Fujitsu LT P-600 User Manual

User’s Guide

Guide de I’utilisateur

Benutzerhandbuch

Manual del Usuario

Manuale Utente

User’s Guide

Guide de I’utilisateur

Benutzerhandbuch

Manual del Usuario

Manuale Utente

Fujitsu PC Corporation has made every effort to ensure the accuracy and completeness of this document; however, because ongoing development efforts are made to continually improve the capabilities of our products, we cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes her ein.

Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu Limited.

Stylistic LT P-600 is a trademark of Fujitsu PC Corporation.

IBM, IBM PC AT, and IBM PS/2 are registered trademarks of IBM Corporation.

Kensington and MicroSaver are registered trademarks of the Kensington Technology Group.

PCMCIA and CardBus are registered trademarks of the Personal Computer Memory Card International Association.

Intel and Pentium are registered trademarks of Intel Corporation.

Microsoft is a registered trademark of Microsoft Corporation. Windows 98 and Windows 2000 are trademarks of Microsoft Corporation.

All other trademarks mentioned herein are the property of their respective owners.

Copyright 2001 - Fujitsu PC Corporation. All rights reserved. No part of this publication may be copied, reproduced, or translated, without the prior written consent of Fujitsu PC Corporation. No part of this publication may be stored or transmitted in any electronic form without the prior consent of Fujitsu PC Corporation.

Stylistic LT P-600 User’s Guide - FPC58-0536-01

DECLARATION OF CONFORMITY

according to FCC Part 15

Responsible Party Name: Fujitsu PC Corporation

Address: 5200 Patrick Henry Drive

Santa Clara, CA 9505 4

Telephone: 408-982-9500

Declares that product: Model: Stylistic LT P-600,

FPC1701ATS FPC1701AVS

Complies with Part 15 of the FCC Rules

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

For more detailed information about the FCC rules and their applicability to the Stylistic LT P-600 pen tablet, refer to Appendix C of this document.

Stylistic LT P-600 Pen Tablet

Table of Contents

GETTING STARTED Getting to Know Your Pen Tablet

In-box Items for the

Stylistic LT P-600 Pen Tablet . . . . . . . . . . . . . . 1

Optional Accessories . . . . . . . . . . . . . . . . . . . . . .2

Stylistic LT P-600 Pen Tablet Features . . . . . . . . . 3

Status Display . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Connectors and Peripheral Interfaces . . . . . . . . . 8

USING THE STYLISTIC LT P-600

System States . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Powering Up the Pen Tablet . . . . . . . . . . . . . . .14

Shutting Down the System . . . . . . . . . . . . . . . . 15

Suspending System Operation . . . . . . . . . . . . . .15

Resuming System Operation . . . . . . . . . . . . . . .17

Using Hotpads . . . . . . . . . . . . . . . . . . . . . . . . . 17

Using the Pen . . . . . . . . . . . . . . . . . . . . . . . . . .20

Using Hovering Mode . . . . . . . . . . . . . . . . . . . . 21

Charging the Battery Pack . . . . . . . . . . . . . . . . . 22

Removing and Installing the Battery Pack . . . . . 23

Tips for Conserving Battery Power . . . . . . . . . . 24

Modem Connection . . . . . . . . . . . . . . . . . . . . . 25

PC Card Slot . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Compact Flash Slot . . . . . . . . . . . . . . . . . . . . . .26

