Fujitsu WB0109 User Manual

Download

Operating Manual

FUJITSU Tablet STYLISTIC Q739

System

Contact address in North America

FUJITSU AM

ERICA INC.

1250 East Arques Avenue, Sunnyvale,

CA 94085-3470, U.S.A.

e: 800 831 3183 or 408 746 6000

Telephon

"http://solutions.us.fujitsu.com"

"http://solutions.us.fujitsu.com/contact"

estion? Email us at: "AskFujitsu@us.fujitsu.com"

Have a qu

ujitsu America, Inc. All rights reser

FPC65-7872-02

ved

FUJITSU Tablet STYLISTIC Q739

Operating Manual

Declarations of conformity 7 Fujitsu Contact Information 8 Ports and controls 10 Important notes 13 First-time setup of your device 17 WorkingwiththeTabletPC 21 Accessories for your Tablet PC

(optional) 37 Security functions 60 Connecting external devices 67 Settings in BIOS Setup Utility 72 Troubleshooting and tips 74 Technical data 83 Manufacturer’s notes 89 FCC and IC Regulatory Information 92 Canadian Notice / Avis pour le Canada 96 Appendix 97 Index 112

Fujitsu America, Incorporated has made every effort to ensure the accuracy and completeness of this document; however, as ongoing development efforts are continually improving the capabilities of our products, we cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.

Fujitsu, the Fujitsu logo and STYLISTIC are registered trademarks of Fujitsu Limited or its subsidiaries in the United States and other countries.

Intel and Intel Core are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

HDMI and HDMI High-Deﬁnition Multimedia Interface and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and/or other countries.

Google is a trademark or registered trademark of Google Incorporated. Bluetooth is a trademark of Bluetooth SIG, Inc., USA. USB Type-C is a trademark or registered trademark of the USB Implementers

Forum in the USA and other countries. USB Type-C is a trademark or registered trademark of the USB Implementers

Forum in Canada and other countries. Adobe, Acrobat, and Adobe Reader are either registered trademarks or trademarks of Adob e

Systems Incorporated in the United States a nd/or other countries. All other trademarks speciﬁed here are the property of their respective owners.

Contents

Declarations ofconformity ............................................................. 7

Fujitsu Contact Informatio

Notational conventions .................................................................. 9

Portsandcontrols ..................................................................... 10

Importantnotes ........................................................................ 13

Safety instructions ...................................................................... 13

Additional safety note Protecting the displa

Energy saving .......................................................................... 14

Energy saving under W

Traveling with your T

Before you travel ................................................................... 15

Transporting the T

Cleaning the Table

First-time setup ofyourdevice ......................................................... 17

Unpacking and checking the device . . . ................................................... 17

Choose a location . ...................................................................... 18

Connecting the AC adapter . . . ........................................................... 18

Switching on the device for the ﬁrst time .................................................. 19

Installing Bonus Apps . . . . . ........................................................... 20

Working with t

Status indic Switching th

Programming Switching t Handwritin Touchscree Select dis Using ﬁng

Using the

Tabl e Camer Recha

Usin Memo

play orientation(portraitor landscape format) ....................................

ers ...........................................................................

Calibrat

stylus .........................................................................

Stylus l Energy s Chargin

ingthestylus ..................................................................

Adjust

atingthe stylus ................................................................

Calibr

ling astylus tether ..............................................................

Instal

tbuttons ..........................................................................

a ................................................................................

rgeablebattery ...................................................................

ging and maintaining the battery .................................................

Char

gthepower-saving functions .........................................................

ry cards ..........................................................................

ported formats ..................................................................

Sup

erting the memorycard ...........................................................

Ins

ovingthememory card ..........................................................

Rem

Mcard(conﬁguration-dependent) . . . ...................................................

tPC ..................................................................

he Tablet PC ............................................................

ators ........................................................................

eTablet PCon ..............................................................

theON/OFF button .....................................................

he Tablet PCoff ..............................................................

g recognition ..................................................................

n ............................................................................

ingthemonitorforstylus ortouchinput ........................................

ocation ......................................................................

avingfunctions ofthestylus ..................................................

gthestylus battery ...........................................................

n ............................................................

s for devices with wireless components . ..............................

yscreen ............................................................

indows .......................................................

abletPC ............................................................

abletPC ...........................................................

14 14

14 15

16 16

21 23 23 24 24 24 25 26 26 26 28 28 28 29 29 29 30 31 31 31 32 32 32 33 33 34

Fujitsu 3

Contents

Insertinga SIM card ................................................................. 34

Removing aSIM card ............................................................... 35

Wireless LAN/Bluetooth/4G/LTE wireless components . . . .................................. 35

Switching the wire less components on and off ......................................... 35

Conﬁguring WLANaccess ........................................................... 35

Furtherinformation onWLAN and Bluetooth ........................................... 35

Access via 4G/LTE ................................................................. 36

Ethernet and LAN (op tional, only with cradle, keyboard cover or adapter cable) . . . ........... 36

Accessories for your Tablet PC (optional) . ............................................. 37

Your docking cradle(optional) ............................................................ 38

Cradle components . . ................................................................ 38

Settingupthecradle ................................................................ 39

Connecting the Tablet PC to the cradle . . ............................................. 39

Disconnecting the Tablet PC from the c radle . ......................................... 41

Keyboard cover (optional) . . . ............................................................ 42

Components of the keyboard cover . . ................................................. 42

Connecting the Tablet PC to the keyboard cover . . . . . .................................. 43

Separating the Tablet PC from the keyboard cover . . . .................................. 44

Foliocover (optional) .................................................................... 45

Protective TPU cover .................................................................... 47

Components of the protective TPU cover . ............................................. 47

Safety precautions .................................................................. 48

Attachinga Smart Cardguide ........................................................ 49

Insertingthe Tablet PCin the protectiveTPU cover .................................... 50

Removing the Tablet PCfromtheprotective TPU cover ................................ 52

Usingthestand ..................................................................... 54

Removing the stand ................................................................. 55

Connecting the Tablet PC/protective TPU cover to the keyboard cover ................... 57

Connecting the Tablet PC/protective TPU cover to the cradle . .......................... 59

Security functions ..................................................................... 60

Conﬁguring the ﬁngerprint sensor (conﬁguration dependent) . . .............................. 60

UsingtheSecurity Lock ................................................................. 61

Conﬁguring passwordprotectioninBIOS SetupUtility ...................................... 61

Protecting BIOS Setup Utility (supervisor passw ord and user password) . . ............... 62

Password protection for booting the operating system .................................. 63

Password protection for the harddisk ................................................. 63

Smart Card reader (conﬁguration-dependent) ............................................. 65

Insertingthe Smart Card ............................................................. 65

Trusted Platform Module - TPM (conﬁguration dependent) .................................. 66

Enabling TPM ....................................................................... 66

Disabling TPM ...................................................................... 66

Connecting external devices ........................................................... 67

Connecting an external monitor . . ........................................................ 67

microHDMIport ..................................................................... 67

External monitorport(VGA) (cradle only) .............................................. 68

Connecting USB devices ................................................................ 69

USBport withcharging function (USB Type-C) ......................................... 70

Howto removeUSBdevicescorrectly ................................................ 70

Headphones/microphone/Line-In/Line-Out/headset-combi port .............................. 71

Settings in BIOS Setup Utility . . ........................................................ 72

4 Fujitsu

Contents

Starting the BIOSSetup Utility ........................................................... 72

BIOS Setup Utility operation ............................................................. 72

ExitingBIOSSetupUtility ................................................................ 73

Exit Saving Changes - save changes and exit BIOS Setup Utility . . ..................... 73

Exit Discarding C hange s - Reject changes and exit BIOS Setup Utility . . . . . .............. 73

Load Setup Defaults – load default values . ............................................ 73

Discard Changes - Discard C hanges without exiting BIOS Setup Utility . . . . .............. 73

Save Changes - save changes without exiting the BIOS Setup Utility . . . . . . .............. 73

Save changes and power off ........................................................ 73

Troubleshooting and tips .............................................................. 74

Executinga reset ....................................................................... 75

Forced shutdown .................................................................... 75

Resetting the rechargeable battery . ................................................... 75

Help ifproblems occur ................................................................... 75

If you need to rest ore your system . ....................................................... 75

TheTablet PC’sdate ortime isincorrect .................................................. 75

Batterychargingindicatornot lit .......................................................... 76

TheTablet PC’stouchscreen remains dark ................................................ 76

The display on the Tablet PC’s touchscreen is difﬁcult to read. . ............................. 76

Theexternal monitor remainsblank ...................................................... 77

Theexternal monitor isblank ortheimageis unstable ..................................... 77

The cursor does not correctly follow the stylus movements . . . . ............................. 77

Stylus input not working ................................................................. 78

TheTablet PCdoes notstart after switchon ............................................... 78

TheTablet PCstopsworking ............................................................. 78

The printer does not print . . . . . ........................................................... 79

The wireless connection t o a network does not work . . . .................................... 79

Thebatterydischargestoo quickly ........................................................ 79

Smart Card re ader is not recognized . . . ................................................... 80

SmartCard PIN forgotten ................................................................ 80

User and/or supervisor Smart Card lost . . . . . . ............................................ 80

SmartCard lost ......................................................................... 80

Acoustic warning ........................................................................ 81

Errormessages onthescreen ........................................................... 81

Technical data ......................................................................... 83

Tablet PC .............................................................................. 83

WLAN speciﬁcations .................................................................... 84

WWAN speciﬁcations ................................................................... 85

Screen resolutionsforintegrated screenandexternal screens .............................. 85

Rechargeablebattery ................................................................... 86

AC adapter 65 W for the Tablet PC with/without keyboard cover . . . ......................... 86

AC adapter 90 W for Tablet PC with cradle . . . . ............................................ 86

Cradle (optional) ........................................................................ 87

Keyboard cover (optional) ............................................................... 87

Folio cover (optional) . . .................................................................. 87

Protective TPU cover with stand, hand strap and shoulder strap (optional) . . . . . .............. 88

Manufacturer’snotes .................................................................. 89

Disposal and recycling .................................................................. 89

Recycling your battery ............................................................... 89

DOC(IndustryCANADA) Notices ........................................................ 90

UL Notice ........................................................................... 90

Fujitsu 5

Contents

ENERGY STAR Compliance ............................................................. 91

FCCandIC RegulatoryInformation .................................................... 92

Regulatory Notes and Statements ........................................................ 92

Wireless LAN,HealthandAuthorizationfor use ........................................ 92

Regulatory Information/Disclaimers . . ................................................. 92

Federal Communications Commission state m ent and Industry Canada statement: . . . . .... 93

Déclaration d’Industrie Canada . . . . . . ................................................. 93

FCCInterference Statement ......................................................... 93

FCC Radio Frequency Exposure statement . . . ......................................... 94

Déclaration de la FCC/d’Industrie Canada sur l’exposition aux radiofréquences ........... 94

Export restrictions ................................................................... 94

Restrictions concernant l’exportation . ................................................. 95

Canadian Notice/ Avispour leCanada ................................................. 96

Canadian Notice . ....................................................................... 96

Avis pour le Canada . . . . . ................................................................ 96

Appendix .............................................................................. 97

Before Using the Optional Wireless LAN . ................................................. 97

Wireless LAN Devices Covered bythisDocument ...................................... 97

Characteristics oftheWLAN Device .................................................. 97

Wireless LAN Modes Using this Device . . ............................................. 98

Deactivating/Disconnecting theWLANDevice ......................................... 100

Conﬁguring the WirelessLAN ............................................................ 101

Connection to the network . . . ........................................................ 101

Troubleshooting the WLAN ........................................................... 102

UsingtheBluetoothDevice ............................................................. 104

4G Sierra Wireless AirPrime EM7455B Regulatory and Safety Information ................... 105

Importantnotice ..................................................................... 105

Safety and hazards .................................................................. 106

Importantsafety/complianceinformationfor North Americanusers ....................... 107

FCC Radio Frequency Exposure statement . . . ......................................... 107

Image Backup and Recovery Procedures ................................................. 108

Windows 10 Procedures . ............................................................ 108

Creating arecovery drive ............................................................ 108

Recovery options inWindows 10 ..................................................... 108

Downloading driver updates . ............................................................ 111

Index .................................................................................. 112

6 Fujitsu

Declarations of conformity

Declarationsofconformity

Declarations of conformity

DECLARATION OF CONFORMITY

according to FCC Part 15

Responsible Party Name: Address:

Telephone: Declares that product:

This device complies with Part 15 of the FCC rules. Operations are subject to the

following two conditions: (1) This device may not cause harmful interference. (2) This

device must accept any interference received, including interference that may cause

undesired operation.

Fujitsu America, Inc.

1250 E. Arques Avenue

Sunnyvale, CA 94085

(408) 746-6000

Base Model Configuration: STYLISTIC Q739 (PQ13B)

Complies with Part 15 of the FCC Rules.

Fujitsu 7

Fujitsu Contact Information

Service and Support

You can contact Fujitsu Service and Support in the f ollowing ways:

• Toll free phone: 1-800-8Fujitsu (1-800-838-5487)

• Website: "

Fujitsu Shopping Online

Please go to "

Maintaining Latest Conﬁguration

To ensure that you always have the most curre nt driver updates related to your system, you should occasionally access t he Fujitsu Software Downlo ad Manager (FSDM) utility. The FSDM utility is available from the Fujitsu Support site. FSDM will allow you to view a list of the most current drivers, utilities and applications to determine whether you have the latest versions. If you have a Windows operating system, you will need to go to the Support Site to download the FSDM Utility: "

Limited Warranty

Your STYLISTIC Tablet PC is backed by a Fujitsu International Limited Warranty. Check the Limited Warranty Terms and Conditions Booklet that came with your Tablet PC .

http://solutions.us.fujitsu.com/www/content/support/contact/index.php"

Before you place the call, have the following information ready so that the customer support representative can provide you with the fastest possible s olution:

• Product name

• Product conﬁguration number

• Product serial number

• Purchase date

• Conditions under which the problem occurred

• Any error messages that have occurred

• Type of device connected, if any

http://www.shopfujitsu.com/store/ ".

http://support.fujitsupc.com/CS/Portal/support.do?srch=DOWNLOADS".

