1. BIOS setup

BIOS SETUP UTILITY

The BIOS Setup Utility is a program that sets up the operating environment for your notebook. Your
BIOS is set at the factory for normal operating condi-tions, therefore there is no need to set or change
the BIOS environment to operate your notebook.

The BIOS Setup Utility configures:

• Device control feature parameters, such as changing I/O addresses and boot devices.

• System Data Security feature parameters, such as passwords.

Entering the BIOS Setup Utility

To enter the BIOS Setup Utility do the following:

1. Turn on or restart your notebook.

2. Press the [F2] key once the Fujitsu logo appears on the screen. This will open the main menu of
the BIOS Setup Utility with the current settings displayed.

3. Press the [RIGHT ARROW] or [LEFT ARROW] key to scroll through the other setup menus to
review or alter the current settings.

Navigating Through the Setup Utility

The BIOS setup utility consists of seven menus: Main, Advanced, Security, Power, Boot, Info and
Exit. This document explains each menu in turn including all submenus and setup items.

The following procedures allow you to navigate the setup utility menus:

1. To select a menu, use the cursor keys:[←], [→].

2. To select a field within a menu or a submenu, use the cursor keys:[ ↑], [ ↓].

3. To select the different values for each field, press the [Spacebar] to change to the next higher
selection and [F5] or [-] to go to the next lower selection.

4. To activate a submenu press the [Enter] key.

5. To return to a menu from a submenu, press the [Esc] key.

6. To go to the Exit menu from any other menu, press the [Esc] key.

Critical Point

Selecting a field causes a help message about that field to be displayed on the right-hand
side of the screen.
Pressing the Enter key with the highlight on a selection that is not a submenu or auto selec­tion will cause a list of all options for that item to be displayed. Pressing the Enter key again
will select the highlighted choice.

7. Pressing the [F9] key resets all items in the BIOS to the default values.

8. Pressing the [F10] key sav es the current configuration and e xit the BIOS Setup Utility. You will be
asked to verify this selection before it is executed.

9. Pressing the [F1] key gives you a general help screen.

2

Entering the Setup Utility After a Configuration Change or System Failure

If there has been a change in the system configuration that does not agree with the parameter
settings stored in your BIOS memory, or there is a failure in the system, the system beeps and/or
displays an error message after the P o wer On Self Test (POST). If the failure is not too sev ere, it will
give you the opportunity to modify the settings of the setup utility , as described in the f ollowing steps:

1. When you turn on or restart the computer there is a beep and/or the following message appears

on the screen:

Error message - please run SETUP program Press <F1> key to continue, <F2> to run
SETUP

2. If an error message is displayed on the screen, and you want to continue with the boot process

and start the operating system anyway, press the [F1] key.

CAUTION

If your notebook beeps a series of beeps that sounds like a code and the display is blank,
please refer to the Troubleshooting Section. The Troubleshooting Section includes a list of
error messages and their meanings.

Critical Point

If your data security settings require it, you may be ask ed for a pass word bef ore the operating
system will be opened.

3. If an error message is displayed on the screen, and y ou w ant to enter the setup utility, press the

[F2] key.

4. When the setup utility starts with a fault present, the system displays the following message:

Warning!
Error message
[Continue]

5. Press any key to enter the setup utility. The system will then display the Main Menu with current

parameters values.

3

MAIN MENU

SETTING STANDARD SYSTEM PARAMETERS

The Main Menu allows you to set or view the current system parameters. Follow the instructions for
Navi-gating Through The Setup Utility to make any changes. (See Navigating Through the Setup
Utility on page 2 for more information)
The following tables show the names of the menu fields for the Main menu and its submenus, all of
the options for each field, the default settings and a description of the field’ s function and any special
information needed to help understand the field’s use. Note that the actual drive labels shown may
vary.

Critical Point

System Time and System Date can also be set from your oper ating system without using the
setup utility. Use the calendar and time icon on your Windows Control panel or type time or
date from the MS-DOS prompt.

Main Advanced Security Power Boot Info Exit

System Time: [02:34:56]
System Date: [05/09/2001]

Floppy Disk A: [Disabled]

:Primary Master: [XXXX]
:Primary Slave: [XXXX]

Language: [English (US)]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

Item Specific Help

Adjust calendar clock

<Tab>, <Shift-Tab>, or
<Enter> selects field.

Figure 1. Main Menu

4

Menu Field

System Time:

System Date:

Floppy Disk A:

Primary Master:

Primary Slave:

Language:

Table 1: Fields, Options and Defaults for the Main Menu

Options

—

—

• Disabled

• 1.44/1.2 MB 3.5"

• Selects Primary
Master submenu

• Selects Primary
Slave submenu

• English (US)

• Japanese (JP)

Default

—

—

[Disabled]

The product # of
the Hard Drive

The product # of
the CD-ROM or
DVD/CD-RW

[English (US)]

Description

Sets and displays the current time.
Time is in a 24 hour format of
hours:minutes:seconds with 2 digits
for each. (HH:MM:SS). Example:
16:45:57. You may change each
segment of the time separately.
Move between the segments with
the [Tab] key and/or [Shift] + [Tab]
keys.

Sets and displays the current date.
Date is in a month/day/year numeric
format with 2 digits each for month
and day and 4 digits for year. (MM/
DD/YYYY) for example: 03/20/1998.
You may change each segment of
the date separately. Move between
the segments with the [Tab] key and/
or [Shift] + [Tab] keys.

Enables or disables a floppy disk.

Display the type of device on this
ATA/ATAPI interface, if there is one.
Pressing the Enter key selects the
Primary Master submenu allowing
additional device configuration
options for this interface.

Display the type of device on this
ATA/ATAPI interface, if there is one.
Pressing the Enter key selects the
Secondary Master submenu
allowing additional device
configuration options for this
interface.

The default setting differs between
the US/European and the Japanese
model. Selects the display language
for the BIOS.

5

Primary Master Submenu of the Main Menu

The Primary Master submenu identifies what ATA devices are installed.

Note:

Actual hard drive label shown may v ary. Depending on the drive type, information such as cylinders,
heads and sectors may also be displayed.

Main Advanced Security Power Boot Info Exit

Type: [Auto]
Maximum Capacity: XXXMB

Multi-Sector Transfers: [16 Sectors]
LBA Mode Control: [Enabled]
PIO Transfer Mode: [Fast PIO 4]
DMA Transfer Mode: [Ultra DMA 2]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

Primary Master xxx

Item Specific Help

Select ATA/ATAPI
drive installed here.

[Auto]
The BIOS auto-type
the drive on boot
time.

Except [Auto]
You enter parameters
of the drive.

[None]
The drive is disabled.

