Fujitsu S300 Getting Started Guide
Contents
Introduction .........................................................1
Conventions ........................................................6
Safety Precautions ..............................................8
Chapter 1 Preparation .......................................11
1.1 Checking the Contents of the Package .......... 11
1.2 Names and Functions of Parts ....................... 12
Chapter 2 Connecting the ScanSnap ...............14
2.1 Installing the Supplied Software ..................... 14
2.2 Connecting the ScanSnap.............................. 17
Chapter 3 How to Use the ScanSnap ...............22
3.1 Scanning Documents ..................................... 22
3.2 About the Scanning Settings .......................... 22
3.3 Scanning Office Documents........................... 23
3.4 Scanning Business Cards .............................. 25
3.5 ScanSnap Organizer ...................................... 27
Chapter 4 Troubleshooting ...............................29
4.1 Troubleshooting Checklist .............................. 29
4.2 Clearing Paper Jams...................................... 31
Chapter 5 Daily Care ........................................32
5.1 Cleaning Materials.......................................... 32
5.2 Cleaning the Scanner Exterior ....................... 32
5.3 Cleaning Inside of the Scanner ...................... 33
Chapter 6 Consumables ...................................34
P3PC-1982-01EN
Please read this guide before connecting the scanner to your computer.
For further details, refer to the "ScanSnap S300 Operator’s Guide"
included in the supplied ScanSnap Setup CD-ROM.
Introduction
Thank you for purchasing the ScanSnap S300 Color Image Scanner product.
The ScanSnap S300 is a color image scanner capable of scanning double-sided
documents. It is a complete Office Solution, which helps you improve productivity and
solve scanning problems in your office. The features of the ScanSnap product are as
follows:
• You can turn images on paper into PDF files by just pressing the [SCAN] button!
You can turn documents cluttering up your desk into PDF files, which are easy to
print and attach to e-mail messages; you can view, edit, manage, and archive them on
your computer right at your fingertips.
In addition, the ScanSnap can automatically recognize the type of documents, color
or black-and-white, so that the size of the scanned image file can be reduced when
documents containing both color and black-and-white pages are scanned. (Moreover,
the ScanSnap can automatically remove blank pages from the document to further
reduce the size of the file.)
• You can scan documents with speed and efficiency!
Double-sided color documents of A4 or letter in size can be scanned at a speed of:
• Power-cable-connected: Approx. 8 sheets/minute
• USB-bus-power-cable-connected: Approx. 4 sheets/minute
(when used with a computer with Intel
runs Windows® 2000, Windows® XP or Windows Vista® and with Scan mode set to
Normal, Color mode Auto, and Compression rate 3, and others set to defaults)
• You can eliminate the nuisance of a bulky device!
Smaller than a sheet of A4 or letter paper in size, the ScanSnap can fit unobtrusively
on your desktop all the time.
®
Celeron® M 430 1.73 GHz or higher that
• Compact, light-weight, portable body design!
Its compact, light-weight design makes it possible to hand-carry the scanner together
with your laptop computer. There is no need to find an electrical outlet for the
ScanSnap if you use the supplied USB bus power cable to connect to your computer.
• You can file business cards with ease!
TM
With CardMinder
, which is supplied with the scanner, business cards can be easily
filed and searched for using the OCR function.
• The Quick menu lets even beginners operate the ScanSnap with automatic
ease!
When the [SCAN] button is pressed, the Quick menu is displayed. What you should
do is to select the action you want to perform on the Quick menu. The Quick menu is
simple enough for first-time use by completely neophytes. (Quick menu mode)
1
• You can send off the scanner image by e-mail or output the scanned image to
the printer immediately after scanning!
Without starting applications, you can attach the scanned image to e-mail or make
copies of the scanned image by outputting it to the printer.
(*The ScanSnap S300 Scanner does NOT comply with TWAIN or ISIS standards.)
Manufacturer
PFU LIMITED
International Sales Dept., Imaging Business Division, Products Group
Solid Square East Tower, 580 Horikawa-cho, Saiwai-ku, Kawasaki-shi Kanagawa 2128563, Japan
Phone: (81) (44) 540-4538
Trademarks
Microsoft, Windows, and Windows Vista are registered trademarks of Microsoft
Corporation in the United States and/or other countries.
Outlook is the product of Microsoft Corporation.
Adobe, Acrobat, Adobe Reader, and Acrobat Reader are either registered trademarks or
trademarks of Adobe Systems Incorporated.
