If you need additional assistance for set-up or operating
after reading owner’s manual, please call
TOLL FREE : 1-800-256-2487
or visit our web site at http://www.funai-corp.com
Please read before using this equipment.
OPEN/CLOSE
OUTPUT
REC
REW
FF
VIDEOAUDIO
CH-DOWN
POWER
CH-UP
STOP/EJECT
PLAY
DVD
VCR
TIMER REC
STOP
PLAY
DISC IN
FWD
REVPLAY
ReWritable
Recordable
H9410UD(EN).qx33 03.1.14 9:21 PM Page 1
EMERSON AND THE G-CLEF LOGO ARE REGISTERED
TRADEMARKS OF EMERSON RADIO CORP., PARSIPPANY,
NEW JERSEY, U.S.A.
DVD PLAYER with VIDEO CASSETTE RECORDER
EWD2203
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
H9410UD(EN).qx33 03.1.14 9:21 PM Page 2
WARNING
:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
:
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
LASER SAFETY
This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to
possible eye injury.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO
NOT STARE INTO BEAM.
LOCATION: INSIDE, NEAR THE DECK MECHANISM.
FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifications to this
equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual.
The user could lose the authority to operate this equipment if an unauthorized change or modification is made.
RADIO-TV INTERFERENCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment and receiver.
3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4) Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA
FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
–2–
EN
1L25
FIGURE A
EXAMPLE OF ANTENNA GROUNDING
AS PER NATIONAL ELECTRICAL CODE
ANTENNA
LEAD
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND
CLAMP
GROUND CLAMP
ELECTRIC
SERVICE
EQUIPMENT
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC – NATIONAL ELECTRICAL CODE
S2898A
H9410UD(EN).qx33 03.1.14 9:21 PM Page 3
IMPORTANT SAFEGUARDS
1. Read Instructions - All the safety and operating instructions
should be read before the appliance is operated.
2. Retain Instructions- The safety and operating instructions
should be retained for future reference.
3. Heed Warnings - All warnings on the appliance and in the
operating instructions should be adhered to.
4. Follow Instructions - All operating and use instructions
should be followed.
5. Cleaning - Unplug this video product from the wall outlet
before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning
or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise
required in item 5.
6. Attachments - Do not use attachments not recommended by
the video product manufacturer as they may cause hazards.
7. Water and Moisture- Do not use this video product near
water, for example, near a bath tub, wash bowl, kitchen sink,
or laundry tub, in a wet basement, or near a swimming pool,
and the like.
8. Accessories - Do not place this video
product on an unstable cart, stand, tripod,
bracket, or table. The video product may
fall, causing serious injury to a child or
adult, and serious damage to the appliance. Use only with a cart, stand, tripod,
bracket, or table recommended by the
manufacturer, or sold with the video
product. Any mounting of the appliance should follow the
manufacturer's instructions and should use a mounting
accessory recommended by the manufacturer. An appliance
and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the
appliance and cart combination to overturn.
9. Ventilation - Slots and openings in the cabinet are provided
for ventilation and to ensure reliable operation of the video
product and to protect it from overheating, and these openings must not be blocked or covered. The openings should
never be blocked by placing the video product on a bed,
sofa, rug, or other similar surface. This video product should
not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to.
10. Power Sources - This video product should be operated only
from the type of power source indicated on the marking
label. If you are not sure of the type of power supply to your
home, consult your appliance dealer or local power company. For products intended to operate from battery power, or
other sources, refer to the operating instructions.
11. Grounding or Polarization - This video product is equipped
with a polarized alternating-current line plug (a plug having
one blade wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try reversing
the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
12. Power Cord Protection - Power supply cords should be routed so that they are not likely to be walked on or pinched by
items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point
where they exit from the appliance.
13. Outdoor Antenna Grounding - If an outside antenna or cable
system is connected to the video product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA
No. 70, provides information with regard to proper ground-
ing of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit, connection
to grounding electrodes, and requirements for the grounding
electrode. (Fig. A)
14. Lightning - For added protection for this video product during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the video product due to lightning and
power-line surges.
15. Power Lines - An outside antenna system should not be
located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from touching
such power lines or circuits as contact with them might be
fatal.
16. Overloading - Do not overload wall outlets and extension
cords as this can result in a risk of fire or electric shock.
