Data Sheet FUJITSU Accessory Wireless Keyboard Set LX901

Data Sheet

FUJITSU Accessory Wireless Keyboard Set LX901

Excellent set with 128 AES encryption and high-precision optical LED mouse

The Wireless Keyboard LX901 is a top of the line desktop solution for lifestyle orientated
customers, who want only the best for their desk. This superb keyboard set offers ambitious
users more functions, security and better features than a conventional interface device. It
even includes 2.4 GHz technology and 128 AES encryption for security.

Usability

 Supports 128 AES encryption for RF keyboard
 Connects easily to every notebook PC with standard USB interface – no driver necessary
 More comfort keyboard with additional function buttons for fast application access
 Optical LED mouse with 10 buttons: 6 buttons are programable

2 b u t t o n s : S c r o l l f o u r w a y s f o r g r e a t e r e f  c i e n c y a n d c o m f o r t w i t h T i l t W h e e l T e c h n o l o g y

2 buttons: for boost function from 800 dpi to 1600 dpi

Ergonomics

 Elegant and extraordinary design
 Stress free and effective use through high contrast keys and ergonomic key design
 Soft touch keys in patented slim key-technology
 An ergonomic shape of the mouse, designed to be held comfortably by the hand for

extended usage

Reliability

 High quality and function stability
 Highest quality combined with very good price/performance ratio
 Abrasion-proof keys through laser technology
 No interference through 2.4 GHz technology: unlimited number of users working with

this set in a room

Page 1 / 4 www.fujitsu.com/fts/keyboards

Data Sheet FUJITSU Accessory Wireless Keyboard Set LX901

Wireless Keyboard Set LX901

Technical specications

Technical specication 2.4 GHz, 78 channels, 1 MHz, 65.000 IDs

Technology 2.4 GHz, 78 channels, 1 MHz, 65.000 IDs
Special features 128 AES encryption

RF LED Mouse with 10 buttons,
6 buttons are programmable
12 quick touch multimedia panel
USB Mini Receiver

2.4 GHz reliable, awless usage

without lag or interference

Keyboard

Height Adjustment 1.5° and 5.5°
Keyboard Type 104/105-key RF keyboard
Keys additional 10 Quick touch multimedia buttons
Keyboard battery info 2 x AAA battery compartment
Keyboard radio range max. 10 m
Power supply keyboard 2 AAA batteries, max.3.3V
Power consumption keyboard max. 2.0 mA at 3.3 V
Keyboard dimension (W x D x H) 465 x 179 x 20 mm
Keyboard weight 920 g

Ethernet (RJ-45)
USB 2.0 total USB 2.0 and 1.1

Mouse

Mouse type Optical RF LED Mouse
Mouse dimension (W x D x H) 73 x 125.5 x 43.5 mm
Mouse resolution 800 dpi, 1,200 dpi, 1,600 dpi
Mouse buttons 10 buttons, 6 are programmable
Mouse battery info 2 x AA battery
Mouse radio range max. 10 m
Channels 78
Speed max. 1 Mbps (GFSK) / 256 kbps (DSSS)
Power supply mouse 2 AA batteries, max. 3.3V
Power consumption mouse max. 9 mA at 3.6 V

Receiver

Receiver type USB Mini stick receiver
Receiver tech info Conform to USB 1.1 and 2.0
Power consumption receiver max. 12 mA at 5 V

Dimensions / Weight / Environmental

Dimensions (W x D x H) 507 x 222 x 77 mm
Height Adjustment 1.5° and 5.5°
Weight 1500 g
Operating ambient temperature 0 - 40 °C

Compliance

Europe CE
Compliance link http://globalsp.ts.fujitsu.com/sites/certicates

System requirements

Required interface USB
