OWNER’S

As an ENERGY STAR

Partner, our company has determined that this product meets the E

NERGY STAR guidelines for

energy efficiency. E

NERGY STAR is

a U.S. registered mark.

MANUAL

“EMERSON AND THE G-CLEF LOGO ARE REGISTERED TRADEMARKS

OF EMERSON RADIO CORP., PARSIPPANY, NEW JERSEY, U.S.A.”

COLOR TV/DVD/VCR TRIPLE COMBO

EWC19T3 EWC27T3

(19 inch) (27 inch)

This Owner’s Manual is

made of recycled paper.

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

27” MODEL ILLUSTRATED

SUPPLIED ACCESSORIES

ACCESSORIES Remote Control Unit Batteries Owner’s Manual 0EMN02182

If you need additional operating assistance after reading this owner’s manual or to order replacement accessories, please call

TOLL FREE : 1-800-256-2487. Or visit our WEB SITE at http://www.funai-corp.com

Please read before using this equipment

PART NO. NE211UD 2 AA Batteries

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE

PORTABLE CART WARNING

S3126A

SYMBOLE D'AVERTISSEMENT POUR

LES COMPOSANTES

APPAREIL ET MEUBLE A ROULETTES

S3126A

TO RAIN OR MOISTURE.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The caution marking is located on the rear of the cabinet.

1.Read instructions-All the safety and operating instructions should be read before the appliance is operated.

2.Retain Instructions-The safety and operating instructions should be retained for future reference.

3.Heed Warnings-All warnings on the appliance and in the operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions should be followed.

5.Cleaning-Unplug TV/DVD/VCR from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6.Attachments-Do not use attachments not recommended by the TV/DVD/VCR manufacturer as they may cause hazards.

7.Water and Moisture-Do not use this TV/DVD/VCR near water-for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8.Accessories-Do not place this TV/DVD/VCR on an unstable cart, stand, tripod, bracket, or table. The TV/DVD/VCR may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the TV/DVD/VCR. Any mounting of the appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care.Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

GEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

IMPORTANT SAFEGUARDS

AMEUBLES- Cet appareil ne doit

être placé que sur un meuble (avec ou sans roulettes) recommandé par le fabricant. Si vous l’installez sur un meuble à roulettes, déplacez les deux ensembles avec précaution. Un arrêt brusque, l’utilisation d’une force excessive et des surfaces irrégulières risquent de désta- biliser l’ensemble et de le renverser.

9. Ventilation-Slots and openings in the cabinet and the back or bottom are provided for ventilation and to ensure reliable operation of the TV/DVD/VCR and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the TV/DVD/VCR on a bed, sofa, rug, or other similar surface. This TV/DVD/VCR should never be placed near or over a radiator or heat register. This TV/DVD/VCR should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10.Power Sources-This TV/DVD/VCR should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For TV/DVD/VCRs intended to operate from battery power, or other sources, refer to the operating instructions.

11.Grounding or Polarization-This TV/DVD/VCR is equipped with a polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12.Power-Cord Protection-Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

THIS SYMBOL INDICATES THAT DAN-

- 2 - EN

1B15

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

S2898A

FIGURE A

ELECTRIC SERVICE EQUIPMENT

NEC - NATIO NAL ELE CTRI CAL CO DE

GROUND

CLAMP

ANTENNA

LEAD IN WIRE

ANTENNA

DISCHARGE UNI T (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTIO N 810- 21)

GROUND CL AMPS

POWER SERVICE GRO UNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

13.Outdoor Antenna grounding-If an outside antenna or cable system is connected to the TV/DVD/VCR, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14.Lightning-For added protection for this TV/DVD/VCR receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV/DVD/VCR due to lightning and power-line surges.

15.Power Lines-An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16.Overloading-Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

17.Object and Liquid Entry-Never push objects of any kind into this TV/DVD/VCR through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the TV/DVD/VCR.

18.Servicing-Do not attempt to service this TV/DVD/VCR yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19.Damage Requiring Service-Unplug this TV/DVD/VCR from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a. When the power-supply cord or plug is damaged or frayed. b. If liquid has been spilled, or objects have fallen into the

TV/DVD/VCR.

c. If the TV/DVD/VCR has been exposed to rain or water. d. If the TV/DVD/VCR does not operate normally by follow-

ing the operating instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the TV/DVD/VCR to its normal operation.

e. If the TV/DVD/VCR has been dropped or damaged in any

way.

f. When the TV/DVD/VCR exhibits a distinct change in per-

formance-this indicates a need for service.

20.Replacement Parts-When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, injury to persons or other hazards.

21.Safety Check-Upon completion of any service or repairs to this TV/DVD/VCR, ask the service technician to perform routine safety checks to determine that the TV/DVD/VCR is in proper operating condition.

22.Heat-This TV/DVD/VCR product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

- 3 - EN

1B15

PRECAUTIONS

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.

FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

LASER SAFETY

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

CAUTION: TO PREVENT ELECTRIC SHOCK,

MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA

PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

- 4 - EN

1B15

LOCATION

For safe operation and satisfactory performance of your TV/DVD/VCR, keep the following in mind when selecting a place for its installation:

Shield it from direct sunlight and keep it away from

•

sources of intense heat. Avoid dusty or humid places.

•

Avoid places with insufficient ventilation for proper

•

heat dissipation. Do not block the ventilation holes at the top and bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

Install unit in a horizontal position.

•

Avoid locations subject to strong vibration.

•

Do not place the TV/DVD/VCR near strong magnetic

•

fields. Avoid moving TV/DVD/VCR to locations where

•

temperature differences are extreme.

AVOID THE HAZARDS OF

ELECTRICAL SHOCK AND FIRE

Do not handle the power cord with wet hands.

•

Do not pull on the power cord when disconnecting

•

it from an AC wall outlet. Grasp it by the plug. If, by accident, water is spilled on your unit, unplug

•

the power cord immediately and take the unit to our Authorized Service Center for servicing.

Do not put your fingers or objects into the

•

TV/DVD/VCR disc loading tray. Do not place anything directly on top of the unit.

•

WARNING

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, or after heating a cold room or under conditions of high humidity. If a DVD is played in a TV/DVD/ VCR which has moisture, it may damage the DVD and TV/DVD/VCR. Therefore when the condensation occurs inside the unit, turn the POWER on and allow at least 2 hours for the unit to dry out.

SYMBOLS USED IN THIS MANUAL

The following symbols below appear in some headings and notes in this manual, with the following meanings

TV/VCR

: Description refers to TV/VCR operation (in the

TV/VCR mode).

DVD-V

: Description refers to playback of DVD video discs

(in the DVD mode).

: Description refers to playback of audio CDs

(in the DVD mode).

MP3

: Description refers to playback of MP3 discs

(in the DVD mode).

QUICK

: Description refers to the items to be set by the

QUICK mode (in the DVD mode).

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

The serial number of this product may be found on the back of the unit. No other TV/DVD/VCR has the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase Dealer Purchase from Dealer Address Dealer Phone No. Model No. Serial No.

- 5 - EN

1C29

TABLE OF CONTENTS

C IMPORTANT SAFEGUARDS . . .2, 3

C PRECAUTIONS . . . . . . . . . . . . . . . .4

LOCATION . . . . . . . . . . . . . . . . . . .5

AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE .5

WARNING . . . . . . . . . . . . . . . . . . . .5

SYMBOLS USED IN THIS

MANUAL . . . . . . . . . . . . . . . . . . . . .5

C TABLE OF CONTENTS . . . . . . . . . .6

C FEATURES . . . . . . . . . . . . . . . . . . . .7

C OPERATING CONTROLS AND

FUNCTIONS . . . . . . . . . . . . . . . .9, 10

C PREPARATION FOR USE . . . . . . .11

ANTENNA/CABLE

CONNECTION . . . . . . . . . . . . . . . .11

CONNECTING TO EXTERNAL

INPUT JACKS . . . . . . . . . . . . . . . .12

INSTALLING THE BATTERIES . .12

EXTERNAL INPUT MODE . . . . . .12

CONNECTING TO A STEREO

SYSTEM . . . . . . . . . . . . . . . . . . . .13

CONNECTING TO A STEREO AMPLIFIER EQUIPPED WITH DIGITAL INPUT JACKS SUCH AS MD DECK OR DAT DECK (for DVD) .13

CONNECTING TO A DOLBY DIGITAL DECODER OR DTS DECODER (for DVD) . . .14

TV/VCR SECTION

C SET UP FOR USE . . . . . . . . . . . . .15

CHANNEL SET UP

FOR THE FIRST TIME . . . . . . . . .15

DELETING (OR ADDING)

CHANNEL . . . . . . . . . . . . . . . . . . .15

CHANNEL SET UPAGAIN . . . . . .16

SELECTING THE LANGUAGE . .16

DAYLIGHT-SAVING TIME . . . . . .16

CLOCK SET UP

(AUTO / MANUAL) . . . . . . . . .17, 18

C TV OPERATION . . . . . . . . . . . . . . .19

WATCHING A TV PROGRAM . . .19

DEGAUSSING . . . . . . . . . . . . . . . .19

PICTURE CONTROL . . . . . . . . . . .19

CLOSED CAPTION SYSTEM . . . .20

V-CHIP SET UP . . . . . . . . . . . . . . .21

C MTS(Multi-Channel Television

sound)SYSTEM . . . . . . . . . . . . . . . .23

CHECKING THE SELECTED

MTS MODE . . . . . . . . . . . . . . . . . .23

MTS RECORDING/MONITOR

MODE . . . . . . . . . . . . . . . . . . . . . .23

SELECTING THE MTS SYSTEM .24

C VIDEO CASSETTE . . . . . . . . . . . . .25

C PLAYBACK . . . . . . . . . . . . . . . . . . .26

NORMAL PLAYBACK . . . . . . . . .26

TRACKING ADJUSTMENT . . . . .26

SLOW MOTION . . . . . . . . . . . . . .26

PICTURE SEARCH . . . . . . . . . . . .26

STILL PICTURE . . . . . . . . . . . . . .26

VERTICAL HOLD CONTROL . . .26

C SPECIAL PLAYBACK . . . . . . . . . .27

RENTAL PLAYBACK . . . . . . . . . .27

AUTO REPEAT PLAYBACK . . . . .27

C SEARCH . . . . . . . . . . . . . . . . . . . . .28

ZERO RETURN . . . . . . . . . . . . . . .28

TIME SEARCH . . . . . . . . . . . . . . .28

INDEX SEARCH . . . . . . . . . . . . . .29

C SPECIAL FEATURES . . . . . . . . . .29

REAL TIME TAPE COUNTER . . .29

AUTO REWIND-EJECT . . . . . . . .29

C RECORDING . . . . . . . . . . . . . . . . .30

NORMAL RECORDING . . . . . . . .30

SKIPPING UNWANTED SCENES DURING

RECORDING . . . . . . . . . . . . . . . . .30

OTR (One Touch Recording) . . . . . .31

COPYING A VIDEO CASSETTE (Requires a VCR or camcorder) . . .31

C TIMER . . . . . . . . . . . . . . . . . . . . . .32

AUTOMATIC

TIMER RECORDING . . . . . . . . . .32

TIMER PROGRAM EXTENSION .33 HINTS FOR AUTOMATIC TIMER

RECORDING . . . . . . . . . . . . . . . . .34

AUTO RETURN . . . . . . . . . . . . . . .34

SLEEP TIMER . . . . . . . . . . . . . . . .34

C ON SCREEN DISPLAY . . . . . . . . .35

C CABLE CHANNEL

DESIGNATIONS . . . . . . . . . . . . . .35

DVD SECTION

C ABOUT THE DISCS . . . . . . . . . . . .36

PLAYABLE DISCS . . . . . . . . . . . .36

DISC TYPES . . . . . . . . . . . . . . . . .36

C PLAYING A DISC . . . . . . . . . . . . . .37

BASIC PLAYBACK . . . . . . . . . . . .37

GENERAL FEATURES . . . . . . . . .37

DISC MENU . . . . . . . . . . . . . . . . .37

TITLE MENU . . . . . . . . . . . . . . . . .37

RESUME . . . . . . . . . . . . . . . . . . . .38

PAUSE . . . . . . . . . . . . . . . . . . . . . .38

STEP BY STEP PLAYBACK . . . . .38

FAST FORWARD/REVERSE

SEARCH . . . . . . . . . . . . . . . . . . . .38

SLOW FORWARD / SLOW

REVERSE . . . . . . . . . . . . . . . . . . . .38

ZOOM . . . . . . . . . . . . . . . . . . . . . .38

C SEARCH FUNCTION . . . . . . . . . . .39

TRACK SEARCH . . . . . . . . . . . . .39

TITLE / CHAPTER SEARCH . . . .39

TIME SEARCH . . . . . . . . . . . . . . .39

MARKER SETUP SCREEN . . . . . .39

SPECIAL PLAYBACK FUNCTION . . .40

REPEAT . . . . . . . . . . . . . . . . . . . . .40

PROGRAM . . . . . . . . . . . . . . . . . . .40

RANDOM PLAYBACK . . . . . . . . .40

C PLAYING A MP3 DISC . . . . . . . . . .41

MP3 PLAYBACK . . . . . . . . . . . . . .41

TRACK SELECTION . . . . . . . . . . .41

PROGRAM . . . . . . . . . . . . . . . . . . .41

RANDOM PLAYBACK . . . . . . . . .41

C CHANGING THE SETTINGS . . . .42

SUBTITLE LANGUAGE . . . . . . . .42

AUDIO LANGUAGE . . . . . . . . . . .42

STEREO SOUND MODE . . . . . . . .42

CAMERA ANGLE . . . . . . . . . . . . .42

BLACK LEVEL SETTING . . . . . . .42

VIRTUAL SURROUND . . . . . . . . .42

THE ON-SCREEN INFORMATION . . .43

C CHANGING THE DVD SETUP

ITEMS . . . . . . . . . . . . . . . . . . . . . . .44

LANGUAGE SETTING . . . . . . . . .44

DISPLAY SETTING . . . . . . . . . . . .45

AUDIO SETTINGS . . . . . . . . . . . .45

PARENTAL CONTROL . . . . . . . . .46

C TROUBLESHOOTING GUIDE . . .47

C MAINTENANCE . . . . . . . . . . . . . . .50

DISC HANDLING . . . . . . . . . . . . .50

C SPECIFICATIONS . . . . . . . . . . . . .51

C WARRANTY . . . . . . . . . . .Back Cover

- 6 - EN

1C29

FEATURES

TV/VCR Mode

Hi-Fi system

•

offers you excellent sound quality with a dynamic range of 80dB, frequency response from 20Hz to 20kHz, and 0.005% wow and flutter.

Rotary 4-head Record/Playback System–Four heads

•

ensure excellent picture quality and special effects playback.

Index Search–

•

Slow Motion–View recorded program at slower

•

than normal speed.

Infrared remote control

•

Trilingual on screen tv/vcr setup display selec-

•

table in English or Spanish or French Real time counter–This shows the elapsed recording

•

or playback time in hours, minutes, and seconds. “–” indication will appear when the tape is rewound further than the tape counter position “0:00:00”.

181 channel capability PLL frequency synthesiz-

•

er tuner with direct station call–

be necessary to view scrambled cable channels.)

Auto Clock Setting–Allows you to set the clock

•

function from a PBS broadcast station.

Closed caption system–You may view specially

•

labeled (cc) TV programs, movies, news, prerecorded tapes, etc. with either a dialogue caption or text display added to the program.

Auto power on and off system–Automatically

•

turns on the TV/DVD/VCR when you insert the cassette, turns off after auto-rewind, and ejects when the beginning of the tape is reached.

Auto rewind when the end of a tape is

•

reached–

timer recording.

Smooth mode change–TV/VCR mode, DVD

•

mode automatically changes without control.

–The Hi-Fi stereo recording system

Fast-forwards to start of next recording.

The

(A converter may

This function doesn’t occur when using

2 Step picture search operation–You can view a

•

video program at a high speed or super high speed in either a forward or reverse direction in LP and SLP mode. For SP mode only high speed.

Three different playback tape speeds : SP/LP/SLP

•

Two different recording tape speeds : SP/SLP

•

Auto Head Cleaner–Automatically cleans video

•

heads as you insert or remove a cassette.

Zero Return–The tape returns to counter of

•

0:00:00 by rewinding or fast forwarding.

Still–“Freeze” the picture at any time, for close

•

viewing of a particular scene.

Digital Auto Tracking (DTR)–Automatically

•

adjusts the tracking for each tape you play.

Rental play mode–Improves playback picture

•

quality from worn tapes, such as rental tapes.

Auto repeat–Allows you to repeat the playing of a

•

tape indefinitely without pressing the PLAY button.

Time search–Let you set the TV/DVD/VCR to

•

advance the tape by entering the desired playback time you want to skip.

OTR (One Touch Recording)–Instant timed

•

recording from 30 to 480 minutes is possible at the push of the REC/OTR button.

1 Year, 8 events (including Daily and Weekly

•

Timer Recording)–

record up to 8 programs at different times on different channels up to 1 year in advance. The Daily timer allows recordings to be made of daily broadcasts, and the Weekly timer allows recording to be made once a week up to the end of the tape.

Auto return–After timer recording is finished, the

•

TV/DVD/VCR can return to the beginning of the recording.

Sleep timer–Allows you to have the

•

automatically turn on or off at a desired time.

Timer Program Extension–Allow you to shift the

time schedule for automatic timer recording.

V-CHIP–Enables parents to prevent their children

•

from watching inappropriate material on TV.

The built-in timer allows you to

TV/DVD/VCR

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

- 7 - EN

1C29

DVD Mode

¡Dolby Digital sound

This player can handle Dolby Digital surround sound having 5.1 channels when connected to a Dolby Digital decoder.

¡Still/fast/slow/step playback

Various playback modes are available including still pictures, fast forward/reverse, slow motion and step frames.

¡Random playback for audio CD and MP3

This player can shuffle the order of tracks to play them in random order.

¡Program playback for audio CD and MP3

You can program the order of tracks to play them in any desired order.

¡DVD menus in a desired language

You can display DVD menus in a desired language, if available on a DVD.

¡Screen saver/Auto power-off functions

The screen saver program starts when there is no input from the player for five minutes in the stop mode. When the screen saver program is activated for 15 minutes, the power automatically turns off.

¡Subtitles in a desired language

You can select a desired language for the display subtitles, if that language is available on a disc.

¡Selecting a camera angle

You can select the desired camera angle, if a disc contains sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound mode, if different languages and modes are available on a disc.

¡Parental lock

You can set the control level to limit playback of discs which may not be suitable for children.

¡Automatic detection of discs

This player automatically detects if the loaded disc is DVD, audio CD or MP3 on disc.

¡Playback MP3 disc

¡On-screen display

Information about the current operation can be displayed on a TV screen, allowing you to confirm the currently active functions (such as program playback), on the TV screen using the remote control.

¡Search

Chapter search / Title search / Track search / Time search

¡Repeat

Chapter / Title / Track / Group / All / A-B

¡Zoom

Magnified screen can be displayed.