17. Object and Liquid Entry - Never push objects of any kind
into this video product through any openings as they may
touch dangerous voltage points or short-out parts that could
result in a fire or electric shock. Never spill liquid of any
kind on the video product.
18. Servicing - Do not attempt to service this video product
yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
19. Damage Requiring Service - Unplug this video product from
the wall outlet and refer servicing to qualified service personnel under the following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the
video product.
c. If the video product has been exposed to rain or water.
d. If the video product does not operate normally by following
the operating instructions. Adjust only those controls that
are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the video product to its normal operation.
e. If the video product has been dropped or damaged in any
way.
f. When the video product exhibits a distinct change in perfor-
mance this indicates a need for service.
20. Replacement Parts - When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may
result in fire, electric shock or other hazards.
21. Safety Check - Upon completion of any service or repairs to
this video product, ask the service technician to perform
safety checks to determine that the video product is in proper operating condition.
22. Heat - This video product should be situated away from heat
sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
–3–
EN
1L25
H9410UD(EN).qx33 03.1.14 9:21 PM Page 4
A NOTE ABOUT RECYCLING
This product’s packaging materials are recyclable and can be reused. Please dispose of all materials in
accordance with your local recycling regulations.
Batteries should never be thrown away or incinerated but disposed of in accordance with your local
regulations concerning chemical wastes.
The serial number of this product may be found on the back of the DVD/VCR COMBINATION UNITS. This
serial number is unique to your machine. You should record the number and other vital information here and
retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are
not kept on file.
Date of Purchase
Dealer Purchase from
Dealer Address
Dealer Phone No.
Model No.
Serial No.
ABOUT COPYRIGHT
Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.
This product incorporates copyright protection technology that is protected by method claims of certain U.S.
patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of
this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home
and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
SUPPLIED ACCESSORIES
Remote control
(NA209UD)
(NA259UD)
Two AA batteriesA/V cables
(approx. 3 feet (100 cm)
long) (WPZ0102TM015)
RF Cable
WPZ0901TM002
SYMBOLS USED IN THIS MANUAL
The following symbols below appear in some headings and notes in this manual, with the following meanings
VCR
: Description refers to playback of video cassette tapes.
DVD-V
: Description refers to playback of DVD video discs.
CD
: Description refers to playback of audio CDs.
MP3
: Description refers to playback of MP3 discs.
QUICK
: Description refers to the items to be set in the QUICK mode.
AJUSTANDO EL CONMUTADOR CH3/CH4
CONECTANDO A UN TV
CONECTADO A UN TV QUE TIENE TOMA DE ENTRADA DE S-VÍDEO o TOMAS DE ENTRADA DE VÍDEO
COMPONENTE
CONECTANDO A UN AMPLIFICADOR EQUIPADO CON TOMAS DE ENTRADA DIGITAL, TALES COMO PLATINA MD O
PLATINA DAT
CONECTANDO A UN DESCODIFICADOR DIGITAL DOLBY
CONECTANDO A UN AUDIO ANALÓGICO
■
PREPARACIÓN
PREPARACIÓN DE CANAL AUTOMÁTICA
PREPARACIÓN DE RELOJ
This DVD/VCR COMBINATION UNITS can handle
Dolby Digital surround sound with 5.1 channels when connected to a Dolby Digital decoder.
¡Still/fast/slow/step playback
¡Random playback for audio CD and MP3
¡Program playback for audio CD and MP3
¡DVD menus in a desired language
¡Screen saver/Auto power-off functions
The screen saver program starts when there is no input
from the player for five minutes in the stop mode. When
the screen saver program is activated for 30 minutes, the
power is automatically turned off.
¡Subtitles in a desired language
¡Selecting a camera angle
¡Choices for audio language and sound mode
¡Parental lock
¡Automatic detection of discs
This player automatically detects if the loaded disc is
DVD, audio CD or MP3 on disc.
¡Playing an MP3 disc
¡Direct Search
¡On-screen display
Information about the current operation can be displayed
on the TV screen, allowing you to confirm the currently
active functions (such as program playback), on the TV
screen using the remote control.
¡Search
Chapter search / Title search / Track search / Time search
¡Repeat
Chapter / Title / Track / Group / All / A-B
¡Zoom
¡Marker
The part designated by user can be called back.
