“EMERSON AND THE G-CLEF LOGO ARE REGISTERED TRADEMARKS
MANUAL
9-INCH COLOR TV/DVD
EWC09D5
EWC09D5 B
OF EMERSON RADIO CORP., PARSIPPANY, NEW JERSEY, U.S.A.”
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
If you need additional assistance for set-up or operating after
reading owner’s manual, please call
Or visit our WEB SITE at http://www.EmersonAudioVideo.com
Please read before using this equipment
TOLL FREE : 1-800-256-2487.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The caution marking is located on the rear of the cabinet.
IMPORTANT SAFEGUARDS
1.Read instructions-All the safety and operating instructions
should be read before the appliance is operated.
2.Retain Instructions-The safety and operating instructions
should be retained for future reference.
3.Heed Warnings-All warnings on the appliance and in the
operating instructions should be adhered to.
4.Follow Instructions-All operating and use instructions
should be followed.
5.Cleaning-Unplug the unit from the wall outlet before clean-
ing. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
EXCEPTION: A product that is meant for uninterrupted
service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to
unplugging the appliance in the cleaning description otherwise required in item 5.
6.Attachments-Do not use attachments not recommended by
the unit manufacturer as they may cause hazards.
7.Water and Moisture-Do not use this unit near water-for
example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and
the like.
8.Accessories-Do not place this unit on an unstable cart,
stand, tripod, bracket, or table. The unit may fall, causing
serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the unit.
Any mounting of the appliance
should follow the manufacturer’s
instructions and should use a mounting accessory recommended by the
manufacturer. An appliance and cart
combination should be moved with
care.
Quick stops, excessive force, and
uneven surfaces may cause the appliance and cart combination to overturn.
PORTABLE CART WARNING
AVERTISSEMENT POUR UNE
TABLE ROULANTE PORTATIVE
S3126A
THIS SYMBOL INDICATES THAT
DANGEROUS VOLTAGE
CONSTITUTING A RISK OF ELECTRIC
SHOCK IS PRESENT WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE
ARE IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE
APPLIANCE.
Accessoires- Ne placez pas cet appareil sur une table
roulante, un support, un trépied, une console ou une table
instable. Cet appareil risquerait de tomber, pouvant gravement blesser quelqu'un et l'appareil même pourrait être
sérieusement endommagé. N'utilisez qu'une table roulante,
un support, un trépied, une console ou une table recommandé par le fabriquant, ou vendu avec l'appareil. Pour
n'importe quelle installation de l'appareil, on devra suivre
les instructions du fabriquant et l'on devra utiliser les accessoires d'installation recommandés par le fabriquant.
L'ensemble combiné de l'appareil avec une table roulante
devra être déplacé avec précaution. Des arrêts brusques,
une force excessive et des surfaces inégales peuvent provoquer le renversement de l'ensemble combiné de
l'appareil/table roulante.
9. Ventilation-Slots and openings in the cabinet and the back
or bottom are provided for ventilation and to ensure reliable
operation of the unit and to protect it from overheating, and
these openings must not be blocked or covered. The openings should never be blocked by placing the unit on a bed,
sofa, rug, or other similar surface. This unit should never be
placed near or over a radiator or heat register. This unit
should not be placed in a built-in installation such as a
bookcase or rack unless proper ventilation is provided or
the manufacturer’s instructions have been adhered to.
10.Power Sources-This unit should be operated only from the
type of power source indicated on the marking label. If you
are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For
units intended to operate from battery power, or other
sources, refer to the operating instructions.
11.Grounding or Polarization-This unit is equipped with a
polarized alternating-current line plug(a plug having one
blade wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you
are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
–2–
–2–
EN
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
S2898A
FIGURE A
ELECTRIC
SERVICE
EQUIPMENT
NEC - NATIONAL ELECTRICAL CODE
GROUND
CLAMP
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNI T
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDI NG
ELECTRODE SYSTEM
(NEC ART 250, PART H)
12.Power-Cord Protection-Power-supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles,
and the point where they exit from the appliance.
