Handheld
EasyGuide
Pocket LOOX N/C Series
English
Are there ...
... any technical problems or other questions which you would like to be clarified?
Please contact:
• our Hotline/Help Desk
(see Help Desk List or the Internet:
• your sales partner
• your sales outlet
Further information can be found in the "Safety" and "Warranty" manuals.
The latest information on our products, tips, updates, etc., can be found on the internet under:
www.fujitsu-siemens.com
www.fujitsu-siemens.com/helpdesk)
This manual was produced by Xerox Global Services.
Published by
Fujitsu Siemens Computers GmbH
Edition 1, September 2005
Order No.:
A26391-K165-Z120-1-7619
Your Pocket LOOX
Pocket LOOX N/C Series
EasyGuide
Important notes
Operating the Pocket PC
Configuring the
Pocket PC
Connecting and
networking the Pocket PC
with other devices
Troubleshooting and tips
Technical data
Edition 1, September 2005
Index
Adobe and Acrobat are trademarks of Adobe systems Incorporated and may be protected in
certain countries.
Intel is a registered trademark, XScale is trademark of Intel Corporation, U.S.A.
Microsoft, Windows and ActiveSync are registered trademarks of the Microsoft Corporation.
Windows Mobile is a trademark of Microsoft Corporation.
The SD Logo is a trademark of Secure Digital.
The Bluetooth trademarks are the property of Bluetooth SIG, Inc., U.S.A. licensed for Fujitsu
Siemens Computers GmbH.
All other trademarks referenced are trademarks or registered trademarks of their respective
owners, whose protected rights are acknowledged.
Copyright © Fujitsu Siemens Computers GmbH 2005
All rights, including rights of translation, reproduction by printing, copying or similar methods,
in part or in whole, are reserved.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or design,
are reserved.
Delivery subject to availability. Right of technical modification reserved.
Contents
Your Pocket LOOX ... ......................................................................................................................... 1
Notational conventions ......................................................................................................................... 2
Software overview ................................................................................................................................3
Important notes .................................................................................................................................. 5
Safety notes.......................................................................................................................................... 5
Underway with the Pocket PC .............................................................................................................. 6
Transporting Pocket PC ............................................................................................................... 6
Using the Pocket PC ............................................................................................................................ 7
Cleaning Pocket PC ............................................................................................................................. 7
Disposal and recycling.......................................................................................................................... 7
Liability.................................................................................................................................................. 7
CE marking........................................................................................................................................... 8
Operating the Pocket PC ................................................................................................................... 9
Overview of operating elements, ports and indicators.......................................................................... 9
Front side of Pocket PC ............................................................................................................... 9
Back side of Pocket PC.............................................................................................................. 10
Indicators.................................................................................................................................... 11
Initial start-up ...................................................................................................................................... 11
Inserting battery.......................................................................................................................... 12
Connecting PSC11R-050 power adapter ................................................................................... 13
Installing ActiveSync on your PC/notebook................................................................................ 15
Starting Pocket PC the first time ................................................................................................ 16
First data synchronisation between the Pocket PC and the PC/notebook ................................. 17
Switching Pocket PC off and on ......................................................................................................... 17
Switching Pocket PC off and on during normal use ................................................................... 17
Switching on and off with soft reset (warm boot)........................................................................ 18
Resetting the Pocket-PC (Cold start) ......................................................................................... 19
Resetting Pocket PC to delivered state...................................................................................... 20
Using standard operating elements.................................................................................................... 21
Using the pen ............................................................................................................................. 21
Using navigation key .................................................................................................................. 21
Using application buttons ........................................................................................................... 22
Switching display lighting off and on................................................................................................... 22
Inserting and removing expansion card.............................................................................................. 23
Inserting expansion card ............................................................................................................ 23
Removing expansion card.......................................................................................................... 24
Using Pocket PC as USB Host device ............................................................................................... 25
On the road with the Pocket PC ......................................................................................................... 26
Using GPS.................................................................................................................................. 26
Charging the battery................................................................................................................... 26
Optimising battery operating time............................................................................................... 30
Synchronising data with ActiveSync................................................................................................... 31
Connecting Pocket PC to PC/notebook ..................................................................................... 32
Synchronising data with new PC/notebook ................................................................................ 32
Using cradle ............................................................................................................................... 33
A26391-K165-Z120-1-7619, edition 1
Contents
Configuring the Pocket PC...............................................................................................................35
Optimising energy management .........................................................................................................35
General information on energy management .............................................................................35
Using energy-saving possibilities................................................................................................ 36
Adjusting menus .................................................................................................................................37
Password protection............................................................................................................................37
Configuring hardware buttons .............................................................................................................38
FSC KeyLock: Preventing switch-on with application buttons ....................................................38
Assigning chosen functions to the hardware buttons..................................................................38
Connecting and networking the Pocket PC with other devices ...................................................39
Wireless data transfer with infrared interface...................................................................................... 39
Wireless connection via wireless LAN ................................................................................................39
Wireless communication with Bluetooth .............................................................................................40
Selecting location for Bluetooth operation ..................................................................................40
Activating and deactivating Bluetooth.........................................................................................40
Troubleshooting and tips ................................................................................................................. 41
Installing new software................................................................................................................41
Date or time of the Pocket PC is incorrect .................................................................................. 41
The display of the Pocket PC remains dark................................................................................ 41
The display is hardly readable ....................................................................................................41
The Pocket PC switches off ........................................................................................................41
The Pocket PC does not start after switch on............................................................................. 42
The Pocket PC stops working..................................................................................................... 42
The battery discharges too quickly .............................................................................................42
The Suspend/Resume button does not respond properly ..........................................................43
No sound or minimal volume ......................................................................................................43
Poor reception via GPS ..............................................................................................................43
Contact with hotline/help desk ....................................................................................................43
Technical data ...................................................................................................................................44
Pocket PC ........................................................................................................................................... 44
Battery (Li-Ion) ....................................................................................................................................45
PSC11R-050 power adapter ...............................................................................................................45
Index................................................................................................................................................... 46
A26391-K165-Z120-1-7619, edition 1
Your Pocket LOOX ...
... is equipped with the Office applications Microsoft Word, Excel and Outlook. In Outlook you cannot
only receive and send mails, but also manage your appointments and be reminded of your tasks.
You can access names, e-mail addresses and telephone numbers while you are away from your
home or office. You can store notes in written form or verbally as with a dictation device. Memory
cards ensure that even large amounts of data can be carried along reliably.
Install
ActiveSync on your notebook or PC, connect the Pocket LOOX to your notebook or PC and you
can synchronise your data. In the office you can then effortlessly transfer all your data and newly
created documents to your notebook or PC.
With the optional USB Host line you can use your Pocket LOOX as a USB Host device. You can
connect different USB devices, such as a MEMORYBIRD, to the Pocket PC.
Read your favourite book quite comfortably away from home on the display or use the MP3 player.
