Fujitsu LifeBook T901 User Guide

Fujitsu LIFEBOOK

FUJITSU AMERICA, INC.

T Series

BIOS Guide

LIFEBOOK T Series Model:

T901

Document Date: 5/20/2011

Document Part Number: FPC58-2902-01

LIFEBOOK T901 BIOS

[ ], [ ].

[ ], [ ].

T Series BIOS

BIOS SETUP UTILITY

The BIOS Setup Utility is a program that sets up the
operating environment for your notebook. Your BIOS
is set at the factory for normal operating conditions,
therefore there is no need to set or change the BIOS
environment to operate your notebook.

The BIOS Setup Utility configures:

• Device control feature parameters, such as changing

I/O addresses and boot devices.

• System Data Security feature parameters, such as

passwords.

Entering the BIOS Setup Utility

To enter the BIOS Setup Utility, do the following:

1. Turn on or restart your notebook.

2. Press [F2] once the Fujitsu logo appears on the
screen. This will open the main menu of the BIOS
Setup Utility with the current settings displayed.

3. Press the [RIGHT ARROW] or [LEFT ARROW]
key to scroll through the other setup menus to
review or alter the current settings.

Navigating through the Setup Utility

The BIOS setup utility consists of six menus: Info,
System, Advanced, Security, Boot, and Exit. This docu­ment explains each menu in turn, including all
submenus and setup items.

The following procedures allow you to navigate the
setup utility menus:

1. To select a menu, use the cursor keys:

2. To select a field within a menu or a submenu, use

the cursor keys:

3. To select the different values for each field, press the
[Spacebar] or [+] to change to the next lower
selection and [F5] or [-] to go to the next higher
selection.

4. To activate a submenu press the [Enter] key.

5. To return to a menu from a submenu, press the [Esc]
key.

6. To go to the Exit menu from any other menu, press
the [Esc] key.

 Selecting a field causes a help message

about that field to be displayed on the
right-hand side of the screen.

 Pressing the Enter key with the highlight

on a selection that is not a submenu or
auto selection will cause a list of all
options for that item to be displayed.
Pressing the Enter key again will select
the highlighted choice.

7. Pressing the [F9] key resets all items in the BIOS to
the default values.

8. Pressing the [F10] key saves the current configura­tion and exits the BIOS Setup Utility. You will be
asked to verify this selection before it is executed.

9. Pressing the [F1] key gives you a general help
screen.

Entering the Setup Utility After a Configuration Change or System Failure

If there has been a change in the system configuration
that does not agree with the parameter settings stored in
your BIOS memory, or there is a failure in the system,
the system beeps and/or displays an error message after
the Power On Self Test (POST). If the failure is not too
severe, it will give you an opportunity to modify the
setup utility settings, as described in the following steps:

1. When you turn on or restart the computer there is a
beep and/or the following message appears on the
screen:

Error message - please run SETUP
program Press <F1> key to continue,
<F2> to run SETUP

2. If an error message is displayed on the screen, and
you want to continue with the boot process and start

the operating system anyway, press the [F1] key.

 If your notebook emits a series of beeps

that sounds like a code and the display is
blank, please refer to the Troubleshoot­ing Section in the system User’s Guide.
The Troubleshooting Section includes a
list of error messages and their meanings.

 If your data security settings require it,

you may be asked for a password before
the operating system will be opened.

2

3. If an error message is displayed on the screen, and
you want to enter the setup utility, press the [F2]
key.

4. When the setup utility starts with a fault present, the
system displays the following message:

Warning!

Error message

[Continue]

5. Press any key to enter the setup utility. The system
will then display the Info Menu with current param­eters values.

Info Menu

3

LIFEBOOK T901 BIOS

INFO MENU - DISPLAYS BASIC SYSTEM INFORMATION

The Info Menu is a display only screen that provides the
configuration information for your notebook.

The following table shows the names of the menu fields
for the Info menu and the information displayed in those

Phoenix SecureCore(tm) Tiano Setup

Info System Advanced Security Boot Exit

Product Name: LIFEBOOK T901

Serial Number: XXXXXXXX
BIOS Version: X.0X (XX/XX/2011)

Processor Type: Intel(R) Core(TM) i7-2620M CPU @ 2.70GHz

Total Memory: 2048 MB
Memory Slot 1: 2048 MB DDR3 SDRAM
Memory Slot 2: None

Onboard MAC Address: XX-XX-XX-XX-XX-XX
UUID: XXXXXXXX-XXXX-XXXX-XXXX-XXXXXXXXXXXX

fields. These fields are for information purposes only,
and cannot be modified by the user.

The information, including CPU type and
speed, and total memory, displayed on this
screen varies according to the unit you
purchased.

F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values
Enter Select ► Sub-Menu

Figure 1. Info Menu

F9 Setup Defaults
F10 Save and Exit

Table 1: Fields, Options and Defaults for the Info Menu

Menu Field Default Menu Field Default

Note that all of the fields on this screen are display only and are for reference.
Note that the parameters listed may be different for your system, depending upon the system configuration.

