Interstage Application Server
V6.0
Product Notes
Product Notes
Trademarks
Trademarks of other companies are used in this user guide only to identify particular products or
systems:
Product Trademark/Registered Trademark
Microsoft, Visual Basic, Visual C++,
Windows, Windows NT, Internet Information
Registered trademarks of Microsoft Corporation in
the U.S.A. and other countries
Server, and Internet Explorer
Sun, Solaris, Java, and other trademarks
containing Java
Trademarks of Sun Microsystems, Inc., in the
U.S.A. and other countries
UNIX Registered trademark in the U.S.A. and other
countries, licensed exclusively through X/Open
Company Ltd.
Netscape, Netscape FastT rack Server,
Netscape Enterprise Server , and Netscape
Navigator
CORBA, Object Management Group, OMG,
OMG IDL, IIOP, Object Request Broker, and
ORB
Registered trademarks of Netscape
Communications Corporation in the U.S.A. and
other countries
Trademarks or registered trademarks of Object
Management Group Inc. in the U.S.A. and other
countries
Interstage and ObjectDirector Registered trademarks of Fujitsu Limited
This document contains technology relating to strategic products controlled by export
control laws of the producing and/ or exporting countries. This document or a portion
thereof should not be exported (or re-exported) without authorization from the
appropriate government authorities in accordance with such laws.
Fujitsu Limited
First Edition (November 2003)
The contents of this manual may be revised without prior notice.
All Rights Reserved, Copyright © FUJITSU LIMITED 2003
ii
Preface
Purpose of this Document
This manual provides additional information on the use of Interstage Application Server
Note
Throughout this manual Interstage Application Server is referred to as Interstage.
Who Should Read this Document?
This document is intended for users installing and operating Interstage Application Server.
It is assumed that readers of this manual have a basic knowledge of:
• The Internet
• Apache
• Windows NT® ,Windows® 2000 and Windows 2003™ Server
• UNIX
• Linux
iii
Product Notes - Preface
Organization of this Document
This document is organized as follows:
• Chapter 1 - Supported Software
This chapter describes the supported software for application development and application
execution. It also describes the client-side software products required to use client applications.
• Chapter 2 - Restrictions
This chapter describes the restrictions on some Interstage functions.
• Chapter 3 - Notes on Interstage Operation
This chapter provides notes about the operation of Interstage.
Functions that are not Supported by the Linux Version
The following functions are not supported by the Linux version. To use those functions, use the
Windows version or Solaris™ Operating Environment version.
• Multi System (available only in the Solaris™ Operating Environment version)
• Cluster System
• Web Server (InfoProvider Pro)
• HTML Page Editing Service
• ebXML Message Service
• MessageQueueDirector
• MQ Communication Service
• InfoDirectory
• COBOL Web Subroutine
• COBOL/OOCOBOL development and execution environment (available on the Windows client)
• Firewall linkage function (proxy linkage and HTTP tunneling) and SSL linkage function of CORBA
applications
• SMEE2 library (The SMEE3 library is available.)
• Online access management function
• Performance monitoring tool (real-time monitoring function of performance information)
• User authentication and access control of the Component Transaction Service
• AIM linkage function
iv
Table of Content s
Chapter 1 Supported Software
Software Products Required for Application Development.............................................................1-2
J2EE (Exclude Security)............................................................................................................1-2
Security......................................................................................................................................1-3
Operation / Administration.........................................................................................................1-4
Framework.................................................................................................................................1-5
Other Functions .........................................................................................................................1-5
Software Products Required for Application Execution..................................................................1-7
J2EE (Exclude Security)............................................................................................................1-7
Security......................................................................................................................................1-8
Operation / Administration.........................................................................................................1-8
Framework...............................................................................................................................1-10
Portal Component....................................................................................................................1-10
Other Functions .......................................................................................................................1-11
Client-side Software Products Required to Use Client Applications.............................................1-12
J2EE (Exclude Security)..........................................................................................................1-12
Security....................................................................................................................................1-13
Framework...............................................................................................................................1-13
Other Functions .......................................................................................................................1-14
Chapter 2 Restrictions
Restrictions on Interstage HTTP Server.........................................................................................2-2
Restrictions on InfoProvider Pro.....................................................................................................2-3
Restrictions on the J2EE Service ...................................................................................................2-4
Restrictions on the Servlet Service.................................................................................................2-5
Restrictions on the EJB Service .....................................................................................................2-6
Restrictions on the SOAP Service................................................................................................2-11
Restrictions on the CORBA Service.............................................................................................2-13
Restrictions on IDL Definitions.................................................................................................2-13
Restrictions on IDL Compilation ..............................................................................................2-17
Restrictions on C and C++ Programming................................................................................2-17
v
Product Notes - Table of Contents
Restrictions on Java Programming..........................................................................................2-18
Restrictions on the Naming Service.........................................................................................2-18
Restrictions on the CORBA Service........................................................................................2-19
Restrictions on the Event Service.................................................................................................2-20
Restrictions on the Component Transaction Service....................................................................2-21
Restrictions on the Database Linkage Service.............................................................................2-22
Restrictions on the Locale of Languages ................................................................................2-22
Restrictions on InfoDirectory.........................................................................................................2-23
Restrictions on the InfoDirectory Administration Tool..............................................................2-23
Restrictions on the JNDI..........................................................................................................2-23
Restrictions on JDK/JRE...............................................................................................................2-24
Restrictions on the Portal Component..........................................................................................2-25
Restrictions on Scripts in Contents..........................................................................................2-25
Restrictions on the Alternative Logon Function.......................................................................2-26
Restrictions on the Load Distribution Environment..................................................................2-27
Restrictions on Using Netscape 4.6/4.7...................................................................................2-27
Restrictions on Using Web USP (List of URLs to be Excluded With Form Authentication
Inherited)..................................................................................................................................2-28
Access from PC to Secure Site (HTTPS)................................................................................2-28
Restrictions on Using the Brick Automatic Update Function...................................................2-28
Restrictions on Other Functions....................................................................................................2-29
Chapter 3 Notes on Interstage Operation
Common Notes for Interstage.........................................................................................................3-2
About Netscape 6 ......................................................................................................................3-2
About the Cross-Site Scripting Problem....................................................................................3-2
Using the JSSE Function...........................................................................................................3-3
Monitor Screen Colors...............................................................................................................3-4
Setting Port Numbers Used for Individual Services...................................................................3-5
Notes on the Interstage Operation Tool ..........................................................................................3-9
Version Level of Each Service Performing the Operation.........................................................3-9
Notes on the Interstage Integration Commands...........................................................................3-10
Dealing with Abnormal Command Termination........................................................................3-10
Starting and Stopping Services................................................................................................3-10
Note on Stopping Interstage....................................................................................................3-10
Notes on the InfoProvider Pro.......................................................................................................3-11
Notes on the Interstage HTTP Server...........................................................................................3-12
Authority to Use the Interstage HTTP Server..........................................................................3-12
vi
Product Notes - Table of Contents
Notes on Operating Interstage HTTP Server ..........................................................................3-12
Notes on J2EE..............................................................................................................................3-13
Notes on the Servlet Service ........................................................................................................3-15
Notes on Using the EJB Service...................................................................................................3-16
Version of Java Development Kit/Java Runtime Environment................................................3-16
Notes on the EJB Customize Tool...........................................................................................3-16
When Operating with WorkUnits..............................................................................................3-18
When Interstage JDBC Driver is Used....................................................................................3-19
Note on Class Names..............................................................................................................3-22
Starting EJB Applications.........................................................................................................3-22
About the EJB Application Process.........................................................................................3-22
Notes on SOAP Service................................................................................................................3-23
When Encryption Communication by SSL is Used..................................................................3-23
When Session Recovery Function of Servlet Service is Used................................................3-23
When J2EE Management Tool or J2EE Deployment Tool is Used.........................................3-23
Notes on the CORBA Service.......................................................................................................3-24
Notes on Installation and Environment Settings......................................................................3-24
Notes about Setting Applications.............................................................................................3-25
Notes on the IDL Compiler ......................................................................................................3-26
Notes on the Java Environment...............................................................................................3-26
Notes on SSL communication .................................................................................................3-26
Notes on the Event Service ..........................................................................................................3-27
Note on Reinitializing Interstage..............................................................................................3-27
Notes on SSL Communication.................................................................................................3-27
Note on Unit Generation..........................................................................................................3-27
Note on Persistent Channel Applications ................................................................................3-28
Notes on Multi-IP Address Operation ......................................................................................3-28
Notes on the Component Transaction Service.............................................................................3-29
Note on Messages in Windows® 2000 ...................................................................................3-29
About CORBA Service Termination using the isstop Command.............................................3-29
Monitoring during Interstage Operation...................................................................................3-29
Notes on the Database Linkage Service......................................................................................3-30
Notes on OTS Command Execution .......................................................................................3-30
Notes on the Use of Oracle .....................................................................................................3-30
Notes on Development using Functions for the Java Language Provided by the Database
Linkage Service of Interstage 1.1 or Earlier ............................................................................3-31
Maximum Number of Resources for One Transaction............................................................3-31
Sample Provided with Database Linkage Service...................................................................3-31
CORBA Server Application is Operated using Multi Thread....................................................3-31
vii
Product Notes - Table of Contents
Notes on InfoDirectory ..................................................................................................................3-32
Setup Item Related to the Maximum Simultaneous Number of Clients Connected................3-32
Error Messages in the Event Log ............................................................................................3-32
Notes on JDK/JRE........................................................................................................................3-33
Notes on Java VM....................................................................................................................3-33
Notes on OutOfMemoryError Caused by a Permanent Area Shortage...................................3-33
Notes on java.lang.Object.wait()..............................................................................................3-33
Notes on the Return Value of java.beans.PropertyDescriptor.getWriteMethod()....................3-34
Notes on Portal Component..........................................................................................................3-35
Notes on Contents Use............................................................................................................3-35
Notes at Logon.........................................................................................................................3-35
Notes on Portal Component Server Operating Mode..............................................................3-35
Notes on USP Use...................................................................................................................3-37
Notes on Web USP Use.....................................................................................................3-37
Notes on Web To Host USP(S2K USP) Use ......................................................................3-37
Notes when Applying Port al Component Independent Authentication to Operation
Management............................................................................................................................3-37
Notes on Using Operation Management Tool Commands......................................................3-38
Notes on Portal Component Repository Database Operation.................................................3-38
About the Specification of Keep-alive between WebUSP and Back Server............................3-38
Notes when Using a Long Character String for Alias ..............................................................3-38
Notes on Using Administrative Console ..................................................................................3-39
Setting the Heap Size in the Java Execution Environment .....................................................3-39
Notes on Framework.....................................................................................................................3-40
Security on the Internet............................................................................................................3-40
Redistributable Files ................................................................................................................3-40
Index
viii
Chapter 1 Supported Software
This chapter describes the supported software.
1-1
Chapter 1: Supported Software
Software Products Required for Application Development
This section describes software products required for application development.
J2EE (Exclude Security)
Table 1-1 lists the J2EE (exclude security) products required for application development.
Table 1-1 J2EE (Exclude Security) Products Required for Application Development
No. Function Name Product Name Version
1 Development of J2EE
applications (*1)
2 Development of EJB applications
using databases.
*1) JDK1.1 and JDK1.2 are not applicable.
Any of
Interstage Apworks (*2)
Interstage Application Server Plus
Developer
SymfoWARE® Server Enterprise
Edition for Windows
Oracle8i Enterprise Edition R8.1.5 (*3)
Oracle9i Database Enterprise
Edition
SQL Server 2000 (*3)
V5.0 or later
V5.0.1 or later
V5.0 or later (*3)
R8.1.6 (*3)
R8.1.7 (*3)
Release1 (9.0.1) (*3)
1-2
*2) If the JSP remote debug function is to be used, the version of the Servlet service must match the
version of Apworks. For this reason, use V6.0.
*3) SymfoWARE Server Enterprise Edition or Oracle8i Enterprise Edition or Oracle9i Database
Enterprise Edition is required.
Use the JDBC driver for JDK 1.2 when you use Symfoware Server Enterprise Edition and
Symfoware Server. Moreover, the JDBC driver for JDK1.2 can use the version of JDK/JRE by 1.2
or later. Do not download it though it is described, “The JNDI class library (jndi package) and
JDBC2.0 Optional Package (javax.sql package) can be downloaded from the homepage of
Javasoft of SUN Microsystems” in JDBC driver online manual of Symfoware when the JDBC driver
for JDK1.2 is used.
Security
Table 1-2 lists the security products required for application development.
Table 1-2 Security Products Required for Application Development
Software Products Required for Application Development
Use the product since V4.0L10 when you use either Symfoware Server Enterprise Edition or
Symfoware Server when you use the Symfoware with RDB2_TCP.
When the decentralized transaction function by JTS and JT A is used, Oracle8i Enterprise Edition
R8.1.7 or Oracle 9i Database Enterprise Edition is required.
Use the Interstage JDBC Driver included while packaging the EJB Service when you use SQL
Server. Refer to the associated software manual when using it. The software manual is in the
following place.
Interstage installation folder\EJB\jdbc\fjisjdbc.txt
Interstage JDBC Driver can be used only with JDK/JRE1.3.
Install the SQL Server client tool in the execution environment of Interstage JDBC Driver when the
installation environment of the execution environment of Interstage JDBC Driver and SQL Server is
different.
No. Function Name Product Name Version
1 SSL communication function of
Systemwalker PkiMGR (*1) V1.0
CORBA Service
*1) It is required on the server issuing certification. It is not required when you acquire certification
from Certificate issue organization.
At the time of UTF-8 certificate creation, Systemwalker PkiMGR is required.
1-3
Chapter 1: Supported Software
Operation / Administration
Table 1-3 lists the operation/administration products required for application development.
Table 1-3 Operation/Administration Products Required for Application Development
No. Function Name Product Name Version
1 Real-time monitoring by
performance monitoring tool and
operation management linked to
Systemwalker CentricMGR V5.0L20 or V5.0L30 or
later
(*1)
Systemwalker
2 Automatic operation linked to
Systemwalker
Systemwalker OperationMGR V5.0L20 or V5.0L30 or
later
(*2)
3 Interstage Operation Tool Microsoft® Internet Explorer
or
Netscape® Communicator
4 Real-time monitoring function of
SNMP service Windows NT® 4.0
performance information by the
Network Manager
5.01, 5.5, or 6.0
6 Series or 7 Series
Windows® 2000
(*3)
*1) If the version level of Systemwalker CentricMGR to be linked is V5.0L20, the following functions
cannot be used:
− Operation status monitoring of the EJB WorkUnit (for old version compatible environment)
− Displaying information on the multi object-resident objects
− Real-time monitoring of the application processing status
1-4
If the version level of Systemwalker CentricMGR is V10L10 or earlier, the following functions
cannot be used:
− Monitoring of the CORBA WorkUnit operating status
− Monitoring of the Servlet container unit operating status (old version Servlet service)
− Real-time monitoring of the application processing status for the Implementation Repository of
the CORBA WorkUnit
− Real-time monitoring of the EJB application processing status of the EJB WorkUnit (for old
version compatible environment)
− Information display of EJB applications on the Light EJB container (for old version compatible
environment)
− Operating status monitoring of the Light EJB container (for old version compatible
environment)
*2) If the version level of Systemwalker OperationMGR to be linked is V5.0L20, the EJB WorkUnit (for
old version compatible environment) cannot be operated automatically.