Changing the BIOS . . . . . . . . . . . . . . . . . . . . . . 27

Troubleshooting Your Stylistic

System Will Not Resume Operation . . . . . . . . . 33

Display Screen Is Blank or Difficult to Read . . . . 33

Cursor Is Not Tracking Pen . . . . . . . . . . . . . . . . 33

Infrared Data Transfer Is Not Working . . . . . . . 33

Pen Tablet Is Not Responding to the Pen . . . . . 34

Audio Volume Too Low . . . . . . . . . . . . . . . . . . 34

Configuring Peripherals Interfaces . . . . . . . . . . . 34

APPENDIX A

HARDWARE SPECIFICATIONS

Stylistic LT P-600 Specifications . . . . . . . . . . . . 37

APPENDIX B

DIGITIZER TECHNOLOGY NOTICE

Additional Display Information . . . . . . . . . . . . . 43

APPENDIX C

AGENCY NOTICES

FCC Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

DOC (Industry Canada) Compliance Notices 50

CARE AND MAINTENANCE Caring for Your Stylistic LT P-600

Protecting the Display Screen . . . . . . . . . . . . . . 31

Storing the Stylistic LT P-600 Pen Tablet . . . . . . 32

Avoiding Overheating . . . . . . . . . . . . . . . . . . . .32

Stylistic LT P-600 Pen Tablet - Table of Contents

Getting Started

Stylistic LT P-600 Pen Tablet - Chapter One

Getting Started

Getting to Know Your Stylistic LT P-600

The Stylistic™ LT P-600 pen tablet is a high-performance, pen-based computer that is designed to work with Microsoft® Windows® 98 or Windows 2000. This chapter provides an overview of the Stylistic LT P-600 pen tablet and its features.

In-box Items for the Stylistic LT P-600 Pen Tablet 0

The following items are included with the Stylistic LT P-600 pen tablet:

• Stylistic LT P-600 pen tablet

• Stylistic LT P-600 pen

• Stylistic LT P-600 battery pack

• AC adapter (with country-specific power cord)

• Screen protectors (quantity: 2)

• Certificate of Authenticity for operating system software

• Stylistic LT P-600 Warranty Card

Stylistic LT P-600 Pen Tablet - Chapter One

Optional Accessories 0

The following optional accessories can be used with the Stylistic LT P-600 pen tablet. Refer to the instructions provided with these accessories for details on their use.

Peripheral/Accessory Fujitsu Part Number

Stylistic LT P-600 mini-dock FPCPR25

Stylistic LT P-600 portfolio case FMWCC45

Stylistic LT Series slipcase FPCCC14

Stylistic LT Series holster FMWCC34

External floppy disk drive FPCFDD02

Mobile USB keyboard (US) FMWKB5A, (UK) FMWKB5B,

(FR) FMWKB5F, (GR) FMWKB5D, (IT) FMWKB5E

Infrared keyboard (US) FMWKB4A, (UK) FMWKB4B,

(FR) FMWKB4F, (GR) FMWKB4D

Auto adapter FPCAA03

VGA Out Adapter FMW43VA1

Serial Adapter FMW43SA1

Compact Desk Stand FMWDS4

AC adapter FPCAC23

Stylistic LT Series battery pack (spare, 6-cell) FPCBP48

Stylistic LT Series external battery charger FMW51BC1

Screen protectors (package of 12) FMWSP11

Stylistic pens (package of 5) FMW29PN1

Getting Started

Stylistic L T P-600 Pen Tablet Features 0

Features and controls that you use to operate the Stylistic LT P-600 pen tablet are described briefly below and illustrated in Figures 1-1 and 1-2. Details on using these features and controls are provided later in this manual.

Kensington Lock Slot

Microphone

System Status LEDs

Speaker

Infrared I/O Port

Headphone Jack

Microphone Jack

Infrared Keyboard Port

Cooling Vents

Suspend/Resume Button

Hotpad Area

Pen Holder

Figure 1-1 Stylistic LT P-600 Pen Tablet Features (Front View)

Front / Top / Left Features:

• Infrared keyboard port: The infrared port wraps around the front and bottom of the display, and

†

is used for communicating with a proprietary infrared keyboard.

• System status LEDs: Indicate the operational status of the pen tablet and hard disk drive, the

charge level of the battery, and the status of the hovering mode.

• Microphone: Allows you to record voice memos.

• Hotpads: Contains several keys that allow you to change settings for the display brightness and

speaker volume, and to allow emulation of a right mouse button. The hotpads also let you select hovering mode and to Save-to-Disk by tapping with the pen.

• Pen: The main pointing device that you use to execute programs and enter data. A pen holder is

built into the pen tablet to store the pen when not in use.

• Kensington™ lock slot: Allows you to attach a Kensington MicroSaver

†

cable.

-compatible security

Stylistic LT P-600 Pen Tablet - Chapter One

• Speaker: Allows you to play back audio files without external hardware.

• Headphone Jack: Allows you to connect a set of headphones.

• Microphone Jack: Allows you to connect an external microphone.

• Infrared I/O port: Provides an infrared interface for communication with devices compliant with

IrDA Standard Revision 1.1.

• Suspend/Resume button: Allows you to suspend and resume pen tablet operation in order to

optimize battery life.

• Cooling vents: Provides secondary cooling for processor. (These vents should not be obstructed.)