Insert the memory card of a digital camera in the slot and you can view the photos on the display.
Depending on the equipment of your unit with infrared or Bluetooth and wireless LAN you can
establish a connection to other devices at the office and away from it without bothersome cables. For
example, you can access the Internet using the Pocket LOOX with Bluetooth via your Bluetoothcapable mobile phone. You can call up both web and WAP pages with the
With a GPS receiver and navigation software you can use the Pocket PC as a navigation system.
Information on additional accessories for your Pocket LOOX is provided on the Internet at
www.fujitsu-siemens.com/accessories.
The following documentation contains additional information on your Pocket PC and the
Mobile
operating system:
• in the manuals "Safety" and "Warranty"
• in the help on your Pocket PC
• in the files on the Microsoft Getting Started CD (e.g. *.TXT, *.PDF)
Internet Explorer.
Windows
A26391-K165-Z120-1-7619, edition 1 1
Notational conventions
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
!
i
► text which follows this symbol describes activities that must be performed in
This font indicates programme names, commands, or menu items.
"Quotation marks" indicate names of chapters, data carriers, and terms that are being
pay particular attention to texts marked with this symbol. Failure to observe
this warning may endanger your life, destroy the system, or lead to loss of
data. Failure to follow the instructions may lead to loss of data, invalidate
your warranty, destroy the Pocket PC, or endanger your life.
indicates important information which is required to use the system properly.
the order shown.
emphasised.
2 A26391-K165-Z120-1-7619, edition 1
Software overview
Software overview
The following table provides an overview of the most important programs which are already installed
on your Pocket PC and where you can find information on using these programs.
Software Used for Operating information
Word Mobile For word processing Help file on Pocket PC
Excel Mobile For spread-sheet functions Help file on Pocket PC
Outlook Mobile Contacts/calendar//things to do Help file on Pocket PC
PowerPoint Mobile Opening and displaying presentations
ActiveSync For data synchronisation Help file on the notebook or
Internet Explorer Mobile Browser for websites and WAP sites Help file on Pocket PC
Windows Media Player
Mobile 10
FSC SpeedMenu Quick start menu for simplifying daily
CONNECTMOBILITY-E2C Connection manager for efficient
FSC Voice Recorder Brings real Dictaphone© functionality
FSC Audio Path Comfortable operation of the multiple
FSC Panning Problems when scrolling in the Internet
FSC KeyLock Protects against accidental starting of
that were created on a PC.
For playing audio and video files Help file on Pocket PC
procedures. Adapt the menu to your
needs. Support for one-handed
operation
management and control of complex
Internet and Intranet connections.
Automates and minimizes user
actions.
Supports, e.g. Bluetooth, wireless LAN
und infrared (IrDA, CIR)
to the Pocket LOOX
active audio outputs on the Pocket
LOOX
Explorer Mobile
FSC Panning quickly brings window
contents into view. Especially useful
on large websites.
the Pocket-PC when a key is pressed.
?
Help file on Pocket PC
PC on which you installed
ActiveSync.
Help file on the Pocket-PC and
user manual "Pocket LOOX
Software Suite" on the
Microsoft Getting Started CD.
Help file on the Pocket-PC and
user manual "Pocket LOOX
Software Suite" on the
Microsoft Getting Started CD.
Help file on the Pocket-PC and
user manual "Pocket LOOX
Software Suite" on the
Microsoft Getting Started CD.
Help file on the Pocket-PC and
user manual "Pocket LOOX
Software Suite" on the
Microsoft Getting Started CD.
Help file on the Pocket-PC and
user manual "Pocket LOOX
Software Suite" on the
Microsoft Getting Started CD.
Help file on the Pocket-PC and
user manual "Pocket LOOX
Software Suite" on the
Microsoft Getting Started CD.
A26391-K165-Z120-1-7619, edition 1 3
Software overview
FSC Password Protection against theft – permanent
passwords for protecting against
misuse.
Patented solution
FSC Backup Partial and full data backup on
external memory modules (if
available)
Help file on the Pocket-PC and
user manual "Pocket LOOX
Software Suite" on the
Microsoft Getting Started CD.
Help file on the Pocket-PC and
user manual "Pocket LOOX
Software Suite" on the
Microsoft Getting Started CD.
4 A26391-K165-Z120-1-7619, edition 1
Important notes
This chapter contains safety notes and important information you must observe when using your
Pocket PC.
This Pocket PC complies with the relevant safety regulations for data processing equipment. If you
have questions as to whether you can set up and operate the Pocket PC in the intended
environment, please contact your sales point or our hotline/help desk.
Safety notes
Observe the safety notes in the "Safety" manual and the following safety notes to prevent
damage to your device, data loss or injuries.
!
• During installation and before operating the device, observe the instructions on environmental
conditions in the "Technical data" chapter.
• Connect the power adapter plug to the PSC11R-050 power adapter. The power adapter plug
must never be plugged into an electrical outlet without the PSC11R-050 power adapter.
• The included PSC11R-050 power adapter complies with the requirements of the country in
which you purchased the Pocket PC. Make sure the PSC11R-050 power adapter is approved
for the country in which it is used.
• The PSC11R-050 power adapter may only be connected to an electrical outlet when the Pocket
PC or the cradle (optional) is connected to the PSC11R-050 power adapter.
• Do not use the PSC11R-050 power adapter for other devices.
• Do not use power adapters which are not specially approved for this Pocket PC.
• You may only operate the Pocket PC with the PSC11R-050 power adapter if the nominal
voltage of the PSC11R-050 power adapter (100 V to 240 V) matches the local mains voltage.
• When transporting the device on a trip, observe the information in the section "Underway with
the Pocket PC".
• The high transmitting power of the consumer infrared interface (CIR) may cause technical
problems for infrared devices (e.g. mobile phone, PDA) which are not suitable for CIR or are too
close to the transmitter. Before you set up an Infrared data connection to a device such as a
mobile phone or PDA, check that the CIR is not active or not currently being used by another
program.
A26391-K165-Z120-1-7619, edition 1 5
Important notes
Underway with the Pocket PC
Observe the following information when you travel with your Pocket PC.
Transporting Pocket PC
• Switch the Pocket PC off.
• Disconnect the cables from the Pocket PC.
• If the device needs to be shipped, use the original packaging or other suitable packaging to
protect it from damage caused by mishandling.
• Use the pouch for transporting the Pocket PC that provides protection against jolts and impacts
(the protective pouch is available as an accessory).
• Protect the Pocket PC from severe shocks and extreme temperatures (e.g., direct sunlight in a
car).
• If you wish to use your Pocket PC during a flight, check first with the airline if this is allowed and
under which conditions.
• In some countries the use of Bluetooth is restricted or completely prohibited. Ask about the
regulations in the country you will be travelling in before starting your trip. As a precaution,
switch Bluetooth off in case there is any uncertainty at your place of residence.
