Monitor
Operating Manual
English
SCENICVIEW B17-3/B19-3/P19-3
Are there…
... any technical problems or other questions which you would like to be clarified?
Please contact
our help desk (see Warranty Booklet).
The latest information on our products, tips, updates, etc., can be found on the internet under:
http://www.fujitsu-siemens.com
This manual was produced by
Xerox Global Services
Published by
Fujitsu Siemens Computers GmbH
Order No.: A26361-K1143-Z120-1-7619
Edition 3
AG 08/07
SCENICVIEW
B17-3/B19-3/P19-3
LCD monitor
Operating Manual
august 2007 edition
VESA, DDC and DPMS are registered trademarks of Video Electronics Standards
Association.
Copyright © Fujitsu Siemens Computers GmbH 2007
All rights, including rights of translation, reproduction by printing, copying or similar methods,
in part or in whole, are reserved.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or design,
are reserved.
Delivery subject to availability. Right of technical modification reserved.
No liability for content and printing error.
Contents
Introduction........................................................................................................................................... 1
Notational conventions ................................................................................................................. 2
Important notes..................................................................................................................................... 2
Safety notes.................................................................................................................................. 2
Power cable.................................................................................................................................. 4
Transport ...................................................................................................................................... 4
Cleaning ....................................................................................................................................... 4
CE marking................................................................................................................................... 4
FCC Class B Compliance Statement ........................................................................................... 5
Declaration of Conformity............................................................................................................. 5
Energy Star Guidelines................................................................................................................. 6
Disposal and recycling ................................................................................................................. 6
Checking the contents of the consignment........................................................................................... 7
Installing an ergonomic video workstation............................................................................................ 8
Mounting and removing the monitor base ............................................................................................ 9
Folding out monitor base.............................................................................................................. 9
Removing monitor base ............................................................................................................. 11
Connecting the monitor .............................................................................................................. 12
Connecting cables to the monitor............................................................................................... 13
Connecting cables to the computer............................................................................................ 14
Operation of the monitor..................................................................................................................... 14
Adjusting height, rake and rotation.............................................................................................14
Adjusting portrait format ............................................................................................................. 15
Switching the monitor on and off (B17-3 / B19-3)....................................................................... 15
Switching the monitor on and off (P19-3) ................................................................................... 16
Notes on power management .................................................................................................... 17
Changing the monitor settings.................................................................................................... 18
Notes on ergonomic colour adjustment.............................................................................................. 23
Troubleshooting.................................................................................................................................. 24
Notes regarding the DIN EN ISO 13406-2 standard .......................................................................... 26
Technical data .................................................................................................................................... 27
VESA-DDC-compatible VGA interface....................................................................................... 28
Preset operating modes ............................................................................................................. 28
Pin assignment D-SUB............................................................................................................... 29
Monitor port DVI-D...................................................................................................................... 29
A26361-K1143-Z120-1-7619, edition 3
Contents
A26361-K1143-Z120-1-7619, edition 3
Introduction
Your new LCD (Liquid Crystal Display) monitor SCENICVIEW B17-3/B19-3/P19-3 offers numerous
features and functions, for example:
● TFT display (Thin Film Transistor; active matrix)
● minimal space requirements thanks to slim casing
● optimum ergonomic characteristics (totally distortion-free, excellent picture definition and colour
purity right into the corners)
● high degree of brightness and good contrast
● high resolution (1280 x 1024)
● presentation of up to 16.7 million colours (in conjunction with an appropriate graphics card)
● automatic scanning of horizontal frequencies from 30 to 82 kHz and refresh rates (vertical
frequencies) from 56 to 76 Hz (absolutely flicker-free)
● digital screen controller with microprocessor for storing 26 different display modes
● freely adjustable colour alignment for matching the screen colours to the colours of various
input and output devices
● convenient operation via integrated OSD (On-Screen-display) menu
● VESA-DDC compatibility
● VESA-FPMPMI compatibility (Flat Panel Monitor Physical Mounting Interface) – Mounting
device for swivel arm and wall bracket
● plug&play capability
● power management for reducing power consumption when the computer is not in use
● compliance with the recommendations in accordance with TCO’03
● The monitor fulfils all GS (“Geprüfte Sicherheit”, Certified Security) requirements.
This operating manual contains important information you require to start up and run your LCD
monitor.
A graphics card (screen controller) with VGA interface or a digital graphics card with DVI interface is
required to control the SCENICVIEW B17-3/B19-3/P19-3 LCD monitor. The monitor processes the
data supplied to it by the screen controller. The screen controller or the associated driver software is
responsible for setting the modes (resolution and refresh rate).
When putting the monitor into operation for the first time, the screen display should be optimally
adapted to the screen controller used and adjusted in accordance with your needs (see the
Changing the monitor settings" section in the "Operation of the monitor" chapter).
"
Target group
You don't need to be an "expert" to perform the operations described here. However, please observe
the safety information given in the operating instructions of the computer and in this manual.
In the event of any problems occurring, please contact your sales outlet or our help desk.
Additional information
Details of how you set the resolution and refresh rate are provided in the documentation on your
screen controller/the associated driver software.
For ergonomic reasons we recommend a screen resolution of 1280 x 1024 pixels for the monitors
SCENICVIEW B17-3, B19-3 and P19-3.
