OWNER’S

MANUAL SYLVANIA

COLOR TV/VCR/DVD TRIPLE COMBO

RSEC720E (20 inch)

SUPPLIED ACCESSORIES

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

ACCESSORIES

PART NO.





Remote Control Unit

NE230UD





Batteries

2 AA Batteries





Owner’s Manual

1EMN20069





As an ENERGYSTAR®

Partner, our company has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. ENERGY STAR® is a U.S. registered mark.

If you need additional operating assistance after reading this owner’s

manual or to order replacement accessories, please call

TOLL FREE : 1-800-968-3429

Please read before using this equipment

PORTABLE CART WARNING
S3126A

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The caution marking is located on the rear of the cabinet.

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

IMPORTANT SAFEGUARDS

1.Read instructions-Allthe safety and operating instructions should be read before the appliance is operated.

2.Retain Instructions-Thesafety and operating instructions should be retained for future reference.

3.Heed Warnings-Allwarnings on the appliance and in the operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions should be followed.

5.Cleaning-UnplugTV/VCR/DVD from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6.Attachments-Donot use attachments not recommended by the TV/VCR/DVD manufacturer as they may cause hazards.

7.Water and Moisture-Donot use this TV/VCR/DVD nearwater-forexample, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8.Accessories-Donot place this TV/VCR/DVD on an unstable cart, stand, tripod, bracket, or table. The TV/VCR/DVD may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the TV/VCR/DVD. Any mounting of

the appliance should follow the manufacturer’s instructions and should use a mounting accessory

recommended by the manufacturer. An appliance and cart combination

should be moved with care.Quick

stops, excessive force, and uneven surfaces may cause the appliance

and cart combination to overturn.

AMEUBLES- Cet appareil ne doit être placé que sur un meuble (avec ou sans roulettes) recommandé par le fabricant. Si vous l’installez sur un meuble à roulettes, déplacez les deux ensembles avec précaution.

Un arrêt brusque, l’utilisation d’une force excessive et des surfaces irrégulières risquent de déstabiliser l’ensemble et de le renverser.

SYMBOLE D'AVERTISSEMENT POUR

LES COMPOSANTES

APPAREIL ET MEUBLE A ROULETTES

S3126A

9.Ventilation-Slotsand openings in the cabinet and the back or bottom are provided for ventilation and to ensure reliable operation of the TV/VCR/DVD and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the TV/VCR/DVD on a bed, sofa, rug, or other similar surface. This TV/VCR/DVD should never be placed near or over a radiator or heat register. This TV/VCR/DVD should not be placed in abuilt-ininstallation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10.Power Sources-ThisTV/VCR/DVD should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For TV/VCR/DVDs intended to operate from battery power, or other sources, refer to the operating instructions.

11.Grounding or Polarization-This TV/VCR/DVD is equipped with a polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12.Power-Cord Protection-Power-supplycords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

- 2 -

EN

1B15

FIGURE A

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECT RICAL CODE













ANTENNA













L EAD I N













W I R E



GROUND



C L A M P













ANTENNA





































DI SCHARGE UN I T













(NEC SECTION 8 10 -20)

EL ECTRI C













SE RV I CE













EQU I PMEN T

























GROUNDI NG CONDUCTORS













(NEC SECTION 8 10 -21)











G RO UND CL AMPS

NEC - NATI O NAL EL ECTRI CAL CODE





POWER SERVI C E GROUNDI NG







EL EC TR ODE SYSTEM

S2 8 9 8 A





(NEC ART 2 50 , PART H)

13.Outdoor Antenna grounding-If an outside antenna or cable system is connected to the TV/VCR/DVD, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14.Lightning-Foradded protection for this TV/VCR/DVD receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV/VCR/DVD due to lightning andpower-linesurges.

15.Power Lines-Anoutside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16.Overloading-Donot overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

17.Object and Liquid Entry-Never push objects of any kind into this TV/VCR/DVD through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the TV/VCR/DVD.

18.Servicing-Donot attempt to service this TV/VCR/DVD yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19.Damage Requiring Service-Unplug this TV/VCR/DVD from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a.When the power-supplycord or plug is damaged or frayed.

b.If liquid has been spilled, or objects have fallen into the TV/VCR/DVD.

c.If the TV/VCR/DVD has been exposed to rain or water.

d.If the TV/VCR/DVD does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the TV/VCR/DVD to its normal operation.

e.If the TV/VCR/DVD has been dropped or damaged in any way.

f.When the TV/VCR/DVD exhibits a distinct change in per- formance-thisindicates a need for service.

20.Replacement Parts-Whenreplacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, injury to persons or other hazards.

21.Safety Check-Uponcompletion of any service or repairs to this TV/VCR/DVD, ask the service technician to perform routine safety checks to determine that the TV/VCR/DVD is in proper operating condition.

22.Heat-ThisTV/VCR/DVD product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

- 3 -

EN

1B15

PRECAUTIONS

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

FCC WARNINGThis equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

RADIO-TVINTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1)Reorient or relocate the receiving antenna.

2)Increase the separation between the equipment and receiver.

3)Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4)Consult the dealer or an experienced radio/TV technician for help.

LASER SAFETY

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003du Canada.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

- 4 -

EN

1B15

LOCATION



WARNING







For safe operation and satisfactory performance of your TV/VCR/DVD, keep the following in mind when selecting a place for its installation:

Shield it from direct sunlight and keep it away from sources of intense heat.

Avoid dusty or humid places.

Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes at the top or bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

Install unit in a horizontal position.

Avoid locations subject to strong vibration.

Do not place the TV/VCR/DVD near strong magnetic fields.

Avoid moving TV/VCR/DVD to locations where temperature differences are extreme.

AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE

Do not handle the power cord with wet hands.

Do not pull on the power cord when disconnecting it from an AC wall outlet. Grasp it by the plug.

If by accident, water is spilled on your unit, unplug the power cord immediately and take the unit to our Authorized Service Center for servicing.

Do not put your fingers or objects into the TV/VCR/DVD disc loading tray.

Do not place anything directly on top of the unit.

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place or after heating a cold room or under conditions of high humidity. If a DVD is played in a TV/VCR/ DVD which has moisture, it may damage the DVD and TV/VCR/DVD. Therefore when the condensation occurs inside the unit, turn the POWER on and allow at least 2 hours for the unit to dry out.

SYMBOLS USED IN THIS MANUAL

The following symbols below appear in some headings and notes in this manual, with the following meanings

TV/VCR

:Description refers to TV/VCR operation (in the TV/VCR mode).

DVD-V

:Description refers to playback of DVD video discs (in the DVD mode).

CD

:Description refers to playback of audio CDs (in the DVD mode).

MP3

:Description refers to playback of MP3 discs (in the DVD mode).

QUICK

:Description refers to the items to be set by the QUICK mode (in the DVD mode).

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

The serial number of this product may be found on the back of the unit. No other TV/VCR/DVD has the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase

Dealer Purchase from

Dealer Address

Dealer Phone No.

Model No.

Serial No.

- 5 -

EN

1C29

TABLE OF CONTENTS

C IMPORTANT SAFEGUARDS . . . . .2

C PRECAUTIONS . . . . . . . . . . . . . . . .4

LOCATION . . . . . . . . . . . . . . . . . . .5

AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE .5

WARNING . . . . . . . . . . . . . . . . . . . .5

SYMBOLS USED IN THIS MANUAL . . . . . . . . . . . . . . . . . . . . .5

C TABLE OF CONTENTS . . . . . . . . . .6

C FEATURES . . . . . . . . . . . . . . . . . . . .7

C OPERATING CONTROLS AND

FUNCTIONS . . . . . . . . . . . . . . . . . . .9

C PREPARATION FOR USE . . . . . . .11

ANTENNA/CABLE

CONNECTION . . . . . . . . . . . . . . . .11

CONNECTING TO EXTERNAL INPUT JACKS . . . . . . . . . . . . . . . .12

INSTALLING THE BATTERIES . .12 EXTERNAL INPUT MODE . . . . . .12

CONNECTING TO A STEREO AMPLIFIER EQUIPPED WITH DIGITAL INPUT JACKS SUCH AS MD DECK OR DAT DECK (for DVD) .13

CONNECTING TO A DOLBY

DIGITAL DECODER (for DVD) . .14

TV/VCR SECTION

C SET UP FOR USE . . . . . . . . . . . . .

15

SELECTING THE LANGUAGE . .15

CLOCK SET UP

(AUTO / MANUAL) . . . . . . . . . . . .15 DAYLIGHT-SAVINGTIME . . . . . .17 CHANNEL SET UP . . . . . . . . . . . .18

DELETING (OR ADDING) CHANNEL(S) . . . . . . . . . . . . . . . . .18

C TV OPERATION . . . . . . . . . . . . . . .19

WATCHING A TV PROGRAM . . .19 DEGAUSSING . . . . . . . . . . . . . . . .19 PICTURE CONTROL . . . . . . . . . . .19 CLOSED CAPTION SYSTEM . . . .20 V-CHIPSET UP . . . . . . . . . . . . . . .21

C MTS(Multi-ChannelTelevision

sound)SYSTEM . . . . . . . . . . . . . . . .23

CHECKING THE SELECTED

MTS MODE . . . . . . . . . . . . . . . . . .23

MTS RECORDING/MONITOR MODE . . . . . . . . . . . . . . . . . . . . . .23

SELECTING THE MTS SYSTEM .24

C VIDEO CASSETTE . . . . . . . . . . . . .25

CPLAYBACK . . . . . . . . . . . . . . . . . . .26

NORMAL PLAYBACK . . . . . . . . .26 TRACKING ADJUSTMENT . . . . .26 SLOW MOTION . . . . . . . . . . . . . .26

STILL PICTURE . . . . . . . . . . . . . .26

VERTICAL HOLD CONTROL . . .26

C SPECIAL PLAYBACK . . . . . . . . . .27

RENTAL PLAYBACK . . . . . . . . . .27

AUTO REPEAT PLAYBACK . . . . .27

C SEARCH . . . . . . . . . . . . . . . . . . . . .28

ZERO RETURN . . . . . . . . . . . . . . .28 PICTURE SEARCH . . . . . . . . . . . .28 TIME SEARCH . . . . . . . . . . . . . . .28 INDEX SEARCH . . . . . . . . . . . . . .29

C SPECIAL FEATURES . . . . . . . . . .29

REAL TIME TAPE COUNTER . . .29

AUTO REWIND-EJECT . . . . . . . .29

C RECORDING . . . . . . . . . . . . . . . . .30

NORMAL RECORDING . . . . . . . .30

SKIPPING UNWANTED SCENES DURING RECORDING . . . . . . . . .30

OTR (One Touch Recording) . . . . . .31

COPYING A VIDEO CASSETTE (Requires a VCR or camcorder) . . .31

C TIMER . . . . . . . . . . . . . . . . . . . . . .32

AUTOMATIC

TIMER RECORDING . . . . . . . . . .32 TIMER PROGRAM EXTENSION .33

HINTS FOR AUTOMATIC TIMER RECORDING . . . . . . . . . . . . . . . . .34

AUTO RETURN . . . . . . . . . . . . . . .34 SLEEP TIMER . . . . . . . . . . . . . . . .34

C ON SCREEN DISPLAY . . . . . . . . .35

C CABLE CHANNEL

DESIGNATIONS . . . . . . . . . . . . . .35

DVD SECTION

C ABOUT THE DISCS . . . . . . . . . . . .36

PLAYABLE DISCS . . . . . . . . . . . .36 DISC TYPES . . . . . . . . . . . . . . . . .36

C PLAYING A DISC . . . . . . . . . . . . . .37

BASIC PLAYBACK . . . . . . . . . . . .37 GENERAL FEATURES . . . . . . . . .37 DISC MENU . . . . . . . . . . . . . . . . .37 TITLE MENU . . . . . . . . . . . . . . . . .37 RESUME . . . . . . . . . . . . . . . . . . . .38 PAUSE . . . . . . . . . . . . . . . . . . . . . .38 STEP BY STEP PLAYBACK . . . . .38

FAST FORWARD/REVERSE SEARCH . . . . . . . . . . . . . . . . . . . .38

SLOW FORWARD / SLOW REVERSE . . . . . . . . . . . . . . . . . . . .38

C SEARCH FUNCTION . . . . . . . . . . .39

TRACK SEARCH . . . . . . . . . . . . .39

TITLE / CHAPTER SEARCH . . . .39

TIME SEARCH . . . . . . . . . . . . . . .39

MARKER SETUP SCREEN . . . . . .39

C SPECIAL PLAYBACK FUNCTION . . .40

REPEAT . . . . . . . . . . . . . . . . . . . . .40 PROGRAM . . . . . . . . . . . . . . . . . . .40 RANDOM PLAYBACK . . . . . . . . .40

C PLAYING A MP3 DISC . . . . . . . . . .41

MP3 PLAYBACK . . . . . . . . . . . . . .41 REPEAT . . . . . . . . . . . . . . . . . . . . .41 PROGRAM . . . . . . . . . . . . . . . . . . .41 RANDOM PLAYBACK . . . . . . . . .41

C CHANGING THE SETTINGS . . . .42

SUBTITLE LANGUAGE . . . . . . . .42 AUDIO LANGUAGE . . . . . . . . . . .42 STEREO SOUND MODE . . . . . . . .42 CAMERA ANGLE . . . . . . . . . . . . .42 BLACK LEVEL SETTING . . . . . . .42 VIRTUAL SURROUND . . . . . . . . .42

C THEON-SCREENINFORMATION . . .43

C CHANGING THE DVD SETUP

ITEMS . . . . . . . . . . . . . . . . . . . . . . .44

LANGUAGE SETTING . . . . . . . . .44 DISPLAY SETTING . . . . . . . . . . . .45 AUDIO SETTINGS . . . . . . . . . . . .45 PARENTAL CONTROL . . . . . . . . .46 INITIALIZE . . . . . . . . . . . . . . . . . .46

C TROUBLESHOOTING GUIDE . . .47

C MAINTENANCE . . . . . . . . . . . . . . .50

DISC HANDLING . . . . . . . . . . . . .50

C SPECIFICATIONS . . . . . . . . . . . . .51

C ESPAÑOL . . . . . . . . . . . . . . . . . . . .52

C WARRANTY . . . . . . . . . . .Back Cover

- 6 -

EN

1C29

FEATURES

TV/VCR Mode

Hi-Fi system–TheHi-Fistereo recording system offers you excellent sound quality with a dynamic range of 80dB, frequency response from 20Hz to 20kHz and 0.005% wow and flutter.

Rotary 4-headRecord/PlaybackSystem–Four video heads ensure excellent picture quality and special effects playback.

Index Search–Fast-forwardsto start of next recording.

Slow Motion–Viewrecorded program at slower than normal speed.

Infrared remote control

Trilingual on screen TV/VCR setup display selectable in English, Spanish or French

Real time counter–Thisshows the elapsed recording or playback time in hours, minutes and seconds. The“–”indication will appear when the tape is rewound further than the tape counter position “0:00:00”.

181 channel capability PLL frequency synthesizer tuner with direct station call–(A converter may be necessary to view scrambled cable channels.)

Auto Clock Setting–Allowsyou to set the clock function from a PBS broadcast station.

Closed caption system–Youmay view specially labeled (cc) TV programs, movies, news, prerecorded tapes, etc. with either a dialogue caption or text display added to the program.

Auto power on and off system–Automatically turns on the TV/VCR/DVD when you insert the cassette, turns off after auto-rewind and ejects when the beginning of the tape is reached.

Auto rewind when the end of a tape is reached–This function doesn’t occur when using timer recording.

Smooth mode change–TV/VCRmode and DVD mode automatically changes without control.

2 Step picture search operation–You can view a video program at high speed or super high speed in either a forward or reverse direction in LP and SLP mode. For SP mode only high speed is available.

Three different playback tape speeds : SP/LP/SLP

Two different recording tape speeds : SP/SLP

Auto Head Cleaner–Automaticallycleans video heads as you insert or remove a cassette.

Zero Return–Thetape returns to counter of 0:00:00 by rewinding or fast forwarding.

Still–“Freeze”the picture at any time, for close viewing of a particular scene.

Digital Auto Tracking (DTR)–Automatically adjusts the tracking for each tape you play.

Rental play mode–Improvesplayback picture quality from worn tapes, such as rental tapes.

Auto repeat–Allowsyou to repeat the playing of a tape indefinitely without pressing the PLAY button.

Time search–Letsyou set the TV/VCR/DVD to advance the tape by entering the desired playback time you want to skip.

OTR (One Touch Recording)–Instant timed recording from 30 to 480 minutes is possible at the push of the REC/OTR button.

1 Year, 8 events (including Daily and Weekly Timer Recording)–The built-in timer allows you to record up to 8 programs at different times on different channels up to 1 year in advance. The Daily timer allows recordings to be made of daily broadcasts and the Weekly timer allows recording to be made once a week up to the end of the tape.

Auto return–Aftertimer recording is finished, the TV/VCR/DVD can return to the beginning of the recording.

Sleep timer–Allowsyou to have the TV/VCR/DVD automatically turn off at a desired time.

Timer Program Extension–Allows you to shift the time schedule for automatic timer recording.

V-CHIP–Enablesparents to prevent their children from watching inappropriate material on TV.

- 7 -

EN

1C29

DVD Mode

¡Dolby Digital sound

This TV/VCR/DVD can handle Dolby Digital surround sound having 5.1 channels when connected to a Dolby Digital decoder.

¡Still/fast/slow/step playback

Various playback modes are available including still pictures, fast forward/reverse, slow motion and step frames.

¡Random playback for audio CD and MP3

This unit can shuffle the order of tracks to play them in random order.

¡Program playback for audio CD and MP3

You can program the order of tracks to play them in any desired order.

¡DVD menus in a desired language

You can display DVD menus in a desired language, if available on a DVD.

¡Screen saver/Autopower-offfunctions

The screen saver program starts when there is no input from the unit for 5 minutes in the stop mode. When the screen saver program is activated for 15 minutes, the power automatically turns off.

¡Subtitles in a desired language

You can select a desired language for the display subtitles, if that language is available on a disc.

¡Selecting a camera angle

You can select the desired camera angle, if a disc contains sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound mode, if different languages and modes are available on a disc.

¡Parental lock

You can set the control level to limit playback of discs which may not be suitable for children.

¡Automatic detection of discs

This unit automatically detects if the loaded disc is DVD, audio CD or MP3 on disc.

¡Playback MP3 disc

¡On-screendisplay

Information about the current operation can be displayed on a TV screen, allowing you to confirm the currently active functions (such as program playback), on the TV screen using the remote control.

¡Search

Chapter search / Title search / Track search / Time search

¡Repeat

Chapter / Title / Track / Group / All / A-B

¡Marker

The part designated by user can be called back.