Intel and Celeron are registered trademarks of Intel Corporation or its subsidiaries in the
United States and other countries.
ISIS and its logo are either registered trademarks or trademarks of Pixel Translations, a
division of EMC Corporation in the United States.
ScanSnap, the ScanSnap logo, and CardMinder are the trademarks of PFU LIMITED.
Other product names are the trademarks or registered trademarks of the respective
companies.
How Trademarks and Product Names Are Indicated In
This Manual
References to operating systems (OS) are indicated as follows:
Windows 2000
Windows XP
Windows Vista
Windows Windows 2000, Windows XP, and Windows Vista
Microsoft
Microsoft
Microsoft
Microsoft
Microsoft
Microsoft
Microsoft
Microsoft
®
Windows® 2000 Professional operating system
®
Windows® XP Professional operating system
®
Windows® XP Home Edition operating system
®
Windows Vista® Home Basic operating system
®
Windows Vista® Home Premium operating system
®
Windows Vista® Business operating system
®
Windows Vista® Enterprise operating system
®
Windows Vista® Ultimate operating system
ScanSnap S300 Getting Started 2
ATTENTION
The screenshots used in this manual are of Windows XP. Depending on
the operating systems you are using, the screen examples and
operations may differ from the actual ones.
ScanSnap and the Manuals
The ScanSnap S300 consists of:
Component Specification
S300 Color image scanner
ScanSnap Manager ScanSnap's driver to scan and save documents
ScanSnap Organizer Software to edit, browse, and manage images
scanned with ScanSnap
CardMinder Software with OCR engine to capture and manage
business card data for Personal Information
Manager software such as Microsoft
Following manuals are prepared for you:
Manual Description
ScanSnap S300
Getting Started (This manual)
ScanSnap S300
Getting Started
(Cable Connection)
ScanSnap S300
Operator's Guide
ScanSnap Organizer
User's Guide
CardMinder
User's Guide
Provides basic information to install and use the
ScanSnap.
Provides detailed information on how to connect the
ScanSnap to your computer.
Provides detailed information about the installation
of the ScanSnap software and hardware, operation
of the scanner hardware and ScanSnap Manager.
Find in: ScanSnap Setup CD-ROM (PDF file)
Provides detailed information on how to use
ScanSnap Organizer.
Find in: ScanSnap Setup CD-ROM (PDF file)
Provides detailed information on how to use
CardMinder.
Find in: ScanSnap Setup CD-ROM (PDF file)
®
Outlook
®
3
Regulatory Information
FCC declaration
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase separation between equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is located.
• Consult your dealer or an experienced radio/TV technician.
WARNING
ATTENTION
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
• The use of a shielded interface cable is required to comply with the
Class B limits of Part 15 of FCC rules.
• The length of the AC cable must be 3 meters (10 feet) or less.
Canadian DOC Regulations
This digital apparatus does not exceed the Class B limit for radio noise emissions from
digital apparatus set out in the Radio interference Regulations of the Canadian
Department of Communications.
This Class B digital apparatus complies with Canadian ICES-003.
Le présent appareil numérique n'ément pas de parasites radioélectriques dépassant les
limites applicables aux appareils numériques de la classe B et prescrites dans le
Réglesment sur le brouillage radioélectrique dictées par le Ministere des
Communications du Canada.
Cet appareil numérique de la classe B est conformme à la norme NMB-003 du Canada.
ScanSnap S300 Getting Started 4
Bescheinigung des Herstellers / Importeurs
Für den S300 wid folgendes bescheinigt:
• In Übereinsstimmung mit den Bestimmungen der EN45014(CE) funkentstört
• Maschinenlärminformationsverordnung 3. GPSGV: Der höchste Schalldruckpegel beträgt 70 dB (A) oder weniger, gemäß EN ISO 7779.
Dieses Gerät wurde nicht für die Benutzung in unmittelbarer Umgebung starker
Lichtquellen (z. B. Projektoren) konzipiert.
International ENERGY STAR® Program
As an ENERGY STAR® Partner, PFU LIMITED has determined that this product meets
the ENERGY STAR® guidelines for energy efficiency.
The International ENERGY STAR
international program that promotes energy saving through the
penetration of energy efficient computers and other office equipment.
The program backs the development and dissemination of products
with functions that effectively reduce energy consumption. It is an
open system in which business proprietors can participate voluntarily.
The targeted products are office equipment such as computers,
monitors, printers, facsimiles, copiers, scanners, and multifunction devices. Their
standards and logos are uniform among participating nations.
