Fujitsu P27T-7 Operating Manual

Display

Operating Manual

P27T-7 LED

Congratulations on your pu

rchase of an innovative

product from Fujitsu.

Latest information about our products, tips, updates etc. can be found on
the Internet at: "

http://fujitsu.com/fts/"

For automatic driver updates, go to: "http://support.ts .fujitsu.com/download"

Should you have any technical questions, please contact:

• our Hotline/Service Desk (see the Service Desk list or visit:

"

http://support.ts.fujitsu.com/contact/servicedesk")

• Your sales partner

• Your sales office

We hope you enjoy working with your new Fujitsu system!

Published by

Fujitsu Tec

hnology Solutions GmbH
Mies-van-der-Rohe-Straße 8 (Mies-van-der-Rohe Street No. 8)
80807 Munich, Germany

Contact

h

ttp://fujitsu.com/fts/

Copyrigh

t

© Fujitsu Technology Solutions GmbH 2012. All rights reserved.

Publication Date

10/2012

Order No.: A26361-K1442-Z320-1-7619, edition 1

P27T-7 LED

Operating Manual

Your LCD screen... 5
Important notes 7
Getting started 11
Operation 18
Notes on ergonomic colour adjustment 27
Troubleshooting 28
Explanatory information about

standard ISO 9241-307 30
Technical specification 31

Remarks

Notes on the product description meet the design requirements of Fujitsu and are
provided for the purposes of comparison. The actual results may differ due to several
factors. Subject to technical changes without prior notification. Fujitsu accepts no
responsibility for technical or editorial mistakes or o m issions.

Trademarks

Fujitsu and the F ujitsu logo are registered trademarks of Fujitsu Limited or its
subsidiaries in the United States and other countries

Microsoft and Windows are trademarks or registered trademarks of the Microsoft
Corporation in the United States and/or other countries.

VESA, DDC and DPMS are registered trademarks of Video Electronics Standards Association.

All other trademarks specified here are the property of their respective owne rs.

Copyright

No part of this publication may be copied, reproduced or translated without
the prior written consent of Fujitsu.

No part of this publication may be saved or transmitted by any electronic means
without the written consent of Fujitsu.

Contents

Contents

YourLCD screen... ..................................................................... 5

Target group ............................................................................ 5

Furtherinformation ...................................................................... 6

Notational conventions .................................................................. 6

Importantnotes ........................................................................ 7

Safetyinstructions ...................................................................... 7

Powercable ............................................................................ 8

Transporting the devic

e ..................................................................

8

Cleaning the device ..................................................................... 9

CEmarking ............................................................................ 9

Power management . . . .................................................................. 9

Disposal and recycli

ng ..................................................................

10

Gettingstarted ......................................................................... 11

Unpacking and checking the delivery . . ................................................... 11

Setting up thedevice .................................................................... 12

Setting up an ergonomic video workstation ............................................ 12

Adjustingheight ..................................................................... 14

Adjustingthe inclination .............................................................. 14

Removing monitorbase .............................................................. 15

Connecting the device . .............................................................. 16

Connecting cables to the computer ................................................... 17

Operation .............................................................................. 18

Switching the

deviceon andoff ..........................................................

18

Notes on powe

rmanagement ............................................................

19

Changing the

monitorsettings ............................................................

20

Changing the

monitor settings with the touch sensors of the control panel . . ..............

20

Changing th

emonitor settingsusing the OSD menu ....................................

22

Noteson ergonomiccolour adjustment ................................................ 27

Troubles

hooting .......................................................................

28

Explanatory information about standard ISO 9241-307 . . .. . ............................. 30

Technic

al specification .................................................................

31

VESA-DD

C-compatible VGAinterface ....................................................

32
Preset o

perating modes . . . . . . ...........................................................

32

Most fr

equent operating modes .......................................................

32

Video/

TV operating modes using DP and HDMI ........................................

33
SUB D p

ort .............................................................................

33
DVI-D

port ..............................................................................

34
Displ

ayPortsocket ......................................................................

35
HDMI

port ..............................................................................

36

Fujitsu 3

Contents

4 Fujitsu

Your LCD screen...

Your LCD screen...

has a whole range of useful features and functions, e.g.:

• TFT display (Thin Film Transistor; active matrix)

• minimal space requirement

s thanks to slim casing

• optimum ergonomic characteristics (totally distortion-free, exce llent picture

definition and colour purity right into the corners)

• high degree of brightne

ss and good contrast

• High resolution via VGA (1920 x 1200) and HDMI (1920 x 1080)

• Maximum resolution (2

560 x 1440) via DVI and Display Port

• presentation of up to 16.7 million colours (in conjunction with an appropriate display a dapter)

• automatic scanning o

f horizontal frequen cies from 30 to 82 kHz and refresh rates

(vertical frequenci

es) from 56 to 76 Hz (absolutely flicker-free)

• digital screen controller with microprocessor for storing 36 different display modes

• freely adjustable

colour alignment for matching the screen colours to the

colours of variou

s input and output devices

• convenient operation via integrated OSD (On-Screen-disp lay) menu

• VESA-DDC compat

ibility

• VESA-FPMPMI compatibility (Flat Panel Monitor Physical Mounting Interface) –

Mounting device for swivel arm or similar accessory

• Plug&Play cap

ability

• Digital video inputs (DVI, HDMI and Display Port DP) with HDCP

• power manage

ment for reducing power consumption when the computer is not in use

• Compliance with the recommendations according to TCO ’03

• the monitor

fulfills all GS ("Geprüfte Sicherheit", Certified Security) requirements.

