Introduction
Thank you for purchasing the "Scanner Utility for Microsoft® Windows® V9.20".
This software contains a TWAIN-compliant image scanner driver (simply called "driver" in this
guide) and utilities.
This guide provides a description summary of the driver, as well as a description of the
installation method and procedures for appropriate use. Please read this guide before starting to
use the software.
In addition, read the README.TXT file on the CD-ROM for the latest information not
included in this manual.
In this guide, product names are abbreviated as follows:
®
• "Microsoft
• "Microsoft
Windows NT
• "Microsoft
• "Microsoft
• "Microsoft
• "Microsoft
• "Microsoft
When "Windows
"Windows
referred to as "Windows
"Windows
®
XP" and "Windows ServerTM 2003" are referred to collectively, they are simply
[High Risk Activity]
The Customer acknowledges and agrees that the Product is designed, developed and manufactured as
contemplated for general use, including without limitation, general office use, personal use, household
use, and ordinary industrial use, but is not designed, developed and manufactured as contemplated for
use accompanying fatal risks or dangers that, unless extremely high safety is secured, could lead
directly to death, personal injury, severe physical damage or other loss (hereinafter "High Safety
Required Use"), including without limitation, nuclear reaction control in nuclear facility, aircraft flight
control, air traffic control, mass transport control, medical life support system, missile launch control in
weapon system. The Customer, shall not use the Product without securing the sufficient safety required
for the High Safety Required Use. In addition, PFU shall not be liable against the Customer and/or any
third party for any claims or damages arising in connection with the High Safety Required Use of the
Product.
Windows® 95 operating system": "Windows® 95"
®
Windows NT® Workstation operating system Version 4.0" and "Microsoft®
®
Server operating system Version 4.0": "Windows NT® 4.0"
®
Windows®98 operating system": "Windows®98"
®
Windows® 2000 Professional operating system": "Windows® 2000"
®
Windows® Millennium Edition operating system": "Windows® Me"
®
Windows® XP operating system": "Windows® XP"
®
Windows ServerTM 2003 operating system": "Windows ServerTM 2003"
®
95" "Windows® 98" "Windows NT® 4.0" "Windows® Me" "Windows® 2000"
®
". Unless otherwise indicated, explanations refer to "Windows® 95,"
8.2 Maintenance Service ..................................................................................179
vi
1. Outline
1.1 Characteristics of this Driver
• This driver complies with TWAIN regulations V1.9 (the latest version as of June 2006),
which are global standards for image scanners. The driver can be used in all TWAINcompliant applications.
• This driver also supports an image scanner that has the "double-sided scan" function. If
the application supports continuous scan, a double-sided document can be scanned.
1.2 Operating Environment
This driver can be used in the following systems:
[SCSI connection]
• A personal computer (recommended: Intel Pentium 100MHz or higher) on which one of
the following operating systems are installed
®
− Windows
− Windows
− Windows
− Windows
− Windows
In case of Windows
Refer to ”FUJITSU TWAIN32 Scanner Driver Version 8.20 User’s Guide”.
• Adaptec
98
®
Me
®
2000
®
XP
®
ServerTM 2003
®
95 or Windows NT® 4.0, FUJITSU TWAIN32 Version 8.20 is installed.
®
SCSI adapter or FUJITSU FMV SCSI adapter
− In some cases, the driver may not operate with the above systems. Please check in
advance with your place of purchase.
− Notes are provided on the accepted SCSI adapters in README.TXT, which is
included in the installation media. Please read these notes before use.
• This driver has the following hardware requirements:
− RAM: 32 MB or more (a minimum of 64 MB is recommended)
− Available hard disk space: 10 MB or more (excluding the area for storing images)
− CD-ROM drive (required for installation)
• Mouse (recommended)
[USB connection]
• A personal computer (recommended: Intel Pentium 100MHz or higher) on which one of
the following operating systems are installed
®
– Windows
− Windows
− Windows
98
®
Me
®
2000
1
− Windows
− Windows
®
XP
®
ServerTM 2003
• USB port
• RAM: 32 MB or more (a minimum of 64 MB is recommended)
• Available hard disk space: 10 MB or more (excluding the area for storing images)
• CD-ROM drive (required for installation)
• Mouse (recommended)
1.3 Explanatory Notes
The descriptions in this manual are prepared based on the following rules:
◊ Menus and buttons
The menus and buttons used in the program description are enclosed in [].