®
Office Equipment Program is an
Use in High-Safety Applications
This product has been designed and manufactured on the assumption that it will be used
in office, personal, domestic, regular industrial, and general-purpose applications. It has
not been designed and manufactured for use in applications (simply called "high-safety
applications" from here on) that directly involve danger to life and health when a high
degree of safety is required, for example, in the control of nuclear reactions at nuclear
power facilities, automatic flight control of aircraft, air traffic control, operation control
in mass-transport systems, medical equipment for sustaining life, and missile firing
control in weapons systems, and when provisionally the safety in question is not ensured.
The user should use this product with adopting measures for ensuring safety in such highsafety applications. PFU LIMITED assumes no liability whatsoever for damages arising
from use of this product by the user in high-safety applications, and for any claims or
compensation for damages by the user or a third party.
5
Conventions
Warning Indications Used in This Manual
WARNING
CAUTION
This sign warns the operator that improper use, indicated with this
sign, may cause death or severe injury of the operator or people in the
vicinity, if not followed.
This sign warns the operator that improper use, indicated with this
sign, may cause minor injury of the operator, or damage to equipment
or property, if not followed.
Symbols Used in This Manual
This manual uses the following symbols in explanations in addition to warning
indications:
ATTENTION
HINT
This symbol alerts operators to particularly important information.
Be sure to read this information.
This symbol alerts operators to helpful advice regarding operation.
This symbol indicates the section where you can get information on
related matters such as operation methods.
R
A TRIANGLE symbol indicates that special care and attention is
required.
The drawing inside the triangle shows the specific caution.
A CIRCLE with a diagonal line inside shows action which users may not
perform.
The drawing inside or under the circle shows the specific action that is
not allowed.
Outline characters on a colored background show instructions users
should follow.
It may also include the drawing that shows the specific instruction.
ScanSnap S300 Getting Started 6
Screen Examples in This Manual
The screen examples in this manual are subject to change without notice in the interest of
product improvement.
The screenshots used in this manual are of Windows XP. If the actual screens differ from
those used as examples in this manual, operate by following the actual ones referring to
the User's manual of the scanner.
The screenshots used in this manual are for ScanSnap Manager, ScanSnap Organizer, and
CardMinder.
About Maintenance
Repairs should be done by properly trained repair technicians.
When this product needs servicing, please contact the store where you purchased it or any
authorized FUJITSU Image Scanner service provider.
7
Safety Precautions
FOLLOW THESE INSTRUCTIONS AND BE SURE TO HEED ALL WARNINGS
AND CAUTIONS DESCRIBED BELOW.
WARNING
The following describes important warnings.
Do not touch the power plug, or connect/disconnect the power or USB bus
power cable with wet hands. Doing so might cause electric shock.
A damaged power or USB bus power cable may cause fire or electric shock.
Do not place heavy objects on the power or USB bus power cable, or pull,
bend, twist, heat, damage or modify it.
Do not use damaged power or USB bus power cables or power plugs. Also,
do not use the power cable when the wall socket is loose.
Use only specified power, USB bus power, and interface cables. Failure to
use the correct cables might cause electric shock and equipment failure.
Use this scanner only at the indicated power voltage and current. Improper
power voltage and current might cause fire or electric shock.
Also, do not connect to multiple-power strips.
Wipe off any dust from the metal part and surrounding section of the power
plug and those of the USB bus power cable with a soft, dry cloth.
Accumulated dust might cause fire or electric shock.
Do not install the scanner in locations subject to oil smoke, steam, humidity,
and dust. Doing so might cause a fire or electric shock.
To avoid low-temperature burn, do not operate the scanner while keeping
touching its heat-generating section such as the bottom of the scanner or the
AC adapter for a long time.
Do not cover the scanner or the AC adapter with a cloth or blanket while the
power is being supplied to the scanner. This can help excessive heat
generation, and may cause fire.
Do not use the scanner at a place such as a bathroom, shower room, or
swimming pool where it may easily get wet or moistured. Doing so might
cause electric shock or fire.
ScanSnap S300 Getting Started 8
If you detect heat coming from the device or detect other problems such as
smoke, strange smells or noises, immediately turn off the scanner, and
disconnect its power plug from the power outlet, or unplug the USB bus
power cable from the computer.
Make sure that the smoking has stopped, and then contact the store where
you bought the scanner or an authorized FUJITSU scanner service provider.
Firmly insert the power plug and into the power outlet, or the USB bus power
cable into the USB port on the computer as far it can go. Not doing so might
cause electric shock or fire.