This operating manual contains important information you require to start up and run your LCD monitor.

A graphics card (display adapter) with VGA interface or a digital display adapter with DVI interface
or video signal source with D P interface is required to control the LCD monitor. The monitor
processes the data supplied to it by the display adapter. The display adapter or the associated
driver software is responsible for setting the modes (resolution and refresh rate).

When putting the monitor into operation for the first time, the screen display should be
optimally adapted to the display adapter used and adjusted in accordance w ith your
needs (see chapter "

Changing the monitor settings", P age 20.

Target group

You d o

n’t need to be an "expert" to perform the operat ions de scribed here.

None

theless, it is important to always observe the safety notes given in the operating

inst

ructions for the computer and in this manual.

In th

e event of any problems, please contact your sales office or our Service Desk.

Fujitsu 5

Your LCD screen...

Further information

Details of how you set the resolution and refresh rate are provided in the do cumentation
for your display adapter and the associated driver software.

For ergo nomic reasons, use of the Dual-Link DVI or DP data cable and a screen
resolution of 2560 x 1440 pixels are recommended.

Because of the technology used (active matrix) an LCD monitor provides a totally
flicker-free picture even with a refresh rate of 60 Hz.

Notational conventions

Pay particular attention to text marked with this symbol. Failure to observe
these warnings could p ose a risk to health, damage the device or lead
to loss of data. The warranty will be invalidated if the device becomes
defective through failure to observe these warnings.

Indicates important information for the proper use of the device.

►

Indicates an activity that must be performed



Indicates a result

This font

indicates data entered using the keyboard in a program dialogue or at
the command line, e.g. your password (Name123) or a command used to
start a program (start.exe)

This font

indicates information tha t is displayed on the screen by a program, e.g.:

Installation is complete.

This fon t

indicates

• terms and texts used in a so ftware interface, e.g.: Click on Save

• names of programs or files, e.g. Windows or setup.exe.

"This fon

t"

indicates

• cross-references to another section, e.g. "Safety information"

• cross-references to an external source , e.g. a web address: For more
information, go to "

http://fujitsu.com/fts/"

• Names of CDs, DVDs and titles or designations of other materials, e.g.:
"CD/DVD Drivers & Utilities" or "Safety" Manual

Key

indicates a button on the monitor, e.g:

MENU

This

font

indicates terms and texts that are emphasised or highlighted, e.g.: Do
not s witch off the device

6 Fujitsu

Important notes

Important notes

ImportantnotesNotes

In this chapter you will find information regarding safety which it is essential to
take note of when working with y our device.

Safety instructions

This device complies wit

h the relevant safety regulations for data processing equipment,

including electronic of

fice machines for use in an office environment. If you have

any questions about whe

ther the device can be used in the intended environment,

please contact y our sal

es office or our Service Desk.

• The display surface of

the device is sensitive to pressure and scratches. You should therefore

be careful with the dis

play surface in order to avoid lasting damage (scratches).

• If the device is brought into the installation site from a cold environment, condensation
can form. Before operating the device, w ait until it is absolutely dry and has reached
approximately the same temperature as the installation site.

• When installing an

d operating the device, please observe the notes on environmental

conditions in chap

ter "

Techni cal specificatio n", Page 31 as w ell as the instructions in

chapter "

Setting

up an ergonomic video works tation", Page 12.

• To ensure sufficient ventilation, the air inlet and outlet openings of the device m u st be kept clear.

• The device autom

atically sets itself to the correct voltage within th e range from 100 V to 240 V.

Make sure that t

he local mains voltage is neither higher nor lower than this range.

• Ensure that the power socket on the device and the mains outlet are freely accessible.

• The ON/OFF swi

tch does not disconnect the monitor from the mains voltage. To discon nect

fully from the

mains supply, disconnect the power plug from the socket.

• The de vice is equipped with a power cable that complies with safety standards.

• Use the suppl

ied power cable only.

• Lay the cables in such a way that they do not create a hazard (danger of tripping)
and cannot be damaged. When connecting the device, observe the relevant
notes in chapter "

Connecting the device", Page 16.

• No data tra

nsfer cables should be connected or disconne cted during a thunderstorm.

• Make sure that no objects (e.g. jewellery chains, paper clips, etc.) or liquids get
inside the device ( danger of electric shock, short circuit).

• The devic

e is not waterproof! Never immerse the device in water and protect

it from s

pray water (rain, sea water).

• In an emergency (e.g. damaged casing, operation controls or cables, penetration
of liquids or foreign m att er), switch off the device, disconnect the power plug
and contact your sales outlet or our Service Desk.

• Repai

rs to the device must only b e performed by qua lified technicians. Unauthorised opening

and in

correct repair may greatly endanger the user (electric shock, fire risk).

• Only use the screen resolution settings and refresh rates specified in chapter

"

Technic al specification", Page 31. Otherwise you may damage the device. If you

are in any doubt, contact your sales outlet or our Help Desk.

•Usea

screen saver with moving images and activate the power management for

you

r m onitor to prevent still images from "burning in".

