Fujitsu Lifebook C6525, Lifebook C6535, LifeBook C-6537, LifeBook C-6557, Lifebook C5235 User Manual

...

SERIES

Advanced Multimedia. Discriminating Style.

User’s Guide

Fujitsu PC Corporation has made every effort to ensure the accuracy and completeness of this document. However, as ongoing development efforts are continually improving the capabilities of our products, we cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.

Fujitsu and the Fujitsu logo are registered trademarks and LifeBook is a trademark of Fujitsu Limited.

First Cabin is a service trademark of Fujitsu PC Corporaton.

ErgoTrac is a trademark of Fujitsu PC Corporation.

The following are registered trademarks of IBMCorporation:IBM,IBMPCAT,IBMPS/2.

The following are registered trademarks of Microsoft Corporation: MS, MS-DOS, Windows.

PCMCIA is a trademark of the Personal Computer Memory Card International Association.

Intel, Pentium, and SpeedStep are registered trademarks of Intel Corporation.

AMD and AMD-K6 are registered trademarks of Advanced Micro Devices, Inc.

Acrobat is a registered trademark of Adobe System Inc.

CompuServe and AOL are registered trademarks of America Online, Inc.

Earthlink is a registered trademark of EarthLink Network, Inc.

Quicken®2000 is a registered trademark of Intuit, Inc.

Sony MiniDisc is a trademark of Sony Electronics Inc.

Philips is a trademark of Koninklijke Philips Electronics N.V.

Netscape Communicator is a registered trademark of Netscape Communications Corporation.

PC-Doctor is a trademark of Watergate Software, Inc.

LapLink is a registered trademark of Traveling Software Inc.

McAfee VirusScan is a trademark of NAI.

All other trademarks mentioned herein are the property of their respective owners.

© Copyright 2000 Fujitsu PC Corporation. All rights reserved. No part of this publication may be copied, reproduced, or translated, without prior written consent of Fujitsu PC Corporation. No part of this publication may be stored or transmitted in any electronic form without the written consent of Fujitsu PC Corporation.

Responsible Party Name: Fujitsu PC Corporation

Address: 5200 Patrick Henry Drive

Telephone: (408) 982-9500

Declares that: LifeBook C Series Configuration:

This device complies with Part 15 of the FCC rules. Operations are subject to the following two conditions:

(1) This device must not be allowed to cause harmful interference, (2) This device must accept any

interference received, including interference that may cause undesired operation.

DECLARATION OF CONFORMITY

according to FCC Part 15

Santa Clara, CA 95054

LifeBook C-6557 LifeBook C-6537 LifeBook C-6177 LifeBook C-4235

Complies with Part 15 of the FCC Rules.

LifeBook C Series

CAUTION

Changes or modifications not expressly approved by Fujitsu PC Corporation could void this user’s authority to operate the equipment.

This equipment is designed to be connected to the telephone network or premises wiring using a standard modular jack type USOC RJ-11C which is FCC Part 68 compliant and a line cord between the modem and the telephone network with a minimum of 26AWG.

FCC NOTICES Notice to Users of Radios and Television

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

■

Reorient or relocate the receiving antenna.

■

Increase the separation between the equipment and receiver.

■

Connect the equipment into an outlet that is on a different circuit than the receiver.

■

Consult the dealer or an experienced radio/TV technician for help.

Shielded interconnect cables must be employed with this equipment to ensure compliance with the pertinent RF emission limits governing this device.

Notice to Users of the US Telephone Network

Your Fujitsu LifeBook notebook may be supplied with an internal modem which complies with Part 68 of the FCCrules.Onthisnotebookisalabelthatcontainsthe FCC Registration Number and the Ringer Equivalence Number (REN) for this equipment among other information. If requested, the user must provide their telephone company with the following information:

1. The telephone number to which the notebook is connected.

2. The Ringer Equivalence Number (REN) for this equipment.

3. That the equipment requires a standard modular jack type USOC RJ-11C which is FCC Part 68 compliant.

4. The FCC Registration Number.

The REN is used to determine the number of devices that you may connect to your telephone line and still have all of those devices ring when your number is called. Too many devices on one line may result in failure to ring in response to an incoming call. In most, but not all, areas the sum of the RENs of all of the devices should not exceed five (5).To be certain of the number of devices you may connect to your line, as determined by the RENs, contact your local telephone company.

If this equipment causes harm to the telephone network, your telephone company may discontinue your service temporarily. If possible, they will notify you in advance. If advance notice is not practical they will notify you as soon as possible. You will also be advised of your right to file a complaint with the FCC.

This fax modem also complies with fax branding requirements per FCC Part 68.

Your telephone company will probably ask you to disconnect this equipment from the telephone network until the problem is corrected and you are sure that the equipment is not malfunctioning. This equipment may not be used on coin-operated telephones provided by your telephone company. Connection to party lines is subject to state tariffs. Contact your state’spublicutility commission, public service commission or corporation commission for more information.

This equipment includes automatic dialing capability. When programming and/or making test calls to emergency numbers:

■

Remain on the line and briefly explain to the dispatcher the reason for the call.

■

Perform such activities in off-peak hours, such as early morning or late evening.

FCC rules prohibit the use of non-hearing aid compatible telephones in the following locations or applications:

■

All public or semipublic coin-operated or credit card telephones.

■

Elevators, highways, tunnels (automobile, subway, railroad or pedestrian) where a person with impaired hearing might be isolated in an emergency.

■

Places where telephones are specifically installed to alert emergency authorities such as fire, police or medical assistance personnel.

■

Hospital rooms, residential health care facilities, convalescent homes and prisons.

■

Workstations for the hearing impaired.

■

Hotel, motel or apartment lobbies.

■

Stores where telephones are used by patrons to order merchandise.

■

Public transportation terminals where telephones are used to call taxis or to reserve lodging or rental cars.

■

In hotel and motel rooms as at least ten percent of the rooms must contain hearing aid compatible telephones or jacks for plug-in hearing aid compatible telephones which will be provided to hearing impaired customers on request.

DOC (INDUSTRY CANADA) NOTICES Notice to Users of Radios and Television

This Class B digital apparatus meets all requirements of the Canadian InterferenceCausing Equipment Regulations.

CET appareil numériquedelaclassBrespectetoutes les exigence du Réglement sur le matérial brouilleur du Canada.

Repairs to telecommunication equipment should be made by a Canadian authorized maintenance facility. Any repairs or alterations not expressly approved by Fujitsu™ PC Corporation or any equipment failures may give the telecommunication company cause to request the user to disconnect the equipment from the telephone line.

The connecting arrangement code for this equipment is CA11A.

The Load Number is 0.3.

TheLoadNumberassignedtoeachtelephoneterminal device denotes the percentage of the total load to be connected to a telephone loop or circuit which is used by thedevicetopreventoverloading.Theterminationona loop may consist of any combination of devices such that the total of the load numbers of all devices does not exceed 100.

CAUTION

For safety, users should ensure that the electrical ground of the power utility, the telephone lines and the metallic water pipes are connected together. Users should NOT attempt to make such connections themselves but should contact the appropriate electric inspection authority or electrician. This may be particularly important in rural areas.

Notice to Users of the CanadianTelephone Network

The Canadian Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational, and safety requirements. The Department does not guarantee the equipment will operate to the user’s satisfaction.

Fujitsu LifeBook computers are supplied with an internal modem which complies with the Industry Canada certification standards for telecommunication network protection and safety requirements. Before connecting this equipment to a telephone line the user should ensure that it is permissible to connect this equipment to the local telecommunication facilities. The user should be aware that compliance with the certification standards does not prevent service degradation in some situations.

Avis Aux Utilisateurs Du Réseau Téléphonique Canadien

L’étiquette canadienne Industrie Canada identifie l’équipement certifié. Cette certification signifie que l’équipement satisfait certaines normes de protection, d’exploitation et de sécurité des réseaux de télécommunications. Le départementnegarantitpaslefonctionnement de l’équipement à la satisfaction de l’utilisateur.

La série LifeBookTM E possède un modem interne conforme aux normes de certification d’Industrie Canada pour protéger les réseaux de télécommunications et satisfaire aux normes de sécurité.Avantde connecter cet équipement à une ligne téléphonique, l’utilisateur doit vérifier s’il est permis de connecter cet équipement aux installations de télécommunications locales. L’utilisateur est averti que même la conformité aux normes de certification ne peut dans certains cas empêcher la dégradation du service.

LifeBook C Series

Les réparations de l’équipement de télécommunications doivent être eVectuées par un service de maintenance agréé au Canada. Toute réparation ou modification, qui n’est pas expressément approuvée par Fujitsu PC Corp., ou toute défaillancedel’équipement peut entraîner la compagniedetélécommunications à exiger que l’utili- sateur déconnecte l’équipement de la ligne téléphonique.

Le code d’arrangement de connexion de cet équipement est CA11A.

AVERTISSEMENT

Pour assurer la sécurité, les utilisateurs doivent vérifier que la prise de terre du service d’électricité, les lignes télphoniques et les conduites d’eau métalliques sont connectées ensemble. Les utilisateurs NE doivent PAS tenter d’établir ces connexions eux-mêmes, mais doivent contacter les services d’inspection d’installations électriques appropriésouunélectricien.Cecipeut être particulièrement important en régions rurales.

Le numéro de charge est 0.3.

Le numéro de charge assignéàchaque terminal téléphonique indique le pourcentage de la charge totale pouvant être connectéàuneboucleouà un circuit téléphonique, utilisé par ce périphériqueafindeprévenir toute surcharge. La terminaison d’unebouclepeutêtre constituéeden’importequellecombinaisondepériphériques de sorte que le total de numérosdechargedetousles périphériques n’excède pas 100.

UL Notice (For Authorized Repair Technicians Only)

CAUTION

For continued protection against risk of fire, replace only with the same type and rating fuse.

Table of Contents

Fujitsu

LifeBook

™

C Series Notebook

Table of Contents

SECTION ONE

Preface

AboutThisGuide......................... 3

FujitsuPCContactInformation .............. 3

Warranty............................... 3

SECTION TWO

Overview

Unpacking.............................. 7

LifeBookFeatures......................... 8

ValuableLifeBookSoftware................. 8

PopularAccessories....................... 9

Keyboard

UsingtheKeyboard...................... 20

NumericKeypad ........................ 20

Windows Keys . . . . . . . . . . . . . . . ........... 20

CursorKeys............................ 21

FunctionKeys .......................... 21

Hard Drive or Removable

MediaDriveAccessIndicator .............. 18

Floppy Disk Drive

AccessIndicator ........................ 19

PCCardAccessIndicators................. 19

NumLk Indicator . . . . . . . . . ............... 19

CapsLockIndicator...................... 19

ScrLkIndicator ......................... 19

Locating the Controls and Connectors

Top and Front Components . . . . . . . . . ....... 10

Left-SidePanelComponents ............... 12

Right-Side Panel Components . . . . . . . . ...... 13

RearPanelComponents................... 15

BottomComponents ..................... 16

Status Indicator Panel

PowerIndicator......................... 17

ACAdapterIndicator .................... 17

BatteryLevelIndicators................... 18

BatteryChargingIndicators................ 18

DVD/CD-RW/CD-ROM Drive

AccessIndicator ........................ 18

ErgoTrac Pointing Device

Clicking............................... 22

Double-Clicking......................... 23

Dragging.............................. 23

ErgoTracControlAdjustment............... 23

Volume Control

ControllingtheVolume................... 24

Setting the Hardware

VolumeControl......................... 24

LifeBook Application Panel

SelectorSwitch ......................... 25

Application Launch CD Player Buttons. . . . . . . . 25

LCDDisplay............................ 25

E-mailNotificationLED ................... 26

LifeBook C Series

Configuring your LifeBook

ApplicationPanel........................ 26

Using the E-mail Notification LED: . . . . . . . .... 27

UsingtheCDPlayer...................... 27

DesktopControlPanel.................... 28

Pre-Installed Software

LearningAboutYourApplications ........... 30

PCDoctor ............................. 30

LapLinkProfessional...................... 30

Quicken2000Basic...................... 30

McAfeeVirusScan....................... 30

PMSet98.............................. 30

AdobeAcrobatReader.................... 30

IntelSpeedstep*......................... 30

LifeBookApplicationPanelSoftware ......... 30

SECTION THREE

Power Sources

ConnectingthePowerAdapters............. 33

Display Panel

OpeningtheDisplayPanel................. 34

AdjustingDisplayPanelBrightness........... 34

ClosingtheDisplayPanel.................. 34

Starting Your LifeBook

PowerOn ............................. 35

BootSequence.......................... 35

BIOSSetupUtility ....................... 35

Booting the System with Windows 98 . . . . . . . . 36

RegisteringYourLifeBook ................. 37

HardDiskTimeout....................... 40

Windows 98 Power Management . . . ........ 40

RestartingtheSystem .................... 40

PowerOff............................. 41

SECTION FOUR

Lithium ion Battery

RechargingtheBatteries .................. 45

ReplacingtheBattery..................... 46

Floppy Disk Drive

LoadingaDisk.......................... 47

EjectingaDisk.......................... 47

PreparingaDiskforUse .................. 47

CD-ROM Drive

LoadingaCD........................... 48

RemovingaCD......................... 49

AutoInsertnotificationFunction............ 49

DVD/CD-ROM Drive

DVDPlayerSoftware..................... 50

LoadingaDVD/CD...................... 51

RemovingaDVD/CD .................... 51

UsingtheDVDPlayerSoftware............. 52

Using the DVD Player on

BatteryPower .......................... 52

AutoInsertNotificationFunction............ 53

PC Cards

Installing PC Cards . . . . . . . . ............... 54

RemovingPCCards...................... 55

Power Management

Suspend/ResumeButton .................. 38

SuspendMode.......................... 38

Save-to-Disk Mode . . .................... 38

IdleMode ............................. 40

StandbyMode.......................... 40

DisplayTimeout......................... 40

Memory Upgrade Module

Installing a Memory Upgrade Module . . . . . . . . 56

Removing a Memory Upgrade Module . . . . . . . 57

Checking the Computer Recognition

ofNewMemoryCapacity................. 58

Table of Contents

Device Ports

Modem (RJ-11) Telephone Jack. . . . . . . ...... 59

ParallelPort ............................ 59

SerialPort.............................. 59

PS/2Port.............................. 59

UniversalSerialBusPort................... 60

InfraredPort............................ 60

Wireless Infrared (IR) Mouse Receiver . . . . . . . . 60

Microphone Jack . . . . . . . . ................ 60

StereoLine-InJack....................... 60

Digital Audio-Out Connector. . . . . . . . ....... 61

Headphone Jack. . . . . . . . . ................ 61

ExternalMonitorPort..................... 61

SECTION FIVE

Troubleshooting

IdentifyingtheProblem ................... 65

SpecificProblems........................ 65

Troubleshooting Table . . . . . . . . . . . ......... 66

PowerOnSelfTestMessages .............. 75

Emergency DVD/CD-RW/CD-ROM

TrayRelease............................ 77

ModemResultCodes..................... 77

RecoveryCD-ROM ...................... 78

SECTION SIX

Care and Maintenance

Fujitsu LifeBook . . . . . . . . . . . . . . ........... 83

Batteries............................... 84

FloppyDisksandDrives................... 84

DVDsandCDs.......................... 85

PCCards.............................. 85

SECTION SEVEN

Specifications

ConfigurationLabel...................... 89

Microprocessor ......................... 90

Memory............................... 90

Video................................. 90

Audio................................. 90

MassStorageDeviceOptions .............. 90

Features............................... 90

DevicePorts............................ 91

Keyboard.............................. 91

Power ................................ 91

DimensionsandWeight................... 91

EnvironmentalRequirements............... 91

SECTION EIGHT

Glossary............................... 95

LifeBook C Series

Section One

Preface

AboutThisGuide......................... 3

FujitsuPCContactInformation ..............3

Warranty...............................3

Preface

LifeBook C Series – Section Seve n

Preface

ABOUT THIS GUIDE

The LifeBook™ C Series notebook from Fujitsu PC Corporation is a powerful notebook computer. It is powered by an Intel® or AMD® microprocessor, has a built-in color display, a vast array of possible configurations, and brings the computing power of desktop personal computers (PCs) to a portable environment.

This manual explains how to operate your Fujitsu LifeBook’s hardware and built-in system software. Your notebook is compatible with the IBM® PC AT.

Your LifeBook comes with Windows® 98 Second Edition pre-installed.

The Fujitsu LifeBook is a completely self-contained unit with an active-matrix (TFT) color LCD display. It has a powerful interface that enables it to support a variety of optional features.

Conventions Used in the Guide

Keyboard keys appear in brackets. Example: [FN], [F1], [ESC], [ENTER] and [CTRL].

Pages with additional information about a specific topic are cross-referenced within the text. Example: (See page xx.)

WARNING

The warning icon highlights information that can be hazardous to either you, your notebook, or your files. Please read all warning information carefully.

FUJITSU PC CONTACT INFORMATION

Service and Support

You can contact Fujitsu Service and Support the following ways:

■

Toll free: 1-800-8FUJITSU (1-800-838-5487)

■

Fax: 1-901-259-5700

■

E-mail: 8fujitsu@fpc.fujitsu.com

■

Web site: http://www.8fujitsu.com

Before you place the call, you should have the following information ready so that the customer support representative can provide you with the fastest possible solution:

■

Product name

■

Product configuration number

■

Product serial number

■

Purchase date

■

Conditions under which the problem occurred

■

Any error messages that have occurred

■

Hardware configuration

■

Type of device connected, if any

On screen buttons or menu items appear in bold Example: Click OK to restart your notebook.

DOS commands you enter appear in Courier type. Example: Shutdown the computer?

POINT

The point icon highlights information that will enhance your understanding of the subject material.

CAUTION

The caution icon highlights information that is important to your safety, to the safe operation of your computer, or to the integrity of your files. Please read all caution information carefully.

Fujitsu On-line

You can go directly to the on-line Fujitsu Product catalog for your notebook by clicking on the LifeBook Accessories Web site URL link, located in the Windows Start menu.

You can also reach Fujitsu Service and Support on-line by clicking on the Fujitsu Service and Support Web site URL link, located in the Service and Support Software folder of the Windows Start menu.

POINT

You must have an active internet connection to use the on-line URL links.

WARRANTY

Your notebook is backed by a one year International Limited Warranty and includes toll-free technical support. Check the service kit that came with your notebook for warranty terms and conditions.

LifeBook C Series – Section On e

Getting to Know Your LifeBook

Section Two

Getting to Know Your LifeBook

Overview

Unpacking.............................. 7

LifeBookFeatures......................... 8

ValuableLifeBookSoftware.................8

PopularAccessories....................... 9

Locating the Controls and Connectors

Top and Front Components . . . . . . . . . .......10

Left-SidePanelComponents ...............12

Right-Side Panel Components . . . . . . . . ......13

RearPanelComponents................... 15

BottomComponents .....................16

Status Indicator Panel

PowerIndicator.........................17

ACAdapterIndicator.....................17

BatteryLevelIndicators ................... 18

BatteryChargingIndicators ................18

DVD/CD-RW/CD-ROM Drive

AccessIndicator......................... 18

Hard Drive or Removable

MediaDriveAccessIndicator...............18

FloppyDiskDriveAccessIndicator...........19

PCCardAccessIndicators .................19

NumLkIndicator ........................ 19

CapsLockIndicator....................... 19

ScrLkIndicator..........................19

Keyboard

UsingtheKeyboard...................... 20

NumericKeypad ........................ 20

Windows Keys . . . . . . . . . . . . . . . ...........21

CursorKeys............................ 21

FunctionKeys ..........................21

ErgoTrac Pointing Device

Clicking............................... 22

Double-Clicking.........................22

Dragging..............................23

ErgoTracControlAdjustment...............23

Volume Control

ControllingtheVolume...................24

Setting the Hardware Volume Control . . . . . . . . 24

LifeBook Application Panel

SelectorSwitch .........................25

Application Launch CD Player Buttons. . . . . . . . 25

LCDDisplay............................ 25

E-mailNotificationLED ...................26

Configuring your LifeBook Application Panel . . . 26

UsingtheE-mailNotificationLED ...........27

UsingtheCDPlayer...................... 27

DesktopControlPanel.................... 28

LifeBook C Series – Section Tw o

Pre-Installed Software

Learning About Your Application Software. . . . . 30

PCDoctor ............................. 30

LapLinkProfessional...................... 30

Quicken2000Basic...................... 30

McAfeeVirusScan.......................30

PMSet98..............................30

AdobeAcrobatReader....................30

LifeBookApplicationPanelSoftware .........30

Getting to Know Your LifeBook

Figure 2-1 Fujitsu LifeBook C Series notebook

Overview

This section describes the components of your Fujitsu LifeBook. We strongly recommend that you read it before using your notebook – even if you are already familiar with notebook computers.