¡Marker

The part designated by user can be called back.

¡Resume Play

User can resume to playback from the part at which the play was stopped.

¡Virtual Surround ¡Bit rate indication ¡DRC (Dynamic range control)

You can control the range of sound volume.

NOTE:

We do not recommend the use of universal remote controls. Not all of the functions may be controlled with

•

a universal remote control. If you decide to use a universal remote control with this TV/VCR/DVD, please be aware that the code num-

ber given may not operate this TV/VCR/DVD. In this case, please call the manufacturer of the universal remote control.

- 8 - EN

1C29

OPERATING CONTROLS AND FUNCTIONS

12 4 56 10715149833 411 12 13 212019181716

SELECT

TV/VCR

DVD

AUDIO

VIDEO

HEADPHONE

DVD buttons TV/VCR buttons

AOPEN/CLOSE

CHANNEL

IREC/OTR

STOP

SKIP G

BPLAY

H SKIP

p VOLUME o

POWER

STOP

F.FWD

BPLAY

REW

AEJECT

PAUSE

PLAY

STOP

ENTER

RECORD

DISC

RETURNTITLESETUP

REPEATSEARCH MODE

CLEAR

MODE

ANGLESUBTITLEAUDIO

DISPLAY

SPEED C.RESET

POWER PICTURE SELECTSLEEP

CH.

VOL.

MUTEZOOM

123

456

789

0 +10

+100

(DVD) 3

(TV/VCR) 14

27 28

30 31

3 (DVD)

15 (TV/VCR)

45 44

- TV/DVD/VCR FRONT PANEL - [Fig.1]

- REMOTE CONTROL -

[Fig. 2]

[TV/VCR P.15 / DVD P.37]

1.POWER Button

Press to turn the power on and off.

2.VOLUME X/Y Buttons

Press to control the volume level for the DVD and TV.

3.SKIP Buttons (for DVD)

Press once to skip chapters or tracks to a desired point. Press and hold to change forward or reverse playback speed.

4.PLAY Button

[TV/VCR P.26 / DVD P.37]

[P.38]

Starts playback of the disc or tape contents.

5.STOP Button

Stops operation of the disc.

6.OPEN/CLOSE Button

Press to insert discs into or remove them from the tray.

7.Disc loading tray

8.DVD Indicator

Lights on during DVD mode.

9.SELECT Button

Press to change to TV/VCR mode, external input mode or DVD mode.

10.TV/VCR Indicator

Lights on during TV/VCR mode.

11. CHANNEL K/L Buttons

Press to select memorized channel.

12. Recording Indicator

Flashes during recording. Lights up in the Standby mode for Timer Recording.

13. REC/OTR (RECORD)Button

Press for manual recording. Activates One Touch Recording. (OTR is only during TV/VCR mode.)

14. REW Button (for TV/VCR)

Press to rewind the tape, or to view the picture rapidly in reverse during playback mode. (Rewind Search)

15. FWD Button (for TV/VCR)

Press to rapidly advance the tape, or to view the picture rapidly in forward during playback mode. (Forward Search)

16. STOP/EJECT Button

Press to stop the tape motion. Press in the Stop mode to remove tape from the TV/VCR/DVD.

17. Remote sensor window

18. HEADPHONE Jack

To connect headphone (not supplied) for personal listening.

19. VIDEO input Jack

Connect to the video output jack of a video camera or VCR.

[P.37]

[DVD P.37]

[TV/VCR P.28]

[TV/VCR P.30, 31]

[TV/VCR P.26]

- 9 - EN

1C29

ANT.

AUDIO OUT

COAXIAL

4746 48 49

- TV/DVD/VCR REAR PANEL - [Fig.3]

20. AUDIO L/R input Jacks

Connect to the audio output jacks of a video camera or VCR.

21. Cassette compartment

22. PICTURE Button

Press to adjust the picture.

23. Number Buttons

TV Mode:

[P.15]

Press two digits to directly access the desired channel. Remember to press a "0" before a single digit channel.

+100 Button–

Press to select cable channels which are equal or greater than number 100.

DVD Mode:

Press to enter the desired number.

+10 Button–

Press to enter the desired numbers which are equal or greater than number 10.

24. PAUSE Button

[TV/VCR P.26 / DVD P.38]

Pauses the current disc or tape operation.

25. SPEED Button

[TV/VCR P.30]

Press to choose the desired recording speed: SP/SLP.

26. C.RESET Button

[TV/VCR P.28]

Press to reset counter to 0:00:00. Press to cancel a setting of timer program. (See page 33.)

27. DISPLAY Button

TV/VCR Mode:

Display the counter or the current channel number and current time on the TV screen.

DVD Mode:

[P.43]

Displays the current status on the TV screen for checking purposes.

28. SETUP Button

Press to enter or exit the TV menu or DVD setup mode.

29. TITLE Button

[TV/VCR P.15] [DVD P.44-46]

[DVD P.37]

Displays the title menu.

30. CLEAR Button

Resets a setting.

31. MODE Button

[DVD P.41]

Activates program playback or random playback mode.

32. SEARCH MODE Button

[DVD P.39]

Press to locate a desired point.

33. AUDIO Button

[DVD P.42]

Press to select a desired audio language or sound mode.

34. SUBTITLE Button

[DVD P.42]

Press to select a desired subtitle language.

35. REPEAT Button

[DVD P.42]

Repeats playback of the current disc, title, chapter or track.

36. ANGLE Button (DVD mode)

[DVD P.42]

Press to change the camera angle to see the sequence being played back from a different angle.

37. A-B REPEAT Button

[DVD P.40]

Repeats playback of a selected section.

38. RETURN Button

Returns to the previous operation in the DVD setup mode.

39. ENTER Button

Press to accept a setting.

40. Arrow Buttons

TV/VCR Mode:

Press to select a setting mode from the menu on the TV screen. Press to select or adjust from a particular menu.

DVD Mode:

Use when making settings while watching the display on a TV screen.

41. DISC MENU Button

[DVD P.37]

Displays the menus in the DVD.

42. ZOOM Button

[DVD P.38]

Enlarges part of a DVD-reproduced image.

43. MUTE Button

Mutes the sound. Press it again to resume sound.

44. SLEEP Button

Sets the Sleep Timer.

45. SELECT Button

Press to switch TV/VCR and DVD mode. You can

[TV/VCR P.34]

see the mode (TV/VCR or DVD) on the front panel indicator.

- 10 - EN

1C29

ANT.

AUDIO OUT

COAXIAL

ANT.

OUT

46. ANT. in Jack

Connect to an antenna, cable system, or satellite system.

47. Power cord

Connect to a standard AC outlet (120V/60Hz).

NOTE: Remove the power cord from the hook to

avoid breaking a wire before you connect to a standard AC outlet.

PREPARATION FOR USE

ANTENNA/CABLE CONNECTION

48. COAXIAL digital audio out Jack

Connect to the digital input of an external amplifier or decoder for DVD audio only.

49. AUDIO L/R output Jack

Connect to the analog audio input of an external amplifier or decoder.

Satellite Box or Cable Box (Not supplied)

From Cable System or Satellite Dish

75-ohm From Cable System

Coaxial

Cable

(Not sup-

plied)

75-ohm Coaxial Cable (Not

supplied)

VHF/UHF SEPARATE ANTENNAS

In some areas it will be necessary to use an outdoor antenna.

CABLE WITHOUT CONVERTER/ DESCRAMBLER BOX

Use this connection if your cable system connects directly to your TV/DVD/VCR without a converter box.

By using this connection you can:

1) Use the TV/DVD/VCR remote to select channels.

2) Program one or more unscrambled channels for Automatic Timer Recording.

NOTE: This TV/VCR/DVD will ONLY record and view the same channel.

VHF/UHF Antenna (Not supplied)

VHF Antenna (Not supplied)

UHF Antenna (Not supplied)

VHF/UHF Combiner (Not supplied)

[Fig. 4]

Flat twin-lead cable

CABLE WITH CONVERTER/ DESCRAMBLER BOX OR SATELLITE BOX

If your cable service supplies you with a converter box or if you use a satellite system, you can use the basic connection shown in the illustration.

By using this connection you can also record scrambled channels. However, channel selection must be made with the converter box or satellite box. This means that channels cannot be changed using the TV/DVD/VCR Remote Control. Unattended timer recording is limited to one channel at a time.

Antenna/Cable Connections Continued on the Next Page.

- 11 - EN

1C29

TO RECORD A SCRAMBLED/UNSCRAM-

L-AUDIO-R

VIDEO

HEADPHONE

BLED CHANNEL

1. Set the TV/DVD/VCR channel selector to the out-

put channel of the Cable Converter Box or Satellite Box. (Ex. CH3)

2.Select the channel to record from your Cable

Converter Box or Satellite Box.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

INSTALLING THE BATTERIES

1)Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.

2)Insert 2 “AA” penlight batteries into the battery compartment in the direction indicated by the polarity (+/-) markings.

3)Replace the cover.

EXTERNAL INPUT MODE

CONNECTING TO EXTERNAL

INPUT JACKS

When you watch a program recorded on an another source (VCR or video camera), use the audio/video input jacks on the front of the TV/DVD/VCR.

Connect the audio/video output jacks of another source to the AUDIO L/R and VIDEO jacks of this TV/DVD/VCR.

Then press the CHANNEL buttons K/L until "AUX" appears on the screen.

NOTE:

When you connect a monaural VCR (another

•

source) to this TV/DVD/VCR, connect the Audio output jack of the monaural VCR (another source) to the AUDIO L jack of this TV/DVD/VCR. The audio will output in both L and R channel equally.

To the audio output jacks

[Another source]

Audio/Video coaxial cable (not supplied)

etc.

To the video output jack

[Front of the TV/DVD/VCR]

[Fig. 5]

When using an external input signal (another VCR or video camera), connect the player’s audio/video output cables to the AUDIO L/R IN/ VIDEO IN jacks of your

AUX

TV/DVD/VCR. Then press the CHANNEL button K or L until “AUX” appears on the screen.

- 12 - EN

1C29

CONNECTING TO A STEREO SYSTEM

ANT.

AUDIO OUT

COAXIAL

To Right (red) and Left (white) AUDIO OUT jacks

Stereo system

To ANALOG AUDIO INPUT jacks

ANT.

AUDIO OUT

COAXIAL

Amplifier equipped with digital

input jacks, MD deck,

DAT deck, etc.

To COAXIAL DIGITAL AUDIO INPUT jack

To DIGITAL AUDIO OUT (PCM/BITSTREAM) COAXIAL jack

(only DVD AUDIO OUT)

[Fig. 6]

NOTES:

Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner's Manuals for your stereo system and any other components to be connected to the

•

TV/DVD/VCR.

CONNECTING TO A STEREO AMPLIFIER EQUIPPED WITH DIGI-

TAL INPUT JACKS SUCH AS MD DECK OR DAT DECK (for DVD)

Use an audio coaxial digital cable available at retail for the audio connections. Connecting to an amplifier equipped with digital input jacks such as MD Deck or DAT Deck.

NOTES:

The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital

•

sound by an MD or DAT deck. Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner's Manuals for the components to be connected to the TV/DVD/VCR.

•

Set Dolby Digital to OFF for audio output in the setup mode. Playing a TV/DVD/VCR using incorrect set-

•

tings may generate noise distortion, and may also damage the speakers.

- 13 - EN

[Fig. 7]

1C29

ANT.

AUDIO OUT

COAXIAL

Front speaker

(left)

Center

speaker

Front speaker

(right)

Surround

speaker

(left)

Surround

speaker

(right)

Subwoofer

To DIGITAL AUDIO OUT (PCM/BITSTREAM) COAXIAL jack

To COAXIAL DIGITAL AUDIO INPUT jack

Dolby Digital

decoder

CONNECTING TO A DOLBY DIGITAL DECODER (for DVD)

If using this TV/DVD/VCR to play a DVD disc in a 5.1 channel Dolby Digital surround format, the TV/DVD/VCR outputs a DOLBY DIGITAL Data stream from its COAXIAL digital audio out jack. By hooking the player up to a Dolby Digital decoder, you can enjoy a more convincing, realistic ambience with powerful and high-quality surround sound as enjoyed in movie theaters.

Use audio coaxial digital cables available at retail for the audio connections.

[Fig. 8]

NOTES:

•

Manufactured under license from Dolby Laboratories.“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

Be sure to turn off the power to all components in the system before connecting another component. Refer to the Owner's Manuals for the components to be connected to the TV/DVD/VCR. If connected to a Dolby Digital decoder, set DOLBY DIGITAL to ON for audio output in the setup mode.

(See page 45 to set DOLBY DIGITAL to ON.) Unless connected to a Dolby Digital decoder, set DOLBY DIGITAL to OFF for audio output in the setup

mode. Playing a TV/DVD/VCR using incorrect settings may generate noise distortion, and may also damage the speakers.

- 14 - EN

1C29

TV/VCR SECTION

SET UP FOR USE

You can program the tuner to scan all the channels you receive in your area. NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just

select the TV/DVD/VCR channel selector to the output channel of the cable box or satellite box (Ex CH3). Then select the channel to be viewed on the Cable Box or Satellite Box.

CHANNEL SET UP FOR THE

FIRST TIME

TV/VCR

1 Plug in the TV/DVD/VCR power

cord

Plug the TV/DVD/VCR power cord into a standard AC outlet.

NOTE:

If some digits appear in the corner of

•

the screen, press the POWER button without unplugging the power cord.

2 Turn on the TV/DVD/VCR

Press the POWER button to turn on the TV/DVD/VCR.

3 Select “ENGLISH” or “ESPAÑOL” or

“FRANÇAIS”

Select “ENGLISH” or “ESPAÑOL”=Spanish or “FRANÇAIS” =French using the

ENTER button. “[ ]” indicate the selected language.

4 Begin auto preset

Press the Arrow button K or L to point to “AUTO PRESET”.

Then press the ENTER button. The tuner scans and memorizes all

active channels in your area.

NOTES:

The TV/DVD/VCR distinguishes between standard

•

TV channels and cable channels. If you want to play or record a video tape

•

BEFORE presetting the tuner, you must press the SETUP button on the remote control. To preset the tuner again, see “CHANNEL SET UP AGAIN” on page 16.

The TV/DVD/VCR may memorize TV channels as

•

CATV channels if reception conditions is poor. If this happens, try AUTO MEMO action again when reception conditions are better.

5 After scanning

The tuner stops on the lowest memorized channel. If you want to recall the selected channels, you can

select the desired channel directly with the remote control number buttons or the CHANNEL button K or L.

– SET UP –

B LANGUAGE

[ENGLISH] ESP FRA

AUTO PRESET

– SET UP –

LANGUAGE [ENGLISH] ESP FRA

B AUTO PRESET

DELETING (OR ADDING)

CHANNEL

TV/VCR

The channels you no longer receive or seldom watch can be deleted from the memory. (Of course, you can

add the deleted channel into the memory again.)

1 Select “CHANNEL SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “CHANNEL SET UP”.

Then, press the ENTER button.

2 Select “ADD/DELETE CH”

Press the Arrow button K or L to point to “ADD/DELETE CH”.

Press the ENTER button.

3 Enter the desired channel number

Press the Arrow button K or L until your desired channel number appears. (You can also use the number buttons or the CHANNEL buttons K/L to enter it) (Example: CH8)

4 Delete (or add) it from (into) memory

Press the ENTER button. The channel number changes to light red. The channel is deleted from memory.

Added channel: Light blue. Deleted channel: Light red.

To delete another channel, repeat steps [3] and [4].

•

If you press the ENTER button again, the channel

•

is memorized again. Press the RETURN button to return to TV/VCR

•

SETUP MENU.

5 Exit the channel setup mode

Press the SETUP button on the remote control to returns to TV mode.

NOTE: To confirm that channel(s) has been deleted or added, press the CHANNEL button K or L.

- 15 - EN

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK

B CHANNEL SET UP

USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– CHANNEL SET UP –

B ADD / DELETE CH (TV)

AUTO PRESET

ADD / DELETE

1C29

CHANNEL SET UP AGAIN

Make sure ...

Press the POWER button to turn on the

•

TV/DVD/VCR.

TV/VCR

NOTE: If Spanish or French is selected accidentally,

1)Press the SETUP button on the remote control.

2) Press the Arrow button K or L to point to “IDIOMA [ESPAÑOL]” or “LANGAGE” [FRANÇAIS].

3) Press the ENTER button to select your desired language.

4)Press the SETUP button to exit.

1 Select “CHANNEL SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “CHANNEL SET UP”.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK

B CHANNEL SET UP

USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

Then, press the ENTER button.

2 Begin auto preset

Press the Arrow button K or L to point to “AUTO PRESET”.

– CHANNEL SET UP –

ADD / DELETE CH (TV)

B AUTO PRESET

Then, press the ENTER button. The tuner scans and memorizes all

the active channels in your area.

3 After scanning

The tuner stops on the lowest memorized channel.

SELECTING THE LANGUAGE

TV/VCR

Make sure ...

Press the POWER button to turn on the

•

TV/DVD/VCR.

NOTE: This function effects only the language on the screen menu and not the audio source.

1 Select “LANGUAGE”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “LANGUAGE”.

2 Select “ENGLISH” or “ESPAÑOL” or

“FRANÇAIS”

Select “ENGLISH” or “ESPAÑOL”= Spanish or “FRANÇAIS”= French using the ENTER button.

3 Exit the Language mode

Press the SETUP button on the remote control to return to TV mode.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP

B LANGUAGE [ENGLISH]

CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

DAYLIGHT-SAVING TIME

TV/VCR

Select this feature and the TV/DVD/VCR’s clock automatically will advance one hour in April, then reverse one hour in October.

When Daylight-Saving Time is ON, the clock will change automatically as follows:

First Sunday of April : At 2 AM the clock imme-

•

diately changes to 3 AM. Any timer programming you have set to occur between 2 AM and 3 AM will not record.

Last Sunday of October : At 2 AM the clock

•

immediately changes to 1 AM.

Make sure ...

Press the POWER button to turn on the

•

TV/DVD/VCR.

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “SETTING CLOCK.”

Then, press the ENTER button.

2 Set “D.S.T.” (Daylight-Saving

Time) to [ON]

Press the Arrow button K or L to point to “D.S.T.”

Then, press the ENTER button until [ON] appears.

3 Exit the Daylight-Saving Time mode

Press the SETUP button on the remote control to return to TV mode.

TO CANCEL THE DAYLIGHT-SAVING TIME

Repeat steps [1] to [2], select [OFF] using the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH AUTO CLOCK CH [02] MANUAL CLOCK SET

B D.S.T. [ON]

- 16 - EN

1C29

CLOCK SET UP

(AUTO / MANUAL)

TV/VCR

The TV/DVD/VCR clock must be set correctly before VCR timer recording is possible. It is suggested that the clock be set manually when first setting up the TV/DVD/VCR. Then, setup auto clock correction which will periodically correct the setting if necessary.