The following functions also cannot be used if the version level of Systemwalker OperationMGR is
V10.0L10 or earlier.
− Automatic operation of the CORBA WorkUnit
− Automatic operation of the Light EJB container WorkUnit (for old version compatible
*3) The SNMP Service is a function provided by the operating system.
Framework
Table 1-4 lists the framework products required for application development.
Table 1-4 Framework Products Required for Application Development
No. Function Name Product Name Version
Software Products Required for Application Development
environment)
1 Using database linkage
components of the Framework
function
2 Using XML linkage function of the
Framework function
3 Using Struts linkage function of
the Framework function
Other Functions
Table 1-5 lists the products required for application development (other functions).
Table 1-5 Products Required for Application Development (Other Functions)
No. Function Name Product Name Version
1 Development of applications of
the SOAP Service
Oracle Database Enterprise
Edition / Standard Edition
Symfoware Server Enterprise
Edition
Fujitsu XML Processor
- Fujitsu XML Library for Java
- Fujitsu XSLT Library for Java
Struts 1.1
Interstage Apworks or
Interstage Application Server Plus
Developer (*1)
Release1(9.0.1) or
Release2(9.2.0)
V5.0
V5.1.1
V6.0
2 Development of applications
using UDDI client
Interstage Apworks or
Interstage Application Server Plus
Developer (*1)
V6.0
1-5
Chapter 1: Supported Software
No. Function Name Product Name Version
3 Use of databases
Symfoware® Server Enterprise
Edition for Windows
V2.0L10 or later
edition
Oracle7 R7.3.4 (*2)
Oracle8 Enterprise Edition R8.0.5 (*2)
Oracle8i Enterprise Edition R8.1.5 or R8.1.6 (*2)
R8.1.7
Oracle9i Database Enterprise
Release1 (9.0.1)
Edition
SQL Server 6.5 or 7.0
4 Development of applications
Microsoft® Visual C++ 5.0, 6.0, .NET
using LDAP SDK
5 Directory service (Only when you
Netscape Enterprise Server 3.5
use Netscape Enterprise Server
as WWW server)
*1) JDK1.1 and JDK1.2 are not supported.
*2) At the time of using SynfinityCLUSTER, it is required Symfoware Server Enterprise Edition V2.0L10
or later.
At the time of using JTS or JTA, Oracle Database Enterprise Edition R8.1.7, R9.0.1 or R9.2.0 is
required.
1-6
Software Products Required for Application Execution
Software Products Required for Application
Execution
This section describes software products required for application execution.
J2EE (Exclude Security)
Table 1-6 lists the J2EE (exclude security) products required for application execution.
Table 1-6 J2EE (Exclude Security) Products Required for Application Execution
No. Function Name Product Name Version
1 Employment of the application which
uses a database
2 J2EE Management Tool Microsoft Internet Explorer®
3 Old version Servlet Service (Only
when Microsoft Internet Information
Server or Microsoft Internet
Information Services is used as the
Web server)
*1) Oracle8i Enterprise Edition or Oracle9i Database Enterprise Edition or SQL Server is required.
When the decentralized transaction function by JTS and JT A is used, Oracle8i Enterprise Edition
R8.1.7 or Oracle9i Database Enterprise Edition is essential.
Use Interstage JDBC Driver included while packaging the EJB Service when you use SQL Server.
Refer to the associated software manual when using it. The software manual is in the following
place.
Interstage installation folder\EJB\jdbc\fjisjdbc.txt
Oracle8i Enterprise Edition R8.1.5 (*1) (*2)
Oracle8i Enterprise Edition R8.1.6 (*1) (*2)
R8.1.7 (*1) (*2)
Oracle 9i Database Enterprise
Edition
SQL Server 6.5 or 7.0 (*1)
Netscape® Communicator
Microsoft Internet Information
Server
Microsoft Internet Information
Services
Release1 (9.0.1)
(*1) (*2)
5.01, 5.5, 6.0
4.7 type (*3)
4.0
5.0 (*4)
Interstage JDBC Driver can be used only with JDK/JRE1.3.
Install the SQL Server client tool in the execution environment of Interstage JDBC Driver when the
installation environment of the execution environment of Interstage JDBC Driver and SQL Server is
different.
*2) When JDBC2.X of Oracle8i Enterprise Edition R8.1.6 or R8.17 or Oracle9i Database Enterprise
Edition is used, download File System Service Provider 1.2 from the JavaSoft
site(http://www.javasoft.com/). The file name as of June 8, 2001 is fscontext1_2beta3.zip, however
note that this may be changed without notice. When the downloaded files are decompressed, the
following files are restored:
1-7
Chapter 1: Supported Software
− providerutil.jar
− fscontext.jar
*3) If Netscape 4.7 type is used, a screen display error may occur .
*4) Microsoft Internet Information Services 6.0 or later cannot be used.
Security
Table 1-7 lists the security products required for application execution.
Table 1-7 Security Products Required for Application Execution
No. Function Name Product Name Version
1 SSL communication function of
Web Server , CORBA Service,
Portable-ORB and J2EE.
*1) It is required on the server issuing certification. It is not required when you acquire certification
from Certificate issue organization.
At the time of UTF-8 certificate creation, Systemwalker PkiMGR is required.
Operation / Administration
Table 1-8 lists the operation/administration products required for application execution.
Table 1-8 Operation/Administration Products Required for Application Execution
No. Function Name Product Name Version
1 Real-time monitoring by
performance monitoring tool and
operation management linked to
Systemwalker
2 Automatic operation linked to
Systemwalker
Systemwalker PkiMGR (*1) V1.0
Systemwalker CentricMGR V5.0L20 or V5.0L30 or
later
(*1)
Systemwalker OperationMGR V5.0L20 or V5.0L30 or
later
(*2)
1-8
3 Interstage Operation Tool Microsoft® Internet Explorer
or
Netscape® Communicator
4 Real-time monitoring function of
SNMP service Windows NT® 4.0
performance information by the
Network Manager
5.01, 5.5, or 6.0
6 Series or 7 Series
Windows® 2000
(*3)
Software Products Required for Application Execution
*1) If the version level of Systemwalker CentricMGR to be linked is V5.0L20, the following functions
cannot be used:
− Operation status monitoring of the EJB WorkUnit (for old version compatible environment)
− Displaying information on the multi object-resident objects
− Real-time monitoring of the application processing status
If the version level of Systemwalker CentricMGR is V10L10 or earlier, the following functions
cannot be used:
− Monitoring of the CORBA WorkUnit operating status
− Monitoring of the Servlet container unit operating status (old version Servlet service)
− Real-time monitoring of the application processing status for the Implementation Repository of
the CORBA WorkUnit
− Real-time monitoring of the EJB application processing status of the EJB WorkUnit (for old
version compatible environment)
− Information display of EJB applications on the Light EJB container (for old version compatible
environment)
− Operating status monitoring of the Light EJB container (for old version compatible
environment)
*2) If the version level of Systemwalker OperationMGR to be linked is V5.0L20, the EJB WorkUnit (for
old version compatible environment) cannot be operated automatically.
The following functions also cannot be used if the version level of Systemwalker OperationMGR is
V10.0L10 or earlier.
− Automatic operation of the CORBA WorkUnit
− Automatic operation of the Light EJB container WorkUnit (for old version compatible
environment)
*3) The SNMP Service is a function provided by the operating system.
1-9
Chapter 1: Supported Software
Framework
Table 1-9 lists the framework products required for application execution.
Table 1-9 Framework Products Required for Application Execution
No. Function Name Product Name Version
1 Using database linkage
components of the framework
function
2 Using XML linkage function of the
framework function
3 Using Struts linkage function of
the framework function
Portal Component
Table 1-10 lists the Portal component products required for application execution.
Table 1-10 Portal Component Products Required for Application Execution
No Function Name Product Name Version
1 Directory server (*1)
Oracle Database Enterprise
Edition / Standard Edition
Symfoware Server Enterprise
Release1(9.0.1), or
Release2(9.2.0)
V5.0
Edition
Fujitsu XML Processor
V5.1.1
- Fujitsu XML Library for Java
- Fujitsu XSLT Library for Java
Struts 1.1
InfoDirectory The LDAP system
enclosed by Interstage
Application Server V6.0
or V1.2L10
1-10
Netscape Directory Server Ver.3.11 (supported only
by Windows NT®)
Interstage HTTP Server V6.0 2 Web Server
Microsoft Internet Information Server 4.0/5.0
Oracle8i Enterprise Edition R8.1.6/R8.1.7 3 RDBMS for repository (*2)
Oracle9i database enterprise edition Release1(9.0.1)
Release2(9.0.2)
4 Web browser(Administrative
Microsoft Internet Explorer 5.5/6.0
Console)
Microsoft Internet Explorer 5.0/5.01/5.5/6.0 5 Web browser(User Page)
Netscape Navigator 4.6/4.7
*1) To use LDAP as an authentication system, it is necessary to install an LDAP system and to register
its users. For more details, refer to the manual for your LDAP product.
*2) It is possible to change the repository (Fujitsu Enabler) of the Portal component installed by default
to RDB by using the repository change command immediately after installation. For more details,
refer to the Portalworks Administration Guide.
Other Functions
Table 1-11 lists the products required for application execution (other functions).
Table 1-11 Products Required for Application Execution (Other Functions)
No. Function Name Product Name Version
Software Products Required for Application Execution
1 Directory Service (Only when
Netscape Enterprise Server is the
WWW server)
2 Use of Databases
(Excluding EJB application)
Netscape Enterprise Server 3.5
Symfoware Server Enterprise
V1.2L11 or later
Edition
Oracle7 R7.3.4
Oracle8 Enterprise Edition R8.0.5
Oracle8i Enterprise Edition R8.1.5
Oracle8i Enterprise Edition R8.1.6
R8.1.7
Oracle 9i Database Enterprise
Release1 (9.0.1)
Edition
SQL Server 6.5 or 7.0
1-11
Chapter 1: Supported Software
Client-side Software Products Required to Use Client Applications
This section describes the client-side software products required to use client applications.
J2EE (Exclude Security)
Table 1-12 lists the J2EE (Exclude Security) client-side software products required to use client
applications.
Table 1-12 J2EE (Exclude Security) Client-side Software Required to Use Client Applications
No Function Name Product Name Version
1 Java application of EJB Service
(including Java applet)
2 Java applet of EJB Service (*2) (*3)
3 Operation of J2EE application clients
using JNDI, JMS, JavaMail.
*1) This product is required when a Java application (including a Java applet) of the EJB service is
created.
*2) To operate Java applets, the following formats are available:
− Format to download the Portable-ORB and EJB Service client from the WWW server:
The jar file (fjcontainer32_plugin.jar) for the Portable-ORB and the client of the EJB Service
must first be installed (resource must be stored) in the WWW server.
The JBK plugin provided by "J Business Kit," a component of Apworks V6.0L10, is required.
The Apworks download installer must be installed in advance.
Interstage Apworks Server
Runtime Package (*1)
Netscape Communicator 4.06, 4.07, 4.08, 4.5,
Microsoft Internet Explorer 4.01, 5.0, 5.01 or 5.5
Interstage Apworks Server
Runtime Package (*5)
V5.0 or later
4.51, 4.6, 4.7, 4.72,
4.73 or 4.75
(*4)
V5.0 or later
1-12
− Format to install the CORBA Service client and EJB Service client:
The CORBA Service client and EJB Service client must first be inst alled in the client.
If installation is performed without selecting JBK in custom installation mode, the JBK plugin
must be installed in advance.
*3) As the Web browser , either Netscape Communicator or Microsoft Internet Explorer is required.
*4) Service Pack 1 or Service Pack 2 is necessary for Microsoft Internet Explorer 4.01. Also, Software
*5) JDK1.1 and JDK1.2 are not supported.
Security
Table 1-13 lists the security client-side software products required to use client applications.
Table 1-13 Security Client-side Software Required to Use Client Applications
No Function Name Product Name Version
Client-side Software Products Required to Use Client Applications
Development Kit for Java V4.0 is necessary for creating cab files used in Microsoft Internet
Explorer.
Netscape Communicator 4.7 1 Encrypted communication with 128bit
Framework
Table 1-14 lists the framework client-side software products required to use client applications.
Table 1-14 Framework Client-side Software Required to Use Client Applications
No Function Name Product Name Version
application using Framework
2 Client (Macintosh®) for the web
application using Framework
Framework function
Microsoft Internet Explorer
5.01
and high reliability pack
(128bit)
Microsoft Internet Explorer 5.x or 6.0 1 Client (Windows®) for the web
Netscape Communicator 4.7x
Microsoft Internet Explorer 5.1 for Mac (OS8.1
9.x) or
5.2 for Mac (OS X)
Netscape 7.1 (Mac OS X)
Safari 1.0
Interstage Application Server
- 3 Using Applet linkage function of the
Plus V6.0
Interstage Application Server
Plus Developer V6.0
Java Plug-in 1.3.1, 1.4.1, 1.4.2
1-13
Chapter 1: Supported Software
Other Functions
Table 1-15 lists the client-side software products required to use client applications (other functions).
Table 1-15 Client-side Software Required to Use Client Applications (Other Functions)
No Function Name Product Name Version
1 WWW Server Linkage
Netscape Communicator 4.0, 4.01, 4.02, 4.03,
Microsoft Internet Explorer 4.0, 5.0, 5.01 or 5.5
2 SOAP Service client
INTERST AGE APWORKS
Client Runtime package
Interstage Apworks Client
Runtime Package
INTERSTAGE Java Server
package (*2)
Interstage Java Server
package (*3)
JCE (Java Cryptography
Extension) (*4)
3 Using the UDDI client INTERSTAGE APWORKS
Client Runtime package (*5)
4 Using the InfoDirectory web connector
Netscape Navigator 4.7, 4.73, 4.75
4.04, 4.05, 4.06, 4.07,
4.08, 4.5, 4.51, 4.6 or
4.7
(*1)
V4.1 or later
V5.0
V4.1 or later
V5.0 or later
1.2.2
V5.0
1-14
Netscape Communicator 4.7, 4.72, 4.73, 4.75,
4.76, 4.78
Netscape 6.0, 6.1, 6.2
Microsoft Internet Explorer 5.01, 5.5, 6.0
*1) Service Pack 1 or Service Pack 2 is necessary for Microsoft Internet Explorer 4.01. Also, Software
Development Kit for Java V4.0 is necessary for creating cab files used in Microsoft Internet
Explorer.