¡Resume Play

User can resume to playback from the part at which the play was stopped.

¡Virtual Surround

¡Bit rate indication

¡DRC (Dynamic range control)

You can control the range of sound volume.

NOTE:

We do not recommend the use of universal remote controls. Not all of the functions may be controlled with a universal remote control.

If you decide to use a universal remote control with this TV/VCR/DVD, please be aware that the code number given may not operate this TV/VCR/DVD. In this case, please call the manufacturer of the universal remote control.

- 8 -

EN

1C29

OPERATING CONTROLS AND FUNCTIONS

- TV/VCR/DVD FRONT PANEL - [Fig.1]

DVD buttons

TV/VCR buttons

SEARCH

DVD TV/VCR

1

2

3

4

3

5

6

7

8

9 10

11

1213 14

4

15

16 17

18 19

20

21

- REMOTE CONTROL -



[Fig. 2]







5.STOP Button [TV/VCR P.26 / DVD P.37]















Stops operation of the disc. (or front panel)



Stops operation of the disc or tape contents. (remote control)

1

POWER PICTURE

SLEEP

SELECT

45









22

1

2

3



44





11

23







CH.

4

5

6







7

8

9



2

24

PAUSE



+100

VOL.







0

+10





25

SPEED

C.RESET

V.SURR

MUTE

43









26









42

(DVD) 3



PLAY



3 (DVD)

(TV/VCR) 14



STOP



15 (TV/VCR)

4

RECORD





DISC

5





MENU

13









41

27

DISPLAY







40





ENTER



28

SETUP

TITLE



RETURN

39









38

29

CLEAR

SEARCH MODE REPEAT

A-B

37

30

MODE

AUDIO

SUBTITLE

ANGLE

31

36









32









35

33









34

1.POWER Button [TV/VCR P.15 / DVD P.37]

Press to turn the power on and off.

2.VOLUME (VOL.) X/Y Buttons

Press to control the volume level for the DVD and TV.

3.SKIP Buttons (for DVD)[P.38]

Press once to skip chapters or tracks to a desired point.

Press and hold to change forward or reverse playback speed.

6.OPEN/CLOSE Button [DVD P.37]

Press to insert discs into or remove them from the tray.

7.Disc loading tray

8.DVD Indicator

Lights up during DVD mode.

9.SELECT Button

Press to change to TV/VCR mode, external input mode or DVD mode.

10.TV/VCR Indicator

Lights up during TV/VCR mode.

11.CHANNEL (CH.) K/L Buttons

Press to select memorized channel.

12.Recording Indicator

Flashes during recording. Lights up in the Standby mode for Timer Recording.

13.REC/OTR Button (Front Panel) [TV/VCR P.30, 31]

Press to start manual recording. Press repeatedly to start One Touch Recording.

RECORD Button (Remote Control) [TV/VCR P.30]

Press to start manual recording.

14.REW Button (for TV/VCR) [TV/VCR P.26]

Press to rewind the tape, or to view the picture rapidly in reverse during playback mode. (Rewind Search)

15.F.FWD Button (for TV/VCR) [TV/VCR P.26]

Press to rapidly advance the tape, or to view the picture rapidly in forward during playback mode. (Forward Search)

16.STOP/EJECT Button [TV/VCR P.28]

Press to stop the tape motion. Press in the Stop mode to remove tape from the unit.

17.Remote sensor window

18.HEADPHONE Jack

To connect headphone (not supplied) for personal listening.

4.PLAY Button [TV/VCR P.26 / DVD P.37]

Starts playback of the disc or tape contents.

19.VIDEO input Jack

Connect to the video output jack of a video camera or VCR.

- 9 -

EN

1C29

- TV/VCR/DVD REAR PANEL - [Fig.3]

ANT.

46

AUDIO OUT

COAXIAL

47

48

20.AUDIO L/R input Jacks

Connect to the audio output jacks of a video camera or VCR.

21.Cassette compartment

22.PICTURE Button

Press to adjust the picture.

23.Number Buttons

TV/VCR Mode:[P.15]

Press two digits to directly access the desired channel.

Remember to press a "0" before a single digit channel.

+100 Button–

Press to select cable channels which are equal or greater than number 100.

DVD Mode:

Press to enter the desired number.

+10 Button–

Press to enter the desired numbers which are equal or greater than number 10.

24.PAUSE Button [TV/VCR P.26 / DVD P.38]

Pauses the current disc or tape operation.

25.SPEED Button [TV/VCR P.30]

Press to choose the desired recording speed: SP/SLP.

26.C.RESET Button [TV/VCR P.28]

Press to reset counter to 0:00:00.

Press to cancel a setting of timer program. (See page 33.)

27.DISPLAY Button TV/VCR Mode:

Display the counter or the current channel number and current time on the TV screen.

DVD Mode:[P.43]

Displays the current status on the TV screen for checking purposes.

28.SETUP Button [TV/VCR P.15] [DVDP.44-46]

Press to enter or exit the TV menu or DVD setup mode.

29.TITLE Button [DVD P.37]

Displays the title menu.

30.CLEAR Button

Resets a setting.

31.MODE Button [DVD P.41]

Activates program playback or random playback mode.

32.SEARCH MODE Button [DVD P.39]

Press to locate a desired point.

33.AUDIO Button [DVD P.42]

Press to select a desired audio language or sound mode.

34.SUBTITLE Button [DVD P.42]

Press to select a desired subtitle language.

35.REPEAT Button [DVD P.42]

Repeats playback of the current disc, title, chapter, group or track.

36.ANGLE Button (DVD mode) [DVD P.42]

Press to change the camera angle to see the sequence being played back from a different angle (if available).

37.A-BREPEAT Button[DVD P.40]

Repeats playback of a selected section.

38.RETURN Button

Returns to the previous operation in the DVD setup mode.

39.ENTER Button

Press to accept a setting.

40.Arrow Buttons TV/VCR Mode:

Press to select a setting mode from the menu on the TV screen.

Press to select or adjust from a particular menu.

DVD Mode:

Use when making settings while watching the display on a TV screen.

41.DISC MENU Button [DVD P.37]

Displays the menus in the DVD.

42.V. SURR (VIRTUAL SURROUND) Button [DVD P.42]

Sets virtual surround on/off.

43.MUTE Button

Mutes the sound. Press it again to resume sound.

44.SLEEP Button [TV/VCR P.34]

Sets the Sleep Timer.

45.SELECT Button

Press to switch TV/VCR and DVD mode. You can see the mode (TV/VCR or DVD) on the front panel indicator.

- 10 -

EN

1C29

46. ANT. in Jack

48. COAXIAL digital audio out Jack

Connect to an antenna, cable system or satellite

Connect to the digital input of an external

system.

amplifier or decoder for DVD audio only.

47.Power cord

Connect to a standard AC outlet (120V/60Hz). NOTE: Remove the power cord from the hook to

avoid breaking a wire before you connect to a standard AC outlet.

PREPARATION FOR USE

ANTENNA/CABLE CONNECTION

Satellite Box or

Cable Box (Not supplied)

OUT

IN

VHF/UHF Antenna (Not supplied)

From Cable System or

VHF Antenna (Not supplied)

Satellite Dish





75-ohm

UHF Antenna

From Cable

Coaxial

(Not supplied)

System

Cable



(Not supplied)

ANT.

AUDIO OUT

or

VHF/UHF

COAXIAL









Combiner







(Not supplied)

75-ohmCoaxial

ANT.





or





Cable (Not



[Fig. 4]





supplied)







or

Flat twin-leadcable





VHF/UHF SEPARATE ANTENNAS

In some areas it will be necessary to use an outdoor antenna.

CABLE WITHOUT CONVERTER/ DESCRAMBLER BOX

Use this connection if your cable system connects directly to your TV/VCR/DVD without a converter box.

By using this connection you can:

1)Use the remote control to select channels.

2)Program one or more unscrambled channels for Automatic Timer Recording.

NOTE: This unit willONLY record and view the same channel.

CABLE WITH CONVERTER/ DESCRAMBLER BOX OR SATELLITE BOX

If your cable service supplies you with a converter box or if you use a satellite system, you can use the basic connection shown in the illustration.

By using this connection you can also record scrambled channels. However, channel selection must be made with the converter box or satellite box. This means that channels cannot be changed using the remote control. Unattended timer recording is limited to one channel at a time.

Antenna/Cable Connections

Continued on the Next Page.

- 11 -

EN

1C29

TO RECORD A SCRAMBLED/UNSCRAMBLED CHANNEL

1. Set the TV/VCR/DVD channel selector to the output channel of the Cable Converter Box or Satellite Box. (Ex. CH3)

2.Select the channel to record from your Cable Converter Box or Satellite Box.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40of the NEC that provides guidelines for proper grounding and in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

CONNECTING TO EXTERNAL

INPUT JACKS

When you watch a program recorded on another source (VCR or video camera), use the audio/video input jacks on the front of the unit.

Connect the audio/video output jacks of another source to the AUDIO L/R and VIDEO jacks of this unit.

Then press the CHANNEL button K orL until "AUX" appears on the screen.

NOTE:

When you connect a monaural VCR (another source) to this unit, connect the Audio output jack of the monaural VCR (another source) to the AUDIO L jack of this unit. The audio will output in both L and R channel equally.



To the audio





output jacks



[Another source]







HEADPHONE VIDEO

L-AUDIO-R



Audio/Video





cable





(not supplied)



etc.





To the video

[Front of the

TV/VCR/DVD]

output jack





[Fig. 5]

INSTALLING THE BATTERIES

1)Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.

2)Insert 2 “AA” penlight batteries into the battery compartment in the direction indicated by the polarity (+/-)markings.

3)Replace the cover.

EXTERNAL INPUT MODE

When using an external input signal (another VCR or video camera), connect the player’s audio/video output cables to the AUDIO L/R IN/

VIDEO IN jacks of your unit. Then AUX press the CHANNEL buttonK or

L until “AUX” appears on the screen.

- 12 -

EN

1C29

CONNECTING TO A STEREO AMPLIFIER EQUIPPED WITH DIGITAL INPUT JACKS SUCH AS MD DECK OR DAT DECK (for DVD)

Use an audio coaxial digital cable available at retail for the audio connections.

Connecting to an amplifier equipped with digital input jacks such as MD Deck or DAT Deck.

ANT.

AUDIO

COAXIAL



Amplifier equipped with digital

To DIGITAL AUDIO OUT

input jacks, MD deck,

(PCM/BITSTREAM)

DAT deck, etc.

COAXIAL jack

To COAXIAL DIGITAL

AUDIO INPUT jack

(only DVD AUDIO OUT)



[Fig. 6]

NOTES:

The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital sound by an MD or DAT deck.

Be sure to turn off the power to all components in the system before connecting another component.

Refer to the Owner's Manuals for the components to be connected to the unit.

Set Dolby Digital to OFF for audio output in the setup mode. Playing a TV/VCR/DVD using incorrect settings may generate noise distortion and may also damage the speakers.

- 13 -

EN

1C29

CONNECTING TO A DOLBY DIGITAL DECODER (for DVD)

When using this unit to play a DVD disc in a 5.1 channel Dolby Digital surround format, the unit outputs a DOLBY DIGITAL Data stream from its COAXIAL digital audio out jack. By hooking the unit up to a Dolby Digital decoder, you can enjoy a more convincing, realistic ambience with powerful and high-qualitysurround sound as enjoyed in movie theaters.

Use audio coaxial digital cables available at retail for the audio connections.

Center







speaker

Front speaker



COAXIAL

Front speaker







ANT.

AUDIO OUT







(left)

(right)





Dolby Digital





To DIGITAL AUDIO OUT

decoder

To COAXIAL DIGITAL

(PCM/BITSTREAM)



AUDIO INPUT jack

COAXIAL jack

Surround

Surround

Subwoofer



speaker

speaker





(left)

(right)











[Fig. 7]

NOTES:

Be sure to turn off the power to all components in the system before connecting another component.

Refer to the Owner's Manuals for the components to be connected to the unit.

If connected to a Dolby Digital decoder, set DOLBY DIGITAL to ON for audio output in the setup mode. (See page 45 to set DOLBY DIGITAL to ON.)

Unless connected to a Dolby Digital decoder, set DOLBY DIGITAL to OFF for audio output in the setup mode. Playing a TV/VCR/DVD using incorrect settings may generate noise distortion and may also damage the speakers.

Manufactured under license from Dolby Laboratories. “Dolby” and the double-Dsymbol are trademarks of Dolby Laboratories.

- 14 -

EN

1C29

TV/VCR SECTION

SET UP FOR USE

SELECTING THE LANGUAGE

TV/VCR

1 Plug in the TV/VCR/DVD power cord

Plug the TV/VCR/DVD power cord into a standard AC outlet.

NOTE:

If any digits appear in the corner of the

screen, press the POWER button without unplugging the power cord.

Make sure ...

Press the SELECT button to select TV/VCR mode or make sure TV/VCR lights on.

Press the POWER button to turn on the unit. NOTE: This function effects only the language on the screen menu and not the audio source.

2 Select “LANGUAGE”

- TV/VCR SETUP -

Press the SETUP button on the

TIMER PROGRAMMING

CHANNEL SET UP



SETTING CLOCK

remote control.

USER’S SET UP

V-CHIPSET UP



B LANGUAGE [ENGLISH]

Press the Arrow button K orL to

CAPTION [OFF]

ZERO RETURN

point to “LANGUAGE”.

TIME SEARCH

INDEX SEARCH

3Select “ENGLISH”, “ESPAÑOL” or “FRANÇAIS”

Select “ENGLISH”, “ESPAÑOL”= Spanish or “FRANÇAIS”= French using the ENTER button.

4Exit the Language mode

Press the SETUP button on the remote control to return to TV mode.

NOTE: If for some reason the menu is in Spanish or French, press the SETUP button on the remote control, press the Arrow buttonK orL to point to “IDIOMA [ESPAÑOL]” or “LANGAGE [FRANÇAIS]”, then press the ENTER button, then press the SETUP button on the remote control.

CLOCK SET UP (AUTO / MANUAL)

TV/VCR

The TV/VCR/DVD clock must be VCR timer recording is possible. It the clock be set manually when first unit, then set to [ON] the auto clock periodically correct the setting if NOTE: If you cannot receive a signals, auto clock setting cannot be manual setting only.

MANUAL CLOCK SETTING

Make sure ...

The unit is turned on.

In the example below, the clock is to



DATE

May 6th, 2004

SETTING TIME

5:40PM







1 Select “SETTING CLOCK”

- TV/VCR SETUP -

Press the SETUP button on the

TIMER PROGRAMMING

remote control.



B SETTING CLOCK



USER’S SET UP





CHANNEL SET UP

Press the Arrow button K orL to

V-CHIPSET UP

CAPTION [OFF]





LANGUAGE [ENGLISH]

point to “SETTING CLOCK”.

ZERO RETURN

TIME SEARCH

INDEX SEARCH

Then press the ENTER button.



2 Select “MANUAL CLOCK SET”

Press the Arrow button K orL to point to “MANUAL CLOCK SET”.

Then press the ENTER button.

3 Select the month

Press the Arrow button K orL until your desired month appears. (Example: May05)

Then press the Arrow button B. (Or press the Arrow button{ to go back one step.)

4 Select the day

Press the Arrow button K orL until your desired day appears. (Example: 6th06)

Then press the Arrow button B.

- 15 -

EN

1C29

5 Select the year

– MANUAL CLOCK SET –

Press the Arrow button K orL

MONTH DAY

YEAR

until your desired year appears.

0 5

/ 0 6

THU 2 0 0 4

(Example: 2004)

HOUR

MINUTE

Then press the Arrow button B.

– –

: – –

– –







6 Select the hour

Press the Arrow button K orL until your desired hour appears. (Example: 5, PM)

Then press the Arrow button B.

7 Select the minute

Press the Arrow button K orL until the desired minute appears. (Example: 40)

8 Start the clock

Press the SETUP button on the remote control.

Although seconds are not displayed, they begin counting from 00 when you press the SETUP button on the remote control. Use this feature to clock with the correct time.

NOTE:

When unplugging the AC cord or if failure for more than 3 seconds, you reset the clock.

TO CHANGE CLOCK SETTING

If you want to change the clock,

1)Follow steps [1] to [2].

2)Select where you want to change button B.

3)Enter correct numbers using the or L.

4)Press the SETUP button on the start the clock.

PLEASE NOTE:

If there is no local PBS station in your cable system, select “AUTO press the ENTER button to turn Then you can manually adjust the

AUTOMATIC CLOCK SETTING

Make sure ...

The unit is turned on.

Confirm the unit is receiving a RF (Radio Frequency) signal from either an antenna or cable system connection using the ANT.

rear of the unit.

If the unit is connected directly to box or satellite box, the local PBS selected on the cable box itself be set to the output channel of the box or satellite box (usually

able to set up or correct the clock

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control.

Press the Arrow button K orL to select “SETTING CLOCK”. Press the ENTER button to enter “SETTING CLOCK” menu.

- TV/VCR SETUP -

TIMER PROGRAMMING

BSETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIPSET UP LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN TIME SEARCH INDEX SEARCH

3 Begin “AUTO CLOCK CH

Press the Arrow button L to select “AUTO CLOCK CH SEARCH”. Press the ENTER button.

The unit is now searching for the station which contain the auto clock set signal. The search for a signal may take up to 20 seconds per channel.

“_ _” appears at the lower left of the screen when the search has ended.

Auto Clock stationwrite down the number(s) that appear on the screen. These are the auto clock

station(s) in your area. See step [4] on page 17.

If no number(s) appear on the TV screen, there are no stations in your area which contain the Auto Clock signal. Auto Clock Setting is not possible. Please use Manual Clock Setting on page 15.

Press the SETUP button to exit the screen.

- 16 -

EN

1C29

NOTE: During Auto Clock CH Search, the picture may be distorted, this is normal.

4Enter the channel number that contains the Automatic Clock Setting Signal

Press the SETUP button on the remote control.

Press the Arrow button K orL to select “SETTING CLOCK”. Press the ENTER button to enter “SETTING CLOCK” menu. Press the Arrow buttonL to select “AUTO CLOCK CH”.

Press the ENTER button or the Arrow button { orB until you locate Auto Clock Set station num ber. See step [3] on page 16. Press the SETUP button to exit screen.

- TV/VCR SETUP -

TIMER PROGRAMMING

BSETTING CLOCK CHANNEL SET UP

USER’S SET UP V-CHIPSET UP

LANGUAGE [ENGLISH] CAPTION [OFF]

ZERO RETURN

TIME SEARCH INDEX SEARCH

5 Turn off the unit

Once the unit is turned off , it will and set the correct date and time.

DAYLIGHT-SAVINGTIME

TV/VCR

Select this feature and the unit’s clock automatically will advance one hour in April, then reverse one hour in October.

