Data Sheet Fujitsu ESPRIMO P5645 E-Star5 Desktop PC
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Data Sheet
Fujitsu ESPRIMO P5645 E-Star5
Desktop PC
Your expandable workhorse
ESPRIMO P5645 E-Star5
The ESPRIMO P5645 E-Star5 is equipped with the latest AMD technology and offers extraordinary
performance. With the powerful six-core processor from AMD this system reaches new performance
levels enabling fast and easy handling of challenging tasks. The ESPRIMO P5645 E-Star5 offers
optimal expandability due to its microtower design. This system, also equipped with an 87% efcient
power supply, is very energy-efcient and meets the requirements of the new ENERGY STAR®
certicate. Reduce your costs by reducing your power consumption.
Microtower
Maximum performance and optimal extendability
Top-quality, high-value microtower, 6 drive bays, 4 PCI/PCI express interfaces
New performance high
Fast and easy handling of challenging tasks at maximum performance
High-quality six-core processor with Turbo Core technology
ENERGY STAR®
Low power consumption and low costs, without any loss in performance
Power supply with up to 87% efciency and enhanced power management settings
Silent operation
Pleasant working environment due to an extremely quiet system
Innovative hardware design, optimized cooling concept
Serviceablitiy
Easy to extend and optimal user-friendliness without any additional tools
Easy access to all replaceable and expandable components
Page 1 / 8 http://ts.fujitsu.com/ESPRIMO
Data Sheet Fujitsu ESPRIMO P5645 E-Star5 Desktop PC
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Components
Processor AMD Phenom™ II X6 1035T (6 Cores, 2.6 GHz, 9 MB)
AMD Phenom™ II X4 945 (4 Cores, 3.0 GHz, 8 MB)
AMD Phenom™ II X2 550 (2 Cores, 3.1 GHz, 7 MB)
AMD Athlon™ II X2 255 (2 Cores, 3.1 GHz, 2 MB)
AMD Athlon™ II X2 220 (2 Cores, 2.8 GHz, 1 MB)
Operating system
Operating system Genuine Windows® 7 Home Basic (EM) 32-bit
Genuine Windows® 7 Home Premium 64-bit
Genuine Windows® 7 Professional 32-bit
Genuine Windows® 7 Professional 64-bit
Operating system compatible openSUSE Linux
Genuine Windows Vista®
Genuine Windows® XP
Operating system notes Microsoft Ofce 2010 preloaded. Purchase a Product Key to activate a full Microsoft Ofce 2010 suite.
Limited Windows XP support. Microsoft discontinued Windows XP certication on system level.
Memory modules 2 GB (1 module(s) 2 GB) DDR3, unbuffered, non-ECC, 1333 MHz, PC3-10600, DIMM
4 GB (1 module(s) 4 GB) DDR3, unbuffered, non-ECC, 1333 MHz, PC3-10600, DIMM
Hard disk drives (internal) SSD SATA, 128 GB, 2.5-inch
SATA II, 7200 rpm, 1000 GB, 3.5-inch, S.M.A.R.T.
SATA II, 7200 rpm, 500 GB, 3.5-inch, S.M.A.R.T. business critical
SATA II, 7200 rpm, 500 GB, 3.5-inch, S.M.A.R.T.
SATA II, 7200 rpm, 320 GB, 3.5-inch, S.M.A.R.T.
SATA II, 7200 rpm, 250 GB, 3.5-inch, S.M.A.R.T.
SATA II, 7200 rpm, 160 GB, 2.5-inch, S.M.A.R.T.