*2) Use the functions corresponding to the APWORKS Client Runtime Package in the Interstage Java
Server Package. For details of the functions corresponding to the APWORKS Client Runtime
Package in the Interstage Java Server Package, refer to Section 4.6 Download Installer in
\DATA4\READMEAP.TXT on the Interstage Java Server Package CD-ROM.
*3) When using the remote installation function of the EJB Deployment tool, the Interstage Operation
Tool needs to be installed on the server for installation.
*4) Required when password management function for client authentication of SSL communication of
SOAP Service client side is used.
*5) JDK1.1 and JDK1.2 are not supported.
Chapter 2 Restrictions
Some functions described in this manual have restrictions. The following tables detail these restrictions.
2-1
Chapter 2: Restrictions
Restrictions on Interstage HTTP Server
Table 2-1 Restrictions on Interstage HTTP Server
No. Restriction Remarks Date of
Removal
1 When a certificate in UTF-8 format,
(such as a CA certificate, site certificate,
or client certificate) is used for SSL
communication, the following restrictions
apply:
- When SSL protocol Version 3 (client
certificate) is used, the CA certificate
and the client certificate in UTF-8 must
be registered on both the Interstage
HTTP Server and the web browser.
- When SSL protocol Version 2 (server
authentication) is used, the CA
certificate and the client certificate in
UTF-8 must be registered on both the
Interstage HTTP Server and the web
browser.
- If Interstage HTTP Server is started in
either of the above SSL versions, normal
access is available only via Internet
Explorer 5.5 or 6.0 on Windows® 2000.
None Not
determined
2-2
Restrictions on InfoProvider Pro
Table 2-2 Restrictions on InfoProvider Pro
No. Restriction Remarks Date of
Restrictions on InfoProvider Pro
Removal
1 When a certificate in UTF-8 format,
(such as a CA certificate, site certificate
or client certificate) is used for SSL
communication, the following restrictions
apply:
- When SSL protocol Version 3 (client
certificate) is used, the CA certificate
and the client certificate in UTF-8 must
be registered on both InfoProvider Pro
and the web browser.
- When SSL protocol Version 2 (server
authentication) is used, the CA
certificate and the client certificate in
UTF-8 must be registered on both
InfoProvider Pro and the web browser.
- If InfoProvider Pro is started in either
of the above SSL versions, normal
access is available only via Internet
Explorer 5.5 or 6.0 on Windows® 2000.
None Not
determined
2-3
Chapter 2: Restrictions
Restrictions on the J2EE Service
Table 2-3 Restrictions on the J2EE Service
No. Restriction Remarks Date of
Removal
1 If the EAR file is opened using the J2EE
Deployment tool and the Application
Display Name of the application is
changed, some contents such as class
files may not be displayed in the
General contents of the Web
application.
2 When the J2EE Deployment tool is
used, a save confirmation dialog box
appears before closing a file. If the
Close button on the title bar of the
window is used, or if Close is selected
from the window menu, the operation is
the same as if No was selected. (Note
that the operation in this case is not the
same as if Cancel was selected!)
3 When the J2EE Deployment tool is used
with JDK/JRE1.3, the details of the file
cannot be displayed on the File
selection or Directory selection screen.
4 The remote installation function of the
EJB Deployment tool cannot be used if
the installation destination machine is a
cluster system.
None.
The files can be saved or
deployed even if they are not
displayed.
Select the Cancel button. Not
None. Not
Transfer the server distribution
generated with the EJB
Deployment tool to the operation
destination machine and install it
with the ejbinstalleb command.
For details on the ejbinstalleb
command, see Chapter 5
ejbinstalleb in the Reference
Manual (Command Edition).
Not
determined
determined
determined
Not
determined
2-4
5 It is not possible to access the database
directly from a J2EE application client
and a Web application while using the
global transaction with the JTA interface.
6 Interstage cannot be stopped forcibly
(the isstop command cannot be
executed by specifying option -f) with
the J2EE Deployment tool activated.
When the global transaction is
used with the JTA interface, be
sure to access the database from
an EJB application.
Stop the J2EE Deployment tool
and then forcibly stop Interstage
(execute the isstop command by
specifying option -f).
Not
determined
Not
determined
Restrictions on the Servlet Service
Table 2-4 Restrictions on the Servlet Service
No. Restriction Remarks Date of
Restrictions on the Servlet Service
Removal
1 When Apworks is used for remote debugging, the
following may occur:
When a Servlet service or servlet container is
stopped, the following message is output to standard
output or the standard input-output log file of the
servlet container:
"Internal debug-agent exception"
2 The following phenomenon may occur when
performing a remote debug using Apworks:
- The Servlet service may end abnormally if
JDK1.3(Java 2 Classic VM, JPDA) is used and the
debug of Apworks is st arted before the Servlet
service is started.
Ignore this message. Not
determined
Start the debug of
Apworks after
starting the Servlet
service.
Not
determined
2-5
Chapter 2: Restrictions
Restrictions on the EJB Service
Table 2-5 Restrictions on the EJB Service
No. Restriction Remarks Date of
Removal
1 The long type data type cannot be used as an argument
or return value for the client/server communication.
2 In JDK/JRE 1.2.2, any class in which String data of 64
KB or more is set to one variable in the class cannot be
used as an argument or return value for EJB
applications.
3 In the client/server communication in JDK/JRE1.2.2,
when the interface shown below is used in business
method parameters and return value, the method for the
stored interface type cannot be issued. This is the case,
even if the interface type that can be communicated in
the application execution by the RMI over IIOP was
stored in that interface.
- java.util.Collection
- java.util.Enumeration
4 When defining a Bean in the Rapid invoking Bean, if it
uses JDK/JRE1.2.2, the return value cannot use the
finder method of java.util.Enumeration or
java.util.Collection.
5 Using "remove" as a business method name may lead
to unexpected results.
6 When distributed transactions are used, if any of the
following methods from the javax.ejb.EJBContext API
are called from some particular methods, an
IllegalStateException will be thrown.
None Not
determined
None Not
determined
None Not
determined
None Not
determined
None Not
determined
None Not
determined
2-6
- getCallerIdentity()
- getCallerPrincipal()
- isCallerInRole(Identity role)
- isCallerInRole(String roleName)
If any of the above methods are called from one of the
following methods, an exception will be thrown.
- For STATEFUL Session Bean
beforeCompletion
afterCompletion
- For Entity Bean
ejbStore
Restrictions on the EJB Service
No. Restriction Remarks Date of
Removal
7 If any of the above methods are called from one of the
following methods, an exception will be thrown.
- getCallerIdentity()
- getCallerPrincipal()
- isCallerInRole(Identity role)
- isCallerInRole(String roleName)
If any of the above methods are called from one of the
following methods, an exception will be thrown.
- For STATEFUL Session Bean
ejbRemove
8 In the following cases, invoking a method that has
method permission setting from an EJB application
method, a RemoteException is thrown.
- When the distributed transaction function is used
[STATEFUL Session Bean]
beforeCompletion
[Entity Bean]
ejbStore
- When the Session Timeout function is used
[STATEFUL Session Bean]
ejbRemove
None Not
determined
None Not
determined
9 If "Application" is specified in the resource connector of
the deployment descriptor file, and a JDBC resource is
being accessed from an EJB application method, an
SQLException is thrown in the following cases.
- When the distributed transaction function is used
[STATEFUL Session Bean]
beforeCompletion
[Entity Bean]
ejbStore
- When the Session Timeout function is used
[STATEFUL Session Bean]
ejbRemove
10 If "Application" is specified in the resource connector of
the deployment descriptor file, and a JDBC resource is
being accessed from an EJB application method, an
SQLException is thrown in some cases.
11 If distributed transactions are used and the Snap output
level is set to "2", an ORA-01002 error in Oracle may be
thrown.
None Not
determined
None Not
determined
None Not
determined
2-7
Chapter 2: Restrictions
No. Restriction Remarks Date of
Removal
12 Currently (May 2002), no database supports JDK1.4,
and therefore, no database can be accessed from EJB
when JDK1.4 is used.
13 When the user snap function is used with JDK1.4, the
log information of the product in which the
java.util.Logging package is installed may be output to
the EJB snap file.
14 The EJB application that implements both Local and
Remote interfaces cannot be used. It becomes an error
at the startup when it is used.
15 CDATA section cannot be described in deployment
descriptor. CDATA section will be deleted when it is
described and then executed the deployment.
16 Distributed Transaction in CMP2.0 cannot be used. It
causes EJB1248 error at the startup when it is used.
17 When the following API of javax.ejb.SessionContext is
executed in a specific method of EJB application that
implements the Local interface, it returns Null.
None. Not
determined
None. Not
determined
Calling of an
Entity Bean
Not
determined
outside the
process is not
recommended.
Therefore, use
the Local
interface instead.
None. Not
determined
None. Not
determined
None. Not
determined
[getEJBLocalObject]
When this method is executed, the following method
returns Null.
[In case of STATEFUL Session Bean or STATELESS
Session Bean]
- ejbCreate
2-8
Restrictions on the EJB Service
No. Restriction Remarks Date of
Removal
18 In a specific method of the EJB application that
implements both Local and Remote interfaces, the
following API of javax.ejb.SessionContext or
javax.ejb.EntityContext is executed, it returns Null.
[getEJBLocalObject]
When this method is executed, the following methods
return Null.
[In case of STATEFUL Session Bean]
- ejbCreate
- afterBegin
- beforeCompletion
- afterCompletion
- bisiness method
- ejbRemove
[In case of STATELESS Session Bean]
- ejbCreate
- bisiness method
- ejbRemove
None. Not
determined
[In case of CMP2.0 Entity Bean]
- ejbRemove
19 In a specific method of the EJB application that
implements both Local and Remote interfaces, when the
None. Not
determined
getEJBHome method is issued to the EJB object got by
getEJBObject of SessionContext, it returns
RemoteException. When the above method is
executed, the following methods cause an exception.
[In case of STATELESS Session Bean]
- ejbCreate
- ejbRemove
20 When the lookup via Remote interface is done in the
EJB application that implements both Local and Remote
See Note 1 below Not
determined
interfaces from the same EJB application,
java.lang.ClassCastException occurs.
Note 1
When the lookup via LocalHome and Home interface is done in the EJB application that implements
both Local and Remote interfaces from the same EJB application, the following works are necessary for
the EJB application development and its runtime operation.
2-9
Chapter 2: Restrictions
[EJB application development]
1. Deployment Edit descriptor
Edit not to duplicate EnterpriseBean reference name for “ejb-ref-name” in the “reference EJB tag”
or“reference LocalEJB tag”.
2. Development of EJB applicationDescribe not to duplicate the EJB application name specified for
the argument at lookup via LocalHome interface and via Home interface. Describe EJB application
name corresponding to the reference EnterpriseBean name defined in reference EJB or reference
LocalEJB set by 1.
[Runtime of EJB application]
Associate it with the EJB application name specified by the argument at lookup in the reference
LastName of EnterpriseBean changed by 1 and the EJB application by using the Naming Conversion
file.
2-10
Restrictions on the SOAP Service
The SOAP Service can be used with the following products:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Standard Edition
• Interstage Application Server Plus
Table 2-6 Restrictions on the SOAP Service
No. Restriction Remarks Date of
Restrictions on the SOAP Service
Removal
1 The Web service information edit
tool cannot edit Web service
information for a server if execution
of client authentication in SSL
communication is set for the server.
To use the Web service information
edit tool when a Web service server
application is operated with client
authentication specified for SSL
communication, the operation
explained in the Remarks column is
necessary.
Use two WWW servers for Web
service information management and
Web service server application
operation.
Set SSL communication without
client authentication for the WWW
server for Web service information
management.
Operate a SOAP Service Web
application with administrator
authority given to the Web service
information edit tool and Web service
manager in this WWW server.
Set SSL communication with client
authentication for the WWW server
for Web service server application
operation.
Operate a SOAP Service Web
application with administrator
authority given to the Web service
manager in this server and connect a
Web service client to this server . For
the Web service manager , set
reference to the same Web service
information management file as the
file for Web information
management.
Not
determined
2 If a message with attachment is sent
using the delivery guarantee
function, the saved attachment data
of the message may be lost and no
attachment may be found in the sent
message.
None Not
determined
2-11
Chapter 2: Restrictions
No. Restriction Remarks Date of
When this occurs, the following
message will be output:
UX: ISSOAP: ERROR: issoap1563:
Method invoke error :
java.io.IOException:
java.io.FileNotFoundException:
/var/tmp/Soapx17284soapx
Removal
3 If a SOAP Message object is built in
a stream including attachment data
and shared with multiple requests in
the SOAP server application, the
following problems occur in the
subsequent request processing:
- An exception occurs when the
attachment of the SOAP Message
object is obtained and executed.
- If the SOAP Message object is
returned as a return message, the
same message as that for the Item 2
above is output and a return
message with no attachment data is
sent back.
4 The user authentication function for
SOAP Message cannot be used.
None Not
determined
None Not
determined
2-12
Restrictions on the CORBA Service
This section provides information on the restrictions on the CORBA Service.
Restrictions on IDL Definitions
The IDL definitions can be used with the following products:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Standard Edition
• Interstage Application Server Plus
Table 2-7 Restrictions on IDL Definitions
No Restriction Alternative Method Date of
Restrictions on the CORBA Service
Removal
1 Type wchar, wstring cannot be used in the
const declaration of the IDL definition
2 The following values cannot exceed 65535 in
the data type declaration.
- Size of the string type (stinrg/wstinrg) with
the specified size
- Size of the sequence type (sequence)
- Number of elements of the enumeration
type (enum), structure (struct), union (union),
and exception structure (exception)
(See Note)
- Size of an array
None Not
determined
None Not
determined
2-13
Chapter 2: Restrictions
No Restriction Alternative Method Date of
Removal
3 Preprocessing declarations cannot be used
under the following conditions:
1) In an exception declaration
2) In a struct/union/enum declaration, and in
a member declaration (ending before a
semicolon)
Example:
struct STR1{
long
#pragma version STR1 2.3
a;
string b;
char c;
};
4 The following recursive declarations cannot
be used in the Java mapping of the IDL
definition:
1) Recursive declaration of a structure
(struct)
None Not
determined
None Not
determined
struct STR1 {
sequence<STR1> para1;
};
2) Recursive declaration of a union (union)
union UNI1 switch(long){
case1: sequence<UNI1> para1;
};
5 Type union cannot be used in the
CORBA/SOAP gateway generation of the
IDL definition.