¡Resume Play
Mode
PRECAUTIONS
FEATURES
¡Virtual Surround
¡Component Video Out Jacks
Jacks located on the back of the DVD/VCR COMBINATION UNITS which are used to send high-quality video to
a TV via Component Video In Jacks.
¡Bit rate indication
¡DRC (Dynamic range control)
You can control the range of sound volume.
¡Black Level Setting
VCR
Hardware specifications
¡Auto Head Cleaner
¡Trilingual on-screen menu display selectable in
English, French, or Spanish
¡181 channel capability PLL frequency synthesiz-
er tuner with direct station call
(A cable converter box may be necessary to view scrambled cable channels.)
Automatic functions
¡Auto power on system
Automatically turns the VCR on when you insert the cassette.
For safety and optimum performance of your
DVD/VCR COMBINATION UNITS:
• Install the DVD/VCR COMBINATION UNITS in a
horizontal and stable position. Do not place anything directly on top of the DVD/VCR COMBINATION UNITS. Do not place the DVD/VCR COMBINATION UNITS directly on top of the TV.
• Shield it from direct sunlight and keep it away from
sources of intense heat. Avoid dusty or humid
places. Avoid places with insufficient ventilation for
proper heat dissipation. Do not block the ventilation
holes on the sides of the DVD/VCR COMBINATION
UNITS. Avoid locations subject to strong vibration
or strong magnetic fields.
AVOID THE HAZARDS OF
ELECTRICAL SHOCK AND FIRE
• Do not handle the power cord with wet hands.
• Do not pull on the power cord when disconnecting it
from AC wall outlet. Grasp it by the plug.
• If, by accident, water is spilled on your DVD/VCR
COMBINATION UNITS, unplug the power cord
immediately and take the unit to our Authorized
Service Center for servicing.
• Do not put your fingers or objects into the DVD/VCR
COMBINATION UNITS cassette holder.
MOISTURE CONDENSATION WARNING
Moisture condensation may occur inside the unit when
it is moved from a cold place to a warm place, or after
heating a cold room or under conditions of high
humidity. Do not use the DVD/VCR COMBINATION
UNITS at least for 2 hours until its inside is dry.
The following discs can be played back on this
DVD/VCR COMBINATION UNITS.
¡
DVD video
¡
DVD+R/RW*
¡
CD-R/RW*
* Depending on the types or the writing method of the
medium some discs can not be played.
• Some DVD-R/RW, DVD+R/RW, or CD-R/RW discs
made on personal computers, or on DVD recorders may
not be played back properly due to factors such as
scratches, dirt or special properties of the disc.
• Discs made on personal computers may not be played
back properly due to different environments or the settings of the application you use. We recommend always
to use the standardized, properly formatted discs.
(Please contact the sales agency for more detail).
This player conforms to the NTSC color system. You cannot play discs recorded in other color systems such as
PAL or SECAM.
¡Some discs include region codes as shown below.
¡
DVD-R/RW*
¡
Audio CD
¡
MP3*
DISC TYPES
[
]
DVD
Data on a DVD is divided into sections called "titles", and
then into subsections called "chapters", each of which is
given a title or chapter number. Playback conditions are
preset on some DVD video discs, and these playback conditions take priority over user operations on this player. If
a function you selected does not run as desired, refer to
the manual accompanying the disc.
[
AUDIO CD
Data on an audio CD is divided into sections called
“tracks”, each of which is given a track number.
]
¡The number inside the symbol refers to a region of the
world, and a disc encoded in a specific region format
can only be played back on DVD/VCR COMBINATION UNITS with the same region code.
The following discs cannot be played back on this
DVD/VCR COMBINATION UNITS.
¡
DVD with region codes other than 1 or ALL.
¡
DVD-ROM
¡
DVD-RAM (Never play back, otherwise malfunc-
¡
CD-ROM
¡
VSD
¡
CDV (Only plays back the audio part.)
¡
CD-G (Only plays back the sound.)
¡
CD-I (Never play back, otherwise malfunction
¡
SACD
¡
Photo CD (Never play back, otherwise malfunc-
¡
Video CD (Never play back, otherwise malfunc-
tion may result.)
may result.)
tion may result.)
tion may result.)
Any other discs without compatibility indications.
[
]
MP3
Data on an MP3 is divided into sections called "groups",
and then into subsections called "tracks", each of which is
given a group or track number.
