA INSERTAR LAS PILAS . . . . . . . . . . . . . . . . . . . . 54 MODO DE ENTRADA EXTERNA . . . . . . . . . . . . . . . . 54 CONEXIÓN A UN SISTEMA ESTÉREO . . . . . . . . . . . . 54 CONEXIÓN A UN AMPLIFICADOR ESTÉREO EQUIPADO CON TOMAS DE ENTRADA DIGITAL, PLATINA MD O PLATINA DAT (Para DVD). . . . . . . . . 54

CONEXIÓN A UN RECEPTOR CON DECODIFICADOR DOLBY DIGITAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

SECCIÓN DE TV/VCR

PREPARACIÓN PARA LA UTILIZACIÓN. . . . . . . . . . 54 PREAJUSTE DE CANALES. . . . . . . . . . . . . . . . . . . . . . 55 CÓMO BORRAR (AGREGAR) CANALES . . . . . . . . . . 55

SECCIÓN DE DVD

REPRODUCCIÓN BÁSICA . . . . . . . . . . . . . . . . . . . . . . 55

11.Botones CHANNEL K/L

Utilice estos botones para seleccionar canales memorizados.

12.Indicador de grabación

Parpadea durante la grabación. Se ilumina durante el modo de espera de grabación controlada por temporizador.

13.Botón REC/OTR (RECORD)

Presione este botón para grabar manualmente. Este botón también activa la función de grabación instantánea (OTR). (La función OTR sólo está disponible durante el modo TV/VCR.)

14.Botón REW (para VCR)

Presione este botón para rebobinar la cinta o para ver la imagen rápidamente en dirección de retroceso durante el modo de reproducción. (Búsqueda en dirección de retroceso)

15.Botón FWD (para VCR)

Presione este botón para adelantar rápidamente la cinta o para ver la imagen rápidamente en dirección de avance durante el modo de reproducción. (Búsqueda en dirección de avance)

16.Botón STOP/EJECT (para VCR)

Presione este botón para detener la cinta. Presiónelo en el modo de parada para retirar la cinta del televisor/DVD/videograbadora.

CONTROLES DE

OPERACIÓN Y FUNCIONES

PANEL FRONTAL DEL

TELEVISOR/DVD

Consulte la figura 1 de la página 9

17.Ventanilla del sensor de mando a distancia

18.Toma HEADPHONE

Para conectar auriculares (no suministrados) y escuchar en privado.

19.Toma de entrada VIDEO

Conecte a la toma de salida de vídeo de una videocámara, videograbadora o juego de vídeo.

20.Tomas de entrada AUDIO L/R

Conecte a las tomas de salida de audio de una videocámara, videograbadora juego de vídeo.



MANDO A DISTANCIA

21.

Compartimiento para cassette de vídeo







22.

Botón PICTURE



Consulte la figura 2 de la página 9





Presione este botón para ajustar la imagen.







23.

Botones numéricos



VISTA POSTERIOR









Modo TV:









Presione dos botones para acceder directamente al



Consulte la figura 3 de la página 10





canal deseado.

1.

Botón POWER





No olvide presionar “0” antes de elegir un canal de un





solo dígito.



Presione este botón para conectar y desconectar la ali-





Botón +100



mentación.





Presione este botón para seleccionar canales de tele-

2.

Botones VOLUME X/Y





visión por cable cuyo número sea igual o superior a 100.



Presione estos botones para controlar el nivel de volumen





Modo DVD:



del DVD y el televisor.





Presione este botón para introducir el número deseado.

3.

Botones SKIP (para DVD)





Botón +10



Presione el botón correspondiente una vez para omitir





Presione este botón para introducir números iguales o



capítulos o pistas y desplazarse a un punto específico.





mayores que 10.



Mantenga el botón presionado para cambiar la veloci-

24.

Botón PAUSE



dad de reproducción en avance o retroceso.





Hace una pausa en la reproducción del disco o cinta.

4.

Botón PLAY

25.

Botón SPEED



Inicia la reproducción del contenido del disco o cinta.





Presione este botón para seleccionar la velocidad de

5.

Botón STOP





grabación deseada: SP/SLP.



Detiene la operación del disco. (unidad principal)

26.

Botón C.RESET



Detiene la operación de los contenidos del disco o





Presione este botón para poner el contador en 0:00:00.



cinta. (control remoto)





Presiónelo también para cancelar un ajuste de progra-

6.

Botón OPEN/CLOSE





ma de temporizador.



