Fujitsu LifeBook S7110 BIOS Guide

Download

Fujitsu LifeBook

S Series

BIOS Guide

LifeBook S Series Model:

S7110

Document Date: 03/14/2006

Document Number: FPC58-1490-01

FUJITSU COMPUTER SYSTEMS

LifeBook S Series Notebook BIOS

S Series BIOS

BIOS SETUP UTILITY

The BIOS Setup Utility is a program that sets up the operating environment for your notebook. Your BIOS is set at the factory for normal operating conditions, therefore there should be no need to set or change the BIOS environment to operate your notebook.

The BIOS Setup Utility configures:

■

Device control feature parameters, such as changing I/O addresses and boot devices.

■

System Data Security feature parameters, such as passwords.

Entering the BIOS Setup Utility

To enter the BIOS Setup Utility do the following:

1. Turn on or restart your notebook.

2. Press the [F2] key when a message appears under the Fujitsu logo prompting you to “Press <F2>: BIOS Setup”. This will open the main menu of the BIOS Setup Utility with the current settings displayed.

3. Press the arrow keys to scroll through the other setup menus to review or alter the current settings.

Navigating Through the Setup Utility

The BIOS setup utility consists of six menus: Main, Advanced, Security, Boot, Info and Exit. This document explains each menu in turn including all submenus and setup items.

The following procedures allow you to navigate the setup utility menus:

1. To select a menu, use the cursor keys:

2. To select a field within a menu or a submenu, use the

cursor keys:

[ ], [ ].

3. To select the different values for each field, press the [Spacebar] to change to the next higher selection and [F5] or [-] to go to the next lower selection.

4. To activate a submenu press the [Enter] key.

5. To return to a menu from a submenu, press the [Esc] key.

6. To go to the Exit menu from any other menu, press the [Esc] key.

[ ], [ ].

■

Selecting a field causes a help message about that field to be displayed on the right-hand side of the screen.

■

Pressing the Enter key with the highlight on a selection that is not a submenu or auto selection will cause a list of all options for that item to be displayed. Pressing the Enter key again will select the highlighted choice.

7. Pressing the [F9] key resets all items in the BIOS to the default values.

8. Pressing the [F10] key saves the current configuration and exits the BIOS Setup Utility. You will be asked to verify this selection before it is executed.

9. Pressing the [F1] key gives you a general help screen.

Entering the Setup Utility After a Configuration Change or System Failure

If there has been a change in the system configuration that does not agree with the parameter settings stored in your BIOS memory, or there is a failure in the system, the system beeps and/or displays an error message after the Power On Self Test (POST). If the failure is not too severe, it will give you the opportunity to modify the settings of the setup utility, as described in the following steps:

1. When you turn on or restart the computer there is a beep and/or the following message appears on the screen:

Error message - please run SETUP program Press <F1> key to continue, <F2> to run SETUP

2. If an error message is displayed on the screen, and you want to continue with the boot process and start

the operating system anyway, press the [F1] key.

■

If your notebook emits a series of beeps that sounds like a code and the display is blank, refer to the Troubleshooting section of your system Use’s Guide. The Troubleshooting Section includes a list of error messages and their meanings.

■

If your data security settings require it, you may be asked for a password before the setup utility will be opened.

3. If an error message is displayed on the screen, and you want to enter the setup utility, press the [F2] key.

4. When the setup utility starts with a fault present, the system displays the following message:

Warning!

Error message

[Continue]

5. Press any key to enter the setup utility. The system will then display the Main Menu with current parameters values.

Main Menu

LifeBook S Series Notebook BIOS

MAIN MENU – SETTING STANDARD SYSTEM PARAMETERS

The Main Menu allows you to set or view the current system parameters. Follow the instructions for Navigating Through The Setup Utility to make any changes.

(See Navigating Through the Setup Utility on page 2 for more information)

The following tables show the names of the menu fields for the Main menu and its submenus, all of the options for each field, the default settings and a description of

PhoenixBIOS Setup Utility

Main Advanced Security Boot Info Exit

System Time: [02:34:56] System Date: [03/14/2006]

▲ ▲

Drive0 [FUJITSU MHV2040BH] Drive1 [MATSHITADVD-RAM UJ-841S]

Language: [English (US)]

the field’s function and any special information needed to help understand the field’s use. Note that the actual drive labels shown may vary

System time and date can also be set from your operating system without using the setup utility. Use the Date and Time icon on your Windows Control panel or type time or date from the MS-DOS prompt.

Item Specific Help

Adjust calendar clock.

<Tab>, <Shift-Tab>, or <Enter> selects field.

F1 Help ESC Exit

Select Item Select Menu

-/Space Change Values Enter Select Sub-Menu

Figure 1. Main Menu

▲

F9 Setup Defaults F10 Save and Exit

Table 1: Fields, Options and Defaults for the Main Menu

Menu Field Options Default Description

System Time: –— –— Sets and displays the current time. Time is in a 24 hour format

System Date: –— –— Sets and displays the current date. Date is in a month/day/year

of hours:minutes:seconds with 2 digits for each. (HH:MM:SS). Example: 16:45:57. You may change each segment of the time separately. Move between the segments with the [Tab] key and/or [Shift] + [Tab] keys.

numeric format with 2 digits each for month and day and 4 digits for year. (MM/DD/YYYY) for example: 03/20/1998. You may change each segment of the date separately. Move between the segments with the [Tab] key and/or [Shift] + [Tab] keys.

Table 1: Fields, Options and Defaults for the Main Menu

Menu Field Options Default Description

Main Menu

Drive0 Selects the Drive0

Serial ATA drive submenu

Drive1: Selects the Drive1

Serial ATA drive submenu

■

Language:

English (US)

■

Japanese (JP)

The product number of the hard drive.

The product number of the CDROM drive.

[English (US)] The default setting differs between the US/European and the

Display the type of device on this ATA/IDE interface. Pressing the Enter key selects the Serial ATA Drive0 submenu allowing additional device configuration options for this interface.