Example: [File] menu
[OK] button
◊ Keyboard
The keytop indications comply with the standard keyboard of the Fujitsu FMV series.
Major differences between the Fujitsu FMV keyboard and other keyboards are shown
below.
FMV keytops Other possible keytops
Alt Previous screen, GRPH
Ctrl CTRL
Esc ESC
Enter Return,
Shift SHIFT
Back space Backspace, BS
F1 PF1, f-1
◊ Terms related to mouse operation
Terms related to major mouse operations are explained below.
Click: To press and release the mouse left button
Double click: To quickly press the mouse left button twice
Drag: Move the mouse while keeping the mouse left button pressed
2
◊ Notes on operation procedures
If some menus need to be operated in a certain order, the procedural order is described as
follows:
[A] - [B] - [C]
In accordance with this description, operation [A] is executed first, followed by [B] and [C]
in that order.
◊ Figures
Figures and screen operations in this guide refer to Microsoft
also followed when using other operating systems.
Note that the expressions may vary with the type of scanner connected.
1.4 Explanation of terms
◊ IPC option board
®
Windows® 2000. They are
IPC-2/2D in this guide refers to the IPC-2 and IPC-2D image processing circuit.
IPC-3/3D in this guide refers to the IPC-3 and IPC-3D option board.
IPC-4D in this guide refers to the IPC-4D option board.
3
2. TWAIN
2.1 TWAIN
TWAIN is the specification that defines the standard software protocol and application
programming interface (API) for data exchange between a software application program and an
image input device such as the image scanner.
[TWAIN development background]
In the past, development of a new scanner inevitably required the development of a compatible
driver and a sample (demonstration) program exclusively designed for the new scanner. As the
scanner is upgraded, the driver may need to be upgraded as well to maintain its compatibility
with the upgraded scanner. Therefore, the use is most likely to be restricted to one specific
scanner model to avoid the complication of learning new operation methods and replacing the
peripheral driver, etc., involved in scanner replacement.
In view of the incompatibility among different scanners and peripheral equipment and the
accompanying inconvenience, there was a demand for standardization of the related hardware
and software, and TWAIN was established as a result.
The user may now choose among all the input devices and software (driver or application
programs) conforming to the TWAIN standard, and configure a most suitable system for
himself, without being restricted to the products of a certain series or a certain manufacturer.
4
2.2 TWAIN Application
TWAIN mainly applies to the following three software components:
Application software
Source manager
Source
The components are related to each other as shown below.
Application software
(photo retouching software, etc)
Source manager
(TWAIN.DLL/TWAIN_32.DLL, etc)
Source
(Image scanner control of the driver, etc)
Image scanner, etc.
Figure TWAIN Application
5
3. Installation
3.1 Preparation
1. Make sure that the operating system (OS) is installed correctly.
2. In case of the SCSI connection, confirm that the SCSI adapter is connected to your PC and
operating correctly.
In case of the USB connection, confirm that the USB port is installed in your PC.
3. Confirm that the hard disk that is the installation destination has enough free space.
4. If old version FUJITSU TWAIN 32 Driver has already been installed on your PC, uninstall
it before installation.
When uninstalling old versions, select [Control Panel] – [Add or Remove Programs] on the [Start]
menu and uninstall “Scanner utility for Microsoft Windows”.
5. Turn off your PC.
6. Connect the scanner to your PC.
Refer to “Operator’s Guide” of the scanner for scanner connection.
6
3.2 Installing the Scanner Driver
The Windows® XP screen samples are shown below. The screen and operations will differ
slightly depending on the OS that is being used.
1. Turn on the scanner.
2. Turn on your PC and Log on to Windows
When using Windows® 2000, Windows® XP or Windows ServerTM 2003, log on as an
administrator.