None Not
determined
2-14
Restrictions on the CORBA Service
No Restriction Alternative Method Date of
Removal
6 In the Java mapping of the IDL definition, the
same name as the module name cannot be
specified in the following declarations. When
the same name is specified, a package
name will become a module name +
‘Package’, and a Java compile error will
occur.
1) interface declaration
2) struct declaration
3) union declaration
4) exception declaration
Example
module AAA {
interface AAA {
short op();
};
};
None Not
determined
2-15
Chapter 2: Restrictions
No Restriction Alternative Method Date of
Removal
7 When registering an updated IDL definition
containing inheritance of two or more
interface declarations in an interface
repository, the inheritance cannot be
registered in the repository under the
following conditions:
1) Another IDL definition file is included in
the IDL definition, and
2) The interface declaration in the included
IDL definition file is inherited in two or more
IDL definition files, and
3) The two or more IDL definition files in
condition 2) are updated and registered in
the interface repository.
Example:
[INTF_A.idl file]
interface A {...}
[INTF_B.idl file]
#include "INTF_A.idl"
interface B:A {...}
When creating IDL definition
files to be registered in an
interface repository, do not
create the same interface
declaration in different IDL
definition files if two or more
interface declarations are to
be inherited.
Example:
[INTF_A.idl file]
interface A {...}
[INTF_BC.idl file]
#include "INTF_A.idl"
interface B:A {...}
interface C:A {...}
Not
determined
[INTF_C.idl file]
#include "INTF_A.idl"
interface C:A {...}
8 ':' cannot be specified in the constant
None Not
expression in the case statement of a union.
Note:
The maximum numbers of elements vary in the Java mapping.
• Enumeration (enum):
1,024
• Structure (struct), union (union), and exception structure (exception):
254 ("long long" and "double" are each counted as 2.)
determined
2-16
Restrictions on IDL Compilation
The IDL compilation can be used with the following products:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Standard Edition
• Interstage Application Server Plus
Table 2-8 Restrictions on IDL Compilation
Restrictions on the CORBA Service
No Restriction Alternative
1 "-noinclude" cannot be specified for the IDL compiler. None Not
2 A prototype module definition file with no PROGRAM-ID
named IDL-file-name_skel.def may be created in the
COBOL mapping of IDL files.
3 Long long overflows are not checked when IDL is
compiled
Restrictions on C and C++ Programming
C and C++ Programming can be used with the following products:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Standard Edition
Table 2-9 Restrictions on C and C++ Programming
No. Restriction Alternative
Date of
Method
Removal
determined
None Not
determined
None Not
determined
Date of
Method
Removal
1
When a child process is generated by a server
application, and the child process is terminated by exit(),
Use _exit()
when you finish
a child process
only.
Not
determined
the parent process is also terminated.
2
None Not
determined
If WS Compilers C++ 6 used, no context object can be
used.
3
None Not
determined
A context cannot be used on the C++ application.
2-17
Chapter 2: Restrictions
Restrictions on Java Programming
Java programming can be used with the following products:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Standard Edition
• Interstage Application Server Plus
Table 2-10 Restrictions on Java Programming
No. Restriction Alternative
1 The data type of the long long cannot be used in
preinstalled type Java client and the Java server of
JDK/JRE 1.2.2 and 1.3
2 In Java, when the equal method is executed with
TypeCode of a structural type that cont ains the Object
type, TypeCode remotely generated and the same
TypeCode generated locally do not match.
3
The green thread of HotSpot VM and Classic VM cannot
be used as Java application execution environment.
Restrictions on the Naming Service
Table 2-11 Restrictions on the Naming Service
No. Restriction Alternative
1
No IP address in the IPv6 format may be specified in
inithost(nshost) of a corbaloc URL schema.
Date of
Method
Removal
None Not
determined
None Not
determined
None Not
determined
Date of
Method
Removal
None Next version
2-18
Restrictions on the CORBA Service
Table 2-12 Restrictions on the CORBA Service
Restrictions on the CORBA Service
No. Restriction Alternative
Method
1
The system may not release the CORBA Service port
number (eg, 8002) when the isstop command is run.
When the OD_start service was started (including
execution of the isstart command) in this status, it is
possible that a communication error occurs in the
application.
Use the netstat
-a command to
check that the
CORBA Service
port number
has been
released then
start the
service.
2
If the OD_start service is terminated before a CORBA
application is terminated, the system may stop
responding or "hang" while the CORBA application is
terminated.
Terminate all
CORBA
applications
before
terminating the
OD_start
service.
3 When the server per method is used for starting a
None Not
CORBA application, starting the CORBA application may
fail.
4
In Windows NT® Server with Service Pack 5, when
simultaneous requests are issued by a client that has
generated multiple threads and a communication error
It is necessary
to stop and
restart the
CORBA
Service.
(COMM_FAILURE exception) occurs, the system
resources used by the CORBA Service may not be
released.
Date of
Removal
Not
determined
Not
determined
determined
Not
determined
This will show up as repeated communication errors,
followed by all requests from client applications causing
communication errors.
5 When the dynamic skeleton interface of C++ language is
used with the server application, memory leak occurs.
(Approximately 150 bytes for a request)
6 The odlistproc process may output the message od10727
while quitting the CORBA service (ObjectDirector).
None Not
determined
None
No operation
Not
determined
problems other
than output
messages
2-19
Chapter 2: Restrictions
Restrictions on the Event Service
The Event Service can be used with the following products:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Standard Edition
• Interstage Application Server Plus
Table 2-13 Restrictions on the Event Service
No. Restriction Remarks Date of
Removal
1 The following functions cannot be used in the
dynamically generated event channels.
- Non-volatilization of connection information and
event data
- Transaction linkage
- Channel-to-channel linkage
- Point-To-Point Messaging Model
None Not
determined
2-20
Restrictions on the Component Transaction Service
Restrictions on the Component Transaction Service
The Component Transaction Service be used with the following product s:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Standard Edition
• Interstage Application Server Plus
Table 2-14 Restrictions on the Component Transaction Service
No. Restriction Remarks Date of
Removal
1
If Interstage is initialized in succession using the
Interstage operation tool or the isinit command,
the initialization of Interstage may fail.
2
When the Component Transaction Service is
used, the start of Interstage and the start of the
WorkUnit may become unusual if the installation
path of Interstage exceeds 230 bytes.
3
If the tdc command is executed before OD has
been started, the following message is displayed
("/tmp/aaa" and "1.0" is variable):
"/tmp/aaa", line 1:
CORBA_ORB_init Error
tdc: St op. IDLparser status = 4
IDLdestroy_rep (I/R)
:CORBA_ORB_init
:IDL:CORBA/StExcep/UNKNOWN:1.0
None Not
determined
Set the installation path
of Interstage to no more
than 230 bytes
Start OD, then reexecute the tdc
command.
Not
determined
Not
determined
2-21
Chapter 2: Restrictions
Restrictions on the Database Linkage Service
The Database Linkage Service can be used with the following products:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Plus.
Restrictions on the Locale of Languages
Table 2-15 Restrictions on the Locale of Languages
No. Restriction Remarks Date of
Removal
1 The client is not returned correctly when UNICODE
is specified in locale when Java server applications
are registered in the implementation repository and
the following exceptions are caused:
org.omg.CORBA.TRANSACTION_ROLLEDBACK
org.omg.CORBA.TRANSACTION_REQUIRED
org.omg.CORBA.TRANSACTION_INVALID_
TRANSACTION
Specify NONE in
locale when
registering in the
implementation
repository
Not
determined
2-22
Restrictions on InfoDirectory
Restrictions on InfoDirectory
Restrictions on the InfoDirectory Administration Tool
Table 2-16 Restrictions on the InfoDirectory Administration Tool
No. Restriction Remarks Date of
Removal
1 Multiple management tool clients
cannot simultaneously access the
same directory server except for
references.
Restrictions on the JNDI
Table 2-17 Restrictions on the JNDI
No. Restriction Remarks Date of
1 The LDAP function of JNDI has not
been supported by JDK/JRE1.4.
None.
Ensure that, when a management
tool client makes other than a
reference, no other management tool
client attempts to access the same
directory server.
None.
Use JDK/JRE1.3.1.
Not
determined
Removal
Not
determined
2-23
Chapter 2: Restrictions
Restrictions on JDK/JRE
This section describes the restrictions on JDK/JRE.
Table 2-18 Restrictions on JDK/JRE
No Restriction Remarks Date of
Removal
1
2
3
4
In using JDK/JRE1.4.1_01 or JDK/JRE1.3.1_06
in Windows XP to run a Java application or a
Java applet, the background color of menu
groups is different from the background color of
the menu bar.
In using the GUI lightweight components
(JTextField or others) in JDK/JRE1.4.1_01,
JDK/JRE1.3.1_06 or JDK/JRE1.2.2_014 in the
IME2002 environment, the language bar may
flicker synchronously with the caret of the
component.
If JServlet is started on HotSpot VM for
debugging, remote debugging of Apworks is
used, and the Servlet container is shut down, the
Java VM may crash generating core and
hs_err_pid***.log or fjvm_pid***.log (*** is the
process ID).
If the J2EE deployment tool is started, the Java
VM may crash generating core and
hs_err_pid***.log or fjvm_pid***.log (*** is the
process ID).
Adjust the menu color to
the menu bar or use the
classic style in the
display property setting
on Windows XP.
To avoid this, specify
the following Java VM
runtime option.
-Dsun.java2d.noddraw
=true
None Not
None Not
Not
determined
Not
determined
determined
determined
2-24
5
The service concerned may be in a hang-up state
at the time of the stop of each service that uses
JavaVM.
6
StackOverflowError cannot be caught in JDK
1.3.1 and 1.4.1. The Java VM may crash
generating core and hs_err_pid***.log or
fjvm_pid***.log (*** is the process ID).
None Not
determined
None Not
determined
Restrictions on the Portal Component
Restrictions on the Portal Component
Restrictions on Scripts in Contents
Table 2-19 Restrictions on Scripts in Contents
No. Restriction Remarks Date of
Removal
1 External contents with a script such as
JavaScript, JScript, and VBScript written may not
be displayed correctly with Portal component or a
script may not operate correctly when the external
contents are referenced via Portal component.(*1)
2 Anchor movement within a page in the brick of
the Portal component differs from that displayed
directly on the browser. In anchor movement in
the brick of the Portal component, content is
redrawn.
Example: <a href="top"> to the top </a>
*1 For JavaScript and JScript, display and operation with Portal component may be impossible under
the following conditions:
1. Exampl:eval("document.location=" + "http://foo/bar" + query);
Exampl:setTimeout("document.location = " + "http://foo/bar" + query",2000);
Exampl:setInterval("document.location = " + "http://foo/bar" + query",1000);
2. A script which can be rewritten with document.write() or HTML is written.
Exampl:document.write("document.location = " + "http://foo/bar" + query");
Exampl:document.write("<IMG ");document.write("SRC='/image.gif'>");
3. "(" or ")" is used in the rewriting target object part.
Exampl:foo(x, y).bar.href = "http://xxxxx";
4. Operation may not be performed correctly if the following properties are referenced in a script:
document.URL
document.domain
document.referer
location.protocol
location.host
location.hostname
location.port
location.pathname
location.hash
location.search
location.href
If a script error occurs,
display the script on
another window by
pressing the button.
If the operation in a
content performed
without using the Portal
component differs from
that with the Portal
component, display the
content in a separate
window.
Not
determined
Not
determined
2-25
Chapter 2: Restrictions
5. A script which can be rewritten with with() is evaluated.
Exampl:with(document.F1){
target="newTarget";
acrion="action.cgi";
}
6. When the window name is set by window.name or self.name, control in the brick frame of the Portal
component is disabled. (When the back icon or home icon in the brick frame of the Portal
component is clicked, another window opens and displays a content.)
7. When a processing is designed so that JavaScript in HTML content controls the Cookie in the
remote server, the Cookie is not posted to the remote server. If the Cookie is needed in the remote
server, a problem may occur in the operation of the remote server.
8. If a method (such as history.back();) used to perform history operation is written in the JavaScript
called by an onLoad event, a content may be repeatedly read in endless manner. If this symptom
occurs, quit the browser and change the settings so that the relevant content is not displayed in the
brick.
Restrictions on the Alternative Logon Function
Table 2-20 Restrictions on the Alternative Logon Function
No. Restriction Remarks Date of
Removal
1 Proxy logon cannot be executed if the one-time
password authentication is used for contents form
authentication.(*1)
2 Form authentication alternative logon cannot be
executed under the following conditions:
- The logon form is displayed using the HTTP
protocol redirection function.(*2)
3 When the user uses a Netscape4.X browser, the
maximum number of characters in each input
item on the basic authentication information
setting screen and form authentication
information setting screen is defined as follows:
a) Basic authentication information setting screen
- User name: 64 bytes
- Password: 64 bytes
- Comment: 64 bytes
b) Form authentication information setting screen
None Not
determined
Register the logon form
URL after redirection as
an alias.
None Not
Not
determined
determined
2-26
- Comment: 64 bytes
Restrictions on the Portal Component
4 In form authentication alternative logon, the
maximum size of post data sent from a browser is
8K bytes. If this value is exceeded, the message
Send post data with
length of 8K bytes or
less.
below is recorded in an event log and the
alternative logon fails.
[Event log message]
Failed to save proxy logon information. The
parameter is incorrect. [too long post data]
*1 In the one-time password authentication, a password that can be only once is created using such a
key which changes for each request as the time in PC and counter value.
*2 The HTTP protocol redirection function in this condition requests a jump to the specified URL for a
browser with response code 301 or 302 returned by the Web server for an HTTP request. The
jump destination URL is written in the location header in the response header.
Restrictions on the Load Distribution Environment
Table 2-21 Restrictions on the Load Distribution Environment
No. Restriction Remarks Date of
1 Values set in the number of logon items and
duplicate logon control under access control are
managed for each server. These values are not
managed totally in a load distribution
environment.
None Not
Not
determined
Removal
determined
Restrictions on Using Netscape 4.6/4.7
Table 2-22 Restrictions on Using Netscape 4.6/4.7
No. Restriction Remarks Date of
1 If Portalworks is used to display contents
containing an ilayer or layer tag usable with
contents for Netscape via a Netscape browser,
error message "Not Found" is displayed and the
contents cannot be displayed correctly.
Removal
None Not
determined
2-27
Chapter 2: Restrictions
Restrictions on Using Web USP (List of URLs to be Excluded With Form Authentication Inherited)
Table 2-23 Restrictions on Using Web USP
No. Restriction Remarks Date of
Removal
1 For a dynamically created logon form, the same
URL as an action URL from a logon form may be
used for access to this logon form. If so, the
function that inherits alternative logon and
displays a new browser window does not operate.