8 Fujitsu

Notational conventions

Pay particular attention to text marked with this symbol. Failure to observe this warning will endanger your life, will damage the device or lead to loss of data. The warranty will be invalidated if the device becomes defective through failure to observe these warnings.

Indicates important informa

Fujitsu Contact Information

tion which is required to use the device properly.

►



This style

"This style" indicates

Key

This style indicates terms and text that are emp hasized or highlighted, e.g.: Do not

indicates an activity th at must be performed indicates a result

indicates data entered the command line, e.g. start a program (star

indicates information that is displayed on the screen b y a program, e.g.:

Installation is complete.

indicates

• terms and texts used in a software interface, e.g.: C lick o n Save.

• names of programs or ﬁles, e.g. Windows or setup.exe.

• Cross-references to another section, e.g. "Safety information"

• cross-references to an external source, e.g. a web address: For more information, go to "

• names of CDs, DVDs and titles or designations of other materials, e.g.: "CD/DVD Drivers & Utilities"

indicates a key on the keyboard, e.g:

switch off the dev ice

using the keyboard in a program dialogue or at

your password (Name123)oracommandusedto

t.exe)

http://solutions.us.fujitsu.com/"

F10

Fujitsu 9

Ports and controls

This chapter presents the individual hardware components of your device. It gives an overview of the indicators and connections of the device. Please familiarize yourself with these items before you start to work with the device.

Front

1 = Power-on indicator 2 = Touchscree 3 = Microphone 4 = Ambient li 5=Camera 6=CameraLE

10 Fujitsu

ght sensor

7 = Speaker 8 = Mechanical

cover / cra

9=SIMcardslot(conﬁguration-dependent,

protected by cover)

10 = Docking p

mounting for keyboard

dle

ort

Left side

Ports and controls

6 7

1 = Battery charging indicator 2 = Wireless indic 3=microHDMIport 4 = USB port 3.1 with charging function

(USB Type-C)

Right side

ator

1 2 3 4 5 6

1 = Security Lock device 2 = USB port 2.0 (USB Type-A) 3 = Combined headphones and

microphone port

5 = USB port 3.0 (USB Type-A) 6 = Memory card slot 7 = DC input connector (DC IN)

4 = Smart Card slot (conﬁgurat ion-dependent) 5 = Attachment point for optional stylus tether 6 = Stylus slot

Fujitsu 11

Ports and controls

Top

1 2 3 4

1 = ON/OFF button 2 = Volume Up button

Rear

1 = Camera light 2=Came 3=CameraLED

3 = Volume Down button 4 = Shortcut button

4 = Fingerprint s enso r (conﬁguration

dependent)

12 Fujitsu

Important notes

ImportantnotesNotes

Safety instructions

SafetyinformationInformation,

This chapter co ntains essential safety information which must be followed when working with your Tablet PC. The other notes provide useful information about your Tablet PC.

Please observe the following safety information. Please pay special attention to the sections in the manual marked

with the symbol on the left. When connecting and d isconnecting cables, observe the relevant

notes in this operating manual. Read the information on the ambient conditions in the "

chapter and the "First-time setup of your device", Page 17 chapter before preparing your Tablet PC for use a nd switching it on for the ﬁrst time.

When cleaning the device, please observe the relevant notes in the section "

When handling this device, you will come into contact with lead, a chemical which in California is held to be a possible cause of birth defects and other damage to fertility.

Wash your hands after using the device. Do not place the device on uneven or unstable surfaces. Do not place any objects on the device. Do not apply any pressure to the device. Do not use the corners of the display to m ove it. Turn the display carefully. In d oing so, do not use excessive force. Lift and carry the device by holding it at the bottom an d not just at the display. Prevent harsh impacts, vibrations and shaking of the device and the display. On devices with touchscreen: Use very little pressure to carefully

tap and write on the display. Keep the ventilation slots free. Switch off the device before you put it inside a bag or backpack. In emergencies (e.g. damage to the device or power cable, entry of liquids

or foreign objects), immediately switch off the device and disconnect the AC plug. Short circuit, smoke and/or ﬁre may occur as a result. Please contact your sales outlet or our Hotline/Service Desk.

Cleaning the Tablet PC", Page 16.

Important notes

Technical data", Page 83

ablet PC complies with the relevant safety regulations for data processing equipment. If

This T

ave questions as to whether you can set up the Tablet PC in the intended environment,

you h

se contact your sales outlet or our hotline/service desk.

plea

Fujitsu 13

Important notes

Additional safety notes for devices with wireless co mponents

WirelesscomponentsWirelessLANBluetooth,Safetynotes

If a wireless component (Wireless LAN, Bluetooth, 4G) is integrated in your Tablet PC, you must be sure to observe the following safety precautions when using your Tablet PC:

• Switch off the wireless components when you are in an aircraft or driving in a car.

• Switch off the wireless compo nents when you are in a hospital, an operating room or near a m edical electronics system. The transmitted radio waves can impair the operation of medical devices.

• Switch off the wireless components, when you let the device get near ﬂammable gases or into hazardou s environments (e.g. gas station, paint stores), as the transmitted radio waves can cause an explosion or a ﬁre.

For further information on how to switch the wireless components on and off, refer to section "

Switching the wireless components on and off", Page 35.

Protecting the display screen

Do not pour liquid items on the top o

During normal u can become embe warranty does

Energy savin

NotesEnergyPowersavin

If you will not be using your Tablet PC, switch it off. Switch off any connected external devices when they are not in use . If you use the energy saving functions, the Tablet PC uses less power. If you do this, you will be able to work longer with the Tablet PC before having to recharge the battery.

The energy efﬁciency is increased an d environmental pollution is reduced. You save money and help p rotect the environment.

Energy saving under Windows

► Make use of the available energy-saving functions as described in chapter

Using the power-saving functions", Page 32.

s on the system or wash it with a heavily soaked cloth. Do not place

f the monitor in order to prevent it from being damaged.

se of the device, small particles from the environment

dded in the stylus tip and scratch the screen. The

not cover a scratched screen.

14 Fujitsu

Traveling with your Tablet PC

MobileoperationNotesTransportationTabletPC

Please follow the instructions below when traveling with your Tablet PC.

Before you travel

► Back up important data stored on your hard disk.

beforeyoutravelTravel

► Switch off the wireless c

connection, it is also po

omponent for data s ecurity reasons. W ith data trafﬁcviaawireless

ssible for unauthorized third parties to receive data.

Important notes

Information on activat for your wireless compo

ing data encryption is provided in the documentation

nent.

► If you want to use your Tablet PC during a ﬂight, ask the ﬂight attendants to seeit is safe to use it.

When traveling in other countries

► If you are traveling abroad, check that the AC adapter can be operated with the

local AC voltage. If this is not the case, obtain the appropriate AC adapter for your Tablet PC. Do not use any other voltage converter!

► Check whether the local AC voltage and the AC cable are compatible. If this is not

the case, buy an AC cable that suits the local conditions.

► Enquire with the appropriate government ofﬁce of the country you will be traveling in as to

whether you may the re operate the wireless component integrated in your Tablet PC.

► Take th e necessary travel adapters with you when traveling abroad. Ch eck in the following

table for which travel adapters you will need, or ask your travel organizer.

Power connection Travel destination

United States, Canada, Mexico, parts of Latin America, Japan, Korea, Philippines, Taiwan

Russia and the Commonwealth of Independent States (CIS), much of Europe, parts of Latin America, the Middle East, parts of Africa, Hong Kong, India, much of south-east Asia

United Kingdom, Ireland, Malaya, Singapore, parts of Africa

China, Australia, New Zealand

Fujitsu 15

Important notes

Transporting the Tablet PC

Protect the Tablet PC from severe shocks and extreme temperatures (e.g. direct sunlight in a car).

• Do not transport your Tablet PC while it is turned on.

• Carry your Tablet PC with you while traveling. Do not ch eck it in as baggage.

• Never put yo ur Tablet PC through a metal detector. Have it hand-inspected by security personnel. You can however put your Tablet PC through a properly tuned X-ray machine. To avoid problems, place it close to the entrance of the machine and remove it as soon as possible or have it hand-inspected by security personnel. Security ofﬁcials may require you to turn your Tablet PC on. So make sure you have a charged battery o n hand for this.

► Switch the Tablet PC off

► Unplug the AC plug of the AC adapter and all external devices from the power outlets. ► Disconnect the AC ad

apter cable and the data cables for all external devices.

► To protect against damaging jolts and bumps, use a suitable Tablet PC

carrying case to transport your Tablet PC.

Cleaning the Tablet PC

Do not clean any in Only use deterg

and polishes ca PC, the paintw

Ensure that no The touchscr

surface with

► Switch the Tablet PC off.

ons

en CleaningInstructi

Tablet PCKeyboardTouchpadTouchscre

The surfaces may be cleaned with a dry cloth. If particularly dirty, use a cloth which has



been moistened in mild domestic detergent and then carefully wrung out.

terior parts yourself; leave this job to a service technician.

ents designed for computers. Normal household cleaners n damage the labels on the keyboard and the Tablet

ork or the Tablet PC itself.

liquid enters the Tablet PC.

een is very sensitive to scratches! Only clean the display a very so ft, slightly damp cloth.

16 Fujitsu

First-time setup of your device

First-time setup of your devic

First-timesetu pGettingstarted

The battery must be charged if you want to operate your device using the battery. When used on the move, the built-in battery provides the device with the necessary power. You

can increase the operating time by using the available energy-saving functions. For instructions on how to connect external devices (e.g. mouse, printer) to your Tablet

PC, please refer to the operating manual for your device.

Unpacking and c

► Unpack all th e individual parts. ► Check your d

Please read the chapter "Important notes", Page 13. If your device is equipped with a Windows operat ing system, the necessary

hardware drivers and supplied software are already pre-installed. Before switching it on for the ﬁrst time, connect the device to the AC voltage using

the AC adapter, see " remain connected during the whole of the installation process.

A system test is performed when your device is ﬁrst switched on. Various messages can appear. The display m ay remain dark for a short time or may ﬂicker.

Please follow the instructions on th e screen. NEVER switch off your device during the ﬁrst-time setup process.

Connecting the AC adapter", Page 18. The AC adapter must

hecking the device

If you ﬁnd that damage has occurred during transport, please notify your local sales outlet immediately!

PackagingTransport

evice for any visible damage which may have occurred during transportation.

You may nee you need t

Fujitsu 17

d to reuse the packaging in the future, for example if

o ship your device.

First-time setup of your device

Choose a location

ChoosealocationSetupACada pter

Choose a suitable location for the device before setting it up. In doing so, please follow these instructions:

• Never place the device or the AC adapter on a heat-sensitive surface. The surface could be damaged as a result.

• Never place the device on a soft surface (e.g. carpeting, upholstered furniture, bed). This can result in damage caused by overheating.

• The back of the device heats up d uring normal op eration. Prolonged contact with skin can become unpleasant or even result in burns.

• Place the device on a stable, ﬂat, non-slippery surface. Please note that the rubber feet of the device may mark certain types of delicate surfaces.

• Keep other objects at least 100 mm / 3.94 inches away from the device and its AC adapter to ensure ade quate ventilation.

• Do not expose the device to extreme environme ntal conditions. Protect the device against dust, humidity and heat.

Connecting the AC adapter

MakingreadytouseACadapter

Please follow the ThesuppliedACc

you purchased yo use in the coun t

safety notes in section "

able conforms to the requirements of the country in which

ur device. Make sure that the AC cable is approved for

ry in which you intend to use it.

Important notes", Page 13.

► Connect the AC cable (1) to the AC adapter. ► Plug the AC cable (2) into a power outlet. ► Connect the AC adapter cable (3) to the

DC jack (DC IN) of the device.

18 Fujitsu

First-time setup of your device

Switching on the device for the ﬁrst time

Switchingonfortheﬁrsttime

To make it easier to use your device for the ﬁrst time, the operating system is pre-installed on the hard disk.

► Press the ON/OFF button (1) for about one second to switch t he device on.

The power



► During the installation process, follow the on-screen instructions.

Fujitsu 19

-on indicator (2) lights up whenever the system is switched on.

You can ﬁnd information and help on the Windows operating system functions online at "

http://windows.microsoft.com".

First-time setup of your device

Installing Bonus Apps

BonusApps

The Fujitsu Bonus Apps utility can be accessed via the Start menu.

► In the Start menu, click on Fujitsu Extras. ► Double-click on the Application folder. ► Double-click on the shortcut Fujitsu BonusApps. ► In the dialog box User Account Control by clicking Yes conﬁrmyouwishtoenterFujitsu Bonus Apps. ► Select the applications you wish to install by selecting the checkbox adjacent to your selection.

► Click Select All if you would like to install all available applications. Applications that are already installed appear in grey, those that are



available for installation appe ar in blue.

► To c on ﬁrm your selection, click Install.

Note that in some cases (depending upon which application was selected for installation) after installation completes, the system will prompt you to reboot.

There are also cases in which if multiple applications are selected to install but one of them needs a reboot, the system will reboot and continue installing the rest of the selected applications.

20 Fujitsu

Working with the Tablet PC

Working with the T ablet PC

Tablet,operationTablet

This chap ter describes the basics for operating your Tablet PC. You can ﬁnd instructions on how to connect external devices (e.g. mouse, ﬂash storage) to the Tablet PC in the chapter "

Status indicators

StatusindicatorsSymbols

The status indicators (1, 2 , 3) provide information about the statuses of the power supply, the rechargeable batteries and the wireless components.

Connecting external devices", Page 67.

Please refer to the notes in the chapter "Important notes", Page 13.

Fujitsu 21

Working with the Tablet PC

No. Status indicator Description

1 Power-on indicator

• The indicator lights up white: The Tablet PC is switched on.

• The indicator ﬂashes: The Tablet PC is in sleep mode (Save-to-RAM).

• The indicator is not lit up: The Tablet PC is switched off or in Save-to-Disk mode.

2 Battery charging indicator

Please note: If the AC adapter is connected whe n the state of charge of the battery is more than 90 %, charging will not be started. When the state of charge of the battery is less than 90 %, the battery will be charged to 100 % as soon as the AC adapter is connected.

• The indicator lights up orange: The rechargeable battery is charging.