Display the type of device on this ATA/IDE interface, if there is one. Pressing the Enter key selects the Serial ATA Drive1 submenu allowing additional device configuration options for this interface.

Japanese model. Selects the display language for the BIOS.

LifeBook S Series Notebook BIOS

Drive0 Submenu of the Main Menu

The Drive0 submenu identifies what Serial ATA/IDE devices are installed.

PhoenixBIOS Setup Utility

Main

Note that actual hard drive label shown may vary. Depending on the drive type, information such as cylinders, heads and sectors may also be displayed.

Drive0 [FUJITSU MHV2040BH]

Type: [Auto] LBA Format Total Sectors: 78140160 Maximum Capacity: 40008MB SATA1

F1 Help ESC Exit

Select Item Select Menu

-/Space

Figure 2. Drive0 Submenu

Change Values

Enter

Select Sub-Menu

▲

Menu Field Options Default Description

Typ e:

■

Auto None

[Auto] Select Auto to have the type of Serial or Parallel ATA device auto-

matically identified by the BIOS at POST. If None is selected, the following Set-up items do not appear.

Item Specific Help

Select Serial ATA/IDE drive installed here.

[Auto] The BIOS auto-types the drive on boot time.

[None] The drive is disabled.

F9 Setup Defaults F10 Save and Exit

LBA Format Logical Block Addressing (LBA)

Tot al S ect ors:

Maximum Capacity:

---

--- The total number of sectors on your hard disk

--- The maximum capacity of your hard disk

Drive1 Submenu of the Main Menu

The Drive1 submenu allows you to configure secondary ATA de v ices .

PhoenixBIOS Setup Utility

Main

Main Menu

Note that actual hard drive label shown may vary. Depending on the drive type, information such as cylinders, heads and sectors may also be displayed.

Drive1 [MATSHITADVD-RAM UJ-841S]

Type: [Auto]

Multi-Sector Transfers: [Disabled] LBA Mode Control: [Disabled] Transfer Mode: [Standard] Ultra DMA Mode: [Disabled]

Item Specific Help

Select ATA/ATAPI drive installed here.

[Auto] The BIOS auto-types the drive on boot time.

[None] The drive is disabled.

F1 Help ESC Exit

Select Item Select Menu

-/Space

Figure 3. Drive1 Submenu

Change Values

Enter

Select Sub-Menu

▲

F9 Setup Defaults F10 Save and Exit

Table 3: Fields, Options and Defaults for the Drive1 Submenu of the Main Menu

Menu Field Options Default Description

Typ e:

■

Auto None

[Auto] Selects the ATA/ATAPI device type. Select Auto to have the device (CD-

ROM, CD-R/RW, DVD-ROM, etc.) automatically identified by the BIOS at POST. If None is selected, the following Set-up items do not appear.

Multi-Sector Tra nsf ers:

LBA Mode Control:

■

Disabled

■

2 Sectors

■

4 Sectors

■

8 Sectors

■

16 Sectors

■

Disabled

■

Enabled

[Disabled] This option cannot be changed when Auto is selected. Specify the num-

[Disabled] Enables or disables Logical Block Addressing in place of Cylinder, Head,

ber of sectors per block for multiple sector transfer.

Sector addressing. This option cannot be changed when Auto is selected.

LifeBook S Series Notebook BIOS

Table 3: Fields, Options and Defaults for the Drive1 Submenu of the Main Menu

Menu Field Options Default Description

Transfer Mode:■Standard

Ultra DMA Mode:

■

Fast PIO 1

■

Fast PIO 2

■

Fast PIO 3

■

Fast PIO 4

■

Multiword DMA 1

■

Multiword DMA 2

■

Disabled

■

Mode 0

■

Mode 1

■

Mode 2

■

Mode 3

■

Mode 4

■

Mode 5

■

A bootable CD-ROM may have either a floppy disk or hard drive format. When the bootable CD-ROM is

[Standard] Selects the method for moving data to/from the drive. Autotype the

drive to select the optimum transfer mode. This option cannot be changed when Auto is selected.

[Disabled] Selects the method for moving data to/from the drive. Autotype the

drive to select the optimum transfer mode. This option cannot be changed when Auto is selected.

used, the drive allocations change automatically without changing the BIOS setup. If a floppy disk format CD-ROM is used, the CD-ROM becomes Drive A. The CD-ROM will only take drive C: (hard drive format) if the internal hard drive is not present or is disabled. The bootable CD-ROM can never use a C: designation if a formatted internal hard drive is present since the C: designator is always reserved for the internal hard drive. The boot sequence ignores the new drive designations, however, your application software will use the new designations.

■

Be aware of the operating environment when booting from a CD-ROM or you may overwrite files by mistake.

Exiting from Main Menu

When you have finished setting the parameters on this menu, you can either exit from the setup utility, or move to another menu. If you wish to exit from the setup utility, press the [Esc] key or use the cursor keys to go to the Exit menu or to move to another menu.

Advanced Menu

ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS

The Advanced Menu allows you to:

■

Set the I/O addresses for the serial and parallel ports.

■

Set the features of the keyboard/mouse.

■

Select between the display panel and/or an external CRT display.

■

Set internal device configurations

■

Configure USB and CPU features.

■

Configure miscellaneous features such as Wake Up On LAN.

■

Configure DMI Event Logging.

PhoenixBIOS Setup Utility

Main Advanced Security Boot Info Exit

▲ ▲ ▲ ▲ ▲ ▲

Serial/Parallel Port Configurations Keyboard/Mouse Features Video Features Internal Device Configurations CPU Features USB Features Miscellaneous Configurations

▲

Event Logging

▲

Follow the instructions for Navigating Through the Setup Utility to make any changes.

(See Navigating Through the Setup Utility on page 2 for

more information)

The following tables show the names of the menu fields for the Advanced Menu and its submenus, all of the options for each field, the default settings and a description of the field’s function, and any special information needed to help understand the field’s use.