None Not
determined
Access from PC to Secure Site (HTTPS)
Table 2-24 Access from PC to Secure Site (HTTPS)
No. Restriction Remarks Date of
Removal
1 "Network Error -1" may be displayed if two or
more secure sites (httpss) are accessed in brick
services in the same roll.
Reduce the number of
brick services displayed
in a roll, for example by
dividing the roll.
Not
determined
Restrictions on Using the Brick Automatic Update Function
Table 2-25 Restrictions on Using the Brick Automatic Update Function
2-28
No. Restriction Remarks Date of
Removal
1 If contents consisting of two or more frames are
registered as Portalworks service (alias), the
contents may not be displayed correctly.
Select [Brick automatic
update] under [Brick
information] and cancel
the automatic update.
Not
determined
Restrictions on Other Functions
Table 2-26 Restrictions on Other Functions
No. Restriction Remarks Date of
Restrictions on Other Functions
Removal
1 When "SystemWalker/CentricMGR" is installed in
the same system, the "SystemWalker console job
monitoring" function cannot be used.
2
In products from SystemWalker/CentricMGR 5.0
through 5.2, the information on the following EJP
application type is not displayed.
- Bean-managed persistence Entity
- Container-managed persistence Entity
3
Do not uninstall the following services specified in
Interstage initialization in other than Interstage
uninstallation:
- Service supported in operating mode
- Service specified in the Interstage operating
environment definition
If these services are uninstalled, Interstage
activation and reinitialization may become
impossible
None Not
determined
None Not
determined
If a service listed in the
column at left is to be
uninstalled, reinitialize
Interstage so that the
service is not a target of
initialization, and then
uninstall the package.
Not
determined
2-29
Chapter 2: Restrictions
2-30
Chapter 3 Notes on Intersta ge Operation
This chapter provides additional information on the use of Interstage Application Server.
3-1
Chapter 3: Notes on Interstage Operation
Common Notes for Interstage
About Netscape 6
Do not install Netscape 6 on the same system.
About the Cross-Site Scripting Problem
What is the Cross-Site Scripting Problem?
The Cross-Site Scripting problem is a security problem that occurs when the client Web Browser sends
input data based on a dynamically generated Web page back to the server. Static HTML pages and
dynamically generated Web pages not using the data input, are not affected by this problem.
This is explained in the following example:
1) The following script is an example of a script that is executed when cross scripting occurs. This
script is placed at the end of the input data form script, just before "Submit".
"<SCRIPT Language=JavaScript>alert("Hello");</SCRIPT>"
2) After the input data was sent, the dialog box with “Hello” will be displayed.
The data input was processed but so was the script. However, if the user sends the input data
directly to the reliable site there is no problem even if there are errors on the page. But when the
user sends input data through an unreliable site, and the unreliable site sends this as input data to
the reliable site then the script that is executed causes the Cross-Site Scripting problem.
Analysis of the Problem
When developing applications like CGI and Servlet that generate dynamic pages to be displayed by the
Web browser and that generate Web pages without investigating the input data, this problem needs to
be fixed.
Examples:
− Retrieved result pages
− Those checking there is no errors in the input
− Those that register the input data in databases and display the input data through key words.
Investigation Method
Review the application programs one by one from the point of retrieving input data to that of generating
the Web pages. This can be done manually, by visual inspection of the source code, or, when reviewing
the source program is not practical, by running tests such as the one described above.
3-2
Countermeasures
When any problem is detected, take one of the following actions.
− Stop embedding input dat a into Web pages
− Convert special characters (< > &) to (< > &).
Security Information
Security information regarding Fujitsu products is announced in the following url.
http://software.fujitsu.com/en/security/main.html
Using the JSSE Function
When Interstage Application Server is installed, a library for the Java Secure Socket Extension (JSSE)
function is stored at the following location:
<Interstage installation folder>\J2EE\lib
The stored JSSE function library is classified into two types: one for JSSE1.0.2 and one for JSSE1.0.3.
The names of the files that are actually stored are as follows:
Common Notes for Interstage
• For JSSE1.0.2
− isj2ee.jar (The class for JSSE1.0.2 is stored in this jar file.)
• For JSSE1.0.3
− jcert.jar
− jnet.jar
− jsse.jar
To use the JSSE function, these files must be set with the environment variable CLASSPATH.
When JSSE1.0.2 is to be used, ensure that isj2ee.jar is set with CLASSPATH.
When JSSE1.0.3 is to be used, set jcert.jar, jnet.jar, and jsse.jar with CLASSPATH so that these files
come before isj2ee.jar.
3-3
Chapter 3: Notes on Interstage Operation
Monitor Screen Colors
For the machine on which Interstage Application Server is installed, use a display monitor and driver for
which 256 colors or more can be specified as monitor screen colors.
If a value of less than 256 colors is set, the GUI program using Java cannot start. This type of display
monitor cannot be used.
Applicable Functions
J2EE common resources
• J2EE resource access definition
• J2EE development tool
InfoDirectory
• InfoDirectory management tool client
• InfoDirectory management tool agent environment setup
• Certificate management utility
• SSL environment setting utility
Other
• User-developed program
3-4
Common Notes for Interstage
Setting Port Numbers Used for Individual Services
When port numbers are set or changed for Interstage Application Server services, unique port numbers
must be set for all individual services including applications in the system. If services are operated with
the same port number set for different services, normal operation cannot be performed (for example, a
client may fail to access a service).
Table 3-1 lists the services and functions for which port numbers are set under Interstage Application
Server. The table also lists the locations where the port numbers are set.
Table 3-1 Services/Functions for Which Port Numbers are Set
Service Name/
Function Name
Interstage
Management
Console
Web server
(Interstage HTTP
server)
“Port number for the virtual hosts”
Port Number Setting Location
“Port number for Interstage management console”
C:\Interstage\gui\etc\httpd.conf
- Port directive
“Port number for the entire Web server (Interstage HTTP server)”
Interstage Management Console
- [Services] > [Web Server] > [Web Server Settings] tab > [Port Number]
Or
The environment definition file (httpd.conf)
- Port directive
Interstage Management Console
- [Services] > [Web Server] > [Virtual Hosts] > [Create a new Virtual Host] > [IP
Address] and [Port Number]
Or
Interstage Management Console
- [Services] > [Web Server] > [Virtual Hosts] > [Virtual Host Name] >
[Configuration] > [IP Address] and [Port Number]
Web server
(InfoProvider Pro)
The environment definition file (httpd.conf)
- Listen directive
Note:
Setting the Listen directive in the environment definition file (httpd.conf) invalidates
the Port directive in the environment definition file (httpd.conf).
"Port number for Web server (InfoProvider Pro)"
InfoProvider Pro environment definition file
- port
3-5
Chapter 3: Notes on Interstage Operation
Service Name/
Port Number Setting Location
Function Name
CORBA Service "Port number for CORBA service"
Interstage Management Console
- [System] > [Update System Settings] > [CORBA Service Settings [Show]] >
[Port number]
Or
The environment definition file (config)
- IIOP_port
"Port number for CORBA service SSL"
Interstage Management Console
- [System] > [Update System Settings] > [CORBA Service Settings [Show]] >
[SSL Encryption] > [SSL listen port]
Or
The environment definition file (config)
- UNO_IIOP_ssl_port
Servlet Service "Port number for Servlet service"
Interstage Management Console
- [WorkUnits] > [Create a new WorkUnit] > [Detailed Settings[Show]] > [Servlet
Container Settings[Show]] > [Port number]
Or
Interstage Management Console
- [WorkUnits] > Select "IJServer name" > [Settings] > [Servlet Container
Settings[Show]] > [Port number]
Interstage Management Console
- [Services] > [Web Server] > [Web Server Settings] > [General Settings] >
[Port number]
Note:
Port numbers must be set when the Web server connector and Servlet container
are provided on separate systems (when "Yes" is selected from "Run Web server
and WorkUnit on the same machine?" on the [System] > [Update System
Settings] > [Detailed Settings[Show] > [Servlet Container Settings[Show]]). A port
number does not need to be set when these components are provided on the
same machine.
3-6
Common Notes for Interstage
Service Name/
Function Name
Servlet Service for
Interstage
operation control
Old version Servlet
Service
Port Number Setting Location
"Port number for Interstage operation control Servlet service"
JServlet environment definition file
- [containername].port definition
Servlet gateway environment definition file
[When Web server is Interstage HTTP Server]
- ApJServMount definition
- ApJServHost definition
[When Web server is other than Interstage HTTP Server]
- Container definition
Servlet container environment definition file
- Parameter tag
"Port number for old version Servlet service"
JServlet environment definition file
- [containername].port definition
Servlet gateway environment definition file
[When Web server is Interstage HTTP Server]
- ApJServMount definition
- ApJServHost definition
[When Web server is other than Interstage HTTP Server]
- Container definition
Servlet container environment definition file
- Parameter tag
Interstage JMX
Service
"Port number used for the Interstage JMX service to receive a request from the
Interstage Management Console"
Customize by specifying a value for the rmi attribute on the "port" tag in the
isjmx.xml file.
"Port number required for operation of the Interstage JMX service"
Customize by specifying a value for the internal attribute on the "port" tag in the
isjmx.xml file.
3-7
Chapter 3: Notes on Interstage Operation
Service Name/
Port Number Setting Location
Function Name
Infodirectory
Directory Service
“DSA LDAP port number”
[When DSA is created]
[Management tool client] > [InfoDirectory Server Management] > [ Create
DSA ] > [Configure Processes] > [Active process] > "Select LDAP process
(mtldapd)" > [Property] > [LDAP Configuration] > [Port No]
[After DSA is created]
[Management tool client] > [InfoDirectory Server Management] > [Configure
Processes] > "Select LDAP process (mtldapd) from [Active process]" >
[Properties...] > [LDAP Configuration] > [Port No]
“Port number for shadowing (DISP)”
[Management tool client] > [Server management] > [Database] > "Select
[Configuration]" > "Select [Network parameter]" > [open] > [Addressing...] >
"Select [DISP]" > "Select [TCP/IP] from "[Network address]" > [Modify] (or [Add]) >
[Port]
“Port number of subordinate reference (DAP or DSP)”
[Management tool client] > [Server management] > [Database] > "Select
[Configuration]" > "Select [Network parameter]" > [open] > [Addressing...] >
"Select [DAP or DSP]" > "Select [TCP/IP] from "[Network address]" > [Modify] (or
[Add]) | [Port]
Windows [Start] menu | [Programs] | [Interstage] | [Application Server] |
[InfoDirectory] | [Directory service property] | [RFC1006] tab | [TCP/IP port
number]
(For [TCP/IP port number], specify the same number as that specified for the port
number for the subordinate reference.
“Web connector port number”
[When DSA is created]
[Management tool client] > [InfoDirectory Server Management] > [ Create
DSA ] > [Configure Processes] > "Select [W eb process] from Process column"
> "idweb selected state" > [Properties...] > [Listening port]
For [LDAP port], specify the same number as that specified for "DSA LDAP
port number."
[After DSA is created]
[Management tool client] > [InfoDirectory Server Management] > [Configure
Processes] > "Select idweb from [Active process]" > [Properties...] >
[InfoDirectory Web configuration] > [Port No]
For [LDAP port], specify the same number as that specified for "DSA LDAP
port number."
3-8
Notes on the Interstage Operation Tool
Notes on the Interstage Operation Tool
The Interstage Operation Tool can be used with the following products:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Standard Edition
• Interstage Application Server Plus
Version Level of Each Service Performing the Operation
The version level of each service operating with Interstage Operation Tool is limited to the service
installed with the same CD-ROM. The service installed with the CD-ROM of other version levels cannot
be operated.
3-9
Chapter 3: Notes on Interstage Operation
Notes on the Interstage Integration Commands
This section provides additional information on the Interstage integration commands.
The Interstage integration commands can be used with the following products:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Standard Edition
• Interstage Application Server Plus
Dealing with Abnormal Command Termination
If the isstart, isstop or isinit command terminates abnormally, terminate the system by using the –f option
in the isstop command.
To start Interstage again, use the isstart command.
Starting and Stopping Services
Do not start or stop the following services when using the isgendef, isregistdef, isinit, isstart or isstop
commands:
• OD_start
• NamingService
• InterfaceRep_Cache Service
• InterfaceRep_Cache_e Service
• EventService
• TransactionDirector
• ObjectTransactionService
• Interstage API
• NS LoadBalancing Option
• F3FMwww
• Interstage JServlet
• CORBA_SOAP ClientGW
Note on Stopping Interstage
To stop Interstage, first stop all WorkUnits, then use the isstop command to stop Interstage.
3-10
Notes on the InfoProvider Pro
This section provides notes on the InfoProvider Pro.
(1) Authority to Use the Web Server
Web server install/uninstall and Web Server start/stop operations can be used only by
Administrators or users with Administrator authority.
(2) SQL Gateway
Articles about the SQL gateway have been deleted from V4.0. This function can still be used in the
current version. Those who use the SQL gateway of V3.0 or earlier and require the manual should
refer to the manuals of V3.0 or earlier.
(3) When accessing from a Web browser using the IPv6 Protocol
When accessing from a Web browser using the IPv6 protocol, use an OS product and Web
browser which support the IPv6 protocol officially.
Notes on the InfoProvider Pro
3-11
Chapter 3: Notes on Interstage Operation
Notes on the Interstage HTTP Server
This section provides notes on the Interstage HTTP Server.
Authority to Use the Interstage HTTP Server
Interstage HTTP Server install/uninstall and Interstage HTTP Server start/stop operations can be used
only by Administrators or users with Administrator authority.
Notes on Operating Interstage HTTP Server
Do not delete the following process management files while operating Interstage HTTP Server.
/opt/FJSVihs/logs/httpd.pid
If the file is deleted, the operation of Interstage HTTP Server cannot be guaranteed. Restart the system
again to operate normally.
3-12
Notes on J2EE
1) J2EE Application Operation
To use the following XML files while the web application or the J2EE application client is operating, add
the Java VM heap area, which is calculated from the formula shown below, to the specified value for the
maximum Java VM heap area size.
• Target XML files during operating web application
− Web application environment definition file (web.xml)
− Name conversion file (FJWebebeProperties.xml).
• Target XML files during operating J2EE application client
− Deployment descriptor file
− Name conversion file.