Figure 2. Primary Master Submenu

6

Table 2: Fields, Options and Defaults for the Primary Master Submenu of the Main Menu

Menu Field

Type:

Cylinders:

Heads:

Sectors:

Options

• Auto

• None

• CD-ROM

• SuperDisk

• Hard Disk

• A number

between 0 and
65,535

• A number

between 1
and 16

• A number

between 0
and 63

Default

[[Auto]

—

—

—

Description

Selects the ATA/ATAPI device type.
Select Auto to have the type
automatically identified by the BIOS
at POST. If None is selected, all of
the following Set-up items do not
appear. Select CD-ROM if a CD­ROM drive is installed at this
connection. If User is selected, you
must specify the number of Cylin­ders, Heads, and Sectors for the
drive. Select ATAPI Removable if a
removable disk drive is installed at
this connection.

This item appears only when Hard
Disk is selected. When selected, you
can change the value. This field is
changed by incrementing (pressing
the [Spacebar]) or by typing in the
number.

This item appears only when the
type is identified as Hard Disk. When
selected, you can change the value.
This field is changed by
incrementing (pressing the
[Spacebar]) or by typing in the
number.

This item appears only when the
type is identified as Hard Disk. When
selected, you can change the value.
This field is changed by
incrementing (pressing the
[Spacebar]) or by typing in the
number.

7

Table 2: Fields, Options and Defaults for the Primary Master Submenu of the Main Menu

Menu Field

Maximum
Capacity:

Multi-Sector
Transfers:

LBA Mode
Control:

PIO T ransf er
Mode:

DMA T r ansf er
Mode:

Options

Display only

• Disabled

• 2 Sectors

• 4 Sectors

• 8 Sectors

• 16 Sectors

• 32 Sectors

• 64 Sectors

• 128 Sectors

• Disabled

• Enabled

• Standard

• Fast PIO 1

• Fast PIO 2

• Fast PIO 3

• Fast PIO 4

• Disabled

• Multiword
DMA 1

• Multiword
DMA 2

• Ultra DMA 0

• Ultra DMA 1

• Ultra DMA 2

Default

—

[16 Sectors]

[Enabled]

[Fast PI0 4]

[Ultra DMA 2]

Description

Displays the maximum capacity of
the drive calculated from the
parameters of the hard disk when
Auto is selected and the type is
identified as hard disk, or User is
selected.

This option cannot be changed
when Auto is selected. Specify the
number of sectors per block for
multiple sector transfer. MAX refers
to the size the disk returns when
required.

Enables or disables logical Block
Addressing in place of Cylinder,
Head, Sector addressing. This
option cannot be changed when
Auto is selected.

Selects the method for moving data
to/from the drive. Autotype the drive
to select the optimum transfer mode.
This option cannot be changed
when Auto is selected. Multi-word
DMA is automatically set to mode 1
for Fast PIO 1, Fast PIO 2, Fast PIO
3, and set to mode 2 for Fast PIO 4 /
DMA.

Selects the method for moving data
to/from the drive. Autotype the drive
to select the optimum transfer mode.
This option cannot be changed
when Auto is selected.

8

Primary Slave Submenu of the Main Menu

The Primary Slave submenu is for the internal CD/ D VD/CD-RW driv e. The driv e type is display ed on
this menu as well as the Main menu. Your notebook auto-senses the characteristics of the internal
drive installed.
You will not need to modify these settings, they are displayed for your reference.

Note:

Actual drive labels shown may vary.

Main Advanced Security Power Boot Info Exit

PhoenixBIOS Setup Utility

Primary Slave xxx

Item Specific Help

Type: [Auto]

Multi-Sector Transfers: [Disabled]
LBA Mode Control: [Disabled]
PIO Transfer Mode: [Standard]
DMA Transfer Mode: [Disabled]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

Select ATA/ATAPI
drive installed here.

[Auto]
The BIOS auto-type
the drive on boot
time.

Except [Auto]
You enter parameters
of the drive.

[None]
The drive is disabled.

Figure 3. Primary Slave Submenu

Table 3: Fields, Options and Defaults for the Primary Slave Submenu of the Main Menu

Menu Field

Type:

Options

• Auto

• None

• CD-ROM

• SuperDisk

• Hard Disk

Default

[Auto]

Description

Selects the ATA/ATAPI device type.
Select Auto to have the type
automatically identified by the BIOS
at POST. If None is selected, all of
the following Set-up items do not
appear. Select CD-ROM, SuperDisk
or Hard Disk for appropriate drive
type installed at this connection.

Multi-Sector
Transfers:

• Disabled

• 2 Sectors

• 4 Sectors

• 8 Sectors

[Disabled]

This option cannot be changed
when Auto is selected. Specify the
number of sectors per block for
multiple sector transfer.

• 16 Sectors

• 32 Sectors

• 64 Sectors

• 128 Sectors

9

Table 3: Fields, Options and Defaults for the Primary Slave Submenu of the Main Menu

Menu Field

LBA Mode
Control:

PIO T ransf er
Mode:

DMA T r ansf er
Mode:

Exiting from Main Menu

When you have finished setting the parameters on this menu, you can either exit from the setup
utility , or move to another men u. If you wish to e xit from the setup utility , press the [Esc] k ey or use the
cursor keys to go to the Exit menu or to move to another menu.

Options

• Disabled

• Enabled

• Standard

• Fast PIO 1

• Fast PIO 2

• Fast PIO 3

• Fast PIO 4

• Disabled

• Multiword
DMA 1

• Multiword
DMA 2

• Ultra DMA 0

• Ultra DMA 1

• Ultra DMA 2

Default

[Disabled]

[Standard]

[Disabled]

Description

Enables or disables Logical Block
Addressing in place of Cylinder,
Head, Sector addressing. This
option cannot be changed when
Auto is selected.

Selects the method for moving data
to/from the drive. Autotype the drive
to select the optimum transfer mode.
This option cannot be changed
when Auto is selected. Multi-word
DMA is automatically set to mode 1
for Fast PIO 1, Fast PIO 2, Fast PIO
3, and set to mode 2 for Fast PIO 4 /
DMA.

Selects the method for moving data
to/from the drive. Autotype the drive
to select the optimum transfer mode.
This option cannot be changed
when Auto is selected.

10

ADVANCED MENU

SETTING DEVICE FEATURE CONTROLS

The Advanced Menu allows you to:

• Enable or disable support for Plug & Play.

• Set the I/O addresses for the serial and parallel ports.

• Set the communication mode and Infrared.

• Set the features of the keyboard/mouse.

• Select between the display panel and an external CRT display.

• Enable or disable compensation for your display.

• Configure PCI devices in your system.

• Configure CPU features.

• Configure USB features.

• Configure DMI Event Logging.
Follow the instructions for Navigating Through the Setup Utility to make any changes.

(See Navigating Through the Setup Utility on page 2 for more information)
The following tables show the names of the menu fields f or the Advanced Men u and its submenus, all

of the options for each field, the default settings and a descrip-tion of the field’s function, and any
special information needed to help understand the field’s use.

