Fujitsu FTP-622MCL001 User Manual

FTP-622MCL001/002/303/304

24V DRIVE, HIGH SPEED LINE
THERMAL PRINTER
2” MECHANISM, WITH OR WITHOUT CUTTER

FTP-622MCL001/002/303/304

■ OVERVIEW

FTP-622MCL/FTP-622DCL Series is an ultra high speed line
thermal printer driven by 24 VDC, printing on 2-inch wide paper
(58 mm/60 mm).

This printer is compact and light weight, and the design allows
easy head maintenance, easy head cleaning and easy head
replacement.

This printer is suitable for a variety of applications, such as POS
terminals, ticket machines, coupon machines, label printers,
medical instruments, etc. A printer with a specially designed cutter
is also available.

■ HIGHLIGHTS

• Ultra high speed printing

It can print at 80 mm/s (640 dotlines/s) maximum by using
Fujitsu Components' unique head drive control.

• Compact and lightweight

This printer has a low profile of only 20 mm, and a light weight
of approximately 81 g.

• Low power consumption

The peak current for head driving is approximately 2.3 A (at 80
mm/s printing speed, 50% printing ratio).

• Easy head access

It is designed for easy head cleaning and head replacement.

• Paper auto loading function

Thermal paper can be loaded without head-up lever operation.

• ESC/POS

The commands conform to ESC/POSTM.

• Auto Cutter

Printer with auto cutter (full cut/partial cut) is also available.

• UL Recognized

File No.E171434

*1 ESC/POSTM is a registered trademark of SEIKO EPSON Corp.

TM*1

Commands

FTP-622MCL001

FTP-622MCL303/304

FTP-622DCL001

1

■ DESIGNATION

Item

FTP-622MCL001/002/303/304

Part number

Printer mechanism

Printer mechanism with cutter

Interface board

LSI(MCU)

Cables

Standard

Centronics Standard
Serial (RS-232C)

Thermal head cable
Parallel (centronics) Interface cable
Serial (RS-232C) Interface cable
Power cable

FTP-622MCL001/002
FTP-622MCL303/304
FTP-622DCL001/011
FTP-622DSL001/011/012
FTP-622CU101
FTP-622Y001
FTP-622Y201
FTP-622Y301
FTP-622Y401

*4

*1: 001/303 is for front paper insertion (curl path) and 002/304 is for rear paper insertion (straight path).
*2: 001/011 supports ANK and 101 supports ANK+Kanji.
*3: 001/011 supports ANK and 112 supports ANK+Kanji.
*4: CU101 supports Kanji and cutter control.

■ GENERAL SPECIFICATIONS

SpecificationsItem

*1

*3

*2

*3

Part number FTP-622MCL001/002 FTP622MCL303/304
Printing method Thermal-sensitive line dot method
Dot structure 448 dots/line
Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density
Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch
Effective printing area 56 mm

Paper width

Paper thickness 60~100 µm*
Cutting tyoe --- 60-100mm full or partial
Number of columns 37 columns/line (24×12 dot font)
Maximum printing speed 640 dotlines/s (80 mm/s)

Character types

Character composition, dimensions (H×W),
Number of characters

MCL001/303 58 mm
MCL002/304 60 mm

1

Alphanumeric KANA: 159 International characters: 195
JIS KANJI (FTP-622DCL101/111): approximately 6800

24 × 12 dots, (3.0 × 1.5 mm), 37 columns
24 × 24 dots, (3.0 × 3.0 mm), 18 columns
16 × 8 dots, (2.0 × 1.0 mm), 56 columns
16 × 16 dots, (2.0 × 2.0 mm), 28 columns

(Continued)

2

FTP-622MCL001/002/303/304

(Continued)

SpecificationsItem
Part number FTP-622MCL001/002 FTP-622MCL303/304
Interface Centronics (ESC/POSTM), RS232C

24VDC ± 5%, Voltage

For head 0.87 (1.16) A (at 80 mm/s printing speed, 25% printing ratio)

Power supply

For motor 24VDC ± 5%, 1.0 A maximum
For cutter --- 24VDC ± 5%, 1.0 A maximum
For logic 5VDC ± 5%, 0.5 A maximum
Mechanism (cutter)

Dimensions

Weight approximately 81 g approximately 280 g

Expected life

Environmental
conditions

Interface board 131 (W) × 89 (D) × 24 (H) mm

Mechanism driving method)

Cutter --- 500,000 cuts
Operating temperature 0 to +50°C
Operating humidity 20 to 85% RH (no condensation)
Storage temperature –20 to +60°C (excluding paper)

Current : average

0.63 (1.16) A (at 50 mm/s printing speed, 25% printing ratio)

0.58 (0.58) A (at 30 mm/s printing speed, 25% printing ratio)

82(W) × 48(D) × 20(H)mm (excluding lever)

Pulse durability : 1 × 108 pulse/dot (using Fujitsu Takamisawa's standard
Wear resistance: 50 km (at 25% printing ratio)

2

*

( ): Peak

97(W) × 57(D) × 38(H)mm (w/cutter)

