LifeBook P7000 Notebook BIOS

LifeBook P Series Notebook BIOS

BIOS SETUP UTILITY

The BIOS Setup Utility is a program that sets up the
operating environment for your notebook. Your BIOS is
set at the factory for normal operating conditions,
therefore there is no need to set or change the BIOS
environment to operate your notebook.

The BIOS Setup Utility configures:

■

Device control feature parameters, such as changing
I/O addresses and boot devices.

■

System Data Security feature parameters, such
as passwords.

Entering the BIOS Setup Utility

To enter the BIOS Setup Utility, do the following (or use
the TrustedCore Menu, as detailed in the next section):

1. Turn on or restart your notebook.

2. Press [F2] once the Fujitsu logo appears on the
screen. This will open the main menu of the BIOS
Setup Utility with the current settings displayed.

3. Press the [RIGHT ARROW] or [LEFT ARROW] key
to scroll through the other setup menus to review or
alter the current settings.

Using the TrustedCore Menu

When the Fujitsu logo appears on the screen. press the
[Enter] key or click on the left mouse or touchpad
button; the TrustedCore Menu will appear.

The TrustedCore Menu provides shortcuts to the
following menus and information screens:

■

BIOS Setup

■

Diagnostic Screen

■

Boot Menu

■

Patent Information

■

System Information

■

Continue Booting

Clicking on any of the fields will invoke the screen,
information, or action described.

Navigating through the Setup Utility

The BIOS setup utility consists of six menus: Main,
Advanced, Security, Boot, Info, and Exit. This document
explains each menu in turn, including all submenus and
setup items.

The following procedures allow you to navigate the
setup utility menus:

1. To select a menu, use the cursor keys:

2. To select a field within a menu or a
submenu, use the cursor keys:

3. To select the different values for each
field, press the [Spacebar] or [+] to change to the
next lower selection and [F5] or [-] to go to the next
higher selection.

4. To activate a submenu press the [Enter] key.

5. To return to a menu from a submenu, press the [Esc]
key.

6. To go to the Exit menu from any other menu, press
the [Esc] key.

■

Selecting a field causes a help message
about that field to be displayed on the
right-hand side of the screen.

■

Pressing the Enter key with the highlight
on a selection that is not a submenu or
auto selection will cause a list of all
options for that item to be displayed.
Pressing the Enter key again will select
the highlighted choice.

7. Pressing the [F9] key resets all items in the BIOS to
the default values.

8. Pressing the [F10] key saves the current configura­tion and exits the BIOS Setup Utility. You will be
asked to verify this selection before it is executed.

9. Pressing the [F1] key gives you a general help screen.

The Boot Menu can also be invoked by pressing the
[F12] key when the Fujitsu logo appears on the screen.

2

Entering the Setup Utility After a Configuration Change or System Failure

If there has been a change in the system configuration
that does not agree with the parameter settings stored in
your BIOS memory, or there is a failure in the system,

the system beeps and/or displays an error message after
the Power On Self Test (POST). If the failure is not too
severe, it will give you an opportunity to modify the
setup utility settings, as described in the following steps:

1. When you turn on or restart the computer there is a
beep and/or the following message appears on the
screen:

Error message - please run SETUP
program Press <F1> key to continue,
<F2> to run SETUP

2. If an error message is displayed on the screen, and
you want to continue with the boot process and start

the operating system anyway, press the [F1] key.

■

If your notebook emits a series of beeps
that sounds like a code and the display is
blank, please refer to the Troubleshoot­ing Section in the system User’s Guide.
The Troubleshooting Section includes a
list of error messages and their meanings.

■

If your data security settings require it,
you may be asked for a password before
the operating system will be opened.

Main Menu

3. If an error message is displayed on the screen, and
you want to enter the setup utility, press the [F2] key.

4. When the setup utility starts with a fault present, the
system displays the following message:

Warning!

Error message

[Continue]

5. Press any key to enter the setup utility. The system
will then display the Main Menu with current
parameters values.

3

LifeBook P7000 Notebook BIOS

MAIN MENU - SETTING STANDARD SYSTEM PARAMETERS

The Main Menu allows you to set or view the current
system parameters. Follow the instructions for

Navigating through the Setup Utility to make any

changes.

The following tables show the names of the menu fields
for the Main menu and its submenus, all of the options
for each field, the default settings and a description of

PhoenixBIOS Setup Utility

Main Advanced Security Boot Info Exit

System Time: [14:57:01]
System Date: [06/05/2007]

▲

Drive0 [TOSHIBA MK6006GAH]

▲

Drive1 [MATSHITADVD-RAM UJ-852S]

Language: [English (US)]

the field’s function and any special information needed
to help understand the field’s use.

System Time and System Date can also be
set from your operating system without
using the setup utility. Use the calendar
and time icon on your Windows Control
Panel.

Item Specific Help

Adjust calendar clock.

<Tab>, <Shift-Tab>, or
<Enter> selects field.

