Fujitsu FTP-607 Series, FTP-627MCL401, FTP-627MCL601 Specification Sheet

FTP-627MCL401/601

24v driveN, FTP-607 Series

2” HiGH SPeed THerMaL PriNTer

FTP-627MCL401/601

n Overview

The FTP-627 MCL Series are 24V driven high-speed printers

with a ultra low prole auto cutter and long life.

The FTP-627 MCL Series can be used for a variety of
applications, such as POS terminals, ticket vending machines,
label printers, banking terminals, and measurement and
medical equipment.

n HiGHLiGHTS

• Ultralowprole

Height 21.8 mm, width 81.2 mm, depth 42.2 mm

• Highspeedprinting

It can print at 100/150 mm/s (800 dotlines/s) maximum by

using Fujitsu's unique head drive control.

• AutoCutter

Long life and high reliable guilotine with dedicated motor.

• Easypapersetting

Our lever platen release mechanism allows a
wide paper route, so paper can be easily inserted.
Conventional auto loading is also available.

• Multifunctionaldie-castframe

Wide operating temperature range, long continuous
printing, high ESD absorbtion and discharge of static
electricity vibration and shock resistant.

• RoHScompliant

FTP-627MCL401/601

FTP-627DSL291R

FTP-627DSL601R

1

n ParT NuMberS

Part Number

Easy Load Model with low prole cutter FTP-627MCL401

FTP-627MCL601

LSI for driving MCL401 FTP-627CU301R

MCL601 FTP-627CU601R

Interface
board for
Mech/Cutter

Interface
cables

Power

cables

Cutter
supported

Parallel (Centronics) FTP-628Y202

Serial (RS232C) FTP-628Y302

USB FTP-629Y301

Logic FTP-629Y401

Head, motor FTP-629Y601

MCL401 FTP-627DSL291R Parallel (Centronics) /Serial (RS-232C)

MCL601 FTP-627DSL601R, Serial (RS-232C) / USB

MCL401 FTP-627DSL603R (USB)

FTP-627DSL605R Serial (RS-232C)

MCL601 FTP-627DSL613 R (USB)

FTP-627DSL615 R Serial (RS-232C)

FTP-627MCL401/601

n SPeCiFiCaTiONS

SpecicationsItem

Part number FTP-627MCL401/601

Printing method Thermal-line dot method

Dot structure 432 dots/line

Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density

Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch

Effective printing area 54 mm

Number of columns ANK 36 columns/line
(maximum 12/24 dot font)

Paper width 58 mm

Paper thickness 60 to 85 µm (some paper in this range may not be
used because of paper characteristics)

Printing Speed Maximum 100mm/sec. (800 dot line/sec.)
Maximum 150mm/sec. (1,200 dot line/sec.)

Alphanumeric, kana: 159 types

Character types

International characters: 195 types
JIS Kanji (Kanji CG loaded board): about 6800 types

MCL401

MCL601

12 × 24 dots, (1.5 × 3.0 mm), 36 columns: ANK

Character, dimensions (W×H), number
24 × 24 dots, (3.0 × 3.0 mm), 18 columns: ANK

of columns
8 × 16 dots, (1.0 × 2.0 mm), 54 columns: ANK

16 × 16 dots, (2.0 × 2.0 mm), 27 columns: ANK

2

FTP-627MCL401/601

n SPeCiFiCaTiONS

Item Specication

Iterface Conforms to RS232C/Centronics / USB

Power supply For print head MCL401 24 VDC average current, 0.5A (0.9 A peak)

(print ratio: 12.5%, print speed 100mm/sec.)

MCL601 24 VDC average current 1.0 A (1.9 A peak)

For motor MCL401 24 VDC ±5%, 1 A maximum

MCL601 24 VDC ±5%, 1.1 A maximum

For cutter MCL401 24 VDC ±5%, 1 A maximum

MCL601 24 VDC ±5%, 1.3 A maximum

For logic 3.3 to 5.25 VDC, 0.1 A maximum

Dimensions Mechanism with cutter 81.2 x 42.2 x 21.8 mm (WxDxH)

Interface
board

Weight Mechanism with cutter Approximately 100g

Interface board Approximately 50g

Life Head Pulse resistance: 50 million pulses/dot (print ratio: 25%).

Cutter MCL401 500,000 cuts

Platen 5,000 times (open/close)

Operating
environment

Detection
function

Operating temperature* 0ºC to +50ºC

Operating humidity 20 to 85% RH (no condensation)

Storage temperature -20ºC to +60ºC (paper not included)

Storage humidity 5 to 95% RH (no condensation)

Head temperature
detection

Paper out/mark
detection

Platen release Detected by sliding switch

Recommended thermal sensitive paper High sensitive paper TF50KS-E4 (Nippon paper)

*+5˚C to +40˚C printing density assurance rance.