UNPACKING

When you receive your notebook, unpack it carefully, and compare the parts you have received with the items listed below.

For a Pre-configured model you should have:

■

LifeBook C Series notebook from Fujitsu (Figure 2-1)

■

Lithium ion battery, pre-installed

■

AC adapter with AC power cord (Figure 2-2)

■

Phone/ Modem (RJ-11) telephone cable

■

Recovery and Application Restore CD

■

Getting Started Guide

■

User’sGuide

■

Product Registration card

■

Product Catalog

■

International Limited Warranty Brochure

■

Getting Started with Microsoft Windows 98 Second Edition

■

First Cabin Registration card and envelope

Depending on your configuration these devices may also come with your notebook:

■

DVDsoftwareCD(formodelswithDVD-ROMdrive)

■

CD-RW Software CD (for models with CD-RW drive)

■

IR Mouse (selected or custom configured models only)

■

USB Camera and software CD (custom configured models only)

Depending on your configuration, one of the following devices will be built-in:

■

6x DVD drive

■

4x/4x/20x max CD-RW drive

■

24x max CD-ROM drive

Once you have checked and confirmed that your notebook system is complete, read through the following pages to learn about all of your notebook’s components.

Figure 2-2 AC Adapter

LifeBook C Series - Section Two

LIFEBOOK FEATURES

The LifeBook C Series notebook is a compact, yet powerful notebook computer available with a variety of features, including: (See Specifications on page 89 for

more information)

■

Latest high-speed Intel or AMD mobile processor

■

SDRAM system memory

■

Clear, bright TFT display

■

Lithium ion battery

■

Built-in 12GB, 9GB or 6GB hard drive

■

ATI Mobility-P video, 4MB of video RAM or Trident

2.5MB of video RAM

■

External monitor support with simultaneous display capabilities

■

Dual monitor support (Performance Models only)

■

LifeBook Application Panel/Audio CD Player

■

Internal 56K fax/data/voice modem with V.90 support

■

One of the following built-in devices:

■

DVD drive

■

4x/4x/20x max CD-RW drive

■

CD-ROM drive

■

Full audio and video features:

■

64 voice wavetable

■

Zoomed Video support for full motion video acceleration

■

Built-in Pioneer bass reflex stereo speakers

■

Built-in mono microphone

■

Stereo line-in jack

■

Stereo headphone jack

■

Microphone jack

■

Digital audio out

■

Combination PC card slot accommodates 2 Type II or 1 Type III cards

■

Fast IrDA (4Mbps) compatible infrared port for wireless data transfer

■

Integrated pointing device for superb cursor control and comfort

■

Full-size 87-key keyboard with three dedicated Windows keys

■

Hot swappable PS/2 port for external components

■

USB device support

■

Wireless mouse support (Performance Models only)

VALUABLE LIFEBOOK SOFTWARE

■

Microsoft Windows 98 operating system

■

Microsoft Internet Explorer

■

Microsoft Press Interactive Training for Windows 98

■

Microsoft Works

■

Quicken 2000

■

LapLink Professional

■

PC-Doctor

■

PMSet 98

■

McAfee VirusScan

■

Adobe Acrobat Reader

■

Netscape Communicator

■

Internet Service Providers:

■

AOL

■

CompuServe™

■

Earthlink

POINT

Some software may come separately on a CD and will have to be installed.

Getting to Know Your LifeBook

POPULAR ACCESSORIES

For ordering or additional information on Fujitsu accessories please visit our Web site at www.fujitsu-pc.com or call 1-877-FPCDirect.

Memory Upgrades

■

32MB SDRAM

■

64MB SDRAM

■

128MB SDRAM

Power

■

Lithium ion battery

■

Auto/Airline Adapter

■

AC Adapter

PC Cards

■

Ethernet 10/100+ Modem 56K

■

Global Access Modem 56K

Additional Accessories

■

Wireless Infrared Mouse (Supported by Performance Models only)

■

Wireless Keyboard and Mouse

■

Numeric Key pad

■

Universa l LAN Hub

■

USB Digital Camera

■

Monitor stand

■

MindPa th PocketPoint

■

Te l e A d a p t 1 6 ’ Te l e C o r d

■

Notebook Guardian Lock

Carrying Cases

■

Diplomat

■

Diplomat with Airpro

■

ProPack Backpack

LifeBook C Series - Section Two

Display Panel

Status Indicator Panel

ErgoTrac Pointing Device

Display Panel Latch

Closed Cover Switch

Built-in Microphone

Wireless IR Mouse Receiver

(Performance Models only)

Stereo Speakers

LifeBook Application Panel

(Application Launcher/Audio CD Player)

Figure 2-3 LifeBook C Series notebook with display open

Locating the Controls and Connectors

TOPANDFRONTCOMPONENTS

The following is a brief description of your notebook’s top and front components.

Display Panel Latch

The display panel latch locks and releases the display panel. (Figure 2-3)

Suspend/Resume Button

Stereo Speakers

Keyboard

Display Panel

The display panel is a color LCD panel with back lighting for the display of text and graphics. (Figure 2-3)

(See Display Panel on page 34 for more information)

Built-in Microphone

Thebuilt-inmicrophoneallowsmonoaudioinput.

(Figure 2-3)

Status Indicator Panel

The Status Indicator Panel displays symbols that correspond with a specific component of your notebook.

(Figure2-3)(SeeStatusIndicatorPanelonpage17for more information)

Getting to Know Your LifeBook

Wireless IR Mouse Receiver

The Wireless IR Mouse Receiver allows the use of an optional wireless IR mouse. No more hassles with cables. (Performance Models only) (Figure 2-3)

Suspend/Resume Button

The Suspend/Resume button allows you to suspend notebook activity without powering off, resume your notebook from suspend mode, and power on your notebook when it has been shut down from Windows 98.

(Figure 2-3) (See Suspend/Resume Button on page 38 for more information)

Stereo Speakers

The built-in dual speakers allow for stereo sound.

(Figure 2-3)

Closed Cover Switch

The closed cover switch turns off the LCD back lighting when the display panel is closed. (Figure 2-3)

Keyboard

A full-size keyboard with dedicated Windows keys. (Figure 2-3) (See Keyboard on page 20 for more

information)

ErgoTrac

The pointing device is a mouse-like cursor control with two buttons. (Figure 2-3) (See ErgoTrac Pointing Device

on page 22 for more information)

LifeBook Application Panel

The LifeBook Application Panel allows you to either launch your favorite applications by the touch of a button or to use as an Audio CD-ROM player when

your unit is on or has been shut down from Windows.

(Figure 2-3) (See LifeBook Application Panel on page 25 for more information)

LifeBook C Series - Section Two

Anti-theft Lock

Power Switch Lithium ion Battery Bay

Figure 2-4 LifeBook C Series notebook left-side panel

PC Card Slot

LEFT-SIDE PANEL COMPONENTS

Following is a brief description of your notebook’s left-side components.

Anti-theft Lock Slot

The anti-theft lock slot allows you to attach a optional physical lock down device. (Figure 2-4)

Power Switch

This switch is the main power switch for your notebook.

(Figure 2-4)

PC Card Slots

The PC Card Slots allow you to install two Type II PC Cards or oneType III PC Card. (Figure 2-4) (See PC

Cards on page 54 for more information)

PC Card Eject Buttons

Lithium ion Battery Bay

The battery bay contains the internal Lithium ion battery. It can be opened for the removal of the battery when stored over a long period of time or for swapping a discharged battery with a charged Lithium ion battery.

(Figure 2-4) (See Lithium ion Battery on page 45 for more information)

Getting to Know Your LifeBook

Headphone Jack

Stereo Line-in Jack and Digital Audio-Out

SPDIF (Preformance Models only)

Microphone Jack

DVD, CD-RW or CD-ROM Drive

Figure 2-5 LifeBook C Series notebook right-side panel

Volume Control

RIGHT-SIDE PANEL COMPONENTS

Following is a brief description of your notebook’s right-side components.

Headphone Jack

The headphone jack allows you to connect headphones or powered external speakers. (Figure 2-5) (See Head-

phone Jack on page 61 for more information)

Stereo Line-in Jack

The stereo line-in jack allows you to connect an external audio source. (Figure 2-5) (See Stereo Line-In Jack on

page 60 for more information)

Modem (RJ-11) Telephone Jack

Floppy Disk Drive

Volume Control

The volume control provides manual control of the sound level of all audio output. (Figure 2-5) (See Volume

Control on page 24 for more information)

DVD/CD-RW/CD Drive

Your notebook will have one of the following built-in devices. (Figure 2-5)

■

DVD drive (See DVD/CD-ROM Drive on page 50 for more information)

■

4x/4x/20x max CD-RW drive

■

CD-ROM drive (See CD-ROM Drive on page 48 for more information)

Digital Audio-Out

The digital audio-out jack (Available on Performance Models only) allows you to download digital audio onto Sony™ &PhilipsMini-discplayer’sSPDIF(SonyPhilips Digital Interface) format. (Figure 2-5) (See Digital

Audio-Out Connector on page 61 for more information)

Microphone Jack

The microphone jack allows you to connect an external mono microphone. (Figure 2-5) (See Microphone Jack on

page 60 for more information)

Floppy Disk Drive

The floppy disk drive provides removable data storage.

(Figure2-5)(SeeFloppyDiskDriveonpage47formore information)

Modem (RJ-11) Telephone Jack

TheModem(RJ-11)telephonejackisforattaching a telephone line to the internal 56K modem.

(Figure2-5)(SeeModem(RJ-11)TelephoneJackon page 59 for more information)

LifeBook C Series - Section Two

WARNING

The internal modem is not intended for use with Digital PBX systems. Do not connect the internal modem to a Digital PBX as it may cause serious damage to the internal modem or your entire notebook. Consult your PBX manufacturer’s documentation for details. Some hotels have Digital PBX systems. Be sure to find out BEFORE you connect your modem.

CAUTION

The internal modem is designed to the ITU-T V.90 standard. Its maximum speed of 53000bps is the highest allowed by FCC, and its actual connection rate depends on the line conditions. The maximum speed is 33600bps at upload.

CAUTION

The internal modem on all Fujitsu notebooks from Fujitsu PC Corporation are certified for use in the United States and Canada. The modem may be certified in other countries.

PS/2 Port

Getting to Know Your LifeBook

Serial Port

External Monitor Port

Parallel Port

Infrared Port

USB Port

DC Power Jack

Figure 2-6 LifeBook C Series notebook rear panel

REAR PANEL COMPONENTS

Following is a brief description of your notebooks rear panel components.

PS/2 Port

ThePS/2portallowsyoutoconnectanexternalPS/2 keyboard, mouse or numeric keypad. (Figure 2-6)

(See PS/2 Port on page 59 for more information)

Serial Port

The serial port allows you to connect serial (RS-232C) devices. (This is also sometimes referred to as a COMM port.) (Figure 2-6) (See Serial Port on page 59 for more

information)

Parallel Port

The parallel port allows you to connect parallel devices. (This is also sometimes referred to as an LPT port.) (Figure 2-6) (See Parallel Port on page 59 for

more information)

External Monitor Port

The external monitor port allows you to connect an external VGA or SVGA CRT monitor. (Figure 2-6) (See

External Monitor Port on page 61 for more information)

Infrared Port

The fast IrDA compatible port allows you to communicate with another IrDA compatible infrared device without a cable. (Figure 2-6) (See Infrared Port on

page 60 for more information)

USB Port

The USB port allows you to connect Universal Serial Bus devices. (Figure 2-6) (See Universal Serial Bus Port on

page 60 for more information)

DC Power Jack

The DC power jack allows you to plug in the AC adapter or the optional Auto/Airline adapter to power your notebook and charge the internal Lithium ion Battery.

(Figure 2-6)

LifeBook C Series - Section Two

Main Unit and Configuration Label

Certificate of Authenticity Label (approximate location)

Lithium ion Battery Bay

Figure 2-7 LifeBook C Series notebook bottom panel

BOTTOM COMPONENTS

Following is a brief description of your notebook’s bottom panel components.

Main Unit and Configuration Label

The configuration label shows the model number and other information about your notebook. In addition, the configuration portion of the label has the serial number and manufacturer information that you will need to give your support representative. It identifies the exact version of various components of your notebook. (Figure 2-7) (See Configuration Label on

page 89 for more information)

Lithium ion Battery Bay

(Figure 2-7) (See Lithium ion Battery on page 45 for more information)

Getting to Know Your LifeBook

Power

AC Adapter

Battery Charging

Battery Identifier

Battery Level

DVD/CD-RW/CD-ROM Drive Access

Hard Drive Access

Figure 2-8 Status Indicator Panel

Floppy Disk Drive Access

Status Indicator Panel

The Status Indicator panel is located in the recess just above your keyboard. Within this panel are symbols that correspond with a specific component of your Fujitsu LifeBook. These symbols tell you how each of those components are operating. (Figure 2-8)

POWER INDICATOR

The Power indicator symbol states whether your system is operational. It has several different states, each of which tells you what mode your notebook is in at that time.

■

Steady On: This means that there is power to your notebook and that it is ready for use.

■

Flashing: This means that your notebook is in Suspend mode.

■

Steady Off: This means that your system is either in Save-to-Disk mode, or that your notebook has been turned off with the power switch.

PC Card Slot Identifier

PC Card Access

NumLk

ScrLk

CapsLk

CAUTION

Your notebook’s power switch must be turned off to prevent all current draw.

AC ADAPTER INDICATOR

The AC Adapter indicator states whether your notebook is operating from the AC adapter, the Auto/Airline adapter or the batteries. This icon has two different states that can tell you what power source your notebook is using.

■

On: This means that either of the adapters are currently in use.

■

Off: Power is only coming from the batteries, and you do not have an adapter connected.

If you are charging your battery, the Power indicator symbol will remain on even if your notebook is shut off. The Power indicator symbol will also remain on if you have either adapter connected and are shut down from Windows, but have not turned off the power switch.

LifeBook C Series – Section Tw o

BATTERY LEVEL INDICATORS

The Battery Level indicators state whether or not the primary Lithium ion battery is installed. In addition, this symbol states how much charge is available within the battery. The symbol will only be displayed for a battery that is currently installed in your notebook.

(Figure 2-9)

76%–100% Charging

76%–100%

51%–75%

26%–50%

11%–25%

Low Warning <11%

Critical Low or Dead Battery

Shorted Battery

Figure 2-9

POINT

If there is no battery activity, the adapters are not connected, and the power switch is Off, the Battery Level indicators will also be off.

CAUTION

Batteries subjected to shocks, vibration or extreme temperatures can be permanently damaged.

DVD/CD-RW/CD-ROM DRIVE

ACCESS INDICATOR

The DVD/CD-RW/CD-ROM Access indicator tells you that the DVD/CD-RW/CD-ROM drive is being accessed. If the Auto Insert Notification function is active, the indicator will flash periodically when your system is checking the DVD/CD-RW/CD-ROM drive. If the Auto Insert Notification function is not active, the indicator will only flash when you access the DVD/CD-RW/CDROM drive. The default setting is the Auto Insert Notification function active. (See Auto Insert Notification Func-

tion on page 53 for more information)

POINT

The Windows 98 SE DVD/CD-RW/CD-ROM Auto Insert Notification function will periodically check for a DVD/CD-RW/CD-ROM installed in the drive, causing the DVD/CD-RW/CD-ROM Access indicator to flash. The DVD/CD-RW/CD-ROM automatic insertion function allows your system to automatically start a DVD/ CD-RW/CD-ROM as soon as it is inserted in the drive and the tray is closed. It will begin playing an audio DVD/CD or will start an application if the DVD/CD has an auto-run file.

on page 53 for more information)

(See Auto Insert Notification Function

CAUTION

A shorted battery is damaged and must be replaced.

BATTERY CHARGING INDICATORS

Located to the left of the Battery Level indicators is a small arrow symbol. This symbol states whether the battery is charging. This indicator operates whether the power switch is in the On or Off position, and will flash if the battery is too hot or cold to charge. (Figure 2-9)

HARD DRIVE OR REMOVABLE

MEDIA DRIVE ACCESS INDICATOR

The Hard Drive Access indicator states whether your internal hard drive or optional second hard drive is being accessed.

POINT

The Hard Drive Access indicator does not show which hard drive is being accessed. It works the same of any of the devices.

Getting to Know Your LifeBook

FLOPPY DISK DRIVE

ACCESS INDICATOR

The Floppy Disk Drive Access indicator states whether the floppy disk drive is being accessed. This indicator will flash if your software tries to access a disk even if no floppy disk drive is installed. (See Floppy Disk Drive on

page 47 for more information)

PC CARD ACCESS INDICATORS

The PC Card Access indicator(s) state whether or not your notebook is accessing a PC Card(s). The indicator will flash if your software tries to access a PC Card even if there is no card installed. The number inside the indicator refers to which PC Card slot is being accessed. (See

PC Cards on page 54 for more information)

NUMLK INDICATOR

The NumLk indicator states that the internalkeyboard is set in ten-key numeric keypad mode.

POINT

If you are using the optional external numerical keypad, pressing the [NumLk] key will activate the external keypad. The indicator will come on, however it will not change any of the functionality of your keyboard keys.

CAPSLOCK INDICATOR

The CapsLock indicator states that your keyboard is set to type in all capital letters.

SCRLK INDICATOR

The ScrLk indicator states that your scroll lock is active.

LifeBook C Series – Section Tw o

Function Keys

Fn Key

Start Key

Numeric Keypad

Figure 2-10 Keyboard

Keyboard

USING THE KEYBOARD

Your Fujitsu LifeBook has an integral 87-key keyboard. The keys perform all the standard functions of a 101-key keyboard, including the Windows keys and other special function keys. This section describes the following keys.

(Figure 2-10)

■

Numeric keypad

■

Cursor keys

■

Function keys

■

Windows keys

NUMERIC KEYPAD

Certainkeysonthekeyboardperformdualfunctionsas both standard character keys and numeric keypad keys. NumLk can be activated by pressing the [NumLk] keys. Turning off the NumLk feature is done the same way. Once this feature is activated you can enter numerals 0 through 9, perform addition ( + ), subtraction ( - ), multiplication ( * ), or division ( / ), and enter decimal

Start Key

Application Key

Cursor Keys

points ( . ) using the keys designated as ten-key function keys. The keys in the numeric keypad are marked on the front edge of the key to indicate their secondary functions.

(Figure 2-10)

POINT

WINDOWS KEYS

Your notebook has three Windows keys, consisting of two Start keys and an Application key. The two Start keys display the Start menu. This button functions the same as your onscreen Start menu button. The Application key functions the same as your right mouse button and displays shortcut menus for the selected item. (Please refer to your Windows documentation for additional information regarding the Windows keys.)

(Figure 2-10)

Getting to Know Your LifeBook

CURSOR KEYS

The cursor keys are the four arrow keys on the keyboard which allow you to move the cursor up, down, left and right in applications. In programs such as Windows Explorer, it moves the “focus” (selects the next item up, down, left, or right). (Figure 2-10)

FUNCTION KEYS

Your notebook has 12 function keys, F1 through F12. The functions assigned to these keys differ for each application. You should refer to your software documentation to find out how these keys are used.

(Figure 2-10)

[FN] Key

The [FN] key provides extended functions for the notebook and is always used in conjunction with another key.

■

[FN+F5]: Pressing [F5] while holding [FN] allows you to toggle between video compensation and no

compensation. (Video compensation controls spacing onthedisplay.Whenitisenabled,displayswithless than 1024 x 768 or 800 x 600 pixel resolution will still cover the entire screen.)

■

[FN+F6]: Pressing [F6] repeatedly while holding [FN] will lower the brightness of your display.

■

[FN+F7]: Pressing [F7] repeatedly while holding [FN] will increase the brightness of the display.

■

[FN+F10]: Pressing [F10] while holding [FN] allows you to change your selection of where to send your display video. Each time you press the combination of keys you will step to the next choice. The choices, in order, are: built-in display panel only, both built-in display panel and external monitor or external monitor only.