Java VM heap area size calculation
Notes on J2EE
Use the following formula to calculate the Java VM heap area size of each XML file. Add them to find the
total required area:
(((a ∗ 460) + b) / 1024) + 500) ∗ c (unit: kilobytes)
a: Number of lines in an XML file
b: XML file size (unit: bytes)
c: Number of clients accessed at the same time (when operating the Web application), or the
number of threads that issue lookups (when operating the J2EE application client)
The specification method of Java VM heap area size
When operating the Web application
Specify the size for the JavaVM option at [WorkUnits] > "IJServer name" > [Settings] tab.>
[WorkUnit setting[Show]] > [Java VM Options] on the Interstage Management Console
Example of specifying 512 megabytes for the maximum Java VM heap area size:
-Xmx512m
When operating the J2EE application client
Use the -Xmx option of the Java command, and specify the size as shown below:
Example of specifying 128 megabytes for the maximum Java VM heap area size:
java -Xmx128m ClientAPL
3-13
Chapter 3: Notes on Interstage Operation
Event resulting when the Java VM heap memory becomes insufficient
When an application is operated, if the Java VM heap area size to be used is not added to the maximum
size, the following event may occur:
javax.naming.NamingException:com.fujitsu.interstage.j2ee.def.FJDefException: unknown error:
java.lang.OutOfMemoryError
2) Use of the J2EE Management Tool or J2EE Deployment Tool
Do not use the "Release Deployment" or "Deleting IJServers" functions of the J2EE Management tool or
the J2EE Deployment tool on a Web application with the following set up:
• A Web service container of SOAP Service
If these functions are used, re-installation is required before the Web application can be used again.
Refer to the SOAP Service User's Guide for details of Web service containers.
3-14
Notes on the Servlet Service
1) Servlet Service Execution Environment
The Servlet Service execution environment is based on Tomcat4.1.2. A Servlet or JSP application that
runs on Tomcat4.1 or later may not function correctly.
2) Execution Environment of Earlier Version Servlet Service
An earlier version Servlet Service (servlet execution environment based on tomcat3.1) is not compatible
with the Microsoft Internet Information Server of Windows 2003 Server.
When the Windows 2003 Server is used, use the Interstage Application Server Web server.
3) Session Management Cookie of Servlet Service
When the Web server runs in an SSL environment, the Secure attribute is automatically added to the
session management cookie.
If the Web server runs in non-SSL (HTTP) mode while the SSL accelerator is used, the Secure attribute
is not automatically added. Use the following method to add the Secure attribute:
Notes on the Servlet Service
[V6.0 Servlet Service]
Refer to Environment Setup for Servlet Service in Chapter 12 in the Security System Guide.
[Earlier version Servlet Service]
Modify the following JServlet properties file:
Definition file name : jservlet.properties
Storage location : C:\Interst age\F3FMjs2\conf
Definition item : com.fujitsu.interstage.jservlet.session.cookie.secure.mode=auto|secure
− auto: Default value
When the Web server runs in an SSL environment, the Secure attribute is automatically added
to the session management cookie.
− secure:
Be sure to add the Secure attribute to the session management cookie.
Select this option when the Web server runs in non-SSL (HTTP) mode while the SSL
accelerator is used.
Definition example: com.fujitsu.interstage.jservlet.session.cookie.secure.mode=secure
3-15
Chapter 3: Notes on Interstage Operation
Notes on Using the EJB Service
This section provides information on using the EJB Service.
Version of Java Development Kit/Java Runtime Environment
1) The same version of Java Development Kit (JDK)/Java Runtime Environment (JRE) is
recommended from development to execution.
The application class created by the Java Development Kit 1.1.x javac command is not always
executable in Java Development Kit/Java Runtime Environment 1.2 and 1.3 execution environment.
In this case, recompile in a Java Development Kit 1.2 or 1.3 environment before execution.
The application class created by JDK 1.2.x or 1.3.x javac command is not executable in a Java
Development Kit/Java Runtime Environment 1.1.x execution environment.
2) Before using the JDK/JRE1.3 environment
When using the Servlet Service in the JDK/JRE1.3 environment, do not log out of Windows. If
Windows is logged off, the Servlet container (JavaVM) terminates abnormally due to a bug in
JDK1.3 (Bug Id: 4323062). For detailed information about the JDK1.3 bugs, refer to Sun
Microsystems' Bug parade. This bug has been corrected in JDK1.3.1. For the JDK1.3.1
environment, specify -Xrs in "default.bin.parameters or [containername].bin.parameters" of the
JServlet environment definition file.
Notes on the EJB Customize Tool
1) Due to JDK/JRE restrictions, the Customize Tool display colors may be unstable or the system
cannot be started if 256 colors or less is selected for display in screen properties. Select more than
256 colors.
In addition, if the customize tool is started using Terminal Service of Windows® 2000 or
Server/Windows® 2000 Advanced Server, the number of colors that appears in the display is 256,
and the displayed colors become unstable. This does not affect the tool’s operation.
2) When the EJB Service is installed over another edition, specify the path setting information for the
Web browser Customize Tool again after installation in order to initialize it.
3) EJB applications created in Interstage V2 in a JDK/JRE 1.3 or later environment cannot be
selected with the Customize Tool when it is started with the ejbcust command. Run setup again
after installation.
3-16
Notes on Using the EJB Service
4) The startup performance of the rapid invocation definition screen of the customize tool that is
started by ejbcustx is improved (V5.0). Because the processing to acquire information on
Enterprise Bean installed when it is listed is accelerated, if Enterprise Bean of the EJB1.1 and
EJB2.0 specification as well as Enterprise Bean of the EJB1.0 specification are installed in the
invoking Bean, they are also listed. If Enterprise Bean of the EJB1.0 specification is selected, an
error message appears, and the edit cannot be performed. As for V3.0, in order not to display
Enterprise Bean of the EJB1.0 specification on the rapid invocation definition screen when it is
listed, add the -v3 (or -V3) option to the ejbcustx command and execute it. However, in this case,
the processing time remains the same as that is for V3.0.
5) In an environment where screen response is slow (such as when using the customize tool in the
terminal service), buttons may be operated in succession during the operation of the customize tool
without visible effect. For example, it may take time to mask the button after it is pressed.
The following are specific operations where this behavior may be in evidence:
Multiple dialogs may be opened in these circumstances:
− When you select a button in the definition information (Note1) panel
− When you select a button on the path settings screen of the WWW browser
− When you select the Change or Add buttons to access environment definition screen
− When you select the Delete.
− When you select EJB Application Runtime Environment Definition in the File menu.
− When you select Rapid invocation definition in the Tool menu.
− When you select DB access environment definition in the Tool menu.
− When you select Path settings of the WWW browser in the Help menu.
− When you select Version information of the Help menu.
If multiple screens or dialogs open, close the unnecessary ones before starting the operation.
1) If HotJava™ Browser is set in the “WWW Browser Path Setup” of the Customize Tool, use
HotJava™ Browser Version 3.0 or after. If a version earlier than 3.0 is used and the manual is
displayed, it may not be output normally.
2) The PC X Server (note1), which works on the common desktop environment (CDE) on X Server
built into Solaris™ Operating Environment OS (SPARC) by the standard or Microsoft Windows, is
necessary for the operation environment of the Customize Tool.
The response time of drawing and the operation slows in an environment that it is far from the
server, and the communication is late when executing it with the PC X server. In this case, the use
of Customize Tool of the operation command is advised.
The screen of Customize Tool might not be displayed when operating in other environments or
even if it is displayed, it might not be displayed correctly. Be sure to login on common desktop
environment (CDE) from the above environment, execute the ejbcust or ejbcustx command to
activate the Customize Tool.
Note1) These are operation results of FUJITSU PC-X V20L30 of FUJITSU Ltd. and the X Vision
Eclipse7.2 of SCO Ltd. as PC X Server product. Operation by other PC X Server products is not
guaranteed.
Set the system to use the font of the font server when using the PC X server. Refer to the Help file
appended to FUJITSU PC-X and X Vision Eclipse for details of how to set the font. In addition, it is
necessary to make font server (xfs) work on the Solaris™ Operating Environment Server side.
3-17
Chapter 3: Notes on Interstage Operation
3) The startup performance of the rapid invocation definition screen of the customize tool that is
started by ejbcustx is improved (V5.0). Because the processing to acquire information on
Enterprise Bean installed when it is listed is accelerated, if Enterprise Bean of the EJB1.1 and
EJB2.0 specification as well as Enterprise Bean of the EJB1.0 specification are installed in the
invoking Bean, they are also listed. If Enterprise Bean of the EJB1.0 specification is selected, an
error message appears, and the edit cannot be performed.
In the same way as for V3.0, in order not to display Enterprise Bean of the EJB1.0 specification on
the rapid invocation definition screen when it is listed, add the -v3 (or -V3) option to the ejbcustx
command and execute it. However, in this case, the processing time remains the same as that for
V3.0.
4) In an environment where screen response is slow (such as when using the customize tool in the
PC X Server), buttons may be operated in succession during the operation of the customize tool
without visible effect. For example, it may take time to mask the button after it is pressed.
The following are specific operations where this behavior may be in evidence:
Multiple dialogs may be opened in these circumstances:
− When you select a button in the definition information (1) panel
− When you select a button on the path settings screen of the WWW browser
− When you select the Change or Add buttons to access environment definition screen
− When you select the Delete
− When you select EJB Application Runtime Environment Definition in the File menu
− When you select Rapid invocation definition in the Tool menu
− When you select DB access environment definition in the Tool menu
− When you select Path settings of the WWW browser in the Help menu
− When you select Version information of the Help menu
If multiple screens or dialogs open, close the unnecessary ones before starting the operation.
When Operating with WorkUnits
1) When operating EJB applications with WorkUnits, do not install the Interstage Java Server Package
and the Interstage package in a folder that includes blank spaces.
2) In the JDK/JRE1.3 environment, if the EJB application is operated in the WorkUnit, do not log off
from Windows NT. When this is done, the JavaVM terminates abnormally due to a JDK1.3 failure
(Bug Id:4323062) and Interstage is forcibly stopped. For more information on JDK1.3 failures, see
the Bug Parade from Sun Microsystems.
Specify without fail –Xrs in the Java Command Option of the WorkUnit definition in case of
JDK1.3.1 environment.
3-18
When Interstage JDBC Driver is Used
1) Data Type
The support range of the data type is as follows.
Supported Data Types
• integer type (int, smallint)
• round number type (float, real)
• character string type (char, varchar, text)
• binary type (binary, varbinary, image)
• money type and smallmoney type
• decimal type and numeric type
• datetime type and smalldatetime type
Notes on Using the EJB Service
• Other data types (timestamp)
The timestamp type of the SQL Server is for fetching only and can be used in the BMP.
Unsupported Data Types
• integer type (tinyint, bigint)
• bit type (bit)
• other data types (cursor, uniqueidentifier, sql_variant, table)
• Unicode character type (nchar, nvarchar, ntext, sysname)
• User-defined type
2) Format of the datetime Type and smalldatetime Type
When updating the data of the column of the datetime type and smalldatetime type, specify the data in
the following format.
Description Format
YYYY-MM-DD hh:mm:ss
• YYYY=year
• MM=month
• DD=day
• hh=hour
• mm=minute
• ss=seconds
Note: millisecond is not supported.
3-19
Chapter 3: Notes on Interstage Operation
3) Stored Procedure
A stored procedure cannot be used.
4) API when datetime Type is Used
When the following API is used for the datetime type, only the values within the smalltime type are valid.
• PreparedStatement.setTimestamp(int parameterIndex, Timestamp x)
5) Unsupported API
Among the JDBC API st andard specifications, the following APIs are not supported.
• Connection class
− nativeSQL(String sql)
− setCatalog(String catalog)
− getCatalog()
• DatabaseMetaData class
− getCatalogTerm()
− isCatalogAtStart()
− supportsCatalogsInProcedureCalls()
− supportsCatalogsInTableDefinitions()
− getMaxCatalogNameLength()
− getCatalogSeparator()
− supportsCatalogsInDataManipulation()
− supportsCatalogsInIndexDefinitions()
− supportsCatalogsInPrivilegeDefinitions()
− getTableTypes()
− getCatalogs()
− getColumnPrivileges(String catalog, String schema, String table,String columnNamePattern)
− getVersionColumns(String catalog, String schema, String t able)
− getCrossReference(String primaryCatalog, String primarySchema,String primaryTable, String
foreignCatalog,St ring foreignSchema, String foreignTable)
− getTablePrivileges(String catalog, String schemaPattern,String tableNamePattern)
− getBestRowIdentifier(String catalog, String schema,String table, int scope, boolean nullable)
− getImportedKeys(String catalog, String schema, String table)
− getExportedKeys(String catalog, String schema, String table)
3-20
• PreparedStatement class
− setBoolean(int parameterIndex, boolean x)
− setByte(int parameterIndex, byte x)
− setLong(int parameterIndex, long x)
− execute()
− setObject(int parameterIndex, Object x)
− setObject(int parameterIndex, Object x, int targetSqlType)
− setObject(int parameterIndex, Object x, int targetSqlType, int scale)
− setBigDecimal(int parameterIndex, BigDecimal x)
When column data type is round number type(real type, float type)
− setTimestamp(int parameterIndex, Timestamp x)
When column data type is character string type(char type, varchar type)
− setString(int parameterIndex, String x)
When column data type is datetime type and smalldatetime type
• ResultSetMetaData class
− getCatalogName(int column)
− getColumnLabel(int column)
• Statement class
Notes on Using the EJB Service
− setEscapeProcessing(boolean enable )
− getQueryTimeout()
− setQueryTimeout(int seconds)
− cancel()
− getMoreResults()
− getResultSet()
− getUpdateCount()
• JDBC 2.0
In the JDBC 2.0, some of the methods that were supported in JDBC1.X are positioned as ‘not
recommended methods’ and others are supported in place of them. Also, new classes and
methods are supported.
The JDBC driver supports the following methods only in place of those no longer recommended. All
other new APIs are not supported yet.
− CallableStatement class
getBigDecimal(int parameterIndex)
− ResultSet class
getBigDecimal(int columnIndex)
getBigDecimal(String columnName)
− DriverManager class
getLogWriter()
setLogWriter(PrintWriter out)
3-21
Chapter 3: Notes on Interstage Operation
6) Fetching a Line from a Text Type and a Table Containing an Image T ype
With regard to fetching a line from a text type and a table containing an image type; in BMP, specify the
row of the text type and the image type such that they are placed last in the selected list.
− Example 1: Specify the line of the text type and the image type so that they are placed in the
COL3.
SELECT COL1, COL2, COL3 FROM SCM.TBL WHERE COL1=?
− Example 2: When handling multiple lines of the text type and the image type, specify the line
of the text type and the image type so that they are placed in the COL2 and COL3 respectively.
SELECT COL1, COL2, COL3 FROM SCM.TBL WHERE COL1=?
In CMP, when operating the text type and a table containing an image type, specify the row of the text
type and the image type last in the CMF mapping definition.
Note on Class Names
When installing multiple EJB applications on the same machine, if there is a class (such as HOME
interface, Remote interface, Enterprise Bean class, and primary key class) that has the same name but
different implementation, the incorrect operation occur. Therefore, when developing EJB applications,
determine a package name so that the class name does not get duplicated.
Starting EJB Applications
In DB access environment definition of the customize tool, if the same port number of the existing
product is specified by mistake, much time is required for starting and an error occurs. Specify a correct
port number and restart.