When Daylight-SavingTime is ON, the clock will change automatically as follows:

First Sunday of April : At 2 AM the clock immediately changes to 3 AM. Any timer programming you have set to occur between 2 AM and 3 AM will not record.

Last Sunday of October : At 2 AM the clock immediately changes to 1 AM.

Make sure ...

Press the POWER button to turn on the unit.

1 Select “SETTING CLOCK”

Press the SETUP

- TV/VCR SETUP -

TIMER PROGRAMMING

remote control

B SETTING CLOCK



USER’S SET UP





CHANNEL SET UP



Press the Arrow

V-CHIPSET UP



CAPTION [OFF]





LANGUAGE [ENGLISH]

point to “SETTING

ZERO RETURN



TIME SEARCH



Then press the

INDEX SEARCH













2 Set “D.S.T.”(Daylight-Saving





Press the Arrow button K orL to

– SETTING CLOCK –

point to “D.S.T.”.

AUTO CLOCK

[ON]

Then press the ENTER button until

AUTO CLOCK CH SEARCH

AUTO CLOCK CH

[ 02 ]

[ON] appears.

MANUAL CLOCK SET



B D.S.T.

[ON]





3 Exit theDaylight-SavingTime

Press the SETUP button on the return to TV mode.

TO CANCEL THE

TIME

Repeat steps [1] to [2], select [OFF]

ENTER button.

- 17 -

EN

1C29

CHANNEL SET UP

TV/VCR

You can program the tuner to scan all the channels you receive in your area.

NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just select the TV/VCR/DVD channel selector to the output channel of the cable box or satellite box (Ex CH3), then select the channel to be viewed on the Cable Box or Satellite Box.

Make sure ...

Press the POWER button to turn on the unit.

1 Select “CHANNEL SET UP”

Press the SETUP button remote control.

Press the Arrow button point to “CHANNEL Then press the ENTER

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK

BCHANNEL SET UP

USER’S SET UP

V-CHIPSET UP LANGUAGE [ENGLISH] CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

2 Begin auto ch programming

Press the Arrow button K orL to point to “AUTO CH PROGRAMMING”.

Then press the ENTER button. The tuner scans and memorizes all the active channels in your area.

– CHANNEL SET UP –

ADD / DELETE CH (CATV)

B AUTO CH PROGRAMMING

3 After scanning

The tuner stops on the lowest

When AUTO CH

where there is no TV signal input, NALS” will appear on the display pletion of the channel scanning.

The unit may recognize TV channels by the receiving

try auto ch programming again antenna connection.

DELETING (OR ADDING)

CHANNEL(S)

TV/VCR

The channels you no longer receive or seldom watch can be deleted from the memory. (Of course, you can add the deleted channel into the memory again.)

1 Select “CHANNEL SET UP”

Press the SETUP button on the

- TV/VCR SETUP -

TIMER PROGRAMMING

remote control.

SETTING CLOCK

USER’S SET UP



B CHANNEL SET UP

Press the Arrow button K orL to

V-CHIPSET UP

CAPTION [OFF]



LANGUAGE [ENGLISH]

point to “CHANNEL SET UP”.

ZERO RETURN

TIME SEARCH

Then press the ENTER button.

INDEX SEARCH







2 Select “ADD/DELETE CH”

– CHANNEL SET UP –

Press the Arrow button K orL to

B ADD / DELETE CH (CATV)

point to “ADD/DELETE CH”.

AUTO CH PROGRAMMING

Press the ENTER button.



3 Enter the desired channel

Press the Arrow button K orL until your desired channel number appears. (You can also use the number buttons or the CHANNEL buttonK orL to enter it) (Example: CH8)

You must precede single-digitwith a zero (Example: 02 ... 09).

When selecting cable channels than 99, press the +100 button last two digits. (Example: to first press the +100 button then

08

ADD / DELETE

4Delete (or add) it from (or

Press the ENTER button. The changes to light red. The channel is memory.

To delete another channel, repeat

If you press the ENTER button is memorized again.

Added channel: Light blue. Deleted channel: Light red.

5Exit the channel setup mode

Press the SETUP button on the remote control to return to TV mode.

NOTE: To confirm that channel(s) has been deleted or added, press the CHANNEL buttonK orL.

- 18 -

EN

1C29

TV OPERATION

WATCHING A TV PROGRAM

TV/VCR

1 Turn on the unit

Press the POWER button to turn on the unit.

2 Select the channel number

Press the CHANNEL button K orL to select your desired channel number or press the number on the remote control.

Note for using the Number button on the remote control:

¡You must precedesingle-digitchannel numbers with a zero (For example: 02, 03, 04 and so on).

¡When selecting cable channels which are higher than 99, press +100 first, then press the last two digits. (Example: to select channel 125, first press “+100” then press “2” and “5”).

Remember: If the unit is connected to a cable box or satellite box, the unit must be on CH3 or CH4, then the channel to be viewed must be selected on the cable box or satellite box.

3 Adjust sound

Press the VOLUME button K orL to adjust the volume.

VOLUME 20

C C C C C C C C C C C C

NOTES:

If you press the CHANNEL button DVD mode, you can change the TV

Even if you turn off the unit in the when you turn it on again, it will TV/VCR mode.

DEGAUSSING

Magnetism from nearby appliances might affect the color of the TV picture

If this happens, move this unit away ance. If the color is still not correct,

cord, then plug it in again 30 minutes later or so.

PICTURE CONTROL

TV/VCR

The TV/VCR/DVD’s picture controls – BRIGHT, CONTRAST, COLOR, TINT andSHARPNESS – are preset to factory specifications. Although they are usually the best, you may need to make some further adjustments for a more natural looking image.

NOTES:

Procedures must be followed within 5 seconds or the Picture Control mode will be cancelled.

When setting the Picture Control, the Game mode will be cancelled.

Make sure ...

The unit must be turned on.

1 Select “PICTURE CONTROL”

Press the PICTURE button on the remote control.

2 Select item you want to adjust

Press the Arrow button K orL until desired control is displayed.

BRIGHT

P P P P P P P C P P P P P P P+

3 Adjust the picture control

Press the Arrow button s orB to adjust to your desired level.



Arrow Button {

Arrow Button B







BRIGHT

to decrease

to increase

brightness

brightness









CONTRAST

to decrease

to increase

contrast

contrast









COLOR

to pale

to brilliant







TINT

to purple

to green







SHAPNESS

to soft

to clear







If there is a power failure of any kind, the TV/VCR/DVD will retain its memory for this feature.

- 19 -

EN

1C29

CLOSED CAPTION SYSTEM

TV/VCR

You can view specially labeled (cc) TV programs, movies, news and pre-recordedtapes with either a dialogue caption or text display.

CAPTION mode: By choosing the caption mode, you can watch dramas, movies and news while captioning the dialogues and the contents of news.

TEXT mode: By choosing the text mode, you can watch half screen text information if you want.1-2: You may get these captions or text information by selecting either “1” or “2”. Caption “2” is used, usually for a second language if available.

NOTE:

Not all programs are broadcast with closed captions. Your unit is designed to provide error free closed captions from high quality antenna, cable and VCR signals. Conversely, poor quality signals are likely to result in caption errors or no captions at all. Common signal conditions which may cause captions errors are listed below:

Automobile ignition noise

Electric motor brush noise

Weak snowy reception on TV screen

Multiplex signal reception displaying picture ghosts or airplane flutter.

Playback of poorly recorded or worn VCR tapes.

NOTE:

If the unit displays a black box on the TV screen, this means that the unit is set to the TEXT mode. To clear screen, select [CAPTION1], [CAPTION2] or [OFF].

Make sure ...

The unit must be turned on.

1 Select “CAPTION”

- TV/VCR SETUP -

Press the SETUP button on the

TIMER PROGRAMMING

CHANNEL SET UP



SETTING CLOCK

remote control.

USER’S SET UP

V-CHIPSET UP



LANGUAGE [ENGLISH]

Press the Arrow button K orL to

B CAPTION [OFF]

TIME SEARCH



ZERO RETURN

point to “CAPTION”.







2 Select your desired caption



Press the ENTER button until your

- TV/VCR SETUP -

desired caption menu appears.

TIMER PROGRAMMING

SETTING CLOCK



CHANNEL SET UP

([CAPTION1], [CAPTION2],

USER’S SET UP

LANGUAGE [ENGLISH]



V-CHIPSET UP

[TEXT1] or [TEXT2])

B CAPTION [CAPTION1]

ZERO RETURN



TIME SEARCH



INDEX SEARCH

3 Exit the caption setting mode

Press the SETUP button on the remote control to return to TV mode.

TO CANCEL THE CLOSED CAPTION SYSTEM

Repeat steps [1] to [2], select [OFF] using the ENTER button. Press the SETUP button on the remote control to return to TV mode.

WHEN THE CLOSED CAPTION MODE IS ON

The On-ScreenDisplay will disappear after 5 seconds.

MUTE button is is pressed

kind, the unit will

- 20 -

EN

1C29

V-CHIPSET UP

V-CHIPSET UP

Make sure ...

The unit is turned on.

1 Select“V-CHIPSET UP”

Press the SETUP button on the remote control.

Press the Arrow button K orL to select“V-CHIPSET UP”.

Then press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP USER’S SET UP

BV-CHIPSET UP LANGUAGE [ENGLISH]

CAPTION [OFF] ZERO RETURN TIME SEARCH

INDEX SEARCH

2 Enter Access code

Use the number buttons on the remote control to enter the access code.

For the first timeset-upor in the event the unit has lost power, enter the default code of the numbers: 0000.

3 Select “TV RATING”









V-CHIPSET UP –











Press the Arrow button K orL to

B TV RATING







MPAA RATING





select “TV RATING”.

CHANGE CODE













Then press the ENTER button.



















4 Blocking TV programs









Press the Arrow button K orL to

B TV–Y



[VIEW]



select “TV rating” that you wish to

TV–Y7(

)

[VIEW]



TV–PG(

)

[VIEW]





TV–G



[VIEW]



block.

TV–14(

)

[VIEW]



TV–MA(

)

[VIEW]



Press the ENTER button to set it [BLOCK].

When you select the rating category and set it [BLOCK], the higher rating will change to [BLOCK] automatically. Also, the lower rating will change to [VIEW] automatically.

When you change “TV-Y”to [VIEW], all ratings will change to [VIEW] automatically.

Selection

Rating Category Explanations

TV-Y

Appropriate for all children

TV-Y7

Appropriate for children seven and older

TV-G

General Audience

TV-PG

Parental Guidance suggested.

TV-14

Unsuitable for children under 14





TV-MA

Mature audience only









5 Exit theV-Chipsetting mode

Press the SETUP button on the remote control to exit the screen.

V-CHIPSET UP SUB RATINGS

When you select the ratings of TV-Y7,TV-PG,TV-14orTV-MAyou will have the option of selecting sub rating categories.

1 Select“V-CHIPSET UP”

- TV/VCR SETUP -

Press the SETUP button on the

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

remote control.

USER’S SET UP

LANGUAGE [ENGLISH]



B V-CHIPSET UP

Press the Arrow button K orL to

CAPTION [OFF]

TIME SEARCH



ZERO RETURN

select “V-CHIPSET UP”. Then

INDEX SEARCH







press the ENTER button.















2 Enter Access code







Use the number buttons on the







remote control to enter the access













code. (Default code is 0000.)















3 Select “TV RATING”







Press the Arrow button K orL to







select “TV RATING”.







Then press the ENTER button.







4Selecting “Sub-Ratings”

Press the Arrow button L orK to ing you wish to block. Then press twice.

When you select [TV-Y7]:

Press the Arrow button L orK to select “FV” (Fantasy Violence). Then press the ENTER button to select [BLOCK] or [VIEW].

When you select [TV-PG],[TV14] or[TV-MA]:

Press the Arrow button L orK to select “D”(Suggestive Dialog), “L”(Coarse Language),

“S”(Sexual Situation) or “V”(Violence) the ENTER button to select

Note: When you select[TV-MA],appear on the TV screen.

The sub-ratingswhich are set to [BLOCK] appears next to the rating category in the TV rating menu.

5Exit the V-Chipsetting mode

Press the SETUP button on the enter the setting and exit the screen.

- 21 -

EN

1C29

CHANGING V-CHIPBLOCKED PROGRAMMING

Note: To change the rating, the TV must be turned to a station that is not protected. If the (PROTECTED) appears on the screen, please change the channel to a station that is not protected.

1)Follow steps [1] and [2].

2)Press the Arrow button K orL to select "TV RATING". Then press the ENTER button. Select a TV rating to be unblocked by pressing the Arrow buttonK orL.

Then press the ENTER button to unblock the rating. 3)Press the SETUP button on the remote control to

exit the screen.

MPAA RATING SET UP

1 Select“V-CHIPSET UP”

- TV/VCR SETUP -

TIMER PROGRAMMING

Press the SETUP button on the

SETTING CLOCK

USER’S SET UP





CHANNEL SET UP

remote control.

B V-CHIPSET UP

LANGUAGE [ENGLISH]





CAPTION [OFF]

Press the Arrow button K orL to

ZERO RETURN

TIME SEARCH

select “V-CHIPSET UP”. Then

INDEX SEARCH







press the ENTER button.















2 Enter Access code

ACCESS CODE

Use the number buttons on the







remote control to enter the access







_ _ _ _















code.

















3 Select “MPAA RATING”







Press the Arrow button K orL to







point to “MPAA RATING”.







Then press the ENTER button.















4 Select your desired item







Press the Arrow button K orL to







point to your desired item.







Then press the ENTER button to







select [BLOCK] or [VIEW].

















Selection

Rating Category







G

General Audience







PG

Parental Guidance







PG-13

Unsuitable for children







RRestricted; under 17 nying parent or adult

NC-17No one under 17

XMature audience only

When you select the rating category and set it [BLOCK], the higher rating will change to [BLOCK] automatically. Also, the lower rating will change to [VIEW] automatically.

When you change “G” to [VIEW], all ratings will change to [VIEW] automatically.

5 Exit theV-Chipsetting mode

Press the SETUP button on the remote control to exit the screen.

CHANGE ACCESS CODE

To change access code, follow the steps below.

1 Select“V-CHIPSET UP”

Press the SETUP button on the remote control. Press the Arrow button K orL to select“V-CHIPSET UP”.

Then press the ENTER button.

2 Enter Access code

ACCESS CODE



























UP –

TV RATING

Press the Arrow button K orL toMPAA RATING

B CHANGE CODE

select "CHANGE CODE". Then press the ENTER button.

4 Enter New code

Use the number buttons to enter your desired access code in the NEW CODE space. Then enter the same code in the CONFIRM CODE will space. V-CHIPSET UP screen appear on the screen.

If you enter wrong code, repeat sure you enter the same new code confirm code space.

5 Exit theV-Chipsetting mode

Press the SETUP button on the exit the screen.

Note: If you unplug the power cord ure occurs, the changed access code will return to default (0000).

code again as necessary.

- 22 -

EN

1C29

MTS(Multi-ChannelTelevision sound)SYSTEM

You can record or listen to a program in MTS stereo.

CHECKING THE SELECTED MTS MODE

When you play a VHS tape, or receive a broadcast on the unit tuner channel you are watching, the status shown below will appear when you press the DISPLAY button

4)





PLAY B



12:00AM







HIFI





CH 123

3)







































STEREO/SAP





2)









































1)







SP

COUNT 0:00:00















SAP



Second Audio Program, which means your





program, can also be received in a second





language or sometimes a radio station.







HIFI



High Fidelity which produces better sound





than standard stereo TV/VCR/DVDs.























TV/VCR

1)When a program is broadcast in stereo, STEREO appears on the TV screen.

2)When a program is broadcast in second audio, SAP appears on the TV screen.

3)When a program broadcast both in stereo and second audio, STEREO and SAP appear on the TV

screen.

NOTE: Although a program may be broadcast in both stereo and second audio, you cannot record in both stereo and second audio at the same time.

4)While the unit is set in HIFI stereo mode and playback mode. HIFI appears on the TV screen. While the unit is set in monaural(MONO) mode, HIFI disappears from the TV screen.

NOTE: If you playnon-HIFItapes while the unit is set in HIFI, HIFI will disappear from the TV screen and the unit will play automatically in monaural.

MTS RECORDING/MONITOR MODE















TV/VCR

































Type of broadcast

Display on

STEREO/SAP

Hi-Fiaudiotrack(2-channel)

Normal audio



the TV screen

SELECTION

L-channel

R-channel



track

















Regular

-None-

-Invalid-

Mono

Mono





Mono

(monaural audio)































Stereo broadcast

STEREO

-Invalid-

L

R





L+R

















Bilingual broadcast

SAP

STEREO*

Main audio

Main audio



Main audio







program

program



program





















SAP*

Sub audio

Sub audio



Sub audio







program

program



program

Stereo & Bilingual

STEREO

STEREO*

L

R





L+R

broadcast

SAP

SAP*

sub audio

sub audio



sub audio







program

program



program

















*You must select the recording mode in TV AUDIO [STEREO] or [SAP] when you record a broadcast.

- 23 -

EN

1C29

SELECTING THE MTS SYSTEM

Make sure ...

The unit must be turned on.

TO SELECT HIFI MODE

1 Select “USER’S SET UP”

Press the SETUP button on the

- TV/VCR SETUP -

TIMER PROGRAMMING

remote control.

SETTING CLOCK



B USER’S SET UP





CHANNEL SET UP



Press the Arrow button K orL to

V-CHIPSET UP



CAPTION [OFF]





LANGUAGE [ENGLISH]

point to “USER’S SET UP”. Then

ZERO RETURN



TIME SEARCH



press the ENTER button.

INDEX SEARCH











2 Select“VCR AUDIO”

– USER’S SET UP –

Press the Arrow button K orL to

RENTAL

[OFF]

point to“VCR AUDIO”.

AUTO RETURN

[OFF]



REPEAT PLAY

[OFF]



B VCR AUDIO

[HIFI]



TV AUDIO

[STEREO]





3 Select [HIFI]

– USER’S SET UP –

Press the ENTER button until

RENTAL

[OFF]

[HIFI] appears.

AUTO RETURN

[OFF]



REPEAT PLAY

[OFF]



B VCR AUDIO

[HIFI]



TV AUDIO

[STEREO]

4 To return to TV mode

Press the SETUP button on the remote return to TV mode.

NOTES:

Normally “HIFI” should be selected with HIFI sound.

When you play non-HIFItapes, automatically in the monaural mode

The unit records automatically MTS HIFI stereo sound unless you select recording before you begin recording

TV/VCR

TO SELECT MONO MODE

You can change the selection to “MONO” if you want to listen to HIFI tapes in normal audio playback.

1)Press the SETUP button on the remote control. Press the Arrow button K orL to point to “USER’S SET UP”. Then press the ENTER button.

