Copyright and Trademark Information

Copyright

Fujitsu Computer Systems Corporation has made every effort
to ensure the accuracy and completeness of this document.
However, as ongoing development efforts are continually
improving the capabilities of our products, we cannot
guarantee the accuracy of the contents of this document. We
disclaim liability for errors, omissions, or future changes. The
absence of a product or service name, slogan, or logo does not
constitute a waiver of any trademark or other intellectual
property rights relating to that name, slogan, or logo owned by
Fujitsu Computer Systems Corporation, its parent, subsidiaries,
and affiliated companies.

Fujitsu, the Fujitsu logo, and LifeBook are registered trade­marks of Fujitsu Limited.

Intel and Pentium are registered trademarks and Centrino is a
trademark of Intel Corporation or its subsidiaries in the United
States and other countries.

IBM, IBM PC AT, and IBM PS/2 are registered trademarks of
IBM Corporation in the United States, other countries, or both.

MS, MS-DOS, and Windows are either registered trademarks
or trademarks of Microsoft Corporation in the United States
and/or other countries.

PCMCIA is a trademark of the Personal Computer Memory
Card International Association.

Memory Stick and Memory Stick Duo are trademarks of Sony,
its parent, and/or its affiliates.

Adobe, Acrobat, and Acrobat Reader are either registered trade­marks or trademarks of Adobe Systems, Incorporated in the
United States and/or other countries.

Dolby Headphone manufactured under license from Dolby
Laboratories. Dolby, Pro Logic, and the double-D symbol are
trademarks of Dolby Laboratories.

Quicken is a registered trademark and/or registered service
mark of Intuit, Inc. or one of its subsidiaries in the United
States and other countries.

InterVideo and WinDVD are registered trademarks of Inter­video, Inc.

Realtek is a registered trademark of Realtek Semiconductor
Corporation.

Norton AntiVirus is a registered trademark of Symantec
Corporation in the United States and other countries.

This product incorporates copyright protection technology that
is protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation
and other rights owners. Use of this copyright protection tech­nology must be authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.

All other trademarks mentioned herein are the property of their
respective owners.

W ar ni ng

Handling the cord on this product will expose
you to lead, a chemical known to the State of
California to cause birth defects or other
reproductive harm.

Wa sh ha nds after han dling.

© Copyright 2005 Fujitsu Computer Systems Corporation. All
rights reserved. No part of this publication may be copied,
reproduced, translated, stored, or transmitted in any electronic
form without the written consent of Fujitsu Computer Systems
Corporation.

B6FH-7661-01EN-00

DECLARATION OF CONFORMITY

according to FCC Part 15

Responsible Party Name: Fujitsu Computer Systems Corporation

Address: 1250 E. Arques Avenue

Telephone: [phone]

Declares that product: Base Model Configurations:

This device complies with Part 15 of the FCC rules. Operations are subject to the following two conditions:

(1) This device may not

cause harmful

interference,

interference received, including interference that may cause undesired operation.

Sunnyvale, CA 94085

LifeBook P7230 notebook

Complies with Part 15 of the FCC Rules.

(2) This device must accept any

P7120.book Page 2 Monday, October 10, 2005 4:38 PM

LifeBook P7000 Notebook

UL Notice

This unit requires an AC adapter to operate. Use only UL
Listed Class 2 Adapters with an output rating of 16
VDC, with a current of 3.75A minimum.

AC Adapter output polarity:

+

■

When using your notebook equipment, basic safety
precautions should always be followed to reduce the
risk of fire, electric shock and injury to persons,
including the following:

■

Do not use this product near water for example,
near a bathtub, washbowl, kitchen sink or laundry
tub, in a wet basement or near a swimming pool.

■

Avoid using the modem during an electrical storm.
There may be a remote risk of electric shock from
lightning.

■

Do not use the modem to report a gas leak in the
vicinity of the leak.

■

Use only the power cord and batteries indicated in
this manual. Do not dispose of batteries in a fire.
They may explode. Check with local codes for
possible special disposal instructions.