■

[FN+Suspend/Resume]: Pressing [Suspend/ Resume] while holding [FN] activates the Save-toDisk mode. (See Power Management on page 38 for

more information)

LifeBook C Series – Section Tw o

Cursor

Left Button

Right Button

Cursor Control

Figure 2-11 ErgoTrac™ pointing device

ErgoTrac Pointing Device

The ErgoTrac pointing device is built into your Fujitsu LifeBook. It is used to control the movement of the cursor to select items on your display panel. The ErgoTrac is composed of a cursor control and a left and right button. The cursor control works the same way a mouse does, and moves the cursor around the display. The left and right buttons function the same as mouse buttons. The actual functionality of the buttons may vary depending on the application that is being used.

(Figure 2-11)

POINT

An external mouse can be connected to either the USB or PS/2 port on your notebook, and used simultaneously with the ErgoTrac. However, if you boot the system with an external mouse connected the ErgoTrac will be disabled or enabled depending on the specifications in your BIOS settings.

Setup Utility on page 35 for more information)

(See BIOS

POINT

If the Infrared Mouse is enabled, your PS/2 external device will be disabled.

(See BIOS Setup Utility on

page 35 for more information)

CLICKING

Clicking means pushing and releasing a button. To left-click, move the cursor to the item you wish to select, press the left button once, and then immediately release it. To right-click, move the mouse cursor to the item you wish to select, press the right button once, and then immediately release it. (Figure 2-12)

Figure 2-12 Clicking

DOUBLE-CLICKING

Double-clicking means pushing and releasing the left button twice in rapid succession. This procedure does not function with the right button. To double-click, move the cursor to the item you wish to select, press and release the left button twice. (Figure 2-13)

Getting to Know Your LifeBook

Figure 2-14 Dragging

ERGOTRAC CONTROL ADJUSTMENT

The Windows Control Panel allows you to customize your ErgoTrac with selections made from within the Mouse Properties dialog box. There are four aspects of the ErgoTrac operation which you can adjust:

Figure 2-13 Double-clicking

POINT

If the interval between clicks are too long, double-clicking will not be executed.

POINT

Parameters for the ErgoTrac can be adjusted from the Mouse Properties dialog box located in the Windows Control Panel.

DRAGGING

Dragging means pressing and holding the left button, while moving the cursor. To drag, move the cursor to the item you wish to move. Press and hold the left button while moving the item to its new location and then release it. (Figure 2-14)

■

Buttons: This tab lets you set up the buttons for right or left handed operation, in addition to setting up the time interval allowed between clicks when double-clicking.

■

Pointers: This tab lets you set up the scheme for the cursor depending on its functionality.

■

Motion: This tab lets you set up a relation between the speed of your finger motion and the speed of the cursor. It also allows you to enable a Pointer Trail for the cursor arrow.

■

General: This tab allows you to choose the type of mouse you are utilizing. Your notebook is setup to use the ErgoTrac pointing device. If you wish to use an external mouse you will need to change the settings.

LifeBook C Series – Section Tw o

Volume Control

Your Fujitsu LifeBook has multiple volume controls whichinteractwitheachother.

CAUTION

Any software that contains audio files will also contain a volume control of its own. Both the main notebook volume control and the software volume control will interact with each other, but it should be noted that if you set your software volume to Off, you will override the main volume control setting and the software setting will control the maximum knob setting.

CONTROLLING THE VOLUME

There is the hardware volume control located on the notebook itself, and the volume control set from within the Volume Control on the Taskbar. In addition to those, there are also application volume controls that are set within each program individually.

Each source discussed above, puts an upper limit on the volume level that must then be followed by the other sources. For example:

■

Your hardware volume control is all the way down, therefore your individual software application’s volume control has no effect on the volume.

We recommend that you use the hardware volume controls to set the upper limit for the sound level and then make fine adjustments with the Volume Control on the Taskbar and individual application software.

SETTING THE HARDWARE VOLUME CONT ROL

1. Turn the volume control knob to the right of your notebook to increase the volume.

2. Turnthevolumecontrolknobtothelefttodecrease the volume. (Seefigure2-5onpage13forlocation)

Getting to Know Your LifeBook

Selector Switch

Application Launcher/CD Player buttons

Figure 2-15 LifeBook C Series Application Launcher/CD Player Buttons

LCD Display

LifeBook Application Panel

A unique feature of your Fujitsu LifeBook is the LifeBook Applications Panel. This panel allows you to operate the DVD/CD-RW/CD-ROM drive as an independent audio CD Player or launch applications with the touch of one button even when your system is on

(Figure 2-15)

POINT

E-mail Notification LED

POINT

The CD Player only works with audio CDs. Neither the CD Player or launch buttons will work when the power switch is in the Off position.

The panel consists of the following elements:

SELECTOR SWITCH

Located at the far left of the panel, this switch allows you to select the function of the panel—either as an Application Launcher, a CD Player, or as a lock.

LifeBook Applications Panel uses the date and time settings of your LifeBook notebook. If the date and time are off, you can adjust this setting in the Windows Control Panel.

Your notebook is pre-installed with software utilities that let you operate and configure your LifeBook Application Panel. These utilities are found under the Start menu, under Programs, then under LifeBook Application Panel. They include a CD Player, Application Panel Setup, E-mail LED Setup, Application Panel Guide (this guide), Activate Panel and Deactivate Panel. The LifeBook Application Panel system makes your notebook more than just another notebook computer.

APPLICATION LAUNCH CD PLAYER BUTTONS

When the selector switch is in the Application position, pressing any of the buttons will launch a user-defined application. When the selector switch is in the CD Player position, the buttons operate the CD player, and when the selector switch is in the Lock position, the buttons are disabled and do nothing when pressed.

LCD DISPLAY

LCD displays the number of the audio track being played. It is only illuminated when the power switch is in the On position and an audio CD is in the DVD/CD-ROM drive.

LifeBook C Series – Section Tw o

POINT

If there is a CD in the player which has finished playing, the LCD will display a “1”, even though it will not auto- matically start playing and will not automatically repeat the CD.

■

Application A – Microsoft Works

■

Application B – Quicken® 99

■

Internet – Internet Explorer® 5.0

■

E-Mail – Netscape® Messenger

POINT

E-MAIL NOTIFICATION LED

By setting upthe E-mail LED notification in conjunction with your E-mail button setup, you can connect to your ISP, check for and retrieve new mail, terminate connection, and activate the E-mail LED to notify that new mail has arrived.

POINT

E-mail Notification LED requires POP3 Server with no Password Authentication to work.

CONFIGURING YOUR LIFEBOOK APPLICATION PANEL

When you start Windows 98, the LifeBook Application Panel is automatically activated. An icon resembling a finger pressing a button will appear on the system tray (the indented portion of the status bar where the clock is displayed). When you see this icon you will know that LifeBook Application Panel is active.

As an application launcher, the LifeBook Application Panel is very flexible, giving you a variety of options. To set up the Panel to best suit your needs, we have provided the Application Panel Setup, utility that quickly and easily helps you make the most of this valuable feature.

To configure your LifeBook Application Panel with Application Panel Setup:

1. Click on Start.

2. Click on Programs.

3. Click on LifeBook Application Panel.

4. Click on Application Panel Setup.

The tabs in Application Panel Setup may not be in the same order as the buttons on your LifeBook, please select the tab you wish to change carefully.

To change an application associated with the Application A, Application B, or E-mail buttons, click on the tab for the button you would like to reconfigure – for example, Application A. Click on Browse from Start Menu, scroll down the list of applications, click on the application youwishtolaunchwiththisbutton,andthenclickOK. The button will now launch the new application.

The Internet tab is different. It comes set to launch your Windows 98 default Internet browser, (Internet Explorer, unless you have changed this in Windows 98.) In order to reconfigure it to launch another program follow these easy steps:

1. Click on Other from the Internet browser box.

2. Click on Browse from Start Menu.

3. Scroll down the list of applications, and the click on the application you wish to launch with this button.

4. Click OK.

The button will now launch the new application. If you want to return to launching your Windows 98 default Internet browser with this button, you need only click on “DefaultInternet Browser” from the Internet browser box. Be aware that you will erase the settings for the “other application”. If you wish to go back to launching the “other application” from this button, you will need to reconfigure it as described above.

POINT

The Application Panel Setup utility will appear. There are tabs that correspond to the application buttons on the LifeBook Application Panel. When you receive your notebook, these buttons are pre-configured to launch the following programs:

The Internet or E-mail buttons can be configured to launch any application you wish, not just an Internet browser or e-mail program.

Getting to Know Your LifeBook

At the bottom of each application setup page are two selectable options. The first will enable/disable the button when your notebook is in Standby mode, and the second will enable/disable the button when your notebook is in the pseudo-off state. You can enable/disable either or both of these functions simply by clicking on the option.

POINT

If you choose to have the buttons work when the notebook is in standby or pseudo-off, they will function even if hit accidentally, and will turn on your notebook even if you are not present or using your notebook. This could deplete your battery, and you will need to recharge it before using the notebook. As a precaution, move the selector switch to the Lock position when you are away from your notebook.

When you have finished with Application Panel Setup click on OK, and the new settings will take effect.You can reconfigure your LifeBook Application Panel as often as you like.

USING THE E-MAIL NOTIFICATION LED:

POINT

To use the E-mail LED notification, you must have access to a POP3 Server with no Security Password Authentication. Contact your service provider to determine if they support POP3 without Security Password Authentication.

To configure the E-mail Notification LED:

1. Click on Start.

2. Click on Programs.

3. Click on LifeBook Application Panel.

4. Click on E-mail LED Setup.

5. TheE-mailLEDSetupscreenwillappear.Choose thetypeofconnection:LANorDialup.IfLAN: Click on LAN. Enter the POP3 Server name, your account name and password for that account. Consult your Service provider if you do not know or are unsure of the information requested. If Dial Up: Click on Dial Up. Choose the Dial up configuration (as previously set in Dial Up Networking) you wish to retrieve mail from. Enter the POP3 Server name, your account name and password for that account.

Theaccountnameandpasswordshouldbethe same information you entered in the Dial UP configuration. After all the information has been entered, test the connection by clicking on “Te s t i n g connection with current setting”. If an error occurs, check the settings and information on Dial Up Network and E-mail LED notification.

Configure the E-mail button (see Configuring Your LifeBook Application Panel) to launch the mail software youwanttouse,i.e.OutlookExpress,Netscape Messenger,etc.YoucanalsoadjusttheLEDblinking time. The default setting is for 60 seconds after mail has been retrieved.

After the setup (Dial Up Networking/E-mail/E-mail LED) is completed, you are ready to retrieve mail. When you press the E-mail button, your system will establish connection with your provider, check for and retrieve new mails, terminate the connection, and activate the blinking LED to alert you of new mail.

USING THE CD PLAYER

The CD player enables you to use your notebook’s DVD/CD-ROM drive as an audio CD player, even when your notebook is in the pseudo-off state, in stand-by mode or in suspend mode. As long as the power switch is in the On position, the CD player will function.

POINT

If you shut down from Windows while the CD player is playing an audio CD, it will stop. To continue to use the CD Player, turn the power switch to the On position and press the play button. The audio CD will start playing at Track 1.

POINT

You cannot go into Suspend Mode or Save-to-Disk Mode while the CD Player is playing a CD. If you press the Suspend button, your notebook will not suspend until you stop the CD Player.

LifeBook C Series – Section Tw o

POINT

If you slide the Selector switch to either Lock or Application while an audio CD is playing, it will stop. You will not be able to start it again until you have returned the Selector switch to the CD Player position. You cannot use the CD Player at any time unless the Selector switch is in the CD Player position.

There is no configuration required for CD player operation. The buttons are pre-configured to work like a normal CD player. When the selector switch is in the bottom position, the buttons will operate as follows:

■

Stop/Eject: This is the first button to the right of the selector switch. If you press it once, it will stop an audio CD that is playing. If you press it twice, it will eject the audio CD.

■

Play/Pause: This is the second button to the right of the Stop/Eject button. Press this button to start playing an audio CD starting at Track 1. While the audio CD is playing, press it to pause. Press it again to continue.

POINT

If you press the play button and nothing happens, you either have the Selector switch set to the Application or Lock position, there is no audio CD in the DVD/CDROM drive, or you have a CD other than an audio CD in the drive.

DESKTOP CONTROL PANEL

Your notebook includes a desktop control panel for your notebook’s desktop that you can use at any time. You may use this panel to operate the CD player when you have the Selector switch in the Application or Lock position.

To use the desktop control panel:

1. Click on Start.

2. Click on Programs.

3. Click on Lifebook Application Panel.

4. Click on Display CD Player.

The desktop control panel will appear in the upper right corner of your screen. To close the panel:

1. Click on the “x” button.

To m i n i m i z e t h e p a n e l :

2. Click on the “-” button.

You can select from four appearances for your desktop control panel. Simply double click on the track display area of the panel, and a menu will appear which will allow you to select from a pull down menu. On the same pop-up are two other options:“Always on top” and “Continuous Play”.Ifyouclickon“Always on top” the desktop controls will always be seen on your screen, no matter what other application you are running. If you click on “Continuous Play”, your CD Player will auto- matically start over at the beginning of the CD in the drive as soon as it finishes the last track.

POINT

Because of the Windows CD auto-insertion function, audio CDs will start playing immediately after they are inserted if your notebook is On. This will not happen if you are using the CD Player in Suspend or Pseudo-off modes.

■

Back:Thisbuttonisimmediatelytotherightof the LCD display. Press this button once to skip one track back.

■

Forward: This is the second button to the right of the LCD.Pressthisbuttononcetoskipforwardonetrack.

You can move the desktop control panel to anywhere on your desktop. Drag it by clicking on the track number display, holding it down,and dragging the control panel. When you place it where you would like, release the mouse button.

POINT

If you have your display set to 256 colors the basic display will appear no matter which one you select. You will need to set your display colors to more than 256 in order to select other display appearances.

POINT

When you close the CD Player’s desktop control panel, it will stop the audio CD Player. Simply press the Play button if you would like to continue listening, and the CD Player will restart at track 1. The Selector switch must be in the CD Player position.

Deactivating and Activating the LifeBook Application Panel

To deactivate the LifeBook Application Panel, follow these easy steps:

1. Click on Start.

2. Click on Programs.

3. Click on LifeBook Application Panel.

4. Click on Deactivate Panel.

To reactivate, follow the same procedure, except for step 4. Click on Activate Panel instead.

Getting to Know Your LifeBook

Application Panel Setup

■

If you insert an audio CD which has both audio and data tracks into the DVD/CD-ROM drive, the CD Player may fail to play the first audio track.

■

The Volume Up, Volume Down and Mute controls for the CD player desktop control panel adjusts the volume of the CD audio line only. It does not adjust your notebook’s master software volume control or the manual volume on the LifeBook notebook.

■

The CD player desktop control panel is designed to be displayed in High Color (16-bit) or in True Color (24-bit or more). If you have your notebook’sdisplay set for 256 colors or less CD Player will display in a “basic” mode.

POINT

Every time you start Windows 98, the LifeBook Application Panel is activated. Even if you deactivated it before you shut down.

LifeBook C Series – Section Tw o

Pre-Installed Software

Your Fujitsu LifeBook comes with pre-installed software for playing audio and video files of various formats. In addition there is file transfer software, virus protection software and Power Management software.

LEARNING ABOUT YOUR APPLICATIONS

Tutorials

All operating systems and most application software have tutorials built-into them upon installation. We highly recommend that you step through the tutorial before you use an application.

Manuals

Included with your notebook you will find manuals for your installed operating system and other pre-installed software. Any manuals that are not included, are available online through the help system of the software. We recommend that you review these manuals for general information on the use of these applications.

PC DOCTOR

PC Doctor by Watergate Software is primarily for use by your support representative when assisting you with troubleshooting.

LAPLINK PROFESSIONAL

LapLink Professional by Traveling Software®, allows you to transfer files directly to other computers via an internal modem, a PC Card modem, the infrared port, the USB port, or a serial or parallel cable (cables not included). (See your LapLink online help for proper

operating procedures)

QUICKEN 2000 BASIC

Quicken 2000 Basic by Intuit is a personal money management program. It has features such as portfolio management, account registries, on-line banking and bill paying features.

MCAFEE VIRUSSCAN

VirusScan, by McAfee, is an antivirus program that can be run after loading data or programs onto your notebook. It assists in protection of the data currently on your hard disk from contamination and destruction.

(See your VirusScan online help or manual for more information on how and when to run this program)

PMSET 98

PMSet 98 allows you to monitor and manage your battery status. (See your PMSet 98 online help for more

information on the correct way to use this program)

POINT

As your notebook does not support the CPU Clock control, the option is not active within the Power Control menu of PMSet 98.

ADOBE ACROBAT READER

TheAdobeAcrobatReader,locatedintheServiceand Support Software folder, allows you to view, navigate, and print PDF files from across all of the major computing platforms.

POINT

For maximum frequency response and bandwidth, leave the graphic equalizer levels at the mid-point (zero level). To customize the frequency response to your personal taste, adjust accordingly.

INTEL SPEEDSTEP*

Intel SpeedStep allows your LifeBook to operate in dual modes. When connected to AC source, the system operates in Maximum Performance Mode. When powered by battery, the system switches to Battery Optimized Mode to conserve battery life. SpeedStep software is automatically loaded when you start your system and appears on the system tray as a one of two flags. A checker flag indicates that the system is set for Maximum Performance Mode. A blue flag with a green center square indicates that the system is set for Battery Optimized Mode. You can change the setting or disable the software by double clicking the flag icon and changing the settings in the Intel SpeedStep Technology window.

LIFEBOOK APPLICATION PANEL SOFTWARE

Your notebook is pre-installed with software utilities that let you operate and configure your LifeBook Application Panel. These utilities are found under the Start menu, under Programs, then LifeBook Application Panel. They include a CD Player, Application Panel Setup, Email LED Setup, Application Panel Guide, Activate Panel and Deactivate Panel.

*Available on select LifeBook models.

Section Three

Getting Started

Power Sources

ConnectingthePowerAdapters.............33

Display Panel

OpeningtheDisplayPanel.................34

AdjustingDisplayPanelBrightness...........34

ClosingtheDisplayPanel.................. 34

Starting Your LifeBook

PowerOn ............................. 35

BootSequence..........................35

BIOSSetupUtility .......................35

Booting the System with Windows 98 . . . . . . . . 36

RegisteringYourLifeBook .................37

Power Management

Suspend/ResumeButton .................. 38

SuspendMode..........................38

Save-to-DiskMode ...................... 38

IdleMode .............................

Standby Mode. . . . . . . . . . . . . . . ...........40

DisplayTimeout.........................40

HardDiskTimeout....................... 40

Windows 98 Power Management . . . ........40

RestartingtheSystem .................... 40

PowerOff............................. 41

LifeBook C Series – Section Tw o

Getting Started

DC Output Cable

AC Cable

Figure 3-1 Connecting the AC Adapter

Power Sources

Your Fujitsu LifeBook has three possible power sources: a primary Lithium ion battery, an AC adapter or an optional Auto/Airline adapter.

CONNECTING THE POWER ADAPTERS

The AC adapter or optional Auto/Airline adapter provides power for operating your notebook and charging the batteries.

DC Power Jack

AC Adapter

Connecting the Optional Auto/Airline Adapter

1. Plug the DC output cable into the DC power jack on your notebook.

2. PlugtheAuto/Airlineadapterintothecigarette lighter of an automobile with the ignition key in the On or Accessories position.

3. PlugtheAuto/AirlineadapterintotheDCpower jack on an airplane seat.

Connecting the AC Adapter

1. Plug the DC output cable into the DC power jack of your notebook.

2. Plug the AC adapter into an AC electrical outlet.

(Figure 3-1)

Switching from AC Adapter Power or the Auto/Airline Adapter to Battery Power

1. Be sure that you have at least one charged battery installed.

2. Remove the AC adapter or the Auto/Airline adapter.

CAUTION

The Lithium ion battery is not charged upon purchase. Initially, you will need to connect either the AC adapter or the Auto/Airline adapter to use your notebook.

LifeBook C Series – Section Thre e

Display Panel Latch

Figure 3-2 Opening the Display Panel

Display Panel

Your Fujitsu LifeBook contains a display panel that is backlit for easier viewing in bright environments and maintains top resolution through the use of activematrix technology.

OPENING THE DISPLAY PANEL

1. Press the latch located at the top of the display panel. This releases the locking mechanism and raises the display slightly.