NOTE: If you cannot receive a station with time signals, auto clock setting cannot be performed. Use manual setting only.

6 Select the hour

Press the Arrow button K or L until your desired hour appears. (Example: 5, PM)

Then, press the Arrow button B.

7 Select the minute

Press the Arrow button K or L until the desired minute appears. (Example: 40)

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 TUE 2 0 0 3

HOUR MINUTE

0 5 : – – PM

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 TUE 2 0 0 3

HOUR MINUTE

0 5 : 4 0 PM

MANUAL CLOCK SETTING

Make sure ...

TV/DVD/VCR power is turned on.

•

In the example below, the clock is to be set to:

DATE May 6th, 2003 SETTING TIME 5:40PM

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “SETTING CLOCK”.

Then, press the ENTER button.

2 Select “MANUAL CLOCK

SET”

Press the Arrow button K or L to point to “MANUAL CLOCK SET”.

Then, press the ENTER button.

3 Select the month

Press the Arrow button K or L until your desired month appears. (Example: May

Then, press the Arrow button

→ 05)

4 Select the day

Press the Arrow button K or L until your desired day appears. (Example: 6th → 06)

Then, press the Arrow button B.

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH AUTO CLOCK CH [02]

B MANUAL CLOCK SET

D.S.T. [OFF]

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / – – – – –– – – –

HOUR MINUTE

– – : – –– –

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 – – –– – – –

HOUR MINUTE

– – : – –– –

8 Start the clock

Press the SETUP button on the

5:40 PM

remote control. Although seconds are not displayed,

they begin counting from 00 when you press the SETUP button on the remote control. Use this feature to synchronize the clock with the correct time.

NOTE:

When unplugging the AC cord or if there is a power failure for more than 3 seconds, you may have to reset the clock.

TO CHANGE CLOCK SETTING

If you want to change the clock,

1)Follow steps [1] and [2].

2)Select where you want to change using the Arrow button B or s.

3)Enter correct numbers using the Arrow button K or L.

4)Press the SETUP button on the remote control to start the clock.

PLEASE NOTE:

If there is no local PBS station in your area or on your cable system, select “AUTO CLOCK” and press the ENTER button to turn [OFF] this function. Then you can manually adjust the clock.

5 Select the year

Press the Arrow button K or L until your desired year appears. (Example: 2003)

Then, press the Arrow button B.

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 TUE 2 0 0 3

HOUR MINUTE

– – : – –– –

- 17 - EN

1C29

AUTOMATIC CLOCK SETTING

Make sure ...

The TV/DVD/VCR is turned on.

•

Confirm the TV/DVD/VCR is receiving a RF

•

(Radio Frequency) signal from either an antenna or cable system connection using the ANT IN jack on the rear of the TV/DVD/VCR.

NOTE:

If a cable converter box is being used, make sure it

•

is powered on. You must use the TV/DVD/VCR remote control to

•

perform the clock setting procedure.

Press the Arrow button K or L to select “SETTING CLOCK”.

Press the ENTER button to enter “SETTING CLOCK” menu.

Press the Arrow button L to select “AUTO CLOCK CH”.

Press the ENTER button, then press the Arrow button B or s until you locate Auto Clock Set station number. See item 3 above.

Press the SETUP button to exit the screen.

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH

B AUTO CLOCK CH [ 45]

MANUAL CLOCK SET D.S.T. [OFF]

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control.

Press the Arrow button K or L to select “SETTING CLOCK”.

Press the ENTER button to enter “SETTING CLOCK” menu.

2 Set “AUTO CLOCK” to [ON]

Press the ENTER button until AUTO CLOCK [ON] appears.

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– SETTING CLOCK –

B AUTO CLOCK [ON]

AUTO CLOCK CH SEARCH AUTO CLOCK CH [02] MANUAL CLOCK SET D.S.T. [OFF]

3 Begin “AUTO CLOCK CH SEARCH”

Press the Arrow button L to select “AUTO CLOCK CH SEARCH”.

Press the ENTER button.

The TV/DVD/VCR is now

•

searching for the station which contain the auto clock set signal. The search for a signal may take up to 20 seconds per channel.

“_ _” appears at the lower left of

•

the screen when the search has ended.

Auto Clock station- write down

•

the number(s) that appear on the screen. These are the auto clock station(s) in your area. See item 4 below.

If no number(s) appear on the TV screen, there are

•

no stations in your area which contain the Auto Clock signal. Auto Clock Setting is not possible.

Please use Manual Clock Setting on page 17. Press the SETUP button to exit the screen. NOTE: During Auto Clock CH Search, the picture

may be distorted. This is normal.

– SETTING CLOCK –

AUTO CLOCK [ON]

B AUTO CLOCK CH SEARCH

AUTO CLOCK CH [02] MANUAL CLOCK SET D.S.T. [OFF]

– AUTO CLOCK CH SEARCH –

08 10 13

_ _

5 Turn off the TV/DVD/VCR

Once the TV/DVD/VCR is turned off , it will periodically check and set the correct date and time.

4 Enter the channel number that contains the

Automatic Clock Setting Signal

Press the SETUP button on the remote control.

- 18 - EN

1C29

TV OPERATION

WATCHING A TV PROGRAM

TV/VCR

1 Turn on the TV/DVD/VCR

Press the POWER button to turn on the TV/DVD/VCR.

2 Select the channel number

Press the CHANNEL button K or L to select your desired channel number or press the number on the remote control.

Note for using the Number button on the remote control:

¡When selecting cable channels which are higher

than 99, press +100 first, then, press the last two

digits. (Example: to select channel 125, first press

“+100” then press “2” and “5”).

¡You must precede single-digit channel numbers

with a zero (For example: 02, 03, 04 and so on). Remember: If the TV/DVD/VCR is connected to a

cable box or satellite box, the TV/DVD/VCR must be on CH3 or CH4, then the channel to be viewed must be selected on the cable box or satellite box.

3 Adjust sound

Press the VOLUME button XXor to adjust the volume.

NOTES:

If you press the CHANNEL button o or p in the

•

DVD mode, you can change the TV channels.

Even if you turn off the TV/DVD/VCR in the

DVD mode, when you turn it on again, it will go

into the TV/VCR mode.

VOLUME 20

C C C C C C C C C C C C

DEGAUSSING

TV/VCR

Magnetism from nearby appliances and speakers might affect the color of the TV picture.

If this happens, move this TV/VCR/DVD away from the appliance. If the color is still not correct, turn off using the POWER button, then turn it on again 30 minutes or so later (27” model), or unplug the power cord, then plug it in again 30 minutes or so later (19” model).

PICTURE CONTROL

TV/VCR

The TV/DVD/VCR’s picture controls – BRIGHT, CONTRAST, COLOR, TINT and SHARPNESS –

are preset to factory specifications. Although they are usually the best, you may need to make some further adjustments for a natural looking image.

NOTES:

Procedures must be followed within 5 seconds or

•

the Picture Control mode will be cancelled. When setting the Picture Control, the Game mode

•

will be cancelled.

Make sure ...

TV/DVD/VCR power must be turned on.

•

1 Select “PICTURE CONTROL”

Press the PICTURE button on the remote control.

2 Select item you want to adjust

Press the Arrow button K or L until desired control is displayed.

BRIGHT CONTRAST COLOR TINT SHARPNESS

3 Adjust the picture control

Press the Arrow button B or s to adjust to your desired level.

Arrow button s Arrow button B

BRIGHT to decrease to increase

brightness brightness

CONTRAST to decrease to increase

contrast contrast

COLOR to pale to brilliant TINT to purple to green

SHARPNESS to soft to clear

If there is a power failure of any kind, the

•

TV/VCR/DVD will retain its memory for this feature.

BRIGHT

PP PP PP PPPPPP PPCC PPPPPP PPPPPP PP

–

- 19 - EN

1C29

CLOSED CAPTION SYSTEM

TV/VCR

You can view specially labeled (cc) TV programs, movies, news, pre-recorded tapes with either a dialogue caption or text display.

CAPTION mode: By choosing the caption mode, you

can watch dramas, movies and news while captioning the dialogues and the contents of news.

TEXT mode: By choosing the text mode, you can

watch half screen text information if you want.

1-2: You may get these captions or text information

by selecting either “1” or “2”. Caption “2” is used, usually for a second language if available.

NOTE:

Not all programs are broadcast with closed captions. Your television is designed to provide error free closed captions from high quality antenna, cable and VCR signals. Conversely, poor quality signals are likely to result in caption errors or no captions at all. Common signal conditions which may cause captions errors are listed below:

Automobile ignition noise

•

Electric motor brush noise

•

Weak snowy reception on TV screen

•

Multiplex signal reception displaying picture

•

ghosts or airplane flutter.

Playback of poorly recorded or worn VCR tapes.

•

NOTE:

If the TV/DVD/VCR displays a black box on the TV screen, this means that the TV/DVD/VCR is set to the TEXT mode. To clear screen, select [CAPTION1], [CAPTION2] or [OFF].

Make sure ...

TV/DVD/VCR power must be turned on.

•

1 Select “CAPTION”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “CAPTION”.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [OFF]

ZERO RETURN TIME SEARCH INDEX SEARCH

2 Select your desired caption menu

Press the ENTER button until your desired caption menu appears.

([CAPTION1], [CAPTION2], [TEXT1] or [TEXT2])

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [CAPTION1]

ZERO RETURN TIME SEARCH INDEX SEARCH

3 Exit the caption setting mode

Press the SETUP button on the remote control to return to TV mode.

TO CANCEL THE CLOSED CAPTION SYSTEM

Repeat steps [1] and [2], select [OFF] using the ENTER button. Press the SETUP button on the remote control to return to TV mode.

WHEN THE CLOSED CAPTION MODE IS ON

The On-Screen Display will disappear after 5 seconds.

It will also disappear when the MUTE button is

•

pressed, and when the PAUSE button is pressed while recording.

If there is a power failure of any kind, the

•

TV/DVD/VCR will retain its memory for this feature.

- 20 - EN

1C29

V-CHIP SET UP

Make sure ...

TV/DVD/VCR is turned on.

•

1 Select “V-CHIP SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to select “V-CHIP SET UP”.

Then, press the ENTER button.

2 Enter Access code

Use the number buttons on the remote control to enter the access code.

For the first time set-up or in the

•

event the TV/DVD/VCR has lost power, enter the default code of the numbers:

0000.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

TV/VCR

ACCESS CODE

_ _ _ _

V-CHIP SET UP SUB RATINGS

When you select the ratings of TV-Y7,TV-PG,TV-14 or TV-MA you will have the option of selecting sub

rating categories.

1 Select “V-CHIP SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to select “V-CHIP SET UP”. Then, press the ENTER button.

2 Enter Access code

Use the number buttons on the remote control to enter the access code. (Default code is 0000.)

3 Select “TV RATING”

Press the Arrow button K or L to select “TV RATING”.

Then, press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

ACCESS CODE

_ _ _ _

– V-CHIP SET UP –

B TV RATING

MPAA RATING CHANGE CODE

3 Select “TV RATING”

Press the Arrow button K or L to

– V-CHIP SET UP –

B TV RATING

MPAA RATING CHANGE CODE

select “TV RATING”. Then, press the ENTER button.

4 Blocking TV programs

Press the Arrow button K or L to select “TV rating” that you wish to block.

Press the ENTER button to turn it [BLOCK].

When you select the rating category and turn it

•

[BLOCK], the higher rating will turn [BLOCK] automatically. Also, the lower rating will turn [VIEW] automatically.

When you turn “TV-Y” to [VIEW], then all ratings

•

will turn to [VIEW] automatically.

Selection Rating Category Explanations

TV-Y Appropriate for all children TV-Y7 Appropriate for children seven and older TV-G General Audience TV-PG Parental Guidance suggested. TV-14 Unsuitable for children under 14

TV-MA Mature audience only

B TV–Y [VIEW]

TV–Y7 ( ) [VIEW] TV–G [VIEW] TV–PG ( ) [VIEW] TV–14 ( ) [VIEW] TV–MA( ) [VIEW]

4 Selecting Sub-Ratings”

Press the Arrow button L to select the sub-rating you wish to block. Then, press the ENTER button twice.

When you select [TV-Y7]:

•

Press the Arrow button L or K to select “FV” (Fantasy Violence). Then, press the ENTER button to select [BLOCK] or [VIEW].

When you select [TV-PG], [TV-

•

TV–Y7 [BLOCK]

B FV [BLOCK]

14] or [TV-MA]:

Press the Arrow button L or K to select “D”(Suggestive Dialog),

“L”(Coarse Language), “S”(Sexual Situation), or

TV–PG [BLOCK]

B D [BLOCK]

L [BLOCK] S [BLOCK] V [BLOCK]

“V”(Violence). Then, press the ENTER button to select [BLOCK] or [VIEW].

Note: When you select [TV-MA], “D” does not appear on the TV screen.

The sub-ratings which set to

•

[BLOCK] appears next to the rating category in the TV rating

B TV–Y [VIEW]

TV–Y7 ( ) [VIEW] TV–G [VIEW] TV–PG (DLSV) [BLOCK] TV–14 (DLSV) [BLOCK] TV–MA ( LSV) [BLOCK]

menu.

5 Exit the V-Chip setting mode

Press the SETUP button on the remote control to enter the setting and exit the screen.

5 Exit the V-Chip setting mode

Press the SETUP button on the remote control to exit the screen.

- 21 - EN

1C29

CHANGING V-CHIP BLOCKED PROGRAMMING

Note: To change the rating, the TV must be turned to a station that is not protected. If the (PROTECTED) appears on the screen, please change the channel to a station that is not protected.

1)Follow steps [1] and [2].

2)Press the Arrow button K or L to select "TV RAT-

ING". Then, press the ENTER button. Select a TV

rating to be unblocked by pressing the Arrow but-

ton K or L.

Then press the ENTER button to unblock the rating.

3)Press the SETUP button on the remote control to

exit the screen.

5 Exit the V-Chip setting mode

Press the SETUP button on the remote control to exit the screen.

CHANGE ACCESS CODE

To change access code, follow the steps.

1 Select “V-CHIP SET UP”

Press the SETUP button on the remote control. Press the Arrow button K or L to select “V-CHIP

SET UP”. Then, press the ENTER button.

MPAA RATING SET UP

1 Select “V-CHIP SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to select “V-CHIP SET UP”. Then, press the ENTER button.

2 Enter Access code

Use the number buttons on the remote control to enter the access code.

3 Select “MPAA RATING”

Press the Arrow button K or L to point to “MPAA RATING”.

Then, press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

ACCESS CODE

_ _ _ _

– V-CHIP SET UP –

TV RATING

B MPAA RATING

CHANGE CODE

4 Select your desired item

Press the Arrow button K or L to point to your desired item.

Then, press the ENTER button to select [BLOCK] or [VIEW].

Selection Rating Category Explanations

G General Audience PG Parental Guidance suggested. PG-13 Unsuitable for children under 13 R Restricted; under 17 requires accompa-

nying parent or adult guardian

NC-17 No one under 17 admitted X Mature audience only

G [VIEW] PG [VIEW] PG–13 [VIEW]

B R [BLOCK]

NC–17 [BLOCK] X [BLOCK]

2 Enter Access code

Use the number buttons on the remote control to enter the access code.

ACCESS CODE

_ _ _ _

The default code is 0000.

3 Select “CHANGE CODE”

Press the Arrow button K or L to select "CHANGE CODE". Then,

– V-CHIP SET UP –

TV RATING MPAA RATING

B CHANGE CODE

press the ENTER button.

4 Enter New code

Use the number buttons to enter your desired access code in the NEW CODE space. Then enter the

NEW CODE

X X X X

CONFIRM CODE

_ _ _ _

same code in the CONFIRM CODE space. V-CHIP SET UP screen appear on the screen.

If you enter wrong code, repeat step 4, making

•

sure you enter the same new code exactly in the confirm code space.

5 Exit the V-Chip setting mode

Press the SETUP button on the remote control to exit the screen.

Note: If you unplug the power code or power failure occurs, the changed access code will be lost and will return to default (0000). Change your access code again as necessary.

When you select the rating category and turn it

•

[BLOCK], the higher rating will turn [BLOCK]

automatically. Also, the lower rating will turn

[VIEW] automatically.

When you turn “G” to [VIEW], then all ratings

•

will turn to [VIEW] automatically.

- 22 - EN

1C29

MTS(Multi-Channel Television sound)SYSTEM

You can record or listen to a program in MTS stereo.

CHECKING THE SELECTED MTS MODE

When you play a VHS tape, or receive a broadcast on the TV/DVD/VCR tuner channel you are watching, the status shown below will appear when you press the DISPLAY button on the remote control.

SAP

HIFI

PLAY

HIFI CH 123

SP COUNT 0:00:00

Second Audio Program, which means your program, can also be received in a second language or sometimes a radio station.

High Fidelity which produces better sound than standard stereo TV/DVD/VCRs.

12:00AM

STEREO/SAP

TV/VCR

1] When a program is broadcast in stereo, STEREO

appears on the TV screen.

2] When a program is broadcast in second audio,

SAP appears on the TV screen.

3] When a program broadcast both in stereo and sec-

ond audio, STEREO and SAP appear on the TV screen.

NOTE: Although a program may be broadcast in

both stereo and second audio, you cannot record in both stereo and second audio at the same time.

4] While the TV/DVD/VCR is set in HIFI stereo

mode and playback mode. HIFI appears on the TV screen. While the TV/DVD/VCR is set in monaural(MONO) mode, HIFI disappears from the TV screen.

NOTE: If you play non-HIFI tapes while the

TV/DVD/VCR is set in HIFI, HIFI will disappear from the TV screen and the TV/DVD/VCR will play automatically in monaural.

MTS RECORDING/MONITOR MODE

TV/VCR

Type of broadcast Display on STEREO/SAP Hi-Fi audio track(2-channel) Normal audio

the TV screen SELECTION L-channel R-channel track

Regular -None- -Invalid- Mono Mono Mono

(monaural audio)

Stereo broadcast STEREO -Invalid- L R L+R

Bilingual broadcast SAP STEREO* Main audio Main audio Main audio

program program program

SAP* Sub audio Sub audio Sub audio

Stereo & Bilingual STEREO STEREO* L R L+R

broadcast SAP

SAP* sub audio sub audio sub audio

*You must select the recording mode in TV AUDIO [STEREO] or [SAP] when you record a broadcast.

- 23 - EN

program program program

1C29

SELECTING THE MTS SYSTEM

TV/VCR

Make sure ...

TV/DVD/VCR power must be turned on.

•

TO SELECT HIFI MODE

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “USER’S SET UP”. Then, press the ENTER button.

2 Select“VCR AUDIO”

Press the Arrow button K or L to point to“VCR AUDIO”.

3 Select [HIFI]

Press the ENTER button until [HIFI] appears.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– USER’S SET UP –

RENTAL [OFF] REPEAT PLAY [OFF] AUTO RETURN [OFF]

B VCR AUDIO [HIFI]

TV AUDIO [STEREO]

– USER’S SET UP –

RENTAL [OFF] REPEAT PLAY [OFF] AUTO RETURN [OFF]

B VCR AUDIO [HIFI]

TV AUDIO [STEREO]

TO SELECT MONO MODE

You can change the selection to “MONO” if you want to listen to HIFI tapes in normal audio playback.