■

To reduce the risk of fire, use only No. 26 AWG or
larger UL Listed or CSA Certified Telecommunication
Line Cord

SAVE THESE INSTRUCTIONS

For Authorized Repair Technicians Only

■

For continued protection against risk of
fire, replace only with the same type and
rating fuse.

■

Danger of explosion if Lithium (clock)
battery is incorrectly replaced. Replace
only with the same or equivalent type
recommended by the manufacturer. Dis­pose of used batteries according to the
manufacturer’s instructi

on.

System Disposal

LAMP(S) INSIDE THIS PRODUCT
CONTAIN MERCURY AND MUST

Hg

BE RECYCLED OR DISPOSED OF
ACCORDING TO LOCAL, STATE, OR
FEDERAL LAWS.

P7120.book Page 3 Monday, October 10, 2005 4:38 PM

Table of Contents

Fujitsu LifeBook® P7000 Notebook

Table of Contents

1

PREFACE

Preface

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . .1

Fujitsu Contact Information . . . . . . . . . . . . . . . . .1

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

2

GETTING TO KNOW YOUR
LIFEBOOK NOTEBOOK

Overview

Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Locating the Controls/Connectors

Top and Front Components . . . . . . . . . . . . . . . . .6

Left-Side Panel Components . . . . . . . . . . . . . . . .8

Right-Side Panel Components . . . . . . . . . . . . . . .9

Rear Panel Components . . . . . . . . . . . . . . . . . . .10

Bottom Components . . . . . . . . . . . . . . . . . . . . .11

Touchpad Pointing Device

Clicking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Double-Clicking . . . . . . . . . . . . . . . . . . . . . . . . .15

Dragging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Scrolling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Touchpad Control Adjustment . . . . . . . . . . . . . .16

Volume Control

Controlling the Volume . . . . . . . . . . . . . . . . . . .17

Flexible Bay Devices

Removing and Installing Modular Devices . . . . .18

3

GETTING STARTED WITH YOUR
LIFEBOOK NOTEBOOK

Power Sources

Connecting the Power Adapters . . . . . . . . . . . . .23

Display Panel

Opening/Closing the Display Panel . . . . . . . . . .24

Adjusting Display Panel Brightness . . . . . . . . . . .24

Status Indicator Panel

Battery Charging Indicators . . . . . . . . . . . . . . . .12

Battery Level Indicators . . . . . . . . . . . . . . . . . . .12

Hard Disk/Optical Drive Access Indicator . . . . . .12

Num Lock Indicator . . . . . . . . . . . . . . . . . . . . . .12

Caps Lock Indicator . . . . . . . . . . . . . . . . . . . . . .12

Scroll Lock Indicator . . . . . . . . . . . . . . . . . . . . . .12

Keyboard

Using the Keyboard . . . . . . . . . . . . . . . . . . . . . .13

Numeric Keypad. . . . . . . . . . . . . . . . . . . . . . . . .13

Windows Keys . . . . . . . . . . . . . . . . . . . . . . . . . .13

Cursor Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Function Keys. . . . . . . . . . . . . . . . . . . . . . . . . . .14

Starting Your LifeBook Notebook

Power On. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

BIOS Setup Utility. . . . . . . . . . . . . . . . . . . . . . . .25

Booting the System . . . . . . . . . . . . . . . . . . . . . .26

Registering Your LifeBook notebook. . . . . . . . . . 26

Installing Click Me! . . . . . . . . . . . . . . . . . . . . . .26

Power Management

Suspend/Resume/Power On Button. . . . . . . . . .27

ECO Button . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Suspend Mode . . . . . . . . . . . . . . . . . . . . . . . . . .27