• The indicator is not lit up: The rechargeable battery is not being charged (the battery is already more than 90% charged or the AC adapter is not connected).

3 Wireless indicator

• The indicator lights up white: The wireless components are switched on while the Tablet PC is switched on.

• The indicator ﬂashes: The wireless components are switched on and Wake On Wireless LAN is activated while the Tablet PC is in Sleep mode or Save-t o-Disk mode, or while the Tablet PC is switched off.

• The indicator is not lit up: The wireless components are switched off.

22 Fujitsu

Switching the Tablet PC on

Tablet:SwitchingonPower-onPower-onindicator

Working with the Tablet PC

► Press the ON

The power-on indicator (2) lights up whenever the system is switched on.



/OFF button (1) for about one second to switch the device on.

Programming the ON/OFF button

You can program the ON/OFF button:

Operating system Menu

Windows 10

If you have assigned a password, you must en ter this wh en requested to do so, in order to start the operating system. Detailed information can be found in the chapter "

Fujitsu 23

Security functio ns", Page 60.

Windows 10 Start - Control Panel - (Browse Control Panel - ) Power Options - Choose what the power buttons do

Working with the Tablet PC

Switching the Tablet PC off

Back up your data and close all applications before you switch off your device. Otherwise data might be lost.

► Shut down the operating system correctly.

Switchingoffthe

► If the Tablet PC does not switch itself off automatically, press the ON/O FF

button for approx. ﬁve seconds.

Handwriting recognition

For detailed information on handwriting recognition, see the documentation for your operating syst em. At present, handwriting recognition on Windows supports the following languages: English, German, French, Italian, Japanese, Korean, Chinese (traditional and simpliﬁed), Dutch,

Portuguese, Spanish, Brazilian, Norwegian (Bokmål and Nynorsk), Swedish, Finnish, Danish, Polish, Rumanian, Serbian (Cyrillic and Latin script), Catalan, Russian, Czech a nd Croatian.

On Windows you can set the required language under Control Panel – Time, Language and Region – Language.

Touchscreen

Touchsc reenNotes

Information on screen resolution can be found in the section "Screen resolutions

for integrated screen and external screens", Page 85.

High-quali these scree only be ens which diff

The scree Current p

isolated faulty p

Exampl

A monit three s subpi dark p subpi

24 Fujitsu

ty LCD screens (TFT) are installed in Fujitsu Tablet PCs. For technical reasons,

ns are manufactured for a speciﬁc re solution. An optimal, clear picture can

ured in the resolution intended for the particular screen. A screen resolution

ers from the speciﬁcation can result in an unclear picture.

n resolution of your Tablet PC’s touchscreen is optimally set at the factory.

roduction technology cannot guarantee an absolutely fault-free screen display. A few

constantly lit or unlit pixels may be present. The maximum permitted number of such

ixelsisspeciﬁed in the international standard ISO 9241-307 (Class II).

or with HD resolution 1280 x 1024 has 1,310,720 pixels. Each pixel consists of

ubpixels (red, green, and blue), which means that there are almost 3.9 million

xels in total. According to ISO 9241-307 (class II), a maximum of 3 light and 3

ixels and, in addition, 7 light or 13 dark subpixels or an equivalent mix (1 light

xel counts as 2 dark subpixels) are allowed to be defective.

Working with the Tablet PC

Pixel

A pixel consists of 3 subpixels, normally red, green and blue. A pixel is the smallest element that can be generated by complete functionality of the display.

Subpixel

A subpixel is a separately addressable internal structure within a pixel that enhances the pixel function.

Cluster A cluster contains two or more

subpixels in a 5 x 5 pixel bloc

defective pixels or

Background lighting

LCD screens are operated with background lighting. The luminosity of the background lighting can decrease over the period of use of the Tablet PC. However, you can set the brightness of your screen yourself.

Ambient light sensor

If your Tablet PC was shipped with the Windows operating system, the screen brightness is regulated by means of the ambient light sensor and depending on the respective light conditions. This results in optimum reada bility and longer battery life at the same time.

If your Tablet PC was shipped with Windows 10, the adaptive brightness setting is activated. To change the ambient light sensor settings, select Control Panel - System and Security - Power Options - Change plan settings - Change advanced power settings - Display - Enable adaptive brightness..

Synchronizing the display on the touchscreen and an external monito r

In Windows 10 you can proceed as follows to set the output type:

► Wipe your ﬁnger o

ver the screen starting from the right-hand edge.

► Select All settings. ► Look for the key

word "project".

► Select the required function.

Select display orientation (portrait or landscape f

eformat

format

rientation Landscap

Portrait

Displayo

You can choose to use either portrait or landscape for the display, or whether the screen orientation should automatically adjust to the orientation of the tablet PC.

You can change these se ttings under Control Panel - Hardware and Sound

- Windows M obility Center / Rotate screen.

In the settings there are proﬁles saved for op eration with different screen orientations. These proﬁles have preset standard conﬁgurations that can be modiﬁed as desired.

These settings do not just affect the monitor settings on the Tablet PC, but also on external monitors that are connected.

Fujitsu 25

ormat)

Working with the Tablet PC

Using ﬁngers

You can execute certain commands by using your ﬁnger tip on the touchscreen of your device.

Alternatively, everything which you can select or activate using your ﬁnger tip can also be selected or activated using the stylus.

Calibrating the monitor for stylus or touch input

Before the ﬁrst ﬁnger-based operation, you must calibrate your Tablet PC via the operating system, so that it recognizes your ﬁngertips as accurately as possible.

As soon as you notice that the accuracy is becoming worse, you must recalibrate the device.

Please note: There are separate calibration programs available for calibrating the stylus and for calibrating ﬁnger-based operation. Do not use the calibra tion tool for the stylus to calibrate ﬁnger-based operation.

Operating system Menu

Windows 10

To calibrate, run the Hardware and Sound / Tablet PC Settings function in the Control Panel. You need to calibrate both portrait and landscape formats.

Using the styl

Pen

You ca n navig write

Asty eyel

26 Fujitsu

use the stylus on your Tablet PC as an electronic writing tool, to select menu items and to

ate through the programs. Programs that support handwriting recognition also allow you to

directly on the screen with the stylus. You can also use the stylus as a drawing tool.

lus tether is available as an optional extra and you can use this to tie the

et on the stylus to the eyelet on the Tablet PC.

1 = stylus tip

2 = stylus button (= eraser) 3 = stylus button (= right mouse button) 4 = charging contacts 5 = eyelet for optional stylus tether

Working with the Tablet PC

Use only the stylus that was provided with your Tablet PC. Do not use any oth er pointed object as a substitute, that w as not specially designed for your Tablet PC. Replace the stylus tip if it is worn. The warranty does not cover a scratched scree n.

While writing, take care that you do not scratch the surface of the display (e.g. with a wristwatch or bracelet).

To prevent the stylus from ja you insert the stylus corr stylus point toward s the r

The s tylus of the Tablet PC is an electronic instrument that can be damaged if used improperly. Handle the stylus with care.

Our recommendations for proper handling of the stylus are as follows:

• Do not gesture with the stylus.

• Do not use the stylus as a pointer.

• Do not use the stylus on surfaces other than the screen of the Tablet PC.

• Do not try to turn the grip of the stylus. The grip is used to put the stylus into its slot or to take it out of its slot.

• Never store the stylus with its weight on the tip (e.g. with the tip pointing down in a pen container). If the stylus is stored with the tip pointing down, this may have an adverse effect on the stylus mechanism (particularly unde r high temperatures). In this case the stylus tip may react as though it is constantly being pressed down. To avoid damage, the stylus should be stored in the slot when not in use.

The stylus can be inﬂuenced by electromagnetic ﬁelds (cursor quivers or jumps). There may be a few areas on the screen where the cursor quivers slightly in spite of pressing the stylus down ﬁrmly.

The screen re tip of the ﬁng

You can use t

sponds to entries made with the tip of the ﬁnger or the stylus when the

er or the stylus directly touches the screen.

he stylus to perform almost all functions for which you would otherw ise use a mouse.

Action Mouse

Selecting menu

Click with the left mouse button. Tap on the menu entry with the tip of

items Starting

programs

Double-c button.

Moving a or wind

Opening a context

nobject

Drag with the left mouse button pressed.

Click with the right mouse button.

ng the cursor

Movi

Move

mming in its slot, always make sure that

ectly into its slot (the cha rging contacts on the

ear of the Tablet PC).

lick with the left mouse

the mouse

Stylus

the stylus. Tap on the program symbol twice in

rapid succession using the stylus tip.

e stylus tip directly on the

Place th

or window. Keep the stylus tip

object

ainst the screen. Drag the

held ag

d object or window.

desire

the desired element with the

Tap o n

s and keep the stylus pressed

stylu

nst the screen.

agai Place the tip of the stylus directly on

the screen.

Fujitsu 27

Working with the Tablet PC

Stylus location

To prevent the stylus from jamming in its slot (1), always ensure that you insert the stylus correctly into its slot (the charging contacts on the stylus point towards the s tylus tether attachment point).

Energy saving fu

To save energy, the stylus automatically switches off after 10 minutes o f inactivity and switches to power saving mode.

The stylus automatically returns to normal operating mode when the stylus tip is touched again.

nctions of the stylus

Charging the stylus battery

The stylus contains a built-in rechargeable battery, which is automatically charged when the stylus is fully inserted in its slot. The stylus is also charged when the Tablet PC is in p ower saving mode or is switched off. A charging time of approximately 15 seconds is sufﬁcient to able to use the stylus for 90 minutes.

► Insert the stylus fully into the slot.

After a charging period of approximately 5



minutes, the stylus battery is fully charged.

28 Fujitsu

Working with the Tablet PC

Adjusting the stylus

Operating system Menu

Windows 10 Under System Control - Hardware and Sound - Pen and Touch you can make

various settings for the stylus.

Calibrating the stylus

Before ﬁrst use with the stylus, you must calibrate your Tablet PC via the operating system, so that it recognizes the stylus as accurately as possible.

You should also always repeat the calibration if the co-ordination between the stylus and the cursor movement deteriorates.

Operating system Menu

Windows 10

To calibrate, run the H Control Panel. You ne

ardware and Sound / Tablet PC Settings function in the

ed to calibrate both portrait and landscape formats.

Installing a stylus

Attach the stylus with a stylus tether to prevent accidentally dropping it or losing it.

► Attac

h one end of the stylus cord to the stylus and the other end of the stylus cord to the Tablet PC.

tether

Fujitsu 29

Working with the Tablet PC

Tablet buttons

In addition to the ON/OFF button (1), your Tablet PC is ﬁtted with three tablet buttons.

1 2 3 4

No. Description Functions

2 Volume Up button Increase volume 3 Volume Down button Decrease volume 4

Shortcut button Start function m

anager or screen shot function

If the Tablet PC’s ON/OFF button is pressed in combination with the volume down button, this corresponds to the function of the key combination

30 Fujitsu

Ctrl+Alt+Del

on a keyboard.

Working with the Tablet PC

Camera

Depending on the software used, you can use your camera to take pictures, record video clips or take part in web chats.

• The picture quality depends on the lighting conditions and the software being used.

• You can only use the camera with a particular application (e.g. an Internet telephony

• The support of the Tablet PC must not shake while the camera is being used.

• The camera automatically adjusts itself to the current light level. For this reason,

Your device has two cameras: one on the front of the device and one on the rear.

program or a video conferencing program which supports cameras).

the touch screen may ﬂicker while the light level is adjusted.

Further information on the use of the camera and additional settings for it can be found in the help fu nction of the program using th e camera.

Rechargeable battery

BatteryBatteryServicelife,batteryRechargeablebatteryBattery

The built-in battery provides the Tablet PC with the necessary power for use on the move. You can increase the service life of the battery by caring for the battery properly. The average battery service life is around 500 charge/discharge cycles.

You can extend the battery service life by taking advantage of the available energy-saving functions.

Charging and maintaining the battery

BatteryBattery

The Tablet PC battery can only be charged when the ambient temperature is between 5°C / 41 °F and max. 35°C / 95°F.

You can charge the battery by connecting the Tablet PC to the AC adapter

Connecting the AC adapter", Page 18).

(see " If the battery is running low you will hear a warning alarm. If you do not connect the AC adapter

within ﬁve minutes of hearing the warning alarm, your Tablet PC will switch off automatically.

Monitoring the battery state of charge

ychargemeter

Batterybatter

A battery symbol for monitoring the battery capacity is d isplayed in the system bar / status indicator. The battery symbol shows you the battery charge.

Fujitsu 31

Working with the Tablet PC

Using the power-saving functions

EnergyPowerBattery

The Tablet PC uses less power wh en the power-saving functions are enabled. You will then be able to work longer when using the battery before having to recharge it.

The energy efﬁciency is increased an d environmental pollution is reduced. By choosing the best power options, you can make signiﬁcant savings and at the same time help protect the environment.

► Set the power-saving fun

ctions in your Control Panel.

When the Tablet PC is in a power-saving mode, you must remember the fol low ing:

During power-saving mode, open data is held in main memory or in a swap ﬁle on the hard disk.

Never switch off the Tablet PC while it is in a power-savin g mode. If the built-in battery is nearly ﬂat, close all open ﬁles and do not go into power-saving mode.

If you do not intend t o use your Tablet PC for a long period of time:

► Exit the power-sav

ing mode if necessary b y touching the screen or by switching the Tablet

PC on.

► Close all opened programs and completely shut down the Tablet PC.

Memory cards

Slot

Your Tablet PC is equipped with an integrated storage card reader. Use storage cards to enlarge the storage of your Tablet PC.

Follow the manufacturer’s instructions when handling the memory cards.

Memorycard

Supported formats

The following formats are su pported:

• Micro Secure Digital (microSD

•microSDHC

•microSDXC

Card)

32 Fujitsu

Inserting the memory card

Removing the memory card

Memorycard

To avoid any loss of data, always follow the correct procedure fo r removing the card (see the documentation for your operating system).

Working with the Tablet PC

► Gently slide the memory card into the slot

until you feel it click into place. The label area must face the front of the Tablet PC. Do not apply any force, otherwise the delicate contact surfaces could be damaged.