Because of the technology used (active matrix) an LCD monitor provides a totally flicker-free picture
even with a refresh rate of 60 Hz.
A26361-K1143-Z120-1-7619, edition 3 1
SCENICVIEW B17-3/B19-3/P19-3
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
► Text which follows this symbol describes activities that must be performed in the order shown.
"Quotation marks" indicate names of chapters or terms.
This font indicates filenames and menu items.
This font indicates screen outputs.
Pay particular attention to text marked with this symbol. Failure to observe this warning
endangers your life, destroys the device, or may lead to loss of data.
!
Supplementary information, remarks, and tips follow this symbol.
i
Important notes
In this chapter you will find information regarding safety which is essential to take note of
with your monitor.
!
Safety notes
This device complies with the relevant safety regulations for data processing equipment, including
electronic office machines for use in an office environment. If you have any questions, contact your
sales outlet or our help desk.
● The display surface of the LCD monitor is sensitive to pressure and scratches. You should
therefore be careful with the display surface so as to avoid lasting damage (scratches).
● If the device is brought into the installation site from a cold environment, condensation can
form. Before operating the device, wait until it is absolutely dry and has reached approximately
the same temperature as the installation site.
● During installing and operating the device, please observe the instructions on environmental
conditions in the "
ergonomic video workstation
Technical data" chapter as well as the instructions in the "Installing an
" chapter.
2 A26361-K1143-Z120-1-7619, edition 3
SCENICVIEW B17-3/B19-3/P19-3
● To ensure sufficient ventilation, the intake and exhaust air openings of the monitor must never
be blocked.
● The monitor automatically sets itself to a mains voltage in the range of 100 V to 240 V. Ensure
that the local mains voltage lies within these limits.
● Ensure that the power socket on the device or the grounded mains outlet is freely accessible.
● The ON/OFF switch does not disconnect the device from the mains voltage. To completely
disconnect the mains voltage, remove the power plug from the socket.
● The monitor is equipped with a power cable that complies with safety standards.
● Lay all cables so that nobody can stand on them or trip over them. When attaching the device,
observe the relevant notes in the "
● No data transfer cables should be connected or disconnected during a thunderstorm.
● Make sure that no objects (e.g. jewellery chains, paper clips, etc.) or liquids get inside the
device (danger of electric shock, short circuit).
● The device is not waterproof! Never immerse the device in water and protect it from spray
water (rain, sea water).
● In emergencies (e.g. damaged casing, elements or cables, penetration of liquids or foreign
matter), switch off the unit, disconnect the power plug and contact your sales outlet or our help
desk.
● The monitor must be disposed of in accordance with the local regulations for disposal of
special waste. The screen background lighting contains mercury. You must observe the
applicable handling and disposal safety regulations for fluorescent tubes.
● Only qualified technicians should repair the device. Unauthorised opening and incorrect repair
may greatly endanger the user (electric shock, fire risk).
● You may set only those resolutions and refresh rates specified in the "
Otherwise you may damage your monitor. If you are in any doubt, contact your sales outlet or
our help desk.
● Use a screen saver with moving images and activate the power management for your monitor
to prevent still images from "burning in".
● If you operate the monitor with the swivel arm or wall bracket, it may not be turned by 180°.
● The SCENICVIEW B17-3/B19-3/P19-3 monitor may only be operated in landscape mode (0°)
and portrait mode (90°). The control buttons are located at the bottom of the monitor in
landscape mode (0°) and at the left-hand side of the monitor in portrait mode (90°).
● Store this manual close to the device. If you pass the device on to third parties, you should
pass this manual on with it.
Connecting the monitor" chapter.
Technical data" chapter.
A26361-K1143-Z120-1-7619, edition 3 3
SCENICVIEW B17-3/B19-3/P19-3
Power cable
To guarantee safe operation, use the cable supplied. Use the following guidelines if it is necessary to
replace the original cable set.
● The female/male receptacles of the cord set must meet IEC60320/CEE-22 requirements.
● The cable has to be HAR-certified or VDE-certified. The mark HAR or VDE will appear on the
outer sheath.
● For devices which are mounted on a desk or table, type SVT or SJT cable sets may be used.
For devices which sit on the floor, only SJT type cable sets may be used.
● The cable set must be selected according to the rated current for your device.
● If necessary, replace the original power cable with a regular grounded 3-core mains lead.
Transport
● Transport the monitor with care and only in its original packaging or another corresponding
packaging fit to protect it against knocks and jolts.
● Never drop the LCD monitor (danger of glass breakage).
Cleaning
● Always pull out the power plug before you clean the monitor.
● Do not clean any interior parts yourself, leave this job to a service technician.
● Do not use any cleaning agents that contain abrasives or may corrode plastic.
● Ensure that no liquid will run into the system.
● Ensure that the ventilation areas of the monitor are free.
● The display surface of the LCD monitor is sensitive to pressure and scratches. Clean it only
using a soft, slightly moistened cloth.
Wipe the monitor casing with a dry cloth. If the monitor is particularly dirty, use a cloth which has
been moistened in mild domestic detergent and then carefully wrung out.
CE marking
The shipped version of this device complies with the requirements of the following EC
Directives: 2004/108/EC "Electromagnetic Compatibility" and 2006/95/EC "Low Voltage
Directive".