2. Lift the display backwards, being careful not to touch the screen, until it is at a comfortable viewing angle. (Figure 3-2)

ADJUSTING DISPLAY PANEL BRIGHTNESS

Once you have turned on your notebook, you may want to adjust the brightness level of the screen to a more comfortable viewing level. There are two ways to adjust the brightness, keyboard and power management utility.

Keyboard

Adjusting the brightness using the keyboard changes the setting only temporarily.

■

[FN+F6]: Pressing repeatedly will lower the brightness of your display.

POINT

If using AC power your brightness setting is set to it’s highest level by default. If using battery power your brightness settings is set to it’s lowest level by default.

Power Management Utility

Adjusting the brightness using the Power Management changes the setting permanently.

1. Double-click the Battery Icon in the lower right corner of your display. This will open the PMSet 98 Properties dialog box.

2. Select the Power Control tab and adjust your LCD Backlighting to the desired level.

3. Click OK or Apply to permanently change the settings.

You may need to readjust the brightness level periodically depending on your operating environment.

POINT

The higher the brightness level, the more power the notebook will consume and the faster your batteries will discharge. For maximum battery life, make sure that the brightness is set as low as possible.

■

[FN+F7]: Pressing repeatedly will increase the brightness of the display.

CLOSING THE DISPLAY PANEL

1. Holding the edge of your display panel, pull it forward until it is flush with the body of your notebook.

2. Push down until you hear a click. This will engage the locking mechanism and prevent your display panel from opening unexpectedly.

Getting Started

Starting Your LifeBook

POWER ON

Power Switch

The power switch is used to turn on your notebook from its off state. Once you have connected your AC adapter or charged the internal Lithium ionbattery, you can power on your notebook. (See figure 2-4 on page 12

for location)

CAUTION

When you turn on your notebook be sure you have a powersource.Thismeansthatatleastonebatteryis installed and charged, or that the AC or Auto/Airline adapter is connected and has power.

Facing the keyboard and display panel, move the power switch towards the rear of your notebook. This is the On position. The power switch moved toward the front of your notebook is in the Off position. When you are done working you can either leave your notebook in Suspend mode, (See Suspend Mode on page 38 for more informa-

tion),oryoucanturnitoff.(See Power Off on page 41 for more information)

CAUTION

Do not carry your notebook around with the power on or subject it to shocks or vibration, as you risk damaging your notebook.

CAUTION

Never turn off your notebook during the Power On Self Test (POST) or it will cause an error message to be displayed when you turn your notebook on the next time.

(See Power On Self Test Messages on page 75 for

more information)

BOOT SEQUENCE

The procedure for starting-up your Fujitsu LifeBook is termed the Bootup sequence and involves your notebook’s BIOS. When your notebook is first turned on, the main system memory is empty, and it needs to find instructions to start up your notebook. This information is in the BIOS program. Each time you power up or restart your notebook, it goes through a boot sequence which displays a Fujitsu logo until your operating system is loaded. During booting, your notebook is performing a standardboot sequence including a Power On Self Test (POST). When the boot sequence is completed without a failure and without a request for the BIOS Setup Utility, the system displays the operating system’s opening screen.

The boot sequence is executed when:

■

You turn on the power to your notebook.

■

You restart your notebook from the Windows Shut Down dialog box.

■

The software initiates a system restart. Example: When you install a new application.

■

You reset the system by pressing the three keys [CTRL+ALT+DEL].

When you Power On your notebook, it will perform a Power On Self Test (POST) to check the internal parts and configuration for correct functionality. If a fault is found, your notebook will emit an audio warning and/or an error message will be displayed. (See Power On Self Test Messages on page 75 for more information)Depending on the nature of the problem, you may be able to continue by starting the operating system or by entering the BIOS setup utility and revising the settings.

After satisfactory completion of the Power On Self Test (POST), your notebook will load your operating system.

BIOS SETUP UTILITY

The BIOS Setup Utility is a program that sets up the operating environment for your notebook. Your BIOS is set at the factory for normal operating conditions, therefore there is no need to set or change the BIOS’ environment to operate your notebook.

The BIOS Setup Utility configures:

■

Device control feature parameters, such as changing I/O addresses and boot devices.

■

System Data Security feature parameters, such as passwords.

LifeBook C Series – Section Thre e

Entering the BIOS Setup Utility

To enter the BIOS Setup Utility do the following:

1. Turn on or restart your notebook.

2. Press the [F2] key once the Fujitsu logo appears on the screen. This will open the main menu of the BIOS Setup Utility with the current settings displayed.

3. Press the [RIGHT ARROW] or [LEFT ARROW] key to scroll through the other setup menus to review or alter the current settings.

BIOS Guide

A guide to your notebook’sBIOSisavailableonline. Please visit our service and support Web site at www.8fujitsu.com.Oncethere,clickontheSelfHelp Center link, and select your notebook series from the pull-down menu. Once you have done that, select the heading BIOS Guides from the pull-down menu and finally, select your specific unit’s BIOS number. If you areunsureofyournotebook’sBIOSnumber,please refertoyourpackingslip.

POINT

If your data security settings require it, you may be asked for a password before the BIOS main menu will appear.

BOOTING THE SYSTEM WITH WINDOWS 98

We strongly recommend that you not attachany external devices and do not put a DVD/CD or floppy disk in any drive until you have gone through the initial power on sequence.

When you turn on your notebook for the first time, it will display a Fujitsu logo on the screen. If you do nothing the system will read the hard drive for the operating system software, flash the notebook configuration information on the screen, and then the Windows 98 Welcome will begin.

■

Getting Started: You have the opportunity to enter custom information for your configuration file and setup your modem so that your notebook will be prepared to dial out.

■

Registration: Easy online registration for Windows 98 with Microsoft, and for your LifeBook Series notebook with Fujitsu PC Corporation.

■

Windows License Agreement and Final Settings: You have the opportunity to review the Windows 98 License Agreement and then your configuration file will be generated.

POINT

You may click Cancel at any time within this process to shutdown Windows 98. You may restart this process at any time in the future, but you must complete it in order to use your computer.

Getting Started

Read the instructions on the screens carefully and fill in the information as directed. You will be asked for such items as the language you wish to use, the country in which you live, your first and last name, and about how you dial out from where you will be using your notebook. For the modem settings, enter your current location information where you will be using your notebook. If you are not connected to a phone line and plan to register at a later time, you may click the Skip button, and you will go directly to the condition of use page.

Once you have set up your notebook to dial out, Windows 98 will make a free telephone call to test the settings. If the call is unsuccessful, you will be returned to the phone settings page where you may try to fix them.Ifyouareunabletofixthesettingspleasecontact Fujitsu PC Ser vice and Support. (See Fujitsu PC Contact Information on page 3 for more information) If you would simply like to move on, and register at a later time, you may click the Skip button, and you will go directly to the Condition of Use page.

Designed to accommodate the needs of many users, in many different countries, Windows 98 needs to be configured the first time you use them. Windows 98 has three parts:

Registration

If your connection is successful, you will go to the Registration Confirmation page. On this page simply enter the requested information, and then check the box at the bottom to register your copy ofWindows 98 with Microsoft. Once you have finished, click the Next button to continue.

Getting Started

POINT

If you do not register at this time you can do it later simply by double-clicking on the LifeBook Registration icon on your desktop and following the instructions.

You will then go through the Fujitsu registration process. Follow the instructions on the screens, and enter all of the necessary information. Be as specific as possible so that if you need help the service and support team will be able to serve you better.

Final Settings

The first part of your final settings is the Windows End User License Agreement. Read the agreement carefully. When you finish reading you must accept or reject the terms of the agreement and then click on the Next button.

POINT

If you reject the terms of the license agreement you will be asked to review the license agreement for information on returning Windows 98 or to shut down you notebook.

POINT

You will find a Recovery CD packet included with your notebook. Please store the packet in a safe place in case there is a loss of data, and it becomes necessary to re-install your operating system and/or application programs.

(See Recovery CD-ROM on

page 78 for more information)

REGISTERING YOUR LIFEBOOK

What are the benefits of registering?

You will receive an identification label for your LifeBook, which, if your LifeBook is ever lost, may help in getting it returned to you. You also receive priority Personal Identification Number (PIN) technical support access and useful product mailings. Proof of purchase is not required if you register within 30 days of your purchase.

How do I register?

With Windows 98, it is a part of the Windows Welcome process. If you do not register during the Welcome process you can double-click on the LifeBook Registration icon on your desktop and follow the instructions.

Next, you will need to enter your Windows Product Key. The Product Key is located on the Windows 98 Certificate of Authenticity with the Windows User’smanual. On the certificate you will find a bar-code with a number above it. This is your product key and the number you need to enter on the Product Key screen. When you have entered the number exactly as shown click on the Next button.

POINT

You cannot use your notebook until you have accepted the License Agreement and entered your product key. If you stop the process your notebook will return to the beginning of the Windows Welcome Process, even if you shut your LifeBook down and start it up again.

POINT

Make sure you have connected a phone line to your modem before you use E-Registration.

You may also complete the pre-printed registration form and either:

■

Fax to 1-949-450-9140

■

Mail to: Fujitsu PC Corporation 15355 Barranca Pkwy Irvine, CA 92618-9520

■

Call: 1-800-8fujitsu (1-800-838-5487)

You may also register on our Web site:

■

www.8fujitsu.com

You will need to be set up with an Internet Service Provider (ISP) to use this option.

POINT

You can register your Fujitsu LifeBook with any operating system via mail, telephone or fax.

LifeBook C Series – Section Thre e

Power Management

Your Fujitsu LifeBook has many options and features for conserving battery power. Some of these features are automatic and need no user intervention, such as those for the internal modem. However, others depend on the parameters you set to best suit your operating conditions, such as those for the display brightness. Internal power management for your notebook may be controlled from settings made in your operating system, pre-bundled power management application, or from settings made in BIOS setup utility.

Besides the options available for conserving battery power, there are also some things that you can do to prevent your battery from running down as quickly. For example, you can create an appropriate power saving profile, put your notebook into Suspend mode when it is not performing an operation, and you can limit the use of high power devices. As with all mobile, battery powered computers, there is a trade-off between performance and power savings.

SUSPEND/RESUME BUTTON

When your notebook is active, the Suspend/Resume button can be used to manually put your notebook into Suspend mode. Push the Suspend/Resume button when your notebook is active, but not actively accessing anything, and immediately release the button. You will hear two short beeps and your system will enter Suspend mode.

If your notebook is suspended, pushing the Suspend/ Resume button will return your notebook to active operation. You can tell whether or not your system is in Suspend mode by looking at the Power indicator. (See figure 2-8 on page 17) If the indicator is visible and not flashing, your notebook is fully operational. If the indicator is both visible and flashing, your notebook is in Suspend mode. If the indicator is not visible at all, the power is off or your notebook is in Save-to-Disk mode.

(See Save-to-Disk Mode)

SUSPEND MODE

Suspend or Standby mode in Windows 98 saves the contents of your notebook’s system memory during periodsofinactivitybymaintainingpowertocritical parts. This mode will turn off the CPU, the display, the hard drive, and all of the other internal components except those necessary to maintain system memory and allow for restarting. Your notebook can be put in Suspend mode by:

■

PressingtheSuspend/Resumebuttonwhenyour system is turned on.

■

Selecting Standby from the Windows Shut Down menu.

■

Timing out from lack of activity.

■

Allowing the battery to reach the Dead Battery Wa r n i n g c on d i t i o n .

Yo u r n o t e b o o k ’s system memory typically stores the file(s) on which you are working, open application(s) information, and any other data required to support the operation(s) in progress. When you resume operation from Suspend mode, your notebook will return to the point where it left off. You must use the Suspend/Resume button to resume operation, and there must be an adequate power source available, or your notebook will not resume.

CAUTION

If you are running your notebook on battery power, be aware that the battery continues to discharge while your notebook is in Suspend mode, though not as fast as when fully operational.

SAVE-TO-DISK MODE

TheSave-to-Diskmodesavesthecontentsofyour notebook’s system memory to the hard drive as a part of the Suspend/Resume mode. Your notebook is pre-configured to perform this function. The Save-to-Disk mode can also be configured through the system BIOS to run in other ways depending on what you need to accomplish. (See BIOS Setup Utility on

page 35 for more information)

Default Methods for using Save-to-Disk Mode:

1. Press the [FN] button together with the Suspend/ Resume button. This will open a Save-to-Disk dialog box and begin the process.

Customer configured BIOS methods for using Save-to-Disk Mode:

1. Click on the Start button, click Shut Down and then Standby. Prior to that you should enable Save-to-Disk in the BIOS setup utility.

2. Enable Save-To-Disk mode from within the Power dialog box of the BIOS setup utility, then press the Suspend/Resume button to execute this command under DOS or Windows 98.

3. Enable Save-To-Disk mode from within the Power dialog box of the BIOS setup utility, then allow the notebook to time out from lack of activity.

POINT

Disabling the Suspend/Resume button prevents it from being used to put your notebook in Suspend or Save-to-Disk mode. The resume function of the button cannot be disabled.

CAUTION

The Suspend or Save-to-Disk mode should not be used with certain PC Cards. Check your PC Card documentation for more information.

Getting Started

POINT

When PC Cards or external devices are in use, Saveto-Disk mode cannot return to the exact state prior to suspension, because all of the peripheral devices will be re-initialized when the system restarts.

POINT

The main advantage of using the Save-to-Disk function is that power is not required to maintain your data. This is particularly important if you will be leaving your notebook in a suspended state for a prolonged period of time. The drawback of using Save-to-Disk mode is that it lengthens the power down and power up sequences and resets peripheral devices.

POINT

Save-to-Disk mode requires allocating a significant amount of hard drive capacity for saving all system memory, which reduces your usable disk space. When you purchase your notebook it will have space allocated for the memory installed. If you upgrade the original system by adding a memory upgrade module without changing the size of your Save-to-Disk allocation you will get an error message when you try to activate Save-to-Disk mode and it will not work. Use the PHDISK Utility to increase the size of the Save-to-Disk file, SAVE2DSK.BIN. You can download the Save-toDisk File Allocation information from our Web site at

www.8fujitsu.com. I

support representative for recommendations.

f you need help, contact your

POINT

If your notebook is actively accessing information when you enter the Suspend or Save-to-Disk mode, changes to open files are not lost. The files are left open and memory is kept active during Suspend mode or the memory is transferred to the internal hard drive during Save-to-Disk mode.

LifeBook C Series – Section Thre e

IDLE MODE

Idle mode is one of the power management parameters. When Idle mode is enabled, the CPU is put into lowspeed operation when there is no activity (keystroke, pointer action, sound generation, video display change, modem transmission or reception, etc.) on your notebook for 16 seconds. Any activity will cause the normal operation to restart automatically. This feature is independent of the Suspend/Resume modes.

STANDBY MODE

Standby mode is one of the power management parameters. When Standby mode is activated, your notebook puts the CPU in low-speed operation, shuts off the display and turns off the hard drive when there is no activity (keystroke, pointer action, sound generation, video display change, modem transmission or reception, etc.) on your notebook for the user selected time-out period. Any activity will cause your notebook to return to normal operation automatically. This feature is independent of the Suspend/Resume button.

HARD DISK TIMEOUT

The Hard Disk Timeout is another one of the power management parameters. This feature saves power by turning off the hard drive if there is no hard drive activity for the user selected timeout period. Any attempt to access the hard drive will cause it to restart automatically. This feature is independent of the Suspend/Resume button and can be enabled and disabled in Windows and BIOS setup utility. (See BIOS

Setup Utility on page 35 for more information)

WINDOWS 98 POWER MANAGEMENT

The Power Management icon located in the Windows 98 Control Panel allows you to configure some of the power management settings. For example, you can use the Power Management to set the timeout values for turning off the display and hard disks whether you are running the notebook on battery power or one of the adapters.

(See Pre-Installed Software on page 30 for more information) The settings may also be changed in the BIOS. (See BIOS Setup Utility on pag e35 for more information)

DISPLAY TIMEOUT

The Video Timeout is one of the power management parameters. This feature saves power by turning off the display if there is no keyboard or pointer activity for the user selected timeout period. Any keyboard or pointer activity will cause the display to restart automatically. This feature is independent of the Suspend/Resume button and can be enabled and disabled inWindows and BIOS setup utility. (See BIOS Setup Utility on page 35 for

more information)

RESTARTING THE SYSTEM

If your system is on and you need to restart it, be sure that you use the following procedure.

1. Click the Start button, and then click Shut Down.

2. Select the Restart option from within the Windows Shut Down dialog box.

3. Click OK to restart your notebook. Your notebook will shut down and then reboot.

CAUTION

Turning off your notebook without exiting Windows or turning on your notebook within 10 seconds of the notebook being shut off may cause an error when you start the next time.

Getting Started

POWER OFF

Before turning off the power by choosing Shut Down from the Windows 98 Start menu, check that the Hard Drive, DVD/CD-ROM, CD-RW, PC Card and the Floppy Disk Drive Access indicators are all Off. (See figure 2-4 on page 12) If you turn off the power while accessing a disk or PC Card there is a risk of data loss. To assure that your notebook shuts down without error, use the Windows shut down procedure.

POINT

You may also use the Suspend/Resume button to shut off your notebook. To do so, first press the Suspend/ Resume button to suspend your notebook. Next press and hold the button again until your notebook shuts off. However, in Windows you should always use the correct way to shut down your notebook. From the start menu select shut down.

CAUTION

Never turn your notebook off while an application is running. Be sure to close all files, exit all applications, and shut down your operating system prior to turning off the power with the power switch. If files are open when you turn the power off, you will lose any changes that have not been saved, and may cause disk errors.

Using the correct procedure to shut down from Windows, allows your notebook to complete its operations and turn off power in the proper sequence to avoid errors. The proper sequence is:

1. Click the Start button, and then click Shut Down.

2. Select the Shut Down option from within the Windows Shut Down dialog box.

3. Click OK to shutdown your notebook.

If you are going to store your notebook for a month or more see Care and Maintenance Section.

LifeBook C Series – Section Thre e

User Installable Features

Section Four

User Installable Features

Lithium ion Battery

RechargingtheBatteries...................45

ReplacingtheBattery.....................46

Floppy Disk Drive

LoadingaDisk..........................47

EjectingaDisk..........................47

PreparingaDiskforUse................... 47

CD-ROM Drive

LoadingaCD...........................48

RemovingaCD.........................49

AutomaticInsertionFunction...............49

DVD/CD-ROM Drive

DVD Player Software . .................... 50

LoadingaDVD/CD...................... 51

RemovingaDVD/CD..................... 51

UsingtheDVDPlayerSoftware.............52

Using the DVD Player on Battery Power. . . . . . . 52

AutoInsertNotificationFunction............ 53

Memory Upgrade Module

Installing a Memory Upgrade Module . . . . . . . . 56

To Remove a Memory Upgrade Module: . . . . . . 57

Checking the Computer Recognition

ofNewMemoryCapacity................. 58

Device Ports

Modem (RJ-11) Telephone Jack . . . . . . . . .....59

ParallelPort............................ 59

SerialPort ............................. 59

PS/2Port..............................59

UniversalSerialBusPort...................60

InfraredPort ...........................60

WirelessInfraredMouseReceiver ........... 60

Microphone Jack . . . . . . . . . ...............60

StereoLine-InJack....................... 60

Digital Audio-Out Connector . . . . . . . . . ......61

HeadphoneJack ........................ 61

ExternalMonitorPort .................... 61

PC Cards

InstallingPCCards....................... 54

RemovingPCCards......................55

LifeBook C Series – Section Fo u r

User Installable Features

Lithium ion Battery

Your Fujitsu LifeBook has a Lithium ion battery that provides power for operating your notebook when no external power source is available. The battery is durable and long lasting, but should not be exposed to extreme temperatures, high voltages, chemicals or other hazards.

The Lithium ion battery operating time may become shorter if it is used under the following conditions:

■

When used at temperatures that exceeds a low of 5°Corahighof35°C. Extreme temperatures not only reduce charging efficiency, but can also cause battery deterioration. The Charging icon on the Status Indicator panel will flash when you try to charge a battery that is outside its operating temperature range. (See Battery Charging Indicators on

page 18 for more information)

■

When using a high current device such as a modem, DVD drive, CD-ROM drive, or the hard drive, using the AC adapter will conserve your battery life.