Cooling Vents

Reset Button

Memory Cover

Battery

Release

Switch

Charging Mini-dock Interface Contacts

(under cover)

Cooling Vents

DC Input Connector

Compact Flash Slot

PCMCIA Card Slot

USB Port A (under cover)

Modem Port

Battery Pack

(under cover)

Figure 1-2 Stylistic LT P-600 Pen Tablet Features (Rear View)

Rear / Bottom / Right Features:

• DC input connector: Allows you to connect the AC adapter or auto adapter.

• Modem port: Allows you to connect a standard RJ-11 connector to the pen tablet’s internal 56

Kbps modem.

Note: The port for the LAN element of the internal LAN/Modem module is available on the

†

optional mini-dock.

• USB port A: Allows you to connect Universal Serial Bus-compliant devices to the pen tablet. USB

port B is located on the optional mini-dock.

†

These peripherals and accessories are sold separately.

†

Getting Started

• PCMCIA Card Slot: Allows you to install PC Cards in the system.

†

• Charging contacts: Allows you to charge the battery pack and supply power to the Stylistic LT P-

600 in an optional mini-dock.

†

• Mini-dock interface: Allows you to install the Stylistic LT P-600 in an optional mini-dock† for

enhanced connectivity

• Reset button: Allows you to reset the system in the event of system difficulty. Note that pressing

this button results in loss of active data.

• Battery release switch: Used to release the removable battery pack.

• Compact flash slot: Used to accommodate a compact flash card.

• Memory cover: Removable cover over the RAM chips.

• Removable battery pack: Can be removed and charged in an optional external charger.

†

• Cooling vents: Provide secondary cooling for processor. (Do not obstruct the vents.)

†

These peripherals and accessories are sold separately.

Status Display 1

Icons appear in the Status display indicating the status of system functions such as system power and battery charge level. The location of icons in the Status display is shown in Figure 1-3.

Power

Charge/DC In

Battery

HDD Access

Hovering

Figure 1-3 Status Display Icons

Table 1-1 explains how individual icons are displayed, and describes what the variations of that display indicate. (If an icon is not displayed, it indicates that the related system function is off or inactive.

Stylistic LT P-600 Pen Tablet - Chapter One

Note: In the following table, a “blinking” LED flashes at the rate of once per second; an LED that is

“blinking, slow” flashes at the rate of one second on, five seconds off.

Table 1-1 System Status Indicators

Icon Mode/State LED State Remarks

Power

Charge/DC Input

• On State

Green (continuous)

• Idle Mode

• Suspend-to-RAM Green

(blinking)

• Off State

Off

• Save-to-Disk

• On State

Green • AC adapter and battery pack are

• Idle Mode

• Suspend-to-RAM

• Save-to-Disk

Amber AC adapter and battery pack are

• Off State

Amber (blinking)

Off AC adapter is not available.

available and system is not charging (battery fully charged).

• AC adapter is available but battery pack is not present.

available and system is charging.

AC adapter and battery pack are available and waiting to charge (battery pack is out of thermal range).

Table 1-1 System Status Indicators

Getting Started

Battery • On State

• Idle Mode

• Suspend-to-RAM

with AC adapter

• Save-to-Disk, with AC adapter

• Off State

• Suspend-to-RAM,

without AC adapter

• Save-to-Disk, without AC adapter

• Off State

HDD

• On State Green Displayed when hard disk drive is

Access

Green (continuous)

Amber

(continuous)

Red (continuous)

Red

Battery pack charge is between 100%50%

Battery pack charge is between 49%13%

Battery pack charge is between 12%0%

There is a battery error.

(blinking)

Off Battery pack is not installed.

Green (blinking slow)

Amber (blinking slow)

Red (blinking slow)

Battery pack charge is between 100%50%.

Battery pack charge is between 49%13%.

Battery pack charge is between 12%0%.

Off If battery is inserted during power off,

LED blinks amber for 4 seconds to detect battery. Battery status is displayed for 5 seconds after that.

accessed.

• Suspend-to-RAM

• Save-to-Disk

• Idle Mode

• Off State

Hovering • On State

(Hovering enabled)

• On State (Hovering disabled)

• Suspend-to-RAM

• Save-to-Disk

• Off State

Off Hard disk drive is not being accessed.

Green Hovering mode is enabled

Off Hovering mode is disabled.

Off Not available when system is in

Suspend-to-RAM, Save-to-Disk, or Off state.

