Fujitsu FTP-623MCL400, FTP-623DCL002 User Manual

BATTERY DRIVE, MICRO LINE THERMAL PRINTER 2” TYPE MECHANISM AND INTERFACE BOARD

FTP-623MCL400/FTP-623DCL002

■ OVERVIEW

This battery driven, micro line thermal printer provides high speed printing for 2-inch wide (58mm) paper. It is suitable for portable equipment that requires compact, light weight components.

In addition to the interface board, a driving LSI (MCU + Gate Array) is also available.

■ HIGHLIGHTS

• Driven by batteries (direct connect between thermal head and batteries)

It can be driven by a broad range of voltages (4.2 to 8.5 V) of NiCd or Nickel-Hydrogen by using Fujitsu Components' unique head drive control system. The battery pack can be connected directly to the print head without a voltage regulator. Also, a lithium-ion battery can be used.

• High speed printing

It can print at approximately 23 character lines/s (460 dotlines/s =

57.5 mm/s).

• Compact and lightweight

It has a light weight of approximately 75 g.

• Low power consumption

The peak current for head driving is approximately 3.0 A.

• Selectable paper paths

Front, rear, and top paper insertion paths can be used.

• Paper auto loading function

Paper feeding is enabled by operating the head up lever.

• Variety of suitable papers

This model is suitable for printing on a variety of papers, including 1-ply roll paper, 2-ply paper (TCC and roll), labels, and long-life paper.

FTP-623MCL400

FTP-623CU001, FTP-633GA101

FTP-623DCL002

■ DESIGNATION

FTP-623MCL400/FTP-623DCL002

Item

Printer mechanism Interface board

Micro Controller Unit

LSI

Gate Array

*: Rear paper insertion type is available: FTP-623MCL402

■ GENERAL SPECIFICATIONS

SpecificationsItem

Printing method Thermal-sensitive line dot method Dot structure 384 dots/line Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch Effective printing area 48 mm

Part number FTP-623MCL400 * FTP-623DCL002 FTP-623CU001

FTP-633GA101

(1) Single density Standard mode HS mode 1. to 3.

Printing mode Reduced mode HS mode 1. to 3.

(2) Double density mode Approximately 23 character lines/s (460 dotlines/s = 57.5 mm/s)

Maximum printing speed

Character types Semi-graphic : 36 International characters : 130

Character grade mode Standard character (12 × 6 dot font)/High grade character (16 × 8 dot font)

Character composition, dimensions (H×W), Number of columns (standard)

Interface 1) Centronics standard 2) Bus interface*

[1ply, 8 columns of “H”, double density, 7.2 V, 1/10” line returns] Approximately 16 character lines/s (416 dotlines/s = 52 mm/s) [1ply, 12 columns of “H”, double density, 7.2 V, 1/8” line returns]

JIS ANK : 128 ASCII : 31 Special : 30 Download : 8

Single density standard : 24 × 12 dots, (3.0 × 1.5 mm), 32 columns Single density reduced* Double density : 16 × 8 dots, (2.0 × 1.0 mm), 48 columns

32 × 16 dots, (4.0 × 2.0 mm), 24 columns

: 24 × 12 dots, (3.0 × 1.5 mm), 34 columns

32 × 16 dots, (4.0 × 2.0 mm), 26 columns

HQ mode HQ mode

(Continued)

FTP-623MCL400/FTP-623DCL002

SpecificationsItem

For print head

Operating voltage

Weight Mechanism: approximately 75 g. Interface board: approximately 60 g Printer mechanism Interface board Dimensions 108 (W) × 91 (D) × 18 (H) mm

Thermal head life

Environmental conditions

Detection Paper out/Mark detect By photointerrupter (command set)

For motor

For logic 5 VDC ± 5%, 0.15 A

Dimensions 73 (W) × 49 (D) × 20 (H) mm (excluding knob, lever, and flexible PC board)

Operating temperature +5 to +40°C* Operating humidity 20 to 85% RH (no condensation) Storage temperature –20 to +60°C (excluding paper) Storage humidity 5 to 95% RH (no condensation) Head temperature By thermistor

4.2 to 8.5 VDC (4 or 5 Ni-Cd or Ni-MH batteries, equivalent to 2 Li-ion) Approximately 3.0 A (peak value, 7.2 V, 100% printing ratio)

4.2 to 8.5 VDC (4 or 5 Ni-Cd or Ni-MH batteries, equivalent to 2 Li-ion) Average 0.7 A or less

Pulse durability : 1 × 108 pulse/dot (using Fujitsu Takamisawa's standard

driving method)

Wear resistance: 50 km (at 25% printing ratio)

Voltage By micro controller

Head-up By microswitch Paper width 58 mm Recommended thermal sensitive paper

+0 –1

1 ply (roll) : FTP-020PG021 Long life (roll) : FTP-020PR202 Label (roll) : FTP-040PL021 2 ply (TCC) : FTP-020P8820 2 ply (roll) : FTP-020P7121

*1: Character composition for single density reduced mode is the same as for single density standard mode. *2: The data to be printed is automatically read out by the printer driver equipment memory (host system frame

memory). The communication is parameter transfer.

*3: Temperature range for guaranteed printing density. It can be operated in the range of 0 to +40°C.

■ DIMENSIONS

Printer mechanism

FTP-623MCL400

6.1

FTP-623MCL400/FTP-623DCL002

62.5

12.5 34

3.9

(3)

30°

(14)

70°

(1): Head down (2): Paper feed (3): Head up lock

FTP-623MCL402

(2)

70°

(1)

(31)

34.5

21.5

ø12

(ø14)

(ø18)

6.1

Paper center

(photo interrupter)

58.2 (paper insertion)

62.5

12.5 34

10.5

Photo interrupter

3.9

16°

60°

Paper out angle

4°

13.7 1.0

2.3 1.7

3°

26°

Unit: mm

Front and top insertion type

(3)

30°

(14)

(1): Head down (2): Paper feed (3): Head up lock

(2)

70°

(1)

(31)

21.5

ø12

(ø14)

(ø18)

Paper center

(Photo interrupter)

58.2 (Paper insertion)

34.5

7.5

60°

Paper out angle

(Photo interrupter)

1.7

3.1

1.0

4°

13.7

Photo interrupter

Rear insertion type

Unit: mm