3

*

Storage humidity 5 to 95% RH (no condensation)
Head temperature By thermistor (applied energy control, abnormal temperature detection)

Detection Paper out/Mark detect By photointerrupter

Head-up By microswitch

Recommended thermal sensitive paper

For front insertion use (58 mm width) : FTP-020PU001,FTP-020P0701
For rear insertion use (60 mm width) : FTP-020P0020,FTP-020P0702
*Recommended papers

· Oji Paper : PD150R,PD160R,PD170R

· NIPPON Paper : TF50KS-E,TF60KS-E,TF60KJ-R

· MITSUBISHI Paper Mills : P220VBB-1,AFP-235

*1: There may be exceptions.
*2: 24VDC, minimum head resistance.
*3: Guarantee: +5°C ~+40°C.

3

■ DIMENSIONS

Mechanism

20.1

47.5

(250)

FTP-622MCL001/002/303/304

PAPER INSERTION (MCLOO1)

HEAD UP LEVER(AT HEAD DOWN)

CENTER OF PAPER

30.5

21.0

PAPER INSERTION

(MCLOO2)

2-POSITIONING HOLE

3-MOUNTING HOLE (M2)

HEAD CONNECTOR

58.4 (POSITIONING HOLE PITCH)

41.747.8

(89.5)

+

1

Unit: mm

4

■ DIMENSIONS

Mechanism

FTP-622MCL001/002/303/304

(cutter cable)

(sensor cable)

Interface board

88.9

78.7

3-2.0 or less

5.1

19.1

CN2*

CN1

87.6

130.8

120.7

116.8

CN5 CN3

(motor cable)

Unit: mm

Unit: mm

5.1

5.1

4-Ø3.6

CN8

39.4

5.1 5.1

5.1

*CN2 on FTP-622DSL only

43.2

CN10

86.4

105.4

120.7

39.4

CN13CN11

5.1

5.1

Unit: mm

5

FTP-622MCL001/002/303/304

■ CONNECTOR PIN ASSIGNMENT OF PRINTER MECHANISM

1. Thermal Head

Head side : B16B-PH-K-S-2.2 (J.S.T.) or equivalent
Board side : -PHR-16 (J.S.T.) or equivalent

.oNlangiStnemmoC

1HVdaehrofrewoP
2HVdaehrofrewoP
3DNGdnuorgdaeH
4DNGdnuorgdaeH
51BTS1langiselbanetnirP
62BTS2langiselbanetnirP
73BTS3langiselbanetnirP
8*HT
94BTS4langiselbanetnirP

1

noitcetederutarepmeT

01TALlangisgnihctalatadtnirP

115BTS5langiselbanetnirP
21DDVcigolrofrewoP
31KLCkcolcnoissimsnartataD
41NIDlangistuptuoatadtnirP
51DNGdnuorgdaeH
61HVdaehrofrewoP

*1: Symbol: " " means a negative logic signal

Thermal head heat sink

Motor

1, 2, 3, ......................................15, 16

Connector Pin No.

2. Motor connectors

Motor side : PHR-4 (J.S.T.) or equivalent
Board side : B4B-PH-K-S (J.S.T.) or equivalent

.oNlangiStnemmoC

Head up level

3. Sensor connectors

Sensor : PHR-5 (J.S.T.) or equivalent
Board side : B5B-PH-K-S (J.S.T.) or equivalent

.oNlangiStnemmoC

1B noitaticxeliocrotomgnippetS
2B noitaticxeliocrotomgnippetS
3A noitaticxeliocrotomgnippetS
4A noitaticxeliocrotomgnippetS

1NESVrosnesrepaprofrewoP
2EHProttimeretpurretniotohP
3KHPedohtacretpurretniotohP
41WS1hctiwstcetedpudaeH
52WS2hctiwstcetedpudaeH

6

FTP-622MCL001/002/303/304

4. Cutter

Mech side : EHR-4 (J.S.T.) or equivalent
Board side : B4B-EH (J.S.T.) or equivalent

oNroloCelbaCemaN

1etihW1noitisopemoH
2etihW2noitisopemoH
3deR+MlangisgnizigrenerotoM
4kcalB-MlangisgnizigrenerotoM

■ FUNCTIONS

metImetI
.1noitcnuftnirptseT.8noitcetedytilamronbarettuC
.2noitcetedtuorepaP.9noitcnufgnivasrewoprotoM
.3noitceteddneraenrepaP.01noitcnufnoitcetedkraM
.4noitcetedpudaeH.11noitcetedytilamronbanoitarepoUCM

.5

noitceted

ytilamronbaerutarepmetdaehlamrehT

.21noitcetorpecneuqesFFO/NOrewoP

.6noitcetedesuftuo-wolB.31noitcetorptnerruc-revorotoM
.7noitcetedytilamronbaegatlovdaeH.41remiterawdraH

■INTERFACE, COMMAND, OPTIONS

Please refer to the FTP-622DCL DATA SHEET and the FTP-622DSL DATA SHEET for Interface, Commands, and
Options.
