FUJITSU SIEMENS Pro V8010 Schematics

5

4

3

2

1

MAX1845 ( +1.5V & VCCP1.05V )

P31

EF6 SYSTEM BLOCK DIAGRAM

SC486IMLTRT ( +1.8SUS & 0.9V )

D D

P32

SC4215 ( +2.5V )

P32

MAX1999 ( 3VPCU & 5VPCU )

P33

BATTERY CHARGER

P34

DDR II

MAX1907 ( CPU_CORE )

P35

C C

DISCHARGE

P36

SODIMM0

SMDDR_VTERM

DDR II
SODIMM1

P10,11

1.8VSUS

Dual Channel
DDR2

Intel Dothan Processor

VCC_CORE
GMCH_VTT
VCCA

478 uFCPGA

FSB
533/400MHz

Alviso-GM

GMCH

GMCH_VTT

1.8VSUS
+1.5V
+2.5V
+3V

82915GM

1257 PCBGA

X'TAL

32.768K

DMI interface

P5,6,7,8,9

P3,4

CPU Thermal
Sensor

+5V

VIN
+5V

LCD/INV

+3V

CONN

+5V
+2.5V

CRT

S-VIDEO

P13

P12

P12

P3

X'TAL

14.318M

CK-GEN

CK410M

+3V

ICS954206

P2

SATA

PATA

USB 2.0

SATA

( reserved )

B B

HDD/CD-ROM

+5V

P18

P18

USB Port 0 ~ 3

5VSUS

P17

AC'97

+3V
3VSUS
+2.5V
+1.5V

1.5VSUS
VCCRTC
GMCH_VTT

EC/KBC

AMCODEC

CONEXANT

20468-31

P19

MIC IN
JACK

A A

P21

Audio
Amplifier
GMT1428

+5V

P21

Stereo Speaker

P21

MODEM DAA

CONEXANT

20463-31

RJ11

P27

P20

ISA BIOS

TOUCHPAD

Keyboard

X'TAL

32.768K

3VPCU

P22

+5V

P23

P23

Headphone Jack

P21

5

4

PC97551

3VPCU
+3V
VCCRTC

COM&PRT
PORT

ICH6-M

P22

609 BGA

LPC

CRT
PORT

USB PORT
5,6

P14,15,16

SIOPC87383

FIR

PORT
REPLICATOR

RJ45
JACK

3

PCI Bus interface

USB,PCI Express

P24

3VSUS
5VSUS

P30

P30

PS/2
CONN.

TYPE III
MINI-PCI
Socket

INTB/C
REQ1
GNT1
AD20

( reserved )

BLUETOOTH

H/P
JACK

P25

NEW
CARD

POWER
JACK

X'TAL

24.576M

P37

P37

2

TI PCI7411
288 PBGA

( PCMCIA+1394
+Cardreader )

+3V
3VSUS+3V
5VSUS
+1.5V

INTA/B/C
REQ0 AD16
GNT0
AD25

3 in 1 Cardreader
Socket

CARDBUS
Slot

type I X II

1394
Conn.

P29

Size Document Number Rev

Date: Sheet

P28

RELTEK

RTL8100CL(10/100M)
RTL8110SB(1G)

X'TAL
25M

LANVCC3
LANVCC18
LANVCC10

P29

P28

PROJECT : EF6

Quanta Computer Inc.

Block Diagram

INTD
REQ2
GNT2

P26

RJ45

P27

137Monday, January 03, 2005

1

of

1ACustom

5

+3V

D D

+3V

C C

L57

ACB2012L-120

120 ohms@100Mhz

L63

ACB2012L-120

120 ohms@100Mhz

CLKVDD

C358

0.047U

R277 2.2

R322 2.2

R326 1

CLK_VDDA

CLKVDD1

CLK_VDD48

CLK_VDDREF

C373

0.047U

C405

0.047U

C368

0.047U

C372

0.047U

C436

0.047U

C409

0.047U

C383

0.047U

C378

4.7U/10V

C452

4.7U/10V

C387

4.7U/10V

C404

0.047U

C375

0.047U

C369

0.01U

FSC FSB FSA CPU SRC PCI
1 0 1 100 100 33
0 0 1 133 100 33
0 1 1 166 100 33
0 1 0 200 100 33
0 0 0 266 100 33
1 0 0 333 100 33
1 1 0 400 100 33
1 1 1 RESERVED

B B

* Frequence select by CPU auto s e n s e .

+3V

VCCP

VCCP

4

Place these termination to close
ICS954226

C111

20P

C109

20P

CLK_EN#35

STP_PCI#15

STP_CPU#15,35

CLK48_USB15 SRC_MCH 6
CLK48_741128

CG_BSEL2

Iref=5mA,
Ioh=4*Iref

DOT965

DOT96#5

R58 22
R61 22

R319 4.7K

R74 475/F

DOT96 R_PCLK_MINI
DOT96#

C TEST modified EMI

+3V

C520
.1U/50V/X7R

C521
.1U/50V/X7R

21

RP31

1
3

Y2

14.318MHZ

33X2

CG_XIN

CG_XOUT

CLK_EN#
STP_PCI#
STP_CPU#

CGCLK_SMB
CGDAT_SMB

CG_BSEL0
CG_BSEL1

U18_FSC
CLK_VDDREF
CLKVDD

CLKVDD1

CLKVDD

CLK_VDD48

IREF

R_DOT96

2

R_DOT96#

4

C522
.1U/50V/X7R

PDAT_SMB15,37

PCLK_SMB15,37

50
49

10
55
54

46
47

12
16
53

48
42

1
7

21
28
34

11
39

14
15

ICS954226

C523
.1U/50V/X7R

3

CLK_VDDA

U12

XTAL_IN
XTAL_OUT

VTT_PWRGD#/PD
PCI_STOP#
CPU_STOP#

SCLK
SDATA

FSA/USB_48
FSB/TEST_MODE
FSC/TEST_SEL

VDD_REF
VDD_CPU

VDD_PCI_1
VDD_PCI_2

VDD_SRC0
VDD_SRC1
VDD_SRC2

VDD_48
IREF

DOT96
DOT96#

ICS954226

Q25

CH2507S

3

Q26

CH2507S

3

37

VDDA

CK-410M

GND_REF

GND_PCI_2

GND_PCI_1

GND_48

51

62945

2

13

+3V

2

+3V

2

38

VSSA

CPU0#

CPU1#

CPU2_ITP/SRC7

CPU2#_ITP/SRC7#

SRC6#

SRC5#

SRC4#

SRC3#

SRC2#

SRC1#

SRC0#

PCIF0/ITP_EN

GND_SRC

GND_CPU

250mA ( MAX. )
SMbus address D2

R330
10K

1

1

REF

CPU0

CPU1

SRC6

SRC5

SRC4

SRC3

SRC2

SRC1

SRC0

PCI5
PCI4
PCI3
PCI2

PCIF1

VCCP9,16,31,36

+3V10,12,13,15,16,18,21,22,23,25,26,30,33,36,37

52
44

43
41

40
36

35
33

32
31

30
26

27
24

25
22

23
19

20
17

18

R_PCLK_591

5

R_PCLK_7411

4

R_PCLK_SIO

3
56

R_PCLK_LAN

9

R_PCLK_ICH

8

R296
10K

CGDAT_SMB

CGCLK_SMB

14M_REF
RHCLK_MCH

RHCLK_MCH#
RHCLK_CPU

RHCLK_CPU#

NEWCARDCLKREQ#

RSRC_MCH
RSRC_MCH#

RSRC_SATA
RSRC_SATA#

RSRC_ICH
RSRC_ICH#

RSRC_NEW
RSRC_NEW#

RDREFSSCLK
RDREFSSCLK#

RP30

RP32

RP35

RP37

RP36

RP34

RP33

+3V

CGDAT_SMB 10

CGCLK_SMB 10

2

R54 12.1/F
R57 12.1/F

1
3

1
3

1
3

3
1

3
1

3
1

3
1

R46 33
R42 33
R38 33
R48 33
R56 33
R50 33

R43
10K

2
4

33X2

2
4

33X2

2
4

33X2

4
2

33X2

4
2

33X2

4
2

*33X2

4
2

33X2

14M_SIO 30
14M_ICH 15

HCLK_MCH 5
HCLK_MCH# 5

HCLK_CPU 3
HCLK_CPU# 3

NEWCARDCLKREQ# 37

SRC_MCH# 6
SRC_SATA 14

SRC_SATA# 14
SRC_ICH 15

SRC_ICH# 15
CLK_PCIE_NEWC 37

CLK_PCIE_NEWC# 37

DREFSSCLK 5
DREFSSCLK# 5

PCLK_591 22
PCLK_7411 28
PCLK_SIO 30
PCLK_MINI 25
PCLK_LAN 26
PCLK_ICH 14

R_PCLK_ICH
R_PCLK_LAN

HCLK_MCH
HCLK_MCH#

HCLK_CPU
HCLK_CPU#

SRC_MCH
SRC_MCH#

SRC_ICH
SRC_ICH#

CLK_PCIE_NEWC
CLK_PCIE_NEWC#

DREFSSCLK
DREFSSCLK#

DOT96
DOT96#

SRC_SATA
SRC_SATA#
R_PCLK_LAN

( 48 MHz )

CLK48_USB
CLK48_7411

( 33 MHz )

PCLK_SIO
PCLK_LAN
PCLK_MINI
PCLK_ICH
PCLK_7411
PCLK_591

( 14 MHz )

14M_SIO
14M_ICH

1

R327 10K
R311 10K

R60 49.9/F
R65 49.9/F

R69 49.9/F
R72 49.9/F

R82 49.9/F
R91 49.9/F

R92 49.9/F
R94 49.9/F

R79 *49.9/F
R83 *49.9/F

R73 49.9/F
R75 49.9/F

R66 49.9/F
R70 49.9/F

R96 49.9/F
R99 49.9/F
R316 *10K

C140 *10P
C144 *10P

C112 *10P
C137 *10P
C126 *10P
C127 *10P
C122 *10P
C125 *10P

C136 *10P
C139 *10P

02

+3V

R288

R302
10K

SELPSB1_CLK3

A A

SELPSB0_CLK3

R281 0

R301 0

5

R294
*10K

*1K

R289
*0

R310
*1K

CG_BSEL0

CG_BSEL1

CG_BSEL2

R318
*0

R282 1K

R293 1K

MCH_BSEL1 5

MCH_BSEL2 5

4

Size Document Number Rev
Custom

3

2

Date: Sheet

PROJECT : EF6

Quanta Computer Inc.

CLOCK GENERATOR

1

of

237Monday, January 03, 2005

1A

A

B

C

D

E

R297
200

C162

0.1U

03

CPUPWRGD 14

THERMDA

C161
2200P

THERMDC

HD#[0..63]

HD#0
HD#1
HD#2
HD#3
HD#4
HD#5
HD#6
HD#7
HD#8
HD#9
HD#10
HD#11
HD#12
HD#13
HD#14

T84

T23
T80
T9
T104
T20

HD#15

HD#16
HD#17
HD#18
HD#19
HD#20
HD#21
HD#22
HD#23
HD#24
HD#25
HD#26
HD#27
HD#28
HD#29
HD#30
HD#31

PM_PSI#

SELPSB0_CLK
SELPSB1_CLK

H_GTLREF

THCLK_SMB
THDAT_SMB
6648_ALERT#
SYS_SHDN#

HDSTBN0#
HDSTBP0#

HD#[0..63]

HDSTBN1#
HDSTBP1#

Layout note: 0.5" max length.

R23
2K/F

THCLK_SMB22
THDAT_SMB22
6648_ALERT#22

SYS_SHDN#33

A19
A25
A22
B21
A24
B26
A21
B20
C20
B24
D24
E24
C26
B23
E23
C25
C23
C22
D25

H23

G25

L23

M26

H24
F25

G24
M23

L26
N24

M25

H26
N25
K25
K24
L24

C16
C14

AF7

AC1

E26

AD26

J23
J25

J26

E1

B2
C3

U10B

D0#
D1#
D2#
D3#
D4#
D5#
D6#
D7#
D8#
D9#
D10#
D11#
D12#
D13#
D14#
D15#
DSTBN0#
DSTBP0#
DINV0#

D16#
D17#
D18#
D19#
D20#
D21#
D22#
D23#
D24#
D25#
D26#
D27#
D28#
D29#
D30#
D31#
DSTBN1#
DSTBP1#
DINV1#

PSI#
BSEL0

BSEL1

RSVD
RSVD
RSVD
RSVD
RSVD

GTLREF

Dothan_478P

2

DATA GRP

0

3

DATA GRP

1

MISC

RSVD/DPRSTP#

+3V

R98
10K

D32#
D33#
D34#
D35#

DATA GRP

D36#
D37#
D38#
D39#
D40#
D41#
D42#
D43#
D44#
D45#
D46#

D47#
DSTBN2#
DSTBP2#

DINV2#

D48#

D49#

D50#

D51#

DATA GRP

D52#

D53#

D54#

D55#

D56#

D57#

D58#

D59#

D60#

D61#

D62#

D63#
DSTBN3#
DSTBP3#

DINV3#
COMP0

COMP1
COMP2
COMP3

DPSLP#

DPWR#

PWRGOOD

SLP#

TEST1
TEST2

R95
10K

R93
10K

Y26
AA24
T25
U23
V23
R24
R26
R23
AA23
U26
V24
U25
V26
Y23
AA26
Y25
W25
W24
T24

AB25
AC23
AB24
AC20
AC22
AC25
AD23
AE22
AF23
AD24
AF20
AE21
AD21
AF25
AF22
AF26
AE24
AE25
AD20

P25
P26
AB2
AB1

G1
B7
C19
E4
A6

C5
F23

HD#32
HD#33
HD#34
HD#35
HD#36
HD#37
HD#38
HD#39
HD#40
HD#41
HD#42
HD#43
HD#44
HD#45
HD#46
HD#47

HD#48
HD#49
HD#50
HD#51
HD#52
HD#53
HD#54
HD#55
HD#56
HD#57
HD#58
HD#59
HD#60
HD#61
HD#62
HD#63

COMP0
COMP1
COMP2
COMP3

DPWR#
CPUPWRGD

H_TEST1
H_TEST2

R63
*1K

R100 200

R85
*10K

VCCP

HD#[0..63]5

HDSTBN0#5
HDSTBP0#5

HDSTBN1#5
HDSTBP1#5

DINV#15

SELPSB0_CLK2

SELPSB1_CLK2

R24 1K/F

DINV#05

AA3
AA2

AF4
AC4
AC7
AC3
AD3
AE4
AD2
AB4
AC6
AD5
AE2
AD6

AF3
AE1

AF1
AE5

P4
U4
V3
R3
V2

W1

T4

W2

Y4
Y1
U1

Y3
U3
R2

P3
T2
P1
T1

C2
D3
A3

C6
D1
D4
B4

U10A

A3#
A4#

ADDR GROUP

0

A5#
A6#
A7#
A8#
A9#
A10#
A11#
A12#
A13#
A14#
A15#
A16#
ADSTB#0

REQ0#
REQ1#
REQ2#
REQ3#
REQ4#

A17#
A18#

ADDR GROUP

1

A19#
A20#
A21#
A22#
A23#
A24#
A25#
A26#
A27#
A28#
A29#
A30#
A31#
ADSTB#1

A20M#
FERR#
IGNNE#

STPCLK#
LINT0
LINT1
SMI#

Dothan_478P

TDI
TMS
TDO
CPURST#

TCK
TRST#

PREQ#
THRMTRIP#_1

ADS#
BNR#

BPRI#

DEFER#

DRDY#
DBSY#

BR0#

IERR#

INIT#

LOCK#

CONTROLXTP/ITP

RESET#

RS0#
RS1#
RS2#

TRDY#

HIT#

HITM#

BPM#0
BPM#1
BPM#2
BPM#3
PRDY#
PREQ#

TCK

TDI
TDO
TMS

TRST#

SIGNALS

DBR#

PROCHOT#

THERMDA
THERMDC

THERMTRIP#

THERMH CLK

ITP_CLK1
ITP_CLK0

BCLK1
BCLK0

R106 150
R104 39.2
R107 *54.9
R105 54.9

R109 27.4
R108 680

R103 56
R115 *56

N2
L1
J3

L4
H2
M2

N4
A4

B5
J2
B11

H1
K1
L2
M3

K3
K4

C8
B8
A9
C9
A10
B10
A13
C12
A12
C11
B13
A7

B17
B18
A18

C17
A15

A16
B14
B15

ADS#
BNR#
BPRI#

DEFER#
DRDY#
DBSY#

HBREQ0#
IERR#

CPUINIT#
HLOCK#
CPURST#

RS#0
RS#1
RS#2
HTRDY#

HIT#
HITM#

BPM#0HA#19
BPM#1HA#20
BPM#2HA#21
BPM#3HA#22
PRDY#
PREQ#HA#24
TCK
TDI
TDO
TMS
TRST#
DBR#

CPU_PROCHOT#
THERMDA
THERMDC

THRMTRIP#_1

HCLK_CPU#
HCLK_CPU

VCCP

VCCP

ADS# 5
BNR# 5
BPRI# 5

DEFER# 5
DRDY# 5
DBSY# 5

HBREQ0# 5

CPUINIT# 14
HLOCK# 5
CPURST# 5

RS#0 5
RS#1 5
RS#2 5
HTRDY# 5

HIT# 5
HITM# 5

T26
T27
T28
T70
T29

DBR# 15

R110

0

T24
T25

HCLK_CPU# 2
HCLK_CPU 2

VCCP

R101
56

VCCP

R114
56

THRMTRIP# 5,14

HA#[3..31]5

4 4

HADSTB0#5

HREQ#05
HREQ#15
HREQ#25
HREQ#35
HREQ#45

3 3

HADSTB1#5

2 2

HA#[3..31]

HA#[3..31]

A20M#14

FERR#14

IGNNE#14

STPCLK#14

INTR14

NMI14

SMI#14

HA#3
HA#4
HA#5
HA#6
HA#7
HA#8
HA#9
HA#10
HA#11
HA#12
HA#13
HA#14
HA#15
HA#16

HADSTB0#
HREQ#0

HREQ#1
HREQ#2
HREQ#3
HREQ#4

HA#17
HA#18

HA#23
HA#25

HA#26
HA#27
HA#28
HA#29
HA#30
HA#31

HADSTB1#

A20M#
FERR#
IGNNE#

STPCLK#
INTR
NMI

HDSTBN2#
HDSTBP2#

HDSTBN3#
HDSTBP3#

R55 27.4
R51 54.9
R345 27.4
R346 54.9

R102
*1K

U14

8

SCLK

7

SDA

6

ALERT#

4

OVERT#

HD#[0..63]

HDSTBN2# 5
HDSTBP2# 5

HD#[0..63]

H_DPRSTP# 14
H_DPSLP# 14
DPWR# 5

H_CPUSLP# 5,14

DINV#2 5

HDSTBN3# 5
HDSTBP3# 5
DINV#3 5

VCCP

CPUSLP#

1.connected between Dothan and
ICH6 for Dothen A Stepping.

2.connected between Dothan and
Alviso for Dothen B Stepping.

6648VCC

1

VCC

2

DXP

3

DXN

5

GND

1 1

A

+3V10,12,13,15,16,18,21,22,23,25,26,30,33,36,37

VCCP9,16,31,36

Size Document Number Rev
Custom

B

C

D

Date: Sheet

G781P8/MAX6648MUA

PROJECT : EF6

Quanta Computer Inc.

Dothan CPU (Host Bus)

337Monday, January 03, 2005

E

1A

of

A

CPU_CORE CPU_CORE

U10C

AA11

VCC0

AA13

VCC1

AA15

VCC2

AA17

VCC3

AA19

4 4

3 3

2 2

AA21

AA5
AA7

AA9
AB10
AB12
AB14
AB16
AB18
AB20
AB22

AB6

AB8
AC11
AC13
AC15
AC17
AC19

AC9
AD10
AD12
AD14
AD16
AD18

AD8
AE11
AE13
AE15
AE17
AE19

AE9

AF10
AF12
AF14
AF16
AF18

AF8
D18
D20
D22

E17
E19
E21

F18
F20
F22

G21

D6
D8

E5
E7
E9

F6
F8

VCC4
VCC5
VCC6
VCC7
VCC8
VCC9
VCC10
VCC11
VCC12
VCC13
VCC14
VCC15
VCC16
VCC17
VCC18
VCC19
VCC20
VCC21
VCC22
VCC23
VCC24
VCC25
VCC26
VCC27
VCC28
VCC29
VCC30
VCC31
VCC32
VCC33
VCC34
VCC35
VCC36
VCC37
VCC38
VCC39
VCC40
VCC41
VCC42
VCC43
VCC44
VCC45
VCC46
VCC47
VCC48
VCC49
VCC50
VCC51
VCC52
VCC53
VCC54
VCC55
VCC56
VCC57
VCC58

Dothan_478P

VCCA1/RSVD
VCCA2/RSVD
VCCA3/RSVD

VCCSENSE
VSSSENSE

CPU_CORE

C397

C391

0.1U

C400

0.1U

C392

0.1U

0.1U

1 1

CPU_CORE

VCC59
VCC60
VCC61
VCC62
VCC63
VCC64
VCC65
VCC66
VCC67
VCC68
VCC69
VCC70
VCC71

VCCA0

VCCP0
VCCP1
VCCP2
VCCP3
VCCP4
VCCP5
VCCP6
VCCP7
VCCP8

VCCP9
VCCP10
VCCP11
VCCP12
VCCP13
VCCP14
VCCP15
VCCP16
VCCP17
VCCP18
VCCP19
VCCP20
VCCP21
VCCP22
VCCP23
VCCP24

VCCQ0

VCCQ1

VID0
VID1
VID2
VID3
VID4
VID5

C467

0.1U

G5
H22
H6
J21
J5
K22
U5
V22
V6
W21
W5
Y22
Y6

F26
B1
N1
AC26

D10
D12
D14
D16
E11
E13
E15
F10
F12
F14
F16
K6
L21
L5
M22
M6
N21
N5
P22
P6
R21
R5
T22
T6
U21

P23
W4

E2
F2
F3
G3
G4
H4

TP_VCCSENSE

AE7

TP_VSSSENSE

AF6

CPU_CORE

CPU_CORE

TP_VCCA1
TP_VCCA2
TP_VCCA3

CPU_VID0
CPU_VID1
CPU_VID2
CPU_VID3
CPU_VID4
CPU_VID5

R349
*54.9

C505

0.1U

CPU_VCCA

C503

0.1U

T75
T99
T10

CPU_VID0 35
CPU_VID1 35
CPU_VID2 35
CPU_VID3 35
CPU_VID4 35
CPU_VID5 35

R347
*54.9

C398

0.1U

C146

0.01U

VCCP

B

C390

0.1U

C149
10U

C466

0.1U

CPU_VCCA

+

CPU_CORE

C469
10U

C429
10U

C135
10U

C472
10U

C165
150U

+

C499
330U

CPU_CORE

C107
10U

CPU_CORE

C428
10U

CPU_CORE

C101
10U

CPU_CORE

C473
10U

C394

0.1U

C147

0.1U

C468
10U

C423
10U

C426
10U

C474
10U

R84 0

R81 *0

C461

C393

0.1U

0.1U

+

C500
*270U

C132
10U

C119
10U

C471
10U

C118
10U

+

C

C498
*270U

C131
10U

C115
10U

C424
10U

C117
10U

C445

0.1U

+1.5V

+1.8V

C444

0.1U

C105
10U

C114
10U

C130
10U

D

VCCPVCCP

C463

0.1U

C450

0.1U

CPU_CORE35,36

C395

0.1U

VCCP9,16,31,36

+1.5V15,16,31,36,37
+1.8V36

C458

0.1U

C396

0.1U

CPU_CORE

C106
10U

C129
10U

C427
10U

C470
10U

CPU_CORE

C113

C116
10U

10U

C425
10U

C102
10U

CPU_CORE

C104
10U

C133
10U

C103
10U

C134
10U

A11
A14
A17
A20
A23

A26
AA1
AA4
AA6
AA8

AA10
AA12
AA14
AA16
AA18
AA20
AA22
AA25

AB3
AB5
AB7
AB9

AB11
AB13
AB15
AB17
AB19
AB21
AB23
AB26

AC2
AC5
AC8

AC10
AC12
AC14
AC16
AC18
AC21
AC24

AD1
AD4
AD7
AD9

AD11
AD13
AD15
AD17
AD19
AD22
AD25

AE3
AE6
AE8

AE10
AE12
AE14
AE16
AE18
AE20
AE23
AE26

AF2

AF5

AF9

AF11
AF13
AF15
AF17
AF19
AF21
AF24

B12

B16

B19

B22

B25

C10

C13

C15

C18

C21

C24

D11

A2
A5
A8

B3
B6
B9

C1
C4
C7

D2
D5
D7
D9

U10D

VSS0
VSS1
VSS2
VSS3
VSS4
VSS5
VSS6
VSS7
VSS8
VSS9
VSS10
VSS11
VSS12
VSS13
VSS14
VSS15
VSS16
VSS17
VSS18
VSS19
VSS20
VSS21
VSS22
VSS23
VSS24
VSS25
VSS26
VSS27
VSS28
VSS29
VSS30
VSS31
VSS32
VSS33
VSS34
VSS35
VSS36
VSS37
VSS38
VSS39
VSS40
VSS41
VSS42
VSS43
VSS44
VSS45
VSS46
VSS47
VSS48
VSS49
VSS50
VSS51
VSS52
VSS53
VSS54
VSS55
VSS56
VSS57
VSS58
VSS59
VSS60
VSS61
VSS62
VSS63
VSS64
VSS65
VSS66
VSS67
VSS68
VSS69
VSS70
VSS71
VSS72
VSS73
VSS74
VSS75
VSS76
VSS77
VSS78
VSS79
VSS80
VSS81
VSS82
VSS83
VSS84
VSS85
VSS86
VSS87
VSS88
VSS89
VSS90
VSS91
VSS92
VSS93
VSS94
VSS95
VSS96

Dothan_478P

VSS97
VSS98

VSS99
VSS100
VSS101
VSS102
VSS103
VSS104
VSS105
VSS106
VSS107
VSS108
VSS109
VSS110
VSS111
VSS112
VSS113
VSS114
VSS115
VSS116
VSS117
VSS118
VSS119
VSS120
VSS121
VSS122
VSS123
VSS124
VSS125
VSS126
VSS127
VSS128
VSS129
VSS130
VSS131
VSS132
VSS133
VSS134
VSS135
VSS136
VSS137
VSS138
VSS139
VSS140
VSS141
VSS142
VSS143
VSS144
VSS145
VSS146
VSS147
VSS148
VSS149
VSS150
VSS151
VSS152
VSS153
VSS154
VSS155
VSS156
VSS157
VSS158
VSS159
VSS160
VSS161
VSS162
VSS163
VSS164
VSS165
VSS166
VSS167
VSS168
VSS169
VSS170
VSS171
VSS172
VSS173
VSS174
VSS175
VSS176
VSS177
VSS178
VSS179
VSS180
VSS181
VSS182
VSS183
VSS184
VSS185
VSS186
VSS187
VSS188
VSS189
VSS190
VSS191

E

D13
D15
D17
D19
D21
D23
D26
E3
E6
E8
E10
E12
E14
E16
E18
E20
E22
E25
F1
F4
F5
F7
F9
F11
F13
F15
F17
F19
F21
F24
G2
G6
G22
G23
G26
H3
H5
H21
H25
J1
J4
J6
J22
J24
K2
K5
K21
K23
K26
L3
L6
L22
L25
M1
M4
M5
M21
M24
N3
N6
N22
N23
N26
P2
P5
P21
P24
R1
R4
R6
R22
R25
T3
T5
T21
T23
T26
U2
U6
U22
U24
V1
V4
V5
V21
V25
W3
W6
W22
W23
W26
Y2
Y5
Y21
Y24

04

C430

0.1U

C399

C504

C502

0.1U

0.1U

A

0.1U

C496

0.1U

C418

0.1U

C497

0.1U

C495

0.1U

0.1U

B

0.1U

Size Document Number Rev
Custom

C

D

Date: Sheet

PROJECT : EF6

Quanta Computer Inc.

Dothan CPU (Power)

E

of

437Monday, January 03, 2005

1A

C501

C494

5

E4
E1
F4
H7
E2
F1
E3
D3
K7
F2

J7

J8
H6
F3
K8
H5
H1
H2
K5
K6

J4

G3

H3

J1
L5
K4

J5
P7
L7

J3
P5
L3
U7
V6
R6
R5
P3
T8
R7
R8
U8
R4
T4
T5
R1
T3
V8
U6

W6

U3
V5

W8
W7

U2
U1
Y5
Y2
V4
Y7

W1
W3

Y3
Y6

W2

C1
C2
D1
T1
L1
P1

U9A

HD0#
HD1#
HD2#
HD3#
HD4#
HD5#
HD6#
HD7#
HD8#
HD9#
HD10#
HD11#
HD12#
HD13#
HD14#
HD15#
HD16#
HD17#
HD18#
HD19#
HD20#
HD21#
HD22#
HD23#
HD24#
HD25#
HD26#
HD27#
HD28#
HD29#
HD30#
HD31#
HD32#
HD33#
HD34#
HD35#
HD36#
HD37#
HD38#
HD39#
HD40#
HD41#
HD42#
HD43#
HD44#
HD45#
HD46#
HD47#
HD48#
HD49#
HD50#
HD51#
HD52#
HD53#
HD54#
HD55#
HD56#
HD57#
HD58#
HD59#
HD60#
HD61#
HD62#
HD63#

HXRCOMP
HXSCOMP
HXSWING
HYRCOMP
HYSCOMP
HYSWING

HADSTB0#
HADSTB1#

HCPURST#

HOST

HDEFER#

HDSTBN0#
HDSTBN1#
HDSTBN2#
HDSTBN3#
HDSTBP0#
HDSTBP1#
HDSTBP2#
HDSTBP3#

HEDRDY#

HPCREQ#

HCPUSLP#

HA3#
HA4#
HA5#
HA6#
HA7#
HA8#

HA9#
HA10#
HA11#
HA12#
HA13#
HA14#
HA15#
HA16#
HA17#
HA18#
HA19#
HA20#
HA21#
HA22#
HA23#
HA24#
HA25#
HA26#
HA27#
HA28#
HA29#
HA30#
HA31#

HADS#

HVREF
HBNR#

HBPRI#

BREQ0#

HCLKINN
HCLKINP

HDBSY#

HDINV#0
HDINV#1
HDINV#2
HDINV#3

HDPWR#

HDRDY#

HHIT#
HHITM#
HLOCK#

HREQ0#

HREQ1#
HREQ2#
HREQ3#
HREQ4#

HRS0#
HRS1#
HRS2#

HTRDY#

ALVISO

HD#[0..63]3

D D

C C

B B

HD#[0..63]

HXRCOMP
HXSCOMP
HXSWING
HYRCOMP
HYSCOMP
HYSWING

HD#0
HD#1
HD#2
HD#3
HD#4
HD#5
HD#6
HD#7
HD#8
HD#9
HD#10
HD#11
HD#12
HD#13
HD#14
HD#15
HD#16
HD#17
HD#18
HD#19
HD#20
HD#21
HD#22
HD#23
HD#24
HD#25
HD#26
HD#27
HD#28
HD#29
HD#30
HD#31
HD#32
HD#33
HD#34
HD#35
HD#36
HD#37
HD#38
HD#39
HD#40
HD#41
HD#42
HD#43
HD#44
HD#45
HD#46
HD#47
HD#48
HD#49
HD#50
HD#51
HD#52
HD#53
HD#54
HD#55
HD#56
HD#57
HD#58
HD#59
HD#60
HD#61
HD#62
HD#63

G9
C9
E9
B7
A10
F9
D8
B10
E10
G10
D9
E11
F10
G11
G13
C10
C11
D11
C12
B13
A12
F12
G12
E12
C13
B11
D13
A13
F13

F8
B9
E13
J11
A5
D5
E7
H10

AB1
AB2

C6
E6
H8
K3
T7
U5
G6
F7
G4
K1
R3
V3
G5
K2
R2
W4
F6
D4
D6
B3
A11
A7
D7
B8
C7
A8
A4
C5
B4
G8
B5

4

HA#3
HA#4
HA#5
HA#6
HA#7
HA#8
HA#9
HA#10
HA#11
HA#12
HA#13
HA#14
HA#15
HA#16
HA#17
HA#18
HA#19
HA#20
HA#21
HA#22
HA#23
HA#24
HA#25
HA#26
HA#27
HA#28
HA#29
HA#30
HA#31

ADS#
HADSTB0#
HADSTB1#
HVREF
BNR#
BPRI#
HBREQ0#
CPURST#

HCLK_MCH#
HCLK_MCH

DBSY#
DEFER#
DINV#0
DINV#1
DINV#2
DINV#3
DPWR#
DRDY#
HDSTBN0#
HDSTBN1#
HDSTBN2#
HDSTBN3#
HDSTBP0#
HDSTBP1#
HDSTBP2#
HDSTBP3#

HIT#
HITM#
HLOCK#

HREQ#0
HREQ#1
HREQ#2
HREQ#3
HREQ#4
RS#0
RS#1
RS#2
HCPUSLP#
HTRDY#

HA#[3..31]

HA#[3..31] 3

ADS# 3
HADSTB0# 3
HADSTB1# 3

BNR# 3
BPRI# 3
HBREQ0# 3
CPURST# 3

HCLK_MCH# 2
HCLK_MCH 2

DBSY# 3
DEFER# 3
DINV#0 3
DINV#1 3
DINV#2 3
DINV#3 3
DPWR# 3
DRDY# 3
HDSTBN0# 3
HDSTBN1# 3
HDSTBN2# 3
HDSTBN3# 3
HDSTBP0# 3
HDSTBP1# 3
HDSTBP2# 3
HDSTBP3# 3

HIT# 3
HITM# 3
HLOCK# 3

HREQ#0 3
HREQ#1 3
HREQ#2 3
HREQ#3 3
HREQ#4 3
RS#0 3
RS#1 3
RS#2 3

HTRDY# 3

VCCP

R335
100/F

R332
200/F

T79

T22

R44 0

SMDDR_VREF10,32

1.8VSUS8,9,10,36
VCCP9,16,31,36

C442

0.1U

SMDDR_VREF

should be populated
to support Dothan B
stepping.