4 A26361-K1143-Z120-1-7619, edition 3
SCENICVIEW B17-3/B19-3/P19-3
FCC Class B Compliance Statement
The following statement applies to the products covered in this manual, unless otherwise specified
herein. The statement for other products will appear in the accompanying documentation.
NOTE:
This equipment has been tested and found to comply with the limits for a "Class B" digital device,
pursuant to Part 15 of the FCC rules and meets all requirements of the Canadian InterferenceCausing Equipment Standard ICES-003 for digital apparatus. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in strict
accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between equipment and the receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
● Consult the dealer or an experienced radio/TV technician for help.
Fujitsu Siemens Computers GmbH is not responsible for any radio or television interference caused
by unauthorised modifications of this equipment or the substitution or attachment of connecting
cables and equipment other than those specified by Fujitsu Siemens Computers GmbH. The
correction of interferences caused by such unauthorised modification, substitution or attachment will
be the responsibility of the user.
The use of shielded I/O cables is required when connecting this equipment to any and all optional
peripheral or host devices. Failure to do so may violate FCC and ICES rules.
Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Product name: Colour LCD Monitor
Trade name: Fujitsu Siemens Computers Inc.
Model number(s): SCENICVIEW B17-3/B19-3/P19-3
Name of responsible party: Fujitsu Siemens Computers Inc.
Contact person: Schroettle-Henning, Bernd
Phone No.: (408) 834-0306
Fax No.: (408) 746-8299
We, Fujitsu Siemens Computers Inc., hereby declare that the equipment bearing the trade name and
model number specified above was tested confirming to the applicable FCC Rules under the most
accurate measurement standards possible, and that all the necessary steps have been taken and
are in force to assure that production units of the same equipment will continue to comply with the
Commissions requirements.
A26361-K1143-Z120-1-7619, edition 3 5
1250E. Arques Avenue
Sunnyvale, CA 94085
U.S.A.
SCENICVIEW B17-3/B19-3/P19-3
Energy Star Guidelines
The Fujitsu Siemens LCD monitor SCENICVIEW B17-3/B19-3/P19-3 is
designed to conserve electricity by dropping to less than 1 W when it goes
into standby, suspend and OFF mode. With this new power management
the LCD monitor SCENICVIEW B17-3/B19-3/P19-3 qualifies for the U.S.
Environmental Protection Agency's (EPA) Energy Star Computers award.
The EPA estimates that computer equipment uses 5 % percent of all business electricity and that
this is growing rapidly. If all desktop computers and peripherals enter a low-power mode when not in
use, the overall savings in electricity could amount to $ 2 thousand million annually. These savings
could also prevent the emission of 20 million tons of carbon dioxide into the atmosphere - the
equivalent of 5 million automobiles.
As an Energy Star Partner, Fujitsu Siemens Computers GmbH has determined that this product
meets the Energy Star guidelines for energy efficiency.
Disposal and recycling
This device has been manufactured to the highest possible degree from materials which can be
recycled or disposed of in a manner that is not environmentally damaging. The device may be taken
back after use to be recycled, provided that it is returned in a condition that is the result of normal
use. Any components not reclaimed will be disposed of in an environmentally acceptable manner.
If you have any questions on disposal, please contact your local office, our help desk, or:
Germany Belgium Switzerland
Fujitsu Siemens Computers
GmbH
Remarketing und Recycling
D-33106 Paderborn
Tel.: +49 5251 / 81 80 10
Fax: +49 5251 / 81 80 15
http://www.fujitsu-siemens.de/wvm
Asia USA
Taiwan: Environmental
Protection Administration
Executive Yuan R.O.C.
http://recycle.epa.gov.tw/
You can find more information on the Internet at www.fujitsu-siemens.com/recycling.
RECUPEL
Boulevard Reyers, 80
B-1030 Brussels
Tel.: +32 2 / 706 86 16
Fax: +32 2 / 706 86 13
E-Mail: info@recupel.be
http://www.recupel.be
Fujitsu Siemens
Computers Inc.
1250E. Arques Avenue
Sunnyvale, CA 94085 U.S.A.
Contact: Schroettle-Henning,
Bernd
Phone No.: (408) 834-0306
Fax No.: (408) 746-8299
SWICO
Schweizerischer
Wirtschaftsverband der
Informations-,
Kommunikations- und
Organisationstechnik
A list of the SWICO
Acceptance places can be
found at:
http://www.swico.ch
6 A26361-K1143-Z120-1-7619, edition 3
SCENICVIEW B17-3/B19-3/P19-3
Checking the contents of the consignment
The display surface of the LCD monitor is sensitive to pressure and scratches. Always
hold the device by the casing!
!
► Unpack all the individual parts.
► Check the delivery for damage incurred during transportation.
► Check whether the delivery agrees with the details in the delivery note.
The complete LCD monitor package includes:
– one monitor
– one data cable (D-SUB)
– one data cable (DVI-D)
– one audio cable
– one power cable
– one CD with software and documentation
– one Warranty Booklet
– one "Getting Started" manual
Should you discover that the delivery does not correspond to the delivery note, notify your local sales
outlet immediately.