Stylistic LT P-600 Pen Tablet - Chapter One

Connectors and P erip heral Inte rfac es 1

Connectors and peripheral interfaces on the Stylistic LT P-600 pen tablet allow you to connect a variety of devices. Specific interface locations are illustrated in Figure 1-4, Figure 1-5, and Figure 1-6.

DC Input

PC Card Eject Button

PC Card Door

Compact Flash Slot

Compact Flash Eject Button

USB Port

Figure 1-4 Right-Side Connectors and Interfaces

Headphone

Jack

Modem Port

Microphone Jack

Cooling Vents Cooling Vents

Infrared Keyboard Port

Speaker

Infrared I/O Port

Figure 1-5 Left-Side Connectors and Interfaces

Charging Contacts

Mini-dock Interface Cover

Figure 1-6 Bottom Connectors and Interfaces

Getting Started

Table 1-2 provides a description of each peripheral connector on the Stylistic LT P-600 pen tablet. Each of the illustrated icons is printed on the pen tablet case.

Table 1-2 Peripheral Connectors/Interfaces

Connector/

Peripheral

DC input connector

Fig. Ref.

Pen Tablet Icon Purpose

1-4 Connect an external power source such as the AC

adapter or auto adapter.

USB Port 1-4 Connect Universal Serial Bus-compliant devices to

the pen tablet. USB (B) port is located on the optional Stylistic LT P-600 mini-dock.

PCMCIA

1-4

Install a Type I or Type II PC Card.

CardBus slot

Microphone jack

1-5 Connect an external microphone. The internal

microphone is disabled when you plug in an external microphone.

Headphone jack

1-5 Connect stereo headphones or powered external

speakers. The internal speaker is disabled when you plug in external headphones or speakers.

IrDA/FIR port 1-5 An infrared transceiver built into the pen tablet

allows you to communicate with other devices that are compliant with the IrDA Standard Rev. 1.1. Effective range for infrared communication is about 3 feet, and within 15 degrees off of center. A clear line-of-sight path must exist between the IrDA port on the pen tablet and the IrDA transceiver on the other device.

Modem 1-4 Connect a telephone line to the optional internal

modem using a standard RJ-11 telephone plug.

Charging Contacts

Mini-dock

†

port

1-6 Install the pen tablet in an approved docking

device. The contacts provide DC input.

1-6 Connect the Stylistic LT P-600 mini-dock. Refer to

the documentation accompanying the docking device for more information.

Stylistic LT P-600 Pen Tablet - Chapter One

Table 1-2 Peripheral Connectors/Interfaces

Connector/

Peripheral

Infrared keyboard port

Fig. Ref.

Pen Tablet Icon Purpose

1-6 An infrared receiver built into the pen tablet allows

you to communicate with a wireless infrared keyboard. The keyboard infrared port works optimally between 10 to 30 cm (approximately 4 in. to 12 in.) from the keyboard infrared port, located on the bottom edge of the pen tablet. Ensure that there is a clear line-of-sight path between the infrared receiver on the pen tablet and the infrared transmitter on the keyboard.

Compact Flash Slot

1-4 CF CARD Install a compact flash card to expand system

memory.

† Remove the mini-dock interface cover to access this port.

In addition to the connector and interface icons, there are a number of icons that illustrate component orientation and buttons. These icons are illustrated in Table 1-3.

Table 1-3 Additional System Icons

Icon Description

Battery Indicates the location of the removable

Icon

Illustration

Purpose

battery cover.

Battery Release Switch Indicates the battery release button.

Suspend/Resume (Power On) Button

Indicates the Suspend/Resume button. This button can be reconfigured as a Power On button through the BIOS.

Shut Off Button No icon Powers down the system in the event of

system difficulty. Use the tip of your stylus to press this button.

Using the Stylistic LT P-600 Pen Tablet

Stylistic LT P-600 – Chapter Two

Using the Stylistic LT P-600

Using Your Stylistic LT P-600

This chapter covers the fundamental concepts, basic system operation and use, and system functions of the Stylistic LT P-600 pen tablet. You should familiarize yourself with this information before you attempt to operate the system.

System States 1

Before you begin using the Stylistic LT P-600 pen tablet, review the different system states (or modes) that the pen tablet can use. Being familiar with these system states will help you to determine whether it is appropriate to turn on, resume, suspend, or shut down the system when you begin a new session or end your current session. System behavior for each system state is described briefly in the following, with each system state listed in decreasing order of power usage:

• On state

The system is running and the display screen is on.