3

L71 BK2125HS121

1 2
1 2

L72 BK2125HS121

H_CPUSLP# 3,14

T108

T105

T110

T107

T113
T111

C577

0.1U

DMI_TXN0
DMI_TXN1
DMI_TXN2
DMI_TXN3

DMI_TXP0
DMI_TXP1
DMI_TXP2
DMI_TXP3

DMI_RXN0
DMI_RXN1
DMI_RXN2
DMI_RXN3

DMI_RXP0
DMI_RXP1
DMI_RXP2
DMI_RXP3

CLK_SDRAM0
CLK_SDRAM1
CLK_SDRAM2
CLK_SDRAM3
CLK_SDRAM4
CLK_SDRAM5

CLK_SDRAM0#
CLK_SDRAM1#
CLK_SDRAM2#
CLK_SDRAM3#
CLK_SDRAM4#
CLK_SDRAM5#

CKE0
CKE1
CKE2
CKE3

SM_CS0#
SM_CS1#
SM_CS2#
SM_CS3#

M_OCDCOMP0
M_OCDCOMP1

M_ODT0
M_ODT1
M_ODT2
M_ODT3

M_RCOMPN
M_RCOMPP

SMXSLEW
SMYSLEW

It's point to point, 55ohm trace,
keep as short as possible.

DMI_TXN015
DMI_TXN115
DMI_TXN215
DMI_TXN315

DMI_TXP015
DMI_TXP115
DMI_TXP215
DMI_TXP315

DMI_RXN015
DMI_RXN115
DMI_RXN215
DMI_RXN315

DMI_RXP015
DMI_RXP115
DMI_RXP215
DMI_RXP315

CLK_SDRAM010
CLK_SDRAM110

CLK_SDRAM310
CLK_SDRAM410

CLK_SDRAM0#10
CLK_SDRAM1#10

CLK_SDRAM3#10
CLK_SDRAM4#10

CKE010,11
CKE110,11
CKE210,11
CKE310,11

SM_CS0#10,11
SM_CS1#10,11
SM_CS2#10,11
SM_CS3#10,11

M_ODT010,11
M_ODT110,11
M_ODT210,11
M_ODT310,11

C576

0.1U

C TEST modified EMI

AA31
AB35
AC31
AD35

AA35
AB31
AC35

AA33
AB37
AC33
AD37

AA37
AB33
AC37

AM33
AE11

AJ34

AF6

AC10
AN33

AK1

AE10

AJ33

AF5

AD10
AP21

AM21
AH21
AK21

AN16
AM14
AH15
AG16

AF22
AF16

AP14

AL15
AM11
AN10

AK10
AK11

AF37

AD1
AE27
AE28

AF9

AF10

Y31

Y33

AL1

2

U9C

DMIRXN0
DMIRXN1
DMIRXN2
DMIRXN3

DMIRXP0
DMIRXP1
DMIRXP2
DMIRXP3

DMITXN0
DMITXN1
DMITXN2
DMITXN3

DMITXP0
DMITXP1
DMITXP2
DMITXP3

SM_CK0
SM_CK1
SM_CK2
SM_CK3
SM_CK4
SM_CK5

SM_CK0#
SM_CK1#
SM_CK2#
SM_CK3#
SM_CK4#
SM_CK5#

SM_CKE0
SM_CKE1
SM_CKE2
SM_CKE3

SM_CS0#
SM_CS1#
SM_CS2#
SM_CS3#

SM_OCDCOMP0
SM_OCDCOMP1

SM_ODT0
SM_ODT1
SM_ODT2
SM_ODT3

SMRCOMPN
SMRCOMPP
SMVREF0
SMVREF1
SMXSLEWIN
SMXSLEWOUT
SMYSLEWIN
SMYSLEWOUT

1

VCCP

R339
1K

CFG0

G16

CFG0
CFG1
CFG2
CFG3
CFG4
CFG5
CFG6
CFG7
CFG8

CFG9
CFG10
CFG11
CFG12
CFG13
CFG14

DMIDDR MUXING

CFG15
CFG16
CFG17
CFG18
CFG19
CFG20

RSVD21
RSVD22
RSVD23
RSVD24
RSVD25

CFG/RSVDPMLCKNC

RSVD26
RSVD27

BM_BUSY#

EXT_TS0#
EXT_TS1#

THRMTRIP#

PWROK

RSTIN#

DREF_CLKN

DREF_CLKP
DREF_SSCLKN
DREF_SSCLKP

ALVISO

Note :
a). DREF_CLKN , DREF_CLKP
Display Clock Frequency at 96MHz ( CRT,SDVO an d T VOU T )
b). DREF_SSCLKN , DREF_SSCLKP
Display Clock Frequency (with SSC) at 96,100MHz ( LVDS)

NC1
NC2
NC3
NC4
NC5
NC6
NC7
NC8

NC9
NC10
NC11

MCH_BSEL1

H13

MCH_BSEL2

G14

CFG3

F16

CFG4

F15

CFG5

G15

CFG6

E16

CFG7

D17

CFG8

J16

CFG9

D15

CFG10

E15

CFG11

D14

CFG12

E14

CFG13

H12

CFG14

C14

CFG15

H15

CFG16

J15

CFG17

H14

CFG18

G22

CFG19

G23

CFG20

D23
G25
G24

CFG[2:0] ==>External Pull-ups are required.

J17

CFG[17:3] ==>has internal pull u p.

A31

CFG[20:18] ==>has internal pull up.

A30
D26
D25

R331

10K

PM_BMBUSY#

J23

PM_EXTTS#0

J21

PM_EXTTS#1

H22

R47 0

F5
AD30

R350 100

AE29

DOT96#

A24

DOT96

A23
C37
D37

TP_NC1

AP37

TP_NC2

AN37

TP_NC3

AP36

TP_NC4

AP2

TP_NC5

AP1

TP_NC6

AN1

TP_NC7

B1

TP_NC8

A2

TP_NC9

B37

TP_NC10

A36

TP_NC11

A37

MCH_BSEL1 2
MCH_BSEL2 2

+2.5V

R329
10K

DOT96# 2
DOT96 2
DREFSSCLK# 2
DREFSSCLK 2

T5
T7
T4
T2
T6
T8
T18
T21
T14
T19
T17

T102

CFG3 6

T92

CFG5 6
CFG6 6
CFG7 6

T98

CFG9 6

T82

CFG11 6
CFG12 6

CFG13 6

T85
T77

CFG16 6

T94

CFG18 6

CFG19 6

T81

PM_BMBUSY# 15

THRMTRIP# 3,14

IMVP_PWG 15,35

PLTRST# 14,15,30,37

05

1.8VSUSVCCP VCCP VCCP

4

HXSCOMP
HXRCOMP

HYSCOMP
HYRCOMP

R351

R352

40.2/F

40.2/F

Route as short
as possible.

3

M_OCDCOMP0
M_OCDCOMP1

R353

80.6/F

M_RCOMPN
M_RCOMPP

R354

80.6/F

Size Document Number Rev
Custom

2

Date: Sheet

PROJECT : EF6

Quanta Computer Inc.

Alviso Host(1/5)

1

of

537Monday, January 03, 2005

1A

R67 54.9

R59

A A

221/F

HXSWING

R303
100/F

C138

0.1U

R343
221/F

HYSWING

R344
100/F

5

C108

0.1U

R64 24.9/F

VCCP

R340 54.9
R32 24.9/F

5

TV_COMP12

TV_Y/G12
TV_C/R12

D D

CRT_COM#
CRT_BLUE
CRT_GREEN
CRT_RED

C C

B B

R292 0
R304 150/F
R291 150/F
R290 150/F

CFG165

CFG195

resistor no stuff

CFG16

Low=FSB Dynamic ODT Disabled
High=FSB Dynamic ODT Enabled

CFG19

Low=CPU VTT 1.05V
High=CPU VTT 1.2V

+2.5V

R333
*2.2K

R275
*1K

R323
*2.2K

CDDCCLK12

CDDCDATA12

CRT_B_COM12
CRT_G_COM12

CRT_R_COM12

VSYNC_COM12
HSYNC_COM12

BLON13

LDDC_CLK13

LDDC_DATA13

DISP_ON13

CFG95CFG55

4

T95
T97

SRC_MCH#2

SRC_MCH2

TV_COMP
TV_Y/G
TV_C/R

R88 150/F
R86 150/F
R87 150/F

C TEST Modified

CDDCCLK
CDDCDATA
CRT_B_COM CRT_BLUE

+2.5V

CFG9

VSYNC_COM
HSYNC_COM

R306 100K
R315 100K

R314 2.2K
R309 2.2K

R307 1.5K/F

TXLCLKOUT-13
TXLCLKOUT+13
TXUCLKOUT-13
TXUCLKOUT+13

TXLOUT0-13
TXLOUT1-13
TXLOUT2-13

TXLOUT0+13
TXLOUT1+13
TXLOUT2+13

TXUOUT0-13
TXUOUT1-13
TXUOUT2-13

TXUOUT0+13
TXUOUT1+13
TXUOUT2+13

R300
*2.2K

R279 39
R280 39
R336 255/F

H24

SRC_MCH#
SRC_MCH

TV_COMP_A
TV_Y/G_A
TV_C/R_A

R334 4.7K/F

CRT_GREENCRT_G_COM
CRT_REDCRT_R_COM

CRT_COM#
VSYNC
HSYNC

REFSET

T78
T83

T86
T90
T88

TLCO-_1
TLCO+_1
TUCO-_1
TUCO+_1

TLO0-_1
TLO1-_1
TLO2-_1

TLO0+_1
TLO1+_1
TLO2+_1

TUO0-_1
TUO1-_1
TUO2-_1

TUO0+_1
TUO1+_1
TUO2+_1

CFG125
CFG135 CFG65

H25
AB29
AC29

A15

C16

A17

J18
B15
B16
B17

E24
E23
E21
D21
C20
B20
A19
B19
H21
G21

J20

E25
F25
C23
C22
F23
F22
F26
C33
C31
F28
F27

B30
B29
C25
C24

B34
B33
B32

A34
A33
B31

C29
D28
C27

C28
D27
C26

CFG12
CFG13

U9F

SDVOCTRL_DATA
SDVOCTRL_CLK
GCLKN
GCLKP

TVDAC_A
TVDAC_B
TVDAC_C
TV_REFSET
TV_IRTNA
TV_IRTNB
TV_IRTNC

DDCCLK
DDCDATA
BLUE
BLUE#
GREEN
GREEN#
RED
RED#
VSYNC
HSYNC
REFSET

LBKLT_CTRL
LBKLT_EN
LCTLA_CLK
LCTLB_DATA
LDDC_CLK
LDDC_DATA
LVDD_EN
LIBG
LVBG
LVREFH
LVREFL

LACLKN
LACLKP
LBCLKN
LBCLKP

LADATAN0
LADATAN1
LADATAN2

LADATAP0
LADATAP1
LADATAP2

LBDATAN0
LBDATAN1
LBDATAN2

LBDATAP0
LBDATAP1
LBDATAP2

R313

R328

*2.2K

*2.2K

3

EXP_COMP

EXP_RXN0
EXP_RXN1
EXP_RXN2
EXP_RXN3
EXP_RXN4
EXP_RXN5
EXP_RXN6
EXP_RXN7
EXP_RXN8
EXP_RXN9

EXP_RXP0
EXP_RXP1
EXP_RXP2
EXP_RXP3
EXP_RXP4
EXP_RXP5
EXP_RXP6
EXP_RXP7
EXP_RXP8
EXP_RXP9

EXP_TXN0
EXP_TXN1
EXP_TXN2
EXP_TXN3
EXP_TXN4
EXP_TXN5
EXP_TXN6
EXP_TXN7
EXP_TXN8
EXP_TXN9

EXP_TXP0
EXP_TXP1
EXP_TXP2
EXP_TXP3
EXP_TXP4
EXP_TXP5
EXP_TXP6
EXP_TXP7
EXP_TXP8
EXP_TXP9

ALVISO

D36
D34

E30
F34
G30
H34
J30
K34
L30
M34
N30
P34
R30
T34
U30
V34
W30
Y34

D30
E34
F30
G34
H30
J34
K30
L34
M30
N34
P30
R34
T30
U34
V30
W34

E32
F36
G32
H36
J32
K36
L32
M36
N32
P36
R32
T36
U32
V36
W32
Y36

D32
E36
F32
G36
H32
J36
K32
L36
M32
N36
P32
R36
T32
U36
V32
W36

MISC

EXP_COMPI

EXP_ICOMPO

TV VGA LVDS

EXP_RXN10
EXP_RXN11
EXP_RXN12
EXP_RXN13
EXP_RXN14
EXP_RXN15

EXP_RXP10
EXP_RXP11
EXP_RXP12
EXP_RXP13
EXP_RXP14
EXP_RXP15

PCI-EXPRESS GRAPHICS

EXP_TXN10
EXP_TXN11
EXP_TXN12
EXP_TXN13
EXP_TXN14
EXP_TXN15

EXP_TXP10
EXP_TXP11
EXP_TXP12
EXP_TXP13
EXP_TXP14
EXP_TXP15

2

R62 24.9/F

VCC3G_PCIE

+2.5V5,8,12,13,16,32,36

VCC3G_PCIE8

VCCP9,16,31,36

ALVISO POWER STRAP PIN define

CFG[2:0] : 001=FSB533
101=FSB400
other = Reserved

CFG[4:3] : Reserved

CFG5 : 0=DMI X 2
1=DMI X 4 ( Default )

CFG6 : 0=DDR2
1=DDR ( Default )

CFG7 : 0=Reserved
1=Dothan ( Default )

CFG8 : Reserved

CFG9 : 0=Reserve Lanes (15->0, 14->1 etc)
1=Normal Operation ( Default )

CFG[11:10] : Reserved

CFG[13:12] : 00=Reserved
01=XOR Mode Enabled
10=All Z Mode Enabled
11=Normal Operation ( Default )

CFG[15:14] : Reserved

CFG16 : 0=Dynamic ODT Disabled
1=Dynamic ODT Enabled ( Default )

CFG17 : Reserved

CFG18 : 0=1.05V ( Default )

1

06

1=1.5V

CFG6

R308

2.2K

CFG19 : 0 =1.05V ( Default )
1=1.2V ( Reserved )

CFG 20 : Reserved

Low=DMIx2
High=DMIx4

CFG7

CFG75

A A

5

R299
*2.2K

Low=Reserved
High=Dothan

CFG185

PCI-E Graphics Lane
Low = Reverse Lane
High = Normal Operation

+2.5V

R276
*1K

CFG18

Low=CPU core VCC 1.05V
High=CPU core VCC 1.5V

4

CFG115

00 : Reserved
01 : XOR Mode Enabled
10 : All Z Mode Enabled
11 : Normal Operation

CFG11

R298
*2.2K

Low=FSB533

CFG35

3

Low=DDR II
High=DDR

CFG3

Low=DDR533

R321
*2.2K

SDVOCRTL_DATA :0=No SDVO device present (Default)
1=SDVO device present

Size Document Number Rev
Custom

2

Date: Sheet

PROJECT : EF6

Quanta Computer Inc.

VGA DMI(2/5)

637Monday, January 03, 2005

1

1A

of

5

4

3

2

1

07

D D

R_B_MD[0..63]10

R_A_MD[0..63]10

C C

B B

R_A_MD[0..63]

R_A_MD0
R_A_MD1
R_A_MD2
R_A_MD3
R_A_MD4
R_A_MD5
R_A_MD6
R_A_MD7
R_A_MD8
R_A_MD9
R_A_MD10 R_B_DQS6
R_A_MD11
R_A_MD12
R_A_MD13
R_A_MD14
R_A_MD15
R_A_MD16
R_A_MD17
R_A_MD18
R_A_MD19
R_A_MD20
R_A_MD21
R_A_MD22
R_A_MD23
R_A_MD24
R_A_MD25
R_A_MD26
R_A_MD27
R_A_MD28
R_A_MD29
R_A_MD30
R_A_MD31
R_A_MD32
R_A_MD33
R_A_MD34
R_A_MD35
R_A_MD36
R_A_MD37
R_A_MD38
R_A_MD39
R_A_MD40
R_A_MD41
R_A_MD42
R_A_MD43
R_A_MD44
R_A_MD45
R_A_MD46
R_A_MD47
R_A_MD48
R_A_MD49
R_A_MD50
R_A_MD51
R_A_MD52 R_B_MD61
R_A_MD53
R_A_MD54
R_A_MD55
R_A_MD56
R_A_MD57
R_A_MD58
R_A_MD59
R_A_MD60
R_A_MD61
R_A_MD62
R_A_MD63

AG35
AH35

AL35
AL37

AH36

AJ35

AK37

AL34
AM36
AN35
AP32
AM31
AM34
AM35

AL32
AM32
AN31
AP31
AN28
AP28

AL30
AM30
AM28

AL28
AP27
AM27
AM23
AM22

AL23
AM24
AN22
AP22

AM9

AL9
AL6

AP7
AP11
AP10

AL7
AM7
AN5
AN6
AN3
AP3
AP6
AM6

AL4
AM3
AK2
AK3
AG2
AG1

AL3
AM2
AH3
AG3

AF3
AE3
AD6
AC4

AF2

AF1
AD4
AD5

U9B

SADQ0
SADQ1
SADQ2
SADQ3
SADQ4
SADQ5
SADQ6
SADQ7
SADQ8
SADQ9
SADQ10
SADQ11
SADQ12
SADQ13
SADQ14
SADQ15
SADQ16
SADQ17
SADQ18
SADQ19
SADQ20
SADQ21
SADQ22
SADQ23
SADQ24
SADQ25
SADQ26
SADQ27
SADQ28
SADQ29
SADQ30
SADQ31
SADQ32
SADQ33
SADQ34
SADQ35
SADQ36
SADQ37
SADQ38
SADQ39
SADQ40
SADQ41
SADQ42
SADQ43
SADQ44
SADQ45
SADQ46
SADQ47
SADQ48
SADQ49
SADQ50
SADQ51
SADQ52
SADQ53
SADQ54
SADQ55
SADQ56
SADQ57
SADQ58
SADQ59
SADQ60
SADQ61
SADQ62
SADQ63

SA_BS0#
SA_BS1#
SA_BS2#

SA_DM0
SA_DM1
SA_DM2
SA_DM3
SA_DM4
SA_DM5
SA_DM6
SA_DM7

SA_DQS0
SA_DQS1
SA_DQS2
SA_DQS3
SA_DQS4
SA_DQS5
SA_DQS6
SA_DQS7

SA_DQS0#
SA_DQS1#
SA_DQS2#
SA_DQS3#
SA_DQS4#
SA_DQS5#
SA_DQS6#
SA_DQS7#

SA_MA0
SA_MA1
SA_MA2
SA_MA3
SA_MA4
SA_MA5
SA_MA6
SA_MA7
SA_MA8

SA_MA9
SA_MA10
SA_MA11
SA_MA12
SA_MA13

DDR SYSTEM MEMORY A

SA_CAS#
SA_RAS#

SA_RCVENIN#

SA_RCVENOUT#

SA_WE#

ALVISO

AK15
AK16
AL21

AJ37
AP35
AL29
AP24
AP9
AP4
AJ2
AD3

AK36
AP33
AN29
AP23
AM8
AM4
AJ1
AE5

AK35
AP34
AN30
AN23
AN8
AM5
AH1
AE4

AL17
AP17
AP18
AM17
AN18
AM18
AL19
AP20
AM19
AL20
AM16
AN20
AM20
AM15

AN15
AP16
AF29
AF28
AP15

R_A_BS0#
R_A_BS1#
R_A_BS2#

R_A_DM0
R_A_DM1
R_A_DM2
R_A_DM3
R_A_DM4
R_A_DM5
R_A_DM6
R_A_DM7

R_A_DQS0
R_A_DQS1
R_A_DQS2
R_A_DQS3
R_A_DQS4
R_A_DQS5
R_A_DQS6
R_A_DQS7

R_A_DQS#0
R_A_DQS#1
R_A_DQS#2
R_A_DQS#3
R_A_DQS#4
R_A_DQS#5
R_A_DQS#6
R_A_DQS#7

R_A_MA0
R_A_MA1
R_A_MA2
R_A_MA3
R_A_MA4
R_A_MA5
R_A_MA6
R_A_MA7
R_A_MA8
R_A_MA9
R_A_MA10
R_A_MA11
R_A_MA12
R_A_MA13

R_A_SCASA#
R_A_SRASA#

R_A_BMWEA#

R_A_DM[0..7]

R_A_DQS[0..7]

R_A_DQS#[0..7]

R_A_MA[0..13]

T106
T109

R_A_BS0# 10,11
R_A_BS1# 10,11
R_A_BS2# 10,11
R_A_DM[0..7] 10

R_A_DQS[0..7] 10

R_A_DQS#[0..7] 10

R_A_MA[0..13] 10,11

R_A_SCASA# 10,11
R_A_SRASA# 10,11

R_A_BMWEA# 10,11

R_B_MD[0..63]

R_B_MD0
R_B_MD1
R_B_MD2
R_B_MD3
R_B_MD4
R_B_MD5
R_B_MD6
R_B_MD7
R_B_MD8
R_B_MD9
R_B_MD10
R_B_MD11
R_B_MD12
R_B_MD13
R_B_MD14
R_B_MD15
R_B_MD16
R_B_MD17
R_B_MD18
R_B_MD19
R_B_MD20
R_B_MD21
R_B_MD22
R_B_MD23
R_B_MD24
R_B_MD25
R_B_MD26
R_B_MD27
R_B_MD28
R_B_MD29
R_B_MD30
R_B_MD31
R_B_MD32
R_B_MD33
R_B_MD34
R_B_MD35
R_B_MD36
R_B_MD37
R_B_MD38
R_B_MD39
R_B_MD40
R_B_MD41
R_B_MD42
R_B_MD43
R_B_MD44
R_B_MD45
R_B_MD46
R_B_MD47
R_B_MD48
R_B_MD49
R_B_MD50
R_B_MD51
R_B_MD52
R_B_MD53
R_B_MD54
R_B_MD55
R_B_MD56
R_B_MD57
R_B_MD58
R_B_MD59
R_B_MD60

R_B_MD62
R_B_MD63

AE31
AE32
AG32
AG36
AE34
AE33

AF31

AF30
AH33
AH32
AK31
AG30
AG34
AG33
AH31

AJ31
AK30

AJ30
AH29
AH28
AK29
AH30
AH27
AG28

AF24
AG23

AJ22
AK22
AH24
AH23
AG22

AJ21
AG10

AG9
AG8

AH8
AH11
AH10

AK9

AK6

AH5

AK8

AK4

AG5

AG4

AD8

AD9

AH4

AG6

AE8

AD7

AC5

AB8

AB6

AA8

AC8

AC7

AA4

AA5

U9G

SBDQ0
SBDQ1
SBDQ2
SBDQ3
SBDQ4
SBDQ5
SBDQ6
SBDQ7
SBDQ8
SBDQ9
SBDQ10
SBDQ11
SBDQ12
SBDQ13
SBDQ14
SBDQ15
SBDQ16
SBDQ17
SBDQ18
SBDQ19
SBDQ20
SBDQ21
SBDQ22
SBDQ23
SBDQ24
SBDQ25
SBDQ26
SBDQ27
SBDQ28
SBDQ29
SBDQ30
SBDQ31
SBDQ32
SBDQ33
SBDQ34
SBDQ35
SBDQ36
SBDQ37

AJ9

SBDQ38
SBDQ39

AJ7

SBDQ40
SBDQ41

AJ4

SBDQ42
SBDQ43
SBDQ44

AJ8

SBDQ45

AJ5

SBDQ46
SBDQ47
SBDQ48
SBDQ49
SBDQ50
SBDQ51
SBDQ52
SBDQ53
SBDQ54
SBDQ55
SBDQ56
SBDQ57
SBDQ58
SBDQ59
SBDQ60
SBDQ61
SBDQ62
SBDQ63

SB_BS0#
SB_BS1#
SB_BS2#

SB_DM0
SB_DM1
SB_DM2
SB_DM3
SB_DM4
SB_DM5
SB_DM6
SB_DM7

SB_DQS0
SB_DQS1
SB_DQS2
SB_DQS3
SB_DQS4
SB_DQS5
SB_DQS6
SB_DQS7

SB_DQS0#
SB_DQS1#
SB_DQS2#
SB_DQS3#
SB_DQS4#
SB_DQS5#
SB_DQS6#
SB_DQS7#

SB_MA0
SB_MA1
SB_MA2
SB_MA3
SB_MA4
SB_MA5
SB_MA6
SB_MA7
SB_MA8

SB_MA9
SB_MA10
SB_MA11
SB_MA12
SB_MA13

DDR SYSTEM MEMORY B

SB_CAS#
SB_RAS#

SB_RCVENIN#

SB_RCVENOUT#

SB_WE#

ALVISO

AJ15
AG17
AG21

AF32
AK34
AK27
AK24
AJ10
AK5
AE7
AB7

AF34
AK32
AJ28
AK23
AM10
AH6
AF8
AB4

AF35
AK33
AK28
AJ23
AL10
AH7
AF7
AB5

AH17
AK17
AH18
AJ18
AK18
AJ19
AK19
AH19
AJ20
AH20
AJ16
AG18
AG20
AG15

AH14
AK14
AF15
AF14
AH16

R_B_BS0#
R_B_BS1#
R_B_BS2#

R_B_DM0
R_B_DM1
R_B_DM2
R_B_DM3
R_B_DM4
R_B_DM5
R_B_DM6
R_B_DM7

R_B_DQS0
R_B_DQS1
R_B_DQS2
R_B_DQS3
R_B_DQS4
R_B_DQS5

R_B_DQS7
R_B_DQS#0

R_B_DQS#1
R_B_DQS#2
R_B_DQS#3
R_B_DQS#4
R_B_DQS#5
R_B_DQS#6
R_B_DQS#7

R_B_MA0
R_B_MA1
R_B_MA2
R_B_MA3
R_B_MA4
R_B_MA5
R_B_MA6
R_B_MA7
R_B_MA8
R_B_MA9
R_B_MA10
R_B_MA11
R_B_MA12
R_B_MA13

R_B_SCASA#
R_B_SRASA#

R_B_BMWEA#

R_B_DM[0..7]

R_B_DQS[0..7]

R_B_DQS#[0..7]

R_B_MA[0..13]

T114
T112

R_B_BS0# 10,11
R_B_BS1# 10,11
R_B_BS2# 10,11
R_B_DM[0..7] 10

R_B_DQS[0..7] 10

R_B_DQS#[0..7] 10

R_B_MA[0..13] 10,11

R_B_SCASA# 10,11
R_B_SRASA# 10,11

R_B_BMWEA# 10,11

A A

Size Document Number Rev
Custom

5

4

3

2

Date: Sheet

PROJECT : EF6

Quanta Computer Inc.