Item Specific Help

Configures serial ports and parallel ports

F1 Help ESC Exit

Select Item Select Menu

-/Space

Figure 4. Advanced Menu

Change Values

Enter

▲

Select Sub-Menu

F9 Setup Defaults F10 Save and Exit

LifeBook S Series Notebook BIOS

Table 4: Fields, Options and Defaults for the Advanced Menu

Menu Field Description

Serial/Parallel Port Configurations

Keyboard/Mouse Features

Video Features When selected, opens the Video Features submenu, which allows selecting between the display panel and/

Internal Device Configurations

CPU Features When selected, opens the CPU Features submenu, which allows you to change the Intel(R) SpeedStep(R)

USB Features Configures USB features.

Miscellaneous Configurations

Event Logging When selected, opens the event logging submenu.

When selected, opens the Serial/Parallel Port Configurations submenu which allows the user to modify settings for serial, infrared and parallel ports.

When selected, opens the Keyboard/Mouse Features submenu, which allows setting external and internal keyboard and mouse parameters.

or an external CRT display or video projector.

When selected, opens the Internal Device Configuration submenu, which allows enabling or disabling the modem, IDE, and LAN Controllers.

Technology settings.

Configures miscellaneous features, such as Wake Up On LAN and Power Button.

Serial/Parallel Port Configuration Submenu of the Advanced Menu

The Serial/Parallel Port Configuration submenu lets you set the I/O addresses and interrupt levels for the serial, infrared and parallel ports of your notebook.

I/O addresses, DMA channels and Interrupt levels can be entered in various ways, including via the BIOS setup utility, the control software for the I/O device, or the hardware. If any two ports or devices, serial or parallel, have the same address assigned, your notebook will not function normally. Keep a record of original settings before making any changes if restoration is required. See your hardware and software documentation as well as the setup utility to determine settings and limitations.

PhoenixBIOS Setup Utility

Advanced

■

To prevent IRQ and address conflicts, avoid changing the default settings. If you must change the settings, you can call 1-800-8Fujitsu for technical assistance.

■

If your notebook emits a series of beeps that sounds like a code and the display is blank, refer to the Troubleshooting Section in the system User’s Guide. The Troubleshooting Section includes a list of error messages and their meanings.

■

All I/O addresses in Table 5 are in hexadecimal.

Advanced Menu

Serial/Parallel Port Configurations

Serial port: [Enabled] Base I/O Address/IRQ: [3F8/IRQ 4] Infrared Port: [Enabled] Mode: [FIR] Base I/O Address/IRQ: [2E8 - 2EF] DMA Channel: [DMA 3] Parallel Port: [Enabled] Mode: [Bi-directional] Base I/O Address: [378] Interrupt: [IRQ 7]

F1 Help ESC Exit

Select Item Select Menu

Figure 5. Serial/Parallel Port Configuration Submenu

-/Space Enter

Change Values Select Sub-Menu

Item Specific Help

[Disabled] The port is disabled.

[Enabled] The port is enabled with user configuration.

[Auto] Plug & Play OS configure the port.

▲

F9 Setup Defaults F10 Save and Exit

LifeBook S Series Notebook BIOS

Table 5: Fields, Options and Defaults for the Serial/Parallel Port Configuration Submenu of Advanced Menu

Menu Field Options Default Description

Serial Port:

Base I/O Address/IRQ:

Infrared Port:

Mode:

Base I/O Address/IRQ:

DMA Channel:

Parallel Port:

Mode:

Base I/O address:

Interrupt:

■

Disabled

■

Enabled

■

Auto

■

3F8/IRQ 4

■

2F8/IRQ 3

■

3E8/IRQ 4

■

2E8/IRQ 3

■

Disabled

■

Enabled

■

Auto

■

IrDA

■

FIR

■

3F8/IRQ 4

■

2F8/IRQ 3

■

3E8/IRQ 4

■

2E8/IRQ 3

■

DMA 1

■

DMA 3

■

Disabled

■

Enabled

■

Auto

■

Output Only

■

Bi-directional

■

ECP

■

378

■

278

■

3BC

■

IRQ 5

■

IRQ 7

[Enabled] Configures the serial port using either no configuration (Disabled),

a user defined configuration (Enabled), or by allowing the BIOS or OS to choose the configuration (Auto).

[3F8/IRQ 4] Allows user to set the serial port base I/O address and interrupt

request when serial port is Enabled.

[Enabled] Configures the infrared port using either no configuration (Dis-

[FIR] When the infrared port is enabled this option is available allowing

abled), a user defined configuration (Enabled), or by allowing the BIOS or OS to choose the configuration (Auto).

the user to set the mode for the infrared port.

[2E8/IRQ 3] Allows user to set the infrared port I/O address and interrupt

request when the infrared port is Enabled.

[DMA 3] Allows user to set the infrared port DMA Channel when the infra-

[Enabled] Configures the parallel port using either no configuration (Dis-

red port is Enabled.

abled), a user defined configuration (Enabled), or by allowing the BIOS or OS to choose the configuration (Auto).

[Bi-directional] When the parallel port is enabled this option is available allowing

the user to set the parallel port mode. Bi-directional allows twoway transfer of information between your notebook and a connected parallel device. Output Only (Half Duplex) allows information to be transferred in only one direction, from your notebook to the printer or similar device. ECP Mode allows communication with the ECP class of parallel I/O devices.

[378 Allows user to set the parallel port base I/O address when the par-

allel port is Enabled.

[IRQ 7] Allows user to set the parallel port interrupt when the parallel port

is Enabled.

Advanced Menu

Keyboard/Mouse Features Submenu of the Advanced Menu

The Keyboard/Mouse Features submenu is for setting the parameters of the integrated and external mouse and keyboard.

PhoenixBIOS Setup Utility

Advanced Security Power Savings Exit

Keyboard/Mouse Features

Numlock: Hot Plug: Internal Pointing Device: Initialization on Resume:

[Auto] [Enabled] [Auto Disabled] [Fast]

Item Specific Help

[On] or [Off] Numlock is On or Off. [On/Padlock Off] Numlock is On, but use with [Fn] for 10-key input. [Auto] Numlock is set to On/ Padlock Off when PS/2 keyboard is connected, otherwise Off.