The scanner may be detected automatically, and the "Found New Hardware Wizard" (or
“Add New Hardware Wizard”) window is displayed.
In this case, click [Cancel] button to close this Wizard window.
®
.
(* Depending on the OS, the window displayed differ.)
In case of Windows® 98
In case of Windows® Me
7
In case of Windows® 2000
In case of Windows® XP, Windows ServerTM 2003
3.Insert the Setup CD-ROM into the CD-ROM drive.
<SETUP DISK START UP SCREEN> is displayed.
This Dialog is not displayed automatically when "Auto play" setting of your PC is off.
In this case, please run “Install.exe” in this CD-ROM directly using “Explore” or “My
computer”.
8
4. Click [INSTALL PRODUCTS].
(* Depending on the scanner model, the different screen may appear.)
5. Click [TWAIN Driver]
(* Depending on the scanner model, the different screen may appear.)
Depending on the scanner model, the screen which confirms whether “Error Recovery
Guide” is installed or not is displayed.
In this case, click [OK] button, and install Error Recovery Guide.
9
6. Select the language you use in [Choose Setup Language], then click [OK] button.
7. Click [Next >] button.
8. Read the information of README File, and then click [Next >] button.
10
9. Read the License Agreement carefully, and then click [Yes] button if you agree.
If you click [No] button, the installation is stopped.
10.Confirm Destination Folder, and then click [Next >] button.
Usually, it is not necessary to change Destination Folder.
11.Confirm Components you install, and then click [Next >] button.
Usually, it is not necessary to change the selection of Components.
11
12. Confirm Program Folder, and then click [Next >] button.
Usually, it is not necessary to change the Program Folder’s name.
13. Click [Next >] button, and copying files is started.
14. Select “Yes, I want to restart my computer now”, and then click [Finish] button.
15. After the restart, the scanner is detected.
Depending on the OS, the following operations may be required.
12
In case of Windows
®
98
There is a request to insert a disc. When this happens, insert the Windows
your CD-ROM drive.
In case of Windows
[Digital Signature not Found] is displayed, click [Yes] button.
®
2000
In case of Windows
1) [Found New Hardware Wizard] is displayed, click [Next >] button.
®
XP, Windows ServerTM 2003
®
98 CD-ROM in
2) If [Hardware Installation] is displayed, click [Continue Anyway] button.
3) Click [Finish] button when the installation is finished.
13
Now, the installation of scanner driver is completed.
14
3.3 Uninstall
The uninstall process removes the software and returns the hard disk to its pre-installation state.
When you want to remove this scanner driver program from your PC, uninstall by the following
procedures.
1. Turn on your PC and Log on to Windows
2. Close all of the applications on Windows®
3. Select [Control Panel] from [Start] menu.
The [Control Panel] is displayed.
4. Double-click [Add/Remove Programs] from the icon list of the [Control Panel].
The properties of [Add/Remove Programs] is displayed.
5. Select "Scanner Utility for Microsoft Windows" from the "Install/Uninstall" list.
6. Click [Add/Remove] button.
®
.
When using Windows® 2000, Windows® XP or Windows ServerTM 2003, log on as an
administrator.
7. When the confirmation dialog is displayed, click [OK] button if you are ready to uninstall.
8. When uninstallation is completed, click [Finish] button.
Image files that have been scanned and saved will not be deleted.
If other TWAIN-compliant applications and drivers have been installed and you are asked
whether or not to delete files shared with them such as the TWAIN Manager, select [NO] to
avoid deleting them.
The screen and operations may differ slightly depending on the OS that is being used.
<In case of Windows® XP>
- [Add/Remove Programs] [Add or Remove Programs]
- [Add/Remove] button [Change/Remove] button
15
4. Using the Driver
4.1 Selecting the Driver
To use this driver from the TWAIN application, select "FUJITSU <Product ID>" from the
TWAIN data source (driver) selection screen. For general application, the data source selection
screen is displayed by selecting the [Select Scanner] or [Acquire ...] menu. Refer to the
instruction manual for the application used for details.