DSL291 70 x 60 x 12 mm (WxDxH)

DSL6xx 95 x 70 x 21.6 mm (WxDxH)

MCL401 Abrasion resistance: paper traveling distance 50km

MCL601 Abrasion resistance: paper traveling distance 100km

MCL601 1,000,000 cuts

Detected by thermistor

Detected by photo-interruptor

Standard paper TF60KS-E (Nippon paper),

FTP-020PU001 (58mm)

PD150R (Oji paper)
FTP-020PU701 (58mm)

Medium life storage

paper

TF60KS-F1 (Nippon paper)

FTP-020P0102 (58mm)
PD170R (Oji paper)
P220VBB-1 (Mitsubishi paper)

Long life storage

paper

PD160R (Oji paper)
AFP-235 (Mitsubishi paper)
TP50KJ-R (Nippon paper)
HA220AA (Nippon paper)

3

FTP-627MCL401/601

7.5

5.4

10.7

28.3 (29.3MAX.)

13.9 (14.4 MAX.)

22.1

13.1

25

44

60

44

81.2

1.6

27.7

Ø1.4

11°

(50~200)

21.8

68.4

n FuNCTiON OF iNTerFaCe bOard

Item Item

1. Test print function 8. Cutter trouble detect

2. Paper out detection 9. Motor power saving function

3. Paper near end detection 10. Mark detection function

4. Paten open detection 11. MCU operation abnormality detection

5. Thermal head temperature abnormality
detection

6. Blow-out fuse detection 13. Motor over-current protection

7. Head voltage abnormality detection 14. Hardware timer

n diMeNSiONS

1.Printermechanism

FTP-627MCL401/601

12. Power ON/OFF sequence protection

Note: 1. Dimensions are nominal value (tolerance ±5 unless otherwise specied).

2. Platen unit (lever, platen, etc) moves by approximately 0.7mm toward paper insertion direction when platen is
open.

Unit: mm

4

M I

M I

M I

M I

oN

langiS O/I stnetnoC

1 KHP — )edohtaC(retpurretniotohP

2 NESV I rosnesrepaprofylppusrewopdnuorG

3 EHP O )rottimE(retpurretniotohP

4 HV I rewopevirddaeH

5 ID I tupniataD

6 2BTS I 2langiselbanetnirP

7 3BTS I 3langiselbanetnirP

8 DDV I rewoPcigoL

9 DNG — dnuorgdaeH

01 DNG — dnuorgdaeH

11 DNG — dnuorgdaeH

21 HT O rotsimrehT

31 1BTS I 1langiselbanetnirP

41 TAL I hctaLataD

51 KLC I kcolC

61 HV I rewopevirddaeH

71 HV I rewopevirddaeH

81 WS — hctiwsneponetalP

91 WS — hctiwsneponetalP

02 AT AlangiseticxerotoM

12 AT AlangiseticxerotoM

22 BT BlangiseticxerotoM

32 BT BlangiseticxerotoM

42 CN — detcennoctoN

FTP-627MCL401

1.Connector(FPC)specication(CN3/CN10)

(1) Connector
Mechanical unit side: FPC connector
Remote side (housing site): 52610-2471 (made by Molex)
(2) Pin assignment on the mechanical side

FTP-627MCL401/601

5

FTP-627MCL601

1.Connector(FPC)specication(CN4)

(1) Connector
Mechanical unit side: FPC connector
Remote side (housing site): 52610-3071 (made by Molex)
(2) Pin assignment on the mechanical side

No. Symbol Signal Name

1 PHK Cathode for photo interrupter

2 VSEN Paper sensor power

3 PHE Emitter for photo interrupter

4 VH Head drive power

5 VH Head drive power

6 VH Head drive power

7 DI Data in

8 STB2 Strobe 2

9 STB3 Strobe 3

10 Vdd Logic power

11 GND Head ground

12

13 GND Head ground

14

15 GND Head ground

16

17

18 NC NC

19 STB1 Strobe 1

20 LAT Data latch

21

22 VH Head drive power

23

24 VH Head drive power

25 SW Platen switch

26 SW Platen switch

27 MT A Excitation signal A

28 MT A Excitation signal A

29 MT B Excitation signal B

30 MT B Excitation signal B

GND Head ground

GND Head ground

GND Head ground

TM Thermistor

CLK Clock

VH Head drive power

FTP-627MCL401/601

6

Platen unit

M I

M I

M I

M I

.oN langiS O/I stnetnoC .oN langiS O/I stnetnoC

1 NESV I rewoprosnesrepaP 2 EHP O )rottime(rotpurretniotohP

3 KHP O )edohtac(rotpurretniotohP 4 AT AlangiseticxerotoM

5 AT AlangiseticxerotoM 6 BT BlangiseticxerotoM

7 BT BlangiseticxerotoM 8 CN — detcennoctoN

Motor

Connector No
(FPC pin numbers)

FTP-627MCL401/601

Sensor (Photo­interruptor)

Thermal head

FPC

Connect terminal:
surface side

24, 23, .....................2,1

2.Cutter(CN4/CN5)

Connector on control circuit side: 52610-0871 Molex or equivalent