Presione para abrir la bandeja de disco e insertar un

27.

Botón DISPLAY



disco o para sacar un disco.





Modo TV/VCR:

7.

Bandeja de carga del disco





Para visualizar el contador o el número del canal y la

8.

Indicador DVD





fecha actual en la pantalla del televisor.



Se ilumina durante el modo DVD.





Modo DVD:

9.

Botón SELECT





Indica el estado actual en la pantalla del televisor para



Presione este botón para cambiar al modo TV/VCR,





fines de comprobación.



modo de entrada externa o modo de DVD.

28.

Botón SETUP

10. Indicador TV/VCR





Presione este botón para activar o salir del modo de



Se ilumina durante el modo TV/VCR.





menús de televisor o configuración de DVD.





– 52 –

ES

0C28

29.

Botón TITLE



ANTENAS SEPARADAS DE VHF/UHF



Para visualizar el menú de títulos.



En algunas zonas será necesario utilizar una antena

30.

Botón CLEAR



exterior.



Para cancelar ajustes.



TELEVISIÓN POR CABLE SIN CAJA DE

31.

Botón MODE





CONVERTIDOR/DECODIFICADOR



Activa el modo de reproducción programada o el modo de





reproducción aleatoria.



Utilice esta conexión si su sistema de televisión por

32.

Botón SEARCH MODE



cable se conecta directamente a su televisor/DVD/



Presione este botón para localizar un punto deseado.



videograbadora, sin una caja de convertidor.

33.

Botón AUDIO



Con esta conexión podrá:



Presione este botón para seleccionar un idioma de



1) Utilizar el mando a distancia del televisor/DVD/



audio o el modo de sonido deseado.





videograbadora para seleccionar canales.

34.

Botón SUBTITLE







2) Programar uno o más canales decodificados para



Presione este botón para seleccionar el idioma de subtí-









grabación automática controlada por temporizador.



tulos deseado.









NOTA: Este televisor/DVD/videograbadoraSÓLO

35.

Botón REPEAT





puede grabar el canal que se está viendo.



Repite la reproducción del disco, título, capítulo o pista actual.



36.

Botón ANGLE (modo DVD)



TELEVISIÓN POR CABLE CON CAJA



Presione este botón para cambiar el ángulo de la cámara



DE CONVERTIDOR/DECODIFICADOR



y ver la secuencia que se está reproduciendo desde un



O CAJA DE SATÉLITE



ángulo diferente.



Si su compañía de televisión por cable le suministra

37.

Botón A-BREPEAT





una caja de convertidor o si utiliza un sistema de



Repite la reproducción de una sección seleccionada.







satélite, podrá utilizar la conexión básica que se

38.

Botón RETURN





Permite volver a la operación anterior en el modo de



muestra en la ilustración.



configuración de DVD.



Al utilizar esta conexión, también podrá grabar canales

39.

Botón ENTER



codificados. Sin embargo, la selección de los canales



Presione este botón para establecer un ajuste.



deberá hacerse con la caja de convertidor o con la caja

40.

Botones de flechas



de satélite. Esto significa que no es posible cambiar de



Modo TV/VCR:



canal utilizando el mando a distancia del televisor/DVD/



Presione estos botones para seleccionar un modo de







videograbadora. La grabación en ausencia (controlada



ajuste en el menú que aparece en la pantalla del televisor.







por temporizador) está limitada a un canal a la vez.



Presiónelos también para seleccionar opciones o





establecer ajustes en un menú en particular.



PARA GRABAR UN CANAL



Modo DVD:



CODIFICADO/DECODIFICADO



Use estos botones para hacer ajustes mientras observa



1.Ajuste el selector de canales del



la imagen en la pantalla del televisor.





televisor/DVD/videograbadora al canal de salida de

41.

Botón DISC MENU









la caja de convertidor de televisión por cable o caja



Muestra los menús contenidos en el DVD.











de satélite. (Ej., CH3)

42.

Botón ZOOM







2.Seleccione el canal que desea grabar en la caja de



Amplía parte de la imagen reproducida de un DVD.



43.

Botón MUTE





convertidor de televisión por cable o caja de satélite.



Suprime la salida de sonido. Presiónelo de nuevo para









restablecer el sonido.



Nota para el instalador de sistemas CATV

44.

Botón SLEEP



Esta nota tiene la finalidad de llamar la atención



Utilice este botón para ajustar el temporizador de dormir.



del instalador de sistemas CATV para que tenga

45.