Product Name: LIFEBOOK T901 Memory Slot 1: 2048 MB DDR3 SDRAM

Serial Number: XXXXXXXX Memory Slot 2: None

BIOS Version: 1.0 (XX/XX/2011 Onboard MAC Address: XX-XX-XX-XX-XX-XX

Processor Type: Intel(R) Core(TM) i7-2620M CPU

Total Memory: 2048 MB

4

@ 2.70GHz

UUID: XXXXXXXX-XXXX0XXXX-

XXXXXXXXXXXX

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values
Enter Select Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Info System Advanced Security Boot Exit

Item Specific Help

Adjust calendar clock.

<Tab>, <Shift-Tab>, or
<Enter> selects field.

System Time: [14:57:01]

System Date: [05/20/2011]

Drive Configurations

Language: [English (US)]



System Menu

SYSTEM MENU – SETTING STANDARD SYSTEM PARAMETERS

The System Menu allows you to set or view the current
system parameters. (See Navigating through the Setup

Utility on page 2 for more information.)

The following tables show the names of the menu fields
for the System menu and its submenus, all of the options
for each field, the default settings and a description of

the field’s function and any special information needed
to help understand the field’s use.

System Time and System Date can also be
set from your operating system without
using the setup utility. Use the Date and
Time icon on your Windows Control panel
or type time or date from the MS-DOS
prompt.

Table 2: Fields, Options and Defaults for the System Menu

Note that the parameters listed in the following table may vary depending upon your system’s configuration.

Menu Field Options Default Description

System Time: –— –— Sets and displays the current time. Time is in a 24 hour format

System Date: –— –— Sets and displays the current date. Date is in a month/day/year

Figure 2. System Menu

of hours:minutes:seconds with 2 digits for each. (HH:MM:SS).
Example: 16:45:57. You may change each segment of the time
separately. Move between the segments with the [Tab] key and/or
[Shift] + [Tab] keys.

numeric format with 2 digits each for month and day and 4 digits for
year. (MM/DD/YYYY) for example: 02/20/2011. You may
change each segment of the date separately. Move between the
segments with the [Tab] key and/or [Shift] + [Tab] keys.

5

LIFEBOOK T901 BIOS

Table 2: Fields, Options and Defaults for the System Menu

Note that the parameters listed in the following table may vary depending upon your system’s configuration.

Menu Field Options Default Description

Drive
Configurations

Language:

--- --- Opens the Drive Configurations submenu to allow you to enable or

 English (US)
 Japanese (JP)

[English (US)] The default setting differs between the US/European and the

disable the installed drives.

Japanese model. Selects the display language for the BIOS.

6

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

F9 Setup Defaults
F10 Save and Exit

Change Values
Select Sub-Menu

Item Specific Help

Enable/Disable SATA
Device.

Drive Configurations

Drive0: [Hitachi HTS545016B9A300 - 160GB ]

[Enabled]

Drive2: [MATSHITADVD-RAM UJ8A0AS - ATAPI ]
[Enabled]

Info System Advanced Security Boot Exit



System Menu

Drive Configurations Submenu of the System Menu

The Drive Configurations submenu identifies the installed S-ATA drives and allows you to enable or disable them.

Figure 3. Drive Configurations Submenu

Table 3: Fields, Options and Defaults for the Drive0 Submenu of the System Menu

Menu Field Options Default Description

Drive0:  Disabled

Drive2:

 Enabled

 Disabled
 Enabled

Exiting from System Menu

When you have finished setting the parameters on this menu, you can either exit from the setup utility, or move to
another menu. If you wish to exit from the setup utility, press the [Esc] key or use the cursor keys to go to the Exit

[Enabled] Allows you to enable or disable the hard drive 0.

[Enabled] Allows you to enable or disable the hard drive 0.

menu. If you wish to move to another menu, use the cursor keys.

7

LIFEBOOK T901 BIOS

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

F9 Setup Defaults
F10 Save and Exit

Change Values
Select Sub-Menu

Item Specific Help

Drive Configurations

Info System Advanced Security Boot Exit



Boot Configurations
Keyboard/Mouse Features
Video Features
Internal Device Configurations
CPU Features
USB Features
Miscellaneous Configurations
Intel(R) Management Engine Configurations

Configures Boot
features.












Event Logging

ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS

The Advanced Menu allows you to:

• Set Boot configurations

• Set the keyboard and mouse features.

• Select between the display panel and an external

display.

• Enable or disable the ATA, Bluetooth, LAN,

WLAN, WWAN, internal camera, and Ambient
Light Sensor controllers.

• Configure CPU and USB features in your system.

• Configure a variety of power-saving features.

(See Navigating through the Setup Utility on page 2 for
more information.)

The following tables show the names of the menu fields
for the Advanced Menu and its submenus, all of the
options for each field, the default settings and a descrip­tion of the field’s function and any special information
needed to help understand the field’s use.

Figure 4. Advanced Menu

Table 4: Fields, Options and Defaults for the Advanced Menu

Menu Field Description

Boot Configurations When selected, opens the Boot Configurations submenu, which allows enabling or disabling various Boot

Keyboard/Mouse Features When selected, opens the Keyboard/Mouse Features submenu, which allows setting NumLock parameters.

Video Features When selected, opens the Video Features submenu to allow routing of video signals to different displays.

Internal Device
Configurations

CPU Features When selected, opens the CPU Features submenu to allow you to enable/disable multi-core processing,

8

features.

When selected, opens the Internal Device Configuration submenu, which allows enabling or disabling the
ATA, Bluetooth, LAN, WLAN, IEEE1394, WWAN, and camera controllers, as well as the ambient light sensor.