Supporting NCQ and 3 GBit
Graphics add on cards (optional) NVIDIA® Quadro® NVS 300, 512 MB
NVIDIA® Quadro® NVS 290, 256 MB
NVIDIA® GeForce® GT 420
NVIDIA® GeForce® 9300GE display port low prole, 512 MB
NVIDIA® GeForce® 9300GE, 512 MB
NVIDIA® GeForce® 405 display port full height
LFH59/ 2x DVI-I adapter cable
LFH59/ 2x DP adapter cable
DP to DVI-D (single link) Adapter Cable
ATI Radeon® HD 5450, 512 MB
Drives (optional) Blu-ray Disc™ Triple Writer
DVD-ROM
DVD Super Multi
MultiCard Reader 20in1, USB 2.0, 3.5-Inch
Interface add on cards/components
(optional)
Parallel Interface
eSATA Interface
Base unit ESPRIMO P5645 E-Star5
Page 2 / 8 http://ts.fujitsu.com/ESPRIMO
Data Sheet Fujitsu ESPRIMO P5645 E-Star5 Desktop PC
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Mainboard
Mainboard type D2981
Formfactor µBTX
Chipset AMD 785G
Processor socket AM3
Processor quantity maximum 1
System bus (FSB / HT / QPI) up to 4000 MHz
Memory slots 4 DIMM (DDR3)
Supported capacity RAM (max.) 16 GB
Memory frequency 1333 MHz
Memory notes Dual channel support.
For dual channel performance, identical memory modules in each channel are necessary (minimum 2 modules).
LAN 10/100/1000 MBit/s Broadcom BCM57780
BIOS version Phoenix 6.0
BIOS features BIOS Flash EPROM update by software
Recovery BIOS
Audio codec Realtek ALC663
Audio features Internal speaker supports audio playback, High Denition audio
I/O controller on board
Serial ATA total 4
thereof eSATA 1 (optional)
Controller functions Serial ATA II
NCQ and 3 GBit
AHCI
Raid 1/0
Interfaces
Audio: line-in 1
Audio: line-in / microphone 1
Audio: line-out 1
Front audio: microphone 1
Front audio: headphone 1
USB 2.0 total 12
USB front 2
USB rear 6
USB internal 4
VGA 1 (via DVI to VGA adaptor; included for onboard graphics only)
DisplayPort 1
DVI 1 (Dual link DVI-I)
Serial (RS-232) 1 (9pin, 16 byte FIFO, 16550 compatible)
Mouse / Keyboard (PS/2) 2
Ethernet (RJ-45) 1
Parallel 1 (optional) (25pin with EPP and ECP)
Interface Module notes Anytime USB charge functionality
Input device / components
Optical USB tilt wheel mouse
Input devices (optional) Optical USB/PS2 tilt wheel mouse
Drive bays
Drive bays total 6
3.5-inch internal bays 2
3.5-inch external bays 2
5.25-inch external bays 2
Page 3 / 8 http://ts.fujitsu.com/ESPRIMO
Data Sheet Fujitsu ESPRIMO P5645 E-Star5 Desktop PC
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Slots
PCI-Express 2.0 x16 1 x (230 mm) FlexySlot
PCI-Express 2.0 x4 (mech. x16) 1 x (230 mm) full height
PCI (32-bit / 33 MHz) 2 x (170 / 315 mm) full height
Graphics on board
Graphics brand name ATI Radeon® HD 4200
Shared video memory up to 2811 MB
Refresh rate 1024 x 768 (recommended
/ max.)
Refresh rate 1280 x 1024
(recommended / max.)
Refresh rate 1600 x 1200
(recommended / max.)