CAUTION

Under federal, state, or local law it may be illegal to dispose of batteries by putting them in the trash. Please take care of our environment and dispose of batteries properly. Check with your local government authority for details regarding recycling or disposing of old batteries. If you cannot find this information elsewhere, contact your support representative at 1-800-8FUJITSU (1-800-838-5487).

RECHARGING THE BATTERIES

If you want to know the condition of the primary Lithium ion battery, check the Battery Level indicator located on the Status Indicator panel. The indicator changes as the battery level changes.

The Lithium ion battery is recharged internally using the AC adapter or Auto/Airline adapter. To recharge the battery make sure the battery that needs to be charged is installed in your notebook and connect the AC or Auto/Airline adapter.

CAUTION

Actual battery life will vary based on screen brightness, applications, features, power management settings, battery condition and other customer preferences. DVD drive, CD-ROM drive or hard drive usage may also have a significant impact on battery life. The battery charging capacity is reduced as the battery ages. If your battery is running low quickly, you should replace it with a new one.

CAUTION

Do not leave a faulty battery in your notebook. It may damage your AC adapter, optional Auto/Airline adapter, another battery or your notebook itself. It may also prevent operation of your notebook by draining all available current into the bad battery.

POINT

Make sure that the Battery Charging indicator and the percentage charge is shown inside the Battery Level icon on the Status Indicator Panel.

There is no memory effect on the Lithium ion battery therefore you do not need to discharge the battery completely before recharging. The charge times will be significantly longer if your notebook is in use while the battery is charging. If you want to charge the battery more quickly, put your notebook into Suspend mode, or turn it off while the adapter is charging the battery.

(See Power Management on page 38 for more information on Suspend mode and shutdown procedure)

CAUTION

Using heavy current devices such as a Modem or frequent DVD/CD-RW/CD-ROM accesses may prevent charging completely.

LifeBook C Series – Section Fo u r

Low Battery State

When the battery is running low, your notebook will beep every 15 seconds and the Battery Level indicator will flash. If you do not respond to the low battery alarm, the batteries will continue to discharge until they are too low to operate. When this happens there will be a multiple beep alarm and the Battery Level indicator will show a dead battery. Your notebook will then go into Suspend mode to try and protect your data for as long as possible. There is no guarantee that your data will not be lost once the notebook reaches this point.

CAUTION

You may not be able to hear the audio alarm if the volume control is set too low or is turned off by either the hardware or software. However, you will still be able to see the Battery Level indicator flash. Once the low battery alarm occurs you need to save all your active data and put your notebook into Suspend mode until you can provide a new power source. You should provide a charged battery, an AC power adapter, or Auto/ Airline as soon as possible.

Shorted Batteries

The Status Indicator panel uses a symbol inside the battery outline of the Battery Level indicator to display the operating level available in that battery. (See figure 2- 9onpage18)If this display shows a Shorted Battery, it means that the battery is damaged and must be replaced so it does not damage any other parts of your notebook.

REPLACING THE BATTERY

With the purchase of an additional battery, you can have a fully charged spare to swap with one that is not charged. (Figure 4-1)

1. Have a charged battery ready to install.

2. Shut down your notebook and disconnect the AC adapter.

3. Slide the battery release panel open.

4. Remove the battery from the bay.

5. Slide the new battery into the bay.

6. Slide the battery release panel close.

7. Plug in the AC adapter and turn the power on.

CAUTION

When you are in Suspend mode there must always be at least one power source active. If you turn off the power with the power switch, or remove all power sources while your notebook is in Suspend mode, any data that has not been saved to the hard drive will be lost.

Dead Battery Suspend mode shows on the Status indicator just like the normal Suspend mode. Once your notebook goes into Dead Battery Suspend mode you will be unable to resume operation until you provide a source of power either from an adapter, or a charged battery. Once you have provided power, you will need to press the Suspend/Resume button to resume operation. In the Dead Battery Suspend mode, your data can be maintained for some time, but if a power source is not provided promptly, the Power indicator will stop flashing and go out, meaning that you have lost the data that was not stored. Once you provide power, you can continue to use your notebook while an adapter is charging the battery.

Battery Release Panel

Figure 4-1 Replacing the Battery

CAUTION

If the Lithium ion battery connector is not fully seated, you may not be able to use your notebook or charge your battery.

User Installable Features

Figure 4-2 Loading/Ejecting a 3.5” Floppy Disk

Eject Button

Floppy Disk Drive

Your Fujitsu LifeBook has a 3.5" floppy disk drive with the ability to read and write information on removable

1.44MB and 720KB floppy disks.

LOADING A DISK

To load a disk into your disk drive, follow these easy steps:

1. Orient the disk so that its label is facing upwards and the shutter side is pointing towards the drive.

(Figure 4-2)

2. Push the disk into the drive until the Eject button pops out and you hear a click.

POINT

When there is no disk in the drive, the Eject button is flush with your notebook.

EJECTING A DISK

To eject a disk from the disk drive, follow these easy steps:

1. Check that the Floppy Disk Drive Access indicator is inactive.

2. Press the Eject button. This will push your disk partially out of the drive.

3. Remove the disk.

PREPARING A DISK FOR USE

Before you can use a new disk, it needs to be prepared so your notebook knows where to store information. This preparation is called formatting or initializing a disk. You will need to format new disks, unless they are preformatted. (Please refer to your operating system

manual for step-by-step instructions on formatting a disk)

To prevent accidental erasure of the data stored on a disk, slide the “write protect” tab until a small hole is exposed. This sets the disk into a protected state where nothing can be added or removed. If you want to add or remove data on a protected disk, slide the “write protect” tab to close the small hole. (Figure 4-3)

Write Enabled

Write Protected

Figure 4-3 Floppy Disk Write Protect

CAUTION

If you eject the disk while the Floppy Disk Drive Access indicator is active, there is a risk of damaging the data on the disk, the disk itself or even the disk drive.

CAUTION

Formattingafloppydiskthatalreadycontainsdatawill erase all of the information on the disk.

LifeBook C Series – Section Fo u r

CD Holder Tray

CD Eject Button

Figure 4-4 CD-ROM Drive

CD-ROM Drive

Your Fujitsu LifeBook contains a CD-ROM drive. This gives you access to both data and audio CDs.

(Figure 4-4)

CAUTION

Do not operate your CD-ROM drive unless your notebook is sitting on a flat surface. Using a CD when the drive is not level may damage the drive or prevent proper operation.

LOADING A CD

To load a CD into your CD-ROM drive, follow these easy steps:

1. Push and release the eject button on the front of the CD-ROM drive to open the holder tray. The tray will come out of the notebook a short distance.

2. Gently pull the tray out until a CD can easily be placed in the tray.

3. PlacetheCDintothetray,labelsideup,withthe hole in the center of the CD. Snap the CD onto theraisedcircleinthecenterofthetray.

4. Gently push the holder tray back in until you hear a click. (Figure 4-5)

POINT

If you have disabled the Auto Insert Notification function, you will have to start the CD from your desktop, as your notebook will not automatically recognize that a CD has been loaded.

CAUTION

There may be a protective sheet in the tray when it was shipped, please make sure it is removed before operating.

Figure 4-5 Loading/Ejecting a CD

User Installable Features

REMOVING A CD

1. Push and release the eject button on the front of the CD-ROM drive. This will stop the CD and the holder tray will come out of the notebook a short distance.

2. Gently pull the tray out until the CD can easily be removed from the tray.

3. Carefully remove the CD from the holder tray.

4. Gently push the holder tray back in until you hear a click.

AUTO INSERT NOTIFICATION FUNCTION

The Auto Insert Notification function allows your notebook to automatically start a CD as soon as it is inserted in the CD-ROM drive and the tray is closed. Your notebook will begin playing an audio CD or will start an application if the CD includes an auto run file.

Disabling Auto Insert Notification Function

To disable the Auto Insert Notification function, follow these easy steps:

1. Save all data and close all open applications.

2. From the Start menu, select Settings,andthen select Control Panel.

3. Double-click the System icon. This will open the System Properties dialog box.

4. Select the Device Manager tab to display the device lists for your notebook.

5. Click on the

to the left of the CD-ROMdrive icon.

The treeview will expand to show the CD-ROM drive manufacturer’snameandmodelnumber.

6. Double-click on the CD-ROM drive manufacturer’s name and model number. This will open the CD-ROM drive manufacturer’snameandmodel number dialog box.

7. Select the Settings tab and then remove the check mark in the Auto Insert Notification box to turn it off.

8. Click OK.

9. Click Close in the System Properties dialog box, then click Ye s in the System Settings Change pop-up window when it asks you to restart your machine and activate this change.

The Auto Insert Notification function can be re-activated by repeating this process and placing a check mark in the Auto Insert Notification function box to turn it back on.

LifeBook C Series – Section Fo u r

DVD/CD Holder Tray

DVD/CD Eject Button

Figure 4-6 DVD/CD-ROM Drive

DVD/CD-ROM Drive

Your Fujitsu LifeBook contains a DVD/CD-ROM drive whichisbotha6xDVDplayerandaCDdrive.This gives you access to movie, software and audio DVD/ CDs.(Figure4-6)

DVD PLAYER SOFTWARE

With the DVD/CD-ROM drive and DVD Player software you can play DVD movies on your notebook. The DVD player includes controls which allow you to take full advantage of the features of a DVD movie, as well as standard features such as fast forward, fast reverse, pause, etc.

You will need to install the DVD Player software before using the DVD/CD-ROM drive. The DVD Player software is included on the CD labeled DVD Application CD. You may also need to re-install your DVD Player software if:

■

Your DVD Player software becomes corrupted and is not operating properly.

■

You perform a complete system software recovery utilizing the recovery CD.

Installing the DVD Player Software

To install the DVD Player software follow theseeasy step:

1. Make sure you either close or disable any open programs, applications and utilities. This includes the MS Office Toolbar, any anti-virus programs and screensavers.

2. Insert the DVD Application CD into the DVD/ CD-ROM drive. If the CD AutoRun feature activates, skip Step 3.

3. From the Start menu, select Run. Depending upon

the internal configuration of your LifeBook, the Setupprogrammaybeinoneoftwodirectories. Browse to your D: drive and select either:

D:\Softdvd\Setup.exe

D:\DVD Player\Setup.exe

Click Open.

4. Go through the installation process by following the directions on screen.

5. Once the installation is complete, you will be asked to restart your notebook.

6. To use the DVD Player software, click Start, Programs,andthenDVD Player.

POINT

You should periodically check the Fujitsu Web site at www.fujitsu-pc.com for current updated drivers.

Un-installing the DVD Player Software

The DVD Player software should be removed if you wish to use a 3rd party DVD player instead of the Fujitsu DVD Player. To un-install the DVD Player software follow these easy steps:

1. Close any open files on the DVD/CD-ROM drive.

2. Remove any DVD/CD from the drive.

3. From the Start menu, select Settings,andthenselect Control Panel.

4. Double-click the Add/Remove Programs icon.

5. Select the Fujitsu DVD Player from the Add/ Remove Programs Properties dialog box.

6. Click the Add/Remove button and the DVD/ CD-ROM software will be un-installed.

POINT

If you wish to use a 3rd party DVD player software, you must un-install the Fujitsu DVD Player software or the 3rd party DVD Player software may not operate correctly.

User Installable Features

CAUTION

There may be a protective sheet in the tray when it was shipped, please make sure it is removed before operating.

3. Place the DVD/CD into the tray, label side up, with the hole in the center of the DVD/CD. Snap the DVD/ CD onto the raised circle in the center of the tray.

4. Gently push the holder tray back in until you hear a click. (Figure 4-7)

POINT

If you have disabled the Auto Insert Notification function, you will have to start the DVD/CD from your desktop, as your notebook will not automatically recognize that a DVD/CD has been loaded.

CAUTION

Do not operate your DVD/CD-ROM drive unless your notebook is sitting on a flat surface. Using a DVD/CD when the drive is not level may damage the drive or prevent proper operation.

CAUTION

Prolonged use of the DVD/CD-ROM drive, such as watching a DVD movie, will substantially reduce your battery life.

LOADING A DVD/CD

To load a DVD/CD into your DVD/CD-ROM drive, follow these easy steps:

1. Push and release the eject button on the front of the DVD/CD-ROM drive to open the holder tray. The tray will come out of the notebook a short distance.

2. Gently pull the tray out until a DVD/CD can easily be placed in the tray.

Figure 4-7 Loading/Ejecting a DVD/CD

REMOVING A DVD/CD

1. Push and release the eject button on the front of the DVD/CD-ROM drive. This will stop the DVD/CD and the holder tray will come out of the notebook a short distance.

2. Gently pull the tray out untilthe DVD/CDcan easily be removed from the tray.

3. Carefully remove the DVD/CD from the holder tray.

4. Gently push the holder tray back in until you hear a click.

LifeBook C Series – Section Fo u r

USING THE DVD PLAYER SOFTWARE

Starting a DVD Movie

1. Insert the DVD movie into the DVD drive of your notebook. If the CD AutoRun feature activates, skip Step 2.

2. From the Start menu, select Programs, then select DVD Player and click DVD Player.Thiswilllaunch the DVD movie.

3. Click OK to close the About DVD Player Performance dialog box and the movie will begin.

Opening the DVD Player Control Panel

In most DVD-ROMs, you have the option to alter how the movie should play and what you wish to view. You can do this by using the DVD Player control panel and the mouse.

1. Right-click on the movie screen to open a dropdown menu for options.

2. Select Panel Control, for all the controls available, select Navigator Control for navigation controls only, or select Angle Control to open a small box that allows you to select different angles to view the movie. From these controls, it is possible to add sub-titles, speed up or slow down, even play movie related games.

Exiting the DVD Player

1. Click on theUlocated in the upper right corner of the title bar. This will open a DVD Player dialog box.

2. Click Ye s to stop and exit the movie, or No to close the DVD Player dialog box and return to the movie.

USING THE DVD PLAYER ON BATTERY POWER

Since DVD drives consume a lot of power, your overall battery life will be shorter when operating the DVD drive continuously (such as watching a DVD movie) than during standard operation. Many movies run-times are longer than your notebook can support on a single battery. If you are watching a DVD movie on battery poweryoumayneedtoswapinanadditional,charged battery or attach AC power during the movie to view it in its entirety.

CAUTION

Prolonged use of the DVD drive, such as watching a DVD movie, will substantially reduce your notebook’s battery life.

CAUTION

Using the DVD Player Control Panel

TheDVDPlayersoftwareallowsyoutowatchthemovie much like a VCR player. You have the option to pause, rewind, fast-forward and stop the movie at any point.

1. Right-click on the movie screen to open a dropdown menu for options.

2. Select Panel Control, for all the controls available. This will open the control panel into the bottom of the screen.

3. To Pause the movie, click thebutton.

4. To Rewind the movie, click thebutton to rewind to a specific portion of the movie, or thebutton to return to the opening screen.

5. To Fast-forward the movie, click thebutton to forward to a specific portion of the movie, or the



button to jump to the ending credits.

6. To Stop the movie, click thebutton.

Many movies run-times are longer than your system can support on a single battery. If you are watching a DVD movie on battery power you may need to swap in an additional, charged battery or attach AC power during the movie to view it in its entirety.

POINT

An additional full-charged battery is highly recommended if you will be watching DVD movies on battery power. If you don’t have an additional battery, you may purchase one either on-line at fujitsu-pc.com or call 1-877-FPCDirect (1-877-372-3473).

To Watch a Movie on Battery Power:

1. Have an additional full-charged battery or your AC adapter ready for use.

2. Start watching your DVD movie.

3. When the low battery warning occurs, immediately stop the movie and exit the DVD player.

User Installable Features

CAUTION

If you do not stop the DVD player quickly and the notebook attempts to auto-suspend (critical battery low state) the notebook will shutdown improperly. If this occurs, you will need to perform a hard reset and follow the instruction, if any, presented to you before the system will reboot.

4. Manually place your notebook into suspend mode by depressing the Suspend button and replace the discharged battery with an additional full-charged battery. Or if you do not have an additional battery, you may attach AC power as soon as you see the low battery warning.

5. Resume your notebook by pressing the Suspend button again. This step is not required if you attached AC power without entering suspend mode.

6. Restart your DVD player, locate and skip to the chapter of the movie you were last watching.

7. Continue watching your DVD movie.

POINT

Some shorter DVD movies may not require you to swap batteries or attach AC power to complete them. However, it is best to be prepared since actual battery life while operating the DVD drive cannot be guaranteed.

AUTO INSERT NOTIFICATION FUNCTION

The Auto Insert Notification function allows your notebook to automatically start a DVD/CD as soon as it is inserted in the DVD/CD-ROM drive and the tray is closed. Your notebook will begin playing an audio DVD/CD or will start an application if the DVD/CD includes an auto run file.

Disabling Auto Insert Notification Function

To disable the Auto Insert Notification function, follow these easy steps:

1. Save all data and close all open applications.

2. From the Start menu, select Settings,andthenselect Control Panel.

3. Double-click the System icon. This will open the System Properties dialog box.

4. Select the Device Manager tab to display the device lists for your notebook.

5. Click on the drive icon. The treeview will expand to show the

DVD/CD-ROM drive manufacturer’snameand model number.

6. Double-click on the DVD/CD-ROM drive manufac- turer’snameand model number.Thiswillopenthe DVD/CD-ROM drive manufacturer’snameand model number dialog box.

7. Select the Settings tab and then remove the check mark in the Auto Insert Notification box to turn it off.

8. Click OK.

9. Click Close in the System Properties dialog box, then click Ye s in the System Settings Change pop-up window when it asks you to restart your machine and activate this change.

to the left of the DVD/CD-ROM

The Auto Insert Notification function can be re-activated by repeating this process and placing a check mark in the Auto Insert Notification box to turn it back on.

LifeBook C Series – Section Fo u r

PC Card

Figure 4-8 Installing/Removing PC Cards

PC Card Slot

Eject Button

PC Cards

Your Fujitsu LifeBook supports Type I, Type II and Type III PC Cards, which can perform a variety of functions depending on which type of PC Card you install.You can install one or two PC Cards at a time, depending on its type. Type I and Type II PC Cards can be installed together, while Type III PC Cards must be installed alone.

Some available PC Cards:

■

Zoomed Video cards (Type II, Slot 1 only).

■

Fax/data modem cards (Type II).

■

Local area network (LAN) cards (Type II).

■

IDE solid-state disk cards (Type II).

■

SCSI cards (Type II).

■

ATA c a rd s ( Ty p e I I I ) .

■

Other PC Cards that conform to PCMCIA 2.1 or CardBus standards.

For further information, refer to the instructions supplied with your PC Card.

INSTALLING PC CARDS

PC Cards are installed in the PC Card slot. To install a PC Card(s), follow these easy steps: (Figure 4-8)

WARNING

Installing or removing a PC Card(s) during your notebook’s shutdown or bootup process may damage the card and/or your notebook.

WARNING

Do not insert a PC Card into a slot if there is water or any other substance on the card as you may permanently damage the card, your notebook, or both.

1. See your PC Card manual for specific instructions on the installation of your card. Some PC Cards may require your notebook to be Off while installing them.

2. Make sure there is no PC Card currently in the slot. If there is, see Removing PC Cards.

3. Insert your PC Card into the slot, with the product label facing up.

4. Push the card into the slot firmly until it is seated in the opening. You will hear a click and the Eject button will pop away from your notebook.

5. Flip the Eject button towards the front of your notebook.

6. Lock the PC Card into the slot by sliding the Lock button toward the front of your notebook.

User Installable Features

POINT

If the dialog box states that the device cannot be removed, you must save all of your open files, close any open applications and shutdown your notebook. Once your notebook has been shutdown, you must turn Off the power using the power switch.

REMOVING PC CARDS

To remove a PC Card(s), follow these easy steps:

CAUTION

Windows has a shutdown procedure for PC Cards that must be followed before removing a card. (Please review your operating system manual for the correct procedure)

1. See your PC Card manual for specific instructions on removing your card. Some PC Cards may require your notebook to be in Suspend Mode or Off while removing them.

2. Unlock the PC Card from the slot by sliding the Lock button toward the rear of your notebook.

3. Flip the Eject button towards the rear of your notebook until it is fully extended, and then push it in until it is flush with the notebook. This will push the PC Card slightly out of the slot allowing you to remove the card.

CAUTION

If the PC Card(s) has an external connector and cable, do not pull the cable when removing the card.