F1 Help
ESC Exit

Table 1: Fields, Options and Defaults for the Main Menu

Menu Field Options Default Description

System Time: –— –— Sets and displays the current time. Time is in a 24 hour format of

System Date: –— –— Sets and displays the current date. Date is in a month/day/year numeric

4

Select Item
Select Menu

-/Space Change Values
Enter Select Sub-Menu

Figure 1. Main Menu

hours:minutes:seconds with 2 digits for each. (HH:MM:SS).
Example: 16:45:57. You may change each segment of the time separately.
Move between the segments with the [
keys.

format with 2 digits each for month and day and 4 digits for year. (MM/
DD/YYYY) for example: 12/20/2006. You may change each segment of
the date separately. Move between the segments with the [
or [

Shift] + [Tab ] keys.

▲

F9 Setup Defaults
F10 Save and Exit

Tab] key and/or [Shift] + [Ta b]

Tab] key and/

Table 1: Fields, Options and Defaults for the Main Menu

Menu Field Options Default Description

Main Menu

Drive0: Selects the Drive0

Serial ATA drive
submenu

Drive1: Selects the Drive1

Serial ATA drive
submenu

Language:

■

English (US)

■

Japanese (JP)

The product
number of
the hard

Displays the type of device on this ATA/ATAPI interface, if there is one.
Pressing the Enter key selects the Primary Master submenu allowing addi­tional device configuration options for this interface.

drive.

The product
number of
the CD-ROM

Displays the type of ATA/IDE device on this ATA/ATAPI interface, if there is
one. Pressing the Enter key selects the Serial ATA Port 0 submenu allowing
additional device configuration options for this interface.

drive.

[English (US)] The default setting differs between the US/European and the Japanese

model. Selects the display language for the BIOS.

5

LifeBook P7000 Notebook BIOS

Drive0 Submenu of the Main Menu

The Drive0 submenu identifies which ATA devices are
installed.

PhoenixBIOS Setup Utility

Main Advanced Security Power Boot Info Exit

Drive0 [TOSHIBA MK6006GAH]

Type: [Auto]
LBA Format
Total Sectors: 117210240
Maximum Capacity: 60012MB

Multi-Sector Transfers: [16 Sectors]
LBA Mode Control: [Enabled]
Transfer Mode: [Multiword DMA 2]
Ultra DMA Mode: [Disabled]

F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values
Enter Select Sub-Menu

Figure 2. Drive0 Submenu

▲

Table 2: Fields, Options and Defaults for the Drive0 Submenu of the Main Menu

Menu Field Options Default Description

Typ e:

■

■

Auto
None

[Auto] Select [Auto] to have the type of Serial or Parallel ATA device automatically

identified by the BIOS at POST. If [None] is selected, the following Set-up
items do not appear.

Item Specific Help

Select Serial ATA/IDE
drive installed here.

[Auto]
The BIOS auto-types the
drive on boot time.

[None]
The drive is disabled.

F9 Setup Defaults
F10 Save and Exit

LBA Format Logical Block Addressing (LBA)

Tota l S e c t o r s:

Maximum
Capacity:

Multi-Sector
Transfers:

6

---

---

■

Disabled

■

2 Sectors

■

4 Sectors

■

8 Sectors

■

16 Sectors

--- The total number of sectors on your hard disk. This information is automati­cally displayed when [Auto] is selected.

--- The maximum capacity of your hard disk. This information is automatically
displayed when [Auto] is selected as the Type.

[16 Sectors] This information is automatically selected when [Auto] is selected as the Type.

Table 2: Fields, Options and Defaults for the Drive0 Submenu of the Main Menu

Menu Field Options Default Description

Main Menu

LBA Mode
Control:

Transfer
Mode:

Ultra DMA
Mode:

■

Disabled

■

Enabled

■

Standard

■

Fast PIO 1

■

Fast PIO 2

■

Fast PIO 3

■

Fast PIO 4

■

Multiword DMA 1

■

Multiword DMA 2

■

Disabled

■

Mode 0

■

Mode 1

■

Mode 2

■

Mode 3

■

Mode 4

■

Mode 5

[Enabled] Enables or disables logical Block Addressing in place of Cylinder, Head, Sector

addressing. This setting is automatically selected when [Auto] is selected as
the Type.

[Multiword
DMA 2]

Selects the method for moving data to/from the drive. This option cannot be
changed when Auto is selected and autotypes the drive to select the optimum
transfer mode.

[Disabled] Selects the method for moving data to/from the drive. This setting is auto-

matically selected when [Auto] is selected and autotypes the drive to select
the optimum transfer mode.

7

LifeBook P7000 Notebook BIOS

Drive1 Submenu of the Main Menu

The Drive1 submenu identifies which ATA/IDE devices are installed.

PhoenixBIOS Setup Utility

Main Advanced Security Power Boot Info Exit

Drive1 [MATSHITADVD-RAM UJ-832S]

Type: [Auto]]

Multi-Sector Transfers: [Disabled]
LBA Mode Control: [Disabled]
Transfer Mode: [Disabled]
Ultra DMA Mode: [Disabled]

F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values
Enter Select Sub-Menu

Figure 3. Drive1 Submenu

Menu Field Options Default Description

Typ e:

Multi-Sector
Transfers:

LBA Mode Control:

Transfer Mode:

■

Auto

■

None

■

Disabled

■

2 Sectors

■

4 Sectors

■

8 Sectors

■

16 Sectors

■

Disabled

■

Enabled

■

Standard

■

Fast PIO 1

■

Fast PIO 2

■

Fast PIO 3

■

Fast PIO 4

■

Multiword DMA 1

■

Multiword DMA 2

[Auto] NOTE: The Type field does not appear as a drop-down menu. Tap the

spacebar to toggle the selections.