SpeedStep(R) Technology, Virtualization Technology, and HT Technology (i7, i5, and i3 CPUs only).

Table 4: Fields, Options and Defaults for the Advanced Menu

Menu Field Description

Advanced Menu

USB Features When selected, opens the USB Features submenu to allow you to enable or disable legacy USB devices and

Miscellaneous
Configurations

Intel(R) Management
Engine Configurations

Event Logging When selected, opens the event logging submenu.

SCSI SubClass support.

When selected, opens the Miscellaneous Configurations submenu to allow you to enable or disable the
power button, Wake Up On LAN, Auto Save, and control volume settings.

When selected, opens the Intel(R) Management Engine Configurations submenu to allow you to enable or
disable lntel Anti-Theft Technology Suspend Mode.

9

LIFEBOOK T901 BIOS

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

F9 Setup Defaults
F10 Save and Exit

Change Values
Select Sub-Menu

Item Specific HelpBoot Configurations

Info System Advanced Security Boot Exit



[Disabled]
All diagnostic tests
will be done.

[Enabled]
Some diagnostic tests
may be skipped while
bootong to speed up.

Quick Boot:
Boot Time Diagnostics Screen: [Disabled]

Preboot Execution Environment: [Enabled]

[Disabled]

Boot Configurations Submenu of the Advanced Menu

The Boot Configurations submenu is for setting a variety of Boot features.

Figure 5. Boot Configurations Submenu

Table 5: Fields, Options and Defaults for the Boot Configurations Submenu of the Advanced Menu

Menu Field Options Default Description

Quick Boot:  Disabled

Boot Time
Diagnostic Screen:

Preboot Execution
Environment:

 Enabled

 Disabled
 Enabled

 Disabled
 Enabled

10

[Disabled] When disabled, all of the diagnostic test will be performed during boot up. If

[Disabled] When disabled, the logo screen is displayed during boot up. If enabled, the

[Enabled] When disabled the Preboot Execution Environment is disabled. When enabled,

enabled, certain test may be skipped in order to speed up the booting process.

diagnostic screen is displayed during the boot up.

the boot from network server is enabled.

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

F9 Setup Defaults
F10 Save and Exit

Change Values
Select Sub-Menu

Item Specific Help

Info System Advanced Security Boot Exit



[On] or [Off]
Numlock is On or Off.

[On/Padlock Off]
Numlock is On, but use
with [Fn] fpr 10-key
input.

* Windows XP or later
OS preserves Numlock
state when the user
logs off.

Keyboard/Mouse Features

Numlock:

[Off]

Advanced Menu

Keyboard/Mouse Features Submenu of the Advanced Menu

The Keyboard/Mouse Features submenu is for setting the parameters of the integrated and external mouse and
keyboard.

Figure 6. Keyboard/Mouse Features Submenu

Table 6: Fields, Options and Defaults for the Keyboard/Mouse Submenu of the Advanced Menu

Menu Field Options Default Description

Numlock:  On

 Off

[Off] Sets the NumLock function state when the computer completes booting.

 On/Padlock Off

When [On] or [Off], Numlock is on or off. When On/Padlock Off is selected,
the NumLock feature is on, but only for use with the [Fn] key and 10-key
input.

Windows preserves Numlock state when the user logs off.

11

LIFEBOOK T901 BIOS

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

F9 Setup Defaults
F10 Save and Exit

Change Values
Select Sub-Menu

Item Specific Help

Info System Advanced Security Boot Exit



Select display terminal.

* This setting is not
effective after
operating system
starts up.

Video Features

Display: [Auto]

Video Features Submenu of the Advanced Menu

The Video Features submenu is for setting the display parameters.

Figure 7. Video Features Submenu

Table 7: Fields, Options and Defaults for the Video Features Submenu of the Advanced Menu

Menu Field Options Default Description

Display:  Internal Flat Panel

12

 External (Analog)
 External (DVI)
 External (DisplayPort)
 Auto

[Auto] Determines to which display device the image is sent.

Advanced Menu

Internal Device Configurations Submenu of the Advanced Menu

The Internal Device Configuration submenu allows the user to enable or disable ATA, Bluetooth, LAN, Wireless
LAN, IEEE1394, Wireless WAN, and Internal Camera controllers.

Phoenix SecureCore(tm) Tiano Setup

Info System Advanced Security Boot Exit

Internal Device Configurations

Serial ATA Controller: [Enabled]
AHCI Configuration: [Enabled]
Bluetooth(R): [Enabled]
LAN Controller: [Enabled]
Wireless LAN: [Enabled]
IEEE1394 Controller: [Enabled]
WWAN Device: [Enabled]

Item Specific Help

[Disabled]
Serial ATA port is
disabled.

[Enabled]
Serial ATA port is
enabled.

Internal Camera: [Enabled]
AMbient Light Sensor: [Enabled]

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

Change Values
Select Sub-Menu



F9 Setup Defaults
F10 Save and Exit

Figure 8. Internal Device Configuration Submenu

Table 8: Fields, Options and Defaults for the Internal Device Configuration Submenu of the Advanced Menu

Menu Field Options Default Description

Serial ATA Controller:  Disabled

 Enabled

AHCI Configuration:

Bluetooth:

LAN Controller:

Wireless LAN:

IEEE1394 Controller:

WWAN Device:

Internal Camera:

Ambient Light Sensor:

 Disabled
 Enabled

 Disabled
 Enabled

 Disabled
 Enabled

 Disabled
 Enabled

 Disable
 Enabled

 Disabled
 Enabled

 Disabled
 Enabled

 Disabled
 Enabled

[Enabled] Enables or disables the Serial ATA port.