Main Advanced Security Power Boot Info Exit

Plug & Play O/S [Yes]
Protected Device Configuration [No]

:Serial/Parallel Port Configurations
:Keyboard/Mouse Features
:Video Features
:Internal Devices Configurations
:PCI Configuration
:CPU Features
:USB Features

:Event Logging

PhoenixBIOS Setup Utility

Item Specific Help

[No]
The BIOS configures
also non-boot devices.
Select if you are
using a non-Plug &
Play OS or a non-ACPI
OS

[Yes]
The BIOS configures
only boot devices.

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

Figure 4. Advanced Menu

11

Menu Field

Plug & Play O/S:

Protected Device
Configuration:

Serial/Parallel
Port Configura­tions

Keyboard/Mouse
Features

Video Features

Internal Device
Configurations

PCI Configura­tions

CPU Features
Page

USB Features
Page

Event Logging

Table 4: Fields, Options and Defaults for the Advanced Menu

Options

•No

•Yes

•No

•Yes

—

—

—

—

—

—

—

—

Default

[Yes]

[No]

—

—

—

—

—

—

—

—

Description

Select Yes if you are using a Plug &
Play capable operating system.
Select No if you need the BIOS to
configure non-boot devices.

No: allows Plug & Play operating
system to change device system
settings.
Yes: prevents a Plug & Play
operating system from changing
system settings.
*ACPI operating system ignores this
setting.

When selected, opens the Serial/
Parallel Port Configurations
submenu which allows the user to
modify settings for serial, infrared
and parallel ports.

When selected, opens the Key­board/Mouse Features submenu,
which allows setting external and
internal keyboard andmouse
parameters.

When selected, opens the Video
Features submenu, which allows
setting of the display parameters,
including routing of video signals to
different displays.

When selected, opens the Internal
Device Configuration submenu,
which allows enabling or disabling
the Floppy Disk, IDE, Modem and
LAN Controllers.

When selected, opens additional
menus to configure PCI devices.

Configures CPU features.

Configures USB features.

When selected, opens the event
logging submenu.

12

Serial/Parallel Port Configuration Submenu of the Advanced Menu

The Serial/Parallel Port Configuration submenu provides the ability to set the I/O addresses and
interrupt levels for the serial, infrared, and parallel ports of your notebook.

CAUTION

CAUTION

I/O addresses, DMA channels, and Interrupt levels can be entered in various ways, including

I/O addresses, DMA channels, and Interrupt levels can be entered in various ways, including
via the BIOS setup utility, the control software for the I/O device, or the hardware. If any two

via the BIOS setup utility, the control software for the I/O device, or the hardware. If any two
ports or devices, serial or parallel, have the same I/O address assigned y our notebook will not

ports or devices, serial or parallel, have the same I/O address assigned y our notebook will not
function normally . Please keep a record of original settings bef ore making any changes in the

function normally . Please keep a record of original settings bef ore making any changes in the
event that a restoration is required. See your hardware and software documentation as well

event that a restoration is required. See your hardware and software documentation as well
as the setup utility to determine settings, limitations, etc.

as the setup utility to determine settings, limitations, etc.
The BIOS will warn you of a resource conflict by placing a yello w asterisk next to each de vice
that is in conflict.

Critical Point

To prevent IRQ and address conflicts, avoid changing the default settings.
All I/O addresses in Table 5 are in hexadecimal.

Main Advanced Security Power Boot Info Exit

Serial/Parallel Port Configurations

Serial Port: [Enabled]

I/O Address: [3F8-3FF]
Interrupt: [IRQ 4]

Infrared Port: [Enabled]

Mode: [FIR]
I/O Address: [2E8 - 2EF]
Interrupt: [IRQ 3]
I/O Address: [118-11F]
DMA Channel: [DMA 3]

Parallel Port: [Enabled]

Mode: [Bi-directional]
I/O Address: [378-37F]
Interrupt: [IRQ 7]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

Item Specific Help

[Disabled]
The port is disabled.

[Enabled]
The port is enabled
with user configura­tion.

[Auto]
The port is
configured depending
on ‘Plug & Play OS’
setting.

Figure 5. Serial/Parallel Port Configuration Submenu

13

Table 5: Fields, Options and Defaults for the Serial/Parallel Port Configuration Submenu of

the Advanced Menu

Menu Field

Serial Port:

I/O Address:

Interrupt:

Infrared Port:

Mode:

I/O Address:

Interrupt:

I/O address:

DMA Channel:

Options

• Disabled

• Enabled

• Auto

• 3F8 - 3FF

• 2F8 - 2FF

• 3E8 - 3EF

• 2E8 - 2EF

• IRQ 3

• IRQ 4

• IRQ 5

• Disabled

• Enabled

• Auto

• IrDA

• FIR

• 3F8 - 3FF

• 2F8 - 2FF

• 3E8 - 3EF

• 2E8 - 2EF

• IRQ 3

• IRQ 4

• IRQ 5

• 100 - 107

• 108 - 10F

• 110 - 117

• 118 - 11F

• DMA 1

• DMA 3

Default

[Enabled]

[3F8 - 3FF]

[IRQ 4]

[Enabled]

[FIR]

[2E8 - 2EF]

[IRQ 3]

[118 - 11F]

[DMA 3]

Description

Configures the serial port using
either no configuration (Disabled), a
user defined configuration (Ena­bled), or by allowing the BIOS or OS
to choose the configuration (Auto).

Allows user to set the serial port
base I/O address when serial port is
Enabled.

Allows user to set the serial port
interrupt when serial port is Enabled.

Configures the infrared port using
either no configuration (Disabled), a
user defined configuration (Ena­bled), or by allowing the BIOS or OS
to choose the configuration (Auto).

When the infrared port is enabled
this option is available allowing the
user to set the mode for the infrared
port.

Allows user to set the infrared port I/
O address when the infrared port is
Enabled.

Allows user to set the infrared port
interrupt when the infrared port is
Enabled.

Allows user to set the infrared port I/
O address when the infrared port is
Enabled.

Allows user to set the infrared port
DMA Channel when the infrared port
is Enabled.

14

Table 5: Fields, Options and Defaults for the Serial/Parallel Port Configuration Submenu of

Menu Field

Parallel Port:

Mode:

I/O address:

Interrupt:

Options

• Disabled

• Enabled

• Auto

• Output Only

• Bi-directional

• ECP

• 378 - 37F

• 278 - 27F

• 3BC - 3BF

• IRQ 5

• IRQ 7

the Advanced Menu

Default

[Enabled]

[Bi-directional]

[378 - 37F]

[IRQ 7]

Description

Configures the parallel port using
either no configuration (Disabled), a
user defined configuration (Ena­bled), or by allowing the BIOS or OS
to choose the configuration (Auto).