We recommend that you keep the original packaging material. Keep it for future
transportation.
i
A26361-K1143-Z120-1-7619, edition 3 7
SCENICVIEW B17-3/B19-3/P19-3
Installing an ergonomic video workstation
2
1
1
1 = Windows
Avoid direct and reflected glare.
1 = Bearing surface for palms
of hands
2 = Reaching area for
frequently used equipment
Position the monitor for
optimum viewing. The viewing
distance to the monitor should
be approximately 50 cm.
Avoid glare from electric
lighting.
Example layout of monitor,
keyboard and copy-holder
Keep ventilated areas clear.
i
1 = Edge of desk
2 = Permissible reaching
sector
Position the keyboard where it
is easiest to reach.
1
0°
60°
65°
65°
30°
30°
22
1 = Preferred viewing distance
2 = Permissible viewing
distance
Position the monitor for
optimum viewing. The viewing
distance to the monitor should
be approximately 50 cm.
Depending on the situation, the use of a swivel arm or wall bracket (VESA FPMPMI), are available
from specialised dealers, may be advisable. For this purpose the monitor base must be removed
beforehand as described in the "
Mounting and removing the monitor base" chapter.
8 A26361-K1143-Z120-1-7619, edition 3
SCENICVIEW B17-3/B19-3/P19-3
Mounting and removing the monitor base
The display surface is susceptible to scratching! Therefore, lay the monitor on a soft
surface when mounting or removing the monitor base.
!
Folding out monitor base
When delivered the lower part of the monitor base is folded up and secured to the monitor by a
collar.
The monitor base springs up about 5 cm when the collar is released.
!
► Lay the monitor on its face on a soft surface (A).
► First release one of the collar fasteners (1).
► Release carefully the second collar fastener (2).
The monitor base can now be folded out.
A26361-K1143-Z120-1-7619, edition 3 9
SCENICVIEW B17-3/B19-3/P19-3
► Proceed according to the four steps in the illustrations to fold out the monitor base.
10 A26361-K1143-Z120-1-7619, edition 3
SCENICVIEW B17-3/B19-3/P19-3
Removing monitor base
Before you can use a swivel arm or a wall bracket, you must remove the monitor base:
The display surface is susceptible to scratching!
!
► Switch off the monitor and pull the power plug out of the power socket.
► Lay the monitor on its face on a soft surface.
► Remove the cover and disconnect all cables.
► Remove the four screws on the rear of the
monitor.
You can now mount a swivel arm or a wall
bracket as per VESA FPMPMI with 100 mm hole
spacing.
For instructions on how to mount the swivel arm
or wall bracket, please see the documentation for
the swivel arm or wall bracket.
A26361-K1143-Z120-1-7619, edition 3 11
If you operate the monitor with the swivel arm or wall bracket, it may not be turned by 180°.
!
SCENICVIEW B17-3/B19-3/P19-3
Connecting the monitor
Please take note of the safety information in the "
!
CE conformance and optimum picture quality are guaranteed only if you use the data
cables supplied.
Do not cover the ventilation openings of the monitor.
The computer power plug must be pulled out!
► Be sure that the monitor and the computer are switched off.
Important notes" chapter.
12 A26361-K1143-Z120-1-7619, edition 3
SCENICVIEW B17-3/B19-3/P19-3
Connecting cables to the monitor
The monitor ports are protected by a cover.
► Remove the cover.
7
7
4 6
The data cables supplied have two 15-pin D-SUB connectors / two 24-pin DVI connectors for
connection to the monitor and to the computer.
► Select the suitable data cable for your computer.
Digital graphics card with DVI interface: DVI connector
Graphics card with VGA interface: D-SUB connector
Information on the computer connections and interfaces is contained in the operating manual
for your computer.
► Connect one of the connectors of the data cable to the D-SUB connector (3) or the DVI-D
connector (2) on the monitor and secure the plug-in connection by tightening the safety screws.
► Insert one plug of the audio line in the AUDIO IN (5) socket on the monitor and make sure it is
► Plug the power cable supplied into the power connector (1) of the monitor.
► Mount the cover over the connections.
The monitor automatically detects the input when only one signal source is connected.
i
properly engaged.
A lock (Kensington Lock) can be mounted in the security slot (4) to protect the monitor
from theft. A Kensington Lock is not included in the consignment of the monitor.
i
1 = Power connector
2 = DVI-D connection socket (DIGITAL)
3 = D-SUB connection socket (ANALOG)
4 = Security slot for "Kensington Lock"
5 = AUDIO-IN connector
6 = Cover position
7 = Holes for fixing swivel arm or wall bracket
1 532
A26361-K1143-Z120-1-7619, edition 3 13
SCENICVIEW B17-3/B19-3/P19-3
Connecting cables to the computer
Information on the computer connections and interfaces is contained in the operating manual for your
computer.
► Connect the data cable to the (active) monitor port on the computer and secure the plug-in
► Insert the other plug of the audio line in the audio output of the computer.
► Plug the connector of the mains cable provided into the monitor outlet of the computer or into a
► Plug the power connector of the computer into a properly grounded mains outlet.
If your computer has two monitor ports ("onboard" screen controller and separate
graphics card), the monitor port for the separate graphics card is usually active.
i
connection by tightening the safety screws.
properly earthed outlet and ensure a safe connection.