[Enabled] Enables or disables the selected Advanced Host Controller Inter-

face (AHCI).

[Enabled] Enables or disables the Bluetooth device.

[Enabled] Enables or disables the LAN controller.

[Enabled] Enables or disables the Wireless LAN controller.

[Enabled] Enables or disables the IEEE 1394 controller.

[Enabled] Enables or disables the Wireless WAN controller.

[Enabled] Enables or disables the Internal Camera.

[Enabled] Enables or disables the Ambient Light Sensor.

13

LIFEBOOK T901 BIOS

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

F9 Setup Defaults
F10 Save and Exit

Change Values
Select Sub-Menu

Item Specific Help

Info System Advanced Security Boot Exit



Select enabling or
disabling for
multiple core in a
physical processor
package.

CPU Features

Multi-core:
HT Technology: [Enabled]
SpeedStep(R) Technology: [Enabled]

Virtualization Technology: [Disabled]
Intel(R) VT-d: [Disabled]
Intel(R) TXT: [Disabled]

[Enabled]

CPU Features Submenu of the Advanced Menu

The CPU Features submenu provides options for configuring the Intel Core Multi-Processing and SpeedStep power
management features of the CPU.

Figure 9. CPU Features Submenu

Table 9: Fields, Options and Defaults for the CPU Features Submenu of the Advanced Menu

Menu Field Options Default Description

Multi-core:  Enabled

HT Technology:

SpeedStep(R)
Technology:

Virtualization
Technology:

Intel(R) VT-d:

Intel(R) TXT:

14

 Disabled

 Disabled
 Enabled

 Disabled
 Enabled

 Disabled
 Enabled

 Disabled
 Enabled

 Disabled
 Enabled

[Enabled] Enables or disables the Intel Core Multi-Processing features.

[Enabled] Enables or disable Hyper-Threading (HT) Technolgy.

[Enabled] Enables or disables the SpeedStep(R) Technology features.

[Disabled] Enables or disables Virtualization Technology, an Intel technology

[Disabled] When Virtualization Technology is enabled, this selection allows

[Disabled] When Virtualization Technology and Intel(R) VT-d are enabled,

which includes hardware enhancements to improve upon soft­ware-based virtualization technologies.

you to enable or disable Directed I/O.

this selection allows you to enable or disable Trusted Execution
Technology.

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

F9 Setup Defaults
F10 Save and Exit

Change Values
Select Sub-Menu

Item Specific Help

Info System Advanced Security Boot Exit



[Disabled]
The feature is disabled.

[Enabled]
Legacy USB Emulation
is enabled and USB
devices are available
without USB aware OS.

Legacy USB Support
SCSI SubClass Support: [Enabled]

[Enabled]

USB Features

Advanced Menu

USB Features Submenu of the Advanced Menu

The USB Features submenu provides options for enabling or disabling the USB devices.

Figure 10. USB Features Submenu

Table 10: Fields, Options and Defaults for the USB Features Submenu of the Advanced Menu

Menu Field Options Default Description

Legacy USB Support:

SCSI SubClass Support:

 Disabled
 Enabled

 Disabled
 Enabled

[Enabled] When Enabled is selected, Legacy USB Emulation is enabled

and the USB devices are available without a USB-aware OS.
When Disabled is selected, Legacy USB support is disabled.

[Enabled] When Enabled is selected, USB devices that belong to the

SCSI subclass in the mass storage class (e.g., USB Memory
Key) are enabled. Note that enabling this feature may cause
the system to hang during POST, depending on the device
that is connected.

15

LIFEBOOK T901 BIOS

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

F9 Setup Defaults
F10 Save and Exit

Change Values
Select Sub-Menu

Item Specific Help

Info System Advanced Security Boot Exit



Configures the
power button.

*ACPI OS ignores
this setting.

Miscellaneous Configurations

Power Button:
Wake up on LAN:
On Battery:
Force LAN Boot:
Resume on LAN:
Auto Save To Disk:
Volume Setting:
Hardware Power Management:
CPU Power Saving on idle state (AC):
CPU Power Saving on idle state (Battery):
Anytime USB Charge:

[Disabled

[Disabled]
[Enabled]
[Disabled]
[Always Enabled]
[On]
[Middle]
[Enabled]
[Energy Saving]
[Long Battery Life]
[Disabled]

Miscellaneous Configurations Submenu of the Advanced Menu

The Miscellaneous Configurations submenu provides options for enabling or disabling the power button and the Wake
Up On LAN feature, and setting the volume and video memory size.

Figure 11. Miscellaneous Configurations Submenu

Table 11: Fields, Options and Defaults for the Miscellaneous Configurations Submenu of Advanced Menu

Menu Field Options Default Description

Power Button:  Disabled

Wake up on LAN:

On Battery:

Force LAN Boot:

Resume on LAN:

Auto Save To Disk:

16

 Power Off

 Disabled
 Enabled

 Disabled
 Enabled

 Disabled
 Enabled

 On AC mode only
 Always Enabled

 Off
 On

[Disabled] Selecting Disabled disables the power button. Selecting Power

[Disabled] Enabled allows the system to wake up when the internal LAN

[Enabled] When disabled, Wake Up On LAN is only enabled when there is

[Disabled] This feature is active only when “Wake up on LAN” is enabled.