Hibernation Feature . . . . . . . . . . . . . . . . . . . . . .28

Display Timeout . . . . . . . . . . . . . . . . . . . . . . . . .28

Hard Disk Timeout . . . . . . . . . . . . . . . . . . . . . . .28

Windows Power Management . . . . . . . . . . . . . .28

Restarting the System. . . . . . . . . . . . . . . . . . . . .28

Power Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

P7120.book Page 4 Monday, October 10, 2005 4:38 PM

LifeBook P7000 Notebook

4

USER-INSTALLABLE FEATURES

Lithium ion Battery

Recharging the Batteries. . . . . . . . . . . . . . . . . . . 31

Replacing the Battery . . . . . . . . . . . . . . . . . . . . . 32

External Floppy Disk Drive

Loading a Disk . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Ejecting a Disk . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Preparing a Disk for Use. . . . . . . . . . . . . . . . . . . 33

Optical Drive

Media Player Software . . . . . . . . . . . . . . . . . . . . 34

Loading a DVD or CD . . . . . . . . . . . . . . . . . . . . 34

Removing Media . . . . . . . . . . . . . . . . . . . . . . . .35

Using the Optical Drive Software . . . . . . . . . . . . 35

Using DolbyTM Headphone. . . . . . . . . . . . . . . . 35

Using the Optical Drive on Battery Power . . . . . 36

Auto Insert Notification Function . . . . . . . . . . . .36

Emergency Tray Release. . . . . . . . . . . . . . . . . . . 36

PC Cards

Installing PC Cards . . . . . . . . . . . . . . . . . . . . . . . 37

Removing PC Cards . . . . . . . . . . . . . . . . . . . . . . 37

Memory Stick/SD/xD Slot

Installing Memory Stick/SD/xD Cards . . . . . . . . 38

Removing A Memory Stick/SD/xD Card . . . . . . 39

Memory Upgrade Module

Accessing the Memory Compartment . . . . . . . . 40

Removing a Memory Module. . . . . . . . . . . . . . . 40

Installing a Memory Module . . . . . . . . . . . . . . .41

Checking the Memory Capacity . . . . . . . . . . . . . 41

Device Ports

Modem (RJ-11) Telephone Port . . . . . . . . . . . . . 42

Internal LAN (RJ-45) Port. . . . . . . . . . . . . . . . . . 42

IEEE 1394 Port . . . . . . . . . . . . . . . . . . . . . . . . . . 43

S-Video Out Port (TV Out) . . . . . . . . . . . . . . . .43

Universal Serial Bus Ports . . . . . . . . . . . . . . . . . . 43

Headphone/Line-Out Jack . . . . . . . . . . . . . . . . .43

Microphone Jack . . . . . . . . . . . . . . . . . . . . . . . . 44

External Video Port . . . . . . . . . . . . . . . . . . . . . . 44

5

WIRELESS LAN USER’S GUIDE

Before Using the Wireless LAN

Wireless LAN Modes Using this Device . . . . . . . 48

Wireless Network Considerations. . . . . . . . . . . . 49

Deactivating the WLAN Device . . . . . . . . . . . . . 49

Activating the WLAN Device . . . . . . . . . . . . . . . 50

Configuration of the WLAN Device

Flow of Operations . . . . . . . . . . . . . . . . . . . . . . 51

Configuration Using Intel PROSet Software . . . . 51

Configuration Using Atheros Client Utility . . . . . 52

Connection to the Network . . . . . . . . . . . . . . . . 53

Troubleshooting the WLAN

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . 57

Wireless LAN Glossary

Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

IP address information

Additional Information. . . . . . . . . . . . . . . . . . . . 60

WLAN Specifications

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Using the Bluetooth Device

What is Bluetooth . . . . . . . . . . . . . . . . . . . . . . . 62

Where to Find Information About Bluetooth . . . 62

6

TROUBLESHOOTING YOUR
LIFEBOOK NOTEBOOK

Troubleshooting

Identifying the Problem . . . . . . . . . . . . . . . . . . . 65

Specific Problems . . . . . . . . . . . . . . . . . . . . . . . . 65

Troubleshooting Table . . . . . . . . . . . . . . . . . . . . 66

Power On Self Test Messages . . . . . . . . . . . . . . 73

Emergency DVD Tray Release . . . . . . . . . . . . . . 74

Modem Result Codes. . . . . . . . . . . . . . . . . . . . . 74

Restoring Pre-installed Software

Restoring the Factory Image . . . . . . . . . . . . . . . 75

Automatically Downloading Driver Updates. . . . 76