* Windows XP preserves Numlock state when the user logs off.

F1 Help ESC Exit

Select Item Select Menu

Figure 6. Keyboard/Mouse Features Submenu

-/Space Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults F10 Save and Exit

Table 6: Fields, Options and Defaults for the Keyboard/Mouse Submenu of the Advanced Menu

Menu Field Options Default Description

Numlock:

Hot Plug:

Internal Pointing Device:

Initialization on Resume:

■

Auto

■

Off

■

On/Padlock Off

■

Disabled

■

Enabled

■

Auto Disabled

■

Manual Setting

■

Always Enabled

■

Always Disabled

■

Fast

■

Normal

[Auto] Sets the NumLock function state when the computer completes

[Enabled] Enables and disables the ability to plug a mouse or keyboard into

[Auto Disabled] Sets the device controlling the mouse cursor on the screen. Always

[Fast] When Fast is selected, initialization for the external devices is opti-

booting.

the port and have it immediately recognized and active.

Enabled makes the pointing device always enabled whether there is an external mouse or not. Always Disabled makes the pointing device always disabled. Auto Disabled disables the internal pointing device when an external pointing device is connected to the port.

mized to speed up on Resume. When Normal is selected, initialization is not optimized.

LifeBook S Series Notebook BIOS

Video Features Submenu of the Advanced Menu

The Video Features Submenu is for setting the display parameters.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Item Specific Help

Select display terminal.

Display:

Video Features

[Auto]

Compensation: [Enabled]

* This setting is not effective after operating system starts up.

F1 Help ESC Exit

Select Item Select Menu

Figure 7. Video Features Submenu

-/Space Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults F10 Save and Exit

Table 7: Fields, Options and Defaults for the Video Features Submenu of the Advanced Menu

Menu Field Options Default Description

Display:

Compensation:

■

Internal Flat Panel

■

External (Analog)

■

External (Digital)

■

Auto

■

Disabled

■

Enabled

[Auto] Selects where the video signal will be routed. Note that

[Enabled] Enables or disables display compensation. Note that

Windows settings take precedence over this setting after system boots up.

Advanced Menu

Internal Device Configurations Submenu of the Advanced Menu

The Internal Device Configuration submenu allows the user to configure other internal devices.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Internal Device Configurations

Item Specific Help

[Disabled] Serial ATA Controller: [Enabled] AHCI Configuration: [Enabled]

Serial ATA port is

disabled. IDE Contoller: [Enabled] Bluetooth(R): [Enabled] LAN Controller: [Enabled] Wireless LAN: [Enabled] IEEE1394 Controller: [Enabled]

F1 Help ESC Exit

Select Item Select Menu

-/Space Enter

Figure 8. Internal Device Configuration Submenu

Change Values

▲

Select Sub-Menu

[Enabled] Serial ATA port is enabled.

F9 Setup Defaults F10 Save and Exit

Table 8: Fields, Options and Defaults for the Internal Device Configuration Submenu of the Advanced Menu

Menu Field Options Default Description

Serial ATA Controller:

AHCI Controller:

■

Disabled

■

Enabled

■

Disabled

■

Enabled

[Enabled] Enables or disables serial ATA devices.

[Enabled] Enables or disables the AHCI (Advanced Host Controller Interface).

This selection does not appear when PATA mode is enabled.

IDE Controller:

Bluetooth(R):

LAN Controller:

Wireless LAN:

IEEE1394 Controller:

■

Disabled

■

Enabled

■

Disabled

■

Enabled

■

Disabled

■

Enabled

■

Disabled

■

Enabled

■

Disabled

■

Enabled

[Enabled] Enables or disables the IDE port.

[Enabled] Enables or disables the Bluetooth(R) device, when present.

[Enabled] Enables or disables the LAN controller.

[Enabled] Enables or disables the Wireless LAN device.

[Enabled] Enables or disables the IEEE 1394 device.

LifeBook S Series Notebook BIOS

CPU Features Submenu of the Advanced Menu

The CPU Features Submenu allows you to change the settings for Intel(R) SpeedStep(R) Technology for your system.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

CPU Features

Core Multi-Processing:

[Enabled]

SpeedStep(R) Technology: [Enabled] On Battery: [Battery Optimized]

Item Specific Help

Select Core Multi-Processing enabled or disabled.

On AC: [Maximum Performance]

XD Bit functionality: [Enabled]

F1 Help ESC Exit

Select Item Select Menu

Figure 9. CPU Features Submenu

-/Space Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults F10 Save and Exit

Table 9: Fields, Options and Defaults for the CPU Features Submenu of the Advanced Menu

Menu Field Options Default Description

Core Multi-Processing:

SpeedStep(R) Technology:

■

Enabled

■

Disabled

■

Disabled

■

Enabled

[Enabled] Enables or disables the Intel Core Multi-Processing features.

[Enabled] Enables or disables SpeedStep(R) Technology which allows the

user to determine the CPU performance when the tablet is running on AC or battery. This technology decreases power consumption by decreasing CPU speeds.

On Battery:

On AC:

■

Maximum Performance

■

Battery Optimized

■

Automatic

■

Maximum Performance

■

Battery Optimized

■

Automatic

[Battery Optimized]

[Maximum Performance]

Allows the user to select the CPU performance when the system is running on battery power.

Allows the user to select the CPU performance when the system is running on AC power.

Advanced Menu

Table 9: Fields, Options and Defaults for the CPU Features Submenu of the Advanced Menu

Menu Field Options Default Description

XD Bit functionality:

■

Enabled]

■

Disabled

[Enabled]

Allows the user to enable and disable the Execute Disable Bit functionality. Execute Disable Bit allows the processor to classify areas in memory where application code can and cannot execute. In the event an internet worm attempts to insert code in the buffer, the processor disables code execution to prevent damage or worm propagation.