[Always
Enabled]

[On] Turns the Auto Save To Disk feature on and off.When it is turned

Off allows you to turn off system power with the power button.

device receives a specific signal while in power-off state. Selecting
Disabled disables this feature.

an AC adapter connected.

When enabled, in the event of a system wake-up on LAN, the
system will try to first boot from the LAN before attempting to
boot from any other device, regardless of the BIOS boot priority
settings or disabling of the Preboot Execution Environment.

When “On AC mode only” is selected, Wake Up On LAN from
standby/hibernate states is only enabled when AC adapter
connected.

on, a system in suspend mode will save its state to disk and
power off when low battery state is reached.

Advanced Menu

Table 11: Fields, Options and Defaults for the Miscellaneous Configurations Submenu of Advanced Menu

Menu Field Options Default Description

Volume Setting:

Hardware Power
Management:

CPU Power Savings on
idle state (AC):

CPU Power Savings on
idle state (Battery):

Anytime USB Charge:

 Off
 Minimum
 Middle
 Maximum

 Disabled
 Enabled

 Energy Saving
 Low Power
 Normal

 Long Battery Life
 Low Power
 Normal

 Disabled
 AC
 AC/Battery

[Middle] Selects the initial volume setting for the system.

[Enabled] Allows you to enable or disable the Hardware Power

Management technology.

[Energy Saving] Allows you to select the power usage when the system is running

on AC.

[Long Battery
Life]

[Disabled] When [Disabled] is selected, the Anytime USB Charge feature

Allows you to select the power usage when the system is running
on the battery.

does not work. When [AC] is selected, an external USB device
can be charged when the system is shut off only when the AC
adapter is plugged in. When [AC/Battery] is selected, an external
USB device can be charged when the system is shut off when the
AC adapter is plugged in and/or a charged battery is installed.

17

LIFEBOOK T901 BIOS

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

F9 Setup Defaults
F10 Save and Exit

Change Values
Select Sub-Menu

Item Specific Help

Info System Advanced Security Boot Exit



[Disabled]
Intel(R) Management
Engine BIOS Extensions
screens are not
displayed.

[Enabled]
Intel(R) Management
Engine BIOS Extensions
screens are displayed.

Intel(R) Management Engine Configurations

Intel(R) ME Setup Menu: [Disabled]

Intel(R) AMT Fast Call for Help: [Enter]
UnConfigure Intel(R) ME: [Enter]
SOL Console Type: [VT-UTF8]
Intel(R) AT Suspend Mode: [Disabled]

Intel Management Engine Configurations Submenu of the Advanced Menu

The Intel Management Engine Configurations submenu configures the Anti-Theft Technology Suspend mode.

Figure 12. Intel(R) Management Engine Configurations Submenu

Table 12: Fields, Options and Defaults for the Event Logging Submenu of the Advanced Menu

Menu Field Options Default Description

Intel(R) ME Setup
Menu:

Intel(R) AMT Fast Call
for Help:

UnConfigure Intel(R)
ME:

SOL Console Type:

Intel(R) AT Suspend
Mode:

18

 Disabled
 Enabled

 Enter ___ Allows you to make a request for help in fixing your system

 Enter ___ Allows you to Un-configure the Intel(R) Management Engine. Note that

 PC-ANSI
 VT-100*
 VT-UTF8

 Disabled
 Enabled

[Enabled] Enables and disables the display of the Intel(R) Management Engine

BIOS Extensions screens.

in order to unconfigure after exiting, you must re-boot your system.

[VT-UTF8] Allows you to select the SOL Console type.

[Disabled] When [Disabled] is selected, the Intel(R) Anti-Theft Technology Suspend

Mode is disabled. When [Enabled] is selected, the Intel(R) Anti-Theft
Technology Suspend Mode is enabled.

Event Logging Submenu of the Advanced Menu

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

F9 Setup Defaults
F10 Save and Exit

Change Values
Select Sub-Menu

Item Specific Help

Info System Advanced Security Boot Exit



Press <Enter> key to
view the contents of
the event log.

Event Logging

Event Log Capacity: Space Available
Event Log Validity: Valid

View Event Log: [Enter]

Event Logging: [Enabled]

Clear All Event Logs: [Enter]

Mark Events as Read: [Enter]

The Event Logging submenu configures event logging features for DMI events.

Advanced Menu

Figure 13. Event Logging Submenu

Table 13: Fields, Options and Defaults for the Event Logging Submenu of the Advanced Menu

Menu Field Options Default Description

Event Log Capacity: Space Available Display only

Event Log Validity: Valid Display only

View Event Log:

Event Logging:

Clear All Event Logs:

Mark Events as Read:

 Enter [Enter] Allows you to view content of event log

 Disabled
 Enabled

 Enter [Enter] After clicking [Enter], a Setup Notice appears prompting you to select [Yes]

 Enter [Enter] After clicking [Enter], a Setup Notice appears prompting you to select [Yes]

[Enabled] Turns event logging on and off for all DMI events.

or [No] to confirm. When set to [Yes] all event logs will be cleared at next
boot.

or [No] to confirm. When set to [Yes] all event in the events log will be
marked as having been read.