13.Outdoor Antenna grounding-If an outside antenna or
cable system is connected to the unit, be sure the antenna or
cable system is grounded so as to provide some protection
against voltage surges and built-up static charges. Article
810 of the National Electrical Code, ANSI/NFPA No. 70,
provides information with respect to proper grounding of
the mast and supporting structure, grounding of the lead-in
wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to
grounding electrodes, and requirements for the grounding
electrode. (Fig. A)
14.Lightning-For added protection for this unit receiver dur-
ing a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall
outlet and disconnect the antenna or cable system. This will
prevent damage to the unit due to lightning and power-line
surges.
15.Power Lines-An outside antenna system should not be
located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them
might be fatal.
16.Overloading-Do not overload wall outlets and extension
cords as this can result in a risk of fire or electric shock.
17.Object and Liquid Entry-Never push objects of any kind
into this unit through openings as they may touch dangerous voltage points or short out parts that could result in a
fire or electric shock. Never spill liquid of any kind on the
unit.
18.Servicing-Do not attempt to service this unit yourself as
opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified
service personnel.
19.Damage Requiring Service-Unplug this unit from the wall
outlet and refer servicing to qualified service personnel
under the following conditions:
a. When the power-supply cord or plug is damaged or frayed.
b. If liquid has been spilled, or objects have fallen into the
unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by following the oper-
ating instructions. Adjust only those controls that are cov-
ered by the operating instructions, as improper adjustment
of other controls may result in damage and will often
require extensive work by a qualified technician to restore
the unit to its normal operation.
e. If the unit has been dropped or damaged in any way.
f. When the unit exhibits a distinct change in performance-
this indicates a need for service.
20.Replacement Parts-When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer that have the same character-
istics as the original part. Unauthorized substitutions may
result in fire, electric shock, injury to persons or other haz-
ards.
21.Safety Check-Upon completion of any service or repairs to
this unit, ask the service technician to perform routine safe-
ty checks to determine that the unit is in proper operating
condition.
22.Heat-This unit product should be situated away from heat
sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
–3–
–3–
EN
PRECAUTIONS
IMPORTANT COPYRIGHT INFORMATION
Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.
This product incorporates copyright protection technology that is protected by U.S. patents and other
intellectual property rights. Use of this copyright
protection technology must be authorized by
Macrovision, and is intended for home and other
limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
FCC WARNING- This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause
harmful interference unless the modifications
are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change
or modification is made.
RADIO-TV INTERFERENCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment
and receiver.
3) Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4) Consult the dealer or an experienced radio/TV
technician for help.
LASER SAFETY
This unit employs a laser. Only a qualified service
person should remove the cover or attempt to service this device, due to possible eye injury.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED
HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
CAUTION: VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN AND INTERLOCK
DEFEATED. DO NOT STARE INTO BEAM.
LOCATION: INSIDE, NEAR THE DECK
MECHANISM.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.
ATTENTION: POUR ÉVITER LES CHOC
ÉLECTRIQUES, INTRODUIRE LA LAME LA
PLUS LARGE DE LA FICHE DANS LA
BORNE CORRESPONDANTE DE LA PRISE
ET POUSSER JUSQU’AU FOND.
A NOTE ABOUT RECYCLING
Batteries should never be thrown away or incinerated but disposed of in accordance with your local
regulations concerning chemical wastes.
The serial number of this product may be found on the back of the unit. No other unit has the same serial
number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.
Date of Purchase
Dealer Purchase from
Dealer Address
Dealer Phone No.
Model No.
Serial No.
–4–
–4–
EN
LOCATION
Owner’s
Manual
WARNING
For safe operation and satisfactory performance of
your unit, keep the following in mind when selecting
a place for its installation:
Shield it from direct sunlight and keep it away from
•
sources of intense heat.