LifeBook C Series – Section Fo u r

Memory Upgrade Module

Your Fujitsu LifeBook comes with 64MB or 128MB high speed Synchronous Dynamic RAM (SDRAM) factory installed. To increase your notebook’s memory capacity, you may install an additional memory upgrade module. The memory upgrade must be a dual-in-line (DIMM) SDRAM module.

CAUTION

Do not remove any screws from the memory upgrade module compartment, except the ones specifically shown in the directions for installing and removing thememoryupgrademodule.

INSTALLING A MEMORY UPGRADE MODULE

To install a memory upgrade module follow these steps:

(Figure 4-9)

5. Flip the keyboard away from you, and set it down on the display screen.

WARNING

You must turn off power before installing the memory upgrade module.

1. Turn off power to your notebook using the power switch, and remove any power adapter (AC or auto/airline).

2. Using the tip of your Phillips head screwdriver, carefully pry the screw covers out of the screw holes just above both ends of your keyboard and remove the two screws located within the screw holes.

3. Press your display panel open until it completely horizontal. Carefully work the panel surrounding the status indicator panel loose and set it aside.

4. Lift the edge of the keyboard that is closest to the display panel upward, approximately one-quarter of an inch, and then pull it away from you. Do not pull too far, as it is still connected to your notebook.

Figure 4-9 Opening the Memory Upgrade Module

6. Once the keyboard is set aside, you will notice a layer of plastic sheeting. In the center of the plastic sheeting is a small notch facing the right side on your notebook. Ease your fingernail under this notch, and lift the sheeting to your left to expose the memory upgrade module compartment.

CAUTION

The memory upgrade module can be severely damaged by electrostatic discharge (ESD). Be sure you are properly grounded when handling and installing the module.

User Installable Features

7. Align the connector edge of the memory upgrade module, chip side up, with the connector slot in the compartment. (Figure 4-10)

8. Insert the memory upgrade module at a 45(angle and press it firmly onto the connector.

9. Press the memory upgrade module down into the compartment until it locks underneath the retaining clip. You will hear a click when it is properly in place.

Figure 4-10 Installing a Memory Upgrade Module

10. Lay the flap of plastic sheeting back into place.

11. Flip the keyboard back over, and slide it back into place, while holding the back of the keyboard up approximately one-quarter of an inch. The tabs will go into the slots at the front of the notebook.

12. Lower the keyboard back into position on your notebook.

13. Return the panel surrounding the status indicator panel back into position.

14. Replace the two screws and the screw covers.

POINT

REMOVING A MEMORY UPGRADE MODULE

1. Perform steps 1 through 6 of Installing a Memory Upgrade Module.

2. Pull the clips sideways away from each side of the memory upgrade module at the same time.

(Figure 4-11)

3. While holding the clips out, remove the module from the slot by lifting it up and pulling towards the rear of your notebook.

Figure 4-11 Removing a Memory Upgrade Module

4. Storethememoryupgrademoduleinastatic guarded sleeve.

5. Replace the cover by following steps 10 and 14 of Installing a Memory Upgrade Module.

POINT

After installing your added memory module, you must complete the Resetting the Save-to-Disk Parameters procedure in order for the Save-to-Disk mode to operate properly on your LifeBook.

on page 38 for more information)

(See Save-to-Disk Mode

The memory upgrade module is not something you routinely remove from your notebook. Once it is installed, you can leave it in place unless you want to increase system memory capacity.

LifeBook C Series – Section Fo u r

CHECKING THE COMPUTER RECOGNITION OF NEW MEMORY CAPACITY

Once you have changed the system memory capacity by either adding or removing a memory upgrade module,besuretocheckthatyournotebookhas recognized the change.

You can check the memory capacity by looking at the main menu of the BIOS setup:

1. Turn on the power to your notebook using the power switch.

2. Allow the system to start booting and press the key once the Fujitsu logo appears on the screen. This will open the main menu of the BIOS setup with the current settings displayed. (See BIOS Setup Utility on

page 35 for more information)

The System Memory and the Extended Memory capacity, as detected by your notebook during the Power On Self Test (POST), are displayed at the bottom of the main menu screen. The chart below shows you the possible displays that can be shown on the main menu screen.

POINT

If the total memory displayed is incorrect, check that your memory upgrade module is properly installed. (If the module is properly installed and the capacity is still not correctly recognized, see the Troubleshooting section starting on page 65)

Installed Displayed

On Board

64MB 64MB 64MB 64MB

Slot 1

0 32MB 64MB

128MB

To ta l R AM

Installed

64MB

96MB 128MB 192MB

System

Memory

640K 640K 640K 640K

Extended

Memory

63MB

95MB 127MB 191MB

User Installable Features

Device Ports

Your Fujitsu LifeBook comes equipped with multiple ports to which you can connect an external device including: disk drives, keyboards, modems, printers, etc.

MODEM (RJ-11) TELEPHONE JACK

Themodem(RJ-11)telephonejackisusedforan internal modem. To connect the telephone cable follow these easy steps: (See figure 2-5 on page 13 for location)

1. Align the connector with the port opening.

2. Push the connector into the port until it is seated.

3. Plug the other end of the telephone cable into a telephone outlet.

WARNING

CAUTION

PARALLEL PORT

The parallel port, or LPT port, allows you to connect parallel devices, such as a printer to your notebook. In order to connect a parallel interface device follow these easy steps: (See figure 2-6 on page 15 for location)

1. Align the connector with the port opening.

2. Push the connector into the port until it is seated.

3. Tighten the two hold-down screws, located on each end of the connector.

SERIAL PORT

The serial port, or COMM port, allows you to connect serial devices, such as printers or scanners. In order to connect a serial interface device follow these easy steps: (See figure 2-6 on page 15 for location)

1. Align the connector with the port opening.

2. Push the connector into the port until it is seated.

3. Tighten the two hold-down screws, located on each end of the connector.

PS/2 PORT

The PS/2 port allows you to connect an external keyboard, and/or numeric keypad and mouse. In order to connect a PS/2 interface device follow these easy steps:

(See figure 2-6 on page 15 for location)

1. Align the connector with the port opening.

2. Push the connector into the port until it is seated.

POINT

CAUTION

The internal modem on all Fujitsu notebooks from Fujitsu PC Corporation are certified for use in the United States and Canada. The modem may be certified in other countries.

A mouse, keyboard, or keypad may be installed and automatically recognized by your notebook without restarting or changing setups.

POINT

The use of two PS/2 devices simultaneously from the port requires a PS/2 splitter.

LifeBook C Series – Section Fo u r

UNIVERSAL SERIAL BUS PORT

The Universal Serial Bus port (USB) allows you to connect USB devices such as external game pads, pointing devices, keyboards and/or speakers. In order to connect a USB device follow these easy steps: (See

figure 2-6 on page 15 for location)

1. Align the connector with the port opening.

2. Push the connector into the port until it is seated.

CAUTION

Due to the ongoing changes in USB technology and standards, not all USB devices and/or drivers areguaranteedtowork.

INFRARED PORT

The Infrared IrDA 1.1 (4Mbps) port allows for wireless data transfer between your notebook and other IrDAcompatible devices, such as another computer or a printer, without the use of a cable. (See figure 2-6 on

page 15 for location)

POINT

With Windows 98, you can use the Infrared Recipient application for infrared file transfers. LapLink Professional software can also be used for infrared file transfers.

WIRELESS INFRARED (IR) MOUSE RECEIVER

The Wireless IR Mouse Receiver (on Performance Models only) allows you to use an optional wireless Infrared Mouse (IR Mouse). The optional IR Mouse communicates directly with the IR Mouse receiver without the use of a cable. (See figure 2-3 on page 10 for

location)

MICROPHONE JACK

The microphone jack allows you to connect an external mono microphone. Your microphone must be equipped with a 1/8"(3.5 mm) mono mini-plug in order to fit into the microphone jack of your notebook. In order to connect a microphone follow these easy steps: (See

figure2-5onpage13forlocation)

It is important to keep in mind that while carrying out this form of communication, both devices must be placed so their infrared ports are directly facing each other without obstruction. The devices must also be separated by at least 6" but no more than 36" for maximum performance.

The following conditions may interfere with infrared communications:

■

A television, radio remote control unit, or a wireless headphone is being used nearby.

■

Direct sunlight, fluorescent light, or incandescent light shines directly on the port.

CAUTION

Do not move either device while communication is active as it may interrupt data transmission.

CAUTION

Be careful not to scratch the infrared port lens. Scratches, dirt, or other surface marks can degrade operation.

1. Align the connector with the port opening.

2. Push the connector into the port until it is seated.

STEREO LINE-IN JACK

The stereo line-in jack allows you to connect an external audio source to your notebook, such as an audio cassette player. Your audio device must be equipped with a 1/8" (3.5 mm) stereo mini-plug in order to fit into the stereo line-in jack of your notebook. In order to connect a external audio source follow these easy steps: (See

figure2-5onpage13forlocation)

1. Align the connector with the port opening.

2. Push the connector into the port until it is seated.

POINT

The stereo line-in jack will not support an external microphone.

User Installable Features

CAUTION

Turn down the audio volume when connecting electronic devices to the line-in jack. The internal speakers might break if unexpected large sounds are inputted.

DIGITAL AUDIO-OUT CONNECTOR

The digital audio-out connector allows you to download digital audio to Sony or Philips MiniDisc players. It uses SPDIF (Sony Philips Digital Interface) format.Pleaseusethefollowingsettingwhenusingthe digital audio-out connector. (See figure 2-5 on page 13

for location)

1. Click on Start, Settings and then click on Control Panel.

2. Select Yamaha Ds-XG Audio Configuration.

3. Click on the SPDIF tab and click ON (Digital Sources Only)

WARNING

CAUTION

Please be careful, as there are several types of cables for connecting a digital electronic device (e.g. MD player) to the digital audio-out connector, depending on the connector type. The connector on your computer is a Optical Mini Plug (3.5mm diameter mini plug)

HEADPHONE JACK

The headphone jack allows you to connect headphones or powered external speakers to your notebook. Your headphones or speakers must be equipped with a 1/8" (3.5 mm) stereo mini-plug. In order to connect headphones or speakers follow these easy steps: (See figure 2-5

on page 13 for location)

1. Align the connector with the port opening.

2. Push the connector into the port until it is seated.

POINT

If you plug headphones into the headphone jack, you will disable the built-in stereo speakers.

Do not look into the connector. There is a beam coming out from the SPDIF connector, so please do not look into the connector when inserting the cable.

POINT

The frequency of the digital sound output from the SPDIF output connector is fixed to 48KHz. If a sampling rate convertor is not installed in your connecting digital electronic device (e.g., MD player), recording is not possible. Please see the user manuals for the electronic devices for further details.

POINT

The sound recorded through connecting a digital electronic device (e.g., MD player) to the SPDIF output connector cannot be used as digital output. All output data from the SPDIF output connector has copyright protection information included.

EXTERNAL MONITOR PORT

The external monitor port allows you to connect an ex ter nal VGA or S VGA monitor. In ord er to co nn ect an external monitor follow these easy steps: (See figure 2-6

on page 15 for location)

1. Align the connector with the port opening.

2. Push the connector into the port until it is seated.

3. Tighten the two hold-down screws, located on each end of the connector.

CAUTION

Pressing the [FN] + [F10] keys allows you to change your selection of where to send your display video. Each time you press the key combination, you will step to the next choice, starting with the built-in display panel only, moving to the external monitor only, finally moving to both the built-in display panel and an external monitor.

LifeBook C Series – Section Fo u r

Section Five

Troubleshooting

IdentifyingtheProblem ................... 65

SpecificProblems........................ 65

Troubleshooting Table . . . . . . . . . . . .........66

PowerOnSelfTestMessages ..............75

Emergency DVD/CD-RW/CD-ROM

TrayRelease............................77

ModemResultCodes.....................77

RecoveryCD-ROM ......................78

Troubleshooting

LifeBook C Series – Section Fiv e

Troubleshooting

Your Fujitsu LifeBook is sturdy and subject to few problems in the field. However, you may encounter simple setup or operating problems that you can solve on the spot, or problems with peripheral devices, that you can solvebyreplacingthedevice.Theinformationinthis section helps you isolate and resolve some of these straightforward problems and identify failures that require service.

IDENTIFYING THE PROBLEM

If you encounter a problem, go through the following procedure before pursuing complex troubleshooting:

1. Turn off your notebook.

2. Make sure the AC adapter is plugged into your notebook and to an active AC power source.

3. Make sure that any card installed in the PC Card slot is seatedproperly.You can also remove the card from the slot, thus eliminating it as a possible cause of failure.

4. Make sure that any devices connected to the external connectors are plugged in properly. You can also disconnect such devices, thus eliminating them as possible causes of failure.

5. Turn on your notebook. Make sure it has been off at least10secondsbeforeyouturniton.

6. Go through the boot sequence.

7. If the problem has not been resolved, refer to the Troubleshooting Table, that follows, for more detailed troubleshooting information.

POINT

If you keep notes about what you have tried, your support representative may be able to help you more quickly by giving additional suggestions over the phone.

8. Ifyouhavetriedthesolutionssuggestedinthe Troubleshooting Table without success, contact your support representative:

Toll free: 1-800-8FUJITSU (1-800-838-5487) Fax: 1-901-259-5700 E-mail: 8fujitsu@fpc.fujitsu.com Web site: http://www.8fujitsu.com.

Before you place the call, you should have the following information ready so that the customer support representative can provide you with the fastest possible solution:

■

Product name

■

Product configuration number

■

Product serial number

■

Purchase date

■

Conditions under which the problem occurred

■

Any error messages that have occurred

■

Hardware configuration

■

Type of device connected, if any

See the Configuration Label on the bottom of your notebook for configuration and serial numbers. (See

figure2-7onpage16forlocation)

SPECIFIC PROBLEMS

Using PC-Doctor

PC-Doctor is a diagnostic program by Watergate Software, Inc. which comes pre-installed on your notebook. If you are an experienced computer user you may find it useful, however, it is intended primarily to help your Fujitsu support representative better serve you. When you call for help, your support representative may ask you to setup your notebook for modem operation. You will be told what to do step by step, and then asked to hang up the phone and plug your phone line into the back of your notebook. Your support representative will then use the service computer to call your notebook and perform diagnostic tests to find the nature of you problem. Messages will be displayed on the screen explaining what is being done and any further instructions that you may need.

CAUTION

Do not return a failed notebook to your supplier until you have talked to a support representative.

Using the Troubleshooting Table

When you have problems with your notebook, try to find the symptoms under the Problem column of the troubleshooting table for the feature giving you difficulty. You will find a description of common causes for that symptom under the column Possible Cause and what, if anything, you can do to correct the condition under Possible Solutions. All possible causes or solutions maynotapplytoyournotebook.

LifeBook C Series – Section Fiv e

TROUBLESHOOTING TABLE

Problem Page

AudioProblems .............................. 66

DVD/CD-RW/CD-ROMDriveProblems......... 66

FloppyDiskDriveProblems.................... 67

HardDriveProblems.......................... 68

KeyboardorMouseProblems................... 68

MemoryProblems............................ 68

ModemProblems............................. 69

Problem Possible Cause Possible Solutions

Audio Problems

Problem Page

Parallel,SerialandUSBDeviceProblems..........69

PCCardProblems.............................70

PowerFailures ................................70

ShutdownandStartupProblems.................72

VideoProblems ...............................73

MiscellaneousProblems ........................75

There is no sound coming from the built-in speakers.

The volume is turned too low. Adjust the volume control on your notebook.

The software volume control is set too low.

Headphones are plugged into your notebook.

BIOS audio settings are incorrect.

Software driver is not configured correctly.

DVD/CD-RW/CD-ROM Drive Problems

Notebook fails to recognize DVD/CD-RW/CD-ROMs.

DVD/CD-RW/CD-ROM is not pushed down onto raised center circle of the drive.

DVD/CD-RW/CD-ROM tray is not latched shut.

Setup utility is set to something other than DVD/CDRW/CD -ROM or Auto for the Secondary Master Controller.

Adjust the sound volume control settings in your software, operating system and applications.

Plugging in headphones disables the built-in speakers, remove the headphones.

Set the BIOS setup utility to the default values within the Multimedia Device Configuration menu. (See

BIOS Setup Utility on pag e35 for more information)

Refer to your application and operating system documentation for help.

Open DVD/CD-RW/CD-ROM tray and re-install DVD/CD-RW/CD-ROM properly.

Push on the front of the DVD/CD-RW/CD-ROM tray until it latches.

Revise BIOS settings for the Secondary Master Controller. (See BIOS Setup Utility on pag e35 for

more information)

Troubleshooting

Problem Possible Cause Possible Solutions

Notebook fails to recognize DVD/CD-RW/CD-ROMs. (continued)

The DVD/CD-RW/CDROM Access indicator on the Status Indicator Panel blinks at regular intervals when no DVD/CD-RW/ CD-ROM is in the tray or the DVD/CD-RW/CDROM drive is not installed.

Wrong drive designator was used for DVD/CD-RW/CDROM in the application.

Windows DVD/CD-RW/CDROM auto insert notification function is disabled.

DVD/CD-RW/CD-ROM is dirty or defective.

The Windows DVD/CD-RW/ CD-ROM auto insert notification function is active and is checking to see if a DVD/CDRW/CD -ROM is rea dy to run.

Verify the drive designator used by the application is thesameastheoneusedbytheoperatingsystem. When the operating system is booted from a DVD/ CD-RW/CD-ROM, drive designations are automatically adjusted.

Start the DVD/CD-RW/CD-ROM from the desktop or application software or re-enable the Windows DVD/CD-RW/CD-ROM auto insert notification function. (See Auto Insert Notification Function on

page 53 for more information)

Wipe DVD/CD-RW/CD-ROM with a non-abrasive CD cleaning cloth and reinsert. It if still will not work try another DVD/CD-RW/CD-ROM in the drive.

This is normal. However, you may disable this feature.

(See Auto Insert Notification Function on page 53 for more information)

The Notebook fails to AutoPlay a DVD movie.

Floppy Disk Drive Problems

You cannot access your floppy disk.

The DVD Player software has not been installed.

You tried to write to a write protected floppy disk.

Floppy disk is not loaded correctly.

BIOS setup utility states

Diskette Controller: Disabled.

The floppy disk drive may not be properly installed.

Security is set to protect access to floppy disk data.

Locate and install the DVD-ROM Applications CD.

Eject the floppy disk and set it to write enable. (See

Floppy Disk Drive on page 47 for more information)

Eject floppy disk, check orientation and re-insert.

(See Floppy Disk Drive on page 47 for more information)

Revise the setup utility Main menu settings to enable Diskette Controller. (See BIOS Setup Utility

on page 35 for more information)

Remove and re-install your floppy disk drive.

Verify your password and security settings.

LifeBook C Series – Section Fiv e

Problem Possible Cause Possible Solutions

Hard Drive Problems

You cannot access your hard drive.

Keyboard or Mouse Problems

The built-in keyboard does not seem to work.

Yo u h a v e i n s t a l l e d a n external keyboard or mouse, and it does not seem to work.

The setup utility is incorrectly set for your internal (Primary Master) or optional second hard drive (Primary Slave).

Thewrongdrivedesignator was used by an application when a bootable CD-ROM was used to start the notebook.

Security is set so your operating system cannot be started without a password.

The notebook has gone into Suspend mode.

Your application has locked out your keyboard.

Yo u r e x t e r n a l d e v i c e i s n o t properly installed.

Your operating system software is not setup with the correct software driver for that device.

Revise BIOS settings to set both Primary Master and Primary Slave correctly. (See BIOS Setup Utility

on page 35 for more information)

Verify drive designator used by application is in usebytheoperatingsystem.Whentheoperating system is booted from a CD, drive designations are automatically adjusted.

Verify your password and security settings.

Push the Suspend/Resume button.

Try to use your intergrated pointing device to restart your system. If this fails, turn your notebook off using the power switch, wait 10 seconds or more, andthenturnitbackon.

Re-install your device. (See Device Ports on page 59

for more information)

Check your device and operating system documentation and activate the proper driver.

You have connected an external keyboard or a mouse and it seems to be locking up the system.

Your operating system software is not setup with the correct software driver for that device.

Your system has crashed. Try to restart your notebook. If that fails, turn off

Memory Problems

Your Power On screen, or Main menu of the

Your memory upgrade module

is not properly installed. BIOS setup utility information, does not show the correct amount of

You have a memory failure. Check for Power On Self Test (POST) messages.

installed memory.