Selects the ATA/ATAPI device type. Select Auto to have the type auto­matically identified by the BIOS at POST. If None is selected, all of the fol­lowing setup items do not appear.

[Disabled] This option cannot be changed (automatically identified by the BIOS).

Specifies the number of sectors per block for multiple sector transfer.

[Disabled] Enables or disables Logical Block Addressing in place of Cylinder, Head,

Sector addressing. This option cannot be changed (automatically identi­fied by the BIOS).

Standard Selects the method for moving data to/from the drive. Autotype the drive

to select the optimum transfer mode. This option cannot be changed
(automatically identified by the BIOS). Multi-word DMA is automatically
set to mode 1 for Fast PIO 1, Fast PIO 2, Fast PIO 3, and set to mode 2
for Fast PIO 4 / DMA.

▲

Item Specific Help

Select Serial ATA/IDE
drive installed here.

[Auto]
The BIOS auto-types the
drive on boot time.

[None]
The drive is disabled.

F9 Setup Defaults
F10 Save and Exit

8

Main Menu

Menu Field Options Default Description

Ultra DMA Mode:

■

■

Disabled

■

Mode 0

■

Mode 1

■

Mode 2

■

Mode 3

■

Mode 4

■

Mode 5

[Disabled] Selects the method for moving data to/from the drive. Autotype the drive

to select the optimum transfer mode. This option cannot be changed
(automatically identified by the BIOS).

A bootable CD-ROM or DVD-ROM may have a floppy disk or hard drive format. When a bootable CD-ROM or
DVD-ROM is used, drive allocations change automatically without changing the BIOS setup. If a floppy disk for­mat CD-ROM or DVD-ROM is used, the disc becomes Drive A. The CD-ROM or DVD-ROM will only take drive
C: (hard drive format) if the internal hard drive is not present or is disabled. The bootable CD-ROM or DVD-ROM
can never use a C: designation if a formatted internal hard drive is present since the C: designator is always
reserved for the internal hard drive. The boot sequence ignores the new drive designations, however, your appli­cation software will use the new designations.

■

Be careful of the operating environment when booting from CD-ROM/DVD-ROM or you may mistakenly over­write files.

Exiting from Main Menu

When you have finished setting the parameters on this menu, you can either exit from the setup utility, or move to
another menu. If you wish to exit from the setup utility, press the [
menu. If you wish to move to another menu, use the cursor keys.

Esc] key or use the cursor keys to go to the Exit

9

LifeBook P7000 Notebook BIOS

ADVANCED MENU - SETTING DEVICE FEATURE CONTROLS

The Advanced Menu allows you to:

■

Select between the display panel and an external CRT
display.

■

Enable or disable compensation for your display.

■

Configure CPU and USB features.

■

Configure Miscellaneous features

PhoenixBIOS Setup Utility

Main Advanced Security Boot Info Exit

▲ ▲ ▲ ▲

Keyboard/Mouse Features
Video Features
Internal Device Configurations
CPU Features

▲

USB Features

▲

Miscellaneous Configurations

▲

Event Logging

The following tables show the names of the menu fields
for the Advanced Menu and its submenus, all of the
options for each field, the default settings and a descrip­tion of the field’s function and any special information
needed to help understand the field’s use.

Item Specific Help

Configures keyboard
/mouse features

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

Figure 4. Advanced Menu

Change Values

▲

Select Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Table 4: Fields, Options and Defaults for the Advanced Menu

Menu Field Description

Keyboard/Mouse
Features

Video Features When selected, opens the Video Features submenu, which allows setting of the display parameters, including

Internal Device
Configurations

CPU Features When selected, opens the CPU Features submenu, which allows configuration of Intel SpeedStep Technology

USB Features When selected, opens the USB Features submenu, which allows enabling or disabling USB and SCSI Subclass sup-

10

When selected, opens the Keyboard/Mouse Features submenu, which allows setting NumLock to Off, On, or On/
Padlock Off.

routing of video signals to different displays.

When selected, opens the Internal Device Configurations submenu, which allows enabling or disabling the IDE,
LAN, and modem controllers.

performance features and enables or disable XD Bit functionality.

port.

Table 4: Fields, Options and Defaults for the Advanced Menu

Menu Field Description

Advanced Menu

Miscellaneous
Configurations

Event Logging When selected, opens the Event Logging submenu which lets you view and enable the event log.

When selected, opens the Miscellaneous Configurations submenu, which allows you to change the power button,
Wake Up On LAN, Volume settings, video memory size, hardware power management, and power-on LED illumi­nation.

11

LifeBook P7000 Notebook BIOS

Keyboard/Mouse Features Submenu of the Advanced Menu

The Keyboard/Mouse Features submenu is for setting the condition of the NumLock button.

.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Numlock:

Keyboard/Mouse Features

[Off]

Item Specific Help

[On] or [Off]
Numlock is On or Off.

[On/Padlock Off]
Numlock is On, but use
with [Fn] for 10-key
input.

* Windows XP preserves
Numlock state when the
user logs off.