TFT resolution (VGA) 1360 x 768 pixel
TFT resolution (DVI) 1360 x 768 pixel
TFT resolution (DisplayPort) 1360 x 768 pixel
Graphics features Dual display support
Graphics notes up to 512 MB dedicated video memory (main memory owned and locked for graphics use)
85 Hz / -
85 Hz / -
85 Hz / -
1440 x 900 pixel
1600 x 900 pixel
1680 x 1050 pixel
1920 x 1080 pixel
1920 x 1200 pixel
1440 x 900 pixel
1600 x 900 pixel
1680 x 1050 pixel
1920 x 1080 pixel
1920 x 1200 pixel
2560 x 1440 pixel
2560 x 1600 pixel
1440 x 900 pixel
1600 x 900 pixel
1680 x 1050 pixel
1920 x 1080 pixel
1920 x 1200 pixel
2560 x 1440 pixel
2560 x 1600 pixel
DirectX 10.1
HDCP support
OpenGL® 2.0
Tested resolutions, depending on display type additional resolutions and frequencies possible
Shared memory depending on main memory size and operating system
Resolution (color depth up to 32 Bit/pixel)
For TFT we recommend using 60Hz
Electrical values
Power efciency note power supply efciency (at 230V; 20% / 50% / 100% load) : 85% / 87% / 85%)
0-Watt mode with hard-off switch
Rated voltage range 100 V - 240 V
Rated frequency range 50 Hz - 60 Hz
Operating voltage range 90 V - 264 V
Operating line frequency range 47 Hz - 63 Hz
Max. output of single power supply 300 W
Power factor correction/active power active
Monitor outlet No
Page 4 / 8 http://ts.fujitsu.com/ESPRIMO
Data Sheet Fujitsu ESPRIMO P5645 E-Star5 Desktop PC
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Power consumption
Power consumption note See white paper Energy Consumption
Link to Energy White Paper http://docs.ts.fujitsu.com/dl.aspx?id=03379136-b9f6-4001-9a0d-319eb452db6a
Heat dissipation
Heat dissipation notes See white paper Energy Consumption
Noise for standard conguration (HDD, ODD, FDD)
Noise emission According to ISO9296
Related Processors for noise AMD® Phenom™ II X4 945
Noise Operation mode 1: ODD load
(Blue angel requirement)
Noise Operation mode 2: HDD load
(Blue angel requirement)
Noise Operation mode 3: CPU 90% load
(Blue angel requirement)
Noise Operation mode 4: High load 4.0B / 24 dB(A)
Noise Operation mode 5: Ofce
applications
Idle mode (Blue Angel requirement) 3.7B / 21 dB(A)
Noise notes / description A weighted sound power level Lwad (in B) / workplace related A-weighted sound pressure level LpAm (in dB(A)),
4.4B / 29 dB(A)
3.8B / 22 dB(A)
3.8B / 24 dB(A)
3.7B / 22 dB(A)
Bystander position
Dimensions / Weight / Environmental
Dimensions (W x D x H) 203 x 390 x 392 mm
Operating position Vertical
Weight approx. 12 kg
Weight notes Actual weight may vary depending on conguration
Operating ambient temperature 10 - 35°C
Compliance
Product ESPRIMO P5645
Model MI3W-D2981
Germany Blauer Engel / Blue Angel
GS optional
Europe CE
Nordic Swan in progress
USA/Canada FCC Class B
cCSAus
Global RoHS (Restriction of hazardous substances)
WEEE (Waste electrical and electronical equipment)
Microsoft Operating Systems (HCT / HCL entry / WHQL)
ENERGY STAR® 5.0
EPEAT® Silver
Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx
Additional Software
Additional software (preinstalled) Nero Essentials S (burning software)
Additional software (optional) Recovery DVD for Windows®
Drivers & Utilities DVD (DUDVD)
CyberLink PowerDVD BD (playback software for Blu-ray Disc™, only with Blu-ray Disc™ drive / Blu-ray playback is not
supported under Windows XP if the system runs on Intel onboard graphics)
Nero 9 Essentials XL
Miscellaneous
Keyboard on (Special Fujitsu keyboard required)
Thermal management
Page 5 / 8 http://ts.fujitsu.com/ESPRIMO
Data Sheet Fujitsu ESPRIMO P5645 E-Star5 Desktop PC
Compatibility (references)
DMI 2.0
PC 2001
WMI 1.5
USB 2.0
SMBIOS
Manageability
Manageability features DeskUpdate Driver management
PXE 2.1 Boot code
Wake up from S5 (off mode)
Intrusion switch (optional)
DASH 1.1 Support (optional)
Manageability type DeskView 10.x client management including:
DeskView features On/Ofine remote client management
Detailed system inventory management and reports
BIOS Management
Remote power management
System notications
Advanced alerts (ASF implementation)
Security Remote Control
DeskView Helpdesk Integration
WoL (Wake on LAN)
Manageability link http://ts.fujitsu.com/manageability
http://www.altiris.com/fujitsu