Press the SETUP button on the remote control. Press the Arrow button K or L to point to “USER’S

SET UP”.Then, press the ENTER button.

2) Press the Arrow button K or L to point to “VCR AUDIO”.

3) Press the ENTER button until [MONO] appears.

4) Press the SETUP button on the remote control to

return to TV mode.

TO SELECT STEREO, SAP, OR MONO

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “USER’S SET UP”.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

4 To return to TV mode

Press the SETUP button on the remote control to return to TV mode.

NOTES:

Normally, “HIFI” should be selected for playback

•

with HIFI sound.

When you play non-HIFI tapes, the TV/DVD/VCR

•

will play automatically in the monaural mode.

The TV/DVD/VCR records automatically MTS

•

broadcasts in HIFI stereo sound unless you select SAP mode recording before you begin recording.

2 Select “TV AUDIO”

Press the Arrow button K or L to point to“TV AUDIO”.

– USER’S SET UP –

RENTAL [OFF] REPEAT PLAY [OFF] AUTO RETURN [OFF] VCR AUDIO [HIFI]

B TV AUDIO [STEREO]

3 Select [STEREO], [SAP], or [MONO]

Press the ENTER button until [STEREO], [SAP], or [MONO] appears.

4 To return to TV mode

Press the SETUP button on the remote control to return to TV mode.

NOTES:

You must select the recording mode,either TV

•

AUDIO [STEREO] or [SAP] when you record a broadcast. Refer to MODE”.

If you select second audio when second audio is

•

not available, the TV/DVD/VCR will record normal audio.

The TV/DVD/VCR records automatically MTS

•

broadcasts in HIFI stereo sound unless you select SAP mode recording before you begin recording.

“MTS RECORDING/MONITOR

- 24 - EN

1C29

VIDEO CASSETTE

This TV/DVD/VCR will operate with any cassette that has the mark. For best results, we recommend the use of high-quality tapes. Do not use poor quality or damaged tapes.

PRECAUTIONS

Avoid moisture. Moisture condensation may occur

•

on the tape if it is moved from a cold place to a warm place or visa versa. Before using a tape with these conditions, to avoid damage of the tape and your TV/DVD/VCR, wait until the tape has warmed to room temperature and the moisture has evaporated.

Avoid extreme heat, high humidity and magnetic

•

fields. Do not tamper with the cassette mechanism.

•

Do not touch the tape with your fingers.

•

TWO DIFFERENT TAPE SPEEDS

Before recording, select the tape speed from : SP mode (Standard Play) or SLP mode (Super Long

Play). The table below shows the maximum recording/play-

back time using T60, T120 or T160 tapes in each mode.

Tape Speed Recording/Playback Time

Type of tape

SP mode 1 hour 2 hours 2-2/3 hours SLP mode 3 hours 6 hours 8 hours

Note: You can play back a tape recorded in LP mode (Long Play).

T60 T120 T160

INSERTING A CASSETTE

Insert the cassette in the direction as shown. Push in gently, but continuously, on the center-back of the cassette until it is drawn into the TV/DVD/VCR. The TV/DVD/VCR will automatically turn on.

Window

CORRECT

WRONG

REMOVING A CASSETTE

1)In the Stop mode, press the EJECT button on the remote control or press the STOP/EJECT button on the TV/DVD/VCR. The cassette will eject.

2)Pull the cassette out of the cassette compartment.

3)Store the cassette in its case as shown.

ERASE PREVENTION

You can prevent accidental erasing of recording by breaking off the tab on the back edge of the cassette.

Ta b

If you decide to record on the tape again, cover the hole with plastic tape.

Transparent Tape

NOTE:

• In DVD mode, Whether the cassette is with tab or

without tab you insert, it doesn’t start playing until you press the PLAY button. In TV/VCR mode, if th cassette without tab is inserted, playback will automatically start.

- 25 - EN

1C29

PLAYBACK

NORMAL PLAYBACK

TV/VCR

Make sure ...

TV/DVD/VCR power must be turned on.

•

1 Insert a prerecorded tape

If the erase-protection tab has been removed, the TV/DVD/VCR will start playback automatically.

2 To begin playback

Press the PLAY button.

3 To stop playback

Press the STOP button when playback is completed.

NOTES:

If you press the PLAY button (of the TV/VCR side)

•

in the DVD mode, you can start the VCR playback. If you press the SELECT button in the VCR play-

•

back, it will stop and the mode will change to the DVD mode. In addition, the same function operates with the DVD side PLAY button or the OPEN/CLOSE button.

PLAY

STOP

TRACKING ADJUSTMENT

TV/VCR

Tracking adjustment will be set automatically

•

(Digital Tracking function) when you start playback.

However when playing pre-recorded tapes or tapes

•

recorded on units other than your own, noise lines (black and white streaks) may appear on the playback picture. If this occurs, you can adjust the tracking control manually by pressing the CHANNEL button K or L until the streaks disappear. To return to the DTR function, stop the tape once and start playback again.

You can reduce the noise lines by pressing the

•

CHANNEL button K or L in slow mode, too. Tracking adjustment in Slow mode will not be set automatically.

SLOW MOTION

TV/VCR

During pause, press the FWD button to reduce the playback speed. The TV/DVD/VCR mutes the sound during slow motion. Press the PLAY button to return to normal playback. NOTE: If it is left in the Slow mode for more than five minutes, the TV/DVD/VCR will automatically go into the Stop mode.

PICTURE SEARCH

TV/VCR

This feature is very useful in finding or skipping over a particular scene on a tape. In this mode, the sound will be muted.

1)You may view a video tape at a high speed in either a forward or reverse direction by pressing the F.FWD or REW button during playback. (in the SP / LP / SLP modes)

NOTE:

If you press the F.FWD or REW button on the

•

front panel in the DVD mode, the VCR forward or reverse will start. Please press the STOP / EJECT button once to stop it, twice to eject it.

Press it again and the TV/DVD/VCR will now search in super high speed. (in the LP / SLP modes only)

NOTE:

Tapes recorded in the SP or LP mode will dis-

•

play a noise bar on the TV screen and the picture may revert to Black and White. This is normal.

3)Press the PLAY button to return to normal speed.

STILL PICTURE

TV/VCR

You can view a still picture on the TV screen during playback (the Still mode). Press the PAUSE button during playback. Only tapes recorded in the SLP mode will show the least amount of lines.Press the PLAY button to return to playback.

NOTES:

You can advance the picture one frame at a time by

•

pressing the PAUSE button during the Still mode. If it is left in the Pause mode for more than five

•

minutes, the TV/DVD/VCR will automatically switch to the Stop mode.

VERTICAL HOLD CONTROL

TV/VCR

In the Pause/Still mode only, when the picture begins to vibrate vertically, stabilize the picture by pressing the CHANNEL button K or L.

NOTE:

If there are video noise lines on the screen, see Tracking Adjustment section.

- 26 - EN

1C29

SPECIAL PLAYBACK

Make sure ...

TV/DVD/VCR power must be turned on.

•

Insert a prerecorded tape.

•

RENTAL PLAYBACK

TV/VCR

This function enables you to improve the picture quality when playing back worn cassettes such as rented tapes.

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “USER’S SET UP”.

Then, press the ENTER button.

2 Set “RENTAL” to [ON]

Press the Arrow button K or L to point to “RENTAL”.

Press the ENTER button until [ON] appears.

3 Exit the Rental setting

Press the SETUP button on the remote control to return to the TV mode.

4 Start playback

Press the PLAY button to start playback. “RENTAL PLAY B” appears.

Once you select the Rental mode, it stays in effect

•

even after you turn off the TV/DVD/VCR.

TO CANCEL THE RENTAL MODE

Repeat steps [1] and [2], select [OFF] using the ENTER button on the remote control. Press the SETUP button on the remote control to return to TV mode.

If there is a power failure of any kind, the tv/vcr/dvd will retain its memory for this feature.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

USER’S SET UP

–

B RENTAL [ON]

REPEAT PLAY [OFF] AUTO RETURN [OFF] VCR AUDIO [HIFI] TV AUDIO [STEREO]

–

AUTO REPEAT PLAYBACK

TV/VCR

The TV/DVD/VCR has the auto repeat function that allows you to repeat a tape indefinitely without touching the PLAY button.

ALL REPEAT: Repeat playback from the beginning

to the end of the tape.

BLANK REPEAT: Repeat playback from the begin-

ning to a blank part, which is blank for more than 10 seconds.

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “USER’S SET UP”.

Then, press the ENTER button.

2 Select “ALL” or “BLANK”

Press the Arrow button K or L to point to “REPEAT PLAY”.

Press the ENTER button repeatedly until your desired selection [ALL] or [BLANK] appears.

3 Exit the Repeat Play setting

Press the SETUP button on the remote control to return to the TV mode.

4 Start playback

Press the PLAY button to start the Repeat Play. ”REPEAT PLAY B” appears.

Once you select the Repeat Play mode, it stays in

•

effect even after you turn off the TV/DVD/VCR. If the Rental mode is set [ON], the “RENTAL

•

PLAY B” display has priority.

TO CANCEL THE REPEAT PLAY MODE

Repeat steps [1] and [2], select [OFF] using the ENTER button on the remote control. Press the SETUP button on the remote control to return to TV mode.

If there is a power failure of any kind, the TV/DVD/VCR will retain its memory for this feature.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

USER’S SET UP

–

RENTAL [OFF]

B REPEAT PLAY [ALL]

AUTO RETURN [OFF] VCR AUDIO [HIFI] TV AUDIO [STEREO]

–

- 27 - EN

1C29

Make sure ...

TV/DVD/VCR power must be turned on.

•

Insert a tape.

•

ZERO RETURN

TV/VCR

This function allows you to search easily a beginning point that you want to review by rewinding or fast forwarding.

NOTE:

Zero Return WILL NOT work on a blank tape or a blank portion of a tape.

1 Stop a tape at your desired point

Rewind or fast forward the tape to the beginning point at which you want to review.

2 Reset the counter to 0:00:00

Press the C.RESET button repeatedly.

3 Begin recording or playback

Press the RECORD or PLAY button. Press the STOP button when recording or playback is

completed.

4 To activate “ZERO RETURN” mode

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “ZERO RETURN”.

Then, press the ENTER button. The counter will appear on the TV screen. The tape will automatically stop when the counter

returns to 0:00:00.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF]

B ZERO RETURN

TIME SEARCH INDEX SEARCH

This function will not operate in recording mode.

•

This function is not operative when a cassette tape

•

is not inserted in the TV/DVD/VCR.

In the example below: To watch a program after 2 hour 50 minutes from the present position, in either direction.

1 Insert a tape.

2 Select “TIME SEARCH” mode

Press the SETUP button on the remote control.

Press the Arrow button K or L to point to “TIME SEARCH”.

Then, press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN

B TIME SEARCH

INDEX SEARCH

3 Enter your desired time

Press the Arrow button K or L until your desired time appears. (Example: “2:50” stands for 2 hours 50 minutes)

If you wish to cancel the Time Search at this point, press the SETUP button on the remote control.

TIME SEARCH

2 : 50

4 Begin Time Search

By pressing the Arrow button s or B, the TV/DVD/VCR will rewind or fast forward to the specified point.

The time counts down as the searching progresses. When 0:00 is reached, the tape will start playback automatically.

TIME SEARCH

TV/VCR

The Time Search function makes it possible to quickly advance the tape to your desired position simply by entering the exact amount of playback time you want to skip.

NOTES:

Time Search can be set up to a maximum of 9

•

hours 50 minutes (9:50) by 10 minutes at a time.

TO CANCEL THE TIME SEARCH at this point

Press the STOP/EJECT button on the TV/DVD/VCR or the STOP button on the remote control. This will delete the selected time.

- 28 - EN

1C29

INDEX SEARCH

Pro.1 Pro.2 Pro.3 Pro.4 Pro.5 Pro.6 Pro.7

4321123

End of tape

Beginning of tape

CURRENT PLAYBACK PROGRAM

INDEX MARK

TV/VCR

This feature provides a method of indexing the starting point so that it can be easily returned to in either fast forward or rewind mode.

The index mark will be made automatically when

•

the REC button is pressed. It will also be marked at the starting point of Timer recording and OTR.

The index mark will not be recorded if the PAUSE

•

button is pressed and released during recording. The time gap between making the index marks on

•

the tape should be greater than 1 minute for SP recording, 2 minutes for LP recording and 3 minutes for SLP recording.

In some cases, the index mark at the beginning of

•

video tape cannot be detected.

Example: You are watching program number 4 and

want to fast forward to program number 7. You must skip three programs.

1 Select “INDEX SEARCH”

Press the SETUP button on the remote control. Press the Arrow button K or L to point to “INDEX SEARCH”. Then,

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

B INDEX SEARCH

press the ENTER button.

2 Enter your desired number

Press the Arrow button K or L until the number of programs that you want to skip appears. (Example: “03” for 3 programs)

The Index Search mode will be

•

canceled if the procedures are not activated in 30 seconds.

INDEX SEARCH

0 3

3 Begin Index Search

Press the Arrow button s or B. The TV/DVD/VCR begins rewinding or fast forwarding to the beginning of desired program.

NOTE: Every time an index signal is skipped, the number in the program indicator decreases by one.

4 After Index Search

When the preset program is reached, the TV/DVD/VCR will start playback automatically.

A video cassette must be inserted in the

•

TV/DVD/VCR for this function to work. The number of Index Searches can be set up to 20.

•

This function will not operate in the recording mode.

•

When you want to cancel the Index Search while

•

in progress, press the STOP button.

SPECIAL FEATURES

REAL TIME TAPE COUNTER

This shows the elapsed recording or playback time in hours, minutes, and seconds. (The displayed time will not change on a blank tape or blank portions on the tape.)The “–” indication will appear when the tape has rewound further than “0:00:00” on the tape counter.

TV/VCR

AUTO REWIND-EJECT

TV/VCR

When the end of a tape is reached during record-

•

ing, playback, or fast-forward, the tape will automatically rewind to the beginning. After rewinding finishes, the TV/DVD/VCR will eject the tape and turn itself to off.

This function is operative when Repeat Play is set

•

to the [OFF] position. The tape will not auto-rewind during timer record-

•

ing or One Touch Recording.

- 29 - EN

1C29

RECORDING

Make sure ...

TV/DVD/VCR power must be turned on.

•

Insert a cassette tape with its erase prevention tab in place. (If necessary, rewind or fast forward the tape to

•

the point at which you want to begin recording.)

NOTES:

This TV/VCR/DVD will ONLY record and view the same channel.

•

This TV/VCR/DVD cannot record the contents from the built-in DVD.

•

NORMAL RECORDING

TV/VCR

You can ONLY watch the same TV program that is being recorded.

1 Select the channel to be

recorded

Press the number buttons on the remote control or the CHANNEL button K or L.

Remember: If the TV/DVD/VCR is connected to a cable box or satellite box, the TV/DVD/VCR must be on CH3 or CH4, then the channel to be recorded must be selected on the cable box or satellite box.

2 Select the tape speed

Press the SPEED button to select the desired tape speed (SP/ SLP).

3 Begin recording

Press the RECORD button.

REC

CH 10

SKIPPING UNWANTED

SCENES DURING RECORDING

TV/VCR

Press the PAUSE button to temporarily stop recording.

Press the PAUSE or RECORD button to resume recording.

NOTES:

After five minutes, the TV/DVD/VCR will auto-

•

matically switch to the Recording mode to prevent tape damage.

If “CLOSED CAPTION (ON)” is selected, the On-

•

Screen Display will appear for 5 seconds, then disappear.

PAUSE

4 Stop recording

Press the STOP button when recording is completed.

- 30 - EN

1C29

OTR (One Touch Recording)

AUDIO

VIDEO

HEADPHONE

EC/OTR

STOP

F.FWD

BPLAY

REW

AEJECT

VIDEO

OUT

AUDIO

OUT

Push(es) Display Recording length

1 push (normal recording)

TV/VCR

This function enables you to set a recording length

2 pushes 0:30 30 minutes 3 pushes 1:00 60 minutes

simply by pressing the REC/OTR button on the TV/DVD/VCR.

17 pushes 8:00 480 minutes

Make sure ...

TV/DVD/VCR power must be turned on.

•

Insert a cassette tape with its erase prevention tab in

•

place. (If necessary, rewind or fast forward the tape to

COPYING A VIDEO CASSETTE

(Requires a VCR or camcorder)

the point at which you want to begin recording.)

NOTES:

This function CANNOT be done from the remote

•

control. Recording starts immediately when the REC/OTR

•

You can make copies of video tapes made by friends or relatives for your enjoyment.

You can not copy a DVD to a videotape.

TV/VCR

button is pressed. When the REC/OTR button is pressed 18 times, the

•

TV/DVD/VCR returns to the Normal Recording mode. To stop the OTR operation, press the STOP button

•

on the TV/DVD/VCR or on the remote control. To show the remaining time, press the DISPLAY

•

WARNING: Unauthorized recordings of copyrighted video tapes may be an infringement of copyright laws.

Connect your TV/DVD/VCR and a Source (Playing) VCR using the following diagram.

button on the remote control so that “OTR” appears on the TV screen. (It will show up momen-

[The TV/DVD/VCR]

[Fig.8]

tarily then disappear.) Recording stops when 0:00 is reached.

•

Please note that in the SLP mode maximum record-

•

ing time, assuming the tape is started at the beginning, is 8 hours using T-160 (or 6 hours using T-120).

If the tape runs out before the end time, the

•

TV/DVD/VCR will switch to the Stop mode immediately, ejects the tape and turns itself off.

If you press the POWER button during OTR, the

•

[Ex: Source (playing) VCR or camcorder]

TV/DVD/VCR continues recording until the selected length is reached.

Audio/Video adapter cable

1 Select the channel to be recorded

(not supplied)

Press the number buttons on the remote control or the CHANNEL button K or L.

Remember: If the TV/DVD/VCR is connected to a cable box or satellite box, the TV/DVD/VCR must be on CH3 or CH4, then the channel to be recorded is selected on the cable box or satellite box.

1)Insert a pre-recorded video cassette into the Source (Playing) VCR or camcorder.

2)Insert a blank video cassette, or one you want to record over, into the TV/DVD/VCR’s cassette compartment.

2 Select the tape speed

Press the SPEED button to select the desired tape speed (SP/ SLP).

3 Begin OTR

Press the REC/OTR button on the TV/DVD/VCR as many times as needed. The recording length will be determined by the number of times you press the REC/OTR button. Each additional push will increase the recording time by 30 minutes. It is set up to 8 hours.

OTR(2 : 30)

3)Press the SPEED button on remote control for the TV/DVD/VCR to select the desired recording speed (SP/SLP).

4)Press the CHANNEL button K or L on the TV/DVD/VCR until “AUX” appears on the screen.

