Data Sheet Fujitsu ESPRIMO P9900 E-Star5 Desktop PC
N
O
R
D
I
C
E
C
O
L
A
B
E
L
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Data Sheet
Fujitsu ESPRIMO P9900 E-Star5
Desktop PC
The expandable business workhorse
ESPRIMO P9900 E-Star5
The ESPRIMO P9900, equipped with state-of-the-art, highly innovative Intel® processor technology
with Turbo Boost and hyperthreading, is the ideal companion for all those highly demanding business
applications. Produced with selected material and equipped with comprehensive powersave options
and energy-saving management, the ESPRIMO microtower PC today already meets the environment
requirements of tomorrow. With extended system management functions, intelligent hardware
design, extensive tests and a lifecycle of up to 18 months, the high performance levels of this PC
meet every requirement. Furthermore, this microtower, equipped with a power supply with up to 87%
efciency, meets ENERGY STAR® certication requirements.
Microtower
Maximum performance and optimal extendability
Top-quality, high-value microtower, 6 drive bays, 4 PCI/PCI express interfaces
Environmentally conscious product with ENERGY STAR certification
Your contribution to environmental protection for the continued existence of our planet
Halogen-free mainboard, sophisticated product concept for the entire lifecycle
Highest energy efficiency coupled with intelligent performance
The best-in-class regarding power consumption combined with new levels of performance
State-of-the-art Intel® Core™ processors with Turbo Boost and hyperthreading technology and a
power supply with up to 89% efciency
System management
Easy system administration for complex IT infrastructure
Intel® vPro™ technology
Silent operation
Pleasant working environment due to an extremely quiet system
Innovative hardware design, optimized fan concept
Page 1 / 8 http://ts.fujitsu.com/ESPRIMO
Data Sheet Fujitsu ESPRIMO P9900 E-Star5 Desktop PC
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Components
Processor Intel® Core™ i7-870 processor (4 Cores / 8 Threads, 2.93 GHz, 8 MB)
Intel® Core™ i7-860 processor (4 Cores / 8 Threads, 2.80 GHz, 8 MB)
Intel® Core™ i5-760 processor (4 Cores / 4 Threads, 2.80 GHz, 8 MB)
Intel® Core™ i5-750 processor (4 Cores / 4 Threads, 2.66 GHz, 8 MB)
Intel® Core™ i5-680 processor (2 Cores / 4 Threads, 3.6 GHz, 4 MB, Intel® HD Graphics)
Intel® Core™ i5-660 processor (2 Cores / 4 Threads, 3.33 GHz, 4 MB, Intel® HD Graphics)
Intel® Core™ i5-650 processor (2 Cores / 4 Threads, 3.20 GHz, 4 MB, Intel® HD Graphics)
Intel® Core™ i3-550 processor (2 Cores / 4 Threads, 3.20 GHz, 4 MB, Intel® HD Graphics)
Intel® Core™ i3-540 processor (2 Cores / 4 Threads, 3.06 GHz, 4 MB, Intel® HD Graphics)
Intel® Pentium® processor G6950 (2 Cores / 2 Threads, 2.80 GHz, 3 MB, Intel® HD Graphics)
Operating system
Operating system Genuine Windows® 7 Home Basic (EM) 32-bit
Genuine Windows® 7 Home Premium 64-bit
Genuine Windows® 7 Professional 32-bit
Genuine Windows® 7 Professional 64-bit
Operating system compatible openSUSE Linux
Genuine Windows Vista®
Genuine Windows® XP
Operating system notes Microsoft Ofce 2010 preloaded. Purchase a Product Key to activate a full Microsoft Ofce 2010 suite.
Limited Windows XP support. Microsoft discontinued Windows XP certication on system level.
Memory modules 2 GB (1 module(s) 2 GB) DDR3, unbuffered, non-ECC, 1333 MHz, PC3-10600, DIMM
4 GB (1 module(s) 4 GB) DDR3, unbuffered, non-ECC, 1333 MHz, PC3-10600, DIMM
Hard disk drives (internal) SSD SATA, 128 GB, 2.5-inch
SATA II, 7200 rpm, 1000 GB, 3.5-inch, S.M.A.R.T.
SATA II, 7200 rpm, 500 GB, 3.5-inch, S.M.A.R.T. business critical
SATA II, 7200 rpm, 500 GB, 3.5-inch, S.M.A.R.T.
SATA II, 7200 rpm, 320 GB, 3.5-inch, S.M.A.R.T.