4.2 Screen Configuration
Scanning Area settings
Preview window
Image scanner name
Setting file name
Message line
Button control
Image scan related data
Data size
Figure Main Dialog
16
4.2.1 Linkage to Image Processing Software Option
When the “Enable Software IPC” checkbox is marked after installation of “Image
Processing Software Option” (sold separately or included as a standard function)*, there
appears setting items of Image Processing Software Option in a part of the Setting Window
for TWAIN Driver.
(*: Depending on the scanner, the option is installed together with the scanner driver. See "Relevant
Image Scanner Specification" in the Appendix.)
Mark this checkbox.
Setting items of “Image Processing
Software Option” are displayed here.
You can change the settings of Image
Processing Software Option here.
• The ”Image Processing Software Option” version 2.1 or later is required for settings on the window of
TWAIN Driver.
• For details about the Image Processing Software Option, refer to the “Image Processing Software
Option User’s Guide”.
The following pages contain the explanation and operation description for each part.
17
4.3 Displaying Driver Information
♦ Image scanner name
The model name, option port name, and capacity of internal scanner memory (in units of
megabytes) of the connected image scanner are displayed.
If no image scanner is connected, this field is blank.
The type of IPC option board is displayed if an image-processing option board is installed
in the scanner.
IPC-3/3D may not be detected normally, as it is affected by the version number of the
machine type and device. In this case, "IPC2" is displayed.
♦ Preview window
Ruler
The preview window is used to display the temporary image of read data and for setting the
"Scanning Area."
For settings, see "Scanning Area" later in this manual. Also see the description of the
[Preview] button later in this manual.
♦ Ruler
The large divisions are labeled as "Unit". The scale also varies with the selected scanner.
♦ Message line
The message line is the bottom line of the dialog in which a brief explanation of an input
item or a setting item is displayed when the mouse cursor is moved over the item.
♦ Data size
The approximate amount of data per image when data is scanned in the present option.
Note.
This value is the amount of uncompressed data. The size of the stored file will differ from this
value and is usually smaller if image compression is chosen and the image is compressed.
18
4.4 Setting Information on Image Scanning
♦ Current side
When a scanner that allows duplex scanning is used, specifies the page which sets the
image scanning information.
To scan using the same settings as those for "Front side" and "Back side," clear the checks
in the "Individual Setting" checkbox on the "Front" and "Back" tabs. A single "Duplex" tab
will be displayed at the left so that the same image scanning information can be set for
"Front side" and "Back side."
To scan using different settings for "Front side" and "Back side," check the "Individual
Setting" checkbox on the "Front" and "Back" tabs. Two tabs, "Front" and "Back," will be
displayed at the left. Select each tab and enter the desired settings.
This is only effective when ADF (Duplex) is selected for the method of paper feed. For
scanner types which permit duplex scanning, see "Relevant Image Scanner Specification"
in the Appendix.
♦ Enable Multi Image
Multi image can scan the document once and output both a Color/Grayscale and a Binary B/W image.
Not all the scanners support Multi image. For details, please refer to “Specification” in the Appendix.
*This function can be used if “Ram cache” or “Use Both Memory” is selected.
If an item other than “Ram cache” or “Use Both Memory” has been selected in the
“Cache Mode:” and this check box is marked, it will change to “Ram cache”.
If this checkbox is checked, the following screen appears.
When “Multi Image Output” is selected When “Auto color Detection” is selected
19
- Output mode
Multi Image Output
One scan outputs both a Color/Grayscale and a Binary B/W image.
Auto color Detection
Outputs either a Color/Grayscale or a Binary B/W image depending on whether the
document is color or black and white.
- Order (for Multi Image Output)
Specify the output order of images when scanning in Multi Image Output mode
.
Primary: Color/Grayscale Secondary: Binary
Output images in the order of “Color/Grayscale image” “Binary B/W image”.
Primary: Binary Secondary: Color/Grayscale
Output images in the order of “Binary B/W image” “Color/Grayscale image”.
- Select Current Side
When “Multi Image Output” is selected When “Auto color Detection” is selected
Select a side and then set the scanning options for it on the main dialog box accordingly.