5)Press the RECORD button on the TV/DVD/VCR.

6)Begin playback of the tape in the source (Playing) VCR or camcorder.

NOTE: For best results during copying, use the TV/DVD/VCR’s front panel controls whenever possible. The remote control might affect the source (Playing) VCR’s playback operation.

- 31 - EN

1C29

TIMER

9:00AM 10:00AM 12:00PM

Program 1 10:00AM-11:00AM Program 2 9:00AM-10:00AM Program 3 9:30AM-12:00PM

11:00AM

Recording Sequence

*Recording period is SHADED

AUTOMATIC TIMER

RECORDING

TV/VCR

You may set the TV/DVD/VCR to start and end a recording while you are away. You can set 8 programs to record on specific days, daily or weekly within a 1 year period.

In the example below, the timer is being set to record:

DATE: July 4th, 2003 SETTING TIME: from 7:30PM to 8:50PM CHANNEL: CH61 TAPE SPEED: SP

Make sure ...

If a cable box or satellite box is connected with the

•

TV/DVD/VCR you will be limited to record only one channel. And the channel selector on the TV/DVD/VCR must be selected to the output channel of the boxes CH 3 or CH 4 and then the actual channel to be recorded must be selected on the boxes.

Clock must be set to the correct time and date

•

before setting the timer. TV/DVD/VCR power must be turn on to program it.

•

Insert a cassette tape with its erase prevention tab

•

in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.)

The channel you want to record is properly set in

•

advance. (See page 16.)

Avoid over lap of programs ...

There is a chance that a program will not be recorded. when programs overlap;

The program with an earlier start has priority.

•

Once the earliest program finishes, the overlapping

•

programs will begin recording in sequence. The illustration below demonstrates the sequence

•

of recordings. Program 1 10:00AM - 11:00AM

Program 2 9:00AM - 10:00AM Program 3 9:30AM - 12:00PM

1 Select “TIMER PROGRAMMING”

Press the SETUP button on the remote control.

Confirm “TIMER PROGRAMMING” is pointed by pressing the Arrow button K. And press the ENTER button.

If you have not yet set the clock, “MANUAL

•

CLOCK SET” appears. If so, follow stops [3] to [8] on page 17. Then set the timer recording.

2 Select your desired program

position (1~8)

Press the Arrow button K or L to select the desired program position.

Then, press the Arrow button B.

- TV/VCR SETUP -

B TIMER PROGRAMMING

SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

3 Set the channel number

Press the Arrow button K or L until the desired channel number appears. (Example: CH61)

Then, press the Arrow button B. Remember: If the TV/DVD/VCR is

connected to a cable box or satellite box, the TV/DVD/VCR must be on CH3 or CH4, then the channel to be recorded is selected on the cable box or satellite box.

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

4 Select once, every day or weekly recording

For once recording :

Press the Arrow button K (up) until the desired date appears. (Example: “7/04” for July 4th). Then, press the Arrow button B.

For every day recording : To record a TV program at the same time on the same channel every day. (Example: Monday through Sunday)

Press the Arrow button L (down) until “EVRY DAY” appears. Then, press the Arrow button B.

For weekly recording : To record a TV program at the same time on the same channel every week. (Example: every Monday)

Press the Arrow button L (down) until “EVRY” and your desired day of the week appear together. Then, press the Arrow button B.

- 32 - EN

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 7/04 FRI -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 EVRY DAY -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 EVRY MON -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

1C29

5 Set beginning hour

Press the Arrow button K or L until the desired hour appears. (Example: “ 7, PM” for 7:30PM)

Then, press the Arrow button B.

6 Set beginning minute

Press the Arrow button K or L until the desired minute appears. (Example: “30” for 7:30PM)

Then, press the Arrow button B.

7 Set end hour

Press the Arrow button K or L until the desired hour appears. (Example: “8, PM” for 8:50PM)

Then, press the Arrow button B.

8 Set end minute

Press the Arrow button K or L until the desired minute appears. (Example: “50” for 8:50PM)

Then, press the Arrow button B.

9 Set the tape speed

Press the Arrow button K or L until the desired tape speed appears. (Example: SP)

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 7/04 FRI 7:12

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 7/04 FRI 7:30

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 7/04 FRI 7:30

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 7/04 FRI 7:30

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 7/04 FRI 7:30

- - -/- - - - - -:- - -:- - - -

8:50

8:30

8:50

-:- - - -

10 Finish setting the program

Press the ENTER or RETURN button. The program is now completed.

To set another program, repeat steps [2] to [10].

•

Press the SETUP button on the remote control to

•

return to original mode.

TIMER PROGRAM EXTENSION

To shift the time schedule of an automatic timer recording.

1)Press the POWER button.

2)Repeat step [1] on page 32.

3)Press the RECORD button and select the desired program using the Arrow button K or L.

4)Press the RECORD button again. Each additional push will shift forward the

begin/end time for recording by 10 minutes. When the recording is already in progress, each additional push will shift forward the end time only. If you want to cancel while setting, press the PAUSE but-

- -

ton on the remote control. The recording time returns to the original time.

NOTE: When you shift forward the time schedule during recording, the recording speed will automatically be set to the SLP mode.

5)Press the ENTER or RETURN button to exit the setting menu. Then press the SETUP button on the remote control to return to original mode.

TO CORRECT A PROGRAM

While setting a program; press the Arrow button

•

s to go back one step and enter the correct numbers using the Arrow button K or L.

After setting a program;

•

1)Press the POWER button.

2)Repeat steps [1] - [2] on page 32.

3)Press the Arrow button B (or press the Arrow

button s to go back one step) until the part you want to correct begins flashing, then make the changes pressing the Arrow button K or L.

4)Press the POWER button to set automatic timer

recording.

TV/VCR

11 Set the timer

Press the POWER button to set automatic timer recording. The RECORDING indicator lights up.

You must turn off the TV/DVD/VCR to activate

•

automatic timer recording. If power is not turned off and you continue watch-

ing TV, “TIMER REC STANDBY” starts flashing on the TV screen 2 minutes before the programmed start time.

TO CANCEL AN AUTOMATIC TIMER RECORDING

After setting a program;

•

1)Press the POWER button.

2)Repeat steps [1] ~ [2] on page 32 and select a

program you want to cancel.

3)Press the C.RESET button.

4)Press the SETUP button on the remote control to

return to TV mode.

While recording is in progress;

•

1)Press the POWER button.

2)Press the STOP/EJECT button on the

TV/DVD/VCR.

- 33 - EN

1C29

TO CHECK THE BEGIN/END TIME

1)Press the POWER button so that the RECORDING indicator goes off.

2)Press the SETUP button on the remote control.

3)Confirm “TIMER PROGRAMMING” is pointed.

4)Press the ENTER button. The details of programs appear on the TV screen.

5)Press the SETUP button on the remote control to return to TV mode.

HINTS FOR AUTOMATIC

TIMER RECORDING

TV/VCR

Make sure the channel you want to record is prop-

•

erly set in advance. It is not necessary to press the RECORD button for

•

timer recording. Recording begins automatically at the Start time.

•

If you are recording using a Timer mode, you may

•

not operate the TV/VCR/DVD manually. The erase-prevention tab on the cassette must be in

•

place (or you must put tape over the hole). If the erase-prevention tab is removed, the cassette

•

will be ejected when the POWER button is pressed to off.

If the tape runs out before the end time, the

•

TV/DVD/VCR will switch to the Stop mode immediately, and the tape will be ejected.

3 Auto Return will begin

When all the timer recordings are completed, the TV/DVD/VCR will rewind to the beginning of the recorded program(s).

NOTE:

If you press the POWER button while tape is

•

rewinding, the Auto Return will stop.

4 Watch the recorded program

Press the PLAY button.

TO CANCEL THE AUTO RETURN MODE

Repeat steps [1] and [2], select [OFF] using the ENTER button.

If there is a power failure of any kind, the TV/VCR/DVD will retain its memory for this feature.

SLEEP TIMER

TV/VCR

The Sleep Timer function turns off the TV/DVD/VCR without using the POWER button after a desired period of time.

NOTE:

This function does not operate during Recording

•

mode.

AUTO RETURN

TV/VCR

With this feature, after timer recording is finished, the beginning of the recorded program(s) can be searched for automatically.

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button

K or L to

point to “USER’S SET UP”. Then, press the ENTER button.

2 Set “AUTO RETURN” to [ON]

Press the Arrow button K or L to point to “AUTO RETURN”.

Press the ENTER button until [ON] appears.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

USER’S SET UP

–

RENTAL [OFF] REPEAT PLAY [OFF]

B AUTO RETURN [ON]

VCR AUDIO [HIFI] TV AUDIO [STEREO]

1 Select “SLEEP TIMER”

Press the SLEEP button on the remote control until “SLEEP TIMER” appears.

2 Set sleep time

Press the SLEEP button until your desired sleep time appears.

Each additional push will increase the time by 30 minutes up to 120 minutes.

SLEEP 120 MINUTES

After 5 seconds, exit the Sleep Timer setting.

TO CANCEL THE SLEEP TIMER

Press the SLEEP button on the remote control until “SLEEP TIMER” appears. Press the SLEEP button

–

until “SLEEP 0 MINUTES” appears.

- 34 - EN

1C29

ON SCREEN DISPLAY

STOP STOP

SP SPCOUNT 0:12:34

COUNT 0:12:34

5:40PM

CH2

5:40PM

CH2

Counter remains

Clock & Channel remains

After 5 seconds After 5 seconds

TV Display

CATV channel

TV Display

W+80 W+81 W+82 W+83 W+84

W+65 W+66 W+67 W+68 W+69 W+70 W+71 W+72 W+73 W+74 W+75 W+76 W+77 W+78 W+79

W+55 W+56 W+57 W+58 A-4 A-3 A-2 A-1 W+59 W+60 W+61 W+62 W+63 W+64

W+40 W+41 W+42 W+43 W+44 W+45 W+46 W+47 W+48 W+49 W+50 W+51 W+52 W+53 W+54

W+25 W+26 W+27 W+28 W+29 W+30 W+31 W+32 W+33 W+34 W+35 W+36 W+37 W+38 W+39

W+10 W+11 W+12 W+13 W+14 W+15 W+16 W+17 W+18 W+19 W+20 W+21 W+22 W+23 W+24

A-5

R S T U V W W+1 W+2 W+3 W+4 W+5 W+6 W+7 W+8 W+9

CDEFGH I JKLMNOPQ

5A 2 3 4 5 6 7 8 9 10 11 12 13 A B

123456789101112131415

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

46 47 48 49 50 51 52 53 54 55 56 57 58 59 60

61 62 63 64 65 66 67 68 69 70 71 72 73 74 75

76 77 78 79 80 81 82 83 84 85 86 87 88 89 90

91 92 93 94 95 96 97 98 99 100 101 102 103 104 105

106 107 108 109 110 111 112 113 114 115 116 117 118 119 120

121 122 123 124 125

CATV channel

To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows:

When the Closed Caption mode is OFF:

Counter mode: After 5 seconds, only the counter

•

remains. To clear it, press the DISPLAY button. Clock mode: After 5 seconds, only the clock and

•

When the Closed Caption mode is ON:

The On Screen Display disappear after 5 seconds.

•

This is true even if the MUTE button is pressed, or

•

the PAUSE button is pressed while recording. the channel number remain. To clear them, press the DISPLAY button.

OFF mode Counter mode Clock mode

OFF mode Clock/Counter mode

STOP 5:40 PM

SP COUNT 0:12:34

CH2

CABLE CHANNEL DESIGNATIONS

If you subscribe to cable TV, the channels are displayed as 1-125. Cable companies often designate channels with letters or letter-number combinations. Please check with your local cable company. The following is a chart of common cable channel designations.

- 35 - EN

1C29

DVD SECTION

Example

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1 Chapter 2Chapter 3 Chapter 4

Example

Track 1 Track 2 Track 3 Track 4 Track 5 Track 6

Example

Group 1 Group 2

Track 1 Track 2 Track 1 Track 2Track 3 Track 4

ABOUT THE DISCS

PLAYABLE DISCS

The following discs can be played back on this TV/DVD/VCR.

DVD video

DVD+R/RW*

CD-R/RW*

* Depending on the types or the writing method of the

medium some discs can not be played.

• Some DVD-R/RW, DVD+R/RW, or CD-R/RW discs made on personal computers, or on DVD recorders may not be played back properly due to the factors such as scratches, dirt or special properties of the disc.

• Discs made on personal computers may not be played back properly due to the different environment or the settings of the application you use. We recommend always to use the standardized, rightly formatted discs. (Please contact the sales agency for more detail).

This player conforms to the NTSC color system. You cannot play discs recorded in other color systems such as PAL or SECAM.

¡Some discs include region codes as shown below.

DVD-R/RW*

Audio CD

MP3*

DISC TYPES

[

]

DVD

Data on a DVD is divided into sections called "titles", and then into subsections called "chapters", each of which is given a title or chapter number. Playback conditions are preset on some DVD video discs, and these playback conditions take priority over user operations on this player. If a function you selected does not run as desired, refer to the manual accompanying the disc.

[

AUDIO CD

Data on an audio CD is divided into sections called “tracks”, each of which is given a track number.

]

¡The number inside the symbol refers to a region of the

world, and a disc encoded in a specific region format can only be played back on TV/DVD/VCR with the same region code.

The following discs cannot be played back on this TV/DVD/VCR.

DVD with region codes other than 1 or ALL.

DVD-ROM

DVD-RAM (Never play back, otherwise malfunc-

CD-ROM

VSD

CDV (Only plays back the audio part.)

CD-G (Only plays back the sound.)

CD-I (Never play back, otherwise malfunction

SACD

Photo CD (Never play back, otherwise malfunc-

Video CD (Never play back, otherwise malfunc-

Any other discs without compatibility indications.

tion may result.)

may result.)

tion may result.)

[

]

MP3

Data on an MP3 is divided into sections called "groups", and then into subsections called "tracks", each of which is given a group or track number.

–36–

01A11

PLAYING A DISC

BASIC PLAYBACK

DVD-V

Getting started

¡Turn on the power of amplifier and any other com-

ponents, if necessary.

1 Press the POWER button.

¡The power will turn on.

2 Press the OPEN/CLOSE button to open disc

loading tray.

3 Place the chosen disc in the tray, with the

label facing up.

4 Press the PLAY button.

¡The tray will close automatically, and playback will

then start from the first chapter or track of the disc. If the playback does not start automatically, press the PLAY button.

¡When you playback the DVD which a title menu is

recorded, it may appear on the screen. In this case, refer to “TITLE MENU”.

5 Press the STOP button to stop playback.

GENERAL FEATURES

DVD may contain menus to navigate the disc and access special features. Press the appropriate number buttons or use the Arrow buttons (L/K/s/B) to high- light your selection in the DVD main menu and press the ENTER button to confirm.

NOTES

¡Select DVD mode by pressing the SELECT button on

the remote control. Then, operate the DVD functions.

¡Unless stated, all operations described are based on

remote control use. Some operations can be carried out using the menu bar on the TV screen.

DISC MENU

DVD-V

1 Press the DISC MENU button.

¡The DVD main menu will appear.

2 If the feature is not available, symbol

may appear on the TV screen.

3 If disc menu is available on the disc, audio

language, subtitle options, chapters for the title and other options will appear for selection.

4 Press the Arrow buttons (L/K/s/B) to

select an item, and the ENTER button to confirm selection.

TITLE MENU

NOTES

¡When the DVD mode has been switched to the

TV/VCR mode, the DVD mode shuts down first and then TV picture and sound appears in about 4 seconds. Similarly, when the POWER button is pressed to turn off in the DVD mode, this mode shuts down first and then the TV/DVD/VCR’s power is turned off.

¡A “prohibited icon” may appear at

the top-right on the TV screen during operation, warning that a prohibited operation has been encountered by the DVD or the disc.

¡With DVDs that use titles for playback program sig-

nals, playback may start from the second title, or it may skip these titles.

¡During the playback of a two layered disc, pictures

may stop for a moment. This happens when the 1st layer switches to the 2nd layer. This is not a malfunction.

1 Press the TITLE button.

¡The title menu will appear.

2 If the feature is not available, symbol

may appear on the TV screen.

3 Press the Arrow buttons (L/K/s/B) to

select an item, and the ENTER button to confirm selection.

CALLING UP A MENU SCREEN DURING PLAYBACK

For DVD-Vs

¡Press the DISC MENU button to call up the DVD menu. ¡Press the TITLE button to call up the title menu.

NOTE

¡Contents of menus and corresponding menu opera-

tions may vary between discs. Refer to the manual accompanying the disc for details.

–37–

DVD-V

01A11

RESUME

DVD-V

1 During playback, press the STOP button.

¡Resume message will appear on the TV screen.

2 Press the PLAY button, playback will resume

from the point at which playback was stopped.

¡To cancel resume, press the STOP button twice. ¡If turn off the TV/DVD/VCR, resume function will

be cancelled.

SLOW FORWARD /

SLOW REVERSE

DVD-V

1 During playback, press the PAUSE button.

2 Press and hold down the FWD g or REV

h button for a few seconds.

3 Each press and hold down the FWD g or

REV

h button repeatedly to select the

required speed: 1/16, 1/8, 1/2 of the normal playback.

PAUSE

DVD-V

1 During playback, press the PAUSE button.

¡Playback will pause and sound will be muted.

2 To continue playback, press the PLAY button.

STEP BY STEP PLAYBACK

DVD-V

1 During playback, press the PAUSE button.

¡Playback will pause and sound will be muted.

2 The disc goes forward by one frame each

time the PAUSE button is pressed.

3 To exit step by step playback, press the

PLAY button.

FAST FORWARD/REVERSE

DVD-V

1 During playback, press and hold down the FWD

g or REV h button for a few seconds.

2 Each press and hold down the FWD g or

REV

h button repeatedly to select the

required speed: x2, x8, x50, x100.

¡For audio CDs, the speed is fixed at ×16. ¡For MP3, the speed is fixed at ×8.

MP3CD

4 To return to normal playback, press the

PLAY button.

Note for using buttons on the main unit:

Press the PAUSE button, then, press and hold down the SKIP G / SEARCHg buttons or the SKIPH /SEARCHh buttons on the TV/DVD/VCR for a few seconds to begin Search in 1/16 speed of the normal playback. Press and hold down again to change speed to 1/8. Repeat this procedure to change to 1/2.

ZOOM

DVD-V

The Zoom function allows you to enlarge the video image and to pan through the enlarged image.

1 Press the ZOOM button during playback.

¡Playback will continue.

2 Press the ZOOM button repeatedly to select

the required zoom factor: ZOOM1, ZOOM2, ZOOM3, or OFF.

3 Use the Arrow buttons (K/L/ s / B) to

move the zoomed picture across the screen.

4 To exit zoom mode, press the ZOOM button

to OFF.

NOTES

¡Zooming function does not work while disc menu is

shown.

¡Zooming function is not available on some discs.

3 To return to normal playback, press the

PLAY button.