P7120.book Page 5 Monday, October 10, 2005 4:38 PM

Table of Contents

7

CARING FOR YOUR
LIFEBOOK NOTEBOOK

Care and Maintenance

Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80

Floppy Disks and Drives . . . . . . . . . . . . . . . . . . .80

Media Care . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

PC Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

8

SYSTEM SPECIFICATIONS

Specifications

Configuration Label . . . . . . . . . . . . . . . . . . . . . .85

Microprocessor. . . . . . . . . . . . . . . . . . . . . . . . . .85

Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Mass Storage Device Options. . . . . . . . . . . . . . .85

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Device Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . .86

Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86

Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86

Dimensions and Weight . . . . . . . . . . . . . . . . . . .86

Environmental Requirements . . . . . . . . . . . . . . .86

Popular Accessories . . . . . . . . . . . . . . . . . . . . . .86

Pre-Installed Software . . . . . . . . . . . . . . . . . . . .87

Learning About Your Application Software. . . . . 87

Regulatory Information . . . . . . . . . . . . . . . . . . .89

9

GLOSSARY

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93

APPENDIX:
FINGERPRINT SENSOR DEVICE

Introducing the Fingerprint Sensor Device . . . . .99

Getting Started. . . . . . . . . . . . . . . . . . . . . . . . . .99

Installing OmniPass . . . . . . . . . . . . . . . . . . . . . .99

User Enrollment . . . . . . . . . . . . . . . . . . . . . . . .100

Using OmniPass . . . . . . . . . . . . . . . . . . . . . . . .101

Configuring OmniPass . . . . . . . . . . . . . . . . . . .103

OmniPass Control Center. . . . . . . . . . . . . . . . .104

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . .105

INDEX

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107

P7120.book Page 6 Monday, October 10, 2005 4:38 PM

LifeBook P7000 Notebook

P7120.book Page 1 Monday, October 10, 2005 4:38 PM

Preface

1

P7120.book Page 2 Monday, October 10, 2005 4:38 PM

LifeBook P7000 Notebook

P7120.book Page 1 Monday, October 10, 2005 4:38 PM

Preface

Preface

ABOUT THIS GUIDE

The LifeBook P7120/P7120D Series notebook from
Fujitsu Computer Systems Corporation is a small but
powerful computer. It is powered by an Intel Pentium M
Ultra Low Voltage (ULV) processor, has a built-in wide­aspect Crystal View color display, and brings the func­tionality of desktop personal computers (PCs) to a
portable environment.

This manual explains how to operate your LifeBook
notebook’s hardware and built-in system software.

It comes with Microsoft Windows® XP Home or
Window XP Pro pre-installed.

Conventions Used in the Guide

Keyboard keys and on-screen buttons appear in
brackets. Example: [Fn], [F1], [ESC], and [CTRL].

Pages with additional information about a specific topic
are cross-referenced within the text.
Example: (See page xx.)

DOS commands you enter appear in Courier type.
Example: Shutdown the computer?

The information icon highlights
information that will enhance your
understanding of the subject material.

FUJITSU CONTACT INFORMATION

Service and Support

You can contact Fujitsu Service and Support in the
following ways:

■

Toll free: 1-800-8Fujitsu (1-800-838-5487)

■

E-mail: [e-mail]

■

Web site:
http://www.computers.us.fujitsu.com/support

Before you place the call, you should have the following
information ready so that the customer support
representative can provide you with the fastest possible
solution:

■

Product name

■

Product configuration number

■

Product serial number

■

Purchase date

■

Conditions under which the problem occurred

■

Any error messages that have occurred

■

Type of device connected, if any

Fujitsu Online

You can go directly to the online Fujitsu Product catalog
for your LifeBook notebook by clicking on the Fujitsu
Weblinks -> LifeBook Accessories Web site URL link,
located in the Windows Start menu, or by going to
www.shopfujitsu.com.