When the parallel port is enabled
this option is available allowing the
user to set the mode for the parallel
port. Bi-directional allows two-way
transfer of information between your
notebook and a connected parallel
device. Output Only (Half Duplex)
allows information to be transferred
in only one direction, from your
notebook to the printer or similar
device. ECP Mode allows communi­cation with the ECP class of parallel
I/O devices.

Allows user to set the parallel port
base I/O address when the parallel
port is Enabled.

Allows user to set the parallel port
interrupt when the parallel port is
Enabled.

15

Keyboard/Mouse Features Submenu of the Advanced Menu

The Keyboard/Mouse F eatures submenu is f or setting the par ameters of the integr ated and external
mouse and keyboard.

Table 6: Fields, Options and Defaults for the Keyboard/Mouse Submenu of

Menu Field

Numlock:

Hot Plug:

Internal Pointing
Device:

Main Advanced Security Power Boot Info Exit

Numlock: [Auto]
Hot Plug: [Enabled]
Internal Pointing Device: [Auto Disabled]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

Item Specific Help

Select power-on state
for Numlock.

Figure 6. Keyboard/Mouse Features Submenu

the Advanced Menu

Options

• Auto

•On

• Off

• Disabled

• Enabled

Default

[Auto]

[Enabled]

Description

Sets the NumLock function state
when the computer completes
booting.

Enables and disables the ability to
plug a mouse or keyboard into the
PS/2 port and have it immediately
recognized and active.

• Auto Disabled

• Manual Setting

• Always Enabled

• Always Disabled

[Auto Disabled]

Sets the device controlling the
mouse cursor on the screen.
Always Enabled makes the pointing
device always enabled whether
there is an external mouse or not.
Always Disabled makes the pointing
device always disabled. Auto
Disabled disables the internal
pointing device when an external
pointing device is connected to the
PS/2 port. Manual Setting allows the
device to be enabled or disabled
using a Hot Key.

16

Video Features Submenu of the Advanced Menu

The Video Features Submenu is for setting the display parameters.

Table 7: Fields, Options and Defaults for the Video Features Submenu of

Menu Field

Display:

Compensation:

Main Advanced Security Power Boot Info Exit

Display: [Internal Flat Panel]
Compensation: [Disabled]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

Video Features

Item Specific Help

Select display
terminal.

Figure 7. Video Features Submenu

the Advanced Menu

Options

• Internal
Flat Panel

Default

[Internal Flat­Panel]

Description

Selects where the video signal will
be routed.

• External

• Simultaneous

• Disabled

• Enabled

[Disabled]

Enables or disables compensation
which controls spacing on the
display. When enabled, displays with
less than pixel resolution 800 x 600
will still cover the entire screen.

17

Internal Device Configurations Submenu of the Advanced Menu

The Internal Device Configuration submenu allows the user to configure other internal devices.

Main Advanced Security Power Boot Info Exit

Floppy Disk Controller: [Disabled]
IDE Controller: [Enabled]
LAN Controller: [Auto]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

Internal Device Configuration

Item Specific Help

[Disabled]
Floppy disk drive is
disabled.

[Enabled]
Floppy disk drive is
enabled.

Figure 8. Internal Device Configuration Submenu

Table 8: Fields, Options and Defaults for the Internal Device Configuration Submenu of

the Advanced Menu

Menu Field

Floppy Disk
Controller:

IDE Controller:

LAN Controller:

Options

• Disabled

• Enabled

• Disabled

• Enabled

• Disabled

• Enabled

• Auto

Default

[Disabled]

[Enabled]

[Auto]

Description

Enables or disables the Floppy Disk
Drive.

Enables or disables selected IDE
devices.

Enables or disables the LAN device.
With the AC Power supply the LAN
device is always enabled.
With the battery, the device is
enabled only when the link is active.

18

PCI Configuration Submenu of the Advanced Menu

The PCI Configuration submenu allows the user to reserve specific interrupts (IRQs) for legacy ISA
devices, and to enable or disable built in PCI device modules.

Main Advanced Security Power Boot Info Exit

:IRQ Reservation

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

PCI Configuration

Item Specific Help

Reserve specific
IRQs for use by
legacy ISA devices.

Figure 9. PCI Configurations Submenu

Table 9: Fields, Options and Defaults for the PCI Configuration Submenu of

the Advanced Menu

Menu Field

IRQ Reservation

Options

—

Default

—

Description

Reserve specific IRQs for use by
legacy ISA devices.

19

IRQ Reservation Submenu of the PCI Configuration Submenu

The IRQ Reservation submenu of the PCI Configuration submenu allows the user to mark various
IRQs as reserved for use by legacy ISA de vices. When an IRQ is reserved, the BIOS does not use it
for embedded PCI or ISA devices.

Critical Point

Only IRQ’s 9, 10, & 11 can be reserved without conflict.

Main Advanced Security Power Boot Info Exit

IRQ 3: [Available]
IRQ 4: [Available]
IRQ 5: [Available]
IRQ 7: [Available]
IRQ 9: [Available]
IRQ 10: [Available]
IRQ 11: [Available]
IRQ 15: [Available]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

IRQ Reservation

Item Specific Help

Reserve the
specified IRQ for
use by legacy ISA
devices.

Figure 10. IRQ Reservation Submenu

20

Table 10: Fields, Options and Defaults for the IRQ Reservation Submenu of the

Menu Field

IRQ 3:

IRQ 4:

IRQ 5:

IRQ 7:

IRQ 9:

IRQ 10:

IRQ 11:

IRQ 15:

PCI Configuration Submenu of the Advanced Menu

Options

• Available

• Reserved

• Available

• Reserved

• Available

• Reserved

• Available

• Reserved

• Available

• Reserved

• Available

• Reserved

• Available

• Reserved

• Available

• Reserved

Default

[Available]

[Available]

[Available]

[Available]

[Available]

[Available]

[Available]

[Available]

Description

Reserves IRQ 3. If Reserved is
selected, the BIOS reserves IRQ 3
for use by legacy ISA devices and
does not use it for embedded PCI or
ISA devices. IRQ 3 is removed from
the IRQ bitmap in the PCI IRQ
routing table.

Reserves IRQ 4.

Reserves IRQ 5.

Reserves IRQ 7.

Reserves IRQ 9.

Reserves IRQ 10.

Reserves IRQ 11.

Reserves IRQ 15.

21

CPU Features Submenu of the Advanced Menu

The CPU Features Submenu configures the system Processor.

Main Advanced Security Power Boot Info Exit

Intel(R) SpeedStep(TM) Technology [Auto]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

CPU Features

Item Specific Help

Configures Processor
Serial Number features
of Pentium(R) III
processor.

[Disabled]
Processor Serial
Number feature is
disabled.