Check your device and operating system documentation and activate the proper driver.

the power using the power switch, wait at least 10 seconds, and then power on.

Remove and re-install your memory upgrade module. (SeeMemoryUpgradeModuleonpage56

for more information)

(See Power On Self Test Messages on page 75 for more information)

Problem Possible Cause Possible Solutions

Modem Problems

Troubleshooting

Messages about modem operation.

Messages about modem

operation are generated

by whichever modem

application is in use.

Parallel, Serial, and USB Device Problems

Yo u h a v e i n s t a l le d a p a r a l l e l port device, a serial port device or a USB device. Your notebook does not recognize the device, or the device does not seem to work properly.

Thedeviceisnot

properly installed.

The device may have been

installed while an application

was running, so your notebook

is not aware of its installation.

Yo u r s o f t w a r e m a y n o t

have the correct software

driver active.

Yo u m a y h a v e t h e w r o n g

I/O address selected for

your device.

Yo u r d e v i c e a n d a n o t h e r

deviceareassignedthesame

I/O address.

See your application software documentation for additional information.

Remove and re-install the device. (See Device Ports

on page 59 for more information)

Close the application and restart your notebook.

See your software documentation and activate the correct driver.

See your device documentation and software documentation to determine the required I/O address. Change the settings in the BIOS setup utility.(See

BIOS Setup Utility on pag e35 for more information)

Check all I/O addresses located within the BIOS setup utility and any other installed hardware or software to make sure there are no duplications.

Parallel port is set to

output only.

Check parallel port setting in the BIOS and set to bi-directional or ECP.

LifeBook C Series – Section Fiv e

Problem Possible Cause Possible Solutions

PC Card Problems

AcardinsertedinthePC Card slot does not work or is locking up the system.

Power Failures

Yo u t u r n o n y o u r notebook and nothing seems to happen.

The card is not

properly installed.

The card may have been

installed while an application

was running, so your notebook

is not aware of its installation.

Yo u r s o f t w a r e m a y n o t

have the correct software

driver active.

Yo u m a y h a v e t h e w r o n g

I/O address selected for your

PC Card device.

Yo u r P C C a r d d e v i c e a n d

another device are assigned the

same I/O address.

The installed primary

battery is completely

discharged, there is no

optional second battery

installed or there is no

Power adapter (AC or Auto/

Airline) installed.

Remove and re-install the card. (See PC Cards on

page 54 for more information)

Close the application and restart your notebook.

See your software documentation and activate the correct driver.

See your PC Card documentation to determine the required I/O address. Change the settings in the BIOS. (See BIOS Setup Utility on pag e35 for

more information)

Check all I/O addresses located within the BIOS setup utility and any other installed hardware or software to make sure there are no duplications.

Check the Status Indicator Panel to determine the presence and condition of the batteries. (See Status

Indicator Panel on page 17 for more information)

Install a charged battery or a Power adapter.

The primary battery is

installed but is faulty.

The battery or batteries are low. Check the Status Indicator Panel to determine the

The power adapter (AC or

auto/airline) is not plugged

in properly.

Use the Status Indicator panel to verify the presence and condition of the batteries. (See Status Indicator Panel on page 17 for more information) If a battery is indicating a short, remove that battery and operate from another power source or replace that battery.

presence and condition of the batteries. (See Status Indicator Panel on page 17 for more information) Use a Power adapter to operate until a battery is charged or install a charged battery.

Verify that your adapter is connected correctly. (See

Power Sources on page 33 for more information)

Troubleshooting

Problem Possible Cause Possible Solutions

You turn on your notebook and nothing seems to happen. (continued)

Your notebook turns off all by itself.

The Power adapter (AC

or auto/airline) has no

power from the AC outlet,

airplane seat jack, or the car’s

cigarette lighter.

The Power adapter (AC or

auto/airline) is faulty.

Power switch is not in the

On position.

The power management

parameters are set for auto

timeouts which are too short

foryouroperatingneeds.

You are operating on battery

power only and have ignored a

low battery alarm until the

batteries are all at the dead

battery state and your machine

has gone into Dead Battery

Suspend mode.

Move the AC cord to a different outlet, check for a line switch or tripped circuit breaker for the AC outlet. If you are using an auto/airline adapter in a car make sure the ignition switch is in the On or Accessories position.

Try a different Power adapter or install a charged optional second battery.

Slide your power switch firmly to the Off position, pause 10 seconds or more and then firmly to the On position.

Pressanybuttononthekeyboard,ormovethe mouse to restore operation. If that fails, push the Suspend/Resume button. Check your power management settings, or close your applications andgotothePowerSavingsmenuofthesetup utility to adjust the timeout valuesto better suit your operation needs.

Install a power adapter and then push the Suspend/ Resume button. (See Power Sources on page 33 for

more information)

Your notebook will not work on battery alone.

You have a battery failure. Verify the condition of the batteries using the

Status Indicator panel, and replace or remove any batteries that are shorted. (See Status Indicator

Panel on page 17 for more information)

Your power adapter has failed

or lost its power source.

The installed batteries

are dead.

Make sure the adapter is plugged in and the outlet has power.

Replacethebatterywithachargedoneorinstall a Power adapter.

No batteries are installed. Install a charged battery.

The batteries are

improperly installed.

Your installed batteries

are faulty.

Verify that the batteries are properly connected by re-installing them.

Verify the condition of the batteries using the Status Indicator panel and replace or remove any batteries that are shorted. (See Status Indicator

Panel on page 17 for more information)

LifeBook C Series – Section Fiv e

Problem Possible Cause Possible Solutions

The batteries seem to discharge too quickly.

You are running an application

that uses a great deal of power

due to frequent hard drive

access or DVD/CD-RW/CD-

ROM access, use of a modem

card or a LAN PC card.

The power savings features

may be disabled.

Thebrightnessisturnedall

the way up.

The batteries are very old. Replace the batteries.

The batteries have been

exposed to high temperatures.

The batteries are too hot

or too cold.

Shutdown and Startup Problems

Use both the primary battery and an optional second battery and/or use a power adapter for this applicationwhenatallpossible.

Check the power management and/or setup utility settings in the Power Savings menu and adjust according to your operating needs.

Turn down the brightness adjustment. The higher thebrightnessthemorepoweryourdisplayuses.

Replace the batteries.

Restore the notebook to normal operating temperature. The Charging icon on the Status Indicator panel will flash when the battery is outside its operating range.

The Suspend/Resume button does not work.

The system powers up, and displays power on information, but fails to load the operating system.

The Suspend/Resume button

is disabled from the Advanced

submenu of the Power menu

of the setup utility.

Yo u d i d n o t h o l d t h e b u t t o n

in long enough.

There may be a conflict with

the application software.

The boot sequence settings

of the setup utility are not

compatible with your

configuration.

Yo u h a v e a s e c u r e d s y s t e m

requiring a password to load

your operating system.

Enable the button from the setup utility.

Hold the button longer. This may need to be a few seconds if your application is preventing the CPU from checking for button pushes.

Close all applications and try the button again.

Settheoperatingsourcebypressingthe[ESC]key while the Fujitsu logo is on screen or use the [F2] key and enter the setup utility and adjust the source settings from the Boot menu. (See BIOS Setup

Utility on page 35 for more information)

Make sure you have the right password. Enter the setup utility and verify the Security settings and modify them as accordingly. (See BIOS Setup Utility

on page 35 for more information)

Troubleshooting

Problem Possible Cause Possible Solutions

The system powers up, and displays power on information, but fails to load the operating system. (continued)

An error message is displayed on the screen during the notebook (boot) sequence.

Your notebook appears to change setup parameters when you start it.

Video Problems

Internal hard drive was

not detected.

Power On Self Test (POST) has

detected a problem.

BIOS setup changes were not

saved when you made them

andexitedtheBIOSsetup

utility returning it to

previous settings.

The BIOS CMOS hold-up

battery has failed.

Use the BIOS setup utility or Primary Master submenu, located within the Main menu, to try to auto detect the internal hard drive.

See the Power On Self Test (POST) messages to determine the meaning and severity of the problem. Not all messages are errors; some are simply status indicators. (See Power On Self Test Messages on

page 75 for more information)

Make sure you select Save Changes And Exit when exiting the BIOS setup utility.

Contact your support representative for repairs. This is not a user serviceable part but has a normal life of 3 to 5 years.

The built-in display is blank when you turn on your notebook.

The notebook turned on with a series of beeps and your built-in display is blank.

Something is pushing on the

Closed Cover switch.

The notebook is set for an

external monitor only.

Theangleofthedisplay

and the brightness settings

are not adequate for your

lighting conditions.

The power management time-

outs may be set for very short

intervals and you failed to

notice the display come on

and go off again.

Power On Self Test (POST)

has detected a failure which

does not allow the display

to operate.

Clear the Closed Cover switch. (See figure 2-3 on

page 10 for location)

Pressing [F10] while holding down the [FN] key allows you to change your selection of where to send your display video. Each time you press the combination of keys you will step to the next choice. The choices, in order are: built-in display only, external monitor only, both built-in display and external monitor.

Move the display and the brightness control until you have adequate visibility.

Press any button the keyboard, or move the mouse to restore operation. If that fails, push the Suspend/ Resume button. (The display may be shut off by Standy mode, Auto Suspend or Video Timeout)

Contact your support representative.

LifeBook C Series – Section Fiv e

Problem Possible Cause Possible Solutions

The display goes blank by itself after you have been using it.

The Built-in Display does not close.

The Built-in Display has bright or dark spots.

The notebook has gone into

Video timeout, Standby mode,

Suspend mode or Save-to-Disk

mode because you have not

used it for a period of time.

Something is pushing on the

Closed Cover switch.

The power management time-

outs may be set for very short

intervals and you failed to

notice the display come on

and go off again.

A foreign object, such as a

paper clip, is stuck between the

displayandthekeyboard.

If the spots are very tiny and

few in number, this is normal

for a large LCD display.

Press any button on the keyboard, or move the mouse to restore operation. If that fails, push the Suspend/Resume button. Check your power management settings, or close your applications andgotothePowerSavingsmenuofthesetup utility to adjust the timeout values to better suit your operation needs. (See BIOS Setup Utility on

page 35 for more information)

Check the Closed Cover switch. (See figure 2-3 on page 10 for location)

Pressanybuttononthekeyboard,ormovethemouse to restore operation. If that fails, push the Suspend/ Resume button. (The display may be shut off by Standby Mode, Auto Suspend or Video Timeout)

Remove all foreign objects from the keyboard.

This is normal; do nothing.

The application display uses only a portion of your screen and is surrounded by a dark frame.

The Display is dark when on battery power.

If the spots are numerous or

large enough to interfere with

your operation needs.

You are running an

application that does not

support 800 x 600/1024 x 768

pixel resolution display and

display compression is

enabled.

The PMSet default is set

on low brightness to

conserve power.

Display is faulty; contact your support representative.

Display compression gives a clearer but smaller display for applications that do not support 800 x 600/1024 x 768 pixel resolution. You can fill the screen but have less resolution by changing your display compression setting, (See the Video Features submenu, located within the Advanced menu of the BIOS. (See BIOS Setup Utility on page 35 for more

information)

Press [FN] + [F7] to increase brightness or doubleclick on PMSet battery gauge and adjust Power Control under battery settings.

Troubleshooting

Problem Possible Cause Possible Solutions

You have connected an external monitor and it does not display any information.

You have connected an external monitor and it does not come on.

Miscellaneous Problems

An error message is displayed on the screen during the operation of an application.

Your BIOS setup is not set to

enable your external monitor.

Your external monitor is not

properly installed.

Your operating system soft-

ware is not setup with the

correct software driver for

that device.

Your external monitor

is not compatible with

your notebook.

Application software often

has its own set of error

message displays.

Try toggling the video destination by pressing [FN] and [F10] together, or check your BIOS setup and enable your external monitor. (See the Video Features submenu, located within the Advanced Menu of the BIOS. (See BIOS Setup Utility on pag e35 for more

information)

Reinstall your device. (See External Monitor Port on page 61 for more information)

Check your device and operating system documentation and activate the proper driver.

See your monitor documentation and the External Monitor Support portions of the Specifications section.

See your application manual and help displays screens for more information. Not all messages are errors some may simply be status.

POWER ON SELF TEST MESSAGES

The following is an alphabetic list of error-and-status messages that Phoenix BIOS and/or your operating system can generate and an explanation of each message. Error messages are marked with an *. The most common errors are marked with a #. If an error message is displayed that is not in this list, write it down and check your operating system documentation both on screen and in the manual. If you can find no reference to the message and its meaning is not clear, contact your support representative for assistance.

nnnn Cache SRAM Passed

Where nnnn is the amount of system cache in kilobytes success-fully tested by the Power On Self Test. (This can only appear if you have an SRAM PC Card installed.)

*Diskette drive A error or Diskette drive B error

DriveA:orB:ispresentbutfailstheBIOSPowerOnSelf Test diskette tests. Check to see that the drive is defined with the proper diskette type in the Setup Utility, (See BIOS Setup Utility on pag e35 for more information) and that the diskette drive is installed correctly. If the disk

drive is properly defined and installed, avoid using it and contact your support representative.

*Extended RAM Failed at offset: nnnn

Extended memory not working or not configured properly. If you have an installed memory upgrade module, verify that the module is properly installed. If it is properly installed, you may want to check your Windows Setuptobesureitisnotusingunavailablememory until you can contact your support representative.

nnnn Extended RAM Passed

Where nnnn is the amount of memory in kilobytes successfully tested.

*Failing Bits: nnnn The hex number nnnn

This is a map of the bits at the memory address (in System, Extended, or Shadow memory) which failed the memory test. Each 1 (one) in the map indicates a failed bit. This is a serious fault that may cause you to lose data if you continue. Contact your support representative.

LifeBook C Series – Section Fiv e

*Fixed Disk x Failure or Fixed Disk Controller Failure(wherex=1-4)

The fixed disk is not working or not configured properly. This may mean that the hard drive type identified in your setup utility does not agree with the type detected by the Power On Self Test. Run the setup utility to check for the hard drive type settings and correct them if necessary. If the settings are OK and the message appears when you restart the system, there may be a serious fault which might cause you to lose data if you continue. Contact your support representative.

*Incorrect Drive A type – run SETUP

Type of floppy drive A: not correctly identified in Setup. This means that the floppy disk drive type identified in your setup utility does not agree with the type detected by the Power On Self Test. Run the setup utility to correct the inconsistency.

*Incorrect Drive B type – run SETUP

Type of floppy drive B: not correctly identified in Setup. This means that the floppy disk drive type identified in your setup utility does not agree with the type detected by the Power On Self Test. Run the setup utility to correct the inconsistency.

*Invalid NVRAM media type

Problem with NVRAM access. In the unlikely case that you see this message you may have some display problems. You can continue operating but should contact your support representative for more information.

*Keyboard controller error

The keyboard controller test failed. You may have to replace your keyboard or keyboard controller but may be able to use an external keyboard until then. Contact your support representative.

*Keyboard error

Keyboard not working. You may have to replace your keyboard or keyboard controller but may be able to use an external keyboard until then. Contact your support representative.

*Keyboard error nn

BIOS discovered a stuck key and displays the scan code for the stuck key.You may have to replace your keyboard but may be able to use an external keyboard until then. Contact your support representative.

*Monitor type does not match CMOS – Run SETUP

Monitor type not correctly identified in Setup. This error probably means your BIOS is corrupted, run the setup utility and set all settings to the default conditions. If you still get this error, contact your support representative.

#*Operating system not found

Operating system cannot be located on either drive A: or drive C: Enter the setup utility and see if both the fixed disk, and drive A: are properly identified and that the boot sequence is set correctly.Unless you have changed your installation greatly, the operating system should be on drive C:. If the setup utility is correctly set, your hard drive may be corrupted and your system may have to be re-installed from your back up media.

*Parity Check 1 nnnn

Parity error found in the system bus. BIOS attempts to locate the address and display it on the screen. If it cannot locate the address, it displays ????. This is a potentially data destroying failure. Contact your support representative.

*Parity Check 2 nnnn

Parity error found in the I/O bus. BIOS attempts to locate the address and display it on the screen. If it cannot locate the address, it displays ????. This is a potentially data destroying failure. Contact your support representative.

#*Press <F1> to resume, <F2> to SETUP

Displayed after any recoverable error message. Press the [F1] key to continue the boot process or the [F2] key to enter Setup and change any settings.

#*Previous boot incomplete – Default configuration used

Previous Power On Self Test did not complete successfully. The Power On Self Test will load default values and offer to run Setup. If the previous failure was caused by incorrect values and they are not corrected, the next boot will likely fail also. If using the default settings does not allow you to complete a successful boot sequence, you should turn off the power with the Power Switch and contact your support representative.

*Real time clock error

Real-time clock fails BIOS test. May require board repair. Contact your support representative.

Troubleshooting

*Shadow RAM Failed at offset: nnnn

Shadow RAM failed at offset nnnn of the 64k block at which the error was detected.You are risking data corruption if you continue. Contact your support representative.

nnnn Shadow RAM Passed

WherennnnistheamountofshadowRAMinkilobytes successfully tested.

*System battery is dead – Replace and run SETUP

The BIOS CMOS RAM memory hold up battery is dead. This is part of your BIOS and is a board mounted battery which requires a support representative to change. You can continue operating but you will have to use setup utility default values or reconfigure your setup utility every time you turn off your notebook. This battery has an expected life of 2 to 3 years.

System BIOS shadowed

System BIOS copied to shadow RAM.

*SystemCMOSchecksumbad– run SETUP

BIOS CMOS RAM has been corrupted or modified incorrectly, perhaps by an application program that changes data stored in BIOS memory. Run Setup and reconfigure the system.

*System RAM Failed at offset: nnnn

System memory failed at offset nnnn of in the 64k block at which the error was detected. This means that there is a fault in your built-in memory. If you continue to operate, you risk corrupting your data. Contact your support representative for repairs.

nnnn System RAM Passed

Where nnnn is the amount of system memory in kilobytes successfully tested.

*System timer error

The timer test failed. The main clock that operates the computer is faulty. Requires repair of system board. Contact your support representative for repairs.

EMERGENCY DVD/CD-RW/CD-ROM TRAY RELEASE

If for some reason the eject button fails, you can open the DVD/CD-RW/CD-ROM tray with a paper clip or similar tool inserted into the eject hole in the far right sideofthefrontofthetray.Straightenonesideofa paper clip and push it gently into the hole. The tray will pop out ashortdistance.

MODEM RESULT CODES

The operating system and application software that is factory installed detects the modem characteristics and provides the necessary command strings to operate the modem. The internal modem operation is controlled by generic AT commands from the operating system and application software. The standard long form result codes may, in some cases, be displayed on your screen to keep you informed of the actions of your modem. The operating system and application software may suppress display of the result codes.

Examples of result codes are:

■

NO CARRIER

■

NO DIALTONE

■

CONNECT 53000 (Connection complete at 53,000 bps.)

■

ERROR

■

FAX

■

RING (This means an incoming call.)

■

BUSY

■

NO ANSWER

When using the internal modem with applications that are not factory installed refer to the application documentation.

UMB upper limit segment address: nnnn

Displays the address of the upper limit of Upper Memory Blocks, indicating released segments of the BIOS memory which may be reclaimed by a virtual memory manager.

Video BIOS shadowed

VideoBIOSsuccessfullycopiedtoshadowRAM.

LifeBook C Series – Section Fiv e

RECOVERY CD-ROM

Included with your notebook are the Emergency Recovery CD and Drivers and Application Restore CD.

The Emergency Recovery CD contains the following:

■

A backup copy of the software originally installed on your Fujitsu LifeBook (can only be used on the listed LifeBook models).

The Drivers and Application Restore CD contains the following:

■

Sets of device drivers and Fujitsu utilities (in specific directories) that are unique to your notebook configuration for use as documented below.

■

Read-me files that provide additional use information for items on this CD-ROM.

POINT

If you have access to the internet, visit the Fujitsu PC Corporation Support Web site at www.8fujitsu.com to check for the most current information, drives and hints on how to perform recovery and system updates.

Restoring Your Pre-installed Software from CD-ROM

The Emergency Recovery CD-ROM enables restoration of your notebook disk drive contents as they were originally shipped from the factory. Most often this is necessary if files or software programs (only those files/ programs that came pre-installed) become corrupt or accidentally erased.