–7–
EN
1L25
OPEN/CLOSE
OUTPUT
REC
REW
FF
VIDEOAUDIO
CH-DOWN
POWER
CH-UP
STOP/EJECT
PLAY
DVD
VCR
TIMER REC
STOP
PLAY
DISC IN
FWD
REVPLAY
1234768
25
23242220
19
18171615141312
11
10
5
921
H9410UD(EN).qx33 03.1.14 9:21 PM Page 8
OPERATING CONTROLS AND FUNCTIONS
FRONT PANEL
REMOTE CONTROL
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
1. Disc loading tray
2. OPEN/CLOSE Button [page 22]
Press to insert discs into or remove them from the
tray.
3. DVD OUTPUT Light (Green) [page 12]
This light appears when the DVD output mode is
selected. You can only watch DVDs when the green
DVD OUTPUT light is on. To make the green DVD
OUTPUT light come on, press DVD on the remote
control or OUTPUT on the front panel.
4. VCR OUTPUT Light (Green) [page 12]
This light appears when the VCR output mode is
selected. You can only watch tapes when the green
VCR OUTPUT light is on. To make the green VCR
OUTPUT light come on, VCR on the remote control
or OUTPUT on the front panel.
5. CASSETTE COMPARTMENT
SPEED AUDIO
POWER
123
456
789
010
DVDVCR
DISPLAY
PLAY
STOP
RECORD
MENU
SETUP
SUBTITLE
T-SET
ZOOMMODE
ANGLE
ENTER
SEARCH
MODE
REPEAT
SKIP/CH.
VCR/TV
SLOW
+
PAUSE
54
52
50
48
RETURNTITLE
CLEAR/
C.RESET
A-B
46
44
42
55
53
51
49
47
45
43
41
6. POWER Button [page 16]
Press to turn the power on and off.
7. POWER Light (red)
Light appears when the power is on.
8. STOP/EJECT Button (VCR)
EJECT Button
Press to remove the tape from the VCR.
STOP Button
Press to stop the tape motion.
9. PLAY Button(VCR) [page 18]
Press to begin playback.
10. CH(ANNEL) Buttons [page 16]
In VCR mode, press to change TV channels on the
VCR; press to adjust the tracking during normal or
slow motion playback; press to remove vertical jitter
in a Still picture.
11. AUDIO In Jacks [page 21]
Connect an audio cable coming from the audio out
jack of a camcorder, another VCR, or an audio source
here.
12. VIDEO In Jack [page 21]
Connect a video cable coming from the video out
jack of a camcorder, another VCR, or a video source
(laser disc player, camcorder, etc.) here.
13. FF Button (VCR) [page 18]
Press to rapidly advance the tape, or view the picture
rapidly in forward during playback. (Forward
Search).
14. REW Button (VCR) [page 18]
Press to rewind the tape, or to view the picture rapidly in reverse during the playback mode (Rewind
Search).
15. REC Button [page 19]
Press once to start a recording. Press repeatedly to
start a One-Touch Recording.
16. REC Light [page 19]
Light appears during recording.
17. TIMER Light [page 20]
Light appears when the DVD/VCR is in standby
mode for a timer recording or during a One-Touch
Recording. It flashes if T-SET is pressed for a timer
recording, but there is no tape in the DVD/VCR. It
flashes when all timer recordings or One-Touch
Recordings are finished.
–
8–
EN
1L25
H9410UD(EN).qx33 03.1.14 9:21 PM Page 9
18. OUTPUT Button [page 12]
Press to select DVD mode or VCR mode.
● You can switch the output mode either by pressing
OUTPUT on the front panel, or by pressing DVD
or VCR on the remote control. However,
press OUTPUT on the front panel first, you
need to re-select the corresponding mode by
pressing DVD or VCR on the remote control.
19.
Remote Sensor Window
20. DISC IN Light (green)
Light appears when a disc is in the DVD Player.
21. PLAY Light (green)
Light appears during Disc playback.
22. FWD Button (DVD)
Press to fast forward the Disc. Press PAUSE, then
press this button to begin slow motion playback.
Press this button repeatedly to change the forward
speed of slow motion.
Press to skip Chapters or Tracks.
23. PLAY Button (DVD) [page 22]
Press to begin playback.
24. REV Button (DVD)
Press to view the DVD picture in fast reverse motion
or to reverse playback of an Audio CD.
Press to skip Chapters or Tracks.