Avoid dusty or humid places.
•
Avoid places with insufficient ventilation for proper
•
heat dissipation. Do not block the ventilation holes at
the top and bottom of the unit. Do not place the unit
on a carpet because this will block the ventilation
holes.
Install the unit in a horizontal position.
•
Avoid locations subject to strong vibration.
•
Do not place the unit near strong magnetic fields.
•
Avoid moving the unit to locations where tempera-
•
ture differences are extreme.
AV OID THE HAZARDS OF
ELECTRICAL SHOCK AND FIRE
Do not handle the power cord with wet hands.
•
Do not pull on the power cord when disconnecting
•
it from an AC wall outlet. Grasp it by the plug.
If by accident, water is spilled on your unit, unplug
•
the power cord immediately and take the unit to our
Authorized Service Center for servicing.
Do not put your fingers or objects into the unit disc
•
loading tray.
Do not place anything directly on top of the unit.
•
Moisture condensation may occur inside the unit
when it is moved from a cold place to a warm place
or after heating a cold room or under conditions of
high humidity. If a DVD is played in a unit which has
moisture, it may damage the DVD and the unit.
Therefore when the condensation occurs inside the
unit, turn the unit on and allow at least 2 hours for the
unit to dry out.
SYMBOLS USED IN THIS MANUAL
The following symbols below appear in some headings and notes in this manual, with the following
meanings
TV
: Description refers to TV operation (in the TV mode).
DVD-V
: Description refers to playback of DVD video discs
(in the DVD mode).
CD
: Description refers to playback of audio CDs
(in the DVD mode).
QUICK
: Description refers to the items to be set by the
QUICK mode (in the DVD mode).
SUPPLIED ACCESSORIES
BatteriesRemote Control Unit
(NE221UD)
Indoor Antenna
(0EMN00723 or
0EMN01183)
If you need to replace these accessories, please refer to the PART NO. under the illustrations and call 1-800-
•
256-2487.
Depending on your antenna system, you may need different types of Combiners (Mixer) or Separators
•
(Splitter). Contact your local electronics store for these items.
(A converter may be necessary to view scrambled
cable channels.)
Infrared remote control
•
Trilingual on screen menu display selectable in
•
English, Spanish, or French
¡Sleep Timer
Allows you to have the unit automatically turn off at a
desired time.
¡Auto Shut Off Function
If there is no air signal input from the antenna terminal and
no operation for 15 minutes, the TV will turn itself off
automatically.
DVD Mode
¡Dolby Digital sound
This unit can handle Dolby Digital surround sound
having 5.1 channels when connected to a Dolby Digital
decoder.
¡Still/fast/slow/step playback
Various playback modes are available including still pictures, fast forward/reverse, slow motion and step frames.
¡Random playback for Audio CD
This unit can shuffle the order of tracks to play them in
random order.
¡Program playback for Audio CD
You can program the order of tracks to play them in any
desired order.
¡DVD menus in a desired language
You can display DVD menus in a desired language, if
available on a DVD.
¡Screen saver/Auto power-off functions
The screen saver program starts when there is no input
from the unit for 5 minutes in the stop mode. After the
screen saver program is activated for 15 minutes, the
power automatically turns off.
¡Subtitles in a desired language
You can select a desired language for the display subtitles,
if that language is available on a disc.
¡Selecting a camera angle
You can select the desired camera angle, if a disc contains
sequences recorded from different angles.
¡Choices for audio language and sound mode
You can select the desired audio language and sound mode,
if different languages and modes are available on a disc.
¡Parental lock
You can set the control level to limit playback of discs
which may not be suitable for children.
¡Automatic detection of discs
This unit automatically detects if the loaded disc is DVD
or Audio CD.
¡On-screen display
Information about the current operation can be displayed
on a TV screen, allowing you to confirm the currently
active functions (such as program playback), on the TV
screen using the remote control.