Fujitsu 7

Important notes

• If you operate the device with the swivel arm or a similar accessory, it
must not be turned through 180°.

• The device must only be operated in landscape mode (0°) and portrait mode (90°). The touch
sensors of the control panel are located in the middle of bottom of the monitor in landscape
mode (0°) and at the left-hand side of the monitor in portrait mode (90°).

• Store this manual close to the device. If you pass the device on to third
parties, you should pass this manual on with it.

• We recommend that you place your device on a durable, non-slip surface. In view
of the many different finishes and varn ishes used on furniture, it is possible that the
feet of the device may mark the surface they stand on.

• To ensure sufficient ventilation, the air supply and air outlet openings of
the monitor must never be blocked.

Power cable

Use the supplied power cable only.

Use the following guidelines if it is necessary to replace the original cable set.

• The female/male receptacles of the cord set must meet I EC 60320/CEE-22 requirements.

• The cable has to be HAR-certified or VDE-ce rti fied . The ma rk HAR or
VDE will appear on the outer sheath.

• For devices which are mounted on a desk or table, type SVT or SJT cable sets may be
used. For devices which sit on the floor, only SJT type cable sets may be used.

• The cable set must be selected according to the rated current for your device.

• If necessary, replace the original power cable with a regular ground ed 3-core mains lead.

Transporting the device

Device,Transport a

tion

Retranspor

tation

Transport all parts separately in their o riginal packaging or in a packaging w h ich
protects them from knocks and jolts, to the new site.

Do not unpack them until all transportation manoeuvres are completed.

If the device is brought from a cold environment into the room where it will be used,
condensation may occur. Before operating the device, wait until it is absolutely dry
and has reached approximately the same temperature as the insta llation site.

8 Fujitsu

Important notes

Cleaning the device

Switch off the device and unplug the power plug.

Do not clean any interior parts yourself, leave this job to a service technician.

Do not use any cleaning agents that contain abrasives or may corrode plastic.

Ensure that no liquid enters the device.

The display surface of th

e device is sensitive to pressure and scratches. Clean

it only using a soft, sli

ghtly moistened cloth.

The surface of the casin

g can be cleaned with a dry cloth. If particularly dirty, use a cloth that

has been moistened in m

ild domestic detergent and then carefully wrung out.

CE marking

The shipped version of this device complies with the re quirements of European Union
directives 2004/108/EC "Electromagnetic c ompat ibility", 2006/95/EC "Low voltage directive" and
2009/125/EC "Ecodesign Directive".

Power management

The Fujitsu LCD monitor is equipped with a power manage ment system which reduces the
power draw in 0 W energy saving mode to less than 0 W (for VGA and DVI).

Fujitsu 9

Important notes

Disposal and recycling

This device has been manufactured as far as possible from materials which can be recycled or
disposed of in such a way that the environment is not damaged. The device may be taken back after
use to be reused or recycled, provided that it is returned in a condition that be fits its intended use.
Any components not reclaimed will be dispose d of in an environmentally acceptable manner.

The device must be disposed of in accordance with the local regulations for disposal of special waste.

If you have any questions on disposal, please contact your local sales office or our
Service Desk, or contact one of the following directly:

Germany

Belgium

Switzerland

Fujitsu Technology Solu

tions

GmbH

Remarketing and Recycl

ing

D-33106 Paderborn

Tel.: +49 5251 / 81 80 1

0

Fax: +49 5251 / 81 80 1

5

"

http://fujitsu.c

om/fts/remarketing"

RECUPEL

Boulevard Reyers, 80

B-1030 Brussels

Tel.: +32 2 / 706 86 16

Fax: +32 2 / 706 86 13

E-Mail: info@recup

el.be

"

http://www.recu

pel.be"

SWICO

Schweizerischer
Wirtschaftsverband
der Informations-,
Kommunikations- und
Organisationstechn

ik

AlistoftheSWICOac

ceptance

locations can be fou

nd at:

"

http://www.swic

o.ch"

Asia

USA

Taiwan:

Environmental Protection
Administration
Executive Yuan R.O.C.

"

http://recycle.epa.gov.tw"

Fujitsu America, Inc.

1250E. Arques Avenue

Sunnyvale, CA 94085 U.S.A.

Phone No.: [phone]

More information on this subject can be found on the Internet at "http://fujitsu.com/fts/recycling".

10 Fujitsu

Getting started

Getting started

Unpacking and checking the delivery

The display surface of the device is s ensitive to pressure and scratches.
Always hold the device by the casing!

The complete de vice package includes:

• one monitor

• one data cable (DP)

• one data cable (DVI Dual Link)

• one USB cable

• one audio cable

• one power cable

• one CD with software and documentation

• one Warranty Booklet

• one "Quick Start Guide" brochure

• one "Safety" manual

► Unpack all the individual parts.
► Check the conten ts of the package for any visible dama g e caused during transport.
► Check whether the delivery conforms to the details in the delivery note.
► Should you discover that the delivery does not correspond to the delivery

note, notify your local sales outlet immediately.

Do not discard the original packing material of the devices. You may need the
packaging in the future if you need to transport your device.

Fujitsu 11

Getting started

Setting up the device

To ensure sufficient ventilation, the air inlet and outlet openings of
the device must be kept clear.