Note for using buttons on the main unit:

During playback, press and hold down the SKIP G / SEARCHg buttons or the SKIPH /SEARCHh buttons on the TV/DVD/VCR for a few seconds to begin Search in x2 speed. Press and hold down again to change speed to x8. Repeat this procedure to change to x50 and x100.

–38–

01A11

SEARCH FUNCTION

TRACK SEARCH

There are three ways to begin playback on an Audio CD at a specific Track.

Using the Number buttons on the remote control

1 Press the Number buttons to enter the

desired Track number.

¡Playback will start at the selected track. ¡For single digit tracks (1-9), press a single number

(eg. track 3, press 3).

¡To play track 26, press +10, 2, 6.

Using the SEARCH MODE button

1 Press the SEARCH MODE button.

¡The track search display appears.

2 Within 30 seconds, select a desired track

number using the Number buttons on the remote control.

¡For single digits press 0 first. ¡Playback will start at the selected track.

TIME SEARCH

DVD-V

1 During playback, press the SEARCH MODE

button three times (CD: twice) to display the Time Search on the TV screen.

2 Within 30 seconds, enter a desired disc

time using the Number buttons on the remote control.

¡Playback will start at the specified time. ¡Press the CLEAR button to erase the incorrect input.

MARKER SETUP SCREEN

DVD-V

Use markers to memorise your favorite places on a disc.

1 Press the SEARCH MODE button four times

(CD: three times) during playback.

¡The display screen and Markers will appear on the

TV screen.

Using the SKIP

buttons

During playback, press the SKIP G button to move the next track. Press it repeatedly to skip subsequent tracks. Press the SKIP H button to go back to beginning of the current track. Press it repeatedly to go to the previous tracks.

¡If the SKIP button is pressed while the playback is

paused, the playback will be paused again after skipping to the next track.

NOTE

¡The SKIP HGbuttons are not available when

playback is stopped.

TITLE / CHAPTER SEARCH

DVD-V

1 Press the SEARCH MODE button once for

the Chapter search, twice for the Title search during playback.

2 Enter the desired chapter/title number using

the Number buttons on the remote control.

¡Playback will start at the selected Chapter or Track. ¡Press the CLEAR button to erase the incorrect input. ¡For single digits press 0 first.

2 Press the Arrow buttons (s/ B) to select 1,

2, 3, 4, 5, 6, 7, 8, 9, or 10 and ensure that “- :

- - : - -” appears in the display.

3 When reaches the desired point, press the

ENTER button.

¡The Title or Track and elapsed playing time will

appear in the TV screen.

4 To return to the Marker later, press the

SEARCH MODE button four times (CD: three times) during playback and the Arrow buttons (

s / B) to choose the desired marker,

then press the ENTER button.

NOTES

¡Opening the disc tray or turning off the power or

select AC at step 2 and press the ENTER button will erase all Markers.

¡To clear a marker, using the Arrow buttons (s / B

position the cursor on to the marker number to be cleared and press the CLEAR button.

¡You can mark up to 10 points.

5 Press the SEARCH MODE or RETURN but-

ton to exit.

)

–39–

01A11

SPECIAL PLAYBACK FUNCTION

TOTAL

PLAY

CD [AUDIO] TOTAL 0:45:55

RANDOM PROGRAM

- - no indication - -

RANDOM

REPEAT

REPEAT is available only during playback.

REPEAT TITLE / CHAPTER

DVD-V

To activate the repeat function, press the REPEAT button during playback.

¡The repeat mode changes as described below every

time you press the button.

CHAPTER TITLE OFF

(current chapter repeat) (current title repeat)

NOTES

¡Repeat Title/Chapter is not available with some

scenes.

¡The REPEAT setting will be cleared when moving

to other title or chapter.

REPEAT TRACK

To activate the repeat function, press the REPEAT button during playback.

¡The repeat mode changes as described below every

time you press the button.

TRACK ALL OFF

(current track repeat) (entire disc repeat)

NOTES

¡Repeat setting will be cleared when moving to other

track.

¡Repeat playback does not function during repeat A-B

playback.

REPEAT A-B

DVD-V

1 Press the REPEAT A-B button at your cho-

sen starting point.

¡ A- appears briefly on the TV screen.

2 Press the REPEAT A-B button again at your

chosen end point.

¡ A-B appears briefly on the TV screen, and the

repeat sequence begins.

(repeat off)

PROGRAM

You may determine the order in which tracks will play.

1 In stop mode, press the MODE button.

¡The PROGRAM screen will appear.

2 Press the Arrow button ▲ or ▼ to select a

track, then press the ENTER button.

¡Press the CLEAR button to

erase the most recently entered program.

3 Repeat step 2 until you have selected all the

tracks you want to play in the program.

4 Press the PLAY button to play the pro-

grammed tracks.

NOTES

¡While the program is being played back, the STOP

works as follows.

¡Press the STOP button once and then the PLAY but-

ton again, playback will restart from the point where the STOP button was pressed. (Program continued)

¡Press the STOP button twice and then the PLAY button

again, playback will restart from the track in the usual way. (Program cleared)

¡Up to 99 programs can be entered. ¡If you like to repeat the current track in the program,

press the REPEAT button repeatedly until TRACK appears during playback. If you like to repeat the entire program press the REPEAT button repeatedly until ALL appears during playback.

RANDOM PLAYBACK

This shuffles the playing order of tracks instead of playback in the sequence.

1 In stop mode, press the MODE button twice.

¡RANDOM screen appears.

3 To exit the sequence, press the REPEAT A-

B button.

NOTES

¡The repeat A-B section can only be set within the cur-

rent title (for DVDs), or current track (for audio CDs).

¡Repeat A-B is not available with some scenes in DVD. ¡To cancel the A point which was set, press the

CLEAR button.

¡Repeat A-B playback does not function during title,

chapter, track or all repeat playback.

2 Press the PLAY button to start random playback.

NOTE

¡If you like to repeat the current track in the random

selection, press the REPEAT button repeatedly until

TRACK appears during playback. If you like to repeat the entire random selection press the REPEAT button repeatedly until ALL appears during playback.

–40–

01A11

PLAYING A MP3 DISC

MP3 PLAYBACK

MP3

When a CD with MP3 files is in the TV/DVD/VCR, the MP3 menu will appear on the TV screen in stop mode.

1 In stop mode, press the Arrow buttons

(

K/L) to select the

desired group track.

¡If a group is selected, press

the Arrow Bor ENTER button to go on to the track selection screen. Press the Arrow buttons (K/L ) to choose a track, then press the ENTER button.

¡If a track is selected, press the ENTER button to start

playing tracks. Starting from the one you’ve just chosen the subsequent tracks will be played.

¡Choose FIRST PLAY to start playback from the

beginning of the listed tracks.

¡Press the TITLE button to return to the first item.

2 Press the STOP button to stop playback.

NOTES

¡Folders are known as Groups; files are known as

Tracks.

¡MP3 files are accompanied by icon. ¡Maximum of 255 folders can be recognized. ¡Maximum of 256 files can be recognized. ¡Up to 8 hierarchies can be created.

This player recommends the use of files recorded at the below specifications:

¡Sampling frequency: 44.1kHz or 48kHz ¡Constant bit rate: 112kbps ~ 320kbps.

TRACK SELECTION

MP3

1 Press the SEARCH MODE button during

playback.

¡The FILE LIST will appear.

2 Select a desired track using the Arrow but-

tons (

K/L/s/B).

¡Press the Arrow button B when you want to go to

the next hierarchy.

¡Press the Arrow button s when you want to go back

to the previous hierarchy.

3 Press the PLAY button to start playback.

NOTES

¡Press the SEARCH MODE button to exit. ¡Some selections may take a while to be recognized.

PROGRAM

MP3

This feature allows you to program an MP3 disc to play in a desired sequence.

1 In stop mode, press the MODE button.

¡The PROGRAM screen will appear.

2 Select a desired track using the Arrow but-

tons (

K/L/s/B). Then, press the ENTER

button.

¡Press the Arrow button B when you want to go to

the next hierarchy.

¡Press the Arrow button s when you want to go back

to the previous hierarchy.

¡Press the CLEAR button to erase the most recently

entered program.

3 Repeat step 2 until you have selected all the

Tracks you want to play in the program.

4 Press the PLAY button to start programmed

playback.

RANDOM PLAYBACK

MP3

1 In stop mode, press the MODE button twice.

¡RANDOM screen appears.

2 Press the PLAY button to start random play-

back.

–41–

01A11

CHANGING THE SETTINGS

OFF

SUBTITLE LANGUAGE CAMERA ANGLE

DVD-V

The DVD allows you to select a language for subtitles during DVD disc (if available) playback.

1 Press the SUBTITLE button during playback.

2 Press the SUBTITLE button repeatedly to

select your desired subtitle language.

¡The subtitle language will be displayed on the dis-

play bar at the top of the screen.

3 To turn off subtitles, press the SUBTITLE

button repeatedly until OFF appears.

NOTES

Some discs allow audio language setting/subtitle language setting on the disc menu. (Operation varies between discs, so refer to the manual accompanying the disc.)

¡If the desired language is not shown after pressing

the SUBTITLE button several times, the disc does not have subtitles in that language.

¡If you choose a Language that has a 3 letter language

code, the code will be displayed every time you change the Subtitle language setting. If you choose any other languages, ‘---’ will be displayed instead. (Refer to page 44.)

AUDIO LANGUAGE

DVD-V

The TV/DVD/VCR allows you to select a language during DVD disc (if multi language available) playback.

1 Press the AUDIO button during playback.

2 Press the AUDIO button repeatedly to select

your desired language.

NOTE

¡Pressing the AUDIO button may not work on some

DVDs with multiple audio languages (e.g. DVDs which allow audio language setting on the disc menu).

STEREO SOUND MODE

DVD-V

Some DVD discs contain scenes which have been shot simultaneously from various angles. You can change the camera angle when the ( ) icon appears on the screen.

1 Press the ANGLE button during playback.

¡The selected angle will be displayed on the display

bar at the top of the screen.

2 Press the ANGLE button repeatedly to

select your desired angle.

BLACK LEVEL SETTING

DVD-V

Adjust the Black Level Settings to make the black parts of the picture brighter.

1 Press the MODE button during playback.

2 Press the ENTER button to switch OFF.

ON: Makes the dark parts brighter. OFF: Shows the original picture as recorded.

3 Press the MODE button twice or the

RETURN button to exit.

VIRTUAL SURROUND

DVD-V

You can enjoy stereophonic visual space on your existing stereo system.

1 Press the MODE button twice (CD/MP3:

once) during playback.

MP3CD

1 Press the AUDIO button repeatedly during

playback to select between STEREO, L-CH or R-CH.

STEREO - both right and left channels are active (stereo) L-CH - only left channel is active R-CH - only right channel is active

NOTE

¡I

f the Virtual Surround setting is ON, the sound mode

will be fixed to STEREO, and can not be changed.

2 Press the ENTER button to set it 1 (Natural

effect) or 2 (Emphasized effect) or OFF.

3 Press the MODE or RETURN button to exit.

NOTE (for CD play only)

¡Virtual Surround will not be effective if the sound

mode is set to something other than STEREO.

–42–

01A11

THE ON-SCREEN INFORMATION

9/49 0:00:00 -0:00:00

DVD-V

MP3CD

You can check the information about the current disc by pressing the DISPLAY button on the remote control.

For DVD-Vs

1 Press the DISPLAY button during playback

to show current Chapter.

¡The elapsed and remaining

playing time of the current

For audio CDs

1 Press the DISPLAY button during playback

to show the current Track.

¡The elapsed and remaining playing time of the cur-

rent track will be displayed.

chapter will be displayed.

2 Press the DISPLAY button again to show

current Title.

¡The elapsed and remaining playing time of the cur-

rent title will be displayed.

current Total Track.

¡The elapsed and remaining playing time of the cur-

rent total track will be displayed.

3 Press the DISPLAY button again to exit the

3 Press the DISPLAY button again.

¡The BIT RATE and the current repeat setting will be

displayed.

¡If you are playing a dual layered disc, the layer num-

ber will also be displayed (L0: Layer 0 is playing. L1: Layer 1 is playing).

display.

For MP3

1 Press the DISPLAY button during playback.

¡The name of the file currently in play will be dis-

played.

4 Press the DISPLAY button again to exit the

display.

2 Press the DISPLAY button repeatedly to

show the track number, the repeat status, and the playback status at the top of the screen.

¡ will be displayed when repeat play has been

selected.

T - indicates Track repeat

G - indicates Group (folder) repeat

A - indicates Disc repeat

3 Press the DISPLAY button again to exit the

display.

–43–

01A11

CHANGING THE DVD SETUP ITEMS

LANGUAGE

AUDIO ORIGINAL SUBTITLE OFF DISC MENU ENGLISH

QUICK SETUP

TV MODE

4:3 LETTER BOX

DOLBY DIGITAL ON

LANGUAGE SETTING

DVD-V

Language options are not available with some discs.

1 Press the SETUP button twice in STOP

mode so that the DVD SETUP menu appears.

¡ If the menu does not appear, press the PLAY button,

the STOP button, then the SETUP button twice.

2 Press the Arrow button B to select CUS-

TOM, then press the ENTER button.

¡CUSTOM mode will appear.

3 Press the Arrow buttons (s/ B) to select

LANGUAGE, then press the ENTER button to confirm.

Press the Arrow buttons (K/L) to select the next items, then press the ENTER button.

AUDIO:

¡Sets the audio language.

SUBTITLE:

¡Sets the subtitle language.

DISC MENU:

¡Sets the language for DVD menu.

5 Press the Arrow buttons (K/L) to select a

setting, then press the ENTER button.

¡If OTHER is selected on the AUDIO, SUBTITLE or

DISC MENU screen, press four-digit number to enter the code for the desired language. (Refer to the language code list below.)

¡Only the languages supported by the disc can be

selected.

6 Press the SETUP button to exit.

NOTE

¡Language Setting for Audio and Subtitle is not avail-

able with some discs. Then use the AUDIO and the SUBTITLE buttons. Details are on page 42.

TO CHANGE THE ON-SCREEN MENUS

You can access the TV/VCR SETUP menu by pressing the SETUP button from the DVD mode. Refer to “Selecting the Language” on page 16 to changing the on-screen menus.

¡In case of selecting from the DVD mode, you cannot

select “CHANNEL SET UP”, “V-CHIP SET UP”, “CAPTION”, “TIME SEARCH”, or “INDEX SEARCH” menus.

Language Code

Abkhazian 4748 Afar 4747 Afrikaans 4752 Albanian 6563 Amharic 4759 Arabic 4764 Armenian 5471 Assamese 4765 Aymara 4771 Azerbaijani 4772 Bashkir 4847 Basque 5167 Bengali;Bangla 4860 Bhutani 5072 Bihari 4854 Bislama 4855 Breton 4864 Bulgarian 4853 Burmese 5971 Byelorussian 4851

Cambodian 5759 Catalan 4947 Chinese [CHI] 7254 Corsican 4961 Croatian 5464 Czech 4965 Danish [DAN] 5047 Dutch [DUT] 6058 English [ENG] 5160 Esperanto 5161 Estonian 5166

Faroese 5261 Fiji 5256 Finnish [FIN] 5255 French [FRE] 5264 Frisian 5271 Galician 5358 Georgian 5747 German [GER] 5051 Greek [GRE] 5158 Greenlandic 5758 Guarani 5360 Gujarati 5367 Hausa 5447 Hebrew 5569 Hindi 5455 Hungarian [HUN] 5467

Icelandic [ICE] 5565 Indonesian 5560 Interlingua 5547 Interlingue 5551 Inupiak 5557 Irish [IRI] 5347 Italian [ITA] 5566 Japanese [JPN] 5647 Javanese 5669 Kannada 5760 Kashmiri 5765 Kazakh 5757 Kinyarwanda 6469 Kirghiz 5771 Kirundi 6460 Korean [KOR] 5761 Kurdish 5767

A-B

C-E

F-H

I-K

Language Code

Laothian 5861 Latin 5847 Latvian;Lettish 5868 Lingala 5860 Lithuanian 5866 Macedonian 5957 Malagasy 5953 Malay 5965 Malayalam 5958 Maltese 5966 Maori 5955 Marathi 5964 Moldavian 5961 Mongolian 5960 Nauru 6047 Nepali 6051 Norwegian [NOR] 6061

Occitan 6149 Oriya 6164 Oromo(Afan) 6159 Panjabi 6247 Pashto;Pushto 6265 Persian 5247 Polish 6258 Portuguese [POR] 6266 Quechua 6367 Rhaeto-Romance 6459 Romanian [RUM] 6461 Russian [RUS] 6467

Samoan 6559 Sangho 6553 Sanskrit 6547 Scots Gaelic 5350 Serbian 6564 Serbo-Croatian 6554 Sesotho 6566 Setswana 6660 Shona 6560 Sindhi 6550 Singhalese 6555 Siswat 6565 Slovak 6557 Slovenian 6558 Somali 6561 Spanish [SPA] 5165 Sundanese 6567 Swahili 6569 Swedish [SWE] 6568

Tagalog 6658 Tajik 6653 Tamil 6647 Tatar 6666 Telugu 6651 Thai 6654 Tibetan 4861 Tigrinya 6655 Tonga 6661 Tsonga 6665 Turkish [TUR] 6664 Turkmen 6657 Twi 6669

Ukrainian 6757 Urdu 6764 Uzbek 6772 Vietnamese 6855 Volapuk 6861 Welsh 4971 Wolof 6961 Xhosa 7054 Yiddish 5655 Yoruba 7161 Zulu 7267

L-N

O-R

U-Z

If you choose a Language that has a 3 letter language code, the code will be displayed every time you change the Audio or Subtitle language setting on page 42. If you choose any other languages, ‘---’ will be displayed instead. (3 letter language code is written in bracket.)

–44–

01A11

AUDIO

DRC OFF DOLBY DIGITAL ON DOWN SAMPLING ON

DISPLAY SETTING

DISPLAY

TV MODE

4:3 LETTER BOX ANGLE ICON ON AUTO POWER OFF ON

QUICK SETUP

TV MODE

4:3 LETTER BOX

DOLBY DIGITAL ON

QUICK SETUP

TV MODE

4:3 LETTER BOX

DOLBY DIGITAL ON

AUDIO SETTINGS

DVD-V

You can change certain aspects of the DVD display screens and on-screen messages on the TV screen.

1 Press the SETUP button twice in STOP mode

so that the DVD SETUP menu appears.

¡ If the menu does not appear, press the PLAY button,

the STOP button, then the SETUP button twice.

2 Press the Arrow button B to select CUS-

TOM, then press the ENTER button.

¡CUSTOM mode will appear.

3 Press the Arrow button (s/ B) to select DIS-

PLAY, then press the ENTER button to confirm.

Choose the appropriate Audio settings for your equipment as it only affect during the playback of DVD discs.

1 Press the SETUP button twice in STOP mode

so that the DVD SETUP menu appears.

¡ If the menu does not appear, press the PLAY button,

the STOP button, then the SETUP button twice.