• If you are travelling abroad, ensure that the PSC11R-050 power adapter can be operated with
the local mains voltage. Do not use any other voltage converter!
• If you use a modem, incompatibilities with the local telecommunications system may result.
6 A26391-K165-Z120-1-7619, edition 1
Important notes
Using the Pocket PC
Store the Pocket PC in a fully charged state in a dry environment. If you store the Pocket PC for up
to a month, the storage temperature should be between –20 °C and +60 °C. If you store the Pocket
PC for up to three months, the storage temperature should be between –20 °C and +45 °C. The
lower the temperature at which the batteries are stored, the lower is the rate of self-discharge.
Please note that batteries discharge themselves over time. Therefore, recharge the battery of your
Pocket PC at regular intervals during the storage period.
Protect the slots for expansion cards and the ActiveSync connection of the Pocket PC from soiling.
Soiling can lead to contact problems.
Avoid leaving your Pocket PC lying in direct sunlight in a car. The temperature could
exceed the permissible 60 °C in such cases!
i
To protect the battery, battery charging is interrupted at excessively high temperatures
(over 48 °C).
Cleaning Pocket PC
► Switch the Pocket PC off.
► Pull the PSC11R-050 power adapter out of the electrical outlet.
The device surface can be cleaned with a dry cloth.
If it is very dirty, you can clean the device and the display with a damp cloth.
Do not use any cleaning agents that contain abrasives or may corrode plastic.
!
Please ensure that no liquid enters the Pocket PC.
Disposal and recycling
You will find further information about country-specific recycling and disposal options in the Internet
under
www.fujitsu-siemens.com/recycling or on the Microsoft Getting Started CD.
Liability
Fujitsu Siemens Computers GmbH cannot be held responsible for radio or television faults arising
from unauthorised changes made to this device. Fujitsu Siemens Computers is, furthermore, not
responsible for replacing and/or exchanging connector cables and devices which have not been
specified by Fujitsu Siemens Computers GmbH. The user is solely responsible for repairing faults
arising from such unauthorised changes made to a device and for replacing and/or exchanging
devices.
A26391-K165-Z120-1-7619, edition 1 7
Important notes
CE marking
Products bearing the CE marking comply with the R&TTE Directive
0470
CE compliance of this device is valid only if powered with by a CE-marked AC Adapter provided by
Fujitsu Siemens Computers. Compliance with these directives implies conformity to the following
European Norms (in parentheses are the equivalent international standards and regulations):
• EN 55022 (CISPR 22) — Electromagnetic Interference
• EN 55024 (IEC 61000-4-2, 3, 4, 5, 6, 8, 11) — Electromagnetic Immunity
• EN 61000-3-2 (IEC 61000-3-2) — Power Line Harmonics
• EN 61000-3-3 (IEC 61000-3-3) — Power Line Flicker
• EN 60950 (IEC 60950) — Product Safety
• ETS 300 328-2 — Technical requirements for 2.4 GHz radio equipment
• EN 301 489-1, -17 — General EMC requirements for radio equipment
The IEEE 802.11b wireless LAN and Bluetooth functionality of this product can be used in the
following EU countries, EU candidate countries and EFTA countries: Belgium, Denmark, Germany,
Estonia, Finland, France, Greece, Great Britain, Ireland, Iceland, Italy, Liechtenstein, Latvia,
Lithuania, Luxemburg, Malta, Netherlands, Norway, Austria, Poland, Portugal, Sweden, Switzerland,
Slovakia, Slovenia, Spain, Czech Republic, Hungary and Cypress.
If you are not sure whether the use of Bluetooth is permitted in your country, please contact the
corresponding supervisory authorities.
For IEEE 802.11b wireless LAN operation of this product, only a limited band is available in France
(Channels 10, 11, 12, and 13 only). The Autorité de régulation des télécommunications (ART) has
special regulations for hotspots allowing other channels, too.
Please check with ART (http://www.art-telecom.fr) on this for local rulings and for authorization.
The user is responsible for radio interference that may occur when operating the device.
!
(1999/5/EC), EMC Directive (89/336/EEC), and the Low Voltage Directive
(73/23/EEC) issued by the Commission of the European Community.
8 A26391-K165-Z120-1-7619, edition 1
Operating the Pocket PC
In this section you will find a description of the operating controls of your Pocket-PC and how you
operate the Pocket-PC.
Please take note of the information in the "Important notes" chapter.
!
Overview of operating elements, ports and indicators
Front side of Pocket PC
1 = Suspend/Resume button
1
2
9
8
7
2 = Power-on indicator (battery, message)
3 = Display
4 = ActiveSync port
5 = Opening for soft reset
6 = Infrared interface
7 = Record button
8 = Microphone opening
9 = Radio indicator (WLAN, GPS, Bluetooth)
3
6
45
A26391-K165-Z120-1-7619, edition 1 9
Operating the Pocket PC
1 = Navigation button (N) or
CONNECTMOBILITY-E2C button (C)
N
1
5
2 = Today button
C
3 = Navigation key
4 = Contacts button
5 = Calendar button
4
23
Back side of Pocket PC
123
5
1 = Stylus
2 = Slot for SD/MMC expansion cards
3 = Port for headphones or active loudspeakers
4 = Battery compartment cover
5 = Port for external GPS antenna (optional)
4
10 A26391-K165-Z120-1-7619, edition 1
Operating the Pocket PC
Indicators
Indicator Colour Description Indicator state
Status: battery charge
level
Status: message green Message present flashing
Radio indicator: WLAN green WLAN activated flashing
Radio indicator: GPS orange GPS activated flashing
Radio indicator: Bluetooth blue Bluetooth activated flashing
If the battery is being charged and a message is present at the same time, the status
indicator flashes orange and green alternately.
i
orange
Battery fully charged on
Battery is being charged flashing
Battery charger not connected off
Initial start-up
Please follow the sequence of these steps! Before the first data synchronisation
between your Pocket PC and your PC/notebook, you must install the program
i
on your PC/notebook.
In just a few steps your Pocket PC is ready to use the first time:
• Inserting battery
• Connecting PSC11R-050 power adapter
• Install ActiveSync on the PC/notebook
• Starting Pocket PC the first time
• Start the initial data synchronisation between the Pocket PC and the PC/notebook
You will learn more about the individual steps in the following sections.
ActiveSync
A26391-K165-Z120-1-7619, edition 1 11
Operating the Pocket PC
Inserting battery
1
► Pull the cover (1) off the Pocket PC in the direction of the arrow.
► Lay the battery in the battery compartment (2 +3). When doing so, watch the contact
connections and hold onto the tab (4).
► Slide the cover (5) in the direction of the arrow as far as it will go.
The battery is not charged at the time of delivery. Therefore, charge the battery for
12 hours before the first mobile use (see section "Connecting PSC11R-050 power
i
adapter").