ALVISO DDR(3/5)

1

of

737Monday, January 03, 2005

1A

5

VCCP

C464

2.2U

D D

C475

4.7U/10V

+2.5V

VCCP

D14

2 1

CH751H-40H

R89 10

4

L10 BLM11A121S

C408

0.1U

VCCA_CRTDAC

C417

0.022U

VVSA_CRTDAC

C481

0.1U

VCCA_MPLL

L66 1uH

+

C485
470U

3

+1.5V

C479

0.1U

L64 1uH

+

C465
470U

+1.5V

2

+1.5V15,16,31,36,37
VCCP9,16,31,36
+3V10,12,13,15,16,18,21,22,23,25,26,30,33,36,37

1

08

C128

0.22U

C C

VCCP_GMCH_CAP4

G1

VTT51

VTT49

VTT50

C95

0.22U

VCCP_GMCH_CAP3

VTT48

VCCP_GMCH_CAP2

VTT47

VTT45

VTT46

C157

0.47U/10V

VTT42

VTT43

VTT44

VTT40

VTT41

VCCP_GMCH_CAP1

VTT38

VTT39

C158

0.47U

VTT37

VTT35

VTT36

VTT34

VTT32

VTT33

VTT30

VTT31

VTT28

VTT29

VCCP

VTT27

VTT25

VTT26

L60 BLM11A121S

+2.5V

N10

M10

K10

J10Y9W9U9R9P9N9M9L9J9N8M8N7M7N6M6A6N5M5N4M4N3M3N2M2B2V1N1M1

VTT19

VTT20

VTT21

VTT22

VTT23

VTT24

P10

VTT18

R10

VTT17

T10

VTT16

U10

VTT15

V10

VTT14

W10

VTT13

K11

VTT12

L11

VTT11

M11

VTT10

N11

P11

VTT9

R11

VTT8

T11

VTT7

C361
10U

U11

VTT6

V11

VTT5

VTT4

W11

VTT3

VCC_SYNC

C432

0.1U

K13

J13

K12

VTT0

VTT1

VTT2

H20

F19

E19

G19

VCC_SYNC

VVSSA_CRTDAC

VCCA_CRTDAC1

VCCA_DPLLB

C389

0.1U

VCCA_DPLLA

+1.5V

J25

K24

K23

K22

K21

W20

U20

T20

K20

V19

U19

K19

W18

V18

T18

K18

K17

AC1

AC2

C35

B23

AA1

AA2

VCC33

VCC34

VCC35

VCC36

VCC37

VCC38

VCC39

VCC40

VCC41

VCC42

VCC43

VCC44

VCC45

VCC46

VCC47

VCC48

VCCA_HPLL

VCCA_MPLL

VCCA_DPLLB

VCCA_DPLLA

VCCH_MPLL0

VCCA_CRTDAC0

VCCH_MPLL1

POWER

VCCSM10

VCCSM11

VCCSM12

VCCSM13

VCCSM14

VCCSM15

VCCSM16

VCCSM17

VCCSM18

VCCSM19

VCCSM20

VCCSM21

VCCSM22

VCCSM23

VCCSM24

VCCSM25

VCCSM26

VCCSM27

VCCSM28

VCCSM29

VCCSM30

VCCSM31

VCCSM32

VCCSM33

VCCSM34

VCCSM35

VCCSM36

VCCSM37

VCCSM38

VCCSM39

VCCSM40

VCCSM41

VCCSM42

VCCSM43

VCCSM44

VCCSM45

VCCSM46

VCCSM47

VCCSM48

VCCSM49

VCCSM50

VCCSM51

VCCSM52

VCCSM53

VCCSM54

VCCSM55

VCCSM56

VCCSM57

VCCSM58

VCCSM59

VCCSM60

VCCSM61

VCCSM62

VCCSM63

VCCSM64

VCCTX_LVDS0

VCCTX_LVDS1

VCCTX_LVDS2

VCCA_SM0

VCCA_SM1

VCCA_SM2

VCCA_SM3

VCC3G0

VCC3G1

VCC3G2

VCC3G3

VCC3G4

VCC3G5

VCC3G6

VCCA_3GPLL0

VCCA_3GPLL1

VCCA_3GPLL2

VCCA_3GBG

VSSA_3GBG

AL26

AK26

AJ26

AH26

AG26

AF26

AE26

AP25

AN25

AM25

AL25

AK25

AJ25

AH25

AG25

AF25

AE25

AE24

AE23

AE22

AE21

AE20

AE19

AE18

AE17

AE16

AE15

AE14

AP13

AN13

AM13

AL13

AK13

AJ13

AH13

AG13

AF13

AE13

AP12

AN12

AM12

AL12

AK12

AJ12

AH12

AG12

AF12

AE12

AD11

AC11

AB11

AB10

AB9

AP8

AM1

AE1

B28

A28

A27

AF20

AP19

AF19

AF18

AE37

W37

U37

R37

N37

L37

J37

Y29

Y28

Y27

F37

G37

C362

4.7U/10V

V1.8_DDR_CAP6
V1.8_DDR_CAP3
V1.8_DDR_CAP4

+2.5V

C83

0.1U

C79

0.1U

C85

0.1U

Note: All VCCSM pins
shorted internally.

+

C75

330uF

C80
10U

1.8VSUS

C77
10U

C81

0.1U

V1.8_DDR_CAP5

VCC3G_PCIE

B B

+2.5V

VCCA_3GPLL

C386

0.1U

VCC_DDRDLL

C382

0.1U

K25

VCC32

VCCSM9

AM26

0.1U

VCC31

VCCSM8

H26

VCC30

VCCSM7

AN26

+

K26

VCC29

VCCSM6

AP26

H27

VCC28

VCCSM5

AC27

V1.8_DDR_CAP2

L62 10uH

C421
470U

C156

0.1U

N27

M27

L27

K27

J27

VCC23

VCC24

VCC25

VCC26

VCC27

VCCSM0

VCCSM1

VCCSM2

VCCSM3

VCCSM4

AM37

AH37

AP29

AD28

AD27

V1.8_DDR_CAP1

C82

0.1U

P27

R27

VCC22

A21

VCC21

VCCHV2

L11 10uH

+

C160
470U

G28

V27

U27

T27

VCC17

VCC18

VCC19

VCC20

VCCA_LVDS

VCCHV0

VCCHV1

A35

B22

B21

H28

J28

VCC16

A25

+1.5V

K28

VCC15

VCCD_LVDS2

B25

L28

VCC14

VCCD_LVDS1

B26

M28

VCC13

VCCD_LVDS0

N28

VCC12

H17

P28

VCC11

VCCDQ_TVDAC

D19

R28

VCC10

VCCD_TVDAC

VCC9

+1.5V

V28

U28

T28

VCC6

VCC7

VCC8

VCCA_TVBG

VSSA_TVBG

H18

G18

VCCA_TVBG

K29

J29

VCC5

VCCA_TVDACC1

F18

E18

C438

0.022U

M29

VCC4

VCCA_TVDACC0

C18

C388

0.022U

VCC3

VCCA_TVDACB1

N29

D18

R29

VCC2

VCCA_TVDACB0

E17

C407

0.022U

VCC1

VCCA_TVDACA1

T29

VCC0

VCCA_TVDACA0

F17

C366

0.1U

U9H
ALVISO

C401

0.1U

L58 BLM11A121SC487

C420

0.1U

C431

0.022U

C478

0.1U

C462

0.1U

D33
CH751H-40H

C416

0.1U

VCCA_TVDAC

C454

C451

0.1U

10U

+1.5V +3V

21

R90
10

R278
0

C446
10U

VCCP

C476
10U

Note: All VCCSM pins
shorted internally.

+1.5V

3

C379

0.1U

+2.5V

C141
10U

+2.5V +1.5V

C380

C381

0.01U

0.1U

BLM11A121S

+

C121

220U

L5

L8

BLM11A121S

VCCA_3GPLL

C480

0.1U

A A

R348 0.5/F
C477
10U

5

L65

BLM11A121S

+1.5V +1.5V

VCC_DDRDLL

VCC3G_PCIE

4

C76

C96

10U

C484

0.1U

VCC3G_PCIE

C100

10U

+

100U

C482

0.1U

VCCD_TVDAC

C402

0.022U

VCCDQ_TVDAC

C437

0.022U

C88
10U

2

L59 BLM11A121S

C367

0.1U

L61 BLM11A121S

C365

0.1U

Size Document Number Rev
Custom

Date: Sheet

+1.5V

+1.5V

PROJECT : EF6

Quanta Computer Inc.

Alviso Power(4/5)

1

1A

of

837Monday, January 03, 2005

5

4

3

2

1

09

D D

AF23

H23

AL22

AH22

J22

E22

D22

A22

AN21

AF21

F21

C21

AK20

V20

G20

F20

E20

D20

A20

AN19

AG19

W19

T19

J19

H19

C19

AL18

U18

B18

A18

AN17

AJ17

AF17

G17

C17

AL16

K16

H16

D16

A16

K15

C15

AN14

AL14

AJ14

AG14

K14

J14

F14

B14

A14

J12

D12

B12

AN11

AL11

AJ11

AG11

AF11

AA11

Y11

H11

F11

AA10

Y10

L10

D10

AN9

AH9

AE9

AC9

AL5W5E5

AN4

B36

C C

AL24J2G2D2Y1

VSS246

VSS247

VSS248

VSS249

VSS250

VSS251

VSS252

VSS253

VSS254

VSS255

VSS256

VSS257

VSS258

VSS259

VSS260

VSS261

VSS262

VSS263

VSS264

VSS265

VSS266

VSS267

VSS268

VSS269

VSS270

VSS271

VSSALVDS

VSS110

VSS111

VSS112

VSS113

VSS114

VSS115

VSS116

VSS117

VSS118

VSS119

VSS120

VSS121

VSS122

VSS123

VSS124

VSS125

VSS126

VSS127

VSS128

VSS129

VSS130

VSS131

VSS132

VSS133

VSS134

VSS135

H29

G29

F29

E29

D29

A29

AC28

AB28

AA28

W28

E28

AN27

AL27

AJ27

AG27

AF27

AB27

AA27

W27

G27

E27

AJ24

AG24

J24

F24

D24

B24

AJ3

AC3

AB3

AA3C3A3

AN2

AL2

AH2

AE2

AD2V2T2P2L2

B27

J26

G26

E26

A26

AN24

AF4Y4U4P4L4H4C4

VSS235

VSS236

VSS237

VSS238

VSS239

VSS240

VSS241

VSS242

VSS243

VSS244

VSS245

VSS99

VSS100

VSS101

VSS102

VSS103

VSS104

VSS105

VSS106

VSS107

VSS108

VSS109

C30

AM29

AJ29

AG29

AD29

AA29

W29

V29

U29

P29

L29

AA6T6P6L6J6B6AP5

VSS214

VSS215

VSS216

VSS217

VSS218

VSS219

VSS220

VSS221

VSS222

VSS223

VSS224

VSS225

VSS226

VSS227

VSS228

VSS229

VSS230

VSS231

VSS232

VSS233

VSS234

VSS78

VSS79

VSS80

VSS81

VSS82

VSS83

VSS84

VSS85

VSS86

VSS87

VSS88

VSS89

VSS90

VSS91

VSS92

VSS93

VSS94

VSS95

VSS96

VSS97

VSS98

V31

U31

T31

R31

P31

N31

M31

L31

K31

J31

H31

G31

F31

E31

D31

AP30

AE30

AC30

AB30

AA30

Y30

AK7

AG7

AA7V7G7

AJ6

AE6

AC6

AA9V9T9K9H9A9AL8Y8P8L8E8C8AN7

VSS136

VSS137

VSS138

VSS139

VSS140

VSS141

VSS142

VSS143

VSS144

VSS145

VSS146

VSS147

VSS148

VSS149

VSS150

VSS151

VSS152

VSS153

VSS154

VSS155

VSS156

VSS157

VSS158

VSS159

VSS160

VSS161

VSS162

VSS163

VSS164

VSS165

VSS166

VSS167

VSS168

VSS169

VSS170

VSS171

VSS172

VSS173

VSS174

VSS175

VSS176

VSS177

VSS178

VSS179

VSS180

VSS181

VSS182

VSS183

VSS184

VSS185

VSS186

VSS187

VSS188

VSS189

VSS190

VSS191

VSS192

VSS193

VSS194

VSS195

VSS196

VSS197

VSS198

VSS199

VSS200

VSS201

VSS202

VSS203

VSS204

VSS205

VSS206

VSS207

VSS208

VSS209

VSS210

VSS211

VSS212

VSS213

U9E

ALVISO

VSS

VSS0

VSS1

VSS2

VSS3

VSS4

VSS5

VSS6

VSS7

VSS8

VSS9

VSS10

VSS11

VSS12

VSS13

VSS14

VSS15

VSS16

VSS17

VSS18

VSS19

VSS20

VSS21

VSS22

VSS23

VSS24

VSS25

VSS26

VSS27

VSS28

VSS29

VSS30

VSS31

VSS32

VSS33

VSS34

VSS35

VSS36

VSS37

VSS38

VSS39

VSS40

VSS41

VSS42

VSS43

VSS44

VSS45

VSS46

VSS47

VSS48

VSS49

VSS50

VSS51

VSS52

VSS53

VSS54

VSS55

VSS56

VSS57

VSS58

VSS59

VSS60

VSS61

VSS62

VSS63

VSS64

VSS65

VSS66

VSS67

VSS68

VSS69

VSS70

VSS71

VSS72

VSS73

VSS74

VSS75

VSS76

VSS77

AG37

Y37

V37

T37

P37

M37

K37

H37

E37

AN36

AL36

AJ36

AF36

AE36

AD36

AC36

AB36

AA36

C36

AE35

Y35

W35

V35

U35

T35

R35

P35

N35

M35

L35

K35

J35

H35

G35

F35

E35

D35

B35

AN34

AH34

AD34

AC34

AB34

AA34

C34

AL33

AF33

AD33

W33

V33

U33

T33

R33

P33

N33

M33

L33

K33

J33

H33

G33

F33

E33

D33

AN32

AJ32

AD32

AC32

AB32

AA32

Y32

C32

A32

AL31

AG31

AD31

W31

VCCP

U9D

W13

V13

U13

T13

R13

P13

N13

M13

L13

W12

V12

U12

T12

R12

P12

N12

M12

VSS_NCTF0

L12

VTT_NCTF17

VTT_NCTF16

VTT_NCTF15

VTT_NCTF14

VTT_NCTF13

VTT_NCTF12

VTT_NCTF11

VTT_NCTF10

VTT_NCTF9

VTT_NCTF8

VTT_NCTF7

VTT_NCTF6

VTT_NCTF5

VTT_NCTF4

VTT_NCTF3

VTT_NCTF2

VTT_NCTF1

VTT_NCTF0

AB26

AA26

Y26

AB25

AA25

Y25

AB24

AA24

Y24

AB23

AA23

Y23

AB22

AA22

Y22

AB21

AA21

Y21

R21

AB20

AA20

AB19

AA19

AB18

AA18

AB17

AA17

Y17

R17

AB16

AA16

Y16

W16

V16

U16

T16

R16

P16

N16

M16

L16

AB15

AA15

Y15

W15

V15

U15

T15

R15

P15

N15

M15

L15

AB14

AA14

Y14

W14

V14

U14

T14

R14

P14

N14

M14

L14

AA13

Y13

AA12

Y12

B B

VSS_NCTF13

VSS_NCTF14

VSS_NCTF15

VSS_NCTF16

VSS_NCTF17

VSS_NCTF18

VSS_NCTF19

VSS_NCTF20

VSS_NCTF21

VSS_NCTF22

VSS_NCTF23

VSS_NCTF24

VSS_NCTF25

VSS_NCTF26

VSS_NCTF27

VSS_NCTF28

VSS_NCTF29

VSS_NCTF30

VSS_NCTF31

VSS_NCTF32

VSS_NCTF33

VSS_NCTF34

VSS_NCTF35

VSS_NCTF36

VSS_NCTF37

VSS_NCTF38

VSS_NCTF39

VSS_NCTF40

VSS_NCTF41

VSS_NCTF42

VSS_NCTF43

VSS_NCTF44

VSS_NCTF45

VSS_NCTF46

VSS_NCTF47

VSS_NCTF48

VSS_NCTF49

VSS_NCTF50

VSS_NCTF51

VSS_NCTF52

VSS_NCTF53

VSS_NCTF54

VSS_NCTF55

VSS_NCTF56

VSS_NCTF57

VSS_NCTF58

VSS_NCTF59

VSS_NCTF60

VSS_NCTF61

VSS_NCTF62

VSS_NCTF63

VSS_NCTF64

VSS_NCTF65

VSS_NCTF66

VSS_NCTF67

VSS_NCTF68

VSS_NCTF7

VSS_NCTF8

VSS_NCTF9

VSS_NCTF10

VSS_NCTF11

VSS_NCTF12

VSS_NCTF6

VSS_NCTF5

VSS_NCTF4

VSS_NCTF3

VSS_NCTF2

VSS_NCTF1

ALVISO

NCTF

VCCSM_NCTF0

VCCSM_NCTF1

VCCSM_NCTF2

VCCSM_NCTF3

VCCSM_NCTF4

VCCSM_NCTF5

VCCSM_NCTF6

VCCSM_NCTF7

VCCSM_NCTF8

VCCSM_NCTF9

VCCSM_NCTF10

VCCSM_NCTF11

VCCSM_NCTF12

VCCSM_NCTF13

VCCSM_NCTF14

VCCSM_NCTF15

VCCSM_NCTF16

VCCSM_NCTF17

VCCSM_NCTF18

VCCSM_NCTF19

VCCSM_NCTF20

VCCSM_NCTF21

VCCSM_NCTF22

VCCSM_NCTF23

VCCSM_NCTF24

VCCSM_NCTF25

VCCSM_NCTF26

VCCSM_NCTF27

VCCSM_NCTF28

VCCSM_NCTF29

VCCSM_NCTF30

VCCSM_NCTF31

VCC_NCTF0

VCC_NCTF1

VCC_NCTF2

VCC_NCTF3

VCC_NCTF4

VCC_NCTF5

VCC_NCTF6

VCC_NCTF7

VCC_NCTF8

VCC_NCTF9

VCC_NCTF10

VCC_NCTF11

VCC_NCTF12

VCC_NCTF13

VCC_NCTF14

VCC_NCTF15

VCC_NCTF16

VCC_NCTF17

VCC_NCTF18

VCC_NCTF19

VCC_NCTF20

VCC_NCTF21

VCC_NCTF22

VCC_NCTF23

VCC_NCTF24

VCC_NCTF25

VCC_NCTF26

VCC_NCTF27

VCC_NCTF28

VCC_NCTF29

VCC_NCTF30

VCC_NCTF31

VCC_NCTF32

VCC_NCTF33

VCC_NCTF34

VCC_NCTF35

VCC_NCTF36

VCC_NCTF37

VCC_NCTF38

VCC_NCTF39

VCC_NCTF40

VCC_NCTF41

VCC_NCTF42

VCC_NCTF43

VCC_NCTF44

VCC_NCTF45

VCC_NCTF46

VCC_NCTF47

VCC_NCTF48

VCC_NCTF49

VCC_NCTF50

VCC_NCTF51

VCC_NCTF52

VCC_NCTF53

VCC_NCTF54

VCC_NCTF55

VCC_NCTF56

VCC_NCTF57

VCC_NCTF58

VCC_NCTF59

VCC_NCTF60

VCC_NCTF61

VCC_NCTF62

VCC_NCTF63

VCC_NCTF64

VCC_NCTF65

VCC_NCTF66

VCC_NCTF67

VCC_NCTF68

VCC_NCTF69

VCC_NCTF70

VCC_NCTF71

VCC_NCTF72

VCC_NCTF73

VCC_NCTF74

VCC_NCTF75

VCC_NCTF76

VCC_NCTF77

VCC_NCTF78

AD26

AC26

AD25

AC25

AD24

AC24

AD23

AC23

AD22

AC22

AD21

AC21

AD20

AC20

AD19

AC19

AD18

AC18

AD17

AC17

AD16

AC16

AD15

AC15

AD14

AC14

AD13

AC13

AB13

AD12

AC12

AB12

W26

V26

U26

T26

R26

P26

N26

M26

L26

W25

V25

U25

T25

R25

P25

N25

M25

L25

W24

V24

U24

T24

R24

P24

N24

M24

L24

W23

V23

U23

T23

R23

P23

N23

M23

L23

W22

V22

U22

T22

R22

P22

N22

M22

L22

W21

V21

U21

T21

P21

N21

M21

L21

Y20

R20

P20

N20

M20

L20

Y19

R19

P19

N19

M19

L19

Y18

R18

P18

N18

M18

L18

W17

V17

U17

T17

P17

N17

M17

L17

A A

5

4

3

2

1.8VSUSVCCP

Size Document Number Rev
Custom

Date: Sheet

PROJECT : EF6

Quanta Computer Inc.

VSS/NCTF(5/5)

1

of

937Monday, January 03, 2005

1A

1

SMDDR_VREF

1.8VSUS

R_A_MD0
R_A_MD1

R_A_DQS#0
R_A_DQS0

A A

B B

CKE05,11 CKE25,11 CKE3 5,11

R_A_BS2#7,11

R_A_BS0#7,11

R_A_BMWEA#7,11

R_A_SCASA#7,11

SM_CS1#5,11
M_ODT15,11

C C

D D

R_A_MD6
R_A_MD3

R_A_MD8
R_A_MD13

R_A_DQS#1
R_A_DQS1

R_A_MD14 R_B_MD10
R_A_MD15

R_A_MD20
R_A_MD17

R_A_DQS#2
R_A_DQS2

R_A_MD18
R_A_MD22

R_A_MD25
R_A_MD24

R_A_DM3

R_A_MD26
R_A_MD30

CKE0

R_A_BS2#
R_A_MA12

R_A_MA9
R_A_MA8

R_A_MA5
R_A_MA3
R_A_MA1

R_A_MA10
R_A_BS0#

R_A_BMWEA#
R_A_SCASA#

SM_CS1#
M_ODT1
R_A_MD32

R_A_MD33
R_A_DQS#4

R_A_DQS4
R_A_MD34

R_A_MD35
R_A_MD40

R_A_MD41
R_A_DM5
R_A_MD43 R_A_MD46

R_A_MD42
R_A_MD48

R_A_MD49

R_A_DQS#6
R_A_DQS6

R_A_MD51

R_A_MD60
R_A_MD57

R_A_DM7
R_A_MD58

R_A_MD59

CGCLK_SMB

+3V

1

101
103
105
107
109
111
113
115
117
119
121
123
125
127
129
131
133
135
137
139
141
143
145
147
149
151
153
155
157
159
161
163
165
167
169
171
173
175
177
179
181
183
185
187
189
191
193
195
197
199

2

CN30

1

VREF

3

VSS47

5

DQ0

7

DQ1

9

VSS37

11

DQS#0

13

DQS0

15

VSS48

17

DQ2

19

DQ3

21

VSS38

23

DQ8

25

DQ9

27

VSS49

29

DQS#1

31

DQS1

33

VSS39

35

DQ10

37

DQ11

39

VSS50

41

VSS18

43

DQ16

45

DQ17

47

VSS1

49

DQS#2

51

DQS2

53

VSS19

55

DQ18

57

DQ19

59

VSS22

61

DQ24

63

DQ25

65

VSS23

67

DM3

69

NC4

71

VSS9

73

DQ26

75

DQ27

77

VSS4

79

CKE0

81
83
85
87
89
91
93
95
97
99

PC4800 DDR2

VDD7
NC1
A16_BA2
VDD9
A12
A9
A8
VDD5
A5
A3
A1
VDD10
A10/AP
BA0
WE#
VDD2
CAS#
S1#
VDD3
ODT1
VSS11
DQ32
DQ33
VSS26
DQS#4
DQS4
VSS2
DQ34
DQ35
VSS27
DQ40
DQ41
VSS29
DM5
VSS51
DQ42
DQ43
VSS40
DQ48
DQ49
VSS52
NCTEST
VSS30
DQS#6
DQS6
VSS31
DQ50
DQ51
VSS33
DQ56
DQ57
VSS3
DM7
VSS34
DQ58
DQ59
VSS14
SDA
SCL
VDD(SPD)

PC4800_DDR2_R_4H

CLOCK 0,1 CLOCK 3,4

2

1.8VSUS 1.8VSUS 1.8VSUS

2

VSS46

4

DQ4

6

DQ5

8

VSS15

10

DM0

12

VSS5

14

DQ6

16

DQ7

18

VSS16

20

DQ12

22

DQ13

24

VSS17

26

DM1

28

VSS53

30

CK0

32

CK0#

34

VSS41

36

DQ14

38

DQ15

40

VSS54

42

VSS20

44

DQ20

46

DQ21

48

VSS6

50

NC3

52

DM2

54

VSS21

56

DQ22

58

DQ23

60

VSS24

62

DQ28

64

DQ29

66

VSS25

68

DQS#3

70

DQS3

72

VSS10

74

DQ30

76

DQ31

78

VSS8

80

CKE1

82

SDRAM SO-DIMM

(200P)

VDD8

84

A15

86

A14

88

VDD11

90

A11

92

A7

94

A6

96

VDD4

98

A4

100

A2

102

A0

104

VDD12

106

BA1

108

RAS#

110

S0#

112

VDD1

114

ODT0

116

A13

118

VDD6

120

NC2

122

VSS12

124

DQ36

126

DQ37

128

VSS28

130

DM4

132

VSS42

134

DQ38

136

DQ39

138

VSS55

140

DQ44

142

DQ45

144

VSS43

146

DQS#5

148

DQS5

150

VSS56

152

DQ46

154

DQ47

156

VSS44

158

DQ52

160

DQ53

162

VSS57

164

CK1

166

CK1#

168

VSS45

170

DM6

172

VSS32

174

DQ54

176

DQ55

178

VSS35

180

DQ60

182

DQ61

184

VSS7

186

DQS#7

188

DQS7

190

VSS36

192

DQ62

194

DQ63

196

VSS13

198

SA0

200

SA1

R_A_MD4
R_A_MD5

R_A_DM0
R_A_MD2

R_A_MD7
R_A_MD12

R_A_MD9
R_A_DM1

CLK_SDRAM0

CLK_SDRAM0#

R_A_MD11
R_A_MD10

R_A_MD16
R_A_MD21

R_A_DM2
R_A_MD23

R_A_MD19
R_A_MD29

R_A_MD28
R_A_DQS#3

R_A_DQS3
R_A_MD27

R_A_MD31
CKE1

R_A_MA11
R_A_MA7
R_A_MA6

R_A_MA4
R_A_MA2
R_A_MA0

R_A_BS1#
R_A_SRASA#

SM_CS0#

M_ODT0
R_A_MA13

R_A_MD36
R_A_MD37

R_A_DM4
R_A_MD38

R_A_MD39
R_A_MD45

R_A_MD44
R_A_DQS#5

R_A_DQS5

R_A_MD47
R_A_MD52

R_A_MD53

CLK_SDRAM1
CLK_SDRAM1#

R_A_DM6
R_A_MD50

R_A_MD54R_A_MD55
R_A_MD61

R_A_MD56
R_A_DQS#7

R_A_DQS7
R_A_MD63

R_A_MD62

R10 10K
R9 10K

SMbus address A0 SMbus address A4

3

CLK_SDRAM0 5
CLK_SDRAM0# 5

SMDDR_VREF

C571

0.1U

C TEST
modified EMI

CKE1 5,11

R_A_BS1# 7,11
R_A_SRASA# 7,11
SM_CS0# 5,11

M_ODT0 5,11

CLK_SDRAM1 5
CLK_SDRAM1# 5

3

R_A_DM[0..7] 7
R_A_DQS[0..7] 7

R_A_DQS#[0..7] 7
R_A_MA[0..13] 7,11

C573

C572

0.1U

0.1U

R_B_BS2#7,11

R_B_BS0#7,11

R_B_BMWEA#7,11

R_B_SCASA#7,11

SM_CS3#5,11
M_ODT35,11

CGDAT_SMB2
CGCLK_SMB2

4

SMDDR_VREF

CN29

1

VREF

3

R_B_MD7
R_B_MD1

R_B_DQS#0
R_B_DQS0

R_B_MD0
R_B_MD2

R_B_MD12
R_B_MD9

R_B_DQS#1
R_B_DQS1

R_B_MD8
R_B_MD14

R_B_MD16
R_B_MD17

R_B_DQS#2
R_B_DQS2

R_B_MD19
R_B_MD22

R_B_MD24
R_B_MD25

R_B_DM3

R_B_MD26
R_B_MD27

CKE2

R_B_BS2#
R_B_MA12

R_B_MA9
R_B_MA8

R_B_MA5
R_B_MA3
R_B_MA1

R_B_MA10
R_B_BS0#

R_B_BMWEA#
R_B_SCASA#

SM_CS3#
M_ODT3
R_B_MD37

R_B_MD33
R_B_DQS#4

R_B_DQS4
R_B_MD35

R_B_MD34
R_B_MD41

R_B_MD40
R_B_DM5
R_B_MD42 R_B_MD47

R_B_MD43
R_B_MD48

R_B_MD49

R_B_DQS#6
R_B_DQS6

R_B_MD50

R_B_MD61
R_B_MD56

R_B_DM7
R_B_MD58

R_B_MD59
CGDAT_SMBCGDAT_SMB

CGCLK_SMB

+3V

VSS47

5

DQ0

7

DQ1

9

VSS37

11

DQS#0

13

DQS0

15

VSS48

17

DQ2

19

DQ3

21

VSS38

23

DQ8

25

DQ9

27

VSS49

29

DQS#1

31

DQS1

33

VSS39

35

DQ10

37

DQ11

39

VSS50

41

VSS18

43

DQ16

45

DQ17

47

VSS1

49

DQS#2

51

DQS2

53

VSS19

55

DQ18

57

DQ19

59

VSS22

61

DQ24

63

DQ25

65

VSS23

67

DM3

69

NC4

71

VSS9

73

DQ26

75

DQ27

77

VSS4

79

CKE0

81

VDD7

83

NC1

85

A16_BA2

87

VDD9

89

A12

91

A9

93

A8

95

VDD5

97

A5

99

A3

101

A1

103

VDD10

105

A10/AP

107

BA0

109

WE#

111

VDD2

113

CAS#

115

S1#

117

VDD3

119

ODT1

121

VSS11

123

DQ32

125

DQ33

127

VSS26

129

DQS#4

131

DQS4

133

VSS2

135

DQ34

137

DQ35

139

VSS27

141

DQ40

143

DQ41

145

VSS29

147

DM5

149

VSS51

151

DQ42

153

DQ43

155

VSS40

157

DQ48

159

DQ49

161

VSS52

163

NCTEST

165

VSS30

167

DQS#6

169

DQS6

171

VSS31

173

DQ50

175

DQ51

177

VSS33

179

DQ56

181

DQ57

183

VSS3

185

DM7

187

VSS34

189

DQ58

191

DQ59

193

VSS14

195

SDA

197

SCL

199

VDD(SPD)

PC4800_DDR2_R_4H

CKE 2,3CKE 0,1

4

5

2

VSS46

4

DQ4

6

DQ5

8

VSS15

10

DM0

12

VSS5

14

DQ6

16

DQ7

18

VSS16

20

DQ12

22

DQ13

24

VSS17

26

DM1

28

VSS53

30

CK0

32

CK0#

34

VSS41

36

DQ14

38

DQ15

40

VSS54

42

VSS20

44

DQ20

46

DQ21

48

VSS6

50

NC3

52

DM2

54

VSS21

56

DQ22

58

DQ23

60

VSS24

62

DQ28

64

DQ29

66

VSS25

68

DQS#3

70

DQS3

72

VSS10

74

DQ30

76

DQ31

78

VSS8

80

CKE1

82

PC4800 DDR2

SDRAM SO-DIMM

(200P)

VDD8

84

A15

86

A14

88

VDD11

90

A11

92

A7

94

A6

96

VDD4

98

A4

100

A2

102

A0

104

VDD12

106

BA1

108

RAS#

110

S0#

112

VDD1

114

ODT0

116

A13

118

VDD6

120

NC2

122

VSS12

124

DQ36

126

DQ37

128

VSS28

130

DM4

132

VSS42

134

DQ38

136

DQ39

138

VSS55

140

DQ44

142

DQ45

144

VSS43

146

DQS#5

148

DQS5

150

VSS56

152

DQ46

154

DQ47

156

VSS44

158

DQ52

160

DQ53

162

VSS57

164

CK1

166

CK1#

168

VSS45

170

DM6

172

VSS32

174

DQ54

176

DQ55

178

VSS35

180

DQ60

182

DQ61

184

VSS7

186

DQS#7

188

DQS7

190

VSS36

192

DQ62

194

DQ63

196

VSS13

198

SA0

200

SA1

5

R_B_MD4
R_B_MD5

R_B_DM0
R_B_MD6

R_B_MD3
R_B_MD11

R_B_MD13
R_B_DM1

CLK_SDRAM3

CLK_SDRAM3#

R_B_MD15

R_B_MD20
R_B_MD21

R_B_DM2
R_B_MD23

R_B_MD18
R_B_MD28

R_B_MD29
R_B_DQS#3

R_B_DQS3
R_B_MD31

R_B_MD30
CKE3

R_B_MA11
R_B_MA7
R_B_MA6

R_B_MA4
R_B_MA2
R_B_MA0

R_B_BS1#
R_B_SRASA#

SM_CS2#

M_ODT2
R_B_MA13

R_B_MD36
R_B_MD32

R_B_DM4
R_B_MD38

R_B_MD39
R_B_MD44

R_B_MD45
R_B_DQS#5

R_B_DQS5

R_B_MD46
R_B_MD52

R_B_MD53

CLK_SDRAM4
CLK_SDRAM4#

R_B_DM6
R_B_MD55

R_B_MD54R_B_MD51
R_B_MD60

R_B_MD57
R_B_DQS#7

R_B_DQS7
R_B_MD63

R_B_MD62

R13 10K
R12 10K

+3V

6

CLK_SDRAM3 5
CLK_SDRAM3# 5

R_B_BS1# 7,11
R_B_SRASA# 7,11
SM_CS2# 5,11

M_ODT2 5,11

CLK_SDRAM4 5
CLK_SDRAM4# 5

6

R_B_DM[0..7] 7R_A_MD[0..63] 7
R_B_MD[0..63] 7
R_B_DQS[0..7] 7
R_B_DQS#[0..7] 7
R_B_MA[0..13] 7,11

7

8

10

1.8VSUS

Place these Caps near So-Dimm1.