¡Search
Chapter search / Title search / Track search / Time search
¡Repeat
Chapter / Title / Track / All / A-B
¡Marker
The part designated by user can be called back.
¡Resume Play
User can resume to playback from the part at which the
play was stopped.
¡Virtual Surround
¡Bit rate indication
¡DRC (Dynamic range control)
You can control the range of sound volume.
NOTE:
We do not recommend the use of universal remote controls. Not all of the functions may be controlled with
•
a universal remote control.
If you decide to use a universal remote control with this unit, please be aware that the code number given
may not operate this unit. In this case, please call the manufacturer of the universal remote control.
–7–
–7––7––7–
EN
DC 13.2V
COAXIAL
ANT.
394038
37
HEADPHONE
CHANNEL
VOLUME
POWER
AUDIO
L
VIDEO
R
OPEN/CLOSE
PAUSE
SKIPSKIP
STOPPLAY
SEARCH
7428 9 10 11 12 13 146531
26
27
16
17
9
11
12
23
20
22
15
25
24
21
10
28
29
30
33
35
5
6
13
34
19
18
8
31
32
4
36
REV
SLOW
PLAY
STOP
FWD
ENTER
PAUSE
DISC
MENU
RETURNTITLESETUP
A
-
B
REPEATSEARCH MODE
CLEAR
MODE
ANGLESUBTITLEAUDIO
DISPLAY
SKIP
SELECT
POWER PICTURE
OPEN/
CLOSE
CH.
VOL.
MUTEV.SURR
SLEEP
123
456
789
0+10
+100
OPERATING CONTROLS AND FUNCTIONS
[Fig. 2]
[Fig. 1]
FRONT PANEL
REMOTE CONTROL
1.Disc loading tray
2.VIDEO input Jack [page 11]
3.AUDIO L/R input Jacks [page 11]
4.POWER Button [page 14]
5.VOLUME (VOL.) K / L Buttons
6.
Connect to the video output jack of a video
camera or VCR.
Connect to the audio output jacks of a video
camera or VCR.
Hit to turn the power on and off.
Press to control the volume level for the DVD and TV.
CHANNEL (CH.) K / L Buttons [page 14]
Press to select memorized channel.
Press to change to TV mode when in DVD mode.
REAR VIEW
7.Remote Sensor Window
8.C STOP Button [page 19]
Stops operation of the disc.
9.H SKIP Button [page 21]
Plays back from the beginning of the current
chapter or track.
E SEARCH Button (Front Panel)
[page 20]
During playback or in the pause mode, press and
hold button down
reverse playback speed.
10. B PLAY Button [page 19]
Starts playback of the disc contents.
Hit to change to DVD mode when TV mode.
11. SKIP G Button [page 21]
Plays back from the beginning of the next chapter
or track.
SEARCH D Button (Front Panel)
[page 20]
During playback or in the pause mode, press and
hold button down
ward playback speed.
12.FPAUSE Button [page 20]
Pauses the current disc operation.
13. A OPEN/CLOSE Button [page 19]
Hit
to insert a disc into or remove it from the tray.
14. HEADPHONE Jack
To connect headphone (not supplied) for personal
listening.
15. MODE Button [pages 22-24]
Activates program playback or random playback
mode when playing CDs.
16. Number Button
TV Mode:
Hit
two digits to directly access the desired channel.
Remember to hit [0] before a single digit channel.
+100 Button–
Hit to select cable channels which are higher than
99.
DVD Mode: [page 21]
Hit to enter the desired number.
+10 Button–
Hit to enter the desired numbers which are higher
than 9.
–8–
–8–
–8––8–
for a few seconds to change
for a few seconds to change for-
[page 14]
[Fig. 3]
EN
17. SLEEP Button [page 15]
Sets the sleep timer.
18. REV h Button [page 20]
Hit to
fast reverse the Disc.
this button to begin slow motion playback. Hit this
button repeatedly to change the reverse speed of slow
motion.