F1 Help
ESC Exit

Select Item
Select Menu

Figure 5. Keyboard/Mouse Features Submenu

-/Space
Enter

Change Values
Select Sub-Menu

▲

F9 Setup Defaults
F10 Save and Exit

Table 5: Fields, Options and Defaults for the Keyboard/Mouse Features Submenu of the Advanced Menu

Menu Field Options Default Description

Numlock:

■

On

■

Off

■

On/Padlock Off

[Off] Sets the NumLock function state when the computer completes

booting.

12

Video Features Submenu of the Advanced Menu

The Video Features Submenu is for setting the display parameters.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Advanced Menu

Video Features

Display [Auto]]
Compensation: [Enabled]

Item Specific Help

Select display terminal.

*This setting is not
effective after
operating system
starts up.

F1 Help
ESC Exit

Select Item
Select Menu

Figure 6. Video Features Submenu

-/Space
Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Table 6: Fields, Options and Defaults for the Video Features Submenu of the Advanced Menu

Menu Field Options Default Description

Display:

■

Internal Flat-Panel

■

External

■

Auto

[Auto] Selects where the video signal will be routed. Note that once the

system boots up, the settings for the Windows video driver take
precedence over this setting. Note that this setting is overridden
after Windows starts up

Compensation:

■

Disabled

■

Enabled

[Enabled] Enables or disables compensation which controls spacing on the dis-

play. When enabled, displays with less than pixel resolution 800 x
600 will still cover the entire screen. Note that this setting is overrid­den after Windows starts up

13

LifeBook P7000 Notebook BIOS

Internal Device Configurations Submenu of the Advanced Menu

The Internal Device Configurations submenu allows the user to configure other internal devices.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Internal Device Configurations

Serial ATA Controller: [Enabled]
IDE Controller: [Enabled]
Bluetooth(R): [Enabled]
LAN Controller: [Enabled]
Wireless LAN: [Enabled]

Item Specific Help

[Disabled]
Serial ATA port is
disabled.

[Enabled]
Serial ATA port is
enabled.

F1 Help
ESC Exit

Select Item
Select Menu

Figure 7. Internal Device Configurations Submenu

-/Space
Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Table 7: Fields, Options and Defaults for the Internal Device Configurations Submenu of Advanced Menu

Menu Field Options Default Description

Serial ATA
Controller:

■

Disabled

■

Enabled

[Enabled]

Enables or disables serial ATA devices.

IDE Controller:

Bluetooth(R):

LAN Controller:

Wireless LAN:

14

■

Disabled

■

Enabled

■

Disabled

■

Enabled

■

Disabled

■

Enabled

■

Disabled

■

Enabled

[Enabled] Enables or disables selected IDE devices.

[Enabled] Enables or disables the Bluetooth(R) device.

[Enabled] Enables or disables LAN controller.

[Enabled] Enables or disables the wireless LAN device.

Advanced Menu

CPU Features Submenu of the Advanced Menu

The CPU Features submenu configures certain features of the CPU in the system.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Item Specific HelpCPU Features

Core Multi-Processing: [Enabled]

SpeedStep(R) Technology: [Enabled]

On Battery: [Battery Optimized]

On AC: [Maximum Performance]

Select Core
Multi-Processing
enabled or disabled.

XD Bit functionality: [Enabled]

F1 Help
ESC Exit

Select Item
Select Menu

Figure 8. CPU Features Submenu

-/Space
Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Table 8: Fields, Options and Defaults for the CPU Features Submenu of the Advanced Menu

Menu Field Options Default Description

Core Multi­Processing

SpeedStep(R)
Technology:

■

Disabled

■

Enabled

■

Disabled

■

Enabled

[Enabled] Enables or disables the Intel Core Multi-Processing features.

[Enabled] Enables or disables SpeedStep(R) Technology.

On Battery:

On AC:

XD Bit
functionality:

■

Maximum Performance

■

Battery Optimized

■

Automatic

■

Maximum Performance

■

Battery Optimized

■

Automatic

■

Enabled

■

Disabled

[Battery Optimized] Allows the user to select the power conditions when the

[Maximum
Performance]

system is running on battery power.

Allows the user to select the power conditions when the
system is running on AC power.

[Enabled] Allows the user to enable and disable the Execute Disable

Bit functionality. Execute Disable Bit allows the processor
to classify areas in memory where application code can and
cannot execute. In the event an internet worm attempts to
insert code in the buffer, the processor disables code
execution to prevent damage or worm propagation.

15

LifeBook P7000 Notebook BIOS

USB Features Submenu of the Advanced Menu

The USB Features submenu configures the USB capabilities of the system.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

USB Features

Legacy USB Support: [Enabled]

SCSI SubClass Support:

[Enabled]

Item Specific Help

[Disabled]
The feature is disabled.

[Enabled]
Legacy USB Emulation
is enabled and USB
devices are available
without USB aware OS.

F1 Help
ESC Exit

Select Item
Select Menu

Figure 9. USB Features Submenu

-/Space
Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Table 9: Fields, Options and Defaults for the USB Features Submenu of the Advanced Menu

Menu Field Options Default Description

Legacy USB
Support:

■

Disabled

■

Enabled

[Enabled] When Disabled is selected, legacy USB emulation is disabled. When Enabled is

selected, legacy USB emulation is enabled and USB devices are available without USB­aware OS.

SCSI SubClass
Support:

16

■

Disabled

■

Enabled

[Enabled] When Enabled is selected, USB devices that belong to the SCSI subclass in the mass

storage class (e.g., USB Memory Key) are enabled. Note that enabling this feature may
cause the system to hang during POST, depending on the device that is connected.