When scanning in Multi Image Output mode
, set the scanning options for primary and
secondary as specified in the “Order” section.
When scanning in Auto color Detection mode
, pre-set the scanning options for
color/grayscale or black and white if detected.
You can use different "Rotation" settings for Multi Image Output and Auto Color
Detection ("Multi Image" setting).
20
When you use the "Multi Image" function (Multi Image Output and Auto Color
Detection) together with the "Filter" function (Page Edge Filter and Digital Endser), the
"Filter" setting is common to both Multi Image Output and Auto Color Detection. You
cannot configure different "Filter" settings for each.
♦ Resolution
Specifies the number of pixels (dots) per inch.
Select a predefined resolution or [Custom] from the list.
[Customize] enables detailed settings by a pixel unit.
By marking [Predefine] checkbox, you can select one from three predefined settings as
[Normal], [Better], [Best] to scan documents instead of configuring settings by yourself.
Otherwise, you can change the details of the predefined settings on the [Resolution Setting]
window, which appears when you click on the […] button.
Resolutions for Image modes (“Color”, “Grayscale”, and “Black &White”) of the each
predefined settings are changed corresponding to the selection of the Image Type.
* Click [Default] button to return the resolutions to the default value.
High resolution produces finer images, meanwhile requires more memory that leads to
longer scanning time.
The supported resolution depends on the type of scanner and the options installed.
Refer to "Relevant Image Scanner Specification" in the Appendix.
21
♦ Paper Size
Specifies a document size for scanning.
Select a standard size or [Custom] size (can be registered up to three) from the list.
Window for customizing the paper size will appear when you click on […] button besides
the list. On this window, you can change the order of the paper size in the list.
[Custom] button : Used for configuration of a custom size.
[Up] button : Used for shifting the order of the selected document size upward.
[Down] button : Used for shifting the order of the selected document size downward.
You can register up to three sizes as the customized document sizes.
[Custom Paper Size Setting] window will appear when you click the [Custom] button.
Enter the size of the document to be scanned. (When entering the size, specify the paper
size by width x length to the scanning direction.)
Some paper sizes may not be accepted by your device. Refer to "Relevant Image Scanner
Specification" in Appendix.
Name :
Width, Length
Enter the name of the customized setting to be displayed in the list.
: To specify a custom paper size, use the scroll bar or enter the paper
size directly. The unit specified in [Option]-[Generic]-[Unit/Scaling]
will be applied to the unit in this window.
♦ Scanning Area
22
Specifies the start position, width and length for the image scan. The maximum allowable
size is the paper size selected previously.
In addition, the minimum size is 1.000 inch, 26 millimeters, or pixels (number of dots per
inch) according to the unit that has been set.
"Left": The left end of the scan area on the scanned document (X coordinate)
"Top": The top end of the scan area or the scanned document (Y coordinate)
"Width": The width of the scan area
"Length": The length of the scan area
These values are related to one another in the following way:
0 ≤ left end coordinate < (paper width - minimum scan area size)
0 ≤ top end coordinate < (paper length - minimum scan area size)
Minimum value ≤ width ≤ (paper width - left end coordinate)
Minimum value ≤ length ≤ (paper length - top end coordinate)
♦ Scan Type
Selects the feeding device.
The image scanner uses a document bed called the flat bed as well as an automatic
document feeder (ADF) for feeding scanned document. The ADF usually enables the
documents to be scanned only once. The flat bed allows scanning the same documents
repeatedly.
Flat bed
Scans a document placed on the flat bed of the device.
ADF (Front Side)
Scans the documents on the device's automatic document feeder (ADF). Here, only the
front sides are scanned.
ADF (Duplex)
To scan both the front and the back of a page, select this option.
If this option is selected, the documents are scanned in the "front to back to front to
back ..." order.
This option can be used only for scanner models that support duplex scanning.
The "Duplex Function" requires that the calling application supports "continuous scan."
If the application does not support "continuous scan," only the data for the front side of
the page is passed to the application.
Some scanner models do not support this option. See "Relevant Image Scanner
Specification" in the Appendix.
23
Loading...
+ 157 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