Setting up an ergonomic video workstation

1

► Do not position the video w orkstation

opposite a w indow (1).

1

► Position the monitor outside the reach

of a light source (1).

12 Fujitsu

Getting started

1

► Position the keyboard where it is

easiest to reach (1).

1

50 cm

► Position the monitor so that the eye distance

to the s creen (1) is around 50 cm.

► Position the monitor for optimum viewing

(1). The monitor should under no
circumstances fall outside the permissible
viewing space (2).

Depending o n the situation, it may be advisable to use a swivel arm or
a similar accessory (VESA FPMPMI), which are available from specialist
dealers. For this purpose the monitor base must be removed beforehand as
described in chapter "

Removing monitor base", Page 15.

Fujitsu 13

Getting started

Adjusting height

The height adjustment is fixed in the transport position.

1

2

► To free the fixing, remove the locking

pin on the flange (1).



The height of the monitor can be adjusted
by approximately 130 mm.

► Grasp the monitor with both h ands on

the right and left edge of the casing
and move it up or down (2).

Adjusting the i

nclination

The inclination of the monitor can be adjusted by -3° (forward ) and +35°
(backwards) from its vertical position.

► Hold the monitor with both hands on the left and right sides o f the casing

and move it to the desired angle.

14 Fujitsu

Getting started

Removing monitor base

Before you can use a swivel arm or a similar acce ssory, you must remove the monitor base.

The display surface is susceptible to scratching!

1

2

3

► Switch off the monitor and pull the power

plug out of the power socket.

► Lay the monitor on its face on a soft surface.
► Remove the cover and disconnect all cables.
► Release the base stand by pressing the

slider down (1). Move it in the direction of the
arrow (2) and lift the base stand upwards (3).



You can now mount a swivel arm or a
similar accessory in accordance with VESA
FPMPMI using a hole spacing of 100 mm.

For instructi

ons on how to mount the swivel arm or a similar accessory, please

see the docume

ntation for the swivel arm or similar accessory.

Fujitsu 15

Getting started

Connecting the device

Please observe the safety information in "Important note s", Page 7.

CE conformance and optimum picture quality are guaranteed only if
you use the data cables supplied.

► Switch off the monitor and the computer.
► Disconnect the power plug

from the computer.

Connecting cables to the m onitor

The supplied data cable

s have two 15-pin D-SUB connectors or two 24-pin DVI connectors

or two 20-pin DP connect

ors for connection to the monitor and to the computer.

Information on the com

puter connections and interfaces is contained in the

operating manual for

the computer.

2

1

3 4 5 6 7 8 9

10

10

1=Securi

ty slot for "Kensington Lock"
2 = Power connector
3=0Wswi

tch
4 = DP socket
5=HDMIs

ocket

6=DVI-Ds

ocket (DVI)
7 = D-SUB socket (VGA)
8 = AUDIO

-IN socket
9 = USB 3.0 (Upstream)
10 = USB 3.

0 (Downstream)

► Select the appropriate data cable for your compu ter.
► Connect one of the connectors of t he data cable to the DVI-D socket or the DP s ocket of

the monitor and secure the DVI-D connection by tightening the safety screws.

16 Fujitsu

Getting started

IfyouareusingaDPdatacable,youmustsetthe0WswitchtoBASICposition.Ifyou
are using a VGA, HDMI or DVI dual link data cable, you can switch the 0 W switch to the
"0" ECO position in order to activate the 0 W energy saving mode if the PC is switched off.

The monitor automatically detects the input (VGA, HDMI, DVI, DP)
when only one signal source is connected.

Note that the 0 W function can

not be guaranteed when using any

kind of signal cable adapt

or.

► Insert one connector of the audio line in the AUDIO IN (8) socket on the

monitor and make sure it is properly engaged.

► Plug the power cable s upplied into the power connector o f the monitor.
► Plug the supplied U SB 3.0 cable into the USB 3.0 socket (Upstream) (9) and the

other end of the cable into a USB 3.0 socket of the computer.

Connect the USB keyb oard and USB mouse directly to the PC, as the USB connector
socket of the monitor is switched off in energy-saving mode.

A lock (Kensington Lock) can be mounted in the security slot to protect the monitor
against theft. A Kensington lock is not supplied with the mon itor.

Connecting cables to the computer

Information on the computer connections and interfaces is contained in the
operating manual for your computer.

► Connect the data cable to the (active) monitor port on the compu ter and secure

the plug-in connection by tightening the safety screws.

► Insert the other plug of the audio cable in the audio output of the computer.
► Plug the power connector of the monitor into a properly grounded mains outlet.
► Plug the power connector of the computer into a properly ground ed mains outlet.

If your computer has two monitor ports ("onboard" screen controller and separate
graphics card), the monitor port for the separate graphics card is active as standard.

Fujitsu 17

Operation

Operation

Switching the device on and off

1 2 3

1

2 3

1 = On/Off touch sensor
2 = Power indic

ator

3 = 0 W switch (on the rear of the monitor)

The colour of the LED indicator changes as follows:

LED indicator Status

blue

Monitor and computer are switched on (norm al mode).

green

Monitor and computer are switched on (ECO mode).

orange

Monitor is not receiving a video signal or is in BASIC power saving
mode.

does not light up

Monitor is s witched off (or is in
0 W energy-saving mode).