When you start working with your monitor for the first time you should install the
appropriate graphics drivers for your application software. Details of how to do this are
i
provided in the documentation on your screen controller/the associated driver software.
Operation of the monitor
The monitor offers the following possibilities that enable it to be optimally adjusted for the respective
user and the respective situation.
Adjusting height, rake and rotation
The height of the monitor can be adjusted by approximately 120 mm.
► Grasp the monitor with both hands on the right and left edge of the casing and move it up or
down.
The rake of the monitor can be adjusted by -2° (forward) and +35° (back) from its vertical position.
► Grasp the monitor with both hands on the right and left edge of the casing and adjust it to the
desired rake.
The monitor can be turned horizontally by approximately 90° from its central position.
► Grasp the monitor with both hands on the right and left edge of the casing and turn it to the
desired position.
14 A26361-K1143-Z120-1-7619, edition 3
SCENICVIEW B17-3/B19-3/P19-3
Adjusting portrait format
The monitor can be turned from the "wide format" (landscape mode) into the "high format" position
(portrait mode).
► Grasp the monitor with both hands on the right and left edge of the casing, move it into the
highest position and turn it clockwise until it is in the portrait position.
► In the OSD menu you have the option of switching the OSD manually from landscape mode
To reset the monitor to the landscape mode, the monitor must be turned counter-clockwise. The
OSD display can be reset again in the OSD menu.
You must use corresponding software (pivot software) so that the screen display is also
shown in the portrait mode. This software is included in the delivery (CD-ROM) and must
i
be installed on your computer.
into portrait mode (see section "
Monitor settings using the OSD menu").
Switching the monitor on and off (B17-3 / B19-3)
The ON/OFF switch at the front is used for switching the monitor on and off.
3 2 1
1 = Buttons for the OSD menu
(On-Screen-display)
2 = ON/OFF switch
3 = Power indicator
1
3
2
A26361-K1143-Z120-1-7619, edition 3 15
The buttons are to be pressed from the bottom upwards.
i
SCENICVIEW B17-3/B19-3/P19-3
Switching the monitor on and off (P19-3)
The main switch on the underside and the On/Off switch on the front of the monitor are used to
switch it on and off.
► Switch on the monitor via the main switch (4) on the underside.
34 2 1
1 = Buttons for the OSD menu
(on-screen display)
2 = On/Off switch
3 = Mains power indicator
4 = Main switch
1
3
2
The mains power indicator (3) lights up blue when the monitor and the computer are switched on.
The mains power indicator lights up orange when the monitor is not receiving a video signal or when
it is in energy saving mode. The mains power indicator goes out when the monitor is switched off.
When you switch the computer system on, you must proceed in the following order:
► First switch on the LCD monitor with the ON/OFF switch (2).
► Then switch on the computer.
If your computer has a power management function (energy-saving mode), you should
read the "
i
Notes on power management" section in this chapter.
16 A26361-K1143-Z120-1-7619, edition 3
SCENICVIEW B17-3/B19-3/P19-3
Notes on power management
If your computer is equipped with power management, the monitor can support this function fully.
Here the monitor does not distinguish between the individual energy-saving modes of the computer
(standby mode, suspend mode and OFF mode), as it is capable of immediately switching into the
mode with the highest energy-saving effect.
Stage ON Power-Saving Mode
Power indicator lights up blue lights up orange
Function the monitor is working
Power consumption Normal
If your computer detects inactivity (no input) it sends an appropriate signal to the monitor to reduce
the power consumption (energy-saving mode). The power indicator of the monitor changes colour to
indicate the status change.
Once an input is made at the computer the screen contents are redrawn and full power is restored.
For detailed information on how energy-saving mode operates refer to the operating manual or
technical manual of the computer.
When the monitor is switched to the energy-saving mode by the power management
system a power consumption of up to 1 W is maintained to feed the circuit for redrawing
i
the screen contents.
In order to stop the monitor from using any power at all, switch it off at the main switch on
the underside (P19-3).
normally
< 37 W typical
the screen is dark
reduced to < 1 W
A26361-K1143-Z120-1-7619, edition 3 17
SCENICVIEW B17-3/B19-3/P19-3
Changing the monitor settings
When putting the monitor into operation for the first time, the screen display should be optimally
adapted to the screen controller used and adjusted in accordance with your needs.
Choosing basic monitor settings using the supplied software
If one of the operating systems Windows 95/98, Windows NT, Windows Me, Windows 2000,
Windows XP or OS/2 (with Windows emulation installed) is used, the basic monitor settings can be
set with the CD supplied.
► Insert the supplied CD into the CD-ROM drive.
► Open the
Your monitor should now already be properly adjusted. If none of the above operating systems is
used or minor corrections are to be made to the screen display, then change the monitor settings
with the OSD menu.
Changing the monitor settings with the buttons of the control panel
1 = Buttons for the OSD menu
(On-Screen-display)
Use the buttons of the control panel to make the following monitor settings directly while the OSD
menu is switched off.
Readme file on the CD and follow the instructions in the file.
2 = ON/OFF switch
3 = Power indicator
Performing auto-adjustment of the monitor
► Press the AUTO button for approx. 1 second while the OSD menu is switched off.
Auto Processing message is displayed.
The
Picture quality and position are set to optimum values for your system.