LifeBook S Series Notebook BIOS

USB Features Submenu of the Advanced Menu

The USB Features Submenu enables and disables legacy USB support for your system.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

USB Features

Legacy USB Support:

[Enabled]

SCSI SubClass Support: [Enabled]

Item Specific Help

[Disabled] The feature is disabled.

[Enabled] Legacy USB Emulation is enabled and USB devices are available without USB aware OS.

F1 Help ESC Exit

Select Item Select Menu

Figure 10. USB Features Submenu

-/Space Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults F10 Save and Exit

Table 10: Fields, Options and Defaults for the USB Features Submenu of the Advanced Menu

Menu Field Options Default Description

Legacy USB Support:

■

Disabled

■

Enabled

[Enabled] When Disabled is selected, legacy USB emulation is disabled. When

Enabled is selected, legacy USB emulation is enabled and USB devices are available without USB-aware OS.

SCSI SubClass Support:

■

Disabled

■

Enabled

[Enabled] When Enabled is selected, USB devices that belong to the SCSI sub-

class in the mass storage class (e.g., USB Memory Key) are enabled.

Advanced Menu

Miscellaneous Configurations Submenu of the Advanced Menu

The Miscellaneous Configurations Submenu configures the miscellaneous features for your system.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Miscellaneous Configurations

Power Button: [Disabled] Wake up on LAN: [Disabled] Volume Setting: [Middle] Hardware Power Management: [Disabled}

F1 Help ESC Exit

Select Item Select Menu

Figure 11. Miscellaneous Configurations Submenu

-/Space Enter

Change Values Select Sub-Menu

▲

Item Specific Help

Configures the power button.

*ACPI OS ignores this setting.

F9 Setup Defaults F10 Save and Exit

Table 11: Fields, Options and Defaults for the Miscellaneous Configurations Submenu

Menu Field Options Default Description

Power Button:

Wake up on LAN:

Force LAN Boot:

Volume Setting:

■

Disabled

■

Power Off

■

Disabled

■

Enabled

■

Disabled

■

Enabled

■

Off

■

Minimum

■

Middle

■

Maximum

[Disabled] Selecting Disabled disables the power button. Selecting Power Off

[Disabled] Selecting Enabled allows the system to wake up when the internal LAN

[Disabled] This feature is active only when “Wake up on LAN” is enabled. When

[Middle] Selects the initial volume setting for the system.

allows you to turn off system power with the power button.

device receives a specific signal while in power-off state. Selecting Disabled disables this feature.

enabled, in the event of a system wake-up on LAN, the system will try to first boot from the LAN before attempting to boot from any other device, regardless of the BIOS boot priority settings or disabling of the Preboot Execution Environment.

LifeBook S Series Notebook BIOS

Table 11: Fields, Options and Defaults for the Miscellaneous Configurations Submenu

Menu Field Options Default Description

UMA Video Memory Size:

Hardware Power Management:

■

64MB

■

128MB

■

224MB

■

Disabled

■

Enabled

[128MB] Allows you to select the maximum shared video memory size. Video

memory is dynamically allocated as needed for running applications by Dynamic Video Memory Technology (DVMT).

[Enabled] Enables or disables the Hardware Power Management feature.

Event Logging Submenu of the Advanced Menu

The Event Logging Submenu configures event logging features for DMI events.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Advanced Menu

Event Logging

Event Log Capacity: Space Available Event Log Validity: Valid

View Event Log: [Enter]

Item Specific Help

Press <Enter> key to view the contents of the event log.

Event Logging: [Enabled] System Boot Event: [Disabled]

Clear All Event Logs: [No]

Mark Events as Read: [Enter]

F1 Help ESC Exit

Select Item Select Menu

Figure 12. Event Logging Submenu

-/Space Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults F10 Save and Exit

Table 12: Fields, Options and Defaults for the Event Logging Submenu of the Advanced Menu

Menu Field Options Default Description

Event Log Capacity:

Space Available Display only.

Event Log Validity: Valid Display only.

■

View Event Log:

Event Logging:

System Boot Event:

Clear All Event Logs:

Mark Events as Read:

Enter [Enter] Allows you to view content of event log.

■

Disabled

■

Enabled

■

Disabled

■

Enabled

■

Yes

■

Enter [Enter] Allows you to make all events currently in the event log as read.

[Enabled] Turns event logging on and off for all DMI events.

[Disabled] Turns event logging on and off for DMI system boot events.

[No] When set to [Yes] all event logs will be cleared at next boot.

LifeBook S Series Notebook BIOS

SECURITY MENU – SETTING THE SECURITY FEATURES

The Security menu allows you to set up the data security features of your notebook to fit your operating needs and to view the current data security configuration. Follow the instructions for Navigating Through the Setup Utility to make any changes. (See Navigating Through the Setup

Utility on page 2 for more information)

The following tables show the names of the menu fields for the Security menu and its submenus, the options for each field, the default settings and a description of the

Entering a password incorrectly three times in a row will cause the keyboard and mouse to be locked out and the warning [System Disabled] to be displayed. If this happens, restart the computer by turning off and on the power with the power switch and use the correct password on reboot.

PhoenixBIOS Setup Utility

Main Advanced Security Boot Info Exit

Supervisor Password Is: Clear User Password Is: Clear

Set Supervisor Password [Enter] Set User Password [Enter] Minimum User Password Length: [0] Password on Boot: [Disabled] On Automatic Wake up: [Disabled] KB Lock on Resume: [Disabled] Boot from Removable Media: [All]

▲ ▲ ▲

Flash Write: [Enabled] Hard Disk Security Owner Information Security Chip Setting Security Panel On Resume: [Enabled]

field's function and any special information needed to help understand the field's use. The default condition is no passwords required and no write protection.

■

If you set a password, write it down and keep it in a safe place. If you forget the password you will have to contact your support representative to regain access to your secured functions and data.

■

If you make an error when re-entering the password a [Warning] will be displayed on the screen. To try again press the [Enter] key and then retype the password. Press the [Esc] key to abort the password setting process.

