Specifications
Model Name LPF-7200 LPF-7205
Liquid Crystal Display Panel 1.3 inches Polysilicon TFT LCD x 3 with micro lens array
Number of Pixels 1024(H) x 768(V) pixels
Projection Lens F=1.8-2.15 with Lens shift
Projection Size 36 to 300 inches
Lamp 250W NHS Lamp
Screen Luminance 2800 ANSI Lumens
Uniformity Over 80%
Contrast Ratio Over 300:1
Connectable PC XGA(real), VGA, SVGA, SXGA(resizing), UXGA (Compression)
Video System NTSC, PAL, SECAM, N-PAL, M-PAL, 4.43 NTSC
Digital RGB DVI digital 24 pin x 1
Input 1
(selectable) Analog RGB HD D-sub 15 pin x 1
Input 2 Analog RGB HD D-sub 15 pin x 1
Input 3 RGB/DVD
BNC (5) x 1 (R/Cr/Pr, G/Y, B/Cb/Pb, H, V)
Video RCA pin, S-terminal
Input
Terminal
Audio
Stereo mini jack x 3 (RGB), RCA (L/R) pin x 1 (Video)
Analog RGB HD D-sub 15 pin x 1
Output Terminal
Audio Stereo mini jack x 1
Sound Output 3W + 3W Stereo Speakers
RS-232C 9 pin D-Sub x 1
Remote Control
Mouse PS/2 Mini DIN 8 pin x 1, USB x 1
Power Supply AC100-240V 50/60Hz
Power Consumption 380W
Dimensions
282(W) x 150(H) x 429(D)mm [11.0"(W) x 16.8"(H) x
5.8"(D)]
Weight
7.8kg [17.2lbs]
6.9kg [15.2lbs]
Remote Control, Lens Cap, RGB Cable, Users Manual, Mouse
Cable (PS/2)
Accessories
Video Cable, Air Filter, Power Cable, Batteries
Option Lamp Box, Cable for Wired remote control
* Specifications and design subject to change without notice for further improvement.
Projection Distance and Screen Size
Size (Inch) 60 80 100 150 200 250
300
L(m) 2.1 2.9 3.6 5.4 7.3 9.1
10.9
Projection Distance
L(Ft) 6.9 9.5 11.8 17.7 24.0 29.9
35.8