SATA II, 7200 rpm, 250 GB, 3.5-inch, S.M.A.R.T.
SATA II, 7200 rpm, 160 GB, 2.5-inch, S.M.A.R.T.
Supporting NCQ and 3 GBit
Graphics add on cards (optional) NVIDIA® Quadro® NVS 290, 256 MB
NVIDIA® GeForce® GT 420
NVIDIA® GeForce® 9500GS, 512 MB
NVIDIA® GeForce® 9300GE display port low prole, 512 MB
NVIDIA® GeForce® 9300GE, 512 MB
NVIDIA® GeForce® 405 display port full height
DP to DVI-D (single link) Adapter Cable
ATI Radeon® HD 5450, 512 MB
Drives (optional) Blu-ray Disc™ Triple Writer
DVD-ROM
DVD Super Multi
MultiCard Reader 20in1, USB 2.0, 3.5-Inch
MultiCard Reader 20in1 USB 3.0 front con., 3.5-Inch
Page 2 / 8 http://ts.fujitsu.com/ESPRIMO
Data Sheet Fujitsu ESPRIMO P9900 E-Star5 Desktop PC
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Interface add on cards/components
(optional)
WLAN III, 802.11g/Draft-n (Windows only)
USB 3.0 PCIe x1
Parallel Interface
Modem adapter kit (EU)
Modem 56k incl. RJ11 modem cable
Gigabit Ethernet PCIe x1
FireWire PCI-Card IEEE1394
eSATA Interface
Dual serial card PCI
Base unit ESPRIMO P9900 E-Star5
Mainboard
Mainboard type D2912
Formfactor µBTX
Chipset Intel® Q57
Processor socket LGA 1156
Processor quantity maximum 1
Memory slots 4 DIMM (DDR3)
Supported capacity RAM (max.) 16 GB
Memory frequency 1333 MHz
Memory notes Dual channel support.
For dual channel performance, identical memory modules in each channel are necessary (minimum 2 modules).
LAN 10/100/1000 MBit/s Intel® 82578 DM
BIOS version Phoenix 6.0
BIOS features BIOS Flash EPROM update by software
Recovery BIOS
Audio codec Realtek ALC663
Audio features Internal speaker supports audio playback, High Denition audio, 5.1 surround sound
I/O controller on board
Serial ATA total 4
thereof eSATA 2 (optional)
Controller functions Serial ATA II
NCQ and 3 GBit
AHCI
Raid 1/0
Interfaces
Audio: line-in 1
Audio: line-in / microphone 1
Audio: line-out 1
Front audio: microphone 1
Front audio: headphone 1
USB 2.0 total 14
USB front 2
USB rear 8
USB internal 4
VGA 1 (via DVI to VGA adapter; included for onboard graphics only)
DisplayPort 1 (for onboard graphics only)
DVI 1 (for onboard graphics only)
Serial (RS-232) 1 (9pin, 16 byte FIFO, 16550 compatible)
Page 3 / 8 http://ts.fujitsu.com/ESPRIMO
Data Sheet Fujitsu ESPRIMO P9900 E-Star5 Desktop PC
Interfaces
Mouse / Keyboard (PS/2) 2
Ethernet (RJ-45) 1
Parallel 1 (optional) (25pin with EPP and ECP)
Interface Module notes Anytime USB charge functionality
Input device / components
Optical USB tilt wheel mouse
Input devices (optional) Optical USB/PS2 tilt wheel mouse
Drive bays
Drive bays total 6
3.5-inch internal bays 2
3.5-inch external bays 2
5.25-inch external bays 2
Slots
PCI-Express 2.0 x16 1 x (230 mm) FlexySlot
PCI-Express x4 (mech x16) 1 x (230 mm) full height
PCI (32-bit / 33 MHz) 2 x (170 / 315 mm) full height
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Graphics on board
Graphics brand name Intel® HD Graphics (integrated in dual-core processors only)
Shared video memory up to 1759 MB
Refresh rate 1024 x 768 (recommended
/ max.)
Refresh rate 1280 x 1024
(recommended / max.)
Refresh rate 1600 x 1200
(recommended / max.)