Advanced Menu

Miscellaneous Configurations Submenu of the Advanced Menu

The CPU Features submenu configures certain features of the CPU in the system.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Miscellaneous Configurations

Power Button:
Wake up on LAN:
Force LAN Boot:
Auto Save To Disk:
Volume Setting:
Hardware Power Management:
FAN Control:

[Disabled]

[Disabled]
[Disabled]
[Off]
[Middle]
[Disabled]
[Silent]

Item Specific Help

Configures the power
button.

*ACPI OS ignores this
setting.

Power on LED Illumination: [Enabled]

F1 Help
ESC Exit

Select Item
Select Menu

Figure 10. Miscellaneous Configurations Submenu

-/Space
Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Table 10: Fields, Options and Defaults for the Miscellaneous Configurations Submenu

Menu Field Options Default Description

Power Button:

■

Disabled

■

Power Off

[Disabled] Selecting Disabled disables the power button. Selecting Power Off

allows you to turn off system power with the power button.

Wake up on LAN:

Force LAN Boot:

Auto Save To Disk:

Volume Setting:

■

Disabled

■

Enabled

■

Disabled

■

Enabled

■

Off

■

On

■

Off

■

Minimum

■

Middle

■

Maximum

[Disabled] Selecting Enabled allows the system to wake up when the internal

[Disabled] This feature is active only when “Wake up on LAN” is enabled.

[Off] Turns the Auto Save To Disk feature on and off. When it is turned

[Middle] Selects the initial volume setting for the system.

LAN device receives a specific signal while in power-off state.
Selecting Disabled disables this feature.

When enabled, in the event of a system wake-up on LAN, the sys­tem will try to first boot from the LAN before attempting to boot
from any other device, regardless of the BIOS boot priority settings
or disabling of the Preboot Execution Environment.

on, when the battery runs low while the system is in suspend mode,
the system will save its current state to disk and turn off.

17

LifeBook P7000 Notebook BIOS

Table 10: Fields, Options and Defaults for the Miscellaneous Configurations Submenu

Menu Field Options Default Description

Hardware Power
Management

FAN Control:

Power on LED
Illumination:

■

Disabled

■

Enabled

■

Normal

■

Silent

■

Disabled

■

Enabled

[Enabled] Allows you to enable or disable the Hardware Power Management

feature.

[Silent] Determines the operating noise level of the fan.

[Disabled] Allows you to enable or disable the illumination of the LEDs when

power is turned on.

18

Event Logging Submenu of the Advanced Menu

The Event Logging submenu is for setting up the logs for DMI event logging.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Advanced Menu

Event Logging

Event Log Capacity: Space Available
Event Log Validity: Valid

View Event Log: [Enter]

Item Specific Help

Press <Enter> key to
view the contents of
the event log.

Event Logging: [Enabled]
System Boot Event: [Disabled]

Clear All Event Logs: [No]

Mark Events as Read: [Enter]

F1 Help
ESC Exit

Select Item
Select Menu

Figure 11. Event Logging Submenu

-/Space
Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Table 11: Fields, Options and Defaults for the Event Logging Submenu of the Advanced Menu

Menu Field Options Default Description

Event Log Capacity: Space

Available

Display only

Event Log Validity: Valid Display only

View Event Log:

Event Logging:

System Boot Event:

Clear All Event Logs:

Mark Events as Read:

■

Enter [Enter] Allows you to view content of event log.

■

Disabled

■

Enabled

■

Disabled

■

Enabled

■

No

■

Yes

■

Enter [Enter] Allows you to mark events currently in the event log as read.

[Enabled] Turns event logging on and off for all DMI events.

[Disabled] Turns event logging on and off for DMI system boot events.

[No] When set to [Yes] all event logs will be cleared at next boot.

19

LifeBook P7000 Notebook BIOS

SECURITY MENU - SETTING THE SECURITY FEATURES

The Security menu allows you to set up the data security
features of your notebook to fit your operating needs
and to view the current data security configuration.
Follow the instructions for Navigating Through the
Setup Utility to make any changes.

The following tables show the names of the menu fields
for the Security menu and its submenus, all the options
for each field, the default settings and a description of
the field's function and any special information needed
to help understand the field's use. The default condition
is no passwords required and no write protection.

Remember your passwords! If you set and
forget your User and Master hard disk
passwords, Fujitsu Computer Systems
service representatives (1-800-8FUJITSU)
may not be able to reset it. You may lose
data and have to replace your system
board or hard disk drive.

PhoenixBIOS Setup Utility

Main Advanced Security Boot Info Exit

Supervisor Password Is: Clear
User Password Is: Clear

Set Supervisor Password [Enter]
Set User Password [Enter]
Minimum User Password Length [0]
Password on Boot: [Disabled]
On Automatic Wake up: [Disabled]
KB Lock on Resume: [Disabled]
Boot from Removable Media: [All]
Flash Write: [Enabled]

▲

Hard Disk Security

▲▲

Owner Information
Security Chip Setting

■

Entering a password incorrectly 3 times
in a row causes the keyboard and mouse
to be locked out and the warning
[System Disabled] to be displayed.
If this happens, restart the computer by
turning off and on the power with the
power switch and use the correct pass­word on reboot.