4
2
3
5
12 A26391-K165-Z120-1-7619, edition 1
Operating the Pocket PC
Connecting PSC11R-050 power adapter
Please take note of the information in the "Important notes" chapter.
!
UK
You can connect the PSC11R-050 power
adapter directly to the Pocket PC.
► Slide the suitable power adapter plug into
the PSC11R-050 power adapter in the
direction of the arrow until it engages.
A26391-K165-Z120-1-7619, edition 1 13
Operating the Pocket PC
3
2 1
► Connect the ActiveSync cable (1) to the ActiveSync port on the Pocket PC.
► Connect the power adapter cable (2) to the DC socket of the ActiveSync cable.
► Connect the PSC11R-050 power adapter (3) to an electrical outlet.
The installed battery will now be charged. The power-on indicator flashes orange.
Please note that:
i
Do not connect your Pocket PC to your computer (PC/notebook) yet. Before the first data
synchronisation between your Pocket PC and your PC/notebook, you must install the
program
ActiveSync on your PC/notebook.
14 A26391-K165-Z120-1-7619, edition 1
Operating the Pocket PC
Installing ActiveSync on your PC/notebook
The data synchronisation helps you always keep your data on your Pocket PC and your
PC/notebook up to date when you work alternately with your PC/notebook and your Pocket PC.
The ActiveSync cable and the
already installed on your Pocket PC. You need only install
you will find the program
► Insert the Microsoft Getting Started CD in the optical drive of your PC/notebook.
The installation program of
► If the installation program of
the file
Setup.exe of ActiveSync.
► Follow the instructions on the screen.
► Prepare the Pocket PC as described in the section "Starting Pocket PC the first time".
During the installation the software attempts to establish a connection to the Pocket PC.
If you have not yet installed
PC/notebook before the first data synchronisation between your Pocket PC and your
i
PC/notebook. You will find
ActiveSync software are provided for data synchronisation. ActiveSync is
ActiveSync on your PC or notebook.
ActiveSync and the necessary driver on the Microsoft Getting Started CD.
ActiveSync will start.
ActiveSync does not start automatically, you must double-click on
Outlook on your PC/notebook, you must install it on your
Outlook on the supplied Microsoft Getting Started CD.
1
► Connect the ActiveSync cable to a USB port (1) of your PC/notebook.
The Pocket PC is now connected to your PC/notebook. The ActiveSync partnership between your
Pocket PC and your PC/notebook will be established.
A26391-K165-Z120-1-7619, edition 1 15
Operating the Pocket PC
Starting Pocket PC the first time
2
1
► Press the Suspend/Resume button (1) to switch on the Pocket PC.
► Pull out the pen (2) in the direction of the arrow.
Adjusting touchscreen
The display of your Pocket PC is a touchscreen. To ensure that the touchscreen of your Pocket PC
reacts correctly when touched with the stylus, you will be asked to align the touchscreen after the
initial start-up.
Touch the centre of the cross hairs that appears on the display with the stylus. This procedure must
be repeated several times, whereby the cross hairs appear at different locations on the display each
time. Follow the instructions on the display.
Becoming familiar with basic operation
Next the operating system provides a brief introduction to the operation of the Pocket PC with the
stylus after the initial start-up.
► Follow the instructions on the display.
Today screen
Following the introduction the Today screen appears. The Today screen shows all important current
information at a glance. From this screen you have access to all programs and to the system
settings.
Please also use the help function that is available on your Pocket PC if you want to know
more about operating the programs contained in the operating system.
i
16 A26391-K165-Z120-1-7619, edition 1
Operating the Pocket PC
First data synchronisation between the Pocket PC and the
PC/notebook
After you have specified the desired and required settings for synchronisation in the ActiveSync
Setup Wizard, the first synchronisation starts automatically.
Switching Pocket PC off and on
Switch the Pocket PC on or off with the Suspend/Resume button. After certain applications or the
installation of new programs, it may be necessary to restart the Pocket PC with the soft reset. It is
only necessary in seldom, exceptional cases to reset the Pocket PC to the delivered state.
Switching Pocket PC off and on during normal use
Switching off with Suspend/Resume button
► Briefly press the Suspend/Resume button to switch off the Pocket PC.
The Pocket PC is switched to suspend mode.
There are two ways to switch on your Pocket PC:
If you have specified a switch-off time with the system settings, your Pocket PC will
automatically switch into the Suspend mode after this specified time.
i
Switching on with Suspend/Resume button
► Briefly press the Suspend/Resume button to switch on the Pocket PC.
Switching on with application buttons
By default, you can also switch your Pocket PC on by briefly pressing one of the application buttons.
The applications assigned to the respective button appears on the screen.
A26391-K165-Z120-1-7619, edition 1 17
With the appropriate setting in
by pressing the application button.
i
FSC KeyLock you can prevent the Pocket-PC being started
Operating the Pocket PC
Switching on and off with soft reset (warm boot)
After certain applications or the installation of new programs, it may be necessary to restart the
Pocket PC with the soft reset.
Unsaved data is lost. Shut down all programs before you restart the Pocket-PC.
i
► Briefly press the stylus tip (1) into the soft
reset opening.
The warm boot is carried out.
1
18 A26391-K165-Z120-1-7619, edition 1
Operating the Pocket PC
Resetting the Pocket-PC (Cold start)
If your Pocket-PC locks up and switching it on and off with the suspend/resume button and soft reset
has no effect, you can reset your Pocket-PC.
Unsaved data is lost. Shut down all programs before you reset the Pocket-PC.
i
1
2
► Simultaneously press the Suspend/Resume button (1) and the stylus tip (2) into the soft reset
opening.
A26391-K165-Z120-1-7619, edition 1 19
Operating the Pocket PC
Resetting Pocket PC to delivered state
1
► Simultaneously press and hold the Suspend/Resume button (1) and the Calendar application
button (2).
► Briefly press the stylus tip into the soft reset opening (3). Continue to hold down the
Suspend/Resume button and the Calendar application button for a few seconds.
The reset can take a few minutes. At the end an acoustic signal sounds. Please follow the further
instructions on the display.
When you reset your Pocket PC to the delivered state, the battery switches off so that the
RAM content is lost. This means: You loose all data (documents, additionally installed
i
programs, personal settings) that you haven't saved elsewhere. Back up your data
regularly (memory card,
If you have set a password with
remains intact.
FSC Backup).
FSC Password and marked it as permanent, the password
2
3
20 A26391-K165-Z120-1-7619, edition 1
Operating the Pocket PC
Using standard operating elements
Using the pen
► Briefly touch the desired element on the display with the stylus to trigger an action.
► To activate popup menus, also touch the desired element with the stylus, however allow the
stylus to rest on the element for a moment. The popup menu appears and you can select an
element by touching it.
Using navigation key
1
With the navigation key (1) you scroll within the
menus (up, down, to the left and right) and
activate menu entries by pressing the centre of
the navigation key.