Botón SELECT



en cuenta el Artículo 820-40de la NEC, que pro-



Presione este botón para cambiar entre los modos



porciona recomendaciones para hacer una conex-



TV/VCR y DVD. El modo seleccionado (TV/VCR o







ión a tierra apropiada y, en particular, especifica



DVD) se visualiza en el indicador del panel delantero.



46.

Toma de entrada ANT.



que la tierra del cable debe conectarse al sistema



Conéctela a una antena, sistema de televisión por cable



de puesta a tierra del edificio, tan cerca del punto



o sistema de satélite.



de entrada del cable como sea posible.

47.

Cable de alimentación















Conéctelo a una toma de CA estándar (120 V, /60 Hz).





CONEXIÓN A TOMAS DE



NOTA: Antes de conectar el cable de alimentación a







una toma de CA estándar, retírelo del gancho





ENTRADA EXTERNA



para evitar dañarlo.



Cuando vea un programa grabado en otra fuente (videograbado-

48.

Toma de salida de audio digital COAXIAL





Conéctela solamente a la entrada digital de un amplifi-



ra o videocámara), utilice las tomas de entrada de audio/vídeo



cador externo o decodificador de audio de DVD.



de la parte delantera del televisor/DVD/videograbadora.

49.

Terminal de salida analógico AUDIO L/R



Conecte las tomas de salida de audio/vídeo de otra fuente a



Conecte a la entrada de audio analógica de un amplifi-



las tomas AUDIO L/R y VIDEO de este



cador externo o sistema estéreo.



televisor/DVD/videograbadora. Luego, presione los botones







CHANNEL K/L hasta que aparezca "AUX" en la pantalla.







NOTA:



PREPARACIÓN PARA LA



Cuando conecte una videograbadora monofónica (otra







fuente) a este televisor/DVD/videograbadora, conecte la



UTILIZACIÓN





toma de salida de audio de la videograbadora monofónica









(otra fuente) a la toma AUDIO L de este









televisor/DVD/videograbadora. El audio saldrá igual-

CONEXIONES DE ANTENA/CABLE









mente por los canales izquierdo y derecho.













Consulte la figura 4 de la página 11





Consulte la figura 5 de la página 12



– 53







ES

0C28

PARA INSERTAR LAS PILAS

1)Abra la cubierta del compartimiento de las pilas empujando la cubierta del mando a distancia en el sentido de la flecha.

2)Inserte 2 pilas "AA" en el compartimiento de las pilas, en el sentido indicado por las marcas de polaridad (+/-).

3) Vuelva a poner la cubierta.

CONEXIÓN A UN RECEPTOR CON DECODIFICADOR DOLBY DIGITAL

Si se utiliza este TV/DVD/VCR para reproducir un disco DVD, el TV/DVD/VCR emite flujo de datos DOLBY DIGITAL de su terminal de salida de audio digital COAXIAL. Al conectar el reproductor a un receptor con codificador DOLBY DIGITAL, puede disfrutar de un ambiente más convincente y real con un sonido envolvente de alta potencia y calidad como el que se escucha en las salas de cine.

MODO DE ENTRADA EXTERNA

Al usar una señal de entrada externa (otra videograbadora o una videocámara), conecte los cables de salida de audio/vídeo del equipo externo a las tomas AUDIO L/R IN/ VIDEO IN de su televisor/DVD/videograbadora. Luego, presione los botones CHANNEL K/L hasta que aparezca "AUX" en la pantalla.

CONEXIÓN A UN SISTEMA

ESTÉREO

NOTAS:

Asegúrese de desconectar la alimentación de todos los componentes del sistema antes de conectar otro componente.

Consulte el manual de instrucciones de su sistema estéreo y de cualquier otro componente que vaya a conectar al televisor/DVD/videograbadora.

Para sonido de TV-VCR-DVDanalógico estéreo (2 canales).

Consulte la figura 6 de la página 13

CONEXIÓN AUN AMPLIFICADOR ESTÉREO EQUIPADO CON TOMAS DE ENTRADADIGITAL, PLATINA MD O PLATINADAT

Utilice un cable digital coaxial de audio de venta en el comercio especializado para hacer las conexiones de audio. Conexión a un amplificador equipado con tomas de entrada digital, platina MD o platina DAT.

Consulte la figura 8 de la página 14

NOTAS:

Asegúrese de desconectar la alimentación de todos los componentes del sistema antes de conectar otro componente.