2)Press the Arrow button K orL to point to

“VCR AUDIO”.

3)Press the ENTER button until [MONO] appears.

4)Press the SETUP button on the remote control to return to TV mode.

RENTAL

[OFF]

REPEAT PLAY

[OFF]

AUTO RETURN

[OFF]

VCR AUDIO

[HIFI]

B TV AUDIO

[STEREO]

3 Select [STEREO], [SAP], or [MONO]

Press the ENTER button until [STEREO], [SAP], or [MONO] appears.

4 To return to TV mode

Press the SETUP button on the remote control to return to TV mode.

NOTES:

You must select the recording mode,either TV AUDIO [STEREO] or [SAP] when you record a broadcast.

Refer to “MTS RECORDING/MONITOR MODE”.

If you select second audio when second audio is not available, the TV/VCR/DVD will record normal audio.

The unit records automatically MTS broadcasts in HIFI stereo sound unless you select SAP mode recording before you begin recording.

- 24 -

EN

1C29

VIDEO CASSETTE

This TV/VCR/DVD will operate with any cassette that has the mark. For best results, we recommend the use ofhigh-qualitytapes. Do not use poor quality or damaged tapes.

PRECAUTIONS

Avoid moisture. Moisture condensation may occur on the tape if it is moved from a cold place to a warm place or visa versa. Before using a tape with these conditions, to avoid damage of the tape and your unit, wait until the tape has warmed to room temperature and the moisture has evaporated.

Avoid extreme heat, high humidity and magnetic fields.

Do not tamper with the cassette mechanism.

Do not touch the tape with your fingers.

INSERTING A CASSETTE

Insert the cassette in the direction as shown. Push in gently, but continuously, on the center-backof the cassette until it is drawn into the unit. The unit will automatically turn on.

Window

CORRECT

WRONG

TWO DIFFERENT TAPE SPEEDS

Before recording, select the tape speed from : SP mode (Standard Play) orSLP mode (Super Long Play).

The table below shows the maximum recording/playback time using T60, T120 or T160 tapes in each mode.

Tape Speed

Recording/Playback Time













Type of tape

T60

T120

T160











SP mode

1 hour

2 hours

2-2/3hours











SLP mode

3 hours

6 hours

8 hours











Note: You can play back a tape recorded in LP mode (Long Play).

REMOVING A CASSETTE

1)In the Stop mode, press the STOP/EJECT button on the unit. The cassette will eject.

2)Pull the cassette out of the cassette compartment. 3)Store the cassette in its case as shown.

ERASE PREVENTION

You can prevent accidental erasing of recording by breaking off the tab on the back edge of the cassette.

If you decide to record on the tape again, cover the hole with plastic tape.

NOTE:

Tab

Plastic Tape

In DVD mode, Whether the cassette is with tab or without tab you insert, it doesn’t start playing until you press the PLAY button.

In TV/VCR mode, if the cassette without tab is inserted, playback will automatically start.

- 25 -

EN

1C29

Press the STOP button when playback is completed.
NOTES:
If you press the PLAY button (of the TV/VCR side) in the DVD mode, you can start the VCR playback.
If you press the SELECT button during the VCR playback, it will stop and the mode will change to the DVD mode. In addition, the same function operates with the DVD side PLAY button or the OPEN/CLOSE button.
TRACKING ADJUSTMENT
TV/VCR
Tracking adjustment will be set automatically (Digital Tracking function) when you start playback.
However when playing pre-recorded tapes or tapes recorded on other VCR, noise lines (black and white streaks) may appear on the playback picture. If this occurs, you can adjust the tracking control manually by pressing the CHANNEL button K or L until the streaks disappear. To return to the DTR function, stop the tape once and start playback again.
You can reduce the noise lines by pressing the CHANNEL button K or L in slow mode too. Tracking adjustment in Slow mode will not be set automatically.
TV/VCR

PLAYBACK

NORMAL PLAYBACK

Make sure ...

The unit must be turned on.

1 Insert a prerecorded tape

If the erase-protectiontab has been will start playback automatically.

2

To begin playback

B



Press the PLAY button.

3 To stop playback

STOP

























SLOW MOTION

TV/VCR

Press the PAUSE button, then press the F.FWD g button to start the playback in slow motion. The unit mutes the sound during slow motion. Press the PLAY button to return to normal playback.

NOTE: If it is left in the Slow mode for more than 5 minutes, the unit will automatically go into the Stop mode.

during playback. Only tapes recorded in the SLP mode will show the least amount of lines. Press the PLAY button to return to playback.

NOTES:

You can advance the picture one frame at a time by pressing the PAUSE button during the Still mode.

If it is left in the Pause mode for more than 5 minutes, the unit will automatically switch to the Stop mode.

VERTICAL HOLD CONTROL

TV/VCR

In the Pause/Still mode only, when the picture begins to vibrate vertically, stabilize the picture by pressing the CHANNEL button K orL.

NOTE:

If there are video noise lines on the screen, see Tracking Adjustment section.

- 26 -

EN

1C29

SPECIAL PLAYBACK

Make sure ...

The unit must be turned on.

Insert a prerecorded tape.

RENTAL PLAYBACK

This function enables you to improve quality when playing back worn rented tapes.

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K orL to point to “USER’S SET UP”. Then press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK

CHANNEL SET UP

BUSER’S SET UP V-CHIPSET UP LANGUAGE [ENGLISH] CAPTION [OFF]

ZERO RETURN

TIME SEARCH INDEX SEARCH

2 Set “RENTAL” to [ON]

– USER’S SET UP –

Press the Arrow button K orL to

B RENTAL

[ON]

point to “RENTAL”.

AUTO RETURN

[OFF]



REPEAT PLAY

[OFF]

Press the ENTER button until [ON]

VCR AUDIO

[HIFI]

TV AUDIO

[STEREO]

appears.

3 Exit the Rental setting

Press the SETUP button on the remote control to return to the TV mode.

4 Start playback

Press the PLAY button to start playback. “RENTAL PLAY B” appears.

Once you select the Rental mode, it stays in effect even after you turn off the unit.

TO CANCEL THE RENTAL MODE

Repeat steps [1] to [2], select [OFF] using the ENTER button on the remote control. Press the SETUP button on the remote control to return to TV mode.

If there is a power failure of any kind, the tv/vcr/dvd will retain its memory for this feature.

AUTO REPEAT PLAYBACK

TV/VCR

The unit has the auto repeat function that allows you to repeat a tape indefinitely without touching the PLAY button.

ALL REPEAT: Repeat playback from the beginning to the end of the tape.

BLANK REPEAT: Repeat playback from the beginning to a blank part, which is blank for more than 10 seconds.

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

B USER’S SET UP

V-CHIPSET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

2 Select “ALL” or “BLANK”

Press the Arrow button K orL to point to “REPEAT PLAY”.

Press the ENTER button repeatedly until your desired selection [ALL] or [BLANK] appears.

– USER’S SET UP –

RENTAL

[OFF]

B REPEAT PLAY

[ALL]

AUTO RETURN

[OFF]

VCR AUDIO

[HIFI]

TV AUDIO

[STEREO]

3 Exit the Repeat Play setting

Press the SETUP button on the remote control to return to the TV mode.

4 Start playback

Press the PLAY button to start the Repeat Play. “REPEAT PLAY B” appears.

Once you select the Repeat Play mode, it stays in effect even after you turn off the unit.

If the Rental mode is set [ON], the “RENTAL PLAY B” display has priority.

TO CANCEL THE REPEAT PLAY MODE

Repeat steps [1] to [2], select [OFF] using the ENTER button on the remote control. Press the SETUP button on the remote control to return to TV mode.

If there is a power failure of any kind, the unit will retain its memory for this feature.

- 27 -

EN

1C29

- TV/VCR
TIMER
SETTING CLOCK
CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH]
CAPTION [OFF]
B ZERO RETURN TIME SEARCH INDEX SEARCH

SEARCH

Make sure ...

The unit must be turned on.

Insert a tape.

ZERO RETURN

This function allows you to search easily that you want to review by rewinding or

NOTE:

Zero Return WILL NOT work on a blank portion of a tape.

1Stop a tape at your desired

Rewind or fast forward the tape to point at which you want to review.

2Reset the counter to 0:00:00

Press the C.RESET button repeatedly

3Begin recording or playback

Press the RECORD or PLAY button Press the STOP button when recording completed.

4To activate “ZERO RETURN”

Press the SETUP button on the remote control.

Press the Arrow button K orL to point to “ZERO RETURN”. Then press the ENTER button.

The counter will appear on the TV screen.

The tape will automatically stop when the counter returns to 0:00:00.

PICTURE SEARCH

TV/VCR

This feature is very useful in finding or skipping over a particular scene on a tape. In this mode, the sound will be muted. 1)You may view a video tape at a high speed in either a forward

or reverse direction by pressing the F.FWD g or REWh button during playback. (in the SP / LP / SLP modes)

NOTE:

If you press the F.FWDg or REWh button on the front panel in the DVD mode, the VCR forward or reverse will start. Please press the STOP / EJECT button once to stop it, twice to eject it.

2)Press it again and the unit will now search in super high speed. (in the LP / SLP modes only)

NOTE:

Tapes recorded in the SP or LP mode will display a noise bar on the TV screen and the picture may revert to Black and White. This is normal.

3)Press the PLAY button to return to normal speed.

TIME SEARCH

TV/VCR

The Time Search function makes it possible to quickly advance the tape to your desired position simply by entering the exact amount of playback time you want to skip.

NOTES:

Time Search can be set up to a maximum of 9 hours 50 minutes (9:50) by 10 minutes at a time.

This function will not operate in recording mode.

This function is not operative when a cassette tape is not inserted in the unit.

In the example below: To watch a program before/ after 2 hour 50 minutes from the present position, in either direction.

1Insert a tape

2Select “TIME SEARCH” mode

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

USER’S SET UP

V-CHIPSET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

B TIME SEARCH

INDEX SEARCH

TIME SEARCH

2 : 50

your desired time appears. (Example: “2:50” stands for 2 hours 50 minutes)

If you wish to cancel the Time

Search at this point, press the SETUP button on the remote control.

4 Begin Time Search

By pressing the Arrow button s orB, the unit will rewind or fast forward to the specified point.

The time counts down as the searching progresses. When 0:00 is reached, the tape will start playback automatically.

TO CANCEL THE TIME SEARCH at this point

Press the STOP/EJECT button on the unit or the STOP button on the remote control. This will delete the selected time.

- 28 -

EN

1C29

INDEX SEARCH

TV/VCR

This feature provides a method of indexing the starting point so that it can be easily returned to in either fast forward or rewind mode.

The index mark will be made automatically when the RECORD button is pressed. It will also be marked at the starting point of Timer recording and OTR.

The index mark will not be recorded if the PAUSE button is pressed and released during recording.

The time gap between making the index marks on the tape should be greater than 1 minute for SP recording, 2 minutes for LP recording and 3 minutes for SLP recording.

In some cases, the index mark at the beginning of video tape cannot be detected.

Example: You are watching program number 4 and want to fast forward to program number 7. You must skip three programs.



CURRENT PLAYBACK PROGRAM

Beginning of tape







End of tape



Pro.1

Pro.2

Pro.3

Pro.4

Pro.5

Pro.6 Pro.7

4

3

2

1

1

2

3

INDEX MARK









1 Select “INDEX SEARCH”

Press the SETUP button on the

- TV/VCR SETUP -

SETTING CLOCK



TIMER PROGRAMMING

remote control.

CHANNEL SET UP

USER’S SET UP

Press the Arrow button K orL to

V-CHIPSET UP

CAPTION [OFF]



LANGUAGE [ENGLISH]

point to “INDEX SEARCH”. Then

ZERO RETURN



press the ENTER button.







2 Enter your desired number



Press the Arrow button K orL until

INDEX SEARCH

the number of programs that you

0 3



want to skip appears.



(Example: “03” for 3 programs)



The Index Search mode will be

canceled if the procedures are not activated in 30 seconds.

3 Begin Index Search

Press the Arrow button s orB. The unit begins rewinding or fast forwarding to the beginning of desired program.

NOTE: Every time an index signal is skipped, the number in the program indicator decreases by one.

4 After Index Search

When the preset program is reached, the unit will start playback automatically.

A video cassette must be inserted in the unit for this function to work.

The number of Index Searches can be set up to 20.

This function will not operate in the recording mode.

When you want to cancel the Index Search while in progress, press the STOP button.

SPECIAL FEATURES

REAL TIME TAPE COUNTER

TV/VCR

This shows the elapsed recording or playback time in hours, minutes, and seconds. (The displayed time will not change on a blank tape or blank portions on the tape.)The “–”indication will appear when the tape has rewound further than “0:00:00” on the tape counter.

AUTO REWIND-EJECT

TV/VCR

When the end of a tape is reached during recording, playback, or fast-forward,the tape will automatically rewind to the beginning. After rewinding finishes, the unit will eject the tape and turn itself off.

This function is operative when Repeat Play is set to the [OFF] position.

The tape will not auto-rewindduring timer recording or One Touch Recording.

- 29 -

EN

1C29

RECORDING

Make sure ...

The unit must be turned on.

Insert a cassette tape with its erase prevention tab in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.)

NOTES:

This unit will ONLY record and view the same channel.

This unit cannot record the contents from the built-inDVD.

NORMAL RECORDING

You can ONLY watch the same TV being recorded.

1 Select the channel to be recorded

Press the number buttons on the remote control or the CHANNEL button K orL.

Remember: If the unit is connected to a cable box or satellite box, the unit must be on CH3 or CH4, then the channel to be recorded must be cable box or satellite box.

2 Select the tape speed

Press the SPEED button to select the desired tape speed (SP/ SLP).

SP

3 Begin recording

REC

Press the RECORD button.

SP

4 Stop recording

Press the STOP button when recording is completed.

SKIPPING UNWANTED

SCENES DURING RECORDING

TV/VCR

PAUSE

SP

Screen Display will appear for 5 appear.

- 30 -

EN

1C29

OTR (One Touch Recording)

TV/VCR

This function enables you to set a recording length simply by pressing the REC/OTR button on the unit.

Make sure ...

The unit must be turned on.

Insert a cassette tape with its erase prevention tab in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.)

NOTES:

You cannot start OTR with the remote control.

Recording starts immediately when the REC/OTR button is pressed.

When the REC/OTR button is pressed 18 times, the unit returns to the Normal Recording mode.

To stop the OTR operation, press the STOP button on the unit or on the remote control.

To show the remaining time, press the DISPLAY button on the remote control so that “OTR” appears on the TV screen. (It will show up momentarily then disappear.)

Recording stops when 0:00 is reached.

Please note that in the SLP mode ing time, assuming the tape is started ning, is 8 hours usingT-160(or 6

If the tape runs out before the end will switch to the Stop mode

the tape and turns itself off.

If you press the POWER button TV/VCR/DVD continues recording ed length is reached.

1 Select the channel to be recorded

Press the number buttons on the remote the CHANNEL button K orL.Remember: If the unit is connected satellite box, the unit must be on CH3 the channel to be recorded is selected box or satellite box.

2 Select the tape speed

Press the SPEED button to select the speed (SP/ SLP).

3 Begin OTR

Press the REC/OTR button on the unit as many times as needed. The recording length will be determined by the number of times you press the REC/OTR button. Each additional push will increase the recording time by 30 minutes. It is set up to 8 hours.

OTR(2 : 30)

SP

Push(es)

Display



Recording length

1 push



(normal recording)

2 pushes

0:30



30 minutes









3 pushes

1:00



60 minutes

















17 pushes

8:00



480 minutes









COPYING A VIDEO CASSETTE (Requires a VCR or camcorder)

TV/VCR

You can make copies of video tapes made by friends or relatives for your enjoyment.

You can not copy a DVD to a videotape.

WARNING: Unauthorized recordings of copyrighted video tapes may be an infringement of copyright laws.

Connect your TV/VCR/DVD and a Source (Playing) VCR using the following diagram.

[The TV/VCR/DVD]

[Fig.8]



[Ex: Source (playing)

Audio/Video

VCR or camcorder]

AUDIO

adapter cable

L

OUT IN

(not supplied)

R

VIDEO





OUT IN

1)Insert a pre-recordedvideo cassette into the Source (Playing) VCR or camcorder.

2)Insert a blank video cassette or one you want to record over, into the unit’s cassette compartment.

3)Press the SPEED button on remote control for the TV/VCR/DVD to select the desired recording speed (SP/SLP).

4)Press the CHANNEL button K orL on the unit until “AUX” appears on the screen.

5)Press the RECORD button on the unit.

6)Begin playback of the tape in the source (Playing) VCR or camcorder.

during copying, use the whenever possible. The

affect the source (Playing)

.

press the STOP/EJECT button on the unit, then stop the tape on the source VCR or camcorder.

- 31 -

EN

1C29

TIMER

AUTOMATIC TIMER

RECORDING

TV/VCR

You may set the unit to start and end a recording while you are away. You can set 8 programs to record on specific days, daily or weekly within a 1 year period.

In the example below, the timer is being set to record:

DATE: July 4th, 2004 SETTING TIME: from 7:30PM to 8:50PM CHANNEL: CH61

TAPE SPEED: SP

Make sure ...

If a cable box or satellite box is connected with the unit you will be limited to record only one channel, and the channel selector on the unit must be selected to the output channel of the boxes CH 3 or CH 4 and then the actual channel to be recorded must be selected on the boxes.

Clock must be set to the correct time and date before setting the timer.

The unit must be turn on to program it.

Insert a cassette tape with its erase prevention tab in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.)

The channel you want to record is properly set in advance. (See page 18.)

Avoid over lap of programs ...

There is a chance that a program will not be recorded, when programs overlap;

The program with an earlier start has priority.

Once the earliest program finishes, the overlapping programs will begin recording in sequence.

The illustration below demonstrates the sequence of recordings.

Program 1 10:00AM - 11:00AM Program 2 9:00AM - 10:00AM Program 3 9:30AM - 12:00PM

Recording Sequence

Program 1 10:00AM-11:00AMProgram 29:00AM-10:00AMProgram 39:30AM-12:00PM

9:00AM

10:00AM

11:00AM

12:00PM

*Recording period is SHADED

1 Select “TIMER PROGRAMMING”

Press the SETUP button on the remote control.

Confirm “TIMER PROGRAMMING” is pointed by pressing the Arrow button K, then press the ENTER button.

If you have not yet set the clock, CLOCK SET” appears. If so, [8] on pages 15, 16. Then set the

- TV/VCR SETUP -

BTIMER PROGRAMMING SETTING CLOCK

CHANNEL SET UP USER’S SET UP

V-CHIPSET UP LANGUAGE [ENGLISH] CAPTION [OFF]

ZERO RETURN TIME SEARCH

INDEX SEARCH

2 Select your desired program

– TIMER PROGRAMMING –

position (1~8)

CH DATE

BEGIN END



Press the Arrow button K orL to

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

select the desired program position.