• Idle state

Some system functions are regulated or turned off to conserve power. The display screen may be turned off. The system returns to the On state when pen activity or other input is detected.

• Suspend-to-RAM mode

System operation is suspended. Most system functions are turned off to conserve power. Power to memory is on, maintaining data in programs that were running before system operation was suspended. The system does not respond to the pen or other input when in Suspend-to-RAM mode. Refer to the “Resuming System Operation” section later in this chapter for information on returning the system to the On state.

• Save-to-Disk mode

System operation is suspended. All system functions are turned off to conserve power. Active data in programs that were running before suspending system operation is stored on the hard disk drive. The system does not respond to the pen or other input. Refer to the “Resuming System Operation” section later in this chapter for information on returning the system to the On state.

• Off state

All system functions are turned off to conserve power. The system does not respond to the pen or other input. The system boots at the next system power-on.

Note: The system consumes the same amount of power whether it is in Save-to-Disk mode or the Off

state.

Your system may be configured to enter some of these states automatically after a period of inactivity to conserve battery power.

When you use the Stylistic LT P-600 pen tablet, you can change the current system state in a number of ways, depending on which state the system is in. To determine the current system state, observe the Power icon in the Status display. Table 2-1, “Changing System States,” on page 14 gives the different system states represented by the Power icon and describes how you can change the system state from the current state.

Stylistic LT P-600 Pen Tablet - Chapter Two

Table 2-1 Changing System States

Power Icon Appearance Current State

Power icon displayed continuously

Power icon blinking

Power icon not displayed

* Information in Table 2-1, “Changing System States,” on page 14 is supplied to help you understand

which system states your system can enter from the current system state. Refer to the procedures on starting the system, shutting down the system, suspending system operation, and resuming system operation given later in this chapter.

†

Your system may be configured to use either Suspend-to-RAM mode or Save-to-Disk mode.

On State or Idle State

Suspend-to-RAM or Standby

Off State or

Save-to-Disk

†

To enter the Off state, shut down the system using the Start menu on your system.

To enter Suspend-to-RAM or Save-to-Disk state, suspend system operation using either a hardware or software suspend.

†

To enter the On state, resume system operation by pressing the Suspend/Resume button.

To enter the Off state, resume system by pressing the Suspend/Resume button, then shut down your system.

To enter the On state, start your system, or resume system operation by pressing the Suspend/Resume button.

To Change State

†

Powering Up the Pen Tablet 1

Follow the procedure below to start the Stylistic LT P-600 pen tablet. Before you begin, confirm that the system is in the Off state. To do so, observe the Status display. If the Power icon is not visible in the Status display, the system is in the Off state or in Save-to-Disk mode and it is safe to perform this procedure. If the Power icon is visible (either blinking or on continuously), do not perform this procedure. See “System States” earlier in this chapter for details on operational modes represented by the Power icon.

1. Ensure that the battery pack in your pen tablet is sufficiently charged, or connect an external power source such as the AC adapter or auto adapter to your pen tablet. See “Status Display” in Chapter 1 to determine the percentage of charge represented by the Battery Gauge icon in the Status display.

2. Press the Suspend/Resume button to start the system.

After performing system initialization, the system starts the operating system installed on the hard disk drive. Once the operating system is running, you can use the system.

Using the Stylistic LT P-600

Shutting Down the System 1

Follow these steps to shut down and turn off your system:

Note: Always use the following procedure unless your system has frozen up and will not allow

normal shutdown. If you need to shut down after your system freezes up, click the recessed Shut Off button located on the back of the system. Do not use the Shut Off button as your normal means of powering down the system; when the Shut Off button is used, all active data is lost.

1. If system operation has been suspended, resume system operation. (See Table 2-1 and “Resuming System Operation” later in this chapter for details.)

2. Save your work and close all running programs.

3. Choose Shut Down from the Windows Start menu and carry out the Shut Down command. The system is now in the Off state.

Suspending Syste m Oper ation 1

The Stylistic LT P-600 pen tablet allows you to suspend the system operation without closing programs or exiting the operating system. Use this feature to conserve battery power when a system shutdown is not practical or when the battery needs to be changed.

To suspend system operation:

1. Press the Suspend/Resume button, or carry out the Standby command from your operating system or power management program. (If your system is configured to suspend operation using Save-to-Disk mode, which is explained later in this procedure, a message is displayed while data

is saved to your hard disk.)