[Enabled]
Processor Serial
Number feature is
enabled.

Figure 11. CPU Features Submenu

Table 11: Fields, Options and Defaults for the CPU Features Submenu of the

Advanced Menu

Menu Field

(R)

Intel
SpeedStep
Technology

(TM)

Options

• Auto

• Max. Perf.

• Batt. Opt.

• Disabled

Default

[Auto]

Description

When Auto is selected, the CPU
speed changes based upon the
power source change. When Max.
Perf. is selected, the CPU speed is
maximized. When Batt. Opt. is
selected, the CPU speed is
optimized for battery operation.
When Disabled is selected, the CPU
speed is fixed to the battery
optimized speed.

22

USB Features Submenu of the Advanced Menu

The USB Features Submenu configures the USB features for your system.

Main Advanced Security Power Boot Info Exit

USB Floppy Disk: [Enabled]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

USB Features

Item Specific Help

[Disabled]
Legacy Floppy
Emulation is
disabled.

[Enabled]
Legacy Floppy
Emulation is enabled
and USB floppy is
available without
USB aware OS.

Figure 12. USB Features Submenu

Table 12: Fields, Options and Defaults for the USB Features Submenu of the Advanced Menu

Menu Field

USB Floppy Disk:

Options

• Disabled

• Enabled

Default

[Enabled]

Description

When Disabled is selected, legacy
floppy emulation is disabled.
When Enabled is selected, legacy
floppy emulation is enabled and
USB floppy is available without USB­aware OS.

23

Event Logging Submenu of the Advanced Menu

The Event Logging submenu is for setting up the logs for DMI event logging.

Main Advanced Security Power Boot Info Exit

Event Log Capacity: Space Available
Event Log Validity: Valid

View Event Log: [Enter]

Event Logging: [Enabled]

System Boot Event: [Disabled]

Clear all event logs: [No]

Mark Events as Read: [Enter]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

Event Logging

Item Specific Help

Press <Enter> key to
view the contents of
the event log.

Figure 13. Event Logging Submenu

Table 13: Fields, Options and Defaults for the Event Logging Submenu of the

Advanced Menu

Menu Field

Event Log

Options

Default

Space Available

Description

Display only

Capacity:
Event Log Validity:

• Disabled

Valid

Display only

• Enabled

View Event Log:

• Enter

[Enter]

Allows you to view content of event
log.

Event Logging:

System Boot
Event:

Clear All Event
Logs:

Mark Events as
Read:

• Disabled

• Enabled

• Disabled

• Enabled

•No

•Yes

• Enter

[Enabled]

[Disabled]

[No]

[Enter]

Turns event logging on and off for all
DMI events.

Turns event logging on and off for
DMI system boot events.

When set to [Yes] all event logs will
be cleared at next boot.

Allows you to make all events
currently in the event log as read.

24

SECURITY MENU

SECURITY MENU – SETTING THE SECURITY FEATURES

The Security menu allows you to set up the data security features of your notebook to fit your oper­ating needs and to view the current data security configuration. Follow the instructions f or Navigating
Through the Setup Utility to make any changes. (See Na vigating Through the Setup Utility on page 2
for more information)
The following tables sho w the names of the menu fields for the Security menu and its submenus, all
of the options for each field, the default settings and a description of the field’s function and any
special information needed to help understand the field’s use. The def ault condition is no pass w ords
required and no write protection.

Critical Point

If you make an error when re-entering the password a [Warning] will be displayed on the
screen. To try again press the Enter key and then retype the password. Press the Esc k ey to
abort the password setting process.
If you set a password, write it down and keep it in a saf e place . If you forget the password you
will have to contact your support representative to regain access to your secured functions
and data.
Boot sector protection must be set to [Normal] to install or upgrade an operating system.

CAUTION

If the Password on Resume is Enabled and the Password on Boot is Disabled you will not
have to type your password upon resuming the system from the Suspend or Save-to-Disk
modes. Password on Resume will work only if Password boot is enabled.
Entering a password incorrectly 3 times in a row will cause the keyboard and mouse to be
locked out and the warning [System Disabled] to be displayed. If this happens restart the
computer by turning off and on the power with the power s witch and use the correct password
on reboot.

Main Advanced Security Power Boot Info Exit

Supervisor Password Is: Clear
User Password Is: Clear

Set Supervisor Password [Enter]
Set User Password [Enter]
Minimum User Password Length: [0]
Password on Boot: [Disabled]
Password on Unattended Boot: [Disabled]
Password on Resume: [Disabled]
Boot from Removable Media: [All]
Floppy Disk Access: [All]

:Hard Disk Security
:Owner Information

Hard Disk Boot Sector: [Normal]
Security Panel on Resume: [Enaled]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

Item Specific Help

Press <Enter> key to
set Supervisor
Password to enable
any password
features.

Then password entry
is required to enter
BIOS Setup.

Figure 14. Security Menu

25

Table 14: Fields, Options and Defaults for the Security Menu

Menu Field

Supervisor
Password is:

User Password is:

Set Supervisor
Password

Set User Pass­word

Options

—

—

[Enter]

[Enter]

Default

Clear

Clear

[Enter]

[Enter]

Description

A display-only field. Set is displayed
when the system Supervisor
Password is set and Clear when it is
not.

A display-only field. Set is displayed
when the general User Password is
set, and Clear when it is not.

Sets, changes or cancels the
Supervisor Password. The Supervi­sor Password may be up to seven
characters long and must include
only letters or numbers (no sym­bols). Passwords are NOT case­sensitive. To cancel a password
press the Enter key instead of
entering characters in the Enter New
Password field and in the Re-enter
New Password field. When a
Supervisor Password is set it must
be used to access the BIOS setup
utility.

This field can only be accessed if
the Supervisor Password is set.
Sets, changes or cancels the User
Password. The User Password may
be up to seven characters long and
must include only letters or numbers
(no symbols). Passwords are NOT
case-sensitive. To cancel a pass­word press the Enter key instead of
entering characters in the Enter New
Password field and in the Re-enter
New Password field. When a User
Password is set it must be used to
access the BIOS setup utility.

Minimum User
Password Length:

26

[0]

[0]

Sets the minimum length for User
Password.

Table 14: Fields, Options and Defaults for the Security Menu

Menu Field

Password on
Boot:

Password on
Unattended Boot:

Password on
Resume:

Floppy Disk
Access:

Boot from
Removable
Media:

Hard Disk
Security:

Owner
Information:

Hard Disk Boot
Sector:

Security Panel
on Resume:

Options

• Disabled

• First Boot

• Every Boot

• Disabled

• Enabled

• Disabled

• Enabled

• All

• Supervisor only

• All

• Supervisor only

–—

–—

• Normal

• Write Protected

• Disabled

• Enabled

Default

[Disabled]

[Disabled]

[Disabled]

[All]

[All]

–—

–—

[Normal]

[Enabled]

Description

When set to Enabled, a password
(User or Supervisor) is required after
the Power On Self Test (POST)
before the operating system will be
read from a disk. When set to
Disabled no password is required. If
no Supervisor Password is set this
feature is not avail-able and no
password is required.