FWD g Button [page 20]
Hit
to fast forward the Disc. Hit [PAUSEF], then
hit
this button to begin slow motion playback.
this button repeatedly to change the forward speed
of slow motion.
19. V.SURR (VIRTUAL SURROUND) Button
[page 24]
Hit to set virtual surround on/off.
20. SETUP Button [pages 16, 26-28]
Hit
to enter or exit the setup menu of TV or
DVD.
21. TITLE Button [page 19]
Displays the title menu.
22. CLEAR Button [pages 21-22]
Hit to clear or cancel a setting currently entered.
23. DISPLAY Button
TV Mode:
Hit
to display the channel number on the screen.
If you hit it again, the channel number will disappear.
DVD Mode: [page 25]
Displays the current status on the TV screen.
24. SEARCH MODE Button [page 21]
Hit
to locate a desired point.
25. AUDIO Button [page 23]
Hit
to select a desired audio language or sound
mode.
26. SUBTITLE Button [page 23]
Hit
to select a desired subtitle language.
27. REPEAT Button [page 22]
Repeats playback of the current disc, title, chapter
or track.
28. ANGLE Button [page 24]
Hit
to change the camera angle to see the sequence
being played back from a different angle
(if available).
29. A-B Button [page 22]
Repeats playback of a selected section.
Hit [PAUSE F], then hit
Hit
30. RETURN Button [page 21, 24]
Returns to the previous screen in the setup menu.
31. ENTER Button [pages 14, 19]
Hit
to accept a setting.
32. K / L / s / B Buttons
TV Mode: [page 14]
Press to select a setting mode from the menu on
the TV screen.
Press to select or adjust from a particular menu.
DVD Mode: [page 19]
Press to select a menu item.
33. DISC MENU Button [page 19]
Calls up the DVD menu.
34. SELECT Button [pages 11, 19]
Hit
to change to TV mode, external input mode or
DVD mode.
NOTE:
button, press [PLAY O] or [OPEN/CLOSE A]
first. Otherwise, the DVD features are not operated.
35. MUTE Button
Mutes the sound
(Volume level display turns LIGHT RED from
LIGHT BLUE.)
Hit
36. PICTURE Button [page 15]
Hit
37. Power cord
Connect to a standard AC outlet (120V/60Hz).
NOTE: Remove the power cord from the hook
to avoid breaking a wire before you connect to
a standard AC outlet.
38. COAXIAL Jack (DVD Audio Only)
Connect to the digital input of an external
amplifier or decoder.
39. ANT(ENNA). Jack
Connect to an antenna, cable system, or satellite
system.
40. DC 13.2V Jack
Connect to the Car Battery Cord.
When you select the DVD mode by this
.
it again or press [VOL. X / Y] to restore sound.
to enter picture adjustment mode.
INSTALLING THE BATTERIES
1)Open the battery compartment cover by pressing
the cover on the remote unit in the direction of the
arrow.
2)Insert 2 “AA” penlight batteries into the battery
compartment in the direction indicated by the
polarity (+/-) markings.
3)Replace the cover.
[BATTERY PRECAUTIONS]
Be sure to follow the correct polarity as indicated
•
in the battery compartment. Reversed batteries
may cause damage to the device.
Do not mix different types of batteries together
•
(e.g. Alkaline and Carbon-Zinc) or old batteries
with fresh ones.
If the device is not to be used for a long period of
•
time, remove the batteries to prevent damage or
injury from possible battery leakage.
Do not try to recharge batteries not intended to be
•
recharged; they can overheat and rupture.
–9–
–9––9––9––9––9–
EN
PREPARATION FOR USE
DC 13.2V
COAXIAL
ANT.
ANT.
ANTENNA/CABLE CONNECTION
Cables used here are commercially available.