A26391-K165-Z120-1-7619, edition 1 21
Operating the Pocket PC
Using application buttons
N
1
4
1 = Navigation button (N) or
CONNECTMOBILITY-E2C button (C)
2 = Today button
C
3 = Contacts button
4 = Calendar button
3
With the application buttons and the appropriate preset (see chapter "Configuring the Pocket PC"),
you can open your preferred programs and applications directly from suspend mode or from within
an application.
Because the application button react differently to short or long keystrokes you can assign a total of
eight different programmes or applications to the application buttons.
2
Switching display lighting off and on
1
If the ambient light conditions permit, you can
switch the display lighting off or reduce its
brightness to save energy. You can also specify
the switching off and on again of the display
lighting in the system settings of your Pocket PC
(see the "Configuring the Pocket PC" chapter).
► Press the Suspend/Resume button (1) for
longer than 1 second to switch the display
lighting on or off.
22 A26391-K165-Z120-1-7619, edition 1
Operating the Pocket PC
Inserting and removing expansion card
A slot enables the operation of an expansion card of the type "Secure Digital I/O" or
"MultiMediaCard".
Inserting expansion card
Observe the manufacturer's instructions when using the expansion cards.
!
Never use force when inserting or removing an expansion card.
Make sure that no foreign objects enter the slot.
2
1
► Also press on the edge of the placeholder (1) so that the placeholder is pushed out of the slot
somewhat.
► Pull the placeholder out of the Pocket PC (2).
► Carefully push the expansion card (3) into the slot.
The expansion card can protrude by one to several millimetres (depending on the type of expansion
card).
Keep the placeholder for the expansion card in a safe place. When you remove the
expansion card again, you should reinsert the expansion card placeholder. This prevents
i
foreign matter from getting into the slot.
3
A26391-K165-Z120-1-7619, edition 1 23
Operating the Pocket PC
Removing expansion card
2
1
► Press on the edge of the expansion card (1) so that the expansion card jumps out of the slot
slightly.
► Slide the expansion card out of the Pocket PC (2).
► Insert the placeholder (3) again into the slot if necessary.
The placeholder protrudes one to two millimetres.
3
24 A26391-K165-Z120-1-7619, edition 1
Operating the Pocket PC
Using Pocket PC as USB Host device
With the optional USB Host cable you can use
your Pocket PC as a USB Host device and
connect various USB devices, such as a
MEMORYBIRD, to the Pocket PC.
The USB Host cable is available as an accessory
under the name "Sync Cable USB client/host".
You can connect USB devices from Fujitsu Siemens Computers (e.g. MEMORYBIRD or
STORAGEBIRD) immediately.
i
If you want to connect other USB devices, ask your dealer whether drivers must be
installed.
The current consumption of the USB device may not exceed 100 mA (at +5 V). USB
devices with a current consumption of more than 100 mA must be supplied with power via
their own power supply.
1
2
► Connect the USB host cable (1) to the ActiveSync port on the Pocket PC.
► Connect the USB device (such as a MEMORYBIRD) to the USB port (2) of the USB Host
cable.
The USB device is now connected to your Pocket PC.
► If the battery charge level of your Pocket PC is low, you should connect the PSC11R-050
power adapter (see section "Connecting PSC11R-050 power adapter").
A26391-K165-Z120-1-7619, edition 1 25
Operating the Pocket PC
On the road with the Pocket PC
Using GPS
With a GPS receiver and navigation software you can use the Pocket PC as a navigation system.
Depending on the equipment, the GPS receiver is either integrated or available as an external
accessory.
You have two options for using the navigation software on your Pocket PC:
● You can use the navigation software on a preinstalled expansion card.
● You can install the navigation software via your PC, e.g. from a DVD.
► Register your navigation software and your card materials as described in the instructions for
A description of how to use the navigation software is provided in the instructions on the navigation
software.
Card materials for your Pocket PC is available from retailers on DVD or on memory cards
or via an online shop.
i
To register your navigation software you require the serial number of the navigation
software and possibly also the device ID of your Pocket PC.
i
The device ID will be displayed after the initial start-up of the navigation software if
necessary.
the navigation software.
Charging the battery
Your Pocket PC is equipped with a powerful battery. When you're on the road your Pocket PC is
supplied with power by the integrated battery. At your home or office you can recharge the battery in
the cradle. You can also take along the PSC11R-050 power adapter and connect your Pocket PC
directly to an electrical outlet to recharge the battery when you're on the go.
You have two ways of doing this:
• You can connect the Pocket PC directly to an electrical outlet with the PSC11R-050 power
• You can connect the cradle (optional) to an electrical outlet with the PSC11R-050 power
In both cases you can work with the Pocket PC during charging. This extends the charging time.
26 A26391-K165-Z120-1-7619, edition 1
The battery is not charged on delivery and should be charged for 12 hours prior to the first
mobile use.
i
The battery charging time is otherwise approx. 4 hours. When the Pocket PC is operating,
the charging time is extended.
adapter.
adapter and insert the Pocket PC in the cradle.
Please take note of the information on the PSC11R-050 mains adapter in the "Connecting
PSC11R-050 power adapter" section.
i
Operating the Pocket PC
Charging battery directly with PSC11R-050 power adapter
You can connect the PSC11R-050 power adapter directly to the Pocket PC. There are two ways to
do this:
• You can use the ActiveSync cable.
• You can use the adapter.
Connecting PSC11R-050 power adapter to Pocket PC with ActiveSync cable
3
2 1
► Connect the ActiveSync cable (1) to the ActiveSync port on the Pocket PC.
► Connect the power adapter cable (2) to the DC socket of the ActiveSync cable.
► Connect the PSC11R-050 power adapter (3) to an electrical outlet.
The installed battery will now be charged. The power-on indicator flashes orange.
When the battery is fully charged, the power-on indicator lights continuously orange.
A26391-K165-Z120-1-7619, edition 1 27
Operating the Pocket PC
Connecting PSC11R-050 power adapter to Pocket PC with adapter
3
2 1
► Connect the adapter (1) to the ActiveSync port of the Pocket PC.
► Connect the power adapter cable (2) to the adapter.
► Connect the PSC11R-050 power adapter (3) to an electrical outlet.
The installed battery will now be charged. The power-on indicator flashes orange.
When the battery is fully charged, the power-on indicator lights continuously orange.
28 A26391-K165-Z120-1-7619, edition 1
Operating the Pocket PC
Charging battery with cradle
There are two ways to connect the PSC11R-050 power adapter to the cradle (optional):
• You can use the ActiveSync cable.
• You can use the adapter.
Connecting PSC11R-050 power adapter to cradle with ActiveSync cable
4
3
2
► Connect the ActiveSync cable (1) to the ActiveSync port of the cradle.
► Connect the power adapter cable (2) to the DC socket of the ActiveSync cable.
► Connect the PSC11R-050 power adapter (3) to an electrical outlet.
► Place the Pocket PC in the cradle (4).