You can also reach Fujitsu Service and Support online by
clicking on the Fujitsu Weblinks -> Service and Support
Web site URL link, located in the Windows Start menu

.

The caution icon highlights information
that is important to the safe operation of
your computer, or to the integrity of your
files. Please read all caution information
carefully.

The warning icon highlights information
that can be hazardous to either you, your
LifeBook notebook, or your files. Please
read all warning information carefully.

You must have an active internet connec­tion to use the online URL links.

WARRANTY

Your LifeBook notebook is backed by an International
Limited Warranty. Check the service kit that came with
your notebook for warranty terms and conditions.

1

P7120.book Page 2 Monday, October 10, 2005 4:38 PM

LifeBook P7000 Notebook – Section One

2

P7120.book Page 3 Monday, October 10, 2005 4:38 PM

Getting to Know
Your LifeBook Notebook

2

3

P7120.book Page 4 Monday, October 10, 2005 4:38 PM

LifeBook P7000 Notebook – Section Two

4

P7120.book Page 5 Monday, October 10, 2005 4:38 PM

Getting to Know Your LifeBook

Figure 2-1 Fujitsu LifeBook P7000 notebook

Overview

This section describes the components of your Fujitsu
LifeBook P7000 notebook. We strongly recommend that
you read it before using your notebook – even if you are
already familiar with notebook computers.

UNPACKING

When you receive your LifeBook notebook, unpack it
carefully, and compare the parts you have received with
the items listed below.

■

LifeBook P7000/P7000D notebook(Figure 2-1)

■

AC adapter with AC power cord (Figure 2-2)

■

Lithium ion battery

■

Wei g ht S ave r

■

Phone/Modem (RJ-11) telephone cable

■

Driver and Application Restore Disc

■

Recovery Disc

■

Getting Started Guide

■

User’s Guide (this document)

■

International Limited Warranty Brochure

■

Certification of Authenticity

Depending upon the configuration of your system, one
or more of the following items may also be included:

■

Modular DVD/CD-RW Combo Drive

■

Modular Dual-Layer Multi-Format DVD Writer

■

External Floppy Disk Drive

■

Modular 2nd battery

■

Additional main high capacity battery

■

RecordNow CD (included with Combo drive)

■

RecordNow and WinDVD Creator CD (included with
Dual-Layer Multi-Format DVD Writer)

Once you have checked and confirmed that your Life­Book system is complete, read through the following
pages to learn about all of your notebook’s components.

Figure 2-2 AC Adapter

5

P7120.book Page 6 Monday, October 10, 2005 4:38 PM

LifeBook P7000 Notebook – Section Two

Fingerprint Sensor/Scroll Button

Built-in Microphone

Wireless LAN On/Off Switch

Display Panel

Status Indicator Panel

ECO Button

Built-in Microphone

Suspend/Resume/
Power On Button

Figure 2-3 LifeBook notebook with display open

Locating the Controls
and Connectors

TOP AND FRONT COMPONENTS

The following is a brief description of your LifeBook
notebook’s top and front components.

Built-in Microphones

The two built-in microphones allow you to input mono
audio. The built-in microphones support noise-cancel­lation when used with applicable third-party software.

Wireless LAN On/Off Switch

Allows you to turn the optional Wireless LAN device on
and off. Note that this switch is present on all models of
the LifeBook P7000 notebook, but it is functional only
on those with an optional Wireless LAN installed.

Display Panel

The display panel is a color LCD panel with back
lighting for the display of text and graphics.