25. STOP Button (DVD) [page 22]
Stops operation of the disc.
26. SPEED Button [page 19]
Press to select the VCR’s recording speed
(SP or SLP)
27. POWER Button
Press to turn the power on and off.
28. Number Buttons
● DVD mode [page 24]
Press to select numbered items in a menu.
+10
Use this button to enter number 10 and above.
● VCR mode [page 16]
Press to select TV channels on the VCR.
To select channels, enter channel numbers as a
two-digit number for the quickest results. For
example, to select channel 6, press 0 then 6.
29. DISPLAY Button
● DVD mode [page 28]
Press to access or remove the display screen during
DVD or Audio CD playback.
● VCR mode [page 21]
Press to access or remove the VCR’s on-screen status display.
30. DVD Button [page 12]
Press to select DVD mode for the remote control.
● You can switch the OUTPUT mode either by
pressing OUTPUT on the front panel, or by pressing
DVD or VCR on the remote control. However,
press OUTPUT on the front panel first, you need
to re-select the corresponding mode by pressing
DVD or VCR on the remote control.
31.
h Button
● DVD mode [page 23]
Press to view the DVD picture in fast reverse
motion.
Press PAUSE, then press this button to begin
slow motion playback. Press this button repeatedly to
change the reverse speed of slow motion.
● VCR mode [page 18]
Press to rewind the tape, or to view the picture rapidly
in reverse during the playback mode (Rewind Search).
if you
if you
32. STOP Button
● DVD mode
Press to stop the disc motion.
● VCR mode
Press to stop the tape motion.
33. RECORD Button [page 19]
Press once to start a recording.
34. MENU Button
● DVD mode [page 23]
Press to display the menu of the Disc.
● VCR mode [page 17]
Press to access the VCR menu.
35. TITLE Button [page 23]
36. SETUP Button [page 28-31]
Press to enter DVD player setup mode.
37. ZOOM Button [page 24]
Enlarges part of a DVD-reproduced image.
38. MODE Button [pages 26,27,and 30]
Activates program playback or random playback
mode when playing CDs or MP3. Sets Black level
and virtual surround.
39. SUBTITLE Button [page 27]
Press to select the desired subtitle language.
39. T-SET Button [page 20]
Press to put the VCR into standby mode for a timer
recording.
40. ANGLE Button [page 27]
Press to change the camera angle to see the sequence
being played back from a different angle.
41. REPEAT Button [page 25]
Repeats playback of the current disc, title, chapter or
track.
42. A-B REPEAT Button [page 25]
Repeats playback of a selected section.
43. SEARCH MODE Button
● DVD mode [page 24]
Press to access or remove the Search display,
which allows you to go directly to a specific
Title/Chapter/Track/Time.
● VCR mode [page 18]
Press to perform a Time Search or an Index Search.
44. CLEAR/C.RESET Button
● DVD mode [page 24,25]
Press to reset the setting.
● VCR mode [page 18]
Press to reset the counter. Press to exit from the
MENU screen.
45. RETURN Button [page 30]
● DVD mode
Returns to the previous operation.
46. Arrow Buttons
Use when making settings while watching the display on a TV screen.
● DVD mode [page 22-31]
Moves the cursor and determines its position.
● VCR mode [page 16]
p/o Buttons
Press to enter digits when setting program (For
example: setting clock or timer program). Press to
select the setting modes from the on screen menu.
B Button
When setting program (For example: setting clock
or timer program), press to determine your selection and proceed to the next step you want to input.
Press to determine the setting modes from the on
screen menu. Press to add or delete channel num-
–9–
EN
1L25
H9410UD(EN).qx33 03.1.14 9:21 PM Page 10
bers during channel preset.
s Button
Press to cancel a setting of timer program. Press to
correct digits when setting program (For example:
setting clock or timer program). Press to add or
delete channel numbers during channel preset.
47. ENTER Button
● DVD mode
[page 22]
Press to accept a setting.
48. g Button
● DVD mode [page 23]
Press to fast forward the Disc. Press PAUSE, then
press this button to begin slow motion playback.
Press this button repeatedly to change the forward
speed of slow motion.
● VCR mode [page 18]
Press to rapidly advance the tape, or view the picture rapidly in forward during playback (Forward
Search).
49. PLAY Button
● DVD mode
Press to begin playback.