The switch position "0" of the 0 W switch (3) on the rear activates ECO
energy saving mode (0 W operating mode), and switch position " I" switches
to BASIC energy saving mode <1 W. This position is required only for the
DP data cable, but can also be necessary for VGA or DVI on some PCs if
the monitor remains dark in 0 W operating mode.

► Switch the device on with the On/Off touch sensor (1).

18 Fujitsu

Operation

Notes on power management

If your computer is equipped with power manageme nt (power saving mode), the monitor can
fully s uppo rt this function. The monitor thereby distinguishes between the individual power
saving modes of the computer (standby mode, suspend mode and OFF mode).

Stage Operation Power-saving mode (0 W switch)

Normal

ECO ECO (0) BASIC (|)

Power supply
indicator

Lights up blue Lit green is unlit illuminated orange

Display Max. brightness

typ.
200 cd/m

2

unlit

orange

Typical power
consumption
(without USB and
audio)

50 W 33 W reduced to 0 W

(only for VGA, DVI
and HDMI)

reducedto<1W(for
all input sources)

If the computer detects inactivity (no input) it sends an appropriate signal to the monitor
to reduce the power consumption (power saving mode). The power indicator of the
monitor changes colour to show the change in status. The ECO operating mode and
BASIC power-saving mode are the preset factory defaults.

Once an input is made at the computer the screen contents are restored.

For detailed information on how energy-saving mode operates, please r efer to
the operating manual or technical manual of the computer.

Fujitsu 19

Operation

Changing the monitor settings

When putting the monitor into operation for the first time, the screen display should
be optimally adapted to the display adapter used.

Changing the monitor setti

ngs with the touch

sensors of th e control panel

The touch elements of the control panel have two functions. When the OSD
menu is active, the current meaning of the touch element is shown directly
over the touch elements on the edge of the screen. With the O SD menu not
activated, you can make the following settings directly:

123

1 = Touch sensors for the OSD menu

(On-Screen-display)

2 = ON/OFF switch

3 = Power supply indicator

Select OSD language

If one of the touch sensors is being touched for the first time for the OSD menu,
the selection screen fo r the language is displayed:

► Touch the

ECO

/ or the

INPUT

/ sensor to select the required language.

► Touch the

MENU

/ sensor to confirm your entries or the

AUTO

/ sensor to cancel the process.

After selecting the OSD language for the first time, you can change
it at any time in the OSD.

Performing auto-adjustment of the monitor

► Touch the

AUTO

/ sensor for about 1 second.



The Auto Processing message appears.

Picture quality and position are set to optimum values for your system.

20 Fujitsu

Operation

Selecting input signal (D-SUB/DVI-D/HDMI/DP)

► Touch the

INPUT

/ sensor to call up the Input select settings window.

► Touch the

ECO

/ or the

INPUT

/ sensor to select the desired

monitor connection (VGA, DVI, HDMI or DP).

► Touch the

MENU

/ sensor to co n firm your entries or the

AUTO

/ sensor to cancel the process.

This setting window can also be called up when the OSD menu is locked.

Locking the OSD menu

The OSD menu can be locked to prevent accident al or unauthorised changes to the monitor settings.

► Touch the

MENU

/ sensor for a few seconds while you switch on the

monitor using the ON/OFF switch.



The message OSD locked / unlocked is displayed.

Please proceed in the same manner to release the locked OSD menu again.

Activate/deactivate ECO operating mode

The power consumption of the device can be decreased by reducing
the brightness of the picture.

► Touch the

ECO

/

sensor to switch the ECO operating mode on or off.



The message ECO Mode on or ECO Mode off appears.

If the ECO

operating mode is activated, the following OSD settings are changed:

Mode

Office

Colour

6,500 K

Brightness

reduced

After the ECO operating mode is switched off, the b rightness previously set by the user is restored.

Fujitsu 21

Operation

Locking the ON/OFF button

The ON/OFF switch can be locked to prevent accidental o r unauthorised
changes to the monitor settings.

► Touch the

ECO

/ and

INPUT

/ sensors at the same time for a few seconds.



The m essage Power button loc

ked / unlocked is displayed.

Proceed in the same way to r

elease the locked ON/OFF switch again.

Changing the monitor se

ttings using the OSD menu

With the buttons on the control panel, you can call up and use the integrated
OSD (On-Screen display) menu.

The English menu names are used in the following description (default setting).

► Touch the

MENU

/ sensor to activate the OSD menu.



The main menu appears, with icons for the setting functions.

The first symbol, (Brightness/Contrast), is highlighted and the associated functions

are visible in the right-hand menu field.

22 Fujitsu

Operation

► Touch the

ECO

/ sensor or the

INPUT

/ sensor to highlight

another icon (e. g. Image adjust ).

► Touch the

MENU

/ sensor to select the highlighted icon.



The Image adjust settings window is displayed.

► To u ch t h e

AUTO

/ sensor to exit the main menu.

► Touch the

ECO

/ sensor or the

INPUT

/ sensor to highlight another function.

► Touch the

MODE

/ sensor or the

/ sensor to

change the setting.

► Touch the

ECO

/ sensor or the

INPUT

/ sensor to highlight another function.

► Touch the

MENU

/ sensor to save the change or touch the

AUTO

/

sensor to exit the function without making any changes.