[ANTENNA CONNECTION]
VHF/UHF
75-ohm
Coaxial Cable
VHF
UHF
VHF
VHF
or
UHF
UHF
or
Flat twinlead cable
OR
VHF/UHF
Combiner
Adaptor
*Some cable TV systems use scrambled signals and
require a special converter to receive these channels.
DC 13.2V
ANT.
COAXIAL
ANT.
Consult your local cable company.
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and in particular, specifies that the cable ground shall be connected to the grounding
system of the building as close to the point of cable entry as practical.
[CATV/SATELLITE CONNECTION]
CATV Box or
Satellite Box *
OUTIN
From Cable System or
Satellite Antenna
75-ohm
OR
Coaxial Cable
From Cable System
[Fig. 4]
Cable
Bent pin
Plug
NOTE:
Before plugging the an antenna into the ANT. jack of the unit, check that the
•
pin is not bent. If it is bent, straighten the pin as illustrated, then plug the pin
into the ANT. jack of the unit.
VHF/UHF COMBINED ANTENNA
A VHF UHF 75 ohm combination antenna can be
connected to ANT. jack of the unit.
VHF/UHF SEPARATE ANTENNAS
In some areas it will be necessary to use an outdoor
antenna.
CABLE WITHOUT CONVERTER/
DESCRAMBLER BOX
Use this connection if your cable system connects
directly to the unit without a converter box.
CABLE WITH CONVERTER/DESCRAMBLER BOX OR SATELLITE BOX
If your cable service supplies you with a converter
box or if you use a satellite system, you can use the
(Needs to be straightened)(Straight pin)
basic connection shown above.
Channel selection must be made with the converter
box or satellite box. This means that channels cannot
be changed using the remote control of this unit.
NOTE:
For your safety and to avoid damages to the unit, unplug the antenna cable from the ANT. jack
•
before moving the unit.
INDOOR ANTENNA
The Indoor Antenna (supplied) is detachable. Insert the stem of the antenna into the
hole on the upper-back portion of the unit. Connect the Indoor Antenna to the unit
as shown in the diagram. For the best reception, fully extend the Indoor Antenna
and make the necessary adjustments. (Avoid touching the top section when adjusting.)
NOTE:
The connection of an Indoor antenna may not always give acceptable TV
•
reception.
–10–
–10–
–10––10–
Indoor Antenna
(Supplied)
Flat twin-lead cable
Matching
Adapter
(Supplied)
[Fig. 5]
EN
CONNECTING TO EXTERNAL INPUT JACKS
DC 13.2V
COAXIAL
ANT.
DC13.2V
ANT.
When you watch a program recorded on another source (VCR or video camera), use the
AUDIO/VIDEO input jacks on the front of the unit.
Connect the AUDIO/VIDEO output jacks of another source to the AUDIO L/R and
VIDEO jacks of this unit.
Then
hit
[SELECT] until “AUX” appears on the screen.
ex.
VCR or video camera
, etc.
To the Audio output jacks
(OUT) Audio Cable (IN)
(commercially available)
VIDEO
AUX
AUDIO
L
VIDEO
R
POWER
L
R
AUDIO
To the Video output jack
(OUT) Video Cable (IN)
NOTE:
When you connect a monaural VCR (another source) to this unit, connect the Audio output jack of the monaural
•
(commercially available)
VCR (another source) to the AUDIO L jack of this unit. The audio will output in both L and R channel equally.
MOBILE CONNECTION
WARNING:The driver should never watch the unit while operating a motor vehicle.
CAUTION:
When used in moving vehicle, be sure that the unit is secure at all the times to prevent injury.
•
Consult a professional installer.
If you use the unit with the vehicle’s engine off, recharge the vehicle’s battery after about every
•
4 hours of use to prevent it from running down. After you finish using the unit be sure you
unplug the car-battery cord from the cigarette-lighter socket.
Do not use this unit while driving.
•
Do not leave this unit in a car.
•
This unit is not designed for use in a car.