C67

C19

C17

C16

2.2U

2.2U

2.2U

2.2U

1.8VSUS

Place these Caps near So-Dimm1.

C51

C55

C46

C54

0.1U

0.1U

0.1U

0.1U

SMDDR_VREF

C49

0.1U

C25

2.2U

+3V

C40

2.2U

Place these Caps near So-Dimm1.
No Vias Between the Trace of PIN to

CAP.

1.8VSUS

Place these Caps near So-Dimm2.

C63

2.2U

C42

0.1U

C50

2.2U

C53

0.1U

C65

2.2U

C68

2.2U

C44

0.1U

+3V

C27

2.2U

C38

2.2U

1.8VSUS

Place these Caps near So-Dimm2.

C52

0.1U

SMDDR_VREF

C20

0.1U

Place these Caps near So-Dimm2.
No Vias Between the Trace of PIN to

CAP.

CLK_SDRAM4CLK_SDRAM3

C61
10P

C31
10P

CLK_SDRAM0# CLK_SDRAM1#

Size Document Number Rev
Custom

System DRAM Expansion (200P-DDR_SODIMM X 2)(1/2)

Date: Sheet

7

PROJECT : EF6

Quanta Computer Inc.

C62

10P

CLK_SDRAM4#CLK_SDRAM3#

CLK_SDRAM1CLK_SDRAM0

C30

10P

10 37Monday, January 03, 2005

8

C18

2.2U

C26

0.1U

C66

2.2U

C39

0.1U

C64

2.2U

C47

2.2U

of

1A

1

2

3

4

5

6

7

8

11

A A

DDRII DUAL CHANNEL A,B.

DDRII A CHANNEL DDRII B CHANNEL

R_A_MA[0..13] 7,10 R_B_MA[0..13] 7,10

SMDDR_VTERM

C35

C70

0.1U

B B

0.1U

C34

0.1U

R_A_BMWEA#7,10
R_A_SCASA#7,10

C57

0.1U

C43

0.1U

M_ODT0
SM_CS0#
R_A_MA5
R_A_MA8
R_A_MA3
R_A_MA1

R_A_MA11
CKE1
R_A_MA10
R_A_BS0#
R_A_MA6
R_A_MA7
R_A_MA0
R_A_MA4

R_A_MA2
R_A_BS1#
R_A_MA9
R_A_MA12
R_A_BMWEA#
R_A_SCASA#

C41

0.1U

M_ODT05,10

SM_CS0#5,10

CKE15,10

R_A_BS0#7,10

R_A_BS1#7,10

C74

C73

0.1U

C37

0.1U

0.1U

1

RP9 56X2

3
1

RP6 56X2

3
1

RP5 56X2

3
1

RP14 56X2

3
1

RP4 56X2

3
1

RP13 56X2

3
1

RP12 56X2

3
1

RP11 56X2

3
1

RP7 56X2

3
1

RP3 56X2

3

C69

0.1U

C71

C72

C48

0.1U

0.1U

0.1U

2
4
2
4
2
4

2
4
2
4
2
4
2
4

2
4
2
4
2
4

SMDDR_VTERM

SMDDR_VTERM

SMDDR_VTERM

SMDDR_VTERM 32,36

SMDDR_VTERM

C32

0.1U

C28

0.1U

C59

0.1U

C45

0.1U

C29

0.1U

C33

0.1U

C21

0.1U

C22

0.1U

C23

0.1U

C24

0.1U

C56

0.1U

C36

0.1U

C58

0.1U

Layout note: Place one cap close to every 2 pullup resistors terminated to SMDDR_VTERM

R_B_MA0

R_B_BS1#7,10

CKE25,10

R_B_BS2#7,10

R_B_SRASA#7,10

SM_CS2#5,10

R_B_BMWEA#7,10

M_ODT35,10
R_B_BS0#7,10

R_B_BS1#
R_B_MA1
R_B_MA3
R_B_MA5
R_B_MA8

R_B_MA4
R_B_MA2
R_B_MA9
R_B_MA12
R_B_MA6
R_B_MA7
CKE2
R_B_BS2#

R_B_SRASA#
SM_CS2#
R_B_BMWEA#
M_ODT3
R_B_MA10
R_B_BS0#

RP24 56X2
RP18 56X2
RP19 56X2

RP25 56X2
RP20 56X2
RP26 56X2
RP21 56X2

RP23 56X2
RP15 56X2
RP17 56X2

2

1

4

3

2

1

4

3

2

1

4

3

2

1

4

3

2

1

4

3

2

1

4

3

2

1

4

3

2

1

4

3

2

1

4

3

2

1

4

3

SMDDR_VTERM

SMDDR_VTERM

SMDDR_VTERM

C C

R_A_SRASA#7,10

M_ODT25,10

R_B_SCASA#7,10

SM_CS3#5,10
M_ODT15,10

C TEST modified EMI

SMDDR_VTERM

C526

C525

C524

0.1U

0.1U

D D

SMDDR_VTERM

C534

0.1U

1

C535

0.1U

0.1U

C536

0.1U

C527

0.1U

C537

0.1U

C528

0.1U

C538

0.1U

C529

C530

0.1U

0.1U

C540

C539

0.1U

0.1U

2

C531

0.1U

C541

0.1U

C532

0.1U

C542

0.1U

C533

0.1U

C543

0.1U

3

SM_CS1#5,10

CKE35,10
CKE05,10

R_A_BS2#7,10

R_A_MA13
R_A_SRASA#
M_ODT2
R_B_MA13
R_B_SCASA#
SM_CS3#
M_ODT1
SM_CS1#
R_B_MA11
CKE3
CKE0
R_A_BS2#

4

1

RP10 56X2

3
1

RP22 56X2

3
1

RP16 56X2

3
1

RP2 56X2

3
1

RP27 56X2

3
1

RP8 56X2

3

2
4
2
4
2
4
2
4
2
4
2
4

SMDDR_VTERM

5

Size Document Number Rev
Custom

6

Date: Sheet

7

PROJECT : EF6

Quanta Computer Inc.

DDR RES.ARRAY(2/2)

of

11 37Monday, January 03, 2005

8

1A

5

ESD PORTECTION

D D

CRT SWITCH

C C

SEL

FUNCTION(COM)

LOW

IN_B0

HIGH

IN_B1

+3V

R150

B B

PR_INSERT#_D

A A

10K

3

2

CH2507S

1

PR_HSYNC24

PR_VSYNC24

INTVGA_E

Q11

VGA_RED
PR_RED-1

VGA_GEN
PR_GEN-1

VGA_BLU
PR_BLU-1

5

+5V

+5V

+5V

TV_Y/G

C238

0.1U

CC0402

C240

0.1U

CC0402

C239

0.1U

CC0402

INTVGA_E
HSYNC_COM

INTVGA_E
VSYNC_COM

CRT_VS_1
CRT_HS_1

CRT_R_1
CRT_G_1

+5V

+5V

+5V

+5V

5
1
3

5
1
3

5
1
3

1
2
3

1
2
3

U32

2

VCC

1

IO1

3

IO2

*DALC208SC6

U30

2

VCC

1

IO1

3

IO2

*DALC208SC6

U5

2

VCC

1

IO1

3

IO2

*DALC208SC6

U27

VCC
IN_B1
IN_B0

NC7SB3157P6X

U28

VCC
IN_B1
IN_B0

NC7SB3157P6X

U29

VCC
IN_B1
IN_B0

NC7SB3157P6X

U24

1OE#
1A
2Y

SN74LVC2G125

U25

1OE#
1A
2Y

SN74LVC2G125

6

IO4

DDCCLK_1

4

IO3

5

GND

CRT_B_1

6

IO4

DDCDAT_1

4

IO3

5

GND

TV_COMP

6

IO4

TV_C/R

4

IO3

5

GND

R154 10K

PR_INSERT#_D

6

2OE#

2OE#

SEL

COM

GND

SEL

COM

GND

SEL

COM

GND

VCC

1Y
2AGND

VCC

1Y
2AGND

CRT_R_COM

4

2

6

CRT_G_COM

4

2

6

CRT_B_COM

4

2

+3V

+3V

C229

0.1U

8
7
6
54

8
7
6
54

CC0402

CRTHS_VGA
HSYNC_COM

+3V

+3V

C230

0.1U

CC0402

CRTVS_VGA
VSYNC_COM

4

+3V

2 1

D18 CH500H-40

CRT_R_COM 6

CRT_G_COM 6

CRT_B_COM 6

HSYNC_COM 6

VSYNC_COM 6

4

PR_INSERT#

CRT PORT

VGA_RED
VGA_GEN
VGA_BLU

R158
150/F

PR_INSERT# 26

3

L31 0
L33 0
L35 0

R160
150/F

R161
150/F

C250
*10P

+2.5V

CDDCCLK6

+2.5V

CDDCDATA6

C256

C253

*10P

*10P

R162 2.2K

CDDCCLK

CRTVS_VGA
CRTHS_VGA

R207 2.2K

CDDCDATA

TV-OUT

To port - replicator C.R.T

PR_RED-1
PR_GEN-1
PR_BLU-1

R148
150/F

3

2 1

+5V

D25 CH500H-40

C TEST Modified

C246

5.6P

+2.5V

2

CH2507S

Q13

R205 39
R206 39

+2.5V

2

CH2507S

Q18

TV_Y/G6

TV_C/R6

TV_COMP6

R139
150/F

3

3

TV_Y/G

TV_C/R

TV_COMP

C226
*10P

R142
150/F

1

1

CRTVDD1

RED_PI
GEN_PI
BLU_PI

R4
150/F

R2
150/F

R3
150/F

C220
*10P

C251

5.6P

DDCCLK2
CRT_VS2
CRT_HS2
DDCDAT2

F2

CRTVDD2

12

POLY_SWITCH_1.1A

L30 BK1608HS470
L32 BK1608HS470
L34 BK1608HS470

C254

5.6P

R163

2.2K

R208

2.2K

CRTVDD_5V

L36 BK1608HM121
L45 BK1608HM121
L47 BK1608HM121
L48 BK1608HM121

CRTVDD_5V

C TEST Modified

L4
BLM18BD151SN1

C10

5.6P

L2

BLM18BD151SN1

C9

5.6P

L3

1 2

BLM18BD151SN1

C8

5.6P

C TEST Modified

L20 0
L18 0
L16 0

C210
*10P

HI0805Q310R-00

CRT_R_1
CRT_G_1
CRT_B_1

C255

5.6P

V4

5.6P

TV_CHROMA_1

V2

5.6P

PR_RED-2
PR_GEN-2
PR_BLU-2

C221

5.6P

2

L46

C252

5.6P

DDCCLK2 24

DDCDAT2 24

TV_COMP_1

C212

5.6P

2

CRTVDD_5V

C297
*0.1U

C249

5.6P

3

L19 BK1608HS470
L17 BK1608HS470
L15 BK1608HS470

C207

5.6P

T50

7

7

V3

5.6P/VPORT-22

C257
*33P

TV_LUMA_1

CN2
S-VIDEO

5

5

10

C296
*33P

2

2

1

CRT_SENSE# 15

12 37Monday, January 03, 2005

12

of

1A

CN18

1617

CRT_CONN

6

111

7

12

2
8

13

3
9

14

4

15

5

DDCCLK_1
CRT_VS_1
CRT_HS_1
DDCDAT_1

C298

C299

*33P

*33P

46

46

89

89

13

C219

C209

5.6P

5.6P

Size Document Number Rev
C

Date: Sheet

CRT_SENSE#

C300
180P

PR_RED 24
PR_GRN 24
PR_BLU 24

C225

5.6P

PROJECT : EF6

Quanta Computer Inc.

SVIDEO/CRT/PANLE/HDTV

1

5

4

3

2

1

PANEL VCC CONTROL

+3V

E E

D D

C205

0.1U

DISP_ON6

R136
10K

U21

6

IN

4

IN

3

ON/OFF

AAT4280-1

OUT
GND
GND

1
2
5

AAT4280_OUT

C206

0.1U

L14
HI0805Q310R-00

12

R137

C201

0.01U

150

LCD CONNECTOR

VIN_BLIGHT

FPBACK

EDID_DATA
EDID_CLK

TXUCLKOUT+6

TXUCLKOUT-6

TXUOUT2+6

TXUOUT2-6

TXUOUT1+6

TXUOUT1-6

TXUOUT0+6

TXUOUT0-6

CN13

1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39

LCDCON40P

+5V

2
4
6

8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40

VADJ_1

TXLCLKOUT+ 6
TXLCLKOUT- 6

TXLOUT2+ 6
TXLOUT2- 6

TXLOUT1+ 6
TXLOUT1- 6

TXLOUT0+ 6
TXLOUT0- 6

+3V

LCDVCCLCDVCC

BACKLIGHT CONTROL

+3V2,3,8,10,12,14,15,16,18,21,22,23,25,26,30,33,35,36,37
3VPCU14,22,23,32,33,34,36
+2.5V5,6,8,12,16,32,36

C C

+3V

R190
10K

+3V

B B

BLON6

FPBACK#15 VADJ22

FPBACK# VADJ

BLON

Q17

DTC144EUA

2

1
2

53

U37
TC7SH08FU

4

D24

2 1

CH500H-40

C288

0.1U

FPBACK

3VPCU

R188
10K

R189 1K

COVERSW#

C286
1000P

CN20

LDDC_CLK6

MXLID# 22

C287

0.1U

1

2

LID

LDDC_DATA6

LDDC_CLK

LDDC_DATA

VIN

L13

C170
.1U/50V

CC0805

L51 BK1608HS121-T

HI0805Q310R-00

1

1

C181
.1U/50V

CC0805

+2.5V

Q23

2

CH2507S

+2.5V

2

CH2507S

VIN_BLIGHT

VADJ_1

3

3

Q22

+3V

R226

2.2K

+3V

R227

2.2K

EDID_CLK

EDID_DATA

A A

1 3

PROJECT : EF6

Quanta Computer Inc.

Size Document Number Rev

B

5

4

3

2

Date: Sheet

GPU Daughter Card & LCD CON.

13 37Monday, January 03, 2005

1

of

1A

5

R97

C92 1U/16V

R16 3K

+3VSUS

C93 0.047U

5

2
1

10M

C159
12P

C97
1U/16V

VCCRTC

5VPCU

R15

4.7K

R14
15K

PLTRST#_1

Y4

VCCRTC

Q4
MMBT3904

2

32.768KHZ

VCCRTC

R26
20K

1 2

RTC

RTC_N01

RTC_N02

C163

D D

D5 CH500H-40

12

BT2
RTC-BAT

2 1

D4 CH500H-40

2 1

C78
1000P

3VPCU

C C

B B

12P

1 3

NS,VGA,SIO Reset

U7

PLTRST#

PLTRST#5,15,30,37

4

7SZ32

IDE Reset

+3V

A A

PLTRST#

C94 0.1U

53

1

4

2

U8
TC7SH08FU

R21 *0

IDERST#_R

5

R18 33

IDERST# 18

A20M#3

FERR#3

IGNNE#3

INTR3

CPUINIT#3

RCIN#22

GATEA2022

AD[0..31]25,26,28

RTCRST#

12

G2
SHORT_ PAD1

ICH_PME#25,26,28
PCLK_ICH2

PCIRST#22,26

CLKRUN#22,25,26,28,30

PDD[0..15]18

PDCS1#18
PDCS3#18

PDA018
PDA118
PDA218

PDIOR#18
PDIOW#18
PIORDY18

IRQ1418

PDDREQ18

PDDACK#18

4

R265 1M

NMI3

+3V

4

CLK_32KX1
CLK_32KX2

RTCRST#

SM_INTRUDER#

NMI
A20M#

R241 56

FERR#
IGNNE#

CPUINIT#
RCIN#
GATEA20

AD[0..31]

PCIRST#
PLTRST#_1
CLKRUN#

R255 8.2K

PDD[0..15]

PDCS1#
PDCS3#
PDA0
PDA1
PDA2
PDIOR#
PDIOW#
PIORDY
IRQ14
PDDREQ
PDDACK#

AD0
AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
AD9
AD10
AD11
AD12
AD13
AD14
AD15
AD16
AD17
AD18
AD19
AD20
AD21
AD22
AD23
AD24
AD25
AD26
AD27
AD28
AD29
AD30
AD31

PDD0
PDD1
PDD2
PDD3
PDD4
PDD5
PDD6
PDD7
PDD8
PDD9
PDD10
PDD11
PDD12
PDD13
PDD14
PDD15

AA2
AA3

AA5

AF25
AF23

AF24
AG26
AG24

AF27
AD23

AF22

AF19

AD14

AF15

AF14
AD12
AE14
AC11
AD11
AB11
AE13

AF13
AB12
AB13
AC13
AE15
AG15
AD13

AD16
AE17
AC16
AB17
AC17
AE16
AC14

AF16
AB16
AB14
AB15

Y1
Y2

E2
E5
C2
F5
F3
E9
F2
D6
E6
D3
A2
D2
D5
H3
B4

J5
K2
K5
D4
L6

G3

H4
H2
H5
B3

M6

B2
K6
K3
A5
L1
K4

P6

G6

R2
R5

U13A

RTCX1
RTCX2

RTCRST#
INTRUDER#

INTVRMEN

NMI
A20M#
FERR#
IGNNE#
INTR
INIT#
RCIN#
A20GATE

AD0
AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
AD9
AD10
AD11
AD12
AD13
AD14
AD15
AD16
AD17
AD18
AD19
AD20
AD21
AD22
AD23
AD24
AD25
AD26
AD27
AD28
AD29
AD30
AD31

PME#
PCICLK
PCIRST#
PLTRST#
CLKRUN#/GPIO32

DD0
DD1
DD2
DD3
DD4
DD5
DD6
DD7
DD8
DD9
DD10
DD11
DD12
DD13
DD14
DD15

DCS1#
DCS3#
DA0
DA1
DA2
DIOR#
DIOW#
IORDY
IDEIRQ
DDREQ
DDACK#

ICH6-M

RTC

CPU

PCI

IDE

3

LAD0
LAD1/FB1
LAD2/FB2
LAD3/FB3

LDRQ0#

LDRQ1#/GPI41

LFRAME#

LPC

CPUPWRGD/GPO49

INIT3_3V#

THRMTRIP#

SMI#
STPCLK#
CPUSLP#

DPSLP#/TP[2]

DPRSTP#/TP[4]

C/BE0#
C/BE1#
C/BE2#
C/BE3#

FRAME#

IRDY#

TRDY#

DEVSEL#

STOP#

PAR
SERR#
PERR#

PLOCK#

REQ0#
REQ1#
REQ2#
REQ3#

REQ4#/GPI40

REQ5#/GPI1
REQ6#/GPI0

GNT0#
GNT1#
GNT2#

GNT3#
GNT4#/GPO48
GNT5#/GPO17
GNT6#/GPO16

PIRQA#
PIRQB#
PIRQC#

PIRQD#
PIRQE#/GPI2
PIRQF#/GPI3

PIRQG#/GPI4
PIRQH#/GPI5

SATALED#

SATA0_RXN
SATA0_RXP
SATA0_TXN

SATA0_TXP

SATA2_RXN
SATA2_RXP
SATA2_TXN

SATA2_TXP

SATA_CLKN
SATA_CLKP

SATA

SATARBIAS#

SATARBIAS

ACZ_BIT_CLK

ACZ_SYNC
ACZ_RST#

ACZ_SDIN0
ACZ_SDIN1
ACZ_SDIN2

ACZ_SDO

AC-97/

AZALIA

3

2

+3V 10,12,13,15,16,18,21,22,23,25,26,30,33,36,37
VCCP 9,16,31,36

LAD0/FWH0

P2

LAD1/FWH1

N3

LAD2/FWH2

N5

LAD3/FWH3

N4
N6
P4

LFRAME#/FWH4

P3

CPUPWRGD

AG25
AE22

THERMTRIP#_ICH

AE23

R118 0

AG27
AE26

H_CPUSLP#_R

AE27

H_DPSLP#_R

AD27

H_DPRSTP#_R

AE24

C/BE0#

J6

C/BE1#

H6

C/BE2#

G4

C/BE3#

G2

FRAME#

J3

IRDY#

A3

TRDY#

J2

DEVSEL#

C3

STOP#

J1

PAR

E1
G5

PERR#

E3

PLOCK#

C5

REQ0#

L5

REQ1#

B5

REQ2#

M5

REQ3#

B8

REQ4#

F7

REQ5#

E8

REQ6#

B7

GNT0#

C1

GNT1#

B6

GNT2#

F1

GNT3# ICH_GPIO3

C8

GNT4#

E7

GNT5#

F6

GNT6#

D8

PIRQA#

N2

PIRQB#

L2

PIRQC#

M1

PIRQD#

L3

PIRQE#

D9

ICH_GPIO3

C7

ICH_GPIO4

C6

ICH_GPIO5

M3

SATA_LED#

AC19

SATA_RXN0_C

AE3

SATA_RXP0_C

AD3

SATA_TXN0_C

AG2

SATA_TXP0_C

AF2
AD7

AC7
AF6
AG6

SRC_SATA#

AC2

SRC_SATA

AC1
AG11

SATABIAS

AF11

C10
B9
A10

F11

AC_SDIN1

F10

AC_SDIN2

B10

AC_SDOUT

C9

LAD0/FWH0 22,30
LAD1/FWH1 22,30
LAD2/FWH2 22,30
LAD3/FWH3 22,30
LPC_DRQ0#

LFRAME#/FWH4 22,30

CPUPWRGD 3

T67

STPCLK#INTR

R117 *0
R268 0
R240 0

C/BE0# 25,26,28
C/BE1# 25,26,28
C/BE2# 25,26,28
C/BE3# 25,26,28

FRAME# 25,26,28
IRDY# 25,26,28
TRDY# 25,26,28
DEVSEL# 25,26,28
STOP# 25,26,28
PAR 25,26,28
SERR# 25,26,28
PERR# 25,26,28

REQ0# 28
REQ1# 25
REQ2# 26

T103
T13

GNT0# 28
GNT1# 25

GNT2# 26

T11
T101
T93
T100

PIRQA# 28

PIRQB# 25,28

PIRQC# 25,28

PIRQD# 26

T96

SATA_LED# 23

SRC_SATA# 2

SRC_SATA 2

R261 24.9/F

R30 *1K

R197 33
R29 33
R28 33

R27 33

T91
T12

AC_SDOUT 19

R244 56

+3V

VCCP

R243
75

SMI# 3
STPCLK# 3
H_CPUSLP# 3,5
H_DPSLP# 3
H_DPRSTP# 3

DPRSTP#

1). Stuff for Dothan B1 Stepping.

2). No stuff for Dothan A Stepping.

Place within 500mils
of ICH6 ball

2

THRMTRIP# 3,5

AC_BITCLK 19
AC_SYNC 19
AC_RESET# 19

AC_SDIN0 19

SERIRQ15,22,28,30

SATA_RXN0_C

SATA_RXP0_C

SATA_TXN0_C

SATA_TXP0_C

Size Document Number Rev
Custom

Date: Sheet

Distance between the ICH-6 M and cap on the "P"
signal should be identical distance between the
ICH-6 M and cap on the "N" signal for same pair.

ICH6(1/3)

1

VCCP

FERR#
H_DPSLP#
RCIN#
GATEA20
PIORDY

R242 56
R263 *56
R253 10K
R245 10K
R259 4.7K

+3V
+3V
+3V

PCI Pullups

FRAME#
REQ0#
PIRQD#
PIRQB#

+3V

REQ5#
REQ4#
SERIRQ

+3V

REQ3#
PIRQC# REQ6#
STOP#
TRDY#

+3V

ICH_GPIO5
PIRQE#

ICH_GPIO4

C491 3900P

C492 3900P

C335 3900P

C337 3900P

RP44

6
7
8
9

10

RP46

6
7
8
9

10

RP28

6
7
8
9

10

7 8
5 6
3 4
1 2

8P4R-8.2K

SATA_RXN0

SATA_RXP0

SATA_TXN0

SATA_TXP0

RP45

8.2KX8

8.2KX8

8.2KX8

5
4
3
2
1

5
4
3
2
1

5
4
3
2
1

+3V

SATA_RXN0 18

SATA_RXP0 18

SATA_TXN0 18

SATA_TXP0 18

PROJECT : EF6

Quanta Computer Inc.

14 37Monday, January 03, 2005

1

+3V

REQ2#
PIRQA#

+3V

IRQ14
SERR#DEVSEL#

PERR#

+3V

REQ1#
PLOCK#
IRDY#

of

14

1A

5

4

3

2

1

15

U13B

USBP5+17
USBP5-17

D D

PCIE_RXN037
PCIE_RXP037

PCIE_TXN037

C C

+3V

+3V

B B

3V_S5

A A

B TEST Modified

R254 10K

R271 10K
R272 10K

RP43

RP42

RP41

THRM#
CRT_SENSE#

SCI#
SWI#
SMLINK1
PDAT_SMB

KBSMI#
RI#
DBR#
BATLOW#

SMBALERT#
SMB_LINK_ALERT#
SMLINK0
PCLK_SMB

SUS_STAT#

5

R246 8.2K
R247 10K

7 8
5 6
3 4
1 2

8P4R-10K

7 8
5 6
3 4
1 2

8P4R-10K

7 8
5 6
3 4
1 2

8P4R-10K

R273 10K

DASP_ON

PWROK
RSMRST#

PCIE_TXP037

HW_RADIO_DIS#37

3V_S5 3V_S5 3V_S5

R111
*10K

C167

*0.1U

USBP4+17
USBP4-17

USBP3+37

USBP3-37 USBP1- 24

USBP0+17

USBP0-17

CLK48_USB2

DMI_RXN05
DMI_RXP05
DMI_TXN05
DMI_TXP05

DMI_RXN15
DMI_RXP15
DMI_TXN15
DMI_TXP15

SRC_ICH#2

SRC_ICH2

PCIE_RXN0
PCIE_RXP0
PCIE_TXN0

C142 *0.1U
C143 *0.1U

T89
T87
T16
T15

PCLK_SMB2,37
PDAT_SMB2,37

PWROK22

DPRSLPVR35

BATLOW#22

DNBSWON#22

RSMRST#22

IMVP_PWG5,35
PM_BMBUSY#5
SUS_STAT#22,30

T72

14M_ICH2

PCSPK19

CRT_SENSE#12

KBSMI#22

SCI#22

SWI#22

HW_RADIO_DIS#

+3V

B TEST Modified

5

U16A

1 6

*NC7WZ14P6X

4

USBP5+
USBP5-

USBP4+ USBP6+
USBP4­OC2#
USBP3+
USBP3­OC4#
USBP0+
USBP0­OC6#

DMI_RXN0
DMI_RXP0
DMI_TXN0
DMI_TXP0

DMI_RXN1
DMI_RXP1
DMI_TXN1
DMI_TXP1

SRC_ICH#
SRC_ICH

PCIE_TXN0_R
PCIE_TXP0_RPCIE_TXP0

PCLK_SMB
PDAT_SMB
SMBALERT#

RI#
THRM#
PWROK
DPRSLPVR
BATLOW#
DNBSWON#
RSMRST#
IMVP_PWG
PM_BMBUSY#
SUS_STAT#
SUSCLK

PCSPK
CRT_SENSE#
KBSMI#
SCI#
SWI#

D13

2 1

CH500H-40

R80
1K

5

U16B

3 4

*NC7WZ14P6X

D21

USBP0P

C21

USBP0N

C27

OC0#

C19

USBP2P

D19

USBP2N

B26

OC2#

D17

USBP4P

E17

USBP4N

C23

OC4#/GPI9

D15

USBP6P

C15

USBP6N

C25

OC6#/GPI14

A27

CLK48

T25

DMI0_RXN

T24

DMI0_RXP

R27

DMI0_TXN

R26

DMI0_TXP

V25

DMI1_RXN

V24

DMI1_RXP

U27

DMI1_TXN

U26

DMI1_TXP

AD25

DMI_CLKN

AC25

DMI_CLKP

H25

HSIN0

H24

HSIP0

G27

HSON0

G26

HSOP0

K25

HSIN1

K24

HSIP1

J27

HSON1

J26

HSOP1

Y4

SMBCLK

W5

SMBDATA

W6

SMBALERT#/GPI11

T2

RI#

AC20

THRM#

AA1

PWROK

AE20

DPRSLPVR/TP1

V2

BATLOW#/TP0

U1

PWRBTN#

Y3

RSMRST#

AF21

VRMPWRGD

AD19

BM_BUSY#/GPIO6

W3 AD22

SUS_STAT#/LPCPD# STP_CPU#/GPO20

V6

SUSCLK

E10

CLK14

F8

SPKR

AE19

GPI7

R1

GPI8

M2

GPI12

R6

GPI13

AB21

GPO19

AD20

GPO21

AD21

GPO23

V3

GPIO24

D12

EE_CS

B12

EE_SHCLK

D11

EE_DOUT

F13

EE_DIN

AC5

RSVD1

AD5

RSVD2

AF4

RSVD3

AG4

RSVD4

AC9

RSVD5

ICH6-M

RSMRST#

USB

DMI

PCI-EXPRESS

SM&SMI

PM

MISC&GPIO

LAN

RESERVED

3

USBP1P
USBP1N

OC1#
USBP3P
USBP3N

OC3#
USBP5P
USBP5N

OC5#/GPI10

USBP7P
USBP7N

OC7#/GPI15

USBRBIAS

USBRBIAS#

DMI2_RXN

DMI2_RXP
DMI2_TXN
DMI2_TXP

DMI3_RXN

DMI3_RXP
DMI3_TXN
DMI3_TXP

DMI_ZCOMP

DMI_IRCOMP

HSIN2

HSIP2
HSON2
HSOP2

HSIN3

HSIP3
HSON3
HSOP3

SMLINK0
SMLINK1

LINKALERET#

SLP_S3#
SLP_S4#
SLP_S5#

LAN_RST#

SYS_RESET#

WAKE#

MCH_SYNC#

STP_PCI#/GPO18

SERIRQ

GPIO25

SATA0GP/GPIO26

GPIO27

GPIO28
SATA1GP/GPIO29
SATA2GP/GPIO30
SATA3GP/GPIO31

GPIO33

GPIO34

LAN_RXD0
LAN_RXD1
LAN_RXD2
LAN_TXD0
LAN_TXD1
LAN_TXD2

LAN_CLK

LAN_RSTSYNC

RSVD6
RSVD7
RSVD8
RSVD9

B20
A20
B27
B18
A18
C26
A16
B16
D23
B14
A14
C24
B22
A22

Y25
Y24
W27
W26

AB24
AB23
AA27
AA26

F24
F23

M25
M24
L27
L26

P24
P23
N27
N26

W4
U6
Y5

T4
T5
T6
V5
U2
U5
AG21

AC21
AB20
P5

AF17
R3
T3
AE18
AF18
AG18

AF20
AC18

E12
E11
C13
C12
C11
E13

F12
B11

AD9
AF8
AG8
U3

USBP2+
USBP2­OC1#OC0#

USBP6­OC3#
USBP1+
USBP1­OC5#
USBP7+
USBP7­OC7#

USBRBIAS

DMI_RXN2
DMI_RXP2
DMI_TXN2
DMI_TXP2

DMI_RXN3
DMI_RXP3
DMI_TXN3
DMI_TXP3

DMI_ZCOMP

SMLINK0
SMLINK1
SMB_LINK_ALERT#

SUSB#
SUSC#

PLTRST#
DBR#
PCIE_WAKE#
MCH_SYNC#

STP_PCI#
STP_CPU#
SERIRQ

SM_EN#
SATA0GP
FPBACK#

SATA1GP
SATA2GP
SATA3GP

DASP_ON

USBP2+ 24
USBP2- 24

USBP6+ 17
USBP6- 17

USBP1+ 24

USBP7+ 37
USBP7- 37

R342 22.6/F

DMI_RXN2 5
DMI_RXP2 5
DMI_TXN2 5
DMI_TXP2 5

DMI_RXN3 5
DMI_RXP3 5
DMI_TXN3 5
DMI_TXP3 5

R320 24.9/F

SUSB# 22
SUSC# 22

T74

PLTRST# 5,14,37
DBR# 3

PCIE_WAKE# 37

T65

STP_PCI# 2
STP_CPU# 2,35
SERIRQ 14,22,28,30

T76

FPBACK# 13

T73

DASP_ON 18

T69

OC3#
OC2#
OC1#
OC0#

Place within 500mils of ICH-6

Place within 500mils of ICH-6

+1.5V

PCIE_WAKE#

MCH_SYNC#

Size Document Number Rev
Custom

2

Date: Sheet

ICH6(2/3)

OC6#
OC7#
OC5#
OC4#

R274 680

R252 10K

SATA3GP
SATA2GP
SATA1GP
SATA0GP

PROJECT : EF6

Quanta Computer Inc.