● VCR mode
Press to begin playback.
50. VCR Button [page 12]
Press to select VCR mode for the remote control.
● You can switch the OUTPUT mode either by
pressing OUTPUT on the front panel, or by pressing
DVD or VCR on the remote control. However,
press OUTPUT on the front panel first, you need
to re-select the corresponding mode by pressing
DVD or VCR on the remote control.
if you
51.
PAUSE Button
● DVD mode [page 22]
Press to pause Disc playback. Press repeatedly to
advance the DVD picture step by step (or one
frame at a time).
●VCR mode [page 18]
While recording, press to temporarily stop the
recording (pause). Press a second time to resume
normal recording. You can not pause a One-Touch
Recording. Or, press during tape playback to
freeze the picture. Press to advance the picture one
frame at a time during still mode.
52. SLOW Button [page 18]
During tape playback, press to view the video tape in
slow motion. Press again to resume normal playback.
This button does not affect DVD playback.
53. VCR/TV Button [page 19]
Use to select VCR or TV position.
●VCR Position
To view playback, to monitor video recording or to
watch TV using the VCR tuner.
● TV Position
To w atch TV or to view one program while recording another.
54. SKIP/CH. Buttons
● DVD mode
Press to skip Chapters or Tracks.
● VCR mode
Press to change TV channels on the VCR.
55. AUDIO Button [page 27]
Press to select a desired audio language or sound
mode.
Notes
¡To use the remote control to operate the DVD/VCR
COMBINATION UNITS and its features, press DVD
on the remote control before pressing other DVD operation button. Verify that the green DVD OUTPUT
Light is on.
¡To use the remote control to operate the VCR and its
features, press VCR on the remote control before
pressing other VCR operation button. Verify that the
green VCR OUTPUT Light is on.
–10–
EN
1L25
ANT-IN
ANT-OUT
VIDEO OUT
AUDIO OUT
S-VIDEO
OUT
AUDIO
OUT
DIGITAL
AUDIO OUT
COAXIAL
Y
CbCrL
R
COMPONENT
VIDEO OUT
AUDIO IN
VIDEO IN
DVD/VCRVCRDVD
R
L
66
65
64
63
62
61
5756585960
H9410UD(EN).qx33 03.1.14 9:21 PM Page 11
REAR VIEW
56. ANT-IN (Antenna In) Jack
Connect your antenna, Cable Box, or Direct
Broadcast System.
57. DVD/VCR AUDIO OUT Jacks
Connect the supplied audio cables here and to the
Audio In jacks of a television or other audio equipment.
58. AUDIO IN Jack
Connect an audio cable coming from the audio out
jack of a camcorder, another VCR, or an audio source
here.
59. AC Power Cord
Connect to a standard AC outlet to supply power to
the DVD/VCR COMBINATION UNITS.
60. COMPONENT VIDEO OUT Jacks
Connect optional component video cables here and
to the component Video In jacks of a television.
61. COAXIAL Jack
Connect an optional coaxial digital audio cable here
and to the Coaxial Digital Audio In jack of a decoder
or audio receiver.
LOADING THE BATTERIES
1. Open the battery compartment cover.
62. DVD AUDIO OUT Jacks
Connect the supplied audio cables here and to the
Audio In jacks of a television or other audio equipment (DVD only).
63. S-VIDEO OUT Jack
Connect an optional S-Video cable here and to the SVideo In jack of a television.
64. VIDEO IN Jack
Connect a cable coming from the video out jack of a
camcorder, another VCR, or an audio-visual source
(laser disc player, video disc player, etc.) here.
65. DVD/VCR VIDEO OUT Jack
Connect the yellow video cable (supplied) here and
to the TV’s Video In jack.
66. ANT-OUT (Antenna Out) Jack
Use the supplied RF coaxial cable to connect this
jack to the ANTENNA IN Jack on your TV.
Caution: Do not touch the inner pins of the jacks
on the rear panel. Electrostatic discharge may
cause permanent damage to the player.
2. Insert two AA batteries (supplied), with each one oriented correctly.
3. Close the cover.
Notes
¡Do not mix alkaline and manganese batteries.
¡Do not mix old and new batteries.
–11–
EN
1L25
H9410UD(EN).qx33 03.1.14 9:21 PM Page 12
VCR/DVD SWITCHING
Since this product comprises VCR and DVD players, it is necessary to select the correct
output mode.