Do not place heavy objects on the scanner or use the scanner's top surface
for performing other work. Improper installation might cause injuries or
scanning failure.
When the scanner is not used for a long period, be sure to disconnect the
power plug from the power outlet, or disconnect the USB bus power cable
from the computer for safety. Not doing so might cause electric shock or fire.
In case you have dropped the scanner and any of the parts (e.g., cover) is
broken, disconnect the power plug from the power outlet, or disconnect the
USB bus power cable from the computer. Then, contact the store where you
bought the scanner or an authorized FUJITSU scanner service provider.
Do not insert or drop metal or flammable foreign objects into the scanner. Do
not scan wet documents or documents with paper clips or staples. Do not
splash or allow the scanner to get wet.
If foreign objects (water, small metal objects, liquids, etc.) get inside the
scanner, immediately turn off the scanner and disconnect the power plug
from the power outlet, or the USB bus power cable from the computer, and
disconnect the interface cable from the computer. Then, contact the store
where you bought the scanner or an authorized FUJITSU scanner service
provider. Pay particular attention to this warning in households where there
are small children.
Do not take apart or modify the scanner. The inside of the scanner contains
high-voltage components. Touching these components might cause fire or
electric shock.
To avoid injuries, do not place the scanner in an area where small children may
be able to reach.
Do not use the scanner while driving a car for safety. Accidents can happen.
9
Do not leave the scanner in the direct sunlight, at high temperature such as in
a car in the scorching sun, or near heating apparatus. Doing so might cause
excessive heat to build up inside the scanner, causing heating, deforming, or
melting of the scanner parts (e.g., cover), and raising the temperature inside
the scanner, which could result in fire or scanner trouble. Install the scanner in
a well-ventilated location.
Do not move the scanner with the power and interface cables connected as
this might damage the cables, causing fire, electric shock or injuries.
Before moving the scanner, be sure to disconnect the power plug from the
power outlet, and disconnect interface cables as well. Also, make sure that
the floor is free of obstructions.
Avoid getting a sleeve, necktie, or hair caught up in any scanner mechanism
when scanning as this may cause injuries.
CAUTION
The following describes important cautions.
Install the scanner on a desk so that none of its parts protrude outside of the
desktop. Also, make sure that the scanner is installed on a flat, level surface.
Install the scanner away from strong magnetic fields and other sources of
electronic noise. Also, protect the scanner from static electricity as this might
cause the scanner to malfunction.
Do not use aerosol sprays to clean the scanner. Aerosol sprays cause dirt and
dust to enter the scanner, resulting in scanner failure and malfunction.
Do not use the scanner immediately after moving it from a cold place to a
warm room. This may cause condensation, which might lead to scanning
errors. Let the device dry about one or two hours before you use it.
When carrying the scanner outside while it is raining or snowing, pay close
attention so the scanner does not get wet or moistured.
When handling the paper, be careful not to cut your fingers by the paper.
ScanSnap S300 Getting Started 10
Chapter 1 Preparation
This chapter describes necessary preparations before using ScanSnap.
ATTENTION
Do not connect the scanner to your computer before installing
"ScanSnap Manager."
If the scanner is connected before installing ScanSnap Manager, it will
not operate correctly.
For the installation of ScanSnap Manager, refer to page 14
1.1 Checking the Contents of the Package
This manual describes how to install and connect the ScanSnap to your computer, and
describes basic operations of the ScanSnap.
Refer to the following manuals when necessary.
Manual See
ScanSnap S300 Getting Started
(Cable Connection)
(paper)
ScanSnap S300 Operator’s Guide
(PDF)
ScanSnap Organizer User’s Guide
(PDF)
CardMinder User’s Guide
(PDF)
Plastic bag where the supplied cables are packed
• ScanSnap Setup CD-ROM
• After installation of ScanSnap Manager, select
[Start] D [All Programs] D [ScanSnap Manager]
D [ScanSnap Operator’s Guide].
• ScanSnap Setup CD-ROM
• After installation of ScanSnap Organizer, select
[Start] D [All Programs] D [ScanSnap
Organizer] D [Manual].
• ScanSnap Setup CD-ROM
• After installation of CardMinder, select [Start] D
[All Programs] D [CardMinder] D [Manual].
11
ATTENTION
To browse the manuals above, you will need to install Adobe® Reader
(Acrobat Reader™) or an equivalent PDF-supported application, or
ScanSnap Organizer.
®
Loading...