Memorycard

► Press the edge of the memory card so

that the memory card jumps (1) s lightly out of the slot (a).

► Pull the memory

in the directio

card out of the slot (a)

n of the arrow (2).

Fujitsu 33

Working with the Tablet PC

SIM card (conﬁguration-dependent)

A SIM Card (Subscriber Identity Module) is a chip card which is inserted in a cellular phone or Tablet PC and, together with an integrated 4G module, enables access to a cellular radio network.

Follow the instructions supplied by the provider of the SIM card. If you do not feel the the SIM card engage as you insert it, use a pointed object to insert the SIM card.

Please note that the SIM card format must be micro-SIM (3FF). Other SIM card formats, such as full-size (1FF), mini-SIM (2FF) or nano-SIM (4FF) do not ﬁt in the SIM card slot of your Tablet PC.

Please do not insert any other format of SIM card a s they may become twisted, they could even damage the system.

Inserting a SIM card

► Open the slot cover ► Remove the SIM card carrier from

its location (2).

► Insert the SIM ca

the SIM card carr

► Push the SIM card carrier back int o

its location (4).

► Close the slot

(1).

rd (3) as shown on

ier.

cover.

34 Fujitsu

Working with the Tablet PC

Removing a SIM card

► Open the slot cover (1). ► Remove the SIM card carrier from

its location (2).

► Remove the SIM card from the SIM

card carrier (3).

► Push the SIM card carrier back into

its location (4).

► Close the slot cover.

Wireless LAN/Bluetooth/4G/LTE wireless components

The installation of wireless components not approved by Fujitsu will invalidate the certiﬁcations issued for this device.

Switching the wireless components on and off

The wireless components are switched on and off using the appropriate functions of the operating system.

► To switch wireless components on and off individually, select Settings – Change

PC settings – Network – A irplane mode.

Conﬁgurin

• Requirement: A WLAN is available and you have the necessary access data on hand.

g WLAN access

Information on conﬁguring WLAN access can be found in the documentation for your operating system.

Further information on WLAN and Bluetooth

rther information about WLAN or Bluetooth, please refer to the

For fu

dix of this Operating Manual.

appen

AN speciﬁcations, see chapter "

For WL

Fujitsu 35

WLAN speciﬁcations", Page 84.

Working with the Tablet PC

Access via 4G / LTE

Embedded WWAN module option is not available on all products, in all regions and requires separately purchased wireless service contract. Please check with your wireless service provider for coverage and availability. Connection speeds w ill vary due to location, environment, n etwork conditions, and other factors.

You c a n ﬁnd information on establishing the connection with the 4G network in the docum entation for the hardware used in the Quick Start Guide.

Ethernet and LAN (optional, only with cradle, keyboard cover or adapter cable)

EthernetLAN

You c an use the optionally available accessories to establish a c onne ction to a local network (LAN = Local Area Network).

► Connect the network cable to the LAN

port of the accessory (1).

► Connect the network cable to your

network connection (2).

Your network administrator can help you to conﬁgure and u se the LAN connections. The network cable is not included in the delivery scope. Th is type of

cable can be obtained from a specialist dealer. Use a shielded network cable (CAT 5e).

36 Fujitsu

Accessories for your Tablet PC (opti

onal)

Accessories for your Tablet PC

The following accessories are available for your Tablet PC:

• Folio cover

• Protective TPU cover with hand strap

• Should strap and stand

• Keyboard cover

• Docking cradle

• Additional stylus

• Additional stylus tips

• Additional AC adapter The following sections p rovide more information on handling the accessories.

(optional)

Fujitsu 37

Accessories for your Tablet PC (opti

onal)

Your docking cradle (optional)

As well as fast charging, your cradle is a device that also allows you to quickly connect your Tablet PC to your peripherals, such as a display, keyboard, mouse etc. You only need to dock the Tablet PC to be able to work with y our peripheral devices.

If the Tablet PC is connected to the cradle, connections at all the USB ports are only supported if the USB cable is up to 3m long.

Cradle components

PortsPortsCradle

1 = Dock release button 2 = Status LED 3 = Docking port 4 = USB port 3.0 5 = VGA monitor port

The status LED (2) of the cradle lights up as soon as the Tablet PC is docked in the cradle, even if it is switched off.

38 Fujitsu

6 = HDMI port 7 = LAN port 8 = Security Lo ck device 9 = DC jack socket (DC IN)

Accessories for your Tablet PC (opti

Settingupthecradle

Select a suitable location for the cradle before setting it up. In doing so, please follow these instructions:

• Placethecradleonaﬂat, stable, non-slippery surface.

• Never place the cradle or the AC adapter o n a heat-sensitive surface.

• Do not expose the cradle to extr eme environmental conditions.

• Protect the cradle from dust, moisture and heat.

Connecting the Tablet PC to the cradle

It is possible to connect the Tablet PC to the cradle while it is running. Disconnect the AC ada pter from the Tablet PC before connecting

the Tablet PC to the cradle.

onal)

When the Tablet PC i to the cradle, to be

Cradle

► Remove the AC plug of the AC adapter from the power outlet. ► Remove the AC adapter cable from the DC jack (DC IN) of the Tablet PC.

s connected to the cradle, you must connect the AC adapter

able to use all the cradle’s functions.

Fujitsu 39

Accessories for your Tablet PC (opti

onal)

► Position the Tablet PC so that it lies against the storage surface of the cradle. ► Push the Tab

on the conne

► Plug the AC adapter cable into the DC jack (DC IN) on the cradle (2). ► Connect th ► Plug the AC cable into the pow er outlet (4).

let PC onto the cradle in the direction of the arrow (1) until you feel it engage ctor and until the slide-out button returns to its original position.

e AC cable to the AC adapter (3).

40 Fujitsu

Accessories for your Tablet PC (opti

Disconnecting the Tablet PC from the cradle

It is possible to separate the Tablet PC from the cradle while it is running.

onal)

► Press the slide-out button in the direction of the arrow (1) until it ﬁrmly

remains in pressed position (red marking visible).

► While holding down the lower part of the cradle, lift the Tablet PC from

the cradle in the direction of the arrow (2).

Fujitsu 41

Accessories for your Tablet PC (opti

onal)

Keyboard cover (optional)

The keyboard cover is a device which has been op timized for convenient input of texts and which enables connection to the Ethernet/LAN. You simply need to dock the Tablet PC.

The keyboard cover does not have a replaceable rechargeable battery.

Components of the keybo

KeyboardcoverPorts

ard cover

1 = Release button 2 = Docking port for the Tablet PC 3 = F-Lock indicator 4 = Num Lock indicator (to switch virtual

numeric keypad on and off)

5 = Caps Lock indicator (to switch

capitalization function on and off)

42 Fujitsu

6 = Scroll Lock indicator (function dependent

on the application program) 7 = DC input connector (DC IN) 8 = LAN port

Accessories for your Tablet PC (opti

Connecting the Tablet PC to the keyboard cover

Keyboardcover

The recommended maximum opening angle of the Tablet PC and keyboard cover is 120 degrees. If the opening angle exceeds 120 degrees, we recommend that you hold the keyboard cover with your free hand when operating the Tablet PC with the stylus or touch. This will prevent the Tablet PC from accidentally falling backwards.

► Position the keyboard cover as shown.

onal)

► Push the Tablet PC onto the keyboard cover in the direction of the arrow

(1) until you feel it engage with the plug.

► Connect

the AC adapter cable to the DC input connector (DC IN) of the Tablet PC (2).

► Connect the AC cable to the AC adapter (3). ► Plug th

e AC cable into the power outlet (4).

Tablet PC is connected to the cover, you can alternatively also connect the

If the

pter to the Tablet PC instead of to the keyboard cover.

AC ada

Fujitsu 43

Accessories for your Tablet PC (opti

onal)

Separating the Tablet PC from the keyboard cover

It is possible to disconnect the Tablet PC from the keyboard cover while it is running. However, to prevent any problems, w e recommend that you execute the appropriate undocking function provided by the operating system.

► Press the slide-out button down (1) until it remains in the pressed position (red marking visible). ► Lift the Tabl

44 Fujitsu

et PC away from the keyboard cover in the direction of the arrow (2).

Folio cover (optional)

When using the cover, we do not recommend connecting the Tablet PC to the keyboard cover. Please note that the device cann ot be placed into the keyboard cover in clamshell mode if the Tablet PC still has its cover on.

• This folio cover contains magnets. Keep it away from objects that may be easily affected by the inﬂuence of magnetism, e.g. pacemakers and magnetic cards.

• Make sure the device is ﬁrmly ﬁtted into the folio cover fasteners in order to prevent it from falling out.

• The folio cover is only designed to safely store and transport the device. Do not use the folio cover for any other purpose.

• Keep the folio cover away from ﬁre or heaters.

• Neither put th e folio cover in direct sunlight nor expose it to high temperature or humidity.

Accessories for your Tablet PC (opti

onal)

► Position the Tablet PC on the cover as shown (1). ► Insert the Tablet PC into the cover (2).

The following illustration shows you the many ways in which the folio cover can be used:

Fujitsu 45

Accessories for your Tablet PC (opti

onal)

46 Fujitsu

Accessories for your Tablet PC (opti

Protective TPU cover

Components of the protective TPU cover

The contents of the protective TPU cover package are:

• Protective TPU cover

• Fall prevention stopper

• Smart Card guide

• Stand spacer (2 pieces)

• Shoulder strap

• Hand strap

onal)

1 = Strap mounting hole (attach both ends

of the shoulder strap before use)

2 = Hand stra

Fujitsu 47

3 = Stand 4 = Smart Car

d guide

Accessories for your Tablet PC (opti

onal)

Safety precautions

• If the Tablet PC is not tightly ﬁtted into the protective TPU cover, the Tablet PC itself may come off during use.

• Firmly ho ld the Tablet PC itself, even if the protective TPU cover is attached to it. The protective TPU cover may come off if you only hold the edges of the protective TPU cover.

•Keepawayfromﬁ re and heating equipment.

• Do not expose the unit to direct sunlight, or places with high temperature or high humidity.

• Store it in a place which is free from dust or chemicals and is cool, dry and ventilated.

• Please keep it out of the reach of children.

• Do not place the protective TPU cover on resin material products (synthetic leather sofa, resin sheet, etc.). Color may get transferred due to contact for long period of time or vigorously rubbing it against the resin product.

• The color of the protective TPU cover may change with time due to th e characteristics of the material.

• The processing is done by giving careful consideration to the texture, so some color fading may be observed or it may become dirty or stained due to water leakage. We appreciate your understanding.

• Please discontinue use of the protective TPU cover when you ﬁnd cracks, brea kage , fraying, tearing, deformation, deterioration, etc.

• The protective TPU cover is a cover for storing and carrying Tablet PCs. Please do not use it for other purposes.

• The protective TPU cover is not a cover for protecting the Tablet PCs and Smart Cards from shocks.

• The protective TPU cover does not guarantee the prevention from scratches on stored items.

• Do not allow alcohol or other chemicals to come into contact with the pro tect ive TPU cover.

• DonotwipetheprotectiveTPUcoverwithanabrasivecloth.

• Material may smell when you open the product, but please note that the odor will decrease with time.

• If you attach a protec tive ﬁlm, etc. to the disp lay, the ﬁlm may peel off during use.

• Re-tighten the hand strap if it loosens.

• Do not swing around with a hand strap. The hand strap may come off.

• Do not apply excessive force to the protective TPU cover with the stand upright.

• Do not carry the unit around while holding the stand

• Do not carry it while holding the Smart Card guide.

• Do not wash. If it gets dirty, remove the protective TPU cover from the Tablet PC, soak a c loth in the water, squeeze it well, wipe off the dirt using that cloth and then wipe with a dry cloth.

• Do not use so lvents such as benzine, thinner, alcohol, household detergents, or chemically treated cloths as they may affect the quality or discolor the product.

• If it gets wet, please wipe off the moisture with a dry towel andkeep it in a shaded area until thoroughly dry.

48 Fujitsu

Attaching a Smart Card guide

Attach a Smart Card guide before using a Smart Card.

Accessories for your Tablet PC (opti

onal)

► Insert the claw on the back of the protective TPU cover into the hole of the Smart

Card guide and move it in the direction shown by the arrow.

Fujitsu 49

Accessories for your Tablet PC (opti

onal)

Inserting the Tablet PC in the protective TPU cover

► Remove the AC plug of the AC adapter from the power outlet. ► Switch off the Tablet PC . ► Close all slot covers. ► If the pen tether is attached to the Tablet PC, remove it and the pen from the Tablet PC.

First attach the pen tether to the protective TPU cover, then insert the Tablet PC in the cover.

► Attach the

50 Fujitsu

removed pen strap to either hole of the protective TPU cover (1).

Accessories for your Tablet PC (opti

► Fit the upper left side of the Tablet PC into the upper left side (2) of the protective

TPU cover, move the Tablet PC in the direction of the a rrow and ﬁt it into the upper right side (3) of the protective TPU cover.

onal)

► Fit the lower side of the Tablet PC into the prote ctive TPU cover: First, ﬁt the lower right side (4),

then ﬁt the lower left side (5). Double-check that the Tablet PC is ﬁtted properly.

Fujitsu 51

Accessories for your Tablet PC (opti

onal)

Removing the Tablet PC from the protective TPU cover

► Remove the AC plug of the AC adapter from the power outlet. ► Switch off the Tablet PC .

► Remove the Tablet PC from the lower side of the protective TPU cover: First remove

the lower right side (1) and then remove the lower left side (2).

52 Fujitsu

Accessories for your Tablet PC (opti

onal)

► Hold the entire unit in a vertical direction, hold the upper left side (3) of the protective TPU cover

by hand, and move the upper right side of the Tablet PC in the direction shown by arrow (4).

Fujitsu 53

Accessories for your Tablet PC (opti

onal)

Using the stand

You can prop up your Tablet PC by resting the stand upright with the protective TPU cover att ached.

► Move the stand

54 Fujitsu

in the direction of the arrow and set the protective TPU cover with the stand upright.

Accessories for your Tablet PC (opti

Removing the stand

You can remove the stand if you do not want to use it.

onal)

► Press the stan

surface of the

Fujitsu 55

d on the back until the stand connectors (1) appear on the

protective TPU cover.