2 Press the Arrow button B to select CUS-

TOM, then press the ENTER button.

¡CUSTOM mode will appear.

3 Press the Arrow buttons (s/ B) to select

AUDIO, then press the ENTER button to confirm.

4 Press the Arrow buttons (K/L) to select the

below items, then press the ENTER button.

TV MODE:

QUICK

¡Press the Arrow buttons (K/L) for an item selection,

then press the ENTER button.

¡Select 4:3 LETTER BOX for a black bars appears

on top and bottom of the screen.

¡Select 4:3 PAN & SCAN for a full height picture

with both sides trimmed.

¡The default setting is 4:3 LETTER BOX.

ANGLE ICON:

¡Press the ENTER button repeatedly to turn Angle

icon ON or OFF.

¡The default setting is ON.

AUTO POWER OFF:

¡Press the ENTER button repeatedly to turn Auto

Power off ON or OFF.

¡The default setting is ON and it will turn the

TV/DVD/VCR to off automatically after 15 minutes of no use.

5 Press the SETUP button to exit.

4 Press the Arrow buttons (K/L) to select the

below items, then press the ENTER buttons.

DRC (Dynamic Range Control):

¡To compress the range of soft to loud sound. ¡The default setting is OFF.

DOLBY DIGITAL:

QUICK

Set to On when the unit is connected to a Dolby Digital Decoder.

(ON: Output a Dolby Digital signal) (OFF: Convert the Dolby Digital to PCM (2 channel stereo))

¡The default setting is ON.

DOWN SAMPLING:

¡Set to ON when outputting in 48 kHz. ¡The default setting is ON.

When playing disc with copyright Protection

¡If you select OFF, copyright protection will be acti-

vated and sound will be down sampled at 48kHz.

5 Press the SETUP button to exit.

–45–

01A11

PARENTAL CONTROL

PARENTAL

PARENTAL LEVEL ALL

QUICK SETUP

TV MODE

4:3 LETTER BOX

DOLBY DIGITAL ON

DVD-V

Parental Control limits the disc viewing that exceed your settings. (with a password or playback will stop.) This feature allows you to prevent discs with alternative scenes from being played by your children.

PARENTAL LEVEL

Parental Level allows you to set the rating level of your DVD discs. Playback will stop if the disc’s ratings exceed the level you set.

1 Press the SETUP button twice in STOP mode

so that the QUICK SETUP menu appears.

¡ If the menu does not appear, press the PLAY button,

the STOP button, then the SETUP button twice.

2 Press the Arrow button B to select CUS-

TOM, then press the ENTER button.

3 Press the Arrow buttons (s/B) to select

PARENTAL, then press the ENTER button.

CONTROL LEVELS

ALL

All parental lock is cancelled.

Level 8

DVD software of any grade (adult/general/children) can be played back.

Levels 7 to 2

Only DVD software intended for general use and children can be played back.

Level 1

Only DVD software intended for children can be played back, with those intended for adult and general use prohibited.

IF YOU FORGET THE PASSWORD

1 Press the number buttons 4, 7, 3, 7 at step 4.

Then enter your new password.

¡Password will be cleared and parental level will be

set to ALL.

2 Proceed the above Steps 5-7 again.

4 Enter your four-digit password then press

the ENTER button.

5 Press the Arrow buttons (K/L) to select

PARENTAL LEVEL, then press the ENTER button.

6 Press the Arrow buttons (K/L) to select

the desired level.

7 Press the SETUP button to exit

NOTES

¡When doing this for the first time, enter any 4 digits.

(except for 4737) That number will be used as the password.(in the event you forget the password, see below)

¡To change the password, press the Arrow buttons

(K/L) to select CHANGE at step 5, then press the ENTER button. Enter the four-digit pass-word, then press the ENTER button.

¡With some DVDs, it may be difficult to find if they

are compatible with parental lock. Be sure to check if the parental lock function operates in the way that you have set.

¡Record the password in case you forget it.

–46–

01A11

TROUBLESHOOTING GUIDE

If the TV/DVD/VCR does not perform properly when operated as instructed in this Owner’s Manual, check the player, consulting the following checklist.

PROBLEM CORRECTIVE ACTION

No power.

The TV/DVD/VCR does not respond to the remote control.

TV/VCR Mode

Sometimes a performance problem can be easily solved by checking seemingly apparent but often overlooked possibilities. Before arranging for service, check these items. It could save your time and money.

PROBLEM CORRECTIVE ACTION

No picture and sound.

No picture or poor picture on TV/DVD/VCR.

No sound or poor sound.

Bars On Screen

Picture Distorted or Blurred

Picture Rolls Vertically Lines or Streaks in Picture

No Color

Poor Reception on Some Channels Ghosts in Picture

Weak Picture

Sound OK, Picture Poor

Make sure the power plug is connected to an AC outlet.

•

Make sure the power is turned on.

•

Check if the power plug is connected to an AC outlet.

•

Check the batteries in the remote control.

•

Aim the remote control directly at the remote sensor. If necessary,

•

remove all the obstacles between the sensor and the remote. You have to be within 23 feet of the TV/DVD/VCR.

•

Check if the correct mode is selected. If not switch the mode by

•

pressing the SELECT button on the remote control,whichever you need.

Make sure the AC cord is connected to an AC outlet.

•

Check antenna connection.

•

Press the SELECT button on the remote control to select TV mode.

•

Then try other TV feature. Let the TV/DVD/VCR program its tuner memory.

•

Adjust direction or replace antenna.

•

Adjust picture controls.

•

Adjust volume control on remote control or main unit.

•

Press the MUTE button to restore sound.

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Try a new channel, if OK, then possible station trouble.

•

If outside antenna is being used, check for broken wire.

•

Try a new channel, if OK, then possible station trouble.

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Adjust COLOR control.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Adjust CONTRAST & BRIGHT control.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Adjust CONTRAST & BRIGHT control.

•

–47–

01A11

PROBLEM CORRECTIVE ACTION

Picture OK, Sound Poor

Timer recording is not possible.

Cannot go into Record mode.

Playback picture is partially noisy. • Adjust tracking control for a better picture using the CHANNEL

Try a new channel, if OK, then possible station trouble.

•

Check for local interference.

•

Make sure the timer recording is set correctly.

•

Make sure the power is off.

•

Make sure the TV/DVD/VCR clock is set correctly.

•

Make sure the tape has an erase-prevention tab. If need, cover the

•

hole with plastic tape.

•

• button K or L on the TV/DVD/VCR.

No picture but the audio is OK in • Head cleaning may be necessary. Refer to “AUTO HEAD playback. • CLEANING” on page 50.

No operation by infrared Remote • Make sure the AC cord is connected to an AC outlet. Control. • Check batteries in remote control. Video or color fades in and out • You can not copy a copyrighted video tape. You are experiencing

when making a copy of a video tape Different color marks on screen.

. • copy guard protection.

Magnetism from nearby appliances and geomagnetism might affect

•

the color of the TV picture. Move the appliances, the want to repair immediately, turn it on again 30 minutes or so later (27” model), or unplug the power cord, then plug it in again 30 minutes or so later (19” model).

TV/DVD/VCR

turn off using the POWER button, then

TV/DVD/VCR

can repair itself automatically. If you

away from the

CLOSED CAPTION PROBLEM POSSIBLE REMEDY

My TV/DVD/VCR is showing • You are watching a live broadcast and spelling errors made by the captions that are misspelled. • closed captioning production company may pass through uncorrected.

• A prerecorded program will not show any misspelled words because

• of the normal time available for editing the captions.

My TV/DVD/VCR will not show • Captions that are delayed a few seconds behind the actual the text dialogue are common for live broadcast. Most captioning production in its entirety or there is a delay of • companies can display a dialogue to a maximum of 220 words what is being said. • per minute. If a dialogue exceeds that rate, selective editing is used

• to insure that the captions remain up-to-date with the current

• TV screen dialogue.

My captions are scrambled with • Interference caused by building, power lines, thunderstorms, etc. white boxes on the TV screen. • may cause scrambled or incomplete captions to appear.

My program guide listed a TV show as being closed captioned but none • up the actual program so that additional advertising time can be of the captions were displayed. • given. Since the decoder cannot read the compressed information,

My prerecorded video tape does not show any captions. The tape box • company accidentally left out the captioning signals during the mentions it being closed captioned. • copying process.

My TV screen shows a black box • You are in the TEXT mode. Select CAPTION mode to CAPTION on certain channels. • [OFF].

• Broadcasters may at times use a time compression process to speed

• captions will be lost.

• The video tape was either an illegal copy or the tape duplicating

–48–

01A11

DVD Mode

PROBLEM CORRECTIVE ACTION

No picture. • Connect the video cables firmly.

• Insert a correct video disc that plays on this TV/DVD/VCR.

• Press the SELECT button on the remote control to select DVD mode.

Then, try other DVD feature.

Disc cannot be played

No sound

No DTS audio is output

Distorted picture

Audio or subtitle language • does not match the set up The camera angle cannot be changed •

Audio or subtitle language cannot be • The DVD does not contain audio source or subtitles in the selected changed language. “Prohibited icon” appears on the • That operation is prohibited by the player or the disc. screen, prohibiting an operation CD sound dropout • Scratched disc. Replace the disc with unscratched one. No CD reproduction DVD picture dropout DVD picture freeze DVD picture in mosaic No DVD reproduction

. • Connect the audio cables firmly.

. • Insert the disc.

• Clean the disc.

• Place the disc correctly, with the label side up.

• Cancel the parental lock or change the control level.

• Turn the power of the audio component on.

• Correct the audio output settings.

• Correct the input settings on the audio component.

. • This TV/DVD/VCR does not support DTS audio. This is not a mal-

function.

. • There are some cases where pictures may be slightly distorted, which

are not a sign of a malfunction.

• Although pictures may stop for a moment, this is not a malfunction. The selected language is not available for audio or subtitles on the DVD.

This is not a malfunction

The DVD does not angles.

This is not a malfunction.

This is not a malfunction

contain sequences recorded from different camera

This is not a malfunction.

NOTES:

Some functions are not available in specific modes, but this is not a malfunction. Read the description in

•

this Owner’s Manual for details on correct operations.

Playback from a desired track and random playback are not available during program playback.

•

–49–

01A11

MAINTENANCE

Recordable

ReWritable

CABINET CLEANING

Wipe the front panel and other exterior surfaces of

•

the TV/DVD/VCR with a soft cloth immersed in lukewarm water and wrung dry.

Never use a solvent or alcohol. Do not spray insec-

•

ticide liquid near the TV/DVD/VCR. Such chemicals may cause damage and discoloration to the exposed surfaces.

1.Please visit your local Audio/Video store and purchase a good quality VHS Video Head Cleaner.

2.If a Video Head Cleaner does not solve the problem, please call our help line at 1-800-256-2487, to locate an Authorized Service Center.

NOTES:

Remember to read the instructions included with

•

the video head cleaner before use. Clean video heads only when problems occur.

•

AUTO HEAD CLEANING

Automatically cleans video heads as you insert or

•

remove a cassette, so you can see a clear picture. Playback picture may become blurred of interrupt-

•

ed while the TV program reception is clear. Dirt accumulated on the video heads after long periods of use, or the usage of rental or worn tapes can cause this problem. If a streaky or snowy picture appears during playback, the video heads in your TV/DVD/VCR may need to be cleaned.

SERVICING

Should your TV/DVD/VCR become inoperative,

•

do not try to correct the problem by yourself. There are no user-serviceable parts inside. Turn off, unplug the power cord, and please call our help line at 1-800-256-2487, to locate an Authorized Service Center.

IF THE LASER OPTICAL PICKUP UNIT IS DIRTY

If the player still does not perform properly when it is operated while referring to the relevant sections and to

•

"TROUBLESHOOTING GUIDE" in this Owner's Manual, the laser optical pickup unit may be dirty. Consult your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.

DISC HANDLING

Use discs which have the following logos on them.

•

(Optical audio digital discs.)

Handle the discs so that fingerprints and dust do

•

not adhere to the surfaces of the discs.

Always store the disc in its protective case when it

•

is not used.

To clean-off, use a soft cloth.

•

Do not use a hard cloth since this will mar the disc.

•

Wipe the disc in a straight line from center to edge.

•

Never wipe with a circular motion.

•

Do not use detergent or abrasive cleaning agents.

•

–50–

01A11

SPECIFICATIONS

GENERAL SPECIFICATIONS ELECTRICAL SPECIFICATIONS

TV/VCR

Sound output: 2 speakers, 1W, 8 ohm

CRT [19 inch model]: 19 inch in-line gun, 90˚

deflection tube

[27 inch model]: 27 inch in-line gun, 110˚

deflection tube Television system : NTSC-M Closed caption system :§15.119/FCC Video Heads : Rotary four-head Tape width : 1/2 inch Tape speed

SP : 33.40mm/sec. LP : 16.67mm/sec. SLP : 11.12mm/sec.

Tuner channel

TV VHF Low : #2~#6 TV VHF High : #7~#13 TV UHF : #14~#69 CATV VHF : 5A MID band : A5~A1, A~I SUPER band : J~W HYPER band : W+1~W+84

DVD

Product type: DVD Player Discs: DVD video, Audio CD Output signal format: NTSC color Frequency response (out put jack)

DVD (linear sound): 20 Hz to 22 kHz

(sample rate: 48 kHz)

20 Hz to 44 kHz

(sample rate: 96 kHz)

CD: 20 Hz to 20 kHz Signal-to-noise ratio (S/N ratio)(out put jack)

CD: 75 dB (EIAJ) Dynamic range (out put jack)

DVD (linear sound): 85 dB

CD: 84 dB (EIAJ) Total distortion factor

CD: 0.07% (EIAJ) Wow and flutter: Below the measurement

limitation (+/-0.001% W PEAK) (EIAJ)

OTHER SPECIFICATIONS

Terminals

Antenna input: VHF/UHF/CATV

75 ohm unbalanced (F-type) Video input: RCA connector [ 1 Audio L/R input: RCA connector Headphone: 1/8” stereo (3.5 mm) Coaxial digital audio output: One pin jack,

500m Vpp (75 ohm) Analog audio L/R output : RCA connector [ 2

Remote control: Digital encoded

infrared light system

Operating temperature: 5ºC to 40ºC

(41ºF~104ºF)

Power requirements: AC 120V, 60Hz

[19 inch model]

Power consumption (Maximum): 90W Picture tube: 19" Dimensions: H:19-11/16” (500mm)

W:21-7/8” (556mm)

D:18-3/4” (476.5mm)

Weight: 45.2 lbs (20.5kg)

[27 inch model]

Power consumption (Maximum): 125W Picture tube: 27" Dimensions: H:25-1/2” (648mm)

W:26-9/16” (675mm)

D:19-11/16” (500mm)

Weight: 86 lbs (39.0kg)

[ 2

Designs and specifications are subject to change without notice.

•

If there is a discrepancy between languages, the default language will be English.

•

–51–

01A11

INDICE

■ CONTROLES DE OPERACIÓN Y FUNCIONES . . . . . 52

PANEL FRONTAL DEL TELEVISOR/DVD. . . . . . . . . . 52

MANDO A DISTANCIA. . . . . . . . . . . . . . . . . . . . . . . . . 52

VISTA POSTERIOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

■ PREPARACIÓN PARA LA UTILIZACIÓN . . . . . . . . . . 53

CONEXIONES DE ANTENA/CABLE . . . . . . . . . . . . . . 53

CONEXIÓN A TOMAS DE ENTRADA EXTERNA. . . . 53

PARA INSERTAR LAS PILAS . . . . . . . . . . . . . . . . . . . . 54

MODO DE ENTRADA EXTERNA . . . . . . . . . . . . . . . . 54

CONEXIÓN A UN SISTEMA ESTÉREO . . . . . . . . . . . . 54

CONEXIÓN A UN AMPLIFICADOR ESTÉREO EQUIPADO CON TOMAS DE ENTRADA DIGITAL,

PLATINA MD O PLATINA DAT (Para DVD). . . . . . . . . 54

CONEXIÓN A UN DECODIFICADOR DOLBY DIGITAL

(para DVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

SECCIÓN DE TV/VCR

■ PREPARACIÓN PARA LA UTILIZACIÓN . . . . . . . . . . 54

PREAJUSTE DE CANALES. . . . . . . . . . . . . . . . . . . . . . 55

CÓMO BORRAR (AGREGAR) CANALES . . . . . . . . . . 55

SECCIÓN DE DVD

REPRODUCCIÓN BÁSICA . . . . . . . . . . . . . . . . . . . . . . 55

CONTROLES DE

OPERACIÓN Y FUNCIONES

PANEL FRONTAL DEL

TELEVISOR/DVD

Consulte la figura 1 de la página 9

MANDO A DISTANCIA

Consulte la figura 2 de la página 9

VISTA POSTERIOR

Consulte la figura 3 de la página 10

1. Botón POWER

Presione este botón para conectar y desconectar la alimentación.

2. Botones VOLUME X/Y

Presione estos botones para controlar el nivel de volumen del DVD y el televisor.

3. Botones SKIP (para DVD)

Presione el botón correspondiente una vez para omitir capítulos o pistas y desplazarse a un punto específico. Mantenga el botón presionado para cambiar la velocidad de reproducción en avance o retroceso.

4. Botón PLAY

Inicia la reproducción del contenido del disco o cinta.

5. Botón STOP

Detiene la reproducción del disco.

6. Botón OPEN/CLOSE

Presione este botón para insertar discos en la bandeja o retirarlos de ella.

7. Bandeja de carga del disco

8. Indicador DVD

Se ilumina durante el modo DVD.

9. Botón SELECT

Presione este botón para cambiar al modo TV/VCR, modo de entrada externa o modo de DVD.

10. Indicador TV/VCR

Se ilumina durante el modo TV/VCR.

11. Botones CHANNEL K/L

Utilice estos botones para seleccionar canales memorizados.

12. Indicador de grabación

Parpadea durante la grabación. Se ilumina durante el modo de espera de grabación controlada por temporizador.

13. Botón REC/OTR (RECORD)

Presione este botón para grabar manualmente. Este botón también activa la función de grabación instantánea (OTR). (La función OTR sólo está disponible durante el modo TV/VCR.)

14. Botón REW (para TV/VCR)

Presione este botón para rebobinar la cinta o para ver la imagen rápidamente en dirección de retroceso durante el modo de reproducción. (Búsqueda en dirección de retroceso)

15. Botón FWD (para TV/VCR)

Presione este botón para adelantar rápidamente la cinta o para ver la imagen rápidamente en dirección de avance durante el modo de reproducción. (Búsqueda en dirección de avance)

16. Botón STOP/EJECT

Presione este botón para detener la cinta. Presiónelo en el modo de parada para retirar la cinta del televisor/DVD/videograbadora.

17. Ventanilla del sensor de mando a distancia

18. Toma HEADPHONE

Para conectar auriculares (no suministrados) y escuchar en privado.

19. Toma de entrada VIDEO

Conecte aquí la toma de salida de vídeo de una videocámara o de una videograbadora.