■

If you make an error when re-entering
the password a Warning will display
on the screen. To try again press [Enter],
then retype the password. Press [Esc] to
abort the password setting process.

Item Specific Help

Press <Enter> key to
set Supervisor Password
to enable any password
features.

Then password entry is
required to enter BIOS
Setup.

F1 Help
ESC Exit

20

Select Item
Select Menu

-/Space

Change Values

Enter

Figure 12. Security Menu

▲

Select Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Table 12: Fields, Options and Defaults for the Security Menu

Menu Field Options Default Description

Security Menu

Supervisor
Password is:

–— Clear A display-only field. Set is displayed when the system supervisor password

is set and Clear when it is not.

User Password is: –— Clear A display-only field. Set is displayed when the general user password is

set, and Clear when it is not.

Set Supervisor
Password

–— [Enter] Sets, changes or cancels the Supervisor Password. The Supervisor Pass-

word may be up to seven characters long and must include only letters or
numbers (no symbols). Passwords are NOT case-sensitive. To cancel a
password press the

Enter key instead of entering characters in the Enter

New Password field and in the Re-enter New Password field. When a
Supervisor Password is set it must be used to access the BIOS setup utility.

Set User Password –— [Enter] Can only be accessed if Supervisor Password is set. Sets, changes or can-

cels User Password. User Password may be up to seven characters long
and must include only letters or numbers (no symbols). Passwords are
NOT case-sensitive. To cancel a password press the
entering characters in the Enter New Password and Re-enter New Pass­word fields. When a User Password is set it must be used to access the

Enter key instead of

BIOS utility.

Minimum User
Password Length:

Password on Boot:

On Automatic
Wake-up:

KB Lock on Resume:

Boot from
Removable Media:

–— [0] Can only be accessed if Supervisor Password is set. Set the minimum

■

Disabled

■

First Boot

■

Every Boot

■

Disabled

■

Enabled

■

Disabled

■

Enabled

■

All

■

Supervisor
only

[Disabled] When set to Disabled, no password is required. When set to First Boot,

[Disabled] When set to Disabled, it is not necessary to enter a password to wake up

[Disabled] When Enabled, keyboard or mouse inputs are locked out at Resume From

[All] When Supervisor Only is selected, only the Supervisor can boot from

length for User Password.

password entry required only before first boot. When Every Boot is
selected, password required whenever the system is booted.

from LAN or Real Time Clock (RTC). When Enabled, it is still necessary to
enter a password after automatic wake-up.

Suspend or Save-to-Disk until entering password.

removable media. Only the user who enters the Supervisor Password
before OS boot is treated as the Supervisor. When All is selected, boot
from removable media is not restricted.

■

Flash Write:

Disabled

■

Enabled

[Enabled] When disabled, the BIOS Flash Memory is write-protected; when

enabled, it is not.

Hard Disk Security –— –— Configures hard disk security features.

Owner Information –— –— Sets Owner information.

Security Chip Setting –— –— Sets setting for the security chip.

Exiting from the Security Menu

When you have finished setting the parameters on the Security Menu, you can either exit from setup utility or move to
another menu. If you wish to exit from setup utility, press the [
another menu, use the cursor keys.

Esc] key to go to the Exit Menu. If you wish to move to

21

LifeBook P7000 Notebook BIOS

Hard Disk Security Submenu of the Security Menu

The Hard Disk Security submenu is for configuring hard disk security features.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Hard Disk Security

Item Specific Help

Drive0: Clear
Set Master Password [Enter]
Set User Password [Enter]

Password Entry on Boot: [Enabled]

F1 Help
ESC Exit

Select Item
Select Menu

Figure 13. Hard Disk Security Submenu

-/Space
Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Table 13: Fields, Options and Defaults for the Hard Disk Security Submenu of the Security Menu

Menu Field Default Description

Drive0: Clear A display-only field. Set is displayed when the Master Password is set and Clear when it is not.

Set Master
Password

Set User Password [Enter] Sets, changes or cancels User Password. The User Password may be up to seven characters long

Password Entry on
Boot:

22

[Enter] Sets, changes or cancels Primary Master Password. The Primary Master Password may be up to

[Enabled] When set to Disabled, it is not necessary to enter a Hard Disk Password before booting the OS.

seven characters long and include only letters or numbers (no symbols). Passwords are NOT case­sensitive. To cancel a password press the Enter key instead of entering characters in the Enter New
Password field and in the Re-enter New Password field. When a Primary Master Password is set it
must be used to access the hard disk. Data on the hard disk cannot be read on other systems.

and include only letters or numbers (no symbols). Passwords are NOT case-sensitive. To cancel a
password press the Enter key instead of entering characters in the Enter New Password field and in
the Re-enter New Password field.

The hard disk is still password-protected without password entry.

Owner Information Submenu of the Security Menu

Main Advanced

The Owner Information submenu is for setting owner information.

PhoenixBIOS Setup Utility

Security

Security Menu

Owner Information

Item Specific Help

Owner Information Is: Clear

Set Owner Information [Enter]

Foreground Color: [Gray]
Background Color: [Black]

F1 Help
ESC Exit

Select Item
Select Menu

Figure 14. Owner Information Submenu

-/Space Change Values
Enter Select Sub-Menu

▲

F9 Setup Defaults
F10 Save and Exit

Table 14: Fields, Options and Defaults for the Owner Information Submenu of the Security Menu

Menu Field Options Default Description

Owner Information Is: –— Clear Display only. (Will only be dis-

played if the Supervisor Pass­word is set).