SWITCHING TO VCR MODE
Press VCR on the remote control.
(Verify that the VCR OUTPUT Light is lit.)
SWITCHING TO DVD MODE
Press DVD on the remote control.
(Verify that the DVD OUTPUT Light is lit.)
Notes
¡Pressing only OUTPUT on the front panel does not switch the mode of the remote control. You always need
to select the correct mode on the remote control too.
OPEN/CLOSE
OUTPUT
STOP
FWD
REV PLAY
PLAY
DISC IN
DVD
VCR
FF
REW
REC
TIMER REC
VIDEOAUDIO
DVD OUTPUT Light
POWER
CH-UP
STOP/EJECT
PLAY
CH-DOWN
POWER
SPEED AUDIO
123
456
SKIP/CH.
789
VCR/TV
SLOW
+
DVD button
DISPLAY
010
DVDVCR
PAUSE
DVD
OUTPUT
VCR
VCR OUTPUT Light
OUTPUT button
–12–
VCR button
RECORD
MENU
SETUP
SUBTITLE
T-SET
ZOOMMODE
ANGLE
PLAY
STOP
ENTER
SEARCH
MODE
REPEAT
RETURNTITLE
CLEAR/
C.RESET
A-B
EN
1L25
ANT-IN
ANT-OUT
VIDEO OUT
AUDIO OUT
S-VIDEO
OUT
AUDIO
OUT
DIGITAL
AUDIO OUT
COAXIAL
Y
CbCrL
R
COMPONENT
VIDEO OUT
AUDIOIN
VIDEO IN
DVD/VCR VCRDVD
R
L
To VIDEO OUT jack
To VIDEO INPUT jack
To Right (red) and Left (white)
Antenna/Cable signal
To ANT. IN
of TV
To AUDIO INPUT jacks
To AUDIO OUT jacks
A/V-compatible or
wide screen TV
UHF/VHF
ANT-IN
ANT-OUT
VIDEO OUT
AUDIO OUT
AUDIO IN
VIDEO IN
DVD/VCR VCR
R
L
[VHF/UHF
combination antenna]
[Back of the DVD/VCR]
IN
OUT
[Cable box or satellite box]
OR
[Indoor antenna]
[Back of the
UHF/VHF combination TV]
RF cable
(supplied)
From Cable or
Satellite Company
OR
H9410UD(EN).qx33 03.1.14 9:21 PM Page 13
CAUTION:
¡Be sure to turn off the DVD/VCR COMBINATION UNITS and equipment to be connected before connecting.
¡Read through the operation manual for the equipment to be connected.
¡Be sure that the colors of the jacks and plugs match up when using VIDEO/AUDIO cables.
¡Be sure to keep the DVD/VCR COMBINATION UNITS connection cables separate from the TV antenna cable
when you install the DVD/VCR COMBINATION UNITS, because it may cause electrical interference when
you are watching television programs.
HOOKUPS
DVD/VCR TO TV CONNECTION
1. Disconnect the AC power cord of the TV from the
AC outlet.
2. Disconnect the antenna or cable from the TV.
3. Connect the antenna or cable to the ANT-IN jack of
the DVD/VCR COMBINATION UNITS.
4. Connect theDVD/VCR COMBINATION UNITS to
the TV using the RF cable.
5. Plug the AC power cords of the DVD/VCR COMBINATION UNITS and TV into the AC outlets.
If your TV does not have A/V terminals:
1. Connect the DVD/VCR COMBINATION UNITS
2. Select channel 3 on your TV.
3. Press PLAY.
¡If noise appears, change the RF output channel of
RF OUTPUT CHANNEL
to a TV using RF cable (see DVD/VCR TO TV
CONNECTION).
the VCR to channel 4 by pressing PLAY for 3 seconds during playback.
¡There is case that the RF output channel does not
change by situation (For example, when you adjust
tracking using CHANNEL(UP/DOWN)).
In this case, stop the playback, and start the playback again. After that, press PLAY on the VCR for
3 seconds.
¡If there is a power failure or the DVD/VCR COM-
BINATION UNITS is unplugged for more than 30
seconds, the RF output channel setting will return to
CH3.
Note to CATV system installer
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground should be connected
to the grounding system of the building, as close to the point of cable entry as practical.