You have two options available when performing recovery:

1. Recover Hard Drive without Format. This choice replaces all the original factory installed files and program structures without eliminating your data files. You will have to re-install any software that was not included with the computer when you bought it, however you data will be intact as long as the installation of the additional programs is performed in the same manner.

2. Format and Recover Hard Drive. This choice removes all the information on the hard disk. If you choose this option, you will lose any software you

have installed and any other files you created since you setup your computer. You will have to re-install any software that was not included with the computer when you bought it.

POINT

It is recommended that you back-up all data files prior to performing either of the recovery options.

POINT

Make certain you have your Operating System Product ID # available (from the Certificate of Authenticity) prior to performing recovery. Once the process is complete and you re-start your notebook, you will be required to perform all the setup steps as when the computer was first purchased.

(See Booting the System with Windows

98 on page 36 for more information)

CAUTION

User data and user installed software CAN NOT be recovered from the Emergency Recovery CD.

To Run the Emergency Recovery Program

To use this portion of the CD-ROM, your notebook must Boot up (upon power up or full system reset/ restart) from the CD-ROM drive.

1. Insert the Emergency Recovery CD in the CD-ROM drive.

2. If your notebook is running when you insert the CD, exit your operating system and power down the notebook.

3. Start (power up) your notebook.

4. At this point, you must either change your BIOS setup configuration through the [F2] key to have the computer boot from the CD-ROM “first” (if you have not previously done so), or you can use the [ESC] key during this boot-up sequence and select the CD-ROM from the menu that will appear. (See BIOS Setup Utility on page 35

for more information)

5. If correctly configured to boot from the Recovery CD-ROM, you will notice your system running a full virus scan of the hard drive and then reach the Emergency Recovery Welcome screen. If this is not what is displayed, check to see that the Recovery CD is installed in the CD-ROM drive and repeat the previous steps, starting with 2. If you received amessage“This program may not be used on your computer” youareusingthewrongRecoveryCD for the model of notebook. Contact Fujitsu PC Service and Support to obtain the correct CD.

6. Read the information displayed on the Welcome screen, then click OK.

7. Select one of the two icons displayed in the Emergency Recovery menu and follow the instructions.

8. When recovery is complete, remove the Recovery CD, replace it in its sleeve and store it in a safe location (with your Operating System Manual/ Certificate of Authenticity).

9. Restart your notebook.

10. Reset your boot device priority in the BIOS setup as desired.

Your notebook now has all of the software installed that was included when you received it from the factory. You must now load any programs which you purchased and installed after you received your notebook. If you chose the Format and Recover Hard Drive option, you should now restore your data files. If you performed the Recover Hard Drive without Format, your data files will still exist (within their original directory structures).

Troubleshooting

POINT

AslongasthereisnobootablediskintheCD-ROM drive or the floppy disk drive, your notebook will boot from the hard drive regardless of the BIOS Boot Device Priority setting.

Drivers and Applications Restore CD

TheDriversandApplicationCDcanbeusedtoselectively re-install drivers and/or applications that may have been un-installed or corrupted. Please refer to installation instructions located in the Drivers and Applications Restore CD. You can also consult our Web site at www.8fujitsu.com.

POINT

Look for and open files with the extensions.DOC and .TXT.

LifeBook C Series – Section Fiv e

Care and Maintenance

Section Six

Care and Maintenance

LifeBookSeriesNotebook.................. 83

Batteries...............................84

FloppyDisksandDrives................... 84

DVDsandCDs..........................85

PCCards..............................85

LifeBook C Series – Section Si x

Care and Maintenance

If you use your Fujitsu LifeBook carefully, you will increase its life and reliability. This section provides some tips for looking after the notebook and its devices.

CAUTION

Electrical equipment may be hazardous if misused. Operations of this product or similar products, must always be supervised by an adult. Do not allow children access to the interior of any electrical products and do not permit them to handle any cables .

Care and Maintenance

■

Keep the covers closed on the connectors and slots when they are not in use.

■

Do not put heavy or sharp objects on the computer.

■

If you are carrying your Fujitsu LifeBook in a briefcase, or any other carrying case, make sure that there are no objects in the case pressing on the lid.

■

Never position your notebook such that the CD-ROM or DVD drive is supporting the weight of the notebook.

■

Do not drop your Fujitsu LifeBook.

■

Do not touch the screen with any sharp objects.

FUJITSU LIFEBOOK

Caring for your Fujitsu LifeBook

■

Your Fujitsu LifeBook is a durable but sensitive electronic device. Treat it with respect and care.

■

Make a habit of transporting it in a suitable carrying case.

■

Do not attempt to service the computer yourself. Always follow installation instructions closely.

■

Keep it away from food and beverages.

■

If you accidentally spill liquid on your notebook:

1. Turn it off.

2. Position it so that the liquid can run out.

3. Let it dry out for 24 hours, or longer if needed.

4. If your notebook will not boot after it has dried out, call your support representative.

■

Do not use your Fujitsu LifeBook in a wet environment (near a bathtub, swimming pool).

■

Always use the AC adapter and batteries that are approved for your notebook.

■

Avoid exposure to sand, dust and other environmental hazards.

■

Do not expose your Fujitsu LifeBook to direct sunlight for long periods of time as temperatures above 140° F (60° C) may damage your notebook.

Cleaning your Fujitsu LifeBook

■

Always disconnect the power plug. (Pull the plug, not the cord.)

■

Clean your Fujitsu LifeBook with a damp, lint-free cloth. Do not use abrasives or solvents.

■

Use a soft cloth to remove dust from the screen. Never use glass cleaners.

StoringyourFujitsuLifeBook

■

If storing your notebook for a month or longer, turn your Fujitsu LifeBook off and remove all Lithium ion batteries.

■

Store your Fujitsu LifeBook and batteries separately. If you store your notebook with a battery installed, the battery will discharge, and battery life will be reduced. In addition, a faulty battery might damage your notebook.

■

Store your Fujitsu LifeBook in a cool, dry location. Temperatures should remain between

-25ºC(13ºF) and 60ºC (140ºF).

Traveling with your Fujitsu LifeBook

■

Do not transport your Fujitsu LifeBook while it is turned on.

■

Do not check your Fujitsu LifeBook as baggage. Carry it with you.

■

Always bring your System Recovery CD that came with your Fujitsu LifeBook when you travel. If you experience system software problems while traveling, you may need it to correct any problems.

LifeBook C Series – Section Si x

■

Never put you Fujitsu LifeBook through a metal detector. Have your notebook hand-inspected by security personnel. You can however, put your Fujitsu LifeBook through a properly tuned X-ray machine. To avoid problems, place your notebook close to the entrance of the machine and remove it as soon as possible or have your notebook hand-inspected by security personnel. Security officials may require you to turn your notebook On. Make sure you have a charged battery on hand.

■

When traveling with the hard drive removed, wrap the drive in a non-conducting materials (cloth or paper). If you have the drive checked by hand, be ready to install the drive if needed. Never put your hard drive through a metal detector. Have your hard drive hand-inspected by security personnel. You can however, put your hard drive through a properly tuned X-ray machine.

■

Take the necessary plug adapters if you're traveling overseas. Check the following diagram to determine which plug adapter you'll need or ask your travel agent.

Outlet Type Location

United States, Canada, parts of Latin America,

Japan, Korea,

the Philippines, Taiwan

BATTERIES

Caring for your Batteries

■

Always handle batteries carefully.

■

Do not short-circuit the battery terminals (that is, do not touch both terminals with a metal object). Do not carry lose batteries in a pocket or purse where they may mix with coins, keys, or other metal objects. Doing so may cause an explosion or fire.

■

Do not drop, puncture, disassemble, mutilate or incinerate the battery.

■

Recharge batteries only as described in this manual and only in ventilated areas.

■

Do not leave batteries in hot locations for more than a day or two. Intense heat can shorten battery life.

■

Do not leave a battery in storage for longer than 6 months without recharging it.

Increasing Battery Life

■

PoweryourFujitsuLifeBookthroughtheACor optional auto/airline adapter whenever possible.

■

If your Fujitsu LifeBook is running on battery power all day, connect it to the AC adapter overnight to recharge the battery.

■

Keep brightness to the lowest level comfortable.

■

Set the power management for maximum battery life.

RussiaandtheCommonwealth

of Independent States (CIS),

most of Europe, parts of Latin

America, the Middle East, parts

of Africa, Hong Kong, India,

most of South Asia

Mexico, United Kingdom,

Ireland, Malaysia, Singapore,

parts of Africa

China, Australia,

New Zealand

■

Put your Fujitsu LifeBook in Suspend mode when it is turned on and you are not actually using it.

■

Limit your DVD/CD-RW/CD-ROM access.

■

Disable the Windows CD auto insert notification function.

■

Always use fully charged batteries.

■

Eject PCMCIA cards when not in use.

FLOPPY DISKS AND DRIVES

Caring for your Floppy Disks

■

Avoid using the floppy disks in damp and dusty locations.

■

Never store a floppy disk near a magnet or magnetic field.

■

Donotuseapenciloraneraseronadiskor disk label.

Care and Maintenance

■

Avoid storing the floppy disks in extremely hot or cold locations, or in locations subject to severe temperature changes. Store at temperatures between 50º F(10ºC) and 125ºF(52ºC).

■

Do not touch the exposed part of the disk behind the metal shutter.

Caring for your Floppy Disk Drive

■

Toclean,wipethefloppydiskdrivecleanwithadry soft cloth, or with a soft cloth dampened with water or a solution of neutral detergent. Never use benzene, paint thinner or other volatile material.

■

Avoid storing the floppy disk drive in extremelyhot or cold locations, or in locations subject to severe temperature changes. Store at temperatures between 50º F (10ºC) and 125ºF(52ºC).

■

Keep the floppy disk drive out of direct sunlight and away from heating equipment.

■

Avoid storing the floppy disk drive in locations subject to shock and vibration.

■

Never use the floppy disk drive with any liquid, metal, or other foreign matter inside the floppy disk drive or disk.

■

Never disassemble or dismantle your floppy disk drive.

DVDs AND CDs

Caring for your DVDs and CDs

DVDs and CDs are precision devices and will function reliably if given reasonable care.

■

Always store your DVD/CDs in its case when it is not in use.

■

Always handle DVD/CDs by the edges and avoid touching the surface.

■

Avoid storing any DVD/CDs in extreme temperatures.

■

Do not bend DVD/CDs or set heavy objects on them.

■

Do not spill liquids on DVD/CDs.

■

Do not scratch DVD/CDs.

■

Do not put a label on DVD/CDs.

■

Do not get dust on DVD/CDs.

■

Never write on the label surface with a ballpoint pen or pencil. Always use a felt pen.

■

If a DVD/CD is subjected to a sudden change in temperature, cold to warm condensation may form on the

surface. Wipe the moisture off with a clean, soft, lint free cloth and let it dry at room temperature. DO NOT useahairdryerorheatertodryDVD/CDs.

■

If a DVD/CD is dirty, use only a DVD/CD cleaner or wipe it with a clean, soft, lint free cloth starting from the inner edge and wiping to the outer edge.

Caring for your DVD, CD-RW, or CD-ROM Drive

Your DVD, CD-RW, or CD-ROM drive is durable but you must treat it with care. Please pay attention to the following points:

■

The drive rotates the compact disk at a very high speed. Do not carry it around or subject it to shock or vibration with the power on.

■

Avoid using or storing the drive where it will be exposed to extreme temperatures.

■

Avoid using or storing the drive where it is damp or dusty.

■

Avoid using or storing the drive near magnets or devices that generate strong magnetic fields.

■

Avoid using or storing the drive where it will be subjected to shock or vibration.

■

Do not disassemble or dismantle the DVD, CD-RW, or CD-ROM drive.

PC CARDS

Caring for your PC Cards

PC Cards are durable, but you must treat them with care. The documentation supplied with your PC Card will provide specific information, but you should pay attention to the following points:

■

Tokeepoutdustanddirt,storePCCardsintheir protective sleeves when they are not installed in your notebook.

■

Avoid prolonged exposure to direct sunlight or excessive heat.

■

Keep the cards dry.

■

Donotflexorbendthecards,anddonotplaceheavy objects on top of them.

■

Do not force cards into the slot.

■

Avoid dropping cards, or subjecting them to excessive vibration.

LifeBook C Series – Section Si x

Section Seven

Specifications

ConfigurationLabel......................89

Microprocessor..........................90

Memory...............................90

Video.................................90

Audio.................................90

Mass Storage Device Options . . . . . . . . .......90

Features...............................90

DevicePorts............................91

Keyboard..............................91

Power ................................91

DimensionsandWeight................... 91

EnvironmentalRequirements...............91

Specifications

LifeBook C Series – Section Seve n

Specifications

This section provides the hardware and environmental specifications for your Fujitsu LifeBook. Specifications of particular configurations will vary.

Model

Processor

CONFIGURATION LABEL

Your Fujitsu LifeBook contains a configuration label located on the bottom of your notebook. (See figure 2-7 on page 16 for location) This label contains specific information regarding the options you’ve chosen for your notebook. Following is an example label and information on how to read your own configuration label.

Screen Size

Configuration IDPart Number

Memory

Operating System

Hard Drive

Device

Figure 7-16 Configuration Label

Models # C-6557 C-6537 C-6177 C-4235

Processor 650 MHz

Pentium III with SpeedStep Technology

500 MHz Pentium III with SpeedStep Technology

500 MHz Celeron

450 MHz AMD K6-2

Display 14.1" XGA TFT 14.1" XGA TFT 14.1" XGA TFT 12.1" SVGA TFT

Memory 128MB 64MB 64MB 64MB

Hard Drive 12GB 9GB 6GB 6GB

DVD/CD Built-in DVD Built-in DVD Built-in CD-ROM Built-in CD-ROM

Floppy Disk Drive

Built-in Floppy Disk Drive

Modem 56K* V.90 support 56K* V.90 support 56K* V.90 support 56K* V.90 support

Wireless IR

Included Optional Optional Not supported

Mouse

Note: For a detailed list of options available for your LifeBook, visit the Fujitsu web site at: www.fujitsu-pc.com

or call FPCDIRECT (1-877-372-3473).

* Actual speeds over U.S. telephone lines vary and are less than 56Kbps due to the current FCC regulations and line conditions. The internal modems on all Fujitsu notebooks from Fujitsu PC Corporation are only qualified for use with telephone systems inside the United States and Canada and may not operate in other countries.

LifeBook C Series – Section Seve n

MICROPROCESSOR

Latest high-speed Intel/AMD Mobile PCI bus architecture and CardBus architecture.

MEMORY

System Memory

64MB, expandable up to 192MB SDRAM.

Cache Memory

On-die L2 or AMD external cache.

BIOS Memory

512KB Flash ROM. 256 Bytes CMOS RAM with back-up battery.

VIDEO

Built-in color flat-panel TFT active matrix LCD display with simultaneous display capability.

Video Color and Resolution

14.1" XGA TFT

■

Internal: 1024 x 768 pixel resolution, 16M colors.

■

External: 1600 x 1200 pixel resolution, 64K colors. Simultaneous Video = Yes (1024 x 768, 64K colors max) XGA, SVGA and VGA compatible.

12.1" TFT SVGA

■

Internal: 800 x 600 pixel resolution, 16M colors.

■

External: 1280 x 1024 pixel resolution, 256 colors. Simultaneous Video = Yes (1024 x 768, 64k colors max) XGA, SVGA and VGA compatible.

Video RAM

4MB or 2.5MB Embedded SDRAM.

Video

Zoomed Video support via PC Card Slot 1.

AUDIO

■

SoundBlaster Pro-compatible 32-bit stereo PCM/FM sound chip.

■

Spatializer 3D-Stereo multiple speaker effect support.

■

Stereo headphone jack, 1 Vrms, or less, minimum impedance 32 Ohms.

■

Stereo line in jack, 880 mVrms or less, minimum impedance 10K Ohms.

■

Mono microphone jack, 125 mVp-p or less, minimum impedance 10K Ohms.

■

Two built-in speakers, 28 mm diameter (Stereo).

■

One built-in monaural microphone.

MASS STORAGE DEVICE OPTIONS

Floppy Disk Drive

Built-in 3. 5" Floppy Disk Drive, which accommodates

1.44MB or 720KB floppy disks.

Hard Drive

2.5"fixedharddrive.

One of the following built-in devices:

CD-ROM Drive

24x maximum, 5" CD-ROM drive.

DVD Drive

6x, 5" DVD drive.

CD-RW Drive

4x CD-R. 4x CD-RW. 20x maximum CD.

FEATURES

Integrated Pointing Device

ErgoTrac pointing device.

Communications

Modem: Internal V.90 standard 56K* fax/modem (ITU V.90, 56K data, 14.4K fax.)

* Actual speeds over U.S. telephone lines vary and are

less than 56Kbps due to the current FCC regulations andlineconditions.Theinternalmodemsonall Fujitsu notebooks from Fujitsu PC Corporation are only qualified for use with telephone systems inside the United States and Canada and may not operate in other countries.

LifeBook Application Panel

Application Launcher and Audio CD Player

Theft Prevention Lock

Lock slot for use with physical restraining security systems. The locking system by Kensington is recommended.

Pre-Installed Software

■

Microsoft Windows 98

■

Microsoft Internet Explorer

■

Microsoft Press Interactive Training for Windows

■

Microsoft Works

■

Quicken 2000

■

LapLink Professional by Traveling Software

■

PC-Doctor by Watergate Software, Inc.

Specifications

■

PMSet 98 by Fujitsu Limited.

■

McAfee VirusScan by Network Associates, Inc.

■

Adobe Acrobat Reader by Adobe Systems, Inc.

■

Netscape Communicator

■

DVD Player (units with DVD drive)

■

LifeBook Application Panel

DEVICE PORTS

■

Combination PC Card slot for one Type III/two Type II cards: PCMCIA Standard 2.1 with CardBus support; Zoomed Video support via Slot 1.

■

One 6-pin mini DIN PS/2 compatible connector, for external keyboard, external mouse or external numeric keypad.

■

One 25-pin D-SUB two-way Centronics type connector for parallel input/output devices; Bi-directional, output only or ECP.

■

One 15-pin D-SUB connector for VGA external monitor (see Display specifications).

■

One 9-pin D-SUB connector for RS-232C serial input/output devices.

■

One connector for USB (Universal Serial Bus) input/output devices.

■

One 25-pin special connector for external floppy disk drive connection.

■

One modular modem (RJ-11) connector.

■

One stereo headphone jack. (See Audio specifications)

■

One mono microphone jack. (See Audio specifications)

■

One stereo line-in jack. (See Audio specifications)

External Mouse Support

PS/2 compatible.

POWER

Batteries

One 9-cell Lithium ion battery, rechargeable, 10.8V, 3600 mAh.

Bridge Battery

Your Fujitsu LifeBook comes equipped with a bridge battery. A bridge battery allows a charged Lithium ion battery to be replaced without shutting down the system. The bridge battery capacity is not large and can vary with the condition or your notebook, so you will have 3 minutes at the most to make the change.

AC Ada pter

Autosensing 100-240V AC, 53W, supplying 16V DC to the notebook, Fujitsu Model FPCAC08 which includes an AC cable.

Power Management

Conforms to APM (Advanced Power Management).

Electro-Static Discharge (ESD)

9kV.

DIMENSIONS AND WEIGHT

Overall Dimensions

12.13" x 11.12" x 1.75" (Performance Models).

KEYBOARD

Built-in keyboard with all functions of 101 key PS/2 compatible keyboards.

■

Total number of keys: 87.

■

Function keys: 12, F1 through F12.

■

Feature extension key: Fn.

■

Three Windows keys: two Start keys and one application key

■

Key pitch: 19 mm.

■

Key stroke: 3 mm.

■

Built-in ErgoTrac pointing device with left and right buttons.

■

Built-in Palm Rest.

External Keyboard Support

PS/2 compatible.

External Numeric Keypad Support

PS/2 compatible.

12.13" x 11.12" x 1.91" (Value Models).

We i g h t s

Approximately 6.9 lbs – 7.5 lbs.

ENVIRONMENTAL REQUIREMENTS

Te m p er a t u r e

Operating: 5° to 35° C(41° to 95° F). Non-operating: –15° to 60° C(5° to 140° F).

Humidity

Operating: 20% to 85%, relative, non-condensing. Non-operating; 8% to 85%, relative, non-condensing.

Altitude

Operating: 10,000 feet (3,048 m) maximum.