+3VSUS

R37
10K

RP29

1

2
4
6
8

10KX4

+3V

RP40

1

2

3

4

5

6

7

8

10KX4

1

+3VSUS

3
5
7

3V_S5

+3V

2A

of

15 37Monday, January 03, 2005

5

4

3

2

1

16

U13C

C336

0.1U

AA22

VCC1_5_1

AA23

VCC1_5_2

AA24

VCC1_5_3

AA25

VCC1_5_4

AB25

VCC1_5_5

AB26

VCC1_5_6

AB27

VCC1_5_7

F25

VCC1_5_8

F26

VCC1_5_9

F27

VCC1_5_10

G22

VCC1_5_11

G23

VCC1_5_12

G24

VCC1_5_13

G25

VCC1_5_14

H21

VCC1_5_15

H22

VCC1_5_16

J21

VCC1_5_17

J22

VCC1_5_18

K21

VCC1_5_19

K22

VCC1_5_20

L21

VCC1_5_21

L22

VCC1_5_22

M21

VCC1_5_23

M22

VCC1_5_24

N21

VCC1_5_25

N22

VCC1_5_26

N23

VCC1_5_27

N24

VCC1_5_28

N25

VCC1_5_29

P21

VCC1_5_30

P25

VCC1_5_31

P26

VCC1_5_32

P27

VCC1_5_33

R21

VCC1_5_34

R22

VCC1_5_35

T21

VCC1_5_36

T22

VCC1_5_37

U21

VCC1_5_38

U22

VCC1_5_39

V21

VCC1_5_40

V22

VCC1_5_41

W21

VCC1_5_42

W22

VCC1_5_43

Y21

VCC1_5_44

Y22

VCC1_5_45

AA6

VCC1_5_46

AB4

VCC1_5_47

AB5

VCC1_5_48

AB6

VCC1_5_49

AC4

VCC1_5_50

AD4

VCC1_5_51

AE4

VCC1_5_52

AE5

VCC1_5_53

AF5

VCC1_5_54

AG5

VCC1_5_55

AA7

VCC1_5_56

AA8

VCC1_5_57

AA9

VCC1_5_58

AB8

VCC1_5_59

AC8

VCC1_5_60

AD8

VCC1_5_61

AE8

VCC1_5_62

AE9

VCC1_5_63

AF9

VCC1_5_64

AG9

VCC1_5_65

AC27

VCCDMIPLL

E26

VCC3_3_1

AE1

VCCSATAPLL

AG10

VCC3_3_22

A13

VCCLAN3_3/VCCSUS3_3_1

F14

VCCLAN3_3/VCCSUS3_3_2

G13

VCCLAN3_3/VCCSUS3_3_3

G14

VCCLAN3_3/VCCSUS3_3_4

A11

VCCSUS3_3_1

U4

VCCSUS3_3_2

V1

VCCSUS3_3_3

V7

VCCSUS3_3_4

W2

VCCSUS3_3_5

Y7

VCCSUS3_3_6

A17

VCCSUS3_3_7

B17

VCCSUS3_3_8

C17

VCCSUS3_3_9

F18

VCCSUS3_3_10

G17

VCCSUS3_3_11

G18

VCCSUS3_3_12

ICH6-M

4

VCC1_5_79
VCC1_5_80
VCC1_5_81
VCC1_5_82
VCC1_5_83
VCC1_5_84
VCC1_5_85
VCC1_5_86
VCC1_5_87
VCC1_5_88
VCC1_5_89
VCC1_5_90
VCC1_5_91

VCC

VCCLAN1_5/VCCSUS1_5_1
VCCLAN1_5/VCCSUS1_5_2

VCC1_5_92
VCC1_5_93
VCC1_5_94
VCC1_5_95
VCC1_5_96
VCC1_5_97
VCC1_5_98

VCC3_3_10
VCC3_3_11

VCC3_3_12
VCC3_3_13
VCC3_3_14
VCC3_3_15
VCC3_3_16
VCC3_3_17
VCC3_3_18
VCC3_3_19
VCC3_3_20
VCC3_3_21

VCCSUS1_5_1
VCCSUS1_5_2

VCCSUS1_5_3

VCC1_5_67
VCC1_5_68

VCC1_5_69
VCC1_5_70
VCC1_5_71
VCC1_5_72
VCC1_5_73
VCC1_5_74
VCC1_5_75
VCC1_5_76
VCC1_5_77
VCC1_5_78

V5REF_SUS

VCCUSBPLL

VCCSUS3_3_20

V_CPU_IO1
V_CPU_IO2
V_CPU_IO3

VCCSUS3_3_13
VCCSUS3_3_14
VCCSUS3_3_15
VCCSUS3_3_16
VCCSUS3_3_17
VCCSUS3_3_18
VCCSUS3_3_19

+1.5V

D D

R31 10

+5V

D8

2 1

+3V

5V_S5

+1.5V

C168
10U

3V_S5

+1.5V

R116

1

+3V

3V_S5

3V_S5

3V_S5

C C

B B

A A

R25 10

2 1

C339

0.1U

VCCDMIPLL_1

C352

0.1U

CH751H-40H

D7

CH751H-40H

C364

0.1U

+1.5V

C356

0.1U

C433

0.1U

5

C440

0.1U

L12

BLM11A121S

C350

0.1U

C457

0.1U

C411

0.1U

C357

0.1U

C359

0.1U

V5REF

C354

0.1U

C422

0.1U

C453

0.1U

C455

0.1U

C376

0.1U

C347

0.01U

C410

0.1U

C385

0.1U

C377

0.1U

VCCDMIPLL_2

C415

0.1U

+

C164
220U

C99
1U

V5REF_SUS

C98
1U

+1.5V

12

+3V

C447

0.1U

VCC3_3_2
VCC3_3_3
VCC3_3_4
VCC3_3_5
VCC3_3_6
VCC3_3_7
VCC3_3_8
VCC3_3_9

VCC2_5_2
VCC2_5_4

V5REF1
V5REF2

VCCRTC

AA19
AA20
AA21
L11
L12
L14
L16
L17
M11
M17
P11
P17
T11
T17
U11
U12
U14
U16
U17
F9

A6
B1
E4
H1
H7
J7
L4
L7
M7
P1

AA12
AA14
AA15
AA17
AC15
AD17
AG13
AG16
AG19
AA10

G19
R7

U7
G8
D24

D25
D26
D27
E20
E21
E22
E23
E24
F20
G20

P7
AB18

A8
AA18

F21
A25

A24
AB3

G10
G11

AB22
AD26
AG23

C16
D16
E16
F15
F16
G15
G16

+1.5V

V5REF

V5REF_SUS

VCCRTC

1.5V_S5

C374

0.1U

C413

0.1U

C435

0.1U

C403

C434

0.1U

C330
1U

C412

0.1U

C414

0.1U

C443

0.1U

C351

0.1U

C353

0.1U

C334

0.1U

0.1U

C345

0.1U

C329
1U

+3V

C360

0.1U

C456

0.1U

3V_S5

VCCP

C346

0.1U

+3V

C340

0.1U

C384

0.1U

C355

0.1U

C331
1U

3

C124

C363

10U

0.01U

+3_3V_PCI

+3_3V_ICH

1.5V_S5

1.5V_S5

+1.5V

+2.5V

+1.5V

C338

0.01U

VCCRTC

C348

0.1U

+1.5V

C328
10U

2

U13D

A12
A15
A19
A21
A23
A26

AA11
AA13
AA16

AA4

AB1
AB10
AB19

AB2

AB7

AB9
AC10
AC12
AC22
AC23
AC24
AC26

AC3

AC6

AD1
AD10
AD15
AD18

AD2
AD24

AD6
AE10
AE11
AE12

AE2
AE21
AE25

AE6

AE7

AF1

AF10
AF12
AF26

AF3

AF7

AG1
AG12
AG14
AG17
AG20
AG22

AG3

AG7

B13
B15
B19
B21
B23
B24

B25
C14
C18
C20
C22

D10
D13
D14
D18
D20
D22

E14

E15

E18

E19

E25

F17

F19

F22

A1

VSS001
VSS002
VSS003
VSS004
VSS005
VSS006
VSS007

A4

VSS008

A7

VSS009

A9

VSS010
VSS011
VSS012
VSS013
VSS014
VSS015
VSS016
VSS017
VSS018
VSS019
VSS020
VSS021
VSS022
VSS023
VSS024
VSS025
VSS026
VSS027
VSS028
VSS029
VSS030
VSS031
VSS032
VSS033
VSS034
VSS035
VSS036
VSS037
VSS038
VSS039
VSS040
VSS041
VSS042
VSS043
VSS044
VSS045
VSS046
VSS047
VSS048
VSS049
VSS050
VSS051
VSS052
VSS053
VSS054
VSS055
VSS056
VSS057
VSS058
VSS059
VSS060
VSS061
VSS062
VSS063
VSS064
VSS065
VSS066
VSS067
VSS068

C4

VSS069

D1

VSS070
VSS071
VSS072
VSS073
VSS074
VSS075
VSS076

D7

VSS077
VSS078
VSS079
VSS080
VSS081
VSS082
VSS083
VSS084
VSS085

F4

VSS086

GND

ICH6-M

VSS087
VSS088
VSS089
VSS090
VSS091
VSS092
VSS093
VSS094
VSS095
VSS096
VSS097
VSS098
VSS099
VSS100
VSS101
VSS102
VSS103
VSS104
VSS105
VSS106
VSS107
VSS108
VSS109
VSS110
VSS111
VSS112
VSS113
VSS114
VSS115
VSS116
VSS117
VSS118
VSS119
VSS120
VSS121
VSS122
VSS123
VSS124
VSS125
VSS126
VSS127
VSS128
VSS129
VSS130
VSS131
VSS132
VSS133
VSS134
VSS135
VSS136
VSS137
VSS138
VSS139
VSS140
VSS141
VSS142
VSS143
VSS144
VSS145
VSS146
VSS147
VSS148
VSS149
VSS150
VSS151
VSS152
VSS153
VSS154
VSS155
VSS156
VSS157
VSS158
VSS159
VSS160
VSS161
VSS162
VSS163
VSS164
VSS165
VSS166
VSS167
VSS168
VSS169
VSS170
VSS171
VSS172

G1
G12
G21
G7
G9
H23
H26
H27
J23
J24
J25
J4
K1
K23
K26
K27
K7
L13
L15
L23
L24
L25
M12
M13
M14
M15
M16
M23
M26
M27
M4
N1
N11
N12
N13
N14
N15
N16
N17
N7
P12
P13
P14
P15
P16
P22
R11
R12
R13
R14
R15
R16
R17
R23
R24
R25
R4
T1
T12
T13
T14
T15
T16
T23
T26
T27
T7
U13
U15
U23
U24
U25
V23
V26
V27
V4
W1
W23
W24
W25
W7
Y23
Y26
Y27
Y6
E27

PROJECT : EF6

Quanta Computer Inc.

Size Document Number Rev

Date: Sheet

ICH6(3/3)

16 37Monday, January 03, 2005

1

of

1ACustom

5

40MIL 40MIL

+5VSUS

D D

USBP5+15

USBP5-15

USBP5- USBP_5-

U3

3

IN

OUT

4

IN

2

GND

OUT

RT9701

EB4

4

4

NCCMQ20D900-TR

1

5

23

23

1

1

M890VDD0

USBP_5+USBP5+

4

M890VDD0

M890VDD0
USBP_5-

USBP_5+

3

+5VSUS24,28,32,33,36

C3

0.1U

+

C6
100U/6.3V

2

USB-0

CN6

1

V+

2

DATA_L

3

DATA_H

4

GND

SHIELD1
SHIELD2

USB_CONN_H

1

17

5
6

40MIL 40MIL

+5VSUS

C C

U33

3
4

2

IN
IN

GND

RT9701

OUT

OUT

1

5

C TEST
Modified

USBP0+15

USBP0-15

+5VSUS

B B

USBP4+15
USBP4-15

EB2

4

4

NCCMQ20D900-TR

U2

3

IN

OUT

4

IN

2

GND

OUT

RT9701

EB3

4

4

NCCMQ20D900-TR

USBP_0+

23

23

USBP_0-

1

1

40MIL40MIL

1

5

USBP_4+

23

23
1

USBP_4-

1

M890VDD1

M890VDD1

B TEST
Modified

Signal pin
swap for
layout

M890VDD2

M890VDD1

USBP_0­USBP_0+

M890VDD2M890VDD2
USBP_4-

USBP_4+

C2

0.1U

C264

0.1U

+

+

C265
100U/6.3V

C5
100U/6.3V

USB-1

CN21

1

V+

2

DATA_L

3

DATA_H

4

GND

USB-2

CN5

1

V+

2

DATA_L

3

DATA_H

4

GND

SHIELD1
SHIELD2

USB_CONN_H

SHIELD1
SHIELD2

USB_CONN_H

5
6

5
6

USB-3

40MIL 40MIL

+5VSUS

U4

3

IN

OUT

4

IN

2

GND

OUT

RT9701

M890VDD3

1

5

M890VDD3

M890VDD3

USBP_6­USBP_6+

C4

0.1U

+

C7
100U/6.3V

1
2

3
4

CN7

V+
DATA_L

DATA_H
GND

SHIELD1
SHIELD2

USB_CONN_H

5
6

A A

USBP6+15

USBP6-15

5

EB5

4

4

NCCMQ20D900-TR

USBP_6+

23

23

USBP_6-

1

1

4

3

2

Size Document Number Rev
Custom

Date: Sheet

USB Ports

PROJECT : EF6

Quanta Computer Inc.

17 37Monday, January 03, 2005

1

of

1A

1

PDD[0..15]14

PDDREQ14
PDIOW#14
PDIOR#14
PIORDY14
PDDACK#14
IRQ1414
PDA114
PDA014
PDCS1#14

A A

PDA214
PDCS3#14
IDERST#14

R210 0

PDD[0..15]
PDDREQ

PDIOW#
PDIOR#
PIORDY
PDDACK#
IRQ14
PDA1
PDA0
PDCS1#
PDA2
PDCS3#
IDERST#

PDIAG-PDIAG

B TEST Modified

+5V +5V

R153
*10K

Q32 *CH2507S

HDDLED#

B B

3

2

DASP_ON_1

R156 *0

1

ADD DASP_ON FOR IDE CABLE SELECT

2

1

DASP_ON_1

Q12
CH2507S

3

2

4

R155
10K

U45

7SH08

ODDLED#

3

CDGND19

+5V

5

2
1

DASP_ON 15

CDAUDL19

ODDLED#23

ODD_VCC

NC for slave

4

ODD CONNECTOR

CDAUDL
CDGND
IDERST#
PDD7
PDD6
PDD5
PDD4
PDD3
PDD2
PDD1
PDD0

PDIOW#
PIORDY
IRQ14
PDA1
PDA0
PDCS1#
ODDLED#

C234

0.1U

R209
470

C15004-15001

CN17

1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49

5

SLAVE

CDAUDR

2
4

PDD8

6

PDD9

8

PDD10

10

PDD11

12

PDD12

14

PDD13

16

PDD14

18

PDD15

20

PDDREQ

22

PDIOR#

24
26

PDDACK#

28
30

-PDIAG

32

PDA2

34

PDCS3#

36
38
40
42
44
46
48
50

51
52

0.1U

CDAUDR 19

ODD_VCC +5V

PBY201209T-300Y-S

C233

L21

80MIL

C235

0.1U

6

7

8

18

ODD_VCC

C3010.1U

C23110U

C2321000P

B TEST Modified

SATA 1 CONNECTOR

HDD CONNECTOR

CN10

IDERST#
PDD7
PDD6
PDD5
PDD4
PDD3
PDD2
PDD1

HDDLED#

PDD0
PDDREQ

PDIOW#
PDIOR#
PIORDY
PDDACK#
IRQ14
PDA1
PDA0
PDCS1#

C87
*100P

C C

HDDLED#23

HDD_VDD

CN9

1 2

12

3 4

34

5 6

56

7 8

78

9 10

910

11 12

11 12

13 14

13 14

15 16

15 16

17 18

17 18

19 20

19 20

21 22

21 22

23 24

23 24

25 26

25 26

27 28

27 28

29 30

29 30

31 32

31 32

33 34

33 34

35 36

35 36

37 38

37 38

39 40

39 40

41 42

41 42

43 44

43 44

45 46

45 46

47 48

47 48

ALLTOP_17859

PDD8
PDD9
PDD10
PDD11
PDD12
PDD13
PDD14
PDD15

PCSEL

PDIAG
PDA2
PDCS3#

R19 470

R17 *10K_0402

HDD_VDD

PBY201209T-300Y-S

L7

2 1

80MIL

+5V

C861000P

C4900.1U

HDD_VDD

C4890.1U

C49310U

23

25

26

24

GND4

H1

H2

GND5

Serial_ATA

GND1

TXN

GND2

RXN
RXP

GND3

3.3V

3.3V

3.3V
GND
GND
GND

GND

RSVD

GND

1
2

TXP

3
4
5
6
7

8
9
10
11
12
13
14

5V

15

5V

16

5V

17
18
19
20

12V

21

12V

22

12V

SATA_TXP0 14
SATA_TXN0 14

SATA_RXN0 14
SATA_RXP0 14

+3.3VSATA

L69

PBY201209T-300Y-S

HDD_VDD

C5164.7U/10V

+3.3VSATA

C5174.7U/10V

C5180.1U

+3V

B TEST Modified

MASTER

D D

C TEST modified (footprint change )

PROJECT : EF6

Quanta Computer Inc.

Size Document Number Rev

1

2

3

4

5

6

Date: Sheet

IDE (HDD&CD_ROM

7

18 37Monday, January 03, 2005

8

2ACustom

of

A

B

C

D

E

SMARTAMC-CONEXANT_20468-31 19

For Layout:

Place decoupling caps near the power pins of
SmartAMC device.

CODEC POWER

L43
*BK2125HM121

MC39

MC41

10U

0.1U_0402

GND

MC2 150P_0402

DIB_DATAN20
DIB_DATAP20

PWRCLKP20

PWRCLKN20

15:5:15 routing , 50 mil
to other signal

1 1

GND

MC3
150P_0402

EC38,May/24

L39 SBK160808T-110Y
L40 SBK160808T-110Y
L41 SBK160808T-110Y
L42 SBK160808T-110Y

GND

AC_SDIN014

AC_BITCLK14

AC_SDOUT14
AC_SYNC14

AC_RESET#14

MC36

MC32

0.1U_0402

0.1U_0402

For Layout: Close to SmartAMC device.

MR16 0
MR17 0
MR18 0
MR19 0

MR23

MR24

*10K

*10K

GND

MC38

0.1U_0402

GND

MC40

0.1U_0402

MR26
249K_(1%)

MR25 33

MR28 *0
MR27 *0

BEEP

RC_OSC

MR33

*0

MU3

1

RCOSC1

3

DIB_DATAN

4

DIB_DATAP

7

PWRCLKP

8

PWRCLKN

15

SDATA_OUT

16

SYNC

17

AC_RESET#

20

AC_ONLY

21

SDATA_IN0

22

BIT_CLK

11

ID0#

12

ID1#

<Conexant Name>

14

EAPD

45

PC_BEEP

13

DSPKOUT

5

VDD5

GND

GNDC2

2

6

18

VDDC18

GND8

GNDC9

9

10

VDDC10

GNDC19

AVSS_CLK

19

26

23

VDD_CLK

LINE_OUT_R

MBIAS/AVDD

AGND35

35

AGND

33

AVDD33

MIC_IN

CD_IN_R

CD_IN_GND

CD_IN_L

LINE_IN_L

LINE_IN_R

LINE_OUT_L

HP_OUT_L

HP_OUT_R

REF_FLT

VC_SCA

VREF_SCA

S_PDIF
GPIO_4
GPIO_5

XTLO

XTLI

AGND41

20468-31

41

44

AVDD44

29
32

31
30

27
28

39
40
42
43

38
37
36

34
46
47
48
24

25

MC27

0.1U_0402

B TEST
Modified

MC24 10U

MIC

AC97OUT_L
AC97OUT_R

MIC_BIAS

MR31 0
MR32 0

R365
*10K

MC251000P_0402
MC261000P_0402

REF_FLT
VC_SCA
VREF_SCA

MR22 33
MR21 *1M

R366
*10K

GND

MC35
1U/10V

1 2

MIC1
RCDR

CDGND1
RCDL

MIC_BIAS 21

MY2

24.576MHZ

1 2

MC29
33P

+3.3VA+3VSUS

MC37
10U

AGND

HPSENSE_PR 24
HPSENSE 21

MC30
33P

GND

MIC1 21

AGND

AC97OUT_L 21
AC97OUT_R 21

PC BEEP CONTROL

For Layout:

Place crystal and associated

Ground Tie

MR2 0

MR30 *0

MR29 *0

MR8 0

B TEST Modified

C TEST modified ESD

MR9 *0

circuitry very near
SmartAMC Device.

PCMSPK#28

PCSPK15

NORMAL : LOW

+5V

SOFTWARE EQ CONTROL TABLE

U39

3

C294

0.47U_0402

IN

OUT

ADJ

GMT_G960T63U

1

R200 *124

R199
0

1 2

AGND

GPIO4 GOIO5 S/W EQ
LOW LOW ON
LOW HIGH OFF
HIGH LOW OFF
HIGH HIGH OFF

MC28

0.1U_0402

1
2

AGND

+3.3VA

53

MC31

0.1U_0402

4

U38
7SH86

C293

0.1U_0402

C292 0.47U_0402

MC33

0.1U_0402

1 2

AGND

MC34
1U/10V

BEEP

2

800mA (30MIL)

12

+3.3VA

AGND

C295

0.1U_0402

GND

AGND

A

SGND

RCDR

C291 10U

RCDL

C289 10U

CDGND1

C290 10U

R193

4.7K

AGND

B

C

R191

4.7K

R196 4.7K
R192 4.7K
R194 4.7K

R195

4.7K

CDAUDR 18
CDAUDL 18
CDGND 18

Size Document Number Rev

SMARTAMC-CONEXANT_20468-31

D

Date: Sheet

PROJECT : EF6

Quanta Computer Inc.

of

E

19 37Monday, January 03, 2005

1A

A

B

C

D

E

SMARTDAA_20493-21 20

1

Vc

3

Vc_LSD

MC944

0.1uF

AGND_LSD

Vdd

MU902

MTP62

1

MC978 0.1uF

MTP59

24

DVdd

1

DGND_LSD

21

RAC1

20

TAC1

19

RAC2

18

TAC2

12

TRDC

11

EIC

9

RXI

1

GPIO1

5

RBias

10

VZ

17

EIO

16

EIF

14

TXO

13

TXF

15

DC_GND

23

DGnd

VRef

4

MTP63

Vref_LSD

1

MC940

MC976
.001uF

1uF

C940 is X5R ceramic.

RAC1

TAC1

TRDC

EIC

RXI

RBias

VZ

EIO

EIF

TXO

TXF

DGND_LSD

1
1

MR902 1M

MR904 1M

1

MTP34

1

MTP33

MC958 15nF

MTP70

1

MR910
237K

R910 must be placed
near pin 9 (RXI).

MR954

1

MTP69

59.0K

AGND_LSD

MTP36
MTP35

AGND_LSD

AGND_LSD

1

RAC1/RING

TAC1/TIP

MR906 6.8M

MC918

0.1uF

RXI-1

MTP68

MR908
348K

R908 must be placed
near pin 10 (VZ).

1

MTP65

1

MTP37

1

MTP38

MC902 0.033uF/100V

MC904 0.033uF/100V

1

MTP40

1

MTP71

MC910

0.047uF/100V

1

MTP67

1

MTP39

RING_2

MBR904
MMBD3004S

A

C AC

A

CAC

AGND_LSD

MBR906
MMBD3004S

TIP_2

MC966

0.01U

AGND_LSD

C test modofoed
(change part number )

1

MTP32

BRIDGE_CC

MQ902
MMBTA42

1

MTP31

MQ906
MMBTA42

1

MTP64

MR938
110

AGND_LSD

REV:B MODIFY

DEL L9 / L10 / RV1 / C458

MQ904
SB29003

MR928
27

AGND_LSD

MFB902

MMZ1608D301B

MFB904

MMZ1608D301B

MTP66

1

1

MTP49

MC906
*470pF

GND

MC908
*470pF

C906 and C908 must be Y3 type
Capacitors for Nordic
Countries only

RING_1

MRV902 KU10S31N

TIP_1

1

MJ2

1
2

FI-S2P-HF(JAE)

1

MTP41

MTP42

Revision History

Description

REV

00

Initial Release

01

27mmx27mm form factor.

6 pins J1 connector-T/R traces for specific uses-100V C902/C904

02

03

add J1B - remove T903

Change J1 & J1B. Change R938 size. Add TP60 to TP71.

04

Removed J1B. Change size for C978, C984, R902, R904, R906, R908,

05

R910 and R978. Changed BR904 and BR906 to different manufacture.

06

Corrected error in Q904 PCB footprint.

Added DIB data transformer footprint, added MC966, deleted ring

07

impedance circuit. Added the letter "M" prefix to all reference
designators.

Changed value for MC966 from 3.3nF to 10nF, 100V, +/-20%, Y5V. By

08

default, MC966 will be populated. Also, changed CX20493 revision from
11 to 21.

MTP52

MTP26

PWRCLKN19

MTP22

1 1

PWRCLKP19

MJ1

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

*HEADER8

MJ3

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

(omit)

*HEADER8

1

GND

PWRCLKN

PWRCLKP

MTP23

MTP24

MTP25

1

1

1

MT902

BR908_AC1

1 4

2 3

MID82154

MC962
47pF

PCLK

DIB_DATAP19

DIB_DATAP

DIB_DATAN19

Depending of the design target and DIB length,
DIB components can be:

-C922/C924 10pF

-C922/C924 47pF (Validation in progress)

C922, C924, C906, and C908, must be Y3 type Capacitors in order
to comply with Nordic Countries deviations of IEC60950 2nd and 3rd ed.
Y3 type capacitors must also be certified for a 2.5KV impulse test.
This must be checked in vendors' specifications (see AVL).

Circuit traces for C922 and C924 should be less
than 2 inches.

1

1

MTP27

Date

February 14, 2002

July 5, 2002

September 24, 2002

October 9, 2002

November 12, 2002

November 26, 2002

January 3, 2003

September 24, 2003

November 06, 2003

C1

1

DIB_DATAN

REV:B MODIFY FOR USE
NEW MODEM MODULE

MTP28

MTP29

MR932
15K

BR908_CC

AC1

A1
A2C2

-+

AC2

MBR908
BAV99DW

MC922 10pF

MC924 10pF

1 4

2 3

*MID82157(omit)

MT922

C970 must be
placed near pins 7
(PWR+) and 6
(AGnd).

MTP72

1

DIB_P1

DIB_N1

1

1

CLK2

MFB906

MMZ1608D301B

MC970

0.1uF

C928, C930 must be
placed near pins 2
(AVdd) and 6
(AGnd).

MR922 0

MR924 0

MTP73

1

AGND_LSD

C926 must be placed
near pin 26 (CLK).

MC926 10pF

1

MTP30

MC930

2.2uF

AGND_LSD

MTP60

1

DIB_P2

DIB_N2

MTP61

1

C944, C974, and C976
must be placed near
pins 3 (Vc) and 4
(VRef).

CLK

PWR+

Vdd

MC928

0.1uF

*0.001uF(omit)

8
22
25

29

26

7

2

6

27

28

MC974

MTP58

NC1
NC2
NC3

PADDLE

CLK

PWR+

AVdd

AGnd

DIB_P

DIB_N

20496-21

PROJECT : EF6

Size Document Number Rev

A

B

C

D

Date: Sheet

Quanta Computer Inc.