If you want to change other settings, select the corresponding function from the OSD
main menu. All possible adjustments of the main menu are described in the following.

Fujitsu 23

Operation

OSD menu functions

The OSD menu for analogue monitor operation is described below. During
digital operation some functions are not available, as they are not required
due to the digital transmission technology used.

Adjusting the brightness and contrast

Call up the Brightness/Con

trast setting window

Brightness

Set the brightness of the display

With this function you change the brightness of the background lighting.

Contrast

Set the contrast of the di

splay

With this function you m

odify the contrast of bright colour tones.

Black level

Set the brightness of the display

With this function you modify the contrast o f dark colour tones.

Auto Brightness

Automatic brightness control

This function is used to automatically control the brightness of the
background lighting using the light sensor.

On = The brightness is adjusted according to the ambient brightness
Off = The brightness is adjusted manually by the user

Auto level

Adjust the signal level

With this function you can automatically set the contrast.

Thefunctionisexecutedwiththe

touch sensor.

If the contrast is set too high, bright surfaces can no longer be distinguished from very
bright surfaces. If the contrast is set too low, the maximum brightness will not be achieved.

Selectin

g the application mode

Call up the Mode setting window

D mode

Setting for DICO M simulation (the values for colour and ACR are locked:
Colour = 7500K, ACR = off)

Office

Office prese ts (the settings for colour and sharpness can be adjusted)


Photo presets (colour, sharpness, saturation, ACR)

Video

Video presets (colour, sharpness, satura tion, ACR)

ACR = Dynamic contrast (on / off)

24 Fujitsu

Operation

Adjusting the picture size and position

Call the Image adjust setting w indo w

Phase

Eliminate picture disturbance

With this function you fine-tune your monitor to eliminate pictu re disturbance.

Clock

Set synchronisation

With this function you adjust the picture width to eliminate vertical picture
disturbances.

H-Position

Adjust the horizontal position

With this function you move the picture to the left or to the right.

V-Position

Adjust the vertical position

With this function you move the picture up or down.

Sharpness

Adjust the sharpness of the picture for the Photo and Video modes.

Saturation

Adjust the saturation for the Photo and Video modes.

Expansion

Adjust the picture size

Full screen = selection of full screen mode
Keep aspect = maximum picture size without distortion (only for PC image)

Adjusting the volume

Call the Audio setting window

Volume

Set the volume for playback with the integrated loudspeakers

Mute

Switch the loudspeakers off or on

Setting colour temperature and colours

Call the Colour setting window

Select the colour temperature

The "warmth" of the screen colours is set using the colour temperature. The
colour temperature is measure d in Kelvin (K). You can choose between

sRGB, 6500 K, 7500 K, 9300 K, Native and Custom Colour.
The options sRGB, Native and Custom colour are only available in the Office

setting mode.

In the user-defined setting you c an change the colour ratios of the basic
colours (red, green, blue) as required.

The 6500K and sRGB settings are recommended for general Windows

applications.

The full c olour space of the LCD panel can be used in the Native and Custom
Colour s ettings .

Fujitsu 25

Operation

Setting functions

Call up the Setup settings window

Input select

Select the input signal

This function is used to select the input signal (VGA, DVI, DP or HDMI).

This is on condition that the display adapter supports this funct ion.

Language

Set the language for the OSD menu

With this function you select the language for the OSD menu.

The default setting is English.

DDC-CI

Activates/deactivates the DDC-CI function

On = The DDC-CI function is activated (default set ting)
Off = The DDC-CI function is deactivated

OSDTimeout

Set the display duration of the OSD menu

With this function you select a value from 10 to 120 seconds.

If the set time expires without a setting being made, the OSD menu is
automatically faded out.

Factory recall

Activate the factory settings

With this function all setting s are reset to the factory settings without
prompting for confirmation.

The function is executed with the

touch sensor. If you are using a VGA

data cable, an Auto Processing message is displayed. The language selection

menu appears.

Displaying information

Call the Information setting window

This function displays the model designation, serial number, resolution, H/V
frequency and ECO mode.

26 Fujitsu

Notes on ergonomic colour adjust men

t

Notes on ergonomic colour adju

stment

If you select colours for the monitor in your a pplication programmes,
take note of the information below.

The primary colours blue and red on a dark background do not produce the minimum
required contrast of 3:1 and are therefore not suitable for continuous text and data entry.

When using several colours for characters and background and giving the primary colours full
modulation, you can obtain very suitable colour combinations (see the following table):

Characters

Background

black white purple blue

cyan green

yellow red

black

++

-

+++

-

white

+++

---

+

purple

++

-----

blue

-

+

-

+

-

+

-

cyan

+

--

+

---

green

+

--

+

---

yellow

+

-

++

--

+

red

-

+

----

+

+ Colour combination very suitable

- Colour combination not suitable because colour hues are too close together, thin characters
are not identifiable or rigorous fo cusing is demanded of the human eye.

Fujitsu 27

Troubleshooting

Troubleshooting

Should an error occur, first check the following points. If the distortion is still not eliminated,
the monitor should, if possible, be checked on another computer.

If you canno t solve the problem, please co ntact our Service Desk.

Having this problem? Check the following points:

No screen display

Power indicator does not light u p

► Check whether changing the 0 W switch

on the rear to setting " I " eliminates the
problem.

