30” OVEN 400 SERIES
Termoventilato
Sistema
Autopulente
per PIROLISI
Porta Fredda
< 50°C
Illuminazione
in Vasca
Digit
Control
Heavy
Duty
Grates
CODE ID
OVEN 400 SERIES
F4SP30S3
True Convection
Self Clean Oven
Multi-level cooking
Cool Touch Door
Interior Lighting
Digital Controls
SPECIFICATIONS
OVEN
Knob and electronic controls
Single fan true convection
Self-cleaning oven with Multifunction baking
Black Porcelain enamel interior
Cool to the touch
Extra-large baking cavity and viewing area
3 Halogen lights for flawless visibility
Gross capacity 4.4 cu. ft.
2 chrome racks
Enameled Broiler Pan
OVEN FUNCTIONS
Bake
Broil
Roast
Convection
True Convection
Dehydrate
Electronic cooking programmer
Self-Clean
Sabbath Mode
OPTIONAL ACCESSORIES
FMTR630 30" Telescopic Rack
FULGOR MILANOfulgor-milano.us
DISTINTO
27-3/8"
( 695 )
24"
( 610 )
27-7/8"
( 707 )
23-1/8"
( 587 )
29-3/4"
( 754 )
28-7/16"
( 722 )
OVEN 400
CODE ID
30" OVEN 400
F4SP30S3
Series 400
Finish Stainless Steel
CONTROL PANEL
Control Type Electronic
Display: Clock - Temperature - Timer White LED
Language English
OVEN
Type True Convection
Temperature Regulation Electronic Control (min/max 120/485°F - 50/250°C)
OVEN FUNCTIONS
Pyrolytic Self-Clean Bake
True Convection Broil
Convection Bake Thaw (Defrost)
Convection Broil Oven Lights
Convection Roast
ELECTRIC OVEN FEATURES
Temperature Display °C/°F
OVEN DOOR(S)
Oven Glass Window Large See Through Glass
Door Cooling System 4 Heat Resistant Glasses
Door Hinges Heavy Duty Steady Tilt
OVEN CAVITY
Gross Capacity (cbft) 4.4
Usable Capacity (cbft) 4.1
Cavity Enamel Color Black
Rack Positions 6
Oven Lights 3x20W Halogen
HEATING ELEMENTS (@240V)
Broil Upper Heating Element 3100 W
Upper Auxiliary Element 1032 W
Lower Auxiliary Element 600 W
Concealed Bake Lower Heating Element 1400 W
Convection Element 2500 W
OVEN ACCESSORIES
Chrome Racks 2
Enameled Broiler Pan (basin + anti splash) 1
Telescopic Chrome Rack Optional
DIMENSIONS/WEIGHT
Overall dim - Width 29 - 11/16" 754 mm
Overall dim - Height 27 - 7/8" 707 mm
Overall dim - Depth 24" 610 mm
Cut-out - Width 28 - 7/16" 722 mm
Cut-out - Height (min) 27 - 1/4" 692 mm
Cut-out - Depth (min) 23 - 1/4" 590 mm
Gross Weight 181 lbs 82 kg
POWER / RATINGS (208/240 V, 60 HZ)
kW / Amps rating at 120-240V, 60Hz 3.70kW - 16.1A
kW / Amps rating at 120-208V, 60Hz 3.49kW - 17.1A
Power Cable Conduit
INSTRUCTIONS FOR USE
Use & Care Manual / Installation Manual English / French / Spanish