Set Owner
Information:

Foreground Color:

Background Color:

–— [Enter] Field to write owner

■

Black

■

Blue

■

Green

■

Cyan

■

Red

■

Magenta

■

Black

■

Blue

■

Green

■

Cyan

■

Red

■

Magenta

■

Brown

■

White

■

Gray

■

Light Blue

■

Light Green

■

Brown

■

White

■

Gray

■

Light Blue

■

Light Green

■

Light Cyan

■

Light Red

■

Light Magenta

■

Light Yellow

■

Bright White

■

Light Cyan

■

Light Red

■

Light Magenta

■

Light Yellow

■

Bright White

[Gray]

[Black]

information, i.e. name.

23

LifeBook P7000 Notebook BIOS

Security Chip Setting Submenu of the Security Menu

The Security Chip Setting Submenu is for enabling or disabling the embedded security chip.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Security Chip Setting

Security Chip:

[Disabled]]

Item Specific Help

Clear Security Chip: [Enter]

Security Chip State: Disabled
Deactivated

F1 Help
ESC Exit

Select Item
Select Menu

-/Space

Enter

Figure 15. Security Chip Setting Submenu

Change Values
Select Sub-Menu

▲

F9 Setup Defaults
F10 Save and Exit

Table 15: Fields, Options and Defaults for the Security Chip Setting Submenu of the Security Menu

Menu Field Options Default Description

Security Chip: • Disabled

• Enabled

[Disabled] Select to enable or disable the security chip. Note that after configuring

the security chip, a system reboot is required.

Clear Security Chip ____ [Enter] Allows you to clear the security chip. Note that if you clear the security

Security Chip State: ____ Disabled

Deactivated

24

chip, you will not be able to access data that has already been encrypted.
This field is only visible when Security Chip is [Enabled].

Information only. Indicates the current state of the security chip.

Boot Menu

BOOT MENU - SELECTING THE OPERATING SYSTEM SOURCE

The Boot Menu is used to select the order in which the BIOS searches sources for the operating system. Follow the
instructions for Navigating Through the Setup Utility to make any changes. The tables show the names of the menu
fields for the Boot menu and its submenu, all of the options for each field, the default settings and a description of the
field's function and any special information needed to help understand the field's use.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Boot

Quick Boot: [Enabled]
Boot Time Diagnostic Screen: [Disabled]
Boot Menu: [Enabled]
Preboot Execution Environment [Enabled]

▲

Boot Device Priority

-/Space

F1 Help
ESC Exit

Select Item
Select Menu

Change Values

Enter

Figure 16. Boot Menu

▲

Select Sub-Menu

Table 16: Fields, Options and Defaults for the Boot Menu

Menu Field Options Default Description

QuickBoot:

Boot-time Diagnostic
Screen:

■

Disabled

■

Enabled

■

Disabled

■

Enabled

[Enabled] Turns on and off booting with a truncated set of Power On Self

Test. (Fewer tests mean faster turn on.)

[Disabled] Turns on and off display of test results instead of Fujitsu logo

screen during Power On Self Test.

Item Specific Help

[Disabled]
All diagnostic tests
will be done.

[Enabled]
Some diagnostic tests
may be skipped while
booting to speed up.

F9 Setup Defaults
F10 Save and Exit

Boot Menu:

Preboot Execution
Environment

Boot Device Priority

■

Disabled

■

Enabled

■

Disabled

■

Enabled

■

Selects Boot
Device Priority
submenu

[Enabled] This field is not active unless the Supervisor’s Password has been

[Enabled] Turns off and on the preboot execution environment feature.

— This menu allows setting up the source for the operating system.

set. When disabled, access to the Boot Menu with the [F12] key is
disabled. When enabled, the Boot Menu is enabled and the [F12]
key will allow you to display it.

25

LifeBook P7000 Notebook BIOS

Boot Device Priority Submenu of the Boot Menu

The Boot Device Priority submenu is for setting the order of checking of sources for the operating system.

■

Be aware of the operating environment when booting from a CD or you may overwrite files by mistake.

■

A bootable CD-ROM has either a floppy disk or a hard drive format. When a bootable CD-ROM is used,
drive allocations change automatically without changing the BIOS setup. If floppy disk format is used, the
CD-ROM becomes Drive A. The CD-ROM will only take drive C: (hard drive format) if the internal hard
drive is not present or is disabled. A bootable CD-ROM cannot use a C: designation if a formatted inter­nal hard drive is present since the C: designator is always reserved for the internal hard drive. The boot
sequence ignores new drive designations, but your application software will use the new designations.

■

In order for a portable USB memory device (e.g., JumpDrive or memory stick) to be recognized in the
Boot Device Priority list, it must have been installed before booting the system.

■

Note that some older portable USB memory devices may not be recognized as bootable devices.

The Boot Menu can also be invoked outside of the Setup Utility using the TrustedCore menu or the [F12]
key.