The installed battery will now be charged. The power-on indicator flashes orange.
When the battery is fully charged, the power-on indicator lights continuously orange.
1
A26391-K165-Z120-1-7619, edition 1 29
Operating the Pocket PC
Connecting PSC11R-050 power adapter to cradle with adapter
3
2
► Connect the adapter (1) to the ActiveSync port of the cradle.
► Connect the power adapter cable (2) to the adapter.
► Connect the PSC11R-050 power adapter (3) to an electrical outlet.
► Place the Pocket PC in the cradle (4).
The installed battery will now be charged. The power-on indicator flashes orange.
When the battery is fully charged, the power-on indicator lights continuously orange.
4
1
Optimising battery operating time
When you have completely charged the battery, you can operate the Pocket PC for up to 12 hours
without a power connection. However, it is not possible to exactly specify the maximum operating
time, as different applications use more or less energy.
In the system settings you can make settings that help you save energy when using your Pocket PC.
These settings enable you to use the battery operating time optimally.
In the default setting, a setting is activated that automatically switches the Pocket PC into
the Suspend mode after three minutes when working without a power connection if no
i
entries are made during this time. You can switch on the Pocket PC again at any time by
briefly pressing the Suspend/Resume button and then continue working where you left off.
30 A26391-K165-Z120-1-7619, edition 1
Operating the Pocket PC
Synchronising data with ActiveSync
To also have the current version of the data you have processed on the road on your Pocket PC
available on your PC/notebook, you must copy these data to your PC/notebook. This procedure is
conveniently enabled with data synchronisation:
In the ActiveSync program you can specify that the respective latest version of a file be detected and
then automatically updated on the respective data carrier - regardless of whether it is the Pocket PC
or a PC/notebook.
You can synchronise your data between your Pocket PC and your PC/notebook via the cradle, using
the ActiveSync cable or via infrared, Bluetooth or wireless LAN.
You will find information on how you synchronise data using
your PC/notebook.
If you have not yet installed the
it on your PC/notebook before the first data synchronisation between your Pocket PC and
i
your PC/notebook (see section "Initial start-up").
ActiveSync program on your PC/notebook, you must install
ActiveSync, in the ActiveSync help file on
A26391-K165-Z120-1-7619, edition 1 31
Operating the Pocket PC
Connecting Pocket PC to PC/notebook
4
3
1
2
► Switch your PC or notebook on.
► Connect the ActiveSync cable (1) to the ActiveSync port on the Pocket PC.
► Connect the ActiveSync cable to a USB port (2) of your PC/notebook.
The Pocket PC is now connected to your PC/notebook. The ActiveSync partnership between your
Pocket PC and your PC/notebook will be established.
Synchronising data with new PC/notebook
If you want to synchronise data with a new PC/notebook, you must first install ActiveSync on this new
PC/notebook and establish a new ActiveSync partnership (see the corresponding explanations in the
"Initial start-up" section).
32 A26391-K165-Z120-1-7619, edition 1
Operating the Pocket PC
Using cradle
With the cradle (optional) you can charge the battery in the Pocket PC and/or carry out a data
synchronisation between the Pocket PC and a PC/notebook.
The cradle has an audio output for connecting active loudspeakers or headphones.
Selecting location for cradle
Place the cradle on a stable, flat and nonslippery surface. In view of the multitude of different finishes
used on furniture, it is possible that the rubber feet of the Pocket PC will mark the surface they stand
on.
The cradle and the PSC11R-050 power adapter should be at least 200 mm apart.
Keep other objects 100 mm away from the cradle and its PSC11R-050 power adapter to ensure
adequate ventilation.
The Pocket PC and the cradle should not be subjected to extreme environmental conditions. Protect
the Pocket PC and cradle from dust, moisture and heat.
A26391-K165-Z120-1-7619, edition 1 33
Operating the Pocket PC
Using cradle for data synchronisation
Before the first data synchronisation between the Pocket PC and the PC/notebook, you
must install the program
i
ActiveSync on your PC/notebook (see section "Initial start-up").
5
4
4
2
3
► Switch your PC or notebook on.
► Place the Pocket PC in the cradle (1).
► Connect the ActiveSync cable (2) to the ActiveSync port of the cradle.
► Connect the ActiveSync cable to a USB port (3) of your PC/notebook.
The Pocket PC is now connected to your PC/notebook. The ActiveSync partnership between your
Pocket PC and your PC/notebook will be established.
► If the battery charge level of your Pocket PC is low, you should connect the PSC11R-050
power adapter (see section "Connecting PSC11R-050 power adapter").
More information on data synchronisation is contained in the section "Synchronising data with
ActiveSync" and in the help file on your Pocket PC.
You can leave the connections between the cradle and PSC11R-050 power adapter, and
between the cradle and your PC/notebook connected all the time. This means you only
i
need to place your Pocket PC in the cradle to charge the battery and for data
synchronisation.
34 A26391-K165-Z120-1-7619, edition 1
Configuring the Pocket PC
You can already choose from a large number of programs when you use the Pocket PC for the first
time. In addition, proven default settings are defined for the menu structure, energy management,
memory management and security functions.
But, of course, you can add and remove programs and configure the Pocket PC as desired.
You will find out how to use some of the functions (e.g. energy management) in this section.
For information on removing and adding programs, please refer to the documentation from the
software manufacturer and the
ActiveSync on your notebook/PC.
Optimising energy management
General information on energy management
The battery operating time is considerably dependent on the applications used. Please consider that
a particularly large amount of energy is required to play sound files or make sound recordings.
Therefore, if you want to work for up to 12 hours without a power connection, limit the use of energyintensive applications.
Data exchange with a PC or notebook also consumes additional battery power. Therefore, always
connect your Pocket PC to an electrical outlet during data exchange if possible.
ActiveSync help file, that you can call at any time after installing
A26391-K165-Z120-1-7619, edition 1 35
Configuring the Pocket PC
Using energy-saving possibilities
You can save energy in several ways to optimally utilise the battery operating time:
● Switch the Pocket PC into the Suspend mode when you are not using it.
● Reduce the processor speed.
● Switch the display lighting off or reduce the brightness.
● Switch off the sound, reduce the volume or only allow acoustic signals for certain applications.
Switching the Pocket PC into Suspend mode
► Select the number of minutes after which the Pocket PC is to switch into the Suspend mode
when it is not used under
Switching off display lighting
► Select the number of minutes after which the display lighting is to be switched off in the battery
Reducing brightness
► Reduce the display brightness under
Switching on the sound and setting the volume
► Touch the loudspeaker symbol in the navigation bar.
A popup window for the loudspeaker settings appears.
► Set the desired volume on the slide control with the stylus.
► To switch off the sound, activate the selection field for
► Touch the display anywhere outside the popup window.
Press the Suspend/Resume button to deactivate the Suspend mode.
i
The Pocket PC returns to the point at which you interrupted your work.
mode when the Pocket PC is not used under
Start - Settings - System - Power.