About the EJB Application Process
In the EJB application, do not control the signal by JNI (Java Native Interface). When the signal is
controlled, it does not operate correctly.
3-22
Notes on SOAP Service
When Encryption Communication by SSL is Used
• It is necessary to construct the SSL environment for the SOAP server and the SSL environment for
the SOAP client with the system environment that the SOAP Service operates.
• It is necessary to construct the SSL communication environment respectively of SOAP
communication between the IIOP communication with the CORBA client application and the SOAP
server application in the CORBA/SOAP client gateway. In addition, the site certificate cannot be
shared by the IIOP communication and SOAP communication. Acquire the certificate in each SSL
communication environment.
• The certificate that the telephone number or the employee number is set for the identification name
cannot be used with the SOAP client. Set neither "Telephone number" nor "Employee number" to
the identification name when you acquire the site certificate.
Notes on SOAP Service
When Session Recovery Function of Servlet Service is Used
When using the session recovery function of the Servlet Service, the SOAP router of the SOAP Service
cannot be employed.
When J2EE Management Tool or J2EE Deployment Tool is Used
Do not use the "Release Deployment" or "Deleting IJServers" functions of the J2EE Management tool or
the J2EE Deployment tool on a Web application of a Web service container. If these are used, reinstallation is needed in order to use the Web application of the Web service container again.
3-23
Chapter 3: Notes on Interstage Operation
Notes on the CORBA Service
This section provides additional information on the CORBA Service.
Notes on Installation and Environment Settings
1) When the CORBA Service is installed and linked to the Systemwalker/CentricMGR operation
management tool, particular care is needed when stopping the CORBA Service and when setting
up the environment uninstalling.
Stopping
The SystemWalker/CentricMGR operation management tool cannot be used when the CORBA
Service (ObjectDirector) has been stopped
Setting Up the Environment
Setting up the CORBA Service environment may affect the SystemWalker/CentricMGR operation
management tool if it is using ObjectDirector. Pay attention to the environments for this product
when setting up the CORBA Service environment.
Uninstalling
The SystemWalker/CentricMGR operation management tool cannot be used when CORBA Service
(ObjectDirector) has been uninstalled.
Refer to Notes for Installing SystemWalker/CentricMGR in the Installation Guide for the inst allation
procedure.
2) When the odadmin_ex command is used to set up the environment in Windows® 2000, the
following message may be displayed, indicating that environment setup has failed:
ObjectDirector environment setup failed
Return code
2
Error details
odsetns : error occurred code = 402, 1072
Cannot execute command. : odsetns
In this case, run the process again and set up the environment correctly. If the Service property
screen is displayed, close the screen and repeat the processing.
3-24
Notes about Setting Applications
1) When specifying environment variables in env when registering the implementation repository, do
not specify multiple character strings delimited by semicolons (;). The system recognizes
semicolons as delimiters between different environment variables.
Examples of acceptable settings:
(1) env = Path=C:\WINDOWS
(2) env = Path=C:\WINDOWS;LIB=C:\USER
Example of unacceptable setting:
(1) env = Path=C:\WINDOWS;C:\WINDOWS\SYSTEM
If it is necessary to specify values delimited by semicolons in the PATH environment variable, do
not register the variable in the implementation repository, but use one of the following methods:
− Set the necessary path in the P ATH system environment variable
− Set the environment variable by the application itself (putenv function)
Also note that system and user environment variables other than those specified in env are invalid.
2) If a server-per-method server is called continuously, increase the value in proc_conc_max.
Notes on the CORBA Service
3) To operate COBOL applications in a Shift JIS environment, specify CBR_CODE_CHECK=no.
4) If the odadmin command, isinit command or CORBA Service is executed during operation of a
CORBA application or WebGateway, the following message is output to the console.
Stop the CORBA application or WebGateway.
"UXOM 1.0:SEV=E,acf=init :demon start fails"
3-25
Chapter 3: Notes on Interstage Operation
Notes on the IDL Compiler
The IDL Compiler can be used with the following products:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Standard Edition
• Interstage Application Server Plus
1) If the IDL compiler is used in a client, install CORBA Service Client and CORBA Service
Development Tool.
2) The IDL file suffix, "idl" must be in lower-case letters. If the suffix is in upper-case letters (such as
when the file is moved with ftp), change the suffix to the lower-case letters, and then execute the
IDL compile.
3) When the IDL compiler is used, it is necessary to set the environment variable OD_HOME.
Notes on the Java Environment
1) The applet viewer in JDK/JRE 1.2.2 and 1.3 cannot be used.
2) In the operation of Java applet, if InfoProvider Pro is used as Web server and if cab file is written in
HTML file, file extension “cab” as data type "application/octet-stream" must be specified to the file
specified as "content-type" in InfoProvider Pro environment definition file.
Notes on SSL communication
• SSL linkage cannot be used from the clients of a version of Interstage earlier than V2.0L10. Also,
the Object Reference for the SSL linkage cannot be registered to the Naming Service of Interstage
earlier than V2.0L10.
• In SSL linkage, requests from the clients cannot be received in the following cases:
− Certificates become invalid or expired after starting the CORBA Service (ObjectDirector).
− Nicknames of certificates were omitted in setting the SSL environment or in executing the
odsetSSL command.
• When deleting or canceling (CRL: Registering in the list of invalid certificates) the certificates that
have been set in the CORBA Service, first terminate the CORBA Service.
• When the server host names or IP addresses from the clients cannot be solved in the SSL
communication, set the server host information in the “hosts” file or DNS.
3-26
Notes on the Event Service
The Event Service can be used with the following products:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Standard Edition
• Interstage Application Server Plus
The following notes relate to the operation of the Event Service.
Note on Reinitializing Interstage
When Interstage is to be reinitialized after the event channel has been generated with the esmkchnl
command, use the esrmchnl command to delete the event channel before reinitializing Interstage. If
Interstage is to be initialized without deleting the event channel, delete the event channel that existed
before initialization, after initialization.
Notes on the Event Service
Notes on SSL Communication
To perform SSL communication in the event service, the SSL environment of the CORBA service must
have been set in advance.
Note on Unit Generation
To generate a unit during persistent channel operation, the storage folder of each control file must
specify a drive whose file system is NTFS. For unit generation, refer to esmkunit in the Reference
Manual (Command Edition).
Note
Persistent channel operation can be used with the following products:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Standard Edition
3-27
Chapter 3: Notes on Interstage Operation
Note on Persistent Channel Applications
Persistent channel applications can be used with the following products:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Standard Edition
If the connection is forcibly disconnected due to a system failure, applications of the persistent channel
must be restarted. If processing continues without restarting persistent channel applications, a system
exception COMM_FAILURE with the minor code 0x464a0109 (invalid dat a received) may be returned.
Notes on Multi-IP Address Operation
Host Name
When the host name is set to either of the following, the Multi-IP address function cannot be used:
• "Corba Host Name" in the Interstage operating environment definition file
• "IIOP_hostname" in the CORBA Service config file
Port Number
Set either of the following for the port number:
When SSL communication is invalid:
• "Corba Port Number" in the Interstage operating environment definition file
• "IIOP_port" in the CORBA Service config file
When SSL communication is effective:
• "SSL Port Number" in the Interstage operating environment definition file
• "UNO_IIOP_ssl_port" in the CORBA Service config file
Refer to the Reference Manual (Command Edition) for the method of specifying the host name and the
port number of the Event Service.
3-28
Notes on the Component Transaction Service
Notes on the Component Transaction Service
The Component Transaction Service can be used with the following product s:
• Interstage Application Server Enterprise Edition
• Interstage Application Server Standard Edition
• Interstage Application Server Plus
This section provides additional information on the Component Transaction Service.
Note on Messages in Windows® 2000
If the system locale value is changed after Interstage is installed in Windows® 2000, EXTP messages
may not be displayed correctly.
About CORBA Service Termination using the isstop Command
When the isstart command is executed, CORBA Service cannot be stopped using the isstop command.
If this occurs, immediately execute the isstop command with –f specified.
Monitoring during Interstage Operation
If Interstage is started using the isstart command and one of the Interstage services terminates
abnormally during operation, execute the following recovery processing:
• If CORBA Service, Naming Service, Interface Repository, Load Balance, Component Transaction
Service, Database Linkage Service, WWW Server , HTML Page Editing Service, or Servlet Service
terminates abnormally, stop the Component Transaction Service, Database Linkage Service,
resource control program, WWW Server, HTML Page Editing Service, and Servlet Service.
• If the Event Service terminates abnormally, then Interstage continues operation. Even if the service
is stopped using an individual command (tdstop for Component Transaction Service), execute
recovery processing in the same manner as when the service terminates abnormally.
3-29
Chapter 3: Notes on Interstage Operation
Notes on the Database Linkage Service
Notes on OTS Command Execution
If an OTS command is executed in an environment in which the CORBA Service has not been installed,
an application error dialog box may be displayed.
In this case, install and start the CORBA Service and re-execute the otssetrsc command.
Notes on the Use of Oracle
Use of Oracle Database by Java Serv er Application
Use Oracle 8.0.5 or later.
Using Oracle8
An error message is displayed at recovery and an unsolved transaction is left in both the following
scenarios:
− By ROLLBACK FORCE, forced rollback using manual rollback function of Oracle8 on the
unresolved function.
− Resource management program restarted. The output messages are shown below.
OTS: WARNING: 9666 Sy stem memory or system resource is insufficient.
The following message would be displayed if committed using the command “otspendlist.”
OTS: ERROR: 9348 Error occurred in commit operation.
Discharge in-doubt status by entering command “otspendlist”.
Installation of Oracle8i(8.1.6)
When Oracle8i(8.1.6) is used for distributed transaction linkage, the installation must be carefully
performed. Install the necessary functions for using the user application in process environment.
3-30
Notes on the Database Linkage Service
Notes on Development using Functions for the Java Language Provided by the Database Linkage Service of Interstage 1.1 or Earlier
Use environment under Database Linkage Service installation directory/pc/lib/J11.
Maximum Number of Resources for One Transaction
The maximum number of resources that can be used in a transaction using the isinit command is four.
This value cannot be changed.
Sample Provided with Database Linkage Service
Use Pro*COBOL1.8.27 when you precompile the COBOL data base cooperation service sample
application. When Pro*COBOL R8.0.5 is used, the following line should be deleted from the COBOL
sample:
COPY SYMBOL-CONST IN CORBA
According to this, reserved words declared in the COBOL register and library
($OD_HOME/include/COBOL/CONST.cbl) cannot be used.
CORBA Server Application is Operated using Multi Thread
If resource management program or OTS system is re-started under the CORBA server application
operation, do not call CORBA server application from client. Restart after start.
3-31
Chapter 3: Notes on Interstage Operation
Notes on InfoDirectory
This section provides additional information on InfoDirectory.
Setup Item Related to the Maximum Simultaneous Number of Clients Connected
The following setting of InfoDirectory is needed when InfoDirectory is used by the security function of
the Component Transaction Service and the online reference function of the WWW server. The exact
setting is also dependent on the maximum simultaneous connection number of clients.
1) Number of IPC messages of InfoDirectory
Set the following value for the "Maximum number of messages for each IPC queue" of the directory
service property when the maximum simultaneous connection number of clients exceeds 40.
Maximum number of connected clients x 5
2) Maximum number of associations of DSA
Set the maximum simultaneous connection number to the maximum number of associations of
network parameters of the InfoDirectory control tool when the maximum simultaneous connection
number of clients exceeds 100.
Error Messages in the Event Log
1) "No DSA in this directory"
When creating a new DSA, this message is output to the event log. This is not a problem because
this message is output when confirming DSA status.
If this message is output when not creating a new DSA however, examine the operating
environment for problems. Call your Fujitsu support center if there is no problem in the operating
environment.
2) Other error messages
If an error is detected in the processing of InfoDirectory, an error message is output to the event log.
In such cases, confirm the contents of the error message and examine the operating environment
for problems. Call your Fujitsu support center if there is no problem in the operating environment.
3-32
Notes on JDK/JRE
Notes on JDK/JRE
Notes on Java VM
The default JavaVM when using JDK/JRE1.3.1_06 and 1.4.1_01 in Interstage Java Server Package is
Fujitsu JavaVM (FJVM). This default is synonymous with specifying "-fjvm" in the java command option.
Notes on OutOfMemoryError Caused by a Permanent Area Shortage
The Permanent area is one of heap areas used to manage objects (Java classes and methods) that are
permanently referenced by HostSpotVM (including FJVM), which is a JavaVM introduced to JDK/JRE
1.3 and later. For a Java application that uses many classes and methods, the size of the Permanent
area must be increased. Especially if an OutOfMemroyError occurs irrespective of how much the
maximum heap value (specified in -Xmx) is increased, a Permanent area shortage may be one of the
possible causes. The default size of the Permanent area is as follows:
• JDK1.3.1(HotSpot ClientVM): 32MB
• JDK1.3.1(FJVM, HotSpot ServerVM): 64MB
• JDK1.4.1(HotSpot ClientVM): 64MB
• JDK1.4.1(FJVM, HotSpot ServerVM): 64MB
The size of the Permanent area can be specified using JavaVM option "-XX:MaxPermSize."
Example: Set the maximum size of the Permanent area to 128 MB:
-XX:MaxPermSize=128m
Notes on java.lang.Object.wait()
After JDK/JRE is installed, java.lang.Object.wait() may be released (spurious wakeups) without waiting
for a restart instruction (notification), interruption, or time-out. Therefore, make a program so that wait()
is used in a loop.
Reference: Notes on the return value of java.beans.PropertyDescriptor.getWriteMethod()
3-33
Chapter 3: Notes on Interstage Operation
Notes on the Return Value of java.beans.PropertyDescriptor.getWriteMethod()
JDK/JRE 1.3.1_08 and 1.4.0_01 solved the problem "bean methods may not be obtained," which
caused by a problem in java.beans.Introspector.getBeanInfor(). The operation of the
java.beans.Introspector that may have produced different results on different JavaVMs (because the
order in which methods should return was not defined in the JavaBeans specifications) has been
corrected. Accordingly, for an application in which the parameter data type of the set***() method that
sets class properties does not match the data type of the return value of the get***() method that obtains
class properties, null will be returned as a return value from PropertyDescriptor.getWriteMethod(). For
this reason, make a program so that these data types match.
3-34
Notes on Portal Component
Notes on Contents Use
A homep age (Web page) or the individual contents (text, images, music, etc.) on the homepage are
copyrighted. Therefore, using these copyrighted materials may infringe the copyright. It is recommended
that the permission of the copyright owner is obtained before using the homepage or its contents.
Notes at Logon
When logging on to Portal component, IDs/passwords of common users are sent without being encoded.
To improve security, it is recommended that the SSL environment be set up by the WWW server.