TFT resolution (VGA) 1360 x 768 pixel
TFT resolution (DVI) 1360 x 768 pixel
TFT resolution (DisplayPort) 1360 x 768 pixel
Graphics features Dual display support
85 Hz / -
85 Hz / -
85 Hz / -
1440 x 900 pixel
1600 x 900 pixel
1680 x 1050 pixel
1920 x 1080 pixel
1920 x 1200 pixel
1440 x 900 pixel
1600 x 900 pixel
1680 x 1050 pixel
1920 x 1080 pixel
1920 x 1200 pixel
1440 x 900 pixel
1600 x 900 pixel
1680 x 1050 pixel
1920 x 1080 pixel
1920 x 1200 pixel
2560 x 1440 pixel
2560 x 1600 pixel
DirectX 10.1
HDCP support
OpenGL® 2.0
Page 4 / 8 http://ts.fujitsu.com/ESPRIMO
Data Sheet Fujitsu ESPRIMO P9900 E-Star5 Desktop PC
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Graphics on board
Graphics notes Graphics controller integrated in dual-core processors. For quad-core processors graphics card is mandatory.
Tested resolutions, depending on display type additional resolutions and frequencies possible
Shared memory depending on main memory size and operating system
Resolution (color depth up to 32 Bit/pixel)
For TFT we recommend using 60Hz
Electrical values
Power efciency note power supply efciency (at 230V; 20% / 50% / 100% load) : 85% / 87% / 85%
0-Watt mode with hard-off switch
Rated voltage range 100 V - 240 V
Rated frequency range 50 Hz - 60 Hz
Operating voltage range 90 V - 264 V
Operating line frequency range 47 Hz - 63 Hz
Max. output of single power supply 300 W
Power factor correction/active power active
Monitor outlet No
Power consumption
Power consumption note See white paper Energy Consumption
0-Watt mode with hard-off switch
Link to Energy White Paper http://docs.ts.fujitsu.com/dl.aspx?id=adfeda65-820c-4844-b1a2-a270b53134db
Heat dissipation
Heat dissipation notes See white paper Energy Consumption
Noise for standard conguration (HDD, ODD, FDD)
Noise emission According to ISO9296
Related Processors for noise Intel® Core™ i5-670 ; Intel® Core™ i7-860 including NVIDIA® Geforce® 9500GS
Noise Operation mode 1: ODD load
(Blue angel requirement)
Noise Operation mode 2: HDD load
(Blue angel requirement)
Noise Operation mode 3: CPU 90% load
(Blue angel requirement)
Noise Operation mode 4: High load 3.9 B / 23 dB(A) ; 3.9 B / 24 dB(A)
Noise Operation mode 5: Ofce
applications
Idle mode (Blue Angel requirement) 3.7 B / 20 dB(A) ; 3.6 B / 20 dB(A)
Noise notes / description A weighted sound power level Lwad (in B) / workplace related A-weighted sound pressure level LpAm (in dB(A)),
Dimensions / Weight / Environmental
Dimensions (W x D x H) 203 x 390 x 392 mm
Operating position Vertical
Weight approx. 12 kg
Weight notes Actual weight may vary depending on conguration
Operating ambient temperature 10 - 35°C
4.4 B / 29 dB(A) ; 4.4 B / 29 dB(A)
3.7 B / 21 dB(A) ; 3.6 B / 21 dB(A)
3.9 B / 24 dB(A) ; 3.9 B / 24 dB(A)
3.8 B / 22 dB(A) ; 3.6 B / 20 dB(A)
Bystander position
Compliance
Product ESPRIMO P9900
Model MI3W-D2912
Germany Blauer Engel / Blue Angel
GS optional
Europe CE
Nordic Swan
Page 5 / 8 http://ts.fujitsu.com/ESPRIMO
Data Sheet Fujitsu ESPRIMO P9900 E-Star5 Desktop PC
Compliance
USA/Canada FCC Class B
cCSAus
Global RoHS (Restriction of hazardous substances)
WEEE (Waste electrical and electronical equipment)
Microsoft Operating Systems (HCT / HCL entry / WHQL)
ENERGY STAR® 5.0
EPEAT® Silver
Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx
Additional Software
Additional software (preinstalled) Nero Essentials S (burning software)
Additional software (optional) Recovery DVD for Windows®
Drivers & Utilities DVD (DUDVD)
CyberLink PowerDVD BD (playback software for Blu-ray Disc™, only with Blu-ray Disc™ drive / Blu-ray playback is not
supported under Windows XP if the system runs on Intel onboard graphics)
Nero 9 Essentials XL
Miscellaneous
Thermal management
Keyboard on (Special Fujitsu keyboard required)
Extended lifetime
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Compatibility (references)
DMI 2.0
PC 2001
WMI 1.5
USB 2.0
SMBIOS
Manageability
Manageability features DeskUpdate Driver management
PXE 2.1 Boot code
Wake up from S5 (off mode)
Intrusion switch (optional)
iAMT 6.0
Manageability type DeskView 10.x client management including:
DeskView features On/Ofine remote client management
Detailed system inventory management and reports
BIOS Management
Remote power management
System notications