CAUTION

If you are replacing the battery pack, wait until system is off or system operation is suspended and the power icon is flashing before you remove the battery pack. Failure to do so could result in loss of your unsaved data.

The Power icon either flashes (Suspend-to-RAM) or is not displayed (Save-to-Disk) when system operation is suspended, depending on how your system is configured. At this point, programs that were running are stopped, active data is saved, and the system enters one of two different low-power states, or suspend modes, as explained in the following paragraphs.

2. Observe the Power icon in the Status display to determine which suspend mode your system is using.

• Power icon is blinking: Suspend-to-RAM mode

In this mode, active data is saved by maintaining power to RAM while most other system components are powered off. The Battery Gauge icon in the Status display indicates the battery charge level.

Stylistic LT P-600 Pen Tablet - Chapter Two

• Power icon is not displayed: Save-to-Disk mode

In this mode, active data is stored on the hard disk drive and power usage is reduced to the same level used in the Off state. When the system is in Save-to-Disk mode, the Battery Gauge icon is not visible in the Status display. In this mode, there is no danger of losing data if battery power is lost.

If you have successfully performed this procedure, system operation is now suspended. Refer to “Resuming System Operation” later in this chapter to resume system operation. Also, note the following with regard to suspending system operation:

CAUTIONS

• If the battery goes dead while the system is in Suspend-to-RAM mode, data loss could occur. If the system will be in Suspend-toRAM mode for an extended period of time, be sure to have a fully charged battery installed.

• The system is supported by a bridge battery for approximately five minutes while the main battery is being replaced. Be sure to replace the main battery quickly or use the AC Adapter when replacing the battery.

• You can remove the battery pack while the system is in Suspend-to-RAM or Save-to-Disk modes in order to install a charged battery pack. To prevent losing unsaved data, wait until system operation has suspended before you remove the battery pack.

• Your system may be configured to suspend operation automatically after a period of inactivity.

• Your system may be configured to enter Save-to-Disk mode automatically after a period of time

in Suspend-to-RAM mode.

• The system uses a small amount of battery power when in Suspend-to-RAM mode. Eventually, the battery will become fully discharged.

Note: If you will not be using the system for an extended period of time, shut down the system rather

than using Suspend-to-RAM mode.

• If the battery pack charge drops to a Low-Battery Warning level while the system is running, the system will beep periodically. If this occurs, suspend system operation, shut down the system, or attach an external power source, such as the AC adapter, to the pen tablet.

• If the battery charge drops to a Critically Low level while the system is running, the system is forced into a pre-selected mode (Suspend-to-RAM or Save-to-Disk). If this occurs, you must either install a charged battery pack, or connect an appropriate external power source such as the AC adapter before you can resume system operation. (If the battery charge drops to a Critically Low level while the system is in Suspend-to-RAM mode, the system stays in Suspend-to-RAM mode until power is restored or totally dissipated.)

• Suspending system operation interrupts data communications; therefore, some programs may block the system from suspending to prevent an interruption.

• The suspend action of the Suspend/Resume button may be disabled to prevent accidental

Using the Stylistic LT P-600

interruption. If this is the case, pressing the Suspend/Resume button will not suspend system operation as described here. (In this case, suspend mode can only be achieved using the system software). Contact your local help desk or reseller if your system configuration is not suitable.

• If your system is equipped with a PC Card that allows you to connect to a wired or wireless network, you may be logged off the network after a period of inactivity while system operation is suspended. Contact your network administrator or local help desk for details on log-off parameters for your network.

Resuming System Operation 1

To resume system operation, (from either Suspend-to-RAM or Save-to-Disk modes), press the Suspend/Resume button.

• From Suspend-to-RAM mode Status lights indicate that the system state is changing. It may take up to a minute before the system returns to the On state and system operation resumes. Note that the display turns on shortly before the pen becomes active due to the power-up sequences observed by the system.

• From Save-to-Disk mode Active data is read from the hard disk drive, and the system returns to the On state after a short period of time.

Note that power to several system components must be restored before system operation resumes. Allow sufficient time for system operation to resume before attempting to use the system. If your system uses Save-to-Disk mode, it will take longer to resume operation as compared to using Suspend-to-RAM mode. Time is needed to read data from the hard disk drive.

• Use the system as you normally would once system operation resumes.

All programs resume at the point where execution stopped when system operation was suspended.