■

If the Password on Boot is Disabled you will not have to type your password upon resuming the system from the Suspend or Save-to-Disk modes.

Item Specific Help

Press <Enter> key to set Supervisor Password to enable any password features.

Then password entry is required to enter BIOS Setup.

F1 Help ESC Exit

Select Item Select Menu

-/Space

Figure 13. Security Menu

Change Values

Enter

Select Sub-Menu

▲

F9 Setup Defaults F10 Save and Exit

Table 13: Fields, Options and Defaults for the Security Menu

Menu Field Options Default Description

Security Menu

Supervisor Password is:

User Password is: –— Clear A display-only field. Set is displayed when the general User Password is

Set Supervisor Password

–— Clear A display-only field. Set is displayed when the system Supervisor

Password is set and Clear when it is not.

set, and Clear when it is not.

[Enter] [Enter] Sets, changes or cancels Supervisor Password. The Supervisor Password

may be up to seven characters long and include only letters or numbers (no symbols). Passwords are NOT case- sensitive. To cancel a password press the Enter key instead of entering characters in the Enter New Password field and in the Re-enter New Password field. When a Supervisor Password is set it must be used to access the BIOS setup utility.

Set User Password [Enter] [Enter] This field can only be accessed if the Supervisor Password is set. Sets,

changes or cancels the User Password. The User Password may be up to seven characters long and must include only letters or numbers (no symbols). Passwords are NOT case-sensitive. To cancel a password press the Enter key instead of entering characters in the Enter New Password field and in the Re-enter New Password field. When a User Password is set it must be used to access the BIOS setup utility.

Minimum User Password Length:

Password on Boot:

On Automatic Wake up:

[0] [0] Sets the minimum length for User Password.

■

Disabled

■

First Boot

■

Every Boot

■

Disabled

■

Enabled

[Disabled] When Enabled, a password (User or Supervisor) is required after the

[Disabled] This field is active only when Password On Boot is set to First Boot or

Power On Self Test (POST) before the operating system will be read from a disk. When set to Disabled no password is required. If no Supervisor Password is set this feature is not available and no password is required.

Every Boot. When disabled, password entry is not required on automatic wake up on LAN or Real Time Clock. When enabled, the password is still required on automatic wake up.

■

KB Lock on Resume:

Boot from Removable Media:

Flash Write:

Disabled

■

Enabled

■

All

■

Supervisor only

■

Disabled

■

Enabled

[Disabled] When set to Enabled, the keyboard and mouse inputs are locked out

upon Suspend from Resume or Save-to-Disk mode until the password is entered. When both passwords are set, the User password is always used to lock. Password entry before OS boot is disabled upon unattended boot.

[All] Enable password allows supervisor access only.

[Enabled] When disabled, the BIOS Flash memory is write protected.

Hard Disk Security –— –— When selected, opens the Hard Disk Security submenu, which allows you

Owner Information

Security Chip Setting

Security Panel On Resume

–— –— When selected, opens the Owner Information submenu, which allows

–— –— When selected, opens the Security Chip Settings submenu, which allows

■

Disabled

■

Enabled

[Enabled] Allows the Security Panel Feature to be enabled or disabled upon

to configure hard disk security features.

you to set Owner information.

you to set Security Chip information.

Suspend from Resume.

LifeBook S Series Notebook BIOS

Hard Disk Security Submenu of the Security Menu

The Hard Disk Security submenu is for configuring hard disk security features.

Main Advanced Security Power Savings Exit

Hard Disk Security

Drive0: Clear Set Master Password [Enter] Set User Password [Enter] Drive1: Not Available Set Master Password [Enter] Set User Password [Enter]

Password Entry on Boot: [Enabled]

F1 Help ESC Exit

Select Item Select Menu

PhoenixBIOS Setup Utility

-/Space

Change Values

Enter

Figure 14. Hard Disk Security Submenu

▲

Select Sub-Menu

Item Specific Help

Press <Enter> key to Set User Hard Disk Password. The hard disk is locked with the password. Data in the locked disk cannot be read on other systems.

F9 Setup Defaults F10 Save and Exit

Table 14: Fields, Options and Defaults for the Hard Disk Security Submenu of the Security Menu

Menu Field Options Default Description

Drive0:

Set Master Password

___

Clear Display-only. Default is Clear. When the Drive0 Password has been set, the field

[Enter] Sets, changes or cancels the Drive0 Master Password. The Drive0 Master Password

changes to Set. When this password is set, the primary hard disk drive cannot be used in another system unless the password is entered.

may be up to seven characters long and must include only letters or numbers (no symbols). Passwords are NOT case-sensitive. When a Drive0 Master Password is set, it must be used to access the hard drive if it is used in another system. Note that the password will not take effect until the system has been rebooted.

Set User Password

Drive1:

Set Master Password:

___

[Enter] Sets, changes or cancels the Drive0 User Password. The Drive0 User Password may

Not Available

[Enter] Sets, changes or cancels the Drive1 Master Password. The Drive1 Master Password

be up to seven characters long and must include only letters or numbers (no symbols). Passwords are NOT case-sensitive. When a Drive0 User Password is set, it must be used to access the modular hard drive if it is used in another system. Note that the password will not take effect until the system has been rebooted.

Display-only. Default is Not Available. When Drive1 Password has been set, the field changes to Set. When this password is set, the secondary (modular) hard disk drive cannot be used in another system unless the password is entered.

may be up to seven characters long and must include only letters or numbers (no symbols). Passwords are NOT case-sensitive. When a Drive1Master Password is set, it must be used to access the hard drive if it is used in another system. Note that the password will not take effect until the system has been rebooted.

Security Menu

Table 14: Fields, Options and Defaults for the Hard Disk Security Submenu of the Security Menu

Menu Field Options Default Description

Set User Password:

Password Entry on Boot:

___

■

Disabled

■

Enabled

[Enter] Sets, changes or cancels the Drive1 USer Password. The Drive1 User Password may

[Enabled] When set to disabled, entry of a Hard Disk Password is not required before OS boot.

be up to seven characters long and must include only letters or numbers (no symbols). Passwords are NOT case-sensitive. When a Drive1 User Password is set, it must be used to access the modular hard drive if it is used in another system. Note that the password will not take effect until the system has been rebooted.