Accessories for your Tablet PC (opti

onal)

► Expand the stand connectors (3) in the direction of arrows and then remove the stand.

► Use alignment marks (4) as a reference and attach the stand spacer (5) to the empty space (6).

56 Fujitsu

Accessories for your Tablet PC (opti

onal)

Connecting the Tablet PC/protective TPU cover to the keyboard cover

You can attach the Tablet PC to the keyboard cover when the protective TPU cover is attached. The fall prevention stopper prevents the unit (with protective TPU cover installed) from

tipping over when the unit is docked on the keyboard cover. To install the fall prevention stopper: ► Peel off the release paper of the double-sided tape on the back side of the fall prevention stopper.

► Carefully align the fall prevention stopper (2) and apply fall prevention stopper into the

support cavity (1) in the direction of the arrow (3). Press ﬁrmly.

Fujitsu 57

Accessories for your Tablet PC (opti

After attaching the stopper, do not a pply force to the fall prevention stopper for about one da y to ensure maximum adhesion.

onal)

► Push the Tablet PC/protective TPU cover unit onto the keyboard cover

in the direction of the arrow (4).

The Tablet PC cannot be closed completely. If you try to completely close the Tablet PC the unit could be damaged.

Do not connect the Tablet PC to the keyboard cover and carry both if the Tablet PC is in the protective TPU cover. This could damage the keyboard cover and/or the Tablet PC.

58 Fujitsu

Accessories for your Tablet PC (opti

onal)

Connecting the Tablet PC/protective TPU cover to the cradle

► Press the Tablet PC /protective TPU cover onto the cradle in the direction of the arrow

Fujitsu 59

Security functions

Securityfunctions

Your Tablet PC has several security features that you can use to secure your system and your personal data from unauthorized access.

This chapter explains how to use these functions, and what the beneﬁts are.

Please remember that in some cases, for example, forgetting your password, you may be locked out of the system and unable to access your data. Therefore, please note the following information:

• Back up your data on external data carriers at regular intervals.

• Some security functio of the passwords and ke

If you forget your passwords you will need to contact our Service Desk. Deletion or resetting of passwords are not covered by your warranty and a charge will be made for assistance.

Conﬁguring the ﬁngerprint sensor (conﬁguration dependent)

sor

sor Fingerprintsen

Fingerprintsen

Whether your device has a ﬁngerp rint sensor or not depends on the device conﬁguration which you ordered.

ns need you to choose passwords. Make a note

ep them in a safe place.

The ﬁngerprint sensor can record the image of a ﬁngerprint. With additional ﬁngerprint software, this image can be processed and used instead of a password.

all the ﬁngerprint software to be able to use the ﬁngerprint sensor (1).

► Inst

60 Fujitsu

Security functions

Using the Security Lock

SecurityLockAnti-theftprotectionSecurityLock

Your device comes with a Security Lock device for the Kensington Lock Cable. With the Kensington Lock Cable, a sturdy steel cable, you c an protect your device and the port replicator against theft. The Kensington Lock Cable is available as an accessory.

► Fit the Kensington Lock Cable to the

corresponding mechanism on your device.

Attach another Kensington Lock Cable to your cradle to protect this from theft as well.

Conﬁguring pass

Before using the various options for password protection in the BIOS Setup Utility, please proceed as follows to increase data security:

Make a note of the passwords and keep them in a safe place. If you forget your supervisor password you will not be able to access your Tablet PC. Passwords are not covered by your warranty and a charge will be made for assistance.

Passwordprotection

Your password can be up to 32 characters long an d can contain letters, numbers and special characters. A distinction is made between up per and lower case.

When using special characters, please note that these are dependent on the country-speciﬁc variant of the keyboard used.

word protection in BIOS Setup Utility

Fujitsu 61

Security functions

Protecting BIOS Setup Utility (supervisor password and user password)

If you have opened these operating instructions on the screen, we recommend that you print them out. You cannot call up the instructions on the screen while you are setting up the password.

BIOSSetupUtility

The supervisor password and the user password both prevent unauthorized use of the BIOS

Setup Utility. The supervisor password allows you to access all of the functions of the BIOS Setup Utility, while the user password will only give you access to some of the functions. You can

only set up a user password if a supervisor password has already been assigned.

Calling and using the BI OS Setup Utility is described in the chapter

Settings in BIOS Setup Utility", Page 72.

Assigning the supervisor and user passwords

► Start the BIOS Setup Utility and go to the Security menu. ► Select the Set Supervisor Password ﬁeld and press the Enter key.

With Enter new Password: you are asked to enter a password.



► Enter the password and press the Enter key.

Conﬁrm new Password requires you to conﬁrm the password.



► Enter the password again and press the Enter key.

Changes have been saved is displayed as a conﬁrmation that the new password has been saved.



► To set the user password, select Set User Password and proceed exactly as

when conﬁguring the supervisor password. If you do not want to change any other settings, you can exit BIOS Setup Utility.



► In the Exit menu, select the option Save Changes & Exit. ► Select Yes and press the Enter key.

PasswordSupervisorpasswordUserpassword

The Tablet PC is rebooted and the new password is effective. It will now be necessary to



ﬁrst enter your supervisor or user password in order to open the BIOS Setup Utility. Please note that the user password only provides access to a few of the BIOS settings.

Changing the supervisor password or user password

You can only change the supervisor password when you have logged into the BIOS Setup Utility with the supervisor password.

PasswordSupervisorpasswordUserpassword

► Start the BIOS Setup Utility and go to the Security menu. ► When changing the password, proceed exactly as when assigning a password.

62 Fujitsu

Security functions

Removing passwords

To remove a password (without setting a new password) perform the following steps:

PasswordSupervisorpasswordUserpassword

► Start the BIOS S etup Utility and go to the Security menu. ► Highlight the Set Supervisor Password or Set User Password ﬁeld and press the Enter key.

You will be requested to enter the current password by t he Enter Current Password prompt.



Enter New Password will appear and you will be requested to enter a new password.

► Press the Enter key twice at this request. ► In the Exit menu, select the option Save Changes & Exit. ► Select Yes and press the Enter key.

The Tablet PC is rebooted and the password is removed.



Removing the supervisor password simultaneously deactivates the user password.

Password protectio

n for booting the operating system

With the supervisor password you have set in the BIOS Setup Utility (see section " also prevent booting of the operating system.

Operatingsystem

Assigning the supervisor and user passwords", Page 62), you can

Activating system protection

► Start the BIOS S etup Utility and go to the Security menu.

Operatingsystem

► Select the PasswordonBootoption and press the Enter key. ► Select the option you require (First Boot or Every Boot) and press the enter key ► Select the Save Changes & Exit opt ion under Exit.

The Tablet PC reboots. You will be prompted to enter your password (the supervisor password).



Deactivating system protection

► Start the BIOS S etup Utility and go to the Security menu.

Operatingsystem

► Select the PasswordonBootoption and press the Enter key. ► Select the Disabled option and press the Enter key.

If you do not want to change any other settings, you can exit BIOS Setup Utility.



► Select the Save Changes & Exit opt ion under Exit.

The Tablet PC reboots. The system is no longer password-protected.



Password protection for the hard disk

ordprotection

Passw

d disk password prevents unauthoriz ed access to the hard disk drives

The har

hecked internally each time the s ystem is booted. The condition for this

and is c

you have assigned at least the supervisor password.

is that

Fujitsu 63

Security functions

Activating hard disk protection

► Call up the BIOS Setup and select the Security menu.

If you have not assigned BIOS passwords yet, deﬁne the supervisor and the user



password now, if desired (see "

► Mark the Hard Disk Security ﬁeld and press the Enter key. ► In the area Drive0, mark the ﬁeld Set Master Password and press the Enter key.

Enter new Password then appears and you are asked to enter a password.



► Enter the password and press the Enter key.

Conﬁrm new Password requires you to conﬁrm the password.



► Enter the password again and press the Enter key.

With Setup Notice: Changes have been saved you receive conﬁrmation that



the new password has been saved. The ﬁeld Password Entry on Boot is set to Enabled by default. You can exit the BIOS

Setup once you have ﬁnished changing the settings.

► From the Exit menu, choose the option Exit Saving Changes. ► Press the Enter key and select Yes.

The Tablet PC reboots and your hard disk is now protected with a p assword. The



password prompt is enabled as soon as the Tablet PC has rebooted.

Security functions", Page 60).

Deactivating hard disk protection

To cancel a password (without setting a new password) proceed as follows:

► Call up the BIOS Setup and select the Security menu. ► Mark the Hard Disk Security ﬁeld and press the Enter key. ► In the area Drive0, mark the ﬁeld Set Master Password and press the Enter key.

With the prompt Enter current Password you are ﬁrst asked to enter the old passw ord again.



With Enter new Password you are then prompted to enter a new password.

► After the request, press the Enter key three times. ► From the Exit menu, choose the option Exit Saving Changes. ► Press the Enter key and select Yes.

The Tablet PC reboots and there is no longer any password protection for this hard disk.



64 Fujitsu

Security functions

Smart Card reader (conﬁguration-dependent)

Your device may be ﬁtted with a Smart Card reader depending on your chosen model (only available in models with screw holes and Smart Card reader).

SecurityfunctionsSecurityfunctions

Smart Cards are not supplied as standard equipment. You can use all Smart Cards that comply with the ISO standard 7816-1, -2 or -3. These Smart Cards are available from various manufacturers.

With the appropriate software you can use your Smart Card as an alternative to password protection, but also as a digital signature, for encrypting your e-mails or for home banking.

We recommend that you always use two Smart Cards. Always keep one of the Smart Cards in a safe place if you are carrying the other Smart Card with you.

Inserting the Smart Card

Your device may be ﬁtted with a Smart Card reader, depending on your chosen model (only available in models w ith screw holes and Smart Card reader).

Do not use force when inserting and removing the S mart Card. Make sure that foreign objects do not fa ll into the Smart Card reader.

► Slide the Smart Card into the Smart Card reader (1) with the chip facing the front of the Tablet PC.

Fujitsu 65

Security functions

Trusted Platform Module - TPM (conﬁguration dependent)

TPMTrustedPlatformModule

To use the TPM, you must enable the TPM in the BIOS Setup before the software is installed. The re quirement for this is that you have assigned at least the supervisor password (see "

Enabling TPM

• Requirement: You have assigned a supervisor password (see "Security functions", Page 60).

► Call BIOS Setup and select the Security menu. ► Mark the TPM Security Chip Setting ﬁeld and press the Enter key. ► Select the entry Enabled to enable the TPM

Once you have enabled the TPM the Clear Security Chip menu item appears.



You can clear the holder in the TPM using Clear Security Chip.WithEnabled, all secret keys (e.g. SRK - Storage Root Keys, AIK - Attestation Identity Keys etc.) generated by applications are deleted.

Take note that you can then no longer access the data you have encrypted on the holder-based keys!

► From the Exit menu, choose the option Exit Saving Changes. ► Press the Enter key and select Yes.

The Tablet PC restarts and the TPM is enabled after the reboot.



Security functions", Page 60).

Disabling TP

• Requirement: You have assigned a supervisor password (see "Security functions", Page 60).

► Call BIOS Se ► Mark the TPM Security Chip Setting ﬁeld and press the Enter key. ► Select the ► From the Exit menu, choose the option Exit Saving Changes. ► Press the

The Tablet PC restarts and the TPM is disabled.



66 Fujitsu

tup and select the Security menu.

entry Disabled to disable the TPM.

Enter key and select Yes.

Connecting external devices

Under all circumstances, please observe the safety notes provided in the

Important notes", Page 13 chapter before connecting or disconnecting

any devices to or from your Tablet PC. Always read the documentation supplied with the device you w ish to connect. Never connect or disconnect cables during a thunderstorm. Never pull at a cable when disconnecting it. Always grasp the plug.

With some devices, such as USB devices, it is not necessary to switch off the Tablet PC and the device befo re co nnecting/disconnecting. For more information about whether or not devices need to be switched off, please refer to the documentation supplied with your external device.

Some of the external devices require special d rivers (see the operating system and external device documentation).

Connecting an external monitor

microHDMI port

microHDMI-port

The micro HDMI port on your device can be used to co nnect an external ampliﬁer, LCD TV or a plasma TV with an HDMI connection.

► Connect the data cable to the

external device.

► Connect the data cable to the

microHDMI port.

Some LCD t elevisions have only two speakers/speaker ports and therefore cannot reproduce Dolby Digital or DT S. To play back HDMI sound, you must change the HDMI sound settings accordingly.

You can ﬁnd the settings under Control Panel - Hardware and Sound. D eac tivate the settings for DTS Audio and Dolby Digital to enable playback of HDMI sound.

Fujitsu 67

Connecting external devices

External monitor port ( VGA) (cradle only)

An analog monitor is connected to the analog external monitor port (VGA). Display output is limited to a maximum of two external screens at the same time.

MonitorVGA portScreenconnectionMonitorconnection

► Switch off the Tablet PC and the

external monitor.

► Plug the data cable of the external

monitor into the monitor port.

► First switch on the external monitor and

then switch on the Tablet PC.

You can a lso switch back and forth between the external monitor and the LCD screen of the Tablet PC, see "

Touchscreen", Page 24.

You can display the same image on the external monitor and on the LCD screen of the Tablet P C at the same time.

68 Fujitsu

Connecting external devices

Connecting USB devices

USBports

On the USB ports you can connect external devices that also have a USB port (e.g. a DVD drive, a printer, a scanner or a modem).

USB devices are hot-pluggable. This means you can connect and disconnect the cables of USB devices while the operating system is running.

USB 1.x has a maximum data transfer rate of 12 Mbps. USB 2.0 has a data transfer rate of up to 480 Mbps. USB 3.0 has a data transfer rate of up to 5 G bps. USB 3.1 Gen 1 has a data transfer rate of up to 5 Gbps. USB 3.1 G en 2 has a data transfer rate of up to 10 Gbps. Additional information can be found in the documentation for the USB devices.

Device drive

USB devices w

► Connect the data ca

bletothe

external device.

► Connect the data cable to the USB

port on the Tablet PC.

► Connect the data cable to a USB

port of the cradle.

ill be automatically recognized and installed by your operating system.