B - -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -



- -

-/-- - - -

-:--

-:-- - -

Then press the Arrow button B.

- -

-/-- - - -

-:--

-:-- - -









3 Set the channel number

Press the Arrow button K orL until the desired channel number appears. (Example: CH61)

Then press the Arrow button B.Remember: If the TV/VCR/DVD is connected to a cable box or must be on CH3 or CH4, then the recorded is selected on the cable

– TIMER PROGRAMMING –

CH

DATE

BEGIN

END

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

B 61

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

4 Select once, every day or

For once recording :

Press the Arrow button K (up)

– TIMER PROGRAMMING –

until the desired date appears.

CH DATE

BEGIN END

- -

-/-- - - -

-:--

-:-- - -

(Example: “7/04” for July 4th).

- -

-/-- - - -

-:--

-:-- - -

B 61

7/04 SUN

-:--

-:-- - -



- -

-/-- - - -

-:--

-:-- - -

Then press the Arrow button B.

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

:- - -

-:-- - -



- -

-/-- - - -

-:--

-:-- - -

For every day recording : To record a TV program at the same

channel every day. (Example: Monday Sunday)

Press the Arrow button L (down) until “EVRY DAY” appears. Then press the Arrow buttonB.

For weekly recording : To record a the same time on the same channel (Example: every Monday)

Press the Arrow button L (down) until “EVRY” and your desired day of the week appear together. Then press the Arrow buttonB.

- 32 -

– TIMER PROGRAMMING –

CH

DATE

BEGIN

END

- -

-/--

- - - -:--

-:-- - -

- -

-/--

- - - -:--

-:-- - -

- -

-/--

- - - -:--

-:-- - -

B 61 EVRY MON -:--

-:-- - -

- - -/--

- - - -:--

-:-- - -

- -

-/--

- - - -:--

-:-- - -

- -

-/--

- - - -:--

-:-- - -

- -

-/--

- - - -:--

-:-- - -

EN

1C29

5 Set beginning hour

– TIMER PROGRAMMING –

Press the Arrow button K orL until

CH DATE

BEGIN END

the desired hour appears.

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -



- -

-/-- - - -

-:--

-:-- - -

(Example: “ 7, PM” for 7:30PM)

B 61

7/04 SUN

7:12PM

-:-- - -

- -

-/

:

-:





- -

-/-- - - -

-:--

-:-- - -

Then press the Arrow button B.

- -

-/-- - - -

-:--

-:-- - -



















6 Set beginning minute

– TIMER PROGRAMMING –

Press the Arrow button K orL until

CH DATE

BEGIN END

- -

-/-- - - -

-:--

-:-- - -

the desired minute appears.

- -

-/-- - - -

-:--

-:-- - -

B 61

7/04 SUN

7:30PM -:-- - -



- -

-/-- - - -

-:--

-:-- - -

(Example: “30” for 7:30PM)

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

Then press the Arrow button B.

- -

-/-- - - -

-:--

-:-- - -













7 Set end hour

– TIMER PROGRAMMING –

Press the Arrow button K orL until

CH DATE

BEGIN END

the desired hour appears.

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

(Example: “8, PM” for 8:50PM)

B 61

7/04 SUN

7:30PM 8:30PM- -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

Then press the Arrow button B.

- -

-/-- - - -

-:--

-:-- - -













8 Set end minute

– TIMER PROGRAMMING –

CH

DATE

BEGIN

END

Press the Arrow button K orL

- -

-/-- - - -

-:--

-:-- - -

until the desired minute appears.

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

B 61

7/04 SUN 7:30PM

8:50PM- -

(Example: “50” for 8:50PM)

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -

Then press the Arrow button B.













9 Set the tape speed

– TIMER PROGRAMMING –

Press the Arrow button K orL

CH

DATE

BEGIN

END

until the desired tape speed

- -

-/-- - - -

-:--

-:-- - -

- -

-/-- - - -

-:--

-:-- - -



- -

-/-- - - -

-:--

-:-- - -

appears. (Example: SP)

B 61

7/04 SUN

7:30PM 8:50PMSP

- -

-/-- - - -

-:--

-:-- - -



- -

-/-- - - -

-:--

-:-- - -



- -

-/-- - - -

-:--

-:-- - -



- -

-/-- - - -

-:--

-:-- - -

10 Finish setting the program

Press the ENTER or RETURN button. The program is now completed.

To set another program, repeat steps [2] to [10].

Press the SETUP button on the remote control to return to original mode.

11 Set the timer

Press the POWER button to set automatic timer recording. The RECORDING indicator lights up.

You must turn off the unit to activate automatic timer recording.

If power is not turned off and you continue watching TV, “TIMER REC STANDBY” starts flashing on the TV screen 2 minutes before the programmed start time.

1)Press the POWER button. 2)Repeat step [1] on page 32.

3)Press the RECORD button and select the desired program using the Arrow button K orL.

4)Press the RECORD button again.

Each additional push will shift forward the begin/end time for recording by 10 minutes. When the recording is already in progress, each additional push will shift forward the end time only. If you want to cancel while setting, press the PAUSE button on the remote control. The recording time returns to the original time.

NOTE: When you shift forward the time schedule during recording, the recording speed will automatically be set to the SLP mode.

5)Press the ENTER or RETURN button to exit the setting menu. Then press the SETUP button on the remote control to return to original mode.

TO CORRECT A PROGRAM

While setting a program; press the Arrow button s to go back one step and enter the correct numbers using the Arrow button K or L.

After setting a program;

1)Press the POWER button. 2)Repeat steps [1] to [2] on page 32.

3)Press the Arrow button B (or press the Arrow buttons to go back one step) until the part you want to correct begins flashing, then make the changes pressing the Arrow buttonK orL.

4)Press the POWER button to set automatic timer recording.

TO CANCEL AN AUTOMATIC TIMER RECORDING

After setting a program;

1)Press the POWER button.

2)Repeat steps [1] to [2] on page 32 and select a program you want to cancel.

3)Press the C.RESET button.

4)Press the SETUP button on the remote control to return to TV mode.

While recording is in progress;

1)Press the POWER button.

2)Press the STOP/EJECT button on the unit.

- 33 -

EN



1C29

TO CHECK THE BEGIN/END TIME

1)Press the POWER button so that the Recording indicator goes off.

2)Press the SETUP button on the remote control. 3)Confirm “TIMER PROGRAMMING” is pointed. 4)Press the ENTER button. The details of programs

appear on the TV screen.

5)Press the SETUP button on the remote control to return to TV mode.

HINTS FOR AUTOMATIC TIMER RECORDING

TV/VCR

Make sure the channel you want to record is properly set in advance.

It is not necessary to press the RECORD button for timer recording.

Recording begins automatically at

The display will not be turned on grammed recording begins. To recorded TV program or to play a the POWER button to turn on the the SELECT button to choose the or the DVD mode.

The erase-preventiontab on the place (or you must put tape over

If the erase-preventiontab is removed, be ejected when the POWER button

If the tape runs out before the end will switch to the Stop mode tape will be ejected.

AUTO RETURN

With this feature, after timer recording the beginning of the recorded program(s) searched for automatically.

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K orL to point to “USER’S SET UP”. Then press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

BUSER’S SET UP V-CHIPSET UP

LANGUAGE [ENGLISH] CAPTION [OFF]

ZERO RETURN

TIME SEARCH INDEX SEARCH

2 Set “AUTO RETURN” to [ON]

– USER’S SET UP –

Press the Arrow button K orL to





point to “AUTO RETURN”.

REPEAT PLAY

[OFF]



RENTAL

[OFF]

Press the ENTER button until [ON]

B AUTO RETURN

[ON]

VCR AUDIO

[HIFI]

TV AUDIO

[STEREO]

appears.





3 Auto Return will begin

When all the timer recordings are completed, the unit will rewind to the beginning of the recorded program(s).

NOTE:

If you press the POWER button while tape is rewinding, the Auto Return will stop.

4 Watch the recorded program

Press the PLAY button.

TO CANCEL THE AUTO RETURN MODE

Repeat steps [1] to [2], select [OFF] using the ENTER button.

If there is a power failure of any kind, the unit will retain its memory for this feature.

SLEEP TIMER

TV/VCR

The Sleep Timer function turns off the unit without using the POWER button after a desired period of time.

NOTE:

This function does not operate during Recording mode.

1 Select “SLEEP TIMER”

Press the SLEEP button on the remote control until “SLEEP TIMER” appears.

2 Set sleep time

Press the SLEEP button until your desired sleep time appears.

Each additional push will increase

the time by 30 minutes up to 120

SLEEP 120 MINUTES

minutes.

After 5 seconds, exit the Sleep Timer

TO CANCEL THE SLEEP

Press the SLEEP button on the remote “SLEEP TIMER” appears. Press the until “SLEEP 0 MINUTES” appears

- 34 -

EN

1C29

ON SCREEN DISPLAY

To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows:

When the Closed Caption mode is OFF:

Counter mode: After 5 seconds, only the counter remains. To clear it, press the DISPLAY button.

Clock mode: After 5 seconds, only the clock and the channel number remain. To clear them, press the DISPLAY button.

When the Closed Caption mode is ON:

The On Screen Display disappear after 5 seconds.

This is true even if the MUTE button is pressed or the PAUSE button is pressed while recording.

OFF mode Counter mode

Clock mode

OFF mode

STOP

STOP

5:40PM

PM





CH2







SP COUNT 0:12:34

SP





After 5 seconds

After 5 seconds







5:40PM







CH2



COUNT 0:12:34







Counter

Clock & Channel



remains

remains





CABLE CHANNEL DESIGNATIONS

If you subscribe to cable TV, the channels are displayed as 1-125.Cable companies often designate channels with letters orletter-numbercombinations. Please check with your local cable company. The following is a chart of common cable channel designations.

CATV channel

5A

2

3

4

5

6

7

8

9

10

11

12

13

A

B



TV Display

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15





































CATV channel

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q



TV Display

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30





































CATV channel

R

S

T

U

V

W

W+1

W+2

W+3

W+4

W+5

W+6

W+7

W+8

W+9



TV Display

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45



CATV channel

W+10

W+11

W+12

W+13

W+14

W+15

W+16

W+17

W+18

W+19

W+20

W+21

W+22

W+23

W+24



TV Display

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60





































CATV channel

W+25

W+26

W+27

W+28

W+29

W+30

W+31

W+32

W+33

W+34

W+35

W+36

W+37

W+38

W+39



TV Display

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75



CATV channel

W+40

W+41

W+42

W+43

W+44

W+45

W+46

W+47

W+48

W+49

W+50

W+51

W+52

W+53

W+54



TV Display

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90





































CATV channel

W+55

W+56

W+57

W+58

A-5

A-4

A-3

A-2

A-1

W+59

W+60

W+61

W+62

W+63

W+64



TV Display

91

92

93

94

95

96

97

98

99

100

101

102

103

104

105





































CATV channel

W+65

W+66

W+67

W+68

W+69

W+70

W+71

W+72

W+73

W+74

W+75

W+76

W+77

W+78

W+79



TV Display

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120



CATV channel

W+80

W+81

W+82

W+83

W+84























TV Display

121

122

123

124

125







































































- 35 -















EN

1C29

DVD SECTION

ABOUT THE DISCS

PLAYABLE DISCS



DISC TYPES







The following discs can be played back on this TV/VCR/DVD.

¡DVD video

¡DVD-R/RW*

¡DVD+R/RW*

¡Audio CD

¡CD-R/RW*

¡MP3*

*Depending on the types or the writing method of the medium some discs can not be played.

Some DVD-R/RW,DVD+R/RW orCD-R/RWdiscs made on personal computers or on DVD recorders may not be played back properly due to the factors such as scratches, dirt or special properties of the disc.

Discs made on personal computers may not be played back properly due to the different environment or the settings of the application you use. We recommend always to use the standardized, rightly formatted discs. (Please contact the sales agency for more detail).

This unit conforms to the NTSC color system. You cannot play discs recorded in other color systems such as PAL or SECAM.

¡Some discs include region codes as shown below.

¡The number inside the symbol refers to a region of the world and a disc encoded in a specific region format can only be played back on this unit with the same region code.

The following discs cannot be played back on this unit.

¡DVD with region codes other than 1 or ALL.

¡DVD-ROM

¡DVD-RAM(Never play back, otherwise malfunction may result.)

¡CD-ROM

¡VSD

¡CDV (Only plays back the audio part.)

¡CD-G(Only plays back the sound.)

¡CD-I(Never play back, otherwise malfunction may result.)

¡SACD

¡Photo CD (Never play back, otherwise malfunction may result.)

¡Video CD (Never play back, otherwise malfunction may result.)

¡DTS-CD

Any other discs without compatibility indications.

[DVD]

Data on a DVD is divided into sections called "titles" and then into subsections called "chapters", each of which is given a title or chapter number. Playback conditions are preset on some DVD video discs and these playback conditions take priority over user operations on this TV/VCR/DVD. If a function you selected does not run as desired, refer to the manual accompanying the disc.

Example





Title 1

Title 2

Chapter 1



Chapter 2



Chapter 3



Chapter 4

Chapter 1



Chapter 2

















































[AUDIO CD]

Data on an audio CD is divided into sections called “tracks”, each of which is given a track number.

Example

Track 1



Track 2



Track 3



Track 4



Track 5



Track 6























































[MP3]

Data on an MP3 is divided into sections called "groups", and then into subsections called "tracks", each of which is given a group or track number.

Example





Group 1

Group 2

Track 1



Track 2



Track 3



Track 4

Track 5



Track 6

















































– 36 –

EN

01A11

PLAYING A DISC

BASIC PLAYBACK



GENERAL FEATURES







DVD-VCDMP3

Getting started

¡Turn on the power of amplifier and any other components, if necessary.

1Press the POWER button.

¡The power will turn on.

2Press the OPEN/CLOSE button to open disc loading tray.

3Place the chosen disc in the tray, with the label facing up.

DVD-V

DVD may contain menus to navigate the disc and access special features. Press the appropriate number buttons or use the Arrow button (K/L/s /B) to highlight your selection in the DVD main menu and press the ENTER button to confirm.

NOTES

¡Select DVD mode by pressing the SELECT button on the remote control. Then operate the DVD functions.

¡Unless stated, all operations described are based on remote control use. Some operations can be carried out using the menu bar on the TV screen.

4 Press the PLAY button.

¡The tray will close automatically and playback will then start from the first chapter or track of the disc. If the playback does not start automatically, press the PLAY button.

¡When you playback a DVD which features a title menu, it may appear on the screen. In this case, refer to “TITLE MENU”.

5 Press the STOP button to stop playback.

DISC MENU

DVD-V

1Press the DISC MENU button.

¡The DVD main menu will appear.

2If the feature is not available, symbol may appear on the TV screen.

3If disc menu is available on the disc, audio language, subtitle options, chapters for the title and other options will appear for selection.

4Press the Arrow button (K/L/s /B) to select an item and the ENTER button to confirm selection.

NOTES

¡When the DVD mode has been switched to the TV/VCR mode, the DVD mode shuts down first and then the TV picture and sound appears in about 4 seconds. Similarly, when the POWER button is pressed to turn off in the DVD mode, this mode shuts down first and then the power is turned off.

¡A “prohibited icon” may appear at thetop-righton the TV screen dur-

ing operation, warning that a prohibited operation has been encountered by the DVD or the disc.

¡With DVDs that use titles for playback program signals, playback may start from the second title or it may skip these titles.

¡During the playback of a two layered disc, pictures may stop for a moment. This happens when the 1st layer switches to the 2nd layer. This is not a malfunction.

TITLE MENU

DVD-V

1Press the TITLE button.

¡The title menu will appear.

2If the feature is not available, symbol may appear on the TV screen.

3Press the Arrow button (K/L/s /B) to select an item and the ENTER button to confirm selection.

CALLING UP A MENU SCREEN

DURING PLAYBACK

¡Press the DISC MENU button to call up the DVD menu.¡Press the TITLE button to call up the title menu.

NOTE

¡Contents of menus and corresponding menu operations may vary between discs. Refer to the manual accompanying the disc for details.

– 37 –

EN

01A11

RESUME

DVD-VCDMP3

1During playback, press the STOP button.

¡Resume message will appear on the TV screen.

2Press the PLAY button, playback will resume

from the point at which playback was stopped.

¡To cancel resume, press the STOP button twice.¡If TV/VCR/DVD is turned off, resume function will

be cancelled.

¡For MP3, playback will resume from the beginning of the track at which playback was stopped.

PAUSE

DVD-VCDMP3

1During playback, press the PAUSE button.

¡Playback will pause and sound will be muted.

2To continue playback, press the PLAY button.

STEP BY STEP PLAYBACK

DVD-V

1During playback, press the PAUSE button.

¡Playback will pause and sound will be muted.

2The disc goes forward by one frame each time the PAUSE button is pressed.

3To exit step by step playback, press the PLAY button.

FAST FORWARD/REVERSE

SEARCH

DVD-VCDMP3

1 During playback, press and hold the SKIP (h /g) button for a few seconds.

¡g 1” or “h 1” appears on the screen.

2 To select another speed, repeat step [1] until your required speed appears on the screen.

¡For DVDs, fast forward/reverse search speed is different depending on the disc. Approximate speed is 1(×2), 2(×8), 3(×50) and 4(×100).

¡For audio CDs, approximate speed is×16.¡For MP3, approximate speed is×8¡When you use buttons on the unit, use the

SKIP G/ SEARCHg or SKIPH/ SEARCHh button.

3To return to normal playback, press the PLAY button.

SLOW FORWARD /

SLOW REVERSE

DVD-V

1During playback, press the PAUSE button.

2Press and hold the SKIP (h /g)button

for a few seconds.

¡1” or “1” appears on the screen.

3To select another speed, repeat step [2] until your required speed appears on the screen.

¡Slow forward or reverse speed varies with the disc. Approximate speed is 1(1/16), 2(1/8) and 3(1/2).

¡When you use buttons on the unit, use the

SKIP G/ SEARCHg or SKIPH/ SEARCHh button.

4To return to normal playback, press the PLAY button.

– 38 –

EN

01A11

SEARCH FUNCTION

TRACK SEARCH



TIME SEARCH























CD

MP3

DVD-V

CD























There are three ways to begin playback on an Audio CD and MP3 at a specific track.

Using the Number buttons on the remote control

1Press the Number buttons to enter the desired Track number.

¡Playback will start at the selected track.

¡For single digit tracks(1-9),press a single number (eg. track 3, press 3).

¡To play track 26, press +10, 2, 6.

Using the SEARCH MODE button

1Press the SEARCH MODE button.