When enabled, the PS/2 keyboard
and mouse are locked out upon
unattended boot (via LAN) until a
password is entered. When both
passwords are set, the USer
password is alwa ys used to loc k.
Entering a password before an OS
boot is disabled during unattended
boot.

When set to Enabled, a password
(User or Supervisor) is required
before the operating system will
resume. When set to Disabled no
password is required. If no Supervi­sor Password is set this feature is
not available and no password is
required.

Enable password allows supervisor
access only.

Enable password allows supervisor
access only.

Configures hard disk security
features.

Sets Owner information.

Sets protection mode for hard disk
drive.

Allows you to enable or disable the
Security Panel upon Resume from
Suspend.

27

Hard Disk Security Submenu of the Security Menu

The Hard Disk Security Submenu is for configuring hard disk security features.

Main Advanced Security Power Boot Info Exit

Primary Master: [Disabled]
Primary Slave: [Disabled]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

Hard Disk Security

Item Specific Help

[Disabled]
The feature is
disabled.

[Enabled]
The hard disk is
locked with the
password.
Data in the locked
disk cannot be read
on any systems other
than the original
system on which it
is locked or systems
that have the
identical password
setting.

Figure 15. Hard Disk Security Submenu

Table 15: Fields, Options and Defaults for the Hard Disk Security Submenu of the

Security Menu

Menu Field

Primary Master:

Options

• Disabled

• Enabled

Default

[Disabled]

Description

Disabled: No password protection.
Enabled: Hard drive password
protected. Password must be
entered to access data on drive.

Primary Slave:

• Disabled

• Enabled

[Disabled]

Disabled: No password protection.
Enabled: Hard drive password
protected. Password must be
entered to access data on drive.

28

Owner Information Submenu of the Security Menu

The Owner Information Submenu is for setting owner information.

Main Advanced Security Power Boot Info Exit

Owner Information Is: Clear

Set Owner Information: [Enter]

Foreground Color: [Gray]
Background Color: [Black]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

Owner Information

Item Specific Help

Press <Enter> key
to set owner
information. Up to
80 characters can
be set. Available
characters are
ASCII codes from 32
through 126.

The owner
information is
always displayed at
the bottom line of
the screen during
POST.

Figure 16. Owner Information Submenu

29

Table 16: Fields, Options and Defaults for the Owner Information Submenu of the

Security Menu

Menu Field

Owner Informa­tion Is:

Set Owner
Information:

Foreground
Color:

Background
Color:

Options

—

—

• Black

• Blue

• Green

• Cyan

• Red

• Magenta

• Brown

• White

• Gray

• Light Blue

• Light Green

• Light Cyan

• Light Red

• Light Magenta

• Yellow

• Bright White

• Black

• Blue

• Green

• Cyan

• Red

• Magenta

• Brown

• White

• Gray

• Light Blue

• Light Green

• Light Cyan

• Light Red

• Light Magenta

• Yellow

• Bright White

Default

Clear

[Enter]

[Gray]

[Black]

Description

Display only.

Field to write owner information i.e.
name.

Set foreground color.

Sets background color.

Exiting from the Security Menu

When you have finished setting the par ameters on the Security Menu, you can either e xit from setup
utility or move to another menu. If you wish to e xit from setup utility, press the Esc key to go to the Exit
Menu. If you wish to move to another menu, use the cursor keys.

30

POWER MENU

SETTING POWER MANAGEMENT FEATURES

The Power menu allows you to set and change the power management parameters. Follow the
instructions for Navigating Through the Setup Utility to mak e any changes . (See Navigating Through
the Setup Utility on page 2 for more information) The following tables show the names of the menu
fields for the P ower men u and its submenus , all of the options for each field, the default settings and
a description of the field’s function and any special inf ormation needed to help understand the field’s
use.

Critical Point

In Windows 98 Auto-suspend Timeout, Hard Disk Timeout, and Video Timeout features are
available exclusively through the operating system.
When resuming from a Save-to-Disk suspension there will be a delay while the contents of
system memory and operating parameters are loaded from the hard drive.

CAUTION

In Save-to-Disk mode there is no indication on the Status Indicator to let you know you are
suspended rather than shut off from the power switch. Y ou may want to make a habit of alw ays
trying the Suspend/ Resume button before using the power switch.
Resume on Modem ring when enabled will draw power from the bridge battery alone when
your system is running off battery power. This ma y potentially dr ain y our bridge battery. Disa­bling Resume on Modem ring will prevent this from happening.

Main Advanced Security Power Boot Info Exit

Power Savings: [Customized]

Hard Disk Timeout: [Off]
Video Timeout: [Off]
Standby Timeout: [4 Minutes]
Auto Suspend Timeout: [15 Minutes]

Suspend Mode: [Suspend]

Auto Save To Disk: [Off]

Resume On Modem Ring: [Off]
Resume On Time: [Off]
Resume Time: [00:00:00]

:Advanced Features

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

Item Specific Help

Select Power
Management Mode.
Choosing modes
changes system power
management settings.
Maximum Power Savings
conserves the
greatest amount of
system power while
Maximum Performance
conserves power but
allows greatest
system performance.
To alter these
settings, choose
Customize. To turn
off power management,
choose Disable.

Figure 17. Power Menu

31

Table 17: Fields, Options and Defaults for the Power Menu

Menu Field

Power Sa vings:

Hard Disk
Timeout:

Display Timeout:

Standby Timeout:

Auto Suspend
Timeout:

Options

• Disabled

• Customized

• Maximum

Power Savings

• Maximum
Performance

• Off

• 30 seconds to

20 Minute

• Off

• 2 to 20 Minutes

• Off

• 1 to 16 Minutes

• Off

• 5 to 60 minutes

Default

[Customized]

[Off]

[Off]

[4 Minutes]

[15 Minutes]

Description

Sets the power savings parameters
to a factory installed combination of
parameters, a custom set of
parameters set by you or no power
saving features.

Sets the length of time that the hard
drive can be inactive before your
notebook automatically turns off the
power to the hard drive controller
and drive motor. If you choose a
factory installed combination of
parameters this field will display the
setting. If you choose to customize
the parameters you will be able to
set this yourself. The options
available vary from Off, which has
no inactivity shutoff, to 20 minutes.

Sets the length of time without any
user input device activity before the
display is turned off. If you choose a
factory combination of parameters,
this field will display the setting. If
you choose to customize the
parameters, you will be able to set
this yourself.
Off has no inactivity shutoff.