Selecting input signal (D-SUB/DVI-D)
► Press the INPUT button for calling the Input select setting window.
► Press the
This setting window can also be called, when the OSD menu is locked.
Activating/deactivating muting
► Press the button to switch the sound off and on again.
A message is displayed that the action has been performed.
18 A26361-K1143-Z120-1-7619, edition 3
or 5 button to select the desired input (analogue D-SUB or digital DVI-D).
6
SCENICVIEW B17-3/B19-3/P19-3
Locking the OSD menu
The OSD menu can be locked to prevent accidental or unauthorised changes to the monitor settings.
► Press and hold the SELECT/MENU button for a few seconds while you switch on the monitor
with the ON/OFF switch.
A message is displayed that the action has been performed.
Please proceed in the same manner to release the locked OSD menu again.
Locking the ON/OFF button
The ON/OFF switch can be locked to prevent accidental or unauthorised changes to the monitor
settings.
► Press and hold both buttons
A message is displayed that the action has been performed.
Please proceed in the same manner to release the locked ON/OFF switch again.
and 5 simultaneously for a few seconds.
6
Monitor settings using the OSD menu
With the buttons on the control panel, call up and use the integrated OSD (On-Screen display) menu.
To set the OSD menu, perform the following steps:
► Press the SELECT/MENU button to activate the OSD menu.
The main menu appears on the screen (on the left-hand side) with icons for the setting functions.
The OSD menu is available in different languages. The English menu names are used in
the following description (default setting). With the OSD function
i
you can select another language.
The first symbol (Brightness/Contrast) is
highlighted. In the right-hand part of the display
the associated functions are shown.
► If necessary, press the
mark another icon (e.g.
► Press the SELECT/MENU button to select
the highlighted icon.
Language in the OSD Setup
6
Image adjust).
or 5 button to
A26361-K1143-Z120-1-7619, edition 3 19
SCENICVIEW B17-3/B19-3/P19-3
The corresponding setting window (here: Image Adjust) is displayed (on the right-hand side).
The first function (H-Position) is highlighted.
► If necessary, press the
mark another function.
► Press the SELECT/MENU button to select
the highlighted function.
► Press the
value for the selected function.
► Press the EXIT/AUTO button to exit the
function.
► If necessary, press the button
mark another function or press the
EXIT/AUTO button to return to the main
menu.
All changes are stored automatically.
If you want to change other settings, select the corresponding function from the OSD main menu. All
possible adjustments of the main menu are described in the following.
Adjusting the brightness and contrast
The OSD menu for analogue monitor operation is described in the following. During digital
operation some functions are not available, as they are not required due to the digital
i
transmission technology used.
or 5 button to adjust the
6
or 5 button to
6
or 5 to
6
Calling the
Brightness
Contrast
Black Level
Auto Level
i
20 A26361-K1143-Z120-1-7619, edition 3
Setting the brightness of the display
With this function you change the brightness of the background lighting.
Setting the contrast of the display
With this function you modify the contrast of bright colour tones.
Setting the brightness of the display
With this function you modify the contrast of dark colour tones.
Setting the brightness of the display
With this function you can automatically set the contrast.
Press the SELECT/MENU button to activate the function.
If the contrast is set too high, bright surfaces can no longer be distinguished from very
bright surfaces. If the contrast is set too low, the maximum brightness will not be achieved.
Brightness / Contrast setting window
SCENICVIEW B17-3/B19-3/P19-3
Adjusting size and position
H-Position
Calling the
Adjusting the horizontal position
Image adjust setting window
With this function you move the picture to the left or to the right.
V-Position
Adjusting the vertical position
With this function you move the picture up or down.
Clock
Setting synchronisation
With this function you adjust the picture width to eliminate vertical picture
disturbances.
Phase
Eliminating picture interference
With this function you fine-tune your monitor to eliminate picture interference.
Adjusting the volume
Volume
Mute
Calling the
Setting the volume for playback with the integrated loudspeakers
Switching the loudspeakers off or on
Audio setting window
Setting colour temperature and colours
Calling the
Colour setting window
Selecting the colour temperature
The "warmth" of the screen colours is set using the colour temperature. The colour
temperature is measured in K (= Kelvin). You can select from
9300 K, Native and Custom Colour.
sRGB
Native
Custom Colour
= setting colour display according to the sRGB standard
= Original colour of the LCD display
= User-defined colours
In the user-defined setting you can change the colour ratios of the basic colours
(red, green, blue) as required.
sRGB, 6500 K,
A26361-K1143-Z120-1-7619, edition 3 21
SCENICVIEW B17-3/B19-3/P19-3
Setting display of the OSD menu
Calling the
Language
OSD
H-Position
OSD
V-Position
OSD
Timeout
OSD
Rotation
Setting functions in the "Advanced" menu
Input select
DDC-CI
Resolution
Notifier
Factory Recall
Setting language for the OSD menu
With this function you choose between English (default setting), French, German,
Italian and Spanish as the language for the OSD menu.
Setting the horizontal position of the OSD menu
With this function you move the OSD menu to the left or to the right.
Setting the vertical position of the OSD menu
With this function you move the OSD menu up or down.
Setting the display duration of the OSD menu
With this function you select a value from 10 to 120 seconds.
If the set time expires without a setting being made, the OSD menu is automatically
faded out.