Advanced alerts (ASF implementation)
Security Remote Control
DeskView Helpdesk Integration
WoL (Wake on LAN)
Security
Physical security Kensington Lock support
Eye for padlock
Optional: Integrated cabinet lock
System security Boot sector virus protection
Write protect option for the Flash EPROM
Embedded security (TPM 1.2)
Control of all USB interfaces
External USB ports can be disabled separately
Control of external interfaces
Page 6 / 8 http://ts.fujitsu.com/ESPRIMO
Data Sheet Fujitsu ESPRIMO P9900 E-Star5 Desktop PC
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Security
User security User and supervisor BIOS password
SystemLock 2 BIOS SmartCard Security
Hard disk password
Optional: Access protection via external SmartCard reader
Optional: Access protection via internal SmartCard reader
Serviceability
FlexySlot
EasyFix
EasyChange for HDD
EasyChange for optical drives
Packaging information
Packaging dimension 500x290x540 mm
Max. quantity / pallet 24
Material - Weight (g) Carton 1270 g
Material - Weight (g) EPS / PS 230 g
Material - Weight (g) PE appr. 60 g
Packaging notes printed user documentation is bleached in chlorine free process
Warranty
Standard Warranty 3 years
Service level Bring-In / On-Site Service (depending on country)
Maintenance and Support Services - the perfect extension
Recommended Service 5x9, Response Time: Next Business Day
Spare Parts availability 5 years
Service Weblink http://ts.fujitsu.com/Supportservice
Page 7 / 8 http://ts.fujitsu.com/ESPRIMO
Data Sheet Fujitsu ESPRIMO P9900 E-Star5 Desktop PC
More information
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Fujitsu platform solutions
In addition to Fujitsu ESPRIMO P9900 E-Star5,
Fujitsu provides a range of platform solutions.
They combine reliable Fujitsu products with
the best in services, know-how and worldwide
partnerships.
Dynamic Infrastructures
With the Fujitsu Dynamic Infrastructures
approach, Fujitsu offers a full portfolio of IT
products, solutions and services, ranging
from clients to datacenter solutions, Managed
Infrastructure and Infrastructure as-a-
Service. How much you benet from Fujitsu
technologies and services depends on the
level of cooperation you choose. This takes IT
exibility and efciency to the next level.
Computing Products
www.fujitsu.com/global/services/computing/
Software
www.fujitsu.com/software/
More information
Learn more about Fujitsu ESPRIMO P9900
E-Star5, please contact your Fujitsu sales
representative or Fujitsu Business partner, or
visit our website.
http://ts.fujitsu.com/ESPRIMO
Fujitsu green policy innovation
Fujitsu Green Policy Innovation is our
worldwide project for reducing burdens on the
environment. Using our global know-how, we
aim to resolve issues of environmental energy
efciency through IT. Please nd further
information at http://www.fujitsu.com/global/
about/environment/
Copyrights
All rights reserved, including intellectual
property rights. Changes to technical data
reserved. Delivery subject to availability. Any
liability that the data and illustrations are
complete, actual or correct is excluded.
Designations may be trademarks and/or
copyrights of the respective manufacturer,
the use of which by third parties for their
own purposes may infringe the rights of such
owner.
For further information see http://ts.fujitsu.
com/terms_of_use.html
Copyright © Fujitsu Technology Solutions
Disclaimer
Technical data are subject to modication and
delivery subject to availability. Any liability
that the data and illustrations are complete,
actual or correct is excluded. Designations
may be trademarks and/or copyrights of the
respective manufacturer, the use of which
by third parties for their own purposes may
infringe the rights of such owner
Contact
FUJITSU Technology Solutions
Website: http://ts.fujitsu.com
2010-12-27 CE-EN
Page 8 / 8 http://ts.fujitsu.com/ESPRIMO
All rights reserved, including intellectual property rights. Changes to technical data reserved. Delivery subject to availability.
Any liability that the data and illustrations are complete, actual or correct is excluded.
Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for their
own purposes may infringe the rights of such owner.
For further information see http://ts.fujitsu.com/terms_of_use.html
Copyright © Fujitsu Technology Solutions
Loading...