SMARTAMC-DAA_20493-21

E

20 37Monday, January 03, 2005

1ACustom

of

5

AUDIO
AMPLIFIER-GMT_1428

4

3

+5V 12,13,16,18,19,22,23,24,25,30,33,36

2

1

21

To Port-Replicator

U36

D D

+5V

L44

+5V_AUG

C284
10U

AGND

AOUT_R
HPINR

HPINL
AOUT_L

+5V_AUG

AGND
AGND

AGND

C269
10U

C272 .47U/10V
C273 .47U/10V

C274 4.7U/10V
R177 *1K

R175 *1K

R178 10K
R176 10K

AGND

12

C282
.1U

+5V_AUG

12

12

C275

C283

.1U

.1U

U34

19

VDD

7

PVDD1

18

PVDD2

23

RLINEIN

20 14

RHPIN PC-BEEP

8

RIN+

6

LHPIN

5

LLINEIN

11

BYPASS

2

GAIN0

3

GAIN1

ROUT+

ROUT-

LOUT+

LOUT-

SE/BTL

HP/LINELIN+

SHUTDOWN

GND4
GND3
GND2
GND1
GND5
GND6
GND7
GND8

GND9
GND10
GND11
GND12
GND13

21
16

4
9

15
1710

22
1

24
13
12
25
26
27
28
29
30
31
32
33

R_SPK+
R_SPK-

L_SPK+
L_SPK-

A_BEEP

AMP_SHDN#

AGND

T49
*PAD

GMT1428/TPA0212

R183
100K

AMP_SHDN#

VOLMUTE#22

21

D23 CH500H-40

Mic in

CN23

1

HPOUT_L
HPOUT_R
HPSENSE

12

12

C276

C277
180P

12

C278
.1U

AGND

AGND AGND

180P

AGND

2
6
3
4
5

HP-JACK-GREEN

7

8

MIC119

R187
15K

C280 .047U
C281 .47U/10V

C271 .47U/10V
C270 .047U

R174
15K

AGND

HI0805R800R-00(5A)

change from

0.47U to

4.7U B satge
modified

AGND

AC97OUT_R19

AC97OUT_L19

C C

R186 1K

R173 1K

Gain Table

Gain0 Gain1 Av

0

0

2 times

1

0
1
1

6 times

0

12 times

1

24 times

Headphone out

B B

INL_SPK+
INR_SPK+

C267
100U/6.3V

+

1 2

+

1 2

C266
100U/6.3V

INL_SPK+_1
INR_SPK+_1

R182
1K

L38
L37

R181
1K

AGND

LZA10-2ACB104MT
LZA10-2ACB104MT

R_SPK+
L_SPK+

R179 10K

+5V_AUG

12

C279
.1U

AGND

4

INT. SPEAKER

R_SPK+

L52 LZA10-2ACB104MT

R_SPK-

L53 LZA10-2ACB104MT
L54 LZA10-2ACB104MT

L_SPK-

L55 LZA10-2ACB104MT

+5V

5

2
1

3

AGND AGND

R172 0

stereo MIC
can not
recording
VER : B
modified

12

16

U35

7SH32

4
7
9

8

1 2

YA
YB
YC
YD

VCC
GND

74CBT3257

C285
.1U

HPSENSE

R185
20K

R_SPK+_1
R_SPK-_1
L_SPK+_1L_SPK+
L_SPK-_1

MIC_BIAS19

12

C268
*180P

IA0
IA1
IB0
IB1
IC0
IC1
ID0
ID1

SEL

/E

INR_SPK+

2
3

INL_SPK+

5
6
11
10
14
13
1
15

R180
10K

R184 1K

HPSENSE 19
HPSENSE_PR 24

MIC_BIAS

T48
*PAD

AGND

+3V

CN12

4
3
2
1

R-L-SPEAKERS

MR20

3K

SPK_R_PR 24
SPK_L_PR 24

HPSENSE_PR 24

CN22

1
2
6
3
4
5

MIC-JACK-PINK

7

8

AGNDAGND

A A

Size Document Number Rev
Custom

5

4

3

2

Date: Sheet of

PROJECT : EF6

Quanta Computer Inc.

AUDIO AMP & JACK

1

21 37Monday, January 03, 2005

1A

5

KBC-NS97551L

D D

3VPCU

R228
470K

KBSMI#15

C324

0.1U

C C

+5V+5V

642

PWROK15

+3V

R225

R229

10K

10K

R264 20M

R270 120K

LAN_POWER36

DNBSWON#15

R221 1K

RN3
10KX4

135

591_32KX3

591_32KX3

C349

5.6P

7 8

MSCLK24

MSDATA24

KPCLK24

KPDATA24

TPCLK23

TPDATA23

CAPSLED23

B B

A A

NUMLED23

Y6

1 4

32.768KHZ

C344
20P

VOLMUTE#21

RSMRST#15

KBSMI#

HWPG31,32,33,35

SUSC#15

SWI#15

S5_ON31,36
SUSON32,36
MAINON32,34,36

VRON31,35,36

LFRAME#/FWH414,30

LAD0/FWH014,30
LAD1/FWH114,30
LAD2/FWH214,30
LAD3/FWH314,30

PCLK_5912

GATEA2014

D30 CH500H-40

R222 *0

SERIRQ14,15,28,30

2 1

D31 CH500H-40

SCI#15

RCIN#14

MY023
MY123
MY223
MY323
MY423
MY523
MY623
MY723
MY823

MY923
MY1023
MY1123
MY1223
MY1323
MY1423
MY1523

T34
T61
T37
T35

2 1

C test modified

5

T63

MX023
MX123
MX223
MX323
MX423
MX523
MX623
MX723

T53

T31

D26

2 1

T45

CH500H-40

T71
T52

SERIRQ

LFRAME#/FWH4
LAD0/FWH0
LAD1/FWH1
LAD2/FWH2
LAD3/FWH3
PCLK_591
591RESET#
KBSMI#591

SCI#

GATEA20
RCIN#

MX0
MX1
MX2
MX3
MX4
MX5
MX6
MX7

MY0
MY1
MY2
MY3
MY4
MY5
MY6
MY7
MY8
MY9
MY10
MY11
MY12
MY13
MY14
MY15

591_32KX1
591_32KX2

2 1

D32 CH500H-40

SWI#2

D29

2 1

CH500H-40

TINT-

BAYSWAP
HWPG

EC_28
CS#

591SEL1#
591CLK

4

3VPCU

D28 *CH500H-40

163445

VDD

Host interface

Key matrix scan

JTAG debug port

PS2 interface

VCC1

VCC2

2 1

C343

0.1U

123

136

157

VCC3

VCC4

VCC5

PORT-E

EC-AVCC

95

166

VCC6

AVCC

AD Input

DA output

PWM or
PORT-A

PORT-B

PORT-C

PORT-D-1

IOPE6/LPCPD/EXWIN45

IOPE7/CLKRUN/EXWINT46

PORT-H

PORT-I

C311

0.1U

IOPA0/PWM0
IOPA1/PWM1
IOPA2/PWM2
IOPA3/PWM3
IOPA4/PWM4
IOPA5/PWM5
IOPA6/PWM6
IOPA7/PWM7

IOPB0/URXD
IOPB1/UTXD

IOPB2/USCLK

IOPB3/SCL1
IOPB4/SDA1

IOPB7/RING/PFAIL

IOPC1/SCL2

IOPC2/SDA2
IOPC4/TB1/EXWINT22
IOPC6/TB2/EXWINT23

IOPC7/CLKOUT

IOPD0/RI1/EXWINT20
IOPD1/RI2/EXWINT21

IOPD2/EXWINT24

IOPE4/SWIN

IOPE5/EXWINT40

IOPH0/A0/ENV0

IOPH1/A1/ENV1
IOPH2/A2/BADDR0
IOPH3/A3/BADDR1

IOPH4/A4/TRIS

IOPH5/A5/SHBM

+3V

C326

0.1U

U41

7

SERIRQ

8

LDRQ

9

LFRAME

15

LAD0

14

LAD1

13

LAD2

10

LAD3

18

LCLK

19

LREST

22

SMI

23

PWUREQ

31

IOPD3/ECSCI

5

GA20/IOPB5

6

KBRST/IOPB6

71

KBSIN0

72

KBSIN1

73

KBSIN2

74

KBSIN3

77

KBSIN4

78

KBSIN5

79

KBSIN6

80

KBSIN7

49

KBSOUT0

50

KBSOUT1

51

KBSOUT2

52

KBSOUT3

53

KBSOUT4

56

KBSOUT5

57

KBSOUT6

58

KBSOUT7

59

KBSOUT8

60

KBSOUT9

61

KBSOUT10

64

KBSOUT11

65

KBSOUT12

66

KBSOUT13

67

KBSOUT14

68

KBSOUT15

105

TINT

106

TCK

107

TDO

108

TDI

109

TMS

110

PSCLK1/IOPF0

111

PSDAT1/IOPF1

114

PSCLK2/IOPF2

115

PSDAT2/IOPF3

116

PSCLK3/IOPF4

117

PSDAT3/IOPF5

118

PSCLK4/IOPF6

119

PSDAT4/IOPF7

158

32KX1/32KCLKOUT

160

32KX2

PORT-J-1

62

IOPJ2/BST0

63

IOPJ3/BST1

69

IOPJ4/BST2

70

IOPJ5/PFS

75

IOPJ6/PLI

76 143

IOPJ7/BRKL_RSTO

148

IOPM0/D8

149

IOPM1/D9

155

IOPM2/D10

156

IOPM3/D11

3

IOPM4/D12

4

IOPM5/D13

27

IOPM6/D14

28

IOPM7/D15

173

SEL0

174

SEL1

47

CLK

4

PORT-M

GND1

GND2

173546

PORTJ-2

GND3

GND4

GND5

122

159

167

GND6

137

GND7

PORT-D-2

PORT-K

PORT-L

AGND

96

11

AGND_591

R217
10

IOPK5/A13/BE0
IOPK6/A14/BE1

IOPK7/A15/CBRD

NC2

NC3

NC4

NC5

NC6

NC1

122021858691929798

C319

1U/16V

R122 0

POP FOR 97551

161

VBAT

81

AD0

82

AD1

83

AD2

84

AD3

87

IOPE0AD4

88

IOPE1/AD5

89

IOPE2/AD6

90

IOPE3/AD7

93

DP/AD8

94

DN/AD9

99

DA0

100

DA1

101

DA2

102

DA3

32
33
36
37
38
39
40
43

153
154
162
163
164
165

168

IOPC0

169
170
171

IOPC3/TA1

172
175

IOPC5/TA2

176
1

26
29
30

2
44
24
25

124
125
126
127
128
131
132

IOPH6/A6

133

IOPH7/A7

138

IOPI0/D0

139

IOPI1/D1

140

IOPI2/D2

141

IOPI3/D3

144

IOPI4/D4

145

IOPI5/D5

146

IOPI6/D6

147

IOPI7/D7

150

IOPJ0/RD

151

IOPJ1/WR0

152

SELIO

41

IOPD4

42

IOPD5

54

IOPD6

55

IOPD7

IOPK0/A8

142

IOPK1/A9

135

IOPK2/A10

134

IOPK3/A11

130

IOPK4/A12

129
121
120

113

IOPL0/A16

112

IOPL1/A17

104

IOPL2/A18

103

IOPL3/A19

48

IOPL4/WR1

NC7

NC8

NC9

NC10

PC97551VPC

3

3

R218 0
R219 0

NBSWON#
PR_INSERT1#

CLKRUN#

EC-AVCC

C309

2.2U

TEMP_MBAT
MBATV

ABATV

ID0

ID1
ID2
KBC_NC02
KBC_TP_11
KBC_TP_12

200HZ-LED

PCICGRST#

MBATLED1
MBATLED0
PWR_LED
MBCLK
MBDATA
PCIRST#

R119 *10K

BATLOW#

FANSIG_1
RF_OFF#
LPCPD#

R266 *0

6648_ALERT#
SUSB#

ACIN
MXLID#

2 1

D27 RB500

ENV0
ENV1
BADDR0
BADDR1
TRIS
SHBM
A6
A7

D0
D1
D2
D3
D4
D5
D6
D7

RD#
WR#

SELIO#

T30

CELL_ SLT
D/C#
BL/C#

A8
A9
A10
A11
A12
A13
A14
A15

A16
A17
A18
A19

T33

WR1#

T51

U40

GND

4

BYP

AAT3218

C314

0.01U

CC-SET
VADJ

ADREF

VFAN_1

SCROLED 23
CELL_SLT 34
D/C# 34
BL/C# 34

Pin 103 internal is
"A19",Can't use to
GPIO

5VPCU

15

INOUT

2
3

EN

TEMP_MBAT 34

MBATV 34

T41
T54

T56
T42
T40

CC-SET 34

T36

VADJ 13

T38
T32

VFAN_1 23

T39
T43

PCICGRST# 28

T46

MBATLED1 23
MBATLED0 23
PWR_LED 23
MBCLK 34
MBDATA 34
PCIRST# 14,25,28

BATLOW# 15
THCLK_SMB 3
THDAT_SMB 3

T68

FANSIG_1 23
RF_OFF# 25
SUS_STAT# 15,30
6648_ALERT# 3

SUSB# 15
ACIN 34
MXLID# 13

PR_INSERT# 26
S5LAN_PME# 26
CLKRUN# 14,25,26,28,30

CS#
RD#
WR#

2

3VPCU

C308

0.1U

C342

0.1U

C313

C315
1U/16V

0.1U

Should have a 0.1uF capacitor close to every
GND-VCC pair + one larger cap on the
supply.

B TEST Modified

R367 *10K
R368 10K
R371 *10K

R372

R369

10K

ID1 (pin88) ID0 (pin87)
0 (PATA HDD)(R370) 0 (PCMCIA)(R369)
0 (PATA HDD)(R370 1( new card >PCI express) (R367)
1 (SATA HDD)(R368) 0 (PCMCIA) (R369)
1 (SATA HDD)(R368) 1( new card > PCI express)(R367)

ID2 --- 0 EF6

--- 1 LW1

U18

12

A0

11

A1

10

A2

9

A3

8

A4

7

A5

6

A6

5

A7

27

A8

26

A9

23

A10

25

A11

4

A12

28

A13

29

A14

3

A15

2

A16

30

A17

22

CE#

24

OE#

31

WE#

PLCC32

R370

10K

*10K

13

D0

14

D1

15

D2

17

D3

18

D4

19

D5

20

D6

21

D7

1

VPP

32

VCC

16

GND

2

3VPCU

D0
D1
D2
D3
D4
D5
D6
D7

A18

3VPCU

C169

0.1U

ENV1

C327

0.1U

BADDR0

BADDR1

TINT-

SHBM

SHBM=1: Enable shared memory with host BIOS

BADDR1-0 Index Data

010
0
1110

HWPG

PR_INSERT1#

FOR EC debug ...
layout ..place to close
K/B connector

NBSWON#

Size Document Number Rev
Custom

Date: Sheet

4E 4F

(HCFGBAH, HCFGBAL) (HCFGBAH, HCFGBAL)+1

LPCPD#
6648_ALERT#

MBATLED1
MBATLED0

3VPCU

R169

10K

SW2

C262

0.1U

KBC-PC97551VPC

1

R248 10K

R250 10K

R251 *10K

R220 10K

R258 10K

I/O Address

Reserved

MBCLK
MBDATA

R211 10K

R216 10K

R143 *10K
R141 *10K

3VPCU

R121 10K
R120 10K

R267 10K
R257 *10K

3VPCU

22

2F2E

3VPCU

3VPCU

+3V

+3V

POWER SWITCH

2

Quanta Computer Inc.

1
34
5

PROJECT : EF6

1

of

22 37Monday, January 03, 2005

1A

A

1st FAN OUT CONNECTOR

+5V

U43

C513
1000P

1

VEN

2

VIN

3

VO

4 5

SET GND

G993P1U

4 4

VFAN_122

3 3

R359

180K

+5V_FAN

12

GND
GND
GND

8
7
6

FANSIG_122

B

C TEST modified EMI

C307

1U

+5V_FAN

C50922U

2

Q27
PDTA124EU

12

+3V

13

C544
.1U/50V/X7R

R355
100K

C

LED

D11 LED_BLUE

CN8

1
234

5

FAN

12

C512
1000P

WL_LED#37

ODDLED#18

HDDLED#18

SATA_LED#14

D10 LED_BLUE

D9 LED_BLUE

R35

0

For PATA/SATA option

SCROLED22

R71 330

R52 330

R41 *330

R40 220

D

SCROLED

NUMLED22

+5V

1 3

1 3

CAPSLED22

MBATLED022

+3V

MBATLED122

PWR_LED22

1 3

2

DTC144EUA
Q15

Q14
DTC144EUA

2

2

1 3
1 3

2

1 3

2

2

DTC144EUA

Q16

DTC144EUA
Q6

Q5
DTC144EUA

Q7
DTC144EUA

E

D22 LED_BLUE

D21 LED_BLUE

D20 LED_BLUE

D3

LED-RED/GREEN

D6 LED_BLUE

23

+5V

R167 330

R165 330

R164 330

5VPCU

R22 330
R20 330

R33 330

KEYBOARD

CN14

2 2

KEYBOARD CONNECTOR

1 1

C TEST modified

MX1

1

A

MY12
MY13
MY14
MY15

10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25

1
2
3
4
5
6
7
8
9

10

9
8
7 4

2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25

RP39

10KX8

MX7
MX6
MY9
MX4
MX5
MY0
MX2
MX3
MY5
MY1
MX0
MY2
MY4
MY7
MY8
MY6
MY3
MY12
MY13
MY14
MY11
MY10
MY15

1
2
3

56

MY11
MY10
MY9
MY8

MX1 22
MX7 22
MX6 22
MY9 22
MX4 22
MX5 22
MY0 22
MX2 22
MX3 22
MY5 22
MY1 22
MX0 22
MY2 22
MY4 22
MY7 22
MY8 22
MY6 22
MY3 22
MY12 22
MY13 22
MY14 22
MY11 22
MY10 22
MY15 22

3VPCU3VPCU

RP38

10

MY4 MY2

9

MY5

8

MY6

7 4

MY7

3VPCU 3VPCU

10KX8

MY3

1
2

MY1

3

MY0

56

CP7 220PX4

1
3
5
7 8

CP6 220PX4

1
3
5
7 8

CP5 220PX4

1
3
5
7 8

CP4 220PX4

1
3
5
7 8

CP3 220PX4

1
3
5
7 8

CP2 220PX4

1
3
5
7 8

B

MY15

2

MY10

4

MY11

6

MY14

MY13

2

MY12

4

MY3

6

MY6

MY8

2

MY7

4

MY4

6

MY2

MX0

2

MY1

4

MY5

6

MX3

MX2

2

MY0

4

MX5

6

MX4

MY9

2

MX6

4

MX7

6

MX1

TOUCHPAD

C

12 MIL

+5V

TPDATA22

TPCLK22

L68 FCM1608K221
L67 FCM1608K221

L6

HI0805Q310R

C486
*10P

C483
*10P

5VTP

C84 0.1U

TPDATA-1
TPCLK-1

CN11

1
2
3
4

TOUCH_PAD_4P

C TEST modified

Size Document Number Rev
Custom

D

Date: Sheet

PROJECT : EF6

Quanta Computer Inc.

K/B & FAN & LED & SW

23 37Monday, January 03, 2005

E

1A

of

5

4

3

2

1

PORT REPLICATOR 24

PD[0..7]

PD[0..7] 30

VAD

D D

H6
EMIPAD

1

H2
EMIPAD

1

H20
EMIPAD

1

CPU

H10
EMIPAD

1

H22
EMIPAD

1

H18
EMIPAD

1

H21
EMIPAD

1

SGND

H5
EMIPAD

1

H7
EMIPAD

1

H4
EMIPAD

1

H3
EMIPAD

1

H11
EMIPAD

1

COM PORT

-MDSR130
BRI#30
INIT#30

PR_INSERT#26

PRT PORT

PR_BLU12
PR_GRN12
PR_RED12

PR_VSYNC12

PR_HSYNC12

HPSENSE_PR19,21 KPDATA 22

DDCCLK212
DDCDAT212

LAN_ACT_LED#26,27
LAN_LINK_LED#26,27

USBP2+15
USBP2-15

USBP1+15
USBP1-15

C312

*330P_0402

PA12
EMIPAD

1

CRT PORT

AVDDL
LANVCC

HPSENSE_PR PR_INSERT#

C227

*330P_0402

H15
EMIPAD

1

H14
EMIPAD

1

PA3
EMIPAD

1

H16
EMIPAD

1

CPUCPUCPU

H13
EMIPAD

1

PA4
EMIPAD

1

H8
EMIPAD

1

C C

H9
EMIPAD

1

PA1
EMIPAD

1

B B

EMIPAD

1

PA5
EMIPAD

1

H17

H12

EMIPAD

EMIPAD

1

1

C TEST MODIFIED

PA7

PA6
EMIPAD

1

EMIPAD

1

PA8
EMIPAD

1

PA9
EMIPAD

PA10

PA11

EMIPAD

1

EMIPAD

1

1

H19

PD8

3

SBM1040

C test modofoed

DDCCLK2
DDCDAT2

LAN_ACT_LED#
LAN_LINK_LED#

USBP2+
USBP2-

USBP1+
USBP1-

VA_PR

1
2

+5V

PD0
PR_INSERT#
PD1
PD2

PD3
PD4
PD5
PD6

PD7

+5VSUS

CN16

102

FG2

100

100

99

99

98

98

97

97

96

96

95

95

94

94

93

93

92

92

91

91

90

90

89

89

88

88

87

87

86

86

85

85

84

84

83

83

82

82

81

81

80

80

79

79

78

78

77

77

76

76

75

75

74

74

73

73

72

72

71

71

70

70

69

69

68

68

67

67

66

66

65

65

64

64

63

63

62

62

61

61

60

60

59

59

58

58

57

57

56

56

52

52

101

FG1

FCI_52456

DOCK-10007221-001-100P-H-EF6

50

50

49

49

48

48

47

47

46

46

45

45

44

44

43

43

42

42

41

41

40

40

39

39

38

38

37

37

36

36

35

35

34

34

33

33

32

32

31

31

30

30

29

29

28

28

27

27

26

26

25

25

24

24

23

23

22

22

21

21

20

20

19

19

18

18

17

17

16

16

15

15

14

14

13

13

12

12

11

11

10

10

9

9

8

8

7

7

6

6

2

2

VA_PR

AGND

L50 NBQ160808T-700Y-S
L49 NBQ160808T-700Y-S

+5VSUS

PR_INSERT#

-MCTS1 30

-MDCD1 30
MRXD1 30
M_TXD1 30
AFD# 30

-MDTR1 30
ERROR# 30

-MRTS1 30
SLIN# 30
SLCT 30
STRB# 30
PE 30

ACK# 30
BUSY 30
MSDATA 22
MSCLK 22

KPCLK 22

EXT_TX1N 26
EXT_TX1P 26
EXT_TX0P 26
EXT_TX0N 26

EXT_TX3N 26
EXT_TX3P 26

EXT_TX2N 26
EXT_TX2P 26

SPK_R_PR 21
SPK_L_PR 21

HEADPHONE

COM PORT

PRT PORT

PS/2 PORT
10/100M LAN

GIGA LAN

PR_VSYNC

C306

10P_0402

PR_HSYNC

C305

10P_0402

C TEST modified EMI

C318
1000P_0402

PA13

PA14

PA15

PA16

A A

EMIPAD

1

EMIPAD

1

5

EMIPAD

1

EMIPAD

1

PA17
EMIPAD

1

4

DDCCLK2

VA_PR

C317
100P_0402

C304

10P_0402

DDCDAT2

C303

10P_0402

LAN_LINK_LED#

C302

*10P_0402

3

+5V

12

C204

4.7U/10V

Size Document Number Rev
Custom

2

Date: Sheet

PORT REPLICATOR

C203
.1U_0402

C310
1000P_0402

PROJECT : EF6

Quanta Computer Inc.

of

24 37Monday, January 03, 2005

1

1A

1

2

3

4

5

6

7

8

+5V 12,13,16,18,19,21,22,23,24,30,33,36
+3V 2,3,8,10,12,13,14,15,16,18,21,22,23,26,30,33,35,36,37

A A

TYPE III MINI PCI SOCKET

+3V

R135

21

T58

PIRQC#

PCLK_MINI

REQ1#
AD31

AD29
AD27

AD25
C/BE3#

AD23
AD21

AD19
AD17

C/BE2#
IRDY#

SERR#
PERR#

C/BE1#
AD14

AD12
AD10

AD8
AD7

AD5
AD3
AD1

10K

D16 CH500H-40

PIRQC#14,28

PCLK_MINI2

REQ1#14

C/BE3#14,26,28

C/BE2#14,26,28

IRDY#14,28

CLKRUN#14,22,26,28,30

SERR#14,26,28

PERR#14,28

C/BE1#14,26,28

+5V

+5V

RF_LINK_0

RF_OFF#22

B B

C C

FOR 80 PORT USED
VER: B modified

RF_OFF#

WLAN_ACTIVE37

AD[0..31]

CN26

MINI-PCI

AC_SDATA_OUTAC_SDATA_IN

AC_CODEC_ID0#AC_BIT_CLK

SYS_AUDIO_IN GNDSYS_AUDIO_OUT GND

AD[0..31] 14,26,28

RINGTIP

8PMJ-18PMJ-3
8PMJ-28PMJ-6
8PMJ-48PMJ-7
8PMJ-58PMJ-8

LED2_YELPLED1_GRNP

LED2_YELNLED1_GRNN

RESERVEDCHSGND

INTA#3.3V

RESERVEDRESERVED

3.3VAUXGROUND
RST#CLK

GNT#REQ#

GROUND3.3V

PME#AD31

RESERVEDAD29

AD30GROUND
AD28AD25

AD26RESERVED
AD24C/BE3#

IDSELAD23

GROUNDGROUND

AD22AD21
AD20AD19

AD18AD17
AD16C/BE2#

GROUNDIRDY#

FRAME#3.3V

TRDY#CLKRUN#
STOP#SERR#

DEVSEL#PERR#
GROUNDC/BE1#

AD15AD14
AD13GROUND
AD11AD12

GROUNDAD10

C/BE0#AD8

RESERVED5V
RESERVEDAD1

GROUNDGROUND

M66ENAC_SYNC

AC_RESET#AC_CODEC_ID1#

RESERVEDMOD_AUDIO_MON

GROUNDAUDIO_GND

SYS_AUDIO_INSYS_AUDIO_OUT

AUDIO_GNDAUDIO_GND

MCPIACT#RESERVED

3.3VAUXVCC5A

+3V

21

C TEST modified

43
65
87
109
1211
1413
1615
1817

5VINTB#

2019
2221
2423
2625
2827

3.3VGROUND

3029
3231
3433
3635
3837
4039

3.3VAD27

4241
4443
4645
4847
5049
5251
5453
5655

PARGROUND

5857
6059
6261
6463
6665
6867
7069

3.3VGROUND

7271
7473
7675
7877
8079
8281
8483

AD9GROUND

8685
8887

3.3VAD7

9089

AD63.3V

9291

AD4AD5

9493

AD2RESERVED

9695

AD0AD3

9897
10099
102101
104103
106105
108107
110109
112111
114113
116115
118117
120119
122121
124123

BROADCOM_LINK

PIRQB#

PCIRST#
GNT1#

AD30
AD28

AD26
AD24

AD22
AD20
PAR
AD18
AD16

FRAME#
TRDY#CLKRUN#
STOP#

DEVSEL#
AD15

AD13
AD11

AD9
C/BE0#

AD6
AD4
AD2
AD0

Z1701

R131 10K

T62

+3VSUS

MINIPCI_PME#

+3VSUS

+5V

PIRQB# 14,28

PCIRST# 22,26
GNT1# 14

BT_AVTIVE 37

R130 33

PAR 14,26,28

FRAME# 14,26,28

TRDY# 14,26,28

STOP# 14,26,28

DEVSEL# 14,26,28

C/BE0# 14,26,28

FOR 80 PORT USED
VER : B modified

AD20

RF_LINK37

+5V

U46

4

7SZ32

R373 *0

5

2

BROADCOM_LINK

1

C519

1 2

R374
1M

C TEST modified

+5V

C190

.1U

U19

7SH08

4

R134 *0

1 2

5

2
1

.1U

RF_OFF#
RF_LINK_0

R132
1M

25

change value
and footprint
100K 0402 to
1M 0603

+3V +3V

R129

+3V

D D

1

C183

0.1U

C182

C195

C184

*0.1U

*0.1U

2

*0.1U

C187
*10U

3

+3VSUS

C186

0.1U

C194
*0.1U

C185
*0.1U

4

5

10K

2

ICH_PME#MINIPCI_PME#

1

Q10
CH2507S

6

3

Size Document Number Rev
Custom

Date: Sheet

ICH_PME# 14,26,28

PROJECT : EF6

Quanta Computer Inc.

MINI PCI Socket & MDC

7

25 37Monday, January 03, 2005

8

2A

of

5

LAN SWITCH

FUNCTION(COM)

SEL
LOW IN_ B1
HIGH

D D

For 8110SB

AVDDH

R223 0

C1800.1U

CTRL25

CTRL18

C1910.1U

VDD33

AVDDL

DVDD

AVDD25

AVDDH

Pin 127

C1930.1U

32

Q9

1

2SB1188

AVDDL

LANVCC

R224

R238

*0

0

32

Q21
2SB1188

1

C1980.1U

C1760.1U

C1750.1U

AVDDH

V_12P

R126
0

C1770.1U

RTL8100C(L) _10/100M

3.3VD
26,41,56,71,84,94,107

3.3VA
3,7,16,20

2.5VD
32,54,78,99

2.5VA
12

NC

5.6k (1%) pull-low

C2160.1U

C C

B B

A A

LANVCC on/off will control by EC.

L56

*PBY201209T-300Y-S

LANVCC

Q24

13

*2SB1197K

R249
*0

RTL8110SB(L) _ 1G

3.3VD
26,41,56,71,84,94,107

2.5VA
3,7,16,20

1.2VD
24,32,45,54,64,78,99,110,116,126

3.3VA
12

3.3VA
10,120

2.49k (1%) pull-low

5

12

C1780.1U

CTRL25

2

C2080.1U

C31622U

12

For 8100CL

C20222U

C1790.1U

IN_B2

C2420.1U

C2130.1U

B STAGE
MODIFIED

PR_INSERT#12,22,24

C2170.1U

C1880.1U

C17110U

C1730.1U

C1740.1U

C1990.1U

AVDDL

C1970.1U

LANVCC

C2140.1U

C172*10U

DVDD

D19

C2150.1U

C2000.1U

TX3N
TX3P

TX2N
TX2P

TX1N
TX1P

TX0N
TX0P

21

CH500H-40

R159 10K

LANVCC

C2430.1U

C2370.1U

4

C236

0.1U

LANVCC

C241

0.1U

2

A0

8

A2

15

A4

23

A7

24 25

SEL 7B2

U26

PI3L301

LAN_ON36

4

LAN_ON

ICH_PME#14,25,28

S5LAN_PME#22

1

67

VDD

VDDGND

PI3L301

GNDA1GND

345

VDD

GNDA3GND

910111213

3VPCU

36

VDD

VDD

GND

578

3 6

40

43

46

GND

GND

GNDA5GND

GNDA6GND

16171819202122

PQ39
AO4414

241

2 1

D15
CH500H-40

3

33

37

48

0B1

GND

GND

GND

47

1B1

42

2B1

41

3B1

35

4B1

34

5B1

29

6B1

28

7B1

45

0B2

44

1B2

39

2B2

38

3B2

32

4B2

31

5B2

26

6B2

NC

GND

GND

TSSOP48-8_1-5

14

27

30

SWITCH

INT_TX3N
INT_TX3P

INT_TX2N
INT_TX2P

INT_TX1N
INT_TX1P

INT_TX0N
INT_TX0P

50mils

LANVCC

LANVCC

12

PC78
.1U/16V/X7R

LANVCC

R127
10K

LAN_PME#

C320

0.01U

R230

R231

49.9/F

49.9/F

R237

R236

49.9/F

49.9/F

C323

0.01U

EXT_TX3N 24
EXT_TX3P 24

EXT_TX2N 24
EXT_TX2P 24

EXT_TX1N 24
EXT_TX1P 24

EXT_TX0N 24
EXT_TX0P 24

INT_TX3N 27
INT_TX3P 27

INT_TX2N 27
INT_TX2P 27

INT_TX1N 27
INT_TX1P 27

INT_TX0N 27
INT_TX0P 27

R12315K

C321

0.01U

R233

R232

49.9/F

49.9/F

R234

R235

49.9/F

49.9/F

C322

0.01U

3

AD[31..0]14,25,28

C/BE0#14,25,28
C/BE1#14,25,28
C/BE2#14,25,28
C/BE3#14,25,28

PIRQD#14
PCIRST#14,25,28

PCLK_LAN2

GNT2#14
REQ2#14

AD16

FRAME#14,25,28
IRDY#14,28
TRDY#14,25,28
DEVSEL#14,25,28
STOP#14,25,28

R124
1K

TX1N
TX1P
TX0N
TX0P

TX3P
TX3N
TX2N
TX2P

PERR#14,28
SERR#14,25,28
PAR14,25,28

R128 2.49K

+3V

LAN_PME#

TX0P
TX0N

TX1P
TX1N

TX2P
TX2N

TX3P
TX3N

AD0
AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
AD9
AD10
AD11
AD12
AD13
AD14
AD15
AD16
AD17
AD18
AD19
AD20
AD21
AD22
AD23
AD24
AD25
AD26
AD27
AD28
AD29
AD30
AD31

R133 100

ISOLATEB

T57

2

LANVCC

R138

U20

104

AD0

103

AD1

102

AD2

98

AD3

97

AD4

96

AD5

95

AD6

93

AD7

90

AD8

89

AD9

87

AD10

86

AD11

85

AD12

83

AD13

82

AD14

79

AD15

59

AD16

58

AD17

57

AD18

55

AD19

53

AD20

50

AD21

49

AD22

47

AD23

43

AD24

42

AD25

40

AD26

39

AD27

37

AD28

36

AD29

34

AD30

33

AD31

92

CBE0B

77

CBE1B

60

CBE2B

44

CBE3B

25

INTAB

27

RSTB

28

CLK

29

GNTB

30

REQB

46

IDSEL

61

FRAMEB

63

IRDYB

67

TRDYB

68

DEVSELB

69

STOPB

70

PERRB

75

SERRB

76

PAR

31

PMEB

23

ISOLATEB

105

LWAKE

RSET CTRL25

127

RSET

1

MDI0+

2

MDI0-

5

MDI1+

6

MDI1-

14

MDI2+

15

MDI2-

18

MDI3+

19

MDI3-

2

RTL8110S(B)/8100C

EECS
EESK

EEDO

VDD33
VDD33
VDD33
VDD33
VDD33
VDD33
VDD33

VDD18
VDD18
VDD18
VDD18
VDD18
VDD18
VDD18
VDD18
VDD18

VDD18

AVDDH
AVDDH

AVDDL
AVDDL
AVDDL
AVDDL

AVDD25

CTRL18

CTRL25

CLKRUNB

SMBCLK

SMBDATA

M66EN

XTAL1
XTAL2

3.6K

1 2

EECS

106

EESK

111

EEDI/AUX

109

EEDI

EEDO

108

26
41
56
71
84
94
107

24
32
45
54
64
78
99
110
116

126
10

120
3

7
16
20

12

21

GND

22

GND

35

GND

38

GND

48

GND

51

GND

52

GND

62

GND

66

GND

73

GND

80

GND

81

GND

91

GND

100

GND

101

GND

112

GND

118

GND

119

GND

123

GND

124

GND

4

VSS

9

VSS

17

VSS

13

VSS

128

VSS

CTRL18

125
8

R125 0

11

NC

R145 0

65
72
74

R144 15K

88

117

LED0

115

LED1

114

LED2

113

LED3

121
122

Size Document Number Rev
C

Date: Sheet

XTAL1

XTAL2

T60
T59

1

8bit/16bit

U22

1
2
3
4 5

CS
SK
DI
DO GND

8

VCC

7

NC

R146 *0

6

NC

AT93C46-10SC-2.7

LANVCC
DVDD

C189 0.1U

L70 NBQ160808T-700Y-S

AVDDH

AVDDL
V_12P

C196 20P

Y5

25.0000MHz

2 1

C192 20P

B STAGE
MODIFIED

CLKRUN# 14,22,25,28,30

LAN_ACT_LED# 24
LAN_LINK_LED# 24

PROJECT : EF6

Quanta Computer Inc.

