Page 1
Issue May 2005
MYRICA V32-1
LCD TV
Pages 2
Elegantly designed and brimming with high-end features, the 32” MYRICA LCD television is ready to meet today’s and
tomorrow’s home entertainment demands. Sharp, lifelike images combines breath-taking sound to give you an
unmatched viewing experience.
32” (81 cm) LCD screen with a wide viewing angle so everyone can enjoy the show HD ready: enjoy the quality of highdefinition television. Resolution of an enormous 1366 x 768 pixels: TV never looked this good. Ultra-high 1000:1
contrast ensures brilliant clarity and detail. Plug-and-play connectivity: connecting your PC is effortless
32 inch wide screen LCD TFT display
High resolution 1366 x 768 pixels
16.7 Mio colours
Viewing angle 176° / 176°
High brightness 550 cd/m²
and enormous contrast (1000:1)
Multi norm TV tuner (PAL/SECAM)
Various video inputs
Teletext (256 pages)
Plug and Play
DDC 2B interface
Immune to external electromagnetic fields
Analogue (D-Sub) input and DVI-D with HDCP support
8 languages OSD menu
Country specific warranty
HD ready
8ms response time
Page 2
Data Sheet MYRICA V32-1 LCD-TV Issue Mai 2005
All rights, including rights created by patent grant or registration of a utility model or design as well
as rights of technical modifications are reserved. Delivery subject to availability. Designations may
be trademarks, the use of which by third parties for their own purposes may violate the rights of the
trademark owners.
Copyright Fujitsu Siemens Computers,09/2004
Published by
Fujitsu Siemens Computers
http://www.fujitsu-siemens.com/
Company stamp
Visible screen diagonal 32 inch (81 cm) WXGA
Panel resolution
pixels 1366 x 768
Picture size 603 x 336 mm
Brightness typical 550 cd/m²
Contrast typical 1000:1
Viewing angle typical
Horizontal 176°
Vertical 176°
Response time g/g 8 ms
Options
TV tuner VHF/UHF/cable
Standard B/G, D/K, I and L/L’
(Multi Europe)
System PAL / SECAM
Sound system mono, stereo, dual tone
Teletext 256 pages (FLOF/TOP)
Video I/O
TV-RF In IEC-connect
DVI-D with HDCP support
D-SUB 15pin
AV1 (In) Component Video (YPbPr)
AV2 (In/Out) 21-pin Scart
AV3 (In/Out) 21-pin Scart
S-Video (In) (4 pin Dim)
Composite video RCA type
PC (Input)
D-Sub
DVI-D with HDCP support
Horizontal frequency 31.15 – 64 kHz
Vertical frequency 56 – 75 Hz
Resolutions 1280 x 1024 60 Hz
1280 x 720 60 Hz
1024 x 768 60 - 75 Hz
800 x 600 56 - 75 Hz
640 x 480 60 - 75 Hz
640 x 350 70 Hz
Video 480i, 480p, 576i, 576p,
720p, 1080i with HDCP
Audio characteristics
Volume control digital
PC Audio (In) 3.5 mm stereo phone jack
6 x RCA (In) Video, S-Video, Component
Earphone (Out) 3.5 mm stereo phone jack
Sub woofer (Out) RCA pin
Sound output 8 W (L) + 8 W (R)
Electrical values
External AC adapter
Rated voltage 100-240 V
Frequency 50-60 Hz
Power draw
Operating typical 155 W
Standby mode < 5 W
Protection class 1
Temperatures/dimensions/weight
Ambient temperature (to IEC721)
Recommended range 15°C to 35°C
Limit 5°C to 35°C
Dimensions incl. stand
(H x W x D) 580 x 792x 240 mm
Weight approx. 19,3 (unpacked)
Reliability
MTBF (demonstrated) 50000 h
Lifetime of backlight 50000 h
(brightness > 50 % of original brightness)
Compliance with standards
Product safety EN60950 + IEC guide 112
Ergonomics GS mark
Radiation immunity and CE certification according
RFI suppression to EC Directive
89/336/EEC
(EN55013, EN55020B,
EN55022/B, EN50024,
61000-3-2/-3)
Accessories
Power cable (1.8 m) for wall socket
Euro-Schuko-Type CEE7
plug type IEC-320-C13
Remote control incl. batteries (2x AAA)
User manual multi language
Special features
PIP (Picture-In-Picture)
Automatic program search
Order code S26361-K1037-V170
EAN 4045827314332