Status Indicator Panel

The Status Indicator Panel displays symbols that corre­spond with a specific component of your LifeBook note­book. (See Status Indicator Panel on page 12 for more

information)

Keyboard

Touchpad Pointing Device

Microphone Jack

Headphone Jack

PC Card Eject Button

Suspend/Resume/Power On Button

The Suspend/Resume/Power On button allows you to
suspend notebook activity without powering off, resume
your LifeBook notebook from suspend mode, and
power on your notebook when it has been shut down
from Windows. (See Suspend/Resume/Power On Button

on page 27 for more information)

ECO Button

The ECO button launches the Power Saving Utility
which is programmed in the LifeBook Application
Pane l. (See ECO Button on page 27 for more information)

Keyboard

A full-size keyboard with dedicated Windows
keys. (See Keyboard on page 13 for more information)

Touchpad Pointing Device/Scroll Button

The Touchpad pointing device is a mouse-like cursor
control with three buttons (left, right, and fingerprint
sensor/scroll button). (See Touchpad Pointing Device on
page 15 for more information).

Microphone Jack

The microphone jack allows you to connect an external
mono microphone. (See Microphone Jack on page 44 for

more information)

6

P7120.book Page 7 Monday, October 10, 2005 4:38 PM

Headphone/Line-Out Jack

The headphone/line-out jack allows you to connect
headphones or powered external speakers. (See Head-

phone/Line-Out Jack on page 43 for more information)

PC Card Eject Button

The PC Card Eject button allows you to remove a card
from the PC Card slot. (See Removing PC Cards on

page 37 for more information)

Getting to Know Your LifeBook

7

P7120.book Page 8 Monday, October 10, 2005 4:38 PM

LifeBook P7000 Notebook – Section Two

Anti-theft Lock Slot

IEEE 1394 Port

PC Card Slot

USB 2.0 Ports

Modem Port

S-Video Out Port

External Monitor Port

LAN (RJ-45) Port

Figure 2-4 LifeBook notebook left-side panel

LEFT-SIDE PANEL COMPONENTS

The following is a brief description of your LifeBook
notebook’s left-side components.

Anti-theft Lock Slot

The anti-theft lock slot allows you to attach an optional
physical lock-down device.

IEEE 1394 Port

The IEEE 1394 port (also known as “Firewire”) is used
to connect between your LifeBook and a peripheral such
as a digital video camera. (See IEEE 1394 Port on page 43

for more information)

PC Card Slot

The PC Card Slot allows you to insert one Type II PC
Card. (See PC Cards on page 37 for more information)

USB 2.0 Ports

The USB ports allow you to connect Universal Serial Bus

2.0 devices. There are two USB ports on the left side of
the system and one on the right. (See Universal Serial Bus

Ports on page 43 for more information)

Modem (RJ-11) Telephone Port

The Modem (RJ-11) telephone port is for attaching
a telephone line to the internal multinational 56K
modem. (See Modem (RJ-11) Telephone Port on page 42

for more information)

The internal multinational modem is
designed to the ITU-T V.90 standard. Its
maximum speed of 53000bps is the
highest allowed by FCC, and its actual
connection rate depends on the line
conditions. The maximum speed is
33600bps at upload.

For additional information about the
multinational modem, refer to the Fujitsu
web site at: us.fujitsu.com/computers.

S-Video Out Port

The S-video out port is used to transmit a higher resolu­tion video signal to a compatible TV or VCR.

(See S-Video Out Port (TV Out) on page 43 for more
information)

External Monitor Port

The external monitor port allows you to connect your
LifeBook notebook to an external monitor. (See External

Video Port on page 44 for more information)

LAN (RJ-45) Port

The internal LAN (RJ-45) port is used for an internal
Fast Ethernet (10/100 Base-TX) connection.

(See Internal LAN (RJ-45) Port on page 42 for more infor­mation)

The internal modem is not intended for
use with Digital PBX systems. Do not
connect the internal modem to a Digital
PBX as it may cause serious damage to the
internal modem or your entire notebook.
Consult your PBX manufacturer’s
documentation for details. Some hotels
have Digital PBX systems. Be sure to find
out BEFORE you connect your modem.

8