•
1) The supplied indoor antenna is adequate when your
vehicle is stationary. For best reception on the road,
use a high-quality VHF/UHF mobile TV antenna.
2) Attach the car battery cord to the DC13.2V(12V)
connector on the back of the unit. Then, connect the
other end to your vehicle’s cigarette-lighter socket.
NOTES:
Be sure your vehicle has a 13.2-volt (12-volt), nega-
•
tive-ground electrical system.
Be sure you use only the supplied car battery cord.
•
Using another cord could damage the unit.
Be sure the socket is free of ashes and other debris.
•
Be sure to push the car battery cord’s plug completely
•
into the cigarette-lighter socket.
Always unplug the car battery from the cigarette-
•
lighter socket before you unplug it from the unit.
You must disconnect the car battery cord from the unit
•
before you can use the AC power.
Be sure to replace the fuse with only the same type, 6A, 250V.
•
–11–
–11–
–11––11–
To the vehicle's
cigarette-lighter socket
VHF/UHF Combination
Mobile Antenna
(Not supplied)
Car battery cord
(Supplied)
[Fig. 6]
EN
CONNECTING TO A STEREO AMPLIFIER EQUIPPED WITH
DC 13.2V
COAXIAL
ANT.
ex.
MD deck, DAT deck, etc.
To Coaxial digital
Audio input jack
Audio coaxial digital cable
(commercially available)
To COAXIAL jack
(Only DVD AUDIO OUT)
(OUT)(IN)
COAXIAL
DIGITAL INPUT JACKS (for DVD)
Use an audio coaxial digital cable (commercially available) for the audio connections.
Connect to an amplifier equipped with digital input jacks such as MD Deck or DAT Deck.
[Fig. 7]
NOTES:
The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital
•
sound by an MD or DAT deck.
Be sure to turn off the power to all components in the system before connecting another component.
•
Refer to the Owner’s Manuals for the components to be connected to the unit.
•
Set DOLBY DIGITAL to “OFF” for audio output in the setup mode. Playing a unit using incorrect settings
•
may generate noise distortion, and may also damage the speakers. (Refer to page 27 to set DOLBY
DIGITAL to “OFF”.)
–12–
–12–
–12––12–
EN
CONNECTING TO A DOLBY DIGITAL DECODER (for DVD)
DC 13.2V
COAXIAL
ANT.
Front speaker
(left)
Center
speaker
Front speaker
(right)
Surround
speaker
(left)
Surround
speaker
(right)
Subwoofer
(IN)
(OUT)
To COAXIAL jack
(Only DVD AUDIO OUT)
Dolby Digital decoder
To Coaxial digital
Audio input jack
Audio coaxial
digital cable
(commercially
available)
COAXIAL
If using this unit to play a DVD disc in a 5.1 channel Dolby Digital surround format, the unit outputs a
DOLBY DIGITAL Data stream from its COAXIAL jack. By hooking the unit up to a Dolby Digital decoder,
you can enjoy a more convincing, realistic ambience with powerful and high-quality surround sound as
enjoyed in movie theaters.
Use audio coaxial digital cables (commercially available) for the audio connections.
[Fig. 8]
NOTES:
Be sure to turn off the power to all components in the system before connecting another component.
•
Refer to the Owner’s Manuals for the components to be connected to the unit.
•
If connected to a Dolby Digital decoder, set DOLBY DIGITAL to “ON” for audio output in the setup mode.
•
(Refer to page 27 to set DOLBY DIGITAL to “ON”.)
Unless connected to a Dolby Digital decoder, set DOLBY DIGITAL to “OFF” for audio output in the setup
•
mode. Playing a unit using incorrect settings may generate noise distortion, and may also damage the speakers.
Manufactured under license from Dolby Laboratories.“Dolby” and the double-D symbol are
trademarks of Dolby Laboratories.
–13–
–13––13––13–
EN
Loading...
+ 28 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