¡The track search display appears.

2Within 30 seconds, select a desired track number using the Number buttons on the remote control.

¡For single digits press 0 first, if the total track of the disc is more than 10 tracks.

¡Playback will start at the selected track.

Using the SKIP H G buttons

During playback, press the SKIP G button to move the next track. Press it repeatedly to skip subsequent tracks. Press the SKIPH button to go back to beginning of the current track. Press it repeatedly to go to the previous tracks.

¡If the SKIP button is pressed while the playback is paused, the playback will be paused again after skipping to the next track.

NOTE

¡The SKIPH G buttons are not available when playback is stopped.

TITLE / CHAPTER SEARCH

DVD-V

1Press the SEARCH MODE button once for the Chapter search, twice for the Title search during playback.

_/2

2Enter the desired chapter/title number using the Number buttons on the remote control.

¡Playback will start at the selected chapter or title.¡Press the CLEAR button to erase the incorrect input.¡For single digits press 0 first, if the total chapter or

title of the disc is more than 10.

1During playback, press the SEARCH MODE button three times (CD: twice) to display the Time Search on the TV screen.

2Within 30 seconds, enter a desired disc time using the Number buttons on the

remote control.

¡Playback will start at the specified time.

¡Press the CLEAR button to erase the incorrect input.¡When there is no need to enter a number, “0” appears automatically. For example, “ 0 : 0- :- -appears in the Time Search display if the total time

of the track or title is less than 10 minutes.

MARKER SETUP SCREEN

DVD-VCD

Use markers to memorize your favorite places on a disc.

1Press the SEARCH MODE button four times (CD: three times) during playback.

¡The display screen and Markers will appear on the TV screen.

2 Press the Arrow button (s /B) to select 1, 2,

3, 4, 5, 6, 7, 8, 9, or 10 and ensure that “- - -

- :- - :- -appears in the display.

3When you reach the desired point, press the ENTER button.

¡The Title or Track and elapsed playing time will appear in the TV screen.

4To return to the Marker later, press the SEARCH MODE button four times (CD: three times) during playback and the Arrow button (s /B) to choose the desired marker, then press the ENTER button.

NOTES

¡Opening the disc tray or turning off the power or selecting AC at step [2] and pressing the ENTER button will erase all Markers.

¡To clear a marker, using the Arrow button (s /B), position the cursor on to the marker number to be cleared and press the CLEAR button.

¡You can mark up to 10 points.

5Press the SEARCH MODE or RETURN button to exit.

– 39 –

EN

01A11

SPECIAL PLAYBACK FUNCTION

REPEAT



PROGRAM







REPEAT is available only during playback.

REPEAT TITLE / CHAPTER

DVD-V

To activate the repeat function, press the REPEAT button during playback.

¡The repeat mode changes as described below every time you press the button.

CHAPTER

TITLE

OFF

(current chapterrepeat)

(current titlerepeat)

(repeat off)

NOTES





CD

You may determine the order in which tracks will play.

1

In stop mode, press the MODE button.

¡The PROGRAM screen will appear.



2

Press the Arrow button orto select a



track, then press the





ENTER button.

TOTAL

¡Press the CLEAR button to



erase the most recently entered



program.



¡Repeat Title/Chapter is not available with some scenes.

¡The REPEAT setting will be cleared when moving to other title or chapter.

REPEAT TRACK

CD

To activate the repeat function, press the REPEAT button during playback.

¡The repeat mode changes as described below every time you press the button.

TRACK

ALL

OFF

(current trackrepeat)

(entire discrepeat)

(repeat off)

NOTES





¡Repeat setting will be cleared when moving to other track.

¡Repeat playback does not function during repeatA-Bplayback.

3Repeat step [2] until you have selected all the tracks you want to play in the program.

4Press the PLAY button to play the programmed tracks.

NOTES

¡While the program is being played back, the STOP works as follows.

¡Press the STOP button once and then the PLAY button again, playback will restart from the point where the STOP button was pressed. (Program continued)

¡Press the STOP button twice and then the PLAY button again, playback will restart from the track in the usual way.

¡Up to 99 programs can be entered.

¡To erase all tracks in the program at once, select ALL CLEAR at the bottom of the list at step [2].

¡If you like to repeat the current track in the program, press the REPEAT button repeatedly until “TRACK” appears during playback. If you like to repeat the entire program press the REPEAT button repeatedly until “ALL” appears during playback.

REPEAT A-B

DVD-VCD

1Press the REPEAT A-Bbutton at your chosen starting point.

¡A- appears briefly on the TV screen.

2Press the REPEAT A-Bbutton again at your chosen end point.

¡A-Bappears briefly on the TV screen and the repeat sequence begins.

3To exit the sequence, press the REPEAT A-

B button.

NOTES

¡The repeatA-Bsection can only be set within the current title (for DVDs) or current track (for audio CDs).

¡RepeatA-Bis not available with some scenes in DVD.¡To cancel the A point which was set, press the

CLEAR button.

¡RepeatA-Bplayback does not function during title, chapter, track or all repeat playback.

RANDOM PLAYBACK

CD

This shuffles the playing order of tracks instead of playback in the sequence.

1 In stop mode, press the MODE button twice.

¡RANDOM screen appears.

RANDOM

CD-DA

TOTAL 0:45:55

RANDOM PROGRAM - - no indication - -

PLAY

2 Press the PLAY button to start random playback.

NOTE

¡If you like to repeat the current track in the random selection, press the REPEAT button repeatedly until “TRACK” appears during playback. If you like to repeat the entire random selection press the REPEAT button repeatedly until “ALL” appears during playback.

– 40 –

EN

01A11

folder name 1
folder name 2 folder name 3 folder name 4 file name 1 file name 2 file name 3
folder name 1

PLAYING A MP3 DISC

MP3 PLAYBACK



PROGRAM





















MP3



MP3

























When a CD with MP3 files is in the unit, press the DISC MENU button to call up the MP3 menu on the TV screen.

1In stop mode, press the Arrow button (K/L) to select the desired group or track.

¡If a group is selected, press

the Arrow button B or the

ENTER button to go on to the track selection screen. Press

the Arrow button (K/L) to

choose a track, then press the ENTER button.

¡If a track is selected, press the ENTER button to start playing tracks. Starting from the one you’ve just chosen the subsequent tracks will be played.

¡Press the TITLE button to return to the first item.

2 Press the STOP button to stop playback.

NOTES

¡Folders are known as Groups; files are known as Tracks.

¡MP3 files are accompanied by3 icon.¡Maximum of 255 folders can be recognized.¡Maximum of 512 files can be recognized.¡Up to 8 hierarchies can be created.

This unit recommends the use of files recorded at the below specifications:

¡Sampling frequency: 44.1kHz or 48kHz¡Constant bit rate: 112kbps ~ 320kbps.

This feature allows you to program an MP3 disc to play in a desired sequence.

1In stop mode, press the MODE button.

¡The PROGRAM screen will appear.

2Select a desired track using the Arrow button (K/L/s/B). Then press the ENTER

button.

¡Press the Arrow buttonB when you want to go to the next hierarchy.

¡Press the Arrow buttons when you want to go back to the previous hierarchy.

¡Press the CLEAR button to erase the most recently entered program.

3Repeat step [2] until you have selected all the Tracks you want to play in the program.

4Press the PLAY button to start programmed playback.

NOTES

¡While the program is being played back, the STOP button as follows.

¡Press the STOP button once and then the PLAY button again, playback will restart from the point where the STOP button was pressed. (Program continued)

¡Press the STOP button twice and then the PLAY button again, playback will restart from the track in the usual way.

¡To erase all tracks in the program at once, select ALL CLEAR at the bottom of the list at step [2].

REPEAT

MP3

REPEAT is available only during playback.

To activate the repeat function, press the

REPEAT button during playback.

¡The repeat mode changes as described below every time you press the button.

TRACK

GROUP



ALL





OFF







(current track

(current group

(entire disc

(repeat off)

repeat)

repeat)

repeat)





































NOTE

¡Repeat setting will be cleared when moving to other track.

RANDOM PLAYBACK

MP3

1In stop mode, press the MODE button twice.

¡RANDOM screen appears.

2Press the PLAY button to start random playback.

– 41 –

EN

01A11

CHANGING THE SETTINGS

SUBTITLE LANGUAGE



CAMERA ANGLE















DVD-V

DVD-V













The TV/VCR/DVD allows you to select a language for subtitles during DVD disc (if available) playback.

1Press the SUBTITLE button during playback.

2Press the SUBTITLE button repeatedly to select your desired subtitle language.

¡The subtitle language will appear on the display bar at the top of the TV screen.

3To turn off subtitles, press the SUBTITLE button repeatedly until OFF appears.

NOTES

¡Some discs allow audio language setting/subtitle language setting on the disc menu. (Operation varies between discs, so refer to the manual accompanying the disc.)

¡If the desired language is not shown after pressing the SUBTITLE button several times, the disc does not have subtitles in that language.

¡If you choose a Language that has a 3 letter language code, the code will be displayed every time you change the Subtitle language setting. If you choose any other languages,‘---’will be displayed instead. (Refer to page 44.)

AUDIO LANGUAGE

DVD-V

The TV/VCR/DVD allows you to select a language during DVD disc (if multi languages are available) playback.

1Press the AUDIO button during playback.

2Press the AUDIO button repeatedly to select

your desired language.

NOTE

¡Pressing the AUDIO button may not work on some DVDs with multiple audio languages (e.g. DVDs which allow audio language setting on the disc menu).

STEREO SOUND MODE

CD

1Press the AUDIO button repeatedly during playback to select between STEREO, L-CHorR-CH.

¡STEREO - both right and left channels are active (stereo)L-CH- only left channel is active

R-CH- only right channel is active

NOTE

¡If the Virtual Surround setting is ON, the sound mode will be fixed to STEREO and can not be changed.

Some DVD discs contain scenes which have been shot simultaneously from various angles. You can change the camera angle when the ( ) icon appears on the screen.

1Press the ANGLE button during playback.

¡The selected angle will be displayed on the display bar at the top of the screen.

2Press the ANGLE button repeatedly to select your desired angle.

BLACK LEVEL SETTING

DVD-V

Adjust the Black Level Settings to make the black parts of the picture brighter.

1 Press the MODE button during playback.

OFF

2Press the ENTER button to switch OFF.

ON: Makes the dark parts brighter.

OFF: Shows the original picture as recorded.

3Press the MODE button twice or the

RETURN button to exit.

NOTE

¡The setting will be saved even if the unit is turned off.

VIRTUAL SURROUND

DVD-VCDMP3

You can enjoy surround-soundeffect over two speakers on this TV/VCR/DVD.

1Press the V.SURR button once or the MODE button twice (CD/MP3: once) during playback.

OFF

2Press the ENTER button to set it 1 (Natural effect) or 2 (Emphasized effect) or OFF.

3Press the V. SURR or RETURN button to exit.

NOTE (for CD play only)

¡Virtual Surround will not be effective if the sound mode is set to something other than STEREO.

– 42 –

EN

01A11

THE ON-SCREENINFORMATION

DVD-VCDMP3

You can check the information about the current disc by pressing the DISPLAY button on the remote control.

For DVD-Vs

1 Press the DISPLAY button during playback to show current Chapter.

¡The elapsed and remaining



playing time of the current

9/49 0:00:00 -0:03:30

chapter will be displayed.



2 Press the DISPLAY button again to show current Title.

¡The elapsed and remaining playing time of the current title will be displayed.

3 Press the DISPLAY button again.

¡The BIT RATE and the current repeat setting will be displayed.

¡If you are playing a dual layered disc, the layer number will also be displayed (L0: Layer 0 is playing. L1: Layer 1 is playing).

4Press the DISPLAY button again to exit the display.

For audio CDs

1 Press the DISPLAY button during playback to show the current Track.

¡The elapsed and remaining playing time of the current track will be displayed.

2 Press the DISPLAY button again to show current Total Track.

¡The elapsed and remaining playing time of the current track will be displayed.

3Press the DISPLAY button again to exit the display.

For MP3

1Press the DISPLAY button during playback.

¡The name of the file currently in play will be displayed.

2Press the DISPLAY button again to show the track number, the elapsed time, the repeat status and the playback status at the top of the screen.

¡will be displayed when repeat play has been selected.

T - indicates Track repeat

G - indicates Group (folder) repeat

A - indicates Disc repeat

3Press the DISPLAY button again to exit the display.

– 43 –

EN

01A11

CHANGING THE DVD SETUP ITEMS

LANGUAGE SETTING

DVD-V

Language options are not available with some discs.

1Press the SETUP button twice in STOP mode so that the DVD SETUP menu appears.

¡If the menu does not appear, press the PLAY button, the STOP button, then the SETUP button twice.

SETUP

QUICK

CUSTOM

INITIALIZE

2Press the Arrow button L to select CUS-

TOM, then press the ENTER button.

¡CUSTOM mode will appear.

3Press the Arrow button (K/L) to select

“LANGUAGE”, then press the ENTER button to confirm.

SETUP CUSTOM

LANGUAGE

DISPLAY

AUDIO

PARENTAL

4Press the Arrow button (K/L) to select the next items, then press the ENTER button.

AUDIO: Sets the audio language.SUBTITLE: Sets the subtitle language.

DISC MENU: Sets the language for DVD menu.

5Press the Arrow button (K/L) to select a setting, then press the ENTER button.

¡If OTHER is selected on the AUDIO, SUBTITLE or DISC MENU screen, pressfour-digitnumber to enter the code for the desired language. (Refer to the language code list.)

¡Only the languages supported by the disc can be selected.

6 Press the SETUP button to exit.

NOTE

¡Language Setting for Audio and Subtitle is not available with some discs. Then use the AUDIO and the SUBTITLE buttons. (Details are on page 42.)

TO CHANGE THE ON-SCREENMENUS

You can access the TV/VCR SETUP menu by pressing the SETUP button from the DVD mode. Refer to “SELECTING THE LANGUAGE” on page 15 to changing the on-screenmenus.

Language

Code

Language

Code

A-B



L-N



Abkhazian

4748

Laothian

5861

Afar

4747

Latin

5847

Afrikaans

4752

Latvian;Lettish

5868

Albanian

6563

Lingala

5860

Amharic

4759

Lithuanian

5866

Arabic

4764

Macedonian

5957

Armenian

5471

Malagasy

5953

Assamese

4765

Malay

5965

Aymara

4771

Malayalam

5958

Azerbaijani

4772

Maltese

5966

Bashkir

4847

Maori

5955

Basque

5167

Marathi

5964

Bengali;Bangla

4860

Moldavian

5961

Bhutani

5072

Mongolian

5960

Bihari

4854

Nauru

6047

Bislama

4855

Nepali

6051

Breton

4864

Norwegian [NOR]

6061

Bulgarian

4853

O-R



Burmese

5971

Occitan

6149

Byelorussian

4851

Oriya

6164

C-E



Oromo(Afan)

6159

Cambodian

5759

Panjabi

6247

Catalan

4947

Pashto;Pushto

6265

Chinese [CHI]

7254

Persian

5247

Corsican

4961

Polish

6258

Croatian

5464

Portuguese [POR]

6266

Czech

4965

Quechua

6367

Danish [DAN]

5047

Rhaeto-Romance

6459

Dutch [DUT]

6058

Romanian [RUM]

6461

English [ENG]

5160

Russian [RUS]

6467

Esperanto

5161

S



Estonian

5166

Samoan

6559

F-H



Sangho

6553

Faroese

5261

Sanskrit

6547

Fiji

5256

Scots Gaelic

5350

Finnish [FIN]

5255

Serbian

6564

French [FRE]

5264

Serbo-Croatian

6554

Frisian

5271

Sesotho

6566

Galician

5358

Setswana

6660

Georgian

5747

Shona

6560

German [GER]

5051

Sindhi

6550

Greek [GRE]

5158

Singhalese

6555

Greenlandic

5758

Siswat

6565

Guarani

5360

Slovak

6557

Gujarati

5367

Slovenian

6558

Hausa

5447

Somali

6561

Hebrew

5569

Spanish [SPA]

5165

Hindi

5455

Sundanese

6567

Hungarian [HUN]

5467

Swahili

6569

I-K



Swedish [SWE]

6568

Icelandic [ICE]

5565

T



Indonesian

5560

Tagalog

6658

Interlingua

5547

Tajik

6653

Interlingue

5551

Tamil

6647

Inupiak

5557

Tatar

6666

Irish [IRI]

5347

Telugu

6651

Italian [ITA]

5566

Thai

6654

Japanese [JPN]

5647

Tibetan

4861

Javanese

5669

Tigrinya

6655

Kannada

5760

Tonga

6661

Kashmiri

5765

Tsonga

6665

Kazakh

5757

Turkish [TUR]

6664

Kinyarwanda

6469

Turkmen

6657

Kirghiz

5771

Twi

6669

Kirundi

6460

U-Z



Korean [KOR]

5761

Ukrainian

6757

Kurdish

5767

Urdu

6764





Uzbek

6772





Vietnamese

6855





Volapuk

6861





Welsh

4971





Wolof

6961





Xhosa

7054





Yiddish

5655





Yoruba

7161





Zulu

7267









If you choose a Language that has a 3 letter language code, the code will be displayed every time you change the Audio or Subtitle language setting on page 42. If you choose any other languages, ‘---’will be displayed instead. (3 letter language code is written in bracket.)

– 44 –

EN

01A11

DISPLAY SETTING



AUDIO SETTINGS













DVD-V



DVD-V















You can change certain aspects of the DVD display screens and on-screenmessages on the TV screen.

1Press the SETUP button twice in STOP mode so that the DVD SETUP menu appears.

¡If the menu does not appear, press the PLAY button, the STOP button, then the SETUP button twice.

SETUP

QUICK

CUSTOM

INITIALIZE

2Press the Arrow button L to select CUS-

TOM, then press the ENTER button.

¡CUSTOM mode will appear.

3Press the Arrow button (K/L) to select “DIS-

PLAY”, then press the ENTER button to confirm.

SETUP CUSTOM

LANGUAGE

DISPLAY

AUDIO

PARENTAL

4Press the Arrow button (K/L) to select the below items, then press the ENTER button.

TV MODE: QUICK

¡Press the Arrow button (K/L) for an item selection, then press the ENTER button.

¡Select 4:3 LETTER BOX for black bars to appear on top and bottom of the screen.

¡Select 4:3 PAN & SCAN for a full height picture with both sides trimmed.

¡The default setting is 4:3 LETTER BOX.

STILL MODE:

¡Press the Arrow button (K/L) for an item selection, then press the ENTER button.

¡Select “AUTO” usually.

¡If you select “FIELD”, the picture in the still mode will be stabilized.

¡If you select “FRAME”, the picture in the still mode will be highly defined.