Setting the display format of the OSD menu
With this function you switch the OSD menu from portrait mode to landscape mode
and vice versa.
Off
On
Calling the
Selecting input signal
With this function you switch the monitor from the analogue to the digital mode and
vice versa, when two signal sources are connected.
The condition is that the graphic card used supports this function.
Activate/deactivate DDC-CI function
On = the DDC-CI function is activated (default setting)
Off = the DDC-CI function is deactivated
Displaying monitor data
The optimum resolution for this monitor is 1280 x 1024 pixels. With the function
activated (
different resolution is set.
Change the resolution to 1280 x 1024 to achieve optimum picture quality.
With the function deactivated (
Activating the factory settings
With this function all settings are reset to the factory settings without prompting for
confirmation.
Press the SELECT/MENU button to activate the function. The
message is displayed.
OSD Setup setting window
= The OSD menu is displayed in portrait mode.
= The OSD menu is displayed in landscape mode.
Advanced setting window
On), a message appears on the screen after approx. 30 seconds if a
Off), no message appears.
Auto Processing
22 A26361-K1143-Z120-1-7619, edition 3
SCENICVIEW B17-3/B19-3/P19-3
Displaying information
Calling the
With this function the model designation, serial number, resolution, H/V frequency,
input signal and polarity of the synchronisation signal are displayed.
Information setting window
Notes on ergonomic colour adjustment
If you select colours for the display in your application programmes, take note of the information
below.
The primary colours blue and red on a dark background do not produce the minimum required
contrast of 3:1 and are therefore not suitable for continuous text and data entry.
When using several colours for characters and background and giving the primary colours full
modulation, you can obtain very suitable colour combinations (see the following table):
Background
black white purple blue cyan green yellow red
black + + - + + + -
white + + + - - - +
purple + + - - - - -
blue - + - + - + -
cyan + - - + - - -
green + - - + - - -
yellow + - + + - - +
red - + - - - - +
+ Colour combination very suitable
- Colour combination not suitable because colour locations are too close together, thin characters
are not identifiable or rigorous focusing is demanded of the human eye.
Characters
A26361-K1143-Z120-1-7619, edition 3 23
SCENICVIEW B17-3/B19-3/P19-3
Troubleshooting
Should an error occur, first check the following points. If the distortion is still not eliminated, the
monitor should, if possible, be checked on another computer.
If you are unable to solve the problem, please inform our help desk.
Having this problem? Check the following points:
No screen display
(power indicator does not light)
No screen display
(power indicator lights)
Message:
No Signal
Message:
Frequency out of range:
## kHz / ## Hz
Please change the display mode to
1280 x 1024 with 60 Hz
Picture position not correct The monitor recognises an undefined mode (see the
Picture is shaking ► Check whether the data cable for the monitor is
► Check whether the main switch on the underside
of the monitor is switched on (P19-3).
► Check whether the power cable on the monitor is
connected correctly.
► Check whether the computer is switched on.
► Check whether the computer is switched on.
► Check whether the data cable for the monitor is
correctly attached to the monitor port on the
computer.
► Press any key on the computer keyboard - the
computer may be in energy saving mode.
► Alter the brightness and/or contrast until you get a
picture.
► Check whether the data cable for the monitor is
correctly attached to the monitor port on the
computer.
► Check whether the computer is switched on.
The input signal (horizontal frequency and refresh rate)
at the displayed input does not correspond to the
technical monitor data.
► Adjust the video frequency range using the
computer software (see documentation for your
computer or your graphics card).
► Adjust a different screen resolution using the
computer software (see documentation for your
computer or your screen controller).
Technical data" chapter).
"
► Press the EXIT/AUTO button to perform the auto-
adjustment of the screen.
correctly attached to the monitor port on the
computer.
► Press the EXIT/AUTO button to perform the auto-
adjustment of the screen.
24 A26361-K1143-Z120-1-7619, edition 3
SCENICVIEW B17-3/B19-3/P19-3
Having this problem? Check the following points:
Picture is wrongly adjusted ► Press the SELECT/MENU button to activate the
function
message is displayed.
Picture disturbances (vertical lines)
► Press the EXIT/AUTO button to perform the auto-
adjustment of the screen.
Picture disturbances (horizontal lines,
picture noise)
► Press the EXIT/AUTO button to perform the auto-
adjustment of the screen.
The screen becomes darker
The background lighting has a limited lifetime. If your
monitor display should become too dark, the
background lighting will have to be exchanged.
► Please contact our help desk.
Factory Recall. The Auto Processing
A26361-K1143-Z120-1-7619, edition 3 25
SCENICVIEW B17-3/B19-3/P19-3
Notes regarding the DIN EN ISO 13406-2 standard
Permanently unlit or lit pixels
The standard of production techniques today cannot guarantee an absolutely fault-free screen
display. A few isolated constant lit or unlit pixels (picture elements) may be present. The maximum
permitted number of pixels faults is stipulated in the stringent international standard ISO 13406-2
(Class II).
Examples:
A 17" or 19" flat-screen monitor with a resolution of 1280 x 1024 has 1280 x 1024 = 1310720 pixels.
Each pixel consists of three subpixels (red, green and blue), so there are almost 4 million subpixels
in total. In accordance with ISO 13406-2 (Class II), a maximum of 6 pixels and 7 subpixels may be
faulty.