(The hard disk is still password-protected without password entry.)

LifeBook S Series Notebook BIOS

Owner Information Submenu of the Security Menu

The Owner Information Submenu is for setting owner information. Note that Owner Information cannot be set without having entered a supervisor’s password.

Main Advanced Security Power Savings Exit

PhoenixBIOS Setup Utility

Owner Information

Item Specific Help

Owner Information Is: Clear

Set Owner Information [Enter]

Foreground Color: [Gray] Background Color: [Black]

F1 Help ESC Exit

Select Item Select Menu

-/Space

Change Values

Enter

Select Sub-Menu

▲

F9 Setup Defaults F10 Save and Exit

Figure 15. Owner Information Submenu

Table 15: Fields, Options and Defaults for the Owner Information Submenu of the Security Menu

Note: The fields on this submenu cannot be changed unless the Supervisor Password is set.

Menu Field Options Default Description

Owner Information Is:

Set Owner Information:

Foreground Color:

Background Color:

–— Clear Display only.

–— [Enter] Field to write owner infor-

■

Black Blue Green Cyan

■

Red

■

Magenta

■

Brown

■

White

■

Red

■

Magenta

■

Brown

■

White

■

Gray

■

Light Blue

■

Light Green

■

Light Cyan

■

Gray

■

Light Blue

■

Light Green

■

Light Cyan

■

Light Red

■

Light Magenta

■

Yellow

■

Bright White

■

Light Red

■

Light Magenta

■

Yellow

■

Bright White

[Gray] Set foreground color.

[Black] Sets background color.

mation, e.g., your name.

Security Menu

Security Chip Setting Submenu of the Security Menu

The Security Chip Setting submenu is used to enable or disabled the embedded security chip.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Security Chip Setting

Security Chip: [Disabled] Clear Security Chip [Enter]

Security Chip State: Disabled Deactivated

F1 Help ESC Exit

Select Item Select Menu

-/Space Enter

Figure 16. Security Chip Setting Submenu

Change Values Select Sub-Menu

Menu Field Options Default Description

Security Chip:

■

Disabled

■

Enabled

[Disabled] Allows you to enable or disable the security chip. Note that this is only active if

a Supervisor Password has been entered. A reboot is required after exit to configure the Security Chip correctly. Clear Security Chip option becomes selectable after reboot.

Item Specific Help

▲

F9 Setup Defaults F10 Save and Exit

Clear Security Chip –— [Enter] This field is not selectable until after the security chip is enabled and the system

■

Security Chip State:

Disabled

■

Deactivated

–— Display only, to indicate the state of the chip if it has been disabled or

is rebooted.

deactivated.

Exiting from the Security Menu

When you have finished setting the parameters on the Security Menu, you can either exit from setup utility or move to another menu. If you wish to exit from setup utility, press the [Esc] key to go to the Exit Menu. If you wish to move to another menu, use the cursor keys.

LifeBook S Series Notebook BIOS

BOOT MENU – SELECTING THE OPERATING SYSTEM SOURCE

The Boot Menu is used to select the order in which the BIOS searches sources for the operating system. Follow the instructions for Navigating Through the Setup Utility to make any changes. (See Navigating Through the

Setup Utility on page 2 for more information)

PhoenixBIOS Setup Utility

Main Advanced Security Boot Info Exit

Quick Boot: [Enabled] Boot Time Diagnostic Screen: [Disabled] Boot Menu: [Enabled] Preboot Execution Environment: [Enabled]

▲

Boot Device Priority

The following tables show the names of the menu fields for the Boot menu and its submenu, all of the options for each field, the default settings and a description of the field's function and any special information needed to help understand the field's use.

Item Specific Help

[Disabled] All diagnostic tests will be done.

[Enabled] Some diagnostic tests may be skipped while booting to speed up.

F1 Help ESC Exit

Select Item Select Menu

-/Space Enter

Change Values

▲

Select Sub-Menu

Figure 17. Boot Menu

Table 17: Fields, Options and Defaults for the Boot Menu

Menu Field Options Default Description

Quick Boot:

Boot Time Diagnostic Screen:

Boot Menu:

Preboot Execution Environment:

Boot Device Priority:

■

Disabled

■

Enabled

■

Disabled

■

Enabled

■

Disabled

■

Enabled

■

Disabled

■

Enabled

Selects the Boot Device Priority submenu

[Enabled] Turns on and off booting with a truncated set of Power On Self

[Disabled] Turns on and off display of test results instead of Fujitsu logo screen

[Enabled] When disabled, the boot menu is disabled and the F12 key is

[Enabled] Turns on and off boot from network server options.

Tests. (Fewer tests mean faster turn on.)

during Power On Self Test.

ignored. When enabled, the boot menu is enabled. Note: This field cannot be changed unless the Supervisor Password is set.

This menu allows setting up the source for the operating system. See “Boot Device Priority Submenu” in the following section.

F9 Setup Defaults F10 Save and Exit

Boot Menu

Boot Device Priority Submenu of the Boot Menu

The Boot Device Priority submenu is for setting the order of checking of sources for the operating system.

■

Be careful of the operating environment when booting from a CD or you may overwrite files by mistake.

■

A bootable CD-ROM has either a floppy disk format or a hard drive format. When the bootable CD-ROM is used, the drive allocations change automatically without changing the BIOS setup. If a floppy disk format is used, the CD-ROM becomes Drive A. The CD-ROM will only take drive C: (hard drive format) if the internal hard drive is not present or is disabled. The bootable CD-ROM can never use a C: designation if a formatted internal hard drive is present since the C: designator is always reserved for the internal hard drive.The boot sequence ignores the new drive designations, however, your application software will use the new designations.