LAN RTL8100C/8110SB

1

26

LANVCC

C218

0.1U

DVDD

1A

of

26 37Monday, January 03, 2005

5

4

3

2

1

AVDDL

R157
0

D D

C C

INT_TX1N26
INT_TX1P26

INT_TX0N26
INT_TX0P26

INT_TX3N26
INT_TX3P26

INT_TX2N26
INT_TX2P26

INT_TX1N
INT_TX1P

INT_TX0N
INT_TX0P

INT_TX3N
INT_TX3P

INT_TX2N
INT_TX2P

C244

0.01U

C245

0.01U

At RTL8100C(L) 10/100M application , use TN8515C transformer
At RTL8110SB(L) 1G application , use GSN5009 transformer

C248

0.01U

C247

0.01U

U31

1

TCT1

2

TD1+

3

TD1-

4

TCT2

5

TD2+

6

TD2-

7

TCT3

8

TD3+

9

TD3-

10

TCT4

11

TD4+

12

TD4-

GSN5009(10/100/1G)

MCT1
MX1+

MX1-

MCT2
MX2+

MX2-

MCT3
MX3+

MX3-

MCT4
MX4+

MX4-

MCT1

R201 75

24
23
22

R202 75

MCT2

21
20
19

MCT3

R203 75

18
17
16

R204 75

MCT4

15
14
13

LAN_1

C258
1500P

CC1808

X-TX1N
X-TX1P

X-TX0N
X-TX0P

X-TX3N
X-TX3P

X-TX2N
X-TX2P

27

C TEST Modified

RJ45 and RJ11 CONNECTOR

R170 150

LANVCC

LAN_LINK_LED#24

B B

C TEST modified

CN24

1
2

JAE-F1-S2P-HF

A A

5

C261
470P/CC1808

C260
470P/CC1808

4

RING_RJ11

TIP_RJ11

RING_RJ11

TIP_RJ11

LAN_ACT_LED#24

MFB3

MMZ1608D301B

MFB2

MMZ1608D301B

LANVCC

KU10S31N

12

X-TX2P
X-TX2N
X-TX1N
X-TX3P
X-TX3N
X-TX1P
X-TX0N
X-TX0P

R168 150

RING_RJ11_1
TIP_RJ11_1

RING_RJ11_1

MRV2

TIP_RJ11_1

CN19

A2

11

LED1_YELP

A3

13

LED1_YELN

4

RJ45_TERM4

5

RJ45_TERM5

6

RDN

7

RJ45_TERM7

8

RJ45_TERM8

3

RDP

2

TDN

1

TDP

B3

16

LED2_GREENN

B1

14 15

12

LED2_GREENP NC2

9

RING

10

TIP

RJ45+RJ11

3

2+
2­1­3+
3­1+
0­0+

NC

GND1
GND2

12

17
18

GND_LAN_CHASIS_2

GND_LAN_CHASIS_1

C263 *1000P

R171 0

C259 1000P

R166 0

C TEST modified ESD

2

Size Document Number Rev
Custom

Date: Sheet

PROJECT : EF6

Quanta Computer Inc.

LAN-2, RJ11, RJ45

27 37Monday, January 03, 2005

1

of

1A

5

+3VSUS

U11-2

A_CSTSCHG/A_BVD1(STSCHG/RI)

A_CCLKRUN/A_WP(IOIS16)

A_CAUDIO/A_BVD2(SPKR)

PCI7411GHK

A_STSCHG#
A_SPKR#
A_A16

+5VSUS

C488
1U

C506
1U

VCCA
VCCA

A_CAD31/A_D10

A_CAD30/A_D9
A_CAD29/A_D1
A_CAD28/A_D8
A_CAD27/A_D0
A_CAD26/A_A0
A_CAD25/A_A1
A_CAD24/A_A2
A_CAD23/A_A3
A_CAD22/A_A4
A_CAD21/A_A5
A_CAD20/A_A6

A_CAD19/A_A25

A_CAD18/A_A7
A_CAD17/A_A24
A_CAD16/A_A17

A_CAD15/A_IOWR

A_CAD14/A_A9

A_CAD13/A_IORD

A_CAD12/A_A11

A_CAD11/A_OE

A_CAD10/A_CE2

A_CAD9/A_A10

A_CAD8/A_D15

A_CAD7/A_D7

A_CAD6/A_D13

A_CAD5/A_D6

A_CAD4/A_D12

A_CAD3/A_D5

A_CAD2/A_D11

A_CAD1/A_D4
A_CAD0/A_D3

A_CC/BE3/A_REG

A_CC/BE2/A_A12

A_CC/BE1/A_A8

A_CC/BE0/A_CE1

A_CPAR/A_A13

A_CFRAME/A_A23

A_CTRDY/A_A22

A_CIRDY/A_A15

A_CSTOP/A_A20
A_CDEVSL/A_A21
A_CBLOCK/A_A19

A_CPERR/A_A14

A_CSERR/A_WAIT

A_CREQ/A_INPACK

A_CGNT/A_WE

A_CCLK/A_A16

A_CINT/A_READY(IREQ)

A_CRST/A_RESET

A_CCD1/A_CD1
A_CCD2/A_CD2

A_CVS1/A_VS1
A_CVS2/A_VS2

A_RSVD/A_D14

A_RSVD/A_D2

A_RSVD/A_A18

R357 0
R356 0
R358 47

VCCCA

C507
10U

C510

0.1U

U11-3

D19

VCCB

K19

VCCB

B15

B_CAD31/B_D10

A16

B_CAD30/B_D9

B16

B_CAD29/B_D1

A17

B_CAD28/B_D8

C16

B_CAD27/B_D0

D17

B_CAD26/B_A0

C19

D D

C C

B B

A A

B_CAD25/B_A1

D18

B_CAD24/B_A2

E17

B_CAD23/B_A3

E19

B_CAD22/B_A4

G15

B_CAD21/B_A5

F18

B_CAD20/B_A6

H14

B_CAD19/B_A25

H15

B_CAD18/B_A7

G17

B_CAD17/B_A24

K17

B_CAD16/B_A17

L13

B_CAD15/B_IOWR

K18

B_CAD14/B_A9

L15

B_CAD13/B_IORD

L17

B_CAD12/B_A11

L18

B_CAD11/B_OE

L19

B_CAD10/B_CE2

M17

B_CAD9/B_A10

M14

B_CAD8/B_D15

M15

B_CAD7/B_D7

N19

B_CAD6/B_D13

N18

B_CAD5/B_D6

N15

B_CAD4/B_D12

M13

B_CAD3/B_D5

P18

B_CAD2/B_D11

P17

B_CAD1/B_D4

P19

B_CAD0/B_D3

F15

B_CC/BE3/B_REG

G18

B_CC/BE2/B_A12

K14

B_CC/BE1/B_A8

M18

B_CC/BE0/B_CE1

K13

B_CPAR/B_A13

G19

B_CFRAME/B_A23

H17

B_CTRDY/B_A22

J13

B_CIRDY/B_A15

J17

B_CSTOP/B_A20

H19

B_CDEVSL/B_A21

J19

B_CBLOCK/B_A19

J18

B_CPERR/B_A14

B18

B_CSERR/B_WAIT

E18

B_CREQ/B_INPACK

J15

B_CGNT/B_WE

F14

B_CSTSCHG/B_BVD1(STSCHG/RI)

A18

B_CCLKRUN/B_WP(IOIS16)

H18

B_CCLK/B_A16

B19

B_CINT/B_READY(IREQ)

F17

B_CRST/B_RESET

C17

B_CAUDIO/B_BVD2(SPKR)

N13

B_CCD1/B_CD1

B17

B_CCD2/B_CD2

C18

B_CVS1/B_VS1

F19

B_CVS2/B_VS2

N17

B_RSVD/B_D14

A15

B_RSVD/B_D2

K15

B_RSVD/B_A18

PCI7411GHK

VPP

C511

C508

0.1U

10U

5

VCCCA

A5
A11

D1
C1
D3
C2
B1
B4
A4
E6
B5
C6
B6
G9
C7
B7
A7
A10

A_IOWR#

E11
G11

A_IORD#

C11
B11

A_OE#

C12

A_CE2#

B12
A12
E12
C13
F12
A13
C14
E13
A14
B14
E14

A_REG#

C5
F9
B10

A_CE1#

G12
G10
C8

A8
B8
A9
C9
E10

F10

A_WAIT#

B3

A_INPACK#

E7

A_WE#

B9

A_STSCHG#

B2

A_IOIS16#

C3
E9

A_IREQ#

C4

A_RESET

A6

A_SPKR#

A2

A_CD1#

C15

A_CD2#

E5

A_VS1#

A3

A_VS2#

E8
B13

D2
C10

A_STSCHG#_P
A_SPKR#_P
A_A16_P

4

A_D10
A_D9
A_D1
A_D8
A_D0
A_A0
A_A1
A_A2
A_A3
A_A4
A_A5
A_A6
A_A25
A_A7
A_A24
A_A17

A_A9
A_A11

A_A10
A_D15
A_D7
A_D13
A_D6
A_D12
A_D5
A_D11
A_D4
A_D3

A_A12
A_A8

A_A13
A_A23

A_A22
A_A15
A_A20
A_A21
A_A19

A_A14

A_A16

A_D14
A_D2
A_A18

4

+3VSUS

PCICGRST#22

40 MIL

40 MIL

VCCCA

VPP

C449

C151

0.1U

1U

PCICGRST# PCICGRST_7411

A_D3
A_CD1#
A_D4
A_D11
A_D5
A_D12
A_D6
A_D13
A_D7
A_D14
A_CE1#
A_D15
A_A10
A_CE2#
A_OE#
A_VS1#
A_A11
A_IORD#
A_A9
A_IOWR#
A_A8
A_A17
A_A13
A_A18
A_A14
A_A19
A_WE#
A_A20
A_IREQ#
A_A21

A_A16_P
A_A22
A_A15
A_A23
A_A12
A_A24
A_A7
A_A25
A_A6
A_VS2#
A_A5
A_RESET
A_A4
A_WAIT#
A_A3
A_INPACK#
A_A2
A_REG#
A_A1
A_SPKR#_P
A_A0
A_STSCHG#_P
A_D0
A_D8
A_D1
A_D9
A_D2
A_D10
A_IOIS16#
A_CD2#

C153
1U

C154
10U

D12

CH500H-40

ICH_PME#14,25,26

CN27

1

35

2

36

3

37

4

38

5

39

6

40

7

41

8

42

9
43
10
44
11
45
12
46
13
47
14
48
15
49
16
50
17
51
18
52
19
53
20
54
21
55
22
56
23
57
24
58
25
59
26
60
27
61
28
62
29
63
30
64
31
65
32
66
33
67
34
68

CARDBUS-SANTA

C155
10U

GND1
GND2
D3
CD1#
D4
D11
D5
D12
D6
D13
D7
D14
CE1#
D15
A10
CE2#
OE#
VS1#
A11
IORD#
A9
IOWR#
A8
A17
A13
A18
A14
A19
WE#
A20
RDY
A21
VCC1
VCC2
VPP1
VPP2
A16
A22
A15
A23
A12
A24
A7
A25
A6
VS2#
A5
RESET
A4
WAIT#
A3
INPACK#
A2
REG#
A1
BVD2
A0
BVD1
D0
D8
D1
D9
D2
D10
WP
CD2#
GND3
GND4

+3VSUS

21

3

C441

0.1U

7411_PME#

VPP

VCCCA

AD[0..31]14,25,26

C459

0.1U

FRAME#14,25,26

DEVSEL#14,25,26

PCLK_74112

PCIRST#22,26

T116

PCICGRST_7411

+3VSUS

R68
10K

C145
*0.22U

GND5
GND6
GND7
GND8

C460

0.1U

C439

0.1U

+3VSUS

2

69
70
71
72

Q8
DTC144EUA

13

C TEST modified ESD

3

C448

0.1U

C/BE3#14,25,26
C/BE2#14,25,26
C/BE1#14,25,26
C/BE0#14,25,26

PAR14,25,26

TRDY#14,25,26

IRDY#14,25,26

STOP#14,25,26

PERR#14,25,26
SERR#14,25,26

REQ0#14
GNT0#14

+3VSUS

+5VSUS

TPS_DATA
TPS_CLOCK
TPS_LATCH

AD[0..31]

C/BE3#
C/BE2#
C/BE1#
C/BE0#

PAR
FRAME#

TRDY#
IRDY#
STOP#
DEVSEL#
AD25

PERR#
SERR#

REQ0#
GNT0#

PCIRST#
PCICGRST_7411

7411_PME#

U42

1

5V_0

2

5V_1

3

DATA

4

CLOCK

5

LATCH

6

NC_0

7

12V_0

8

AVPP/AVCORE

9

AVCC0

10

AVCC1

11

GND

12

RESET#

TPS2220ADBR

VCCCA

2

+3VSUS +3VSUS

AD31
AD30
AD29
AD28
AD27
AD26
AD25
AD24
AD23
AD22
AD21
AD20
AD19
AD18
AD17
AD16
AD15
AD14
AD13
AD12
AD11
AD10
AD9
AD8
AD7
AD6
AD5
AD4
AD3
AD2
AD1
AD0

R77 100

R34 10K
R36 10K

R39 100

C110

0.1U

U11-1

W3

VCCP

W10

VCCP

U2

AD31

V1

AD30

V2

AD29

U3

AD28

W2

AD27

V3

AD26

U4

AD25

V4

AD24

V5

AD23

U5

AD22

R6

AD21

P6

AD20

W6

AD19

V6

AD18

U6

AD17

R7

AD16

V9

AD15

U9

AD14

R9

AD13

N9

AD12

V10

AD11

U10

AD10

R10

AD9

N10

AD8

V11

AD7

U11

AD6

R11

AD5

W12

AD4

V12

AD3

U12

AD2

N11

AD1

W13 M1

AD0 CLK_48

W4

C/BE3

W7

C/BE2

W9

C/BE1

W11

C/BE0

P9

PAR

V7

FRAME

R8

TRDY

U7

IRDY

W8

STOP

N8

DEVSEL

W5

IDSEL

V8

PERR

U8

SERR

U1

REQ

T2

GNT

P5

PCLK

R3

PRST

T1

GRST

T3

RI_OUT/PME

E2

A_USB_EN

E1

B_USB_EN

H2

VR_EN

M19

1.5V_1

H1

1.5V_2

PCI7411GHK

C123

0.1U

VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC

SUSPEND

DATA

CLOCK

LATCH

SPKROUT

MFUNC0
MFUNC1
MFUNC2
MFUNC3
MFUNC4
MFUNC5
MFUNC6

TEST0

VCO_LF

SC_PWR_CTRL

SC_CD
SC_CLK
SC_RST

SC_VCC_5V

SC_DATA

SC_OC

GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND

NC

ID Select : AD25
Interrupt Pin : PIRQA# ,PIRQB# ,PIRQC#
Request indicates : REQ0#
Grant indicates : GNT0#

T115

+3VSUS

Size Document Number Rev
Custom

Date: Sheet

SHDN#

BVPP/BVCORE

BVCC1
BVCC0

3.3VIN0

3.3VIN1

C89
10U/10V_8

2

5V_2
NC_3
NC_2

12V_1

NC_1

OC#

C90

0.1U

24
23
22
21
20
19
18
17
16
15
14
13

+5VSUS

C91

0.1U

H8
H9
H10
H11
H12
J8
M7
J12
M9
M10
M12
K8
K12
N7

R2
N1

L6
N2

L7

N3
M5
P1
P2
P3
N5
R1

P12
W17
T19

L5
L2

K5
K3
K7
L1
L3

G7
G8
G13
H13
J9
J10
J11
K9
K10
K11
L8
L9
L10
L11
L12
M8

+3VSUS

TPS_DATA
TPS_CLOCK
TPS_LATCH

PCMSPK#

R198 10K

PIRQA#
PIRQB#
PIRQC#
SERIRQ

R324 10K
R49 *10K
R53 0

R325 220

R337 10K

R45
10K

+3VSUS

+5VSUS

PROJECT :EF6

Quanta Computer Inc.

TI 7411E (PCI,CARD BUS)

1

28

PCMSPK# 19

PIRQA# 14
PIRQB# 14,25
PIRQC# 14,25
SERIRQ 14,15,22,30

FM_LED 29

CLKRUN# 14,22,25,26,30

CLK48_7411 2

+5VSUS

of

28 37Monday, January 03, 2005

1

+3VSUS

1A

A

U11-4

MC_PWR_CTRL_0#

SD_CDZ#

4 4

3 3

MS_CDZ#

MS_CLK_SM_ELWPZ

MS_BS_SM_WEZ
MS_DATA3_SD_DAT3_SM_D3
MS_DATA2_SD_DAT2_SM_D2
MS_DATA1_SD_DAT1_SM_D1
MS_DATA0_SD_DAT0_SM_D0

SD_WP_SM_CEZ

R341

F1

MC_PWR_CTRL_0

F2

MC_PWR_CTRL_1

E3

SD_CD

F5

MS_CD

F6

SM_CD

G5

33

MS_CLK/SD_CLK/SM_EL_WP

F3

MS_BS/SD_CMD/SM_WE

H5

MS_DATA3/SD_DAT3/SM_D3

G3

MS_DATA2/SD_DAT2/SM_D2

G2

MS_DATA1/SD_DAT1/SM_D0

G1

MS_SDIO(DATA0)/SD_DAT0/SM_D0

J5

SD_CLK/SM_RE/SC_GPIO1

J3

SD_CMD/SM_ALE/SC_GPIO2

H3

SD_DAT0/SM_D4/SC_GPIO6

J6

SD_DAT1/SM_D5/SC_GPIO5

J1

SD_DAT2/SM_D6/SC_GPIO4

J2

SD_DAT3/SM_D7/SC_GPIO3

H7

SD_WP/SM_CE

J7

SM_CLE/SC_GPIO0

K1

SM_R/B/SC_RFU

K2

SM_PHYS_WP/SC_FCB

PCI7411GHK

B

R13

AVDD

R14

AVDD

V17

AVDD

V19

AVDD

T18

VDPLL

U18

R0

U19

R1

U15

TPBIAS0

V15

TPA0+

W15

TPA0-

V14

TPB0+

W14

TPB0-

CPS
CNA

SCL
SDA

VSPLL
AGND
AGND
AGND
AGND

TPBIAS1

TPA1+
TPA1-

TPB1+
TPB1-

R17

M11
P15

R19

XO

R18

XI

M3
M2

R12
U13
V13

T17
N12
P14
U14
U16
U17

V18
W18

V16
W16

PHY_TEST_MA

PC0 (TEST1)
PC1 (TEST2)
PC2 (TEST3)

7621_T18
1394_R0

1394_R1
1394BIAS0

R317 4.7K

R338 0

1394_XOUT

1394_XIN
1394_SCLK

1394_SDATA

3VSUS_7411

R295

6.34K/F

Y3

24.576MHZ

2 1

BLM11A121S

C120 12P

C148 12P

C406 1U

L9

+3VSUS

C

+3VSUS

R285 56.2 EB7 1632090
R286 56.2

R283 56.2
R284 56.2

3VSUS_7411

C150

C419

1U

0.1U

C370 1U

1394_TPA0+
1394_TPA0-

1394_TPB0+ 1394_TPB0- 1394_TPB0-_C

1394_TPB0-

C371 220P
R287 5.11K/F

D

C152
10U

1394_TPA0­1394_TPA0+

1394_TPB0+ 1394_TPB0+_C

B TEST Modified

1394_SCLK
1394_SDATA

R312 220
R305 220

7621_T18

R76 220

2

2

2

2

EB6 1632090

R112

2.7K

1
43

1
43

+3VSUS

1394_TPA0-_C

1

1394_TPA0+_C

43

1
43

R113

2.7K

IEEE 1394

1394_TPA0+_C
1394_TPA0-_C
1394_TPB0+_C
1394_TPB0-_C

U15

6

SCL

5

SDA

7

WP

NM24C02-WMN6T

VCC
GND

1

A0

2

A1

3

A2

8
4

E

+3VSUS

C166

0.1U

5

6

5

4

4

3

3

2

2

1

1

1

CN4
1394_CONNECTOR

29

6

2 2

MC_PWR_CTRL_0#

R8 8.2K

+3VSUS

FM_LED28

1 1

SD_CDZ#

+3VSUS

R7

8.2K

1
2

FM_LED

D2 CH500H-40

2

21

B test modified

+3VSUS

53

4

U6
TC7SH08FU

3

Q2
CH2507S

1

R5 100K

VCC_XD_CTRL

+3VSUS

+3VSUS

1

2

3

R6

43K

WORKAROUND PROPOSAL

VCC_XD

C13

0.01U

P

Q3
AO3403

VCC_XD

C12
10U

CLOSE TO XD SOCKET

C14

0.1U

C11
1U

VCC_XD_CTRL

C15
10U

SD_CDZ#
SD_WP_SM_CEZ

MS_CLK_SM_ELWPZ
MS_BS_SM_WEZ

MS_DATA1_SD_DAT1_SM_D1
MS_DATA0_SD_DAT0_SM_D0
MS_DATA3_SD_DAT3_SM_D3
MS_DATA2_SD_DAT2_SM_D2

VCC_XD

PR152
22C

3

PQ59
2N7002E

2

1

B test modified

A

B

C

3 IN1 CARD READER

CON2

20

CARD DETECT (CD)

22

DETECT GND

21

VCC_XD

SD_WP

5

SD_CLK

2

SD_CMD

8

SD_DAT1

7

SD_DAT0

1

SD_DAT3

9

SD_DAT2

18

MS_VCC1

4

SD_VDD

FOXCONN_3_1

MS_DATA1
MS_DATA2
MS_DATA3

Supporting MMC/SD/MS Cards

MS_BS

MS_SDIO

MS_INS

MS_SCLK

MS VSS0
MS VSS1
SD VSS0
SD VSS1

SHIELD1
SHIELD2
SHIELD3
SHIELD4

D

11
13

15
12

14
16

17
10

19
6
3

23
24
25
26

MS_BS_SM_WEZ
MS_DATA0_SD_DAT0_SM_D0

MS_CDZ#
MS_DATA1_SD_DAT1_SM_D1

MS_DATA2_SD_DAT2_SM_D2
MS_DATA3_SD_DAT3_SM_D3

MS_CLK_SM_ELWPZ

Size Document Number Rev
Custom

Date: Sheet

TI 7411E (1394 & CARD_READER)

PROJECT :EF6

Quanta Computer Inc.

of

29 37Monday, January 03, 2005

E

1A

A

SUPER I/O - PC87383 30

4 4

+3V

12

R140
10K

D17

SUS_STAT#15,22

PCLK_SIO

R147

3 3

2 2

*33

12

C223
*22P

21

CH500H-40

LAD0/FWH014,22
LAD1/FWH114,22
LAD2/FWH214,22
LAD3/FWH314,22

PCLK_SIO2

LPC_DRQ0#

LFRAME#/FWH414,22

PLTRST#5,14,37

SERIRQ14,15,22,28

CLKRUN#14,22,25,26,28

INIT#24

ERROR#24

BUSY24

AFD#24
ACK#24

STRB#24

SLIN#24

SLCT24

PE24

PRINT PORT

PD[0..7]24

PD[0..7]

B

LAD0/FWH0
LAD1/FWH1
LAD2/FWH2
LAD3/FWH3
PCLK_SIO
LPC_DRQ0#
LFRAME#/FWH4
PLTRST#
SERIRQ
SUS_STAT_1#
CLKRUN#

INIT#

ERROR#

BUSY
AFD#
ACK#
STRB#
SLIN#
SLCT
PE

PD7
PD6
PD5
PD4
PD3
PD2
PD1
PD0

U23

42

LAD0

46

LAD1

51

LAD2

53

LAD3

33

LCLK

38

LFRAME

35

LRESET

36

SERIRQ

29

LPCPD/GPIO21

27

CLKRUN/GPO22

56

INIT

54

ERR

26

BUSY_WAIT

57

AFD_DSTRB/TRIS

28

ACK/GPO24

14

STB_WRITE/TEST

55

SLIN_ASTRB

24

SLCT

25

PE

30

PD7/PGIO23

34

PD6

37

PD5

39

PD4

6

PD3

43

PD2

50

PD1

52

PD0

18

17

NC

NC

VSS

123144

VSS

C

C211

0.1U_0402

113245

1

2

NC

NC

VDD

VDD

VSS

VCORF

13

VDD

NCNCNC

474849

GPIO00
GPIO01
GPIO02
GPIO20
GPIO03
GPIO04LDRQ/XOR_OUT
GPIO05
GPIO06
GPIO07

CLKIN

IRRX1

IRRX2_IRSL0/GPIO17

CTS1/GPIO11
DCD1/GPIO16
DSR1/GPIO15

RTS1/GPIO13

SIN1/GPIO14

SOUT1/GPIO12

RI1/GPIO10

DTR1_BOUT1/BADDR

NC

PC87383

64

IRTX

C228

0.1U_0402

15
16
19
23
20
2122
40
7
41

58

8
9
10

3
59
60
62
61
63
5
4

+3V

C224
10U/6.3V

14M_SIO

IRRX1
IRTX
IRSEL

-MCTS1

-MDCD1

-MDSR1

-MRTS1
MRXD1
M_TXD1
BRI#

-MDTR1

14M_SIO 2

R151
10K

SET ADDRESS
For PC87383 Use

164E ~ 164F

D

-MCTS1 24

-MDCD1 24

-MDSR1 24

-MRTS1 24
MRXD1 24
M_TXD1 24
BRI# 24

-MDTR1 24

E

40mil: Power/ GND

FIR

35mil: VCC_LED, VCC_IC, GND_IC
10mil: TXD, RXD, IRSEL, IRTX,
IRRX1

+5V

IRTX
IRRX1 RXD

IRSEL

+3V

C341
10U

R260 22
R256 22

C325
10U

M_TXD1

-MRTS1

-MDSR1

-MDCD1

-MCTS1
BRI#

R269 5.6_1206

R262 5.6_1206

TXD

T64

PAD

R239 0_8

RN2 10KX4

6
4
2

R152 10K
R149 10K

3

TXD

4

RXD

7

FIR_SELMOD

5

SD/MODE

VCC_IC

C332
.1U/10V_4

VCC_LED

78
5
3
1

1

U17

LEAD

LED_C

VCC

GND

6

8

C333
1000P_4

+3V

2

TFDU6102F

T66 PAD

C222

0.1U_0402

1 1

Size Document Number Rev
Custom

A

B

C

D

Date: Sheet

SUPER I/O - PC87383

PROJECT : EF6

Quanta Computer Inc.

of

E

30 37Monday, January 03, 2005

1A

1

2

3

4

5

31

A A

10A Current limit

VIN_1845

PC102

1845AGND

PU7

19
20
17
18
16
15
14

7
11
12

13

3

1845VCC

VIN_1845

BST2
DL2
LX2
DH2
CS2
OUT2
FB2

PGOOD
ON1
ON2

ILIM2
ILIM1

1U/10V

15mil

1845VCC

4

22

V+

MAX1845

UVP

8

9

15mil

VCC

BST1

OUT1

SKIP

OVP

VDD

DH1

LX1
DL1
CS1

FB1

TON

REF

GND

21
25
26
27
24
28
1
2

1845TON

5

10
6

23

VCCP

VCCP

B-stage

B B

EC10QS04_PSM

PD15

2 1

PC95
.1U/50V

12

1.05V
7A

S0

VCCP_1

PC87

10U/25V/X6S/1206

12

*220U/2.5V-18m_7343

+

PC100

160mil

PC101
330U/2.5V-12m_7343

+

PC91

10U/25V/X5R/1210

1.5UH_SIL104R-1R5_10A/8.1 mohm

PR120
499/F

Rc

B-stage

Rd

PR124
10K/F

1845AGND

C C

Vout=(1+Rc/Rd)*1

12

+

1 2

*EC10QS04_PSM

PC112
*100P

PR123
*0

120mil

PC90

.1U/50V

B-stage

PL16

PD17

Rds on =10.5mohm

C TEST
Modified

1845VCC

578

PQ44

1 2

2 1

AO4404

PC103

B-stage

.1U/50V

1845_BST2

1845_DL2
1845_LX2
1845_DH2

1845FB2

PR127

PR126 0

PR125 0

1845ILIM2
1845ILIM1

PR153

2.2

0

PP5
PP6
PP7

3 6

241

578

PQ43

AO4704

HWPG22,32

3 6

241

S5_ON22
VRON22,35

HWPG

VRON

12

20mil
120mil
20mil 120mil

21

D34

CH500H-40

1845REF

2

PR110
18

B-stage

1845_DH1
1845_LX1
1845_DL1

1845FB1

1 2

PR128 *0

1845REF

20mil

1845AGND1845AGND

15mil15mil

1

3

15mil

PR154

2.2

PC122
.22U/25V/0805/X7R

2V

PJ3 SHORT

1845AGND

1.5V_S5

PR103
75K/F

PR104
100K/F

PR102

48.7K/F

1845ILIM21845ILIM1

PR101
100K/F

1.5V_S5

PD18
CHP202U

PC104

4.7U/10V

1845_BST1

20mil

20mil

5VPCU

1845VCC

PR159

PC92

.1U/50V

0

PC105
.1U/50V

B-stage

1 2

12

PQ46

AO4704

Rds on =10.5mohm

PR129
0

1845VCC

578

3 6

578

PC94

10U/25V/X5R/1210

PQ45
AO4404

241

1.5UH_SIL104R-1R5_10A/8.1 mohm

3 6

241

Re

PR131
*5K1/F

Rf

PR130
*10K/F

1845AGND

12

+

B-stage

PL14

1 2

PD16

*EC10QS04_PSM

2 1

PC118
*100P

1.5V_S5

12

+

PC93
*10U/25V/X5R/1210

330U/2.5V-12m_7343

1.5V_S5_1

1 2

PC89

0805/5A

PC98
.1U/50V

+

PL13

VINVIN_1845

160mil120mil

160mil

10U/25V/X6S/1206

+

PC88

*330U/2.5V-12m_7343

B-stage

12

PC86

10U/25V/X6S/1206

12

PC113

PC96
.1U/50V

1.5V_S5_1

6A

S0-S5

8.5A Current
limit

1.5V_S5

PD19

EC10QS04_PSM

2 1

1 2

Vout=(1+Re/Rf)*1
Or

Vout=1845FB1 connect to 1845VCC
Fix Vout=1.5V

PC99

SI4810DY

.1U/16V/X7R

+1.5V

6A

S0-S1

PR12=75K Current
Limit=8.5A

+1.5V

2

578

MAIND33,36

D D

1

MAIND

+1.5V

PC82

.1U/16V/X7R

PQ42

3 6

241

1845AGND1845AGND

PR13=48.7K Current
Limit=10A

C548

C547

0.1U

0.1U

C549

0.1U

3

C550

0.1U

C551

0.1U

C546

C545

0.1U

0.1U

C TEST modified EMI

4

Size Document Number Rev
Custom

Date: Sheet

PROJECT : EF6

Quanta Computer Inc.