Sets the length of time without any
user input device activity before the
CPU is set to half speed and the
display and the hard drive are turned
off. If you choose a factory combina­tion of parameters this field will
display the setting. If you choose to
customize the parameters you will
be able to set this yourself.

Sets the length of time without any I/
O activity before your notebook goes
into Suspend mode. If you choose a
factory combination of parameters
this field will display that setting. If
you choose to customize the
parameters you will be able to set
this yourself. Off has no inactivity
suspension.

32

Table 17: Fields, Options and Defaults for the Power Menu

Menu Field

Suspend
Mode:

Auto Save To
Disk:

Resume On
Modem Ring:

Resume On Time:

Resume Time:

Advanced
Features:

Options

• Suspend

• Save to Disk

• Off

• After 1 Hour

• Off

• On

• Off

• On

• 00:00:00 to

23:59:59

—

Default

[Suspend]

[Off]

[Off]

[Off]

[00:00:00]

—

Description

Sets the form of suspension state. If
you choose Suspend, you will
suspend operation with power to
system memory, and everything else
powered down or in a very low
power state. If you choose Save-to­Disk your notebook will save all of
system memory and the operating
parameters to the hard drive before
turning your notebook to the
pseudo-off condition.

When set to After 1 Hour your
notebook will automatically save all
of system memory and the operating
parameters to the hard drive and go
to the pseudo-off if you leave your
notebook in Suspend mode for an
hour.

Sets whether or not to Resume from
a suspension state when a message
is received by telephone line. This
feature will not operate if the Save­to-Disk mode is enabled. This
feature applies to internal and
external modems.

Sets whether or not to resume from
a suspension state at a designated
time. This feature is available from
either the Suspend mode or the
Save-to-Disk mode.

Sets the designated time, on a 24­hour clock, when the notebook is to
automatically resume operation from
the Suspend state. The format of the
clock setting is hours: min utes:
seconds. Each segment of the time
is set separately, either by
incrementing or by typing in the
numbers. You move between the
segments with the [Tab] key or the
[Shift]+[Tab] keys. This only applies
when Resume on Time is set to On.

When selected, opens the Advanced
Features submenu which allows
setting additional power saving
parameters.

33

Factory Installed Values for Power Saving Profiles

Customized:
Maximum Power Sa vings:
Maximum Perf ormance:
Disabled:
Sample Customized Profile:

(To get even better battery
life keep the display and volume
settings as low as possible and
use the sample customized
profile.)

Hard Disk
Timeout

Off
30 Seconds
Off
Off
2 Minutes

Video
Timeout

Off
2 Minutes
Off
Off
2 Minutes

Standby
Timeout

4 Minutes
1 Minute
Off
Off
1 Minute

Auto
Suspend
Timeout

15 Minutes
5 Minutes
15 Minutes
Off
5 Minutes

34

Advanced Features Submenu of the Power Menu

The Advanced Features submenu is for setting some non-time related power saving parameters.

Main Advanced Security Power Boot Info Exit

PhoenixBIOS Setup Utility

Advanced Features

Item Specific Help

Suspend/Resume Switch: [Enabled]
Lid Closure Suspend: [On]
Lid Open Resume: [On]
Resume On LAN: [Off]
Performence control: [Fixed]

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

Configures the
Suspend/Resume
switch.

Figure 18. Advanced Features Submenu

Table 18: Fields, Options and Defaults for the Advanced Features Submenu of the

Power Menu

Menu Field

Suspend/Resume
Switch:

Options

• Disabled

• Enabled

Default

[Enabled]

Description

Sets the function of the Suspend/
Resume button when your notebook
is in an active state. The resume
function can not be disabled as it
works regardless of any other
settings.

Lid Closure
Suspend:

• Off

• On

[On]

Enables and disables having closure
of the Display panel put your
notebook in Suspend mode.

Lid Open
Resume:

• Off

• On

[On]

Enables and disables having
opening the Display panel acting as
an automatic resume.

Resume of
LAN:

• Off

• On

[Off]

Enables and disables having LAN
activity cause the system to
reactivate from inactivity timeouts.

Performance
control:

• Fixed

• Auto

[Fixed]

Configure the ACPI Performance
Control

Exiting from Power Menu

When you have finished setting the boot parameters with the Power menu, you can either exit from
the setup utility or move to another menu. If you wish to e xit from the setup utility press the Esc k ey to
go to the Exit menu. If you wish to move to another menu, use the cursor keys.

35

BOOT MENU

SELECTING THE OPERATING SYSTEM SOURCE

The Boot Menu is used to select the order in which the BIOS searches sources for the operating
system. Follow the instructions for Navigating Through the Setup Utility to make any changes. (See
Navigating Through the Setup Utility on page 2 for more information)
The following tables show the names of the men u fields for the Boot men u and its submenu, all of the
options for each field, the default settings and a description of the field’s function and any special
information needed to help understand the field’s use.

Menu Field

QuickBoot:

Boot Time
Diagnostic
Screen:

Preboot
Execution
Environment:

Boot Device
Priority:

Main Advanced Security Power Boot Info Exit

Quick Boot: [Enabled]
Boot-time Diagnostic Screen: [Disabled]

Preboot Execution Environment: [Disabled]

:Boot Device Priority

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

Item Specific Help

[Disabled]
All diagnostic test
will be done.

[Enabled]
Some diagnostic tests
may be skipped while
booting to speed up.

[Auto]
Diagnostic tests will
be automatically
skipped or done
according to the
order of the ACPI OS.

Figure 19. Boot Menu

Table 19: Fields, Options and Defaults for the Boot Menu

Options

• Disabled

• Enabled

• Auto

• Disabled

• Enabled

Default

[Enabled]

[Disabled]

Description

Turns on and off booting with a
truncated set of Power On Self Test.
(Fewer tests mean faster turn on.)

Turns on and off display of test
results instead of Fujitsu logo screen
during Power On Self Test.

• Disabled

• Enabled

[Disabled]

—

Turns on and off boot from network
server options.

This menu allows setting up the
source for the operating system.
See “The Boot Device Priority
Submenu” in the following section.

36

The Boot Device Priority Submenu of the Boot Menu

The Boot Device Priority Submenu is for setting the order of checking of sources for the operating
system.

Main Advanced Security Power Boot Info Exit

+ Floppy Disk Drive
+ Hard Disk Drive

ATAPI CD-ROM Drive

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

Boot Device Priority

Item Specific Help

The top device has
the highest priority.

<Enter> expands or
collapses devices
with a + or -.
<Ctrl+Enter> expands
all.
<↑> or <↓> selects a
device.
<+>/<Space> or <->
moves the device up
or down.
<Shift+1> enables or
disables adevice.