Start - Settings - System - Backlight.
Start - Settings - System - Brightness.
Off with the stylus.
36 A26391-K165-Z120-1-7619, edition 1
Configuring the Pocket PC
Adjusting menus
Frequently used programs appear in the Start menu. You can adjust the Start menu to meet your
needs.
► Touch the
A list of programs/applications appears.
To remove programs from the Start menu, click in the checkbox of the program. The check mark is
removed from the checkbox.
To add programs to the Start menu, click in the checkbox of the desired program. A check mark
appears in the checkbox.
You can also use the program
You can quickly and simply adapt
subject is provided in the user manual "Pocket LOOX Software Suite" on the Microsoft Getting
Started CD.
Menus symbol under Start - Settings - Private.
FSC SpeedMenu as an alternative for fast access to programs and files.
FSC SpeedMenu to your requirements. Additional information on this
Password protection
You can protect your Pocket PC from unauthorised access with a password. This makes your data
accessible only to persons who know the password.
► Touch the
► Select the type of password you prefer:
− A password consisting of four numbers (simple 4-digit password).
− A password of alphanumeric characters (a complex alphanumeric password).
► Select whether the password is to remain intact if the unit is reset to the delivered state.
If a password has been entered, you will have to enter this password the next time you switch on.
If you have forgotten your password, you can restart your Pocket PC by resetting it to the delivered
state (see section "Resetting the Pocket-PC (Cold start)"). If you have decided on a permanent
password, you will have to contact our service (help desk) in this case.
Password symbol under Start - Settings - Private.
A26391-K165-Z120-1-7619, edition 1 37
Configuring the Pocket PC
Configuring hardware buttons
FSC KeyLock: Preventing switch-on with application buttons
By default, your Pocket LOOX starts up if the Suspend button and an application button are pressed.
In the program
pressed.
You will find further information in the help file on your Pocket LOOX and in the user manual "Pocket
LOOX Software Suite" on the Microsoft Getting Started CD.
Assigning chosen functions to the hardware buttons
The buttons of your Pocket PC are assigned certain functions such as running programs. However,
you can change these default settings and assign the buttons the functions of your choice.
► Tap
► Select the
► Touch the
A list of the hardware buttons and the assigned programs or functions appears. The four application
buttons appear in the list twice. This is because you can assign different applications to these
buttons for short and for long keystrokes.
► Mark the button in the list for which you want to change the assignment.
► Select the program you want to assign to this button from the list below it.
► Touch
The button is now assigned the desired program.
If you want to change the function of several buttons, we advise you to make a note of the new
functions.
FSC KeyLock you can specify that the Pocket PC only starts if the Suspend button is
Start.
Settings entry in the menu.
Buttons symbol on the Private tab.
OK (navigation bar) to confirm your setting.
38 A26391-K165-Z120-1-7619, edition 1
Connecting and networking the Pocket PC with other devices
The Pocket PC offers a wide range of ways to exchange data with other devices or to work in a
network.
You have already become familiar with data synchronisation via
in the "Synchronising data with ActiveSync" section. You can connect the ActiveSync cable provided
to any PC or notebook equipped with a USB port. An active ActiveSync cable for devices with a
serial port is also available as an accessory.
In addition, the infrared interface, wireless LAN (optional) and Bluetooth (optional) are available for
wireless communication.
This chapter provides you with information on wireless data transfer
● via infrared interface
● via wireless LAN (optional)
● via Bluetooth (optional)
Wireless data transfer with infrared interface
The infrared interface (IrDA) permits wireless serial data transfer with up to 115 kbits/s.
For data transfer, you must align the infrared interface of your Pocket PC with that of the partner
device. The devices must not be more than one metre apart. The infrared interface of one device
must be in the range of influence (horizontally approx. 30 ° and vertically approx. 15 °) of the infrared
interface of the other device.
The infrared interface is simultaneously a consumer infrared interface (CIR). The CIR interface can
transmit over greater distances. As a result, you can also use the Pocket PC as a remote control with
suitable software.
ActiveSync and an ActiveSync cable
Wireless connection via wireless LAN
Your Pocket PC is equipped with an integrated wireless LAN (optional). Information on this topic is
provided in the help file on your Pocket PC.
You can also activate and deactivate the integrated wireless LAN just as you wish.
► Touch the
A26391-K165-Z120-1-7619, edition 1 39
WLAN Power symbol under Start - Settings - System.
Connecting and networking the Pocket PC with other devices
Wireless communication with Bluetooth
With your Pocket PC with an integrated Bluetooth module (optional) you can communicate wirelessly
with other Bluetooth devices, e.g. with another Pocket PC, a notebook or a mobile phone.
In the following sections, you will find out how to put Bluetooth into operation.
The help file for the software on your Pocket PC explains how you operate the software concerned.
Selecting location for Bluetooth operation
• We recommend that you use the Pocket PC with the Bluetooth components in a typical
operating environment. Other Bluetooth devices, which you want to communicate with, should
be located at a distance of up to 10 m.
• Only install a partner device within the recommended distance. Observe the output power class
of the partner device when doing so. Details are contained in the operating manual of the
partner device.
• Use the Pocket PC with the Bluetooth at least 2 m away from other electrical or electronic
systems. If you must use the Pocket PC near a microwave cooker, then maintain a distance of
at least 3 m from the microwave cooker, as the reception is subject to interference with regard
to microwaves.
• Should problems result when communicating via Bluetooth because radios or radio devices are
located in the vicinity, then move the Pocket PC to a different location.
Activating and deactivating Bluetooth
You can switch Bluetooth on and off just as you wish.
► Touch the Connections tab under
You can switch Bluetooth on and off here.
Start - Settings and then touch the Bluetooth symbol.
40 A26391-K165-Z120-1-7619, edition 1
Troubleshooting and tips
If a fault occurs in your Pocket PC, try to eliminate it with the measures described in this chapter. If
you fail to correct the problem, proceed as follows:
► Make a note of the steps and the circumstances that led to the fault. Also make a note of any
error messages displayed.
► Switch the Pocket PC off.
► Contact your sales outlet or our hotline/help desk.
Installing new software
You will find information on installing supplementary programs in the ActiveSync help file that you can
call up after installing
► When installing programs or drivers, important files may be overwritten and modified. You
should make a backup before the installation in order to access the original files if any problem
should occur after installation (see section "Synchronising data with ActiveSync").
Date or time of the Pocket PC is incorrect
► Touch the Clock symbol under Start - Settings - System.
► Change the time.
or
► Connect your Pocket PC via
► Synchronise data between the Pocket PC and the PC/notebook. The time and date are also
synchronised in the process.
ActiveSync on your PC/notebook.
ActiveSync to your PC/Notebook.
The display of the Pocket PC remains dark
Display lighting is switched off.
► Press the Suspend/Resume button longer than 1 second.