20. Tomas de entrada AUDIO L/R

Conecte aquí las tomas de salida de audio de una videocámara o de una videograbadora.

21. Compartimiento del cassette

22. Botón PICTURE

Presione este botón para ajustar la imagen.

23. Botones numéricos Modo TV:

Presione dos botones para acceder directamente al canal deseado. No olvide presionar “0” antes de elegir un canal de un solo dígito.

Botón +100

Presione este botón para seleccionar canales de televisión por cable cuyo número sea igual o superior a 100.

Modo DVD:

Presione este botón para introducir el número deseado.

Botón +10

Presione este botón para introducir números mayores que 10

24. Botón PAUSE

Hace una pausa en la reproducción del disco o cinta.

25. Botón SPEED

Presione este botón para seleccionar la velocidad de grabación deseada: SP/SLP.

26. Botón C.RESET

Presione este botón para poner el contador en 0:00:00. Presiónelo también para cancelar un ajuste de programa de temporizador.

27. Botón DISPLAY Modo TV/VCR:

Para visualizar el contador o el número del canal y la fecha actual en la pantalla del televisor.

Modo DVD:

Indica el estado actual en la pantalla del televisor para fines de comprobación.

28. Botón SETUP

Presione este botón para activar o salir del modo de menús de televisor o configuración de DVD.

29. Botón TITLE

Para visualizar el menú de títulos.

–52–

iguales o

0C28

30. Botón CLEAR

Para cancelar ajustes.

31. Botón MODE

Activa el modo de reproducción programada o el modo de reproducción aleatoria.

32. Botón SEARCH MODE

Presione este botón para localizar un punto deseado.

33. Botón AUDIO

Presione este botón para seleccionar un idioma de audio o el modo de sonido deseado.

34. Botón SUBTITLE

Presione este botón para seleccionar el idioma de subtí- tulos deseado.

35. Botón REPEAT

Repite la reproducción del disco, título, capítulo o pista actual.

36. Botón ANGLE (modo DVD)

Presione este botón para cambiar el ángulo de la cámara y ver la secuencia que se está reproduciendo desde un ángulo diferente.

37. Botón A-B REPEAT

Repite la reproducción de una sección seleccionada.

38. Botón RETURN

Permite volver a la operación anterior en el modo de configuración de DVD.

39. Botón ENTER

Presione este botón para establecer un ajuste.

40. Botones de flechas Modo TV/VCR:

Presione estos botones para seleccionar un modo de ajuste en el menú que aparece en la pantalla del televisor. Presiónelos también para seleccionar opciones o establecer ajustes en un menú en particular.

Modo DVD:

Use estos botones para hacer ajustes mientras observa la imagen en la pantalla del televisor.

41. Botón DISC MENU

Muestra los menús contenidos en el DVD.

42. Botón ZOOM

Amplía parte de la imagen reproducida de un DVD.

43. Botón MUTE

Suprime la salida de sonido. Presiónelo de nuevo para restablecer el sonido.

44. Botón SLEEP

Utilice este botón para ajustar el temporizador de dormir.

45. Botón SELECT

Presione este botón para cambiar entre los modos TV/VCR y DVD. El modo seleccionado (TV/VCR o DVD) se visualiza en el indicador del panel delantero.

46. Toma de entrada ANT.

Conéctela a una antena, sistema de televisión por cable o sistema de satélite.

47. Cable de alimentación

Conéctelo a una toma de CA estándar (120 V, /60 Hz). NOTA: Antes de conectar el cable de alimentación a

una toma de CA estándar, retírelo del gancho para evitar dañarlo.

48. Toma de salida de audio digital COAXIAL

Conéctela solamente a la entrada digital de un amplificador externo o decodificador de audio de DVD.

49. Toma de salida AUDIO L/R

Conéctela a la entrada de audio analógico de un amplificador o decodificador externo.

PREPARACIÓN PARA LA

UTILIZACIÓN

CONEXIONES DE ANTENA/CABLE

Consulte la figura 4 de la página 11

–53–

ANTENAS SEPARADAS DE VHF/UHF

En algunas zonas será necesario utilizar una antena exterior.

TELEVISIÓN POR CABLE SIN CAJA DE CONVERTIDOR/DECODIFICADOR

Utilice esta conexión si su sistema de televisión por cable se conecta directamente a su televisor/DVD/ videograbadora, sin una caja de convertidor. Con esta conexión podrá:

1) Utilizar el mando a distancia del televisor/DVD/ videograbadora para seleccionar canales.

2) Programar uno o más canales decodificados para grabación automática controlada por temporizador.

NOTA: Este televisor/DVD/videograbadora SÓLO puede grabar el canal que se está viendo.

TELEVISIÓN POR CABLE CON CAJA DE CONVERTIDOR/DECODIFICADOR O CAJA DE SATÉLITE

Si su compañía de televisión por cable le suministra una caja de convertidor o si utiliza un sistema de satélite, podrá utilizar la conexión básica que se muestra en la ilustración. Al utilizar esta conexión, también podrá grabar canales codificados. Sin embargo, la selección de los canales deberá hacerse con la caja de convertidor o con la caja de satélite. Esto significa que no es posible cambiar de canal utilizando el mando a distancia del televisor/DVD/ videograbadora. La grabación en ausencia (controlada por temporizador) está limitada a un canal a la vez.

PARA GRABAR UN CANAL CODIFICADO/DECODIFICADO

1.Ajuste el selector de canales del

televisor/DVD/videograbadora al canal de salida de la caja de convertidor de televisión por cable o caja de satélite. (Ej., CH3)

Seleccione el canal que desea grabar en la caja de convertidor de televisión por cable o caja de satélite.

Nota para el instalador de sistemas CATV

Esta nota tiene la finalidad de llamar la atención del instalador de sistemas CATV para que tenga en cuenta el Artículo 820-40 de la NEC, que proporciona recomendaciones para hacer una conexión a tierra apropiada y, en particular, especifica que la tierra del cable debe conectarse al sistema de puesta a tierra del edificio, tan cerca del punto de entrada del cable como sea posible.

CONEXIÓN A TOMAS DE

ENTRADA EXTERNA

Cuando vea un programa grabado en otra fuente (videograbadora o videocámara), utilice las tomas de entrada de audio/vídeo de la parte delantera del televisor/DVD/videograbadora. Conecte las tomas de salida de audio/vídeo de otra fuente a las tomas AUDIO L/R y VIDEO de este televisor/DVD/videograbadora. Luego, presione los botones CHANNEL K/L hasta que aparezca "AUX" en la pantalla.

NOTA:

Cuando conecte una videograbadora monofónica (otra

•

fuente) a este televisor/DVD/videograbadora, conecte la toma de salida de audio de la videograbadora monofónica (otra fuente) a la toma AUDIO L de este televisor/DVD/videograbadora. El audio saldrá igualmente por los canales izquierdo y derecho.

Consulte la figura 5 de la página 12

0C28

PARA INSERTAR LAS PILAS

1) Abra la cubierta del compartimiento de las pilas empujando la cubierta del mando a distancia en el sentido de la flecha.

2) Inserte 2 pilas "AA" en el compartimiento de las pilas, en el sentido indicado por las marcas de polaridad (+/-).

3) Vuelva a poner la cubierta.

MODO DE ENTRADA EXTERNA

Al usar una señal de entrada externa (otra videograbadora o una videocámara), conecte los cables de salida de audio/vídeo del equipo externo a las tomas AUDIO L/R IN/ VIDEO IN de su televisor/DVD/videograbadora. Luego, presione los botones CHANNEL K/L hasta que aparezca "AUX" en la pantalla.

CONEXIÓN A UN SISTEMA

ESTÉREO

NOTAS:

Asegúrese de desconectar la alimentación de todos

•

los componentes del sistema antes de conectar otro componente. Consulte el manual de instrucciones de su sistema

•

estéreo y de cualquier otro componente que vaya a conectar al televisor/DVD/videograbadora.

Consulte la figura 6 de la página 13

CONEXIÓN A UN AMPLIFICADOR

ESTÉREO EQUIPADO CON TOMAS

DE ENTRADA DIGITAL, PLATINA

MD O PLATINA DAT (Para DVD)

Utilice un cable digital coaxial de audio de venta en el comercio especializado para hacer las conexiones de audio. Conexión a un amplificador equipado con tomas de entrada digital, platina MD o platina DAT.

Consulte la figura 7 de la página 13

NOTAS:

La fuente de audio de un disco grabado en formato

•

de sonido envolvente Dolby Digital de 5,1 canales no se puede grabar como sonido digital mediante una platina MD o DAT. Asegúrese de desconectar la alimentación de todos

•

los componentes del sistema antes de conectar otro componente. Consulte los manuales de instrucciones de los

•

componentes que va a conectar al televisor/DVD/videograbadora. Ajuste la función Dolby Digital a OFF para salida

•

de audio en el modo de configuración. La reproducción en un televisor/DVD/videograbadora utilizando ajustes incorrectos puede generar ruido y distorsión, y también puede causar daños a los altavoces.

CONEXIÓN A UN DECODIFICADOR

DOLBY DIGITAL (para DVD)

Si utiliza este televisor/DVD/videograbadora para reproducir un disco DVD grabado en formato de sonido envolvente Dolby Digital de 5,1 canales, el televisor/DVD/videograbadora emitirá un flujo de datos DOLBY DIGITAL desde su toma de salida de audio digital COAXIAL. Si conecta el reproductor a un decodificador Dolby Digital, podrá disfrutar de una tonalidad más convincente y real, con un sonido envolvente potente y de alta calidad similar al de los cines.

Utilice cables digitales coaxiales de audio disponibles en el comercio especializado para hacer las conexiones de audio.

Consulte la figura 8 de la página 14

NOTAS:

Asegúrese de desconectar la alimentación de todos

•

los componentes del sistema antes de conectar otro componente. Consulte los manuales de instrucciones de los

•

componentes que va a conectar al televisor/DVD/videograbadora. Si conecta un decodificador Dolby Digital, ajuste

•

la función DOLBY DIGITAL a ON para salida de audio en el modo de configuración. A menos que se haga la conexión a un decodifi-

•

cador Dolby Digital, ajuste la función Dolby Digital a OFF para salida de audio en el modo de configuración. La reproducción en un televisor/DVD/videograbadora utilizando ajustes incorrectos puede generar ruido y distorsión, y también puede causar daños a los altavoces.

Fabricado bajo licencia de Dolby Laboratories. “Dolby”y el símbolo de la D doble son marcas de fábrica de Dolby Laboratories.

SECCIÓN DE TV/VCR

PREPARACIÓN PARA LA

UTILIZACIÓN

Puede programar el sintonizador para explorar todos los canales que pueda recibir en su zona.

NOTA: La programación de la memoria de canales NO es necesaria cuando se hace la conexión a una caja de televisión por cable o a una caja de satélite. Simplemente ajuste el selector de canales del televisor/DVD/videograbadora a la posición correspondiente al canal de salida de la caja de televisión por cable o caja de satélite (ej., CH3). Luego, seleccione el canal que desea ver en la caja de televisión por cable o en la caja de satélite.

–54–

0C28

PREAJUSTE DE CANALES

TV/VCR

1 Conecte el cable de alimentación del televi-

sor/DVD/videograbadora

Conecte el cable de alimentación del televisor/DVD/videograbadora

NOTA:

Si aparecen algunos dígitos en la esquina de la pan-

•

talla, presione el botón POWER sin desconectar el cable de alimentación.

2 Encienda el televisor/DVD/videograbadora

Presione el botón POWER para encender el televisor/DVD/videograbadora.

3 Seleccione “ENGLISH”, “ESPAÑOL” o

“FRANÇAIS”

Presione el botón ENTER para seleccionar "ENGLISH" = inglés, "ESPAÑOL" o "FRANÇAIS" = francés. "[ ]" indica el idioma seleccionado.

4 Inicie el preajuste automático

Presione el botón de flecha K o L para señalar "AUTOPRESELECCION".

Luego, presione el botón ENTER. El sintonizador explora y memoriza todos los canales

activos de su zona.

NOTAS:

El televisor/DVD/videograbadora distingue entre

•

los canales de TV estándar y los canales de televisión por cable.

Si desea reproducir o grabar una cinta de vídeo

•

ANTES de preajustar el sintonizador, deberá presionar el botón SETUP del mando a distancia.

El televisor/DVD/videograbadora puede memorizar

•

canales de TV como canales de CATV si las condiciones de recepción no son buenas. Si esto sucede, vuelva a intentar la acción AUTO MEMO cuando las condiciones de recepción mejoren.

5 Una vez finalizada la exploración

El sintonizador se detiene en el canal memorizado más bajo. Si desea recuperar los canales seleccionados, podrá seleccionar los canales directamente con los botones numéricos o los botones CHANNEL K o L del mando a distancia.

CÓMO BORRAR (AGREGAR)

CANALES

TV/VCR

Puede borrar de la memoria los canales que ya no recibe o que ve muy raramente. (Por supuesto, puede volver a agregar a la memoria los canales que haya borrado de la misma.)

1 Seleccione “AJUSTE DE CANAL”

Presione el botón SETUP del mando a distancia. Presione el botón de flecha K o L para señalar

“AJUSTE DE CANAL”. Luego, presione el botón ENTER.

2 Seleccione “AGREGAR/BORRAR”

Presione el botón de flecha K o L para señalar “AGREGAR/BORRAR”.

Presione el botón ENTER.

3 Introduzca el número del canal deseado

Presione el botón de flecha K o L hasta que aparezca el número del canal deseado. (También puede utilizar también los botones numéricos o los botones CHANNEL K/L para introducirlo.) (Ejemplo: CH8)

4 Borre el canal de la memoria o agréguelo a

ella

Presione el botón ENTER. El número del canal seleccionado se ilumina de color rojo. El canal de borra de la memoria.

Canal agregado: Se enciende en azul. Canal borrado: Se enciende en rojo.

Para borrar otro canal, repita los pasos [3] y [4].

•

Si vuelve a presionar el botón ENTER, el canal se

•

memorizará de nuevo. Presione el botón RETURN para hacer que el tele-

•

visor/videograbadora vuelva al menú SETUP.

5 Salga del modo de preajuste de canales

Presione el botón SETUP del mando a distancia para volver al modo de televisor.

NOTA: Para confirmar que los canales han sido borrados o agregados, presione el botón CHANNEL K o L.

SECCIÓN DE DVD

REPRODUCCIÓN BÁSICA

DVD-V

Para empezar

¡Conecte la alimentación del amplificador y otros

componentes, si es necesario.

1 Presione el botón POWER.

¡La alimentación se conectará.

2 Presione el botón OPEN/CLOSE para abrir

la bandeja de carga del disco.

3 Ponga el disco deseado en la bandeja, con

la etiqueta hacia arriba.

4 Presione el botón PLAY.

¡La bandeja se cerrará automáticamente y la repro-

ducción comenzará desde el primer capítulo o pista del disco. Si la reproducción no comienza automáti- camente, presione el botón PLAY.

¡Cuando reproduzca un DVD que tenga grabado un

menú de títulos, el menú podrá aparecer en la pantalla.

5 Presione el botón STOP para detener la

reproducción.

–55–

0C28

LIMITED WARRANTY

FUNAI CORP. will repair this Emerson product, free of charge in the USA in the event of defect in materials or workmanship as follows:

DURATION:

PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the

date of original retail purchase. Two (2) years for Picture Tube. Certain parts are excluded from this warranty.

LABOR: FUNAI CORP. will provide the labor without charge for a period of ninety (90) days from the date

of original retail purchase.

LIMITS AND EXCLUSIONS:

THIS WARRANTY IS EXTENDED ONLY TO THE ORIGINAL RETAIL PURCHASER. A PURCHASE RECEIPT OR OTHER PROOF OF ORIGINAL RETAIL PURCHASE WILL BE REQUIRED TOGETHER WITH THE PRODUCT TO OBTAIN SERVICE UNDER THIS WARRANTY.

This warranty shall not be extended to any other person or transferee.

This warranty is void and of no effect if any serial numbers on the product are altered, replaced, defaced, missing or if service was attempted by an unauthorized service center. This FUNAI CORPORATION Limited warranty does not apply to any product not purchased and used in the United States.

This warranty only covers failures due to defects in material or workmanship which occurs during normal use. It does not cover damage which occurs in shipment, or failures which are caused by repairs, alterations or product not supplied by FUNAI CORP., or damage which results from accident, misuse, abuse, mishandling, misapplication, alteration, faulty installation, improper maintenance, commercial use such as hotel, rental or office use of this product or damage which results from fire, flood, lightning or other acts of God.

THIS WARRANTY DOES NOT COVER PACKING MATERIALS, ANY ACCESSORIES (EXCEPT REMOTE CONTROL), ANY COSMETIC PARTS, COMPLETE ASSEMBLY PARTS, DEMO OR FLOOR MODELS.

FUNAI CORP. AND ITS REPRESENTATIVES OR AGENTS SHALL IN NO EVENT BE LIABLE FOR ANY GENERAL, INDIRECT OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR OCCASIONED BY THE USE OF OR THE INABILITY TO USE THIS PRODUCT. THIS WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND OF ALL OTHER LIABILITIES ON THE PART OF FUNAI, ALL OTHER WARRANTIES INCLUDING THE WARRANTY OF MERCHANTABILITY, AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED BY FUNAI AND ITS REPRESENTATIVES IN THE UNITED STATES.

ALL WARRANTY INSPECTIONS AND REPAIRS MUST BE PERFORMED BY A FUNAI AUTHORIZED SERVICE CENTER. THIS WARRANTY IS VALID WHEN THE UNIT IS CARRIED-IN TO FUNAI AUTHORIZED SERVICE FACILITY.

IMPORTANT:

THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE, IF, AT ANY TIME DURING THE WARRANTY PERIOD, YOU ARE UNABLE TO OBTAIN SATISFACTION WITH THE REPAIR OF THIS PRODUCT, PLEASE CONTACT FUNAI CORP.

ATTENTION:

FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY DESIGN OF THIS PRODUCT WITHOUT PRIOR NOTICE.

To locate your nearest Emerson Authorized Service Center or for general service procedure, please call 1-800-256-2487 or write to the following:

FUNAI CORPORATION, INC.

Customer Service

100 North Street; Teterboro, NJ 07608

Tel :1-800-256-2487

http://www.funai-corp.com

PLEASE DO NOT SHIP YOUR UNIT TO THE TETERBORO ADDRESS.

Printed in Malaysia 0EMN02182

TD853UD/TD953UD ★★★★★

documentation manual, user maintenance, brochure, user reference, pdf manual

This file has been downloaded from:

User Manual and User Guide for many equipments like mobile phones, photo cameras, monther board, monitors, software, tv, dvd, and othes..

Manual users, user manuals, user guide manual, owners manual, instruction manual, manual owner, manual owner's, manual guide,

manual operation, operating manual, user's manual, operating instructions, manual operators, manual operator, manual product,

Funai EWC27T3, EWC19T3 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