For a detailed description of the setup method, refer to the manual for the WWW server to be used.
Notes on Portal Component
Notes on Portal Component Server Operating Mode
When opening the Portal component server to the Internet, a secure environment must be built. In such
cases, it is recommended that an environment that places the SecurityDirector on DMZ and Portal
component on IDC, and connects the access to Portal component via SecurityDirector is built.
Also, always register the Portal component server in the DNS (Domain Name System).
Notes
• DMZ (DeMilitarized Zone)
This is a segment that is separated from the Internet and IDC by a firewall.
• IDC (Internet Data Center)
This is a secure data center connected to the Internet.
Communicate between the Internet zone and DMZ (SecurityDirector) using HTTPS protocol. Only HTTP
and HTTPS protocols are valid between DMZ (SecurityDirector) and Portal component.
When opening the Portal component server to the Internet, use the procedure described below to
execute file access right commands. This prevents illegal file modification by Windows end users.
(1) Logon to the Windows server using the user ID that installed Portal component.
(2) Confirm that Portal component installation is completed.
(3) Open the command prompt.
The command prompt can be displayed by the following method:
Windows® 2000:
Start | Programs | Accessories | Command prompt
3-35
Chapter 3: Notes on Interstage Operation
Windows NT® 2000:
Start | Programs | Command prompt
(4) Execute the following program:
<Interstage install directory>\portalworks\bin\pwinetop.exe -d|-w
When this system is installed to "C:\Interstage\portalworks" on a machine belonging to the domain.
C:\Interstage\portalworks\bin\pwinetop.exe -d
When the system is installed to "C:\Interstage\portalworks" on a machine (work group machine)
that does not belong to the domain.
C:\Interstage\portalworks\bin\pwinetop.exe –w
(5) Change the permissions to the shared folder of Fujitsu Enabler.
Share folder name Directory
\\[Machine name]\enabler <Interstage install
\\[Machine name]\FAS$ADM <Interstage install
directory>\Enabler\Server\control
directory>\Enabler\Server\FASADM
Change the following permissions to the above-mentioned folder
Administrators group (full control).
Everyone (read only).
• Communicate between the Internet zone and DMZ (SecurityDirector) using HTTPS protocol. Only
HTTP and HTTPS protocols are valid between DMZ (SecurityDirector) and Portal component.
• When Portal component is connected to a server on IDC using USP, set up a firewall between DMZ
and IDC to let only packets from the Portal component server be filtered out.
• The recommended protocol to be filtered out through DMZ and IDC is HTTPS.
• When more than one Portal component is installed to share the repository data and directory
information with the database server and LDAP server, copy information required for Portal
component operations to the DMZ only, and hide the master data in IDC.
3-36
Notes on USP Use
Notes on Web USP Use
1) Processing when "Network Error:503" Occurs
If "Network Error : 503" is displayed when a Web page was added as a private client, check that the
following are specified correctly:
• URL description
• [Bypass the proxy server for addresses beginning with] setting at Proxy server specification
If "Network error : 503" is generated even when the above processing is performed, the Web server
may have stopped.
2) Processing when "No response from service" Occurs
The message "No response from service. Processing interrupted by timeout." may be displayed in the
brick.
Check for the following probable causes:
Notes on Portal Component
• The server power of the connection destination server is down, etc.
• Some kind of problem occurred in the communication path up to the connection destination server
Notes on Web To Host USP(S2K USP) Use
1) Notes on Server2000 USP(S2K USP) Operation
The proxy logon function cannot be used in connection to Server2000 V1.1L40 and Server2000 1.1.
Also, the proxy logon function cannot be used when the Server2000 service name and screen name
contains Japanese language characters.
Notes when Applying Portal Component Independent Authentication to Operation Management
The password can be changed using the command. The previous password is not required. However,
the command must be called on the server where the Portal component operation control is operating,
and the Servlet must be stopped.
Modification Method
Start the command prompt on the server that runs Portal component.
(1) Stop the [PortalServer] WorkUnit.
(2) Move to "<Interstage install folder>\portalworks\bin\"
(3) Input "pwadminpasschg.bat {new password}". "{" and "}" are unnecessary.
Example: "pwadminpasschg.bat pwadmin_password"
3-37
Chapter 3: Notes on Interstage Operation
(4) Start the [PortalServer] WorkUnit.
(5) Start Portal component operation management and check the password change.
Modification Method
(1) Stop the [PortalServer] WorkUnit.
(2) Move to "/opt/FJSVispw/bin/"
(3) Input "pwadminpasschg.sh {new password}". "{" and "}" are unnecessary.
Example: "pwadminpasschg.sh pwadmin_password"
(4) Start the [PortalServer] WorkUnit.
(5) Start Porta component operation management and check the password change.
Notes on Using Operation Management Tool Commands
When each command of the operation management tool starts, a message that shows the start state
may be displayed. This message shows that the command is running normally. If command execution
generates an error, a report message is displayed. Check the error contents by means of this message.
Notes on Portal Component Repository Database Operation
The following precautions are necessary when starting and ending a database (Fujitsu Enabler or
Oracle) used as a Portal component repository.
(1) If the [PortalServer] WorkUnit was made automatic the starting service, Portal component start fails
depending on the start sequence with the database. In this case, restart the [PortalServer]
WorkUnit.
(2) If the database was stopped and restarted during Portal component operation, restart the
[PortalServer] WorkUnit.
About the Specification of Keep-alive between WebUSP and Back Server
If HTTP communication between WebUSP and back server (or proxy, load distribution device) does not
use keep-alive, add “-Dhttp.keepAlive=false” to the [JavaVM option] by the Interstage Management
Console.
Notes when Using a Long Character String for Alias
If the message shown below was output at the user's window, the system may enter the URL not
handled state because the alias character name is long. Check the alias or scenario name.
3-38
The page cannot be found
HTTP 400 - Bad Request
Notes on Portal Component
Notes on Using Administrative Console
• In the setting example of definition in the server that is displayed on the scenario registration
window or the USP addition window, Windows NT® server is used.
Example: file:/temp/scenario/scenario.jar
Make the actual settings in accordance with the syntax for the Solaris™ Operating Environment
system.
• If only a host name is specified to start the Administrative console, an error may occur when the
operation control function is used because of the DNS settings.
Example: http://hostA/portalworks/PWAdminSystem
In such cases, specify FQDN as shown in the following example. In addition, when the URL is
specified for adding USP, be sure to specify FQDN.
Example: http://hostA.domain.com/portalworks/PWAdminSystem
Setting the Heap Size in the Java Execution Environment
It is recommended to set the heap size in the Java execution environment to 256 MB or more.
The procedure for changing the heap size is as follows:
(1) Start the Interstage Management Console.
(2) Select [System], [WorkUnit], and then [PortalServer].
(3) Add the following options to [JavaVM option]:
-XX:NewSize=64m, -XX:MaxNewSize=64m, -Xms256m, -Xmx256m
(4) Restart [PortalServer] WorkUnit.
Select the [Operation] tab and restart [PortalServer].
Change the values for -XX:NewSize, -XX:MaxNewSize, -Xms, and -Xmx according to the environment
of the machine on which the Portal component is installed and the scope of using the Portal component.
-Xmsn
Specify the number of bytes for the initial size (n) of the memory allocation pool.
The value to be specified must be a multiple of 1024 that is greater than 2 megabytes.
To specify the value in kilobytes, suffix the value with character k or K.
To specify the value in megabytes, suffix the value with character m or M.
The default is 64 megabytes.
-Xmxn
Specify the number of bytes for the maximum size (n) of the memory allocation pool.
Specify the same value as the size specified for the -Xms option.
-XX:NewSize=64m, -XX:MaxNewSize=64m
When specifying 256 MB or more for the maximum size of the memory allocation pool, specify also
these three Java execution options.
3-39
Chapter 3: Notes on Interstage Operation
Notes on Framework
Security on the Internet
When using applications that use framework on the Internet, design them considering the security of
application development. Security may also be necessary depending on the firewall or other
infrastructure products.
Redistributable Files
The following files can be redistributed. These files can be distributed to the client environment and
used.
C:\Interstage\APC\redist\applet\ujiapplet.jar
C:\Interstage\APC\redist\ejb\ujiejbcl.jar
3-40
Index
access from PC to secure site
restrictions, 2-28
administrative console
notes, 3-39
alternative logon function
restrictions, 2-26
application development
required software, 1-2
application execution
required software, 1-7
Authority to Use the Web Server , 3-11
Brick Automatic Update Function
restrictions, 2-28
C and C++ programming
restrictions, 2-17
class names
notes, 3-22
client applications
required software, 1-12
Component Transaction Service
Interstage operation, 3-29
messages in Windows® 2000, 3-29
restrictions, 2-21
CORBA server application
using multi thread, 3-31
CORBA Service
IDL Compiler, 3-26
installation and environment settings, 3-24
Interstage operation, 3-24
Java environment, 3-26
restrictions, 2-13, 2-19
setting applications, 3-25
termination using isstop command, 3-29
cross-site scripting problem
notes, 3-2
Database Linkage Service
Interstage operation, 3-30
provided sample, 3-31
restrictions, 2-22
EJB application process, 3-22
EJB Customize Tool
notes, 3-16
EJB Service
class names, 3-22
Interstage JDBC Driver , 3-19
Java Development Kit/Java Runtime Environment,
3-16
notes, 3-16
operating with WorkUnits, 3-18
restrictions, 2-6
starting applications, 3-22
encryption communication by SSL, 3-23
error messages in Event Log, 3-32
Event Service
Interstage operation, 3-27
multi-IP address operation, 3-28
persistent channel applications, 3-28
reinitializing Interstage, 3-27
restrictions, 2-20
unit generation, 3-27
Framework
notes, 3-40
IDL compilation
restrictions, 2-17
IDL definitions
restrictions, 2-13
InfoDirectory
Index-1
Product Notes - Index
error messages, 3-32
Interstage operation, 3-32
restrictions, 2-23
setup items, 3-32
InfoDirectory Administration T ool
restrictions, 2-23
InfoProvider Pro
notes, 3-11
restrictions, 2-3
internet security, 3-40
Interstage HTTP Server
notes, 3-12
restrictions, 2-2
Interstage integration commands
abnormal command termination, 3-10
notes, 3-10
Interstage JDBC Driver , 3-19
Interstage operation
Component Transaction Service, 3-29
CORBA Service, 3-24
Database Linkage Service, 3-30
Event Service, 3-27
InfoDirectory, 3-32
monitoring during, 3-29
overview, 3-1
Interstage Operation Tool
notes, 3-9
J2EE
notes, 3-13
J2EE Deployment tool, 3-23
J2EE Management tool, 3-23
J2EE Service
restrictions, 2-4
Java Development Kit/Java Runtime Environment
versions, 3-16
Java language development
notes, 3-31
Java programming
restrictions, 2-18
JDK/JRE
notes, 3-33
restrictions, 2-24
JNDI
restrictions, 2-23
JSSE function
notes on use, 3-3
keep-alive specification
notes, 3-38
load distribution environment
restrictions, 2-27
locale of languages
restrictions, 2-22
long character string for alias
notes, 3-38
monitor screen colors
notes, 3-4
Naming Service
restrictions, 2-18
Netscape 4.6/4.7
restrictions, 2-27
Netscape 6
notes, 3-2
notes
abnormal command termination, 3-10
applying Portal Comonent independent
authentication to operation management, 3-37
class names, 3-22
common notes for Interstage, 3-2
Component Transaction Service, 3-29
CORBA server application operated using multi
thread, 3-31
CORBA Service, 3-24
cross-site scripting problem, 3-2
Database Linkage Service, 3-30
development using functions for Java language, 3-
31
EJB Customize Tool, 3-16
EJB Service, 3-16
Event Service, 3-27
Framework, 3-40
IDL Compiler, 3-26
InfoDirectory, 3-32
Index-2
Product Notes - Index
InfoProvider Pro, 3-11
installation and environment settings, 3-24
internet security, 3-40
Interstage HTTP Server, 3-12
Interstage integration commands, 3-10
Interstage Operation Tool, 3-9
J2EE, 3-13
Java environment, 3-26
JDK/JRE, 3-33
JSSE function, 3-3
keep-alive specification, 3-38
maximum no. of resources for transaction, 3-31
monitor screen colors, 3-4
multi-IP address operation, 3-28
Netscape 6, 3-2
operation management tool commands, 3-38
Oracle use, 3-30
OTS command execution, 3-30
persistent channel applications, 3-28
portal component, 3-35
Portal Component repository database operation,
3-38
redistributable files, 3-40
reinitializing Interstage, 3-27
Servlet Service, 3-15
setting applications, 3-25
setting port numbers for individual services, 3-5
SOAP Service, 3-23
stopping Interstage, 3-10
unit generation, 3-27
using administrative console, 3-39
using long character string for alias, 3-38
USP use, 3-37
operation management tool commands, 3-38
Oracle
notes, 3-30
OTS command execution
notes, 3-30
port number setting for individual services
notes, 3-5
portal component
notes, 3-35
Portal component
restrictions, 2-25
Portal Component
independent authentication, 3-37
Portal Component repository database operation,
3-38
redistributable files, 3-40
restrictions
access from PC to secure site, 2-28
alternative logon function, 2-26
Brick Automatic Update Function, 2-28
C and C++ programming, 2-17
Component Transaction Service, 2-21
CORBA Service, 2-13, 2-19
Database Linkage Service, 2-22
EJB Service, 2-6
Event Service, 2-20
IDL compilation, 2-17
IDL definitions, 2-13
InfoDirectory, 2-23
InfoDirectory Administration T ool, 2-23
InfoProvider Pro, 2-3
Interstage HTTP Server, 2-2
J2EE Service, 2-4
Java programming, 2-18
JDK/JRE, 2-24
JNDI, 2-23
load distribution environment, 2-27
locale of languages, 2-22
Naming Service, 2-18
Netscape 4.6/4.7, 2-27
other functions, 2-29
overview, 2-1
Portal component, 2-25
scripts in contents, 2-25
Servlet Service, 2-5
SOAP Service, 2-11
Web USP, 2-28
scripts in contents
restrictions, 2-25
Servlet Service
notes, 3-15
restrictions, 2-5
session recovery function, 3-23
Index-3
Product Notes - Index
session recovery function, 3-23
setting the heap size in the java execution
environment, 3-39
setup item related to maximum simultaneous no. of
clients connected, 3-32
SOAP Service
notes, 3-23
restrictions, 2-11
software
for application development, 1-2
for application execution, 1-7
for using client applications, 1-12
SQL Gateway, 3-11
starting and stopping services, 3-10
starting EJB applications, 3-22
stopping Interstage, 3-10
USP
notes on use, 3-37
Web USP
restrictions, 2-28
WorkUnits
operating with, 3-18
WWW Server
SQL gateway, 3-11
Index-4
Loading...