ANGLE ICON:

¡Press the ENTER button repeatedly to turn Angle icon ON or OFF.

¡The default setting is ON.

AUTO POWER OFF:

¡Press the ENTER button repeatedly to turn Auto Power off ON or OFF.

¡The default setting is ON and the screen saver program starts when there is no input from the TV/VCR/DVD for 5 minutes in the stop mode. When the screen saver program is activated for 15 minutes, the power automatically turns off.

Choose the appropriate Audio settings for your equipment as it only affects during the playback of DVD discs.

1Press the SETUP button twice in STOP mode so that the DVD SETUP menu appears.

¡If the menu does not appear, press the PLAY button, the STOP button, then the SETUP button twice.

SETUP

QUICK

CUSTOM

INITIALIZE

2 Press the Arrow buttonL to select “CUS-

TOM”, then press the ENTER button.

¡CUSTOM mode will appear.

3Press the Arrow button (K/L) to select

“AUDIO”, then press the ENTER button to confirm.

SETUP CUSTOM

LANGUAGE

DISPLAY

AUDIO

PARENTAL

4Press the Arrow button (K/L) to select the below items, then press the ENTER buttons.

DRC (Dynamic Range Control):

¡To compress the range of soft to loud sound.¡The default setting is ON.

DOWN SAMPLING:

¡Set to ON when outputting in 48 kHz.¡The default setting is ON.

When playing disc with copyright Protection

¡If you select OFF, copyright protection will be activated and sound will be down sampled at 48kHz.

DOLBY DIGITAL: QUICK

Set to On when the unit is connected to a Dolby Digital Decoder.

(ON: Output a Dolby Digital signal)

(OFF: Convert the Dolby Digital to PCM (2 channel stereo))

¡The default setting is ON.

5 Press the SETUP button to exit.

5 Press the SETUP button to exit.

– 45 –

EN

01A11

PARENTAL CONTROL

DVD-V

Parental Control limits the disc viewing that exceed your settings (with a password or playback will stop). This feature allows you to prevent discs with alternative scenes from being played by your children.

PARENTAL LEVEL

Parental Level allows you to set the rating level of your DVD discs. Playback will stop if the disc’s ratings exceed the level you set.

1Press the SETUP button twice in STOP mode so that the QUICK SETUP menu appears.

¡If the menu does not appear, press the PLAY button, the STOP button, then the SETUP button twice.

2Press the Arrow button L to select “CUS-

TOM”, then press the ENTER button.

SETUP

QUICK

CUSTOM

INITIALIZE

3Press the Arrow button (K/L) to select

“PARENTAL”, then press the ENTER button.

SETUP CUSTOM

LANGUAGE

DISPLAY

AUDIO

PARENTAL

4Enter your four-digitpassword then press the ENTER button.

5Press the Arrow button (K/L) to select

“PARENTAL LEVEL”, then press the ENTER button.

6Press the Arrow button (K/L) to select the desired level, then press the ENTER button.

7Press the SETUP button to exit

NOTES

¡When doing this for the first time, enter any 4 digits. (except for 4737) That number will be used as the password.(in the event you forget the password, see below)

¡To change the password, press the Arrow button (K/L) to select CHANGE at step [5], then press the ENTER button. Enter thefour-digitpassword, then press the ENTER button.

¡With some DVDs, it may be difficult to find if they are compatible with parental lock. Be sure to check if the parental lock function operates in the way that you have set.

¡Record the password in case you forget it.

CONTROL LEVELS

¡ALL

All parental lock is cancelled.

¡Level 8

DVD software of any grade (adult/general/children) can be played back.

¡Levels 7 to 2

Only DVD software intended for general use and children can be played back.

¡Level 1

Only DVD software intended for children can be played back, with those intended for adult and general use is prohibited.

IF YOU FORGET THE PASSWORD

1 Press the number buttons 4, 7, 3, 7 at step [4]. Then enter your new password.

¡Password will be cleared and parental level will be set to ALL.

2 Proceed the steps [5] to [7] again.

INITIALIZE

This allows you to return all selections of SETUP (except for PARENTAL) to their default settings.

1Press the SETUP button twice in STOP mode so that the INITIALIZE menu appears.

2Press the Arrow button (K/L) to select “INI-

TIALIZE”, then press the ENTER button.

3Select “YES”, then press the ENTER button twice. All the settings (except for “PARENTAL”) will be cleared.

¡To cancel the initialization, select “NO”.

4 Press the SETUP button to exit.

– 46 –

EN

01A11

TROUBLESHOOTING GUIDE

If the TV/VCR/DVD does not perform properly when operated as instructed in this Owner’s Manual, check the TV/VCR/DVD, consulting the following checklist.

PROBLEM

CORRECTIVE ACTION

No power

Make sure the power plug is connected to an AC outlet.



Make sure the power is turned on.

The TV/VCR/DVD does not

Check if the power plug is connected to an AC outlet.

respond to the remote control

Check the batteries in the remote control.



Aim the remote control directly at the remote sensor. If necessary,



remove all the obstacles between the sensor and the remote.



You have to be within 23 feet of the TV/VCR/DVD.



Check if the correct mode is selected. If not switch the mode by



pressing the SELECT button on the remote control,whichever you need.

TV/VCR Mode

Sometimes a performance problem can be easily solved by checking seemingly apparent but often overlooked possibilities. Before arranging for service, check these items. It could save your time and money.

PROBLEM

CORRECTIVE ACTION



No picture and sound

Make sure the AC cord is connected to an AC outlet.





Check antenna connection.





Press the SELECT button on the remote control to select TV mode.



Then try other TV feature.





Let the TV/VCR/DVD program its tuner memory.



No picture or poor picture on

Adjust direction or replace antenna.



TV/VCR/DVD

Adjust picture controls.



No sound or poor sound

Adjust volume control on remote control or main unit.





Press the MUTE button to restore sound.



Bars On Screen

If outside antenna is being used, check for broken wire.





Check for local interference.



Picture Distorted or Blurred

Try a new channel, if OK, then possible station trouble.





If outside antenna is being used, check for broken wire.



Picture Rolls Vertically

Try a new channel, if OK, then possible station trouble.



Lines or Streaks in Picture

If outside antenna is being used, check for broken wire.





Check for local interference.



No Color

Try a new channel, if OK, then possible station trouble.





Is antenna connected to terminal on the back of the set?





If outside antenna is being used, check for broken wire.





Adjust COLOR control.



Poor Reception on Some Channels

Try a new channel, if OK, then possible station trouble.



Ghosts in Picture

Is antenna connected to terminal on the back of the set?





If outside antenna is being used, check for broken wire.





Check for local interference.



Weak Picture

Try a new channel, if OK, then possible station trouble.





Is antenna connected to terminal on the back of the set?





If outside antenna is being used, check for broken wire.





Adjust CONTRAST & BRIGHT control.



Sound OK, Picture Poor

Try a new channel, if OK, then possible station trouble.





Is antenna connected to terminal on the back of the set?





If outside antenna is being used, check for broken wire.





Check for local interference.





Adjust CONTRAST & BRIGHT control.





– 47 –

EN

01A11

PROBLEM

CORRECTIVE ACTION

Picture OK, Sound Poor

Try a new channel, if OK, then possible station trouble.



Check for local interference.

Timer recording is not possible

Make sure the timer recording is set correctly.



Make sure the power is off.



Make sure the unit clock is set correctly.

Cannot go into Record mode

Make sure the tape has anerase-preventiontab. If need, cover the



hole with plastic tape.

Playback picture is partially noisy

Adjust tracking control for a better picture using the CHANNEL



buttonK orL on the unit.

No picture but the audio is OK in

Head cleaning may be necessary. Refer to “AUTO HEAD

playback

CLEANING” on page 50.

No operation by infrared Remote

Make sure the AC cord is connected to an AC outlet.

Control

Check batteries in remote control.

Video or color fades in and out

You can not copy a copyrighted video tape. You are experiencing

when making a copy of a video tape

copy guard protection.

Different color marks on screen

Magnetism from nearby appliances and geomagnetism might affect



the color of the TV picture. Move the unit away from the appliances,



the unit can repair itself automatically. If you want to repair immedi-



ately, unplug the power cord, then plug it in again 30 minutes later or



so. This automatically resets the unit.









CLOSED CAPTION PROBLEM

POSSIBLE REMEDY

My TV/VCR/DVD is showing

• You are watching a live broadcast and spelling errors made by the

captions that are misspelled.

closed captioning production company may pass through uncorrected.



A prerecorded program will not show any misspelled words because



of the normal time available for editing the captions.





My TV/VCR/DVD will not show

• Captions that are delayed a few seconds behind the actual

the text dialogue in its entirety or

are common for live broadcast. Most captioning production

there is a delay of what is being

companies can display a dialogue to a maximum of 220 words

said.

per minute. If a dialogue exceeds that rate, selective editing is used



to insure that the captions remainup-to-datewith the current



TV screen dialogue.

My captions are scrambled with

• Interference caused by building, power lines, thunderstorms, etc.

white boxes on the TV screen.

may cause scrambled or incomplete captions to appear.





My program guide listed a TV show

• Broadcasters may at times use a time compression process to speed

as being closed captioned but none

up the actual program so that additional advertising time can be

of the captions were displayed.

given. Since the decoder cannot read the compressed information,



captions will be lost.





My prerecorded video tape does not

• The video tape was either an illegal copy or the tape duplicating

show any captions. The tape box

company accidentally left out the captioning signals during the

mentions it being closed captioned.

copying process.





My TV screen shows a black box

• You are in the TEXT mode. Select CAPTION mode to CAPTION

on certain channels.

[OFF].





– 48 –

EN

01A11

DVD Mode

PROBLEM

CORRECTIVE ACTION

No picture

• Insert a correct video disc that plays on this unit.



• Press the SELECT button on the remote control to select DVD mode.



Then, try other DVD feature.

Disc cannot be played

• Insert the disc.



• Clean the disc.



• Place the disc correctly, with the label side up.



• Cancel the parental lock or change the control level.

No sound

• Connect the audio cables firmly.



• Turn the power of the audio component on.



• Correct the audio output settings.



• Correct the input settings on the audio component.

No DTS audio is output

• This unit does not support DTS audio. This is not a malfunction.

Distorted picture

• There are some cases where pictures may be slightly distorted, which



are not a sign of a malfunction.



• Although pictures may stop for a moment, this is not a malfunction.

Audio or subtitle language

• The selected language is not available for audio or subtitles on the

does not match the set up

DVD.



This is not a malfunction

The camera angle cannot be

• The DVD does not contain sequences recorded from different camera

changed

angles. This is not a malfunction

Audio or subtitle language cannot

• The DVD does not contain audio source or subtitles in the selected

be changed

language. This is not a malfunction.

“Prohibited icon” appears on the

• That operation is prohibited by this unit or the disc.

screen, prohibiting an operation

This is not a malfunction.

CD sound dropout

• Scratched disc. Replace the disc with an unscratched one.

No CD reproduction



DVD picture dropout



DVD picture freeze



DVD picture in mosaic



No DVD reproduction







NOTES:

Some functions are not available in specific modes, but this is not a malfunction. Read the description in this Owner’s Manual for details on correct operations.

Playback from a desired track and random playback are not available during program playback.

– 49 –

EN

01A11

MAINTENANCE

CABINET CLEANING

Wipe the front panel and other exterior surfaces of the TV/VCR/DVD with a soft cloth immersed in lukewarm water and wrung dry.

Never use a solvent or alcohol. Do not spray insecticide liquid near the TV/VCR/DVD. Such chemicals may cause damage and discoloration to the exposed surfaces.

AUTO HEAD CLEANING

Automatically cleans video heads as you insert or remove a cassette, so you can see a clearer picture.

Playback picture may become blurred or interrupted while the TV program reception is clear. Dirt accumulated on the video heads after long periods of use or the usage of rental or worn tapes can cause this problem.

If a streaky or snowy picture appears during playback, the video heads in your TV/VCR/DVD may need to be cleaned.

1.Please visit your local Audio/Video store and purchase a good quality VHS Video Head Cleaner.

2.If a Video Head Cleaner does not solve the problem, please call our help line at 1-800-968-3429,to locate an Authorized Service Center.

NOTES:

Remember to read the instructions included with the video head cleaner before use.

Clean video heads only when problems occur.

SERVICING

Should your TV/VCR/DVD become inoperative, do not try to correct the problem by yourself. There are no user-serviceableparts inside. Turn off,

unplug the power cord and please call our help line at 1-800-968-3429,to locate an Authorized Service Center.

IF THE LASER OPTICAL PICKUP UNIT IS DIRTY

If the TV/VCR/DVD still does not perform properly when it is operated, while referring to the relevant sections and to "TROUBLESHOOTING GUIDE" in this Owner's Manual, the laser optical pickup unit may be dirty. Consult your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.

DISC HANDLING

Use discs which have the following logos on them. (Optical audio digital discs.)

Recordable ReWritable

Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.

To clean-off,use a soft cloth.

Do not use a hard cloth since this will mar the disc.

Wipe the disc in a straight line from center to edge.

Never wipe with a circular motion.

Do not use detergent or abrasive cleaning agents.

Always store the disc in its protective case when it is not used.

– 50 –

EN

01A11

SPECIFICATIONS

GENERAL SPECIFICATIONS

TV/VCR

CRT

20 inch in-linegun,



90˚ deflection tube

Television system :

NTSC-M

Closed caption system :§15.119/FCC

Video Heads :

Rotary four-head

Tape width :

1/2 inch

Tape speed



SP :

33.40mm/sec.

LP :

16.67mm/sec.

SLP :

11.12mm/sec.

Tuner channel



TV VHF Low :

#2~#6

TV VHF High :

#7~#13

TV UHF :

#14~#69

CATV



VHF :

5A

MID band :

A5~A1, A~I

SUPER band :

J~W

HYPER band :

W+1~W+84

DVD

Product type:

DVD Player

Discs:

DVD video, Audio CD

Output signal format:

NTSC color

ELECTRICAL SPECIFICATIONS

Sound output: 2 speakers, 1W, 8 ohm

OTHER SPECIFICATIONS

Terminals



Antenna input:

VHF/UHF/CATV



75 ohm unbalanced (F-type)

Video input:

RCA connector [ 1

Audio L/R input:

RCA connector [ 2

Headphone:

1/8” stereo (3.5 mm)

Coaxial digital



audio output:

One pin jack,



500m Vpp (75 ohm)

Remote control:

Digital encoded



infrared light system

Operating



temperature:

5°C to 40°C



(41°F~104°F)

Power requirements:

AC 120V, 60Hz

Power consumption



(Maximum):

90W

Picture tube:

20"PF

Dimensions:

H:20-3/16”(513mm)



W:22-1/8”(562mm)



D:19-7/8”(505mm)

Weight:

50.7 lbs (23.0kg)

Designs and specifications are subject to change without notice.

If there is a discrepancy between languages, the default language will be English.

– 51 –

EN

01A11

INDICE

12. Indicador de grabación



Parpadea durante la grabación. Se ilumina durante el



CONTROLES DE OPERACIÓN Y FUNCIONES . . . . . 52

modo de espera de grabación controlada por temporizador.

13. Botón REC/OTR (Panel frontal)



PANEL FRONTAL DEL TELEVISOR/DVD. . . . . . . . . . 52



MANDO A DISTANCIA . . . . . . . . . . . . . . . . . . . . . . . . . 52

Presione para empezar la grabación manual. Presione

VISTA POSTERIOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

repetidamente para empezar la grabación instantánea



PREPARACIÓN PARA LA UTILIZACIÓN . . . . . . . . . . 53

(OTR).



CONEXIONES DE ANTENA/CABLE . . . . . . . . . . . . . . 53

Botón RECORD (Mando a distancia)



CONEXIÓN A TOMAS DE ENTRADA EXTERNA. . . . 53

Presione para empezar la grabación manual.



PARA INSERTAR LAS PILAS . . . . . . . . . . . . . . . . . . . . 54

14. Botón REW (para TV/VCR)



MODO DE ENTRADA EXTERNA . . . . . . . . . . . . . . . . 54

Presione este botón para rebobinar la cinta o para ver

CONEXIÓN A UN SISTEMA ESTÉREO . . . . . . . . . . . . 54

la imagen rápidamente en dirección de retroceso



CONEXIÓN A UN AMPLIFICADOR ESTÉREO

durante el modo de reproducción. (Búsqueda en direc-

EQUIPADO CON TOMAS DE ENTRADA DIGITAL,

ción de retroceso)



PLATINA MD O PLATINA DAT (Para DVD). . . . . . . . . 54

15. Botón F.FWD (para TV/VCR)



CONEXIÓN A UN DECODIFICADOR DOLBY DIGITAL



Presione este botón para adelantar rápidamente la cinta

(para DVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

o para ver la imagen rápidamente en dirección de









SECCIÓN DE TV/VCR

avance durante el modo de reproducción. (Búsqueda en

PREPARACIÓN PARA LA UTILIZACIÓN. . . . . . . . . . 54

dirección de avance)



SELECCIÓN DE IDIOMA . . . . . . . . . . . . . . . . . . . . . . . 54

16. Botón STOP/EJECT



AJUSTE DE CANALES . . . . . . . . . . . . . . . . . . . . . . . . . 55

Presione este botón para detener la cinta. Presiónelo en

AJUSTE DEL RELOJ . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

el modo de parada para retirar la cinta del



SECCIÓN DE DVD

televisor/videograbadora/DVD.



17. Ventanilla del sensor de mando a distancia



REPRODUCCIÓN BÁSICA . . . . . . . . . . . . . . . . . . . . . . 55



CONTROLES DE

18. Toma HEADPHONE



Para conectar auriculares (no suministrados) y escuchar





OPERACIÓN Y FUNCIONES

en privado.



19. Toma de entrada VIDEO







Conecte aquí la toma de salida de vídeo de una













videocámara o de una videograbadora.



PANEL FRONTAL DEL







20. Tomas de entrada AUDIO L/R



TELEVISOR/DVD



Conecte aquí las tomas de salida de audio de una







videocámara o de una videograbadora.



Consulte la figura 1 de la página 9







21. Compartimiento del cassette







22. Botón PICTURE



MANDO A DISTANCIA







Presione este botón para ajustar la imagen.







23. Botones numéricos



Consulte la figura 2 de la página 9







Modo TV:









VISTA POSTERIOR



Presione dos botones para acceder directamente al





canal deseado.







No olvide presionar “0” antes de elegir un canal de un

Consulte la figura 3 de la página 10





solo dígito.









1. Botón POWER

Botón +100



Presione este botón para seleccionar canales de tele-



Presione este botón para conectar y desconectar la ali-



visión por cable cuyo número sea igual o superior a 100.

mentación.

Modo DVD:



2. Botones VOLUMEX/Y



Presione este botón para introducir el número deseado.