Using Hotpads 1

The Hotpad area consists of several pen-active “keys” on the right side of the system display that you can use to change several settings. The hotpads allow you to:

• Adjust the display and speaker settings

• Invoke right mouse button

• Invoke hovering capability

• Use as a numeric pad

• Use as a NumLock key

To use a hotpad key, tap directly on it with the pen. You can also press and hold the pen tip against the Volume and Brightness hotpad keys to automatically repeat the hotpad function. The location of each hotpad key is shown in Table 2-1, “Stylistic Hotpad Arrays,” on page 18.

Stylistic LT P-600 Pen Tablet - Chapter Two

Display Key

Brightness

Figure 2-1 Stylistic Hotpad Arrays

A summary of each hotpad’s function is given below.

Escape

Mouse

Right

Button

Key

Keys

ESC

7 456

123 0

SPACE

BSTAB

NumLock Key

Cursor Keys

Numeric Keys

Hovering Key

Speaker Keys

Note: Equivalent key codes are included for applicable hotpad keys. These can be used when a

keyboard is connected.

Table 2-2 Hotpad Keys

Icon Name Description

Escape Functions the same as the [Esc] key on a typical

ESC

keyboard.

Display Each time the Display Device hotpad key is tapped,

the display unit is switched (in the following order): LCD -> CRT -> both LCD and CRT -> LCD... External video is available from the docking station.

NumLock Acts in the same way as the NumLock key on the

keyboard. (The default is Off).

Using the Stylistic LT P-600

Table 2-2 Hotpad Keys

Icon Name Description

Cursor Control Acts in the same way as the cursor keys on a

keyboard. (Up, Down, Left, and Right).

Numeric Keypad Acts in the same way as the numeric keypad on a

BSTAB

keyboard. (Note that "BS" signifies "Backspace")

998877 654 321

SPACE

Right Mouse Button Switches the pen function from left mouse button to

right mouse button emulation for a single mouse event after tapping the hotpad.

Pen Hovering Switches the hovering mode on or off. Throughout

the hovering mode, the hovering status indicator is lit green. Refer to the section of this chapter entitled “Using Hovering Mode” for additional information.

Speaker Volume Down Decreases the speaker volume.

Speaker Volume Up Increases the speaker volume.

Speaker Volume Mute Toggles the speaker off and on.

Brightness Down Decreases the luminance of the display backlight.

(Changes in brightness level can be monitored with the on-screen indicator)

Brightness Up Increases the luminance of the display backlight.

(Changes in brightness level can be monitored with the on-screen indicator)

Stylistic LT P-600 Pen Tablet - Chapter Two

Using the Pen 1

You can use the Stylistic LT P-600 pen to generate and create electronic “ink”, to select items, and to navigate through programs on the pen tablet. The pen can be used like a two button mouse when used in conjunction with the right-mouse button hotpad. Programs which support handwriting recognition allow you to write characters directly on the screen with the pen and then translate your printed text into keyboard-style input.

CAUTIONS

• Ensure that a screen protector is installed on the pen tablet screen before you use the pen. The warranty does not cover a screen that is scratched as a result of not using a screen protector.

• Use only the pen stylus provided with your pen tablet. Do not use substitutes that were not designed for the Stylistic LT P-600.

To toggle between using the pen for inking and using it as a mouse, click on the small pen icon in the system tray at the bottom right of the screen.

Here are some hints on using the pen like a two-button mouse on a desktop system:

• To select an object, tap the mouse tip on the object once. This functions like a mouse button click

with the left mouse button.

• To “double-click” an object, tap twice on the object quickly.

• To ge n er ate a “right mouse button single-click”, tap on the hotpad icon once and then tap once

on the display. To generate a “right mouse button double click”, tap on the hotpad icon once and then double tap on the display.

• To mo ve, o r “drag”, an object on the screen, place the pen tip directly over the object, then as you

hold the pen tip against the screen, move the pen.

Calibrating the pen 1

Calibration of the pen adjusts the cursor position on the screen relative to the position of the pen tip. You calibrate the pen to adjust the distance error between where the pen actually touches the screen and where the system “thinks” the pen is touching. If the event you wish to invoke is not displayed under the pen tip when you use the pen, you should calibrate the pen.

Pen calibration may be required due to the following situations:

• The pen is being used for the first time.

• The previous user of the Stylistic LT P-600 pen tablet writes with the opposite hand or at a

different pen angle.

• The system has been in use for some time and the pen has not been recalibrated.

• The original system image has been restored.

+ 250 hidden pages