See Using the TrustedCore Menu for more information.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Boot

Boot Device Priority

Boot priority order:
1: Floppy Disk Drive
2: Drive0: TOSHIBA MK6006GAH
3: CD/DVD Drive
4: NETWORK: B02 D00 Yukon PXE
5:
6:
7:
8:
Excluded from boot order:
: USB MEMORY: None
: USB HDD: None

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

Figure 17. Boot Device Priority Submenu

Keys used to view or
configure devices:

<+>/<Space> or <->
moves the device up or
down.
<x> exclude or include
the device to boot.

Change Values

▲

Select Sub-Menu

Item Specific Help

F9 Setup Defaults
F10 Save and Exit

26

Boot Menu

Table 17: Fields, Options and Defaults for the Boot Device Priority Submenu of the Boot Menu

Menu Field Description

Boot priority order:
1: Floppy Disk Drive
2: Drive0:
3: CD/DVD Drive:
4: NETWORK:
5:
6:
7:
8:
Excluded from boot order:
: USB MEMORY:
: USB HDD:

The boot selections determine the order in which the BIOS searches for the operating
system during a startup sequence. To change the order, highlight one source by using
the [up] or [down] cursor keys and then press the [+] or [-] key to change the order
number. Tapping [x] removes from the list a device that is not installed. Tapping [x] on
an item in the Excluded list adds the device to the Boot priority list. Be sure to save your
changed order when you exit the BIOS setup utility.

NOTE: Be aware that if you use the CD-ROM drive as the first boot device, certain files
may be overwritten, depending upon your operating environment.

Exiting from Boot Menu

When you have finished setting the boot parameters with the Boot menu, you can either exit from the setup utility or
move to another menu. If you wish to exit from the setup utility press the [
to move to another menu, use the cursor keys.

Esc] key to go to the Exit menu. If you wish

27

LifeBook P7000 Notebook BIOS

INFO MENU - DISPLAYS BASIC SYSTEM INFORMATION

The Info menu is a display-only screen that provides the
configuration information for your notebook.

The following table shows the names of the menu fields
for the Info menu and the information displayed in
those fields. These fields are for information purposes
only, and are not editable

.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Boot Info

BIOS Version: 1.07
BIOS Date: 04/11/2007
BIOS Area: E000h - FFFFh

CPU Type: Intel(R) Core(TM) Duo CPU U2500
CPU Speed: 1.20 GHz
L1 Cache: 128 KB
L2 Cache: 2048 KB

Total Memory: 1024 MB
Memory Slot: 1024 MB DDR2 SDRAM

The information displayed on this screen is
variable according to the unit you
purchased.

F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values

Enter Select Sub-Menu

Figure 18. Info Menu

▲

F9 Setup Defaults
F10 Save and Exit

Table 18: Fields, Options and Defaults for None

Menu Field Default Menu Field Default

BIOS Version: 1.xx L1 Cache: 128 KB

BIOS Date: mm/dd/yyyy L2 Cache: 2048 KB

BIOS Area: E000h – FFFFh Total Memory: 1024 MB

CPU Type: Intel(R) Core(TM) Duo CPU U2500 Memory Slot: 1024 MB DDR2 SDRAM

CPU Speed: 1.20 GHz

28

Exit Menu

EXIT MENU - LEAVING THE SETUP UTILITY

The Exit Menu is used to leave the setup utility. Follow the instructions for Navigating through the Setup Utility to
make any changes. The table shows the names of the menu fields for the Exit menu and a description of the field's
function and any special information needed to help understand the field's use.

Main Advanced Security Power Savings Boot Exit

Exit Saving Changes
Exit Discarding Changes
Load Setup Defaults
Discard Changes
Save Changes
Save Changes and Power Off

F1 Help
ESC Exit

Select Item
Select Menu

PhoenixBIOS Setup Utility

-/Space Change Values

Enter Select Sub-Menu

Figure 19. Exit Menu

Table 19: Fields, Options and Defaults for the Exit Menu

Menu Field Shortcut Description

Exit Saving
Changes

Press the
F10 key

Exit Saving Changes and Exit will store all the entries on every menu of the setup utility to the BIOS
memory and then exit the setup utility. A confirmation message Save Configuration changes and exit
now? [Yes] [No] will be displayed.

Item Specific Help

Exit System Setup and
save your changes to
CMOS.

▲

F9 Setup Defaults
F10 Save and Exit

Exit Discarding
Changes

Load Setup
Defaults

Discard
Changes

Save Changes –— Selecting Save Changes will cause the new settings in all menus to be written to the BIOS memory. The

Save Changes
and Power Off

–— Selecting Exit Discarding Changes and Exit will exit the setup utility with out writing to the BIOS mem-

Press the
F9 key

–— Selecting Discard Changes will load the previous values in BIOS memory for all menu fields. The mes-

___ Selecting Save Changes and Power Off will cause the new settings in all menus to be written to the

ory. When the BIOS recognizes this selection it will load the operating system and begin operation.

Selecting Load Setup Defaults will load the factory preset default values for all menu fields, then dis­play the message Load default configuration now? [Yes] [No]. When confirmed the setup utility will
return to the Exit Menu.

sage Load previous now? [Yes] [No] will be displayed. When confirmed the setup utility will return to
the Exit menu.

message Save configuration changes now? [Yes] [No] will be displayed. When confirmed, the setup
utility will return to the Exit menu.

BIOS memory, then power the system off. The message Save configuration changes now
and power off? will be displayed. When confirmed, the setup utility shut down the system.

29