Main Advanced Security Power Savings Boot

Boot Device Priority

Boot priority order: 1: Floppy Disk Drive 2: Drive0: FUJITSU MHV2060BH 3: Drive1: None 4: CD/DVD Drive 5: NETWORK: B02 D00 Yukon PXE 6: 7: 8: Excluded from boot order: : USB MEMORY: None : USB HDD: None

F1 Help ESC Exit

Select Item Select Menu

PhoenixBIOS Setup Utility

Keys used to view or configure devices:

<+>/<Space> or <-> moves the device up or down. <x> exclude or include the device to boot.

-/Space

Change Values

Enter

▲

Select Sub-Menu

Item Specific Help

F9 Setup Defaults F10 Save and Exit

Figure 18. Boot Device Priority Submenu

Table 18: Fields, Options and Defaults for the Boot Device Priority Submenu of the Boot Menu

Menu Field Description

Boot priority order: 1: Floppy Disk Drive 2: Drive0: 3: Drive1: 4: CD/DVD Drive 5: NETWORK: 6: 7: 8: Excluded from boot order: : USB MEMORY: : USB HDD:

The boot selections determine the order in which the BIOS searches for the operating system during a startup sequence. To change the order, highlight one source by using the [up] or [down] cursor keys and then press the [+] or [-] key to change the order number. Tapping [x] removes from the list a device that is not installed. Tapping [x] on an item in the Excluded list adds the device to the Boot priority list. Be sure to save your changed order when you exit the BIOS setup utility.

NOTE: Be aware that if you use the CD-ROM drive as the first boot device, certain files may be overwritten, depending upon your operating environment.

Exiting from Boot Menu

When you have finished setting the boot parameters with the Boot Menu, you can either exit from the setup utility or move to another menu. If you wish to exit from the setup utility press the [Esc] key to go to the Exit Menu. If you wish to move to another menu, use the cursor keys.

LifeBook S Series Notebook BIOS

INFO MENU – DISPLAYS BASIC SYSTEM INFORMATION

The Info menu is a display only screens that provides the configuration information for your notebook.

The following table shows the names of the menu fields for the Info menu and the information displayed in those fields. These fields are for information purposes only, and are not editable.

PhoenixBIOS Setup Utility

Main Advanced Security Boot Info Exit

BIOS Version: 1.04 BIOS Date: 12/27/2006 BIOS Area: E000h - FFFFh

CPU Type: Genuine Intel(R) CPU T2400 CPU Speed: 1.83 GHz L1 Cache: 128 KB L2 Cache: 2048 KB

Total Memory: 1024 MB Memory Slot 1: 512 MB DDR2 SDRAM Memory Slot 2: 512 MB DDR2 SDRAM

The information, including CPU type and speed, and total memory, displayed on this screen varies according to the unit you purchased.

F1 Help ESC Exit

Select Item Select Menu

-/Space Change Values Enter Select Sub-Menu

Figure 19. Info Menu

▲

F9 Setup Defaults F10 Save and Exit

Table 19: Fields, Options and Defaults for the Info Menu

Note that the parameters listed in the following table may be different, depending upon your system configuration.

Menu Field Default Menu Field Default

BIOS Version: 1.XX L1 Cache: 128 KB

BIOS Date: XX/XX/XXXX L2 Cache: 2048 KB

BIOS Area: E000h – FFFFh Total Memory: 1024 MB

CPU Type: Genuine Intel(R) CPU T2400 Memory Slot 1: 512 MB DDR2 SDRAM

CPU Speed: 1.83 GHz Memory Slot 2: 512 MB DDR2 SDRAM

Exit Menu

EXIT MENU – LEAVING THE SETUP UTILITY

The Exit Menu is used to leave the setup utility. Follow the instructions for Navigating Through the Setup Utility to make any changes. (See Navigating Through the Setup Utility on page 2 for more information). The following table shows the names of the menu fields for the Exit menu, the default settings and a description of the field's function and any special information needed to help understand the field's use.

Main Advanced Security Boot Exit

Exit Saving Changes Exit Discarding Changes Load Setup Defaults Discard Changes Save Changes Save Changes and Power Off

F1 Help ESC Exit

Select Item Select Menu

PhoenixBIOS Setup Utility

-/Space Change Values Enter Select Sub-Menu

Figure 20. Exit Menu

Table 20: Fields, Options and Defaults for the Exit Menu

Menu Field Description

Exit Saving Changes

Exit Saving Changes and Exit will store all the entries on every menu of the setup utility to the BIOS memory and then exit the setup utility. A confirmation message Save Configuration changes and exit now? [Yes] [No] will be displayed.

Item Specific Help

Exit System Setup and save your changes to CMOS.

▲

F9 Setup Defaults F10 Save and Exit

Exit Discarding Changes

Load Setup Defaults

Discard Changes Selecting Discard Changes will load the previous values in BIOS memory for all menu fields. The message Load

Save Changes Selecting Save Changes causes the new settings in all menus to be written to the BIOS memory. The message Save

Save Changes and Power Off

Selecting Exit Discarding Changes and Exit will exit the setup utility with out writing to the BIOS memory. When the BIOS recognizes this selection it will load the operating system and begin operation.

Selecting Load Setup Defaults will load the factory preset default values for all menu fields, then display the message Load default configuration now? [Yes] [No]. When confirmed the setup utility will return to the Exit Menu. To return to another menu follow the directions in the Navigating Through the Setup Utility Section.

previous configuration now? [Yes] [No] will be displayed. When confirmed the utility will return to the Exit menu. To return to another menu, follow the directions in the Navigating Through the Setup Utility Section.

configuration changes now? [Yes] [No] will be displayed. When confirmed, the setup utility will return to the Exit menu. To go to another menu, follow the directions in the Navigating Through the Setup Utility section.

Selecting Save Changes and Power Off will cause the new settings in all menus to be written to the BIOS memory, then power the system off. The message Save configuration changes now and power off? [Yes] [No] will be displayed. When confirmed, the setup utility shut down the system.

Fujitsu LifeBook S7110 BIOS Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