► Check whether the power

cable on the

monitor is connected co

rrectly.

► Check whether the computer is switched on.

No screen display

LEDs not lit

► Check if you are using a DP data c able and

if the 0 W switch is set to "l".

No screen display

Power indicator is lit

► Check whether the computer is switched on.
► Check whether the data cable for the

monitor is correctly attached to the monitor
port on the computer.

► Press any key on the computer keyboard.

The computer may be in power saving
mode.

► Alter the brightness and/or contrast until you

get a picture.

Message: No Signal

► Check whether the data cable for the

monitor is correctly attached to the monitor
port on the computer.

► Check whether the computer is switched on.

Message:

Frequency out of range:
##kHz/##Hz
Please change the display mode
to 2560 x 1440 with 60 Hz

The input signal (horizontal frequency and
refresh rate) at the displayed input does not
correspond to the technical data for the monitor.

► Adjust th e video frequency ran ge using the

computer software (see documentation for
the computer or display adapter).

► Set a di

fferent screen resolution using the

comput

er software (see documentation for

the com

puter or display a dapter).

Pictu

re position not correct

The monitor recognises an undefined mode (see
chapter "

Techni cal specification", Page 31).

► Touch the

AUTO

sensor to perform

auto-adjustment of the screen.

Picture is shaking

► Check whether the data cable for the

monitor is correctly attached to the monitor
port on the computer.

► Touch the

AUTO

sensor to perform

auto-adjustment of the screen.

28 Fujitsu

Troubleshooting

Having this problem? Check the following points:

Picture is wrongly adjusted

► Run the F actory Recall function

in the OSD

menu.

The Auto Processing message appears.

Picture disturbances (vertical lines) ► To u c h th e

AUTO

sensor to perform

auto-adjustment of the screen.

Picture disturbances (horizontal lines, picture
noise)

► To u c h th e

AUTO

sensor to perform

auto-adjustment of the screen.

The screen becomes darker

The background lighting has a limited lifetime.
If your monitor display should become too dark,
the background lighting will have to be replaced.

► Contact our Service Desk.

For DVI connection:

Despite the correct resolution of 2560 x 1440,
small fonts are not sharp or are illegible and
black font is shown coloured. (The information
menu of the monitor shows a resolution of 1 280
x 1440).

► Use the DVI ‑ Dual Link data cable which

was supplied with the monitor.

Fujitsu 29

Explanatory information about stan

dard I SO 9241-307

Explanatory information abou

t

standard ISO 9241-307

Permanently unlit or lit pixels

Today’s production techniques cannot guaran tee an absolutely fault-free screen display. Depending
on the total number of pixels (resolution), there may be a few constantly lit or unlit pixels or subpixels.

Pixel

A pixel consists of 3 subpixels, norm ally red, green and blue. A pixel is
the smallest element that can be generated by co mplete functionality of
the display.

Subpixel

A subpixel is a separately addressable internal structure within a pixel tha t
enhances the pixel function.

The maximum permitted number of faulty pixels is stipulated in the international standard ISO
9241-307. In accordan ce with standard ISO 9241-3, LCD monitors b y Fujitsu comply with Class II
for low resolutions and Class I for resolutions of 1680 x 1050 (1764000 pixel) and higher.

Examples:

A flat-screen monitor with a resolution of 1280 x 1024 has 12 80 x 1024 = 1310720 pixels. Each pixel
consists of three subpixels (red, green and blue), so there are almost 3.9 million subpixels in total.
According to ISO 9241-3 (Class II), a maximum of 3 lit and 3 unlit pixels plus 7 lit or 13 unlit subpixels,
or a correspon ding combination, may b e faulty (1 lit subpixel counts as two unlit subpixels).

A flat-screen monitor with a resolution of 2560 x 1440 has 25 60 x 1440 = 3686400 pixels. Each pixel
consists of three subpixels (red, green and blue), so there are almost 11.1 million subpixels in total.
According to ISO 9241-3 (Class I), a maximum of 2 lit and 2 u nlit pixels plus 9 lit or 18 unlit subpixels,
or a correspon ding combination, may b e faulty (1 lit subpixel counts as two unlit subpixels).

30 Fujitsu

Technical specification

Technical specification

Condensation is not permitted, neither in the rated range of operation
nor in the limit range of operation.

Product name P27T-7 LED

Model name P27T-7

Dimensions and weight

Visible diagonals 68.5 cm

Dot pitch 0.2331 mm

Width 596.7 mmImage size

Height 335.7 mm

Maximum resolution 2560 x 1440

Width 646 mm

Height 417 mm

Dimensions incl. monitor base

Depth 252 mm

Weight (without packaging)

approx. 9.5 kg

Storable d

isplay modes

36

Pixel fault classes according to
ISO 9241-307

Class

I

Electrical data

Analog

positive, 0.7 V

ss

,75Ω

Video

Digital

DP/DV

I-D/HDMI with HDCP

Synchronisation Separate Sync. TTL,

positive or negative

Horizontal frequency

30 kHz ....100 kHz

(multi-scanning)

Refresh rate

56 Hz .... 76 Hz

Maximum pixel rate

VG

A: 205 MHz

H

DMI: 270 MHz

D

P: 360 MHz

DVI: 330 MHz

Power supply automatic switching

100 V – 2 40 V, 50/60 Hz

Normal operation 50 W

ECO operating mode

33 W

Total power consumption
(excluding audio, USB)