Presione estos botones para controlar el nivel de volumen

Botón +10



del DVD y el televisor.



Presione este botón para introducir números iguales o

3. Botones SKIP (para DVD)

mayores que 10.



Presione el botón correspondiente una vez para omitir

24. Botón PAUSE



capítulos o pistas y desplazarse a un punto específico.



Hace una pausa en la reproducción del disco o cinta.



Mantenga el botón presionado para cambiar la veloci-



25. Botón SPEED



dad de reproducción en avance o retroceso.



Presione este botón para seleccionar la velocidad de



4. Botón PLAY



grabación deseada: SP/SLP.



Inicia la reproducción del contenido del disco o cinta.



26. Botón C.RESET



5. Botón STOP



Presione este botón para poner el contador en 0:00:00.

Detiene la reproducción del disco.

Presiónelo también para cancelar un ajuste de progra-

6. Botón OPEN/CLOSE

ma de temporizador.



Presione este botón para insertar discos en la bandeja o

27. Botón DISPLAY



retirarlos de ella.



Modo TV/VCR:



7. Bandeja de carga del disco



Para visualizar el contador o el número del canal y la

8. Indicador DVD

fecha actual en la pantalla del televisor.



Se ilumina durante el modo DVD.

Modo DVD:



9. Botón SELECT

Indica el estado actual en la pantalla del televisor para

Presione este botón para cambiar al modo TV/VCR,

fines de comprobación.



modo de entrada externa o modo de DVD.

28. Botón SETUP



10. Indicador TV/VCR

Presione este botón para activar o salir del modo de



Se ilumina durante el modo TV/VCR.

menús de televisor o configuración de DVD.



11. Botones CHANNELK/L

29. Botón TITLE



Utilice estos botones para seleccionar canales memorizados.

Para visualizar el menú de títulos.

ES

– 52 –

0C28

30.Botón CLEAR

Para cancelar ajustes.

31.Botón MODE

Activa el modo de reproducción programada o el modo de reproducción aleatoria.

32.Botón SEARCH MODE

Presione este botón para localizar un punto deseado.

33.Botón AUDIO

Presione este botón para seleccionar un idioma de audio o el modo de sonido deseado.

34.Botón SUBTITLE

Presione este botón para seleccionar el idioma de subtítulos deseado.

35.Botón REPEAT

Repite la reproducción del disco, título, capítulo, grupo o pista actual.

36.Botón ANGLE (modo DVD)

Presione este botón para cambiar el ángulo de la cámara y ver la secuencia que se está reproduciendo desde un ángulo diferente.

37.Botón A-BREPEAT

Repite la reproducción de una sección seleccionada.

38.Botón RETURN

Permite volver a la operación anterior en el modo de configuración de DVD.

39.Botón ENTER

Presione este botón para establecer un ajuste.

40.Botones de flechas Modo TV/VCR:

Presione estos botones para seleccionar un modo de ajuste en el menú que aparece en la pantalla del televisor. Presiónelos también para seleccionar opciones o establecer ajustes en un menú en particular.

Modo DVD:

Use estos botones para hacer ajustes mientras observa la imagen en la pantalla del televisor.

41.Botón DISC MENU

Muestra los menús contenidos en el DVD.

42.Botón V.SURR

Activar/desactivar el envolvente virtal.

43.Botón MUTE

Suprime la salida de sonido. Presiónelo de nuevo para restablecer el sonido.

44.Botón SLEEP

Utilice este botón para ajustar el temporizador de dormir.

45.Botón SELECT

Presione este botón para cambiar entre los modos TV/VCR y DVD. El modo seleccionado (TV/VCR o DVD) se visualiza en el indicador del panel delantero.

46.Toma de entrada ANT.

Conéctela a una antena, sistema de televisión por cable o sistema de satélite.

47.Cable de alimentación

Conéctelo a una toma de CA estándar (120 V, /60 Hz). NOTA: Antes de conectar el cable de alimentación a

una toma de CA estándar, retírelo del gancho para evitar dañarlo.

48.Toma de salida de audio digital COAXIAL

Conéctela solamente a la entrada digital de un amplificador externo o decodificador de audio de DVD.

PREPARACIÓN PARA LA

UTILIZACIÓN

CONEXIONES DE ANTENA/CABLE

Consulte la figura 4 de la página 11

ANTENAS SEPARADAS DE VHF/UHF

En algunas zonas será necesario utilizar una antena exterior.

TELEVISIÓN POR CABLE SIN CAJA DE CONVERTIDOR/DECODIFICADOR

Utilice esta conexión si su sistema de televisión por cable se conecta directamente a su televisor/ videograbadora/DVD, sin una caja de convertidor. Con esta conexión podrá:

1)Utilizar el mando a distancia del televisor/ videograbadora/DVD para seleccionar canales.

2)Programar uno o más canales decodificados para grabación automática controlada por temporizador.

NOTA: Este televisor/videograbadora/DVDSÓLO puede grabar el canal que se está viendo.

TELEVISIÓN POR CABLE CON CAJA DE CONVERTIDOR/DECODIFICADOR O CAJA DE SATÉLITE

Si su compañía de televisión por cable le suministra una caja de convertidor o si utiliza un sistema de satélite, podrá utilizar la conexión básica que se muestra en la ilustración.

Al utilizar esta conexión, también podrá grabar canales codificados. Sin embargo, la selección de los canales deberá hacerse con la caja de convertidor o con la caja de satélite. Esto significa que no es posible cambiar de canal utilizando el mando a distancia del televisor/ videograbadora/DVD. La grabación en ausencia (controlada por temporizador) está limitada a un canal a la vez.

PARA GRABAR UN CANAL CODIFICADO/DECODIFICADO

1.Ajuste el selector de canales del televisor/videograbadora/DVD al canal de salida de la caja de convertidor de televisión por cable o caja de satélite. (Ej., CH3)

2.Seleccione el canal que desea grabar en la caja de convertidor de televisión por cable o caja de satélite.

Nota para el instalador de sistemas CATV

Esta nota tiene la finalidad de llamar la atención del instalador de sistemas CATV para que tenga en cuenta el Artículo 820-40de la NEC, que proporciona recomendaciones para hacer una conexión a tierra apropiada y, en particular, especifica que la tierra del cable debe conectarse al sistema de puesta a tierra del edificio, tan cerca del punto de entrada del cable como sea posible.

CONEXIÓN A TOMAS DE ENTRADA

EXTERNA

Cuando vea un programa grabado en otra fuente (videograbadora o videocámara), utilice las tomas de entrada de audio/vídeo de la parte delantera del televisor/videograbadora/DVD. Conecte las tomas de salida de audio/vídeo de otra fuente a las tomas AUDIO L/R y VIDEO de este televisor/ videograbadora/DVD. Luego, presione los botones CHANNELK/L hasta que aparezca "AUX" en la pantalla.

NOTA:

Cuando conecte una videograbadora monofónica (otra fuente) a este televisor/videograbadora/DVD, conecte la toma de salida de audio de la videograbadora monofónica (otra fuente) a la toma AUDIO L de este televisor/videograbadora/DVD. El audio saldrá igualmente por los canales izquierdo y derecho.

Consulte la figura 5 de la página 12

– 53 –

ES

0C28

PARA INSERTAR LAS PILAS

1)Abra la cubierta del compartimiento de las pilas empujando la cubierta del mando a

distancia en el sentido de la flecha.

2)Inserte 2 pilas "AA" en el compartimiento de las pilas, en el

sentido indicado por las marcas de polaridad (+/-).

3)Vuelva a poner la cubierta.

MODO DE ENTRADA EXTERNA

Al usar una señal de entrada externa (otra videograbadora o una videocámara), conecte los cables de salida de audio/vídeo del equipo externo a las tomas AUDIO L/R IN/ VIDEO IN de su televisor/videograbadora/DVD. Luego, presione los botón CHANNEL K oL hasta que aparezca "AUX" en la pantalla.

CONEXIÓN A UN AMPLIFICADOR ESTÉREO EQUIPADO CONTOMAS DE ENTRADA DIGITAL, PLATINA MD O PLATINA DAT (Para DVD)

Utilice un cable digital coaxial de audio de venta en el comercio especializado para hacer las conexiones de audio. Conexión a un amplificador equipado con tomas de entrada digital, platina MD o platina DAT.

Consulte la figura 6 de la página 13

NOTAS:

La fuente de audio de un disco grabado en formato de sonido envolvente Dolby Digital de 5,1 canales no se puede grabar como sonido digital mediante una platina MD o DAT.

Asegúrese de desconectar la alimentación de todos los componentes del sistema antes de conectar otro componente.

Consulte los manuales de instrucciones de los componentes que va a conectar al televisor/videograbadora/ DVD.

Ajuste la función Dolby Digital a OFF para salida de audio en el modo de configuración. La reproducción en un televisor/videograbadora/DVD utilizando ajustes incorrectos puede generar ruido y distorsión, y también puede causar daños a los altavoces.

CONEXIÓN A UN DECODIFICADOR

DOLBY DIGITAL (para DVD)

Si utiliza este televisor/videograbadora/DVD para reproducir un disco DVD grabado en formato de sonido envolvente Dolby Digital de 5,1 canales, el televisor/videograbadora/DVD emitirá un flujo de datos DOLBY DIGITAL desde su toma de salida de audio digital COAXIAL. Si conecta el reproductor a un decodificador Dolby Digital, podrá disfrutar de una tonalidad más convincente y real, con un sonido envolvente potente y de alta calidad similar al de los cines.

Utilice cables digitales coaxiales de audio disponibles en el comercio especializado para hacer las conexiones de audio.

Consulte la figura 7 de la página 14

NOTAS:

Asegúrese de desconectar la alimentación de todos los componentes del sistema antes de conectar otro componente.

Consulte los manuales de instrucciones de los componentes que va a conectar al televisor/ videograbadora/DVD.

Si conecta un decodificador Dolby Digital, ajuste la función DOLBY DIGITAL a ON para salida de audio en el modo de configuración.

A menos que se haga la conexión a un decodificador Dolby Digital, ajuste la función Dolby Digital a OFF para salida de audio en el modo de configuración. La reproducción en un televisor/videograbadora/DVD utilizando ajustes incorrectos puede generar ruido y distorsión, y también puede causar daños a los altavoces.

Fabricado bajo licencia de Dolby Laboratories. “Dolby” y el símbolo de la D doble son marcas de fábrica de Dolby Laboratories.

SECCIÓN DE TV/VCR

PREPARACIÓN PARA LA

UTILIZACIÓN

SELECCIÓN DE IDIOMA

TV/VCR

1 Enchufe el cordón de alimentación del televisor/videograbadora/DVD

Enchufe el cordón de alimentación del televisor/videograbadora/DVD en una toma de CA estándar.

NOTA:

Si aparecen algunas cifras en la esquina de la pantalla, pulse el botón POWER sin desenchufar el cordón de alimentación.

Asegúrese de que ...

Pulse el botón POWER para encender el televisor/videograbadora/DVD.

NOTA: Esta función afecta sólo el idioma en el menú de la pantalla y no la fuente de audio.

2 Seleccione “LANGUAGE”

Pulse el botón SETUP en el mando a distancia. Pulse el botón K oL para señalar “LANGUAGE”.

3 Seleccione “ENGLISH”, “ESPAÑOL” o “FRANÇAIS”

Seleccione “ENGLISH”, “ESPAÑOL” o “FRANÇAIS” con el botón ENTER.

4 Salga del modo de idioma

Pulse el botón SETUP en el mando a distancia para volver al modo del televisor.

– 54 –

ES

0C28

NOTA: Si, por alguna razón, el menú está en inglés o francés, pulse el botón SETUP en el mando a distancia, pulse el botónK oL para señalar el “LANGUAGE [ENGLISH]” o “LANGAGE [FRANÇAIS]”, a continuación, pulse el botón ENTER y pulse el botón SETUP en el mando a distancia.

AJUSTE DE CANAL

TV/VCR

Puede programar el sintonizador para buscar todos los canales que recibe en su localidad.

NOTA: El canal preparado NO es necesario cuando esté conectado a una caja de cable o caja de satélite. Sólo tiene que seleccionar con el selector de canal del televisor/videograbadora/DVD al canal de salida de la caja de cabe o caja de satélite (por ejemplo el canal CH3). Seleccione el canal a ver en la caja de cable o caja de satélite.

Asegúrese de que ...

Pulse el botón POWER para encender el televisor/videograbadora/DVD.

1 Seleccione “AJUSTE DE CANAL”

Pulse el botón SETUP en el mando a distancia. Pulse el botón K oL para señalar “AJUSTE DE CANAL”.

A continuación, pulse el botón ENTER.

2 Empiece el prefijado automático

Pulse el botón K oL para señalar “AUTOPROGRAMACION DE CA”.

1)Pulse el botón SETUP en el mando a distancia. Pulse el botón K oL para indicar “AJUSTE RELOJ”.

Luego, pulse el botón ENTER.

2)Pulse el botón K oL para indicar “AJUSTE MANUAL RELOJ”.

Luego, pulse el botón ENTER.

3)Pulse el botón K oL hasta que aparezca el mes deseado. (Ejemplo: Mayo - 05)

Luego, pulse el botón B.

4)Pulse el botón K oL hasta que aparezca el día del mes deseado. (Ejemplo: 6 - 06)

Luego, pulse el botón B.

5)Pulse el botón K oL hasta que aparezca el año deseado. (Ejemplo: 2004)

Luego, pulse el botón B.

6)Pulse el botón K oL hasta que aparezca la hora deseada. (Ejemplo: 5, PM)

Luego, pulse el botón B.

7)Pulse el botón K oL hasta que aparezca el minuto deseado. (Ejemplo: 40)

8)Pulse el botón SETUP en el mando a distancia. Aunque los segundos no se visualizan, éstos empiezan a contar desde 00 cuando se pulsa SETUP en el mando a distancia. Utilice esta función para sincronizar el reloj con la hora correcta.

SECCIÓN DE DVD

A continuación, pulse el botón ENTER.

El sintonizador busca y memoriza todos los canales activos en su localidad.

3 Después de buscar

REPRODUCCIÓN BÁSICA

DVD-VCDMP3

El sintonizador se detiene en el canal memorizado

Para empezar

más bajo.

¡Conecte la alimentación del amplificador y otros

Cuando se activa AUTOPROGRAMACION DE



componentes, si es necesario.

CA, donde no hay entrada de señal del televisor,



1 Presione el botón POWER.

aparecerá “NO HAY SEÑAL DE TV” en la pan-

¡La alimentación se conectará.

talla después de terminar la búsqueda de canales.







2 Presione el botón OPEN/CLOSE para abrir

El televisor/videograbadora/DVD puede reconocer





la bandeja de carga del disco.

los canales de TV para que sean canales de TV de







antena de cable con las condiciones de recepción.



3 Ponga el disco deseado en la bandeja, con

En este caso, pruebe nuevamente con el prefijado



la etiqueta hacia arriba.

automático en las condiciones de recepción fina.







4 Presione el botón PLAY.







¡La bandeja se cerrará automáticamente y la repro-

AJUSTE DEL RELOJ







ducción comenzará desde el primer capítulo o pista









del disco. Si la reproducción no comienza automáti-









Cerciórese...

TV/VCR





camente, presione el botón PLAY.





¡Cuando reproduzca un DVD que tenga grabado un

• La alimentación del televisor/videograbadora/DVD



menú de títulos, el menú podrá aparecer en la pan-

deberá estar conectada.



talla.

En el ejemplo de abajo, el reloj va a ajustarse así:



5 Presione el botón STOP para detener la

FECHA: 6 de mayo de 2004



reproducción.

HORA: 5:40 PM







– 55 –

ES

0C28

SYLVANIA

LIMITED WARRANTY

FUNAI CORP. will repair this product, free of charge in the USA in the event of defect in materials or workmanship as follows:

DURATION:

PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the date of original retail purchase. Two (2) years for Picture Tube. This warranty does not cover any cosmetic parts or complete assembly parts.

LABOR: FUNAI CORP. will provide the labor without charge for a period of ninety (90) days from the date of original retail purchase.

LIMITS AND EXCLUSIONS:

This warranty is extended only to the original retail purchaser. A purchase receipt or other proof of original retail purchase will be required together with the product to obtain service under this warranty.

This warranty shall not be extended to any other person or transferee.

This warranty is void and of no effect if any serial numbers on the product are altered, replaced, defaced, missing or if service was attempted by an unauthorized service center. This FUNAI Limited warranty does not apply to any product not purchased and used in the United States.

This warranty only covers failures due to defects in material or workmanship which occurs during normal use. It does not cover damage which occurs in shipment, or failures which are caused by repairs, alterations or product not supplied by FUNAI CORP. or damage which results from accident, misuse, abuse, mishandling, misapplication, alteration, faulty installation, improper maintenance, commercial use such as hotel, rental or office use of this product or damage which results from fire, flood, lightning or other acts of God.

THIS WARRANTY DOES NOT COVER PACKING MATERIALS, ANY ACCESSORIES (EXCEPT REMOTE CONTROL), ANY COSMETIC PARTS, COMPLETE ASSEMBLY PARTS, DEMO OR FLOOR MODELS.

FUNAI CORP. AND ITS REPRESENTATIVES OR AGENTS SHALL IN NO EVENT BE LIABLE FOR ANY GENERAL, INDIRECT OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR OCCASIONED BY THE USE OF OR THE INABILITY TO USE THIS PRODUCT. THIS WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED AND OF ALL OTHER LIABILITIES ON THE PART OF FUNAI, ALL OTHER WARRANTIES INCLUDING THE WARRANTY OF MERCHANTABILITY, AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED BY FUNAI AND ITS REPRESENTATIVES IN THE UNITED STATES. ALL WARRANTY INSPECTIONS AND REPAIRS MUST BE PERFORMED BY A FUNAI AUTHORIZED SERVICE CENTER. THIS WARRANTY IS VALID WHEN THE UNIT IS CARRIED-INOR DELIVERED TO A FUNAI AUTHORIZED SERVICE FACILITY.

IMPORTANT:

THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS., YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE, IF, AT ANY TIME DURING THE WARRANTY PERIOD, YOU ARE UNABLE TO OBTAIN SATISFACTION WITH THE REPAIR OF THIS PRODUCT, PLEASE CONTACT FUNAI CORP. IN WRITING SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGE SO THE ABOVE LIMITATION OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

ATTENTION:

FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY DESIGN OF THIS PRODUCT WITHOUT PRIOR NOTICE.

To locate your nearest FUNAI Authorized Service Center or for general service procedure, please call 1-800-968-3429or write to the following:

FUNAI CORPORATION, INC. Service Center

19900 Van Ness Avenue, Torrance, CA 90501

Tel : 1-800-968-3429

Printed in China

1EMN20069



T1008UJ