CONNECTING TO A TV
Notes
¡Connect the DVD/VCR COMBINATION UNITS directly to a TV. If the A/V cables are connected to a
VCR, pictures may be distorted due to the copy protection system.
–13–
[Fig. 1]
EN
1L25
ANT-IN
ANT-OUT
VIDEO OUT
AUDIO OUT
S-VIDEO
OUT
AUDIO
OUT
DIGITAL
AUDIO OUT
COAXIAL
Y
CbCrL
R
COMPONENT
VIDEO OUT
AUDIO IN
VIDEO IN
DVD/VCR VCRDVD
R
L
A/V-compatible
or
wide screen TV
To COMPONENT VIDEO
INPUT jacks
To COMPONENT VIDEO
OUT jacks
To Right (red) and Left (white)
AUDIO INPUT jacks
To Right (red) and Left (white)
AUDIO OUTPUT jacks
ANT-IN
ANT-OUT
VIDEO OUT
AUDIO OUT
S-VIDEO
OUT
AUDIO
OUT
DIGITAL
AUDIO OUT
COAXIAL
Y
CbCrL
R
COMPONENT
VIDEO OUT
AUDIO IN
VIDEO IN
DVD/VCR VCRDVD
R
L
To COAXIAL DIGITAL AUDIO INPUT jack
To COAXIAL DIGITAL
AUDIO OUT jack
Amplifier equipped with digital
input jacks, MD deck,
DAT deck, etc.
ANT-IN
ANT-OUT
VIDEO OUT
AUDIO OUT
S-VIDEO
OUT
AUDIO
OUT
DIGITAL
AUDIO OUT
COAXIAL
Y
CbCrL
R
COMPONENT
VIDEO OUT
AUDIO IN
VIDEO IN
DVD/VCR VCRDVD
R
L
To S-VIDEO OUT jackTo S-VIDEO INPUT jack
To Right (red) and Left (white)
To AUDIO OUT jacksTo AUDIO INPUT jacks
A/V-compatible or
wide screen TV
H9410UD(EN).qx33 03.1.14 9:21 PM Page 14
CONNECTING TO A TV THAT HAS AN S-VIDEO INPUT JACK OR
COMPONENT VIDEO IN JACKS
FOR TVs WITH S-VIDEO INPUT JACK
Use an S-Video cable (commercially available) in place of the yellow video cable to enjoy higher quality pictures.
The S-Video connection only supplies video (picture) in the DVD mode of the DVD/VCR COMBINATION
UNITS. Therefore, in order to use the VCR features or view TV channels on the DVD/VCR COMBINATION
UNITS, you still need to either connect the RF cable between the ANT-OUT jack of the DVD/VCR COMBINATION UNITS and the TV’s Antenna In jack, or connect the yellow video cable as described earlier (Fig.1).
To connect the supplied RF cable, see “DVD/VCR TO TV CONNECTION” on page 13.
[Fig. 2]
FOR TVs WITH
COMPONENT VIDEO IN JACKS
Use a component video cable (commercially available) in place of the yellow video cable to enjoy higher quality pictures.
The component video connection only supplies video (picture) in the DVD mode of the DVD/VCR COMBINATION
UNITS. Therefore, in order to use the VCR features or view TV channels at the DVD/VCR COMBINATION UNITS,
you still need to either connect the RF coaxial cable between the ANT-OUT jack of the DVD/VCR COMBINATION
UNITS and the TV’s Antenna In jack, or connect the yellow video cable as described earlier (Fig. 1). To connect the
supplied RF cable, see “DVD/VCR TO TV CONNECTION” on page 13.
[Fig. 3]
CONNECTING TO AN AMPLIFIER EQUIPPED WITH DIGITAL
INPUT JACKS SUCH AS MD DECK OR DAT DECK
Use an audio coaxial digital cable (commercially available) for the audio connections.
Connecting to an amplifier equipped with digital input jacks such as MD Deck or DAT Deck.
Notes
¡The audio source on a disc in the 5.1 channel Dolby Digital surround format cannot be recorded as digital
sound by an MD or DAT deck.
¡Set DOLBY DIGITAL to OFF for audio output in the setup mode. Playing a DVD disc using incorrect set-
tings may generate noise distortion, and may also damage the speakers. (See page 29 to set DOLBY DIGITAL
to ON)
–14–
[Fig. 4]
EN
1L25
Loading...
+ 30 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