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Security
Physical security Kensington Lock support
Eye for padlock
Optional: Integrated cabinet lock
System security Boot sector virus protection
Write protect option for the Flash EPROM
Embedded security (TPM 1.2)
Control of all USB interfaces
External USB ports can be disabled separately
Control of external interfaces
User security User and supervisor BIOS password
SystemLock 2 BIOS SmartCard Security
Hard disk password
Optional: Access protection via external SmartCard reader
Optional: Access protection via internal SmartCard reader
Serviceability
FlexySlot
EasyFix
EasyChange for HDD
EasyChange for optical drives
Packaging information
Packaging dimension 500x290x540 mm
Max. quantity / pallet 24
Material - Weight (g) Carton 1270 g
Material - Weight (g) EPS / PS 230 g
Material - Weight (g) PE appr. 60 g
Packaging notes printed user documentation is bleached in chlorine free process
Warranty
Standard Warranty 1 year
Service level Bring-In / On-Site Service (depending on country)
Page 6 / 8 http://ts.fujitsu.com/ESPRIMO
Data Sheet Fujitsu ESPRIMO P5645 E-Star5 Desktop PC
Warranty
Maintenance and Support Services - the perfect extension
Recommended Service 5x9, Response Time: Next Business Day
Spare Parts availability 5 years
Service Weblink http://ts.fujitsu.com/Supportservice
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Page 7 / 8 http://ts.fujitsu.com/ESPRIMO
Data Sheet Fujitsu ESPRIMO P5645 E-Star5 Desktop PC
More information
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Fujitsu platform solutions
In addition to Fujitsu ESPRIMO P5645 E-Star5,
Fujitsu provides a range of platform solutions.
They combine reliable Fujitsu products with
the best in services, know-how and worldwide
partnerships.
Dynamic Infrastructures
With the Fujitsu Dynamic Infrastructures
approach, Fujitsu offers a full portfolio of IT
products, solutions and services, ranging
from clients to datacenter solutions, Managed
Infrastructure and Infrastructure as-a-
Service. How much you benet from Fujitsu
technologies and services depends on the
level of cooperation you choose. This takes IT
exibility and efciency to the next level.
Computing Products
www.fujitsu.com/global/services/computing/
Software
www.fujitsu.com/software/
More information
Learn more about Fujitsu ESPRIMO P5645
E-Star5, please contact your Fujitsu sales
representative or Fujitsu Business partner, or
visit our website.
http://ts.fujitsu.com/ESPRIMO
Fujitsu green policy innovation
Fujitsu Green Policy Innovation is our
worldwide project for reducing burdens on the
environment. Using our global know-how, we
aim to resolve issues of environmental energy
efciency through IT. Please nd further
information at http://www.fujitsu.com/global/
about/environment/
Copyrights
All rights reserved, including intellectual
property rights. Changes to technical data
reserved. Delivery subject to availability. Any
liability that the data and illustrations are
complete, actual or correct is excluded.
Designations may be trademarks and/or
copyrights of the respective manufacturer,
the use of which by third parties for their
own purposes may infringe the rights of such
owner.
For further information see http://ts.fujitsu.
com/terms_of_use.html
Copyright © Fujitsu Technology Solutions
Disclaimer
Technical data are subject to modication and
delivery subject to availability. Any liability
that the data and illustrations are complete,
actual or correct is excluded. Designations
may be trademarks and/or copyrights of the
respective manufacturer, the use of which
by third parties for their own purposes may
infringe the rights of such owner
Contact
FUJITSU Technology Solutions
Website: http://ts.fujitsu.com
2010-12-27 CE-EN
Page 8 / 8 http://ts.fujitsu.com/ESPRIMO
All rights reserved, including intellectual property rights. Changes to technical data reserved. Delivery subject to availability.
Any liability that the data and illustrations are complete, actual or correct is excluded.
Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for their
own purposes may infringe the rights of such owner.
For further information see http://ts.fujitsu.com/terms_of_use.html
Copyright © Fujitsu Technology Solutions
Loading...