Fujitsu 69

Connecting external devices

USBportwithchargingfunction(USBType-C)

USBportwithchargingfunction(USBType-C™)

At this USB port, you can charge a connected USB device or operate devices without an additional power supply (e.g. a monitor or printer).

This is also possible with the notebook switched off, if the USB Type-C Power Delivery on System-Off function is activated in the Advanced - Miscellaneous Conﬁgurations menu of the BIOS Set up Utility. Calling up and using the BIOS Setup Utility is described in section "

Settings in BIOS Setup Utility", Page 72.

USB devices are hot-pluggable. This means you can connect and disconnect the cables of USB devices while the operating system is running.

Additional information can be found in the documentation for the USB devices.

► Connect the data ca ble to the

external device.

► Connect the data cable to a USB port

(USB Type-C) on the Tablet PC.

How to remove USB devices correctly

Always correctly remove the device according to the rules described below, to ensure that none of your data is lost.

► Tap the symbol for safe removal of the hardware. ► Select the device you wish to shut down and remove. ► Tap OK.

Wait for the dialog box which tells you that it is now safe to remove the device.



70 Fujitsu

Connecting external devices

Headphones/microphone/Line-In/Line-Out/ headset-combi port

ConnectingaudiodevicesAudioconnectionsConnectingheadphones

Using the headphone/microphone/Line-In/Line-Out/headset-combi port, you can connect a headset, headphones, a microphone or external loudspeakers to your Tablet PC.

► Connect the audio cable to the

external device.

► Connect the audio cable to the headphone

port of the Tablet PC. The internal speakers are disabled.



If you purchase a cable from a retailer, please note the following information: The headphone/microphone/Line-In/Line-Out/headset-combi port on your

Tablet PC is a "3.5 mm jack socket". If you want to connect headphones or speakers you will need a "3.5 mm jack plug".

Fujitsu 71

Settings in BIOS Setup Utility

BIOSSetupUtilitySystemsettings,BIOSSetupUtilityConﬁguration,BIOSSetupUtilitySetupConﬁguringsy stemConﬁguringhardware

The BIOS Setup Utility allows you to set the system functions and the hardware conﬁguration for the Tablet PC.

When the Tablet PC is delivered, the default settings are effective. You can change these settings in the menus of the BIOS Setup Utility. Any changes you make take effect as soon as you save and exit the BIOS Setup Utility.

The BIOS Setup Utility program contains the f ollowing m enus:

Info System Advanced

Security Boot Exit

Starting the BIOS Setup Utility

► Keep the Volume

BIOSSetupUtility

► If a password has been assigned, enter the password and press the Enter key.

If you have forgotten the password, contact your system administrator or contact our customer service center.

Displays information relating to the BIOS, processor and Tablet PC Advanced system settings Conﬁguration of various hardware components, such as mouse, keyboard,

processor Password settings a nd security functions Conﬁguration of the start-up sequence Exits the BIO S Setup Utility

Down b utton pressed and switch on the Tablet PC.

The BIOS Setup Utility starts.

BIOS Setup Utility operation

BIOSSetupUtility

► Use the cursor keys



► Select the option you want to change with the cursor keys ► Press the "Enter" key. ► Press the ► For future reference, make a note of the changes you have made (for example, in this manual).

72 Fujitsu

Press theF1key to display help about operation of the BIOS Setup Utility. The description of the individual settings is shown in the right-h and window of the BIOS Setup Utility.

With the

key you can load the de fault settings of the BIOS Setup Utility.

←

→

to select the menu you wish to a ccess to make changes.

The m enu is displayed on the screen.

↑

or↓.

ESC

key to exit the selected menu.

Settings in BIOS Setup Utility

Exiting BIOS Setup Utility

BIOSSetupUtility

You need to select the de sired option in the Exit menu and activate it by pressing the Enter key:

Exit Saving Changes - save ch

► To save the current menu settings and exit the BIOS Setup Utility,selectExitSaving Changes and Yes.

The Tablet PC is rebooted



and the new settings come into effect.

anges and exit BIOS Setu p Utility

Exit Discarding Changes - Reject changes and exit BIOS Setup Utility

► To discard the changes, select Exit Discarding Changes and Yes.

The settings which were valid when BIOS Setup Utility was called remain effective.



The BIOS Setup Utility ends and the Tablet PC is reboote d.

Load Setup Defaul

► To copy the standard entries for all menus of the BIOS Setup Utility,

choose Load Setup Defaults and Yes.

ts – load default values

Discard Changes - Discard Changes without exiting BIOS Setup Utility

► To discard the changes you have made, select Discard Changes and Yes.

ThesettingsinplacewhenBIOS Setup Utility was called remain effective.



You can now make additional settings in the BIOS Setup Utility.

► If you want to exit the BIOS Setup Utility withthesesettings,selectExit Saving Changes and Yes.

Save Chan

ges - save changes without exiting

the BIOS Setup Utility

► To save the changes, select Save Changes and Yes.

The changes are saved. You can now make additional settings in the BIOS Setup Utility.



► If you want to exit BIOS Setup Utility with these settings, choose Exit Saving Changes and Yes.

Save changes and power off

► To save the changes and switch off your device, select Save Changes and Power Off and Yes.

The changes are saved. Your device is shut down.



Fujitsu 73

Troubleshooting and tips

TroubleshootingTipsFaultProblemsolving

If a fault occurs, try to correct it as described. If you fail to correct the problem, proceed as follows: ► Make a note of the steps and the circumstances that led to t he fault. Also

make a note of any error messages displayed.

► Switch the Tablet PC off. ► Please contact the Hotline/Service Desk.

You can contact Fujitsu Service and Support in the following ways:

• Toll free phone: 1-800-8Fujitsu (1-800-838-5487)

• Website: " Before you place the call, have the following information ready so that the customer

support representative can provide you with the fastest possible s olution:

• The model name and serial number of the Tablet PC. The serial number is located on a sticker on the underside o f the Tablet PC.

• Notes with the mess informationonaco

• All changes you have made to the hardware or software after receiving the Tablet PC.

• All changes you ha

• Your system conﬁguration and all peripheral devices connected to your system.

• Your sales cont

Our Tablet PCs have been designed primarily with m obile applications in mind. This means that considerable effort has been made to optimize components and equipment in terms of weight, space and energy requirements. Depending on the particular conﬁguration you have purchased, it is possible that functionality may be slightly reduced compared to a desktop PC if you are running processor-intensive gaming software, e.g. games with intensive 3D graphics. Updating your hardware with drivers which have not been approved by Fujitsu may result in performance losses, data losses or malfunction of the equipment. A list of approved drivers and current BIOS versions can be downloaded from: "

http://solu

tions.us.fujitsu.com/www/content/support/contact/index.php"

ages that appeared on the screen and

ustic s ignals.

ve made to the BIOS Setup settings after receiving the Tablet PC.

ract.

http://solutions.us.fujitsu.com"

74 Fujitsu

Troubleshooting and tips

Executing a reset

If the d evice no longer responds to your inputs, choose one of the following options:

Forced shutdown

► Press and hold the ON/OFF button for at least 4 seconds.

The device will be sh ut down. You can then restart it.



Resetting the rechargea

► Shut down the device.

If the device does not respond, you may have to force the shutdown, as described above.

► Disconnect the AC adapter from the device. ► Press the Volume Up button and t he Shortcut button at the same time.

The device resets in a similar way to the removal of the rechargeable



battery. You can then restart it.

ble battery

Help if problems occur

Should you encounter a problem with your computer that you cannot resolve yourself: ► Note the ID number of your device. The ID number is found on the type rating

plate on the back or underside of the casing.

► For further clariﬁcation of the problem, contact the Fujitsu Service Desk. When you do

this, please have ready the ID number and serial number of your system.

If you need to restore your system

In the event you need to restore your original Factory Image, please refer to the appendix of this Operating Manual.

The Tablet PC’s date or time is incorrect

SummertimeWintertimeIncorrecttimeTimenotcorrectWrongdate/timeDatenotcorrect

Cause Troubleshooting

Time and date are incorrect. ► With the BIOS-Setup-Utility, you can set the

Date and time are still set incorrectly after switchingontheTabletPC.

Fujitsu 75

date and time in the Main menu.

► Please contact your sales outlet or our

hotline/service desk.

Troubleshooting and tips

Battery charging indicator not

Cause

The battery is not being charge

Troubleshooting

► Connect the Tablet PC to a power outlet

Note: The battery will only be charged again when the battery capacity is less than 90%.

lit

using the AC adapter.

The Tablet PC’s touchscreen remains dark

Touchsc reendarktouchsc reen

Cause Troubleshooting

Touchscreen is switched

External monitor or t

elevision set connected.

off.

► Press a key (external key

the touchscreen.

► Check whether the graphics driver settings

are correct or whether an external monitor has been detected in "Intel Graphics Media Accelerator Driver for mobile".

board) or tap on

The display on the Tablet PC’s touchscreen is difﬁcult to read.

Touchsc reenTou chscre en

Cause Troubleshooting

Reﬂected glare ► Move the Tablet PC into a different position.

► Increase the brightness of the screen.

76 Fujitsu

Troubleshooting and tips

The external monitor remains bl

Monitor

Cause Troubleshooting

Monitor is switched off. ► Switch the external monitor on. Power saving has been activat ed (monitor is

blank). Brightness is set to dark. Screen output is set to the Tablet PC

touchscreen.

The external mo nitor’s AC cable or data cable is not connected properly.

The external mo

MonitorMonitor

Cause Troubleshooti

The wrong exte or the wrong sc the applicat

rnal monitor has been selected

reen resolution has been set for

ion program.

nitor is blank or the image is unstable

► Press a key (external keyboard) or tap on

► Adjust the brightness of the ► Check whether the graphics driver settings

► Switch off the Tablet PC and the e xternal

► Check whether the AC cable is plugged

► Check that the data cable is properly

► Switch on the external monitor and the

► Shut down the application program in

► Set the screen resolution: Set the screen

► Select monitor: Select monitor 1 or 2 as

ank

the touchscreen.

are correct or whether an external monitor has been detected in "Intel Graphics Media Accelerator Driver for mobile".

monitor.

properly into the external monitor and into the power outlet.

connected to the Tablet PC and the external monitor (if it is plugged in with a connector).

Tabl e t PC .

Windows. If the error persists after shutting down the program, use the key combination for switching the screen output in order to switch to the touchscreen of the Tablet PC. Change the following setting:

resolution as described in the documentation for your operating system.

described in the documentation for your operating system.

monitor.

The cursor does not correctly follow the stylus movements

Cause

Stylus incorrectly calibrated. ► Calibrate the stylus as described in chapters

Fujitsu 77

Troubleshooting

Adjusting the stylus", Page 29 and

Calibrating the stylus", Page 29.

Troubleshooting and tips

Stylus input not working

Cause

Incorrect driver installed.

The stylus is in power saving mode.

The stylus battery is completely discharged.

Troubleshooting

► If your device is one which can only be

operated using the stylus, install the driver for the standard model.

► If your device is one which can be

operated using the stylus and by ﬁnger, install the driver for the "Dual Digitizer" model.

► Press gently on the tip of the stylus to

reactivate the stylus.

► Carefully insert the

Tablet PC to charge th

stylus in its slot on the

e stylus battery.

The Tablet PC does not start after switch on

TabletPC

Cause Troubleshooting

The battery is dead.

The AC adapter is not connected properly. ► Check w hether the AC adapter is properly

► Charge the battery.

► Connect the AC adapter to the Tablet

PC.

connected to the Tablet PC.

► Switch the Tablet PC on.

The Tablet PC stops working

TabletPCEnding

Cause Troubleshooting

The Tablet PC is in energy saving mode. An application program has caused the

malfunction.

The battery is dead.

78 Fujitsu

► End energy saving mode. ► Close the application program or restart

the Tablet PC (by restarting the operating system or switching the device off and back on again).

► Charge the battery.

► Connect the AC adapter to the Tablet

PC.

Troubleshooting and tips

The printer does not print

Printerdoesnotprint

Cause Troubleshooting

The printer is not switched on. ► Make sure that the printer is sw

The printer is not connected c

The printer driver is faulty or not correctly installed, or it is the wrong printer driver.

orrectly.

on and ready for operation (ref documentation supplied with t

► Check that the data cable between the Tablet

PC and the printer is properly connected.

► Check that the data cable between the Tablet

PC and the printer is properly connected.

► Check whether the correct printer driver is

loaded (refer to the printer d ocumentation).

itched

er to the

he printer).

The wireless connect

ctiontoanetworkdoesnotw or k

Thewirelessconne

Cause Troubleshooting

The wireless component is switched off. ► Switch the wireless component on (see

The wireless component is switched on. Despite this, the wireless connection to a netwo rk does not work.

The battery di

Battery

Cause

The battery i case the batt

You may have an application running that consumes a great deal of power due to frequent accessing of the hard disk or optical drive.

The maximum brightness may have been set for the screen.

s either too hot or too cold. In this

ery indicator ﬂashes.

scharges too quickly

ion to a network does not work

Switching the wirel ess components on and

" off", Page 35).

► Check whether the wireless connection is

enabled by the software.

► Further information on using the wireless

component can be found in the help ﬁles.

Troubleshooting

► Bring the Tablet PC up/down to a normal

operating temperature again.

► If the operating time of the battery life is

extremely short, the battery is probably too old. Replace the battery if necessary.

► Use the AC adapter whenever possible.

► Reduce the brightness of the screen to

lower energy consumption: You will ﬁnd the setting under Control Panel – Hardware and Sounds – Windows Mobility Center.

Fujitsu 79

Troubleshooting and tips

Smart Card reader is not recognized

Cause

Smart Card inserted incorrectly. ► Make sure you have inserted your Smart

Troubleshooting

Card into the Smart Card reader with the chip facing upwards / downwards (device-dependent).

► Check whether the Smart Card you are

using is supported. Your Smart Card must comply with the ISO standard 7816-1, -2,

-3 and -4.

Smart Card PIN forgott

Cause

PIN forgotten ► If you work in a network, contact your

Troubleshooting

system administrator, who can unlock your Tablet PC using a supervisor PIN.