19

LIFEBOOK T901 BIOS

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

F9 Setup Defaults
F10 Save and Exit

Change Values
Select Sub-Menu

Item Specific Help

Info System Advanced Security Boot Exit



Press <Enter> key to
set Supervisor Password
to enable any password
features.

Then password entry is
required to enter BIOS
Setup.

Supervisor Password Is: Clear
User Password Is: Clear

Set Supervisor Password [Enter]
Set User Password [Enter]
Minimum User Password Length: [0]
Password on Boot: [Disabled]
On Automatic Wake up: [Disabled]
Boot from Removable Media: [All]
Flash Write: [Enabled]
Boot Menu: [Enabled]
Hard Disk Security
Owner Information
TPM (Security Chip) Setting







SECURITY MENU – SETTING THE SECURITY FEATURES

The Security menu allows you to set up the data security features of your notebook to fit operating needs and to view
the current data security configuration. (See Navigating through the Setup Utility on page 2 for more information.)

The following tables show the names of the menu fields for the Security Menu and its submenus, all the options for
each field, the default settings and a description of the field's function and any special information needed to help
understand the field's use. The default condition is no passwords required and no write protection.

 Remember your passwords! If you set and forget your User and Master hard disk passwords, Fujitsu

America will not be able to reset it. You may lose data and have to replace your system board or hard disk
drive.

 WARNING. VERY IMPORTANT if your hard disk drive is protected using a Full Disk Encryption (FDE)

"engine". FDE encrypts all data as it is written to the hard drive. When data is retrieved from the hard
drive, it is decrypted by the same engine. If you forget your hard disk security password on a system with

FDE, all data and applications on the hard drive will remain encrypted and will effectively be lost. Be

sure to remember your hard disk password.

 Entering a password incorrectly 3 times in a row causes the keyboard and mouse to be locked out and

[System Disabled] to be displayed. If this occurs, restart the computer by turning off and on the power
with the power switch and use the correct password on reboot.

 If you make an error when re-entering the password a Warning will be displayed. To try again press

[Enter], then retype the password, or press [Esc] to abort the password process.

 If the Security Panel on Resume is Enabled and the Password on Boot is Disabled you will not have to

type your password upon resuming the system from the Suspend or Save-to-Disk modes. Power Man­agement Security will work only if Password boot is enabled.

20

Figure 14. Security Menu

Table 14: Fields, Options and Defaults for the Security Menu

Menu Field Options Default Description

Security Menu

Supervisor
Password is:

User Password is: –— Clear A display-only field. Set is displayed when the general user

Set Supervisor
Password

–— Clear A display-only field. Set is displayed when the system supervisor password is set

and Clear when it is not.

password is set, and Clear when it is not.

–— [Enter] Sets, changes or cancels the Supervisor Password. The Supervisor Password may

be up to seven characters long and must include only letters or numbers (no
symbols). Passwords are NOT case-sensitive. To cancel a password press the
Enter key instead of entering characters in the Enter New Password field and in
the Re-enter New Password field. When a Supervisor Password is set it must be
used to access the BIOS setup utility.

Set User Password –— [Enter] This field can only be accessed if the Supervisor Password is set. Sets, changes or

cancels the User Password. A User Password may be up to seven characters long
and must include only letters or numbers (no symbols). Passwords are NOT
case-sensitive. To cancel a password press [Enter] key instead of entering char­acters in the Enter New Password field and in the Re-enter New Password field.
When a User Password is set it must be used to access the BIOS setup utility.

Minimum User
Password Length:

Password on Boot:

On Automatic
Wake Up:

Boot from
Removable Media:

Flash Write:

–— [0] Supervisor can set password length (0 to 8) for user password. User cannot set a

password shorter than the minimum length.

 Disabled
 First Boot
 Every Boot

 Disabled
 Enabled

 All
 Supervisor only

 Disabled
 Enabled

[Disabled] When set to First Boot, a password (User or Supervisor) is required just once

[Disabled] When disabled, password entry is not required when the system wakes up

[All] Supervisor only allows access to boot the computer to removable media after

after the Power On Self Test (POST) before the operating system will be read
from a disk. When set to Every Boot, a password (User or Supervisor) is required
every time after the Power On Self Test (POST) before the operating system will
be read from a disk. When set to Disabled no password is required.

automatically. When enabled, password entry is required upon wake up.

the Supervisor Password is entered.

[Enabled] When disabled, the BIOS Flash memory will be write protected.

Boot Menu:

 Disabled
 Enabled

[Enabled] When disabled, the Boot Menu is disabled and cannot be opened using the

[F12] key.

Hard Disk Security: –— –— Configures hard disk security features

Owner
Information:

TPM (Security

–— –— Sets Owner information.

___ ___ Sets the TPM (Security Chip) settings

Chip) Setting

Exiting from the Security Menu

When you have finished setting the parameters on the Security Menu, you can either exit from setup utility or move to
another menu. If you wish to exit from setup utility, press the [Esc] key to go to the Exit Menu. If you wish to move to
another menu, use the cursor keys.

21

LIFEBOOK T901 BIOS

Hard Disk Security Submenu of the Security Menu

The Hard Disk Security submenu is for configuring hard disk security features.