Consulte los manuales de instrucciones de los componentes que va a conectar al televisor/DVD/videograbadora.

Si se conecta a un receptor con decodificador Dolby Digital, ajuste DOLBY DIGITAL a ON para salida de audio en el modo de configuración.

A menos que esté conectado a un receptor con decodificador Dolby Digital, ajuste DOLBY DIGITAL a OFF para salida de audio en el modo de configuración. Cuando se reproduce un TV/DVD/VCR utilizando unos ajustes incorrectos puede hacer que se genere ruido y también puede causar daño a los altavoces.

Solo el audio DVD está disponible utilizando la toma de salida de audio COAXIAL.

Para el sonido de audio de TV y VCR, por favor remítase a la sección “CONEXIÓN A UN SISTEMA ESTÉRO”. Es necesario utilizar esta conexión en adición a la anterior para poder disfrutar de un sonido de TV y VCR a través del mismo receptor.

Fabricado bajo licencia de Dolby Laboratories. “Dolby” y el símbolo de la D doble son marcas de fábrica de Dolby Laboratories.

Consulte la figura 7 de la página 13

NOTAS:

La fuente de audio de un disco grabado en formato de sonido envolvente Dolby Digital de 5,1 canales no se puede grabar como sonido digital mediante una platina MD o DAT.

Asegúrese de desconectar la alimentación de todos los componentes del sistema antes de conectar otro componente.

Consulte los manuales de instrucciones de los componentes que va a conectar al televisor/DVD/videograbadora.

Ajuste la función Dolby Digital a OFF para salida de audio en el modo de configuración. La reproducción en un televisor/DVD/videograbadora utilizando ajustes incorrectos puede generar ruido y distorsión, y también puede causar daños a los altavoces.

Solo para sonido de DVD digital estéreo (2 canales).

SECCIÓN DE TV/VCR

PREPARACIÓN PARA LA

UTILIZACIÓN

Puede programar el sintonizador para explorar todos los canales que pueda recibir en su zona.

NOTA: La programación de la memoria de canales NO es necesaria cuando se hace la conexión a una caja de televisión por cable o a una caja de satélite. Simplemente ajuste el selector de canales del televisor/DVD/videograbadora a la posición correspondiente al canal de salida de la caja de televisión por cable o caja de satélite (ej., CH3). Luego, seleccione el canal que desea ver en la caja de televisión por cable o en la caja de satélite.

– 54 –

ES

0C28

PREAJUSTE DE CANALES

TV/VCR

1Conecte el cable de alimentación del televisor/DVD/videograbadora

Conecte el cable de alimentación del televisor/DVD/videograbadora

NOTA:

Si aparecen algunos dígitos en la esquina de la pantalla, presione el botón POWER sin desconectar el cable de alimentación.

2Encienda el televisor/DVD/videograbadora

Presione el botón POWER para encender el televisor/DVD/videograbadora.

3Seleccione “ENGLISH”, “ESPAÑOL” o “FRANÇAIS”

Presione el botón ENTER para seleccionar "ENGLISH" = inglés, "ESPAÑOL" o "FRANÇAIS" = francés. "[ ]" indica el idioma seleccionado.

4 Inicie el preajuste automático

Presione el botón de flecha K oL para señalar "AUTOPRESELECCION".

Luego, presione el botón ENTER.

El sintonizador explora y memoriza todos los canales activos de su zona.

NOTAS:

El televisor/DVD/videograbadora distingue entre los canales de TV estándar y los canales de televisión por cable.

Si desea reproducir o grabar una cinta de vídeo ANTES de preajustar el sintonizador, deberá presionar el botón SETUP del mando a distancia.

El televisor/DVD/videograbadora puede memorizar canales de TV como canales de CATV si las condiciones de recepción no son buenas. Si esto sucede, vuelva a intentar la acción AUTO MEMO cuando las condiciones de recepción mejoren.

5 Una vez finalizada la exploración

El sintonizador se detiene en el canal memorizado más bajo. Si desea recuperar los canales seleccionados, podrá seleccionar los canales directamente con los botones numéricos o los botones CHANNEL K oL del mando a distancia.

CÓMO BORRAR (AGREGAR)

CANALES

TV/VCR

Puede borrar de la memoria los canales que ya no recibe o que ve muy raramente. (Por supuesto, puede volver a agregar a la memoria los canales que haya borrado de la misma.)