Pixel A pixel consists of 3 subpixels, normally red, green and blue. A pixel
Subpixel A subpixel is a separately addressable internal structure within a pixel
Cluster A cluster contains two or more defective pixels or subpixels in a 5 x 5
is the smallest element that can be generated by complete
functionality of the display.
that enhances the pixel function.
pixel block.
26 A26361-K1143-Z120-1-7619, edition 3
SCENICVIEW B17-3/B19-3/P19-3
Technical data
B17-3 B19-3 / P19-3
Dimensions and weight
Visible diagonals: 43 cm 48 cm
Dot pitch: 0.264 mm 0.294 mm
Screen size: Width:
Maximal resolution: 1280 x 1024 1280 x 1024
Dimensions incl.
monitor base:
Box dimensions:
Weight (without packaging): approx. 6.8 kg approx. 7.5 kg
Storable display modes: 25 25
Pixel error classes according to
ISO 13406-2:
Accessories: Power cable (1.8 m)
Height:
Width:
Height:
Depth:
Width:
Height:
Depth:
337.9 mm
270.3 mm
375 mm
469 mm
249 mm
438 mm
418 mm
176 mm
Class II Class II
D-SUB data cable (1.8 m)
DVI-D data cable (1.8 m)
Audio cable (1.8 m)
376.3 mm
301 mm
412 mm
497 mm
249 mm
484 mm
452 mm
176 mm
Electrical data
Video: Analogue, positive, 0.7 Vpp, 75 Ω
Synchronisation: Separate Sync. TTL, positive or negative
Horizontal frequency: 30 kHz .... 82 kHz (multi-scanning)
Refresh rate: 56 Hz .... 76 Hz
Maximum pixel rate: 135 MHz
Power supply: switches automatically
Total power consumption: < 37 W in normal mode
Sound output: 2.0 W left; 2.0 W right
A26361-K1143-Z120-1-7619, edition 3 27
Digital: DVI-D
100 V - 240 V, 50 Hz - 60 Hz
< 1 W in energy-saving mode
(standby mode, suspend mode and OFF mode)
SCENICVIEW B17-3/B19-3/P19-3
Environmental conditions
Environment class 3K2, IEC 721
Rated range of operation:
Humidity:
Limit range of operation:
Humidity:
Condensation must be avoided.
15 °C .... 35 °C
20 % .... 85 %
5 °C .... 35 °C
20 % .... 85 %
VESA-DDC-compatible VGA interface
Your monitor is equipped with a VESA-DDC-compatible VGA interface. VESA-DDC (Video
Electronics Standard Association, Display Data Channel) is used as the communications interface
between the monitor and the computer. If your computer is equipped with a VESA-DDC-compatible
VGA interface, it can automatically read the data for ensuring optimum operation from your monitor
and select the appropriate settings.
If the monitor SCENICVIEW B17-3/B19-3/P19-3 is not yet displayed in the list of
monitors, you can select the following monitor instead:
i
Fujitsu Siemens P17-2, P19-2, B17-2, B19-2
Preset operating modes
The picture position and size have been set to optimum values at the factory for the
operating modes listed above. Depending on the screen controller used, it may be
i
necessary to adjust the display position and size. In this case, you can change and save
the settings (see "
The following are the most frequently used of the preset operating modes:
Horizontal frequency Refresh rate Screen resolution
31.5 kHz
31.5 kHz
37.5 kHz
37.9 kHz
46.9 kHz
48.4 kHz
60.0 kHz
64.0 kHz
80.0 kHz
For ergonomic reasons, a screen resolution of 1280 x 1024 pixels is recommended. Because of the
technology used (active matrix) an LCD monitor provides a totally flicker-free picture even with a
refresh rate of 60 Hz.
Operation of the monitor").
70 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
75 Hz
720 x 400
640 x 480
640 x 480
800 x 600
800 x 600
1024 x 768
1024 x 768
1280 x 1024
1280 x 1024
28 A26361-K1143-Z120-1-7619, edition 3
SCENICVIEW B17-3/B19-3/P19-3
Pin assignment D-SUB
1
5
6
10
11
15
Pin Meaning Pin Meaning
1 Video input red 9 +5 V (DDC)
2 Video input green 10 Sync. earth
3 Video input blue 11 Earth
4 Earth 12 DDC-Data
5 Earth 13 H. sync
6 Red video earth 14 V. sync
7 Green video earth 15 DDC Clock
8 Blue video earth
Monitor port DVI-D
1
9
17
Pin Meaning Pin Meaning Pin Meaning
1 TMDS Data2- 9 TMDS Data1- 17 TMDS Data0-
2 TMDS Data2+ 10 TMDS Data1+ 18 TMDS Data0+
3 TMDS Data 2/4 Shield 11 TMDS Data 1/3 Shield 19 TMDS Data 0/5 Shield
4 not connected 12 not connected 20 not connected
5 not connected 13 not connected 21 not connected
6 DDC Clock 14 +5V Power 22 TMDS Clock Shield
7 DDC Data 15 Earth 23 TMDS Clock+
8 Analogue Vertical Sync 16 Hot Plug Detect 24 TMDS Clock-
A26361-K1143-Z120-1-7619, edition 3 29
Loading...