The display is hardly readable
Reflection
► Turn the Pocket PC until you can see the information in the display again.
The Pocket PC switches off
If you operate the Pocket PC too long with only the battery, the Pocket PC switches into the
Suspend mode when the battery charging level is too low.
► Connect the PSC11R-050 power adapter to charge the battery.
► Press the Suspend/Resume button.
A26391-K165-Z120-1-7619, edition 1 41
Troubleshooting and tips
The Pocket PC does not start after switch on
If the Pocket PC does not start after switch on, this may be due to one of the following:
The battery is dead.
► Charge the battery.
► Connect the PSC11R-050 power adapter to the cradle with the Pocket PC.
► Check whether the PSC11R-050 power adapter is connected correctly to the cradle.
► Check whether the power cable is plugged properly into the power adapter and into the
electrical outlet. The indicator on the power adapter should illuminate.
The battery is charged. The power-on indicator flashes orange.
PSC11R-050 power adapter is not properly connected.
► Switch the Pocket PC off.
► Check whether the PSC11R-050 power adapter is properly connected to the Pocket PC and
the electrical outlet.
► Then switch the Pocket PC on again
The Pocket PC stops working
If the Pocket PC stops working, this may have the following reasons:
An application program has caused the fault.
► Restart the Pocket PC (see section "Switching on and off with soft reset (warm boot)").
or
► If the restart does not function, reset the Pocket PC to the delivered state (see section
"Resetting the Pocket-PC (Cold start)").
The battery is dead.
► Connect the PSC11R-050 power adapter to the Pocket PC to charge the battery.
or
► Connect the PSC11R-050 power adapter to the cradle and insert the Pocket PC in the cradle to
charge the battery.
The battery discharges too quickly
The battery is either too hot or too cold.
► Bring the Pocket PC up/down to a normal temperature again.
If the operating time of the battery mode is extremely short, the battery is probably old and should be
replaced. Please contact your dealer for a new battery.
42 A26391-K165-Z120-1-7619, edition 1
Troubleshooting and tips
The Suspend/Resume button does not respond properly
You have pressed and held the Suspend/Resume button too long to switch the Pocket PC on
or off.
► Briefly press the Suspend/Resume button until the Pocket PC switches on or off.
No sound or minimal volume
Check whether the volume is set correctly.
► Touch the loudspeaker symbol in the navigation bar.
A popup window for the loudspeaker settings appears.
► Activate the selection field for
or
► Set the desired volume on the slide control with the stylus.
On with the stylus.
Poor reception via GPS
The installation position of the Pocket PC in your vehicle is unfavourable.
► Change the installation position of the Pocket PC.
Your vehicle's windscreen is coated.
► Use an external GPS antenna (available as an accessory).
Contact with hotline/help desk
If you are unable to solve a certain problem, please contact the hotline/help desk. Additional details
are contained in the "Safety" and "Warranty" manuals. Please have the following information ready
when you call:
• The model name and serial number of the Pocket PC. The serial number is located on a sticker
on the backside of the Pocket PC.
• Notes of any messages that appear on the screen and information on acoustic signals.
• Any changes you have made to the hardware or software after receiving the Pocket PC.
• Your system configuration and all peripheral devices connected to your system (e. g. keyboard).
• Your sales contract.
A26391-K165-Z120-1-7619, edition 1 43
Technical data
Pocket PC
Processor: Intel PXA270 with up to 624 MHz (depending on model)
Main memory: 64 - 256 Mbyte ROM (depending on model)
64 Mbyte RAM
Electrical data
Regulations complied with: CE, FCC Part 15 Class B, EN 60950, UL, cUL
Protection class: III
Maximum power draw:
(when Pocket PC is on with
battery charging)
Display
Transflective TFT display: 3.5 inch QVGA, 240 x 320
Card slots
1 x slot: "Secure Digital I/O", "MultiMediaCard"
Ports/interfaces
Audio: Microphone, loudspeaker, headphones (3.5 mm) or remote control
Data: Consumer IrDA, USB 1.1 Host/Client,
Environmental conditions
Environment class 3K2, 2K2 DIN IEC 721 EN 60721
Housing class 7M2 DIN IEC 721 EN 60721
Temperature:
• Operating (3K2)
• Transport (2K2)
10 W
pixels, 65,536 colours
serial (RS232; supports DTR/DTS), Bluetooth 1.2 Class 2,
wireless LAN (IEEE 802.11g), GPS Sirf Star 3
(depending on model)
5 °C – 40 °C
-25 °C – 60 °C
3.6 inch VGA, 480 x 640 pixels,
65,536 colours
Dimensions
Height/width/depth: 115.7 mm x 70.2 mm x 14.6 mm
Weight: approx. 145 g (depending on model)
44 A26391-K165-Z120-1-7619, edition 1
Technical data
Battery (Li-Ion)
Rated capacity: 1200 mAh1,200 mAh
Charging time (when not in
operation):
Operating time: up to 12 hours
Max. 4 hours
up to 350 hours in stand-by mode
PSC11R-050 powe r
Primary:
• Rated voltage:
• Frequency:
Secondary:
• Rated voltage:
• Max. rated c
urr
ent:
r adapte
100 V to 240 V (aut
50 Hz to 60 Hz (aut
5 V ±5%
2.0 A ±5%
omatic)
omatic)
A26391-K165-Z120-1-7619, edition 1 45
Index
A
ActiveSync partnership, establishing 17
ActiveSync port 10
Adjusting touchscreen 18
Application button
calendar button 11
CONNECTMOBILITY-E2C button 11
Contacts button 11
navigation button 11
switching on 20
today button 11
Date not correct 45
Date/Time incorrect 45
Delivered state 22
Display 10
cleaning 7
difficult to read 46
reflected glare 46
remains dark 45
Display lighting 40
switching off 25
switching on 25
Display, difficult to read 46
Disposal 7
B
Battery
capacity 7
charging with cradle 32
charging with PSC11R-050 power adapter
30
discharges 47
inserting 14
storing 7
technical data 50
Battery compartment
cover 12
Bluetooth 44
activating 44
deactivating 44
indicator 13
C
Calendar button 11
CE marking 8
Cleaning 7
Configuring hardware buttons 42
CONNECTMOBILITY-E2C button 11
Contacts button 11
D
Dark display 45
Data
technical 49
Data synchronisation 34
via cradle 37
Data transfer
bluetooth 44
infrared 43
wireless LAN 43
E
Electromagnetic compatibility 8
Energy-saving possibilities 40
Expansion card
handling 26
inserting 26
removing 27
Expansion card slot 12
F
First start 18
FSC KeyLock 42
G
GPS 29
indicator 13
GPS antenna 12
H
Hardware reset 22
Hardware, overview 10
Headphones port 12
Hotline/Help Desk 47
I
Indicator
battery charge level 13
bluetooth 13
GPS 13
message 13
WLAN 13
Indicators 10
Infrared interface 10, 43
46