Figure 20. Boot Device Priority Submenu

Table 20: Fields, Options and Defaults for the Boot Device Priority Submenu of the

Boot Menu

Menu Field

+Floppy Disk Drive

Options

—

Description

The boot selections determine the order in
which the BIOS searches for the operating
system during a startup sequence. To
change the order highlight one source by
using the [up] or [down] cursor keys and
then press the [+] or [-] key to change the
order number for that source. Be sure to
save your changed order when you exit the

BIOS setup utility.
+Hard Disk Drive
ATAPI CD-ROM

—
—

—

—

Drive

Exiting from Boot Menu

When you have finished setting the boot parameters with the Boot men u, you can either e xit from the
setup utility or move to another menu. If y ou wish to e xit from the setup utility press the Esc ke y to go
to the Exit menu. If you wish to move to another menu, use the cursor keys.

37

INFO MENU

DISPLAYS BASIC SYSTEM INFORMATION

The Info menu is a display only screens that provides the configuration information for your note­book.
The following table shows the names of the menu fields for the Info menu and the information dis­played in those fields. These fields are for inf ormation purposes only , and are not editab le (e xcept for
the Asset Number as in the Point below).

Main Advanced Security Power Boot Info Exit

BIOS Version: 1.XX
BIOS Date: 09/29/2001
BIOS Area: E400h - FFFFh

CPU Type:
CPU Speed: XXX MHz
L1 Cache: 32 KB
L2 Cache: 512 KB

Total Memory: 128 MB

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

Pentium(R) III processor-M

Memory Slot: 128 MB SDRAM

Table 21: Fields, Options and Defaults for the Info Menu

PhoenixBIOS Setup Utility

Item Specific Help

Figure 21. Info Menu

Menu Field

BIOS Version:
BIOS Date:
BIOS Area:
CPU T ype:

CPU Speed:
L1 Cache:
L2 Cache:
T otal Memory:
Memory Slot:

38

Options

—
—
—
—

—
—
—
—
—

Default

1.XX
09/29/2001
E400h – FFFFh
Pentium(R) III

processor-M
XXXMHz
32KB
512KB
128MB
128MB SDRAM

Description

—
—
—
—

—
—
—
—
—

EXIT MENU

LEAVING THE SETUP UTILITY

The Exit Menu is used to leave the setup utility. Follow the instructions for Navigating Through the
Setup Utility to make any changes. (See Navigating Through the Setup Utility on page 2 for more
information)
The following table sho ws the names of the menu fields for the Exit menu, the default settings and a
description of the field’s function and any special information needed to help understand the field’s
use.

Main Advanced Security Power Boot Info Exit

Exit Saving Changes
Exit Discarding Changes
Load Setup Defaults
Discard Changes
Save Changes

F1 Help ↑↓ Select Item -/Space Change Value F9 Setup Defaults
ESCExit ←→ Select Menu Enter Select :Sub-Menu F10Save and Exit

PhoenixBIOS Setup Utility

Figure 22. Exit Menu

Item Specific Help

Exit System Setup and
save your changes to
CMOS.

39

Table 22: Fields, Options and Defaults for the Exit Menu

Menu Field

Exit Saving
Changes

Exit Discarding
Changes

Load Setup
Defaults

Discard Changes

Save Changes

Options

—

—

—

—

—

Default

—

—

—

—

—

Description

Exit Saving Changes and Exit will
store all the entries on every menu
of the setup utility to the BIOS
memory and then exit the setup
utility. A confirmation message Save
Configuration changes and exit
now? [Yes] [No] will be displayed.

Selecting Exit Discarding Changes
and Exit will exit the setup utility with
out writing to the BIOS memory.
When the BIOS recognizes this
selection it will load the operating
system and begin operation.

Selecting Load Setup Defaults will
load the factory preset default values
for all menu fields, then display the
message Load default configuration
now? [Yes] [No]. When con-firmed
the setup utility will return to the Exit
Menu. To return to another menu
follow the directions in the Navigat­ing Through the Setup Utility
Section.

Selecting Discard Changes will load
the previous values in BIOS memory
for all menu fields. The message
Load previous now? [Yes] [No] will
be displayed. When confirmed the
setup utility will return to the Exit
menu. To return to another menu,
follow the directions in the Navigat­ing Through the Setup Utility
Section.

Selecting Save Changes will cause
the new settings in all menus to be
written to the BIOS memory. The
message Save configura-tion
changes now? [Yes] [No] will be
displayed. When confirmed, the
setup utility will return to the Exit
menu. To return to another menu,
follow the directions in the Navigat­ing Through the Setup Utility section.

40

2. POST Diagnostic Screen

PhoneixBIOS 4.0 Release 6.0
Copyright 1985-1999 Phoenix Technologies Ltd.
All Rights Reserved

Copyright FUJITSU LIMITED 1995-2001.

CPU = Intel (R) Mobile Pentium (R) III processor xxx MHz-M
128M System Memory Passed
512K Memory Cache Passed
System BIOS Shadowed
Mouse Initialized
Fixed disk 0: xxxx

ATAPI CD-ROM: xxxx

<F12>:Boot Menu / <F2>:BIOS Setup

Figure 23. Typical Diagnostic Screen

Normal Messages

0640K System Memory Passed
nnnnM Extended Memory Passed
nnnnK Memory Cache Passed
System BIOS shadowed
Mouse initialized
Press <F2> to enter SETUP
Entering SETUP ...

Table 23: Normal Messages in Diagnostic Screen

Error Messages

System Memory Failed at offset: xxxx
Failing Bits: zzzz

Extended Memory Failed at offset: xxxx
Failing Bits: zzzz zzzz

System cache error - Cache disabled
Keyboard controller error
Keyboard error
Diskette drive A error
Failure Fixed Disk n

41

Table 23: Error Messages in Diagnostic Screen

Error Messages

System timer error
Real time clock error
System CMOS checksum bad - Default configuration used
Previous boot incomplete - Default configuration used
Press <F1> to resume,<F2> to Setup
Check date and time settings
Password locked: Fixed Disk n
No Save To Disk partition or file exists on Fixed Disk

- Save To Disk features is disabled.
Not enough Save To Disk partition or file exists on Fixed Disk.

- Save To Disk feature is disabled.
Hard Disk Drive is not installed.

- Save To Disk feature is disabled.
Unknown Save To Disk error.

- Save To Disk feature is disabled.
Hard disk sector read function failed.

- Save To Disk feature is disabled.
Hard disk sector write function failed.

- Save To Disk feature is disabled.
Save To Disk partition or file corrupted.

- Save To Disk feature is disabled.
Fixed Disk is not installed. Cannot restore from disk.

To restore from disk : turn off system, install original fixed disk and reboot.
Press <F1> to continue to boot without save to disk data.

Fixed Disk has been changed. Cannot restore from disk.
To restore from disk : turn off system, install original fixed disk and reboot.
Press <F1> to continue to boot without save to disk data.

42