1.05V/1.5V

5

of

31 37Monday, January 03, 2005

1A

5

4

3

2

1

+2.5V

1500mA

32

of

32 37Monday, January 03, 2005

2A

VIN

D D

10A Current
limit

1.8VSUS

B-stage

12

PC11

C C

10U/25V/X6S/1206

PC9

+

220U/2.5V-18m_7343

PL5

FBMJ3216HS800-T

PC15

10U/25V/X5R/1210

1.8V_P

12

PC10

0.1U/16V

+

220U/2.5V-18m_7343

18mOhm 18mOhm

+1.8VSUS

5.1A

S0-S1

1.8VSUS 8,9,10,36

PC4

0.1U

B B

PC5

0.1U

A A

65241

+1.8V

1.8VSUS

PQ8

3

C552

0.1U

C554

0.1U

5

1.8VSUS

AO6402

MAIND 33,36

+1.8V

+1.8V 36

C553

0.1U

C555

0.1U

486_VIN

486_VIN

12

PC7

+

12

10U/25V/X5R/1210

12

PR21

2K/F

12

PR20
10K/F

PC12

+

1 2

1.5UH_SIL104R-1R5_10A/8.1_mohm

12

PC20
22P/NC

C TEST modified EMI

MAINON22,34,36

PC14

0.1U/50V

PL4

1 2

PD3

*EC10QS04

MAINON22,34,36

12

PC13
2200P

2 1

PR19 10

4

MAINON

578

PQ19
AO4406

3 6

241

578

PQ18
AO4704

RDS(ON)=13m
ohm

3 6

241

12

PC18

1U/10V

486_VIN

C TEST Modified

PR73 10

PR76
*0

3.3V

PR75
100K

MMBT3904

0.99V

PR74

12

43K

PQ26

2

PC65
1U/X5R

21

PD4
RB751V

PR18 0

1.8V_BST

PC22

12

0.1U/50V

1 2

B-stage

PR145 1M

1 3

+5VSUS

12

1U/10V

PU2

SC486IMLTRT

24

1.8V_DH

23

1.8V_LX

22

PR25

21

12.1K/F

1.8_DL

19

18

1.8V_OUT

3

1.8V_FB

6

486TON

2

12

12

PC17
1000P

D35 CH500H-40

21

PR72
200K

PC63

.1U/50V/X7R

3VPCU

B-stage

PR162

0

PC29

BST

DH

LX
ILIM
DL

PGND1

VDDQS
FB

TON

PR27 10

20

VDDP1

REFOUT

VSSA

8

4

PC60

10U/25V/X6S/1206

3

486VCCA

POK

EN/PSV
EN/VTT

VDDP2
VDDP2

PGND2
PGND2

VTT
VTT

VTTS

COMP

5

VCCA

80mil

12

12

PC19

1U/10V

7

SUS_R

1

RUN_ON_D_R

11

1.8VSUS

12
13

PC150

0.1U/16V

16
17

0.9V_P

14
15
10

486COMP

9

PR24

10

MVREF

12

PC61

10U/25V/X6S/1206

PR22 0

PR144 0
PR26 0

12

12

PC25

10U/25V/X6S/1206

PC28

0.1U/16V

1 2

PC23

1000P/50V/NC

PR23
10

12

PC21

1U/10V

1

NC0

2 6

EN VO

3

VIN

4

NC1

PC62
.1U/50V/X7R

PR77
0

12

SMDDR_VREF

12

PC27
10U/25V/X6S/1206

12

PC24
10U/25V/X6S/1206

1 2

R11 0ohm

1000P_NC

NC2

GND
GND

ADJ

PU5

7

SC4215

R2

C TEST Modified

HWPG 22,31,33,35

SUSON 22,36

MAINON 22,34,36

12

PC26
10U/25V/X6S/1206

C60

5

8
9

R1

PR78
*52.3K/F

1.8VSUS

B-stage

0.9V_P

80mil

PC66

*220U_7343_2.5V

PC71

+

12

10U/25V/X6S/1206

Vo=0.8(R1+R2)/R2

2

SMDDR_VTERM

PC34

+

*220U_7343_2.5V

2.5VPCU

12

PC72

10U/25V/X6S/1206

<OrgAddr1>
<OrgAddr2>
<OrgAddr3>
<OrgAddr4>
Size Document Number Rev
Custom

Date: Sheet

PC76
.1U/50V/X7R

PROJECT : EF6

Quanta Computer Inc.

1.8V/0.9V

1

5

4

3

2

1

VIN

PL9

PC31

+

PC149

4.7U_1206_16V_X6S

C

MAIND31,32

12

+

PC74

4.7U/10V

FB5

C557
.1U/50V/X7R

PC57
.01U/50V/X7R

FB3

PR141
*0R

PR140
0R

PC144

*1000P

DD

PC143

*1000P

4A

PC32
.1U/50V/X7R

+3V

.1U/50V/X7R

MAIND

PC75
.1U/50V/X7R

PR138
*0R

PC136

PR139

0R

C558
.1U/50V/X7R

Size Document Number Rev
Custom

Date: Sheet

876

123

PC146

5VPCU

MAIND36

*1000P

PC139
*1000P

C559
.1U/50V/X7R

Quanta Computer Inc.

SYS POWER 3V & 5V MAX1999

3VPCU

5

PQ53
AO4812

4

SUSD

C

PC148
.1U/50V/X7R

578

MAIND

3 6

241

B-stage

PROJECT : EF6

1

3VPCU

+3VSUS

5VPCU

PQ27
SI4810DY

+5V

33 37Monday, January 03, 2005

SUSD 36

PC70

0.1U

PC67
.1U/16V/X7R

of

6A

2A

PD7

VIN_5V

10U/25V/X5R/1210

1 2

PD21

*EC10QS04

2 1

PC56
1000P

PL10

3.3UH/6.9A

PR136

0B

VIN_3V

*10U/25V/X6S/1206

B-stage

1 2

2 1

12

PC128

+

220U/6.3V/7343

PL8

3.3UH/6.9A

PC64

5VPCU

10V

3VPCU

12

PC53

220U/6.3V/7343

12

PC54
10U/25V/X6S/1206

PC30

PL17

HI0805R800R-00(5A)

12

PC129
*10U/25V/X6S/1206

+

+

PC68

150U/6.3V/7343

C556
.1U/50V/X7R

HI0805R800R-00(5A)

*150U/6.3V/7343

+

VIN

PR70

PR61

5V_AL

REF2V_1999

0R

PC58

.1U/50V/X7R

PD24
0R

+3V

1999PG

PR59 0R

REF2V_1999

PC141 1U

0R

PR63
100K/F

PR142

*10K

PR67

PR69
0R

ILIM5

PR64

ILIM3

0R

FB3

FB5

SYS_SHDN#3

D D

C C

C TEST modified EMI

+3V

C578
.1U/50V/X7R

PR46=40.2K
=>Ilimit=5.5A

ILIM3

ILIM5

PR60
100K/F

PR62

40.2K

PR65
100K/F

C579
.1U/50V/X7R

REF2V_1999

PR66

PR47=26.1K
=>Ilimit=6A

26.1K

C580
.1U/50V/X7R

HWPG22,32

C TEST modified EMI

B B

5VPCU

5V_S5

C574
.1U/50V/X7R

C575
.1U/50V/X7R

5V_S5

A

PQ50
AO6402

5V_S5

PC125

0.1U

SUSD36

S0-S5

65241

S5_OND36

A A

S5_OND

3

PC126
.1U/16V/X7R

PR68

390K/F

PC142

12

+

4.7U/10V

PU9

1

N.C

2

PGOOD

3

ON3

4

ON5

5

ILIM3

6

SHDN-

7

FB3

8

REF

9

FB5

10

PRO-

11

ILIM5

12

SKIP-

13

TON

14 15

BST5 LX5

MAX1999

PR156

0R

BST3

LX3

DH3

LDO3

DL3

GND
OUT3
OUT5

V+

DL5

LDO5

VCC

DH5

1999_BST5

B-stage

5VSUS

5VPCU

2.5A

S0-S3

SUSD

3

3V_AL

B-stage

PR1550R

28
27
26
25
24
23

3VPCU

22

5VPCU

21
20
19
18

PC132 1UB/10V/X7R

17
16

PR137

4.7

1 2

65241

PQ31
AO6402

+5VSUS

PC77
.1U/16V/X7R

10R

PR71

10R
PC59
.1U/50V/X7R

1999_DL3

1999_LX3

PC145
.1U/50V/X7R

1999_BST3

PC140

+

1 2

4.7U/25V

1999_DH5

12

+

PC73

0.1U

C TEST modified EMI

2

PC137

4.7U/10V

+5V

1999_DL5

PC135

1

PD23

CHP202U

3

5V_AL

C560
.1U/50V/X7R

.1U/50V/X7R

4

S2

5

1999_DH3

C561
.1U/50V/X7R

2

3

G2

S1D2

7

6

B-stage

PC130
.1U/50V/X7R

1

D1

G1

8

3

PD22
CHN217

PQ25

SI4814DY

22 m ohm

578

578

2

1

PC131

.1U/50V/X7R

*EC10QS04

PC127
1000P

PQ52
SI4800DY

3 6

241

PQ51
SI4810DY

3 6

241

10V_1

PC133

4.7U_1206_16V_X6S

C TEST modified EMI

5

4

3

2

33

1

ADAPTER 19V 65W 3.4A

BATTERY CHARGER

A A

CN3

POWER_JACK

VA-1

1
2
3
4
5

VA-2

C TEST modified ESD

3VPCU13,14,22,23,26,32,33,36

VIN

5VPCU14,22,23,31,33

MBDATA22

VIN13,31,32,33,36
5VPCU

PD9

SW1010

CN25

7

1ST_BAT_CONN

PR92

P331

5
4

2
1

MBDATA

1

.01U/50V

SMC
SMD

PC85

475K/F

PR90
332K/F

PR98
100

2 1

2 1

5
4
3
216

B B

C C

D D

FBJ3216HS480NT_1206

PC152
.1U/50V_0805

5VPCU14,22,23,31,33
3VPCU

3

PQ38
2N7002E

1

3VPCU

PD11
ZD5.6V

2

PR97
10K/F

2 1

PL3

5VPCU

1
3

PR99
100

MBCLK

PD12
ZD5.6V

+

-

BATTERY 4400mAH 8cell/6cell
4800mAh 8cell/6cell

VA

PC2

.1U/50V_0805

PR91
100K

ACOK

3VPCU

SW1010

PR89
100K

5

4

PU6
LMV331

2

TEMP_MBAT 22

BAT-V1

MBCLK 22

PR88
100K

PR172
0

PD2 SBM1040

1
2

ACOK-1

21

PD10

ACOK-2

3

1

BL/C# 22

MAINON22,32,36

FBMJ3216HS480NT(6A)

PC83
.01U/50V

2

PR173

PL12

2

3

PR87
10K

2

2

PQ35
2N7002E

*0

VAD

PR2

0.033/3720/1W

CSSP

PR135

4.7

VAD-5

PC124
.1U/50V

3

PQ37
2N7002E

1

D/C#

PR95
14K/F

D/C# 22

VIN

VA-5

2

1

PQ40

*UMD2

PD13

6

5

4 3

*SW1010

VA-6

VA-4 VA-3

2 1

PR93

*0

AC can not power on
when plug in docking
ver : B modified

BAT-V

PR96
100K/F

MBATV

2

2P11P

VAD-1

PR134

4.7

PC81
.01U/50V

PR171

CSSN

0

PC119
.1U/50V

VAD

21

MBATV 22

B-stage

PQ3

AO4407

1
2
3

1 3

PC153
*0.01U

PQ2

DTA124EUA

1772_CSSN

1772_CSSP

AC_C

PD14
SW1010

PR132
0

2

PC3 0.01U

.1U/50V

1U25V_X6S/0805

3

VIN

PL15

FBJ3216HS480NT_1206

8
7
6

PR108

54

200K

PR109
100K

PC16

4.7U_1210/25V-X5R

1772_5.4V

PR119

33

15mil

B-stage

PC120

PC123

1 2

1U/10V/X7R

PC121

1772_5.4V

REF4.096

PR133
10K

15mil

REF4.096

PR105
10K/F

B:For 65W adapter

PR81=11K =>P
limit=61.75W

3

VIN_1772

PC97

4.7U_1210/25V-X5R

PC116

.1U/50V

PD20

2 1

SW1010

PR157

0R

26

27

28

INP

CSSP

DCIN

LDO

123

1772_DCIN

1772_CLS

PC117

1U/10V/X7R

VAD

PR107
75K/F

PR106
10K/F

CSSN

CLS

12.1K/F

PR100

15mil

20mil

1772_BST

1772_DHI

24

25

BST

REF

465

1772_CCS

PC114

0.01U

ACIN22

PQ41

1
2
3
4

1772_LX

23

LX

DHI

MAX1772EEI

CCI

CCS

1772_CCI

PC111

0.01U

SI4814DY

G1

D1

G2

S2

PC115

1U/10V/X7R

S1D2

8
7
6
5

20mil

1772_DLO

1772_DLOV

18

19

20

21

22

DLO

CSIP

GND

ACOK

PGND

GND

PR121
10K

PR122
15K

ICHG

PQ49
DTA124EUA

CSIN

ACIN

ACOK#

DLOV

CCV

1772_CCV

78910111213

PR118
1K

1772-3

PC109

.1U/50V

1772_ACIN

17

BATT

ACOK

2

1772_CSIP
1772_CSIN
BAT-V
1772_CELLS

16

CELLS

REFIN

14 15

13

4

10uH/4.5A_SIQ124-100

PU8

1772_ICHG

ICTL VCTL

3VPCU

1772_ICTL

PC107
.1U/50V

PC108

.1U/50V

1772_5.4V

4

B-stage

1
2

VIN-V

PR113
100K

PL11

3

1

3

1772-1

CSIP

PR117

4.7

PC110
.1U/50V

10K/F
PR111

PR112

3.4K

3VPCU 13,14,22,23,26,32,33,36

CC-SET

D/C#

2

PQ47
*2N7002E

VIN

5

PQ36
AO4407

PR94

0.05/3720/1W

3VPCU

8
7
6
54

PC84

10U/25V/X5R/1210

PQ48

120mil

12

+

*10U/25V/X5R/1210

1772_5.4V

PR116
100K

PR115
100K

1772-2

3

1

PC80

2

2

2P11P

CSIN

PR114

4.7

PC106
.1U/50V

2N7002E

12

+

CELL_SLT 22

10U/25V/X5R/1210

CELL-SET
0 = 4 CELL
1 = 3 CELL

CC-SET = 1.05V/A

CC-SET 22

C TEST modified EMI

D/C# 22

C564
.1U/50V/X7R

C565
.1U/50V/X7R

Size Document Number Rev
Custom

Date: Sheet

C566
.1U/50V/X7R

C567
.1U/50V/X7R

PROJECT : EF6

Quanta Computer Inc.

CHARGER

5

PC79

12

+

C568
.1U/50V/X7R

34 37Monday, January 03, 2005

34

BAT-VVAD-2

C569
.1U/50V/X7R

1A

of

1

+3V

HWPG

1907S2
1907S1
1907S0

1907B0
1907B1
1907B2

PR166 0
PR167 0
PR43 0

1907REF

1907ILIM

PU3

74SH02

C-stage

PR33
10K

VRON-1

1907TIME

1907CC

20mil

PC35

0.1U

4

+5VSUS24,28,32,33,36
3VPCU13,14,22,23,26,32,33,36
+3V10,12,13,15,16,18,21,22,23,25,26,30,33,36,37

1907AGND

36
37
38

21
22
23
24
25
26

6
5
4

1
3

35
20

7

39

12

8

9

27

PC47

1U/X5R

1 2

PU4

SYSPOK
IMVPOK
CLKEN

D5
D4
D3
D2
D1
D0

S2
S1
S0

B0
B2

SUS
DPSLP
SHDN

TIME

CC

REF

ILIM
DDO

MAX1907AETL

1907AGND

N1

1907VCC

2

CPU VCC_CORE
(MAX1907)

A A

C:For Intel change C4 Deeper
sleep voltage

1907VCC 1907REF

PR45
*0

1907S0

1907AGND

0.748V for suspend mode
(Deeper sleep)

B B

SFI0603-050E101NP

4ms delay to ICH4-M.

IMVP_PWG5,15

PR46
*0

PR50
0

1907AGND

C TEST modified EMI

MR955 0

PJ2 SHORT

C C

1907AGND

CLK_EN#2

DPRSLPVR15

D D

CLK_EN#
DPRSLPVR

B-stage

1

C570

HWPG22,32

PR34 10K

+3V

CLK_EN#2

CPU_VID54
CPU_VID44
CPU_VID34
CPU_VID24
CPU_VID14
CPU_VID04

T3

1907VCC

B-stage

DPRSLPVR15

STP_CPU#2,15

VRON22,31,36

49.9K/F
PR35

PR51
232K/F

PR48

40.2K/F

1907AGND 1907AGND

+5VSUS

2
1

PR143
100K

1907AGND

1907AGND

PC46
100P

53

270P
PC52

0.22U
PC45

PR40

20mil

10

VCC

3

1

1907AGND

GND

41

2

+5VSUS

10

PQ20

2N7002E

2

30

VDD

BST

GNDB1

PGND

TON

OA+

CSN

CSP

NEG

POS

13

1907POS

PR28
*12.4K/F

PR165

0

20mil

V+

DH

LX

DL

OA-

FB

B-stage

PC44

4.7U/10V

VIN_1907

34

PR158

31

0

1907DH

33

1907LX

32

1907DL

29

1907TON

1907AGND

1907TIMEPP4

PR29
*49.9K/F

1907AGND

PC50
4700P

1907FB

PR52

1.24K/F

PR53
100K/F

112
28

40

17
16

15
19

18

14

1907AGND

For Yonah

21

PD5
CH500H-40

PC36 .22U/25V/0805/X7R

1907BST

B-stage

20mil

20mil

1907VCC

*10K
PR36

PR58 2K/F
PC55 100P

CM-1
CM+1

C:For Load line.

PR54 200
PR55 200

B:For offset.

PR44

1907B2 1907B1

*0

3

160mil

PC43

PC42

2200P/50V

0.1U

12

PC38

43

PQ22

AOD404

1

10U/25V/X5R/1206

10U/25V/X5R/1206

VIN_1907

12

PC39

10U/25V/X5R/1210

12

+

PC41

4

12

PC40

+

10U/25V/X5R/1210

30V/52A_14m

PL7

0.62uH

160mil

43

PQ21

1

AOD414

43

PQ24

AOD414

1

PD25
SSM24

2 1

1907_7

30V/70A_9m

1907_OA+

1907_OA-1907FB

CM­CM+

1907VCC1907VCC

PR39
0

1907REF

PR37
*0

PR38
*0

VCC_BOOT
B2

B1

GND

GND
REF

REF

OPEN

OPEN
VCC

VCC

REF

VCC

1907B0

B0
GND
REF
OPEN
VCC
VCC

1907REF 1907VCC 1907REF

PR42
0

PR41
*0

1907AGND 1907AGND 1907AGND

MAXIM Change MAXIM Change MAXIM Change

SUSPEND MODE (SUS=HIGH)

S0

S1

S2
OPEN

VCC

Output

GND

0.748V

3

PR32
0

Output

1.708V

1.372V

1.036V

0.700V

1.212V

PC51
*470P

4

PL6

3216-800T40

PR49

0.001

1

1P

CM+

PR56

1.5K

PR30
*0

PR31
*0

5

VIN

VIN 13,31,32,33,36

12

PC33
10U/25V/X5R/1206

CPU_CORE

0.844V ~ 1.356V
27A

CPU_CORE

PC48

PC138

PC147

2

2P

CM-

PR57
2K/F

PR47

*0

D5
1
1
1
1
1
10
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
11

1
1
1
1
1
1
1

PC49

*330U/2.5V/7343

D4 D2
0
0
0
0
0
0
0
0
0
0
0
0
0
0

0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1

330U/2.5V/7343

+

330U/2.5V/7343

D3
0
0
0
0
0
0
0
0
1
1
1
1
1
1
10
1
0
0
0
0
0
0
0
0
1
1
1

1
1
1
1

Size Document Number Rev
Custom

Date: Sheet

+

+

330U/2.5V/7343

D2

D0

D1
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1 0.972V

0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1

Output

0

1.196V

0

1.180V

0

1

1.164V

0

1

1.148V

1

1

0

0

1.132V

1.116V

0

1
0

1.100V

1

1

1

1.084V

0

0

1.068V

0

1.052V

1
0

1

1.036V

1.020V

1

1

0

1.004V 0

0

0.988V

1

0

0

1

0.956V1

1

1

0

0.940V

0

0

0.924V

1

1

0.908V

0

1

1

0.892V

0

0.876V

00

0.860V

0

1

1

0

0.844V 0

1

0.828V

0

0

0.812V1

0

0.796V

1

0.780V

1

0

0.764V

1

1
0

0.748V

0

0

1

0.732V

0.716V

1

0

0.700V

1

1

PC134

330U/2.5V/7343

+

+

PD6
SSM24

2 1

D5

D4
0

0
0

0
0

0
0

0
0

0
0

0

0
0

0

0

0

0

0
0

0

0

0

0

0

0

0
0
0

0
1

0
0

1
1
1

01

1

0
0

1
1

0

1

0

1

0

1
1

0

1

0

1

0

1

0
0

1
1

0

D3

D1

0

0
0

0

0
1

0

0

0

1

01

0

0

1
1

0

0
1

0

1

0

1

1

1

0

0

1

0

0

1

0

1

0

1

1
1

0

1
1

0

1

1 1.484V

1

1

1

1

1

0

0

0
0

0

0

1

00

0
0

0

1

1

0

0

1

0

0
0

1

1

1

0

1

0

0

1

0

0

1
1

1

0

1

0

1
1

0

1

1

1

0

1

1

1

1

1

1

D0
010
1
0

0
1
0
1
0
1
0
1

1
00
1
0
1
0

1
0
1
0
1
0
1
0
1
0
1

PROJECT : EF6

Quanta Computer Inc.

Block Diagram

5

35 37Monday, January 03, 2005

35

CPU_CORE 4,36

Output

1.708V

1.692V

1.676V

1.660V

1.644V

1.628V

1.612V

1.596V

1.580V

1.564V

1.548V

1.532V

1.516V

1.500V

1.468V

1.452V

1.436V

1.420V

1.404V

1.388V

1.372V

1.356V

1.340V

1.324V

1.308V

1.292V

1.276V

1.260V

1.244V

1.228V

1.212V

of

1A

1

2

3

4

5

36

VIN VCCP

A A

3VPCU

PR14
22C

S5_OND 33

65241

PQ23
AO6402

3V_S5

PC37
.01U

2

3V_S5
72mA

S0-S5

VIN

PR5
*1M

3

1

PQ7
2N7002E

10V

MAIND

SUSON22,32

PR170
1M

PC8
2200P

VRON22,35

PQ32
DTC144EUA

SUSON

MAIND 31,32,33

LAN_POWER22

PR11
22C

3V_S55V_S5

PR149
22C

Z2712

3

2

1

PQ56
2N7002E

PR9
22C

Z2705

3

2

1

PQ9
2N7002E

PR148
*1M

2

2

3

1

PQ55
2N7002E

+5V

PQ13
2N7002E

10V

S5_OND

PR13
22C

Z2706

3

1

PR168
1M

3

PC151
2200P

+3V+1.5V+2.5V

Z2707Z2704

3

2

1

PQ14
2N7002E

VIN 1.5V_S5 VIN

PR147

PQ54
DTC144EUA

PR4
1M

PR3
1M

1M

PR146
1M

+1.8V SMDDR_VTERM

PR10
22C

Z2726 Z2725

3

2

1

PQ10
2N7002E

S5_ONG

S5_ON

2

PQ4

DTC144EUA

2

1 3

VIN

MAINON_G

1 3

S5_ON22

B B

C C

MAINON22,32,34

PR151
22C

Z2724

3

2

1

PQ58
2N7002E

PR12
22C

3

2

1

PQ12
2N7002E

PR150
22C

Z2711

3

2

1

PQ57
2N7002E

3

2

1

PQ11
2N7002E

VRON_D

2

1 3

VIN

SUSON_G

2

PQ6

1 3

DTC144EUA

DTC144EUA

PR85
1M

PR86
1M

PR6
1M

PR8
1M

PQ29

CPU_CORE

PR84
22C

Z2788 Z2789

3

2

1

PQ34
2N7002E

1.8VSUS

PR17
22C

Z2708 Z2709

3

2

1

PQ17
2N7002E

2

1 3

PR83
22C

3

2

1

PQ33
2N7002E

+3VSUS VIN+5VSUS

PR16
22C

3

2

1

PQ16
2N7002E

VIN LANVCC VIN

PR80
1M

LAN_POWER_G

PR79
1M

PR15
22C

Z2710

3

2

1

PQ15
2N7002E

PR82
22C

Z2713

3

2

1

PQ30
2N7002E

PR7
*1M

2

2

PQ28
2N7002E

PQ5
2N7002E

PR81
1M

3

1

3

1

LAN_ON

10V

SUSD

PR169
1M

PC69
2200P

SUSD 33

PC6
2200P

LAN_ON 26

D D

Size Document Number Rev
Custom

1

2

3

4

Date: Sheet

PROJECT : EF6

Quanta Computer Inc.

DISCHARGE

5

of

36 37Monday, January 03, 2005

1A

A

B

C

D

E

37 37Monday, January 03, 2005

37

1A

of

BLUETOOTH CONNECTOR

CN15

1

GND1

USBP3+15

USBP3-15

D D

C C

HW_RADIO_DIS#15

BT_AVTIVE25

WLAN_ACTIVE25

+3V

BT_AVTIVE_R
HW_RADIO_DIS#
WLAN_ACTIVE_R

BLUELED

NEWCARD (PCIEXPRESS*1 + USB*1)

B B

USBP7-15
USBP7+15

PCIE_WAKE#15

CLK_PCIE_NEWC#2
CLK_PCIE_NEWC2

PCIE_RXN015
PCIE_RXP015

A A

PCIE_TXN015
PCIE_TXP015

1.5V_NEWCARD

-USBCONP7
+USBCONP7

CPUSB#

NEW_CGCLK_SMB
NEW_CGDAT_SMB

3VAUX

R363 *0

1 2

R364 *0

1 2

PERST#

CLKREQ#
CPPE#

3V_NEWCARD

*NEW_CARD_SLOT

1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26

CN28

GND_1
USB­USB+
CPUSB#
RSV_0
RSV_1
SMBCLK
SMBDATA
+1.5V
+1.5V
WAKE#
+3.3VAUX
PERST#
+3.3V_1
+3.3V_2
CLKREQ#
CPPE#
REFCLK­REFCLK+
GND_2
PERn0
PERp0
GND_3
PETn0
PETp0
GND_4

NC4

NC3

NC2

NC1

302928

27

C TEST modified ESD

A

B

2

USB_D+

3

USB_D-

4

RSVD

5

BT_AVTIVE(PIO5)

6

HW_RADIO_DIS#

7

WLAN_ACTIVE(PIO6)

8

+3.3V

9

LED

10

GND2

BLUETOOTH

R213 *0

1 2

R214 0

1 2

R212 0

1 2

R215 *0

1 2

CLKREQ#

PLTRST#5,14,15,30

WLAN_ACTIVE_R

BT_AVTIVE_R

WLAN_ACTIVE_R

BT_AVTIVE_R

3V_NEWCARD

T117 PAD

WL_LED#23

RF_LINK25

For bluetooth V1.2 spec option and combine intel wireless
lan module use ,BC2-ext also provide the co-existence
solution .

+3V

R78
10K

NEWCARDCLKREQ#

3

1

Q31

PERST#
CPUSB#
CPPE#
RCLKEN

Q28

*CH2507S

2
3

11
12
19
20

9

RCLKEN

U44

SHDN#
STBY#

CPUSB#
CPPE#
RCLKEN
OC#

NC

*TPS2231

R360
*10K

2

T118PAD

2

3

*CH2507S

1

2231_SHDN#
2231_STBY#

C

Q19

2

DTC144EUA

NEWCARDCLKREQ# 2

41

3.3V_IN1SYSRST#

5

3.3V_IN2

6

3.3V_OUT1

78

3.3V_OUT2PERST#

AUX_OUT

1.5V_IN1

1.5V_IN2

1.5V_OUT1

1.5V_OUT2

GND

18
17

15
16
13
14

10

3.3VAUX_IN

1 3

PCLK_SMB2,15

PDAT_SMB2,15

Q20

BLUELED

2

DTC144EUA

C TEST Modified

+3V
3V_NEWCARD

+3VSUS
3VAUX

+1.5V

1.5V_NEWCARD

D

1 3

3V_NEWCARD

2

3

*CH2507S

Q29

2

3

Q30

3VAUX

C514

*0.1U

Size Document Number Rev
Custom

Date: Sheet

R361
*4.7K

NEW_CGCLK_SMB

1

3V_NEWCARD

R362
*4.7K

NEW_CGDAT_SMB

1

*CH2507S

1.5V_NEWCARD

C515

*0.1U

PROJECT : EF6

Quanta Computer Inc.

NEW CARD

E