1 Seleccione “AJUSTE DE CANAL”

Presione el botón SETUP del mando a distancia. Presione el botón de flecha K oL para señalar “AJUSTE DE CANAL”.

Luego, presione el botón ENTER.

2 Seleccione “AGREGAR/BORRAR”

Presione el botón de flecha K oL para señalar “AGREGAR/BORRAR”.

Presione el botón ENTER.

3Introduzca el número del canal deseado

Presione el botón de flecha K oL hasta que aparezca el número del canal deseado. (También puede utilizar también los botones numéricos o los botones CHANNELK/L para introducirlo.) (Ejemplo: CH8)

4Borre el canal de la memoria o agréguelo a ella

Presione el botón ENTER. El número del canal seleccionado se ilumina de color rojo. El canal de borra de la memoria.

Canal agregado: Se enciende en azul. Canal borrado: Se enciende en rojo.

Para borrar otro canal, repita los pasos [3] y [4].

Si vuelve a presionar el botón ENTER, el canal se memorizará de nuevo.

Presione el botón RETURN para hacer que el televisor/videograbadora vuelva al menú SETUP.

5 Salga del modo de preajuste de canales

Presione el botón SETUP del mando a distancia para volver al modo de televisor.

NOTA: Para confirmar que los canales han sido borrados o agregados, presione el botón CHANNELK oL.

SECCIÓN DE DVD

REPRODUCCIÓN BÁSICA

DVD-VCD

Para empezar

¡Conecte la alimentación del amplificador y otros componentes, si es necesario.

1Presione el botón POWER.

¡La alimentación se conectará.

2Presione el botón OPEN/CLOSE para abrir la bandeja de carga del disco.

3Ponga el disco deseado en la bandeja, con la etiqueta hacia arriba.

4Presione el botón PLAY.

¡La bandeja se cerrará automáticamente y la reproducción comenzará desde el primer capítulo o pista del disco. Si la reproducción no comienza automáticamente, presione el botón PLAY.

¡Cuando reproduzca un DVD que tenga grabado un menú de títulos, el menú podrá aparecer en la pantalla.

5Presione el botón STOP para detener la reproducción.

– 55 –

ES

0C28

Get it fixed, at your home or ours!

Your Home

For repair- in your home -ofall major brand appliances, lawn and garden equipment, or heating and cooling systems,no matter who made it, no matter who sold it!

For the replacement parts, accessories and owner's manuals that you need to do-it-yourself.

For Sears professional installation of home appliances and items like garage door openers and water heaters.

1-800-4-MY-HOMER (1-800-469-4663)

Call anytime, day or night (U.S.A. and Canada)

www.sears.com www.sears.ca

Our Home

For repair of carry-initems like vacuums, lawn equipment, and electronics, call or goon-linefor the location of your nearest

Sears Parts & Repair Center.

1-800-488-1222

Call anytime, day or night (U.S.A. only)

www.sears.com

To purchase a protection agreement on a product serviced by Sears:

1-800-827-6655(U.S.A.)

1-800-361-6665(Canada)

Para pedir servicio de reparación a domicilio, y para ordenar piezas:

1-888-SU-HOGARSM

(1-888-784-6427)

Au Canada pour service en français:

1-800-LE-FOYERMC

(1-800-533-6937)www.sears.ca

R Registered Trademark /TM Trademark /SM Service Mark of Sears, Roebuck and Co.



R Marca Registrada /TM Marca de Fábrica /SM Marca de Servicio de Sears, Roebuck and Co.



MC Marque de commerce /MD Marque déposée de Sears, Roebuck and Co.

© Sears, Roebuck and Co.

FULL 90 DAY WARRANTY

For 90 days from the date of purchase, Sears will repair any defect in material or workmanship in this TV/DVD/VCR combination, free of charge. For one year from the date of purchase, Sears will supply, at no charge, replacement for defective parts. Two (2) years for Picture Tube. Certain parts are excluded from this warranty.

The above warranty coverage applies only to TV/DVD/VCR combination which are used for private household purposes.

TO OBTAIN WARRANTY SERVICE, SIMPLY RETURN THE TV/DVD/VCR COMBINATION TO THE NEAREST SEARS SERVICE CENTER IN THE UNITED STATES.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

Sears Roebuck and Co., Dept. 817WA Hoffman Estates, IL 60179

For the location of a Sears Service Center in your area : 1-800-488-1222

Printed in Malaysia

0EMN02178



TD945UF/TD955UF