Phoenix SecureCore(tm) Tiano Setup

Info System Advanced Security Boot Exit

Hard Disk Security

Drive0: Clear
Set Master Password [Enter]

Item Specific Help

Configure hard disk

security feature.

Set User Password [Enter]
Drive2: Not Available
Set Master Password [Enter]
Set User Password [Enter]

Password Entry on Boot: [Enabled]

F1 Help
ESC Exit

Select Item
Select Menu

Figure 15. Hard Disk Security Submenu

-/Space
Enter

Change Values
Select Sub-Menu



F9 Setup Defaults
F10 Save and Exit

Table 15: Fields, Options and Defaults for the Hard Disk Security Submenu of the Security Menu

Menu Field Options Default Description

Drive0:

Set Master Password

Set User Password

Drive2:

Set Master Password

Set User Password

Password Entry on
Boot:

___

___

___

___

___

___

 Disabled
 Enabled

Clear Display-only. Default is Clear. When the Drive0 Password has been set, the field

[Enter] Sets, changes or cancels the Drive0 Master Password. The Drive0 Master Pass-

[Enter] Sets, changes or cancels the Drive0 User Password. The Drive0 User Password

Not Available Not available in this configuration.

[Enter] Not available in this configuration.

[Enter] Not available in this configuration.

[Enabled] When set to disabled, entry of a Hard Disk Password is not required before OS

changes to Set. When this password is set, the primary hard disk drive cannot be
used in another system unless the password is entered.

word may be up to seven characters long and must include only letters or num­bers (no symbols). Passwords are NOT case-sensitive. When a Drive0 Password is
set, it must be used to access the hard drive if it is used in another system. Note
that the password will not take effect until the system has been rebooted. The

Master Password does not provide security; it simply allows the user to set the
User Password, which provides true security.

may be up to seven characters long and must include only letters or numbers (no
symbols). Passwords are NOT case-sensitive. When a Drive0 Password is set, it
must be used to access the hard drive if it is used in another system. Note that the
password will not take effect until the system has been rebooted.

boot. (The hard disk is still password-protected without password entry.)

22

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

F9 Setup Defaults
F10 Save and Exit

Change Values
Select Sub-Menu

Item Specific Help

Info System Advanced Security Boot Exit



Owner Information

Owner Information Is: Clear

Set Owner Information [Enter]

Foreground Color: [Gray]
Background Color: [Black]

Set owner information.

Security Menu

Owner Information Submenu of the Security Menu

The Owner Information submenu is for setting owner information. Note that the owner information cannot be set
without having entered a Supervisor Password.

Figure 16. Owner Information Submenu

Table 16: Fields, Options and Defaults for the Owner Information Submenu of the Security Menu

Menu Field Options Default Description

Owner Information Is: –— Clear Display only.

Set Owner
Information:

Foreground Color:

Background Color:

–— [Enter] Field to write owner information,

 Black
 Blue
 Green
 Cyan
 Red
 Magenta

 Black
 Blue
 Green
 Cyan
 Red
 Magenta

 Brown
 White
 Gray
 Light Blue
 Light Green

 Brown
 White
 Gray
 Light Blue
 Light Green

 Light Cyan
 Light Red
 Light Magenta
 Yellow
 Bright White

 Light Cyan
 Light Red
 Light Magenta
 Yellow
 Bright White

(i.e., name).

[Gray] Set foreground color.

[Black] Set background color.

23

LIFEBOOK T901 BIOS

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

F9 Setup Defaults
F10 Save and Exit

Change Values
Select Sub-Menu

Item Specific Help

Info System Advanced Security Boot Exit



Configure Security Chip.

TPM (Security Chip) Setting

Security Chip: Enabled

Current TPM State: Enabled and Activated
Change TPM State: [No Change]
Clear Security Chip: [Enter]

TPM (Security Chip) Setting Submenu of the Security Menu

The Trusted Platform Module (TPM) Security Chip Setting submenu is used to enable or disabled the embedded secu­rity chip.

Figure 17. TPM (Security Chip) Setting Submenu

Table 17: Fields, Options and Defaults for the TPM (Security Chip) Setting Submenu of the Security Menu

Menu Field Options Default Description

Security Chip:  Disabled

Current TPM State: –— Disabled and

Change TPM State:

Clear Security Chip:

24

 Enabled

 No Change
 Disable and

Deactivate

 Enter [Enter] Allows you to clear the Security Chip. Note that this does not allow you

[Enabled] Allows you to enable or disable the Trusted Platform Module (TPM)

Deactivated

[No Change] Allows you to enable or disable the TPM chip when the Supervisor Pass-

chip. Note that this is only active if a Supervisor Password has been
entered. A reboot is required after exit to configure the Security Chip
correctly. Clear Security Chip option becomes selectable after reboot.

Indicates the current state of the TPM chip.

word has been set.

to access already-encrypted data.

Boot Menu

BOOT MENU – SELECTING THE OPERATING SYSTEM SOURCE

The Boot Menu is used to select the order in which the
BIOS searches sources for the operating system. Follow
the instructions for Navigating Through the Setup
Utility to make any changes. (See Navigating through

the Setup Utility on page 2 for more information.)

 Be careful of the operating environment when booting from a CD or you may overwrite files by mistake.