User and/or supervisor Smart Card lost

Cause

User and/or Supervisor Smart Card lost. ► If you have lost your user S mart Card, you

Troubleshooting

can continue working with the Supervisor Smart Card and initialize a new user Smart Card.

► If you have los

you can also c longer have a another Sup

► If you have lost both Smart Cards, you

cannot boot your system. Please contact our customer service center. You must provide proof of ownership for the device. The customer service center will then refer you to our service partner, who will unlock your device (for a charge).

t the Supervisor Smart Card, ontinue working, but you no

ll rights and cannot initialize

ervisor Smart Card.

Smart Card lost

eshooting

Cause

Smart Card lost. ► If you work in a network, contact your

Troubl

system administrator, who can boot your Tablet PC with a supervisor Smart Card.

80 Fujitsu

Troubleshooting and tips

Acoustic warning

Acousticwarn ingsErrors

Cause

A beep sounds every few seconds. The battery is almost dead.

Troubleshooting

► Charge the battery.

Error messages on the screen

reen Errormessagesonthesc

Errors

This section de scribes the error messages generated by the BIOS Setup. Error messages displayed by the operating system or programs a re described in the documentation for these programs.

If the error message app ears repeatedly despite troubleshooting measures, contact the place of purchase or our customer service center.

Fujitsu 81

Troubleshooting and tips

Error message/cause Troubleshooting

CMOS battery bad

If the error message occurs repeatedly, the

► Contact your sales outlet or our

service center.

buffer battery in the Tablet PC is ﬂat.

System CMOS checksum bad - Default conﬁguration used

The system conﬁguration information is incorrect.

► Switch the Tablet PC off. ► Switch the Tablet PC on. ► In the BIOS Setup, select t ► Select the entry Load Setup Defaults. ► Select OK and press the En

Extended memory failed zzzz zzzz

When testing the exten has resulted at the ad

Failure Fixed Disk

The settings of th

Keyboard contro

at offset: xxxx Failing Bits:

ded memory. an error

dress xxxx.

eharddiskdriveareincorrect.

ller error

► Contact your sales outlet or our customer

service center.

► Start the BIOS Setup (Primary Master

submenu) and select the correct settings.

► Switch your Tablet PC off with the ON/OFF

button.

► Wait 3 - 5 seconds and switch the Tablet PC

on again.

Keyboard error

If you use an external keyboard: ► Check the connection and reboot the Tablet

PC.

nn Stuck key Operating system not found

► Make sure that no key is pressed. ► Check in the BIOS Setup whether your hard

disk has been set correctly.

► Make sure t

d on the corresponding drive.

installe

Press <F1> to resume, <F2> to SETUP

This error message appears if an error occurs during the self-test before starting the operating system.

► Press th

BIOS set

► If you are working with an external

eVolumeUpbuttontostartthe

up.

keyboard, press the the keyboard.

Real time clock error

nK Shadow RAM failed at offset: xxxx Failing

nnn

ts: zzzz

Bi System battery is dead - Replace and run SETUP

► Cont

► Contact your sales outlet or our customer

act your sales outlet or our customer

ice center.

serv

service center.

System cache error - Cache disabled

System timer error

ontact your sales outlet or our customer

► C

ervice center.

► Contact your sales outlet or our customer

service center.

customer

he Exit menu.

ter key.

hat the operating system is

key on

82 Fujitsu

Technical data

Tablet PC

General

Processor

Main memory (SO DIMM) 8 GB / 16 GB DIMM onboard

Electrical data

Safety regulations complied with CE, cULus Protection class III Maximum power consumption (when the Tablet

PC is switched on and the rechargeable battery is charging):

Touchscreen

Size Resolution Pixel class II Brightness control 12 levels Technology Wide-View High-Bright Display with LED

Cameras

Display adapter

Chip Intel® U Maximum resolution of external monitor:

Dimensions

Width x Depth x Height

Weight depending on conﬁguration

Intel® i7-8665U (Whiskeylake-U UMS3) [vPro : Yes]

® i5-8365U (Whiskeylake-U UMS1) [vPro : Yes]

Intel

with keyboard cover: 65 W with cradle: 90 W

13.3" Full HD Antiglare 1920 x 1080 / 16 million colors

background lighting

• Front: 2 megapixels

• Rear: 5 megapixels, autofocus, mobile light

HD Graphics 620

4096 x 2

• Standard version:

• Version with keyboard cov

• Standard version:

• Vers

Depending on the conﬁguration, the weight of your device variant may differ from the speciﬁed values.

160

• 12.40 x 7.87 x 0.38 inch

• 315 x 200 x 9.7 mm

• 12.91 x

• 328 x 213 x 33 mm

•.71lbs

•789g

•3.03lbs

•370 g

8.39 x 1.30 inch

ion with keyboard cover:

er:

Fujitsu 83

Technical data

Input d evices

Tablet buttons 4 buttons Stylus (optional) Stylus with 2 stylus buttons

Slots

Memory card slot SIM card slot (conﬁguration-dependen t) 1 x Micro-SIM Smart Card slot (conﬁgu

Ports

Combined headphones and microphone port Docking port 1 x Micro HDMI port 1 x USB (Universal Serial Bus) 1 x USB 2.0, 1 x USB 3.0, 1 x USB port 3.0 with

Security Lock dev

Ambient conditi

Environment class DIN IEC 721 Mechanism class DIN IEC 721 Operating tem

Transport temperature (2K2) 5 °F .... 140 °F / -15 °C .... 60 °C

perature

ration-dependent)

ice

ons

1xmicroSD

3.5mmstereominijack

charging function (USB Type-C) 1x

7K1 7M2

41 °F .... 95 °F

/ 5 °C .... 35 °C

WLAN speciﬁcations

Type of network

Transfer rate (Automatic switching) IEEE802.11 a and g: 54

Active frequency • 802.11n: 2.4 GHz or 5 GHz

Typical operating distances** • 802.11a: 40 ft. (12 m) @ 54 Mbps; 300 ft.

Intel® Dual Band Wireless 9560NGW (11ac/abgn), WLAN and Bluetooth*

Mbps max. data rate; IEEE802.11n: 300 Mbps max. data rate, IEEE802.11ac: 867 Mbps max. data rate

• 802.11b/g: 2400~2473 MHz

• 802.11a: 4900~5850 MHz

• 802.11ac: 2.4 GHz / 5 GHz

(91m)@6Mbps

• 802.11ac: 40 ft. (12 m) @ 54 Mbps; 300 ft.(91 m) @ 6 Mbps

• 802.11b: 100 ft. (30 m) @ 11 Mbps; 300 ft. (91m)@1Mbps

• 802.11g: 100 ft. (30 m) @ 54 Mbps; 300 ft. (91m)@1Mbps

• 802.11n: Estimated double the o perating distance of 802.11g and 802.11a in their respective frequencies

84 Fujitsu

Technical data

Number of channels

Security

Maximum recommended number of computers to be connected over wireless LAN (during ad hoc connection)

* “Wi-Fi based” indicates that the interconnectivity test of the organization which guarantees the interconnectivity of wireless LANs (Wi-Fi Alliance) was passed.

** The operating distances given above increase or decrease depending on factors such as the number of walls, reﬂecting material or interference by external RF sources.

*** Network key encryption (WEP) occurs with the number of bits given above, after deduction of the ﬁxed length of 24 bits the user may however also set 40 or 104 bits.

**** Depending on the particular practical application, the number o f computers which can be networked is reduced if necessary.

• 802.11a: 8 independent channels

• 802.11b/g: 11 channels, 3 non-overlapping channels

• 802.11n: Chan nel bonding takes two of the non-overlapping 20MHz channels and combines it into one 40MHz channel. It is actually 12 non-overlapping channels with channel bonding and 24 without. Also it is 1 non-overlapping channel in 2.4GHz when channel bonding is used.

• 802.11ac: 5 independent channels

Encryption types: compatible with WEP, TKIP, AES***, WPA 1.0 and WPA 2.0

Encryption key, lengths supported: 64 bits and 128 bits

10 units or less ****

WWAN speciﬁcations

Card certiﬁcation Sierra Wireless Air Prime EM7455B

Screen resolutions for integrated screen and external screens

Max. number of screens

Only Tablet PC

Fujitsu 85

Number of external screens

Integrated screen

1920x1080@60Hz

System interface microHDMI port

4096x2160@24Hz 3840x2160@30Hz

1920x1080

@60Hz

Technical data

Rechargeable battery

For information on the batteries used in your device, please see

http://solutions.us.fujitsu.com/www/content/support/contact/index.php".

3-cell lithium ion rechargeable battery 3450 mAh Rated voltage 11.1 V Rated capacity 38 Wh

AC adapter 65 W for the Tablet PC with/without keyboard cover

Technicaldata

Rated voltage 19 Volts Max. rated current 3.42 A

An additional AC adapter or AC cable can be ordered at any time.

AC adapter 90 W for

Technicaldata

Rated voltage 19 Volts Max. rated current 4.74 A

An additional A

C adapter or AC cable can be ordered at any time.

Tablet PC with cradle

86 Fujitsu

Cradle (optional)

Electrical data

Safety regulations complied with CE Protection class III

Ports

Docking port 11-pin HDMI port 1 x VGA monitor port USB (Universal Seria LAN port 1 x Security Lock device

Ambient conditions

Environment class DIN IEC 721 Mechanism clas

Operating temperature 41 °F .... 95 °F / 5 °C .... 35 °C

Temperature in transit

lBus)

s DIN IEC 721

1x 3xUSB3.0

7K1 7M2

41 °F .... 95 °F / 5 °C .... 35 °C

Keyboard cover (optional)

Electrical data

Safety regulations complied with CE Protection class III

Ports

Docking port 9-pin LAN port 1 x

Ambient conditions

Environment class DIN IEC 721 Mechanism class DIN IEC 721

Operating temperature 41 °F .... 95 °F / 5 °C .... 35 °C

Temperature in transit

7K1 7M2

41 °F .... 95 °F / 5 °C .... 35 °C

Technical data

Folio cover (optional)

Dimensions

Width x Depth x Height

Weight

Fujitsu 87

332 mm x 231 mm x 27 mm /

13.1 in. x 9.1 in. x 1.1 in. Approx. 480 g / 1.1 lbs.

Technical data

Protective TPU cover with stand and shoulder strap (optional)

Dimensions

Width x Depth x Height

Weight

328 mm × 213 mm × 33 mm /

12.91 in. x 8.36 in. x 1.3 in.

Approx. 370 g / 0.82 lbs.

, hand strap

88 Fujitsu

Manufacturer’s notes

Disposal and recycling

Notes

You can ﬁnd information on this subject on your Tablet PC or on our website

http://solutions.us.fujitsu.com/www/content/products/trade-in_program/").

Recycling your battery

Over time, the batteries that run your mobile computer will begin to hold a charge for a shorter amount of time; this is a natural occurrence for all batteries. When this occurs, you may want to replace the battery with a brand new one*. If you replace it, it is important that you dispose of the old battery properly because batteries contain materials that could cause environmental damage if disposed of improperly.

Fujitsu is v ery concerned with environmental protection, and has enlisted the services of th e Rechargeable Battery Recycling Corporation (RBRC)**, a nonproﬁt public service organization dedicated to protecting our environment by recycling old batteries at no cost to you.

RBRC has drop-off points at many convenient locations throughout the United States and Canada. To ﬁnd the location nearest you, go to "

If there are no convenient RBRC locations near you, you can also go to the EIA Consumer Education Initiative website "

Remember – protecting the environment is a cooperative effort, and you should make every effort to protect it for current and future generations.

* To order a new battery for your Fujitsu mobile computer, go to the F ujitsu shopping site

www.shopfujitsu.com" in the US or "www.fujitsu.ca/products/notebooks" in Canada.

at " ** RBRC is an independent third party to which Fujitsu provides funding for

battery recycling; RBRC is in no w ay afﬁliated with Fujitsu.

http://EIAE.org/ " and search for a convenient disposal location.

www.RBRC.org" or call 1-800-822-8837.

Fujitsu 89

Manufacturer’s notes

DOC (Industry CANADA) Notices

DOC(INDUSTRYCANADA)NOTICES

Radios and Television

This Class B digital apparatus meets all requirements of Canadian Interference-Causing Equipment Regulations.

CET appareil numérique de la class B respecte toutes les exigence du Réglement sur le matérial brouilleur du Canada.

UL Notice

IMPORTANT SAFETY INSTRUCTIONS

This unit requires an AC adapter to operate. Only use UL Listed I.T.E. adapters with an output rating of 19 VDC, with a minimum current of 3.42A (65W). T he correct output rating is indicated on the AC adapter label. Refer to the illustration below for the correct AC adapter output polarity:

CAUTION:

When using your Tablet PC equipment, basic safety precautions should always be followed to reduce the risk of ﬁre, electric shock and injury to persons, including the following:

• Do not use this product near water for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

• Use only the power co rd and batteries indicated in this manual.

• Do not dispose of batteries in a ﬁre. They may explode.

• Check with local codes for possible special disposal instructions.

SAVE THESE INSTRUCTIONS.

For Aut horized Repair Technicians Only

CAUTION:

For continued protection against risk of ﬁre, replace only with the same type and rating fuse.

WARNING:

Danger of explosion if Lithium (CMOS) battery is incorrectly replaced. Replace only with the same or equivalent type recommended by th e manufacturer.

Dispose of used batteries according to the ma nufacturer’s instruction.

90 Fujitsu

Manufacturer’s notes

ENERGY STAR Compliance

Your Fujitsu system is an ENERGY STAR qualiﬁed mobile PC. By choosing a computer with the latest energy-saving te chnology, you’re helping to preserve our environment for future gen erations. ENERGY STAR is a joint program of the U.S. Environme ntal Protection Agency, U.S. Department of Energy, Natural Resources Canada, and other governments around the world helping us save money while protecting the environment through energy efﬁcient products and practices. With energy costs and global warming top-of-mind for consumers, Fujitsu is committed to offering solutions that help consumers conse rve energy and improve the quality of our environment.

Sleep mode:

You will notice that your compu ter is initially set so that the display turns off after 5 minutes and sleep after 15 minutes. When plugged in: the display turns off after 10 minutes and sleeps after 30 minutes (as OS default value). When going into Sleep mode, the computer also red uces the spe ed of any active Ethernet network links. To “wake” the computer from Sleep mode, press the Suspend/Resume Button.