Energy saving mode
(0 W operating mode)

0W

Sound output 2. 0 W left; 2.0 W right

Fujitsu 31

Technical specification

Environmental conditions

Environment class 3K2, DIN IEC 721

Rated range of operation

Humidity

15 ° C .... 35 °C

20 % .... 85 %

Limit range of opera tion

Humidity

5 ° C .... 35 °C

20 % .... 85 %

VESA-DDC-compatible VGA interface

Your monitor is equipped with a VESA-DDC-compatible VGA interface. VESA-DDC (Video
Electronics Standard Association, Display Data Channel) is used as the communications
interface between the monitor and the c omputer. If the computer is equipped with a
VESA-DDC-compatible VGA interface, it can automatically read the data for ensuring
optimum operation from the monitor a nd select the appropriate settings.

Preset operating modes

The picture posit

ion and size have been set to optimum values at the factory for t he

operating m od es l

isted above. Depending on the display adapter use d, it may be

necessary to adj

ust the display position or size. In this case, you can change and

save the settin

gs (see chapter "

Changing the monitor settings", Page 20).

For ergonomic r

easons, a screen resolution of 2560 x 1440 pixels is recommended.

Because of the

technology used (active matrix), an LCD monitor provides a

totally flicke

r-free picture, even with a refresh rate of 60 H z.

Most frequent operating modes

Horizontal frequency Refresh rate Screen resolution

31.5 kHz 70 Hz 720 x 400

31.5 kHz 60 Hz 640 x 480

37.5 kHz 75 Hz 640 x 480

37.9 kHz 60 Hz 800 x 600

46.9 kHz 75 Hz 800 x 600

48.4 kHz 60 Hz 1024 x 768

55.4 kHz 60 Hz 1440 x 900

60.0 kHz 75 Hz 1024 x 768

64.0 kHz 60 Hz 1280 x 1024

65.0 kHz 60 Hz 1680 x 1050

74.0 kHz 60 Hz 1920 x 1200
(only VGA, DVI, DP)

80.0 kHz 75 Hz 1280 x 1024

88.7 kHz 60 Hz

2560 x 1440 (only DVI, DP)

32 Fujitsu

Technical specification

Video/TV operating modes using DP and HDMI

Screen resolution Refresh r ate

Aspect ratio

720 x 480 i 60 Hz

4:3 / 16:9

720x480p 60Hz

4:3 / 16:9

720 x 576 i 50 Hz

4:3 / 16:9

720x576p 50Hz

4:3 / 16:9

1280 x 720 p

50 / 60 Hz

16:9

1920 x 1080 i

50 / 60 Hz

16:9

1920 x 1080 p

50 / 60 Hz

16:9

SUB D port

610

1115

51

Pin Meaning

1 Video input red

2 Video input green

3 Video input blue

4

Ground

5

Ground

6 Video ground red

7

Video ground g reen

8 Video ground blue

9

+5 V (DDC)

10

Sync

. ground

11

Ground

12

DDC Data

13 H. sync

14 V. sync

15

D

DC Clock

Fujitsu 33

Technical specification

DVI-D port

9

1

17

Pin Meaning

1

TMDS Data2–

2

TMDS Data2+

3

TMDS Data 2/4 Shield

4 not connected

5

not connected

6

DDC Clock

7

DDC Data

8

Analog Vertica

lSync

9

TMDS Data1–

10

TMDS Data1+

11

TMDS Data 1/

3 Shield

12 not connec

ted

13 not connec

ted

14 +5V Power

15 Earth

16 Hot Plu

g Detect

17

TMDS Data0–

18

TMDS Data0+

19

TMDS

Data 0/5 Shield

20 not

connected

21 no

t connected

2

2

TMDS Clock Shield

23

TMDS Clock+

24

TMDS Clock–

34 Fujitsu

Technical specification

DisplayPort socket

1319 17 15 13 11 9 7 5

2420 19 16 14 12 10 8 6

Pin Meaning

1

Lane 3 (negative)

2Earth

3

Lane 3 (positive)

4

Lane 2 (negative)

5

Earth

6

Lane 2 (positive

)

7

Lane 1 (negative)

8Earth

9

Lane 1 (positive)

10

Lane 0 (nega

tive)

11 Earth

12

Lane 0 (positive)

13

Connected to earth

14

Connect

ed to earth

15

Auxiliary channel (positive)

16 Earth

17

Auxiliary channel (negative)

18 Hot Plug Detect

19

Ret

urn for Power

20

Power for connector
(3.3 V 500 mA)

Fujitsu 35

Technical specification

HDMI port

13

24681012141618

5791113151719

Pin Meaning

1

TMDS Data2+

2

TMDS Data2 Shield

3

TMDS Data2–

4

TMDS Data1+

5

TMDS Data1 Shield

6

TMDS Data1–

7

TMDS Data0+

8

TMDS Data0 Shield

9

TMDS Data0–

10

TMDS Clock+

11

TMDS Clock Shield

12

TMDS Clock–

13

CEC

14

N.C.

15

SCL

16

SDA

17

DDC/CEC G round

18 +5 V Power

19 Hot plug detect

36 Fujitsu