 A bootable CD-ROM has either a floppy disk format or a hard drive format. When the CD-ROM is used,

drive allocations change automatically without changing the BIOS setup. If a floppy disk format is used,
the CD-ROM becomes Drive A. The CD-ROM will only take drive C: (hard drive format) if the internal
hard drive is not present or disabled. The bootable CD-ROM can never use a C: designation if a formatted
internal hard drive is present since the C: designator is always reserved for the hard drive.The boot
sequence ignores the new drive designations, but your application software will use the new designations.

Info System Advanced Security Boot Exit

Boot Priority Order:

1: Floppy Disk Drive:
2: Drive0 HDD: Hitachi HTS545016B9A300
3: Drive2 HDD:
4: CD/DVD Drive: MATSHITADVD-RAM UJ8A0AS
5: NETWORK: IBA GE Slot 00C8 v1363
6: USB HDD:
7: USB CD/DVD:

Phoenix SecureCore(tm) Tiano Setup

The following table shows devices associated with your
notebook and the order in which they will be searched

for the boot device.

Item Specific Help

Configures order of
Boot Device.

Keys used to view or
configure devices.

‘' and '': Select a
device:
’+’ and ‘-’: Move the
device up or down.
‘Shift + 1’: Enables or
disables(!) a device.

F1 Help
ESC Exit

Select Item
Select Menu

Figure 18. Boot Device Priority Submenu

-/Space
Enter

Change Values
Select Sub-Menu



F9 Setup Defaults
F10 Save and Exit

Table 18: Fields, Options and Defaults for the Boot Device Priority Submenu of the Boot Menu

Menu Field Description

Boot priority order:
1: Floppy Disk Drive
2: Drive0 HDD:
3: Drive2 HDD:
4: CD/DVD Drive:
5: NETWORK:
6: USB HDD:
7: USB CD/DVD:

The boot selections determine the order in which the BIOS searches for the operating system during the
startup sequence. To change the order, highlight one source by using the [up] or [down] cursor keys and
then press the [+] or [-] key to change the order number. Tapping [x] removes from the list a device that is
not installed. Tapping [x] on an item in the Excluded list adds the device to the Boot priority list. Be sure to
save your changed order when you exit the BIOS setup utility by either going to the Exit Menu and
choosing Exit Saving Changes, or pressing F10 and choosing Yes to Save and Exit.
NOTE: Be aware that if you use the CD-ROM drive as the first boot device, certain files may be
overwritten, depending upon your operating environment.

Exiting from Boot Menu

When you have finished setting the boot parameters with the Boot Menu, you can either exit from the setup utility or
move to another menu. If you wish to exit from the setup utility press the [Esc] key to go to the Exit Menu. If you wish
to move to another menu, use the cursor keys.

25

LIFEBOOK T901 BIOS

EXIT MENU – LEAVING THE SETUP UTILITY

The Exit Menu is used to leave the setup utility. Follow
the instructions for Navigating Through the Setup
Utility to make any changes. (See Navigating through

the Setup Utility on page 2 for more information.)

Phoenix SecureCore(tm) Tiano Setup

Info System Advanced Security Boot Exit

Exit Saving Changes
Exit Discarding Changes
Load Setup Defaults
Discard Changes
Save Changes
Save Changes and Power Off

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

Figure 19. Exit Menu

Table 19: Fields, Options and Defaults for the Exit Menu

The following table shows the names of the menu fields
for the Exit menu, the default settings and a description
of the field's function and any special information
needed to help understand the field's use.

Item Specific Help

Exit System Setup and
save your changes to
CMOS.

Change Values
Select Sub-Menu



F9 Setup Defaults
F10 Save and Exit

Menu Field Description

Exit Saving
Changes

Exit Discarding
Changes

Load Setup
Defaults

Discard
Changes

Save Changes Selecting Save Changes will cause the new settings in all menus to be written to the BIOS memory. The message Save

Save Changes
and Power Off

26

Exit Saving Changes and Exit will store all the entries on every menu of the setup utility to the BIOS memory, then exit
the utility. A confirmation message Save Configuration changes and exit now? [Yes][No] is displayed.

Selecting Exit Discarding Changes and Exit will exit the setup utility without writing to the BIOS memory. When the
BIOS recognizes this selection it will reboot, load the operating system and begin operation.

Selecting Load Setup Defaults will load the factory preset default values for all menu fields, then display the message
Load default configuration now? [Yes] [No]. When confirmed the setup utility will return to the Exit
Menu. To return to another menu follow the directions in the Navigating Through the Setup Utility Section.

Selecting Discard Changes will load the previous values in BIOS memory for all menu fields. The message Load
previous configuration now? [Yes] [No] will be displayed. When confirmed the setup utility will return to
the Exit menu. To return to another menu, follow the directions in the Navigating Through the Setup Utility Section.

configuration changes now? [Yes] [No] will be displayed. When confirmed, the setup utility will return to
the Exit menu. To return to another menu, follow the directions in the Navigating Through the Setup Utility section.

Selecting Save Changes and Power Off will cause the new settings in all menus to be written to the BIOS memory. The
message Save configuration changes and power off now? [Yes] [No] will be displayed. When con­firmed, the system will shut down. If No is selected, the system will return to the Exit menu. To return to another menu,
follow the directions in the Navigating Through the Setup Utility section.