Energy saving beneﬁts:

Fujitsu ENERGY STAR qualiﬁed mobile PCs use about half as much electricity as standard equipment – saving half in utility costs. But more than that, ENERGY STAR also makes a difference for the environment. Did you know that the average house can be responsible for twice the greenhouse gas emissions as the average car? That’s because every time you ﬂip on a light switch, run your dishwasher, or turn on your PC, you use energy, which means more greenhouse gas emissions from power plants. So the more energy we can save through energy efﬁciency, the more we help to reduce greenhouse gase s and the risks of global w arming.

To learn more about the imp ortant ENERGY STAR program, visit:" To read about how Fujitsu is supporting Sustainable Management along with

several other environmental activities, visit the F ujitsu Corporate Citizenship page at:

http://www.computers.us.fujitsu.com/www/content/aboutus/environmental/environment.ph p".

www.energystar.gov".

Fujitsu 91

FCC and IC Regulatory Information

FCC and IC Regulatory Informat

Please note the following regulatory information related to the wireless LAN device.

Regulatory Notes and Stat

ements

ion

Wireless LAN, Health and Authorization for use

Radio frequency electromagnetic energy is emitted from Wireless LAN devices. The energy levels of these emissions, however, are far much l ess than the electromagnetic energy emissions from wireless devices such as mobile phones. Wireless LAN devices are safe for use by consumers because they operate within the guidelines found in radio frequency safety standards and recommendations. The use of Wireless LAN devices may be restricted in some situations or environments, such as:

• On board an airplane, or

• In an explosive environment, or

• In situations where the interference risk to other devices or services is perceived or identiﬁed as harmful.

In cases in which the policy regarding use of Wireless LAN devices in speciﬁc environments is not clear (e.g., airports, hospitals, chemical/oil/gas industrial plants, private buildings), obtain authorization to use these devices prior to operating the equipment.

WARNING: The Fujitsu Tablet when used in dock mode in the c rad le will communicate via RF. The device radiates radio frequency energy at a level below the United States FCC and Canada’s ISED radio frequency exposure limits. However, the Tablet in docked mode shall not be used in body worn positions. Human con tact during normal operation should be minimized and a body to Tablet distance of >20cms shall be maintained. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. Details of the authorized conﬁgurations can be found on FCC website by entering the FCC ID number that is shown on this device.

Regulatory Information/Disclaimers

Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modiﬁcations mad e to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. The manufacturer is not responsible for any radio or television interference caused by unauthorized modiﬁcation of this device, or the substitution or attachment of connecting cables and equipment other than those speciﬁed by the manufacturer. It is the responsibility of the user to correct any interference caused by such unauthorized modiﬁcation, substitution or attachment. The manufacturer and its authorized resellers or distributors w ill assume no liability for any damage or violation of government regulations arising from failure to comply with these guidelines.

This device must not be co-located or operated in conjunction with any other antenna or transmitter.

92 Fujitsu

FCC and IC Regulatory Information

Federal Communications Commission statement and Industry Canada statement:

This device complies with Part 15 of FCC Rules and Industry Canada license exempt RSS standard (s). Operation is subject to the following two conditions: (1) This device may not cause

interference, and, (2) This device must accept any interference, including interference that may cause undesired operation o f this device.

Déclaration d’Industrie Canada

Cet appareil est con forme à la RSS concernant les appareils exempt s de licence par Industrie Canada. Son fonctionnement est soumis aux deux condition s suivantes : (1) cet appareil ne doit pas causer d’interférence nuisib le; (2) cet appareil doit accepter toutes les interférences reçues, y compris celles pouvan t causer un mauvais fonctionnement de l’appareil.

FCC Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the F CC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed an d used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the distance between the equipment and the receiver.

3. Connect the equipment to an outlet on a circuit different from the one the receiver is connected to.

4. Consult the dealer or an experienced radio/TV technician for help.

Fujitsu 93

FCC and IC Regulatory Information

FCC Radio Frequency Exposure statement

The available scientiﬁc evidence does not show that any health problems are associated with using low power wireless devices. There is no proof, however, that these low power wireless devices are absolutely safe. Low power wireless devices emit low levels of radio frequency energy (RF) in the microwave range while being used. Wherea s high levels of RF can produce health effects (by heating tissue), exposure to low-level RF that does not produce heating effects causes no known adverse health effects. Many studies of low-level RF exposure have not found any biological effects. Some studies have suggested that some biological effects might occur, but such ﬁndings have not been conﬁrmed by additional research.

The wireless LAN radio device has been tested and found to comp ly with FCC radiation exposure limits set forth for an uncontrolled equipment and meets t he FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.

The exposure standard for wireless devices employs a unit of measurement known as the Speciﬁc Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg, and 1.6 W/kg by Industry Canad a.

This device is compliant with SAR for ge neral population /uncontrolled exposure limits in ANSI/IEEE C9 5.1-19 92 and Canada RSS 102, and had been tested in accordance with the m easurement meth ods and procedures speciﬁed in OE T Bulletin 65 Supplement C , and Canada RSS 10 2. This device has been tested, and meets the FCC, IC RF exposure guidelines when tested with the device operating conditions.

Déclaration de la FCC/d’Industrie Canada sur l’exposition aux radiofréquences

La norme régissant l’exposition des appareils sans ﬁl aux radiofréquences emploie une unité de mesure dénommée Taux d’absorption spéciﬁque, ou TAS. La FCC et Industrie Canada ont déﬁni la même limite de TAS : 1,6 W/kg. Cet appareil est conforme au TAS pour les limites d’exposition générales de la population/non contrôlées déﬁnies par les règles C95.1-1992 de l’ANSI/IEEE et RSS 102 d’Industrie Canada ; il a été testé en conformité avec les métho des et procédures de mesure spéciﬁées dans le supplément C du bulletin 65 de l’OET (Ofﬁce d’ingénierie et de technologie) et la règle RSS 102 d’Industrie Canada. Cet appareil a été testé selon les directives de la FCC et d’IC concernant l’exposition aux radiofréquences et s’est révélé conforme à ces dernières lorsqu’il a été testé en contact direct avec le corps.

Export restrictions

This product or software contains encryption code which may not be exported or transferred from the US or Canada without an approved US Department of Commerce export license. This device complies with P art 15 of FCC Rules., as well as ICES 003 B / NMB 003 B. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation. Modiﬁcations not expressly authorized by Fujitsu America, Inc. may invalidate the user’s right to operate this equipment.

94 Fujitsu

FCC and IC Regulatory Information

Restrictions concernant l’exportation

Ce produit ou logiciel contient du code de chiffrement qui ne peut être exporté ou transféré du Canada ou des États-Unis sans un permis d’exportation du départeme nt du commerce des États-Unis. Ce matériel est conforme à la Partie 15 des règlements de la FCC, ainsi qu’à la norme ICES 003 B/NMB 003 B. Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d’interférence nuisible; (2) cet appareil doit accepter toutes les interférences reçues, y compris celles pouvant causer un mauvais fonctionnement de l’appareil. Toute modiﬁcation n’ayant pas été expressément approuvée par la société Fujitsu America Incorporated peut annuler le droit de l’utilisateur de se servir du matériel.

Fujitsu 95

Canadian Notice / Avis pour le Canada

Canadian Notice / Avis pour le C

anada

Canadian Notice

The device for the 5150 - 5250 MHz band is only for indoor usage to reduce the potential for harmful interference to co-channel mobile satellite systems.

The maximum antenna gain of 6 dBi permitted (for devices in the 5250 - 5350 MHz, 5470 - 5725 MHz and 5725 - 5825 MHz bands) to comply with the e.i.r.p. limit as stated in RSS-247.

In addition, users are cautioned to take note that high power radars are allocated as primary users (meaning they have priority) of 5250 - 5350 MHz and 5650 - 5850 MHz and these radars could c ause interference and/or damage to LE-LAN devices.

Avis pour le Canada

Le matériel destin uniquement à l’in systèmes mobiles

Un gain d’antenne

- 5 350 MHz, 5 470 -

p.i.r.e. maxima En outre, les u

sont considér bandes 5 250 - 5 et/ou des dom

é à un usage sur la bande 5 150 - 5 250 MHz doit être utilisé

térieur aﬁn de réduire les risques de brouillage nuisible causé aux

par satellite fonctionnant sur un même canal.

de 6 dBi est autorisé (pour le matériel utilisant les bandes 5 250

5 725 MHz et 5 725 - 5 825 MHz), conformément à la limite

le permise afférent aux périphériques RSS-247.

tilisateurs doivent prendre garde au fait que les radars de grande puissance

és comme des utilisateurs principaux (ce qui signiﬁe qu’ils sont prioritaires) des

350 MHz et 5 650 - 5 850 MHz et qu’ils pourraient causer des interférences

mages aux appareils de réseau exempts de licence.

AVERTISSEME

lorsqu’ell l’énergie r aux radiofr Toutefois contacts être mini corps et l conform sujet de alors le

NT – La tablette Fujitsu communiquera par radiofréquences (RF)

e est utilisée en mode station d’accueil dans le socle. L’appareil émet de

adiofréquence d’une intensité inférieure aux limites d’exposition humaine

équences établies par la FCC aux États-Unis et par ISDE a u Canada.

, en mode station d’accueil, la tablette ne doit pas toucher le corps. Les

avec le corps pendant le fonctionnement normal de l’appareil doivent

misés et une distance de plus de 20 cm doit être m aintenue entre le

a tablette. L’utilisation d’autres accessoires peut conduire à un usage non e aux limites d’exposition aux radiofréquences de la FCC. Des détails au sconﬁgurations autorisées sont fournis sur le site Web de la FCC. Entrez

numéro d’identiﬁcation FCC qui apparaît sur cet appareil.

96 Fujitsu

Appendix

Before Using the Optional Wireless LAN

This manual describes the procedures required to properly set up and conﬁgure the optional integrated Wireless LAN Mini-PCI device (referred to as "WLAN device" in the rest of the manual). Before using the WLAN device, read this manual carefully to ensure its correct operation. Keep this manual in a safe place for future reference.

Wireless LAN Devices Covered by this Document

This document is applicable to systems containing the following device:

• Intel® Dual Band Wireless-AC 9560 – (11a/ac/b/g/n) WLAN and Bluetooth

Characteristics of the WLAN Device

• The WLAN devices are PCI Express Mini cards attached to the main board of the mobile computer.

• The WLAN devices operate in license-free RF bands, eliminating the need to procure an F CC operating license. The WLAN operates in the 2.4GHz Industrial, Scientiﬁc, and Medical (ISM) RF band and the lower, middle, and upper band s of the 5GHz Unlicensed National Information Infrastructure (UNII) bands.

• The WLAN devices are capable of ﬁve operating modes, IEEE802.11a, IEEE802.11ac, IEEE802.11b, IEEE802.11g, and IEEE802.11n.

• The WLAN device is Wi-Fi certiﬁed and operates (as applicable) at the maximum data rate of 867 Mbps in IEEE802.11ac mode, 450 Mbps in IEEE802.11n mode (300 Mbps in this conﬁguration); 54 Mbps in IEEE802.11g mode; and 11 Mbps in IEEE802.11b mode.

• The WLAN devices support the following encryption methods - WEP, TKIP, CKIP, and AES encryption.

• The Wireless LAN devices are compliant with the following standards: WPA, WPA2, CCX1.0, CCX2.0, CCX3.0, and CCX4.0.

Fujitsu 97

Appendix

Wireless LAN Modes Using this Device

Ad Hoc Mode

"Ad Hoc Mode" refers to a wireless network architecture where wireless network connectivity between multiple computers is established without a central wireless network device, typically known as Access Point(s). Connectivity is accomplished using only client devices in a peer-to-peer fashion. That is why Ad Hoc networks are also known as peer-to-peer networks. Ad Hoc networks are an easy and inexpensive method for establishing network connectivity between multiple computers. Ad Hoc mode requires that the SSID, network authentication, and encryption key settings are identically conﬁgured on all co m puters in the Ad Hoc network.

98 Fujitsu

Fujitsu WB0109 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Declarations of conformity

Fujitsu Contact Information

Notational conventions

Ports and controls

Front

Left side

Right side

Rear

Important notes

Safety instructions

Additional safety notes for devices with wireless co mponents

Protecting the display screen

Energy saving under Windows

Traveling with your Tablet PC

Before you travel

Transporting the Tablet PC

Cleaning the Tablet PC

First-time setup of your device

Choose a location

Connecting the AC adapter

Installing Bonus Apps

Working with the Tablet PC

Status indicators

Switching the Tablet PC on

Programming the ON/OFF button

Switching the Tablet PC off

Handwriting recognition

Touchscreen

Background lighting

Ambient light sensor

Synchronizing the display on the touchscreen and an external monito r

Calibrating the monitor for stylus or touch input

Stylus location

Charging the stylus battery

Adjusting the stylus

Calibrating the stylus

Tablet buttons

Camera

Rechargeable battery

Charging and maintaining the battery

Using the power-saving functions

Memory cards

Supported formats

Inserting the memory card

Removing the memory card

Inserting a SIM card

Removing a SIM card

Wireless LAN/Bluetooth/4G/LTE wireless components

Switching the wireless components on and off

Further information on WLAN and Bluetooth

Access via 4G / LTE

Ethernet and LAN (optional, only with cradle, keyboard cover or adapter cable)

Your docking cradle (optional)

Cradle components

Settingupthecradle

Connecting the Tablet PC to the cradle

Disconnecting the Tablet PC from the cradle

Keyboard cover (optional)

Connecting the Tablet PC to the keyboard cover

Separating the Tablet PC from the keyboard cover

Folio cover (optional)

Protective TPU cover

Components of the protective TPU cover

Safety precautions

Attaching a Smart Card guide

Inserting the Tablet PC in the protective TPU cover

Removing the Tablet PC from the protective TPU cover

Using the stand

Removing the stand

Connecting the Tablet PC/protective TPU cover to the keyboard cover

Connecting the Tablet PC/protective TPU cover to the cradle

Security functions

Using the Security Lock

Protecting BIOS Setup Utility (supervisor password and user password)

Password protection for the hard disk
